Page 1
Handbook
Handbook
OPTISONIC 6300 P
OPTISONIC 6300 P
OPTISONIC 6300 POPTISONIC 6300 P
HandbookHandbook
Portable ultrasonic clamp-on flowmeter
Electronic Revision:
ER 1.1.2_
(SW.REV 01.01.01_)
© KROHNE 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 2
: IMPRINT :::::::::::::::::::::::::::::::::::::::
All rights reserved. It is prohibited to reproduce this documentation, or any part thereof, without
the prior written authorisation of KROHNE Messtechnik GmbH.
Subject to change without notice.
Copyright 2013 by
KROHNE Messtechnik GmbH - Ludwig-Krohne-Str. 5 - 47058 Duisburg (Germany)
2
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 3
OPTISONIC 6300 P
CONTENTS
1 Safety instructions 5
1.1 Intended use ..................................................................................................................... 5
1.2 Certification ...................................................................................................................... 5
1.3 Safety instructions from the manufacturer ..................................................................... 6
1.3.1 Copyright and data protection ................................................................................................ 6
1.3.2 Disclaimer ............................................................................................................................... 6
1.3.3 Product liability and warranty ................................................................................................ 7
1.3.4 Information concerning the documentation........................................................................... 7
1.3.5 Warnings and symbols used................................................................................................... 8
2 Device description 9
2.1 Scope of delivery............................................................................................................... 9
2.2 Nameplates .................................................................................................................... 10
3 Installation for flow measurement 12
3.1 General safety instructions ............................................................................................ 12
3.2 Step 1: Find location and determine data...................................................................... 13
3.3 Step 2: Initialise the UFC 300 P converter ..................................................................... 17
3.4 Step 3: Mount the sensor rails ....................................................................................... 23
3.4.1 2 or 4 traverses with 1 rail................................................................................................... 26
3.4.2 2 traverses with 2 rails ......................................................................................................... 27
3.4.3 1 traverse with 2 rails (DN400...1500) .................................................................................. 28
3.4.4 Apply coupling grease........................................................................................................... 29
3.4.5 Connect the sensor cable ..................................................................................................... 30
3.5 Step 4: Optimization loop ............................................................................................... 31
3.6 Step 5: start flow measurement .................................................................................... 32
3.7 Error messages.............................................................................................................. 33
4 Installation for energy measurement 35
4.1 Preparation of energy measurement............................................................................. 35
4.2 Mechanical installation .................................................................................................. 36
4.3 Program the converter................................................................................................... 38
4.3.1 Program the I/O input ........................................................................................................... 38
4.3.2 Program the process input................................................................................................... 39
4.3.3 Program the counters........................................................................................................... 40
4.4 Start measurement ........................................................................................................ 41
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
3
Page 4
CONTENTS
OPTISONIC 6300 P
5 Electrical connections 42
5.1 Safety instructions.......................................................................................................... 42
5.2 Location of connectors at the converter ........................................................................ 42
5.3 Power supply .................................................................................................................. 43
5.4 Signal cable .................................................................................................................... 43
5.5 USB connector................................................................................................................ 44
5.6 I/O cable.......................................................................................................................... 46
5.7 Connection diagrams ..................................................................................................... 47
6 Operation 52
6.1 Display configuration......................................................................................................52
6.1.1 Step 1: how to set up the display for showing measured values ......................................... 52
6.1.2 Basic settings of display ....................................................................................................... 53
6.2 Programming the transducer calibration number........................................................ 54
6.3 Data logging.................................................................................................................... 55
6.3.1 Step 1: how to set up the data logger................................................................................... 55
6.3.2 Step 2: how to start data logging.......................................................................................... 58
6.3.3 Step 3: how to view logged data............................................................................................ 58
6.4 How to transfer data to a PC .......................................................................................... 59
6.4.1 Site files................................................................................................................................. 59
6.4.2 Log files................................................................................................................................. 60
6.4.3 Managing your files from your pc.........................................................................................61
6.5 Menu description ............................................................................................................ 62
7 Service 73
7.1 Spare parts availability...................................................................................................73
7.2 Availability of services .................................................................................................... 73
7.3 Returning the device to the manufacturer..................................................................... 73
7.3.1 General information.............................................................................................................. 73
7.3.2 Form (for copying) to accompany a returned device............................................................ 74
7.4 Disposal .......................................................................................................................... 74
8 Technical data 75
8.1 Measuring principle........................................................................................................75
8.2 Technical data................................................................................................................. 76
8.3 Dimensions and weights ................................................................................................ 82
8.3.1 Clamp-on sensor .................................................................................................................. 82
8.3.2 Converter............................................................................................................................... 83
8.3.3 I/O box ................................................................................................................................... 84
8.3.4 Trunk on wheels.................................................................................................................... 85
9 Notes 86
4
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 5
OPTISONIC 6300 P
1.1 Intended use
CAUTION!
Responsibility for the use of the measuring devices with regard to suitability, intended use and
corrosion resistance of the used materials against the measured fluid lies solely with the
operator.
INFORMATION!
The manufacturer is not liable for any damage resulting from improper use or use for other than
the intended purpose.
The OPTISONIC 6300 P
OPTISONIC 6300 P portable clamp-on flow meter is designed for measurement of liquid
OPTISONIC 6300 POPTISONIC 6300 P
flows in full pipes, datalogging and transfer of logged results to the PC. The portable clamp-on
flow meter makes it possible to measure the flow on places temporary or you can make use of it
if you want to compare the output with other measurement devices.
If an inline measurement device is broken and you are in need of the information the OPTISONIC
6300 P might be the solution for you.
1.2 Certification
SAFETY INSTRUCTIONS 1
In accordance with the commitment to customer service and safety, the device
described in this document meets the following safety requirements:
• EMC Directive 2004/108/EC and 93/68/EEC in conjunction with EN 61326-1 (1997) and
A1 (1998), A2 (2001)
• Low-Voltage Directives 73/23/EEC and 93/68/EEC in conjunction with EN 61010-1 (2001)
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
5
Page 6
1 SAFETY INSTRUCTIONS
1.3 Safety instructions from the manufacturer
1.3.1 Copyright and data protection
The contents of this document have been created with great care. Nevertheless, we provide no
guarantee that the contents are correct, complete or up-to-date.
The contents and works in this document are subject to copyright. Contributions from third
parties are identified as such. Reproduction, processing, dissemination and any type of use
beyond what is permitted under copyright requires written authorisation from the respective
author and/or the manufacturer.
The manufacturer tries always to observe the copyrights of others, and to draw on works created
in-house or works in the public domain.
The collection of personal data (such as names, street addresses or e-mail addresses) in the
manufacturer's documents is always on a voluntary basis whenever possible. Whenever
feasible, it is always possible to make use of the offerings and services without providing any
personal data.
OPTISONIC 6300 P
We draw your attention to the fact that data transmission over the Internet (e.g. when
communicating by e-mail) may involve gaps in security. It is not possible to protect such data
completely against access by third parties.
We hereby expressly prohibit the use of the contact data published as part of our duty to publish
an imprint for the purpose of sending us any advertising or informational materials that we have
not expressly requested.
1.3.2 Disclaimer
The manufacturer will not be liable for any damage of any kind by using its product, including,
but not limited to direct, indirect or incidental and consequential damages.
This disclaimer does not apply in case the manufacturer has acted on purpose or with gross
negligence. In the event any applicable law does not allow such limitations on implied warranties
or the exclusion of limitation of certain damages, you may, if such law applies to you, not be
subject to some or all of the above disclaimer, exclusions or limitations.
Any product purchased from the manufacturer is warranted in accordance with the relevant
product documentation and our Terms and Conditions of Sale.
The manufacturer reserves the right to alter the content of its documents, including this
disclaimer in any way, at any time, for any reason, without prior notification, and will not be liable
in any way for possible consequences of such changes.
6
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 7
OPTISONIC 6300 P
1.3.3 Product liability and warranty
The operator shall bear responsibility for the suitability of the device for the specific purpose.
The manufacturer accepts no liability for the consequences of misuse by the operator. Improper
installation and operation of the devices (systems) will cause the warranty to be void. The
respective "Standard Terms and Conditions" which form the basis for the sales contract shall
also apply.
1.3.4 Information concerning the documentation
To prevent any injury to the user or damage to the device it is essential that you read the
information in this document and observe applicable national standards, safety requirements
and accident prevention regulations.
If this document is not in your native language and if you have any problems understanding the
text, we advise you to contact your local office for assistance. The manufacturer can not accept
responsibility for any damage or injury caused by misunderstanding of the information in this
document.
This document is provided to help you establish operating conditions, which will permit safe and
efficient use of this device. Special considerations and precautions are also described in the
document, which appear in the form of underneath icons.
SAFETY INSTRUCTIONS 1
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
7
Page 8
1 SAFETY INSTRUCTIONS
1.3.5 Warnings and symbols used
Safety warnings are indicated by the following symbols.
DANGER!
This information refers to the immediate danger when working with electricity.
DANGER!
This warning refers to the immediate danger of burns caused by heat or hot surfaces.
DANGER!
This warning refers to the immediate danger when using this device in a hazardous atmosphere.
DANGER!
These warnings must be observed without fail. Even partial disregard of this warning can lead to
serious health problems and even death. There is also the risk of seriously damaging the device
or parts of the operator's plant.
OPTISONIC 6300 P
WARNING!
Disregarding this safety warning, even if only in part, poses the risk of serious health problems.
There is also the risk of damaging the device or parts of the operator's plant.
CAUTION!
Disregarding these instructions can result in damage to the device or to parts of the operator's
plant.
INFORMATION!
These instructions contain important information for the handling of the device.
LEGAL NOTICE!
This note contains information on statutory directives and standards.
• HANDLING
HANDLING
HANDLINGHANDLING
This symbol designates all instructions for actions to be carried out by the operator in the
specified sequence.
i RESULT
RESULT
RESULTRESULT
This symbol refers to all important consequences of the previous actions.
8
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 9
OPTISONIC 6300 P
2.1 Scope of delivery
INFORMATION!
Do a check of the packing list to make sure that you have all the elements given in the order.
INFORMATION!
Inspect the cartons carefully for damages or signs of rough handling. Report damage to the
carrier and to the local office of the manufacturer.
CAUTION!
The device arrives in a plastic trunk on wheels, unless ordered otherwise.
DEVICE DESCRIPTION 2
Figure 2-1: Scope of delivery
1 Product documentation, factory calibration report
2 Trunk on wheels
3 Carrying bag
4 Tray with one or two rails
5 Metal / textile straps for mounting rail(s) and converter
6 Sensor(s) with fixing units (small version 1, medium version 2 sensors)
2 Transducers (small versions: 2 MHz, medium version: 1 MHz), including 3 m cable, coupling grease
7 Power adapter including plugs for EU, UK, US and AUS
8 USB memory stick, measure band
optionally I/O box and/or temperature sensors, PC connection cable
9 UFC 300 P Signal converter
INFORMATION!
Delivered content can be different, dependent on the ordered version. A checklist is included
with the product, check if all items on this checklist are delivered.
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
9
Page 10
2 DEVICE DESCRIPTION
2.2 Nameplates
Figure 2-2: Nameplate flow sensor
1 Ambient temperature operating range
2 Protection category
3 Process temperature
4 Manufacturing year
5 Article number
6 Description
7 Device type
8 Name and address of the manufacturer
OPTISONIC 6300 P
10
Figure 2-3: Nameplate converter
1 Name and address of the manufacturer
2 Device type
3 Serial number
4 Manufacturing year
5 Protection class and temperature data
6 Treat device as electronic garbage according WEEE rules.
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 11
OPTISONIC 6300 P
DEVICE DESCRIPTION 2
Figure 2-4: Nameplate I/O box, standard version
Figure 2-5: Nameplate I/O box with 2 temperature transmitters included.
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
11
Page 12
3 INSTALLATION FOR FLOW MEASUREMENT
INFORMATION!
Four steps are needed to start a measurement on a new location:
1. Find a suitable location and determine some basic data of the pipe.
2. Initialise the UFC 300 P converter and enter the data from step 1. The converter advises a mea-
surement mode.
3. Mount the sensor rails as advised for the chosen measurement mode.
4. Perform an optimisation loop and make small changes in the position of the transducers.
These four steps are described in section 3.2...3.5.
3.1 General safety instructions
WARNING!
In general, devices from the manufacturer may only be installed, commissioned, operated and
maintained by properly trained and authorized personnel.
This document is provided to help you establish operating conditions, which will permit safe and
efficient use of this device.
Specific for sensors:
OPTISONIC 6300 P
WARNING!
•
Be careful when locking the rail back on to the mounting units as your fingers may get stuck
between rail and pipe it is mounted on. This may cause injury.
•
Be careful when mounting the fixation units using the metal strap. The edge of the strap may
cause injury.
CAUTION!
•
Do not bend the metal mounting strap. This may cause improper mounting of the fixation
units of the sensor rails.
•
Protect the pipe contact side of the transducer. Scratches or other damages may have a
negative impact on its proper functioning.
•
Before fitting the transducer to the transducer knob in the sensor rail, check the connection
groove of the transducer cover for damages or dirt. Clean or replace when dirty or damaged.
•
Check sensor cabling with regular intervals for damages and wear as this may cause
improper functioning. Replace when necessary.
•
Check presence of sufficient grease on the transducer pipe contact side in case of acoustic
signal failure.
•
Check the sensor rail sliding area regularly for dirt or other pollution or excess coupling fat,
that may cause improper functioning.
•
Excess of coupling fat may be removed from the sensor rails and transducers with a dry piece
of cloth. Coupling fat on the converter housing may be removed using soapy water.
Specific for converters:
12
WARNING!
Be careful moving the handle of the converter, as your fingers may get stuck between the handle
and the housing of the converter. This may cause injury.
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 13
OPTISONIC 6300 P
INSTALLATION FOR FLOW MEASUREMENT 3
CAUTION!
•
In order to comply with the EMC directive 2004/108/EC, I/O cables that provide a galvanic
connection to the UFC 300 P should have a maximum total length of 3 meter.
•
When not used, put the connector covers of the connectors on the bottom side of the
converter in place. This to prevent improper functioning caused by dust/dirt.
•
When the sensor cables are connected while the converter is positioned on a flat surface,
turn the handle fully backwards (towards the housing) in order to prevent excess stress on
the sensor cables.
•
In order to keep the battery at an optimum condition the battery should be charged at least
once every 6 months.
•
If the main battery is empty for a period longer than one year, the backup battery of the real
time clock may run empty.
•
The protection degree of the battery charger / mains adapter is IP 40 / NEMA 1. It should be
protected against moisture entering.
•
To prevent damage due to vibrations, do not firmly attach the converter to or place it on top of
a vibrating object.
3.2 Step 1: Find location and determine data
CAUTION!
Do not start to mount the rails yet! Step 1 is only meant to find a suitable location for a
measurement. The installation itself will be done in Step 3.
Inlet, outlet and recommended mounting area
To perform an accurate flow measurement preferably mount the sensor rail at least 10 DN
downstream of a flow disturbance like elbows, valves, headers or pumps. Follow the given
installation recommendations.
Figure 3-1: Inlet, outlet and recommended mounting area
1 Min. 10 DN
2 Min. 5 DN
3 Recommended installation location (120°)
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
13
Page 14
3 INSTALLATION FOR FLOW MEASUREMENT
CAUTION!
Make sure that the rail is not mounted at the highest point (risk for air bubbles) or at the lowest
point (risk for particles) of the pipe.
Long horizontal pipes
• Install on slightly ascending pipe section.
• If not possible, make sure that the flow velocity is high enough to prevent air, gas or vapor to
collect in upper part.
• In partially filled pipes, the clamp-on flowmeter will report incorrect flow rates, or not
measure.
OPTISONIC 6300 P
Figure 3-2: Long horizontal pipes
Vertical pipelines
CAUTION!
Make sure that the pipe is fully filled at all times.
INFORMATION!
Both ascending and descending flow directions are measurable.
14
Figure 3-3: Mounting on vertical pipelines is possible
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 15
OPTISONIC 6300 P
Open feed or discharge
Install meter on a lowered section of the pipe to make sure that there is a full pipe condition.
Figure 3-4: Open feed or discharge
Down going pipeline over 5 m / 16 ft length
Install an air vent downstream of the flowmeter to prevent vacuum. It may cause gases to come
out of solution (cavitate) that prevent a proper measurement.
INSTALLATION FOR FLOW MEASUREMENT 3
Figure 3-5: Down going pipeline over 5 m / 16 ft length
Position of control valve
Always install control valves downstream of the flowmeter in order to avoid cavitation or
distortion of the flow profile.
Figure 3-6: Position of control valve
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
15
Page 16
3 INSTALLATION FOR FLOW MEASUREMENT
Position of pump
CAUTION!
Never install the flowmeter at the suction side of a pump in order to avoid cavitation or flashing
in the flowmeter.
Figure 3-7: Position of pump
Determine data and dimensions of pipe
CAUTION!
The next data must be available before proceeding with Step 2.
OPTISONIC 6300 P
• Use the supplied tape measure to determine the outside diameter of the pipe.
• Determine the pipe wall thickness. A pipe wall thickness gauge or pipe tables can be used for
this.
• Find out what the material of the pipe is.
• If the pipe has a liner, find out the liner material and the thickness of the liner.
16
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 17
OPTISONIC 6300 P
INSTALLATION FOR FLOW MEASUREMENT 3
3.3 Step 2: Initialise the UFC 300 P converter
Figure 3-8: Keys UFC 300 P
1 TFT Display
2 Navigation keys
3 Quick access keys
4 Text and numerical keypad
5 On / off button
• Turn on the converter by pressing the on / off button for one second. Wait until the menu
appears, this will take approximately 30 seconds.
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
17
Page 18
3 INSTALLATION FOR FLOW MEASUREMENT
INFORMATION!
FIRST TIME USE:
FIRST TIME USE:
FIRST TIME USE:FIRST TIME USE:
When the UFC 300 P converter is started for the first time, the startup menu will be shown. In
this menu, set the language, time and date.
To show the menu again at the next startup, select "Settings and information Device Startup sequence? Yes".
First time use
Menu
Language English
Time and date
Units
Continue
13-04-2010 14:11:09 13 MB free
First time use, program the units in the converter
If you use the converter for the first time, it will prompt you for the unit setting automatically.
Otherwise go to menu number 2.4.1 ("Measurement Setup Units").
Choose in each line the required unit with the buttons as shown in the next table.
OPTISONIC 6300 P
Navigate through the menu
Back Back one page
∧ Up Up one line
∨ Down Down one line
Forward Enter item to edit or to select it
When editing, only the Back and Forward buttons are functional:
Back Delete previous character or leave item
Forward Move cursor right, accept item when at
unchanged when at position one
last position
18
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 19
OPTISONIC 6300 P
REGULAR USE:
REGULAR USE:
REGULAR USE:REGULAR USE:
If the device has been used before, the screen will look like:
Menu
Installation
Installation
Installation Installation
Measurement
View logged data
File Management
Settings and information
13-04-2010 14:11:09 13 MB free
Program the converter
CAUTION!
Normally, all settings are saved in a site file. To load the default values, load the default site file
via "Measurement > Load site".
If needed you can recover the factory settings for the site file via "Settings and Information >
Load factory settings". Previous saved site files are kept during this process.
INSTALLATION FOR FLOW MEASUREMENT 3
• Select "Installation" from the main menu.
Menu
Installation
Installation
Installation Installation
Measurement
View logged data
File management
Settings & information
13-04-2010 14:11:09 13 MB free
The next screen is shown:
1.1
1 pipe / 1 path
1 pipe / 1 path
1 pipe / 1 path 1 pipe / 1 path
1 pipe / 2 path
2 pipes
13-04-2010 14:11:09 13 MB free
See the next figure for an explanation of the options:
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
19
Page 20
3 INSTALLATION FOR FLOW MEASUREMENT
OPTISONIC 6300 P
Figure 3-9: System configuration possibilities
1 1 pipe / 1 path
2 1 pipe / 2 path
3 2 pipes
• Choose the desired configuration.
• In the next screen, fill in the data that was found in Step 1.
1.2
Pipe tag
Outer diameter
Material
Wall thickness
Liner material
Liner thickness
< Previous | Next >
< Previous | Next >
< Previous | Next > < Previous | Next >
13-04-2010 14:11:09 13 MB free
Pipe1
100.00 mm
Carbon steel
5.00 mm
Epoxy
0.50 mm
Pipe tag Enter a name for the pipe
Press again "" and "".
Outer diameter Use the outside diameter
Material Choose the right material
Wall thickness Fill in the pipe wall thickness
Liner material Select whether there is a liner or not
Liner thickness Fill in the liner thickness
The liner thickness will only be shown if a liner
material is chosen.
20
Choose next
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 21
OPTISONIC 6300 P
CAUTION!
Inaccurate input of the outside diameter will affect the accuracy of the measured flow rate.
INFORMATION!
In case of a two pipe configuration, the converter will ask if the data entered for pipe 1 has to be
used for pipe 2 too.
Menu 1.2 and 1.3 are shown again to enter the data for the second pipe.
1.3
Fluid
VoS Fluid
Viscosity
< Previous | Next >
< Previous | Next >
< Previous | Next > < Previous | Next >
13-04-2010 14:11:09 13 MB free
Fluid Select the correct fluid from the table.
VoS Fluid Velocity of Sound of the selected fluid. Only change it if
Viscosity Only change it if the viscosity is well known.
INSTALLATION FOR FLOW MEASUREMENT 3
Water
1485.0 m/s
2
/s
1 mm
highly accurate values are available, for instance
temperature compensated.
Choose next
An advise is given in the next menu:
CAUTION!
Find the calibration numbers that are noted on the labels on the cable of each transducer. Make
sure that both transducers have the same calibration number as shown by the converter.
1.7
Transducer set
Calibration number
Number of traverses
< Previous | Next >
< Previous | Next >
< Previous | Next > < Previous | Next >
13-04-2010 14:11:09 13 MB free
Ta
522505050
2
CAUTION!
Normally, do not change the settings in this menu.
INFORMATION!
In case of a two sensor configuration, this loop will be shown twice. After installing the first
transducer the converter will produce a second advice for the second installation.
Transducer set Select the value that is on the label on the transducer
cable.
Note: A maximum of three transducer sets can be
programmed in the converter, called Ta, Tb or Tc.
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
21
Page 22
3 INSTALLATION FOR FLOW MEASUREMENT
Calibration number Compare the calibration number with the number on the
transducer cable. If needed, select a different transducer
set to change the calibration number.
Number of traverses 1 traverse = Z mode
2 traverses = V mode
4 traverses = W mode
See figure below for an explanation of the number of
traverses.
OPTISONIC 6300 P
Figure 3-10: Number of traverses
1 1 traverse (Z mode)
2 2 traverses (V mode)
3 4 traverses (W mode)
The best suitable sensor is automatically selected from the available sensor types in the
converter and the appropiate number of traverses is indicated. If none of the sensors is suitable,
the converter will show "Transducer set : None".
Pipe Available sensor Traverse mode
DN15...150 Small 2 MHz, 1 rail
DN50...250 Medium 1 MHz, 1 rail
DN200...750 Medium 1 MHz, 2 rails
DN400...1500 Medium 1 MHz, 2 rails
CAUTION!
Normally, install the sensors as advised. If the quality of the pipe walls is poor and / or in case of
scaling inside the pipes, try to decrease the amount of traverses or (if possible) use a medium
sensor instead of a small sensor.
22
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 23
OPTISONIC 6300 P
• Press Next to go to the next menu:
1.8
Advised sensor position
34.30 mm
Signal quality
< Previous | Next >
< Previous | Next >
< Previous | Next > < Previous | Next >
13-04-2010 14:11:09 13 MB free
Advised distance [mm] Number of rails needed
< 190 1
≥ 190 2
INFORMATION!
The maximum distance that can be covered with 1 rail is 195 mm.
The minimum distance for two rails is 180 mm.
INSTALLATION FOR FLOW MEASUREMENT 3
0%
INFORMATION!
On request it is possible to use the large rail of the OPTISONIC 6300 with
0,5 MHz transducers. Using this you can measure up to DN4000.
3.4 Step 3: Mount the sensor rails
Before mounting the rails, determine the colors on the connectors of the transducers. Make
sure that the blue transducer is upstream and the green transducer is downstream.
Installation with metal straps (DN15...250)
Put the metal straps around the pipe. Put the sensor rail(s) on the pipe including the transducers
with fixed cables.
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
23
Page 24
3 INSTALLATION FOR FLOW MEASUREMENT
OPTISONIC 6300 P
1 Insert straps in the lower opening.
2 Repeat the same for the other strap.
3 Pull the straps around the pipe.
4 Insert the straps in the upper opening.
5 Pull the straps tight.
6 Use an allan key nr 5 (or a big screwdriver) to fixate the rails.
24
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 25
OPTISONIC 6300 P
Installation with textile straps (> DN250)
For pipe diameters above DN250, the textile straps must be used.
1 Insert the long strap in the upper opening.
2 Insert the short strap in the lower opening at the other side of the rail.
3 Pull the strap around the pipe.
4 Fix the strap, as indicated below.
INSTALLATION FOR FLOW MEASUREMENT 3
1 Push lever to create a opening.
2 Insert the textile strap as indicated.
3 Release lever.
4 Pull strap tight.
5 Use an allan key nr 5 (or a big screwdriver) to fixate the rails.
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
25
Page 26
3 INSTALLATION FOR FLOW MEASUREMENT
3.4.1 2 or 4 traverses with 1 rail
Applicable diameters with one rail:
OPTISONIC 6300 P
Number of
Diameter range
traverses
2 DN15...250
4 DN15...150
Put the first transducer at position "0". Put the other transducer at the advised distance, shown
on the screen in Step 2. See the figures below.
Figure 3-11: Advised distance with one rail
1 Advised distance is measured from center first transducer to indicator at second transducer.
• Unlock the transducer by turning the locking knob 2 counter clockwise.
• Slide the transducer 1 to the new position 3.
• Lock the transducer by turning the locking knob 2 clockwise.
26
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 27
OPTISONIC 6300 P
3.4.2 2 traverses with 2 rails
Applicable diameters with two rails:
INSTALLATION FOR FLOW MEASUREMENT 3
Number of
Diameter range
traverses
2 DN200...750
INFORMATION!
The two rails must be installed in a straight line.
Figure 3-12: Mounting 2 rails in V-mode (2 traverses)
1 Advised distance
2 Distance between 2 rails
• Mount the first rail on the pipe. Make sure that you mount the rail in line with the pipe!
• Position the left transducer in any position X (see next section).
• Mount the second rail (align it with the first rail) at a distance 2 to arrange that the transducer
in the second rail is within the range it can be moved.
• The advised distance 1 is defined from the center
center of the left transducer to the left
centercenter
left side of the
leftleft
right transducer. Put the second transducer at position Z = advised distance 1 + X - distance
2 - 415 mm / 16.3".
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
27
Page 28
3 INSTALLATION FOR FLOW MEASUREMENT
3.4.3 1 traverse with 2 rails (DN400...1500)
Applicable diameters with two rails:
OPTISONIC 6300 P
Number of
Diameter range
traverses
1 DN400...1500
• Measure the outer diameter of the pipe with the tape measure.
• Calculate the half of the outer diameter.
• Start at the left side of the rail and locate the opposite side using the calculated half of the
outer diameter.
• Put a mark at this position.
• Repeat this at the right side of the rail.
• Draw a line between the two markings.
• Mount the DOWN rail in such a way that the transducer is at the marked location.
28
Figure 3-13: Mounting second rail in Z mode (1 traverse) using a reference point
1 Measure the distance between the transducer of the UP rail and the reference point.
2 Add the advised distance to determine the position of the second transducer.
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 29
OPTISONIC 6300 P
Figure 3-14: Mounting second rail in Z mode (1 traverse) without using a reference point
1 Advised distance 1 = 2 + 3
3.4.4 Apply coupling grease
Push the buttons of the fixing units to unlock and tilt the rail. Then put some coupling grease on
the transducers and put the rail back by clicking.
INSTALLATION FOR FLOW MEASUREMENT 3
Figure 3-15: Greasing transducers
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
29
Page 30
3 INSTALLATION FOR FLOW MEASUREMENT
3.4.5 Connect the sensor cable
OPTISONIC 6300 P
1
2
1
2
1
123
456
GHI JKL MNO
789
PQRS TUV WXYZ
+/- 0
A/a
I/O
DEF
ABC
DISPLAY
LOGGER
EXP
MENU
-
2
Figure 3-16: Connecting signal cables
1 Connector for "UP" transducer (blue)
2 Connector for "DOWN" transducer (green)
INFORMATION!
After mounting the transducers in the proper position, it takes up to 60 seconds to find a signal.
INFORMATION!
The signal strength is given and can be qualified as shown:
Signal strength Qualification
> 75% High signal
50...75% Fairly high signal
10...50% Low signal
< 10% Bad or no signal
Check settings in menu, change transducer distance
until there is at least a low signal.
30
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 31
OPTISONIC 6300 P
1.8
Advised sensor position
52.18 mm
52.18 mm
52.18 mm52.18 mm
Signal quality
< Previous | Next >
13-04-2010 14:11:09 13 MB free
INSTALLATION FOR FLOW MEASUREMENT 3
78%
• Proceed with the optimization loop in step 4.
3.5 Step 4: Optimization loop
CAUTION!
If the actual sensor position is not entered accurately, the sound velocity can not be calculated
correctly and optimization of the sensor position will fail.
• Press "".
1.10
Advised sensor position
Actual sensor position
< Previous | Next >
13-04-2010 14:11:09 13 MB free
66.05 mm
66.05 mm
• Make sure that the transducers are mounted at the advised distance.
• Press Next .
1.12
Volume flow
Velocity of sound
Signal quality
Optimize position
Optimize position
Optimize position Optimize position
< Previous | Next >
13-04-2010 14:11:09 13 MB free
50 m3/h
1481.3 m/s
69%
• Press Optimize position .
INFORMATION!
The optimization loop uses the measured VoS and compares it to the entered VoS.
• The optimization loop will give a new advise on the transducer distance. Slide the transducers
to the new position. Repeat this loop until the advised distance does not change more than 1%
or 1 mm.
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
31
Page 32
3 INSTALLATION FOR FLOW MEASUREMENT
• In menu 1.12, press Next .
1.19
Sensor 1 status
Signal quality
< Previous | Next >
13-04-2010 14:11:09 13 MB free
• Press Next .
1.20
Site name
Site name
Site name Site name
Cancel
Skip saving
Save site file
13-04-2010 14:11:09 13 MB free
test
test
testtest
Installed
80 %
OPTISONIC 6300 P
INFORMATION!
You can save the settings in a site file, so they can be used again later when measuring at the
same site (location).
• Enter a file name.
• Select Save site file .
Measurement
Site name
Display measurement
Display measurement
Display measurement Display measurement
Load site
Save current site
Setup
13-04-2010 14:11:09 13 MB free
test
INFORMATION!
The device is now ready to measure.
3.6 Step 5: start flow measurement
Press "" on the converter. The converter checks the received signal and initiates the flow
measurement mode.
The display will show the actual flow now.
32
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 33
OPTISONIC 6300 P
INSTALLATION FOR FLOW MEASUREMENT 3
3.7 Error messages
Error
Error
Error Error
code
code
codecode
F (bold)
F (bold) error in
F (bold)F (bold)
F application
S out of
C check in
I information no direct impact on measurements no action needed
F (bold)
F (bold) IO 1 (or IO 2) error or failure of IO Module 1 (or 2) try to load settings (menu C8.6.3);
F (bold)F (bold)
F (bold)
F (bold) parameter error or failure of data manager,
F (bold)F (bold)
F (bold)
F (bold) configuration incorrect configuration or no
F (bold)F (bold)
F (bold)
F (bold) display error of failure of display unit,
F (bold)F (bold)
F (bold)
F (bold) current output
F (bold)F (bold)
F (bold)
F (bold) software user
F (bold)F (bold)
F (bold)
F (bold) hardware
F (bold)F (bold)
F (bold)
F (bold) hardware
F (bold)F (bold)
F (bold)
F (bold) RAM/ROM
F (bold)F (bold)
F (bold)
F (bold) communication
F (bold)F (bold)
F (bold)
F (bold) front end malfunctioning of front end PCB contact manufacturer service center
F (bold)F (bold)
F (bold)
F (bold) uproc malfunctioning of microcontroller
F (bold)F (bold)
F (bold)
F (bold) dsp malfunctioning of DSP contact manufacturer service center
F (bold)F (bold)
F empty pipe signal lost at two paths check process conditions
F flow > max 1 max volume flow exceeded for pipe 1 check parameter in menu C1.7.1
F flow > max 2 max volume flow exceeded for pipe 2 check parameter in menu C1.7.1
F open circuit A
F over range A
F over range A
F active settings error during CRC check (Cyclic
Group
Group
Group Group
message
message
messagemessage
device
error
specification
progress
Error message
Error message Description
Error messageError message
A (or B, C)
interface
settings
detection
error IO 1
(or IO 2)
dsp-up
(or B, C)
(or B, C)
(or B, D)
Description Error handling
DescriptionDescription
no measurement possible,
measured values are not valid
no measurement possible, but
device ok
unreliable measurement maintenance required, check
test function is active, device is
stand-by
parameter or hardware error
confirmation
parameter or hardware error
error or failure of the current output
A (or B, C), parameter or hardware
error
detected hardware and set hardware
settings do not match
hardware can not be detected defect; replace electronics units
no communication between DSP and
microprocessor PCB
PCB
current on current output A (or B, C)
too low
current on current output A (or B, C)
is limited by parameter setting
pulse on frequency output A (or B, D)
is limited by parameter setting
Redundancy Check) of the active
settings
Error handling
Error handlingError handling
repair or replace device and/or CPU;
contact manufacturer service center
check parameter settings / power
off - wait 5 seconds - power on
device
flowprofile
wait until finished
if error does not disappear, replace
electronics unit
try to load settings (menu C8.6.3);
if error does not disappear, replace
electronics unit
confirm change of module;
if configuration is unchanged,
replace electronics unit
defect; replace electronics units
defect; replace electronics units
defect; replace electronics units
follow display instructions
defect; replace electronics units
contact manufacturer service center
contact manufacturer service center
check cable or reduce resistance
(< 1000 Ohm)
extend upper or lower limit for
current output in menu C5.2.8
extend upper or lower limit for
frequency output in menu C5.3.7
load settings; factory setting, back
up 1 or back up 2
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
33
Page 34
3 INSTALLATION FOR FLOW MEASUREMENT
OPTISONIC 6300 P
F factory settings error during CRC check of factory
F back up 1 (or 2)
settings
F signal lost
path 1
F signal lost
path 2
F pipe/sens1
param.
F pipe/sens2
param.
S unreliable 1 unreliable measurement at pipe 1 check process conditions for gas
S unreliable 2 unreliable measurement at pipe 2 check process conditions for gas
S zero converter invalid value at power up power off - wait 5 seconds - power
S overflow
counter 1 (or 2,
3)
S backplane
invalid
I counter 1 (or 2,
3) stopped
I control input A
(or B) active
I over range
display 1 (or 2)
I backplane
sensor
I backplane
settings
I backplane
difference
I optical
interface
I softw sync
error
settings
error during CRC check of back up 1
(or 2) settings
signal lost at path 1 check signal cable / check for pipe
signal lost at path 2 check signal cable / check for pipe
unrealistic parameter settings for
pipe in combination with path 1
unrealistic parameter settings for
pipe in combination with path 2
counter is overflowing and will start
again at zero
error during CRC check of
backplane
counter has stopped reset counter in menu C8.9.1
information only no action needed
1st row on 1st (or 2nd) measurement
page is limited by parameter setting
incompatible data sensor on
backplane
incompatible data on backplane
different data on backplane and
display
optical interface is operational, local
display can not be used
incompatible DSP and
microprocessor software
obstructions
obstructions
check parameters in menu X6
check parameters in menu X6
bubbles, solids
bubbles, solids
on device
no action needed
restore data records on backplane
(or C8.9.2, C8.9.3)
extend upper or lower limit for
limitation in menu C8.3.4
34
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 35
OPTISONIC 6300 P
The combination of the measured flow rate and a temperature difference over a device can be
used to determine the amount of energy used by that device. The temperature difference can
either be programmed manually in the converter or be measured with temperature
transmitters, connected to an optional I/O box. in this case, the temperature difference is
determined by measuring the temperature before and after the heat/cold producer/consumer.
INSTALLATION FOR ENERGY MEASUREMENT 4
Figure 4-1: Energy measurement of heat user
1 Mounted rail (in any measuring mode)
2 PT 100 temperature sensor, before the heat/cold producer/consumer
3 PT 100 temperature sensor, after the heat/cold producer/consumer
4 Radiator
5 Optional I/O box with temperature option
6 Converter
INFORMATION!
Please find more detailed information in the next sections to set up an energy measurement.
4.1 Preparation of energy measurement
1 Install a flow measurement as described in the previous chapter. Make sure that the rail and
converter are installed close to the location of the place where the temperature sensors must
be installed, because of the fixed (limited) length of the sensor cables.
2 Check if temperature transmitters are already available on site.
Transmitters are already available on site:
Make sure that the basis I/O box
current input of basic I/O, which is connected to the UFC 300 P.
Transmitters are not available on site:
Make sure that the Extended I/O box
included. Optionally, clamp-on PT 100 temperature sensors can be delivered, with a
temperature range of 0...120°C / 32...248°F, including two meter cable and suitable for pipes up
to DN300.
basis I/O box is used. Connect the temperature transmitters to the 4...20 mA
basis I/O boxbasis I/O box
Extended I/O box is used. In this version, the temperature transmitters are
Extended I/O boxExtended I/O box
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
35
Page 36
4 INSTALLATION FOR ENERGY MEASUREMENT
4.2 Mechanical installation
Mounting of temperature sensors
The delivered PT 100 sensors are clamp-on elements. Clamp them on the pipe with the hose
clamp.
INFORMATION!
Mount the temperature sensors close to the rail for flow measurement. All cables have a fixed
length!
OPTISONIC 6300 P
Figure 4-2: Mounting PT 100 with hose clamp
1 PT 100 temperature transmitter
2 Hose clamp
If the temperature sensors on the pipe have temperature transmitters 4...20 mA it is possible to
make use of the standard I/O box.
• Connect the PT 100 elements to the I/O box according to the sticker on the I/O box.
36
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 37
OPTISONIC 6300 P
INSTALLATION FOR ENERGY MEASUREMENT 4
Figure 4-3: Extended I/O box with 2 temperature transmitters included for PT 100 sensors.
Figure 4-4: Basic I/O box for 4...20 mA temperature transmitters
• Plug the connector 2 of the I/O box 3 in the connector 1 of the converter, as shown in the
figure below.
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
37
Page 38
4 INSTALLATION FOR ENERGY MEASUREMENT
Figure 4-5: I/O box
1 I/O connector on converter
2 Connector of I/O box
3 I/O box with screw terminals for 1 mm
4 Screw terminal pin 1...15
2
wiring
4.3 Program the converter
Three settings must be programmed in order to measure the amount of energy.
OPTISONIC 6300 P
4.3.1 Program the I/O input
• Go to menu nr. 2.4.5 via "Measurement Setup I/O"
2.4.5
Current output
Current inputs
Current inputs
Current inputs Current inputs
Status output / limit switch
Frequency / pulse output
Simulation
13-04-2010 14:11:09 13 MB free
If the recommended KROHNE energy set is used, the standard settings are correct. The
temperature range is 4 mA = 0°C / 32°F and 20 mA = 120°C / 248°F:
INFORMATION!
On the converter, you must scroll down in the menu to see all settings.
38
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 39
OPTISONIC 6300 P
2.4.5.2
Function
Function
Function Function
Extended range A 0%
Extended range A 100%
Extended range B 0%
Extended range B 100%
Temperature range A 0%
Temperature range A 100%
Temperature range B 0%
Temperature range B 100%
Time constant A
Time constant B
4 mA trimming A
20 mA trimming A
4 mA trimming B
20 mA trimming B
13-04-2010 14:11:09 13 MB free
If another energy set is used, teach in the required values.
INFORMATION!
The "Extended range A/B 0% and 100%" are meant for an alarm function. If a value is measured
that is lower than the "Extended range A/B 0%" value or higher than the "Extended range A/B
100%" value, an event will be logged in the event logger.
INSTALLATION FOR ENERGY MEASUREMENT 4
On
On
OnOn
3.6 mA
21 mA
3.6 mA
21 mA
0.0 °C
120.0 °C
0.0 °C
120.0 °C
1 s
1 s
4 mA
20 mA
4 mA
20 mA
4.3.2 Program the process input
• Go to menu 2.4.2.3.1 via "Measurement Setup Process input Heat Function off "
2.4.2.3.1
Heating
Heating
Heating Heating
Cooling
Off
13-04-2010 14:11:09 13 MB free
• Choose "Heating" or "Cooling" to activate energy measurement.
2.4.2.3
Function
Temperature input
Temperature input
Temperature input Temperature input
Sensor location
Fluid
13-04-2010 14:11:09 13 MB free
• Choose in "Temperature input " which sensor is is located at the supply side of the process.
Heating
Terminal A at supply
Terminal A at supply
Terminal A at supplyTerminal A at supply
Supply
Water
INFORMATION!
In case the function is "Heating", the temperature at the "supply" side is the highest.
In case the function is "Cooling", the temperature at the "supply" side is the lowest.
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
39
Page 40
4 INSTALLATION FOR ENERGY MEASUREMENT
Manually entering the temperature values
• If there are no temperature sensors available for connecting, set the "Temperature input" to
"Manual".
2.4.2.3
Function
Temperature input
Temperature input
Temperature input Temperature input
Supply temperature
Return temperature
Sensor location
Fluid
13-04-2010 14:11:09 13 MB free
• Set the location of the flow sensor (supply or return side of the installation) in order to
calculate the correct specific heat of the liquid.
• Check whether the shown fluid is correct.
INFORMATION!
The type of fluid is set in the flow sensor installation wizard. In case the fluid is set to waterglycol mixture in the flow sensor installation wizard the concentration of glycol in water can be
set in the heating/cooling setup menu.
Heating
Manual
Manual
ManualManual
80.0 °C
120.0 °C
Supply
Water
OPTISONIC 6300 P
2.4.2.3
Function
Temperature input
Temperature input
Temperature input Temperature input
Sensor location
Fluid
13-04-2010 14:11:09 13 MB free
4.3.3 Program the counters
• Go to menu 2.4.6 and select a counter for counting energy. Use counter 3 or 4 for energy
measurements as they have a higher limit.
2.4.6.1
Function of counter
Function of counter
Function of counter Function of counter
Measurement
Low flow cutoff threshold
Low flow cutoff hysteresis
Preset value
Reset counter
Set counter
Stop counter
13-04-2010 14:11:09 13 MB free
• At the "Function of counter", select "Sum" for counting both positive and negative energy
flows.
• Select "+ counter" for only counting positive energy flows.
• Select "- counter" for only counting negative energy flows.
• At the "Measurement" option, select "Power". The energy value counter unit is kJ.
Heating
Terminal A at supply
Terminal A at supply
Terminal A at supplyTerminal A at supply
Supply
Water
+ counter
+ counter
+ counter+ counter
Power
0.000 kW
0.000 kW
0 kJ
40
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 41
OPTISONIC 6300 P
INSTALLATION FOR ENERGY MEASUREMENT 4
4.4 Start measurement
The following parameters are available when heating or cooling measurement is switched on:
• Temperature A/B
• Temperature difference
• Themal power (power)
• Thermal energy (totalized power)
To setup the display to view those parameters please refer to the display setup paragraph.
The unit for energy measurement can standard be set to Joule (kilo, mega, giga), Wh (kilo, mega)
or BTU (kilo, million (MM)). In case any other unit is required the free unit can be used. To setup
the free unit go to "Measurement Setup Units ". Select the power or energy parameter,
then select "Free unit". Enter the text for the unit, then the factor for the unit entered.
The factor for energy is the amount of Joules in the free unit. The factor for power is the amount
of Watt's in the free unit.
Underneath you find a table with factors for alternative energy units.
Unit of power Description W factor
(amount of Watt in unit)
Ton (refrigeration) A ton of refridgeration is defined
as the cooling power to melt one
short ton (2000 pounds or 907 kg)
of ice in a 24 hour period. This is
equal to 12000 BTU per hour or
3527 W.
kilo calorie per second Power required to heat 1 kg of
water with 1 degree Celsius in 1
second.
3527
4187
Unit of energy Description J factor
(amount of Joule in unit)
Ton-hour (refrigeration) A ton-hour of refridgeration is
defined as the energy to melt one
short ton (2000 pounds or 907 kg)
of ice.
kilo calorie per second Amount of heat required to
increase 1 kg of water with 1
degree Celsius.
Therm Equal to 100000 BTU 105506000
12660000
4187
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
41
Page 42
5 ELECTRICAL CONNECTIONS
5.1 Safety instructions
DANGER!
All work on the electrical connections may only be carried out with the power disconnected. Take
note of the voltage data on the nameplate!
DANGER!
Observe the national regulations for electrical installations!
WARNING!
Observe without fail the local occupational health and safety regulations. Any work done on the
electrical components of the measuring device may only be carried out by properly trained
specialists.
INFORMATION!
Look at the device nameplate to ensure that the device is delivered according to your order.
Check for the correct supply voltage printed on the nameplate.
OPTISONIC 6300 P
5.2 Location of connectors at the converter
All connectors are located at the bottom side of the converter.
USB
123
DEF
ABC
456
GHI JKL MNO
789
PQRS TUV WXYZ
+/- 0
EXP
-
A/a
I/O
DISPLAY
LOGGER
MENU
12
i/o
DC in
42
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 43
OPTISONIC 6300 P
5.3 Power supply
WARNING!
Only use the supplied AC charger to charge the battery of the converter!
ELECTRICAL CONNECTIONS 5
Plug in the connector of the supplied charger at the connector 1. Then insert the main power
connector into your mains outlet.
CAUTION!
The battery status indicator will be accurate after an initial full discharge directly followed by a
full charge of the battery.
5.4 Signal cable
CAUTION!
Find the calibration numbers that are noted on the labels on the cable of each transducer. Make
sure that both transducers have the same calibration number as shown by the converter.
INFORMATION!
The signal cables are prefixed to the transducers in the factory.
USB
i/o
12
DC in
1
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
43
Page 44
5 ELECTRICAL CONNECTIONS
OPTISONIC 6300 P
Figure 5-1: Connecting signal cables
1 Connector for "UP" transducer (blue)
2 Connector for "DOWN" transducer (green)
INFORMATION!
You can measure two paths with this converter simultaneously. Use the left pair of connectors
for path 1 and the right pair for path 2.
5.5 USB connector
There are 2 USB connections available on the converter:
123
DEF
ABC
456
GHI JKL MNO
789
PQRS TUV WXYZ
EXP
+/- 0
-
A/a
1
2
1
2
1
I/O
DISPLAY
LOGGER
MENU
2
1. Read / write data to a memory stick with the USB connector (the converter acts as the master),
for transferring data (log files and site files).
2. Control the converter with a PC (the converter acts as the slave) for file management. The
memory of the converter appears as a memory in your explorer tree view, just like a memory
stick.
1. Read / write data to a memorystick
Figure 5-2: Connecting a memory stick to the converter
1 Remove the protection cap by turning the knob counter clockwise
2 Insert the memory stick
44
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 45
OPTISONIC 6300 P
Figure 5-3: Using a memory stick for a measurement
1 Perform a measurement on site and log the data to the memorystick
2 Put the memory stick in your pc and evaluate the measurement.
2. Control the converter with a PC
ELECTRICAL CONNECTIONS 5
Figure 5-4: Connecting a pc to the converter
1 I/O connector
2 USB connector
3 optional USB / I/O cable
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
45
Page 46
5 ELECTRICAL CONNECTIONS
5.6 I/O cable
To use the available inputs and outputs of the converter, you need an optional I/O box. The I/O
box is available in two versions (standard I/O functions and heat measurement version).
Figure 5-5: I/O box
1 I/O connector on converter
2 Connector of I/O box
3 I/O box with screw terminals for 1 mm
4 Screw terminal pin 1...15
2
wiring
OPTISONIC 6300 P
• Plug the connector 2 of the I/O box 3 in the connector 1 of the converter. Then use the
connectors 4 to setup the wanted I/O, as shown in the connection diagrams on the next
pages.
Versions of I/O box
Screw terminal
pin
1 Frequency / pulse output D Frequency / pulse output D
2 Frequency / pulse output D- Frequency / pulse output D-
3 Status output X Status output X
4 Status output X- Status output X-
5 Current output C+ Current output C+
6 Current output C Current output C
7 Current output C- Current output C-
8 Current input A+ Temperature sensor 1
9 Current input A-
10 Current input B+
11 Current input B-
12 Not connected Temperature sensor 2
13 Not connected
14 Not connected
15 Not connected
Table 5-1: Terminals of I/O box
Standard I/O box I/O box with heat option
(PT 100, 4 wire connection)
(PT 100, 4 wire connection)
46
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 47
OPTISONIC 6300 P
5.7 Connection diagrams
ELECTRICAL CONNECTIONS 5
mA meter
0...20 mA or 4...20 mA and other
RL is the internal resistance of the measuring point including the cable
resistance
DC voltage source (U
), external power supply, any connection polarity
ext
Table 5-2: Description of symbols
DC voltage source (U
connection diagrams
Internal DC voltage source
Controlled internal power source in the device
Electronic or electromagnetic counter
At frequencies above 100 Hz, shielded cables must be used to connect the
counters.
Ri Internal resistance of the counter
Button, NO contact or similar
), observe connection polarity according to
ext
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
47
Page 48
5 ELECTRICAL CONNECTIONS
CAUTION!
Observe connection polarity.
4...20 mA current output active
• U
• I ≤ 22 mA
• R
• Not galvanically isolated.
= 15 VDC nominal
int,nom
≤ 600 Ω
L
OPTISONIC 6300 P
Figure 5-6: Current output active I
a
Current output passive, basic I/Os
• U
• I ≤ 22 mA
• U
• R
• Not galvanically isolated.
Figure 5-7: Current output passive I
≤ 32 VDC
ext
≥ 1.8 V
0
≤ (U
L
ext-U0
)/I
max
p
48
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 49
OPTISONIC 6300 P
INFORMATION!
Pulse / frequency output
•
Any connection polarity.
•
Galvanically isolated.
Pulse/frequency output passive
• U
ext
• f
max
I ≤ 100 mA
open:
I ≤ 0.05 mA at U
closed:
U
0, max
U
0, max
• f
max
I ≤ 20 mA
open:
I ≤ 0.05 mA at U
closed:
U
0, max
U
0, max
U
0, max
• If the following maximum load resistance R
reduced accordingly by parallel connection of R:
f ≤ 100 Hz: R
f ≤ 1 kHz: R
f ≤ 10 kHz: R
• The minimum load resistance R
R
L, min
• Can also be set as a status output; for the electrical connection, see status output connection
diagram.
≤ 32 VDC
in operating menu set to f
= 32 VDC
ext
≤ 100 Hz:
max
= 0.2 V at I ≤ 10 mA
= 2 V at I ≤ 100 mA
in the operating menu set to 100 Hz < f
= 32 VDC
ext
= 1.5 V at I ≤ 1 mA
= 2.5 V at I ≤ 10 mA
= 5.0 V at I ≤ 20 mA
= 47 kΩ
L, max
= 10 kΩ
L, max
= 1 kΩ
L, max
is calculated as follows:
L, min
=(U
ext-U0
)/I
max
ELECTRICAL CONNECTIONS 5
≤ 10 kHz:
max
is exceeded, the load resistance RL must be
L, max
Pulse/frequency output active
• U
• f
• f
= 15 VDC
nom
in operating menu set to f
max
I ≤ 20 mA
open:
I ≤ 0.05 mA
closed:
U
= 15 V at I = 20 mA
0, nom
in the operating menu set to 100 Hz < f
max
I ≤ 20 mA
open:
I ≤ 0.05 mA
closed:
U
U
U
= 13.5 V at I ≤ 1 mA
0, nom
= 12.5 V at I ≤ 10 mA
0, nom
= 9.0 V at I ≤ 20 mA
0, nom
≤ 100 Hz:
max
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
≤ 10 kHz:
max
49
Page 50
5 ELECTRICAL CONNECTIONS
OPTISONIC 6300 P
• If the following maximum load resistance R
reduced accordingly by parallel connection of R:
f ≤ 100 Hz: R
f ≤ 1 kHz: R
f ≤ 10 kHz: R
• The minimum load resistance R
L, min
=(U
ext-U0
R
L, max
L, max
L, max
= 47 kΩ
= 10 kΩ
= 1 kΩ
)/I
max
is calculated as follows:
L, min
C+
C-
D
D-
is exceeded, the load resistance RL must be
L, max
Figure 5-8: Pulse frequency output active P
a
INFORMATION!
•
Any connection polarity.
•
Galvanically isolated.
Status output
• U
• I ≤ 100 mA
• R
• open:
• The output is open when the device is de-energized.
≤ 32 VDC
ext
= 47 kΩ
L, max
L, min
=(U
ext-U0
R
I ≤ 0.05 mA at U
closed:
U
U
= 0.2 V at I ≤ 10 mA
0, max
= 2 V at I ≤ 100 mA
0, max
)/I
= 32 VDC
ext
max
50
Figure 5-9: Status output / limit switch passive S
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
p
Page 51
OPTISONIC 6300 P
Current input active
• U
int, nom
• I ≤ 22 mA
• I
max
• U
0, min
• no
no HART
nono
• Not galvanically isolated
• X designates the connection terminals A or B, depending on the version of the signal
converter.
ELECTRICAL CONNECTIONS 5
= 15 VDC
≤ 26 mA (electronically limited)
= 19 V at I ≤ 22 mA
®
Figure 5-10: Current input active IIn
1 Signal
2 2-wire transmitter (e.g. temperature)
a
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
51
Page 52
6 OPERATION
6.1 Display configuration
6.1.1 Step 1: how to set up the display for showing measured values
There are two ways of setting up screens for showing measured values. Standard 4 information
screens can be shown in the measuring mode. Additional screens showing graphs can be added
when the datalogger is used. Setting up the display is done in menu nr. 2.4.3.1 via "Measurement
Setup Display Screen setup". The following menu will be shown. Page 1 and 2 show
parameters in numeric values or bar graphs or both, the graphical page shows trend graphs.
The fourth page shows status and error messages.
2.4.3.1
Page 1
Page 2
Graphical page
Default page
Default page None (cyclic)
Default page Default page
13-04-2010 14:11:09 13 MB free
The appearance of the screens can be set. None (cyclic) means that the screen page will cycle
through the 4 screens automatically. It is possible to define the default screen to display, for
instance "1st meas. page".
OPTISONIC 6300 P
2.4.3.1.4
None (cyclic)
1st meas. page
1st meas. page
1st meas. page 1st meas. page
2nd meas. page
Graphical page
Status page
13-04-2010 14:11:09 13 MB free
• Select 1st meas. page
2.4.3.1.1
Presentation mode 1
Presentation mode 1
Presentation mode 1 Presentation mode 1
Low flow cutoff threshold
Low flow cutoff hysteresis
Time constant
Line 1
13-04-2010 14:11:09 13 MB free
1 line
0 %
0%
0.1 s
• Presentation mode: Program the number of lines (number of parameters) to be shown.
• Low flow cutoff threshold and hysteresis: Use the default values.
• Time constant: Only change the default value to a higher value if the signal is unstable.
• Line 1: Select the parameter to be shown and set the display format.
INFORMATION!
2nd meas. page can be programmed in the same way.
52
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 53
OPTISONIC 6300 P
• Select Graphical page
2.4.3.1.4
None (cyclic)
1st meas. page
2nd meas. page
Graphical page
Graphical page
Graphical page Graphical page
Status page
13-04-2010 14:11:09 13 MB free
2.4.3.1.3
Parameter
Parameter
Parameter Parameter
Range 0%
Range 100%
Minimum scale
Maximum scale
Low flow cutoff threshold
low flow cutoff hysteresis
Time constant
13-04-2010 14:11:09 13 MB free
Volume flow
Volume flow
Volume flowVolume flow
0.000 m3/h
540.0 m3/h
-120 %
120 %
0 %
0 %
0.1 %
OPERATION 6
• Parameter: Select the parameter to be shown in the graph (Volume flow, Velocity of Sound or
Temperature).
• Range 0% / 100%: Program the minimum and maximum value of the measurement
• Minimum scale / maximum scale: Program the minimum and maximum value of the axis in
the graph.
• Low flow cutoff threshold / hysteresis: Use the default values.
• Time constant: Only change the default value to a higher value if the signal is unstable.
INFORMATION!
Additional screens showing trend graphs in measuring mode can be setup at the datalogger set
up, go to "Measurement Setup Logger Logger setup View log in screens".
6.1.2 Basic settings of display
To change the brightness of the display, go to menu 2.4.3.2
2.4.3.2
Brightness
Brightness
Brightness Brightness
Sleep time
13-04-2010 14:11:09 13 MB free
• Brightness: Set the percentage of the maximum brightness.
• Sleep time: Set the time after which the display turns off if no key is pressed.
50 %
50 %
50 %50 %
60 s
CAUTION!
Setting the brightness to 100% instead of 50% decreases the total operating time approximate
5%.
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
53
Page 54
6 OPERATION
6.2 Programming the transducer calibration number
• Select Settings & information:
Menu
Installation
Measurement
View logged data
File management
Settings & information
Settings & information
Settings & information Settings & information
13-04-2010 14:11:09 13 MB free
• Select Transducer sets:
Settings & information
Load factory settings
Device
Transducer sets
Transducer sets
Transducer setsTransducer sets
Information
Service
13-04-2010 14:11:09 13 MB free
OPTISONIC 6300 P
• Enter the data of the transducer sets Ta...Tc. The information is noted on a label on the cable
of the transducers and on the calibration report.
Figure 6-1: Calibration number on cable
5.3
Ta serial number
Ta serial number
Ta serial number Ta serial number
Ta calibration number
Tb serial number
Tb calibration number
Tc serial number
Tc calibration number
13-04-2010 14:11:09 13 MB free
A10 xxxxx
511505050
A10 xxxxxx
522505050
0
54
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 55
OPTISONIC 6300 P
6.3 Data logging
The measured data can be logged with the converter. The function of the data logger is explained
in this chapter.
6.3.1 Step 1: how to set up the data logger
OPERATION 6
Figure 6-2: Location of keys
1 Logger key
• Go to menu 2.4.4 with the logger button on the converter or via "Measurement Setup
Logger.
• Select Logger setup.
2.4.4
Start/stop logger now
Set start time
Set stop time
Arm/disarm logger
Logger setup
Logger setup
Logger setup Logger setup
13-04-2010 14:11:09 13 MB free
INFORMATION!
It is advised to use the same name for the site file as for the data logger file.
2.4.4.5
Filename
Filename
Filename Filename
Parameters
Sample interval
Event logging
View log in screens
13-04-2010 14:11:09 13 MB free
12345678
12345678
1234567812345678
All
60 s
• Filename: Set a filename in which the logged data will be stored. The filename can have a
maximum of eight characters, do not use the underscore character (_).
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
55
Page 56
6 OPERATION
INFORMATION!
Automatically, three numbers will be added at the end of the filename, starting with "000". Every
time a log file is created with the same filename, this number will be increased, eg 001, 002 etc.
• Parameters: Select which data must be logged (predefined sets of parameters "Flow",
"Energy" or "Analysis"). Choose "Custom" to select your own set of parameters by setting
each individual available parameter on or off.
• Sample interval: Set the interval at which the data is logged.
• Event loggings: Select if "status" or "limits" events must be logged.
• View log in screens: select if the logged data must be shown and how many screens must be
used for it.
"Sample interval"
The standard sample interval is 60 s; this means that one data point is created every minute. The
maximum number of data points in one file is 150000. If this number is exceeded during logging,
the oldest data points are overwritten. The total memory size for data logging is sufficient for 50
files, each with 150000 data points.
Calculation examples:
Velocity of sound, supply temperature and flow speed must be logged one time per minute.
This means that 150000 data points / 3 = 50000 data points are available per subject. Required is
one data point per minute, resulting in a maximum logging time of 50000 minutes = 833 hours.
OPTISONIC 6300 P
Another example:
Volume flow and velocity of sound must be logged every five seconds.
This means that 150000 data points / 2 = 75000 data points are available per subject. Required is
one data point per five seconds, so twelve data points per minute. The maximum logging time is
75000 / 12 = 6250 minutes (104 hours).
2.4.4.5
Filename
Parameters
Sample interval
Sample interval
Sample intervalSample interval
Event logging
View log in screens
13-04-2010 14:11:09 13 MB free
log
Custom
60 s
60 s
60 s 60 s
"Event logging" to log parameters exceeding pre-set limits and errors. To make use of event
logging, data logging must be on. The event logging can be filled in fully independent from the
data logging. The event logging will be logged on event regardless of the interval set.
56
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 57
OPTISONIC 6300 P
The event logging can be set to "Status", the occurrence of a pre-defined event will be logged
with time and date. The pre-defined events are "Error in device", "Application error", "Out of
specification". for more information, refer to
2.4.4.5
Filename
Parameters
Sample interval
Event logging
Event logging
Event logging Event logging
View log in screens
13-04-2010 14:11:09 13 MB free
"Limit"
If the event logger is set to "Limit" the event of a parameter exceeding a pre-set limit can be
logged.
"Measurement"
Choose the parameter for which the events should be logged.
"Threshold" and "Hysteresis"
The threshold is the limit setting. The hysteresis is the change required before the limit event
can be logged again.
Example: Threshold is set to 10 m
exceeds 10 m
has gone under 10-1= 9 m
Error messages
log
Custom
60 s
3
/h, hysteresis to 1 m3/h. An event will be logged if the flow
3
/h. Another event can only be logged after the value
3
/h.
on page 33.
OPERATION 6
"Polarity"
If the polarity stands on "Normal" the polarity of the parameter is regarded. If the polarity stands
on "Absolute value" the direction of flow is not regarded and events will be logged at for example
both negative and positive values.
"Direction"
"Normal" or "Inverse" shows the direction of exceeding the threshold setting in order to log an
event. Normal is when the threshold value is passed by an increasing value of the parameter.
2.4.4.5.4.3
Measurement
Measurement
Measurement Measurement
Threshold
Hysteresis
Polarity
Direction
13-04-2010 14:11:09 13 MB free
Volume flow
Volume flow
Volume flowVolume flow
180.0 m
3.600 m
Normal
Normal
3
/h
3
/h
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
57
Page 58
6 OPERATION
6.3.2 Step 2: how to start data logging
2.4.4
Start/stop logger now
Set start time
Set stop time
Arm/disarm logger
Logger setup
Logger setup
Logger setup Logger setup
13-04-2010 14:11:09 13 MB free
Data logging can only be done in the measurement mode.
Start logger now:
Start logger now:
Start logger now:Start logger now:
To start / stop the logger directly, select Start/stop logger now.
Start logger later:
Start logger later:
Start logger later:Start logger later:
To start the logger later, set a start and/or stop time and date for the logger. Then arm the
logger. The logger will start/stop at the set date and time.
2.4.4
Start/stop logger now
OPTISONIC 6300 P
Set start time
Set start time
Set start time Set start time
Set stop time
Arm/disarm logger
Logger setup
13-04-2010 14:11:09 13 MB free logging
6.3.3 Step 3: how to view logged data
With the UFC 300 P it is possible to view logged data. This is only possible for one logged
parameter at the time.
"View logged data", , choose saved file. Press
View logged data
Select log file
Select parameter
13-04-2010 14:11:09 13 MB free
Choose a parameter and change the percent of the scale for viewing as required. Press "Next".
A graph is displayed.
With the keys and zooming on the time scale axis is possible. The actual level of zooming is
shown in the upper left corner as a percentage and through the bar on the time scale. After
zooming in the 4 and 6 keys can be used to step to the beginning or the end of the data. The 1 and
3 key can be used to step backwards and forwards through the data.
58
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 59
OPTISONIC 6300 P
6.4 How to transfer data to a PC
6.4.1 Site files
Site files are used to save and load all configured data from different applications / sites. At the
startup of the converter, the site file is loaded that was last used. If no site file is present, the
default site file will be used.
Site files can be saved and loaded in the "Measurement" menu. When a parameter setting is
changed, the converter will ask if you want to save it when you enter the measuring mode.
CAUTION!
Make sure that site files have a valid name: minimum one character, maximum 12 characters
and underscores (_) are not allowed.
In the menu "File management Site files" you can manage your site files. You can copy,
rename or delete site files.
With the "Import" or "Export" option you can copy site files from/to a memory stick connected to
the USB port.
It is highly recommended to backup your site files on a memory stick or on your pc.
The site files are XML files. You can store, copy or rename the site files on your pc, however if you
edit a site file on your pc the site file might not have the correct format anymore and may give an
error when reading it on the converter.
OPERATION 6
By saving the default site file the parameters settings of the factory are overwritten. To restore
the factory default settings, select "Settings and information Load factory settings". If the
default site file is deleted the converter will create a new one at the next startup of the device.
File management Site files
Import
Rename
Copy
Export
Delete
13-04-2010 14:11:09 13 MB free
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
59
Page 60
6 OPERATION
6.4.2 Log files
Log files can be managed on the converter itself. You can rename, copy or delete log files. You
can find this option in the file management menu (4.2). All log files are stored on the converter as
binary files.
File management Log files
Import
Rename
Copy
Export
Delete
Export to CSV
13-04-2010 14:11:09 13 MB free
With the import and export function you can transfer the log files in their original format.
The Export to CSV option is only possible when a memory stick is connected to the converter.
The converter exports the log files to the memory stick as a CSV (Comma Seperated Value) file.
INFORMATION!
The value's in the log file are separated with a ";" and "." is used as a decimal separator. A
thousands separator is not used. Use the correct settings in Excel during the import of a CSV file.
OPTISONIC 6300 P
CAUTION!
Make sure that log files have a valid name: minimum one character, maximum 12 characters
and underscores (_) are not allowed.
60
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 61
OPTISONIC 6300 P
6.4.3 Managing your files from your pc
The converter can be connected to a pc with a USB cable (option). The memory of the converter is
shown in the explorer treeview on your pc in a similar way as a memory stick.
The site files are stored in \pcf\data\configuration (as .XML files).
The log files are stored in \pcf\data\log (as .log files).
You can copy the configuration and log files to your pc for backup and storage. You can copy
configuration files that were created with the UFC 300 P emulation software on your pc.
You can copy log files that were created during earlier data logging sessions on a UFC 300 P to
the UFC 300 P.
CAUTION!
Do not create / change other files than the ones mentioned. Do not delete other files or folders
from the signal converter.
When the converter is connected to your pc you can not convert log files to CSV format on the
converter. This will only work with a memory stick connected to the converter.
Emulation of the signal converter operation on a pc
Emulation of the signal converter operation on a pc
Emulation of the signal converter operation on a pcEmulation of the signal converter operation on a pc
OPERATION 6
On the memory stick provided with the OPTISONIC 6300 P there is a folder "UFC400emul". In this
folder there is a file named "pcf.exe". Start this program and you can load site files, change
settings and store them. You can also convert logged data to CSV format. The CSV file will be
stored in the \win32 folder. With this program of course there is no measurement function
available.
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
61
Page 62
6 OPERATION
6.5 Menu description
Menu Start-up
Menu item Remarks
Language Selection of language from list
Time and date Enter date and time
Units Selection of units from list
Size
Volume flow
Text Only if free unit is chosen
m3/s factor
Velocity
Volume
Text Only if free unit is chosen
m3 factor
Viscosity
Temperature
Temperature difference
Density
Text Only if free unit is chosen
kg/m3 factor
Energy
Text Only if free unit is chosen
J factor Only if free unit is chosen
Power
Text Only if free unit is chosen
W factor Only if free unit is chosen
Specific heat
Continue
OPTISONIC 6300 P
Only if free unit is chosen
Only if free unit is chosen
Only if free unit is chosen
62
Menu 1: Installation
Menu nr Menu item Remarks
1 Pipe configuration Selection from list
2 (Pipe 1 data 1)
1 Pipe tag
2 Outer diameter
3 Material
4 Wall thickness
5 Liner material
6 Liner thickness
3 (Pipe 1 data 2)
1 Fluid
2 VoS fluid
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 63
OPTISONIC 6300 P
Menu nr Menu item Remarks
4 (Copy data pipe 1)
5 (Pipe 2 data 1)
6 (Pipe 2 data 2)
7 (Sensor 1 advice)
8 (Sensor 1 position)
9 (Sensor 1 warning) No check
10 (Sensor 1 position)
11 (Sensor 1 warning) No check
12 (Sensor 1 test)
OPERATION 6
3 Viscosity
1 Pipe tag
2 Outer diameter
3 Material
4 Wall thickness
5 Liner material
6 Liner thickness
1 Fluid
2 VoS fluid
3 Viscosity
1 Transducer set
2 Calibration number
3 Number of traverses
1 Advised Sensor position
2 Signal quality
1 No signal
2 Shift sensor position
1 Gain
2 Signal quality
3 Change settings
4 Continue
5 Abort installation
1 Advised sensor position
2 Actual sensor position
1 VoS out of range
2 Shift sensor position
1 Gain
2 Signal quality
3 Change settings
4 Continue
5 Abort installation
1 Volume flow
2 Velocity of sound
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
63
Page 64
6 OPERATION
Menu nr Menu item Remarks
3 Signal quality
4 Optimize position
13 (Sensor 2 advice)
1 Transducer set
2 Calibration number
3 Number of traverses
14 (Sensor 2 position)
1 Advised transducer position
2 Signal quality
15 (Sensor 2 warning) No check
1 No signal
2 Shift sensor position
3 Change settings
4 Continue
5 Abort installation
16 (Sensor 2 position)
17 (Sensor 2 warning) No check
1 VoS out of range
2 Shift sensor position
3 Change settings
4 Continue
5 Abort installation
18 (Sensor 2 test)
1 Volume flow
2 Velocity of sound
3 Signal quality
4 Optimize position
19 (Status)
1 Sensor 1 status
2 Signal quality
3 Sensor 2 status
4 Signal quality
20 (Save site?)
1 Site name
2 Cancel Move to main Menu
3 Skip saving Move to Measurement
4 Save site file Move to Measurement
OPTISONIC 6300 P
1 Gain
2 Signal quality
1 Gain
2 Signal quality
64
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 65
OPTISONIC 6300 P
Menu 2: Measurement
Menu nr Menu item Remarks
X Site name
1 Display measurements
2 Load site
3 Save current site
4 Setup
1 Units
1 Size
2 Volume flow Selection from list
Text Only if free unit is chosen
m3/s factor
3 Velocity
4 Volume Selection from list
Text Only if free unit is chosen
m3 factor
5 Viscosity Selection from list
6 Temperature Selection from list
7 Temperature difference Selection from list
8 Density Selection from list
Text Only if free unit is chosen
kg/m3 factor
9 Energy Selection from list
Text Only if free unit is chosen
J factor Only if free unit is chosen
10 Power Selection from list
Text Only if free unit is chosen
W factor Only if free unit is chosen
11 Specific heat Selection from list
2 Process input
1 Pipe 1
1 Calibration
1 Zero calibration Selection from list
2 Meter factor
3 Reynolds correction Selection from list
2 Filter
1 Limitation minimum
2 Limitation maximum
3 Flow direction Selection from list
4 Time constant
5 Low flow cutoff treshold
6 Low flow cutoff
hysteresis
Only if free unit is chosen
Only if free unit is chosen
Only if free unit is chosen
OPERATION 6
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
65
Page 66
6 OPERATION
Menu nr Menu item Remarks
3 Display
OPTISONIC 6300 P
3 Plausibility
1 Error limit
2 Counter decrease
3 Counter limit
2 Pipe 2 Same as "Pipe 1"
3 Heat
1 Function Selection from list
2 Temperature input Selection from list
3 Supply temperature
4 Return temperature
5 Sensor location Selection from list
6 Fluid
7 Glycol % volume (Water/Glycol mixture)
8 Density
9 Specific heat
4 Volume flow calculation Selection from list
1 Screen setup
1 Page 1
1 Presentation mode Selection from list
2 Low flow cutoff threshold
3 Low flow cutoff
hysteresis
4 Time constant
5 Line 1
1 Parameter Selection from list 1
2 Presentation format Selection from list
3 Range 0%
4 Range 100%
6 Line 2
1 Parameter Selection from list 1
2 Presentation format Selection from list
3 Range 0%
4 Range 100%
2 Page 2 Same as "Page 1"
3 Graphical page
1 Parameter Selection from list 1
2 Range 0%
3 Range 100%
4 Minimum scale
5 Maximum scale
6 Low flow cutoff threshold
66
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 67
OPTISONIC 6300 P
Menu nr Menu item Remarks
OPERATION 6
7 Low flow cutoff
8 Time constant
9 Time scale
4 Default page Selection from list
2 Display settings
1 Brightness
2 Sleep time
4 Logger
1 Start/stop logger now Selection from list
2 Set start time
3 Set stop time
4 Arm/disarm logger Selection from list
5 Logger setup
1 Filename
2 Parameters
1 All
2 Flow
3 Energy
4 Analysis
5 Custom Selection from list 1
3 Sample interval
4 Event logging
1 Function Selection from list
2 Status Selection from list
3 Limit
1 Measurement Selection from list 1
2 Polarity Selection from list
3 Direction Selection from list
5 View log in screens
1 number of screens Selection from list
2 Screen 1
1 Time scale
2 Layout Selection from list
3 Graph 1
4 Graph 2 Same as "Graph 1"
5 Graph 3 Same as "Graph 1"
hysteresis
Threshold
Hysteresis
1 Parameter List acc. To "logger setup -
Parameters selection"
2 Minimum scale
3 Maximum scale
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
67
Page 68
6 OPERATION
Menu nr Menu item Remarks
5 I/O
OPTISONIC 6300 P
6 Graph 4 Same as "Graph 1"
3 Screen 2 as Screen 1
4 Screen 3 as Screen 1
5 Screen 4 as Screen 1
1 Current output
1 Function Selection from list
2 Range 0%
3 Range 100%
4 Extended range min
5 Extended range max
6 Error current
7 Error condition
8 Measurement Selection from list 1
9 Range 0%
10 Range 100%
11 Polarity Selection from list
12 Limitation minimum
13 Limitation maximum
14 Low flow cutoff threshold
15 Low flow cutoff
hysteresis
16 Time constant
17 4mA trimming
18 20mA trimming
2 Current inputs
1 Function Selection from list
2 Extended range A 0%
3 Extended range A 100%
4 Extended range B 0%
5 Extended range B 100%
6 Temperature range A 0%
7 Temperature range A
100%
8 Temperature range B 0%
9 Temperature range B
100%
10 Time constant A
11 Time constant B
12 4mA trimming A
13 20mA trimming A
14 4mA trimming B
15 20mA trimming B
68
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 69
OPTISONIC 6300 P
Menu nr Menu item Remarks
OPERATION 6
3 Status output / limit
1 Function Selection from list
2 Status output
1 mode Selection from list 1
2 invert signal Selection from list
3 Limit switch
1 Measurement Selection from list 1
2 Threshold
3 Hysteresis
4 Polarity Selection from list
5 Time constant
6 Invert signal Selection from list
4 Frequency / pulse output
1 Function Selection from list
2 Frequency output
1 Pulse shape Selection from list
2 Pulse width
3 100% pulse rate
4 Measurement Selection from list 1
5 Range 0%
6 Range 100%
7 Polarity Selection from list
8 Limitation minimum
9 Limitation maximum
10 Low flow cutoff threshold
11 Low flow cutoff
12 Time constant
13 Invert signal Selection from list
3 Pulse output
1 Pulse shape Selection from list
2 Pulse width
3 Maximum pulse rate
4 Measurement Selection from list 1
5 Pulse value unit Selection from list
6 Value per pulse
7 Polarity Selection from list
8 Low flow cutoff threshold
9 Low flow cutoff
10 Time constant
11 Invert signal Selection from list
5 Simulation
switch
hysteresis
hysteresis
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
69
Page 70
6 OPERATION
Menu nr Menu item Remarks
6 Counters
7 Reset errors Selection from list
1 Items shown are dependent on settings in other menu items, e.g. 1 pipe / 2 pipes, 1 path / 2 paths, energy on / off, flow
calculation on / off etc.
OPTISONIC 6300 P
1 Output Selection from list
2 Set simulation value
1 Counter 1
1 Function of counter Selection from list
2 Measurement Selection from list 1
3 Low flow cutoff treshold
4 Low flow cutoff
hysteresis
5 Preset value
6 Reset counter Selection from list
7 Set counter
1 Value
2 Set counter Selection from list
8 Stop counter Selection from list
9 Start counter Selection from list
2 Counter 2 Same as "Counter 1"
3 Counter 3 Same as "Counter 1"
4 Counter 4 Same as "Counter 1"
Menu 3: View logged data
Menu nr Menu item Remarks
3 View logged data
1 Select log file
2 Select parameter configured list
3 (Range setting)
1 Offset
2 Limit
3 Next
4 3 Next
Menu 4: File management
Menu nr Menu item Remarks
1 Site files Selection from list
1 Import
2 Rename
3 Copy
4 Export
5 Delete
2 Log files
70
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 71
OPTISONIC 6300 P
Menu nr Menu item Remarks
Menu 5: Settings and information
Menu number Menu item Remarks
1 Load factory settings Selection from list
2 Device
1 Tag
2 Language
3 Time and date
4 Start-up sequence ? Selection from list
5 Password In measuring mode the password blocks the
3 Transducer sets
1 Ta serial number
2 Ta calibration number
3 Tb serial number
4 Tb calibration number
5 Tc serial number
6 Tc calibration number
4 Information Information on hardware and software
1 General
2 Components
3 Operating hours
OPERATION 6
1 Import
2 Rename
3 Copy
4 Export
5 Delete
6 Export to CSV
measurement mode after the display sleep
time has passed. The measurement mode
can only be left after typing the password.
versions and serial numbers. Not required
for day to day use but may be asked for
when support from the supplier is required.
1 Identification number
2 Device serial number
3 Electronic serial number
1 Device
2 Sensor CPU Same as "Device"
3 Sensor DSP Same as "Device"
4 Sensor driver Same as "Device"
5 Current output Same as "Device"
6 Current input A Same as "Device"
7 Current input B Same as "Device"
8 UI controller Same as "Device"
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
71
Page 72
6 OPERATION
Menu number Menu item Remarks
OPTISONIC 6300 P
5 Service These settings are specific for the
1 Signal data
1 Signal path 1 Selection from list
2 Signal path 2 Selection from list
3 Window path 1
1 Method Selection from list
2 Window size
3 Window weight
4 Window minimum
5 Window start
6 Window end
4 Window path 2 Same as "Window path 1"
5 Detection path 1
1 Method Selection from list
2 Trigger level
3 Trigger margin
4 Dead time
6 Detection path 2 Same as "Detection path 1"
2 Service calibration
1 zero device
1 path 1
2 path 2
2 zero converter
1 path 1
2 path 2
3 Reset to defaults Selection from list
ultrasonic measurement operation.
Changing service settings may affect proper
operation of the instrument. It is advised
that changing of these parameters is
performed by qualified engineers only.
72
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 73
OPTISONIC 6300 P
7.1 Spare parts availability
The manufacturer adheres to the basic principle that functionally adequate spare parts for each
device or each important accessory part will be kept available for a period of 3 years after
delivery of the last production run for the device.
This regulation only applies to spare parts which are subject to wear and tear under normal
operating conditions.
7.2 Availability of services
The manufacturer offers a range of services to support the customer after expiration of the
warranty. These include repair, maintenance, technical support and training.
INFORMATION!
For more precise information, please contact your local sales office.
7.3 Returning the device to the manufacturer
SERVICE 7
7.3.1 General information
This device has been carefully manufactured and tested. If installed and operated in accordance
with these operating instructions, it will rarely present any problems.
CAUTION!
Should you nevertheless need to return a device for inspection or repair, please pay strict
attention to the following points:
•
Due to statutory regulations on environmental protection and safeguarding the health and
safety of our personnel, manufacturer may only handle, test and repair returned devices that
have been in contact with products without risk to personnel and environment.
•
This means that the manufacturer can only service this device if it is accompanied by the
following certificate (see next section) confirming that the device is safe to handle.
CAUTION!
If the device has been operated with toxic, caustic, flammable or water-endangering products,
you are kindly requested:
•
to check and ensure, if necessary by rinsing or neutralising, that all cavities are free from
such dangerous substances,
•
to enclose a certificate with the device confirming that is safe to handle and stating the
product used.
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
73
Page 74
7 SERVICE
7.3.2 Form (for copying) to accompany a returned device
Company: Address:
Department: Name:
Tel. no.: Fax no.:
Manufacturer's order no. or serial no.:
The device has been operated with the following medium:
OPTISONIC 6300 P
This medium is: water-hazardous
toxic
caustic
flammable
We checked that all cavities in the device are free from such
substances.
We have flushed out and neutralized all cavities in the
device.
We hereby confirm that there is no risk to persons or the environment through any residual media
contained in the device when it is returned.
Date: Signature:
Stamp:
7.4 Disposal
CAUTION!
Disposal must be carried out in accordance with legislation applicable in your country.
74
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 75
OPTISONIC 6300 P
8.1 Measuring principle
• Like canoes crossing a river, acoustic signals are transmitted and received along a diagonal
measuring path.
• A sound wave going downstream with the flow travels faster than a sound wave going
upstream against the flow.
• The difference in transit time is directly proportional to the mean flow velocity of the medium.
TECHNICAL DATA 8
Figure 8-1: Measuring principle
1 Transducer A
2 Transducer B
3 Flow velocity
4 Transit time from transducer A to B
5 Transit time from transducer B to A
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
75
Page 76
8 TECHNICAL DATA
8.2 Technical data
INFORMATION!
•
The following data is provided for general applications. If you require data that is more
relevant to your specific application, please contact us or your local sales office.
•
Additional information (certificates, special tools, software,...) and complete product
documentation can be downloaded free of charge from the website (Download Center).
Measuring system
Measuring principle Ultrasonic transit time
Application range Flow measurement of liquids
Measured value
Measured value
Measured valueMeasured value
Primary measured value Transit time
Secondary measured value Volume flow, mass flow, flow speed, flow direction, speed of sound, gain,
OPTISONIC 6300 P
signal to noise ratio, diagnosis value, reliability of flow measurement,
quality of acoustic signal, thermal energy (requires input of temperature
(2x)).
Design
The measurement system consists of one or two measuring sensors and
a portable signal converter.
Signal converter
Signal converter
Signal converterSignal converter
Portable housing UFC 300 P
Measuring sensor
Measuring sensor
Measuring sensorMeasuring sensor
Standard Single or dual rail sensors with 1 or 2 MHz transducers
Optional OPTISONIC 6300 flow sensors using cable adapters
Diameter ranges
Diameter ranges
Diameter rangesDiameter ranges
DN15...150 / ½...6" One rail, 2 MHz transducers
Outer diameter must be at least 20 mm / ¾".
DN50...250 / 2...10" One rail, 1 MHz transducers
DN200...1500 / 8...60" Two rails, 1 MHz transducers
Options
Options
OptionsOptions
Outputs 0(4)...20 mA, pulse, frequency and/or status output
Inputs 0(4)...20 mA (2x) with optional I/O box.
Counters 4 internal counters with a maximum of 8 counter places, for counting
USB 1x host port (PC can use OPTISONIC 6300 P as a removable media
Self diagnostics Integrated verification, diagnostic functions: flowmeter, process,
volume, energy and/or mass units.
device)
1x slave (memory stick can be written by converter)
measured value, empty pipe detection, bar graph.
76
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 77
OPTISONIC 6300 P
Display and user interface
Display and user interface
Display and user interfaceDisplay and user interface
Graphic display 4.3" TFT with LED backlight, daylight readable
Operator input elements 21 Key tactile keypad:
Display functions
Display functions
Display functionsDisplay functions
Menu Wizard for setup and configuration of measurements.
Thermal energy
measurement
Data logger Logging of selected measured / calculated values. Data to be logged and
Language of display texts English, French, German, Italian, Spanish.
Units Metric, British and US units selectable from list / free unit.
TECHNICAL DATA 8
272x480 dots resolution
The readability of the display could be reduced at ambient temperatures
below -25°C / -13°F.
1 on/off key
4 cursor keys for menu operation
12 keys for alpha / numerical input (SMS style)
4 function keys for direct access to main functions
Support for the configuration of 2 path / 2 pipe or 2 path / 1 pipe
measurement.
Averaging, adding or subtracting of measurement results of 2 path
measurements.
Storage of measurement configurations as site file.
Maximum of site files is 100.
Measurement data can be displayed as value or as bar or trend graph.
By input of 2 temperature sensors providing a temperature difference,
thermal energy can be calculated.
time interval can be set. A maximum number of 150000 values / 50 files
can be stored. Display of logged data through line graphs.
Other languages on request.
Measuring accuracy
Reference conditions Medium: water
Temperature: 20°C / 68°F
Straight inlet section: 10 DN
Maximum measuring error ±1% of the measured value for DN≥50 mm / 2" and v > 0.5 m/s / 1.5 ft/s
±3% of the measured value for DN<50 mm / 2" and v > 0.5 m/s / 1.5 ft/s
Repeatability <±0.2%
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
77
Page 78
8 TECHNICAL DATA
Operating conditions
Temperature
Temperature
TemperatureTemperature
Process temperature Standard version: -40...+120°C / -40...+248°F
Ambient temperature Sensor: -40...+70°C / -40...+158°F
Storage temperature -30…+80°C / -22…+176°F
Pipe specifications
Pipe specifications
Pipe specificationsPipe specifications
Material Metal, plastic, ceramic, asbestos cement, internal / external coated
Pipewall thickness < 200 mm / 7.87"
Liner thickness < 20 mm / 0.79"
Media properties
Media properties
Media propertiesMedia properties
Physical condition Liquids
Viscosity < 100 cSt (general guideline)
Permissible gas content
(volume)
Permissible solid content
(volume)
Recommended flow velocity 0.5...20 m/s
OPTISONIC 6300 P
Signal converter: -20…+55°C / -4…+131°F
(Humidity: 5...80%, non condensing)
(Humidity: 5...80%, non condensing)
pipes (coatings and liners fully bonded to pipe wall)
For detailed information please contact your local representative.
≤ 2%
≤ 5%
Installation condititions
Measurement configuration Single pipe, single path
Single pipe, dual path
Dual pipe, dual path
Inlet run ≥ 10 DN straight length
Outlet run ≥ 5 DN straight length
Dimensions and weights For detailed information refer to
Dimensions and weights
on page 82.
Materials
Sensor Anodized aluminum (rail)
Converter Polyamide PA12, covered with TPE soft touch layer on the sides
Trunk on wheels Polypropylene
78
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 79
OPTISONIC 6300 P
Electrical connections
Power supply Adapter for 100…240 VAC (-10% / +10%), 47...63 Hz
Signal cable double shielded, internal triax, length: 3 m / 15 ft
USB ports 1x for PC, 1x for memorystick
Inputs / outputs 15 pin connector for I/O interfacing with optional I/O box
TECHNICAL DATA 8
Adapter voltage: 13.2 V
Maximum power consumption: 10 W (25 W during charging)
Charging time: 8 hours
Battery type: Lithium polymer
Battery lifetime:
Battery lifetime:
Battery lifetime:Battery lifetime:
Measuring operation (display at 50% brightness): 14 hours
Optional: PT100 input:
Optional: PT100 input:
Optional: PT100 input:Optional: PT100 input:
Function: PT 100 temperature input by 2x KROHNE TT30C temperature
transmitters build into an I/O box
For specifications see TT30C datasheet.
Optional: temperature input:
Optional: temperature input:
Optional: temperature input:Optional: temperature input:
Function: temperature input by 2x KROHNE TSR-W 30 clamp-on
temperature sensors only in combination with I/O box with temperature
transmitters.
For specifications see TSR-W 30 datasheet.
Inputs and outputs
Connections Inputs and outputs can only be connected using the optional I/O box.
Description of used
abbreviations
Current output
Current output
Current outputCurrent output
Isolation The output is not galvanically isolated from the other circuits.
Output data All analog measurement parameters like volume and mass flow (at
Settings Q = 0%: 0…20 mA; Q = 100%: 10…21.5 mA
Operating data
Active U
Passive U
U
= external voltage
ext
= load + resistance
R
L
Uo = terminal voltage
= nominal current
I
nom
constant density), flow speed, speed of sound, gain, signal to noise ratio,
reliability of flow measurement, quality of acoustic signal, thermal
energy (requires input of temperature (2x)).
Error identification: 0…22 mA
= 15 VDC
int,nom
I ≤ 22 mA
RL ≤ 450 Ω
≤ 32 VDC
ext
I ≤ 22 mA
≥ 1.8 V at I = 22 mA
U
0
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
79
Page 80
8 TECHNICAL DATA
Pulse or frequency output
Pulse or frequency output
Pulse or frequency outputPulse or frequency output
Isolation The output is galvanically isolated from the other circuits.
Output data For pulse counting and/or analog output: Volume flow, mass flow,
Function Can be set as a pulse output or frequency output
Settings For Q = 100%: 0.01...10000 pulses per second or pulses per unit volume
Operating data
Active U
Passive U
OPTISONIC 6300 P
thermal energy (requires input of temperature (2x)
As analog output: Flow speed, speed of sound, gain, signal to noise ratio,
reliability of flow measurement, quality of acoustic signal
Pulse width: setting automatic, symmetric or fixed (0.05...2000 ms)
= 15 VDC
nom
ffff
≤ 100 Hz:
100 Hz:
100 Hz: 100 Hz:
max
max
maxmax
I ≤ 20 mA
open:
I ≤ 0.05 mA
closed:
= 15 V at I = 20 mA
U
0,nom
100 Hz < f
100 Hz < f
100 Hz < f100 Hz < f
I ≤ 20 mA
open:
I ≤ 0.05 mA
closed:
U
0,nom
U
0,nom
U
0,nom
≤ 32 VDC
ext
ffff
≤ 100 Hz:
max
max
maxmax
I ≤ 100 mA
open:
I ≤ 0.05 mA at U
closed:
U
0, max
U
0, max
100 Hz < f
100 Hz < f
100 Hz < f100 Hz < f
I ≤ 20 mA
open:
I ≤ 0.05 mA at U
closed:
U
0, max
U
0, max
U
0, max
≤ 10 kHz:
10 kHz:
10 kHz: 10 kHz:
max
max
maxmax
= 13.5V at I=1mA
= 12.5 V at I = 10 mA
= 9 V at I = 20 mA
100 Hz:
100 Hz: 100 Hz:
= 32 VDC
ext
= 0.2 V at I ≤ 10 mA
= 2 V at I ≤ 100 mA
≤ 10 kHz:
10 kHz:
10 kHz: 10 kHz:
max
max
maxmax
=32VDC
ext
= 1.5 V at I ≤ 1mA
= 2.5 V at I ≤ 10 mA
= 5.0 V at I ≤ 20 mA
80
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 81
OPTISONIC 6300 P
Status output
Status output
Status outputStatus output
Isolation The output is galvanically isolated from the other circuits.
Function and settings Settable as automatic measuring range change, indicator for direction of
Operating data
Active U
Passive U
Current inputs
Current inputs
Current inputsCurrent inputs
Isolation The inputs are not galvanically isolated from the other circuits.
Function Input of temperature, used for energy calculation in combination with
Operating data
Active U
Passive U
TECHNICAL DATA 8
flow, overflow, error, operating point or empty pipe detection
Status and/or control: ON or OFF
= 15 VDC
int
I ≤ 20 mA
open:
I ≤ 0.05 mA
closed:
= 15 V at I = 20 mA
U
0, nom
≤ 32 VDC
ext
I ≤ 100 mA
open:
I ≤ 0.05 mA at U
closed:
= 0.2 V at I ≤ 10 mA
U
0, max
U
= 2 V at I ≤ 100 mA
0, max
flow measurement
Range: -50...500°C / -58...932°F (default: 0...120°C / -32...248°F)
= 15 VDC
int
I ≤ 22 mA
= 26 mA (electronically limited)
I
max
U
= 9 V with I ≤ 22 mA
0, min
≤ 32 VDC
ext
®
No HART
I ≤ 22 mA
= 26 mA (electronically limited)
I
max
U
= 5 V with I ≤ 22 mA
0, max
No HART
®
=32VDC
ext
Approvals and certificates
CE
CE
CECE
This device fulfills the statutory requirements of the EC directives.
The manufacturer certifies successful testing of the product by applying
the CE mark.
Electromagnetic compatibility Directive: 2004/108/EC
Harmonized standard: EN 61326-1: 2006
Low voltage directive Directive: 2006/95/EC
Harmonized standard: EN 61010: 2001
Other approvals and standards
Other approvals and standards
Other approvals and standardsOther approvals and standards
Protection category acc. to
IEC 529 / EN 60529 /
NEMA 250/2003
Shock test sensor IEC 60068-2-27
Vibration test sensor IEC 60068-2-64
Sensor: IP 67 / NEMA 6
Converter: IP 65 / NEMA 4
Trunk on wheels: IP 67 / NEMA 6
Power adapter: IP 40 / NEMA 1
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
81
Page 82
8 TECHNICAL DATA
8.3 Dimensions and weights
8.3.1 Clamp-on sensor
Dimensions [mm] Approx. weight
L H W
OPTISONIC 6300 P
[kg]
406 76 39.2 2.1 1
1 with transducers / cable, without mounting strap
Dimensions [inches] Approx. weight
[lb]
L H W
16.0 3.0 2.5 4.6 1
1 with transducers / cable, without mounting strap
82
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 83
OPTISONIC 6300 P
8.3.2 Converter
TECHNICAL DATA 8
123
456
GHI JKL MNO
789
PQRS TUV WXYZ
+/- 0
A/a
ABC DEF
-
I/O
DISPLAY
LOGGER
EXP
MENU
Dimensions UFC 300 P converter
Dimensions [mm] Approx. weight
a b c d
247 289 168 66 1.6
Dimensions [inch] Approx. weight
a b c d
9.7 11.4 6.6 2.6 3.5
[kg]
[lb]
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
83
Page 84
8 TECHNICAL DATA
8.3.3 I/O box
OPTISONIC 6300 P
a
b
b
c
Dimensions I/O box
Dimensions [mm] Approx. weight [kg]
a b c
112.5 84.6 41.3 0.2
Dimensions [inch] Approx. weight [lb]
a b c
4.4 3.3 1.6 0.44
84
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 85
OPTISONIC 6300 P
8.3.4 Trunk on wheels
Dimensions trunk on wheels
Dimensions [mm] Approx. weight [kg]
a b c
TECHNICAL DATA 8
565 374 241 6.2
Dimensions [inch] Approx. weight [lb]
a b c
22.2 14.7 9.5 13.7
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
85
Page 86
9 NOTES
OPTISONIC 6300 P
86
www.krohne.com 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
Page 87
OPTISONIC 6300 P
NOTES 9
www.krohne.com03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en
87
Page 88
KROHNE product overview
• Electromagnetic flowmeters
• Variable area flowmeters
• Ultrasonic flowmeters
• Mass flowmeters
• Vortex flowmeters
• Flow controllers
• Level meters
• Temperature meters
• Pressure meters
• Analysis products
• Products and systems for the oil & gas industry
• Measuring systems for the marine industry
Head Office KROHNE Messtechnik GmbH
Ludwig-Krohne-Str. 5
47058 Duisburg (Germany)
Tel.:+49 (0)203 301 0
Fax:+49 (0)203 301 10389
info@krohne.de
The current list of all KROHNE contacts and addresses can be found at:
© KROHNE 03/2013 - 4000972603 - MA OPTISONIC 6300 P R03 en - Subject to change without notice.
www.krohne.com
Loading...
