PORTABLE DVD PLAYER
MT-705
SAFETY INFORMATION
TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.
: To reduce
CAUTION
the risk of fire and electric shock,
do not remove the cover (or back)
of the unit. Refer servicing only to
The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of uninsulated
"dangerous voltage" within product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operation and servicing
instructions in the literature accompanying the appliance.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF
PLUG TO WIDE SLOT, FULLY INSERT.
IMPORTANT SAFEGUARDS
In addition to the careful attention devoted to quality standards
in the manufacture of your video product, safety is a major factor
in the design of every instrument. However, safety is your
responsibility, too. This sheet lists important information that will
help to assure your enjoyment and proper use of the video
product and accessory equipment. Please read them carefully
before operation and using your video product.
Installation
Read and Follow Instructions- All the safety and operation instructions
1.
should be read before the video product is operated. Follow all operating
instructions.
2.
Retain Instructions- The safety and operating instructions should be retained
for future reference.
3.
Heed all Warnings-Comply with all warnings on the video product and in the
operating instructions.
4.
Polarization- This video product is equipped with a polarized alternating current line plug . This plug will fit into the power outlet, try reversing the
plug. If the plug still fails to fit, contact your electrician to replace your
obsolete outlet. To prevent electric shock, do not use this polarized plug
with an extension cord, receptacle, or other outlet unless the blades can be
fully inserted without blade exposure. If you need an extension cord, use a
polarized cord.
5.
Power Sources- This video product should be operated only from the type
of power source indicated on the marking label. If you are not sure of the
type of power supply to your home, consult your video dealer or local power
company. For video products intended to operate from battery power, or
other sources, refer to the operating instructions.
6.
Overloading- Do not overload wall outlets or extension cords as this can
result in a risk of fire or electric shock. Overloaded AC outlets, extension
cords, frayed power cords, damaged or cracked wire insulation, and
broken plugs are dangerous, They may result in a shock or fire hazard.
Periodically examine the cord, and if its appearance indicated damage or
deteriorated insulation, have it replaced by your service technician.
7.
Power-Cord Protection- Power-supply cords should be routed so that they
are not likely to be walked on or pinched by items placed upon or against
them, paying particular attention to cords at plugs, convenience receptacles,
and the point where they exit from the video product.
8.
Ventilation- Slots and openings in the case are provided for ventilation to
ensure reliable operation of the video product and to protect it from
overheating. These openings must not the blocked or covered. The openings
should never be blocked by placing the video product on a bed, sofa, rug, or
heat register. This video product should not be placed in a built-in installation
such as a book case or rack, unless proper ventilation is provided or the
video product manufacturer's instructions have been followed.
9.
Attachments- Do not use attachments unless recommended by the video
product manufacturer as they may cause hazards.
Water and Moisture- do not use this video product near water for example,
10.
near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement,
or near a swimming pool and the like. Caution: Maintain electrical safety.
Powerline operated equipment or accessories connected to this unit
should bear safety certification mark on the accessory itself and should not
be modified so as to defeat the safety features. This will help avoid any
qualified service personnel.
danger and should not be modified so as to defeat the safety features. This
will help avoid any potential hazard from electrical shock or fire. If in doubt,
contact qualified service personnel.
11.
Accessories- Do not place this video product on an unstable cart, stand,
tripod, bracket, or table. The video product may fall, causing serious injury
to a child or adult as well as serious damage to the video product. Use this
video product only with a cart, stand, tripod, bracket, or table recommended
by the manufacturer's or sold with the video product. Any mounting of the
product should follow the manufacturer's instructions and use of a mounting
accessory recommended by the manufacturer.
12.
A video product and cart combination should be moved with care. Quick
stops, excessive force, and uneven surfaces may cause the video product
and cart combination to overturn.
Note to CATV system installer
This reminder is provided to call the CATV system installer's attention to
Section 820-40 of the NEC which provides guidelines for proper grounding
and, in particular, specifies that the cable ground shall be connected to the
grounding system of the building, as close to the point of cable entry as
practical.
Outdoor Antenna Grounding- If an outside antenna or cable system is
13.
connected to the video product, be sure the antenna or cable system is
grounded so as to provide some protection against voltage surges and builtup static charges. Section 810 of the National Electrical Code, ANSI/NFPA
No.70-1984 (Section 54 of Canadian Electrical Code, Part1) provides
information with respect to proper grounding of the mast and supporting
structure, grounding of the lead-in wire to an antenna-discharge unit,
connection to grounding electrodes, and requirements for the grounding
electrode.
14.
Power Lines-An outside antenna system should not be located in the vicinity
of overhead power lines, other electric light or power circuits, or where it can
fall into such power lines or circuits. When installing an outside antenna
system, extreme care should be taken to keep from touching or approaching
such power lines or circuits, as contact with them might be fatal. Installing an
outdoor antenna can be hazardous and should be left to a professional
antenna installer.
Use
15.
Cleaning- Unplug this video product from the wall outlet before cleaning.Do
not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
16.
Objects that may touch dangerous voltage points or "short-out" parts could
result in a fire or electric shock. Never spill liquid of any kind on the video
product.
17.
Lightning-For added protection for this video product during a lightning storm,
or when it is left unattended and unused for long periods of time, unplug it
from the wall outlet and disconnect the antenna or cable system. This will
prevent damage to the video product due to lightning and power line surges.
Service
Servicing-Do not attempt to service this video product yourself, as opening
18.
or removing covers may expose you to dangerous voltage or other hazards.
Refer all servicing to qualified service personnel.
19.
Conditions requiring service-unplug this video product from the wall outlet,
refer servicing to qualified service personnel under the following conditions:
A. When the power-supply cord or plug is damaged.
B. If liquid has been spilled, or objects have fallen into the video product.
C. If the video product has been exposed to rain or water.
D. If the video does not operate normally by following the instruction manual..
Adjust only those controls that are covered by operating instructions.
Improper adjustment of other controls may result in damage and will
often require extensive work by a qualified technician to restore the
video product to its normal operation.
E. If the video product has been dropped or cabinet has been damaged.
F. When the video product exhibits a distinct change in performance-this
indicates a need for service.
20.
Replacement Parts-When replacement parts are required, have the service
technician verify that the replacements he uses have the same safety
characteristics as the original parts. Use of replacements specified by the
video product manufacturer can prevent fire, electric shock, or other hazards.
21.
Safety Check-Upon completion of any service or repairs to this video product,
ask the service technician to perform safety checks recommended by the
manufacturer to determine that the video product is in safe operating
condition.
Wall or Ceiling Mounting- The product should be mounted to a wall or ceiling
22.
only as recommended by the manufacturer.
Heat-The product should be situated away from heat sources such as
23.
radiators, heat registers, stoves, or other products (including amplifiers)
that products heat.
FEATURES
CONTENTS
DVD, CD, MP3 compatible
CD-R, CD-RW capable
TV format:
PAL / NTSC color system
4:3 / 16:9 screen format select
Video:
Video input / output
S-Video output
Component Video output
Audio :
Audio input/output
Down-mix stereo output
Digital audio output (coaxial)
Dolby Digital output
DVD features:
Multi Subtitle select
Multi Language select
Multi Angle se lect
Other features:
On screen display menu
Digital zooming
Slow motion
Parental control
Auto screen saver
JPEG picture view
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of
Dolby Laboratories. Confidential Unpublished Works.
C
1992-1997 Dolby Laboratories.
All rights reserved.
This product incorporates copyright protection technology that is
protected by method claims of certain U.S. patents and other
intellectual property rights owned by Macrovision Corporation and
other rights owners. Use of this copyright protection technology
must be authorized by Macrovision Corporation, and is intended for
home and other limited viewing uses only unless otherwise
authorized by Macrovision Corporation. Reverse engineering or
disassembly is prohibited.
SAFETY INFORMATION
FEATURES
CONTENTS
INTRODUCTION
About DVD
About MP3
About the player
DVD player panel
Right panel
Load the battery
Remote control
SYSTEM CONNECTION
System connection figure
GETTING STARTED
Play a disc
Problem disc message
Power management
ON SCREEN DISPLAY
DVD mode
CD mode
MP3 mode
FUNCTION BUTTONS
SETUP MENU
LANGUAGE
AUDIO SETUP
SCREEN SETUP
CUSTOM SETUP
TROUBLE SHOOTING
SPECIFICATIONS
Page
1-5
1-2
2
3-4
3
4
4
5
6
6
7-8
7
8
8
9-10
9
10
10
11-14
14-16
14-15
15
16
16
17-18
19
The player has built in copyright
protection technology that
prevents copying from a DVD
disc to any media.
If a video recorder is connected to
the player, the video output image
will be distorted during recording.
INTRODUCTION
About DVD
DVD (Digital Versatile Disc) is a digital video medium
under the MPEG II format, featuring a variety of
revolutionary entertainment capabilities. The MPEG II
video compression technology provides capacity for an
excellent picture of minimum 500 lines resolution on
screen, up to 8 language soundtracks, up to 9 views
from different camera angles and up to 32 language
subtitles (provided by the DVD disc itself which supports
these features).
Disc information
Disc types
Decoding
Method
Capacity
Disc size
Horizontal
Resolution
Sub-titles
Sound tracks
Symbol
DVD features symbols
Each DVD disc contains various features depending
on production of the disc. Below are some of the
symbols representing the features:
2
Number of Audio Tracks
2
Number of Subtitles
2
Angle Indicator
DVD
Digital / MPEG II
Single-layer / Single side
4.7GB = 2 hr
Single-layer / Double sides
8.5GB = 4 hr
Double-layers / Single side
9.4GB = 4.5 hr
Double-layers / Double sides
17GB = 8 hr
12cm / 8cm
500 lines up
32
8
16 : 9
++
650MB = 74min
12cm / 8cm
L B
Screen Format
Zoom
CD
Digital
Select a DVD disc
DVD Region Code
DVD discs and DVD players are manufactured
under the worldwide agreed DVD Regional
Code System that the player will operate only
with corresponding disc of the same Regional
Code.
Region code
-
-
1
Care of disc
Video disc contains high-density compressed data
that needs proper handling
Hold the disc with fingers. Hold the disc's outer
edge and/or the center spindle hole. Do not touch
the disc surface.
Do not bend or press the disc. Do NOT expose the
disc to direct sunlight or heating sources.
Region
1
Canada, USA
2
Europe (incl. Poland, Romania, The Czech
republic), Japan, Middle East (incl. Saudi
Arabia, Egypt, Iran, South Africa)
East Asia (incl. Hong Kong, Taiwan, South
3
Korea),
South-East Asia
Australia, Caribbean, Central & South
4
America, Mexico,
New Zealand
Africa, Former Soviet Union, India, North
5
Korea, Pakistan, Turkmenistan
China
6
The player has built in copyright
protection technology that
prevents copying from a DVD
disc to any media.
If a video recorder is connected to
the player, the video output image
will be distorted during recording.
Some features contained in this DVD player are related to
the DVD disc's software.
Some features cannot be performed if the disc does not
support the feature, or requires special settings.
Check the features printed on the disc's packing or follow
the instructions of the Disc's on screen menu.
REMARK
Store discs in cabinet vertically, in dry condition.
Prevent exposure to:
Direct sunlight
Heat or exhaust from a heating device.
Extreme humidity.
Clean the disc surface with a soft, dry cleaning cloth.
Wipe the disc surface gently, radically, from center
toward the outer edge.
Do not apply thinner, alcohol chemical solvent, or
sprays when cleaning. Such cleaning fluids will
permanently damage the disc surface.
1
INTRODUCTION
This player is compatible to the following
disc types:
single sided / double sided
DVD
single layered / double layered
CD-DA
CD-MP3
CD-R / CD-RW*
PICTURE CD
*NOTE: Some PC application files on CD-R or
CD-RW CANNOT be accepted by the unit,
e.g. CD-ROM under PC Windows, etc.
(CD-R / CD-RW writing format may be
different, some discs are not acceptable)
About MP3
MP3 (MPEG 1, Audio Layer 3) is a digital audio format
for quick downloading files that sound as good as CDs.
MP3 uses entropy encoding to reduce the number of
redundant sounds in an audio signal to a minimum. It
takes music from a CD and reduces it by a factor of 12,
with no noticeable loss of quality. On a normal CD of
74 minutes you can store over 130 songs.
Disc information
Sampling rate should be 44.1 kHz and bit rate is
recommended within the range from 128 Kbps to
256 Kbps, in order to achieve the best performance.
In general, higher quality settings result in larger
file sizes.
MP3 Format
Sampling rate
44.1 kHz
44.1 kHz
44.1 kHz
44.1 kHz
44.1 kHz
44.1 kHz
44.1 kHz
44.1 kHz
44.1 kHz
44.1 kHz
Bit rate
56 Kbps
64 Kbps
80 Kbps
96 Kbps
112 Kbps
128 Kbps
160 Kbps
192 Kbps
224 Kbps
256 Kbps
Quality
FM Radio Quality
Near CD Quality
Good CD Quality
Better than CD Quality
Studio Quality
No-play disc
The following discs are NOT acceptable
by the DVD player:
DVD disc with region code that does
not match the player's region code
(Check the disc's region code printed
on the disc packing. Region code "ALL"
will be acceptable by all players.)
Some DVD discs that were purchased
outside the application country
PC application on CD-R/CD-RW
CD-ROM for PC interface only
CD-MP3 under Windows format
MP3 CD-R/CD-RW of not proper format
(see "Tips for making a good MP3 CD" below)
Tips for making a good MP3 CD
Use good quality CD-RW disc, CD-R Gold Ultima
is recommended. Up to 650 MB (74-minute CD)
of MP3 files can be recorded.
Select a high quality CD Recorder (Writer).
HP CD-Write+9200 is recommended.
Select an advance CD burning software. Easy CD
Creator 4.0 or higher version is recommended.
MP3 is data and not WAV information as such
Mode 1 must be selected when compiling and
burning your discs.
Drag and drop (Direct CD) must not be used to
compile the disc. The player will not recognise
this format.
Only single session recordings can be used.
Multi session recordings are not recognized and
will not be played
Select Data CD Project (software user interface),
file system should comply with the standard of
ISO 9660 or Joliet. OR select MP3 CD Project for
convenience operation (available in Easy CD
Creator 5.0)
It is advised to " finalize " the CD after burnt.
2
3
INTRODUCTION
About the player
DVD player
4
1
2
3
5
6
1.Open
2.TFT LCD Screen
3.Speakers
4.Disc tray
5.Open button(disc tray)
6.Remote control Sensor
7.Play/pause button
OPEN
V
O
L-
E
N
T
E
R
V
O
L+
M
OD
E
M
E
N
U
S
T
O
P
13
12
11
10
9
8
7
8.Previous/Next, Fast Forward/Backward
9.stop button
10.Menu button
11.Mode button
12.Enter button
13.Directions/volume button
3
Up and right panel of the player
INTRODUCTION
DC IN 12V
POWER
ON OFF
3 2 1
INPUT OUTPUT
VIDEO
4
YUV
5
S-VIDEO
6
AUDIO
IN/OUT
7
COAXIAL
9 8
VOLUME
1.Power input
2.Power ON/OFF
3.Video input/output button
4.Composit video output
5.YUV S-Video
Load the battery
Note:
Put the battery under the
player, aim the three grooves
and push down as the
diagram shows. When
unloading, press push to the
opposite direction.
6.Audio input/output
7.Coaxial digital audio
7.Headphone output
8.Volume +/-
1
Push
2
Battery
4
INTRODUCTION
Remote control surface
Mute
PAL/NTSC
LCD
LCD ON/OFF
Title
Subtitle
Angle
ON/OFF
TITLE
SUBTITLE
ANGLE
MUTE
1 2
4
7
Search
SEARCH
Audio
Menu
AUDIO
MENU
10+ 0
CLEAR
Enter
Direction, volume + / -
Mode
Scan mode
ENTER
VOL- VOL+
MODE
PS/IS
Play/Pause
Previous/Next,
Fast Forward/Backward
Stop
Notes
The remote control transmits a directional infrared beam. Be sure to aim the
remote control directly at the infrared sensor during operation. When the
sensor is covered or there is a large object between the remote control and
the sensor, the sensor cannot receive signals. The sensor may not be able
to receive signals properly when it is exposed to direct sunlight or a strong
artificial light (such as a fluorescent or strobe light). In this case, change
the direction of the light or reposition the unit to avoid direct lighting.
P/N
5
8 9
PBC
A-B
DISPLAY
3
6
RETURN
SETUP
PROG
SLOWSTEP
ZOOM
REPEAT
Display
Number keys
Clear
Return
Setup
Playback control
Program
Step
Slow
Zoom
Segment repeat select
Repeat
5
RE
E
C.
C
M
R
U
O
O
D
S
POWER
S-VIDEO
DV IN
VIDEO L R
TM
Connecting to other DVD players which has
L/R Audio Output & Video Output (RCA).
E
VOL+
VOL-
RECORD
C
H
+
H
-
C
STANDBY
DVD/TV
Connecting to the
headphone
Connect to the coaxial
with optical output
(optional)
VOLUME
Audio output
COAXIAL
AUDIO
IN/OUT
S-VIDEO
Video output
YUV
VIDEO
INPUT OUTPUT
Video input
POWER
ON OFF
DC IN 12V
Connecting to the
power supply
Audio input
To Coaxial input
L
Center
SL
R
C
SR
6
Unpack the unit.
Read through this owner`s manual before
installation and use.
Load batteries into the remote control unit.
Connect the system, make sure the connectons are secured.
Connect the power plug to the AC power outlet.
Loading batteries to the remote control
Remove the battery compartment cover.
Load two AAA (UM-4 or R03) batteries into the
battery compartment.
Make sure that the batteries have been inserted
in the correct polarities matching to the symbols+, marked in the battery compartment. Close the
battery compartment cover.
When replacing batteries, replace both batteries.
Do not mix new and used batteries operating
together, otherwise, the operation lifetime will be
much shorter than normal.
Remove the batteries if the unit will not be used for
a prolonged period of time.
GETTING STARTED
Switch on the player
Press the main power switch on the DVD player.
Power on the TV set, and the amplifier if connected.
Set up the system
Select the corresponding setting of the TV set
(AV1, AV2, S-Video, DVD etc.).
For R F modulator connection, select the
corresponding turned channel until the DVD
screen appears.
If amplifier has been connected, select the corr esponding output mode.
Load a disc
Press OPEN button to eject the disc tray.
Load a disc, label side up, onto the disc tray.
Automatic playback
The unit will take a few seconds to load the disc`s
initial data, display the disc type logo on the left
upper corner on screen, and then start playing back
automatically.
Normally, when a MP3 disc is loaded, the player
E
will take longer time to load.
If a DVD disc menu appears on screen
Press PLAY button on the remote
(or on the unit)to start playing.
+
The remote control transmits a directional infrared beam. Be sure to aim the remote control
directly at the infrared sensor of the unit during
operation.
If the sensor has been covered or there is a large object between the remote control and the sensor, the sensor will not respond.
The sensor may not able to receive the remote
signal when it is exposed to direct sunlight or
a strong artificial light (fluorescent or strobe
light). In this case, change the direction of the
light or reposition the unit to avoid direct lighting.
VOL- VOL+
7
ENTER
Press the ARROW buttons to select
the desired feature in the menu.
And then press ENTER button to
confirm a selection in the menu.
Remote
sensor
Within approximately
6 meter (20 feet)
0
0
30
30
1
2
3
4
5
6
7
8
9
GETTING STARTED
Problem disc messages
The following message will display on screen when there is a format problem with the loaded disc:
WRONG REGIONAL DISC
Region code of the disc is not matching to the player`s region code (region 1 to region 6).
WRONG PASSWORD
The rating level of the disc is higher then the rating level setting of the player.
The player will not play the disc.
WRONG DISC
The player is equipped with automatic disc quality detection software. When the player
detects a problem disc or a damaged disc, the player may keep playing the disc at lower
quality or stop playing, depending on the damaged level of the disc.
Production qualities of DVD discs vary, some discs might deviate from the industrial
standard. Some incorrectly formatted discs may playback on the player. However,
the playback and operational quality of those disc may be substandard.
DTS DISC
For DTS digital audio stream only
No analog audio output.
Make sure you select Dolby 5.1 or 2 channel down mix instead of DTS setting .
Connect the digital audio output (coaxial) to a digital amplifier, in order to enjoy DTS audio
system.
This player does not have a DTS decoder bulti-in. It may
result in no analog audio output if you select DTS sound
output.
Power management
If the player will not be in use for a long time, unplug the player for personal safety.
8
An On Screen Display ( OSD ) indicator will be displayed at the upper part of the TV screen when certain
functions are executed, or when pressing the DISPLAY button on the remote control.
The OSD indicator is a user friendly interface designed to display the status of playback type. When a
different disc is loaded ( DVD, CD, MP3) ; the OSD indicator bar will be different.
The OSD bar will appear automatically if it is activated by pressing the
DISPLAY button. Press the DISPLAY button again and a new status bar
will appear. Press DISPLAY button a third time and the OSD bar will disappear. When OSD indicator bar appears, press other button, the OSD
indicator bar will disappear automatically.
DVD mode - OSD
1
00 : 02 :30
:1/2
current title
Disc Title
current chapter
Chapter
: 3/10
Playback time
Disc Title
Disc Subtitle
Audio format
Chapter
Playback time
2
: 1 /3
:
AC3 2CH
Off
TV-System
INTERLACE
PAL
: 1 / 30
: English-1/1
Scan mode
00:02:30
Play status
Multi-Audio
:
Multi-angle
9
CD mode - OSD
Current track
Disc Track
MP3 mode - OSD
Track : 3/15 00:02:30
Playback time
Directory
structure
ROOT
MP3 01
Mp3 02
MP3 03
Program
Press key to button
10
107
108
109
110
111
112
Thumbnail
7
8
9
10
11
12
Current track
FUNCTION BUTTONS
DISPLAY
Press DISPLAY button.
To show the time and status information.
Play/Pause/Stop
Press PLAY button to play the disc.
Press PAUSE button twice to pause
(still picture).
Press PLAY button to resume normal
Playback again.
Press STOP button to stop in two modes.
a) Press the STOP button once and the STOP
function memorizes the position. The
OSD will show Prestop . Press the PLAY
button to resume playback.
b) Press the STOP button twice to completely
Stop disc.the OSD shows STOP .
Pressing PLAY will start the disc from
the beginning.
Skip Forward / Backward
Press button skip advance DVD
chapter or CD track.
Press button skip backward DVD
chapter or CD track.
E
Player will not skip forward or backward during
WARNING section of a DVD disc.
Single chapter DVD or single track CD cannot
skip.
E
The player is muted in
fast backward
fast forward or
this mode.
Player will not fast forward or fast backward
during WARNING section of a DVD disc.
LCD display settings
During playback, press the "MODE"
MODE
button to trigger the following menu
for LCD display settings:
RESET
Select to adjust Brightness, Contrast,
or Color by repeatedly pressing the
MODE
buttons. Use key to
increase or decrease the value. The
menu will disappear automatically
after settings complete.
The player is muted in SLOW mode.
Press SLOW button to play at slow
SLOW
motion. Repeatedly pressing the
button will decrease the slow speed.
Normal
Fast forward/
backward
Press button to fast forward
through the disc. Repeatedly pressing
the button;
Normal
Press button to fast backward
through the disc. Repeatedly pressing
the button will increase the search speed.
Normal
Press PLAY button to resume normal
playback.
DISC TITLE / MENU
MENU
TITLE
E
11
While playing a DVD.
Press the MENU button return to
the DVD disc start menu.
Press PLAY button to resume play
from where you previously stopped
it.
While playing a DVD, press the
TITLE button return to the beginning
of the DVD disc.
Some DVD disc refuse the TITLE function.
FUNCTION BUTTON
Select an item in menu
In a DVD disc start menu or in the palyer`s setup menu.
ENTER
VOL- VOL+
ENTER
Press DIRECTION button to
highlight function icons.
Press ENTER button to confirm a
selection.
CLEAR
RETURN
Press CLEAR button to cancel an
entry.
Press RETURN button returning
to the upper level menu.
Numeric Key Pad
(Random Program access)
1
2
4
5
7
8
10+
E
Some DVD disc`s do not allow direct
To direct access a DVD Chapter
3
or a CD track, input the desired
6
DVD Chapter or CD Track number
using the numeric key pad.
9
0
Input data for the DVD disc start
menu or the player`s setup menu.
access function.
ENTER
Press ENTER button to execute the search.
E
Some DVD discs and MP3 disc do not allow
Search function. Search does not function during program play.
Repeat section A-B
To repeat playback a specific section of a disc.
Press the A-B button at the starting point
A-B
of the desired section. A display
on screen.
Press the A-B button again, at the end of
A-B
the desired section, A-B will display
on the screen. The play will start repeat
playback of the desired section A to B until
the function is cancelled.
To cancel the function. Press the A-B
A-B
button again return to normal play.
E
Some DVD discs do not allow A-B function.
Repeat A-B do not apply to MP3 disc.
MUTE
Press MUTE button to select mute
on or mute off.
Search a desired section
To search for a desired Title, Chapter, Time or Track.
In DVD mode
SEARCH
pressing the SEARCH button once appear
Current title
X/X
Total title
pressing the SEARCH button twice appear
X/X
Current title
Total title
X/XX
Curren chapter
XX : XX :XX
Hour
Second
Minute
Total chapter
Repeat
Repeatedly playback desired Title, Chapter or Track.
Press REPEAT button repeatedly to select
REPEAT
the repeat mode .
In DVD mode
REP.CHAPTER
REP.TITLE
REP.DISC
REP.OFF
Repeat chapter
Repeat title
Repeat all disc
Repeat off
In CD mode
REP.TRK
REP.DISC
REP.OFF
Repeat track
Repeat disc
Repeat off
In Mp3 mode
REP.TRK
REP.DISC
REP.OFF
E
Repeat track
Repeat disc
Repeat off
Some DVD disc`s do not allow REPEAT function.
12
Multi - Angle / Subtitle / Audio
While playing a DVD disc
ANGLE
Press ANGLE button repeatedly to select
the desired camera angle. A DVD disc may
contain up to 9 selectable camera angles.
While playing a DVD disc. Press SUBTITLE
button repeatedly to select the desired
SUBTITLE
subtitle. A DVD disc may contains up to 32
selectable subtitles.
While playing a DVD disc, Press AUDIO
AUDIO
button repeatedly to select the desired
audio sound track. A DVD disc may contains
up to 8 selectable audio sound tracks.
E
DVD disc start menu may contains set up of
Angle, Subtitle and Audio soundtrack selection.
You may do the selection in the disc start menu.
FUNCTION BUTTON
Press the SETUP button to enter the
SETUP
player`s setup menu.
Setup menu is a facility for the owner
to adjust the detail setting of the player.
For the detail of Setup menu see SET
UP MENU of this instruction manual.
PROGRAM
To program play a disc in a desired sequence.
PROG
1
2
4
5
7
8
10+
ENTER
In PBC off mode, Press PROG button,
to enter the program menu.
3
In DVD mode
6
When the program menu appears
9
push the Title button , press ENTER.
0
Then input title Chapter number,
press ENTER button. When the programming is complected.
Volume Up / Down
While playback a disc.
VOL+
Press the VOLUME button- or +
to adjust the volume output.
VOL-
Volume level will display on screen.
VOLUME 16
The Volume level control does not apply to
digital audio output level when a DVD
disc is playing.
PLAY DVD
Press the ZOOM button repeatedly
ZOOM
TV Screen display:
ZOOM X2--> ZOOMX 4--> ZOOM OFF
PLAY JPEG
Press the ZOOM button repeatedly
TV Screen display scale:
25%-->50%-->100%-->150%-->200%
While zoom 100%, press direction button
to rotate picture.
While zoom 150%.200%,press direction
button to move picture position.
E
The picture quality is degraded as the
picture size is increased.
13
CLEAR
PROG
ENTER
(PLAY) --- Press PLAY button to start
program play.
(CLEAR) --- Press CLEAR button if you
want to cancel the wrong information
you input. Press CLEAR again to cancel
all the tracks.
(PROG) --- Press PROG button to quit
the program menu.
PROGRAM
1.
2.
3.
4.
5.
:Select
Chapter
Title
01
02
03
04
05
:Play
01
02
03
04
05
In CD mode
When the program menu appears, input
the Track number, press ENTER , when
the programming is completed.
FUNCTION BUTTON
(PLAY) --- Press PLAY button to start program
play.
(STOP) --- Press the STOP button to quit
the program mode.
(CLEAR) --- Press CLEAR button if you want to
CLEAR
cancel the wrong information you input
before or cancel the desired track. Press
CLEAR again to cancel all the tracks.
twice
B
A
C
Language Setup
OSD
Menu
Audio
Subtitle
: Move :select SETUP:Quit
PROGRAM
1. 02
2.
3.
4.
5.
:Select
:Play
Track
01
02
03
04
05
E
Some DVD disc do not allow program
setting. Single track disc cannot be
programmed, MP3 disc cannot be programmed.
SETUP MENU
Various features of the player can be adjusted in the
SETUP menu:
1 Press SETUP button
SETUP menu appears.
2 Press the UP/DOWN button
to highlight the desired menu.
SETUP
E
Do not move any bar to select item, please
make sure the mode is in stop mode.
LANGUAGE MENU
In STOP mode, press SETUP button
SETUP
Highlight LANGUAGE.
Press UP/DOWN button
Press ENTER button , the screen displays submenu.
Press UP/DOWN button to highlight
the desired
item in the LANGUAGE.
Menu
ENTER
ENTER
Press to confirm your selected item.
OSD ENGLISH
FRENCH
GERMAN
ITALIAN
SPANISH
Select the players OSD .
ENTER
Press to confirm the selection.
Press SETUP button to quit.
Default setting
SETUP
ENGLISH
MENU
VOL- VOL+
MODE
CLEAR
ENTER
RETURN
B
A
C
SETUP
PBC
PROG
1
Language Setup
OSD
Menu
Audio
Subtitle
: Move :select SETUP:Quit
English
French
German
Italian
Spanish
14
LANGUAGE MENU (continued)
English
Chinese
Japanese
French
German
Italian
Spanish
Dutch
Portuguese
Indian
Hindi
Thai
Korean
Others
Select the disc language setting.
ENTER
Press to confirm the selection.
Press SETUP button to quit.
Default setting ENGLISH
B
A
C
Language Setup
OSD
Menu
Audio
Subtitle
SETUP
English
Chinese
Japanese
French
German
Italian
SETUP MENU (Press SETUP button)
SUBTITLE
Select the disc subtitle setting.
ENTER
Press to confirm the selection.
Press SETUP button to quit.
Default setting OFF
B
A
C
Language Setup
OSD
Menu
Audio
Subtitle
English
Chinese
Japanese
French
German
Italian
Spanish
Dutch
Portuguese
Indian
Hindi
Thai
Korean
Others
Off
SETUP
INDIAN
THAI
RUSSIAN
KOREAN
OTHERS
OFF
: Move :select SETUP:Quit
Select the disc audio setting.
ENTER
Press to confirm the selection.
Press SETUP button to quit.
Default setting ENGLISH
B
A
C
Language Setup
OSD
Menu
Audio
Subtitle
: Move :select SETUP:Quit
SETUP
English
Chinese
Japanese
French
German
Italian
Spanish
Dutch
Portuguese
Indian
Hindi
Thai
Korean
Others
English
Chinese
Japanese
French
German
Italian
15
: Move :select SETUP:Quit
AUDIO SETUP
In STOP mode. Press SETUP button
highlight AUDIO SETUP.
ENTER
Press to enter next sub-menu.
OUTPUT
B
A
C
Audio Setup
Digital Out
: Move :select SETUP:Quit
ENTER
Press to confirm the selection,or
Press SETUP button to quit.
Default setting SPDIF/RAW
E
When digital output is NOT in use, it is recommended to turn. OFF the digital out
put setting for the purpose on minimizing
circuit interference.
SETUP
SPDIF/PCM
SPDIF/RAW
OFF
SETUP
SETUP MENU (Press SETUP button)
SCREEN MENU
In STOP mode, press SETUP button
SETUP
highlight SCREEN SETUP.
Press UP/DOWN button to highlight
the desired item in the SCREEN menu.
ENTER
Press to confirm the selection.
B
A
C
Screen Setup
TV Type
TV System
Video Output
Brightness
Contrast
: Move :select SETUP:Quit
Adjust TV screen viewable format
TV TYPE
4:3 PS (Pan Scan)
4:3 LB (Letter Box)
16:9 (Wide Screen)
Default setting 4:3 PS
TV SYSTEM
NTSC
PAL
AUTO
Default setting PAL
VIDEO OUT
Default setting NORMAL
BRIGHTNESS
NORMAL
Y Cb Cr
NORMAL
BRIGHT
SOFT
Default setting NORMAL
CONTRAST
-4
-3
-2
-1
0
1
2
3
4
Default setting 0
E
1. Certain DVD disc are formatted in wide screen (16:9) or letter box
(4:3)only. Adjusting the setting of the disc player will not alter the
screen size for these Format-only discs.
2. The PS/IS Button on remote control ,in normal status uneffect.
3. If the TV without Y Cb Cr function,please do not set from normal
to Y Cb Cr
CUSTOM SETUP
After entering the main menu, choose and confirm
CUSTOM setup and then the following window
will appear on the TV screen.
B
A
C
Custom Setup
Parental Ctrl
Password
Angle Mark
Detault
: Move :select SETUP:Quit
4: PG13
5
6: R
7: NC17
8
A) Parental Ctrl
There are total eight levels of this control 8 levels
as follow:
1.G;2.;3.PG;4.PG13;5.;
6.R;7.NC17;8.;
The first level discs are open to people of ever age
eight is
and level only suitable for an adult. If you
want to change the Parental ctrl setting, enter
the user`s age control item and then enter four
digital secret code. The default secret code is 8888
(if you are using this player for the first time, just
input this code.) If the input code has been confirm
ed, the level setting up menu will appear. Move the
cursor to choose the expected level and press ENTER
button to confirm and memory it. Move the cursor
to the ENTER and press ENTER button to confirm
and withdraw to the User setup menu or press
setup button to directly withdraw form the operation.
B) PASSWORD
Move the cursor to the PASSWORD
item and press ENTER button to confirm and then input
the secret code 8888 (if it is the first use). After
confirmation, you are required to input new secret
code and then press ENTER button to confirm. And re
treat to the Custom setup interface.
Warning: Please remember the new secret code,
otherwise you will not be able to change the Parental
Ctrl.
C) ANGLE MARK there is an ON and OFF
choice for this item. If in the ON mode, when
playing a disc with a multi-angle shot, you may press
the ANGLE button on the remote control to enjoy the
scene in different angles.
D) DEFAULT ,this is the factory default setting
up. When you choose Read ,the previous setup
by the user will be cancelled and the player will
come to the factory setting up state.
16
Should your DVD player develop a problem, please check below before
requesting service:
Symptom
No Power
Does not play
No Picture
noise / distorted
Picture not full
screen
Check and Action
Check if the power cord has been properly connected to the power outlet.
Check if the main power has been switched on.
No disc, load a disc.
Disc has been loaded upside down. Place the disc with the label side up.
Disc's region code does not match to the player.
Disc's rating level is higher than the player's rating level setting
Disc is not correct type for the player.
Disc is damaged or dirty, clean the disc or try another disc.
Moisture may be condensed inside the player. Remove the disc and
leave the unit power on for one or two hours.
Check if the TV set has power on, use TV remote to select A/V signal for
DVD rather than broadcast.
Check if the system connection is proper and secure.
Check if the connection cables are damaged.
Clean the disc.
Please press OPEN button, then press PROGRAM and ZOOM button to
return to factory default status.
The disc is dirty or damaged. Clean the disc or try another disc.
Reset the color system of the TV set.
Try to connect the player directly to the TV set without using a VCR.
Select the screen format from the player's SETUP MENU,
see "SETUP MENU" of this manual.
Select the screen format from DVD disc menu.
Problem
message display
on screen
Malfunction
Following message will display when there is a problem with the loaded disc:
"WRONG REGIONAL DISC " : Disc's region code dose not match to the player.
"WRONG PASSWORD" : The player refuse to play a disc with rating
level higher than the player's rating level setting.
"WRONG DISC " : The player is equipped with automatic disc
quality detection software. When the player detects a problem disc or a
damaged disc, the player may keep playing the disc at lower quality or
stop playing, depending on the damage level of the disc.
Press and hold the standby button (if any) for about 5 second to power off.
Should the player develop a malfunction, unplug the player for
30 minutes. After 30 minutes, power on the player and the restore
function should reset the player.
17
TROUBLE SHOOTING
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Symptom Check and Action
Cannot SKIP
or SEARCH
No sound or
sound output
not complete
MP3 disc no
sound or noisy
Remote control
does not function
CAUTION : To reduce the risk of fire and electric
shock, do not remove the cover (or back) of the unit. Refer
servicing only to qualified service personnel.
Some discs are programmed that do not allow users to SKIP or SEARCH
at some sections, especially at the beginning WARNING section.
Single Chapter disc cannot apply SKIP function.
Check if the TV and Amplifier have been switched on, and correctly set.
Check if the TV and Amplifier system connection is secured.
Press AUDIO button to select other audio tracks output of disc.
Check if the MUTE function of the TV or Amplifier has been activated.
There will be no sound output during REVERSE PLAY / PAUSE / STEP /
SLOW and SEARCH.
When PC program files or other data files are mixed with
MP3 files in the same disc, the player may play the non-MP3
files with noise or no sound.
Check the disc, if all the files on disc are MP3 files
Skip the file, try other files.
Remove the obstacles between the remote control and the player.
Point the remote control towards the remote sensor on the player.
Check if the batteries of the remote control have been loaded with
correct polarities.
Replace the batteries of the remote control.
Type of Disc
DVD
CD-DA
CD-MP3
CD-R / CD-RW
18
Video(composite) outputx1
S-Video output x1
Component Video output
Down Mix Stereo output(Left and Right)x1
Digital Audio(coaxial) outputx1
SPECIFICATIONS
Accessories
AC 100-240V/DC 12V 2.0A
Body size: 206x155x35mm
Packing size: 375x85x238mm
Net weight: 0.9kg
Video/Audio Cord 1
Audio Cord 3
S-Video Cord 1
Adaptor 1
Battery 1
Remote Control 1
User Manual 1
Earphone (for option)
Earphone commutator (for option)
Car Cigarette Adaptor (for option)
19
Loading...
