LOGITECH QuickCam Pro 9000 User Manual [fr]

Logitech

®

QuickCam

®

Pro 9000

User’s Guide

 QuickCam® Pro 9000

QuickCam® Pro 9000

Contents

1 Camera Features

English

English . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Español. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Français . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Português . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Snapshot button Thank you for purchasing your

Autofocus glass

lens system

Activity light

new Logitech® QuickCam® Pro 9000,
with an autofocus, glass lens
system. This guide will help you install
and get the best performance from
your webcam.

Microphone

Universal clip

 Install the Software First

Insert the installation CD into your
CD-ROM/DVD-ROM drive. Your CD
should start automatically. If it does not,
follow the steps below:

Double-click the My computer icon.

•
Alternatively, click Start My computer.

Right-click the CD-ROM/DVD-ROM

Install the software
Many of your camera’s extended features,
including autofocus, will not operate properly
without the complete software installation.

before

plugging in the camera.

•
drive icon, and then click Autoplay.

 QuickCam® Pro 9000

QuickCam® Pro 9000

 Connect Your Camera to Your Computer

 The Audio Tuning Wizard

Wait until you are prompted by the software before
connecting your camera to an available USB port on
your computer.

 Position Your Camera, Microphone,

and Speakers

Your camera comes with Logitech® RightSound™ Technology.
RightSound™ Technology cancels echo and significantly reduces
background noise. The following steps will ensure the best
possible audio performance:

Position your camera in the middle of your monitor

•
for optimal eye contact.

Position your camera’s microphone no more than 3 feet

•
(1 m) away from you and point it toward you.

Position your speakers (if used) at least 12 inches

•
(30 cm) away from your microphone to reduce feedback,
and then angle your speakers away from your microphone.

Tip Do not place objects between you and the microphone.

The first time that you start QuickCam, you are guided through
the Microphone/Speaker Setup Utility and Audio Tuning Wizard
that lets you do the following:

Select the audio input device (microphone)

•
and audio output device (speakers).

Enable Acoustic Echo Cancellation (AEC)—recommended.

•

Enable background suppression—recommended.

•

Specify microphone input volume and speaker output volume.

•

Test audio settings.

•

In situations with loud and irregular background noise, your voice
can become distorted when using noise suppression. If this occurs,
disable noise suppression in the QuickCam® software.

Tip To change your audio settings in the QuickCam® software,

click the Settings button, and then click the Audio tab.

 QuickCam® Pro 9000

QuickCam® Pro 9000

Your camera is now set up and ready to go!

There are many ways to enjoy using your new webcam, including

Making free video calls to friends and family. (Installation and use of an instant messaging application

•
is required. Click in the QuickCam® software to learn more.)

Taking still photos or recording videos to share or e-mail.

•

Adding videos to your E-bay auctions (see www.logitech.com/videosnap).

•

8 QuickCam

Record videos or capture images.

Enable Logitech Video Effects.

Enable Audio & Video Mute (when on a video call).

®

Software Features Congratulations

 Using the QuickCam

To start the Logitech® QuickCam® software, do either of the following:

On your desktop, double-click the QuickCam® icon.

•

- or-

In the lower-right corner of your desktop in the taskbar, click the QuickCam® icon.

•

®

Software

Specify camera settings.

Install and use video programs and services.

Tip To personalize your video calls with customized Avatar images, Face Accessories, or Fun Filters,

click the Video Effects button.

9 Ensure Quality Images

Logitech® RightLight™2 ensures that you automatically get the best image quality in harsh, dim, or back lit
conditions that usually cast a shadow on your face. When your camera determines that you are experiencing
these situations, a dialog box appears asking if you want to turn on Logitech® RightLight™2. Click Yes to let
your camera automatically adjust frame rates, color, and exposure to produce the best image quality.

To manually adjust these settings, click the Settings button.

8 QuickCam® Pro 9000

9QuickCam® Pro 9000

10 Using Autofocus

Logitech

®

Hardware Product Limited Warranty

The autofocus system will ensure that images as close as 10 cm to the camera will be put in focus,
automatically. If you wish to control the lens focus manually, switch to manual mode in ‘‘autofocus’’
controls on the Settings tab of the QuickCam® software.

11 For More Information

Audio Information. Go to http://www.logitech.com/rightsound.

Software Updates. Go to http://www.logitech.com/support.

Additional Help. Launch the software and click the Help button.

To learn more about Logitech® products, go to http://www.logitech.com.

UL Testing. Your product is UL tested and should only be used with other UL listed devices.

Compliance. For compliance information, go to http://www.logitech.com/compliance.

Logitech® warrants that your Logitech hardware product shall be free from defects in material and workmanship for two (2) years, beginning
from the date of purchase. Except where prohibited by applicable law, this warranty is nontransferable and is limited to the original purchaser.
This warranty gives you specific legal rights, and you may also have other rights that vary under local laws.

Remedies

Logitech’s entire liability and your exclusive remedy for any breach of warranty shall be, at Logitech’s option, (1) to repair or replace the hardware,
or (2) to refund the price paid, provided that the hardware is returned to the point of purchase, or such other place as Logitech may direct,
with a copy of the sales receipt or dated itemized receipt. Shipping and handling charges may apply except where prohibited by applicable
law. Logitech may, at its option, use new or refurbished or used parts in good working condition to repair or replace any hardware product.
Any replacement hardware product will be warranted for the remainder of the original warranty period, or thirty (30) days, whichever is longer
or for any additional period of time that may be applicable in your jurisdiction.

Limits of Warranty

This warranty does not cover problems or damage resulting from (1) accident, abuse, misapplication, or any unauthorized repair,
modification or disassembly; (2) improper operation or maintenance, usage not in accordance with product instructions or connection
to improper voltage supply; or (3) use of consumables, such as replacement batteries, not supplied by Logitech except where such restriction
is prohibited by applicable law.

How to Obtain Warranty Support

Before submitting a warranty claim, we recommend you visit the support section at www.logitech.com for technical assistance. Valid warranty
claims are generally processed through the point of purchase during the first thirty (30) days after purchase; however, this period of time may
vary depending on where you purchased your product. Please check with Logitech or the retailer where you purchased your product for details.
Warranty claims that cannot be processed through the point of purchase and any other product related questions should be addressed directly to
Logitech. The addresses and customer service contact information for Logitech can be found in the documentation accompanying your product
and on the web at www.logitech.com/contactus.

Limitation of Liability

LOGITECH SHALL NOT BE LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGES WHATSOEVER, INCLUDING BUT NOT
LIMITED TO LOSS OF PROFITS, REVENUE OR DATA (WHETHER DIRECT OR INDIRECT) OR COMMERCIAL LOSS FOR BREACH OF ANY EXPRESS OR IMPLIED
WARRANTY ON YOUR PRODUCT EVEN IF LOGITECH HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Some jurisdictions do not allow
the exclusion or limitation of special, indirect, incidental, or consequential damages, so the above limitation or exclusion may not apply to you.

Duration of Implied Warranties

EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY OR CONDITION OF MERCHANTABILITY OR FITNESS FOR
A PARTICULAR PURPOSE ON THIS HARDWARE PRODUCT IS LIMITED IN DURATION TO THE DURATION OF THE APPLICABLE LIMITED WARRANTY
PERIOD FOR YOUR PRODUCT. Some jurisdictions do not allow limitations on how long an implied warranty lasts, so the above limitation may
not apply to you.

National Statutory Rights

Consumers have legal rights under applicable national legislation governing the sale of consumer goods. Such rights are not affected
by the warranties in this Limited Warranty.

No Other Warranties

No Logitech dealer, agent, or employee is authorized to make any modification, extension, or addition to this warranty.

Logitech® Address. Logitech, Inc., 6505 Kaiser Drive, Fremont, California 94555, U.S.A.

10 QuickCam® Pro 9000

11QuickCam® Pro 9000

1 Componentes de la cámara

Español

 Conexión de la cámara a la computadora

Botón de captura
de instantáneas

Sistema de

objetivo de

cristal y enfoque

automático

Diodo de actividad

Clip universal

Micrófono

Le agradecemos la adquisición de
Logitech® QuickCam® Pro 9000 con

sistema de objetivo de cristal y
enfoque automático. Aquí encontrará

instrucciones de instalación e información
para obtener el mejor rendimiento
posible de esta cámara Web.

 Primer paso: instalación del software

Introduzca el CD de instalación en la unidad
de CD-ROM o DVD-ROM de la computadora.
El CD debería iniciarse automáticamente.
De no ser así, haga lo siguiente:

Haga doble clic en el icono Mi PC.

•
También puede hacer clic en Inicio
Mi PC.

Debe instalar el software antes de conectar la cámara.
Muchas de las funciones avanzadas, entre ellas la de enfoque
automático, no funcionarán correctamente a menos que se
realice una instalación de software completa.

Haga clic con el botón derecho en el

•
icono CD-ROM/DVD-ROM y luego haga
clic en Reproducción automática.

Espere hasta que aparezca la indicación en pantalla
para conectar la cámara a un puerto USB de la
computadora.

 Colocación de la cámara, el micrófono

y las bocinas

La cámara está equipada con la tecnología Logitech® RightSound™.
La tecnología RightSound™ elimina el eco y reduce el ruido
ambiental. Para asegurar el mejor sonido posible, siga este
procedimiento:

Coloque la cámara sobre la parte central del monitor para

•
obtener un contacto visual más directo.

El micrófono de la cámara debe estar orientado hacia el

•
hablante, a una distancia no superior a un metro.

Si utiliza bocinas, colóquelas al menos a 30 cm del

•
micrófono y en ángulo, para reducir la retroalimentación.

Consejo No debería haber objetos entre el hablante y el

micrófono.
