Getting Started
Chapter 1
Getting Started
Thank you for choosing the P35 Neo Combo/ G33 Neo Combo Series (MS-7365 v1.X) ATX mainboard. The P35 Neo Combo/ G33 Neo Combo Series mainboards are based on Intel® P35/G33 & ICH9/ICH9R chipsets for optimal system efficiency. Designed to fit the advanced
Intel® Core 2 Extreme, Core 2 Quad, Core 2 Duo, Pentium and Celeron processor, the P35 Neo Combo/ G33 Neo Combo Series deliver a high performance and professional desktop platform solution.
1-1
MS-7365 Mainboard
Mainboard Specifications
Processor Support
- Intel® Core 2 Extreme, Core 2 Quad, Core 2 Duo, Pentium and
Celeron in the LGA775 package
(For the latest information about CPU, please visit http://www.msi. com.tw/cpusupport.htm)
Supported FSB
- 1333/ 1066/ 800 MHz
Chipset
-North Bridge: Intel® P35/ G33 (optional)
-South Bridge: Intel® ICH9/ ICH9R (optional)
Memory Support
-2 DDR2 DIMMs support DDR2 800/ 667 SDRAM (240pin/ nonECC/ 4GB Max)
-2 DDR3 DIMMs support DDR3 1066/ 800 SDRAM ( 240pin/ non-
ECC/ 4GB Max)
(For more information on compatible components, please visit http:/ /www.msi.com.tw/testreport.htm)
LAN
-Supports Giga LAN 10/100/1000 Fast Ethernet by Realtek RTL8111B
IEEE 1394(optional)
-Chip integrated by VIA VT6308
-Transfer rate is up to 400Mbps
Audio
-Controlled by Realtek ALC888
-Supports 7.1 channels audio out
-Compliant with Azalia Spec
IDE
-1 IDE port controlled by Marvell 88SE6111
-Supports Ultra DMA 66/100/133, PIO & Bus Master operation mode
SATA
-4 SATA ports (SATA1~4) are controlled by ICH9
-6 SATA ports (SATA1~6) are controlled by ICH9R
-SATA 7 is controlled by Marvell 88SE6111 (optional)
-Supports storage and data transfers at up to 300 MB/s
RAID
-SATA1~6 support RAID 0/ 1/ 0+1/ 5 or JBOD mode (for ICH9R only, optional)
1-2
Getting Started
Floppy
-1 floppy port
-Supports 1 FDD with 360KB, 720KB, 1.2MB, 1.44MB and 2.88MB
Connectors
Back panel
-1 PS/2 mouse port
-1 PS/2 keyboard port
-1 Parallel port supporting SPP/EPP/ECP mode
-1 serial port (COM1)
-1 VGA port (for G33 Neo Combo series only)
-1 IEEE1394 port (optional)
-4 USB 2.0 Ports
-1 LAN jack
-6 audio jacks
On-Board Pinheaders
-4 USB 2.0 pinheaders
-1 IEEE1394 pinheader (optional)
-1 Chassis Intrusion Switch pinheader
-1 Front Panel Audio pinheader
-1 CD-In pinheader
-1 SPDIF-out pinheader
Slots
-1 PCI Express x 16 slot
-3 PCI Express x 1 slots
-2 PCI slots, support 3.3V/ 5V PCI bus Interface
Form Factor
- ATX (30.5 cm X 22.5 cm)
Mounting
- 6 mounting holes
1-3
MS-7365 Mainboard
Mainboard Layout
Top : mouse |
|
|
|
|
CPUFAN1 |
|
|
|
|
|
Bottom: |
|
|
|
|
|
|
|
|
|
|
keyboard |
|
JPW1 |
|
|
|
|
|
|
|
|
Top : |
|
|
|
|
DIMM A1 |
DIMM A2 DIMM B1 |
DIMM B2 |
|
|
|
Parallel Port |
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
Bottom: |
|
|
|
|
|
|
|
|
|
|
COM portA |
|
|
|
|
|
|
|
|
|
|
VGA port |
|
|
|
|
|
|
|
|
|
|
(optional) |
|
|
|
|
|
|
|
|
|
|
Top:1394(op tional) |
|
|
|
|
|
|
|
|
|
|
Bottom: USB ports |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Intel |
|
|
|
|
|
IDE1 |
Top: LAN Jack |
|
|
|
P35/ G33 |
|
|
|
|
|
|
Bottom: USB ports |
|
|
|
|
|
|
|
|
|
|
T:Line-In |
|
|
|
|
|
|
|
|
|
|
M:Line-Out |
LAN chip |
|
|
|
|
|
JPWR3 |
|
|
|
B:Mic |
|
|
|
|
|
|
|
|
||
T:RS-Out |
|
SYSFAN2 |
|
|
|
|
|
|
||
M:CS-Out |
|
|
|
|
|
|
|
|||
B:SS-Out |
|
|
|
|
|
|
|
|||
|
PCI_E1 |
|
|
|
Marvell 88SE6111 |
|
|
|||
|
|
|
|
|
|
|
||||
|
|
PCI_E2 |
|
|
|
|
|
SATA7 |
|
SYSFAN1 |
|
|
|
|
|
|
|
|
|
||
I/O |
|
PCI_E3 |
|
|
|
|
|
|
|
|
Chip |
|
|
|
Intel ICH9/ |
|
|
|
|
||
|
|
|
|
|
|
SATA6 |
SATA4 |
SATA2 |
||
|
|
|
|
|
ICH9R (optional) |
|
||||
|
|
|
|
JCI1 |
|
|
|
|||
|
|
PCI_E4 |
JBAT1 |
|
|
|
|
|
|
|
CD_IN1 |
|
|
BATT |
|
|
|
|
SATA5 |
SATA3 |
SATA1 |
|
|
|
|
|
|
|
||||
|
|
PCI 1 |
+ |
|
|
|
|
|||
Codec |
|
|
|
|
|
JUSB2 |
JUSB4 |
|||
|
|
|
|
|
|
|||||
|
|
|
|
VIA |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
VT3608P |
|
|
|
|
|
|
|
PCI 2 |
|
|
(optional) |
|
JUSB3 |
JUSB1 |
|
|
|
|
|
|
|
|
|
|
|||
JAUD1 |
|
JSPD1 |
|
FDD1 |
J1394_1 |
|
|
|
|
|
|
|
|
|
(optional) |
|
JFP2 |
JFP1 |
|
||
|
|
|
|
|
|
|
|
|||
P35 Neo Combo/ G33 Neo Combo Series (MS-7365 v1.X) ATX Mainboard
1-4
Getting Started
Packing Checklist
MSI motherboard |
MSI Driver/Utility CD |
Standard Cable |
|
(Optional) |
|||
|
Power Cable |
SATA Cable |
USB Bracket (Optional) |
|
||
|
|
Back IO Shield |
1394 Bracket (Optional) |
User’s Guide |
* The pictures are for reference only and may vary from the packing contents of the product you purchased.
1-5
Hardware Setup
Chapter 2
Hardware Setup
This chapter provides you with the information about hardware setup procedures. While doing the installation, be careful in holding the components and follow the installation procedures. For some components, if you install in the wrong orientation, the components will not work properly.
Use a grounded wrist strap before handling computer components. Static elec tric ity may damage the components.
2-1
MS-7365 Mainboard
Quick Components Guide
SYSFAN2, |
CPU, |
p.2-3 |
DDR2 DIMMs, |
|
p.2-7 |
|
|||
p.2-14 |
|
|
|
|
|
DDR3 DIMMs, |
|
||
|
|
|
||
JPW1, |
|
p.2-7 |
|
|
|
|
|
|
|
p.2-9 |
|
|
|
|
|
|
|
|
CPUFAN1, |
|
|
|
CPUFAN1 |
p.2-14 |
|
|
|
|
|
Back Panel |
|
|
|
|
I/O, p.2-10 |
|
|
|
|
|
|
|
|
IDE1, p.2-12 |
|
|
|
|
JPWR3, p.2-9 |
PCI Express |
|
|
|
|
slots, p.2-20 |
|
|
|
SYSFAN1, |
|
|
|
|
|
|
|
|
|
p.2-14 |
JBAT1, |
|
|
|
SATA1~7, |
p.2-19 |
|
|
|
|
|
|
|
p.2-13 |
|
CD_IN1, |
|
|
|
|
p.2-14 |
|
|
|
JUSB1~4, |
|
|
|
|
p.2-16 |
PCI Slots, |
|
|
|
|
p.2-20 |
|
|
|
JFP1, p.2-18 |
|
|
|
|
|
|
|
|
JFP2, p.2-18 |
|
JSPD1, p.2-17 |
|
|
|
|
|
|
|
J1394_1, p.2-17 |
|
JAUD1, p.2-15 |
|
JCI1, p.2-14 |
|
|
|
|
|
||
FDD1, p.2-12 |
|
|
||
2-2 |
|
|
|
|
Hardware Setup
CPU (Central Processing Unit)
This mainboard supports Intel® Core 2 Extreme, Core 2 Quad, Core 2 Duo, Pentium and Celeron processor in LGA 775 package. When you are installing the CPU, make sure to install the cooler to prevent overheating. If you do not have the CPU cooler, consult your dealer before turning on the computer. For the latest information about CPU, please visit http://www.msi.com.tw/testreport.htm
Important
Overheating
Overheating will seriously damage the CPU and system. Always make sure the cooling fan can work properly to protect the CPU from overheating. Make sure that you apply an even layer of thermal paste (or thermal tape) between the CPU and the heatsink to enhance heat dissipation.
Replaceing the CPU
While replacing the CPU, always turn off the ATX power supply or unplug the power supply’s power cord from the grounded outlet first to ensure the safety of CPU.
Overclocking
This mainboard is designed to support overclocking. However, please make sure your components are able to tolerate such abnormal setting, while doing overclocking. Any attempt to operate beyond product specifications is not recommended. We do not guarantee the damages or risks caused by inadequate operation or beyond product specifications.
Introduction to LGA 775 CPU
The pin-pad side of LGA 775 CPU.
The surface of LGA 775 CPU. Remember to apply some thermal paste on it for better heat dispersion.
Alignment Key |
Alignment Key |
Yellow triangle is the Pin 1 indicator |
Yellow triangle is the Pin 1 indicator |
|
2-3
MS-7365 Mainboard
CPU & Cooler Installation
When you are installing the CPU, make sure the CPU has a cooler attached on the top to prevent overheating. Meanwhile, do not forget to apply some thermal paste on CPU before installing the heat sink/cooler fan for better heat dispersion.
Follow the steps below to install the CPU & cooler correctly. Wrong installation will cause the damage of your CPU & mainboard.
1.The CPU socket has a plastic cap on it to protect the contact from damage. Before you install the CPU, always cover it to protect the socket pin.
2.Remove the cap from lever hinge side (as the arrow shows).
3. The pins of socket reveal.
4. Open the load lever.
Important
1.Confirm if your CPU cooler is firmly installed before turning on your system.
2.Do not touch the CPU socket pins to avoid damaging.
3.The availability of the CPU land side cover depends on your CPU packing.
2-4
5.Lift the load lever up and open the load plate.
Hardware Setup
6.After confirming the CPU direction for correct mating, put down the CPU in the socket housing frame. Be sure to grasp on the edge of the CPU base. Note that the alignment keys are matched.
alignment key
7.Visually inspect if the CPU is seated well into the socket. If not, take out the CPU with pure vertical motion and reinstall.
8.Cover the load plate onto the package.
2-5
MS-7365 Mainboard
9.Press down the load lever lightly onto the load plate, and then secure the lever with the hook under retention tab.
11.Press the four hooks down to fasten the cooler. Then rotate the locking switch (refer to the correct direction marked on it) to lock the hooks.
locking switch
10.Align the holes on the mainboard with the heatsink. Push down the cooler until its four c lips get wedged into the holes of the mainboard.
12.Turn over the mainboard to confirm that the clip-ends are correctly inserted.
Important
1.Read the CPU status in BIOS (Chapter 3).
2.Whenever CPU is not installed, always protect your CPU socket pin with the plastic cap covered (shown in Figure 1) to avoid damaging.
3.Mainboard photos shown in this section are for demonstration of the CPU/ cooler installation only. The appearance of your mainboard may vary depending on the model you purchase.
2-6
Hardware Setup
Memory
These DIMM slots are used for installing memory modules.
Since DDR3 modules are not interchangeable with DDR2 and the DDR3 standard is not backward compatible, you should always install DDR3 memory module in DDR3 slot (DIMM_A1 & DIMM_B1), and DDR2 memory module in DDR2 slot (DIMM_A2 & DIMM_B2). Wrong installation may cause damage of mainboard. Meanwhile, you are not able to boot up your system if you install DDR2 & DDR3 memory modules simultaneously.
For more information on compatible components, please visit http://www.msi.com. tw/testreport.htm
DDR2
240-pin, 1.8V
56x2=112 pin 64x2=128 pin
DIMM_A2 & DIMM_B2 are for DDR2 memory module
Dual-Channel: Channel A in GREEN; Channel B in ORANGE
DDR3
240-pin, 1.5V
72x2=144 pin |
48x2=96 pin |
DIMM_A1 & DIMM_B1 are for DDR3 memory module
Dual-Channel: Channel A in SKYBLUE; Channel B in PINK
Dual-Channel mode Population Rule
In Dual-Channel mode, the memory modules can transmit and receive data with two data bus lines simultaneously. Enabling Dual-Channel mode can enhance the system performance. Please refer to the following illustrations for population rules under Dual-Channel mode.
1
DIMM_A1
DIMM_A2
DIMM_B1
DIMM_B2
D u a l c h a n n e l m o d e population rule for DDR3
2 |
DIMM_A1 |
|
DIMM_A2 |
DIMM_B1
DIMM_B2
D u a l c h a n n e l m o d e population rule for DDR2
Installed
Empty
2-7
MS-7365 Mainboard
Installing Memory Modules
1.The memory module has only one notch on the center and will only fit in the right orientation.
2.Insert the memory module vertically into the DIMM slot. Then push it in until the golden finger on the memory module is deeply inserted in the DIMM slot.
Important
You can barely see the golden finger if the memory module is properly inserted in the DIMM slot.
3. The plastic clip at each side of the DIMM slot will automatically close.
Volt Notch
Important
-In Dual-Channel mode, make sure that you install memory modules of the same type and density in different channel DIMM slots.
-To enable successful system boot-up, always insert the memory modules into the DIMM_A1 or DIMM_A2 first.
-Due to the chipset resource deployment, the system density will only be detected up to 3+GB (not full 4GB) when each DIMM is installed with a 2GB memory module.
2-8
Hardware Setup
Power Supply
ATX 24-Pin Power Connector: JPWR3
This connector allows you to connect an ATX 24-pin power supply. To connect the ATX 24-pin power supply, make sure the plug of the power supply is inserted in the proper orientation and the pins are aligned. Then push down the power supply firmly into the connector.
You may use the 20-pin ATX power supply as you like. If you’d like to use the 20-pin ATX power supply, please plug your power supply along with pin 1 & pin 13 (refer to the image at the right hand). There is also a foolproof design on pin 11, 12, 23 & 24 to avoid wrong installation.
Pin Definition
pin 13
pin 12
12 |
24 |
PIN |
SIGNAL |
PIN |
SIGNAL |
|
|
|
1 |
+3.3V |
13 |
+3.3V |
|
|
|
2 |
+3.3V |
14 |
-12V |
|
|
|
3 |
GND |
15 |
GND |
|
JPWR3 |
|
4 |
+5V |
16 |
PS-ON# |
|
|
5 |
GND |
17 |
GND |
||
|
|
|||||
|
|
6 |
+5V |
18 |
GND |
|
|
|
7 |
GND |
19 |
GND |
|
|
|
8 |
PWROK |
20 |
Res |
|
|
|
9 |
5VSB |
21 |
+5V |
|
|
|
10 |
+12V |
22 |
+5V |
|
1 |
13 |
11 |
+12V |
23 |
+5V |
|
12 |
+3.3V |
24 |
GND |
|||
|
|
ATX 12V Power Connector: JPW1
This 12V power connector JPW1 is used to provide power to the CPU.
Pin Definition
3 |
4 |
PIN |
SIGNAL |
1 |
2 |
1 |
GND |
JPW1 |
|
2 |
GND |
|
3 |
12V |
|
|
|
4 |
12V |
Important
1.Maker sure that all the connectors are connected to proper ATX power supplies to ensure stable operation of the mainboard.
2.Power supply of 350 watts (and above) is highly recommended for system stability.
2-9
MS-7365 Mainboard
Back Panel
Mouse |
Parallel Port |
(optional) |
LAN |
|
|
|
|
|
|||
|
|
1394 Port |
|
||
|
|
|
|
|
|
|
|
|
|
|
Line-In RS-Out |
|
|
|
|
|
Line-Out CS-Out |
Keyboard |
Serial Port |
VGAPort |
USB Ports |
Mic SS-Out |
|
|
|||||
(optional)
Mouse/Keyboard Connector
The standard PS/2® mouse/keyboard DIN connector is for a PS/2® mouse/keyboard.
Parallel Port Connector
A parallel port is a standard printer port that supports Enhanced Parallel Port (EPP) and Extended Capabilities Parallel Port (ECP) mode.
Serial Port
The serial port is a 16550A high speed communications port that sends/ receives 16 bytes FIFOs. You can attach a serial mouse or other serial devices directly to the connector.
VGA Port (for G33 Neo Combo Series)
The DB15-pin female connector is provided for monitor.
1394 Port (optional)
The IEEE1394 port on the back panel provides connection to IEEE1394 devices.
USB Port
The USB (Universal Serial Bus) port is for attaching USB devices such as keyboard, mouse, or other USB-compatible devices.
2-10
Hardware Setup
LAN (RJ-45) Jack
The standard RJ-45 jack is for connection to single Local Area Network (LAN). You can connect a network cable to it.
ActivityIndicator |
LinkIndicator |
LED |
Color |
LED State |
condition |
|
|
Off |
LAN link is not established. |
Left |
Orange |
On (steady state) |
LAN link is established. |
|
|
On (brighter & pulsing) The computeris communicating with another computer on the LAN. |
|
|
Green |
Off |
10 Mbit/sec data rate is selected. |
Right |
|
On |
100 Mbit/sec data rate is selected. |
|
Orange |
On |
1000 Mbit/sec data rate is selected. |
Audio Ports
These audio connectors are used for audio devices. You can differentiate the color of the audio jacks for different audio sound effects.
Line-In (Blue) - Line In, is used for external CD player, tapeplayer or other audio devices.
Line-Out (Green) - Line Out, is a connector for speakers or headphones.
Mic (Pink) - Mic, is a connector for microphones.
RS-Out (Black) - Rear-Surround Out in 4/ 5.1/ 7.1 channel mode.
CS-Out (Orange) - Center/ Subwoofer Out in 5.1/ 7.1 channel mode. SS-Out (Gray) - Side-Surround Out 7.1 channel mode.
2-11
MS-7365 Mainboard
Connectors
Floppy Disk Drive Connector: FDD1
This connector supports 360KB, 720KB, 1.2MB, 1.44MB or 2.88MB floppy disk drive.
FDD1
IDE Connector: IDE1
This connector supports IDE hard disk drives, optical disk drives and other IDE devices.
IDE1 |
Important
If you install two IDE devices on the same cable, you must configure the drives separately to master / slave mode by setting jumpers. Refer to IDE device’ s documentation supplied by the vendors for jumper setting instructions.
2-12
Hardware Setup
Serial ATA Connector: SATA1/ SATA2/ SATA3/ SATA4/ SATA5/ SATA6/ SATA7 (SATA5 & SATA6 are for ICH9R only, SATA7 is controlled by Marvell 88SE6111)
This connector is a high-speed Serial ATA interface port. Each connector can connect to one Serial ATA device.
SATA7
(optional)
SATA6 SATA4 SATA2
SATA5 SATA3 SATA1
*SATA5 & SATA6 are for ICH9R only.
Important
Please do not fold the Serial ATA cable into 90-degree angle. Otherwise, data loss may occur during transmission.
2-13
MS-7365 Mainboard
Fan Power Connectors: CPUFAN1, SYSFAN1, SYSFAN2
The fan power connectors support system cooling fan with +12V. When connecting the wire to the connectors, always note that the red wire is the positive and should be connected to the +12V; the black wire is Ground and should be connected to GND. If the mainboard has a System Hardware Monitor chipset on-board, you must use a specially designed fan with speed sensor to take advantage of the CPU fan control.
Control SENSOR +12V GND
CPUFAN1
SENSOR |
|
|
|
SENSOR |
|
|
|
+12V |
|
|
|
+12V |
|
|
|
GND |
|
|
|
GND |
|
|
|
|
|
|
|
||||
SYSFAN1 |
SYSFAN2 |
||||||
Important
1.Please refer to the recommended CPU fans at processor’s official website or consult the vendors for proper CPU cooling fan.
2.Fan cooler set with 3 or 4 pins power connector are both available for CPUFAN1.
3.CPUFAN1 supports fan control. You can setup it in H/W Monitor of BIOS Setup. You can install Dual Core Center utility that will automatically control the CPU fan speed according to the actual CPU temperature.
Chassis Intrusion Switch Connector: JCI1
This connector connects to a 2-pin chassis switch. If the chassis is opened, the switch will be short. The system will record this status and show a warning message on the screen. To clear the warning, you must enter the BIOS utility and clear the record.
GND
2
CINTRU
1
JCI1
CD-In Connector: CD_IN1
This connector is provided for external audio input.
CD_IN1
R
L
GND
2-14
Loading...
