JR-6
STEREO ROCK SPEAKER
SPECIFICATIONS
FREQUENCY RESPONSE 67Hz-22KHz
HIGH FREQUENCY DRIVER
LOW FREQUENCY DRIVER 6.5” (16.5cm) DVC IMG Woofer
SENSITIVITY 88dB (2.83V @ 1m)
Dual .75” (1.9cm)
Aluminum Tweeters
DESIGN + PERFORMANCE
The satin painted finish and compact design of the
JR-6 allows it to blend seamlessly into even the
most luxurious of outdoor living spaces, while the
.75” aluminum tweeters and 6.5” dual voice coil
IMG woofer provide detailed, dynamic, balanced
sound.
SINGLE POINT STEREO
The JR-6 rock speaker is equipped with dual
inputs, a dual voice coil woofer, and dual
tweeters for true stereo reproduction from a
single speaker. Inputs can also be summed to
mono for maximum system flexibility in any
listening environment, from small residential
systems to massive commercial installs.
ALL WEATHER DURABILITY
A UV-resistant, fiberglass cabinet provides the
utmost in all-weather capability. With an IP45
rating, the Jamo JR-6 rock satellite is lab tested
and certified to offer the best in outdoor audio
year in and year out.
POWER HANDLING 2 x 50W
IMEDANCE 2 x 8 Ohm / 70V
ENCLOSURE MATERIAL UV Treated Fiberglass
FINISH Granite, Sandstone
GRILLE MATERIAL Rust-proof Aluminum
DIMENSIONS
(H x W x D)
WEIGHT 5.53 kg (12.2 lbs)
ACCESSORIES
(SOLD SEPARATELY)
JAMO.COM
310mm x 307mm x 295mm
12.24” x 12.09” W x 11.65”
JDA-500 DSP Amplier
(120V: 10634321, 230V: 10634322)
ALL SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
©2017 KLIPSCH GROUP, INC. JAMO IS A REGISTERED TRADEMARK OF KLIPSCH GROUP, INC. IN THE USA AND OTHER COUNTRIES.
A WHOLLY-OWNED SUBSIDIARY OF VOXX INTERNATIONAL CORPORATION.
OPTIMIZED WITH JDA-500
The new Jamo JDA-500 DSP amplifier is the
perfect match for the Jamo rock speakers series
- with 70V and low impedence compatibility and
one-click Jamo speaker presets to optimize the
acoustic performance of your Jamo speakers
- no amplifier sounds better with Jamo rock
speakers.
V01 - 0824
