1 Welcome to the World of GUITAR RIG 4!
GUITAR RIG KONTROL EDITION
The stage-ready RIG KONTROL foot pedal integrates seamlessly with the GUITAR RIG 4
software and provides studio-quality sound with its built-in audio interface. It is designed
and optimized for GUITAR RIG 4, but as it complies with industry standards and features
full MIDI support, it works perfectly with most professional audio software.
The RIG KONTROL connects to your computer via high-speed USB 2.0, which also provides
its power supply. It features two inputs, suited either for instrument or line level signals.
A two-channel line-out connects to your monitoring system, and a stereo jack allows for
headphone monitoring at an independent volume.
As a controller, the RIG KONTROL offers 9 switches and a pedal, giving you control over
almost all of GUITAR RIG 4’s functions. Moreover, it features MIDI connections as well as
two analogue inputs to connect external controllers.
In the following chapters you will learn more about the
best use of it. Please read this manual carefully in order to get acquainted with the product.
is the complete solution for guitar and bass players.
RIG KONTROL
and how to make the
GUITAR RIG KONTROL Hardware Reference – 7
2 Before you Start – Important Notes
First things rst; before using GUITAR RIG 4, it is advised that you read this chapter carefully.
2.1 Serial Numbers & Nameplate
GUITAR RIG KONTROL EDITION comes with two serial numbers. The RIG KONTROL
serial number can be found on the bottom of the hardware, along with the nameplate listing
the product model name and other technical information. The serial number for activating
GUITAR RIG 4 is located on the sleeve of the product CD.
2.2 Using the Unit Safely
Please read the following instructions thoroughly to prevent from health risks and
damaging the product.
2.2.1 Warning
To prevent hearing damage, always follow these important security advices:
►
This Product, in combination with an amplier, headphones or speakers, can produce
sounds in decibel ranges that may cause hearing damage.
►
For protection, set all volume levels to a minimum before using the
Gradually raise the volume controls while music is playing to set the desired
listening level.
►
Do not operate it at high volume levels for long periods. If you experience any hearing
problems or ringing in the ears, consult an audiologist immediately.
RIG KONTROL
.
GUITAR RIG KONTROL Hardware Reference – 8
2.2.2 Caution
To make sure that the
usage or maintenance, it is important that you follow these instructions:
►
Do not open the device or attempt to disassemble or modify the internal parts. The
device contains no user-serviceable parts. If it appears to be malfunctioning,
discontinue use immediately and have it inspected by qualied service personnel.
RIG KONTROL
or any device connected is not damaged during
► Do not expose the unit to rain, use it near water or in damp or wet conditions.
► Do not allow any objects or liquids of any kind to penetrate the unit.
►
Never use or store the unit in areas that are subject to temperature extremes (e.g.
direct sunlight in an enclosed vehicle or near heat-generating equipment) or high
levels of vibration.
►
Do not place the
could accidentally fall. Remove all connected cables before moving the unit.
►
Before turning the power on or off for any component, set all volume levels to their minimum.
RIG KONTROL
in an unstable position where it is possible the unit
► Do not use excessive force on the knobs or connectors.
►
When cleaning the
solvents, cleaning uids or chemical-impregnated wiping cloths.
RIG KONTROL
, use a soft, dry cloth. Never use paint thinners,
2.2.3 Disposal Notice
Should this product become damaged beyond repair, or if you wish to dispose it, please observe
the regulations of your area and country that relate to the disposal of electronic products.
2.3 Disclaimer
Native Instruments GmbH cannot be held responsible for damage or lost or destroyed data
caused by improper use or modication to the RIG KONTROL.
The information contained in this manual is believed to be correct at the time of printing
or digital release. However, Native Instruments reserves the right to make changes to the
specications at any time without notice or obligation to update existing units.
GUITAR RIG KONTROL Hardware Reference – 9
3 The RIG KONTROL Hardware
This section will give you an overview of the RIG KONTROL hardware.
3.1 Top Panel
1 The footswitches can be assigned in the software to perform tasks such as stepping
through presets, or turning individual components on and off. Each switch has an LED
to indicate whether it is activated. The top row is labeled with the most frequently used
functions of GUITAR RIG 4, matching their pre-congured assignments.
2
The expression pedal can be used to control any continuous parameter of the
software, such as volume or wah-wah. There is an additional freely assignable switch
underneath the tip of the pedal.
3 Shows the number of the currently activated GUITAR RIG 4 preset.
4
This LED-Meter shows the level of the audio signal at the input. The red LEDs indicate
clipping and should never light up. Turn the according input gain down if it does.
GUITAR RIG KONTROL Hardware Reference – 10
5
This LED-Meter shows the level of the audio signal at the output. The red LEDs
indicate clipping and should never light up. Turn the output level down if it does.
6
This LED indicates that the
or from another controller.
7 This LED shows whether the switch underneath the pedal is activated.
RIG KONTROL
is receiving MIDI signals from a sequencer
3.2 Rear Panel
1
The Inst/Line switch sets the input sensitivity for Input 1 and 2. When depressed,
the inputs will handle instrument signals such as a guitar or bass, when pressed, line
level signals are accepted. The selected input type is also indicated on the unit’s top.
2 This knob controls the gain of Input 1.
3
The socket for Input 1 (¼” jack, TRS balanced) will accept line level or instrument
level signals, depending on the position of the Line/Inst switch. Connect a guitar, bass
guitar, keyboard or the left channel of a stereo device.
4
The socket for Input 2 (¼” jack, TRS balanced) will accept line level or instrument
level signals, depending on the position of the Line/Inst switch. Connect a second
guitar, bass guitar, keyboard or the right channel of a stereo device.
5 This knob controls the gain of Input 2.
6
These jacks transmit the processed output from the audio interface. Connect both
for stereo sound.
GUITAR RIG KONTROL Hardware Reference – 11
7 The output amplication can be set to full or –14dB.
8 Separately controls the volume of the headphones output.
9 For connecting stereo headphones.
10
For connecting external expression pedals, footswitches, volume pedals or switchboxes.
11
The RIG KONTROL features a MIDI interface with 1 input and 1 output. The RIG
KONTROL does not require MIDI to send controller messages to GUITAR RIG 4, but
it is able to send MIDI signals to other applications.
12 The USB port connects the unit to your computer. Your computer must support USB
2.0 in order to work with GUITAR RIG SESSION I/O. The unit also relies on the USB
bus power to function. Connect this unit directly to your computer’s USB 2.0 port
and avoid using un-powered USB hubs. You should always secure the USB cable by
wrapping it around the USB Hook.
GUITAR RIG KONTROL Hardware Reference – 12
4 Installation under Windows XP / Windows Vista
This chapter describes the installation of the RIG KONTROL hardware under Windows
XP and Windows Vista, focusing on the setup of the audio interface. To activate the foot
pedal as a controller in GUITAR RIG 4 and to use its MIDI capabilities, please refer to
section 6 of this manual.
For detailed information about the
Reference. You can nd this on the product CD or in the
> Open Manual > Your Language.
GUITAR RIG 4
software, please consult the Application
GUITAR RIG 4
menu under Help
4.1 Software Installation
Make sure you are logged in with administrator privileges. Don’t connect the RIG KONTROL yet.
1.
Browse the content of the product CD and locate the setup le. It is called “Guitar Rig
4 Setup”. If you are using a download version of GUITAR RIG 4, you need to extract
the setup les rst.
2.
Double-click “Guitar Rig 4 Setup” to start the installation procedure.
GUITAR RIG KONTROL Hardware Reference – 13
3.
Follow the on-screen instructions, which will guide you through the installation procedure.
4. You will be asked to specify the path to the plug-in folder of your DAW (Digital Audio
Workstation, e.g. your sequencer software). If you will use
GUITAR RIG 4
exclusively in
standalone mode, or if you don’t know what a plug-in is, just use the standard setting.
5.
You will be asked if you want to install drivers for the
GUITAR RIG
audio interfaces.
Select “RIG KONTROL” and click on “Continue”.
6.
During installation of the driver, several Windows security messages will
show up, e.g. “The driver has not passed the Windows Logo Test” or
“Windows can’t verify the publisher of this driver software”. Don’t worry,
everything is ne here. Simply click “Continue anyway” (Windows XP) or “Install
this driver software anyway” (Windows Vista) to continue the installation.
7. Restart your computer upon completion.
GUITAR RIG KONTROL Hardware Reference – 14
The following applications have been placed onto your hard drive:
► GUITAR RIG 4 – the fully featured standalone application.
►
GUITAR RIG 4 plug-ins – Use GUITAR RIG 4 as a plug-in for your Digital Audio
Workstation (DAW) of choice. On Windows computers, GUITAR RIG 4 supports the
VST and RTAS® plug-in formats.
►
Native Instruments Service Center – this application handles product activation as well
as update management. Please refer to the Setup Guide for details.
► The drivers for the RIG KONTROL.
In case you want to install the hardware drivers only, a separate driver installer le is
available on the installation CD. You can also download its latest version from the Support
section of the Native Instruments website.
4.2 Hardware Installation
Use the supplied USB cable to connect the RIG KONTROL directly to a USB 2.0 port on
your computer.
GUITAR RIG KONTROL Hardware Reference – 15
The
RIG KONTROL
is powered via USB. Operation is guaranteed only with a USB 2.0
controller as a single device or with self-powered USB 2.0 hubs. On Windows XP systems,
Service Pack 2 or higher is required for the
RIG KONTROL
to work – you can nd out
about your Windows version in the System Properties window.
After successfully installing the driver, the
RIG KONTROL
will be recognized automatically.
If not, start the software installation again as explained above.
GUITAR RIG KONTROL Hardware Reference – 16
Several driver modules will be assigned to the
RIG KONTROL
now, each one causing a
pop-up window in which you are asked how you want to install the new device.
1. Choose not to connect to the “Windows Update Web site”.
2.
Choose “Install the software automatically” (Windows XP) or “Locate and install driver
software” (Windows Vista).
3. Follow the on-screen instructions to complete the procedure.
4.
The Windows security warnings will appear. Please ignore them and click “Continue
anyway” (Windows XP) or “Install this driver software anyway” (Windows Vista) to
properly install the drivers.
On a Windows computer, the driver is associated with a particular USB port. If you plug
the USB cable into a different port than the one it was installed at, the driver assignment
process starts again – if this happens, just follow the steps described above.
If at any time the computer does not seem to recognize the RIG KONTROL, disconnect
the USB cable, wait a few seconds, then re-connect it. If the problem remains, restart
your computer with the interface connected.
GUITAR RIG KONTROL Hardware Reference – 17
4.3 Conguration
This chapter explains how to use the RIG KONTROL audio interface with Windows XP /
Windows Vista and particularly with
activated
help on this process.
GUITAR RIG 4
using the Service Center – please refer to the Setup Guide for
GUITAR RIG 4
. It is assumed that you have already
4.3.1 Conguring GUITAR RIG 4
We will now set up
software before you proceed.
When the software is started for the rst time, you will be prompted with the Audio Setup
window automatically, where you need to make the following settings. To access these
settings later on, select File > Audio and MIDI Settings from the program menu.
GUITAR RIG 4
to use the
RIG KONTROL
audio interface. Start the
1. On the “Audio” tab, choose ASIO as the “Driver” interface.
2. Select RIG KONTROL from the “Device” dropdown menu.
If RIG KONTROL does not appear in the list, something went wrong. Restart the
installation as explained in section 4.1.
GUITAR RIG KONTROL Hardware Reference – 18
You can access the Driver Control Panel by clicking on “ASIO Cong”. In the Driver Control
Panel, two status elds on the bottom show whether the RIG KONTROL hardware is
connected and ready to use.
The audio interface allows to be congured by the following parameters:
►
Presets: Several presets for common types of usage are included, from minimal
latency suitable for fast systems with strong CPU power, to higher latencies suitable
for slower systems. If you are experienced in setting up audio drivers and want to
create your own custom settings, select User Dened Settings (see next).
►
UsB BUffersize and aUdio BUffersize: These parameters are grayed out, unless you have
selected User Dened Settings from the Presets Menu. Together, they dene the
system’s latency, i.e. the time that passes from the moment an audio signal is sent
into the
your speakers. The value for Audio Buffersize must always be at least twice as large
as the USB Buffersize value. Note that the USB Buffersize parameter has a direct
impact on the CPU usage of the system. The resulting CPU usage differs between
computers, so it could make sense to experiment with different settings.
RIG KONTROL
hardware until the moment you hear it in your headphones or
GUITAR RIG KONTROL Hardware Reference – 19
►
s
amPle rate
: Choose a sample rate that is compatible with your music application and
suited to your computing power. Per default, the sample rate is set to 44100 Hz
(CD-Quality). Higher sample rates may improve sound quality, but will cause a higher
CPU load as well.
It is recommended that you try the latency presets rst and then continue with the
subsequent steps of the installation. Once you are nished, you should revisit the Audio
and MIDI Settings to gure out the best latency setting for your system. If audio dropouts
occur with the preset minimal latency, you can try the low latency or standard latency set-
tings instead. Higher latency values will reduce the probability of audio dropouts.
4.3.2 Using the RIG KONTROL as your Default Audio Interface
If you want to use the RIG KONTROL for playback of all audio applications on your
computer (not only for music software), you have to set it as your default audio interface.
For Windows XP, this works as follows:
1. Open Start > Control Panel > Sounds and Audio Devices.
2. Select the “Audio” tab.
3.
In the “Sound playback” and “Sound recording” sections, click on the Default Device
menu, and then select RIG KONTROL.
4. Click OK to close the “Sounds and Audio Devices” dialog.
GUITAR RIG KONTROL Hardware Reference – 20
For Windows Vista, this works as follows:
1. Open Start > Control Panel > Hardware and Sound > Sound.
2. Select the “Playback” tab.
3. In the device list, select RIG KONTROL and click on “Set Default.”
4. Select the “Recording” tab.
5. In the device list, select RIG KONTROL and click on “Set Default.”
6. Click ok to close the dialog.
GUITAR RIG KONTROL Hardware Reference – 21
4.4 Audio Connections and Levels
In the following chapters you will learn how to connect your guitar and your monitoring
system to the RIG KONTROL and how to set the right amplication levels both on the
hardware and on the software side of your setup.
Please start GUITAR RIG 4 before proceeding.
4.4.1 Connecting your Instrument and Adjusting the Input Level
1. Turn down the volume on your monitoring system to prevent hearing damages.
2. Make sure the input selector is set to “Instrument” (button not depressed) except if
you are using a preamp to boost your signal to line level.
3.
Plug the cable connected to your guitar or bass into one of the input jacks of the
RIG KONTROL.
4. Completely turn down the volume of the input channel you are not using.
Keep in mind that for an instrument that generates a stereo signal, such as a synthesizer
keyboard, you need to connect it to both input channels for stereo sound.
In order to achieve the best sound quality by providing the interface with a sufciently
powerful signal, you need to carefully adjust the input level of the RIG KONTROL.
GUITAR RIG KONTROL Hardware Reference – 22
The Input Level Meter helps you identify the level of the incoming signal:
Meter Status Meaning
All LEDs are off No incoming signal
Green LEDs ashing Incoming signal
Green and red LEDs ashing Incoming signal is too loud
Before adjusting the input sensitivity, turn up the volume knob on your guitar. Strum some
chords at the volume level you are typically playing at and look at the Input Level Meter:
1.
Turn up the input level knob next to the input jack you chose, just until the meter
is reaching the red zone when you play.
2. At that point, slightly turn the knob down until you are safely in the green zone, even
when you are playing really powerful chords.
Now the input sensitivity is set to its optimum level, enabling the RIG KONTROL to provide
the highest dynamical range without clipping.
4.4.2 Connecting a Second Instrument
You can connect different instruments to both input channels, as long as they both provide
a signal at the same level (line or instrument). Just plug the cable of your second instrument
into the other input jack and set the right input level as described in the previous section.
For instruments generating a stereo signal, the second channel needs to be connected
for stereo sound.
If only one channel is used, set
%
to zero.
the other channel’s G
ain
knob
GUITAR RIG KONTROL Hardware Reference – 23
4.4.3 The Input Level of GUITAR RIG 4
It is assumed that your guitar is connected to the
properly adjusted (see section 4.4.1). Now you need to make sure that the input signal
is processed at the right level by the software.
Please take a look at the header of the GUITAR RIG 4 window: It consists of the input
module with channel selectors (l/r), a basic noise gate, the output module with a limiter
and information about the processing power consumed.
Note that the Input Meter shows an amplitude when you are playing. It also features an
integrated volume fader that controls the input level of the software. Please adjust it to
achieve the highest possible level for your signal without clipping. This is indicated by the
Level Meter getting close to the red zone without actually hitting it.
If only one guitar is connected, GUITAR RIG 4 will receive a mono signal. You can set up
the Input module to route your guitar signal to both channels. Per default, GUITAR RIG 4
is set to process both input channels (l + r are activated), so one of the input
RIG KONTROL
and its input level is
channels remains mute. To change this, deactivate the channel you are not using: Click on the
appropriate button (l or r) on the left hand side of the Input Meter once, so that only the
input channel in use is active. This will route the mono signal to both channels.
GUITAR RIG KONTROL Hardware Reference – 24
4.4.4 Connecting the Output
The RIG KONTROL provides two mono outputs (L/R) to connect your monitoring system,
be it a mixing desk, a pair of active speakers or your home stereo. Mind that both of
them have to be connected for stereo sound. A separate stereo output (TRS) allows for
connecting your headphones.
1.
Connect the output jacks to the input of your amp with its volume level turned down.
2. If you are using headphones, connect them to the output jack and put them on with
the headphone level fully turned down.
3. Go to the Preset Browser and select one of the presets by clicking on it.
4. Start playing and carefully turn up the volume of your amp or the headphone level of
the RIG KONTROL to the desired level.
You should be all set now, and ready to rock!
GUITAR RIG KONTROL Hardware Reference – 25
5 Installation under Mac OS X
This chapter describes the basic installation of the
X, focusing on the setup of the audio interface. To activate the foot pedal as a controller
in
GUITAR RIG 4
For detailed information about the
Reference. You can nd it on the product CD or in the GUITAR RIG 4 menu under Help
> Open Manual > Your Language.
and to use its MIDI capabilities, please refer to section 6 of this manual.
GUITAR RIG 4
RIG KONTROL
software, please consult the Application
hardware under Mac OS
5.1 Software Installation
Make sure you are logged in with administrator privileges. Don’t connect the RIG KONTROL yet.
1.
Browse the content of the product CD and locate the le “Guitar Rig 4 Installer”. If
you are using a download version of GUITAR RIG 4, you need to extract the installer
le rst.
2.
Double -click the installer file to sta rt the installation pr ocedure.
GUITAR RIG KONTROL Hardware Reference – 26
3.
Follow the on-screen instructions that will guide you through the installation procedure.
4.
You will be asked if you want to install drivers for the
Select “RIG KONTROL” and click on “Continue”.
5. Restart your computer upon completion.
The following applications will be placed onto your hard drive:
GUITAR RIG
audio interfaces.
► GUITAR RIG 4 – the fully featured standalone application.
►
GUITAR RIG 4 plug-ins – use GUITAR RIG 4 as a plug-in for your digital audio
workstation (DAW) of choice. On computers running Mac OS X, the VST, AU and
RTAS® plug-in formats are supported.
►
Native Instruments Service Center – this application handles product activation as well
as update management. Please refer to the Setup Guide for details.
► The drivers for the RIG KONTROL audio interface.
In case you want to install the hardware drivers only, a separate driver installer le is
available on the installation CD. You can also download its latest version from the Support
section of the Native Instruments website.3
If you have never owned a
%
uct, you will need to register by following
the on-screen instructions. More information about creating a NI User Account
and about activating GUITAR RIG XE is
available in the Service Center Quick
Start Guide and manual located in the
Service Center installation folder.
NATIVE INSTRUMENTS prod-
GUITAR RIG KONTROL Hardware Reference – 27
5.2 Hardware Installation
Use the supplied USB cable to connect the
on your computer.
The
RIG KONTROL
controller as a single device or with self-powered USB 2.0 hubs.
After successfully installing the driver, the RIG KONTROL should be recognized
automatically. If at any time the computer does not seem to recognize the RIG KONTROL,
is powered via USB. Operation is guaranteed only with a USB 2.0
RIG KONTROL
directly to a USB 2.0 port
disconnect the USB cable, wait a few seconds, then re-connect it. If this does not solve
the problem, restart your computer with the interface connected.
5.3 Conguration
This chapter explains how to use the
ticularly with the included
RIG 4 using the Service Center – please refer to the Setup Guide for help on this process.
GUITAR RIG 4
RIG KONTROL
. It is assumed that you have already activated
audio interface under Mac OS X and par-
GUITAR
GUITAR RIG KONTROL Hardware Reference – 28
5.3.1 Conguring GUITAR RIG 4
We will now set up GUITAR RIG 4 to use the RIG KONTROL audio interface. Start
the software before you proceed.
1.
When the software is started for the rst time, you will be prompted with the Audio
Setup window automatically, where you need to make the following settings. If you want
to access these settings later, select Guitar Rig 4 > Preferences from the program menu.
2. On the Audio tab, choose CoreAudio as the “Driver” interface.
3. Select RIG KONTROL from the “Device” dropdown menu.
If
RIG KONTROL
wrong. Restart the installation as explained in section 5.1.
does not appear in the list even though it is connected, something went
GUITAR RIG KONTROL Hardware Reference – 29
The audio interface allows to be congured by the following parameters:
►
s
amPle rate
: Choose a sample rate that is compatible with your music application and
suited to your computing power. Per default, the sample rate is set to 44100 Hz
(CD-Quality). Higher sample rates may improve sound quality, but cause a higher CPU
load as well.
►
latency: Use the Latency slider to set the buffer size of the audio interface, measured
in samples. The buffer size has two effects: The higher it is set, the lower is the
probability of dropouts during real-time audio processing. On the other hand, the size
of the buffer directly affects the overall latency of your system. The time between the
moment you hit a note and the moment you hear the processed sound will be longer
if the buffer size is increased.
It is recommended that you start with the default buffer size and continue with the
subsequent steps of the installation. Once you are nished, you should load a clean
preset and revisit the Audio and MIDI Settings to gure out the best latency setting for your
system. This is done by gradually reducing the buffer size: Drag the latency slider to the
left while playing something. Once you begin to hear crackles or dropouts, carefully drag
the latency slider to the right until you reach the point where no crackles or dropouts occur.
GUITAR RIG KONTROL Hardware Reference – 30
5.3.2 Using RIG KONTROL as your Default Audio Interface
If you want to use the RIG KONTROL for all audio playback (not only for music software),
you have to set it as your default audio interface. For Mac OS X, this works as follows:
1. From the Apple menu, select System Preferences.
2. In the panel that opens, click on “Sound”.
3.
On the Sound Effects tab, select RIG KONTROL in the “Play alerts and sound effects
through” menu.
4.
Click on the Output tab, and then select RIG KONTROL from the “Choose a device
for sound output” list.
5.
Click on the Input tab, and then select RIG KONTROL from the “Choose a device
for sound input” list.
GUITAR RIG KONTROL Hardware Reference – 31
5.4 Audio Connections and Levels
In the following chapters you will learn how to connect your guitar and your monitoring
system to the RIG KONTROL and how to set the right amplication levels both on the
hardware and on the software side of your setup.
Please start GUITAR RIG 4 before you proceed.
5.4.1 Connecting your Instrument and Adjusting the Input Level
1. Turn down the volume on your monitoring system to prevent hearing damages.
2. Make sure the input selector is set to “Instrument” (button not depressed) except if
you are using a preamp to boost your signal to line level.
3.
Plug the cable connected to your guitar or bass into one of the input jacks of the
RIG KONTROL.
4. Completely turn down the volume of the input channel you are not using.
Keep in mind that for an instrument that generates a stereo signal, such as a synthesizer
keyboard, you need to connect it to both input channels for stereo sound.
In order to achieve the best sound quality by providing the interface with a sufciently
powerful signal, you need to carefully adjust the input level of the RIG KONTROL.
GUITAR RIG KONTROL Hardware Reference – 32
The Input Level Meter helps identifying the level of the incoming signal:
LED Status Meaning
All LEDs are off No incoming signal
Green LEDs ashing Incoming signal
Green and red LEDs ashing Incoming signal is too loud
Before adjusting the input sensitivity, turn up the volume knob on your guitar. Strum some
chords at the volume level you are typically playing at and look at the Input Level Meter:
1. Turn up the input level knob next to the input jack you chose, just until the meter is
reaching the red zone when you play.
2. At that point, slightly turn the knob down until you are safely in the green zone, even
when you are playing really powerful chords.
Now the input sensitivity is set to its optimum level, enabling the RIG KONTROL to provide
the highest dynamical range without clipping.
5.4.2 Connecting a Second Instrument
You can connect different instruments to both input channels, as long as they both provide
a signal at the same level (line or instrument). Just plug the cable of your second instrument
into the other input jack and set the right input level as described in the previous section.
For instruments generating a stereo signal, the second channel needs to be connected
for stereo sound.
If only one channel is used, set
%
to zero.
the other channel’s G
ain
knob
GUITAR RIG KONTROL Hardware Reference – 33
5.4.3 The Input Level of GUITAR RIG 4
It is assumed that your guitar is connected to the
properly adjusted (see section 4.4.1). Now we need to make sure that the input signal
is processed at the right level by the software.
Please take a look at the header of the
module with channel selectors (l/r), a basic noise gate, the output module with a limiter
and information about the processing power consumed.
Note that the Input Meter shows an amplitude when you play. It also features an integrated
volume fader that controls the input level of the software. Please adjust it to achieve the
highest possible level for your signal without clipping. This is indicated by the Level Meter
getting close to the red zone without actually hitting it.
If only one guitar is connected, GUITAR RIG 4 will receive a mono signal. You can set up
the Input module to route your guitar signal to both channels. Per default, GUITAR RIG 4
is set to process both input channels (l + r are activated), so one of the input
GUITAR RIG 4
RIG KONTROL
window: It consists of the input
and its input level is
channels remains mute. To change this, deactivate the channel you are not using: Click on the
appropriate button (l or r) on the left hand side of the Input Meter once, so that only the
input channel in use is active. This will route the mono signal to both channels.
GUITAR RIG KONTROL Hardware Reference – 34
5.4.4 Connecting the Output
The RIG KONTROL provides two mono outputs (L/R) to connect your monitoring system,
be it a mixing desk, a pair of active speakers or your home stereo. Mind that both of
them have to be connected for stereo sound. A separate stereo output (TRS) allows for
connecting your headphones.
1.
Connect the output jacks to the input of your amp with its volume level completely
turned down.
2. If you are using headphones, connect them to the Phones output jack and put them
on with the headphone level fully turned down.
3.
Go to the Preset Browser and select any of the presets by clicking on it. Start
playing and carefully turn up the volume of your amp or the headphone level of the
RIG KONTROL to the desired level.
You should be all set now, and ready to rock!
GUITAR RIG KONTROL Hardware Reference – 35
6 Using the RIG KONTROL as a Controller Interface
The
RIG KONTROL
a hardware controller. Aside from the built-in controller features, it offers MIDI connections
and two jacks for external footswitches and pedals. The following sections explain how to set
up the hardware to fully exploit these features. To learn how to assign functions of GUITAR
enhances your experience using
GUITAR RIG 4
by integrating perfectly as
RIG 4
To use the
CONTROLLER EDITOR software. Please refer to the Controller Editor Manual for details.
to controller inputs, refer to the Getting Started Guide and the Application Reference.
RIG KONTROL
as a standard MIDI controller, you have to use the included
6.1 Activating the RIG KONTROL in GUITAR RIG 4
The
RIG KONTROL
connected. The rst time it is activated, a window will pop up asking you to calibrate the
foot pedal. Please press the pedal all the way up and down and conrm by clicking on
ok. To recalibrate the pedal at any time, go to the o
Click on the Reset button next to “RIG KONTROL Pedal Calibration”.
The
RIG KONTROL
after clicking on the VirtUal kontrol button above the rack.
is activated automatically in
hardware has a graphical counterpart in
GUITAR RIG 4
Ptions
when the hardware is
page and select P
GUITAR RIG 4
which is shown
references
.
If you are running multiple instances of GUITAR RIG 4 (e.g. in a sequencer), you may want
to dene which of them is controlled by the foot pedal. By default, the RIG KONTROL is
activated in the instance of GUITAR RIG 4 you launched rst. By clicking on the connect
button on the VirtUal kontrol in another instance, it gets the focus of the RIG KONTROL
– only one instance can have it at a time!
Some functions are assigned to the footswitches 5-8 by default, as indicated by text
labels on the hardware. You can instantly step through the presets currently visible in the
browser with switches 5 (PREV) and 6 (NEXT). Switches 7 and 8 are for activating the
tuner and tapping in a tempo with your foot. These buttons can of course be re-assigned
to other functions as you please.
GUITAR RIG KONTROL Hardware Reference – 36
The easiest way to assign a button or the pedal of the
the rack is to drag it from the VirtUal kontrol and drop it on the parameter you want to
control. For a detailed description of the way controller assignments work, please refer to
the Getting Started Guide and the Application Reference.
RIG KONTROL
to any function in
6.2 Using MIDI Controllers with the RIG KONTROL MIDI Interface
While being capable of sending MIDI messages to control other applications, the
KONTROL communicates with GUITAR RIG 4 directly via USB. Nonetheless, it features a
standard MIDI interface with one input and output channel.
To use a controller connected to the MIDI input jack, make sure that the RIG KONTROL
MIDI channel is activated in GUITAR RIG 4:
1.
Open the “Audio and MIDI Settings”. On Windows, they are found in the “File” menu,
under Mac OS in the “Guitar Rig 4” menu.
2. Go to the MIDI tab.
3.
On the “Inputs” table, locate “RIG KONTROL” and switch it on by clicking in
the “Status” column.
The MIDI input channel is set on the oPtions pane of GUITAR RIG 4: On the controllers
tab, click on the dropdown menu labeled “MIDI channel” and select 1-16 or omni. To learn
how to assign functions to external MIDI controllers, refer to the Getting Started Guide
and the Application Reference.
RIG
GUITAR RIG KONTROL Hardware Reference – 37
6.3 Using Additional Footswitches and Pedals
The RIG KONTROL features two jacks for connecting external footswitches and pedals with a
¼” patch cable. Once connected and set up, they can be assigned just like MIDI controllers in
GUITAR RIG 4. Refer to the Getting Started Guide and the Application Reference to see how.
Under P
references
on the o
Ptions
page of
GUITAR RIG 4
, the following settings are available:
► To calibrate an external pedal, click on the Reset button next to “RIG KONTROL Ext
Pedals Calibration.”
►
The two lines “RIG KONTROL Ext Pedal 1/2 Mode” allow to congure each both
inputs to match your external footswitch or pedal. Consult the manufacturer’s product
specications to nd out if it is a tip or ring active pedal, or respectively, if it is an
opening or a closing switch. If problems occur, try out the other available modes.
►
The “External Switch Mode” determines the behavior of external footswitches. Either
they are “on” while pressed (Toggle) or they switch between “on” and “off” each time
they are pressed (Switch).
GUITAR RIG KONTROL Hardware Reference – 38
7 Troubleshooting
Should you encounter any problems with your hardware, it is recommended that you
follow these steps to nd a solution to your problem before contacting Technical Support:
►
Visit NI’s online Knowledgebase. The easiest way to nd it is by selecting Help >
Knowledgebase from the GUITAR RIG 4 menu.
►
Visit the NI User Forum on our website (native-instruments.com/forum/) and perform
a search for helpful answers from the GUITAR RIG user community.
When contacting Technical Support, please make sure to have all relevant information
about your computer at hand. For information about the driver’s version and the rmware
revision, please check the Driver Control Panel.
► On Windows computers you can nd driver and rmware version in the GUITAR RIG 4
application folder in the Start menu. Click on “About” to display the information desired.
►
On Mac OS X computers, you can access the Driver Control Panel from the system
preferences. The information is shown in the main window.
Please visit this URL to contact the support team:
native-instruments.com/support/
All products by Native Instruments are tested extensively in real life situations during the
development phase. However, if your product needs to be returned, the Technical Support
team will assign you an RA (Return Authorization) number to expedite the processing
of your return. Please contact our Technical Support team prior to returning any item.
Packages returned without this RA number will not be correctly identied and as such
might not be processed efciently.
GUITAR RIG KONTROL Hardware Reference – 39
7.1 Audio Issues
This section provides help with the most common audio issues you may encounter.
7.1.1 No Sound or Low Volume
There are several possible reasons for a silent or low audio output:
► Disconnected or broken cables. Please check all connections and cables.
►
Incorrect soundcard or audio input selected. Please check the Audio and MIDI Settings
in the GUITAR RIG 4 menu if the RIG KONTROL driver is selected.
►
Wrong channel selected in the Input Module of GUITAR RIG 4. Either connect your
instrument to the other input jack or switch to the other channel by choosing “L”
in the INPUT Module.
► The RIG KONTROL’s input gain is set too low. Turn up the according Input Level.
► Your instrument’s volume is turned down. Turn up the volume knob.
7.1.2 Distorted Signal
If the audio signal sounds distorted, and no distortion is being added by the
RIG 4 software, then this is most likely caused by the RIG KONTROL’s gain being set
too high. Reduce the Input Level at the Interface to prevent the preamp from clipping.
If your instrument delivers such a high signal that the preamp is always overdriven, you
should reduce its volume. Usually, this only happens if the instrument is equipped with
special high power pickups.
GUITAR
GUITAR RIG KONTROL Hardware Reference – 40
7.1.3 Noise
Audible hum can have several reasons, some of which are listed below:
►
Single-coil pickups are prone to collecting electrical interferences. Humbucker pickups
produce much less hum, which is why they got their name.
►
Your guitar is too close to electrical equipment. To reduce this type of hum, move the
guitar further away from the equipment.
►
The guitar’s volume knob is set to a low level. Turn the knob up. If your guitar has
more than one volume knob, make sure to check all knobs.
►
You are using a non-shielded or broken guitar cable. Your guitar’s shielding may also be
insufcient. Try replacing the cable with a shielded model rst. If this does not help, you
should consider having your guitar’s electronics serviced and shielded by a professional.
If you are experiencing hiss, the input level at the
low. Turn up the instrument’s volume or increase the input level on the RIG KONTROL.
For more information on setting the input level, see section 4.4 (Windows XP/ Windows
Vista) or section 5.4 (Mac OS X) of this manual.
RIG KONTROL
preamp might be too
7.1.4 Ground Loops
Ground loops (usually perceived as a hum or buzz) are a common problem when multiple
electrical devices are connected to the same power circuit. The following steps should
help to eliminate them:
►
Disconnect all devices that you are not currently using, e.g. peripheral devices you
may have connected to your computer (external data storage, CD burners).
►
Hook up a DI box behind the RIG KONTROL outputs. Most of these boxes have a
ground lift switch, which allows breaking the ground loop and eliminating the noise.
GUITAR RIG KONTROL Hardware Reference – 41
7.2 Hardware-Related Problems
Check the Native Instruments website and the NI Service Center for updates of the
RIG KONTROL driver and more information.
7.2.1 Driver Issues
Make sure that the RIG KONTROL is connected to the computer and open the Driver
Control Panel. See the intro to this chapter on how to nd the Control Panel.
If the Control Panel is missing, the driver is most likely not installed at all. In this case,
please re-install the driver as described above.
If all the drop-down menus of the Control Panel are grayed out, the RIG KONTROL is not
recognized by the driver. Something might be wrong with the USB connection, see the
following sections for details.
7.2.2 USB Issues
The RIG KONTROL is a USB 2.0 interface and will not work on a USB 1.0/1.1 port.
Always connect it directly to a USB 2.0 port on your computer. The port needs to fulll the
minimum power specication for a USB 2.0 port (500 mA). On certain computers, the
USB 2.0 ports do not meet the ofcial USB 2.0 power specication. In this case, you may
see a message, saying that there is not enough power available to operate your device.
The RIG KONTROL may produce crackles or may not work at all.
►
If your computer is unable to supply the necessary amount of bus power, try
connecting your RIG KONTROL to a USB 2.0 hub with external power-supply. Avoid
connecting other devices to the hub, as every bus-powered device will diminish the
total amount of power available.
► In case of failures, it is useful to check if RIG KONTROL works if you disconnect any
other USB device from the computer.
►
If you are experiencing audio dropouts or other problems that may be related to the
USB connection, try connecting the RIG KONTROL to another USB 2.0 port.
GUITAR RIG KONTROL Hardware Reference – 42
►
A bad USB cable can be responsible for audio dropouts and/or other connectivity
problems. Try using a different cable bearing the ofcial USB logo, in some cases
using a shorter cable might help.
►
If you are experiencing problems with RIG KONTROL crashing or performing badly on
a Windows machine, the rst thing to do is to disable power management for the USB
hubs, which is turned on by default. Go to the Device Manager (Control Panel > System
> Hardware) and right click a USB hub to bring up its properties. On the Power
Management page, uncheck all boxes. Repeat for each hub and reboot.
7.2.3 Using the RIG KONTROL with a Laptop
Please check if your computer is suited for handling real-time audio processing without
dropouts. There are a couple of freeware tools to analyze your system, for example:
www.thesycon.de/deu/latency_check.shtml
Start the tool with the
handle glitch-free audio processing, the tool will show red latency bars and report this in
the box on the bottom.
In general, it is not recommended to use laptops with shared-memory graphic cards. You
will need all the memory and processing power available for your audio project.
There are some steps to optimize your laptop’s audio performance:
►
It is not recommended to run the laptop on battery, as power management might slow
the clock rate of the CPU down, to save battery.
RIG KONTROL
disconnected. In case your computer is unable to
► Disconnect all unused hardware (e.g. printer, scanner). This will increase the amount
of processing power available for your music software.
► Laptops often are equipped with built-in devices that disturb audio processing, most
commonly a network adapter or a wireless LAN card. You might need to disable these
devices while working with the RIG KONTROL.
GUITAR RIG KONTROL Hardware Reference – 43
8 Technical Specications
This section contains all relevant technical specications of the RIG KONTROL hardware.
8.1 Jacks and Sockets
► 2 input jacks (In 1, In 2) for mono 6.3mm (1/4 inch) phone plugs
►
2 output jacks (Out 1, Out 2) for 6.3mm (1/4 inch) mono (unbalanced) or TRS
(balanced) phone plugs
► 1 Headphones jack for stereo 6.3mm (1/4 inch) phone plug
► 2 input jacks for external pedals / footswitches / switchboxes
► (Pedal 1, Pedal 2) for stereo 6.3mm (1/4 inch) phone plugs
► 2 MIDI (In/Out) 5-pin DIN circular connector
► 1 USB 2.0 Type B
GUITAR RIG KONTROL Hardware Reference – 44
8.2 Audio Specications
Audio Inputs (A/D)
Channels 2
Sample Rate 44.1, 48, 88.2, 96, 192kHz
Bit Resolution 16, 24 Bit
Converter Cirrus Logic
Instrument Inputs
Input Impedance 1M Ohm
Full Scale Level at Maximum Gain -11,5 dBu
Maximum Input Level +16dBu
SNR (weighted) >100dB
THD+N 0,009%
Frequency Response +/- 0,5dB 20Hz – 24KHz
Dynamic Range 105dB (ADC)
GUITAR RIG KONTROL Hardware Reference – 45
Line Inputs
Input Impedance 44 KOhm
Full Scale Level at Maximum Gain -5,5dBu
Maximum Input Level +16dBu
SNR (weighted) >100dB
THD+N 0,009%
Frequency Response +/- 0,5dB 20Hz – 36KHz
Dynamic Range 105 dB (ADC)
Audio Outputs (D/A)
Channels 2
Sample Rate 44.1, 48, 88.2, 96, 192 kHz
Bit Resolution 16, 24 Bit
Converter Cirrus Logic
GUITAR RIG KONTROL Hardware Reference – 46
Line Outputs
Output Impedance 100 Ohm
Maximum Output Level +6,3dBu
SNR (weighted) >100dB
THD+N 0,010%
Frequency Response +/- 0,5dB 22Hz – 44KHz
High/low level switch Full scale 5Vpp / -14dB
Headphone Output
Load Impedance 8-600 Ohm
Maximum Output Level 1,61V rms @ 100 Ohm
SNR (weighted) >91dB
THD+N (60 Ohms) 0,013%
Frequency Response +/- 0m5dB 22Hz – 44KHz
GUITAR RIG KONTROL Hardware Reference – 47
8.3 Power Supply
USB 2.0 interface, 5V/ 500mA bus power
No additional power supply or battery is needed, only power from the USB is required.
However, proper operation is guaranteed only when
device with a USB 2 controller, or with a self-powered USB 2 hub.
RIG KONTROL
is used as a single
8.4 Dimensions and Weight
Dimensions: 360 x 237 x 102 mm (14.1 x 9.3 x 4 inches)
Weight: 2.6 kg (5.7 lbs)
8.5 Environmental Specications:
Operating temperature: 0°C to 40°C (32°F to 104°F) (85% non-condensing humidity)
Storage temperature: -20°C to 50°C (-4°F to 122°F) (85% non-condensing humidity)
8.6 System Requirements
8.6.1 General System Specications
Mac OS 10.4.x, G4 1.4 GHz or Intel® Core™ Duo 1.66 GHz, 1024 MB RAM,
USB 2.0
Windows XP with Service Pack 2 or Windows Vista (32 bit),
Pentium/Athlon XP 1.4 GHz, 512 MB RAM,USB 2.0
GUITAR RIG KONTROL Hardware Reference – 48
8.6.2 Supported Driver Formats
Mac OS: CoreAudio™
Windows: ASIO® (recommended), DirectSound™
8.6.3 Supported Platforms
Mac OS: Stand-alone,VST®,AudioUnits™, RTAS®(ProTools7/8)
Windows: Stand-alone,VST®, RTAS®(ProTools7/8)
GUITAR RIG KONTROL Hardware Reference – 49
Loading...
