Dear Customer,
Congratulations and thank you for choosing LANCIA.
We have written this handbook to help you appreciate all the fine qualities of your car.
You should read it right through before taking to the road for the first time.
You will find information, tips and important warnings regarding the driving of your car to help you derive the maximum from your LANCIA’s technological features. You will also discover all its special features and find very valuable information for your car’s care, maintenance, driving safety and running which will help you keep your car in tip-top condition for a long time to come.
You are recommended to read carefully the warnings and indications, marked with the respective symbols, at the end of the page:
personal safety;
the car’s well-being;
environmental protection.
The enclosed Warranty Booklet booklet lists the services you have acquired and contains details relating to the following:
–the Warranty Certificate, with terms and conditions for maintaining it
–the range of services offered to LANCIA owners.
We are sure that these instruments will help you easily attune to and appreciate both your new car and the LANCIA team that will be on hand to provide you with any help you may require.
Bestregards and good motoring!
This Owner Handbook describes all the LANCIA Ypsilon versions. As a consequence, you should therefore consider only the information which is related to the engine and bodywork version of the car you purchased.
SAFEGUARDING THE ENVIRONMENT
Safety and respect for the environment are the guidelines that inspired the LANCIA Ypsilon design from the drawing board onwards.
This concept has meant that the LANCIA Ypsilon has been able to face and pass the strictest safety tests.
So much so that, from this point of view, the car is the best in its class and has probably already incorporated features that belong to the future.
In addition, ongoing research into new and effective features to help safeguard the environment makes the LANCIA Ypsilon a car to imitate for this reason as well.
All versions are in fact equipped with environmental protection devices that reduce harmful exhaust fumes in compliance with the limits provided for by current legislation.
SAFEGUARDING THE ENVIRONMENT
Safeguarding the environment has directed the design and manufacturing of the LANCIA Ypsilon right from the start. The result is the use of materials and the perfection of devices that can reduce or sweepingly reduce harmful influences on the environment.
The LANCIA Ypsilon equipped with environment safeguarding devices which curtail harmful exhaust gas emissions, is ready to travel well ahead of the most stringent international pollution control standards.
USE OF MATERIALS THAT DO NOT HARM THE ENVIRONMENT
None of the car’s components contain asbestos. Padding and the air conditioning system do not contain CFCs (Chlorofluorocarbides), the gases considered responsible for the destruction of the ozone layer. None of the colourings and anti-corrosion coatings of the nuts and bolts contain airor water-table-polluting cadmium or chromates, but envi- ronmentally-friendly substances.
DEVICES FOR REDUCING EMISSIONS (petrol engines)
Three-way catalytic converter (catalytic exhaust pipe)
The exhaust system is equipped with a catalyst made up of noble metal alloys; it is housed in a stainless steel container capable of withstanding the very high operating temperatures.
The catalyst converts the unburnt hydrocarbons, the carbon monoxide and the nitric oxides found in the exhaust gases (though in small amounts, thanks to the electronic-injection ignition systems) into non-polluting substances.
When functioning normally, the catalytic converter reaches high temperatures. For this reason do not park the car over inflammable material (e.g. paper, fuel oil, grass, dead leaves, etc.).
Lambda sensors
The Lambda sensors detect the oxygen content in the exhaust gas. The signal sent by the oxygen sensor is used by the injection system electronic control unit to constantly mix air and fuel in the correct proportion.
Evaporation control system
As it is impossible to stop the build-up of petrol fumes, also when the engine is not running, the system traps them in a special container holding active carbon.
The fumes are sucked in from here and burnt while the engine is running.
DEVICES FOR REDUCING EMISSIONS (Multijet engine)
Oxidising catalytic converter
This device converts the polluting substances in the exhaust gas (carbon monoxide, unburnt hydrocarbons and particulates) into harmless substances, thus reducing the smokiness and smell associated with diesel engine exhaust fumes.
The catalytic converter consists of a stainless steel case containing a honeycomb ceramic core in which there is the precious metal that carries out the catalysing action.
Exhaust Gas Recirculation (E.G.R.) system
This system recirculates or reuses part of the exhaust gas in a proportion which varies according to engine operating conditions.
When necessary, it is used for the control of nitrogen oxide emissions.
MUST BE READ!
REFUELLING
Petrol engines: only refuel with unleaded petrol with octane rating (RON) not less than 95 conforming
Kto the European specification EN 228.
Multijet engines: only refuel with diesel fuel conforming to the European specification EN590.
The use of other products or mixtures may irreparably damage the engine with invalidation of the warranty due to the damage caused.
ENGINE STARTING
Petrol engines: make sure that the handbrake is engaged; set the gearshift lever to neutral; fully depress the clutch without pressing the accelerator, then turn the ignition key to AVV and release it as soon as the engine has started.
Multijet engines: turn the ignition key to MAR and wait for the instrument panel warning light Yand m to go out, then turn the ignition key to AVV and release it as soon as the engine starts.
PARKING ON FLAMMABLE MATERIAL
While working, the catalyst develops a very high temperature. Do not park the car over grass, dry leaves, pine needles or any other inflammable materials: risk of fire.
RESPECTING THE ENVIRONMENT
A system for continuously monitoring emission system components to ensure greater environmental protection is fitted in your car.
ELECTRICAL ACCESSORIES
If, after buying the car, you decide to add electrical accessories (that will gradually drain the battery), visit a Dealership. They can calculate the overall electrical requirement and check that the car’s electric system can support the required load.
CODE card
Keep the code card in a safe place, not in the car. You should always keep the electronic code written on the CODE card with you in case you need to carry out an emergency start-up procedure.
SCHEDULED SERVICING
Correct maintenance of the car is essential for ensuring it stays in tip-top condition and safeguards its safety features, its environmental friendliness and low running costs for a long time to come.
THE OWNER HANDBOOK CONTAINS…
…information, tips and important warnings regarding the safe, correct driving of your car, and its maintenance. Pay particular attention to the symbols " (personal safety) # (environmental protection) â (car well-being).
U
DASHBOARD AND CONTROLS
DASHBOARD .................................................. |
8 |
INSTRUMENT PANEL ..................................... |
9 |
SYMBOLS ......................................................... |
10 |
THE LANCIA CODE SYSTEM ......................... |
11 |
THE KEYS ....................................................... |
12 |
IGNITION SWITCH .......................................... |
18 |
INSTRUMENTS ................................................ |
19 |
MULTIFUNCTION DISPLAY ........................... |
21 |
SEATS .............................................................. |
35 |
HEAD RESTRAINTS ........................................ |
38 |
STEERING WHEEL ......................................... |
38 |
REARVIEW MIRRORS ..................................... |
39 |
CLIMATE CONTROL SYSTEM ....................... |
41 |
HEATING AND VENTILATION ....................... |
42 |
MANUAL CLIMATE CONTROL SYSTEM ....... |
45 |
AUTOMATIC CLIMATE CONTROL SYSTEM .. |
48 |
EXTERNAL LIGHTS ....................................... |
58 |
AUTOMATIC HEADLIGHTS SENSOR |
|
(DAYLIGHT SENSOR)...................................... |
60 |
WINDOW WASHING ....................................... |
61 |
RAIN SENSOR .................................................. |
62 |
CRUISE CONTROL .......................................... |
64 |
CEILING LIGHTS ............................................ |
66 |
CONTROLS ...................................................... |
66 |
INTERIOR FITTINGS ....................................... |
68 |
SUNROOF ......................................................... |
70 |
DOORS ............................................................. |
71 |
POWER WINDOWS ......................................... |
72 |
BOOT ............................................................... |
73 |
BONNET .......................................................... |
77 |
ROOF RACK/SKI RACK ................................... |
78 |
HEADLIGHTS .................................................. |
78 |
ABS SYSTEM .................................................. |
80 |
ESP SYSTEM .................................................... |
81 |
ASR SYSTEM ................................................... |
82 |
EOBD SYSTEM ................................................ |
83 |
SOUND SYSTEM .............................................. |
84 |
BOSE HI-FI SYSTEM ....................................... |
84 |
ACCESSORIES PURCHASED BY THE USER .. |
85 |
“DUALDRIVE” ELECTRIC POWER |
|
STEERING SYSTEM ....................................... |
86 |
PARKING SENSORS ........................................ |
87 |
AT THE FILLING STATION ............................ |
88 |
PROTECTING THE ENVIRONMENT .............. |
90 |
DASHBOARD |
AND CONTROLS |
|
SAFETY |
DEVICES |
|
CORRECT |
USE OF |
THE CAR |
WARNING |
LIGHTS AND |
MESSAGES |
IN AN |
EMERGENCY |
|
CAR |
MAINTENANCE |
|
TECHNICAL |
SPECIFICATIONS |
|
INDEX |
|
|
7
|
DASHBOARD |
AND CONTROLS |
|
SAFETY |
DEVICES |
CORRECT |
USE OF |
THE CAR |
WARNING |
LIGHTS AND |
MESSAGES |
|
IN AN |
EMERGENCY |
|
CAR |
MAINTENANCE |
|
TECHNICAL |
SPECIFICATIONS |
|
|
INDEX |
DASHBOARD
The presence and the position of the instruments and warning lights may vary according to the versions.
fig. 1 |
L0C0266m |
1. Side vents - 2. Left-hand stalk: external lights - 3. Driver’s airbag - 4. Right-hand stalk: windscreen wiper, rear window wiper, trip computer control - 5. Central vents - 6. Sound system (where provided) / Glove compartment - 7. Instrument panel - 8. Front passenger’s airbag - 9. Front passenger’s airbag deactivation switch - 10. Glove compartment - 11. Heating/ventilation/climate controls - 12. Gear lever - 13. Control badge - 14. Ignition switch - 15. Steering wheel adjustment locking/unlocking lever - 16. Cruise control (where provided) - 17. Bonnet release lever.
8
INSTRUMENT PANEL
A Speedometer
B Fuel gauge with reserve warning light
C Rev. counter
D Multifunction display
fig. 2
A Speedometer
B Fuel gauge with reserve warning light
C Engine coolant temperature gauge with high temperature warning light
D Rev counter
E Multifunction display
fig. 3
L0C0223m
L0C0224m
DASHBOARD |
AND CONTROLS |
|
SAFETY |
DEVICES |
|
CORRECT |
USE OF |
THE CAR |
WARNING |
LIGHTS AND |
MESSAGES |
IN AN |
EMERGENCY |
|
CAR |
MAINTENANCE |
|
TECHNICAL |
SPECIFICATIONS |
|
INDEX |
|
|
9
|
DASHBOARD |
AND CONTROLS |
|
SAFETY |
DEVICES |
CORRECT |
USE OF |
THE CAR |
WARNING |
LIGHTS AND |
MESSAGES |
|
IN AN |
EMERGENCY |
|
CAR |
MAINTENANCE |
|
TECHNICAL |
SPECIFICATIONS |
|
|
INDEX |
SYMBOLS
Special coloured labels have been attached near or actually on some of the components of your Lancia Ypsilon. These labels bear symbols that remind you of the precautions to be taken as regards that particular component.
fig. 4 |
L0C0004m |
|
The plate summarising the symbols used can be found under the bonnet fig. 4.
THE LANCIA CODE SYSTEM
To further protect your car from attempted theft, it has been fitted with an electronic engine immobiliser system. This system is automatically activated when the ignition key is removed.
An electronic device, in fact, is fitted in each ignition key grip. The device transmits a radio-frequency signal when the engine is started through a special aerial built into the ignition switch. The modulate signal, which changes each time the engine is started, is the password by means of which the control unit recognises the key and enables to start the engine.
10
OPERATION
Each time the car is started turning the ignition key to MAR, the Lancia CODE system control unit sends a recognition code to the engine control unit to deactivate the inhibitor.
The code is sent only if the Lancia CODE system control unit has recognised the code transmitted from the key.
Each time the ignition key is turned to the STOP position, the Lancia CODE system deactivates the functions of the engine electronic control unit.
At starting, if the code has not been recognised correctly, the warning light
Ywill come on.
In this case, the key should be moved to the STOP position and then back to MAR; if the lock continues, possibly try again with the other key provided with the car. If it is still not possible to start the car apply to Lancia Dealership.
IMPORTANT Every key has its own code, which must be memorised by the system control unit. To memorise new keys, up to a maximum of eight, apply to Lancia Dealership.
Warning light Ycoming on when driving
If the warning light Y lights up, this means that the system is running a self-test (e.g. due to a voltage drop).
If the warning light Y stays on apply to Lancia Dealership.
DASHBOARD |
AND CONTROLS |
|
SAFETY |
DEVICES |
|
CORRECT |
USE OF |
THE CAR |
WARNING |
LIGHTS AND |
MESSAGES |
IN AN |
EMERGENCY |
|
CAR |
MAINTENANCE |
|
TECHNICAL |
SPECIFICATIONS |
|
INDEX |
|
|
11
|
DASHBOARD |
AND CONTROLS |
|
SAFETY |
DEVICES |
CORRECT |
USE OF |
THE CAR |
WARNING |
LIGHTS AND |
MESSAGES |
|
IN AN |
EMERGENCY |
|
CAR |
MAINTENANCE |
|
TECHNICAL |
SPECIFICATIONS |
|
|
INDEX |
12
THE KEYS
CODE CARD fig. 5
The car is delivered with two copies of the key and the CODE card which bears the following:
the electronic code A;
the mechanical key code B to be given to the Lancia Dealership when ordering duplicate keys.
IMPORTANT In order to ensure perfect efficiency of the electronic devices contained inside the keys, they should never be exposed to direct sunlight.
All the keys and the CODE card must be handed over to the new owner when selling the car.
fig. 5 |
L0C0267m |
|
fig. 6/a |
L0C0047m |
|
KEY WITHOUT REMOTE
CONTROL fig. 6/a
The key is fitted with metal insert A and operates:
the ignition switch;
door lock;
Button B operates the power-assisted opening of metal insert A.
fig. 6/b |
L0C0278m |
|
KEY WITHOUT REMOTE CONTROL
(where required) fig. 6/b
The metal insert A of the key is fixed.
The key operates:
the ignition switch;
the driver’s door.
To refit the metal insert into the key grip, keep button B pressed and turn the metal insert in the direction shown by the arrow until hearing the click as it locks into place. Then release button B.
WARNING
Button B should only be pressed when the key is away from the body, in particular
from the eyes and from objects that can be spoilt (e.g. clothes). Make sure the key can never be touched by others, especially children, who may inadvertently press the button.
fig. 7 |
L0C0275m |
|
KEY WITH REMOTE CONTROL fig. 7
The key is fitted with metal insert A and operates:
the ignition switch;
the door lock.
Button B operates the power-assisted opening of metal insert.
To refit the metal insert into the key grip, keep button B pressed and turn the metal insert in the direction shown by the arrow until hearing the click as it locks into place. Then release button
B.
Button Ë for unlocking of doors and tailgate.
Button Áfor locking of doors and tailgate.
Button R for remote opening of the boot.
DASHBOARD |
AND CONTROLS |
|
SAFETY |
DEVICES |
|
CORRECT |
USE OF |
THE CAR |
WARNING |
LIGHTS AND |
MESSAGES |
IN AN |
EMERGENCY |
|
CAR |
MAINTENANCE |
|
TECHNICAL |
SPECIFICATIONS |
|
INDEX |
|
|
13
|
DASHBOARD |
AND CONTROLS |
|
SAFETY |
DEVICES |
CORRECT |
USE OF |
THE CAR |
WARNING |
LIGHTS AND |
MESSAGES |
|
IN AN |
EMERGENCY |
|
CAR |
MAINTENANCE |
|
TECHNICAL |
SPECIFICATIONS |
|
|
INDEX |
If the inside locking button is pressed accidentally, when getting out of the car only the doors used will un-
lock whereas the tailgate will stay locked.To realign the system, press the lock / unlock button again.
WARNING
Button B should only be pressed when the key is away from the body, in particular
from the eyes and from objects that can be spoilt (e.g. clothes). Make sure the key can never be touched by others, especially children, who may inadvertently press the button.
When unlocking the doors, the internal lights will come on for a preset length of time.
IMPORTANT The remote control system frequency can be disturbed by significant radio transmissions outside the car (e.g.: mobile phones, ham radio systems, etc.) that could cause remote control malfunctioning.
Opening the doors and the tailgate
Press briefly button Ë: for opening of the doors, tailgate, timed switching on of passenger’s compartment lights and double flashing of direction indicators.
Doors will be unlocked automatically if the fuel inertial cut-off switch comes into operation.
IMPORTANT The remote control system frequency can be disturbed by significant radio transmissions outside the car (e.g.: mobile phones, HAM radio systems, etc.) that could cause remote control malfunctioning.
14
Closing the doors and the tailgate
Press briefly button Á: for remote locking of doors and tailgate, for switching the passenger’s compartment lights off and flashing once the direction indicators.
IMPORTANT The remote control system frequency can be disturbed by significant radio transmissions outside the car (e.g.: mobile phones, HAM radio systems, etc.) that could cause remote control malfunctioning.
Opening the tailgate from the outside
The tailgate can be opened from the outside by pressing the remote control button R.
Tailgate opening will obtain double direction indicators flashing.
IMPORTANT The remote control system frequency can be disturbed by significant radio transmissions outside the car (e.g.: mobile phones, HAM radio systems, etc.) that could cause remote control malfunctioning.
|
|
DASHBOARD |
AND CONTROLS |
|
|
|
SAFETY |
DEVICES |
|
fig. 8 |
L0C0050m |
CORRECT |
USE OF |
THE CAR |
|
||||
Driver’s door led indications |
||||
fig. 8 |
|
|
LIGHTS AND |
|
When locking the doors, led A |
WARNING |
MESSAGES |
||
switches on for about 3 seconds and |
||||
than starts flashing (deterrence func- |
||||
tion). |
|
|||
|
|
EMERGENCY |
|
|
Once doors are locked, if one or more |
IN AN |
|
||
doors or the tailgate are not closed |
|
|||
correctly, the led and direction indi- |
|
|||
cators start flashing quickly and the |
|
|||
|
|
|
||
command will not be performed. |
|
MAINTENANCE |
|
|
|
|
CAR |
|
|
|
|
TECHNICAL |
SPECIFICATIONS |
|
|
|
INDEX |
|
|
|
|
15 |
|
|
|
DASHBOARD |
AND CONTROLS |
|
SAFETY |
DEVICES |
CORRECT |
USE OF |
THE CAR |
WARNING |
LIGHTS AND |
MESSAGES |
|
IN AN |
EMERGENCY |
|
CAR |
MAINTENANCE |
|
TECHNICAL |
SPECIFICATIONS |
|
|
INDEX |
fig. 9 |
L0C0276m |
|
Replacing the battery of the key with remote control fig. 9
Battery replacement:
press button A and move the metal insert B to open position;
use a finely-tipped screwdriver to turn the screw C;
pull out the battery holder D and replace the battery E making sure that the bias is correct;
re-insert the battery holder D in the key and lock it turning the screw C.
Request for additional remote controls
The system can recognise up to 8 keys with incorporated remote control. Should a new key with remote control be necessary, contact a Lancia Dealership, taking with you the CODE card, a personal identity document and the car’s ownership documents.
Used batteries are harmful to the environment. They should be disposed of as specified by law in the spe-
cial containers provided, or take them to a Lancia Dealership, which will deal with their disposal.
16
The main functions that can be activated with the keys (with or without remote control) are the following:
Type of key |
Door opening |
Door closing |
Boot opening |
Key without remote control
Key with remote control
Direction indicators flashing (only with key with remote control)
Key turning |
Key turning |
– |
|
counterclockwise |
clockwise |
||
Key turning |
Key turning |
– |
|
counterclockwise |
clockwise |
||
|
|||
Pressing briefly |
Pressing briefly |
Prolonged pressing |
|
button Ë |
button Á |
(> 2 seconds) |
|
|
|
on button R |
|
Two flashings |
One flashing |
Two flashings |
Led on driver door |
Turning off |
Turned on fixed |
Deterrent led flashing |
|
deterrence led |
for approx. 3 seconds, |
|
|
|
followed by deterrence |
|
|
|
led flashing |
|
DASHBOARD |
AND CONTROLS |
|
SAFETY |
DEVICES |
|
CORRECT |
USE OF |
THE CAR |
WARNING |
LIGHTS AND |
MESSAGES |
IN AN |
EMERGENCY |
|
CAR |
MAINTENANCE |
|
TECHNICAL |
SPECIFICATIONS |
|
INDEX |
|
|
17
|
DASHBOARD |
AND CONTROLS |
|
SAFETY |
DEVICES |
CORRECT |
USE OF |
THE CAR |
WARNING |
LIGHTS AND |
MESSAGES |
|
IN AN |
EMERGENCY |
|
CAR |
MAINTENANCE |
|
TECHNICAL |
SPECIFICATIONS |
|
|
INDEX |
IGNITION SWITCH
The key can be turned to 3 different positions:
STOP: engine off, key can be removed, steering column locked. Certain electrical devices (e.g.: sound system, power windows…) can work.
MAR: driving position. All electrical devices are powered.
AVV: engine starting.
The ignition switch is fitted with a safety mechanism that, in the event the engine is not started, turns back the ignition key to STOP before repeating the starting operation.
WARNING
If the ignition device is tampered with (e.g.: attempted theft), have it checked over
by a Lancia Dealership.
STEERING COLUMN LOCK
Engaging
When the key is to STOP remove the key and turn the steering wheel until it locks.
|
Disengaging |
|
fig. 12 |
L0C0054m Rock the steering wheel slightly as |
|
you turn the ignition key to MAR. |
||
|
WARNING
When getting out of the car, always remove the key to prevent any occupants from accidentally activating the controls. Remember to engage the handbrake. If the car is parked on uphill slope to engage the first gear. If the car is facing downhill, engage the reverse gear. Never leave unsupervised chil-
dren in the car.
WARNING
Never remove the ignition key while the car is moving. The steering wheel would au-
tomatically lock as soon as you try to turn it. This also applies when the car is being towed.
18
INSTRUMENTS
REV. COUNTER fig. 13
Rev counter shows engine rpm.
IMPORTANT The electronic injection control system gradually shuts off the flow of fuel when the engine is “overrevving” resulting in a gradual loss of engine power.
When the engine is idling, the rev counter may indicate a gradual or sudden highering of the speed.
This is normal as it takes place during normal operation, for example when activating the climate control system or the fan. In particular a slow change in the speed preserves the battery charge.
fig. 13 |
L0C0010m |
|
FUEL LEVEL GAUGE fig. 14-15
This shows the amount of fuel left in the fuel tank.
The reserve warning light K turns on to indicate that approx. 6/7 litres of fuel are left in the tank (see the indications given in paragraph “At the filling station").
Do not travel with the fuel tank almost empty: the gaps in fuel delivery could damage the catalyst.
fig. 14 |
L0C0253m |
|
fig. 15 |
L0C0254m |
|
IMPORTANT If the needle reaches the 0 with warning light K flashing this means that there is a failure. Contact a Lancia Dealership.
DASHBOARD |
AND CONTROLS |
|
SAFETY |
DEVICES |
|
CORRECT |
USE OF |
THE CAR |
WARNING |
LIGHTS AND |
MESSAGES |
IN AN |
EMERGENCY |
|
CAR |
MAINTENANCE |
|
TECHNICAL |
SPECIFICATIONS |
|
INDEX |
|
|
19
|
DASHBOARD |
AND CONTROLS |
|
SAFETY |
DEVICES |
CORRECT |
USE OF |
THE CAR |
WARNING |
LIGHTS AND |
MESSAGES |
|
IN AN |
EMERGENCY |
|
CAR |
MAINTENANCE |
|
TECHNICAL |
SPECIFICATIONS |
|
|
INDEX |
fig. 16 |
L0C0252m |
|
ENGINE COOLANT TEMPERATURE GAUGE (where provided) fig. 16
This shows the temperature of the engine coolant fluid and begins working when the fluid temperature exceeds approx. 50°C.
During the normal use of the car, the needle should move to different positions of the scale according to the working conditions.
The turning on of the warning light u together with the message on the multifunction display indicates that the coolant fluid temperature is too high; in this case, stop the engine and contact a Lancia Dealership.
If the needle reaches the red area, stop the engine immediately and contact a Lancia Dealership.
fig. 17 |
L0C0190m |
|
SPEEDOMETER (speed indicator) fig. 17
It indicates the car speed.
20
MULTIFUNCTION DISPLAY
(where provided)
The car can be provided with the multifunction display that shows useful information, according to the previous settings made, necessary when driving.
“STANDARD” SCREEN fig. 20
The standard screen shows the following indications:
A Data
B Symbol for possible ice on road
C External temperature
DDisplay of the CITY mode (if selected)
EClock (always displayed, also with key removed and front doors closed)
fig. 20 |
L0C1158i |
|
F Scheduled maintenance programme intervals
GHeadlight aiming position display (only with dipped beam headlights on).
H Odometer (covered km or miles)
Note When opening one of the front doors, the display will turn on and show for a few seconds the clock and the km or mi covered.
fig. 21 |
F0L0225m |
|
CONTROL BUTTONS fig. 21
öTo scroll the display and the related next options or to increase the value displayed.
MODE Brief press to open the menu and/or to move to next screen or to confirm the option required.
Long press to go back to the standard screen.
õTo scroll the display and the related previous options or to decrease the value displayed.
NOTE Buttons ö and õ activate different functions according to the following situations:
DASHBOARD |
AND CONTROLS |
|
SAFETY |
DEVICES |
|
CORRECT |
USE OF |
THE CAR |
WARNING |
LIGHTS AND |
MESSAGES |
IN AN |
EMERGENCY |
|
CAR |
MAINTENANCE |
|
TECHNICAL |
SPECIFICATIONS |
|
INDEX |
|
|
21
|
DASHBOARD |
AND CONTROLS |
|
SAFETY |
DEVICES |
CORRECT |
USE OF |
THE CAR |
WARNING |
LIGHTS AND |
MESSAGES |
|
IN AN |
EMERGENCY |
|
CAR |
MAINTENANCE |
|
TECHNICAL |
SPECIFICATIONS |
|
|
INDEX |
Headlight aiming position (only with dipped beam headlights on)
– to adjust the headlight aiming position, with standard screen active, (refer to paragraph “Headlight” in this section).
Setup menu
–to scroll the menu options upwards and downwards;
–to increase or decrease values during settings.
SETUP MENU fig. 22
The menu comprises a series of functions arranged in a “circular fashion” which can be selected through buttons ö and õ to access the different select operations and settings (setup) given in the following paragraphs.
The setup menu can be activated by pressing briefly button MODE.
Single presses on buttons ö or õ will scroll the setup menu options.
Handling modes differ with each other according to the characteristic of the option selected.
NOTE If the car is equipped with the Connect Nav+ system, the only functions that can be adjusted/set through the instrument panel display are the following: “Light.”, “Speed lim.”, “Light sensor” (where provided), “Belt buzz..” and “Pass. bag”. The other functions are displayed by and can be adjusted/set through the Connect Nav+ system display.
22
Selecting a menu option
–press briefly button MODE to select the menu option to set;
–press buttons ö or õ (by single presses) to select the new setting;
–press briefly button MODE to store the new setting and to go back to the previously selected menu option.
Selecting “Date” and “Set Clock”:
–briefly press button MODE to select the first value to change (e.g. hours /minutes or year / month / day);
–press buttons ö or õ (by single presses) to select the new setting;
–briefly press button MODE to store the new setting and to go to the next setup menu option, if this is the last one you will go back to the previously selected option of the main menu.
Press button MODE for long:
– to quit the setup menu and to save only the settings stored yet by the user (and confirmed by pressing briefly button MODE).
The setup menu displaying is timed; when quitting the menu due to timing expiry, only settings stored yet by the user (and confirmed by pressing briefly button MODE) will be saved.
DASHBOARD |
AND CONTROLS |
|
SAFETY |
DEVICES |
|
CORRECT |
USE OF |
THE CAR |
WARNING |
LIGHTS AND |
MESSAGES |
IN AN |
EMERGENCY |
|
CAR |
MAINTENANCE |
|
TECHNICAL |
SPECIFICATIONS |
|
INDEX |
|
|
23
|
DASHBOARD |
AND CONTROLS |
|
SAFETY |
DEVICES |
CORRECT |
USE OF |
THE CAR |
WARNING |
LIGHTS AND |
MESSAGES |
|
IN AN |
EMERGENCY |
|
CAR |
MAINTENANCE |
|
TECHNICAL |
SPECIFICATIONS |
|
|
INDEX |
24
Example: |
|
|
|
|
|
|
|
Briefly press button MODE to start surfing from the |
Example: |
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Deutsch |
|
|
|
|
|
|
standard screen. To surf the menu use buttons ö or õ. |
|
|
|
|
Day |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
NOTE For safety reasons, when the car is running, it is |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
English |
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||
|
Italiano |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
possible to access only the reduced menu (for setting the |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Year |
|
|
|
Month |
||||
|
|
|
|
|
|
|
|
|
|
|
|
“Light.” and “Speed lim.”). When the car is stationary |
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
Español |
|
access to the whole menu is enabled. On cars provided |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||||
Português |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
with the Connect Nav+ system, many functions are dis- |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Français |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
played on the navigator display. |
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
õ |
|
|
MODE |
|
|
|
õ |
|
briefly |
|
|
|
õ |
|
|
||
MODE |
|
|
|
|
press |
|
|
|
ö |
ö |
õ |
button |
|
briefly |
õ |
ö SPEED LIM. |
LIGHT SENSOR |
ö |
|
|
press |
|
|
|
TRIP B |
|
|
button |
ö LIGHT. |
|
|
|
|
|
|
õ |
CLOCK ADJUST. |
ö õ |
|
ö |
EXIT MENU |
|
|
CLOCK MODE |
||
|
|
||
õ |
BAG PASS. |
|
ö õ |
|
ö |
|
|
|
|
|
|
|
|
SERVICE |
|
|
|
|
DATE ADJUSTM. |
|
|
|
|
|
|
|
|
|
|
||
õ ö |
|
|
|
|
|
|
ö |
õ |
|
|
|
BELT BUZZ. (*) (where provided) |
|
|
|
INDEP. BOOT |
|
|
|
õ |
ö |
|
|
|
|
|
ö |
õ |
|
VOL. KEY |
|
|
|
DOOR LOCK |
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
ö BUZZER VOL. |
|
|
|
DIST. UNIT |
ö |
|
L0C2169g |
|
õ |
|
|
CONSUMP. |
ö |
õ |
|
|
|
|
|
ö |
LANG. |
TEMP. UNIT |
|
|
|
||
|
|
ö |
|
|
|
|
|||
|
|
|
|
õ (*) This function can be only displayed af- |
|||||
|
|
õ |
|
ö |
|
||||
fig. 22 |
|
|
|
õ |
õ |
ter Lancia Dealership has deactivated the |
|||
|
|
|
S.B.R. system. |
|
|
||||
Instrument panel and sound system/automatic climate control light dimmer (Light.)
(only with sidelights on)
With this function it is possible to adjust on 8 levels (with sidelights on) the light intensity of the instrument panel, sound system controls and automatic climate control (where provided) controls.
To adjust the light intensity level required, proceed as follows:
–briefly press button MODE the previously set level will flash on the display;
–press button ö or õ to select the required level;
–briefly press button MODE to go back to the menu screen or press the button for long to go back to the standard screen without storing settings.
Speed limit (Speed lim.)
With this function it is possible to set the car speed limit (km/h or mph); when this limit is exceeded the driver is immediately alerted (see section “Warning lights and messages”).
To set the speed limit, proceed as follows:
– briefly press button MODE, the display will show the wording (Speed lim.);
–press button ö or õ to select speed limit activation (On) or deactivation (Off);
–after pressing (On), press button ö
or õ to select the required speed limit value and then press MODE to confirm.
Note The possible setting is between 30 and 250 km/h, or between 20 and 155 mph depending on the unit set previously (see “Distance unit (Dist. unit)” paragraph described later. Every press on button ö / õ increases/decreases by 5 units. Keeping the button ö / õ pressed obtains the fast automatic increase or decrease.
When you are near the required setting complete adjustment by single presses.
briefly press button MODE to go back to the menu screen or press the button for long to go back to the standard screen without storing settings.
To abort the setting, proceed as follows:
–briefly press button MODE, (On) will flash on the display;
–press button õ, (Off) will flash on the display;
–briefly press button MODE to go back to the menu screen or press the button for long to go back to the standard screen without storing settings.
Automatic headlight daylight sensor (Light sensor)
(where provided)
With this function it is possible to adjust the light sensor sensitivity according to 3 levels (level 1 = min. level, level 2 = average level, level 3 = max. level); the higher the sensitivity is, the lower is the external light intensity required to switch on the lights. The car is delivered with sensitivity level “2”.
To set the light level required, proceed as follows:
–briefly press button MODE, the previously set level will flash on the display;
–press button ö or õ to select the required level;
–briefly press button MODE to go back to the menu screen or press the button for long to go back to the standard screen without storing settings.
DASHBOARD |
AND CONTROLS |
|
SAFETY |
DEVICES |
|
CORRECT |
USE OF |
THE CAR |
WARNING |
LIGHTS AND |
MESSAGES |
IN AN |
EMERGENCY |
|
CAR |
MAINTENANCE |
|
TECHNICAL |
SPECIFICATIONS |
|
INDEX |
|
|
25
|
DASHBOARD |
AND CONTROLS |
|
SAFETY |
DEVICES |
CORRECT |
USE OF |
THE CAR |
WARNING |
LIGHTS AND |
MESSAGES |
|
IN AN |
EMERGENCY |
|
CAR |
MAINTENANCE |
|
TECHNICAL |
SPECIFICATIONS |
|
|
INDEX |
Trip B On/Off (Trip B)
Through this option it is possible to activate (On) or deactivate (Off) the Trip B (partial trip).
For further information see paragraph “Trip computer”.
For activation / deactivation, proceed as follows:
–briefly press button MODE: (On) or (Off) will flash on the display (according to previous setting);
–press button ö or õ for setting;
–briefly press button MODE to go back to the menu screen or press the button for long to go back to the standard screen without storing settings.
Setting the clock (Clock adjust.)
This function enables to set the clock.
To set the clock (hours - minutes) proceed as follows:
–briefly press button MODE: “hours” will flash on the display;
–press button ö or õ for setting;
–briefly press button MODE: “minutes” will flash on the display;
–press button ö or õ for setting.
Note Every press on the button ö or õ increases/decreases by one unit. Keeping the button pressed obtains automatic fast increase/decrease. When you are near the required setting complete adjustment by single presses.
– briefly press button MODE to go back to the menu screen or press the button for long to go back to the standard screen without storing settings.
Setting the clock in 12h or 24h mode (Clock mode)
This function enables to set the clock in the 12h or 24h mode.
To set the clock in 12h or 24h mode, proceed as follows:
–briefly press button MODE: 12h or 24h will flash on the display (according to previous setting);
–press button ö or õ for setting;
–briefly press button MODE to go back to the menu screen or press the button for long to go back to the standard screen without storing settings.
Setting the date (Date adjustm.)
This function enables to update the date (year - month - day).
To correct the date proceed as follows:
–briefly press button MODE: “year” will flash on the display;
–press button ö or õ for setting;
–briefly press button MODE: “month” will flash on the display;
26
–press button ö or õ for setting;
–briefly press button MODE: “day” will flash on the display;
–press button ö or õ for setting.
Note Every press on button ö or õ increases/decreases by 1 unit. Keeping the button pressed obtains automatic fast increase or decrease. When you are near the required setting complete adjustment by single presses.
– briefly press button MODE to go back to the menu screen or press the button for long to go back to the standard screen without storing settings.
Independent boot unlocking (Indep. boot)
If On, when unlocking the doors the boot stays closed and therefore protected. To unlock the boot press button R on the key with remote control.
If Off, the boot is unlocked together with the doors.
To activate (On) or to deactivate (Off) this function proceed as follows:
–briefly press button MODE: (On) or (Off) will flash on the display (according to previous setting);
–press button ö or õ for setting;
–briefly press button MODE to go back to the menu screen or press the button for long to go back to the standard screen without storing settings.
Automatic central door locking when travelling (Door lock)
When activated (On), this function locks automatically the doors when the car speed exceeds 20 km/h.
To activate (On) or to deactivate (Off) this function proceed as follows:
–briefly press button MODE: (On) or (Off) will flash on the display (according to previous setting);
–press button ö or õ for setting;
–briefly press button MODE to go back to the menu screen or press the button for long to go back to the standard screen without storing settings.
Unit - “distance” (Dist. unit)
With this function it is possible to set the units for distance covered (km or mi).
To set the required unit proceed as follows:
–briefly press button MODE: km or mi will flash on the display (according to previous setting);
–press button ö or õ for setting;
–briefly press button MODE to go back to the menu screen or press the button for long to go back to the standard screen without storing settings.
DASHBOARD |
AND CONTROLS |
|
SAFETY |
DEVICES |
|
CORRECT |
USE OF |
THE CAR |
WARNING |
LIGHTS AND |
MESSAGES |
IN AN |
EMERGENCY |
|
CAR |
MAINTENANCE |
|
TECHNICAL |
SPECIFICATIONS |
|
INDEX |
|
|
27
|
DASHBOARD |
AND CONTROLS |
|
SAFETY |
DEVICES |
CORRECT |
USE OF |
THE CAR |
WARNING |
LIGHTS AND |
MESSAGES |
|
IN AN |
EMERGENCY |
|
CAR |
MAINTENANCE |
|
TECHNICAL |
SPECIFICATIONS |
|
|
INDEX |
Unit - “consumption” (Consump.)
With this function it is possible to set the units for fuel consumption (km/l, l/100 km or mpg) according to the distance unit set previously (km or mi, see previous paragraph “Unit - distance”).
If the distance unit set is km, fuel consumption will be displayed in km/l or l/100 km.
If the distance unit set is “mi”, fuel consumption will be displayed in “mpg”.
To set the required unit proceed as follows:
–briefly press button MODE: km/l or l/100km will flash on the display (according to previous setting);
–press button ö or õ for setting;
–briefly press button MODE to go back to the menu screen or press the button for long to go back to the standard screen without storing settings.
Unit - “temperature” (Temp. unit)
With this function it is possible to set the temperature unit (°C or °F).
To set the required unit proceed as follows:
–briefly press button MODE: °C or °F will flash on the display (according to previous setting);
–press button ö or õ for setting;
–briefly press button MODE to go back to the menu screen or press the button for long to go back to the standard screen without storing settings.
Selecting the language (Language)
Display messages can be shown in the following different languages: Italian, German, English, Spanish, French, and Portuguese.
To set the required language proceed as follows:
–briefly press button MODE: the previously set “language” will flash on the display;
–press button ö or õ for setting;
–briefly press button MODE to go back to the menu screen or press the button for long to go back to the standard screen without storing settings.
Adjusting the failure/warning buzzer volume (Buzzer vol.)
With this function the volume of the buzzer accompanying any failure/ warning indication can be adjusted according to 8 levels.
To adjust the volume proceed as follows:
–briefly press button MODE: the previously set volume “level” will flash on the display;
–press button ö or õ for setting;
–briefly press button MODE to go back to the menu screen or press the button for long to go back to the standard screen without storing settings.
28
Adjusting the button volume (Vol. key)
With this function the volume of the roger-beep accompanying the activation of buttons MODE, ö and õ can be adjusted according to 8 levels.
To adjust the volume proceed as follows:
–briefly press button MODE: the previously set volume “level” will flash on the display;
–press button ö or õ for setting;
–briefly press button MODE to go back to the menu screen or press the button for long to go back to the standard screen without storing settings.
S.B.R. buzzer reactivation (Belt buzz.) (where provided)
This function can be only displayed after Lancia Dealership has deactivated the S.B.R. system (see paragraph “S.B.R. system” in section “Safety devices”).
Scheduled Servicing (Service)
Through this function it is possible to display information connected to proper car servicing.
To display scheduled servicing info proceed as follows:
–briefly press button MODE: service in km or mi, according to previous setting, will be displayed (see paragraph “Unit - distance”);
–press button ö or õ to select displaying in days;
–briefly press button MODE to go back to the menu screen or press the button for long to go back to the standard screen without storing settings.
NOTE The “Service schedule” includes car maintenance every 30,000 km (or equivalent value in mi) or every year; this is shown automatically, with the ignition key at MAR, starting from 2,000 km (or equivalent value in mi) or 30 days from this deadline and it is shown again every 200 km (or equivalent value in mi) or every 3 days. Below 200 km servicing indications are displayed more frequently. As concerns 1.3 Multijet version, refer to paragraph “Service Schedule” in section "Car Maintenance" for changing air cleaner, engine oil and engine oil filter. Service indications will be displayed km or mi according to previous unit setting.
When a programmed maintenance interval (coupon) is near to come, turning the ignition key to MAR, it will display the message “Service” followed by the number of km/mi or days to go before car servicing. “Scheduled servicing” message is displayed in km/mi or days according to the approaching service interval. Contact a Lancia Dealership to carry out any service operation provided by the “Service schedule” or “Annual inspection plan”, and to reset the display.
DASHBOARD |
AND CONTROLS |
|
SAFETY |
DEVICES |
|
CORRECT |
USE OF |
THE CAR |
WARNING |
LIGHTS AND |
MESSAGES |
IN AN |
EMERGENCY |
|
CAR |
MAINTENANCE |
|
TECHNICAL |
SPECIFICATIONS |
|
INDEX |
|
|
29
Loading...
