HP Deskjet 1000 J User Guide

HP Deskjet 1000 J110 series

1 How Do I?..................................................................................................................................3

2Get to know the HP Printer

Printer parts................................................................................................................................5

On button....................................................................................................................................5

3Print

Print documents..........................................................................................................................7

Print photos.................................................................................................................................8

Print envelopes...........................................................................................................................9

Tips for print success................................................................................................................10

5 Work with cartridges

Check the estimated ink levels.................................................................................................21

Order ink supplies.....................................................................................................................22

Replace the cartridges..............................................................................................................23

Use single-cartridge mode........................................................................................................25

Cartridge warranty information.................................................................................................25

6 Solve a problem

Improve print quality.................................................................................................................27

Clear a paper jam.....................................................................................................................29

Unable to print..........................................................................................................................31

HP support................................................................................................................................35

7 Technical information

Notice........................................................................................................................................37

Specifications...........................................................................................................................37

Environmental product stewardship program...........................................................................39

Regulatory notices....................................................................................................................42

Index..............................................................................................................................................45

Contents

1How Do I?

Learn how to use your HP Printer

Printer parts

• Load media

• Replace the cartridges

• Clear a paper jam

•

How Do I?

How Do I? 3

How Do I?

Chapter 1

4 How Do I?

2 Get to know the HP Printer

• Printer parts

•

On button

Printer parts

1 Input tray

2 Paper width guide

3 On button: Turns the product on or off. When the product is off, a minimal amount of power is

still used. To completely remove power, turn off the product, then unplug the power cord.

4 Output tray

5 Output tray extender (also referred to as the tray extender)

6 Cartridge door

7 Print cartridges

8 USB port

9 Power connection: Use only with the power adapter supplied by HP

On button

Get to know the HP Printer

On button 5

Chapter 2

• When the product is turned on, the On button light will be lit.

• When the product is processing a job, the On button light will be blinking.

• If the On button light is blinking very quickly, the printer is in an error state that you

can resolve by following the onscreen messages. If you do not see any onscreen messages, try printing a document to generate an onscreen message.

• If you cleared a paper jam or the printer was out of paper, you will need to press the

On button to resume printing.

Get to know the HP Printer

6 Get to know the HP Printer

3Print

Choose a print job to continue.

Print documents

Print photos

Print envelopes

Print documents

To print from a software application

1. Make sure the output tray is open.

2. Make sure you have paper loaded in the input tray.

3. From your software application, click the Print button.

4. Make sure the product is the selected printer.

5. Click the button that opens the Properties dialog box.

Depending on your software application, this button might be called Properties, Options, Printer Setup, Printer, or Preferences.

6. Select the appropriate options.

•On Layout tab select Portrait or Landscape orientation.

•On Paper/Quality tab select the appropriate paper type and print quality from the

Media drop-down list.

• Click Advanced to select the appropriate paper size from the Paper/Output list.

Print documents 7

Print

Chapter 3

7. Click OK to close the Properties dialog box.

8. Click Print or OK to begin printing.

NOTE: You can print your document on both sides of the paper, instead of just one

side. Click on the Advanced button on the Paper/Quality or Layout tab. From the Pages to Print drop-down menu select Print Odd Pages Only. Click OK to print.

After the odd numbered pages of the document have been printed, remove the document from the output tray. Reload the paper in the input tray with the blank side facing up. Return to the Pages to Print drop-down menu and then select Print Even

Pages Only. Click OK to print.

Print photos

To print a photo on photo paper

1. Make sure the output tray is open.

2. Remove all paper from the input tray, and then load the photo paper with side to be

printed on facing up.

NOTE: If the photo paper you are using has perforated tabs, load photo paper

so that tabs are on top.

8Print

3. On the File menu in your software application, click Print.

4. Make sure the product is the selected printer.

5. Click the button that opens the Properties dialog box.

Depending on your software application, this button might be called Properties, Options, Printer Setup, Printer, or Preferences.

6. Click the Paper/Quality tab.

7. Select the appropriate options.

•On Layout tab select Portrait or Landscape orientation.

•On Paper/Quality tab select the appropriate paper type and print quality from the Media drop-down list.

• Click Advanced to select the appropriate paper size from the Paper/Output list.

NOTE: For maximum dpi resolution, go to the Paper/Quality tab and select

Photo Paper, Best Quality from the Media drop-down list. Make sure you are printing in color. Then go to the Advanced tab and select Yes from the Print in Max DPI drop-down list. For more information, see

dpi.

8. Click OK to return to the Properties dialog box.

9. Click OK, and then click Print or OK in the Print dialog box.

NOTE: Do not leave unused photo paper in the input tray. The paper might start to

curl, which could reduce the quality of your printout. Photo paper should be flat before printing.

Print envelopes

You can load one or more envelopes into the input tray of the HP Printer. Do not use shiny or embossed envelopes or envelopes that have clasps or windows.

NOTE: For specific details on how to format text for printing on envelopes, consult

the help files in your word processing software. For best results, consider using a label for the return address on envelopes.

Print using the maximum

To print envelopes

1. Make sure the output tray is open.

2. Slide the paper guide all the way to the left.

3. Place the envelopes in the right side of the tray. The side to be printed on should face

up. The flap should be on the left side.

4. Push the envelopes into the printer until they stop.

5. Slide the paper guide firmly against the edge of the envelopes.

Print envelopes 9

Chapter 3

6. Click the button that opens the Properties dialog box.

Depending on your software application, this button might be called Properties,

Options, Printer Setup, Printer, or Preferences.

7. Select the appropriate options.

•On Paper/Quality tab select a Plain paper type.

• Click the Advanced button, and select the appropriate envelope size from the

Paper Size drop down menu.

8. Click OK, and then click Print or OK in the Print dialog box.

Tips for print success

To successfully print, the HP cartridges should be functioning properly with sufficient ink, the paper should be loaded correctly, and the product should have the appropriate settings.

Cartridge tips

• Use genuine HP ink cartridges.

• Install both the black and tri-color cartridges correctly.

For more information, see Replace the cartridges.

• Check the estimated ink levels in the cartridges to make sure there is sufficient ink.

For more information, see

• For more information, see

Check the estimated ink levels. Improve print quality.

Paper loading tips

• Load a stack of paper (not just one page). All of the paper in the stack should be the

same size and type to avoid a paper jam.

• Load paper with side to be printed on facing up.

• Ensure that paper loaded in the input tray lays flat and the edges are not bent or torn.

• Adjust the paper-width guide in the input tray to fit snugly against all paper. Make sure

the paper-width guide does not bend the paper in the input tray.

• For more information, see

Printer settings tips

• On the Paper/Quality tab of the print driver, select the appropriate paper type and

quality from the Media drop down menu.

• Click the Advanced button, and select the appropriate Paper Size from the Paper/

Output drop-down menu.

• Click the HP Printer desktop icon to open the Printer Software. In the Printer Software,

click Printer Actions and then click Set Preferences to access the print driver.

NOTE: You can also access the Printer Software by clicking Start > Programs

> HP > HP Deskjet 1000 J110 series > HP Deskjet 1000 J110 series

Load media.

10 Print

Notes

• Genuine HP ink cartridges are designed and tested with HP printers and papers to

help you easily produce great results, time after time.

NOTE: HP cannot guarantee the quality or reliability of non-HP supplies. Product

service or repairs required as a result of using a non-HP supply will not be covered under warranty.

If you believe you purchased genuine HP ink cartridges, go to:

www.hp.com/go/anticounterfeit

• Ink level warnings and indicators provide estimates for planning purposes only.

NOTE: When you receive a low-ink warning message, consider having a

replacement cartridge available to avoid possible printing delays. You do not need to replace the cartridges until print quality becomes unacceptable.

For more information, see

• You can print your document on both sides of the paper, instead of just one side.

NOTE: Click the Advanced button on the Paper/Quality or Layout tab. From

the Pages to Print drop-down menu select Print Odd Pages Only. Click OK to print. After the odd numbered pages of the document have been printed, remove the document from the output tray. Reload the paper in the input tray with the blank side facing up. Return to the Pages to Print drop-down menu and then select Print Even Pages Only. Click OK to print.

Check the estimated ink levels.

• Print using black ink only

NOTE: If you want to print a black and white document using black ink only, click

the Advanced button. From the Print in Grayscale drop-down menu select Black Ink Only, then click the OK button. If you see Black and White as an option

on the Paper/Quality tab or the Layout tab, select it.

Click here to go online for more information.

Print using the maximum dpi

Use maximum dots per inch (dpi) mode to print high-quality, sharp images on photo paper.

See technical specifications for the print resolution of the maximum dpi mode.

Printing in maximum dpi takes longer than printing with other settings and requires a large amount of disk space.

To print in Maximum dpi mode

1. Make sure you have photo paper loaded in the input tray.

2. On the File menu in your software application, click Print.

3. Make sure the product is the selected printer.

Print using the maximum dpi 11

Chapter 3

4. Click the button that opens the Properties dialog box.

Depending on your software application, this button might be called Properties,

Options, Printer Setup, Printer, or Preferences.

5. Click the Paper/Quality tab.

6. In the Media drop-down list, click Photo Paper, Best Quality.

NOTE: Photo Paper, Best Quality must be selected from the Media drop-down

list on the Paper/Quality tab to enable printing in maximum DPI.

7. Click the Advanced button.

8. In the Printer Features area, select Yes from the Print in Max DPI drop-down list.

9. Select Paper Size from Paper/Output drop-down menu.

10. Click OK to close the advanced options.

11. Confirm Orientation on Layout tab, then click OK to print.

12 Print

4 Paper basics

You can load many different types and sizes of paper in the HP Printer, including letter or A4 paper, photo paper, transparencies, and envelopes.

This section contains the following topics:

Load media
