SENTRY
INSTALLATION GUIDE
NEC America, Inc.
NDA-30080
Revision 1.0
September, 1998
Stock # 241676
LIABILITY DISCLAIMER
Copyright 1998
NEC America, Inc.
Sentry Installation Guide CONTENTS
TABLE OF CONTENTS
Page
Chapter 1 - Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Chapter 2 - Sentry Alarm Control Terminal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Software Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
UNIX Subsystem Database Update. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Database Creation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Sentry Master Database . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Feature Application Database . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Window Configuration Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Configuration Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Master Configuration File. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Data Buffer Configuration File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Initialization Configuration File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Screen Saver Configuration File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Function Keys Configuration File. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Dialogs Configuration File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Windows Con fig u r ation Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Chapter 3 - Annoyance Trap. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Additional Manuals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Software Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Application Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Primary Configuration Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
OAI Facilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Secondary OAI Configuration Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
User-Defined Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Database Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Database Creation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Database Records. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Building Database . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Tenant Number Database . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Chapter 4 - Emergency Conference. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Additional Manuals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Software Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Application Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Primary Configuration Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
OAI Facilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Secondary OAI Configuration Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
User-Defined Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Database Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
NDA-30080 Revision 1.0 Page i
CONTENTS Sentry Installation Guide
Page
Database Creation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Database Records. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Sentry Database . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Conference Card Database. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Tenant Number Database . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Building Database . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Contacts Database . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Authorized Caller Database. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Chapter 5 - Executive Override . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Executive Override. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Override Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Installation and Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Additional Manuals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Software Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Application Characteri stics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Primary Configuration Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
OAI Facilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Secondary OAI Configuration Paramete rs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
User-Defined Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Database Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Database Creation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Database Records. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Authorization Code Database . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Special Station Database. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Tenant Number Database . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Executive Override Configuration Sample . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Chapter 6 - MAT Assignments and PBX Information. . . . . . . . . . . . . . . . . . . . . . . . . . 99
PBX Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
MAT Assignments. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Executive Override. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Annoyance Trap. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Emergency Conference. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
No Dial Alarm Conferencing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Conference Cards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
PA-CFTB Conference Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Chapter 7 - Platform Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Logging In . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Attendant Terminal Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Error Log File Browser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
UNIX Prompt. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
Log Out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
Appendix A - History Logging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Master Configuration Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Page ii NDA-30080 Revision 1.0
Sentry Installation Guide CONTENTS
Page
Printer Configuration Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 9
Printer Count . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
Printer Device Name . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
Printer Device Baud Rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
Printer Device Parity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
Printer Device Data Bits. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Printer Device Stop Bits. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Format Configuration Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
History Log Count . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
History Log Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
History Log Name . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
History Log Message Formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
Annoyance Trap Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
Emergency Conference Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
Executive Override Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
NDA-30080 Revision 1.0 Page iii
CONTENTS Sentry Installation Guide
This Page Left Blank.
Page iv NDA-30080 Revision 1.0
Sentry Installation Guide FIGURES
LIST OF FIGURES
Figure Title Page
6-1 OAI Function Key Assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
6-2 OAI Function Key Assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
NDA-30080 Revision 1.0 Page v
FIGURES Sentry Installation Guide
This Page Left Blank.
Page vi NDA-30080 Revision 1.0
Sentry Installation Guide TABLES
LIST OF TABLES
Table Title Page
2-1 Sentry Master Database Fields. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2-2 Feature Application Database Fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3-1 Building Master Database Fields. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
3-2 Buildi n g Ap p lication Data ba s e Fi e ld s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
3-3 Tenant Master Database Fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
3-4 Tenant Number Application Database Fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
4-1 Sentry Master Database Fields. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
4-2 Sentry A p p lic a t io n Da t ab a s e Fi e ld s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
4-3 Conference Card Master Database Fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
4-4 Conference Card Application Database Fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
4-5 Tenant Master Database Fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
4-6 Tenant Number Application Database Fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
4-7 Building Master Database Fields. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
4-8 Buildi n g Ap p lication Data ba s e Fi e ld s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
4-9 Contacts Master Database Fields. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
4-10 Contacts Application Database Fields. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
4-11 Authorized Caller Master Database Fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
4-12 Authorized Caller Application Database Fields. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
5-1 Executive Override Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
5-2 Authorization Code Master Database Fields. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
5-3 Author iz a tio n C o de A p p lic a tion Database Fi e ld s . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
5-4 Special Station Master Database Fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
5-5 Special Station Application Database Fields. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
5-6 Tenant Master Database Fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
5-7 Tenant Number Application Database Fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
NDA-30080 Revision 1.0 Page vii
TABLES Sentry Installation Guide
This Page Left Blank.
Page viii NDA-30080 Revision 1.0
Sentry Installation Guide Introduction

Chapter 1 Introduction

This manual descri bes th e i nstal lati on, dat abases , an d confi gurat ion f or the Sen try Alarm Control Terminal and the appli cations that can be used with the terminal.

Overview

This manua l contains the following chapters:
Chapter 1, Introduction - Describes the chapters in this installation guide. Chapter 2, Sentry Alarm Control Terminal - Provides an overview of Sentry
Alarm Control Terminal and describes the installa tion, databases and conf iguration parameters.
Chapter 3, Annoyance Trap - Provides an overview of the Annoyance Trap application an d descri bes the instal lation, configur ation pa rameters , and database s.
Chapter 4, Emergency Conference - Provides an overview of the Emergency Conference application and describes the installation, configuration parameters, and databases.
Chapter 5, Executive Override - Pr ovides an over view of the Exec utive Override application and descr ibes the installatio n, configuration para meters, and databases. Also provides a sample configuration.
Chapter 6, MAT Assignments and PBX Information - Describes the NEAX Maintenance Administration Terminal (MAT) commands that need to be used for each OAI Monitor application as well as the PBX software and conference cards that you need to run Sentry Alarm C ontrol Ter minal
Chapter 7, Platform Maintenance - Describes how to use the plat form maintenance utility to perform adm inistrative tasks, including: activating, deactivati ng, and resetting terminals.
Appendix A, History Logging - Provides a description of the History Logging configuration.
NDA-30080 Revision 1.0 Page 1
Introduction Sentry Installation Guide
This Page Left Blank.
Page 2 NDA-30080 Revision 1.0
Sentry Installation Guide Sentry Alarm Control Terminal

Chapter 2 Sentry Alarm Control Terminal

This chapter describes the databases and configuration parameters for the Sentry Alarm Cont rol Termina l software. F or information about us ing the Sentry Alarm Control Te rminal, see the Sentry Alarm Control Terminal User Guide.

Overview

The Sentry Alarm Control Termin al is a versa tile UAP operator interface application that communic ates with on e or more Sentry OAI Monitor applicat ions (such as the Emergency Conference Monitor or the Annoyance Trap Monitor) using message protocols defined by these applications. Data received from the monitors is displayed in real time.
Multiple instances of the Sentry Alarm Control Terminal may be executed simultaneously from the system console and/or from one or more d u mb te rmi nal s connected to the UAP via RS-232. The content and format of displayed data is controlled through configuration files, allowing a high degree of customization. Each terminal can use a separate configuration, or configurations can be shared.
The Sentry Alarm Control Termina l uses text windows to display i nformatio n and allows the user to manipul ate window te xt from a keyb oard. Specia l functi on keys are defined to permit the user to quickly perform needed tasks. System messages are used to inform the user of er rors and othe r status chan ges. Dialog windo ws are displayed to show current configuration settings or when the program requires information from the user.
The following features are controlled through the configuration file set:
Window and Dialog Attributes
• Screen position
• Size in rows and columns
• Text colors and attributes (bold, blinking, etc.)
• Static text fields
• Dynamic text field formats
Real Time Message Display Attributes
• Message text field format s
• Text colors and attributes (bold, blinking, etc.)
Screen Saver Attributes
• Time out values
• Text colors and attributes (bold, blinking, etc.)
• Static text fields
Function Key Assignments
NDA-30080 Revision 1.0 Page 3
Sentry Alarm Control Terminal Sentry Installation Guide
There are several processes included in the Sent ry Alarm Control Terminal installation:
• Software Installation - Install software from media and follow prompts.
• Database Creation - Build, process, and install databases.
• Window Configuration Files - Creat e con figuration files for te rminal windows.
• Configuration Parameters- Set configuration parameters.
• Activate Terminals - Use platform maintenance tools t o activate terminals.
The following sections describe these processes.
Page 4 NDA-30080 Revision 1.0
Sentry Installation Guide Sentry Alarm Control Terminal
login: apmadm
password:
NEC America APM Administra tion Wed J an 31, 1996
APM Platform Release Rel2. 0 (Oct 09, 1995
Main Menu
APM
Debug Facilities
Halt APM System
File Archive
Installation of Appli cations/Packages
Removal of Packa ges
Start-up APM Sys tem
Logout
UNIX
Enter Option: [ ]
APM Status: ACTIVE

Software Installation

The Sentry Alarm Control Terminal software must first be loaded from the release media. Remember to use the Applications Manager (A PM) I ns tal lation Manual if you need fur ther instructions for installing softw are using the APM.
Note:
You will be prompted for several values when you install the software. For more information about these and other parameters, refer to the next section,
Configuration P arameters on page 16.
1. T o begin the Sentry Alarm Control Terminal software installation, log in to the
APM Platform Management Menu by typing apmadm at the UNIX login prompt, then press Enter. The login and password prompts are shown below.
If your “apmadm” account requires a password, enter the appropriate password at the subsequent password prompt.
The APM Administration main menu displays.
)
NDA-30080 Revision 1.0 Page 5
Sentry Alarm Control Terminal Sentry Installation Guide
2. Type i and press Enter to select the Installation of Applications/Packages
option. The Installation of Application/Packages screen displays.
NEC America APM Administr ation Wed - Jan 31, 19 96
Installation of Appli cations/Packages
Available Package s are:
applications asl mtl tcpip u pdate x25
Enter Package to be installed :
3. At the “
press Enter. The “
Enter Package to be installed
Enter Release Media Device
NEC America APM Administr ation Wed Ja n 31, 1996
Installation of Appli cations/Packages
Available Package s are:
applications asl mtl tcpip u pdate x25
Enter Package t o be installed : applicati ons
Release Media Devices are :
(F)loppy Disk De vice (C)artridg e Tape Device
Enter Release M edia Device:
” prompt, type applications and
” prompt displays.
Page 6 NDA-30080 Revision 1.0
Sentry Installation Guide Sentry Alarm Control Terminal
Installation Proced ure
Installing from /dev/fd0
Insert OAI Release Media #1
Enter <Return> t o continue:
Has all release media been lo aded [y or n] ?
x oai/app/sentryTr m/install/ansi_sa t, 1038 bytes, 3 tape blocks
x oai/app/sentr yTrm/install/M default.cfg , 434 bytes, 1 tape blocks
x oai/app/sentryTr m/install/.profil e, 1673 bytes, 4 tape blocks
.
x oai/chksum_app, 1011 bytes, 2 tape block s
x oai/app/sentryTrm. ins, 8459 bytes, 17 tape blocks
x oai/app/sentryT rm/bin/sentryT erm, 540414 bytes, 1056 ta pe blocks
.
.
.
4. Select th e floppy dis k devic e as the inst allation media b y typing f and pressing Enter.
The following screen displays:
5. Insert the Sentry Alarm Contro l Terminal disk ette into the fl oppy dis k devic e, and press Enter to continue.
The screen displays files in the application installation. Many files may scroll off the screen, until all of the files from the diskette have been processed.
The “
Has all release media been loaded
” prompt displays.
NDA-30080 Revision 1.0 Page 7
Sentry Alarm Control Terminal Sentry Installation Guide
6. Type y and press Enter to indicate that all release media has been loaded.
The APM installation begins processing all of the Sentry Alarm Control Terminal installation files and checking them for correctness. The screen indicates the status of the installation.
OAI Platform is a t revision 5 f or machine i386 (Dec 19 1 994 Rel 1.6. 1)
sentryTrm Revisi on: 5 mach ine type: i 386 Versio n: 1.7 Processing, plea se wait... Validating insta lled files
..............
Validation Compl eted
Installing t he Release Files
Processing files
After the files have been processed, the “root password” prompt displays. In order to com plete the Sentry Alarm Co ntrol Terminal installation, you must modify certain files that require “root” privileges.
NEC America Inc Sentry Termin al Installa tion Wed - Ap r 29, 1998
Installation re quires Super Us er (root) p rivileges.
Please Enter su/root Pas sword:
Page 8 NDA-30080 Revision 1.0
Sentry Installation Guide Sentry Alarm Control Terminal
Creating Sentry Terminal direc tories . . .
/oai/app/sentry created
NEC America Inc Sentry Termin al Installa tion Wed - Ap r 29, 1998
/oai/app/sentry /bin created
/oai/app/sentry /install created
/oai/app/sentry /cfg created
/oai/app/sentry /cfg/terminals creat ed
/oai/app/sentry /cfg/terminals/de fault created
/oai/log alread y exists
/oai/log/sentry created
Press Enter to continue. [ ]
Installing sent ry user on SCO UNIX.
Enter (sentry) user id [6000]:
NEC America Inc Sentry Termin al Installa tion Wed - Ap r 29, 1998
User (sentry) a lready belongs to a group.
User (sentry) i nstalled.
Press Enter to continue. [ ]
7. Type in the root password at the prompt and press Enter to continue. The Sentry Alarm Control T erminal installation will create any directory that
does not already e xi st. The pa th s of the direc tori es will display on the scree n, as illustrat ed below.
8. Press Enter to continu e the inst al la ti on. The sentry user is added to the SCO UNIX operating system.
NDA-30080 Revision 1.0 Page 9
Sentry Alarm Control Terminal Sentry Installation Guide
9. Press Enter again and the sntryadm user is adde d to the SCO UNIX operati ng
system.
NEC America Inc Sentry Termin al Installa tion Wed - Ap r 29, 1998
Installing sntr yadm user on SC O UNIX.
Enter (sntryadm ) user id [6000 ]:
Warning: The us er id [6000] is already as signed on this system, Install (sntrya dm) with user i d [6000] (y /n)
10. A warning indi cating t hat the user ID has a lready b een assi gned to t he syste m
displays. T ype y and press Enter to install the sntryadm user with the same ID. The sntryadm user is added to the system.
NEC America Inc Sentry Termin al Installa tion Wed - Ap r 29, 1998
Installing sntr yadm user on SC O UNIX.
Enter (sntryadm ) user id [6000 ]:
Warning: The us er id [6000] is already as signed on this system, Install (sntrya dm) with user i d [6000] (y /n) y
User (sntryadm) alrea dy belongs to a group.
User (sntryadm) installed.
Press Enter to continue [ ]
Page 10 NDA-30080 Revision 1.0
Sentry Installation Guide Sentry Alarm Control Terminal
Installing the Sentry Terminal Binary . . .
NEC America Inc Sentry Termin al Installa tion Wed - Ap r 29, 1998
Installing the Sentry Database Files . . .
Installing the Default Termina l Configura tion Files . . .
Installing the ansi_s at terminal information . . .
Installing the Sentry Platform Maintenanc e Utilities . . .
Installing /etc /mygetty . . .
Updating /etc/g ettydefs . . .
Press Enter to continue. [ ]
Sentry Terminal Installation C omplete.
The following c onfiguration ta sks must be completed bef ore
NEC America Inc Sentry Termin al Installa tion Wed - Ap r 29, 1998
1. Build, proce ss, and install the sentry _m database.
starting Sentry Terminal appli cation
2. Build a wind ow configuratio n file for each entry in the
sentry_m dat abase
See the Sentry Terminal Ins tallation guide for more inf ormation.
Press Enter to continue. [ ]
11. Press Enter to continue the installation.
12. Press Enter to continue. The following screen displays when the installati on is comple te.
13. Press Enter.
NDA-30080 Revision 1.0 Page 11
Sentry Alarm Control Terminal Sentry Installation Guide

UNIX Subsystem Database Update

The SCO UNIX Subsystem database must be update d for the Sentry Alarm Control Terminal.
At the UNIX prompt, login as the superuser (root) and execute the SCO UNIX Subsystem Database authorization checking program (/tcb/bin/authck -s) and password deletion program (passwd -d) as shown below.
login: root Password: <root password> # /tcb/bin/authck -s
.
The following us ers have Protec ted Passwor d Database ent ries that do not matc h their Subsyst em Database entries:
. .
sentry sntryadm
.
There are errors in the databas e. fix them (y/n)> Y <ENTER>
# passwd -d sent ry
Deleting passwor d for user sen try # passwd -d sntryadm
Deleting passwor d for user snt ryadm
Answer yes when asked to fix the subsyst em databases. This ensures that the SCO UNIX Subsystem Databases are left in a proper state.
Page 12 NDA-30080 Revision 1.0
Sentry Installation Guide Sentry Alarm Control Terminal

Database Creation

The Sentry Master Database contains information used by the Emergency Conference, Annoyance Trap, and Sentry Alarm Control Terminal applications. The Feature Application Database contains a sub se t of the Sentry Master Databa se and is used by the Sentry Ala rm Control Ter minal program. Eac h featu re database record contains an entry for each Sentry feature (Emergency Conference or Annoyance Trap) used by the system. Refer to the APM Configuration Manual for more information.
Each sentry master database record contains the following fields:
Monitored Number
The monitored number used by the caller to access the Emergency Conference or Annoyance Trap.
Category
An ASCII string containing the record category, which is set to “conference” for Emergency Conference records or “annoyance” for Annoyance Trap records.
Name
An ASCII string containing the Emerge ncy Confere nce or Annoyan ce Trap name.
Minimum Lines Used
The minimum number of lines requi red by an Emergency Confe rence. This field is not used by the Sentry Alarm Control Terminal.
First Line Number
The first line number of the dedicated conference card set used by an Emergency Conference. This field is not used by the Sentry Alarm Control Terminal .
Override Allowed
A simple Y/N character that determines whether or not an emergency conference will override bus y dest in ations . This fie ld is not used by the Se ntry Alarm Con trol Terminal.
Warning Tone Issued
A simple Y/N char acter t hat deter mines whether or not a n Emerg ency Co nfe rence will issue a warning tone when a caller joins a conference. This field is not used by the Sentry Alarm Contr ol Terminal.
Window Symbol
The name of the window symbol associated with an Emergency Conference or Annoyance Trap.
Contact Database
The name of the contacts database file used by an Emergency Conference. This field is not used by the Sentry Alarm Control Terminal.
Authorized Database
The name of the authorized ca ller database fi le used by an Emergency Confer ence. This field is not used by the Sentry Alarm Control Terminal.
NDA-30080 Revision 1.0 Page 13
Sentry Alarm Control Terminal Sentry Installation Guide

Sentry Maste r Database

Field Description T ype Size
Monitored Number ASCII 10 5776
Minimum Lines Used Numeric 2 0 42 0
First Line Number N umer ic 5 0 99999 0
Override Allowed ASCII 1 n y
Warning Tone Issued ASCII 1 y y
Window Symbol ASCII 25 ALARM_WIN
Contact Database ASCII 25 /oai/db/cur/conf1
Authorized Database ASCII 25 /oai/db/cur/caller1

Feature Application Database

The Sentry master database is named “sentry_m” by default and contains the following fields.
Minimum
Value
Category ASCII 25 conference
Name ASCII 25 conference1
Table 2-1 Sentry Master Database Fields
Maximum
Value
Example
Value
The feature applic ation database uses data contained in the sentry master database. It is called “features” by default and contains the following fields.
Field Description Data Type
Monitored Number ASCII
Name ASCII
Window Symbol ASCII
Category ASCII
Table 2-2 Feature Application Database Fields
Page 14 NDA-30080 Revision 1.0
Sentry Installation Guide Sentry Alarm Control Terminal

Window Configuration Files

To create window configuration files:
1. Log in as apmadm to access the APM Administration Main Menu.
2. At the APM Administration Main Menu, type U to exit to UNIX.
3. At the UNIX prompt, type the following to change to the Sentry Alarm Control Terminal default configuration directory:
cd /oai/app/sentry/cfg/terminals/default
4. Make a feature configuration file for each Sentry Feature by copying the
“feature.def” file us ing the following command:
cp feature.def <name.cfg>
where <name.cfg> is a unique name assigned by you. For example,
cp feature.def fire.cfg
5. Use a UNIX editor (such as vi) to edit each feature configuration file, following the instructions contained in the file’s head er. For example,
vi fire.cfg
6. After the feature configuration files have been created and edited, use the following command to change to the Sentry Alarm Control Terminal configuration directory:
cd /oai/app/sentry/cfg/terminals
7. Use a UNIX editor (such as vi) to edit the Default Master Configuration file (Mdefault.cfg). Add the full path of each feature configuration file to the list within the Master Configuration file. For example,
vi Mdefault.cfg
Note:
Refer to the next section, Configuration Parameters on page 16 and Feature
Window Configuration on page 29 for more information about configuration
param eters .
NDA-30080 Revision 1.0 Page 15
Sentry Alarm Control Terminal Sentry Installation Guide

Configuration Parameters

The Sentry Alarm Control Terminal application uses configuration parameters defined in configuration files found in the “/oai/app/sentry/cfg/terminals” directory. The following sections describe the formats and functionality of these files.

Master Configuration File

When a Sentry Alarm Control Terminal is started it will determine which UNIX tty device it is using (t ty01, tty02, etc.). It will then look f or a master config uration file in the “/oai/app/sentry/cfg/terminals” directory that is associated with the tty device (“/oai/app/sentry/cfg/terminals/Mtty01.cfg”, “/oai/app/sentry/cfg/ terminals/Mtty02.cfg”, etc.).
If a master configuration file has not been created for this tty then the file “Mdefault.cfg” is used by default. Ea ch ma ster confi gurati on fi le co nta ins a list of configuration file paths. A subdirectory is normally created to hold the configuration fil es associat ed with th e default c onfiguration a nd each tt y (“oai/app/ sentry/cfg/terminals/default/”, “/oai/app/sentry/cfg/terminals/tty01/”, etc.).
The master configuration file can lis t files that are lo cated in different directories, allowing different tty devices to share configuration files. Each master configuration file contains a complete path for the following configuration files:
db.cfg
The data buffer configuration file (
See, Data Buffer Configuration File on page 17
).
init.cfg
The initialization configuration file (
See, Initialization Configuration File on page 21
logos.cfg
The screen save configuration file (
See, Screen Saver Con figuration File on page 22
).
keys.cfg
The function keys configuration file (
23
).
See, Function Ke y s Con figuration File on page
).
dialogs.cfg
The dialogs configuration file (
See, Dialogs Configuration File on page 25
).
titleBar.cfg
The title bar configuration file (
See, Title Bar Configuration on page 27
).
msgBar.cfg
The message bar configuration file (
See, Message Bar Configuration on page 28
).
login.cfg
The login screen configuration file (
See, Login Screen Configuration on page 28
).
status.cfg
The status window configuration file (
See, Status Window Configuration on page 28
xxxxxx.cfg
One or more feature window confi guration fil es (
on page 29
Page 16 NDA-30080 Revision 1.0
).
See, Feature Window Conf igurati on
).
Sentry Installation Guide Sentry Alarm Control Terminal

Data Buffer Configuration File

The data buffer configuration file, “db.cfg”, contains constants and data buffer field definitions. Data buffers are used to store fields of ASCII character information contained in messages or read from a ter minal. The fields withi n a data buffer may be used to build configurable display strings.
The data buffer configuration file contains field definitions consisting of a field symbol, the number of characters in the field, and the offset of the field (offsets start with 0). Data buffer configurations will not require modifications unless the Sentry Alarm Control Te rminal appli cation is cha nged. The foll owing data buf fers are defined below.
Dynamic Window Area Configuration
The dynamic window area is the portion of the screen that is used to display dynamic windows. Usually, this area is located be tween the title and mes sage bars. The following constants define the dynamic window area:
DYNAMIC_START
The screen positi on of the first row of the dynamic windo w area (row 0 = the first row of the screen, row 23 = the last row of the screen).
DYNAMIC_END
The screen position of the last row of the dynamic window.
Feature Window Sorting Methods
Each feature window can have a unique sor ting method which controls the or der of stations in the window. (See, Feature Window Configuration on page 29.) The sorting method is selected from one of the following:
SORT_NONE
Stations are not sorted.
SORT_BY_TIME
Stations are sorted b y event time, with the newest events at the top of the window and the oldest events at the bottom.
Feature Window Filtering Methods
Each feature window can have a unique filtering method which limits station updates to a pa rt ic ula r class of station includin g c al le r, oper at or, and source. (See,
Feature Window Configuration on page 29.)
The filtering method is selected from one of the following:
PASS_CALLER
Stations are not sorted.
PASS_OP
Stations with a clas sificat ion of oper ator are passed. Al l other st ations a re ignore d.
PASS_SRC
Stations with a classification of source are passed. All other stations are ignored.
NDA-30080 Revision 1.0 Page 17
Sentry Alarm Control Terminal Sentry Installation Guide
PASS_OP_CALLER
Stations with a c lassificati on of operato r or caller are passed . All other s tations are ignored.
PASS_SRC_CALLER
Stations with a classification of source or caller are passed. All other stations are ignored.
PASS_SRC_OP
Stations with a classification of source or operator are passed. All other stations are ignored.
PASS_ALL
All stations are passed.
Login Screen User Name and Password Data Buffer Configuration
The user name and p assword data buffer is used b y t he login screen to contain the user name and password. It contains the following fields.
U_NAME The user na me field. U_PASSWORD The user passw ord field.
Feature Title Data Buffer Configuration
The feature title data buffer is used to build a feature title string. It contains the following fields:
FEAT_TITLE The feature title field.
Feature Statistics Data Buffer Configuration
The feature statistics data buffer contains feature stati stics. The following fields are defined:
FEAT_NAME The feature name field. FEAT_EXT The feature monitored number extension field. FEAT_RING The ringing caller count field. FEAT_ANS The answered caller count field. FEAT_REL The released caller count field. FEAT_QUEUED The queued caller count field. FEAT_ABANDON The abandoned caller count field. FEAT_ACTIVE The active caller count field. FEAT_IDLE The idle caller count field. FEAT_TOTAL The total caller count field. FEAT_RECORD The recording flag field. FEAT_OFFLINE The monitor off line flag field.
Page 18 NDA-30080 Revision 1.0
Sentry Installation Guide Sentry Alarm Control Terminal
Clock and Caller Information Data Buffer Configuration
The clock and caller information data buffer contains date and time fields which may be used to create date and time dis play strings. The optiona l caller status fiel ds (along with the date and time fi elds) are used to display ca ller status. The following fields are defined:
MONTH_NUM
MONTH_ABRV MONTH_FULL DAY_NUM WEEK_DAY_ABRV WEEK_DAY_FULL YEAR_ABRV
YEAR_FULL HOURS_24
HOURS_12 MINUTES SECONDS
The numeric month (1...12, where 1 = January, 2 = February, etc.)
The three character month name (Jan, Feb, etc.). The full month name (January, February, etc.) The numeric date (1...31). The three character week day (Mon, Tue, etc.). The full week day (Monday, Tuesday, etc.). The last two digits of the current year (95 for 1995, 96
for 1996, etc.) The full current year (1995, 1996, etc.). The 24 hour v al ue (0. ..23 , wh ere 0 = midnight, 1...11
= 1:00 AM to 11:00 AM, 12 = noon, and 13...23 = 1:00 PM to 11:0 0 PM).
The 12 hour value (1...12). The minutes value (0...59). The seconds value (0...59).
AM_PM CALLER_ROW CALLER_EXT CALLER_LOC CALLER_STAT
CALLER_CLASS CALLER_CONNECT
NDA-30080 Revision 1.0 Page 19
The AM/PM string (“AM” or “PM”). The caller window row. The caller’s extension. The location of the caller’s extension. The caller’s status (“Released”, “Ringing”,
“Answered”, “Queued”, or “Abandoned”). The caller’s class (“Operator”, “Caller”, or “Source”). Contains the extension of the party connected to the
caller. This data is a vailable for Anno yance Trap calls only
Sentry Alarm Control Terminal Sentry Installation Guide
Function Key Assignments Data Buffer Configuration
The function key assignments data buffer contains the function key assignment descriptions which are display ed in the function key h elp dial og (see Function K e y
Help Dialog Configuration on page 25). A function key assignment descri pt ion
field corresponding to the respective function key may be defined in the function key assignment data buffer. The following function key assignment description fields and the corresponding function keys are defined below.
F1_DESC F1 F2_DESC F2 F3_DESC F3 F4_DESC F4 F5_DESC F5 F6_DESC F6 F7_DESC F7 F8_DESC F8 F9_DESC F9 F10_DESC F10 F11_DESC F11 F12_DESC F12 SHIFT_F1_DESC Shift-F1 SHIFT_F2_DESC Shift-F2 SHIFT_F3_DESC Shift-F3 SHIFT_F4_DESC Shift-F4 SHIFT_F5_DESC Shift-F5 SHIFT_F6_DESC Shift-F6 SHIFT_F7_DESC Shift-F7 SHIFT_F8_DESC Shift-F8 SHIFT_F9_DESC Shift-F9 SHIFT_F10_DESC Shift-F10 SHIFT_F11_DESC Shift-F11 SHIFT_F12_DESC Shift-F12
Title Bar Terminal Name Data Buffer Configuration
The title bar ter mina l name data buffer contains the tt y terminal name used by the title bar window (s ee T itle Bar Conf iguration on page 27). It conta ins the foll owing fields:
TITLE_TERM The tt y terminal name field.
Page 20 NDA-30080 Revision 1.0
