4 CHANNEL DVR
User Manual
SDE-3001/3003
4 Channel DVR
User Manual
Copyright
©2011 Samsung Techwin Co., Ltd. All rights reserved.
Trademark
is the registered logo of Samsung Techwin Co., Ltd.
The name of this product is the registered trademark of Samsung Techwin Co., Ltd.
Other trademarks mentioned in this manual are the registered trademark of their respective company.
Restriction
Samsung Techwin Co., Ltd shall reserve the copyright of this document. Under no circumstances, this document shall be reproduced, distributed or changed, partially or wholly, without formal authorization of Samsung Techwin.
Disclaimer
Samsung Techwin makes the best to verify the integrity and correctness of the contents in this document, but no formal guarantee shall be provided. Use of this document and the subsequent results shall be entirely on the user’s own responsibility. Samsung Techwin reserves the right to change the contents of this document without prior notice.
Warranty
If the product does not operate properly in normal conditions, please let us know. Samsung Techwin will resolve the problem for free of charge. The warranty period is 3 years. However, the followings are excluded:
•Data loss due to a damaged hard disk
•If the system behaves abnormally because you run a program irrelevant to the system operation.
•Data loss due to virus infection
•Deteriorated performance or natural worn-out in process of time
•Sensory phenomenon that does not affect the performance or quality of the product (ex: working noise).
Design and specifications are subject to change without prior notice.
The default password can be exposed to a hacking thread so it is recommended to change the password after installing the product.
Note that the security and other related issues caused by the unchanged password shall be responsible for the user.
overview
IMPORTANT SAFETY INSTRUCTIONS
Read these operating instructions carefully before using the unit.
Follow all the safety instructions listed below.
Keep these operating instructions handy for future reference.
1) |
Read these instructions. |
|
|
2) |
Keep these instructions. |
OVERVIEW |
|
3) |
Heed all warnings. |
|
|
|
|
||
4) |
Follow all instructions. |
|
|
5) |
Do not use this apparatus near water. |
|
|
6) |
Clean only with dry cloth. |
|
|
7) |
Do not block any ventilation openings, Install in accordance with the manufacturer’s instructions. |
|
|
8) |
Do not install near any heat sources such as radiators, heat registers, stoves, or other |
|
|
|
apparatus (including amplifiers) that produce heat. |
|
|
9) |
Do not defeat the safety purpose of the polarized or groundingtype plug. A polarized plug has |
|
|
|
two blades with one wider than the other. A grounding type plug has two blades and a third |
|
|
|
grounding prong. The wide blade or the third prong are provided for your safety. if the provided |
|
|
|
plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. |
|
|
10) |
Protect the power cord from being walked on or pinched particularly at plugs, convenience |
|
|
|
receptacles, and the point where they exit from the apparatus. |
|
|
11) |
Only use attachments/accessories specified by the manufacturer. |
|
|
12) |
Use only with the cart, stand, tripod, bracket, or table specified by the |
|
|
|
manufacturer, or sold with the apparatus. When a cart is used, use |
|
|
|
caution when moving the cart/apparatus combination to avoid injury from |
|
|
|
tip-over. |
|
|
13) |
Unplug this apparatus during lightning storms or when unused for long |
|
|
|
periods of time. |
|
|
14) |
Refer all servicing to qualified service personnel. Servicing is required when the apparatus has |
|
|
|
been damaged in any way, such as power-supply cord or plug is damaged, liquid has been |
|
|
|
spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or |
|
|
|
moisture, does not operate normally, or has been dropped. |
|
|
English _3
overview
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This symbol indicates that dangerous voltage consisting a risk of electric shock is present within this unit.
This exclamation point symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
WARNING
•To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.
•To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation instructions.
WARNING
1.Be sure to use only the standard adapter that is specified in the specification sheet. Using any other adapter could cause fire, electrical shock, or damage to the product.
2.Incorrectly connecting the power supply or replacing battery may cause explosion, fire, electric shock, or damage to the product.
3.Do not connect multiple cameras to a single adapter. Exceeding the capacity may cause abnormal heat generation or fire.
4.Securely plug the power cord into the power receptacle. Insecure connection may cause fire.
5.When installing the camera, fasten it securely and firmly. The fall of camera may cause personal injury.
6.Do not place conductive objects (e.g. screwdrivers, coins, metal parts, etc.) or containers filled with water on top of the camera. Doing so may cause personal injury due to fire, electric shock, or falling objects.
7.Do not install the unit in humid, dusty, or sooty locations. Doing so may cause fire or electric shock.
8.If any unusual smells or smoke come from the unit, stop using the product. In such case, immediately disconnect the power source and contact the service center. Continued use in such a condition may cause fire or electric shock.
9.If this product fails to operate normally, contact the nearest service center. Never disassemble or modify this product in any way. (SAMSUNG is not liable for problems caused by unauthorized modifications or attempted repair.)
10.When cleaning, do not spray water directly onto parts of the product. Doing so may cause fire or electric shock.
11.Do not expose the product to the direct airflow from an air conditioner.
Otherwise, it may cause moisture condensation inside the Clear Dome due to temperature difference between internal and external of the dome camera.
12.If you install this product in a low-temp area such as inside a cold store, you must seal up the wiring pipe with silicon, so that the external air can not flow inside the housing.
Otherwise, external high, humid air may flow inside the housing, pooling moisture or vapor inside the product due to a difference between internal and external temperature.
4_ overview
BEFORE START
This user manual provides Information for using the DVR such as brief introduction, part names, functions, connection to other equipment, menu setup, etc.
You have to keep in mind the following notices :
• SAMSUNG retains the copyright on this manual. |
|
|
|
||
• This manual cannot be copied without SAMSUNG’s prior written approval. |
|
|
|||
• We are not liable for any or all losses to the product incurred by your use of non-standard product or violation of |
|
|
|||
instructions mentioned in this manual. |
|
|
|
||
• Prior to opening the case, please consult a qualified technician first. Whenever this is needed power must be |
|
|
|||
removed from the unit. |
|
OVERVIEW |
|
||
• Before installing an additional HDD or connecting an external storage device (USB memory or USB HDD) to this |
|
||||
DVR, check the compatibility. Consult your provider for the compatibility list. |
|
||||
|
Warning |
|
|
||
|
|
|
|
||
|
Battery |
|
|
|
|
|
It is essential that when changing the battery in the unit, the replacement battery must be of the same type |
|
|
||
|
otherwise there may be a possibility of an explosion. |
|
|
||
|
The following are the specifications of the battery you are using now. |
|
|
||
|
• Normal voltage : 3V |
|
|
|
|
|
CALIFORNIA USA ONLY |
|
|
||
|
• |
Normal capacity : 170mAh |
|
|
|
|
|
This Perchlorate warning applies only to primary CR (Manganese Dioxide) |
|
|
|
|
• Continuous standard load : 0.2mA |
Lithium coin cells in the product sold or distributed ONLY in California USA. |
|
|
|
|
• Operating temperature : -20°C ~ +85°C |
“Perchlorate Material - special handling may apply, |
|
|
|
|
See www.dtsc.ca.gov/hazardouswaste/perchlorate.” |
|
|
||
|
|
(-4°F ~ +185°F) |
|
|
|
|
|
|
|
|
JConnect the power cord into a grounded outlet.
The Mains plug is used as a disconnect device and shall stay readily operable at any time.
Batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
System Shutdown
Turning off the power while the product is in operation, or undertaking improper actions may cause damage or malfunction to the hard drive or the product.
Please turn off the power using the Power button on the front of your DVR. After selecting <OK> in the pop-up menu, you can pull off the power cord.
You may want to install a UPS system for safe operation in order to prevent damage caused by an unexpected power stoppage. (Any questions concerning UPS, consult your UPS retailer.)
Operating Temperature
The guaranteed operating temperature range of this product is 0°C ~ 40°C (32°F ~ 104°F).
This product may not work properly if you run right after a long period of storage at a temperature below the guaranteed one.
Prior to using a device that has been stored for a long period in low temperatures, allow the product to stand at room temperature for a period.
Especially for the built-in HDD in the product, its guaranteed temperature range is 5°C ~ 55°C (41°F ~ 131°F). Likewise, the hard drive may not work at a temperature below the guaranteed one.
English _5
overview
CONTENTS
OVERVIEW |
3 |
Important Safety Instructions |
5 |
Before Start |
|
3 |
8 |
Features |
10 |
Part Names and Functions (Front) |
|
11 |
Part Names and Functions (Rear) |
|
|
12 |
Remote Control |
CONNECTING WITH |
13 |
Installation |
OTHER DEVICE |
13 |
Checking the installation environment |
13 |
14 |
Connecting the Video, Audio, and Monitor |
14 |
Connecting the USB |
|
15 |
Connecting the Camera |
|
18 |
Connecting the Alarm Input/Output |
|
|
19 |
Connecting the Network |
LIVE |
21 |
Getting Started |
23 |
Live Screen Configuration |
|
21 |
27 |
Live Mode |
29 |
Spot Out |
|
29 |
Zoom |
|
|
30 |
Audio ON/OFF |
|
30 |
Freeze |
|
30 |
Event Monitoring |
USING THE DVR |
32 |
System Setup |
42 |
Setting the Device |
|
32 |
48 |
Setting the Recording |
51 |
Setting the Event |
|
54 |
Backup |
|
|
55 |
Network Configuration |
6_ overview
SEARCH & PLAY |
62 |
Search |
62 |
65 |
Playback |
WEB VIEWER |
67 |
Introducing Web Viewer |
68 |
Connecting Web Viewer |
|
67 |
69 |
Using Live Viewer |
73 |
Using Search Viewer |
|
77 |
Viewer Setup |
|
|
87 |
About |
|
87 |
Mobile Viewer |
BACKUP VIEWER |
88 |
SEC Backup Viewer |
88
APPENDIX |
90 |
Product Specification (Camera) |
92 |
Product Specification |
|
90 |
94 |
Default Setting |
97 |
Troubleshooting |
|
|
99 |
Open Source License Report on the Product |
OVERVIEW
English _7
overview
FEATURES
The DVR employs H.264 video encoding for 4 channel inputs and audio encoding for 4 channels while simultaneously supports hard disc recording and playback.
These DVRs also supports network connectivity, providing remote monitoring from a remote PC transferring video and audio data.
•Provides a convenient User Interface
•4 CH Composite Input Connectors
•Supports CIF(S)/2CIF(M)/4CIF(L) recording formats
•With the network specific codec, network transfer enabled regardless of the recording conditions
•De-interlacing processor for better picture quality
•Display of HDD information and status by using HDD SMART
•Hard Disk overwrite function
•Mass storage hard disk backup through high-speed USB 2.0
•Simultaneous Record and Playback of 4 channel video data
•Various Search Modes (Search by Time, Event, Backup and Motion Detection)
•Various Recording Modes (Time Lapse, Event, Scheduled Recording)
•Alarm Interface
•Remote Monitoring function by Network Viewer, Smart Viewer and Mobile Viewer
8_ overview
Standards Approvals
MThis equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
Package Contents
Please unwrap the product, and place the product on a flat place or in the place to be installed. Please check the following contents are included in addition to the main unit.
DIGITAL VIDEO RECORDER
DVR |
Adapter / Power Cable |
Mouse |
Remote Control / Battery (AAA x 2) |
SEB-1005R (4EA) |
SEB-1007R (4EA) |
|
Model : SDE-3003 |
Model : SDE-3001 |
||
|
SEB-1005R (Bracket 4EA, Screws 12EA) |
SEB-1007R (Bracket 4EA, Screws 12EA) |
Camera Cables(4EA), 18.3m (60ft) / |
||
Model : SDE-3003 |
Model : SDE-3001 |
Network Cables |
||
|
|
|
|
|
Network Viewer Software |
User Manual CD, |
Quick Guide |
|
Quick Connect Program CD |
|||
|
|
OVERVIEW
English _9
overview
PART NAMES AND FUNCTIONS (FRONT)
DIGITAL VIDEO RECORDER
POWER REC
b c
|
Part Names |
Functions |
|
|
USB Port |
Connects the USB devices. |
|
b |
Remote Control |
Input the remote control signal. |
|
Receiver |
|||
c |
LED Indicator |
Power LED : Displays the power ON/OFF status. |
|
REC : Lights on when recording is in progress. |
|||
|
|
10_ overview
PART NAMES AND FUNCTIONS (REAR)
|
|
b |
c |
|
|
|
|
1 |
2 |
|
AUDIO IN |
|
|
|
NETWORK |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
DC 12V |
|
|
|
|
ALARM IN |
ALARM OUT |
|
|
|
|
|
|
1 2 3 |
4 |
G 1 COM G |
CONSOLE |
|
|
|
|
|
|
|
|
3 |
4 |
VIDEO OUT |
AUDIO OUT |
VGA |
|
|
USB |
|
|
|
|||||
|
|
|
|
|
|
|
|
Part Names |
|
|
|
|
Functions |
|
|
CAMERA IN |
|
Video Signal input ports (UTP type connector). |
|
||||
b VIDEO OUT |
|
Video Signal Output Port (RCA jack). |
|
|
|
||
c AUDIO IN |
|
Audio input signal port (RCA jack, CH1). |
|
|
|
||
|
For SEB-1006R (MIC integrated camera), it is also recommended not to connect other |
||||||
NETWORK |
|
input devices to the AUDIO IN port. |
|
|
|
||
|
NETWORK connector port. |
|
|
|
|||
DC 12V |
|
Camera and DVR power input port. |
|
|
|
||
USB |
|
USB connector port. |
|
|
|
|
|
ALARM IN |
|
1~4, G : Alarm Input port. |
|
|
|
||
ALARM OUT |
|
1, COM : Alarm Output port. |
|
|
|
||
VGA |
|
VGA Video Signal Output Port. |
|
|
|
||
AUDIO OUT |
|
Audio Signal Output Port (RCA jack). |
|
|
|
MIf using the VGA cable, the source from VGA will be displayed as main image on the screen along with the OSD menus. Then, the BNC port will output the video signal alone.
If not using the VGA cable, the source from BNC will be displayed as main image on the screen along with the OSD menus. If you connect the VGA cable after the system boot, only the video signal from VGA will be displayed.
OVERVIEW
English _11
overview
REMOTE CONTROL
SEARCH
Displays the search menu.
MODE
Changes the screen mode.
POWER
Displays the Exit pop up screen.
NUMBER [0~+10]
Used as the numeric input keys, or displays a single channel.
Skip Backward (by unit time),
Slow Rewind, Slow Forward,
Skip Forward (by unit time)
T/W
Zooms in or out.
MENU
Goes to the system menu screen.
Up/Down/Left/Right(▲▼◄ ►)/ENTER
Moves the cursor up/down/left/right, and runs the Select Menu.
FREEZE
Freezes the screen temporarily.
ZOOM
Runs the digital zoom (x2) function.
REC
Starts or ends the live recording.
BACKUP
Displays the Backup Menu.
DVR
Activates the DVR function.
ID
Sets the ID of the system.
Select 2 digits from 0 ~ 9 while pressing the ID Key.
Move Frame
While paused, moves to the previous/next frame.
FR, STOP, PLAY/PAUSE, FF
SCROLL ,.
Moves the menu scroll.
RETURN
Returns to the previous screen.
AUDIO
Turns Audio on/off.
ALARM
Cancels the Alarm.
REC LOCK
Selects the recording lock function.
PIP
Selects or deselects the PIP function.
EP10-000522
Using the Numeric buttons
1.Press any button among 1 to 4.
2.Move to the selected channel number.
Changing the Remote Control ID
1.Press the ID button of the remote control and check the ID displayed on the DVR screen. The factory default ID of the remote control is 00.
2.Enter 2 digits of your selection in order, while pressing the system [ID] button.
3.When ID input is done, press the system [ID] button again to check the setting.
MIf you want to change the remote control ID to 08: Press 0 and 8 in order while the system [ID] button is pressed. Remote control's ID and DVR’s ID should be matched for proper operation. Refer to “Remote Devices”. (Page 45)
12_ overview
connecting with other device
INSTALLATION
Please take note of the followings before using this product.
•Do not use the product outdoor.
•Do not spill water or liquid in the connection part of the product.
•Do not impose the system to excessive shock or force.
•Do not pull out the power plug forcefully.
•Do not disassemble the product on your own.
•Do not exceed the rated input/output range.
•Use a certified power cord only.
•For the product with an input ground, use a grounded power plug.
CHECKING THE INSTALLATION ENVIRONMENT
Samsung Digital Video Recorder (“DVR” hereinafter) is a state-of-art security device, and contains mass storage hard disk(s) and critical circuits inside.
When the temperature rises inside the product, the product may breakdown and the product life be shortened.
Temperature |
One Year: 24HR X 365 DAY =8,760 HR |
Unit: ºC |
|
Life (Unit: HOURS)
DEVICE OTHER WITH CONNECTING
English _13
connecting with other device
CONNECTING THE VIDEO, AUDIO, AND MONITOR
1 |
2 |
|
AUDIO IN |
|
NETWORK |
|
|
|
|
|
|
|
|
|
|
|
DC 12V |
|
|
|
|
ALARM IN |
ALARM OUT |
|
|
|
|
1 2 3 4 G |
1 COM G |
|
|
|
|
|
CONSOLE |
3 |
4 |
VIDEO OUT |
AUDIO OUT |
VGA |
USB |
|
M Only one mouse port is available.
CONNECTING THE USB
1.By factory default, a USB port is provided for external connection.
2.You can connect a USB HDD, USB memory or mouse to the USB port.
3.If a USB HDD is connected to the system, recognition and settings are available in “Menu > Setting the Device >
Storage Device”. (Page 43)
4.This product supports hot-plugging, which connects/removes the USB device during the system operation.
J If you use the USB device for Backup purposes, format it with FAT32 on PC if it is not formatted on the DVR.
14_ connecting with other device
CONNECTING THE CAMERA
Equipped with the IR LED and the illumination sensor, enables you to monitor at night as well as in daytime. The camera is suitable for both internal and external use.
|
|
|||
|
SEB-1005R |
SEB-1007R |
|
|
|
|
b
c
|
Name |
Description |
|
Camera Fitting |
Groove that is used to fit the camera bracket. |
|
Groove |
There are two grooves; one on the top and one on the bottom. |
b IR LED |
These infrared LED's are controlled by the illumination sensor. |
|
c Lens |
Focal length of 3.6mm enables you to cover relatively longer range of monitoring. |
Illumination Sensor Detects incoming light to control the IR LED.
DVR Connection Connect the cable directly to the DVR without using a particular power cable. Cable You can use the RJ-45 cable to connect to a remote camera.
RJ-45 Cable (Length: 18.3m, 60ft)
This cable is specific to UTP connection, which is not compliant with the LAN cable. You can use the UTP direct cable (all of 8 pins are used) to extend the length to a max of 200m. (based on UTP CAT 5e)
|
|
|
|
|
|
|
|
|
|
|
|
|
|
1. CVBS+ |
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
2. CVBS- |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
3. AUDIO |
|
|
|||
CVBS+ |
|
|
|
|
|
|
|
|
|
|
|
|
12V |
4. GND |
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
5. 12V |
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
6. N.C |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
CVBS |
- |
|
|
|
|
|
|
|
GND |
7. N.C |
|
|
|
|||||
|
N.C |
|
|
|
|
|
GND(AUDIO) |
8. N.C |
|
|
|
||||||||
|
|
|
|||||||||||||||||
|
GND |
|
|
|
|
|
12V |
<Cable pin information |
|
provided> |
|||||||||
|
|
|
|
|
|
||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
DEVICE OTHER WITH CONNECTING
English _15
connecting with other device
Installing the camera
The camera can be installed on the wall, ceiling, shelf or a desired position using the provided bracket.
1.Select a position where you want to install the camera.
Make sure the selected position can sustain the weight of the camera.
2.Use the screw bolts (M4 X L15) to mount the camera bracket onto the wall or ceiling.
3.Place the camera on the selected position and fit the hole either on the top or the bottom of the camera into the fixing bolt of the bracket, and turn the camera clockwise.
JYou should be careful when installing the BOX camera outdoors because the cable connectors may be wet with moisture or pile up with impurities.
M4 X L15 sized screws
wall or ceiling
SEB-1005R
M4 X L15 sized screws
wall or ceiling
SEB-1007R
Camera Bracket
The camera bracket can be used to install the camera on the wall, ceiling or shelf.
Camera Bracket Specification
|
SEB-1005R |
SEB-1007R |
|
|
|
|
|
Name |
|
Description |
|
SEB-1005R |
|
SEB-1007R |
|
|
|
||
Use |
Indoor |
|
|
Installation |
Wall or Ceiling |
|
|
Dimensions |
57(W) X 47.2(H) X 100.5(L) mm/ |
|
40(W) X 58(H) X 40(D) mm/ |
2.25(W) X 1.86(H) X 3.95(L) inch |
|
1.57(W) X 2.28(H) X 1.57(D) inch |
|
Weight |
130g(0.29 lbs) |
|
55g (0.12 lbs) |
Operating Temperature |
-10˚C ~ 50˚C (14˚F ~ 122˚F) |
|
|
Accessories |
SCREW (M4 X L15) : 3 pcs |
|
|
16_ connecting with other device
Adjusting the Camera Bracket
1. Choose an installation site that can sufficiently support the weight of the equipments to be installed.
2. Attach the camera bracket to the wall using the supplied screws (M4 X L15). 4x15 sized screws wall or ceiling.
3. Adjust the camera to target the video location and tighten the camera bracket handle on the camera bracket. Install the camera on to the male screw of the camera bracket by rotating the camera clockwise.
4. |
Loosen the handle by turning it counter clockwise |
|
|
|
|
and then adjust the camera position. Tighten the |
|
|
|
|
handle, turning it clockwise to lock the camera in |
|
|
|
5. |
position. |
Handle |
Handle |
|
Connect the camera cable to the camera. |
||||
|
DEVICE OTHER WITH CONNECTING
English _17
connecting with other device
CONNECTING THE ALARM INPUT/OUTPUT
Connecting the alarm input signal
Connection port for the alarm input signal.
Connect one strand of the sensor signal line (four strands) to the alarm input port and connect the other to the [G] port.
Connecting the alarm output signal
Connection port for the alarm output signal.
Connect one strand of the sensor signal line to the alarm output port and connect the other to the [COM] port.
•ALARM IN : 5mA sink
•ALARM OUT : 24V DC 1A, 125VAC/0.5A
CONSOLE
USB
VGA
|
|
ALARM IN |
|
|
ALARM OUT |
|||||||
1 |
|
2 |
ALARM IN |
|
ALARM OUT |
|||||||
1 |
2 |
3 |
3 |
4 |
|
G |
|
1 COM G |
||||
|
|
|
4 |
|
G |
|
G 1 COM |
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
18_ connecting with other device
CONNECTING THE NETWORK
Connecting to Network through Ethernet (10/100BaseT)
1 |
2 |
AUDIO IN |
NETWORK
DC 12V
|
|
|
|
ALARM IN |
ALARM OUT |
|
|
|
|
1 2 3 4 G |
1 COM G |
|
|
|
|
|
CONSOLE |
3 |
4 |
VIDEO OUT |
AUDIO OUT |
VGA |
USB |
|
RJ-45 Ethernet Cable
(Direct Cable)
NETWORK
Back Bone |
Hub/Switcher |
Hub/Switcher |
Windows |
Network Viewer |
Connecting to the Network using the router
1 |
2 |
|
AUDIO IN |
|
|
|
NETWORK |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
DC 12V |
|
|
|
|
1 |
ALARM IN |
G |
ALARM OUT |
|
|
|
|
2 3 4 |
1 COM G |
||
|
|
|
|
|
|
|
CONSOLE |
3 |
4 |
VIDEO OUT |
AUDIO OUT |
VGA |
|
|
USB |
|
|
|
|
|
NETWORK |
Broadband Router |
xDSL or Cable |
xDSL or Cable |
Modem |
Modem |
External Remote PC
DDNS Server
(Data Center)
DEVICE OTHER WITH CONNECTING
English _19
connecting with other device
Connecting to Internet through ADSL
1 |
2 |
|
AUDIO IN |
|
NETWORK |
|
|
|
|
|
|
|
|
|
|
ALARM IN |
ALARM OUT |
|
|
|
|
1 2 3 4 |
G 1 COM G |
|
|
|
|
|
CONSOLE |
3 |
4 |
VIDEO OUT |
AUDIO OUT |
VGA |
USB |
|
|
|
|
|
DC 12V |
|
RJ-45 Ethernet Cable |
|
INTERNET |
(Direct Cable) |
|
ADSL MODEM |
||
Phone(ADSL) Line |
||
Hub/Switcher |
Windows |
|
Network Viewer |
20_ connecting with other device
live
GETTING STARTED
Starting the system
1. Connect the power cable of the DVR to the wall outlet.
MIt takes about 10 seconds to display the start screen after booting.
2. You will see the initialization screen. |
|
|
|
|
|
The initialization process will last about 1 minute. |
|
|
|
|
|
If a new HDD is installed, the initialization process may take |
|
|
|
REC |
|
|
|
|
|
|
|
longer. |
|
|
|
|
|
3. The live screen appears with a beep.
2011-01-01 01:10:25
2011-01-01 01:10:25
Shutting Down the System
You can shut down the system only if you have logged into the DVR.
You require permission to shut down the system if you are not logged in as admin.
1. |
Press the [POWER] button on the remote control or |
2011-01-01 01:10:25 |
|
right-click to display the context sensitive menu and select |
|
2. |
<Shutdown>. |
|
The “Shutdown” confirmation window appears. |
Shutdown |
|
3. |
Use the arrow keys on the remote control to move to |
Are you sure to shutdown? |
OK Cancel |
||
|
<OK> and press the [ENTER] button or click <OK>. |
|
4. |
The system will shut down. |
|
Disconnecting the power cable for power off and |
|
|
|
reconnecting the power cable to restart. |
|
M For the permission management, refer to “Permission Management > Setting Permissions”. (Page 37)
LIVE
English _21
live
Login
To access a DVR or restricted menu, you should have logged in to the DVR.
1. In live mode, right-click any area of the screen. |
Scene Mode |
You will see the context sensitive menu as in the right |
2011-01-01 01:10:25Spot Out |
Audio Off |
|
figure. |
Freeze |
|
|
|
Stop Alarm |
|
Record |
|
Play |
|
Search |
|
Backup |
|
Main Menu |
|
Shutdown |
|
Hide Launcher |
|
Login |
2.Click <Login>.
The login dialog appears.
You can also see the login dialog to access a desired menu by pressing the [MENU] button on the remote control.
The login dialog will also appear if you press a menu button on the remote control of the DVR when the corresponding menu requires logging in.
After logged in, press [RETURN] on the remote control to display the logout dialog.
By default, initial ID and password are set to “admin”, and “4321”.
2011-01-01 01:10:25
Login
ID |
admin |
Password
OK Cancel
JThe default password can be exposed to a hacking thread so it is recommended to change the password after installing the product.
Note that the security and other related issues caused by the unchanged password shall be responsible for the user.
M For the restricted permission, refer to “Permission Management > Setting Permissions”. (Page 37)
Locking All Buttons
This will restrict access to all buttons available in the DVR.
1.In Live mode, press buttons in the order of [STOP (@)] [FREEZE][STOP (@)][FREEZE][MENU].
All buttons will be locked.
2.In the lock condition, press any button to display a dialog where you are prompted to enter the password for unlocking the buttons.
The button lock will be released if you enter the admin password.
2011-01-01 01:10:25
Key Lock Password
ID |
admin |
Password
OK Cancel
22_ live
LIVE SCREEN CONFIGURATION
Icons on the Live Screen
You can check the status or operation of the DVR with the icons on the live screen.
2011-01-01 |
00:00:01 |
LIVE
CAM 01
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Name |
Description |
||||||||||
|
Current Date, Time |
Displays the current time and date. |
|||||||||||
b |
Login Information |
When you are logged in, the “LOG ON” icon will be displayed. |
|||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
Displayed if the zoom function is activated. |
|
|
|
|
|
|
|
|
|
|
|
|
|
Displayed if you press the Pause button. |
c |
Screen Mode |
|
|
|
|
|
|
|
|
Displayed in Auto Sequence mode where all channels are switched at the |
|||
|
|
|
|
|
|
|
|
specific time interval. |
|||||
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
This icon is displayed if a user with restricted access to the Record button tries |
|
|
|
|
|
|
|
|
|
|
|
|
|
to make manual recording. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Only the user with the applicable permission can release (stop) the recording. |
|
|
|
|
|
|
|
|
|
|
|
|
|
Displayed if the HDD is full and the DVR has an insufficient space to record. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
System Operation |
|
|
|
|
|
|
|
|
Displayed if no HDD is installed or the existing HDD should be replaced. |
|||
|
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
Displayed if the HDD needs a technical examination. |
||||
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
This will be displayed if the backup operation is in process. |
|
|
|
|
|
|
|
|
|
|
|
|
|
Displayed if a new firmware is found from the network. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Video Input Status |
|
|
|
|
|
|
|
|
Displayed if no input is entered in the condition that the camera is set to <ON>. |
|||
|
|
|
|
|
|
|
|
Nothing will be displayed on the screen if the camera is set to <OFF>. |
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Camera Name/ Channel |
Displays the camera name and the changed channel, if any. |
|||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
Displays the resolution of the recording screen. (Page 49) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Displays AUDIO ON/MUTE. |
|
|
|
|
|
|
|
|
|
|
|
|
|
Not displayed in video mode if deactivated. |
|
Camera Operation |
|
|
|
|
|
|
|
|
If the sensor is set to <ON>, the input signal will be displayed on the screen of |
|||
|
|
|
|
|
|
|
|
|
the connected channel. |
||||
|
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
Displayed if a motion detected in the condition that the motion detection is set to |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
<ON>. |
|
|
|
|
|
|
|
|
|
|
|
|
|
Displays the current record mode from Record/Event/Schedule. |
English _23
live
Error Information
•If the internal HDD is not connected, the “NO HDD”( ) message will appear; if there occurs a problem,
you will see the “HDD FAIL”( ) message in the top left corner. In this case, make sure you contact the service center for assistance as this may cause a failure of recording, playback or backup.
M If you see the No HDD, HDD FAIL icons on the screen, contact the service center for more details.
Live Screen Menu
In addition to the buttons the remote control, you can access a desired menu by right-clicking the mouse any area in live mode.
The context sensitive menu that appears by right-clicking the screen may differ, depending on the login/ logout, screen split mode and DVD operation mode.
M Menu items of Search, Record, Backup, Shutdown can be deactivated, depending on the user permission.
Scene Mode |
|
Scene Mode |
|
2011-01-01 01:10:25Spot Out |
|
||
|
2011-01-01 01:10:25 |
|
|
Audio Off |
|
Spot Out |
|
|
Zoom In |
|
|
|
|
|
|
Freeze |
|
Audio |
|
|
|
|
|
Stop Alarm |
|
Freeze |
|
Record |
|
Stop Alarm |
|
Play |
|
Record |
|
Search |
|
Play |
|
Backup |
|
Search |
|
Main Menu |
|
Backup |
|
Shutdown |
|
Main Menu |
|
Hide Launcher |
Shutdown |
|
|
Logout |
|
Hide Launcher |
|
|
Logout |
|
|
|
|
|
< Split Mode Menu > < Single Mode Menu >
Split Mode Menu
The context sensitive menu in split mode differs, depending on the login/logout status.
1 |
Scene Mode |
2011-01-01 01:10:25 |
|
Spot Out |
|
||
2 |
Audio Off |
|
|
3 |
Freeze |
|
|
4 |
Stop Alarm |
|
|
5 |
Record |
|
|
6 |
Play |
|
|
7 |
Search |
|
|
8 |
Backup |
|
|
9 |
Main Menu |
|
|
10 |
Shutdown |
|
|
11 |
Hide Launcher |
|
|
12 |
Logout |
|
|
13 |
|
|
|
24_ live
Menu |
Description |
Scene Mode |
Refer to “Live Mode”. (Page 27) |
b Spot Out |
Refer to “Spot Out”. (Page 29) |
c Audio On/Off |
Refer to “Audio ON/OFF”. (Page 30) |
Freeze |
Refer to “Freeze”. (Page 30) |
Stop Alarm |
Stops the alarm output and the event monitoring. Refer to “Event Monitoring”. (Page 30) |
Record/Stop |
Starts/stops the standard recording. |
Play |
Refer to “Search & Play > Play”. (Page 65) |
Search |
Refer to “Search & Play > Search”. (Page 62) |
Backup |
Refer to “Using the DVR > Setting the Backup”. (Page 54) |
Main Menu |
Accesses the main menu. Refer to the Using the DVR section. (Page 32) |
Shutdown |
Turns down the DVR. |
Show/Hide Launcher Shows or hides the launcher. Refer to “View the Launcher Menu”. (Page 26)
m Login/Logout |
You can log in or out. |
Single Mode Menu
The single mode menu is available only in Single Mode.
The context sensitive menu for the One Channel mode, in Split mode is different from that of the Single mode.
1 |
Full Screen |
2011-01-01 01:10:25 |
|
||
Spot Out |
|
|
2 |
Zoom In |
|
Audio |
|
|
|
Freeze |
|
|
Stop Alarm |
|
|
Record |
|
|
Play |
|
|
Shutdown |
|
|
Hide Launcher |
|
|
Logout |
|
Menu |
|
Description |
|
Full Screen |
Select and click a desired channel in Split mode to switch to the full screen of the selected |
channel. |
||
b |
Zoom In |
Enlarges the selected image. (Page 29) |
LIVE
English _25
live
View the Launcher Menu
The Launcher menu appears on the bottom of the live screen.
1.In Live mode, right-click to display the context menu and select <Show Launcher>.
2.Move the cursor to the bottom and click a desired item in the Launcher menu.
MIf no input is entered for 10 seconds, the menu will disappear.
The Launcher menu can be accessed only by using the mouse.
2011-01-01 01:10:25
2011-01-01 |
Alarm Freeze |
01:10:25 |
|
2011-01-01 01:10:25
2011-01-01 01:10:25
Menu |
Description |
Date/Time |
Displays the current time and date. |
The indication of AM/PM is displayed if you set 12 hours for the time format in |
|
|
“System > Date/Time/Language > Time”. (Page 32) |
b Screen Mode |
Press this button to switch the screen mode in sequence. |
cMenu Expansion Button Click to display the hidden menu to the right.
Audio |
Turns ON/MUTE the sound of the selected channel. |
Zoom |
Enlarges the selected area. This is available only in Single Live mode. |
Alarm |
Stops the alarm if it's activated. |
Freeze |
Freezes the Live screen temporarily. |
Play |
Enters Play mode if a file to play exist, and if not, enters Search mode. |
Record |
Start/End recording the Live screen. |
26_ live
LIVE MODE
Displays 4 live video images in 3 different modes.
Switching the screen mode
To switch the split mode, select a screen mode in the launcher menu, or right-click to select a screen mode in the context menu.
Press the [MODE] button on the remote control to switch the mode in the sequence of the launcher menu items.
CH1 |
|
CH2 |
|
|
|
|
|
|
|
||
|
|
|
|
|
|
CH3 |
|
CH4 |
CH1 |
CH2 |
CH1 |
|
4-split |
mode |
PIP |
|
Auto Sequence |
Switching the screen automatically
With SDE-3001/3003 you can display 4 live single screens in sequence.
LIVE
CH1 |
4 |
CH1 |
|
CH1 |
|
CH1 |
|
Single mode |
1 |
MIn Single mode, If you have set <SEQ-Dwell Time> in “Setting the Device > Camera”, Auto Sequence will be conducted at the set interval. (Page 42)
English _27
live
Channel Setting
You can display the channel in a desired area of a split screen.
1.Click a camera name to display a channel list where you can select a different channel.
2.Select a desired channel and click it.
The current channel will be switched to the selected one.
Use the cursor to select a channel to move, and drag and drop it to a desired channel; this can also change the channel position.
Ex : if switching CH 1 to CH 4
CH1 |
CH2 |
|
CH4 |
CH2 |
|
|
|
CH3 |
CH1 |
CH3 |
CH4 |
|
||
|
|
|
|
|
Switching to Single Mode
When in split mode, select and double-click a desired channel to switch to its Single mode.
Press the number corresponding to a desired channel the remote control to switch to its Single mode. Refer to “Remote Control > Using the numeric buttons”. (Page 12)
Ex : If double-clicking CH 3 or pressing the number “3” on the remote control.
CH1 |
CH2 |
|
|
||
CH3 |
CH4 |
CH3 |
28_ live
SPOT OUT
The Spot Out monitoring is independent of the Live mode, which monitors a specific channel through the Spot Out port.
Selecting a Spot Out mode
If an event occurs such as sensor, motion or alarm from the Spot Out port in connection with a monitor, you can select a output screen mode.
1.In Live mode, right-click any area on the screen. The Live menu appears.
2.Click Spot Out.
Supports the Spot output in Single screen with Auto Sequence mode.
The Spot output is supported only for a designated channel. For the Spot Out port of a model, refer to “Part Names and
Functions (Rear)”. (Page 11)
Scene Mode |
|
2011Auto Sequence-01-01 01:10:25 |
Spot Out |
|
|
Audio Off |
|
CH1 |
Freeze |
|
CH2 |
Stop Alarm |
|
CH3 |
Record |
|
CH4 |
|
|
|
Play |
|
|
Search |
|
|
Backup |
|
|
Main Menu |
|
|
Shutdown |
|
|
Hide Launcher |
|
|
Logout |
|
|
< Multichannel Live Menu >
ZOOM
This is available only in Single Live mode. In Single mode, select a desired area and use the Zoom function to enlarge it twice.
1.Select <Zoom In> in the right-click menu.
Press the [ZOOM] button on the remote control, or simply click < > in the launcher menu. The zoom box appears.
2.Use the direction keys, or drag and drop to specify an area to enlarge.
3.Press the [ENTER] button, or double-click the selected area to enlarge it twice.
In the enlarged image, use the direction buttons (◄ ►) on the remote controlto move the enlarged area.
4.Press the [ZOOM] button on the remote control, or simply click < > in the launcher menu to release the zoom.
2011-01-01 01:10:25
LIVE
English _29
live
AUDIO ON/OFF
You can turn the sound on/off corresponding to the channel in Live mode.
AUDIO ON/OFF in Single mode
Click the audio icon () on the screen, or press the [AUDIO] button on the remote control to turn it on/off.
MOnly the channel where <AUDIO> is set to <ON> in “Device > Camera” displays the audio icon () in Live mode that you can use to turn the sound on/off.
FREEZE
This is available only in Live mode, this pauses playing the Live image temporarily.
1. Press the [FREEZE] button the remote control, or click < Freeze > in the launcher menu. The playback of the image is stopped temporarily.
2.Press the [FREEZE] button again, or click < Freeze >. This will release the freeze.
EVENT MONITORING
This will display the channel in sync with a specific event (Sensor/Motion/Video Loss) if it occurs.
In “Monitor > Event Display”, set the event monitoring to ON/OFF and specify the event display time. (Page 46)
•If multiple events occur simultaneously, the screen will switch to a split mode. - 2~4 events : 4-split mode
•If the second event occurs within the set time of <Event Display>, the first event will last until the second one is terminated. (Page 46)
Ex : If you set <Event Display> to 5 seconds, and only one event occurs in CH 1.
Event occurrence |
5 seconds |
|||
|
|
|
|
|
|
|
|
|
|
Stop alarm
CH1
30_ live
