TECHNICAL DAT A SHEET - Vision•Point
™
Vertical Desktop Mount with S tationary Base
MODEL: LCV 100
Peerless' Vision Point™ Vertical Desktop mount model LCV 100 comes
with a 1" stationary base and offers a dramatic design with a clean
aluminum upright, and a light gray coated base and slider. The superior
functionality of this mount delivers 60° of adjustable tilt, full side-to-side
rotation, and height adjustment.
Features:
• For LCD TVs and monitors up to 25 lbs (10" to 20" range)
• Clean looks – arm is anodized in clear aluminum, and base and slider are
finished with a light gray coating
• Full 360 degree rotation
• Screen can travel on a slider a total of 9.5" up and down the arm; locks in place
with a knob.
• Arm tilt s 30° backward and forward
• Comes with both VESA 75 and VESA 100 mounting plates (non-vesa
adapter plates sold separately)
• Bolts down to wood and/or wood composite surfaces between 3/4" to 1.5"
thick
Accessories:
• Other screen adapter plates available for screens not featuring a VESA stan-
dard hole pattern
A R C H I T E C T S S P E C I F I C A T I O N S
Dimensions:
Weight:
3.95 lb (1.8 kg)
Shipping weight:
4.5 lb (2.1 kg)
Load Capacity:
25 lb (11.4 kg)
Shipping Carton dimensions:
L= 16.9 in (429 mm)
W= 5.6 in (141 mm)
H= 3.9 in (100 mm)
page 2 of 2
TECHNICAL DATA SHEET
60O (±30O) TILT
MODEL: LCV 100
VESA 100
SIDE VIEW
360° HORIZONTAL ROTATION AT BASE
VESA 75
9.5” RANGE
16.48”
