G-02
Master Clock Generator
OWNER’S MANUAL .................... 5
MODE D’EMPLOI .......................19
MANUAL DEL USUARIO ........... 33
D01168821D
IMPORTANT SAFETY PRECAUTIONS
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
For U.S.A.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the equipment and/or the receiving
antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
CAUTION
o DO NOT REMOVE THE EXTERNAL CASES OR CABINETS TO EXPOSE
THE ELECTRONICS. NO USER SERVICEABLE PARTS ARE INSIDE.
o IF YOU ARE EXPERIENCING PROBLEMS WITH THIS PRODUCT,
CONTACT THE STORE WHERE YOU PURCHASED THE UNIT FOR A
SERVICE REFERRAL. DO NOT USE THE PRODUCT UNTIL IT HAS BEEN
REPAIRED.
o USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF
PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT
IN HAZARDOUS RADIATION EXPOSURE.
IN NORTH AMERICA USE ONLY ON 120 V SUPPLY.
China RoHS
o The information in the following table is only applicable to products for sale in the People’s Republic of China.
o The products sold in the European area are manufactured in accordance with the European RoHS Directive.
CAUTION
Changes or modifications to this equipment not expressly
approved by TEAC CORPORATION for compliance will void the
user’s warranty.
For Canada
Industry Canada’s Compliance Statement:
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme
NMB-003 du Canada.
*
3
IMPORTANT SAFETY INSTRUCTIONS
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with
the manufacturer's instructions.
8) Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
9) Do not defeat the safety purpose of the polarized or groundingtype plug. A polarized plug has two blades with one wider than
the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided
for your safety. If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination
to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms
or when unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way, such
as power-supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has
been dropped.
o The apparatus draws nominal non-operating power from the
AC outlet with its POWER or STANDBY/ON switch not in the ON
position.
o The mains plug is used as the disconnect device, the disconnect
device shall remain readily operable.
o Caution should be taken when using earphones or headphones
with the product because excessive sound pressure (volume) from
earphones or headphones can cause hearing loss.
CAUTION
o Do not expose this apparatus to drips or splashes.
o Do not place any objects filled with liquids, such as vases, on
the apparatus.
o Do not install this apparatus in a confined space such as a book
case or similar unit.
o The apparatus should be located close enough to the AC outlet
so that you can easily reach the power cord plug at any time.
o If the product uses batteries (including a battery pack or
installed batteries), they should not be exposed to sunshine, fire
or excessive heat.
o CAUTION for products that use replaceable lithium batteries:
there is danger of explosion if a battery is replaced with an
incorrect type of battery. Replace only with the same or
equivalent type.
WARNING
Products with Class construction are equipped with a power
supply cord that has a grounding plug. The cord of such a product
must be plugged into an AC outlet that has a protective
grounding connection.
MEXCEL is a registered trademark of Mitsubishi Cable Industries, Ltd. in
Japan and other countries.
ESOTERIC is a trademark of TEAC CORPORATION, registered in the U.S.
and other countries.
Company names, product names and logos in this document are the
trademarks or registered trademarks of their respective owners.
4
For European Customers
Pb, Hg, Cd
Disposal of electrical and electronic equipment
(a) All electrical and electronic equipment should be disposed of
separately from the municipal waste stream via collection facilities designated by the government or local authorities.
(b)
By disposing of electrical and electronic equipment correctly,
you will help save valuable resources and prevent any potential
negative effects on human health and the environment.
(c)
Improper disposal of waste electrical and electronic equipment
can have serious effects on the environment and human health
because of the presence of hazardous substances in the
equipment.
(d) The Waste Electrical and Electronic Equipment (WEEE)
symbol, which shows a wheeled bin that has been
crossed out, indicates that electrical and electronic
equipment must be collected and disposed of separately from household waste.
(e) Return and collection systems are available to end users. For
more detailed information about the disposal of old electrical and electronic equipment, please contact your city office,
waste disposal service or the shop where you purchased the
equipment.
English
Disposal of batteries and/or accumulators
(a) Waste batteries and/or accumulators should be disposed of
separately from the municipal waste stream via collection facilities designated by the government or local authorities.
(b)
By disposing of waste batteries and/or accumulators correctly,
you will help save valuable resources and prevent any potential
negative effects on human health and the environment.
(c) Improper disposal of waste batteries and/or accumulators can
have serious effects on the environment and human health
because of the presence of hazardous substances in them.
(d) The WEEE symbol, which shows a wheeled bin that
has been crossed out, indicates that batteries and/
or accumulators must be collected and disposed of
separately from household waste.
If a battery or accumulator contains more than the specified
values of lead (Pb), mercury (Hg), and/or cadmium (Cd) as
defined in the Battery Directive (2006/66/EC), then the chemical symbols for those elements will be indicated beneath the
WEEE symbol.
(e) Return and collection systems are available to end users. For
more detailed information about the disposal of waste batteries and/or accumulators, please contact your city office, waste
disposal service or the shop where you purchased them.
5
Contents
Before use
Thank you for choosing Esoteric. Read this manual carefully
to get the best performance from this unit.
Before use ...........................................................6
Identifying the parts .................................................7
Connections .........................................................8
Basic operation ....................................................10
Clock output frequency setting ..................................... 11
Setting mode ......................................................14
Messages ...........................................................15
Troubleshooting ....................................................16
Restoring factory default settings ...................................16
Maintenance .......................................................17
Specifications ......................................................17
Rear panel ..........................................................18
Check to be sure the box includes all the supplied accessories
shown below.
Please contact the store where you purchased this unit if any
of these accessories are missing or have been damaged during
transportation.
Power cord x 1
Owner’s manual x 1
Warranty card x 1
CAUTION
0 Do not put anything on top of the unit.
0 Avoid placing the unit in direct sunlight or close to any source of
heat, such as a radiator, heater, open fireplace or amplifier. Also
avoid locations that are subject to vibrations or exposed to excessive dust, cold or moisture.
0 Place the unit in a stable location near the audio system that you
will use with it.
0 Do not move the unit during use.
0 Be careful to avoid injury when moving the unit due to its weight.
Get someone to help you if necessary.
0 The voltage supplied to the unit should match the voltage as
printed on the rear panel. If you are in any doubt regarding this
matter, consult an electrician.
0 As the unit could become warm during operation, always leave
sufficient space around it for ventilation. Make sure there is at least
20 cm (8”) of open space above and at least 5 cm (2”) of open
space on each side of the unit. DO NOT place anything, not even
CDs, CD-Rs, LP records or cassette tapes, on top of the unit.
0 Do not open the body of the unit as this might result in damage to
the circuitry or cause electric shock. If a foreign object should get
into the unit, contact your dealer.
0 When removing the power plug from the wall outlet, always pull
directly on the plug, never yank on the cord.
0 Depending on the electromagnetic waves of television broadcasts,
interference might appear on television screens when this unit’s
power is on. This does not indicate that this unit or the TV is malfunctioning. If this occurs, turn this unit’s power off.
6
Identifying the parts
A C D E FB
English
A
POWER button
Press this to turn the unit on and off.
When on, the ring around the button lights blue.
0 After the power is turned on, the oscillator is preheated to its
operating temperature. It takes 15 minutes for the oscillator
frequency to stabilize.
V
Turn this unit’s power off when you do not plan to use it for
an extended period.
B
LOCK indicator
This shows the clock status.
This blinks when locking or when an error occurs. It stays lit when
locked completely.
The indicator color depends on the clock source.
It lights blue when using the internal clock source (INT OCXO
setting), and it lights green when using an external 10 MHz reference frequency input through the EXT IN connector (EXT 10M-IN
setting).
C
MASTER/MENU button
Use this to set the mode (see page 14).
Press for 2 seconds or more to set the reference clock (see page 10).
D
Remote control signal receiver
Signals sent from remote controls are received here. When using
a remote, point it toward this spot.
0 This unit does not include a remote control.
0 A remote control included with another Esoteric product can
be used to adjust the brightness of this unit (see page 15).
E
Display
This shows the output clock frequency (ordinary display), setting
screens and error messages.
0 During ordinary display, if any output is ON, the name and
output frequency of the one that was last set is shown.
0 When all clock outputs are OFF, “A/B/C OFF” appears on the
display.
F
Frequency selection [A/B/C] buttons
Use these to set the clock frequency output from the CLOCK OUT
connectors (see page 11).
0 In setting mode, use these buttons for the following functions.
A button: Exit setting mode
B and C buttons: Select setting items
OCXO
This unit uses an Oven Controlled Crystal Oscillator (OCXO) that
has outstanding temperature stability to generate its reference
master clock. This OCXO contains a crystal oscillator and oscillation
circuit in a small thermostatic chamber that controls the internal
heat to realize an extremely high frequency stability of ±0.01 ppm
at temperatures ranging from −20°C to +70°C.
7
Connections
transport, player, etc.
External reference
V
Precautions when making connections
0 Complete all other connections before connecting power plugs to power outlets.
0 Read the owner’s manuals of all devices that will be connected, and follow their instructions.
0 For connections other than clock/word sync, refer to the owner’s manuals of the other devices.
0 When using separate components, such as a CD transport and a D/A converter, together, send this unit’s CLOCK OUT signal to
each component.
signal generator, etc.
Reference oscillation
frequency output
(10 MHz)
BNC coaxial cable
A
50 Ω
C
B
D
Grounding wire
BNC coaxial cable
75 Ω
BNC coaxial cable
75 Ω
Wall socket
CLOCK SYNC IN
Super Audio CD
CLOCK SYNC IN
D/A converter, etc.
8
Reference frequency input connector [EXT IN]
A
To use an external reference signal generator (10 MHz output) for
the reference frequency, connect the output connector of the
reference signal generator to this EXT IN connector using standard BNC coaxial cables (50 Ω impedance).
0 If the output level of the external oscillator is outside the
allowable input range of this unit, it cannot be used. Refer to
the oscillator manual for information on the output level and
accuracy of the oscillator.
CLOCK OUT connectors
B
These connectors output the clock signal.
Connect these CLOCK OUT connectors to the clock/word sync
inputs of CD players, D/A converters and other digital equipment
using standard BNC coaxial cables (75 Ω impedance).
0 Use the A, B and C buttons on the front panel to change their
frequencies (see page 10).
0 Use the frequency mode setting (FREQ) to set the clock refer-
ence frequency (see page 14).
D
AC power inlet
Connect the included power cord to this inlet. After completing
all other connections, plug the power plug into the AC power
outlet.
0 This unit uses a 3-pin power cord socket, but the grounding
pin does not connect to the chassis of the unit.
V
Use only the supplied Esoteric power cord.
Use of other power cords could result in fire or
electric shock.
Unplug the power cord from the outlet when
you are not planning to use the unit for an
extended period of time.
English
Ground connector [SIGNAL GND]
C
Audio quality might be improved by making ground connections
with connected devices such as digital equipment and amplifiers.
0 This is NOT an electrical safety ground.
At Esoteric, we use Esoteric MEXCEL stressfree cables for
reference.
For detailed information, access the following website.
http://www.esoteric.jp/products/esoteric/accessory/indexe.html
9
Basic operation
1 2 3 43
1
Turn the power on.
The power indicator will light.
0 When the power is turned on, the unit starts preheating the
oscillator to its operating temperature. It takes 15 minutes for
the oscillator frequency to stabilize.
44 (44.1kHz)
Use for playback of CDs, Super Audio CDs and other 44.1 kHz
sources.
48 (48kHz)
Use for playback of DVDs, DATs and other 48 kHz sources.
(Some DVDs and DATs are recorded at 44.1 kHz. In this case,
use the 44.1 kHz setting.)
0 When using only universal clock (100 kHz or 10 MHz), either
setting is fine.
0 Only use 44EXP or 48EXP for frequencies that are not covered
by the 44 and 48 modes (see pages 12-13).
4
Use the A, B and C buttons to set the frequencies
sent to connected devices (see page 11).
2
Press the MASTER/MENU button for 2 or more seconds
to select the clock source.
The clock source changes each time you press the MASTER/
MENU button for 2 or more seconds.
INT OCXO
The internal OCXO is used for the reference clock.
EXT 10M-IN
The 10 MHz signal input through the EXT IN is used as the reference clock
3
Set the clock reference frequency to 44.1 or 48 kHz.
Press the MASTER/MENU button to open the FREQ menu and
use the B and C buttons to set the frequency mode (see page 14).
.
5
On the connected devices, turn clock/word sync ON
(or set to slave mode).
Read the owner’s manual for each device for instructions on how
to set their clock/word sync status properly.
NOTE
0 When this unit is not in use, turn its power off.
0 Settings are retained even when the power is turned off.
0 Once settings have been made, those settings can be used when
the power is turned on again.
Set the frequency mode according to the type of disc to be played
or device being used (see page 14).
10
Clock output frequency setting (1)
Press 2 or more seconds
You can set the clock frequency output from the CLOCK OUT connectors.
0 This unit has 3 pairs (A, B and C) of clock outputs that can be sepa-
rated further into 6 individual outputs (A1, A2, B1, B2, C1 and C2).
You can set the clock frequency independently for each of these
outputs.
0 By default, the A, B and C outputs are set to be used as pairs.
Setting A, B and C outputs by pair (default)
When you change the A setting, the output frequency is set for
both A1 and A2 simultaneously.
Likewise, setting B or C affects B1 and B2 or C1 and C2, respectively.
When “A >”, “B >” or “C >” appears, pressing the A, B or C button
changes the output frequency of that pair. Press repeatedly to
cycle through the options.
0 Press and hold the A, B or C button for at least two seconds to set
A2, B2 or C2, respectively. (See “Setting A2, B2 or C2” on the right.)
Setting A1, A2, B1, B2, C1 and C2 independently
Press the A button for at least two seconds until “A2>” appears.
Then, press the A button to change the A2 setting. You can set
different clock frequencies for A1 and A2. The same is true for the
B and C pairs.
Setting A1, B1 or C1
English
When A2 is set to any value that is not the same as the A1 setting,
when “A1>” appears, press the A button to change just the A1
output frequency. Follow the same procedure for B1 and C1.
Setting A2, B2 or C2
Press the A, B or C button for at least two seconds to set A2, B2
or C2.
0 If you do not press any buttons for 10 or more seconds, setting
mode will end and the display will return to normal. (If DISP is
set to SHORT, this will happen after 3 seconds.)
If you connect this unit to devices from other manufacturers, be
sure to read the manuals of those devices to confirm the clock frequencies that they can receive.
Some devices require the clock frequency to be set to the same
value as the audio signal sampling frequency.
Some dual AES connection might require that the clock frequency
be set to half of the audio signal frequency.
When “A2>” appears, press the A button to change just the A2
output frequency. Follow the same procedure for B2 and C2.
0 To set A1 after setting A2, press the A button again after return-
ing to the ordinary display.
0 If you set A2 to the same value as A1, “A” will appear again, and
you can set the output frequency used by both outputs in the
A pair simultaneously. Follow the same procedure for B and C
pairs. (See “Setting A, B and C outputs by pair” on the left.)
11
Clock output frequency setting (2)
Frequency setting options
The frequency setting options depend on the frequency mode (FREQ)
setting (see page 14).
When the frequency mode (FREQ) is set to 44:
OFF
No clock signal is output.
44.1k
44.1 kHz clock frequency is output.
88.2k
2 × 44.1 kHz (88.2 kHz) clock is output.
176.4k
4 × 44.1 kHz (176.4 kHz) clock is output.
22.5MHz
512 × 44.1 kHz (22.5792 MHz) clock is output.
100kHz
100 kHz clock is output.
10MHz
10 MHz clock is output.
A2 = A1
The A2 clock output matches the A1 clock output and will be
switched with the A1 setting.
This only appears for the A2 clock setting.
When the frequency mode (FREQ) is set to 48:
OFF
No clock signal is output.
48kHz
48 kHz clock frequency is output.
96kHz
2 × 48 kHz (96 kHz) clock is output.
192k Hz
4 × 48 kHz (192 kHz) clock is output.
24.5MHz
512 × 48 kHz (24.576 MHz) clock is output.
100kHz
100 kHz clock is output.
10MHz
10 MHz clock is output.
A2 = A1
The A2 clock output matches the A1 clock output and will be
switched with the A1 setting.
This only appears for the A2 clock setting.
B2 = B1
C2 = C1
These settings for B2 and C2 function in the same way as the “A2 =
A1” setting.
B2 = B1
C2 = C1
These settings for B2 and C2 function in the same way as the “A2 =
A1” setting.
12
When the frequency mode (FREQ) is set to 44EXP:
When the frequency mode (FREQ) is set to 48EXP:
OFF
No clock signal is output.
44.1k
44.1 kHz clock frequency is output.
88.2k
2 × 44.1 kHz (88.2 kHz) clock is output.
176.4k
4 × 44.1 kHz (176.4 kHz) clock is output.
352.8k
8 × 44.1 kHz (352.8 kHz) clock is output.
705.6k
16 × 44.1 kHz (705.6 kHz) clock is output.
1.4MHz
32 × 44.1 kHz (1.4112 MHz) clock is output.
2.8MHz
64 × 44.1 kHz (2.8224 MHz) clock is output.
5.6MHz
128 × 44.1 kHz (5.6448 MHz) clock is output.
11. 2M Hz
256 × 44.1 kHz (11.2896 MHz) clock is output.
OFF
No clock signal is output.
48kHz
48 kHz clock frequency is output.
96kHz
2 × 48 kHz (96 kHz) clock is output.
192k Hz
4 × 48 kHz (192 kHz) clock is output.
384kHz
8 × 48 kHz (384 kHz) clock is output.
768kHz
16 × 48 kHz (768 kHz) clock is output.
1.5MHz
32 × 48 kHz (1.536 MHz) clock is output.
3.0MHz
64 × 48 kHz (3.072 MHz) clock is output.
6.1MHz
128 × 48 kHz (6.144 MHz) clock is output.
12. 2MH z
256 × 48 kHz (12.288 MHz) clock is output.
English
22.5MHz
512 × 44.1 kHz (22.5792 MHz) clock is output.
100kHz
100 kHz clock is output.
10MHz
10 MHz clock is output.
A2 = A1
The A2 clock output matches the A1 clock output and will be
switched with the A1 setting.
This only appears for the A2 clock setting.
B2 = B1
C2 = C1
These settings for B2 and C2 function in the same way as the “A2 =
A1” setting.
24.5MHz
512 × 48 kHz (24.576 MHz) clock is output.
100kHz
100 kHz clock is output.
10MHz
10 MHz clock is output.
A2 = A1
The A2 clock output matches the A1 clock output and will be
switched with the A1 setting.
This only appears for the A2 clock setting.
B2 = B1
C2 = C1
These settings for B2 and C2 function in the same way as the “A2 =
A1” setting.
13
Setting mode
FREQ>***
↓
↓
(DIMMER>***)
1
Press the MASTER/MENU button.
Press the MASTER/MENU button again to cycle through the setting items.
DISP>***
0 The DIMMER item only appears when DISP is set to ON.
Frequency mode setting
(FREQ>***)
Set the clock reference frequency to 44.1 kHz or 48 kHz. Use an EXP
mode to increase the range of output frequency options that can be
used.
0 Set the reference frequency according to the playback source.
44.1kHz
Use for playback of CDs, Super Audio CDs and other 44.1 kHz
sources.
48kHz
Use for playback of DVDs, DATs and other 48kHz sources.
(Some DVDs and DATs are recorded at 44.1 kHz. In this case, use
the 44.1kHz setting.)
0 100 kHz and 10 MHz clock output can be set and output with either
setting.
2
Use the B and C buttons to change the settings.
For explanations of each setting, see the right column and page 15.
3
Press the A button to exit setting mode.
44
Sets the reference frequency to 44.1 kHz.
The frequency can be set to 44.1, 88.2 or 176.4 kHz or 22.5792 MHz.
48
Sets the reference frequency to 48 kHz.
The frequency can be set to 48, 96 or 192 kHz or 24.576 MHz.
44EXP
Sets the reference frequency to 44.1 kHz.
The frequency can be set to 44.1, 88.2, 176.4, 352.8 or 705.6 kHz or
1.4112, 2.8224, 5.6448, 11.2896 or 22.5792 MHz.
48EXP
Sets the reference frequency to 48 kHz.
The frequency can be set to 48, 96, 192, 384 or 768 kHz or
1.536, 3.072, 6.144, 12.288 or 24.576 MHz.
If you do not press any buttons on the unit for 10 seconds, the
unit will exit setting mode and the display will resume showing
its usual contents.
0 When DISP is set to SHORT, after 3 seconds without use the
unit will exit setting mode and the display will resume showing its usual contents (see page 15).
0 Settings are retained even when the power is turned off.
14
3 (Standard brightness)
2
1
0 (Unlit)
Messages
Display illumination time setting
(DISP>***)
You can set the amount of time that the clock frequency is shown on
the display to ON, LONG or SHORT.
0 If the display backlight (FL) is left ON with the same indication for a
long time, brightness irregularities might occur. For this reason, we
recommend that you set this to LONG or SHORT.
ON
In this mode, the display always stays lit.
LONG
When ordinary display continues without any operation being
conducted for about 20 seconds, the backlight (FL) will automatically turn off.
SHORT
When ordinary display continues without any operation being
conducted for about 3 seconds, the backlight (FL) will automatically turn off.
PLL LCKING
The internal crystal oscillator (OCXO) or the 10 MHz clock source
input by the EXT IN is being locked by the internal PLL circuit.
When locking completes, this message will disappear.
0 Ordinarily, only a few seconds are needed until locking completes
(PLL locking time), but it can take up to a minute depending on
the operating temperature and other factors.
0 If locking cannot be completed because input conditions are
not met when set to EXT 10M-IN, the message will continue to
be displayed.
In this case, check the input clock source.
NO 10M-IN!
No 10 MHz reference clock signal is being input to the reference frequency input connector (EXT IN).
Check the input clock source.
When not using an external clock source, set it to INT OCXO (see
page 10).
English
Dimmer setting
(DIMMER>***)
You can set the brightness of the backlight (FL) and indicators to one
of four levels.
You can only set this when the DISP setting is set to ON.
0 You can also change this setting using the DIMMER button on a
remote control that is included with another Esoteric product such
as the P-05 or K-05.
0 When set to 0 (unlit), display and indicators will not be lit.
0 When unlit, pressing a button will cause the display to light for a
few seconds.
0 Even when set to a value other than 3, standard brightness will be
used when an error message or settings menu item is shown.
15
