Omega Excalibur RS-310 User's Manual

4 (1)
Omega Excalibur RS-310 User's Manual

L I M I T E D L I F E T I M E W A R R A N T Y

Products manufactured and sold by OMEGA RESEARCH & DEVELOPMENT, INC. (the "Company"), are warranted to be free from defects in materials and workmanship under normal use. If a product sold by the Company proves to be defective, the Company will repair or replace it free of charge within the first year and thereafter all parts to be repaired will be free with only a nominal charge for Omega's labor and return shipping, to the original owner during the lifetime of the car in which it was originally installed.

All products for warranty repair must be sent postage prepaid to Omega Research & Development, Inc., P.O. Box 508, Douglasville, Georgia 30133, or send via UPS to: 981 N. Burnt Hickory Rd., Douglasville, Georgia 30134, with bill of sale or other dated proof of purchase. This warranty is nontransferable and does not apply to any product damaged by accident, physical or electrical misuse or abuse, improper installation,BACKalteration,COVERany use contrary to its intended function, unauthorized service, fire, flood, lightning, or other acts of God.

This warrantyPRINTER’Slimits the Company's liabilityNOTE:to the repair or replacement of theproduct.TheCompanyshallnotberesponsibleforremovaland/orreinstallation

charges, damageproductionto r theft of he vehiclebackor its ontents,coverr any incidental or consequential damages caused by any failure or alleged failure of the product to

function properly. UNDERis color;NO CIRCUMSTANCESthis is aSHOULD THIS

WARRANTY, OR THE PRODUCT COVERED BY IT, BE CONSTRUED

AS A GUARANTEEplaceOR INSURANCEmarkerPOLICYcoverAGAINST. LOSS. The Company neither assumes nor authorizes any person or organization to make any

warranties or assume any liability in connection with the sale, installation, or use of this product.

This device complies with F.C.C Rules part 15. Operation is subject to the following two conditions: (1) This device may not cause harmful interference and, (2) This device must accept any interference that may be received, including interference that may cause undesired operation.

The manufacturer is not responsible for any radio TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment.

Omega Research and Development, Inc.

P. O. Box 508

Douglasville, Georgia 30133

www.caralarm.com

07/08 MO-RS-310 REV1

Omega

RS-310

OPERATION MANUAL

FRONT COVER

PRINTER’S NOTE: production front cover is color; this is a place marker cover.

COPYRIGHT 2007: OMEGA RESEARCH & DEVELOPMENT, INC.

Table of Contents



Introduction/System Overview ................................................

3-5

Valet Switch Overview ................................................................

4

Transmitter Overview ...................................................................

4-5

Using the RS-310 System ........................................................

5-9

Locking The Doors .......................................................................

5

Unlocking The Doors ...................................................................

5

Trunk Release/2nd Channel .........................................................

6

Remote Starting ............................................................................

6

Panic Mode ...................................................................................

7

Using The Valet Switch ..........................................................

7-8

Valet Mode ...................................................................................

7

Emergency Override .....................................................................

7-8

Other Remote Start Features ...................................................

8-9

Pit-Stop Feature ............................................................................

8

Low Battery Automatic Starting ..................................................

8

Turbo Timer Feature ....................................................................

8-9

Optional Status Light Functions ..............................................

9-10

Transmitter Protection .............................................................

10

How to Program Transmitters .................................................

11-12

How to Program Features ........................................................

12-13

User Programmable Features ..................................................

13-15

Installer Programmable Features.............................................

15-18

Complete Programmable Features Matrix ..............................

19

Limited Lifetime Warranty ..............................................

Back Cover

Complete Programmable Features Matrix



USER Features

Ignition on, off, then press Valet Switch 5 times















#

Feature

Lock Button

Unlock Button

Trunk / || Button

Start / ||| Button













1

Remote Start Run Time

10 Min.

5 min.

15 min.

20 min.













2

Steady/Flash Lights Rem. Start

Steady

Flashing

















3

Confirmation Chirps/Volume

Low

Loud

On Demand/Loud

OFF













4

Pulsed Horn / Steady Siren

Pulsed Lo

Pulsed Med.

Pulsed Hi

Steady Siren













5

Doors Lock With Ignition On

ON

OFF

















6

Doors Unlock With Ignition Off

ON

OFF



















INSTALLER Features

Ignition on, off, then press Valet Switch 10 times















1

“Tach Wire” or “Tachless “

Tachless

Tach

















2

Gasoline or Diesel Engine

Gasoline

Diesel

















3

Sat. Port Green Wire Function

Starter

Pulse After Start

Pulse After Stop

Accessory Output













4

Ext. Starter Cranking Time

.7 (minimum)

1.25

1.75

2.5 (maximum)













5

Doorlock Functions

.8 second

3 Seconds

Double Unlock

Total Closure













6

Turbo Timer

OFF

1 min.

2 min.

3 min.













This device complies with FCC Rules part 15. Operation is subject to the following two conditions, (1) This device may not cause harmful interference and, (2) This device must accept any interference that may be received, including interference that may cause undesired operation.

The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user's authority to operate the equipment.

Coin batteries used in the transmitter which is used to operate this security system may contain Perchlorate Material - special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate

Omega Research and Development, Inc.

www.caralarm.com

Page - 2

Page - 19

The second setting (programmed by the “unlock” button) changes the

lock and unlock outputs to be a longer 3 second pulse output. This is for certain vehicles which require a longer output pulse from the system’s control unit;

typically cars having vacuum pump systems, although the longer setting is also more suitable in some newer vehicles.

Some newer vehicles require a double pulse output to remotely unlock the doors and/or to disarm a factory-equipped security system, which is what the Double Pulse Unlock setting provides (it is programmed by the “trunk” button ). The lock output pulse, in this setting, is 0.8 second.

The Total Closure Lock Output (programmed by the “start” button) may be used with vehicles which are originally equipped with the total-closure feature. Typically, a total closure feature is when locking the vehicle’s doors if the key in the door is held to “lock” for a period of time the vehicle will close all windows and the sunroof, in addition to locking the doors.

Selecting this feature setting changes the system’s door lock output pulse from a 0.8 second to as long as a 28 second duration output. The unlock output is 3 seconds in this setting.

Note: When this feature is turned on, during the 28 second period after arming the system, the lock output can be stopped on demand by pressing the “lock” or “unlock” button. Only the output will stoppressing

either button again will normally operate the system, and at any time after the 28 second lock output period ends.

If either of the programmable relays are set for lock or unlock operation (the next two Installer Programmable Features), the settings if this feature will operate the programmable relays accordingly, in addition to the primary system doorlocking outputs.

Feature #6 Turbo Timer

Factory Default Setting

Off





(press “lock” button to program)

Options:



Run 1

Minute

(press “unlock” button to program)

Run 2

Minutes

(press “trunk” button to program)

Run 3

Minutes

(press “start” button to program)

This feature when turned on configures the RS-310 to automatically keep the engine running briefly after it is turned off. This operation is designed specifically for vehicles having turbocharged engines (the user may temporarily bypass the feature if desired).

This feature should only be programmed by the installer, and the operation of this feature depends on the correct connection of the safety wire to the vehicle’s parking brake. Please refer to the “Black/White wire” in the installation manual for the proper connection of this important wire.

Introduction

Welcome to the convenience which is offered by your RS-310 keyless entry & remote start system. The RS-310 is designed and manufactured by Omega Research and Development, a world leader in vehicle convenience and security since 1975. Your system offers easy, carefree operation, and the modular design allows its many impressive features to be customized to suit your needs. Omega systems are designed for professional installation, and are available only through new car retail outlets and selected mobile electronics specialist dealers.

Please note that this guide is written to reflect:

-That a power doorlock interface is installed with your system (the RS-310 also operates your power doorlocks). The type

of interface may vary from one vehicle to the other, and in some cases may involve optional components.

-That the RS-310 operating the vehicle's existing horn is an available option.

-That the Programmable Features are in the default settings; the operations of these features are also explained.

Your RS-310 system has two principal user components: the Valet Switch, and the Remote Transmitter. An LED Status Light can be added to the system by your installing dealer.

The Valet Switch is used to access Valet Mode, which allows the operator to suspend some of the system's normal functions for as long as desired. The Valet Switch may also be used, instead of the remote transmitter, to override a locked system. The Valet Switch is also used when programming remote transmitters and system features.

See “Using the Valet Switch” on pages 19-20.

Transmitters are used to operate the RS-310. Each system is capable of being operated by up to four different remote Transmitters, which are described on the following page. The remote transmitter has four pushbutton switches, each being labeled with an icon as to function.

The OPTIONAL LED Status Light informs you at a glance which of the different conditions the system is in, and also serves as a visual deterrent to break-ins and theft. Specific operations of this light are described on pages 9-10. A status light is not included with your system. If you do not have one and would like one, contact your installing dealer for more information.
