harman/kardon Service Manual

AVR 347/230 AVR 350/230

7 x 55W 7.1 CHANNEL A/V RECEIVERS

CONTENTS

ESD WARNING 2 BASIC SPECIFICATIONS 3 TROUBLESHOOTING GUIDE 4 PROCESSOR RESET 4 AVR 347 PACKAGE LIST AND PARTS 5 AVR 347 DISASSEMBLY 6 AVR 347 DISASSEMBLY PROCEDURE 7 AVR347 EXPLODED VIEW AND PARTS 11 AVR350 PACKAGE LIST AND PARTS 12

AVR 350 DISASSEMBLY 13 AVR 350 EXPLODED VIEW AND PARTS 14 ELECTRICAL PARTS LIST 15 PCB DRAWINGS 74 BLOCK DIAGRAM 83 WIRING DIAGRAM 84 AMP BIAS ADJUSTMENT 85 SCHEMATIC DIAGRAMS 86

(For Semiconductor Pinouts, see separate file )

Released EU2008 harman/kardon, Inc. Rev 0, 07/2008 250 Crossways Park Dr. Woodbury, New York, 11797

harman/kardon

AVR 347/230 - AVR 350/230 Service Manual

Page 1 of 95

Each precautionin thismanual shouldbe followedduring servicing.

Components identified with the IEC symbol in the parts list are special significance to safety. When replacing a component identified with

, use only the replacement parts designated, or parts with the same ratings or resistance, wattage, or voltage that are designated in the

parts list in this manual. Leakage-current or resistance measurements must be made to determine that exposed parts are acceptably

insulated from the supply circuit before retuming the product to the customer.

Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called

Electrostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field effect transistors and

semiconductor "chip" components.

The following techniques should be used to help reduce the incidence of component damage caused by static electricity.

1. Immediately before handling any semiconductor component or semiconductor-equipped assembly, drain off any electrostatic charge on

your body by touching a known earth ground. Alternatively, obtain and wear a commercially available discharging wrist strap device,

which should be removed for potential shock reasons prior to applying power to the unit under test.

2. After removing an electrical assembly equipped with ES devices, place the assembly on a conductive surface such as aluminum foil, to

prevent electrostatic charge build-up or exposure of the assembly.

3. Use only a grounded-tip soldering iron to solder or unsolder ES devices.

4. Use only an anti-static solder removal device. Some solder removal devices not classified as "anti-static" can generate electrical charges

sufficient to damage ES devices.

5. Do not use freon-propelled chemicals. These can generate electrical change sufficient to damage ES devices.

6. Do not remove a replacement ES device from its protective package until immediately before you are ready to install it. (Most replacement

ES devices are packaged with leads electrically shorted together by conductive foam, aluminum foil or comparable conductive material.)

7. Immediately before removing the protective material from the leads of a replacement ES device, touch the protective material to the

chassis or circuit assembly into which the device will be installed.

Be sure no power is applied to the chassis or circuit, and observe all other safety precautions.

8. Minimize bodily motions when handling unpackaged replacement ES devices. (Otherwise harmless motion such as the brushing together

or your clothes fabric or the lifting of your foot from a carpeted floor can generate static electricity sufficient to damage an ES devices.

CAUTION :

harman/kardon

AVR 347/230 - AVR 350/230 Service Manual

Page 2 of 95

Technical Specifications

harman/kardon

AVR 347/230 - AVR 350/230 Service Manual

Page 3 of 95

Audio Section

Stereo Mode Continuous Average Power (FTC)

70 Watts per channel, 20Hz–20kHz, @ < 0.07% THD, both channels driven into 8 ohms

7 Channel Surround Modes

Power Per Individual Channel (all channels driven simultanously)

Front L&R channels: 55 Watts per channel, @ < 0.07% THD, 20Hz–20kHz into 8 ohms

Center channel: 55 Watts, @ < 0.07% THD, 20Hz–20kHz into 8 ohms

Surround (L & R Side, Back) channels: 55 Watts per channel, @ < 0.07% THD, 20Hz–20kHz into 8 ohms

Input Sensitivity/Impedance

Linear (High Level) 200mV/47kohms Signal-to-Noise Ratio (IHF-A) 100dB Surround System Adjacent Channel Separation

Analog Decoding 40dB

(Pro Logic, etc.)

Dolby Digital (AC-3) 55dB

DTS 55dB

FM Tuner Section

Frequency Range 87.5–108MHz Usable Sensitivity IHF 1.3 µV/13.2dBf Signal-to-Noise Ratio Mono/Stereo: 70/68dB (DIN) Distortion Mono/Stereo: 0.2/0.3% Stereo Separation 40dB @ 1kHz Selectivity ±400kHz: 70dB Image Rejection 80dB IF Rejection 90dB

AM Tuner Section

Frequency Range 522–1620kHz Signal-to-Noise Ratio 45dB Usable Sensitivity Loop: 500µV Distortion 1kHz, 50% Mod: 0.8% Selectivity ±10kHz: 30dB

Video Section

Video Format PAL/NTSC Input Level/Impedance 1Vp-p/75 ohms Output Level/Impedance 1Vp-p /75 ohms Video Frequency Response (Composite and S-Video) 10Hz–8MHz (-3dB) Video Frequency Response (Component) 10Hz–100MHz (-3dB)

Frequency Response

@ 1W (+0dB, –3dB) 10Hz–130kHz High Instantaneous

Current Capability (HCC) ±35 Amps Transient Intermodulation

Distortion (TIM) Unmeasurable Rise Time 16 µsec Slew Rate 40V/µsec**

This product incorporates copyright protection technology that is protected by method claims of certain U.S.patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or

disassembly is prohibited.

General

Power Requirement AC 220–240V/50Hz Power Consumption 118W idle, 890W maximum

(7 channels driven)

Dimensions (Max)

Width 440mm Height 165mm Depth 382mm Weight 13.9 kg

Depth measurement includes knobs, buttons and terminal connections. Height measurement includes feet and chassis. All features and specifications are subject to change without notice.

Harman Kardon, The Bridge and Logic 7 are registered trademarks of Harman International Industries, Incorporated.

is a trademark of Harman International Industries, Inc.

*Manufactured under license from Dolby Laboratories. “Dolby,”“Pro Logic” and the Double-D symbol are trademarks of Dolby Laboratories.

"DTS","DTS ES","Neo:6"and"96/24" are trademarks of DTS,Inc.

SA-CD is a trademark of Sony Electronics, Inc.

Blu-ray Disc is a trademark of the Blu-ray Disc Association.

Apple and iPod are registered trademarks of Apple Computer, Inc.

Cirrus is a registered trademark of Cirrus Logic Corp.

**Without input anti slewing and output isolation networks.

READY

A-BUS and A-BUS/ Australia. Faroudja and DCDi by Faroudja are trademarks of Genesis Microchip, Inc. HD-DVD is a trademark of the DVD Format/Logo Licensing Corporation (DVD FLLC). HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing, LLC.

Ready are registered trademarks of Leisure Tech Electronics Pty Ltd

Troubleshooting Guide

harman/kardon

AVR 347/230 - AVR 350/230 Service Manual

Page 4 of 95

SYMPTOM CAUSE SOLUTION

Unit does not function when Main • No AC Power • Make certain AC power cord is plugged Power Switch

Display lights, but no sound • Intermittent input connections • Make certain that all input and speaker or picture connections are secure

No sound from any speaker; • Amplifier is in protection mode • Check speaker-wire connections for shorts at receiver light around Power switch

No sound from surround or • Incorrect surround mode • Select a mode other than Stereo center speakers • Input is mono • There is no surround information from mono sources (except with

is pushed into a live outlet

• Check to see if outlet is switch controlled

• Mute is on • Press Mute button

• Volume control is down • Turn up volume control

is red due to possible short and speaker ends

• Amplifier is in protection mode • Contact your local Harman Kardon service depot due to internal problems

Theater and Hall surround modes)

• Incorrect configuration • Check speaker mode configuration

• Stereo or Mono program material • Some surround modes may not create rear-channel information

from nonencoded programs



Unit does not respond to • Weak batteries in remote • Change remote batteries remote commands • Wrong device selected • Press the AVR Selector

• Remote sensor Úis obscured • Make certain front-panel sensor is visible to remote or

connect remote sensor

Intermittent buzzing in tuner • Local interference • Move unit or antenna away from computers, fluorescent lights,

motors or other electrical appliances

Letters flash in the Channel Indicator • Digital audio feed paused • Resume play for DVD

Display $and Digital Audio stops • Check that Digital Signal is fed to the Digital Input selected

Processor Reset

In the rare case where the unit’s operation or the displays seem abnormal, the cause may involve the erratic operation of the system’s memory or microprocessor.

To correct this problem, first unplug the unit from the AC wall outlet and wait at least three minutes. After the pause, reconnect the AC power cord and check the unit’s operation. If the system still malfunctions, a system reset may clear the problem.

To clear the AVR’s entire system memory including tuner presets, output level settings, delay times and speaker configuration data, first put the unit in Standby by pressing the System Power Control button the Tone Mode button

The unit will turn on automatically. Note that once you have cleared the memory in this manner, it is necessary to re-establish all system configuration settings and tuner presets.

. Next press and hold

for three seconds.

NOTE: Resetting the processor will erase any configuration settings you have made for speakers, output levels, surround modes, digital input assignments as well as the tuner presets. After a reset the unit will be returned to the factory presets, and all settings for these items must be reentered.

If the system is still operating incorrectly,there may have been an electronic discharge or severe AC line interference that has corrupted the memory or microprocessor.

If these steps do not solve the problem, consult an authorized Harman Kardon service depot.

MANUAL ASS'Y

BOX,OUT CARTON

DESCRIPTIONNO

CPS6A564

CQXAVR347

CPG1A822W

Q,tyPARTS NO.

CPS6A565SNOW,PAD(R)

31SNOW,PAD(L)

SET AVR347SET 1

MICROPHONE ASS'Y CJXAVR340MICRO 1

2. Package Drawing

AVR347

SNOW PAD (R)

BOX ,OUT CARTON

SET

SNOW PAD (L)

MICROPHONE ASS'Y

MANUAL ASS'Y

REMOCON ASS'Y

REMOCON ASS'Y CARTAVR347 1

POLY BAG

NO DESCRIPTION PARTS NO. Q,ty

CPB1061YPOLY BAG

1. Instruction manual ass'y - Accessories

SHEET GUIDE

STAPLE

KPL0905

CQE1A331Z

HARTZONE23

CABR03P3

CSA1A027Z

REMOCON ASS'Y(ZONE2)

AM LOOP ANTENNA ASS'Y

BATTERY

CARD WARRANTY

CQE1A172X 1

INSTRUCTION MANUAL

FM 1 POL ANT(UL)

CQX1A1185Z

CSA1A019Z 1

CARD WARRANTY

SHEET GUIDE

BATTERY ASS'Y

AM LOOP ANTENNA ASS'Y

MANUAL INSTRUCTION

FM 1 POLE ANT(UL)

STAPLE

TRANSMITTER ASS'Y

REMOCON

REMOCON ASS'Y(ZONE2)

BATTERY ASS'Y

A REMOCON ASS'Y CARTAVR347 1

BATTERY CANR03P 2

COVER ASS'Y

SHEET,FRONT COVER

COVER A

COVER B

BAG , POLY

PAD, COVER

COVER ASS'Y12

CQE1A219Z

CGR1A332M7H43

CGR1A331M7H43

CPS1A676

CPB1A176Z 1

CGRAVR130ZA 1

CORD,POEWR (UL)

IMAGE BROCHURES13 HQE1A273Z 1

MICROPHONE ASS'Y

B MICROPHONE ASS'Y CJXAVR340MICRO 1

IMAGE BROCHURES

CJA2A070ZCORD,POWER(UL)

harman/kardon

AVR 347/230 - AVR 350/230 Service Manual

Page 5 of 95

1. Removing the Top Cabinet Remove the Screws

DISASSEMBLY

Remove the Screws

2. Removing the Front Panel

1 9

Remove the Screws

4. Removing the Main PCB

1 7

Remove the Screws

30 32 33

3. Removing the Rear Panel

AVR347

7 6 5 4

34 35

25 26

20 21

3837

harman/kardon

AVR 347/230 - AVR 350/230 Service Manual

Page 6 of 95

DISASSEMBLY PROCEDURE (AVR347)

<1> TOP-CABINET(21) REMOVAL

1. Remove 13 screws(S1,S7) and then remove the Top-cabinet.

<2> FRONT PANEL ASS’Y REMOVAL

1. Remove the Top-cabinet, referring to the previous step<1>.

2. Disconnect the card cable between connector(CN72-17p) on the Fip PCB(37-1) and connector(CN72) on the Input PCB(39-1).

3. Disconnect the lead wire(BN81-8P) on the Fip PCB(37-1) from connector(CN81) on the Trans PCB(40-4).

4. Disconnect the lead wire(BN22-6P) on the Phone PCB(37-5) from connector(CN22) on the Input PCB(39-1).

5. Disconnect the lead wire(BN18-5P) on the Phone PCB(37-5) from connector(CN18) on the Input PCB(39-1).

6. Disconnect the lead wire(BN10-4P) on the Volume PCB(37-6) from connector(CN10) on the Input PCB(39-1).

7. Disconnect the lead wire(BN41-6P) on the Volume PCB(37-6) from connector(CN41) on the Video PCB(41).

8. Disconnect the lead wire(BN90-2P) on the Main PCB(38-1) from connector(CN86) on the Moms PCB(37-4).

9. Remove 1 screw(S10) and then lead wire(JW82-1P,JW83-1P) on the Phone PCB(37-5).

10 .Remove 1screw(S10) and then lead wire(JW84-1P) on the Volume PCB(37-3).

11. Remove 10 screws(S1) and then remove the Front Panel ASS’Y.

<3> Volume PCB(37-6) REMOVAL

1. Remove the Top-cabinet, referring to the previous step<1>.

2. Remove the Front Panel ASS’Y, referring to the previous step<2>.

3. Pull out the Volume Knob ASS’Y.

4. Disconnect connector(CN84) on the Volume PCB(37-6) from the lead wire(BN84-5P) on the Fip PCB(37-1).

5. Disconnect the lead wire(BN92-5P)on the Volume PCB(37-6) from connector(CN92) on the Phone PCB(37-5).

6. Remove 8 screws(S2,S14), and then remove the Volume PCB(37-6).

<4>PHONE PCB(37-5) REMOVAL

1. Remove the Top-cabinet, referring to the previous step<1>.

2. Remove the Front Panel ASS’Y, referring to the previous step<2>.

3. Disconnect connector(CN92) on the Phone PCB(37-5) from the lead wire(BN92-5P) on the Volume PCB(37-6).

4.. Disconnect connector(CN85)on the Phone PCB(37-5) from the lead wire(BN85-3P) on the Fip PCB(37-1).

5. Remove 2 screws(S2) and then remove the Phone PCB(37-5).

<5>POWER LED PCB(37-3) REMOVAL

1. Remove the Top-cabinet, referring to the previous step<1>.

2. Remove the Front Panel ASS’Y, referring to the previous step<2>.

3. Disconnect connector(CN88) on the Power Led PCB(37-3) from the lead wire(BN88-4P) on the Fip PCB(37-1) .

4. Remove 2 screws(S2) and then remove the Power led PCB(37-3).

<6>FIP PCB(37-1) REMOVAL

1. Remove the Top-cabinet, referring to the previous step<1>.

2. Remove the Front Panel ASS’Y, referring to the previous step<2>.

3. Disconnect the lead wire(BN84-5P) on the Fip PCB(37-1) from connector(CN84) on the Volume PCB(37-6).

4. Disconnect the lead wire(BN85-3P) on the Fip PCB(37-1) from connector(CN85) on the Phone PCB(37-5).

5. Disconnect the lead wire(BN88-4P) on the Fip PCB(37-1) from connector(CN88) on the Power Led PCB(37-3).

6. Disconnect the connector (CN89) on the Fip PCB(37-1) from lead wire(BN89-4P) on the Key PCB(37-2).

7. Remove 3 screws(S2) and then remove the Guide PCB(37-8) & the Fip PCB(37-1).

<7>KEY PCB(37-2) REMOVAL

1. Remove the Top-cabinet, referring to the previous step<1>.

2. Remove the Front Panel ASS’Y, referring to the previous step<2>.

harman/kardon

AVR 347/230 - AVR 350/230 Service Manual

Page 7 of 95

3. Remove the Fip PCB(37-1), referring to the previous step<6>.

4. Remove 10 screws(S2) and then remove the Key PCB(37-2).

<8>TUNER MODULE(43) REMOVAL

1. Remove the Top-cabinet, referring to the previous step<1>.

2. Disconnect the card cable between connector(CON1-13P) on the Tuner module(43) and connector(CN13) on the Input PCB(39-1).

3. Remove 2 screws(S8) and then remove the Tuner Module(43).

<9>HUDSON PCB(42) REMOVAL

1. Remove the Top-cabinet, referring to the previous step<1>.

2. Disconnect connector(CN80) on the HUDSON PCB(42) from the lead wire(BN80-3P) on the RS232 PCB(37-7).

3. Remove 3 screws(S15).

4. Disconnect the board to board connector between and connector(CN81-44P) on the HUDSON PCB(42)

and connector(BN81-44P) on VIDEO PCB(41) and then remove the HUDSON PCB(42).

<10>VIDEO PCB(41) REMOVAL

1. Remove the Top-cabinet, referring to the previous step<1>.

2. Remove the Hudson PCB(42), referring to the previous step<9>.

3. Disconnect the card cable between connector(BN14-17p) on the Video PCB(41) and connector(CN14) on the Input PCB(39-1).

4. Disconnect connector(CN43) on the Video PCB(41) from the lead wire(BN43-3P) on the Regulator PCB(A)(40-2).

5. Disconnect connector(CN41) on the Video PCB(41) from the lead wire(BN41-6P) on the Volume PCB(37-6).

6. Disconnect the card cable between connector(CN42) on the Video PCB(41) and connector(BN44-11P) on the iPod PCB(39-2).

7. Disconnect the card cable between connector(BN15-15P) on the Video PCB(41) and connector(CN15-15P) on the INPUT PCB(39-1).

8. Remove 6 screws(S8) and then remove the Video PCB(41).

<11>iPod PCB(39-2) REMOVAL

1. Remove the Top-cabinet, referring to the previous step<1>.

2. Remove the Hudson PCB(42), referring to the previous step<9>.

3. Remove the Video PCB(41), referring to the previous step<10>

4. Disconnect the card cable between connector(BN19-15P) on the the iPod PCB(39-2) and connector(CN19) on the Input PCB(39-1).

5. Disconnect the card cable between connector(BN44-11P) on the iPod PCB(39-2) and connector(CN42) on the Video PCB(41).

6. Disconnect the card cable between connector(CN47-7P) on the iPod PCB(39-2) and connector(CN47) on the RS232 PCB(37-7).

7. Disconnect the board to board connector between and connector(CN23) on the XM PCB(39- 4)

and connector(BN17-12P) on the iPod PCB(39-2).

8. Remove 2 screws(S13) and then remove the iPod PCB(39-2).

<12>XM PCB(39-4) REMOVAL

1. Remove the Top-cabinet, referring to the previous step<1>.

2. Remove the Hudson PCB(42), referring to the previous step<9>.

3. Remove the Video PCB(41), referring to the previous step<10>

4. Disconnect the card cable between connector(BN21-7P) on XM PCB(39-4)

and connector(CN21) on the input PCB(39-1).

5. Disconnect the lead wire(BN85-2P) on the XM PCB(39-4) from connector(CN85) on the Regulator PCB(A)(40-2).

6. Disconnect the board to board connector between and connector(CN23) on the XM PCB(39- 4)

and connector(BN17-12P) on the iPod PCB(39-2).

7. Remove 1 screws(S15) and then remove the XM PCB(39-4).

harman/kardon

AVR 347/230 - AVR 350/230 Service Manual

Page 8 of 95

<13>RS232 PCB(37-7) REMOVAL

1. Remove the Top-cabinet, referring to the previous step<1>.

2. Remove the Hudson PCB(42), referring to the previous step<9>.

3. Remove the Video PCB(41), referring to the previous step<10>.

4. Disconnect the card cable between connector(CN47-7P) on the iPod PCB(39-2) and connector(CN47) on the RS232 PCB(37-7).

5.Remove 2 screws and then remove the RS232 PCB(37-7).

<14>INPUT PCB(39-1) REMOVAL

1. Remove the Top-cabinet, referring to the previous step<1>.

2. Remove the Tuner module(44), referring to the previous step<8>.

3. Remove the Hudson PCB(42), referring to the previous step<9>.

4. Remove the Video PCB(41), referring to the previous step<10>.

5. Disconnect connector(CN20) on the the Input PCB(39-1)

from the lead wire(BN20-5P) on the Regulator PCB(B)(40-5).

6. Disconnect connector(CN22) on the Input PCB(39-1) from the lead wire(BN22-6P) on the Phone PCB(37-5).

7. Disconnect connector(CN18) on the Input PCB(39-1) from the lead wire(BN18-5P) on the Phone PCB(37-5)

8. Disconnect connector(CN10) on the Input PCB(39-1) from the lead wire(BN10-4P) on the Volume PCB(37-6).

9. Disconnect the card cable between connector(CN14) on the Input PCB(39-1). and connector(BN14-17P) on the Video PCB(41).

10. Disconnect the card cable between connector(CN19) on the Input PCB(39-1) and connector(BN19-15P) on the I-Pod PCB(39-2).

11. Disconnect the card cable between connector(CN21) on the input PCB(39-1)

and connector(BN21-7P) on XM PCB(43).

12. Disconnect the card cable between connector(CN12-21p) on the Input PCB(39-1)

and connector(CN12-21p)) on the main PCB(38-1)

13. Disconnect the card cable between connector(CN11-17p) on the Input PCB(39-1)

and connector(CN11) on the main PCB(38-1)

14. Disconnect the card cable between connector(CN72) on the Input PCB(39-1)

and connector(CN72-17p) on the Fip PCB(37-1)

15. Disconnect the card cable between connector(CN16-12P) on the Input PCB(39-1)

and connector(BN16) on the A-BUS PCB(39-3)

16. Remove 11 screws(S8,S15) and then remove the Input PCB(39-1).

<15>POWER TRANS(36) & POWER PCB ASS’Y(40) REMOVAL

1. Remove the Top-cabinet, referring to the previous step<1>.

2. Disconnect lead wire of the Power Trans(36) from connector (CN91-3P) on the Main PCB(38-1)

3. Disconnect connector(CN19-3P,CN20-4P) on TRANS PCB(40-3)

from the lead wire(BN19-3P,BN20-4P) on the Main PCB(38-1).

4. Disconnect the lead wire(BN96-8P) on the Power PCB(40-4)

from connector(CN96) on the Regulator PCB(B)(40-5).

5. Disconnect the lead wire(BN99-8P) on the Power PCB(40-4)

from connector(CN99) on the Regulator PCB(A)(40-2).

6. Disconnect connector(CN81) on the Trans PCB(40-4) from the lead wire(BN81-8P) on the Fip PCB(37-1).

7. Remove 4 Trans screws(S9) and then remove the Power Trans(36)& Power PCB ASS’Y(40) REMOVAL .

<16>REMOTE PCB ASS’Y(40-7) REMOVAL

1. Remove the Top-cabinet, referring to the previous step<1>.

2.Disconnect connector(CN88) on the remote PCB(40-7) from the lead wire(BN88-6P) on the Main PCB(38-1)

3. Remove 3screws(S13) and then remove the Remote PCB ASS’Y(40-7).

<17>A-BUS’Y(39-3) REMOVAL

1. Remove the Top-cabinet, referring to the previous step<1>.

2. Disconnect connector(CN90-2P) on the Regulator(C) PCB(39-6)

harman/kardon

AVR 347/230 - AVR 350/230 Service Manual

Page 9 of 95

from the lead wire(BN90) on the A-BUS PCB(39-3).

3. Disconnect the card cable between connector(CN16-12P) on the Input PCB(39-1). and connector(BN16-12P) on the A-BUS PCB(39-3).

4. Remove 3screws(S13) and then remove the A-BUS PCB ASS’Y(39-3).

<18>MAIN PCB ASS’Y(38-1) REMOVAL

1. Remove the Top-cabinet, referring to the previous step<1>.

2. Remove the Tuner module(43), referring to the previous step<8>.

3. Remove the Hudson PCB(42), referring to the previous step<9>.

4. Remove the Video PCB(41), referring to the previous step<10>.

5. Remove the iPod PCB(39-2), referring to the previous step<11>.

6. Remove the XM PCB(39-4), referring to the previous step<12>.

7. Remove the RS232 PCB(37-7), referring to the previous step<13>.

8. Remove the Input PCB(39-1), referring to the previous step<14>.

9. Remove the A-BUS PCB(39-3), referring to the previous step<17>.

10. Remove the AC Cord wire from the connector (CN92-2P) of the Main PCB(38-1)

11. Disconnect the lead wire(BN90-2P) on the Main PCB(38-1) from connector(CN86) on Moms PCB(37-4).

12. Disconnect connector (CN91-3P) on the Main PCB(38-1) from lead wire of the Power Trans(36)

13. Disconnect the lea d wire(BN89-2P) on the Main PCB(38-1)

from connector(CN89) on Regulator PCB(C)(39-6).

14. Disconnect the lea d wire(BN19-3P,BN20-4P) on the Main PCB(38-1)

from connector(CN19-3P,CN20-4P) on TRANS PCB(40-4).

15. Disconnect the lea d wire(BN88-6P) on the Main PCB(38-1) from connector(CN88) on remote PCB(40-7).

16. Disconnect the lea d wire of the DC, FAN(49) from connector(CN89-2P) on the Main PCB(38-1).

17. Disconnect the lea d wire(BN97-3P) on the Main PCB(38-1)

from connector(CN97) on Regulator PCB(C)(39-6).

18. Remove 11screws(S13-1EA, S4-2EA, S6-2EA, S8-6EA) and then remove the Main PCB ASS’Y(38-1).

harman/kardon

AVR 347/230 - AVR 350/230 Service Manual

Page 10 of 95

S10

S17

S12 S13 S14

S11

S10

S7 S8

S2 S3

13CTB3+8JFCSCREW

SCREW SCREW

SCREW

CTB3+10JRR CTB3+8FFZR

CTB3+16GFZR

SCREW,TRANS SCREW

SCREW SCREW

SCREW

CTB4+6FFC

CTB3+6JR

CTB3+10GFZR CHD1A023R

CTB3+10GR

CTW3+12JR

CTB3+8JR

CTW3+8JR

3 8

4 19

6 22

DESCRIPTION PARTS NO. Q,ty

38-1

39-1

S13

S11

S13

S15

40-4

40-3

37-7

40-1

40-7

37-6

37-3

37-4

37-5

37-1

S15

S16

SCREW,SPECIAL CHD3A012R 7

S16

S12

37-9

14-1

S17

SCREW,SPECIAL CHD4A012R 5

SCREW,SPECIAL CHD1A012R 21 SCREW,SPECIAL CHD1A012ZR 2

40-5

S16

40-2

S14

37-8

S15

38-2

BRACKET,PCB CMK2A010

BRACKET,PCB(H/T)

SUPPORT,CUSHION

FRONT PCB ASS'Y

BUSHING,AC CORD

BRACKET,TRANS

36 37

30 31 32 33

TRANS,POWER

PANEL,REAR

BRACKET,PCB

CORD,POWER

23 24 25 26

17 18 19 20

HOLDER,PCB

BRACKET,PCB

HEAT SINK

RUBBER,CUSHION FOOT

PLATE,SHIELD

BRACKET,FIP

HOLDER,LED

CHASSIS,BOTTOM

CABINET,TOP

CMD1A487

CKF6A319Z

COP11910D

CJA2A070Z

KHR1A028

CMD1A387

CMD1A398

CMY1A270

CUA2A229

CKL2A069H43

CKC5B145S46Z

CMD1A209

CHE170

CMD1A417

CHG1A104Z

CHG1A360

CMC1A302

CMH1A215

INDICATOR,VOLUME

BDAGE,HARMAN/KARDON

INDICATOR,POWER

10 11 12 13

KNOB,MOMS

KNOB,POWER

KNOB,DISPLAY

KNOB,FUNCTION

FILTER,FIP

WINDOW ASS'Y

BRACKET,SIDE

PANEL,FRONT

HOLDER,VOLUME

CAP,VOLUME

DESCRIPTION

CGL1A222 CGUAVR347

CGW1A427RDRH43

CBC1A158MBZG27

CBT1A1026MMZG27

CBT1A1028MBZG27

CMD2A443

CBT1A1027K128

KGB1A158Z

CMZ1A088

CGL1A258Z

CGX1A338MBC63

PARTS NO.

CMH1A214

1 1

2 1

Q,ty

37-1 37-2 37-3 37-4 37-5 37-6 37-7 37-8

FIP PCB KEY PCB POWER LED PCB MOMS PCB PHONE PCB VOLUME PCB RS232 PCB GUIDE PCB(CARD CABLE)

MAIN PCB ASS'Y COP11911D 1

38-1

MAIN PCB

1 1

INPUT PCB ASS'Y COP119113D 1

39-1 39-2

INPUT PCB ipod PCB 1

POWER PCB ASS'Y40COP11916D 1

40-1

DIGITAL IN/OUT PCB 1

BADGE,MODEL

BADGE ASS'Y47CGX1A375ZA

CGB1A180Z

ORNAMENT,VOLUME CGU1A318Z 1

CHG1A160ZCUSHION 1

1 2

ORNAMENT,BADGE BADGE,H/K(TOP)

CGX1A375M7G32 KGB1A159Z

1 1

WINDOW,FIP CGU1A399Y

1 2

1 1

CMZ2A090SHEET,VOLUME 1

BRACKET,PCB CMD1A570 1

REMARK

VIDEO PCB ASS'Y41COP11918D 1

TUNER MODULE

RUBBER

CHG1A309

1CMD1A555BRACKET,SIDE(L)

BRACKET , FAN CMD1A600 1

FAN(80*80*25mm)

BEACKET,FAN(A) CMD1A615 1

SHEET,REFLECTION CMZ1A120 1

CLT5W027ZU

38-2

GUIDE PCB(CARD CABLE) 1

39-6

40-2

REGULATOR PCB(A) 7

40-3

TRANS PCB 1

40-4

TRANS PCB 1

CNVM9001MS0J72L

HUDSON PCB ASS'Y COP11915D 1

HEAT SINK CMY2A249 1

CFNCF12825MS

39-6

S15

39-3

A-BUS PCB 1

39-3

RECEPTACLE , AC CJJ8A006ZW 1

37-2

39-4

39-2

39-4

XM PCB 1 REGULATOR PCB(C)

40-5

REGULATOR PCB(B) 1

AVR347 EXPLODED VIEW

harman/kardon

AVR 347/230 - AVR 350/230 Service Manual

Page 11 of 95

harman/kardon

AVR 347/230 - AVR 350/230 Service Manual

Page 12 of 95

harman/kardon

AVR 347/230 - AVR 350/230 Service Manual

Page 13 of 95

S15

S10

S13

S14 S15

S12

S10

S7 S8

S2 S3

13CTB3+8JFZRSCREW

SCREW

CHD4A012ZR CHD1A023R

CHD1A012R

SCREW,TRANS

SCREW

SCREW SCREW

SCREW

CTB3+8JR

CTW3+8JR

CTB3+6FFZR CTW3+12JR

CTB4+6FFZR

CTB3+6JR

CTB3+10JFZR

CTWS3+10GR

5 4

2 6

10 12

DESCRIPTION PARTS NO. Q,ty

38-1

39-1

40-4

40-3

39-2

37-7

40-1

40-7

37-2

S15

S12

37-3

40-5

S13

40-2

S14

37-6

S15

39-5

38-2

PLATE , SHIELD CMC1A323

BRACKET,PCB(H/T)

SUPPORT,CUSHION

FRONT PCB ASS'Y

BRACKET,TRANS

36 37

30 31 32 33

TRANS,POWER

PANEL,REAR

BRACKET,PCB

CORD,POWER

23 24 25 26

17 18 19 20

HOLDER,PCB

BRACKET,PCB

HEAT SINK

FOOT A FOOT B

RUBBER

BRACKET,FIP

CHASSIS,BOTTOM

CABINET,TOP

CMD2A487

CKF6A319W

COP12015Q

CJA2B054Z

CMD1A387

CMD1A398

CMY1A270

CUA3A229

CKL1A095

CKC6B145S60

CMD1A209

CHE170

CMD1A417

CHG1A104Z

CKL1A094

CHG1A309

INDICATOR,VOLUME

BADGE,AVR350

10 11 12 13

PANEL , FRONT

WINDOW , FIP

BADGE, HARMAN/KARDON

FILTER , FIP

HOLDER,VOLUME

CAP,VOLUME

DESCRIPTION

CGL1A222 CGB1A158Y

CMZ1A126

CGW2A440R4ZB24

CGB1A184Y

CGU1A410A25Z

CGX1A338MBC63

PARTS NO.

CMH1A214

1 1

2 1

Q,ty

37-1 37-2 37-3 37-4 37-5 37-6

FIP & KEY PCB

POWER LED PCB

PHONE PCB

VOLUME PCB

GUIDE PCB(CARD CABLE)

MAIN PCB ASS'Y COP11911Q 1

38-1

MAIN PCB

1 1

INPUT PCB ASS'Y COP119113Q 1

39-1 39-2

INPUT PCB ipod PCB 1

POWER PCB ASS'Y40COP11916Q 1

40-1

DIGITAL IN/OUT PCB 1

ORNAMENT,VOLUME CGU1A318Y 1

CHG1A160ZCUSHION 1

1 1

CGX1A390C66ZSHEET,AL FRONT 1

BRACKET,PCB CMD1A570 1

REMARK

VIDEO PCB ASS'Y41COP11918Q 1

TUNER MODULE

1 43 44

FAN(80*80*25mm)

48 49

BEACKET,FAN(A) CMD1A615 1

SHEET,REFLECTION CMZ1A120 1

CLT5W027ZE

38-2

GUIDE PCB(CARD CABLE) 1

39-5

RDS PCB 1

40-2

REGULATOR PCB(A) 7

40-3

TRANS PCB 1

40-4

TRANS PCB 1

40-5

REGULATOR PCB(B) 1

CNVM9014MS171L

HUDSON PCB ASS'Y COP11915Q 1

HEAT SINK CMY2A249 1

CFNCF12825MS

39-6

S15

39-3

A-BUS PCB 1

39-3

RECEPTACLE , AC CJJ8A006ZW 1

39-6

REGULATOR PCB(C)

KNOB , STANDBY CBT2A1056 1 KNOB , TUNING CBT2A1057

INDICATOR , POWER CGL1A265Y 1 BRACKET , SIDE (L) CMD1A555 1 BRACKET , SIDE CMD2A443 1

HOLDER , LED CMH2A215 1

CUSHION , FOOT CHG1A373 4

37-1

37-5

37-4

VIDEO PCB

SCREW CTB3+10JR 29

SCREW

S11

SCREW CT33+8JFZR 4

S16

CHD1A036RSCREW, SPECIAL 4

S13

SCREW CHD3A012R 21

S10

PLATE , EARTH CMC1A325

KNOB , MOMS CBC1A159Z 1

PLATE,EARTH CMC2A326 1

BRACKET, HDMI CMD1A628 1

2PLATE , EARTH CMC2A338

S11

AVR350/230 EXPLODED VIEW

harman/kardon

AVR 347/230 - AVR 350/230 Service Manual

Page 14 of 95

AVR 347/230 and AVR 350/230 Electrical Parts List

Ref. # Part Number

Description

Value

CARTAVR347/230 REMOCON TRANSMITTER ASS'Y ASS'Y CGL1A222 INDICATOR , VOLUME INDICATOR CGUAVR345 WINDOW ASS'Y ASS'Y CGB1A170Z BADGE , AVR BADGE CGU1A399Y WINDOW , FIP FIP WINDOW CGU1A318Z ORNAMENT , VOLUME ORNAMET CGX1A338MBC63 CAP , VOLUME CAP CGX1A375ZA BADGE ASS'Y ASS'Y CGX1A375M7G32 ORNAMENT , BADGE ORNAMET KGB1A159Z BADGE , HARMAN/KARDON(TOP) BADGE CKC5B145S46Z CABINET , TOP TOP CABINET BKC5C145S46 CABINET , TOP TOP CABINET CLZ9Z028Z FERRITE CORE(21.2X6.4X12.7) FERRITE CORE CMH1A214 HOLDER , VOLUME HOLDER CMZ2A090 SHEET,VOLUME SHEET CQB1A549Z LABEL , ATTENTION LABEL CQB1A551Z LABEL , BAR CODE LABEL CQB1A622 LABEL , SERIAL NO LABEL CTB3+8JFC SCREW SCREW CTB4+6FFC SCREW SCREW CHE154 CLAMPER , ARM CLAMPER CJXAVR340MICRO MICROPHONE ASS'Y ASS'Y CPG1A820U BOX , OUT CARTON BOX CPS6A564 PAD , SNOW L SNOW PAD CPS6A565 PAD , SNOW R SNOW PAD CQB1A551Z LABEL , BAR CODE LABEL CQB1A795Z LABEL , COUNTRY LABEL CQB1A797Z LABEL , HDMI LABEL CQS1A001 RIBBON , BAR CODE SONY(TR-4070) CQXAVR345/230 INSTRUCTION MANUAL ASS'Y ASS'Y CARTAVR345/230 REMOCON ASS'Y ASS'Y CGRAVR130/230ZA COVER ASS'Y ASS'Y CGR1A331M7H43 COVER A COVER CGR1A332M7H43 COVER B COVER CPS1A676 PAD , COVER PAD CQE1A220Z SHEET , FRONT COVER SHEET CJA2B054Z CORD , POWER(DETACHABLE/EUR) POWER CORD CPL0905 STAPLE STAPLE CQE1A180Z BOOKLET , IMFORMATIONS BOOKLET CQX1A1137Z MANUAL , INSTRUCTION MANUAL CQX1A1138X MANUAL , SETUP SETOP MANUAL CSA1A018Z FM 1 POLE ANT ANT CSA1A027Z AM LOOP ANT ANT HARTZONE2G REMOCON ASS'Y(ZONE2) ASS'Y HQE1A273Z HARMAN IMAGE BROCHURES BROCHURES

harman/kardon

AVR 347/230 - AVR 350/230 Service Manual

Page 15 of 95

FRONT PANEL ASSY

Ref. # Part Number

Description

Value

CGWAVR347/230 FRONT PANEL ASS'Y ASS'Y CBC1A158MBZG27 KNOB , MOMS KNOB CBT1A1026MMZG27 KNOB , POWER KNOB CBT1A1027K128 KNOB , DISPLAY KNOB CBT1A1028MBYG27 KNOB , FUNCTION KNOB CGL1A258Z INDICATOR , POWER INDICATOR CGW1A427RDMH43 PANEL , FRONT AVR347/230 PANEL CHG1A309 RUBBER RUBBER CHR301 CLAMPER CLAMPER CMC1A302 PLATE , SHIELD PLATE CMD1A555 BRACKET , SIDE (L) BRACKET CMD2A443 BRACKET , SIDE BRACKET CMH1A215 HOLDER , LED HOLDER CMK2A010 BRACKET , PCB BRACKET CMZ1A088 FILTER , FIP FIP FILTER CMZ1A120 SHEET , REFLECTION SHEET CTB3+10GR SCREW SCREW CTB3+16GFZR SCREW SCREW KGB1A158Z BADGE , HARMAN/KARDON(FRONT) BADGE

CB72 CWCAVR350CN72 SHIELD CARD CABLE ASS'Y 17PIN, 230MM, 1MM

Ref. # Part Number

Description

Value

CUAAVR347/230 BOTTOM CHASSIS ASS'Y ASS'Y CHD1A012ZR SCREW , SPECIAL SCREW CHD1A023R SCREW , SPECIAL SCREW CHD4A012R SCREW , SPECIAL SCREW CHE170 HOLDER , PCB HOLDER CHE36-3 CLAMPER , WIRE CLAMPER CHG1A104Z CUSHUON , RUBBER CUSHION CHG1A160Z CUSHION , RUBBER CUSHION CHG1A360 CUSHION , FOOT CUSHION CHS1A032 TAPE , HEMELON TAPE CKF6A319X PANEL , REAR AVR347/230 REAR PANEL CKL2A069H43 FOOT FOOT CMD2A487 BRACKET , TRANS BRACKET CNVM9014MS171L MODULE , TUNER(EUR) MODULE CQB1A173Y LABEL, FUSE CAUTION LABEL CTB3+10GFZR SCREW SCREW CTB3+6FFZR SCREW SCREW CTB3+6JR SCREW SCREW CTB3+8JR SCREW SCREW CTW3+12JR SCREW SCREW

BOTTOM CHASSIS ASS'Y

harman/kardon

AVR 347/230 - AVR 350/230 Service Manual

Page 16 of 95

Ref. # Part Number

Description

Value

CTW3+8JR SCREW SCREW CUA3A229 CHASSIS , BOTTOM CHASSIS

BN92 CWZSR4001BN91A WIRE ASS'Y ASS'Y

CLZ9W003Z FERRITE , RING 29X7.7X19 CB11 CWC1B2A17A100B CABLE , CARD (1MM) 17PIN CARD CABLE CB12 CWC1C4A21B110B CABLE , CARD CARD CABLE CB13 CWC1C4A13B080B CABLE , CARD CARD CABLE CB14 CWC6F2A17A120B CABLE , CARD(17PIN, 120MM) 17PIN, 120MM, 1 MM CB15 CWCAVR347BN15 CARD CABLE COPPER SHIELD 15PIN, COPPER SHI

CB16 CWC1C4A12B100B WAFER, CARD CABLE (1.25mm) CARD CABLE CB19 CWC1B2A09A240B CABLE , CARD CARD CABLE CB42 CWC1B2A07A120B CABLE, CARD (1mm PITCH) CARD CABLE CB47 CWC1B2A07A060B CABLE , CARD CARD CABLE F901 KBA2C6300TLEZ FUSE(233TYPE, 6.3A,250V) LITTEL FUSE RC91 CJJ8A006ZW RECEPTACLE , AC(15A/250V,R-301) R-301(B21) T901 CLT5W027ZE TRANS , POWER MAIN TRANS

FRONT PCB ASSY

Ref. # Part Number

Description

Value

CUP11910X PCB , FRONT PCB , FRONT C402 CCEA1HH100T CAP , ELECT 10UF 50V C403 CCEA1HH100T CAP , ELECT 10UF 50V C714 HCBS1H151KBT CAP , CERAMIC 150UF 50V K C716 CCEA1AH331T CAP , ELECT 330UF 10V C719 HCBS1H102KBT CAP , CERAMIC 1000PF 50V K C720 HCBS1H102KBT CAP , CERAMIC 1000PF 50V K C721 HCBS1H102KBT CAP , CERAMIC 1000PF 50V K C723 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z C728 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z C729 HCBS1H473ZFT CAP , CERAMIC 0.047UF 50V Z C731 CCEA1HH100T CAP , ELECT 10UF 50V C735 CCEA1CKS100T CAP , ELECT 10UF 16V C742 HCBS1H223ZFT CAP , CERAMIC 0.02UF 50V Z C793 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z C794 HCBS1C222MXT CAP , CERAMIC 2200PF 16V C795 HCBS1H102KBT CAP , CERAMIC 1000PF 50V K C796 HCBS1H102KBT CAP , CERAMIC 1000PF 50V K C805 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z C806 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z C807 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z C808 HCBS1H181KBT CAP , CERAMIC 180PF 50V C809 CCEA1AH471T CAP , ELECT 470UF 10V C812 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z C817 HCBS1H100JCT CAP , CERAMIC 10PF 50V

BOTTOM CHASSIS ASS'Y

harman/kardon

AVR 347/230 - AVR 350/230 Service Manual

Page 17 of 95

FRONT PCB ASSY

Ref. # Part Number

Description

Value

C820 CCEA1HH100T CAP , ELECT 10UF 50V C821 CCEA1EH470T CAP , ELECT 47UF 25V C822 CCEA1EH470T CAP , ELECT 47UF 25V C823 CCEA1HH100T CAP , ELECT 10UF 50V C824 HCBS1H471KBT CAP , CERAMIC 470PF 50V C825 HCBS1H151KBT CAP , CERAMIC 150PF 50V C828 HCBS1H470JT CAP , CERAMIC 47PF 50V C830 HCBS1H473ZFT CAP , CERAMIC 0.047F 50V C841 CCEA1HH100T CAP , ELECT 10UF 50V C842 CCEA1HH100T CAP , ELECT 10UF 50V C843 CCEA1HH100T CAP , ELECT 10UF 50V C850 HCBS1H471KBT CAP , CERAMIC 470PF 50V C851 HCBS1H471KBT CAP , CERAMIC 470PF 50V C852 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z C855 HCBS1H101KBT CAP , CERAMIC 100PF 50V K C856 HCBS1H101KBT CAP , CERAMIC 100PF 50V K C857 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z C862 HCBS1H101KBT CAP , CERAMIC 100PF 50V K C863 HCBS1H101KBT CAP , CERAMIC 100PF 50V K C866 CCEA1HKS100T CAP , ELECT 10UF 50V C867 CCEA1HKS100T CAP , ELECT 10UF 50V C868 CCEA1EKS470T CAP , ELECT 47UF 25V C869 CCEA1EKS470T CAP , ELECT 47UF 25V C870 HCBS1H681KBT CAP , CERAMIC 680PF 50V K C871 HCBS1H681KBT CAP , CERAMIC 680PF 50V K C872 CCEA1CH331T CAP , ELECT 330UF 16V C873 CCEA1CH331T CAP , ELECT 330UF 16V

C874 HCBS1H101KBT CAP , CERAMIC 100PF 50V K C882 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z C889 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z C891 HCBS1H223ZFT CAP , CERAMIC 0.023UF 50V Z C892 HCBS1H223ZFT CAP , CERAMIC 0.023UF 50V Z C893 HCBS1H223ZFT CAP , CERAMIC 0.023UF 50V Z C894 CCEA1CKS100T CAP , ELECT 10UF 16V C896 HCBS1H223ZFT CAP , CERAMIC 0.023UF 50V Z C897 CCEA1AH471T CAP , ELECT 470UF 10V C901 HCBS1H390JT CAP , CERAMIC 39PF 50V Z C903 CCEA1HKS2R2T CAP , ELECT 2.2UF 50V C905 CCEA1HKS2R2T CAP , ELECT 2.2UF 50V C953 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z C954 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z C957 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z D455 CVD1SS133MT DIODE 1SS133 D730 CVD1SS133MT DIODE 1SS133

harman/kardon

AVR 347/230 - AVR 350/230 Service Manual

Page 18 of 95

FRONT PCB ASSY

Ref. # Part Number

Description

Value

D774 CVD1SS133MT DIODE 1SS133 D778 HVD1N5819T DIODE , SCHOTTKY 1N5819 D784 CVD1SS133MT DIODE 1SS133 D785 CVD1SS133MT DIODE 1SS133 J906 CRD20TJ391T RES , CARBON 390OHM 1/5W L702 HLQ02C100KT COIL , AXAIL 10uH Q401 HVTKRC104MT T.R KRC104M Q451 HVTKRC107MT T.R KRC107M Q452 HVTKRA107MT T.R KRA107M Q454 HVTKRC107MT T.R KRC107M Q701 HVTKRC107MT T.R KRC107M Q722 HVTKRA107MT T.R KRA107M Q724 HVTKRC107MT T.R KRC107M Q725 HVTKRC107MT T.R KRC107M Q734 HVTKTC2874BT T.R , MUTE KTC2874B Q735 HVTKTC2874BT T.R , MUTE KTC2874B Q736 HVTKTC2874BT T.R , MUTE KTC2874B Q737 HVTKTC2874BT T.R , MUTE KTC2874B Q738 HVTKRC107MT T.R KRC107M Q739 HVTKTA1271YT T.R KTA1271Y R402 CRD20TJ101T RES , CARBON 100 OHM 1/5W J R403 CRD20TJ104T RES , CARBON 100K OHM 1/5W J R404 CRD20TJ101T RES , CARBON 100 OHM 1/5W J R452 CRD20TJ103T RES , CARBON 10K OHM 1/5W J R453 CRD20TJ362T RES , CARBON 3.6K OHM 1/5W J R454 CRD20TJ102T RES , CARBON 1K OHM 1/5W J R701 CRD20TJ103T RES , CARBON 10K OHM 1/5W J R704 CRD20TJ100T RES , CARBON 10 OHM 1/5W J R705 CRD20TJ820T RES , CARBON 82 OHM 1/5W J R706 CRD20TJ820T RES , CARBON 82 OHM 1/5W J R708 CRD20TJ820T RES , CARBON 82 OHM 1/5W J R709 CRD20TJ470T RES , CARBON 47 OHM 1/5W J R710 CRD20TJ470T RES , CARBON 47 OHM 1/5W J R711 CRD20TJ470T RES , CARBON 47 OHM 1/5W J R718 CRD20TJ222T RES , CARBON 2.2K OHM 1/5W J R737 CRD20TJ100T RES , CARBON 10 OHM 1/5W J R747 CRD20TJ103T RES , CARBON 10K OHM 1/5W J R753 CRD20TF1001T RES , CARBON 1K /1/5W /F R754 CRD20TF1501T RES , CARBON 1.5K /1/5W /F R755 CRD20TF1801T RES , CARBON 1.8K /1/5W /F R756 CRD20TF2701T RES , CARBON 2.7K /1/5W/F R757 CRD20TF3301T RES , CARBON 3.3K /1/5W/F R758 CRD20TF5601T RES , CARBON 5.6K 1/5W F R759 CRD20TF1001T RES , CARBON 1K /1/5W /F

harman/kardon

AVR 347/230 - AVR 350/230 Service Manual

Page 19 of 95

FRONT PCB ASSY

Ref. # Part Number

Description

Value

R760 CRD20TF1501T RES , CARBON 1.5K /1/5W /F R761 CRD20TF1801T RES , CARBON 1.8K /1/5W /F R762 CRD20TF2701T RES , CARBON 2.7K /1/5W/F R763 CRD20TF3301T RES , CARBON 3.3K /1/5W/F R764 CRD20TF5601T RES , CARBON 5.6K/1/5W/F R765 CRD20TF7501T RES , CARBON 7.5K/1/5W/F R766 CRD20TF1001T RES , CARBON 1K /1/5W /F R767 CRD20TF1501T RES , CARBON 1.5K /1/5W /F R768 CRD20TF1801T RES , CARBON 1.8K /1/5W /F R769 CRD20TF2701T RES , CARBON 2.7K /1/5W/F R781 CRD20TJ102T RES , CARBON 1K OHM 1/5W J R782 CRD20TJ103T RES , CARBON 10K OHM 1/5W J R783 CRD20TJ102T RES , CARBON 1K OHM 1/5W J R784 CRD20TJ102T RES , CARBON 1K OHM 1/5W J R786 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J R787 CRD20TJ101T RES , CARBON 100 OHM 1/5W J R791 CRD20TJ822T RES , CARBON 8.2K OHM 1/5W J R805 CRD20TJ104T RES , CARBON 100K OHM 1/5W J R806 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J R824 CRD20TJ221T RES , CARBON 220 OHM 1/5W J R825 CRD20TJ681T RES , CARBON 680 OHM 1/5W J R828 CRD20TJ221T RES , CARBON 220 OHM 1/5W J R829 CRD20TJ681T RES , CARBON 680 OHM 1/5W J R864 CRD20TJ272T RES , CARBON 2.7K OHM 1/5W J R865 CRD20TJ101T RES , CARBON 100 OHM 1/5W J R866 CRD20TJ272T RES , CARBON 2.7K OHM 1/5W J R869 CRD20TJ750T RES , CARBON 75 OHM 1/5W J R871 CRD20TJ104T RES , CARBON 100K OHM 1/5W J R872 CRD20TJ104T RES , CARBON 100K OHM 1/5W J R873 CRD20TJ471T RES , CARBON 470 OHM 1/5W J R874 CRD20TJ471T RES , CARBON 470 OHM 1/5W J R875 CRD20TJ103T RES , CARBON 10K OHM 1/5W J R876 CRD20TJ750T RES , CARBON 75 OHM 1/5W J R877 CRD20TJ750T RES , CARBON 75 OHM 1/5W J R878 CRD20TJ750T RES , CARBON 75 OHM 1/5W J R892 CRD20TJ222T RES , CARBON 2.2K OHM 1/5W J R893 CRD20TJ333T RES , CARBON 33K OHM 1/5W J R895 CRD20TJ101T RES , CARBON 100 OHM 1/5W J R896 CRD20TJ101T RES , CARBON 100 OHM 1/5W J R897 CRD20TJ101T RES , CARBON 100 OHM 1/5W J R898 CRD20TJ101T RES , CARBON 100 OHM 1/5W J R899 CRD20TJ104T RES , CARBON 100K OHM 1/5W J R900 CRD20TJ104T RES , CARBON 100K OHM 1/5W J R901 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J

harman/kardon

AVR 347/230 - AVR 350/230 Service Manual

Page 20 of 95

FRONT PCB ASSY

Ref. # Part Number

Description

Value

R902 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J R903 CRD20TJ102T RES , CARBON 1K OHM 1/5W J R904 CRD20TJ102T RES , CARBON 1K OHM 1/5W J R905 CRD20TJ104T RES , CARBON 100K OHM 1/5W J R906 CRD20TJ104T RES , CARBON 100K OHM 1/5W J R907 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J R908 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J R909 CRD20TJ221T RES , CARBON 220 OHM 1/5W J R910 CRD20TJ221T RES , CARBON 220 OHM 1/5W J R911 CRD20TJ221T RES , CARBON 220 OHM 1/5W J R912 CRD20TJ221T RES , CARBON 220 OHM 1/5W J R913 CRD20TJ102T RES , CARBON 1K OHM 1/5W J R915 CRD20TJ473T RES , CARBON 47K OHM 1/5W J R918 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J R919 CRD20TJ472T RES , CARBON 4.7K OHM 1/5W J R920 CRD20TJ102T RES , CARBON 1K OHM 1/5W J R921 CRD20TJ103T RES , CARBON 10K OHM 1/5W J R922 CRD20TJ102T RES , CARBON 1K OHM 1/5W J R923 CRD20TJ101T RES , CARBON 100 OHM 1/5W J R924 CRD20TJ101T RES , CARBON 100 OHM 1/5W J R926 CRD20TJ103T RES , CARBON 10K OHM 1/5W J R931 CRD20TJ104T RES , CARBON 100K OHM 1/5W J R934 CRD20TJ222T RES , CARBON 2.2K OHM 1/5W J R935 CRD20TJ103T RES , CARBON 10K OHM 1/5W J R936 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J R937 CRD20TJ104T RES , CARBON 100K OHM 1/5W J R956 CRD20TJ1R0T RES , CARBON 1 OHM 1/5W J S701 HST1A020ZT SW , TACT 1A020 S702 HST1A020ZT SW , TACT 1A020 S703 HST1A020ZT SW , TACT 1A020 S704 HST1A020ZT SW , TACT 1A020 S705 HST1A020ZT SW , TACT 1A020 S706 HST1A020ZT SW , TACT 1A020 S707 HST1A020ZT SW , TACT 1A020 S708 HST1A020ZT SW , TACT 1A020 S709 HST1A020ZT SW , TACT 1A020 S710 HST1A020ZT SW , TACT 1A020 S711 HST1A020ZT SW , TACT 1A020 S712 HST1A020ZT SW , TACT 1A020 S713 HST1A020ZT SW , TACT 1A020 S714 HST1A020ZT SW , TACT 1A020 S715 HST1A020ZT SW , TACT 1A020 S716 HST1A020ZT SW , TACT 1A020 S717 HST1A020ZT SW , TACT 1A020

harman/kardon

AVR 347/230 - AVR 350/230 Service Manual

Page 21 of 95

FRONT PCB ASSY

Ref. # Part Number

Description

Value

S718 HST1A020ZT SW , TACT 1A020 S719 HST1A020ZT SW , TACT 1A020 S720 HST1A020ZT SW , TACT 1A020 BK71 CMD1A209 BRACKET , FLT A4-92-1739 BK72 CMD1A209 BRACKET , FLT A4-92-1739 BK73 CMD1A209 BRACKET , FLT A4-92-1739 BN10 CWZAVR230BN10 WIRE ASS'Y (SHIELD) WIRE BN18 CWZAVR125BN18 WIRE ASS'Y (SHIELD) WIRE BN22 CWZAVR145BN22 WIRE ASS'Y (SHIELD) WIRE BN41 CWZAVR130BN41 WIRE ASS'Y (SHIELD) WIRE BN80 CWB2B903180EN WIRE ASS'Y WIRE BN81 CWB2B908250BM WIRE ASS'Y WIRE BN84 CWB2B905080EN WIRE ASS'Y WIRE BN85 CWB2B903100EW WIRE ASS'Y WIRE BN88 CWB2B904100EN WIRE ASS'Y WIRE BN89 CWB2B904100EN WIRE ASS'Y WIRE BN92 CWB2B905100EN WIRE ASS'Y WIRE CN47 CJP07GA117ZY WAFER WAFER CN72 CJP17GA193ZY WAFER, CARD CABLE (SMD) WAFER CN84 CJP05GB46ZY WAFER WAFER CN85 CJP03GA19ZY WAFER , STRAIGHT, 3PIN WAFER CN86 CJP02GA89ZM WAFER WAFER CN88 CJP04GB46ZY WAFER WAFER CN89 CJP04GB46ZY WAFER WAFER CN92 CJP05GA19ZY WAFER, STRAIGHT, 5PIN WAFER D701 CVD52CSBBCEAB2 L.E.D , BLUE L.E.D D703 CVD52CSBBCEAB2 L.E.D , BLUE L.E.D D705 CVD52CSBBCEAB2 L.E.D , BLUE L.E.D D723 CVD50BOBBWGA L.E.D , 2 COLOR (ORG , BLU) TOL-50BOBBWGA D727 CVD50BOBBWGA L.E.D , 2 COLOR (ORG , BLU) TOL-50BOBBWGA ET03 CMD1A569 BRACKET , PCB BRACKET FIP1 HFLHCA18ML03 F.I.P SAMSUNG IC41 CVINJU7301M I.C , C-MOS SPST ANALOG SWITCH SWITCH IC73 HRVNJL34H380A SENSOR , REMOCON REMOCON

IC75 HVI74ACT04MTR I.C , HEX HEX IC76 HVI74HCU04AFNG I.C , INVERTER INVERTER IC86 HVINJM4556AL I.C , HEADPHONE HEADPHONE IC87 HVINJM2068MDTE1 I.C , OP AMP OP AMP IC97 HVIST202EBW IC , RS232C TRANSCEIVER TRANSCEIVER JK81 CJJ4M043Y JACK , BOARD ORANGE,SILVER,F JK82 HJSTORX177L MODULE , OPTICAL(RX) TORX177L JK83 CJJ2E026Z JACK , HEADPHONE(SILVER PLATE) JACK JK85 CJJ9M003Z JACK , S-VIDEO JACK JK86 CJJ4S023Y JACK , BOARD JACK

harman/kardon

AVR 347/230 - AVR 350/230 Service Manual

Page 22 of 95

FRONT PCB ASSY

Ref. # Part Number

Description

Value

JK97 CJJ9W001Z 9P D-SUB FEMALE(RS-232C) SEMC

JACK JW82 CWE8202300RV WIRE ASS'Y WIRE JW83 CWE8202150RV WIRE ASS'Y WIRE JW84 CWE8202110RV WIRE ASS'Y WIRE RL45 CSL4A014ZE RELAY (+12V) AXICOM SW1 CSH1A008ZV SW , PUSH (MOMS) MOMS SW SW95 KST1A010Z SW , TACT 1A010 SW96 HSH2B018Z SW , PUSH SPUJ19XSM011 SW97 HSH2B018Z SW , PUSH SPUJ19XSM011 VR74 CSR2A037Z ENCODER ENCODER

MAIN PCB ASSY

Ref. # Part Number

Description

Value

CFNCF12825MS MOTOR, FAN(80*80*25MM) FAN CHD1A036R SCREW , SPECIAL SCREW CHD3A012R SCREW , SPECIAL SCREW CHS1A032 TAPE , HEMELON TAPE

CMD1A615 BRACKET , FAN BRACKET CTW3+8JR SCREW SCREW

CIP11911G MAIN PCB AUTO ASS'Y ASS'Y

CUP11911X PCB , MAIN(330X247, FR-1) PCB C501 CCEA1HH100T CAP , ELECT 10UF 50V C502 CCEA1HH100T CAP , ELECT 10UF 50V C503 CCEA1HH100T CAP , ELECT 10UF 50V C504 CCEA1HH100T CAP , ELECT 10UF 50V C505 CCEA1HH100T CAP , ELECT 10UF 50V C506 CCKT1H331KB CAP , CERAMIC 330PF 50V C507 HCBS1H331KBT CAP , CERAMIC 330PF 50V C508 HCBS1H331KBT CAP , CERAMIC 330PF 50V C509 CCKT1H331KB CAP , CERAMIC 330PF 50V C510 HCBS1H331KBT CAP , CERAMIC 330PF 50V C561 CCEA1CH101T CAP , ELECT 100UF 16V C562 CCEA1CH101T CAP , ELECT 100UF 16V C563 CCEA1CH101T CAP , ELECT 100UF 16V C564 CCEA1CH101T CAP , ELECT 100UF 16V C565 CCEA1CH101T CAP , ELECT 100UF 16V C566 CCEA1CH101T CAP , ELECT 100UF 16V C567 CCEA1CH101T CAP , ELECT 100UF 16V C568 CCEA1CH101T CAP , ELECT 100UF 16V C569 CCEA1CH101T CAP , ELECT 100UF 16V C570 CCEA1CH101T CAP , ELECT 100UF 16V C571 HCBS1H681KBT CAP , CERAMIC 680PF 50V C572 HCBS1H681KBT CAP , CERAMIC 680PF 50V C573 HCBS1H681KBT CAP , CERAMIC 680PF 50V

harman/kardon

AVR 347/230 - AVR 350/230 Service Manual

Page 23 of 95

MAIN PCB ASSY

Ref. # Part Number

Description

Value

C574 HCBS1H681KBT CAP , CERAMIC 680PF 50V C575 HCBS1H681KBT CAP , CERAMIC 680PF 50V C601 CCCT1H120JC CAP , CERAMIC 12PF 50V C602 CCCT1H120JC CAP , CERAMIC 12PF 50V C603 CCCT1H120JC CAP , CERAMIC 12PF 50V C604 CCCT1H120JC CAP , CERAMIC 12PF 50V C605 CCCT1H120JC CAP , CERAMIC 12PF 50V C606 CCCT1H330JC CAP , CERAMIC 33PF 50V C607 CCCT1H330JC CAP , CERAMIC 33PF 50V C608 CCCT1H330JC CAP , CERAMIC 33PF 50V C609 CCCT1H330JC CAP , CERAMIC 33PF 50V C610 CCCT1H330JC CAP , CERAMIC 33PF 50V C681 CCEA1HH100T CAP , ELECT 10UF 50V C682 CCEA1HH100T CAP , ELECT 10UF 50V C683 CCEA1HH100T CAP , ELECT 10UF 50V C684 CCEA1HH100T CAP , ELECT 10UF 50V C685 CCEA1HH100T CAP , ELECT 10UF 50V C721 CCKT1H221KB CAP , CERAMIC 220PF 50V C722 CCKT1H221KB CAP , CERAMIC 220PF 50V C723 CCKT1H221KB CAP , CERAMIC 220PF 50V C724 CCKT1H221KB CAP , CERAMIC 220PF 50V C725 CCKT1H221KB CAP , CERAMIC 220PF 50V C726 CCKT1H221KB CAP , CERAMIC 220PF 50V C727 CCKT1H221KB CAP , CERAMIC 220PF 50V C728 CCKT1H221KB CAP , CERAMIC 220PF 50V C801 CCEA1HH100T CAP , ELECT 10UF 50V C802 CCEA1HH100T CAP , ELECT 10UF 50V C803 CCCT1H330JC CAP , CERAMIC 33PF 50V C804 CCCT1H330JC CAP , CERAMIC 33PF 50V C805 CCCT1H120JC CAP , CERAMIC 12PF 50V C806 CCCT1H120JC CAP , CERAMIC 12PF 50V C811 CCEA1CH101T CAP , ELECT 100UF 16V C812 CCEA1CH101T CAP , ELECT 100UF 16V C813 CCEA1CH101T CAP , ELECT 100UF 16V C814 CCEA1CH101T CAP , ELECT 100UF 16V C815 CCKT1H331KB CAP , CERAMIC 330PF 50V C816 HCBS1H331KBT CAP , CERAMIC 330PF 50V C817 CCEA1HH100T CAP , ELECT 10UF 50V C818 CCEA1HH100T CAP , ELECT 10UF 50V C819 HCBS1H681KBT CAP , CERAMIC 680PF 50V C820 HCBS1H681KBT CAP , CERAMIC 680PF 50V C900 HCQI1H473JZT CAP , MYLAR 0.047UF 50V C901 HCQI1H473JZT CAP , MYLAR 0.047UF 50V C905 CCFT1H223ZF CAP , CERAMIC 0.022UF 50V

harman/kardon

AVR 347/230 - AVR 350/230 Service Manual

Page 24 of 95

MAIN PCB ASSY

Ref. # Part Number

Description

Value

C907 CCEA1CH101T CAP , ELECT 100UF 16V C908 CCFT1H223ZF CAP , CERAMIC 0.022UF 50V C910 HCQI1H473JZT CAP , MYLAR 0.047UF 50V C912 CCEA1CH221T CAP , ELECT 220UF 16V C913 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V ZF C914 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J C917 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J C918 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J C919 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J C924 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V ZF C925 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V ZF C932 CCEA1CH101T CAP , ELECT 100UF 16V C933 CCEA1CH221T CAP , ELECT 220UF 16V C934 CCFT1H223ZF CAP , CERAMIC 0.022UP 50V C939 CCEA1HH4R7T CAP , ELECT 4.7UF 50V C940 CCEA1AH471T CAP , ELECT 470UF 10V C948 CCFT1H104ZF CAP , SEMICONDUCTOR 0.1UF 50V ZF C949 CCEA1HH220T CAP , ELECT 22UF 50V C950 CCEA1AH471T CAP , ELECT 470UF 10V C971 HCQI1H562JZT CAP , MYLAR 5600PF 50V C972 HCQI1H562JZT CAP , MYLAR 5600PF 50V C973 HCQI1H562JZT CAP , MYLAR 5600PF 50V C974 HCQI1H562JZT CAP , MYLAR 5600PF 50V C975 HCQI1H562JZT CAP , MYLAR 5600PF 50V C980 HCQI1H562JZT CAP , MYLAR 5600PF 50V C981 HCQI1H562JZT CAP , MYLAR 5600PF 50V C990 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J C991 CCEA1HH1R0T CAP , ELECT 1UF 50V C992 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J C993 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J C994 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J C995 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J C996 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J C997 HCQI1H473JZT CAP , MYLAR 0.047UF 50V J C999 CCFT1H223ZF CAP , CERAMIC 0.022UP 50V D501 CVD1SS133MT DIODE 1SS133 D502 CVD1SS133MT DIODE 1SS133 D503 CVD1SS133MT DIODE 1SS133 D504 CVD1SS133MT DIODE 1SS133 D505 CVD1SS133MT DIODE 1SS133 D581 CVD1SS133MT DIODE 1SS133 D582 CVD1SS133MT DIODE 1SS133 D583 CVD1SS133MT DIODE 1SS133 D584 CVD1SS133MT DIODE 1SS133

harman/kardon

AVR 347/230 - AVR 350/230 Service Manual

Page 25 of 95

MAIN PCB ASSY

Ref. # Part Number

Description

Value

D585 CVD1SS133MT DIODE 1SS133 D801 CVD1SS133MT DIODE 1SS133 D802 CVD1SS133MT DIODE 1SS133 D803 CVD1SS133MT DIODE 1SS133 D804 CVD1SS133MT DIODE 1SS133 D901 CVD1N4003SRT DIODE , RECT 1N4003 D902 CVD1SS133MT DIODE 1SS133 D911 CVD1SS133MT DIODE 1SS133 D912 CVD1SS133MT DIODE 1SS133 D914 CVD1SS133MT DIODE 1SS133 D917 CVD1SS133MT DIODE 1SS133 D953 CVD1SS133MT DIODE 1SS133 D954 CVD1N4003SRT DIODE , RECT 1N4003 D955 CVD1N4003SRT DIODE , RECT 1N4003 D956 CVD1N4003SRT DIODE , RECT 1N4003 D957 CVD1N4003SRT DIODE , RECT 1N4003 D961 CVD1N4003ST DIODE , RECT 1N4003 D962 CVD1N4003SRT DIODE , RECT 1N4003 D963 CVD1N4003ST DIODE , RECT 1N4003 D964 CVD1SS133MT DIODE 1SS133 D967 CVD1SS133MT DIODE 1SS133 D968 CVD1SS133MT DIODE 1SS133 D969 CVD1SS133MT DIODE 1SS133 D971 CVD1SS133MT DIODE 1SS133 D972 CVD1SS133MT DIODE 1SS133 D973 CVD1SS133MT DIODE 1SS133 D974 CVD1SS133MT DIODE 1SS133 D979 HVDMTZJ6.2BT DIODE , ZENER MTZJ6.2B D980 CVD1SS133MT DIODE 1SS133 ET90 HJT1A025 PALTE , EARTH MET37-0002 ET91 HJT1A025 PALTE , EARTH MET37-0002 F901 KJCFC5S HOLDER , FUSE HOLDER F902 KBA2D2500TLET FUSE(SR-5,2.5A,250V) SAVE FUSETECH Q501 HVTKTA1268GRT T.R KTA1268GR Q502 HVTKTA1268GRT T.R KTA1268GR Q503 HVTKTA1268GRT T.R KTA1268GR Q504 HVTKTA1268GRT T.R KTA1268GR Q505 HVTKTA1268GRT T.R KTA1268GR Q511 HVTKTC3200GRT T.R KTC3200GR Q512 HVTKTC3200GRT T.R KTC3200GR Q513 HVTKTC3200GRT T.R KTC3200GR Q514 HVTKTC3200GRT T.R KTC3200GR Q515 HVTKTC3200GRT T.R KTC3200GR Q516 HVTKTC3200GRT T.R KTC3200GR

harman/kardon

AVR 347/230 - AVR 350/230 Service Manual

Page 26 of 95

MAIN PCB ASSY

Ref. # Part Number

Description

Value

Q517 HVTKTC3200GRT T.R KTC3200GR Q518 HVTKTC3200GRT T.R KTC3200GR Q519 HVTKTC3200GRT T.R KTC3200GR Q520 HVTKTC3200GRT T.R KTC3200GR Q541 HVTKTC3198YT T.R KTC3198Y Q542 HVTKTC3198YT T.R KTC3198Y Q543 HVTKTC3198YT T.R KTC3198Y Q544 HVTKTC3198YT T.R KTC3198Y Q545 HVTKTC3198YT T.R KTC3198Y Q556 HVTKTC3200GRT T.R KTC3200GR Q557 HVTKTC3200GRT T.R KTC3200GR Q558 HVTKTC3200GRT T.R KTC3200GR Q559 HVTKTC3200GRT T.R KTC3200GR Q560 HVTKTC3200GRT T.R KTC3200GR Q561 HVTKTC3200GRT T.R KTC3200GR Q562 HVTKTC3200GRT T.R KTC3200GR Q563 HVTKTC3200GRT T.R KTC3200GR Q564 HVTKTC3200GRT T.R KTC3200GR Q565 HVTKTC3200GRT T.R KTC3200GR Q601 HVTKTA1268GRT T.R KTA1268GR Q602 HVTKTA1268GRT T.R KTA1268GR Q603 HVTKTA1268GRT T.R KTA1268GR Q604 HVTKTA1268GRT T.R KTA1268GR Q605 HVTKTA1268GRT T.R KTA1268GR Q681 HVTKSC2785YT T.R KSC2785Y Q682 HVTKSC2785YT T.R KSC2785Y Q683 HVTKSC2785YT T.R KSC2785Y Q684 HVTKSC2785YT T.R KSC2785Y Q685 HVTKSC2785YT T.R KSC2785Y Q801 HVTKSC2785YT T.R KSC2785Y Q802 HVTKSC2785YT T.R KSC2785Y Q812 HVTKTA1268GRT T.R KTA1268GR Q813 HVTKTC3200GRT T.R KTC3200GR Q814 HVTKTA1268GRT T.R KTA1268GR Q815 HVTKTC3200GRT T.R KTC3200GR Q816 HVTKTA1268GRT T.R KTA1268GR Q817 HVTKTA1268GRT T.R KTA1268GR Q818 HVTKTC3200GRT T.R KTC3200GR Q819 HVTKTC3200GRT T.R KTC3200GR Q820 HVTKTC3200GRT T.R KTC3200GR Q821 HVTKTC3200GRT T.R KTC3200GR Q822 HVTKTC3200GRT T.R KTC3200GR Q823 HVTKTC3200GRT T.R KTC3200GR Q824 HVTKTC3198YT T.R KTC3198Y

harman/kardon

AVR 347/230 - AVR 350/230 Service Manual

Page 27 of 95

MAIN PCB ASSY

Ref. # Part Number

Description

Value

Q825 HVTKTC3198YT T.R KTC3198Y Q901 HVTKSC2785YT T.R KSC2785Y Q911 HVTKTA1271YT T.R KTA1271Y Q912 HVTKTA1271YT T.R KTA1271Y Q913 HVTKTA1271YT T.R KTA1271Y Q914 HVTKTA1271YT T.R KTA1271Y Q915 HVTKSC2785YT T.R KSC2785Y Q916 HVTKSC2785YT T.R KSC2785Y Q917 HVTKSC2785YT T.R KSC2785Y Q918 HVTKSC2785YT T.R KSC2785Y Q938 HVTKRA107MT T.R KRA107M Q939 HVTKRA107MT T.R KRA107M Q942 HVTKSC2785YT T.R KSC2785Y Q943 HVTKSC2785YT T.R KSC2785Y Q951 HVTKRC107MT T.R KRC107M Q952 HVTKRA107MT T.R KRA107M Q960 HVTKRC107MT T.R KRC107M Q961 HVTKTA1024YT T.R KTA1024YT Q991 HVTKRC107MT T.R KRC107M Q992 HVTKRA107MT T.R KRA107M Q993 HVTKRA107MT T.R KRA107M Q994 HVTKRC107MT T.R KRC107M Q997 HVTKRA107MT T.R KRA107M Q998 HVTKRC107MT T.R KRC107M R501 CRD20TJ433T RES , CARBON 43K OHM 1/5W J R502 CRD20TJ433T RES , CARBON 43K OHM 1/5W J R503 CRD20TJ433T RES , CARBON 43K OHM 1/5W J R504 CRD20TJ433T RES , CARBON 43K OHM 1/5W J R505 CRD20TJ433T RES , CARBON 43K OHM 1/5W J R506 CRD20TJ333T RES , CARBON 33K OHM 1/5W J R507 CRD20TJ333T RES , CARBON 33K OHM 1/5W J R508 CRD20TJ333T RES , CARBON 33K OHM 1/5W J R509 CRD20TJ333T RES , CARBON 33K OHM 1/5W J R510 CRD20TJ333T RES , CARBON 33K OHM 1/5W J R511 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J R512 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J R513 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J R514 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J R515 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J R516 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J R517 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J R518 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J R519 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J R520 CRD20TJ152T RES , CARBON 1.5K OHM 1/5W J

harman/kardon

AVR 347/230 - AVR 350/230 Service Manual

Page 28 of 95

MAIN PCB ASSY

Ref. # Part Number

Description

Value

R521 CRD20TJ471T RES , CARBON 470 OHM 1/5W J R522 CRD20TJ471T RES , CARBON 470 OHM 1/5W J R523 CRD20TJ471T RES , CARBON 470 OHM 1/5W J R524 CRD20TJ471T RES , CARBON 470 OHM 1/5W J R525 CRD20TJ471T RES , CARBON 470 OHM 1/5W J R531 CRD20TJ221T RES , CARBON 220 OHM 1/5W J R532 CRD20TJ221T RES , CARBON 220 OHM 1/5W J R533 CRD20TJ221T RES , CARBON 220 OHM 1/5W J R534 CRD20TJ221T RES , CARBON 220 OHM 1/5W J R535 CRD20TJ221T RES , CARBON 220 OHM 1/5W J R536 CRD20TJ221T RES , CARBON 220 OHM 1/5W J R537 CRD20TJ221T RES , CARBON 220 OHM 1/5W J R538 CRD20TJ221T RES , CARBON 220 OHM 1/5W J R539 CRD20TJ221T RES , CARBON 220 OHM 1/5W J R540 CRD20TJ221T RES , CARBON 220 OHM 1/5W J R541 CRD20TJ271T RES , CARBON 270 OHM 1/5W J R542 CRD20TJ271T RES , CARBON 270 OHM 1/5W J R543 CRD20TJ271T RES , CARBON 270 OHM 1/5W J R544 CRD20TJ271T RES , CARBON 270 OHM 1/5W J R545 CRD20TJ271T RES , CARBON 270 OHM 1/5W J R556 CRD20TJ273T RES , CARBON 27K OHM 1/5W J R557 CRD20TJ273T RES , CARBON 27K OHM 1/5W J R558 CRD20TJ273T RES , CARBON 27K OHM 1/5W J R559 CRD20TJ273T RES , CARBON 27K OHM 1/5W J R560 CRD20TJ273T RES , CARBON 27K OHM 1/5W J R561 CRD20TJ162T RES , CARBON 1.6K OHM 1/5W J R562 CRD20TJ162T RES , CARBON 1.6K OHM 1/5W J R563 CRD20TJ162T RES , CARBON 1.6K OHM 1/5W J R564 CRD20TJ162T RES , CARBON 1.6K OHM 1/5W J R565 CRD20TJ162T RES , CARBON 1.6K OHM 1/5W J R566 CRD20TJ561T RES , CARBON 560 OHM 1/5W J R567 CRD20TJ561T RES , CARBON 560 OHM 1/5W J R568 CRD20TJ561T RES , CARBON 560 OHM 1/5W J R569 CRD20TJ561T RES , CARBON 560 OHM 1/5W J R570 CRD20TJ561T RES , CARBON 560 OHM 1/5W J R571 CRD20TJ561T RES , CARBON 560 OHM 1/5W J R572 CRD20TJ561T RES , CARBON 560 OHM 1/5W J R573 CRD20TJ561T RES , CARBON 560 OHM 1/5W J R574 CRD20TJ561T RES , CARBON 560 OHM 1/5W J R575 CRD20TJ561T RES , CARBON 560 OHM 1/5W J R576 CRD20TJ100T RES , CARBON 10 OHM 1/5W J R577 CRD20TJ100T RES , CARBON 10 OHM 1/5W J R578 CRD20TJ100T RES , CARBON 10 OHM 1/5W J R579 CRD20TJ100T RES , CARBON 10 OHM 1/5W J

harman/kardon

AVR 347/230 - AVR 350/230 Service Manual

Page 29 of 95

+ 66 hidden pages
