Before connecting, operating or adjusting this product, please read these
instructions completely.
Please keep this manual for future reference.
RQT6530-P
Dear customer
Thank you for purchasing this product.
For optimum performance and safety, please read these
instructions carefully.
Table of contents
Before use
These operating instructions are applicable to the following
system.
SystemSC-PM47
Main unitSA-PM47
SpeakersSB-PM27
Before use
The model number and serial number of this product can
be found on either the back or the bottom of the unit.
Please note them in the space provided below and keep
for future reference.
MODEL NUMBER
SERIAL NUMBER
User memo:
DATE OF PURCHASE
DEALER NAME
DEALER ADDRESS
TELEPHONE NUMBER
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK OR PRODUCT DAMAGE, DO NOT
EXPOSE THIS APPARATUS TO RAIN,
MOISTURE, DRIPPING OR SPLASHING AND
THAT NO OBJECTS FILLED WITH LIQUIDS,
SUCH AS VASES, SHALL BE PLACED ON
THE APPARATUS.
When moving the unit ...................................Back cover
2
RQT6530
CAUTION:
TO PREVENT ELECTRIC SHOCK MATCH
WIDE BLADE OF PLUG TO WIDE SLOT,
FULLY INSERT.
CAUTION!
THIS PRODUCT UTILIZES A LASER.
USE OF CONTROLS OR ADJUSTMENTS OR
PERFORMANCE OF PROCEDURES OTHER THAN
THOSE SPECIFIED HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.
DO NOT OPEN COVERS AND DO NOT REPAIR
YOURSELF. REFER SERVICING TO QUALIFIED
PERSONNEL.
CAUTION!
DO NOT INSTALL, OR PLACE THIS UNIT, IN A
BOOKCASE, BUILT-IN CABINET OR IN ANOTHER
CONFINED SPACE. ENSURE THE UNIT IS WELL
VENTILATED. TO PREVENT RISK OF ELECTRIC
SHOCK OR FIRE HAZARD DUE TO OVERHEATING,
ENSURE THAT CURTAINS AND ANY OTHER MATERIALS DO NOT OBSTRUCT THE VENTILATION
VENTS.
Supplied accessories
Please check and identify the supplied
accessories.
Use numbers indicated in parentheses
when asking for replacement parts.
(Only for U.S.A.)
To order accessories contact
1-800-332-5368 or web site
(http://www.panasonic.com).
AC power supply cord ...................................... 1 pc.
(RJA0065-A)
FM indoor antenna ............................................ 1 pc.
(RSA0006-L)
AM loop antenna ............................................... 1 pc.
(RSA0033A-1)
THE FOLLOWING APPLIES ONLY IN THE U.S.A.
CAUTION:
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference will
not occur in a particular installation. If this equipment
does cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
Any unauthorized changes or modifications to this
equipment would void the user’s authority to operate
this device.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
Before use
Remote control transmitter .............................. 1 pc.
(EUR648268)
Remote control batteries ................................ 2 pcs.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE SCREWS.
NO USER-SERVICEABLE PARTS
INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the product’s
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
3
RQT6530
IMPORTANT SAFETY INSTRUCTIONS
Read these operating instructions carefully before using the unit. Follow the safety instructions on the unit and the safety
precautions listed below. Keep these operating instructions handy for future reference.
Safety
1. Power source—Connect the unit to a power source of
the type described in these instructions or as marked
on the unit.
2. Polarization—The unit is equipped with a polarized
power plug where one blade is wider than the other.
This safety feature ensures that the plug fits into your
household AC outlet only one way. If the plug doesn’t fit
Before use
one way, try reversing it. If the plug still doesn’t fit,
contact an electrician to replace the obsolete outlet. Do
not attempt to defeat the safety purpose of the plug.
3. Power cord protection—Route the AC power supply
cord so that it will not be walked on or pinched by items
placed on or against it. Never take hold of the plug or
cord with wet hands. Always grasp the plug body firmly
when connecting and disconnecting it.
4. Overloading—When connecting the AC power supply
cord, be careful not to overload the household AC outlet, extension cord, or outlet from any other device as
this can result in fire or electric shock.
5. Nonuse periods—Turn the unit off when it is not in
use. Unplug the unit from the household AC outlet if it is
not to be used for a long time. Unplug the unit during
lightning storms.
6. Attachments and accessories—Use only the attach-
ments and accessories recommended in these operating instructions.
Installation
3. Power lines—Take care when setting up an outdoor
antenna that it is not near overhead power lines, electric lights, or electrical circuits, and that there is no danger of the antenna falling on power lines, electric lights,
or electrical circuits. When installing an outdoor antenna,
take extreme care not to touch such power lines or
circuits, as contact with them can be fatal.
4. Outdoor antenna grounding—If you connect an out-
door antenna, ground the antenna system to protect
against voltage surges and built-up static charges. Section 810 of the National Electrical Code, ANSI/NFPA
No. 70-1990, provides information about grounding of
the mast and supporting structure, grounding of the leadin wire to an antenna discharge unit, size of grounding
conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the
grounding electrode. Refer to this diagram.
ANTENNA
LEAD IN
GROUND
CLAMP
ELECTRIC
SERVICE
EQUIPMENT
GROUND CLAMPS
WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
4
RQT6530
Placement
1. Ventilation—Situate the unit so that it receives proper
ventilation. Do not install in a confined space such as a
bookcase or cabinet. Allow at least 10 cm (4 inches)
clearance from the rear of the unit. To prevent the risk
of electric shock or fire due to overheating ensure curtains and other materials do not obstruct the unit’s ventilation.
2. Foreign material—Ensure objects and liquids do not
get into the unit. Avoid exposing the unit to excessive
smoke, dust, mechanical vibration, and shock.
3. Magnetism—Situate the unit away from equipment and
devices that generate strong magnetic fields.
4. Stacking—Do not place heavy objects on top of this
unit.
5. Surface—Place the unit on a flat, level surface.
6. Carts and stands—Use the unit only
with carts and stands recommended by
the manufacturer. Move carts with care.
Sudden stops, excessive force, and
uneven surfaces can cause carts to
overturn.
7. Wall and ceiling mounting—Do not mount the unit on
walls or ceilings unless specified in the instructions.
Environment
1. Water and moisture—Do not use the unit near water,
such as near a bathtub or swimming pool. Avoid damp
basements.
2. Heat—Situate the unit away from heat sources, such
as radiators.
Do not situate where temperatures fall below 5˚C (41˚F)
or rise above 35˚C (95˚F).
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
NEC—NATIONAL ELECTRICAL CODE
Maintenance
(See page 30 for details.)
Unplug the unit from the household AC outlet before clean-
ing.
Clean with a damp cloth.
Do not use abrasive pads, scouring powders, or solvents.
Service
1. Damage requiring service—The unit should be serv-
iced by qualified service personnel if:
(a) The AC power supply cord or the plug has been
damaged; or
(b) Objects or liquids have gotten into the unit; or
(c) The unit has been exposed to rain; or
(d) The unit does not operate normally or exhibits a
marked change in performance; or
(e) The unit has been dropped or the cabinet damaged.
2. Servicing—Do not attempt to service the unit beyond
that described in these operating instructions. Refer all
other servicing to authorized servicing personnel.
3. Replacement parts—When parts need replacing en-
sure the servicer uses parts specified by the manufacturer or parts that have the same characteristics as the
original parts. Unauthorized substitutes may result in
fire, electric shock, or other hazards.
4. Safety check—After repairs or service, ask the servicer
to perform safety checks to confirm that the unit is in
proper working condition.
The remote control
Listening caution
EST. 1924
Selecting fine audio equipment such as the unit you’ve just
purchased is only the start of your musical enjoyment. Now
it’s time to consider how you can maximize the fun and excitement your equipment offers. This manufacturer and the
Electronic Industries Association’s Consumer Electronics
Group want you to get the most out of your equipment by
playing it at a safe level. One that lets the sound come
through loud and clear without annoying blaring or distortion—and, most importantly, without affecting your sensitive hearing.
We recommend you to avoid prolonged exposure to excessive noise.
Sound can be deceiving. Over time your hearing “comfort
level” adapts to higher volumes of sound. So what sounds
“normal” can actually be loud and harmful to your hearing.
Guard against this by setting your equipment at a safe
level BEFORE your hearing adapts.
To establish a safe level:
• Start your volume control at a low setting.
• Slowly increase the sound until you can hear it
comfortably and clearly, and without distortion.
Once you have established a comfortable sound level:
• Set the dial and leave it there.
Taking a minute to do this now will help to prevent hearing
damage or loss in the future. After all, we want you listening for a lifetime.
Battery installation
R6, AA, UM-3
1
2
Before use
Use of batteries
• Align the poles (+ and –) properly when inserting the
batteries.
• Do not mix old and new batteries or different types of
batteries.
• Do not recharge ordinary dry cell batteries.
• Do not heat or disassemble the batteries. Do not allow
them to contact flame or water.
• Remove the batteries if the unit is not to be used for a long
time.
• Do not keep together with metallic objects such as
necklaces.
• Do not use rechargeable type batteries.
• Do not use batteries if the covering has been peeled off.
Mishandling of batteries can cause electrolyte leakage
which can damage items the fluid contacts and may cause a
fire.
If electrolyte leaks from the batteries, consult your dealer.
Wash thoroughly with water if electrolyte comes in contact
with any part of your body.
Placement of speakers
Place the speakers so that the super woofer is on the
outside.
Super
woofer
Notes
• Keep your speakers at least 10 mm (13/32˝) away from the
system for proper ventilation.
• The super woofers are located on the sides of the
speakers. Leave 10-cm clearance for them to be effective.
• These speakers do not have magnetic shielding. Do not
place them near televisions, personal computers or other
devices easily influenced by magnetism.
• To avoid damage to the speakers, do not touch the
speaker cones if you have taken the nets off.
Correct method of use
Remote control
signal sensor
Transmission
window
About 7 meters in
front of the signal
sensor.
Operation notes
• Do not place obstacles between the remote control signal
sensor and remote control unit.
• Do not expose the remote control signal sensor to direct
sunlight or to the bright light of a fluorescent light.
• Take care to keep the remote control signal sensor and the
end of the remote control unit free from dust.
• If this system is installed in a rack with glass doors, the
glass doors’ thickness or color might make it necessary to
use the remote control unit a shorter distance from the
system.
To prevent damage
• Never place heavy items on top of the unit.
• Do not disassemble or reconstruct the unit.
• Do not spill water or other liquids into the unit.
5
RQT6530
Before use
R
L
LOW(6
)
HIGH(6
)
1
2
(R)
Adhesive
tape
FM indoor
antenna
1
Connections
• Plug the AC power supply cord into a household AC outlet
only after all other connections have been made.
• To prepare the AM loop antenna wire and speaker cords,
twist the vinyl cover tip and pull off.
1
2
(L)
1 Connect the FM indoor antenna.
3
4
Tape the antenna to a wall or column, in a position
where radio signals are received with the least amount
of interference.
Note
For the best reception:
An FM outdoor antenna is recommended. (\ page 7)
2 Connect the AM loop antenna.
Stand the antenna up on its base. Keep loose antenna
cord away from other wires and cords.
3 Connect the speaker cords.
A Confirm the colors of the tags on the ends of the
cords.
2
B For White tags:
Connect cords to gray terminals.
For Blue, Black and Red tags:
Connect cords so tag colors match the terminal
colors.
Cords with white and blue tags are for high frequency.
Cords with red and black tags are for low frequency.
Incorrect connection can damage the unit.
Caution
Use only the supplied speakers.
The combination of the main unit and speakers provide
the best sound. Using other speakers can damage the
unit and sound quality will be negatively affected.
6
RQT6530
3
AM loop antenna
A
B
Gray (+)
Blue (–)
Black (–)
Red (+)
1
Red (
··
Black (
·)Black (
··
3
ªª
ª)
ªª
Caution
• Use the speakers only with the
recommended system. Failure to do
so may lead to damage to the
amplifier and/or the speakers, and
may result in the risk of fire.
Consult a qualified service person if
damage has occurred or if you
experience a sudden change in
White
Blue
Black
Red
2
··
·)
··
Red (
4 Connect the AC power supply cord.
Note
The included AC power supply cord is for use with this
ªª
ª)
ªª
unit only. Do not use it with other equipment.
performance.
• Do not attach these speakers to walls
or ceilings.
A
Connections
1
2
B
C
"LINE OUT"
position
Analog player (not included)
FM outdoor antenna
(not included)
19
(
AM outdoor antenna
(not included)
5-12 m
AM loop antenna
(included)
(L)
(R)
AUX
Rear panel of this unit
(1
3/16"
Shield braid
/32"
)
Core wire
L
R
Optional antenna connections
You may need an outdoor antenna if you use this system in
a mountainous region or inside a reinforced-concrete
building, etc.
)
Disconnect the FM indoor antenna if an FM outdoor
antenna is installed.
An outdoor antenna should be installed by a qualified
technician only.
Connect the outdoor antenna without removing the AM loop
antenna. Run 5 to 12 m of vinyl-covered wire horizontally
along a window or other convenient location.
When the unit is not in use, disconnect the outdoor antenna
to prevent possible damage that may be caused by
lightning. Never use an outdoor antenna during an electrical
storm.
FM outdoor antenna
A
Note
AM outdoor antenna
B
Note
Before use
External unit connections
• Make sure that the power supply for all components has
been turned off before making any connections.
• For details, refer to the operating instructions of the unit
which is to be connected.
• All peripheral components and cables sold separately.
Connecting analog equipment
C
This example shows how to connect an analog player with a
PHONO OUT/LINE OUT switch.
When units other than those described are to be connected,
please consult your audio dealer.
Note
• Only an analog player with a built-in phono equalizer can
be connected.
• Set the switch to the “LINE OUT” position at the back of
the analog player.
7
RQT6530
Before use
PRESET EQ 4/REW/g 3/FF/f L/–DEMO [REC/J
SUPER SOUND EQ
AC IN
POWER
f/ 7
CD CHECK
PRESET EQ 4/REW/g 3/FF/f L/–DEMO [REC/J
TUNER/
TAPE
CD
AUX
£
-/ J
BAND
CD 1 CD 2 CD 3 CD 4 CD 5
Front panel controls
Main unit
11
Cassette lid
1
11
22
Cassette open button (c OPEN) ........................... 19
2
22
33
Tape indicator
3
33
This indicator changes in the following manner:
a Orange (when no cassette is inserted.)
OPEN
VOLUME
DOWN
OPEN/CLOSE
UP
CD CHANGE
PHONES
b Green (when cassette is inserted.)
c Red (when in recording mode.)
44
4 AC supply indicator (AC IN)
44
This indicator lights when the unit is connected to the
AC mains supply.
55
5 Standby/on switch (
55
Press to switch the unit from on to standby mode or vice
versa. In standby mode, the unit is still consuming a
small amount of power.
66
6 CD check button (CD CHECK) ............................... 13
66
77
7 CD trays
77
88
8 Display
88
99
9 Remote control signal sensor
99
!!
! Volume control (VOLUME DOWN, UP) ..... 10, 12, 19
!!
""
" CD tray open/close button (c OPEN/CLOSE) ...... 12
""
##
# CD change button (c CD CHANGE) ..................... 13
##
$$
$ Headphone jack (PHONES) .................................... 22
The unit comes on automatically.
Every time you press the button:
FM ↔ AM
3
/
4
1
2 Press [PLAY MODE] on the remote control to
select “MANUAL”.
Every time you press the button:
MANUAL ↔ PRESET
3 Press [
44
4/REW/g] or [
44
33
3 /FF/f] to select
33
the frequency of the required station.
“ST” is displayed when a stereo FM broadcast is being
received.
4 Adjust the volume.
Auto tuning
Press and hold [
until the frequency starts changing rapidly. The unit begins
auto tuning, stopping when it finds a station.
• Auto tuning may not function when there is excessive
interference.
• To cancel auto tuning, press [
once again.
A
By remote control only
Press and hold [PLAY MODE] to display
“MONO”.
This mode improves sound quality if reception is weak, but
broadcasts will be heard in monaural.
Press and hold [PLAY MODE] again to cancel the mode.
“MONO” goes out. MONO is also cancelled if the frequency
is changed.
Turn off “MONO” for normal listening. Stereo and monaural
broadcasts are automatically played as they are received.
44
4/REW/ g ] or [
44
33
3 /FF/ f] for a moment
33
44
4/REW/ g ] or [
44
If noise is excessive in FM
33
3 /FF/ f ]
33
10
RQT6530
DOWNUP
A
DISPLAY DI MM ER
AUX TUNER TAPE CD
ALBUM
SLEEP
CLOCK/
PLAY/
-AUTO OFF
TIMER
PLAY MODE
/REW/ /FF/ /CLEAR
S SOUND EQ PRESET EQ
VOLUME
REC
DISC
≥
10
PROGRAM
MUTING
/
123
456
7890
PLAY MODE
FM allocation setting
By main unit only
By adjusting the allocation, you can enable this tuner to
receive FM broadcasts allocated in 0.1 MHz steps.
Press and hold [TUNER/BAND]. After a few seconds, the
display will change to a flashing display of the current minimum FM frequency. If you continue to hold the button down,
the minimum frequency will change. Release the button at
this time.
To return to the original frequency indication, repeat above.
Note
• After changing the “allocation” setting, the frequencies you
previously preset in the memory will be cleared.
• Sound is momentarily interrupted if you load/unload a
cassette while listening to an AM broadcast.
Loading...
+ 22 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
