JLG G6-23A Operator Manual

Download

Operation & Safety

An Oshkosh Corporation Company

Manual

Original Instructions

Keep this manual with machine at all times.

Models

G6-42A, G9-43A

& G10-43A

G6-42A

S/N 0160048658 & After

G9-43A & G10-43A

S/N 0160048671 & After

excluding 0160048773

31200744

Revised

October 1, 2014

CALIFORNIA PROPOSITION 65

BATTERY WARNING

Battery posts,

terminals and related

accessories contain

lead and lead compounds,

chemical known to the

State of California

to cause cancer and

reproductive harm.

WASH HANDS

AFTER HANDLING!

CALIFORNIA PROPOSITION 65

EXHAUST WARNING

Diesel Engine exhaust and

some of its constituents

are known to the State of

California to cause cancer,

birth defects and other

reproductive harm.

Revision Log

September 28, 2012 - A - Original Issue of Manual

November 16, 2012 - B - Revised pages 3-6, 9-6 & 9-7.

July 31, 2013 - C - Revised cover and pages 1-6, 1-7, 1-14, 1-15, 2-3, 2-4, 2-5, 2-6, 2-7, 3-2, 3-3, 3-4, 3-5, 3-14, 3-22, 3-24, 4-10, 5-2, 5-15, 6-2, 8-1, 8-2, 9-3, 9-4, 9-5 & 9-6.

October 1, 2014 - D - Revised cover and pages 1-13, 2-4, 2-7, 3-2, 3-3, 3-4, 3-5, 3-22, 5-11, 8-1, 8-2, 9-1 & 9-3.

REVISION LOG

a31200744

Read This First

This manual is a very important tool! Keep it with the machine at all times.

The purpose of this manual is to provide owners, users, operators, lessors, and lessees with the precautions and operating procedures essential for the safe and proper machine operation for its intended purpose.

Due to continuous product improvements, JLG Industries, Inc. reserves the right to make specification changes without prior notification. Contact JLG Industries, Inc. for updated information.

Operator Qualifications

The operator of the machine must not operate the machine until this manual has been read, training is accomplished and operation of the machine has been completed under the supervision of an experienced and qualified operator. Operation within the U.S.A. requires training per OSHA 1910.178.

Operators of this equipment must possess a valid, applicable driver’s license, be in good physical and mental condition, have normal reflexes and reaction time, good vision and depth perception and normal hearing. Operator must not be using medication which could impair abilities nor be under the influence of alcohol or any other intoxicant during the work shift.

In addition, the operator must read, understand and comply with instructions contained in the following material furnished with the telehandler:

• This Operation & Safety Manual

• Telehandler Safety Manual (ANSI only)

• All instructional decals and plates

• Any optional equipment instructions furnished

The operator must also read, understand and comply with all applicable Employer, Industry and Governmental rules, standards and regulations.

Modifications

Modifications to this machine may affect compliance with Industry Standards and/or Governmental Regulations. Any modification must be approved by JLG.

b 31200744

Read This First

This product must comply with all safety related bulletins. Contact JLG Industries, Inc. or the local authorized JLG representative for information regarding safetyrelated bulletins which may have been issued for this product.

JLG Industries, Inc. sends safety related bulletins to the owner of record of this machine. Contact JLG Industries, Inc. to ensure that the current owner records are updated and accurate.

JLG Industries, Inc. must be notified immediately in all instances where JLG products have been involved in an accident involving bodily injury or death of personnel or when damage has occurred to personal property or the JLG product.

FOR:

• Accident Reporting and Product Safety Publications

• Current Owner Updates

• Questions Regarding Product Applications and Safety

• Standards and Regulations Compliance Information

• Questions Regarding Product Modifications

CONTACT:

Product Safety and Reliability Department JLG Industries, Inc. 13224 Fountainhead Plaza Hagerstown, MD 21742 USA

or Your Local JLG Office (Addresses on back cover)

In USA:

Toll Free: 1-877-JLG-SAFE (1-877-554-7233)

Outside USA:

Phone: +1-717-485-6591

E-mail:

ProductSafety@JLG.com

c31200744

Read This First

OY2700

ULTRA LOW

SULFUR DIESEL

FUEL ONLY

S < 15 mg/kg

1001125387 A

REAR VIEW OF CAB

Other Publications Available

Service Manual..........................................................................................31200792

Illustrated Parts Manual.............................................................................31200727

Note: The following standards may be referenced in this manual: ANSI is compliant to ANSI/ITSDF B56.6 AUS is compliant to AS 1418.19 CE is compliant to EN1459 Refer to the machine Serial Number Plate to identify the applicable compliance standard.

Machine Configuration

Two configurations of each machine are included in this manual. Determine if machine is equipped with Ultra Low Sulfur Fuel Decal (1) as indicated below.

• If equipped with the Ultra Low Sulfur decal, all specific references to this machine configuration will be referred to as Ultra Low Sulfur (ULS) from this point forward.

•If not equipped with the Ultra Low Sulfur decal, all specific references to this machine configuration will be referred to as Low Sulfur (LS) from this point forward.

d 31200744

TABLE OF CONTENTS

Revision Log

Read This First

Operator Qualifications ...................................................... b

Modifications ...................................................................... b

Other Publications Available .............................................. d

Machine Configuration ....................................................... d

Table of Contents

Section 1 - General Safety Practices

1.1 Hazard Classification System ..............................................1-1

Safety Alert System and Safety Signal Words................1-1

1.2 General Precautions ............................................................1-1

1.3 Operation Safety ..................................................................1-2

Electrical Hazards ...........................................................1-2

Tip Over Hazard..............................................................1-3

Travel Hazard ................................................................. 1-6

Load Falling Hazard ........................................................1-7

Lifting Personnel .............................................................1-8

Driving Hazards On Slopes.............................................1-9

Pinch Points and Crush Hazards ..................................1-10

Fall Hazard....................................................................1-12

Chemical Hazards.........................................................1-13

1.4 ClearSky (if equipped) .......................................................1-14

Federal Communications Commission

(FCC) Information for Users..........................................1-14

Table of Contents

Section 2 - Pre-Operation and Inspection

2.1 Pre-Operation Check and Inspection...................................2-1

2.2 Safety Decals .......................................................................2-3

ANSI................................................................................2-3

ISO..................................................................................2-6

2.3 Walk-Around Inspection.....................................................2-10

2.4 Warm-Up and Operational Checks ....................................2-12

Warm-Up Check ...........................................................2-12

Operational Check ........................................................2-12

2.5 Operator Cab .....................................................................2-13

2.6 Windows ............................................................................2-14

Cab Door Window (if equipped)....................................2-14

Section 3 - Controls and Indicators

3.1 General ................................................................................3-1

3.2 Controls ...............................................................................3-2

G6-42A & G9-43A ...........................................................3-2

i31200744

Table of Contents

G10-43A ......................................................................... 3-4

Dash Controls and Indicators ......................................... 3-6

Ignition ............................................................................ 3-7

Park Brake...................................................................... 3-8

Parking Procedure.......................................................... 3-8

Transmission Control Lever.......................................... 3-10

Boom Joystick .............................................................. 3-12

Frame Level and Attachment Tilt

(if equipped) Joystick.................................................... 3-14

Auxiliary Hydraulic Joystick .......................................... 3-15

Outrigger Joysticks (G10-43A) ..................................... 3-16

Right Hand Panel ......................................................... 3-17

Accessory Control Lever (if equipped) ......................... 3-18

3.3 Steer Modes ...................................................................... 3-19

Steer Mode Change ..................................................... 3-19

3.4 Operator Seat.................................................................... 3-20

Adjustments.................................................................. 3-20

Seat Belt ....................................................................... 3-21

3.5 Reverse Sensor System (if Equipped) .............................. 3-22

3.6 Boom Angle and Extension Indicators .............................. 3-23

Section 4 - Operation

4.1 Engine ................................................................................. 4-1

Starting the Engine ......................................................... 4-1

Extreme Cold Weather Starting (if equipped) ................. 4-2

Battery Boosted Starting................................................. 4-3

Normal Engine Operation ............................................... 4-4

Shut-Down Procedure .................................................... 4-4

4.2 Operating with a Non-Suspended Load .............................. 4-5

Lift Load Safely............................................................... 4-5

Picking Up a Load .......................................................... 4-5

Transporting a Load ....................................................... 4-6

Leveling Procedure......................................................... 4-6

Placing a Load................................................................ 4-7

Disengaging a Load........................................................ 4-7

4.3 Operating with a Suspended Load ...................................... 4-8

Lift Load Safely............................................................... 4-8

Picking Up a Suspended Load ....................................... 4-8

Transporting a Suspended Load .................................... 4-9

Leveling Procedure......................................................... 4-9

Placing a Suspended Load........................................... 4-10

Disengaging a Suspended Load .................................. 4-10

4.4 Loading and Securing for Transport .................................. 4-11

Tiedown ........................................................................ 4-11

Lifting ............................................................................ 4-12

ii 31200744

Section 5 - Attachments

5.1 Approved Attachments ........................................................ 5-1

5.2 Unapproved Attachments ....................................................5-1

5.3 JLG Supplied Attachments .................................................. 5-2

5.4 Telehandler/Attachment/Fork Capacity................................ 5-4

5.5 Use of the Capacity Chart....................................................5-5

Capacity Indicator Locations ...........................................5-5

Sample Capacity Chart ...................................................5-6

Example ..........................................................................5-8

5.6 Attachment Installation ........................................................ 5-9

Mechanical Quick Switch ..............................................5-10

Hydraulic Quick Switch .................................................5-11

5.7 Hydraulic Operated Attachment.........................................5-12

5.8 Adjusting/Moving Forks......................................................5-13

5.9 Attachment Operation ........................................................5-14

Carriage with Forks .......................................................5-15

Side Shift Carriage ........................................................5-16

Side Tilt Carriage .......................................................... 5-18

Swing Carriage .............................................................5-20

Dual Fork Positioning Carriage .....................................5-22

Mast Carriage ...............................................................5-24

Mast Carriage w/Side Tilt ..............................................5-26

Fork Extension ..............................................................5-28

Fork Mounted Hook ......................................................5-30

Bucket ...........................................................................5-32

Grapple Bucket .............................................................5-34

Truss Boom...................................................................5-36

Personnel Work Platform - Fork Mounted.....................5-38

Table of Contents

Section 6 - Emergency Procedures

6.1 Towing a Disabled Product ..................................................6-1

Moving Short Distances ..................................................6-1

Moving Longer Distances ............................................... 6-1

6.2 Emergency Lowering of Boom.............................................6-2

6.3 Emergency Exit from Enclosed Cab ....................................6-2

Fixed Window (if equipped) ............................................6-2

Latch Window (if equipped) ............................................6-2

iii31200744

Table of Contents

Section 7 - Lubrication and Maintenance

7.1 Introduction.......................................................................... 7-1

Clothing and Safety Gear ............................................... 7-1

7.2 General Maintenance Instructions....................................... 7-2

7.3 Service and Maintenance Schedule .................................... 7-3

10, 1st 50 & 50 Hour Maintenance Schedule ................. 7-3

1st 250, 250 & 1st 500 Hour Maintenance Schedule ..... 7-4

500, 1000 & 1500 Hour Maintenance Schedule............. 7-5

7.4 Lubrication Schedules ......................................................... 7-6

50 Hour Lubrication Schedule ........................................ 7-6

250 Hour Lubrication Schedule ...................................... 7-7

1000 Hour Lubrication Schedule .................................... 7-8

7.5 Operator Maintenance Instructions ................................... 7-10

Fuel System.................................................................. 7-10

Air Intake System ......................................................... 7-12

Engine Oil ..................................................................... 7-16

Hydraulic Oil ................................................................. 7-17

Tires.............................................................................. 7-18

Transmission Oil........................................................... 7-21

Engine Cooling System ................................................ 7-22

Battery .......................................................................... 7-23

Windshield Washer System (if equipped)..................... 7-24

Section 8 - Additional Checks

8.1 General................................................................................ 8-1

8.2 Reverse Sensor System (if equipped)................................. 8-1

Section 9 - Specifications

9.1 Product Specifications......................................................... 9-1

Fluids .............................................................................. 9-1

Capacities....................................................................... 9-4

Tires................................................................................ 9-5

Performance ................................................................... 9-6

Dimensions..................................................................... 9-7

Index

Inspection, Maintenance and Repair Log

iv 31200744

Section 1 - General Safety Practices

DANGER

OW0010

WARNING

OW0021

CAUTION

OW0031

SECTION 1 - GENERAL SAFETY PRACTICES

1.1 HAZARD CLASSIFICATION SYSTEM

Safety Alert System and Safety Signal Words

DANGER indicates an imminently hazardous situation which, if not avoided, will

result in death or serious injury.

WARNIN G indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.

CAUTION indicates a potentiality hazardous situation which, if not avoided, may result in minor or moderate injury.

1.2 GENERAL PRECAUTIONS

WARNING

Before operation, read and understand this manual. Failure to comply with the safety precautions listed in this manual could result in machine damage, property damage, personal injury or death.

1-131200744

Section 1 - General Safety Practices

OW0040

10 FT

(3 M)

1.3 OPERATION SAFETY

Electrical Hazards

• This machine is not insulated and does not provide protection from contact or being near electrical current.

• NEVER operate the telehandler in an area where overhead power lines, overhead or underground cables, or other power sources may exist without ensuring the appropriate power or utility company de-energizes the lines.

• Always check for power lines before raising the boom.

• Follow employer, local and governmental regulations for clearance from power lines.

1-2 31200744

Section 1 - General Safety Practices

OW0050

OW0080

OW0100

4 FT

(1,2 M)

Tip Over Hazard

General

• For additional load requirements, refer to the appropriate capacity chart.

• Never use an attachment without the appropriate JLG approved capacity chart installed on the telehandler.

• Understand how to properly use the capacity charts located in cab.

• DO NOT exceed rated lift capacity.

• Be sure that the ground conditions are able to support the machine.

• DO NOT raise boom unless frame is level (0 degrees), unless otherwise noted on capacity chart.

• DO NOT level machine with boom/attachment above 4 ft (1,2 m). (AUS - DO NOT level machine with load more than 300 mm (11.8 in) above ground surface.)

1-331200744

Section 1 - General Safety Practices

OH2291

OH20911

OH2221

• MAINTAIN proper tire pressure at all times. If proper tire pressures are not maintained, this machine could tip over.

• Refer to manufacturer’s specifications for proper fill ratio and pressure requirements for tires equipped with ballast.

• Always wear the seat belt.

• Keep head, arms, hands, legs and all other body parts inside operator’s cab at all times.

If the telehandler starts to tip over:

• DO NOT JUMP

• BRACE YOURSELF and STAY WITH THE MACHINE

• KEEP YOUR SEAT BELT FASTENED

• HOLD ON FIRMLY

• LEAN AWAY FROM THE POINT OF IMPACT

1-4 31200744

Non-Suspended Load

OW0060

W0150

• DO NOT drive with boom raised.

Suspended Load

Section 1 - General Safety Practices

• Tether suspended loads to restrict movement.

• Weight of all rigging (slings, etc.) must be included as part of load.

• Beware of wind. Wind can cause a suspended load to swing and cause dangerous side loads - even with tag lines.

• DO NOT attempt to use telehandler frame-leveling to compensate for load swing.

• Keep heavy part of load closest to attachment.

• Never drag the load; lift vertically.

When driving with a suspended load:

• Start, travel, turn and stop slowly to prevent load from swinging.

• DO NOT extend boom.

• DO NOT raise the load more than 11.8 in (300 mm) above ground surface or the boom more than 45°.

• DO NOT exceed walking speed.

1-531200744

Section 1 - General Safety Practices

OAL2030

2-Wheel Front Steer 4-Wheel Circle Steer 4-Wheel Crab Steer

Travel Hazard

• Steering characteristics differ between steer modes. Identify the steer mode settings of the telehandler being operated.

• DO NOT change steer modes while traveling. Steer modes must be changed while telehandler is stationary.

• Visually verify proper wheel alignment after each steer mode change.

• Ensure that adequate clearance is provided for both rear tail swing and front fork swing.

• Look out for and avoid other personnel, machinery and vehicles in the area. Use a spotter if you DO NOT have a clear view.

• Before moving be sure of a clear path and sound horn.

• When driving, retract boom and keep boom/attachment as low as possible while maintaining visibility of mirrors and maximum visibility of path of travel.

• Always look in the direction of travel.

• Always check boom clearances carefully before driving underneath overhead obstructions. Position attachment/load to clear obstacles.

• When driving in high speed, use only front wheel steer (if steering modes are selectable).

• Telehandlers equipped with solid tires should not be used in applications requiring excessive roading or driving extended distances. In the event an application requires excessive roading or driving expanded distances, JLG recommends the use of telehandlers not equipped with solid tires.

1-6 31200744

Section 1 - General Safety Practices

OW0130

Load Falling Hazard

• Never suspend load from forks or other parts of carriage weldment. Use only JLG approved lift points.

• DO NOT burn or drill holes in fork(s).

• Forks must be centered under load and spaced apart as far as possible.

1-731200744

Section 1 - General Safety Practices

OW0170

W0190

Lifting Personnel

• When lifting personnel, USE ONLY an approved personnel work platform, with proper capacity chart displayed in the cab.

• DO NOT drive machine from cab when personnel are in platform.

1-8 31200744

Section 1 - General Safety Practices

OW0200

Driving Hazards On Slopes

To maintain sufficient traction and braking capabilities, travel on slopes as follows:

• When unloaded, drive with forks pointed downhill.

• When loaded, drive with the forks pointed uphill.

• For additional travel requirements, refer to the appropriate capacity chart.

• To avoid overspeeding the engine and drivetrain when driving down slopes, downshift to a lower gear and use the service brake as necessary to maintain a slow speed. DO NOT shift into neutral and coast downhill.

• Avoid excessively steep slopes or unstable surfaces. To avoid tip over DO NOT drive across excessively steep slopes under any circumstances.

• Avoid turning on a slope. Never engage “inching” or shift to “Neutral” when going downhill.

• DO NOT park on a slope.

1-931200744

Section 1 - General Safety Practices

OW0210

OW0220

W0230

Pinch Points and Crush Hazards

Stay clear of pinch points and rotating parts on the telehandler.

• Stay clear of moving parts while engine is running.

• Keep clear of steering tires and frame or other objects.

• Keep clear from under boom.

1-10 31200744

Section 1 - General Safety Practices

OW0240

OW0250

OW0260

OW0960

• Keep clear of boom holes.

• Keep arms and hands clear of attachment tilt cylinder.

• Keep hands and fingers clear of carriage and forks.

• Keep others away while operating.

1-1131200744

Section 1 - General Safety Practices

OW0280

OW0290

Fall Hazard

• Enter using the proper hand holds and steps provided. Always maintain 3-point contact when mounting or dismounting. Never grab control levers or steering wheel when mounting or dismounting the machine.

• DO NOT get off the machine until the shutdown procedure on page 4-4 has been performed.

• DO NOT carry riders. Riders could fall off machine causing death or serious injury.

1-12 31200744

Section 1 - General Safety Practices

OW0300

OW0950

Chemical Hazards

Exhaust Fumes

• DO NOT operate machine in an enclosed area without proper ventilation.

• DO NOT operate the machine in hazardous environments unless approved for that purpose by JLG and site owner. Sparks from the electrical system and the engine exhaust can cause an explosion.

Flammable Fuel

• DO NOT fill the fuel tank or service the fuel system near an open flame, sparks or smoking materials. Engine fuel is flammable and can cause a fire and/or explosion.

Hydraulic Fluid

• DO NOT attempt to repair or tighten any hydraulic hoses or fittings while the engine is running or when the hydraulic system is under pressure.

• Stop engine and relieve trapped pressure. Fluid in the hydraulic system is under enough pressure that it can penetrate the skin.

• DO NOT use your hand to check for leaks. Use a piece of cardboard or paper to search for leaks. Wear gloves to protect hands from spraying fluid.

1-1331200744

Section 1 - General Safety Practices

1.4 CLEARSKY (IF EQUIPPED)

Federal Communications Commission (FCC) Information for Users

FCC Statement Regarding Interference

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

Notice Regarding Radio Frequency Radiation Exposure

Do not operate your unit when a person is within eight inches (20 centimeters) of the antenna. A person or object within eight inches (20 centimeters) of the antenna could impair call quality and may cause the unit to operate at a higher power level than necessary, as well as expose that person to RF energy in excess of that established by the FCC RF Exposure Guidelines.

Important: The unit must be installed in a manner that provides a minimum separation distance of eight inches (20 centimeters) or more between the antenna and persons and just not be co-located or operate in conjunction with any other antenna or transmitter in order to satisfy FCC RF exposure requirements for mobile transmitting devices.

Important: To comply with the FCC RF exposure limits and to satisfy the categorical exclusion requirements for mobile transmitters, the requirements described in the following section, “Antenna Installation”, must be met.

1-14 31200744

Section 1 - General Safety Practices

Antenna Installation

A minimum separation distance of eight inches (20 centimeters) must be maintained between the antenna and all persons.

The combined cable loss and antenna gain must not exceed +7.5 dBi (850 band). The combined cable loss and antenna gain must not exceed +2.5 dBi and total system output must not exceed 2.0W EIRP in the PCS (1900) band in order to comply with the EIRP limit of 24.232 (b). OEM installers must be provided with antenna installation instruction and transmitter operating conditions for satisfying RF exposure compliance

1-1531200744

Section 1 - General Safety Practices

This Page Intentionally Left Blank

1-16 31200744

Section 2 - Pre-Operation and Inspection

OAH1000

PARENT METAL CRACK WELD CRACK

SECTION 2 - PRE-OPERATION AND INSPECTION

2.1 PRE-OPERATION CHECK AND INSPECTION

Note: Complete all required maintenance before operating unit.

WARNING

FALL HAZARD. Use extreme caution when checking items beyond your normal

reach. Use an approved ladder.

The pre-operation check and inspection, performed at beginning of each work shift or at each change of operator, should include the following:

1. Cleanliness - Check all surfaces for leakage (oil, fuel or battery fluid) or foreign objects. Report any leakage to the proper maintenance personnel.

2. Structure - Inspect the machine structure for dents, damage, weld or parent metal cracks or other discrepancies.

3. Safety Decals - Ensure all safety decals are legible and in place. Clean or replace as required. See page 2-3 for details.

4. Operation and Safety Manuals - Operation & Safety Manual and AEM Safety Manual (ANSI only) are located in cab manual holder.

5. Walk-Around Inspection - See page 2-10 for details.

6. Fluid Levels - Check fluids, including fuel, hydraulic oil, engine oil, transmission fluid and coolant. When adding fluids, refer to Section 7 - Lubrication and Maintenance and Section 9 - Specifications to determine proper type and intervals. Before removing filler caps or fill plugs, wipe all dirt and grease away from the ports. If dirt enters these ports, it can severely reduce component life.

7. Attachments/Accessories - Ensure correct capacity charts are installed on the telehandler. If provided, reference the Operation & Safety Manual of each attachment or accessory installed for specific inspection, operation and maintenance instructions.

2-131200744

Section 2 - Pre-Operation and Inspection

8. Operational Check - Once the walk-around inspection is complete, perform a warm-up and operational check (see page 2-12) of all systems in an area free of overhead and ground level obstructions. See Section 3 - Controls and Indicators for more specific operating instructions.

WARNING

If telehandler does not operate properly, immediately bring machine to a stop, lower boom and attachment to ground and stop the engine. Determine cause and correct before continued use.

2-2 31200744

Section 2 - Pre-Operation and Inspection

OY3131

1706850A

CRUSHINGHAZARD

Keepothers

awaywhile operating.

Loweringboom or falling load could

causedeath or serious injury.

WARNING

1706850-ENGLISH

1001163304-ENGLISH/FRENCH

1706306A

1706306-ENGLISH

1001163285-ENGLISH/FRENCH

1706299A

CONTACTING POWERLINES

willresult in death

orserious injury.

1706299-ENGLISH

1001163210-ENGLISH/FRENCH

1702300

DO NOT use Ether or other high energy starting aids.

Engine equipped with Pre-heating system.

ENGINE EXPLOSION could result in death or serious injury.

1706300C

1706300-ENGLISH

1001163212-ENGLISH/FRENCH

1001125387-ENGLISH

1001163355-ENGLISH/FRENCH

91503112

(G9-43A IF

EQUIPPED)

(G10-43A)

9150-3112 REV -

1701640

ULTRA L OW

SULFUR DIESEL

FUEL ONL Y S < 15 mg/kg

1001125387A

(OPEN CAB)

1706768-ENGLISH

1001163300-ENGLISH/FRENCH

(ENCLOSED CAB)

1001154575

1706768-ENGLISH

1001163300-ENGLISH/FRENCH

IMPORTANT

1001160071 RevA

EMERGENCYEXIT

1001160071-ENGLISH

1001160787-ENGLISH/FRENCH

(IF EQUIPPED)

BBC

VIEW B-B

(G6-42A & G9-43A)

VIEW C-C (G10-43A)

VIEW D-D

VIEW A-A

2.2 SAFETY DECALS

Ensure all DANGER, WARNING, CAUTION and instructional decals and proper capacity charts are legible and in place. Clean and replace as required.

ANSI

2-331200744

Section 2 - Pre-Operation and Inspection

1706296-ENGLISH

1001163174-ENGLISH/FRENCH

4100181

91563220

9156-3220 REVA

1706301A

1706301-ENGLISH 1001163222-ENGLISH/FRENCH

1001139578

(UNDERSIDE OF

ENGINE COVER)

1001109053 (UNDERSIDE OF ENGINE COVER)

2.5 GPM

9.5 lpm

MAX

1001109053 REVA

91163028

1706767A

1706767-ENGLISH

1001163291-

ENGLISH/FRENCH

1706851A

1706851-ENGLISH

1001163321-

ENGLISH/FRENCH

Fasten

seat belt.

1706303A

Operator must be trained and

must read and underst and

allcap acity chart s, operator

andsafety manuals.

1706303-ENGLISH

1001163273-ENGLISH/FRENCH

1706304A

RUN-OVER

HAZARD

could cause

death or

serious

injury.

1706304-ENGLISH

1001163276-

ENGLISH/FRENCH

1001109459

(G6-42A &

G9-43A, IF

EQUIPPED)

1001109459C

1001109458

(G10-43A)

(G9-43A, IF

EQUIPPED)

1001131745A

1001131745

(G6-42A, IF

EQUIPPED)

91413061

1001108847

(G10-43A)

(G6-42A & G9-43A,

IF EQUIPPED)

1001108836

(G6-42A & G9-43A,

IF EQUIPPED)

1001108836B

1001111229

(G10-43A)

1001131509

(G9-43A)

1001131509

(G10-43A)

1001118911 B

IF EQUIPPED

1000

1001130782

(G6-42A &

G9-43A)

1001130792

(G10-43A)

CAPACITY

CHARTS

1001130802 1001130920

1001160072-ENGLISH

1001160945-ENGLISH/FRENCH

(IF EQUIPPED WITH

REVERSE SENSOR SYSTEM)

OY3141

IMPORTANT

•VEHICLE EQUIPPED WITH REVERSE

SENSING SYSTEM

•THIS REVERSE SENSING SYSTEM IS

TO BE USEDASANAID ONLY

•LOOK OUT FOR AND AVOID OTHER

PERSONNEL, MACHINERYAND VEHICLES INTHEAREA

•USE A SPOTTER IF YOU DO NOT HAVE

ACLEAR VIEW

1001160072 REVA

VIEW E-E

2-4 31200744

OY2111

0 °

0°

1706302-ENGLISH

1001163223-ENGLISH/FRENCH

-10

4105262

1706298A

1706298-ENGLISH

1001163206-ENGLISH/FRENCH

91553072

1706302-ENGLISH

1001163223-ENGLISH/FRENCH

1706302-ENGLISH

1001163223-ENGLISH/FRENCH

1706302-ENGLISH

1001163223-ENGLISH/FRENCH

1706302-ENGLISH

1001163223-ENGLISH/FRENCH

VIEW F-F

VIEW G-G

Section 2 - Pre-Operation and Inspection

2-531200744

Section 2 - Pre-Operation and Inspection

OY3151

1706288

1706284

1001092877

1702300

91503112

(G9-43A IF

EQUIPPED)

(G10-43A)

9150-3112 REV -

1701640

1706098

1706098B

1001092878

(ENCLOSED CAB)

1001092878

(OPEN CAB)

1001154575

1001139654A

15 mg/kg

1001139654

(IF EQUIPPED FOR LS)

1001160912 RevA

1001160912

(IF EQUIPPED)

BCC

VIEW B-B

(G6-42A & G9-43A)

VIEW C-C

(G10-43A)

VIEW D-D

VIEW A-A

ISO

2-6 31200744

Section 2 - Pre-Operation and Inspection

1706281

4100181

91563220

9156-3220 REVA

1706285

1001139942

(UNDERSIDE OF

ENGINE COVER)

1001139069

1001109053

(UNDERSIDE OF

ENGINE COVER)

2.5 GPM

9.5 lpm

MAX

1001109053 REVA

91163028

1001109459

(G6-42A & G9-43A, IF

EQUIPPED)

1001109459C

1001109458

(G10-43A) (G9-43A, IF EQUIPPED)

1001131745A

1001131745

(G6-42A, IF

EQUIPPED)

91413061

1001108847

(G10-43A)

(G6-42A & G9-43A,

IF EQUIPPED)

1001108836

(G6-42A & G9-43A,

IF EQUIPPED)

1001108836B

1001111229

(G10-43A)

1001131509

(G9-43A)

1001131509

(G10-43A)

1001118911 B

IF EQUIPPED

1000

1001130782

(G6-42A &

G9-43A)

1001130792

(G10-43A)

CAPACITY

CHARTS

1001130802 1001130920

1706283

1706287

1706289

1706293

OY3161

1001160916 REVA

1001160916

(IF EQUIPPED

WITH REVERSE

SENSOR SYSTEM)

VIEW E-E

2-731200744

Section 2 - Pre-Operation and Inspection

OY2140

1706282

1706292

91553072

1706292

1 0 °

0°

-10

4105262

1706292

VIEW F-F

VIEW G-G

2-8 31200744

Section 2 - Pre-Operation and Inspection

This Page Intentionally Left Blank

2-931200744

Section 2 - Pre-Operation and Inspection

OAL3491

2.3 WALK-AROUND INSPECTION

Begin your walk-around inspection at item 1, as noted below. Continue to your right (counterclockwise when viewed from top) checking each item in sequence.

INSPECTION NOTE: On all components, make sure there are no loose or missing parts, that they are securely fastened and no visible leaks or excessive wear exists in addition to any other criteria mentioned. Inspect all structural members including attachment for cracks, excessive corrosion and other damage.

1. Boom Sections and Lift, Tilt, Extend/Retract, Compensating (Slave) Cylinders

• Check front, top, side and rear wear pads for presence of grease.

• Pivot pins secure; hydraulic hoses undamaged, not leaking.

2. Left Outrigger undamaged, not leaking.

3. Front Axle hydraulic hoses undamaged, not leaking.

4. Wheel/Tire Assembly nuts. Inspect for worn tread, cuts, tears or other discrepancies.

2-10 31200744

(G10-43A) - Pins secure; hydraulic hoses and cylinder

- Steer cylinders undamaged, not leaking; pivot pins secure;

- Properly inflated and secured; no loose or missing lug

Section 2 - Pre-Operation and Inspection

5. Mirror - Clean and undamaged.

6. Cab and Electrical

• General appearance; no visible damage.

• Frame level indicator and window glass undamaged and clean.

• Gauges, switches, joysticks, foot controls and horn operational.

• Emergency escape hammer in place (enclosed cab only).

• Check seat belt for damage, replace belt if frayed or cut webbing, damaged buckles or loose mounting hardware.

7. Air Cleaner condition. Replace element as required.

- Air cleaner element condition indicator, check for clogged

8. Wheel/Tire Assembly nuts. Inspect for worn tread, cuts, tears or other discrepancies.

9. Main Control Valve

10. Rear Axle

hydraulic hoses undamaged, not leaking.

11. Wheel/Tire Assembly nuts. Inspect for worn tread, cuts, tears or other discrepancies.

12. Engine Compartment

• Drive belts, check condition and replace as required.

• Engine mounts - See inspection note.

• Battery cables tight, no visible damage or corrosion.

• Engine cover properly secured.

13. Mirror

14. Outrigger Control Valve

15. Wheel/Tire Assembly

nuts. Inspect for worn tread, cuts, tears or other discrepancies.

16. Frame Level Cylinder

17. Right Outrigger

undamaged, not leaking.

18. Attachment

- Steer cylinders undamaged, not leaking; pivot pins secure;

- Clean and undamaged.

- Properly installed, see “Attachment Installation” on page 5-9.

- Properly inflated and secured; no loose or missing lug

- See inspection note.

- Properly inflated and secured; no loose or missing lug

(G10-43A) - See inspection note.

- Properly inflated and secured; no loose or missing lug

- Pins secure; hydraulic hoses undamaged, not leaking.

(G10-43A) - Pins secure; hydraulic hoses and cylinder

2-1131200744

Section 2 - Pre-Operation and Inspection

2.4 WARM-UP AND OPERATIONAL CHECKS

Warm-Up Check

During warm-up period, check:

1. Heater, defroster and windshield wiper (if equipped).

2. Check all lighting systems (if equipped) for proper operation.

3. Voltmeter should show 13.5 to 14 volts.

4. Adjust mirrors for maximum visibility.

WARNING

CUT/CRUSH/BURN HAZARD. Keep engine cover closed while engine is

running except when checking transmission oil level.

Operational Check

When engine warms, perform an operational check:

1. Service brake and parking brake operation.

2. Forward and reverse travel.

3. Each gear.

4. Steering in both directions with engine at low idle (steering lock to lock will not be reached). Check in each steering mode.

5. Horn and back-up alarm. Must be audible from inside operator cab with engine running.

6. All boom and attachment functions - operate smoothly and correctly.

7. Perform any additional checks described in Section 8.

2-12 31200744

Section 2 - Pre-Operation and Inspection

2.5 OPERATOR CAB

The telehandler is equipped with an open or enclosed ROPS/FOPS cab.

WARNING

Never operate telehandler unless the overhead guard, cab structure and right side glass or screen are in good condition. Any modification to this machine must be approved by JLG to assure compliance with ROPS/FOPS certification for this cab/machine configuration. If the overhead guard or cab structure is damaged, the CAB CANNOT BE REPAIRED. It must be REPLACED.

2-1331200744

Section 2 - Pre-Operation and Inspection

OAL0011

2.6 WINDOWS

Keep all windows and mirrors clean and unobstructed.

Cab Door Window (if equipped)

• Cab door (1) must be closed during operation.

• During operation the cab door window (2) must either be latched open or closed.

• Open the cab door window and secure it in the latch (3).

• Press release button inside the cab or pull on lever (4) outside the cab to unlatch the window.

2-14 31200744

Section 3 - Controls and Indicators

SECTION 3 - CONTROLS AND INDICATORS

3.1 GENERAL

This section provides the necessary information needed to understand control functions.

Note: The manufacturer has no direct control over machine application and operation. The user and operator are responsible for conforming with good safety practices.

3-131200744

Section 3 - Controls and Indicators

OY3170

3.2 CONTROLS

G6-42A & G9-43A

3-2 31200744

Section 3 - Controls and Indicators

1. Transmission Control Lever: See page 3-10.

2. Instrument Panel

: See page 3-6.

3. Steering Wheel machine in the corresponding direction. Three steering modes are available. See “Steer Modes” on page 3-19.

4. Frame Level Indicato condition of the telehandler.

5. Accessory Control Lever

6. Right Hand Panel

7. Boom Joystick

8. Frame Level and Attachment Tilt (if equipped) Joystick

9. Auxiliary Hydraulic Joystick

10. Decompression Valve

hydraulic circuit. See “Hydraulic Operated Attachment” on page 5-12.

11. Accelerator Pedal

12. Service Brake Pedal

travel speed.

13. Ignition Switch

14. Auxiliary Hydraulic Joystick

: Turning the steering wheel to the left or right steers the

r: Enables the operator to determine the left to right level

(if equipped): See page 3-18.

: See page 3-17.

: See page 3-12.

: See page 3-14.

(G9-43A): See page 3-15.

(G9-43A if equipped): Pull to relieve pressure in auxiliary

: Pressing down pedal increases engine and hydraulic speed.

: The further the pedal is depressed, the slower the

: Key activated. See page 3-7.

(G6-42A): See page 3-15.

3-331200744

Section 3 - Controls and Indicators

OY3180

G10-43A

3-4 31200744

Section 3 - Controls and Indicators

1. Transmission Control Lever: See page 3-10.

2. Instrument Panel

: See page 3-6.

3. Steering Wheel machine in the corresponding direction. Three steering modes are available. See “Steer Modes” on page 3-19.

4. Frame Level Indicato condition of the telehandler.

5. Accessory Control Lever

6. Right Hand Panel

7. Boom Joystick

8. Frame Level Joystick

9. Outrigger Joysticks

10. Decompression Valve

“Hydraulic Operated Attachment” on page 5-12.

11. Accelerator Pedal

12. Service Brake Pedal

travel speed.

13. Ignition Switch

14. Auxiliary Hydraulic Joystick

: Turning the steering wheel to the left or right steers the

r: Enables the operator to determine the left to right level

(if equipped): See page 3-18.

: See page 3-17.

: See page 3-12.

: See page 3-14.

: See page 3-16.

: Pull to relieve pressure in auxiliary hydraulic circuit. See

: Pressing down pedal increases engine and hydraulic speed.

: The further the pedal is depressed, the slower the

: Key activated. See page 3-7.

: See page 3-15.

3-531200744

Section 3 - Controls and Indicators

OY3190

1 3

4 52

Dash Controls and Indicators

1. Transmission Temperature Indicator: Illuminates red when transmission

temperature is too high. Immediately bring machine to a stop, retract and lower boom and stop the engine. Determine cause and correct before continued use.

2. Engine Pre-Heat Indicator position. Indicator goes out when start temperature is reached.

3. Steer Select Switch and 2-wheel steer. See page 3-19 for details.

4. Park Brake Switch

5. Horn Button

6. Auxiliary Electrics Switches

require auxiliary electrics. See Section 5 - Attachments for approved attachments and control instructions.

7. Quick Switch Switch hydraulic joystick to hydraulically lock or unlock an attachment. See “Hydraulic Quick Switch” on page 5-11.

8. Engine Warning Indicator Immediately bring machine to a stop, retract and lower boom and stop the engine. Determine cause and correct before continued use.

9. Check Engine Indicator Engine may derate. See Service Manual for details.

10. 3-in-1 Gauge and Display

a. Engine Coolant Temperature Gauge

b. Engine Oil Pressure Gauge

c. Fuel Gauge

d. Display - Displays engine operating hours, battery voltage and engine rpm.

Engine fault codes displayed when detected. See Service Manual for details.

: See page 3-8 for details.

: Depress button to sound horn.

: Illuminates yellow with ignition key in the “RUN”

: Three positions: 4-wheel circle steer, 4-wheel crab steer

(if equipped): Enables functions of attachments that

(if equipped): Use in conjunction with the auxiliary

: Illuminates red when the engine is in a critical state.

: Illuminates orange when maintenance is required.

3-6 31200744

Section 3 - Controls and Indicators

OY2760

ACC

RUN

START

OFF

Ignition

• In "ACC" or "RUN" position, voltage is available for all electrical functions.

• Full clockwise rotation to "START" engages starter motor.

• Counter-clockwise rotation to "OFF" stops engine and removes voltage from all electrical functions.

3-731200744

Section 3 - Controls and Indicators

OY2770

Park Brake

Park brake switch controls the application and release of the park brake. Indicator light on switch illuminates to indicate brake is applied.

• With the engine running and the park brake switch in "OFF" position (1), park brakes are disengaged.

• With switch in "ON" position (2), park brake is engaged and transmission will not engage forward or reverse.

WARNING

MACHINE ROLL-AWAY HAZARD. Always move park brake switch to "ON"

position, lower boom to ground and stop engine before leaving cab.

WARNING

CRUSH HAZARD. Turning engine off applies the park brake. Applying park

brake or turning engine off while traveling will cause unit to stop abruptly and could cause load loss. Either may be used in an emergency situation.

Parking Procedure

1. Using service brake, stop telehandler in an appropriate parking area.

2. Follow “Shut-Down Procedure” on page 4-4.

3-8 31200744

Section 3 - Controls and Indicators

This Page Intentionally Left Blank

3-931200744

Section 3 - Controls and Indicators

OY2780

Transmission Control Lever

Direction of Travel Selection

Transmission control lever (1) engages forward or reverse travel.

• Lift and push lever forward for forward travel; lift and pull lever rearward for reverse travel. Move lever to centered position for neutral.

• Forward or reverse travel can be selected while in any gear.

• When traveling in reverse, the back-up alarm will automatically sound.

• Drive in reverse and turn only at slow rates of speed.

• Do not increase engine speed with the transmission in forward or reverse and the service brake depressed in an attempt to get quicker hydraulic performances. This could cause unexpected machine movement.

WARNING

TIP OVER/CRUSH HAZARD. Bring telehandler to a complete stop before

shifting transmission control lever. A sudden change in direction of travel could reduce stability and/or cause load to shift or fall.

3-10 31200744

Section 3 - Controls and Indicators

OY2790

1st

2nd

3rd

4th

Gear Selection

Gear selection is located on the twist grip handle (2) of transmission control lever.

• Twist hand grip to select gear.

• Select the appropriate gear for the task being performed. Use a lower gear when transporting a load. Use a higher gear only when driving unloaded for longer distances.

• Slow down prior to downshifting.

Do not downshift more than one gear at a time.

3-1131200744

Section 3 - Controls and Indicators

OY3200

Boom Joystick

WARNING

TIP OVER/CRUSH HAZARD. Rapid, jerky operation of controls will cause rapid,

jerky movement of the load. Such movements could cause the load to shift or fall or could cause the machine to tip over.

G6-42A, G9-43A If Equipped

The boom joystick (1) controls the boom and attachment tilt (if equipped) functions.

Boom Functions

• Move the joystick back to lift boom; move joystick forward to lower boom; move joystick right to extend boom; move joystick left to retract boom.

• The speed of boom functions depends upon the amount of joystick travel in corresponding direction. Increasing engine speed will also increase function speed.

• For two simultaneous boom functions, move the joystick between quadrants. For example; moving the joystick forward and to the left will lower and retract boom simultaneously.

Attachment Function (if equipped)

Tilt control is actuated by the switch (2).

• Depress the left side of the switch to tilt up; depress the right side of switch to tilt down.

• Use knob (3) to regulate the speed of the tilt. Rotate knob counter-clockwise to increase speed; rotate knob clockwise to decrease speed.

3-12 31200744

Section 3 - Controls and Indicators

OY3210

G9-43A If Equipped, G10-43A

The boom joystick (1) controls the boom, attachment tilt and clutch lock functions.

Boom Functions

• Move the joystick back to lift boom; move joystick forward to lower boom; move joystick right to extend boom; move joystick left to retract boom.

Speed of boom functions depends upon amount of joystick travel in corresponding

• direction. Increasing engine speed will also increase function speed.

• For two simultaneous boom functions, move the joystick between quadrants. For example; moving the joystick forward and to the left will lower and retract boom simultaneously.

Attachment Tilt Function

Attachment tilt is controlled by the roller switch (4).

• Push roller switch up to tilt attachment down; push roller switch down to tilt attachment up.

Clutch Lock

Clutch Lock is controlled by the joystick trigger (5).

• Squeeze and release trigger once to disengage the transmission. Quickly squeeze and release trigger twice to re-engage the transmission.

3-1331200744

Section 3 - Controls and Indicators

OY3220

Frame Level and Attachment Tilt (if equipped) Joystick

The middle joystick (1) controls the left to right frame level and attachment tilt (if equipped) functions.

Frame Level

• Move the joystick left to rotate frame left, move the joystick right to rotate frame right.

• A level indicator is located above the front cab window to permit operator to determine whether the telehandler frame is level.

WARNING

TIP OVER HAZARD. Always move boom as low as possible while allowing for

best visibility of right hand mirror before leveling frame. Attempting to level machine with boom raised could cause it to tip over.

Attachment Tilt Function (if equipped)

• Move the joystick forward to tilt down, move the joystick back to tilt up.

WARNING

TIP OVER/CRUSH HAZARD. Rapid, jerky operation of controls will cause rapid,

jerky movement of the load. Such movements could cause the load to shift or fall or could cause the machine to tip over.

3-14 31200744

Section 3 - Controls and Indicators

OY3240

G6-42A, G9-43A IF EQUIPPED G9-43A IF EQUIPPED, G10-43A

(G6-42A)

(G10-43A)

(G9-43A)

Auxiliary Hydraulic Joystick

The auxiliary hydraulic joystick (1) controls function of attachments that require hydraulic supply for operation. See Section 5 - Attachments for approved attachments and control instructions.

3-1531200744

Section 3 - Controls and Indicators

OY3230

Outrigger Joysticks (G10-43A)

The rear joysticks (1) control the outriggers.

• The left joystick controls left outrigger and the right joystick controls right outrigger.

• Push joysticks forward to lower outriggers; push joysticks back to raise outriggers.

• Use outriggers to increase stability and/or load capacity and in leveling the telehandler. Study capacity charts to determine maximum load capacities, with and without outriggers.

WARNING

TIP OVER HAZARD. Outriggers increase stability and load capacity only if they

are used properly. Using outriggers on soft surfaces could cause telehandler to tip over. Always ensure surface can support telehandler and load.

3-16 31200744

Section 3 - Controls and Indicators

OAL0543

Right Hand Panel

Heater and Air Conditioning Controls (if equipped)

1. Air Vent

2. Air Louver

: Two individually adjustable round vents.

: Three individually adjustable air louvers.

3. Defroster Fan switch up for fast speed. Return switch to middle position to turn off.

4. Temperature Control Switch

5. Fan Speed

6. Air Conditioning Switch

7. Air Louver

8. Recirculation Vent

operating air conditioning.

Other Controls (if equipped)

9. Work Light Switch

10. Beacon Light Switch

11. Hazard Light Switch

12. Windshield Wiper and Washer Switch

activate washer. Return to first position to turn off wiper.

13. Attachment Tilt Speed Switch

: Two speed fan. Press fan switch down for slow speed; press

: Adjustable rotary switch

: Four-position rotary switch.

: On/Off switch.

: Two individually adjustable air louvers.

: Open louvers when operating heat. Close louvers when

: On/Off switch.

: Two speed rotary switch. Depress to

(if equipped): See page 3-12.

3-1731200744

Section 3 - Controls and Indicators

OY1 350

Accessory Control Lever (if equipped)

The accessory control lever (1) operates the turn signals, parking lights and headlights.

Tur n S ignal

• Push the lever forward (2) to activate the left turn signal.

• Pull the lever back (3) to activate the right turn signal.

• The lever must be manually returned to the center position to deactivate either turn signal. The lever will not cancel automatically after a turn.

Parking Lights and Headlights

• Turn the twist grip (4) of the lever counterclockwise to the first position (5) to turn on the parking lights.

• Turn the twist grip to the second position (6) to turn on the headlights.

• Raise/lower the lever to switch between low beam and high beam.

• Turn the twist grip clockwise to the OFF position (7) to turn all lights off.

3-18 31200744

Section 3 - Controls and Indicators

OAL2030

2-Wheel Front Steer 4-Wheel Circle Steer 4-Wheel Crab Steer

OY1491

1 2 3

OAM2400

4 5

3.3 STEER MODES

Three steer modes are available for operator use.

Note: 2-Wheel Front Steer mode is required for travel on public roads.

Steer Mode Change

1. Bring machine to a stop using service brake while either circle steer mode (1) or crab steer mode (3) is selected.

2. Turn the steering wheel until the left rear wheel (4) is aligned with the side of the machine.

3. Select front steer mode (2).

4. Turn the steering wheel until the left front wheel (5) is aligned with the side of the machine.

5. Wheels are now aligned. Select desired steer mode.

3-1931200744

Section 3 - Controls and Indicators

OW0480

3.4 OPERATOR SEAT

Adjustments

Prior to starting engine adjust seat for position and comfort.

1. Suspension clockwise to increase stiffness. Turn counterclockwise to reduce stiffness.

2. Fore/Aft

3. Arm Rest

4. Seat Belt

seat belt is available.

3-20 31200744

: Use knob to adjust suspension to the appropriate setting. Turn

: Pull up on handle to move seat fore and aft.

: Arm rest can be moved up or down for comfort.

: Always fasten seat belt during operation. If required, a 3 in (76 mm)

Section 3 - Controls and Indicators

OH20912

Seat Belt

Fasten seat belt as follows:

1. Grasp both free ends of the belt making certain that belt webbing is not twisted or entangled.

2. With back straight in the seat, couple the retractable end (male end) of the belt into the receptacle (buckle) end of the belt.

3. With belt buckle positioned as low on the body as possible, pull the retractable end of the belt away from the buckle until it is tight across the lap.

3-2131200744

Section 3 - Controls and Indicators

3.5 REVERSE SENSOR SYSTEM (IF EQUIPPED)

Reverse Sensor System provides audible indication of objects to rear of unit while in reverse gear.

• Alarm sounds signaling machine is placed in reverse gear.

Note: Reverse Sensing System detects objects larger than 36 square inches (232.25 square centimeters) area and is functional when machine is moving in reverse direction.

• No alarm when detection zone is clear of objects.

•

Pulsing alarm sounds Alarm increases in frequency as object becomes closer.

• If alarm sounds at a frequency of eight pulses per second (8 Hz) an object is detected within 5 feet (1.5 m). Stop reverse direction of machine by applying service brake. Perform “Shut-Down Procedure” on page 4-4. Check and clear area behind machine of objects before proceeding in a reverse direction.

when an object is in range of Reverse Sensing System.

3-22 31200744

Section 3 - Controls and Indicators

OX0541

-1 0°

0°

20°

70°

3.6 BOOM ANGLE AND EXTENSION INDICATORS

• The boom angle indicator (1) is located on the left side of the boom. Use this indicator to determine the boom angle when using the capacity chart (see “Use of the Capacity Chart” on page 5-5).

• The boom extension indicators (2) are located on the left side of the boom. Use these indicators to determine boom extension when using the capacity chart (see “Use of the Capacity Chart” on page 5-5).

3-2331200744

Section 3 - Controls and Indicators

This Page Intentionally Left Blank

3-24 31200744

Section 4 - Operation

SECTION 4 - OPERATION

4.1 ENGINE

Starting the Engine

This machine can be operated under normal conditions in temperatures of 0°F to 104°F (-20°C to 40°C). Consult JLG for operation outside this range or under abnormal conditions.

If equipped for extreme cold weather, -40°F to 0°F (-40°C to -20°C), see page 4-2 for starting procedure.

1. Make sure all controls are in “Neutral” and all electrical components (lights, heater, defroster, etc.) are turned off. Apply park brake.

2. Turn the ignition switch to “RUN” position and wait until engine pre-heat indicator light goes out.

3. Turn ignition switch to “START” to engage starting motor. Release key immediately when engine starts. If engine fails to start within 20 seconds, release key and allow starting motor to cool for two minutes before trying again.

Note: (If equipped for ULS) Engine is equipped with starter lockout feature and may prevent starter engagement under certain conditions. Fault code will appear on gauge display. Return ignition switch to “RUN” position for a minimum of two minutes to allow system to reset before trying to start again.

4. After engine starts, observe oil pressure gauge. If gauge remains on zero for more than ten seconds, stop engine and determine cause before restarting engine.

5. Warm up engine at approximately 1/2 throttle.

Note: Engine will not start unless transmission control lever is in “Neutral” and park brake switch is applied.

WARNING

ENGINE EXPLOSION. Do not use ether for cold weather starting.

WARNING

UNEXPECTED MOVEMENT HAZARD. Always ensure that transmission control

lever is in neutral and the service brake is applied before releasing park brake. Releasing park brake in either forward or reverse could cause the machine to move abruptly.

4-131200744

Section 4 - Operation

OY1971

Extreme Cold Weather Starting (if equipped)

If equipped with extreme cold weather components, machine can be operated in temperatures of -40°F to 0°F (-40° C to -20° C).

1. Machine must be equipped with heating components and extreme cold weather fluids. See Section 9 - Specifications for fluid details.

2. Locate the two yellow extension cords stored behind seat in cab.

3. Connect the oil pan and hydraulic tank heaters to one extension cord and the battery and block heaters to the other extension cord. Connect each extension cord to separate A/C power supplies with a minimum rating of 15 Amps each.

4. Allow heating components to operate a minimum of 12 hours prior to machine operation.

5. Locate recirculation hoses stored behind seat in cab.

6. Connect recirculation hose (1) to tilt circuit quick disconnects (2). Connect the

7. Follow start-up procedure on page 4-1 and allow engine to idle 20 minutes.

8. Operate tilt and auxiliary hydraulic functions continuously for five minutes to

9. Operate all boom functions continuously for another five minutes.

10. Perform “Shut-Down Procedure” on page 4-4.

11. Disconnect recirculation hoses and A/C power supplies and place back in

12. Machine is ready for operation.

4-2 31200744

other recirculation hose (1) to auxiliary hydraulic quick disconnects (3).

circulate the warm hydraulic fluid.

storage locations.

Section 4 - Operation

OW0530

Battery Boosted Starting

If battery-boost starting (jump-start) is necessary, proceed as follows:

• Never allow vehicles to touch.

• Ensure boosting vehicle engine is running.

• Connect the positive (+) jumper cable to positive (+) post of discharged battery.

• Connect the opposite end of positive (+) jumper cable to positive (+) post of booster battery.

• Connect the negative (-) jumper cable to negative (-) post on booster battery.

• Connect opposite end of negative (-) jumper cable to ground point on machine away from discharged battery.

• Follow standard starting procedures.

• Remove cables in reverse order after machine has started.

WARNING

BATTERY EXPLOSION HAZARD. Never jump start or charge a frozen battery

as it could explode. Keep sparks, flames and lighted smoking materials away from the battery. Lead acid batteries generate explosive gases when charging. Wear safety glasses.

4-331200744

Section 4 - Operation

Normal Engine Operation

• Observe instrument panel frequently to be sure all systems are functioning properly.

• Be alert for unusual noises or vibration. When an unusual condition is noticed, park machine in safe position and perform shut-down procedure. Report condition to your supervisor or maintenance personnel.

• Avoid prolonged idling. If the engine is not being used, turn it off.

Shut-Down Procedure

When parking the telehandler, park in a safe location on flat level ground and away from other equipment and/or traffic lanes.

1. Apply the park brake.

2. Shift the transmission to “Neutral.”

3. Lower forks or attachment to the ground.

4. Operate engine at low idle for 3 to 5 minutes. DO NOT over rev engine.

5. Shut off engine and remove ignition key.

6. Exit telehandler properly.

7. Block wheels (if necessary).

4-4 31200744

Section 4 - Operation

4.2 OPERATING WITH A NON-SUSPENDED LOAD

Lift Load Safely

• You must know the weight and load center of every load you lift. If you are not sure of the weight and load center, check with your supervisor or with the supplier of the material.

WARNING

TIP OVER HAZARD. Exceeding lift capacity of the telehandler could damage the

equipment and/or cause tip over.

• Know the rated load capacities (see Section 5) of the telehandler to determine the operating range in which you can safely lift, transport and place a load.

Picking Up a Load

• Note the conditions of the terrain. Adjust travel speed and reduce amount of load if conditions warrant.

• Avoid lifting double-tiered loads.

• Make sure load is clear of any adjacent obstacles.

• Adjust spacing of forks so they engage the pallet or load at maximum width. See “Adjusting/Moving Forks” on page 5-13.

• Approach load slowly and squarely with fork tips straight and level. NEVER attempt to lift a load with just one fork.

• NEVER operate telehandler without a proper and legible capacity chart in the operator cab for the telehandler/attachment combination you are using.

4-531200744

Section 4 - Operation

OW0540

Transporting a Load

After engaging the load and resting it against the backrest, tilt the load back to position it for travel. Travel in accordance with the requirements set forth in Section 1 - General Safety Practices and Section 5 - Attachments.

Leveling Procedure

1. Position machine in best location to lift or place load.

2. Apply parking brake and move transmission control lever to NEUTRAL.

3. Observe level indicator to determine whether machine must be leveled prior to lifting load.

4. Move boom/attachment to 4 ft (1,2 m) off ground. (AUS - Move boom so forks are no more than 300 mm (11.8 in) above ground surface.)

Important things to remember:

• Never raise the boom/attachment more than 4 ft (1,2 m) above ground unless telehandler is level. (AUS - Never raise the forks more than 300 mm (11.8 in) above ground surface unless telehandler is level.)

• The combination of side tilt and load could cause the telehandler to tip over.

4-6 31200744

Section 4 - Operation

Placing a Load

Before placing any load be sure that:

• The landing point can safely support the weight of the load.

• The landing point is level; front to back and side to side.

• Use the capacity chart to determine safe boom extension range. See “Use of the Capacity Chart” on page 5-5.

• Align forks at the level load is to be placed, then extend boom slowly until load is just above area where it is to be placed.

• Lower the boom until the load rests in position and the forks are free to retract.

Disengaging a Load

Once the load has been placed safely at the landing point, proceed as follows:

1. With the forks free from the weight of the load, the boom can be retracted and/or the telehandler can be backed away from under the load if surface will not change level condition of telehandler.

2. Lower the carriage.

3. The telehandler can now be driven from the landing location to continue work.

4-731200744

Section 4 - Operation

4.3 OPERATING WITH A SUSPENDED LOAD

Lift Load Safely

• You must know the weight and load center of every load you lift. If you are not sure of the weight and load center, check with your supervisor or with the supplier of the material.

WARNING

TIP OVER HAZARD. Exceeding lift capacity of the telehandler could damage the

equipment and/or cause tip over.

• Know rated load capacities (refer to Section 5) of telehandler to determine operating range in which you can safely lift, transport and place a load.

Picking Up a Suspended Load

• Note the conditions of the terrain. Adjust travel speed and reduce amount of load if conditions warrant.

• Avoid lifting double-tiered loads.

• Make sure load is clear of any adjacent obstacles.

• NEVER operate telehandler without a proper and legible capacity chart in the operator cab for the telehandler/attachment combination you are using.

• Only use approved lifting devices rated for the lifting of the load.

• Identify the proper lifting points of the load, taking into consideration the center of gravity and load stability.

• Ensure to always properly tether loads to restrict movement.

• Refer to “Use of the Capacity Chart” on page 5-5 for proper lifting guidelines in addition to the appropriate capacity chart in the operator cab.

4-8 31200744

Section 4 - Operation

OW0130

OZ3160

Transporting a Suspended Load

• Travel in accordance with the requirements set forth in Section 1 - General Safety Practices and Section 5 - Attachments.

• For additional requirements, refer to the appropriate capacity chart in the operator cab.

Important things to remember:

• Ensure the boom is fully retracted.

• Never raise the load more than 11.8 in (300 mm) above ground surface or the boom more than 45°.

• Combination of frame leveling and load could cause telehandler to tip over.

• The guide persons and operator must remain in constant communication (verbal or hand) and be in visual contact with the operator at all times.

• Never place the guide persons between the suspended load and the telehandler.

• Only transport the load at walking speed, 0.9 mph (0.4 m/s), or less.

Leveling Procedure

1. Position machine in best location to lift or place load.

2. Apply parking brake and move transmission control lever to NEUTRAL.

3. Observe level indicator to determine whether machine must be leveled prior to lifting load.

4. Move boom so load is no more than 11.8 in (300 mm) above ground surface and boom/or boom is raised no more than 45°.

4-931200744

Section 4 - Operation

Placing a Suspended Load

Before placing any load be sure that:

• The landing point can safely support the weight of the load.

• The landing point is level; front to back and side to side.

• Use the capacity chart to determine safe boom extension range. “Use of the Capacity Chart” on page 5-5

• Align load at the level load is to be placed, then position boom slowly until load is just above area where it is to be placed.

• Ensure that the guide persons and operator remain in constant communication (verbal or hand) when placing the load.

Disengaging a Suspended Load

• Never place the guide persons between the suspended load and the telehandler.

• Once at load destination, bring telehandler to a complete stop and apply park brake prior to disengagement of lifting devices and tethers.

4-10 31200744

Section 4 - Operation

OY1821

G10-43A G6-42A & G9-43A

4.4 LOADING AND SECURING FOR TRANSPORT

Tiedown

1. Level the telehandler prior to loading.

2. Using a spotter, load the telehandler with boom as low as possible.

3. Once loaded, apply parking brake and lower boom until boom or attachment is resting on deck. Move all controls to “Neutral,” stop engine and remove ignition key.

4. Secure machine to deck by passing chains through the designated tie down points as shown in the figure.

5. Do not tie down front of boom.

Note: The user assumes all responsibility for choosing the proper method of transportation and tie-down devices, making sure the equipment used is capable of supporting the weight of the vehicle being transported and that all manufacturer’s instructions and warnings, regulations and safety rules of their employer, the Department of Transportation and/or any other local, state or federal/provincial laws are followed.

WARNING

TELEHANDLER SLIDE HAZARD. Before loading telehandler for transport,

make sure deck, ramps and telehandler wheels are free of mud, snow and ice. Failure to do so could cause telehandler to slide.

4-1131200744

Section 4 - Operation

Lifting

• When lifting machine, it is very important that the lifting device and equipment is attached only to designated lifting points. If machine is not equipped with lifting lugs contact JLG Product Safety for information.

• Make adjustments to lifting device and equipment to ensure machine will be level when elevated. Machine must remain level at all times while being lifted.

• Ensure that the lifting device and equipment is adequately rated and suitable for the intended purpose. See Section 9 - Specifications for machine weight or weigh machine.

• Remove all loose items from machine prior to lifting.

• Lift machine with smooth, even motion. Set machine down gently. Avoid quick or sudden motions that could cause shock loads to machine and/or lifting devices.

4-12 31200744

Section 5 - Attachments

SECTION 5 - ATTACHMENTS

5.1 APPROVED ATTACHMENTS

To determine if an attachment is approved for use on the specific telehandler you are using, perform the following prior to installation.

• The attachment type, weight, dimensions and load center must be equal to or less than the data shown on a capacity chart located in the operator cab.

• The model on the capacity chart must match the model telehandler being used.

• Hydraulically powered attachments must only be used on machines equipped with auxiliary hydraulics.

If any of the above conditions are not met, do not use the attachment. The telehandler may not be equipped with the proper capacity chart or the attachment may not be approved for the model telehandler being used. Contact JLG or a local distributor for further information.

5.2 UNAPPROVED ATTACHMENTS

Do not use unapproved attachments for the following reasons:

• Range and capacity limitations for “will fit,” homemade, altered, or other non-approved attachments cannot be established.

• An overextended or overloaded telehandler can tip over with little or no warning and cause serious injury or death to the operator and/or those working nearby.

• The ability of a non-approved attachment to perform its intended function safely cannot be assured.

WARNING

Use only approved attachments. Attachments which have not been approved for use with your telehandler could cause machine damage or an accident.

5-131200744

Section 5 - Attachments

5.3 JLG SUPPLIED ATTACHMENTS

Attachment Part Number

Carriage, 50 in (1270 mm)

Carriage, 60 in (1524 mm)

Carriage, 72 in (1829 mm)

Side Shift Carriage, 50 in (1270 mm) 1001142790 X X X

Side Tilt Carriage, 50 in (1270 mm) 1170054 X X X

Side Tilt Carriage, 60 in (1524 mm) 1001101956 X X X

Side Tilt Carriage, 72 in (1829 mm) 1170057 X X X

90° Swing Carriage, 72 in (1829 mm) 1001095418 X X X

Dual Fork Positioning Carriage, 50 in

8 ft Mast Carriage, 50 in (1270 mm) 1001108668 X X X

8 ft Mast Carriage w/ Side Tilt, 50 in

Fork, Dual Taper 1.75x7x60 in

Fork, Dual Taper 2.36x6x60 in

Fork, Block 2x2x48 in (50x50x1220 mm) 2340037 X X X

Fork Extension, 90 in (2286 mm) 1001137512 X X X

Grapple Bucket, 96 in - 1.75 yd

Truss Boom, 12 ft (3658 mm) 1001099902 X X X

Truss Boom w/ Winch, 12 ft (3658 mm) 1001099351 X X X

Truss Boom, 15 ft (4572 mm) 1001099901 X X X

Platform, Fork Mounted (ASME) 1001103637 X X X

Platform, Fork Mounted (ASME - French) 1001103736 X X X

Platform, Fork Mounted (ISO) 1001103730 X X X

(1270 mm)

Fork, Pallet 2.36x4x48 in

(60x100x1220 mm)

Fork, Pallet 2.36x5x48 in

(60x127x1220 mm)

(44x178x1524 mm)

(60x152x1524 mm)

Fork, Dual Taper 2x6x72 in

(50x152x1830 mm)

Bucket, 72 in - 1.0 yd

Bucket, 96 in - 1.5 yd

Bucket, 102 in - 2.0 yd

Hook, Fork Mounted 91565094 X X X

1170021 X X X

1001146084 X X X

1170024 X X X

1001146086 X X X

1001132514 X X X

1001146088 X X X

7301295 X X X

1001108669 X X X

2340045 X X X

2340038 X X X

2340046 X X X

2340039 X X X

1001092391 X X X

1001100822 X X X

1001100823 X X X

1001100824 X X X

0930020 X X X

Applicable Model

G6-42A G9-43A G10-43A

5-2 31200744

Section 5 - Attachments

This Page Intentionally Left Blank

5-331200744

Section 5 - Attachments

OW0550

5.4 TELEHANDLER/ATTACHMENT/FORK CAPACITY

Prior to installing the attachment verify it is approved and the telehandler is equipped with the proper capacity chart. See “Approved Attachments” on page 5-1.

To determine the maximum capacity of the telehandler and attachment, use the smallest of the following capacities:

• Capacity stamped on the attachment identification plate (1).

• Fork capacities and load centers are stamped on the side of each fork (2) (if equipped). This rating specifies the maximum load capacity that the individual fork can safely carry at the maximum load center (3). Total attachment capacity is multiplied by the number of forks on the attachment (if equipped), up to the maximum capacity of the attachment.

• Maximum capacity as indicated on the proper capacity chart. See “Approved Attachments” on page 5-1.

• When the load rating of the telehandler differs from the capacity of the forks or attachment, the lower value becomes the overall load capacity.

Use the proper capacity chart to determine maximum capacity at various machine configurations. Lifting and placing a load may require use of more than one capacity chart based on machine configuration.

Other than block forks, all forks should be used in matched pairs, block forks used in matched sets.

Never use an attachment without the appropriate JLG approved capacity chart installed on the telehandler.

5-4 31200744

WARNING

Section 5 - Attachments

OY1510

-10

DO NOT GO NEAR LEAKS

10814B

* High pressure oil easily punctures skin causing serious injury, gangrene or death. * If injured, seek emergency medical help. Immediate surgery is required to remove oil. * Do not use finger or skin to check for leaks. * Lower load or relieve hydraulic pressure before loosening fittings.

BOOM

EXTENSION

INDICATOR

BOOM ANGLE

INDICATOR

ATTACHMENT

IDENTIFICATION

PLATE

FORK

WEIGHT

STAMP

5.5 USE OF THE CAPACITY CHART

To properly use the capacity chart (see page 5-6), the operator must first determine and/or have the following:

1. An approved attachment. See “Approved Attachments” on page 5-1.

2. The proper Capacity Chart(s).

3. Weight of the load being lifted.

4. Load placement information:

a. HEIGHT where the load is to be placed.

b. DISTANCE from the front tires of the telehandler where the load is to be

placed.

5. On capacity chart, find the line for height and follow it over to distance.

6. The number in the load zone where the two cross is the maximum capacity for this lift. If the two cross at a division between zones, the smaller number must be used.

The number in the load zone must be equal to or greater than the weight of the load to be lifted. Determine the limits of the load zone on the capacity chart and keep within these limits.

Capacity Indicator Locations

5-531200744

Section 5 - Attachments

OAL1071

XXXXX

XXXX XX

XX XX XX XX XX XX XX XX XX

XXXX

XX XX

This Capacity Chart may be used with this model ONLY.

The telehandler model is indicated on the boom or chassis.

Model XXXXX is used for demonstration purposes only.

Boom Extension

Indicator (arc)

Boom Angle

Load zones indicate the

maximum weight that

may be safely lifted.

Load center must

be equal to or less

than value shown.

Attachment type,

weight and

dimensions must

be equal to or less

than the data

shown.

Sample Capacity Chart

Note: This is a sample capacity chart only! DO NOT use this chart, use the one located in your operator cab.

TIP OVER HAZARD. All loads shown on rated capacity chart are based on machine being on firm ground with frame level (see page 4-6); the forks being positioned evenly on carriage; the load being centered on forks; proper size tires being properly inflated; and the telehandler being in good operating condition.

5-6 31200744

WARNING

Section 5 - Attachments

OAL1090

OAL1100

To identify the proper capacity chart on telehandlers equipped with outriggers, refer to the following icons which may be located on the capacity chart.

• Use when lifting a load with outriggers up.

• Use when lifting a load with outriggers down.

5-731200744

Section 5 - Attachments

XXXXX

XXXX

XX XX

OAL1080

Example 2

Example 1

Example 3

Example 4

Example

A contractor owns a model xxxxx telehandler with a fork carriage. He knows this attachment may be used with his model since:

• The attachment style, weight, dimensions and load center match the attachment data on the capacity chart.

• The capacity chart is clearly marked for model xxxxx and corresponds with machine configuration being used.

Below are examples with various conditions the contractor may encounter and whether or not the load may be lifted.

Load Weight Distance Height OK to Lift

1 2500 lb (1134 kg) 16 ft (4,9 m) 12 ft (3,6 m) Yes

2 2000 lb (907 kg) 21 ft (6,4 m) 20 ft (6,1 m) NO

3 4000 lb (1814 kg) 10 ft (3,0 m) 18 ft (5,5 m) Yes

4 6500 lb (2948 kg) 8 ft (2,4 m) 28 ft (8,5 m) NO

Note: This is a sample capacity chart only! DO NOT use this chart, use the one located in your operator cab.

5-8 31200744

5.6 ATTACHMENT INSTALLATION

OY2 851

MECHANICAL

HYDRAULIC

1. Attachment

2. Attachment Pin Recess

Section 5 - Attachments

3. Attachment Pin

4. Lock Pin

5. Retaining Pin

6. Quick Switch

(mechanical quick switch)

(attachment tilt control in cab, see page 3-12)

WARNING

5-931200744

CRUSH HAZARD. Always be certain that carriage or attachment is properly positioned on boom and is secured by lock pin and retainer pin. Failure to ensure proper installation could permit carriage/attachment/load to disengage.

Section 5 - Attachments

OY1550

OY1560

OY15

OY1580

Mechanical Quick Switch

This installation procedure is designed for one-person operation. Prior to exiting cab, perform “Shut-Down Procedure” on page 4-4.

1. Tilt quick switch back to provide clearance. Check to be sure lock pin is removed.

2. Align attachment pin with recess in attachment. Raise boom slightly to engage attachment pin in recess.

3. Tilt quick switch forward to engage attachment.

4. Lift retainer pin and insert lock pin completely through quick switch. Release retainer pin and ensure lock pin is secured.

5. If equipped, connect auxiliary hydraulic hoses. See “Hydraulic Operated Attachment” on page 5-12.

6. If equipped, connect auxiliary electric harness.

5-10 31200744

Section 5 - Attachments

OY3250

3260

OY3270

OY3280

OY3290

(G10-43A)

(G9-43A)

Hydraulic Quick Switch

This installation procedure is designed for one-person operation.

1. Tilt quick switch back to provide clearance.

2. Align attachment pin with recess in attachment. Raise boom slightly to engage attachment pin in recess.

3. Check to be sure lock pin is disengaged. Tilt quick switch forward to engage attachment.

4. G6-42A - Press and hold the quick switch switch (1). At the same time push auxiliary hydraulic joystick (2) up to engage lock pin. Push auxiliary hydraulic joystick down to disengage lock pin.

G9-43A & G10-43A - Press and hold quick switch switch (1). At the same time push auxiliary hydraulic joystick (3) left to engage lock pin. Push auxiliary hydraulic joystick right to disengage lock pin.

5-1131200744

Section 5 - Attachments

OY3310

ENGAGED

DISENGAGED

OY3300

OY1 720

5. Raise boom to eye level and visually check that the lock pins protrude through the holes on both sides of the quick switch. If the lock pins do not protrude through the holes, place the attachment on the ground and return to step 2.

6. If attachment is equipped, connect auxiliary hydraulic hoses. See “Hydraulic Operated Attachment” on page 5-12.

5.7 HYDRAULIC OPERATED ATTACHMENT

1. Install attachment (see page 5-9).

2. Lower attachment to ground and perform “Shut-Down Procedure” on page 4-4.

3. G9-43A if equipped, G10-43A - Pull the decompression valve (1) to relieve auxiliary hydraulic pressure.

4. Connect attachment hoses to both auxiliary fittings (2).

5-12 31200744

Section 5 - Attachments

5.8 ADJUSTING/MOVING FORKS

Carriages may have different locations where forks can be positioned. Two different methods can be used for repositioning, depending upon the carriage structure.

Note: Apply a light coating of appropriate lubricant to ease sliding of forks or fork bar.

To slide forks:

1. Ensure attachment is properly installed. See “Attachment Installation” on page 5-9.

2. Elevate attachment to approximately 5 ft (1,5 m) and tilt carriage forward until fork heel is free from attachment.

3. Stand at the side of the carriage. To slide fork toward the center of the carriage, push the fork near the fork eye. To slide fork toward the edge of the carriage, pull the fork near the fork eye. To avoid pinching, do not place fingers or thumb between the fork and carriage structure.

If removing fork bar is necessary:

1. Rest forks on ground.

2. Remove fork bar.

3. Reposition forks.

4. Reinstall the fork bar and fork bar retaining mechanism(s).

5-1331200744

Section 5 - Attachments

5.9 ATTACHMENT OPERATION

• Capacities and range limits for the telehandler change depending on the attachment in use.

• Separate attachment instructions must be kept in manual holder in cab with this Operation & Safety Manual. An additional copy must be kept with the attachment if it is equipped with a manual holder.

Note: Operations described in this section reference the G9-43A & G10-43A with attachment tilt on the boom joystick. Refer to Section 3 for other configurations.

NOTICE

EQUIPMENT DAMAGE. Some attachments may contact the front tires or machine structure when the boom is retracted and the attachment is rotated. Improper use of attachment may result in attachment or machine structural damage.

NOTICE

EQUIPMENT DAMAGE. Avoid contact with any structure or object when lifting a load. Maintain clearance around boom structure and load. Failure to maintain clearance may result in attachment or machine structural damage.

5-14 31200744

Carriage with Forks

OY0690

OY3320

Use Carriage Attachment Capacity Chart

To determine maximum capacity, refer to “Telehandler/

Attachment/Fork Capacity” on page 5-4.

Suspend loads in accordance with requirements set forth in Section 1 - General Safety Practices.

Section 5 - Attachments

The joystick (1) controls lift/lower and extend/retract movement of the boom.

The tilt roller switch (2) controls fork tilt.

• Press roller switch down to tilt up.

• Press roller switch up to tilt down.

Installation Procedure:

• Refer to “Attachment Installation” on page 5-9.

Operation:

• When utilizing lifting lug, weight of rigging must be included as part of total load lifted

Equipment Damage Precautions:

• Do not use forks as a lever to pry material. Excessive prying forces could damage forks or machine structure.

• Do not attempt to lift loads that are attached or connected to another object.

5-1531200744

Section 5 - Attachments

OAL1540

OY3330

G9-43A

G10-43A

Side Shift Carriage

Use Side Shift Carriage Capacity Chart

To determine maximum capacity, refer to “Telehandler/ Attachment/Fork Capacity” on page 5-4.

The joystick (1) controls lift/lower and extend/retract movement of the boom.

The tilt roller switch (2) controls fork tilt.

• Press roller switch down to tilt up.

• Press roller switch up to tilt down.

To Side Shift:

The auxiliary hydraulic joystick (3) controls carriage side shift.

• Move joystick left to shift left.

• Move joystick right to shift right.

Installation Procedure:

• Refer to “Attachment Installation” on page 5-9.

5-16 31200744

Section 5 - Attachments

WARNING

CRUSH HAZARD. Do not use side shift to push or pull objects or load. Failure to

comply could cause object or load to fall.

Equipment Damage Precautions:

• Do not use forks as a lever to pry material. Excessive prying forces could damage forks or machine structure.

• Do not attempt to lift loads that are attached or connected to another object.

5-1731200744

Section 5 - Attachments

OAL1550

OY3340

G9-43A

G10-43A

Side Tilt Carriage

Use Rotate/Side Tilt Carriage Capacity Chart

To determine maximum capacity, refer to “Telehandler/ Attachment/Fork Capacity” on page 5-4.

The joystick (1) controls lift/lower and extend/retract movement of the boom.

The tilt roller switch (2) controls fork tilt.

• Press roller switch down to tilt up.

• Press roller switch up to tilt down.

To Rotate:

The auxiliary hydraulic joystick (3) controls carriage rotation.

• Move joystick left to rotate left.

• Move joystick right to rotate right.

Installation Procedure:

• Refer to “Attachment Installation” on page 5-9.

5-18 31200744

Section 5 - Attachments

WARNING

CRUSH HAZARD. Do not use rotation to push or pull objects or load. Failure to

comply could cause object or load to fall.

Equipment Damage Precautions:

• Do not use forks as a lever to pry material. Excessive prying forces could damage forks or machine structure.

• Do not attempt to lift loads that are attached or connected to another object.

5-1931200744

Section 5 - Attachments

OU2150

OY3350

G9-43A

G10-43A

Swing Carriage

Use Swing Carriage Capacity Chart

To determine maximum capacity, refer to “Telehandler/ Attachment/Fork Capacity” on page 5-4.

The joystick (1) controls lift/lower and extend/retract movement of the boom.

The tilt roller switch (2) controls fork tilt.

• Press roller switch down to tilt up.

• Press roller switch up to tilt down.

To Swing:

The auxiliary hydraulic joystick (3) controls carriage swing.

• Move joystick left to swing left.

• Move joystick right to swing right.

Installation Procedure:

• Refer to “Attachment Installation” on page 5-9.

5-20 31200744

Section 5 - Attachments

WARNING

CRUSH HAZARD. Always level forks (horizontally) and telehandler frame before

swinging load to side. Swinging unlevel forks could cause load to slide off forks.

WARNING

CRUSH HAZARD. Do not use swing carriage to push or pull objects or load.

Failure to comply could cause object or load to fall.

WARNING

CRUSH HAZARD. Use retaining pin (if equipped) for locking swing frame to fixed

frame when carrying loads greater than 5000 lb. Failure to comply could cause object or load to fall.

Operation:

• To drive with a load, keep forks pointed forward and travel in accordance with the requirements set forth in Section 1 - General Safety Practices.

Equipment Damage Precautions:

• Do not use forks as a lever to pry material. Excessive prying forces could damage forks or machine structure.

• Do not attempt to lift loads that are attached or connected to another object.

5-2131200744

Section 5 - Attachments

OZ3670

OY3360

G9-43A

G10-43A

Dual Fork Positioning Carriage

Use Dual Fork Positioning Carriage Capacity Chart

To determine maximum capacity, refer to “Telehandler/ Attachment/Fork Capacity” on page 5-4.

The joystick (1) controls lift/lower and extend/retract movement of the boom.

The tilt roller switch (3) controls fork tilt.

• Press roller switch down to tilt up.

• Press roller switch up to tilt down.

To Fork Position:

The auxiliary hydraulic joystick (4) controls fork position.

• Move joystick left to shift forks out.

• Move joystick right to shift forks in.

Installation Procedure:

• Refer to “Attachment Installation” on page 5-9.

5-22 31200744

Section 5 - Attachments

WARNING

CRUSH HAZARD. Do not use fork positioning to push or pull objects or load.

Failure to comply could cause object or load to fall.

Operation:

• Travel in accordance with the requirements set forth in Section 1 - General Safety Practices.

Equipment Damage Precautions:

• Do not use forks as a lever to pry material. Excessive prying forces could damage forks or machine structure.

• Do not attempt to lift loads that are attached or connected to another object.

5-2331200744

Section 5 - Attachments

OY0580

OY3370

G9-43A

G10-43A

Mast Carriage

Use Mast Carriage Capacity Chart

To determine maximum capacity, refer to “Telehandler/ Attachment/Fork Capacity” on page 5-4.

The joystick (1) controls lift/lower and extend/retract movement of the boom.

The tilt roller switch (3) controls fork tilt.

• Press roller switch down to tilt up.

• Press roller switch up to tilt down.

To Raise/Lower Mast:

The auxiliary hydraulic joystick (3) controls the raise/lower movement of the mast.

• Move joystick left to lower.

• Move joystick right to raise.

Installation Procedure:

• Refer to “Attachment Installation” on page 5-9.

5-24 31200744

JLG G6-23A Operator Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Revision Log

Read This First

Table of Contents

Section 1 - General Safety Practices

Section 2 - Pre-Operation and Inspection

Section 3 - Controls and Indicators

Section 4 - Operation

Section 5 - Attachments

Section 6 - Emergency Procedures

Section 7 - Lubrication and Maintenance

Section 8 - Additional Checks

Section 9 - Specifications

Section 1 - General Safety Practices

1.1 HAZARD CLASSIFICATION SYSTEM

Safety Alert System and Safety Signal Words

1.2 GENERAL PRECAUTIONS

1.3 OPERATION SAFETY

Electrical Hazards

Tip Over Hazard

Travel Hazard

Load Falling Hazard

Lifting Personnel

Driving Hazards On Slopes

Pinch Points and Crush Hazards

Fall Hazard

Chemical Hazards

1.4 CLEARSKY (IF EQUIPPED)

Federal Communications Commission (FCC) Information for Users

Section 2 - Pre-Operation and Inspection

2.1 PRE-OPERATION CHECK AND INSPECTION

2.2 SAFETY DECALS

ANSI

2.3 WALK-AROUND INSPECTION

2.4 WARM-UP AND OPERATIONAL CHECKS

Warm-Up Check

Operational Check

2.5 OPERATOR CAB

2.6 WINDOWS

Cab Door Window (if equipped)

Section 3 - Controls and Indicators

3.1 GENERAL

3.2 CONTROLS

G6-42A & G9-43A

G10-43A

Dash Controls and Indicators

Ignition

Park Brake

Parking Procedure

Transmission Control Lever

Boom Joystick

Frame Level and Attachment Tilt (if equipped) Joystick

Auxiliary Hydraulic Joystick

Outrigger Joysticks (G10-43A)

Right Hand Panel

Accessory Control Lever (if equipped)

3.3 STEER MODES

Steer Mode Change

3.4 OPERATOR SEAT

Adjustments

Seat Belt

3.5 REVERSE SENSOR SYSTEM (IF EQUIPPED)

3.6 BOOM ANGLE AND EXTENSION INDICATORS

Section 4 - Operation

4.1 ENGINE

Starting the Engine

Extreme Cold Weather Starting (if equipped)

Battery Boosted Starting

Normal Engine Operation

Shut-Down Procedure

4.2 OPERATING WITH A NON-SUSPENDED LOAD

Lift Load Safely

Picking Up a Load

Transporting a Load

Leveling Procedure

Placing a Load

Disengaging a Load
