VENTILATION AND GAS COOKTOP PAIRINGS

G A S C O O KT O P S

		60,000 BTU TOTAL OR MORE				LESS THAN 60,000 BTU TOTAL
M O D E L S			36"		30"	36"		30"
		JGC7636B		JGC3536G	JGC7530B	JGC2536EB	JGC2530EB		JGC3530G
VENTILATION STYLE
ACCOLADE® DOWNDRAFT SYSTEM
JXD7836BS		■		■	■	■	■		■
TELESCOPING DOWNDRAFT SYSTEMS
JXD7030YS		—		—	■	—	■		■
JXD7036YS		—		■	■	■	■		■
PROFESSIONAL-STYLE HOODS
JXU9130WP / JXU9130HP		—		—	■	—	■		■
JXW9030WP / JXW9030HP		—		—	■	—	■		■
JXW9036WP / JXW9036HP		—		■	■	■	■		■
JXU9136WP / JXU9136HP		■		■	■	■	■		■
JXW9048WP / JXW9048HP		■		■	■	■	■		■
CUSTOM HOOD LINERS*
UXL5430BSS		—		—	—	—	■		■
JXL6536CSS		1,200 CFM only		■	■	■	■		■
JXL6536HS		1,200 CFM only		■	■	■	■		■
UXL6036YSS		1,200 CFM only		—	■	■	■		■
UXL6048YSS		1,200 CFM only		—	■	■	■		■
ISLAND-MOUNT PERIMETRIC HOODS
JXI8536HS		—		■	■	■	■		■
JXI8936DS		■		■	■	■	■		■
ISLAND-MOUNT HOODS
JXI8736DS / JXI8536DS		■		■	■	■	■		■
JXI8742DS		■		■	■	■	■		■
WALL-MOUNT PERIMETRIC HOODS
JXW8530HS		—		—	■	—	■		■
JXW8536HS		—		■	■	■	■		■
JXW8936DS		■		■	■	■	■		■
WALL-MOUNT HOODS
JVR0430H		—		—	■	—	■		■
JXW8530DS		—		—	■	—	■		■
JVR0436H		—		■	■	■	■		■
JXW8736DS / JXW8536DS		■		■	■	■	■		■
MICROWAVE / HOOD COMBOS
JMV8208CS		—		—	■	—	■		■
JMV9196CS		—		—	■	—	■		■

*Custom hood liners can be used with any of the following blower motors: UXB1200DYS, UXB0600DYS or UXI1200DYS.

KEY

■Recommended

—Not Recommended

IMPORTANT: Dimensional specifications are provided for planning purposes only. Do not make any cutouts based on this information. Refer to installation instructions packaged with product before selecting cabinetry, making cutouts or beginning installation.

All JennAir® appliances are appropriately UL, CUL or CSA approved.

VENTILATION AND INDUCTION COOKTOP PAIRINGS

I N D U C T I O N

M O D E L S			36"			30"		24"
		JIC4536X		JIC4736H	JIC4430X		JIC4730H	JIC4724H
VENTILATION STYLE
ACCOLADE® DOWNDRAFT SYSTEM
JXD7836BS		■		■	■		■	■
TELESCOPING DOWNDRAFT SYSTEMS
JXD7030YS		—		—	■		—	—
JXD7036YS		■		■	■		■	■
PROFESSIONAL-STYLE HOODS
JXU9130WP / JXU9130HP		—		—	■		—	—
JXW9030WP / JXW9030HP		—		—	■		—	—
JXW9036WP / JXW9036HP		■		■	■		■	■
JXU9136WP / JXU9136HP		■		■	■		■	■
JXW9048WP / JXW9048HP		■		■	■		■	■
CUSTOM HOOD LINERS*
UXL5430BSS		—		—	■		—	■
JXL6536CSS		■		■	■		■	■
JXL6536HS		■		■	■		■	■
UXL6036YSS		■		■	■		■	■
UXL6048YSS		■		■	■		■	■
ISLAND-MOUNT PERIMETRIC HOODS
JXI8536HS		■		■	■		■	■
JXI8936DS		■		■	■		■	■
ISLAND-MOUNT HOODS
JXI8736DS / JXI8536DS		■		■	■		■	■
JXI8742DS		■		■	■		■	■
WALL-MOUNT PERIMETRIC HOODS
JXW8530HS		—		—	■		■	■
JXW8536HS		■		■	■		■	■
JXW8936DS		■		■	■		■	■
WALL-MOUNT HOODS
JVR0430H		—		—	■		■	■
JXW8530DS		—		—	■		—	—
JVR0436H		■		■	■		■	■
JXW8736DS / JXW8536DS		■		■	■		■	■
MICROWAVE / HOOD COMBOS
JMV8208CS		—		—	■		■	■
JMV9196CS		—		—	■		■	■

*Custom hood liners can be used with any of the following blower motors: UXB1200DYS, UXB0600DYS or UXI1200DYS.

KEY

■Recommended

—Not Recommended

IMPORTANT: Dimensional specifications are provided for planning purposes only. Do not make any cutouts based on this information. Refer to installation instructions packaged with product before selecting cabinetry, making cutouts or beginning installation.

All JennAir® appliances are appropriately UL, CUL or CSA approved.

VENTILATION AND RADIANT COOKTOP PAIRINGS

R A D I A N T

			36"
M O D E L S
		JEC4536H	JEC3536B	JEC3536H
VENTILATION STYLE
ACCOLADE® DOWNDRAFT SYSTEM
JXD7836BS		■	■	■
TELESCOPING DOWNDRAFT SYSTEMS
JXD7030YS		—	—	—
JXD7036YS		■	■	■
PROFESSIONAL-STYLE HOODS
JXU9130WP / JXU9130HP		—	—	—
JXW9030WP / JXW9030HP		—	—	—
JXW9036WP / JXW9036HP		■	■	■
JXU9136WP / JXU9136HP		■	■	■
JXW9048WP / JXW9048HP		■	■	■
CUSTOM HOOD LINERS*
UXL5430BSS		—	—	—
JXL6536CSS		■	■	■
JXL6536HS		■	■	■
UXL6036YSS		■	■	■
UXL6048YSS		■	■	■
ISLAND-MOUNT PERIMETRIC HOODS
JXI8536HS		■	■	■
JXI8936DS		■	■	■
ISLAND-MOUNT HOODS
JXI8736DS / JXI8536DS		■	■	■
JXI8742DS		■	■	■
WALL-MOUNT PERIMETRIC HOODS
JXW8530HS		—	—	—
JXW8536HS		■	■	■
JXW8936DS		■	■	■
WALL-MOUNT HOODS
JVR0430H		—	—	—
JXW8530DS		—	—	—
JVR0436H		■	■	■
JXW8736DS / JXW8536DS		■	■	■
MICROWAVE / HOOD COMBOS
JMV8208CS		—	—	—
JMV9196CS		—	—	—

*Custom hood liners can be used with any of the following blower motors: UXB1200DYS, UXB0600DYS or UXI1200DYS.

KEY

■Recommended

—Not Recommended

IMPORTANT: Dimensional specifications are provided for planning purposes only. Do not make any cutouts based on this information. Refer to installation instructions packaged with product before selecting cabinetry, making cutouts or beginning installation.

All JennAir® appliances are appropriately UL, CUL or CSA approved.

VENTILATION AND RADIANT COOKTOP PAIRINGS

R A D I A N T

				30"			24"
M O D E L S
		JEC4430B	JEC4430H		JEC3430B	JEC3430H	JEC4424H
VENTILATION STYLE
ACCOLADE® DOWNDRAFT SYSTEM
JXD7836BS		■	■		■	■	■
TELESCOPING DOWNDRAFT SYSTEMS
JXD7030YS		■	■		■	■	■
JXD7036YS		■	■		■	■	■
PROFESSIONAL-STYLE HOODS
JXU9130WP / JXU9130HP		■	■		■	■	■
JXW9030WP / JXW9030HP		■	■		■	■	■
JXW9036WP / JXW9036HP		■	■		■	■	■
JXU9136WP / JXU9136HP		■	■		■	■	■
JXW9048WP / JXW9048HP		■	■		■	■	■
CUSTOM HOOD LINERS*
UXL5430BSS		■	■		■	■	■
JXL6536CSS		■	■		■	■	■
JXL6536HS		■	■		■	■	■
UXL6036YSS		■	■		■	■	■
UXL6048YSS		■	■		■	■	■
ISLAND-MOUNT PERIMETRIC HOODS
JXI8536HS		■	■		■	■	■
JXI8936DS		■	■		■	■	■
ISLAND-MOUNT HOODS
JXI8736DS / JXI8536DS		■	■		■	■	■
JXI8742DS		■	■		■	■	■
WALL-MOUNT PERIMETRIC HOODS
JXW8530HS		■	■		■	■	■
JXW8536HS		■	■		■	■	■
JXW8936DS		■	■		■	■	■
WALL-MOUNT HOODS
JVR0430H		■	■		■	■	■
JXW8530DS		■	■		■	■	■
JVR0436H		■	■		■	■	■
JXW8736DS / JXW8536DS		■	■		■	■	■
MICROWAVE / HOOD COMBOS
JMV8208CS		■	■		■	■	■
JMV9196CS		■	■		■	■	■

*Custom hood liners can be used with any of the following blower motors: UXB1200DYS, UXB0600DYS or UXI1200DYS.

KEY

■Recommended

—Not Recommended

IMPORTANT: Dimensional specifications are provided for planning purposes only. Do not make any cutouts based on this information. Refer to installation instructions packaged with product before selecting cabinetry, making cutouts or beginning installation.

All JennAir® appliances are appropriately UL, CUL or CSA approved.

VENTILATION AND PROFESSIONAL-ST YLE RANGETOP PAIRINGS

P R O F E S S I O N A L - S T Y L E R A N G E T O P S

			60,000 BTU TOTAL OR MORE
M O D E L S				48"
		JGCP548WP	JGCP548H		JGCP648H	JGCP748H
VENTILATION STYLE
ACCOLADE® DOWNDRAFT SYSTEM
JXD7836BS		—	—		—	—
TELESCOPING DOWNDRAFT SYSTEMS
JXD7030YS		—	—		—	—
JXD7036YS		—	—		—	—
PROFESSIONAL-STYLE HOODS
JXU9130WP / JXU9130HP		—	—		—	—
JXW9030WP / JXW9030HP		—	—		—	—
JXW9036WP / JXW9036HP		—	—		—	—
JXU9136WP / JXU9136HP		—	—		—	—
JXW9048WP / JXW9048HP		■	■		■	■
CUSTOM HOOD LINERS*
UXL5430BSS		—	—		—	—
JXL6536CSS		—	—		—	—
JXL6536HS		—	—		—	—
UXL6036YSS		—	—		—	—
UXL6048YSS		■	—		—	■
ISLAND-MOUNT PERIMETRIC HOODS
JXI8536HS		—	—		—	—
JXI8936DS		—	—		—	—
ISLAND-MOUNT HOODS
JXI8736DS / JXI8536DS		—	—		—	—
JXI8742DS		—	—		—	—
WALL-MOUNT PERIMETRIC HOODS
JXW8530HS		—	—		—	—
JXW8536HS		—	—		—	—
JXW8936DS		—	—		—	—
WALL-MOUNT HOODS
JVR0430H		—	—		—	—
JXW8530DS		—	—		—	—
JVR0436H		—	—		—	—
JXW8736DS / JXW8536DS		—	—		—	—
MICROWAVE / HOOD COMBOS
JMV8208CS		—	—		—	—
JMV9196CS		—	—		—	—

*Custom hood liners can be used with any of the following blower motors: UXB1200DYS, UXB0600DYS or UXI1200DYS.

KEY

■Recommended

—Not Recommended

IMPORTANT: Dimensional specifications are provided for planning purposes only. Do not make any cutouts based on this information. Refer to installation instructions packaged with product before selecting cabinetry, making cutouts or beginning installation.

All JennAir® appliances are appropriately UL, CUL or CSA approved.
