24000F Valve
D103330X012
Baumann™ 24000F Wafer Body
Control Valve
The Baumann unique 24000F wafer style control valve
mates with ASME and EN line flange connections and is
designed to control a wide range of process liquids,
gasesandvapors.Thisverycompact package provides
the connection integrity of flanged body globe valves
while being significantly lighter and easier to install.
Special alloy constructions are available and round out
the standard S31603 stainless steel offering. The
24000F serves as a general purpose, modulating valve
suitable for process line pressures up to 99 barg (1440
psig) and operating temperatures to 537_C (1000_F).
Product Bulletin
52.1:24WF
March 2013
Features
Compact and light-weight design reduces installed
piping costs.
Universal valve body construction mates with both
ASME and EN flanges (see table 9).
Multiple trim capacity reductions available to meet
changing process requirements with Cv ratings as
low as 0.00013.
Optional extended bonnet for applications ranging
from -195 to 537_C (-320 to 1000_F).
Optional ENVIRO-SEAL™ packing system to meet
critical emission control requirements
Epoxy powder-coated actuator with stainless steel
fasteners for corrosion resistance.
Multi-spring, field-reversible actuator with reduced
deadband, permits direct operation from remote
signal devices.
Actuator and yoke can be removed from the valve
assembly while maintaining packing integrity.
W9762
24000F Control Valve
with Baumann 32 Dual-Stop Actuator
W9763
24000F Control Valve with Baumann 32 Actuator and
FIELDVUE DVC2000 Digital Valve Controller
Fisherr FIELDVUE™digital valve controller available
for remote calibration and diagnostics in facilities
utilizing the PlantWeb™ architecture.
www.Fisher.com
Product Bulletin
52.1:24WF
March 2013
24000F Valve
D103330X012
Figure 1. Baumann 24000F Valve Body with Standard
Bonnet and NPS 1 Integral Seat
Figure 2. Baumann 24000F Valve Body with
Extension Bonnet and Screwed-In Seat Ring
E1278
E1279
2
Product Bulletin
24000F Valve
D103330X012
Table 1. Materials of Construction
Key
No.
1 Valve Body
2
4
5 Stem ASTM A276 S31600 ASME SB574 N10276 ASTM B473N08020 ASME SB164N04400
8 Bonnet
9 Drive Nut(Yoke) S30400
10 Packing Follower
14
27 Lock Nut Stainless Steel (18-8 Stainless Steel)
49 Body Gasket Graphite Grade GHR withS31600 Insert
58 TravelIndicator ASME SA240 S30400
1. For optional valve and trim materials, consult your Emerson Process Management sales office for price anddelivery. N08020 and N 04400 nickel alloy materialshave pressure-temperature
ratings less than 206 barg (3000 psig)or 413 barg (6000psig) respectively.
Description
Seat Ring (standard)
(ForLowFlowTrim,see
tables 2 and 3)
Plug (Metal Seat) Cv ≤
2.5
Plug (Metal Seat) Cv ≥
4.0
Plug (Soft Seat)
V- Ring Packing (standard) (Refer to page 4)
Packing (optional) (Refer to page 4)
S31603 Stainless Steel N10276 Nickel Alloy
ASME SA479 S31600/ S31603
Dual Certified
ASTM A276 S31600/ S31603 Dual
Certified
ASME SA479 S21800 (standard) /
ASTM A582 S41600
Condition T (optional)
ASTM A276S31600/
S31603(standard) / ASTM A582
S41600 Condition T (optional)
ASTM A276 S31600/ S31603 with
PTFE (Polytetrafluoroethylene)
insert
ASME SA479 S31600/ S31603
Dual Certified
ASTM A276 S31600/ S31603 Dual
Certified
ASME SB574 N10276 ASTM B473N08020 ASME SB164N04400
ASME SB574 N10276 ASTM B473N08020 ASME SB164N04400
ASME SB574 N10276 ASTM B473N08020 ASME SB164N04400
ASME SB574
N10276/PTFE
ASME SB574 N10276 ASTM B473N08020 ASME SB164N04400
ASME SB574 N10276 ASTM B473N08020 ASME SB164N04400
Material
(1)
N08020 Nickel Alloy
ASTM B473
N08020/PTFE
(1)
N04400 Nickel Alloy
52.1:24WF
March 2013
ASME SB164 N04400/
PTFE
(1)
Figure 3. Optional 151 Low Flow Trim Assembly
E1270
Table 2. 151 Low Flow Trim
Key
Number
4 Plug ASME SA479 S21800
51
Description Material
Seat Sub-Assembly
52 Cage ASTM A276S31600/ S31603
53 Seat PTFE
54 Collar ASTM A276S31600/ S31603
55 Washer ASTM A276 S31600 Cond B
56 Insert ASTM A276 S31600/ S31603
Figure 4. Optional 177 Low Flow Trim Assembly
E1271
Table 3. 177 Low Flow Trim
Key Number Description Material
Seat Sub-Assembly
23 Gland ASTM A276 S31600/ S31603
(1)
2
1. For optional trim materials, consultyour Emerson Process Managementsales office
for price and delivery. Baumann 32 actuator requiresdual-stopswith177 trimseries.
24 Retainer Nut ASTM A276 S31600/ S31603
25 Insert Reinforced PTFE
26 Housing ASTM A276 S31600/ S31603
(1)
4
Plug ASME SA479 S21800
3
Product Bulletin
52.1:24WF
March 2013
24000F Valve
D103330X012
Figure 5. Standard Spring-Loaded PTFE V-Ring
Packing Kit
E1240
Table 4. Standard Spring-Loaded PTFE V-Ring
Packing Kit
Key Number Description Material
(1)
6
14 Packing Set
16 Washer ASME SA240 S31600
20 Spacer
1. N10276 nickel alloy valve body construction is furnished with N10276 nickelalloy
spring.
Spring ASTM A313 S30200
PTFE (Polytetrafluoroethylene) /
PTFE, 25%carbon filled
J-2000
(filled-Polytetrafluoroethylene)
Figure 7. ENVIRO-SEAL Packing Kit (Optional)
E1248
Table 6. ENVIRO-SEAL Packing Kit (Optional)
Key Number Description Material
13 Bushings Carbon-Graphite
14 Packing Rings
17
18 Bushing PEEK (polyetheretherketone)
19 Washers Modified PTFE
Belleville
Spring
PTFE (Polytetrafluoroethylene) /
PTFE, 25% carbon filled
N06600 Nickel Alloy (ASTM B637
N07718, 40HRC max)
Figure 6. Molded Graphite (Flexible Graphite)
Packing Kit (Optional)
E1241
Table 5. Molded Graphite (Flexible Graphite)
Packing Kit (Optional)
Key Number Description Material
13 Bushings Carbon-Graphite
14A Packing Rings Graphite
14B Packing Ring Graphite
Special ENVIRO-SEAL
Packing Note
The ENVIRO-SEAL PTFE packing system is suitable for
100 ppm environmental applications on services up to
51.7 barg (750 psig) and process temperatures
ranging from -46 to 232_C(-50to450_F).
For non-environmental applications, this packing
system offers excellent performance at the same
temperature range up to the maximum valve working
pressure.
Temperature limits apply to packing arrangements
only. Complete valve assembly temperature limits may
differ, refer to appropriate pressure/temperature
ratings.
(Reference Fisher Packing Selection Guidelines for
Sliding-Stem Valves, Bulletin 59.1:062,
D101986X012).
4
24000F Valve
D103330X012
Table 7. Technical Specifications
NOMINAL PIPE SIZE DN 15, 20, and 25 NPS1/2,3/4,and1
END CONNECTIONS Refer to table 9
PRESSURE RATING Refer to tables 13,14, 15, and 16
CHARACTERISTIC Equal Percentage or Linear
Product Bulletin
52.1:24WF
March 2013
Table 8. Temperature Ratings for Packing and Seat Material
PTFE Soft Seat
SEATING MATERIAL
PACKING AND BONNET
COMBINATIONS
1. Temperature limits apply to seating or packing arrangements only. Complete valve assembly temperature limits may differ, refer to appropriate pressure/temperature ratings. For more
information on packing selection, reference Fisher Packing Selection Guidelines for Sliding - Stem Valves, Bulletin 59.1:062, D101986X012.
Reinforced PTFE 177 Trim -73 to232_C (-100 to 450_F)
Metal Seat 102, 548, 588, 648, 688 Trim -195 to 537_C (-320 to 1000_F)
BONNET STYLE PACKING TEMPERATURE LIMIT
Standard Bonnet
Extension Bonnet
(1)
151 Trim -29 to177_C(-20to350_F)
577 & 677 Trim -73 to 232_C (-100 to 450_F)
Spring Loaded PTFE -73 to232_C (-100 to 450_F)
ENVIRO-SEAL -45 to 232_C(-50to450_F)
Graphite -73 to232_C (-100 to 450_F)
Spring Loaded PTFE -195 to 232_C (-320 to 450_F)
ENVIRO-SEAL -45 to 232_C(-50to450_F)
Graphite -195 to537_C (-320 to 1000_F)
Table 9. Connections Available
VALVE SIZE MATING LINE FLANGES
DN NPS CL150 CL300 CL600 PN10-40
CONNECTIONS
15 1/2 NO Yes Yes Yes
20 3/4 Yes Yes Yes Yes
25 1 Yes Yes Yes Yes
Table 10. Actuator Specifications
TYPE 32, 54, 70 Multi-SpringDiaphragm (Single Acting)
DIAPHRAGM AREA 210, 350, 450 cm2/ 32,54, 70 in
AIR FAILURE 32 and 54 Fails Open or Closed (Field Reversible) / 70 Fails Closed ONLY
(1)
TRAVEL
AMBIENT TEMPERATURE RANGE -29_Cto71_C/-20_F to 160_F
MAXIMUM AIRPRESSURE 2.4 barg / 35 psig
DIAPHRAGM MATERIAL
SPRING CASES Steel, Powder Epoxy-Coated with Stainless Steel Fasteners
YOKE Ductile Iron, Powder Epoxy-Coated
1. Dual travelstops are availableon Baumann 32 and 54 actuators. These are not field reversible.
2. Optional reinforced VMQ (Silicone) diaphragm with FKM (Fluorocarbon) O-ring actuator stem seal for high temperature conditions (-29_Cto121_C/-20_F to250_F) is available with
Baumann 32 and 54 actuators ONLY.
(2)
NBR (Nitrile) / TPES (Polyester Thermoplastic)
12.7 mm/ 0.50 inches
2
5
Product Bulletin
52.1:24WF
March 2013
Table 11. Cv Values at 100% Plug Opening (Kv = 0.86 x Cv)
VALVE SIZE ORIFICE DIAMETER PLUG TRAVEL
DN NPS mm inch mm inch Cv Cv Cv Cv Cv Cv Cv
3.97 0.156 12.7 0.50 ---
15
20
25
15
20
25 1 9.5 0.375 12.7 0.50 --- --- ---
(1)
25
1. 24000F NPS 1, Cv 4.0 and 6.5 are integral seat.
1/2
3/4
1
6.3 0.25 12.7 0.50
7.9 0.3125 12.7 0.50 --- ---
1/2
3/4
1 20.6 0.8125 12.7 0.50 --- --- --- 4.0, 6.5 4.0, 6.5 4.0 4.0, 6.5
9.5 0.375 12.7 0.50 --- --- ---
102 151 177 577 548 / 588 677 648 / 688
0.00013
0.00025
0.0005
0.001
0.002
0.004
0.008
0.015
0.03
0.06
0.10
0.20
0.45
0.02
0.05
0.10
0.20
--- --- ---
PLUG SERIES
--- --- --- --- ---
0.0005
0.001,
0.002
0.005,
0.01
0.02,
0.05
--- --- --- ---
1.0, 1.5
2.0
1.0, 1.5
2.5
1.5 2.0
24000F Valve
D103330X012
0.2
0.5
1.0
0.1, 0.2,
0.5, 1.0,
2.0
0.1, 0.2,
2.5
0.5, 1.0,
2.5
---
0.5
1.0
1.5
2.0
1.5
2.5
Figure 8. Baumann 24000F Trims
102 Linear
LowFlowTrim
W9747
6
151 Modified Equal %
LowFlowTrim
W9751 W9748 W9749
177 Modified Equal %
LowFlowTrim
548 / 577 / 588
Equal % Trim
648 / 677 / 688
Linear Trim
W9750
24000F Valve
D103330X012
Table 12. ISA Sizing Coefficients
Series Cv Rating FL Fd XT KC
102
151
177
548/588
577
677
648/688
0.02
0.04
0.09
0.17
0.0001
0.0002
0.0004
0.0009
0.0017
0.003
0.007
0.013
0.026
0.052
0.09
0.17
0.39
0.0005
0.001
0.002
0.005
0.01
0.02
0.05
0.2
0.5
1
1.5
2
2.5
4
6.5
1
1.5
2
4
6.5
0.1
0.2
0.5
1
2
2.5
4
0.5
1
1.5
2
2.5
4
6.5
0.95
0.98
0.95 0.70 0.76 0.76
0.90 0.28 0.68
0.90
0.90
0.90
0.90
0.06
0.09
0.013
0.18
0.35
0.04
0.05
0.06
0.075
0.10
0.11
0.15
0.18
0.22
0.25
0.30
0.40
0.40
0.33
0.42
0.46
0.40
0.33
0.42
0.46
0.08
0.12
0.19
0.27
0.46
0.40
0.33
0.42
0.46
0.76 0.86
0.81 0.94
0.68
0.68 0.73
0.68 0.73
0.68 0.73
Product Bulletin
52.1:24WF
March 2013
0.94
7
Product Bulletin
52.1:24WF
March 2013
24000F Valve
D103330X012
Table 13. Pressure-Temperature Ratings for S31603 Stainless Steel Valve Body (Standard)
Temperature (_C)
-195 to37 99 -320 to100 1440
93 85 200 1240
149 77 300 1120
204 70 400 1025
232 68 450 990
260 65 500 955
288 63 550 927
315 62 600 900
343 61 650 890
371 60 700 870
398 58 750 855
426 58 800 845
454 57 850 835
482 57 900 830
510 53 950 775
537 48 1000 700
1. Do not exceed seating and packing material ratings.
(1)
Working Pressure(barg) Temperature (_F)
(1)
Table 14. Pressure-Temperature Ratings for N10276 Nickel Alloy Valve Body (Optional)
Temperature (_C)
-195 to37 103 -320 to100 1500
93 103 200 1500
149 100 300 1455
204 97 400 1410
232 94 450 1370
260 91 500 1330
288 87 550 1270
315 83 600 1210
343 81 650 1175
371 78 700 1135
398 73 750 1065
426 69 800 1015
454 67 850 975
482 62 900 900
510 53 950 775
537 49 1000 725
1. Do not exceed seating and packing material ratings.
(1)
Working Pressure(barg) Temperature (_F)
(1)
Working Pressure(psig)
Working Pressure(psig)
8
24000F Valve
D103330X012
Product Bulletin
52.1:24WF
March 2013
Table 15. Pressure-Temperature Ratings for N04400 Nickel Alloy Valve Body (Optional)
Temperature (_C)
-195 to37 82 -320 to100 1200
93 72 200 1055
149 68 300 990
204 65 400 955
232 65 450 952
260 65 500 950
288 65 550 950
315 65 600 950
343 65 650 950
371 65 700 950
398 64 750 935
426 63 800 915
454 46 850 680
482 34 900 495
1. Do not exceed seating and packing material ratings.
(1)
Working Pressure(barg) Temperature (_F)
(1)
Table 16. Pressure-Temperature Ratings for N08020 Nickel Alloy Valve Body (Optional)
Temperature (_C)
-195 to37 82 -320 to100 1200
93 72 200 1045
149 67 300 980
204 67 400 980
232 67 450 980
260 67 500 980
288 67 550 980
315 67 600 980
343 67 650 980
371 67 700 980
398 67 750 980
426 67 800 980
1. Do not exceed seating and packing material ratings.
(1)
Working Pressure(barg) Temperature (_F)
(1)
Working Pressure(psig)
Working Pressure(psig)
9
Product Bulletin
52.1:24WF
March 2013
Table17.AllowablePressureDrops(bar)
AIR-TO-OPEN ACTION AIR-TO-CLOSE ACTION
0.2-1.0 barg SIGNAL
PORT
DIA.
(mm)
TRAVEL
(mm)
6.4 12.7
7.9 12.7
PLUG
ACT
TYPE
BENCH
RANGE
(barg)
32 0.3-1.0 61 --- 99 --- 0.2-0.9 61 --- 99
32 0.5-1.0 99 --- 99
32 0.3-1.0 --- 28 --- 71 0.2-0.9 --- 28 --- 99
32 0.5-1.0 --- 71 --- 99 0.2-0.7 --- 92 --- 99
TO ACTUATOR
Max CL
IV
Shutoff
Pressure
Max CL
VI
Shutoff
Pressure
32 0.3-1.0 31 19 62 50 0.2-0.9 31 19.1 99 97
9.5 12.7
32 0.5-1.0 62 50 93 81 0.2-0.7 77 65 99
54 0.6-1.0 99
(1)
99
32 0.3-1.0 7.7 1.3 15.5 9.1 0.2-0.9 7.7 1.3 27 20
32 0.5-1.0 15.5 9.1 23 16.8 0.2-0.7 19.5 12.9 38 32
20.6 12.7
54 0.5-1.0 23 17.0 35 28 0.2-0.7 29.5 23 59 52
54 0.8-1.0 47 40 59 52 --- --- --- --- --70 0.7-1.0 56 49 72 65 --- --- --- --- ---
1. The maximumshutoff pressure whenusing ENVIRO-SEAL packing is defined by: nP= Table Value -[1112/(Port Diameter)2]. These table values should not be modified bythis formula and
the maximum nP of 51 bar should be used for ENVIRO-SEAL packing.
2. The maximumshutoff pressure when using Flexible Graphite packing is defined by: nP = TableV alue - [5337/(Port Diameter)
and the maximum nP of 99 bar should be used for Flexible Graphite packing.
WITH POSITIONER
Max CL
Shutoff
Pressure
(1)
1.38 bargAIR
SUPPLY
IV
(1)
(1,2)
99
Max CL
VI
RANGE
(barg)
Shutoff
Pressure
--- 0.2-0.7 99
(1,2)
BENCH
99
0.2-0.7 --- --- --- ---
2
]. These tablevalues should notbe modified by this formula
0.2-1.0 barg SIGNAL
TO ACTUATOR
Max CL
Max CL
IV
Shutoff
Pressure
Shutoff
Pressure
(1)
24000F Valve
D103330X012
WITH POSITIONER
1.38 barg AIR
VI
--- 99
Max CL
IV
Shutoff
Pressure
SUPPLY
Pressure
(1)
(1,2)
(1)
Max CL
VI
Shutoff
---
---
(1)
(1,2)
(1)
99
Table18.AllowablePressureDrops(psi)
AIR-TO-OPEN ACTION AIR-TO-CLOSE ACTION
3-15 psig SIGNAL TO
PORT
DIA. (in)
PLUG
TRAVEL
(in)
0.25 0.50
0.3125 0.50
ACT
TYPE
BENCH
RANGE
(psig)
32 5-15 887 --- 1440 --- 3-13 887 --- 1440
32 7-15 1440 --- 1440
32 5-15 --- 418 --- 1033 3-13 --- 418 --- 1440
32 7-15 --- 1033 --- 1440 3-10 --- 1341 --- 1440
ACTUATOR
Max CL
IV
Shutoff
Pressure
Max CL
VI
Shutoff
Pressure
32 5-15 452 278 905 730 3-13 452 278 1440 1409
0.375 0.50
32 7-15 905 730 1357 1182 3-10 1131 956 1440
54 9-15 1440
(1)
1440
32 5-15 113 19 226 132 3-13 113 19 396 301
32 7-15 226 132 339 245 3-10 283 188 565 471
0.8125 0.50
54 7-15 343 248 514 419 3-10 428 334 856 762
54 11-15 685 591 856 762 --- --- --- --- --70 10-15 815 720 1048 953 --- --- --- --- ---
1. The maximumshutoff pressure whenusing ENVIRO-SEAL packing is defined by: nP= Table Value -[25/(Port Diameter)2]. These tablevalues should notbe modified bythis formula andthe
maximum nP of 750 psi should be used for ENVIRO-SEAL packing.
2. The maximumshutoff pressure when using Flexible Graphite packing is defined by: nP = TableV alue - [120/(Port Diameter)
the maximum nP of 1440 psi should be used for Flexible Graphite packing.
WITH POSITIONER
20 psigAIR SUPPLY
Max CL
IV
Shutoff
Pressure
(1)
1440
(1)
(1,2)
Max CL
VI
Shutoff
BENCH
RANGE
(psig)
Pressure
--- 3-10 1440
(1,2)
1440
3-10 --- --- --- ---
2
]. These tablevalues should not be modified by this formula and
3-15 psigSIGNAL TO
ACTUATOR
Max CL
IV
Shutoff
Pressure
(1)
Max CL
VI
Shutoff
Pressure
--- 1440
WITH POSITIONER
20 psigAIR SUPPLY
Max CL
Max CL
IV
Shutoff
Pressure
(1)
(1,2)
(1)
Shutoff
Pressure
1440
VI
---
---
(1)
(1,2)
(1)
10
24000F Valve
D103330X012
Product Bulletin
52.1:24WF
March 2013
Figure 9. Dimensional Drawings
141
(5.5)
216
(48.5)
229
(9.0)
A
C 4B
BAUMANN 32 ACTUATOR with
3660/3661 POSITIONER
216
(48.5)
152 (46.0)
94
(3.7)
MAX
31 (1.24)
BAUMANN 32 ACTUATOR
WITH ADJUSTABLE OPEN/
163 (6.4)
MAX
216
(48.5)
CLOSE DUAL TRAVEL
STOPS
216
(48.5)
160 (46.3)
279
(411.0)
127 (5.0)
276
(10.9)
BAUMANN 54 ACTUATOR
w/ FIELDVUE DVC2000
DIGITAL VALVE
CONTROLLER
279 (411.0)
152 (46.0)
71 (2.8)
MAX
60
(2.4)
271
(10.7)
130 (5.1)
MAX
333
(413.1)
229
(9.0)
3/4 INCH
SQUARE
BAUMANN 70 ACTUATOR w/
FIELDVUE DVC6010 DIGITAL
VALVE CONTROLLER
279 (411.0)
160 (46.3)
BAUMANN 32 ATO/
FAIL CLOSED
ACTUATOR WITH
BAUMANN 32 ATC/
FAIL OPEN ACTUATOR
WITH HANDWHEEL
BAUMANN 54 ATO/FAIL
CLOSED ACTUATOR w/
HANDWHEEL
BAUMANN 54 ATC /
FAIL OPEN ACTUATOR
WITH HANDWHEEL
HANDWHEEL
E1280
Note: Actuator removal requires 115 mm (4.5 inches) verticalclearance.
Table19.ValveDimensions
VALVE SIZE
DN NPS mm Inch mm Inch mm Inch mm Inch
15 1/2 83.8 3.3 218.4 8.6 88.9 3.5 38.1 1.5
20 3/4 83.8 3.3 218.4 8.6 107.95 4.25 38.1 1.5
25 1 78.7 3.1 215.9 8.5 114.3 4.5 50.8 2.0
Standard Extension
ABONNET
BDIAMETER C
mm
(inch)
11
Product Bulletin
52.1:24WF
March 2013
24000F Valve
D103330X012
Table 20. Valve Assembly Weights
VALVE SIZE WEIGHT
DN NPS kg lb
15 1/2 1.7 3.8
20 3/4 2.4 5.3
25 1 3.3 7.3
Table 21. Actuator Weights
ACTUATOR TYPE
32 4.5 10
54 11.3 25
70 15.4 34
MV 10 22
VA 14 30
kg lb
Table 22. Model Numbering System
24 F
Actuator
(1)
32
54 151 Modified Equal % / PTFE Seat VI E Extension
70 177 Modified Equal % / Reinforced PTFE VI
mv 548 Equal % / Metal Seat(S41600) IV
va 577 Equal % / PTFE Seat VI
1. Baumann 32actuator requires dual stops with 177 trim series.
Valve Body
Series
Plug Series Characteristic Seat Leakage
102 Linear / Metal Seat IV --- Standard
588 Equal % / Metal Seat(S31600) IV
648 Linear / Metal Seat IV
677 Linear / PTFE Seat VI
688 Linear / Metal Seat IV
Wafer Valve
Body
Bonnet Style
WEIGHTS
Neither Emerson, Emerson Process Man agement, nor any of their affiliated entities assumes responsibility for the selection, use or maintenance
of anyproduct. Responsibility for proper selection, use, and maintenance of any product remains solely with the purchaser and end user.
Baumann, Fisher, FIELDVUE, PlantWeb, and ENVIRO-SEAL are marks owned by one of the companies in the Emerson Process Management business unit of
Emerson Electric Co. Emerson Process Management, Emerson, and the Emerson logo are trademarks and service marks of EmersonElectric Co.All other
marks are the property of their respective owners.
The contents of this publication are presented for informational purposes only, and while every effort has been made to ensure their accuracy, they arenot
to be construed as warranties or guarantees, express or implied, regarding the products or services described herein or their use or applicability. All sales are
governed by our terms and conditions, which are availableupon request. We reserve the right tomodify or improve the designs or specifications of such
products at any time without notice.
Emerson Process Management
Marshalltown, Iowa 50158 USA
Sorocaba, 18087 Brazil
Chatham, Kent ME4 4QZ UK
Dubai, United Arab Emirates
Singapore 128461 Singapore
www.Fisher.com
E 2009, 2013 Fisher Controls International LLC. All rightsreserved.
12
Loading...
