PORTABLE DVD
USER'S MANUAL
MT-739
Before connecting, operating or adjusting this product, please read this user's manual carefully and completely.
Table of Contents
Contents
Table of Contents |
P1 |
SETUP Menu Setting |
P9-P12 |
Safety Precautions |
P2 |
Parameters and specifications |
P12-P13 |
Before Use(Continued) |
P2-P3 |
Troubleshooting tips |
P13 |
Identification of Controls |
P3-P5 |
|
|
Getting Started |
P5-P6 |
|
|
Basic operation |
P7-P8 |
|
|
1
Safety Precautions
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Warning:To reduce the risk of electric shock,do not remove
the cover or back of this product.There are no user-serviceable parts inside. Refer servicing to qualified service personnel.
Warning: To reduce the risk of fire or electric shock, do not expose this product to dripping or splashing water,rain, or moisture. Do not place objects filled with water such as vases, on the Product.
Warning: This digital video disc player employs a laser system. Use of controls,adjustments, or the performance of procedures other than those specified herein may result in hazardous radiation Exposure.
Warning: To prevent direct exposure to laser beam,do not open the enclosure.Visible laser radiation when open.
Warning: Never stare directly into the laser beam.
Caution: Do not install this product in a confined space such as a book case or similar unit.
N Notes on Copyrights:
It is forbidden by law to copy, broadcast, show,broadcast via cable, play in public, or rent copyrighted material without permission.
This product features the copy protection function developed by Macrovision.Copy protection signals are recorded on some discs. When recording and playing the pictures of these discs picture noise will appear.This product incorporates copyright protection technology that is protected by method claims of certain U.S. Patents and other intellectual property rights owned by Macrovision Corporation and other rights owners.Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by macrovision Corporation. Reverse engineering or disassembly is prohibited.
SERIAL NUMBER:
You can find the serial number on the back of the unit.This number is unique to this unit and not available to others.You should record requested information here and retain this guide as a permanent record of your purchase.
Model No. ______________________________
Serial No. ______________________________
Date of Purchase_________________________
Before Use(Continued)
Introduction
To ensure proper use of this product, please read this owner's manual carefully and retain for future reference.
This manual provides information on the operation and maintenance of your DVD player. Should the unit require service, contact an authorized service location.
Symbol Used in this Manual
The lightning flash symbol alerts you to the presence of dangerous voltage within the product enclosure that may constitute a risk of electric shock.
The exclamation point alerts you to the presence of important operating and maintenance / servicing instructions.
Indicates hazards likely to cause harm to the unit itself or other material damage.
N Note:
Indicates special notes and operating features.
Tip:
Indicates tips and hints for making the task easier.A section whose title has one of the following symbols is applicable only to the disc represented by the symbol.
DVD DVD and finalized DVD+R/RW
VCD Video CDs
CD Audio CDs
WMA WMA Discs
JPEG JPEG Discs
About the Symbol Display
¡°¡±may appear on your TV display during operation and indicates that the function explained in this owner's manual is not available on that specific DVD video disc.
Notes on Discs Handling Discs
Do not touch the playback side of the disc. Hold the disc by the edges so that fingerprints do not get on the surface. Never stick paper or tape on the disc.
Storing Discs
After playing,store the disc in its case.Do not expose the disc to direct sunlight or source of heat and never leave it in a parked car exposed to direct sunlight.
Cleaning Discs
Fingerprints and dust on the disc can cause poor picture quality and sound distortion. Before playing,clean the disc with a clean cloth. Wipe the disc from the center out.
Do not use strong solvents such as alcohol,benzine,thinner, commercially available cleaners, or anti-static spray intended for older vinyl records.
2
Before Use (Continued)
Types of Playable Discs
_________________________________________
DVD
(8 cm / 12 cm disc)
_________________________________________
Video CD (VCD)
(8 cm / 12 cm disc)
_________________________________________
Audio CD
(8 cm / 12 cm disc)
_________________________________________
In addition, this unit plays , DVD -R, DVD +R,DVD -RW,DVD +RW, Kodak Picture CDs, SVCD, and CD-R / CD-RW that contains audio
titles,WMA and JPEG files.
_________________________________________
RW |
This indicates a product feature that is |
capable of playing DVD-RW discs |
|
C0MPATIBLE |
recorded with Video Recording format. |
Manufactured under license from Dolby Laboratories."Dolby", "Pro Logic", and the double-D symbol are trademarks of Dolby Laboratories.
Region code |
2 |
This DVD player is designed and manufactured for |
|
playback of region "2"encoded DVD software. |
This unit can play only DVD discs labeled "2" or "ALL".
N Notes on Region Codes
Most DVD discs have a globe with one or more numbers in it clearly visible on the cover. This number must match your DVD player's region code or the disc cannot play. If you try to play a DVD with
a different region code from your player,the message "Check region Code" appears on the TV screen.
N Notes:
1.Depending on the conditions of the recording equipment or the CD-R/RW (or DVD -R, DVD +R,DVD -RW, DVD +RW) disc itself, someCD-R/RW (or DVD -R, DVD +R, DVD -RW, DVD +RW) discs cannot be played on the unit.
2.Do not attach any seal or label to either side (the labeled side or the recorded side) of a disc.
3.Do not use irregularly shaped CDs (e.g., Heartshaped or octagonal)since they may result in malfunctions.
4.Some playback operations of DVDs and Video CDs may be intentionally programmed by software manufacturers. This unit plays DVDS and Video CDs according to disc content designed by the software manufacturer, therefore some playback features may not be available or other functions may be added.
Identification of Controls
Main Unit
|
1 |
2 |
2 |
|
3 |
|
4 |
|
5 |
|
6 |
|
7 |
|
8 |
|
9 |
|
10 |
|
11 |
|
12 |
|
13 |
|
14 |
|
15 |
17 |
16 |
1.LCD screen
2.Speakers
3. Mode
Select LCD size:16:9, 4:3 mode and set the LCD s brightness/contrast/hue.
4.Stop
5.Previous/Fast backward
6.Next/Fast forward
7.Play/Pause
8.Menu
9. (Left/right/up/down)
10.Enter
11.DC in
12.DC out
13.DC in 9V Jack
14.Headphone Jack
15.AV out
16.Volume knob
17.Power ON/OFF switch
3
Identification of Controls
Battery Pack
1
3
2
1
1.Power charge indicator during recharging , indicator is red.If recharging is complete, charge indicator changes to green.
2.Remote sensor.
3.Battery pack.
RELEASE
Indentification of Controls
Remote control unit
1. PLAY/PAUSE ( )
Starts playback or pause playback.
2. STOP ( ) |
11 |
Stops playback. |
3. Reverse Skip ( )
Go to previous chapter / track or to the beginning.
4. Forward Skip( )
Go to the next chapter / track.
5.ZOOM |
17 |
|
|
|
|
|
|
||
18 |
|
|
||
Enlarges video image. |
|
|
10
6.REPEAT
Repeat chapter, track, title all.
|
13 |
|
|
|
||
7.A B |
19 |
|
|
|
|
|
|
|
|
|
|
||
Repeat sequence. |
5 |
|
|
|
|
|
|
|
|
|
|
8. PROGRAM |
6 |
|
|
|
|
|
|
|
|||
Place a track on the program list. |
7 |
|
|
|
|
|
|
|
|
||
8 |
|
|
|
|
|
15 |
|
|
|
||
9. MUTE |
|
|
|
||
Disable Audio o utput. |
22 |
|
|
10.TITLE
Return to DVD title menu.
11.POWER
Switches DVD Player ON and OFF.
12.0-9 NUMBER BUTTON
Selects numbered items in a menu.
13.ENTER
Confirms menu selection.
2
Charge the battery pack before using it for the first time.
Attaching the battery pack
1.Match the hooks of the battery pack into the holes on the bottom of the player.
2.Combine the battery pack to push up until you can hear the click sound.
3
Detaching the battery pack to separate the battery pack,pull the switch which is locate beside the battery pack then slide down the battery pack at the same time.
9
12
21
20
24
16
1
2
25
14
4
3
23
MT-739
14.MENU
Accesses menu on a DVD disc. (Left/right/up/down)or set PBC on or off on a VCD disc.
15.DISPLAY
Accesses On-Screen display.
16.AUDIO
Selects an audio language (DVD).
17.SUBTITLE
Selects a subtitle language.
18.ANGLE
Selects a DVD camera angle if available
19.SETUP
Accesses or removes setup menu.
20.10+ BUTTON
Add 10+ while your selection is more than10.
21.STEP
Step the motion.
22. BUTTON
Fast backward.
23. BUTTON
Fast forward.
24. PBC
PBC on/off switch.
25.MODE
Set LCD parameter.
4
