Denon AVR-4310 CI Service Manual

D&M Holdings lnc.

e

WARNING: Violators will be prosecuted to the maximum extent possible.

s

d

Ver. 6

●

For purposes of improvement, specifications and design are subject to change without notice.

●

Please use this service manual with referring to the operating instructions without fail.

●

Some illustrations using in this service manual are slightly different from the actual set.

Please refer to the MODIFICATION NOTICE.

SERVICE MANUAL

MODEL JP EU EC E2 EK E2A E1C EUT

AVR-4310CI

AVR-4310

MODEL JP EU EC E2 EK E2A E1C EUT

AVC-4310

33

3

AV SURROUND RECEIVER

3

AV SURROUND AMPLIFIER

S0025-1V06DM/DG0912

SAFETY PRECAUTIONS

The following check should be performed for the continued protection of the customer and service technician.

LEAKAGE CURRENT CHECK

Before returning the unit to the customer, make sure you make either (1) a leakage current check or (2) a line to chassis resistance check. If the leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either side of the power cord is less than 460 kohms, the unit is defective.

CAUTION

Please heed the points listed below during servicing and inspection.

◎ Heed the cautions!

Spots requiring particular attention when servicing, such as the cabinet, parts, chassis, etc., have cautions indicated on labels or seals. Be sure to heed these cautions and the cautions indicated in the handling instructions.

◎ Caution concerning electric shock!

(1) An AC voltage is impressed on this set, so touching in-

ternal metal parts when the set is energized could cause electric shock. Take care to avoid electric shock, by for example using an isolating transformer and gloves when servicing while the set is energized, unplugging the power cord when replacing parts, etc.

(2)There are high voltage parts inside. Handle with extra

care when the set is energized.

◎ Caution concerning disassembly and

assembly!

Though great care is taken when manufacturing parts from sheet metal, there may in some rare cases be burrs on the edges of parts which could cause injury if fingers are moved across them. Use gloves to protect your hands.

◎ Inspect for safety after servicing!

Check that all screws, parts and wires removed or disconnected for servicing have been put back in their original positions, inspect that no parts around the area that has been serviced have been negatively affected, conduct an insulation check on the external metal connectors and between the blades of the power plug, and otherwise check that safety is ensured.

(Insulation check procedure) Unplug the power cord from the power outlet, disconnect the antenna, plugs, etc., and turn the power switch on. Using a 500V insulation resistance tester, check that the insulation resistance between the terminals of the power plug and the externally exposed metal parts (antenna terminal, headphones terminal, microphone terminal, input terminal, etc.) is 1MΩ or greater. If it is less, the set must be inspected and repaired.

CAUTION

Concerning important safety

parts

◎ Only use designated parts!

The set's parts have specific safety properties (fire resistance, voltage resistance, etc.). For replacement parts, be sure to use parts which have the same properties. In particular, for the important safety parts that are marked z on wiring diagrams and parts lists, be sure to use the designated parts.

◎ Be sure to mount parts and arrange

the wires as they were originally!

For safety reasons, some parts use tape, tubes or other insulating materials, and some parts are mounted away from the surface of printed circuit boards. Care is also taken with the positions of the wires inside and clamps are used to keep wires away from heating and high voltage parts, so be sure to set everything back as it was originally.

Many of the electric and structural parts used in the set have special safety properties. In most cases these properties are difficult to distinguish by sight, and using replacement parts with higher ratings (rated power and withstand voltage) does not necessarily guarantee that safety performance will be preserved. Parts with safety properties are indicated as shown below on the wiring diagrams and parts lists is this service manual. Be sure to replace them with parts with the designated part number.

(1) Schematic diagrams ... Indicated by the z mark. (2) Parts lists ... Indicated by the z mark.

Using parts other than the designated parts could result in electric shock, fires or other dangerous situations.

2

AVR-4310CI/AVR-4310/AVC-4310

DIMENSION

344

434

155

15.5

170.5

20.7

244.5

372.8

20.5

414

54.7

AVR-4310CI/AVR-4310/AVC-4310

3

AVR-4310CI/AVR-4310/AVC-4310

WIRE ARRANGEMENT

If wire bundles are untied or moved to perform adjustment or parts replacement etc., be sure to rearrange them neatly as they were originally bundled or placed afterward. Otherwise, incorrect arrangement can be a cause of noise generation.

Wire arrangement viewed from the top

Front Panel side

Back Panel side

4

AVR-4310CI/AVR-4310/AVC-4310

CAUTION IN SERVICING

BeforetheDigitalP.W.B.arereplaced

If you cannot specify the cause of the digital PWB defect, carry out "Initializing" → "Update to latest firmware". The defect may be cleared.

・See the following for the method of initializing the μcom.

Initializing AV SURROUND RECEIVER

AV SURROUND RECEIVER initialization should be performed when the µcom, peripheral parts of µcom, and Digital P.W.B. are replaced.

1. Switch off the unit.

2. Hold the following STANDARD button and DSP SIMULATION button, and switch on the unit.

3. Check that the entire display is flashing with an interval of about 1 second, and release your fingers from the 2 buttons and the microprocessor will be initialized.

Note:・If step 3 does not work, start over from step 1.

・ All user settings will be lost and this factory setting will be recovered when this initialization mode.

So make sure to memorize your setting for restoring after the initialization.

1,2 2,3

JIG to use for servicing

When you repair the printing board, you can use the following JIG. Please order to Denon Official Service Distributor in your region if necessary.

Extention cable kit

00D SPK- 561 EXTENSION UNIT KIT : 1 Set 00D SPK- 562 TUCP CONN. JOINT KIT : 1 Set

Extention cable for Idling Current

Parts Number for Extension Cables and Quantity of Unit.

Parts Number Parts Name Q'ty / unit Remarks

612050082004D 6P 250mm NH 1 L=250mm 6P NH Cable 612050083007D 8P 250mm NH 1 L=250mm 8P NH Cable

How to use and Adjust Idle Current.

1. The thin and hard plate (ex. Ruler) is fixed with the tape behind the cable.

2. The voltmeter is connected with the other side of the extension cable.

3. Refer to ADJUSTMENT(Idling Current).

5

AVR-4310CI/AVR-4310/AVC-4310

DISASSEMBLY

• Disassemble in order of the arrow of the figure of following flow.

• In the case of the re-assembling, assemble it in order of the reverse of the following flow.

• In the case of the re-assembling, observe "attention of assembling" it.

TOP COVER

BACK PANEL UNIT ASSY FRONT PANEL UNIT ASSY

Refer to "DISASSEMBLY

2. BACKPANEL UNIT ASSY" Refer to "DISASSEMBLY 1.FRONT PANEL UNIT ASSY"

DIGITAL UNIT ASSY

Refer to "DISASSEMBLY (Ref. No. of EXPLODED VIEW : B-4) (Ref. No. of EXPLODED VIEW : E-4)

3. DIGITAL UNIT ASSY" REG CONNECT-1 UNIT FRONT USB UNIT

and "EXPLODED VIEW" (Ref. No. of EXPLODED VIEW : A-15) (Ref. No. of EXPLODED VIEW : E-3)

DIGITAL UNIT CONNECT UNIT-2 MIC UNIT

(Ref. No. of EXPLODED VIEW : G) (Ref. No. of EXPLODED VIEW : D-4) (Ref. No. of EXPLODED VIEW : A-9)

REG UNIT FRONT HDMI UNIT

A.VIDEO UNIT, AUDIO UNIT AMP UNIT

and RADIATOR UNIT ASSY

Refer to "DISASSEMBLY 6. AMP UNIT" VOLUME UNIT

4. A.VIDEO UNIT, AUDIO UNIT and "EXPLODED VIEW" (Ref. No. of EXPLODED VIEW : A-4)

and RADIATOR UNIT ASSY" AMP UNIT FUNC CONNECT UNIT

and "EXPLODED VIEW" (Ref. No. of EXPLODED VIEW : D-1) (Ref. No. of EXPLODED VIEW : A-7)

A.VIDEO UNIT FUNC UNIT

(Ref. No. of EXPLODED VIEW : E-1) (Ref. No. of EXPLODED VIEW : A-6)

AUDIO UNIT

(Ref. No. of EXPLODED VIEW : E-2) Refer to "DISASSEMBLY (Ref. No. of EXPLODED VIEW : A-1)

MAIN CPU UNIT 7. P.AMP JOINT UNIT"

(Ref. No. of EXPLODED VIEW : F) and "EXPLODED VIEW"

REMOTE/IPOD UNIT P.AMP JOINT UNIT

(Ref. No. of EXPLODED VIEW : B-5) (Ref. No. of EXPLODED VIEW : D-2)

232C UNIT

(Ref. No. of EXPLODED VIEW : B-6)

REG UNIT

5. REG UNIT" P.SW UNIT

and "EXPLODED VIEW" (Ref. No. of EXPLODED VIEW : A-8)

FRONT IN UNIT

(Ref. No. of EXPLODED VIEW : A-10)

VR CONNECT UNIT

Refer to "DISASSEMBLY (Ref. No. of EXPLODED VIEW : A-5)

P.AMP JOINT UNIT

FLD UNIT

P.AMP UNIT

Refer to "DISASSEMBLY

9.P.AMP UNIT"

and "EXPLODED VIEW"

P.AMP UNIT

(Ref. No. of EXPLODED VIEW : D-1〜7)

Refer to "DISASSEMBLY

6

AVR-4310CI/AVR-4310/AVC-4310

About the photos used for descriptions in the “DISASSEMBLY” section.

• The direction from which the photographs used herein were photographed is indicated at "Direction of photograph: ***" at

the left of the respective photographs.

• Refer to the table below for a description of the direction in which the photos were taken.

• Photographs for which no direction is indicated were taken from above the product.

The viewpoint of each photograph (Photografy direction)

［View from above］

Direction of photograph: C

Direction of photograph: B

Front side

Direction of photograph: D

Direction of photograph: A

1. FRONT PANEL UNIT ASSY

Proceeding : TOP COVER →

(1) Remove the screws.

View from bottom

(2) Cut the wire clampers then disconnect the connector wires.

CX021

Direction of photograph: D

FRONT PANEL UNIT ASSY

cut

CY062

cut

7

AVR-4310CI/AVR-4310/AVC-4310

(3) Remove the FFC cover and acetate tapes. Disconnect the FFC Cables.

FFC Cable

Direction of photograph: C

Acetate tape

(4) Remove the screws.

ٟ

Please refer to "EXPLODED VIEW" for the disassembly method of each P.W.B included in FRONT PANEL ASSY.

FFC Cover

[Attention of assembling]

When mounting the FRONT PANEL ASSY on the CHASSIS, do so with the DOOR open so as to prevent breaking the EARTH PLATE(DOOR).

If the FRONT PANEL ASSY is mounted on the chassis with the DOOR closed, the EARTH PLATE(DOOR) will hit the CHASSIS and break.

DOOR open

EARTH PLATE (DOOR)

Direction of photograph: A

DOOR closed (EARTH PLATE (DOOR) will be broken.)

EARTH PLATE (DOOR)

Direction of photograph: A

DOOR

8

AVR-4310CI/AVR-4310/AVC-4310

2. BACK PANEL UNIT ASSY

Proceeding : TOP COVER → BACK PANEL UNIT ASSY

(1) Remove the Sheets, then remove the screws.

View from bottom

Sheets

(2) Remove the screws.

Direction of photograph: A

(3) Disconnect the connector wires and FFC Cable, then remove the screws.

CX055

CX074

ً

FFC Cable

CY101

CY153

CY052

9

AVR-4310CI/AVR-4310/AVC-4310

(4) Remove the FFC cover, PWB HOLDER and acetate tapes. Cut the wire clamper, then disconnect the connector wire

and FFC Cable.

FFC Cable

CX068

Direction of photograph: C

cut

Acetate tape

(5) Cut the wire clamper, then disconnect the connector wire.

BACK PANEL UNIT ASSY

PWB HOLDER

v

FFC Cover

Direction of photograph: D

Acetate tape

CX091

cut

10

AVR-4310CI/AVR-4310/AVC-4310

3. DIGITAL UNIT ASSY

Proceeding : TOP COVER →

(1) Remove the alminium tape, then cut the wire clampers. Disconnect the connector wire, FFC Cables, and board to

board.

BACK PANEL UNIT ASSY

→

DIGITAL UNIT ASSY

MAIN CPU UNIT

Board to board

CX124

(2) Remove the screws.

FFC Cable

CX058

ً

cut

FFC Cable

Alminium Tape

CX047

cut

DIGTAL UNIT ASSY

FFC Cable

CY124

CY061

◆

Direction of photograph: A

11

AVR-4310CI/AVR-4310/AVC-4310

4. A.VIDEO UNIT, AUDIO UNIT and RADIATOR UNIT ASSY

Proceeding : TOP COVER →

→

A.VIDEO UNIT, AUDIO UNIT and RADIATOR UNIT ASSY

(1) Disconnect the board to board.

Direction of photograph: C

v

(2) Disconnect the connector wires.

BACK PANEL UNIT ASSY

CX073CX192

→

MAIN CPU UNIT

DIGITAL UNIT ASSY

(3) Remove the screws.

Direction of photograph: A

A.VIDEO UNIT

AUDIO UNIT

RADIATOR UNIT ASSY

12

AVR-4310CI/AVR-4310/AVC-4310

5. REG UNIT

Proceeding : TOP COVER →

→

A.VIDEO UNIT, AUDIO UNIT and RADIATOR UNIT ASSY

→

REG UNIT

(1) Disconnect the board to board and connector wires.

BACK PANEL UNIT ASSY

v

→

DIGITAL UNIT ASSY

Board to board

Direction of photograph: A

(2) Disconnect the connector wires, then remove the screws.

ً

Direction of photograph: A

ٟ

6. AMP UNIT

Proceeding : TOP COVER →

→

A.VIDEO UNIT, AUDIO UNIT and RADIATOR UNIT ASSY

→→

REG UNIT AMP UNIT

(1) Disconnect the VH connector and conector.

BACK PANEL UNIT ASSY

CX231

→

DIGITAL UNIT ASSY

CX092

CX871

CX874

View from bottom

CX876

CX873

CX851CX891

13

AVR-4310CI/AVR-4310/AVC-4310

CX872

CX875

CX877

7. P.AMP JOINT UNIT

Proceeding : TOP COVER →

→

A.VIDEO UNIT, AUDIO UNIT and RADIATOR UNIT ASSY

→→→

REG UNIT AMP UNIT P.AMP JOINT UNIT

(1) Disconnect the connector.

Direction of photograph: A

BACK PANEL UNIT ASSY

→

DIGITAL UNIT ASSY

CX806CX811CX812CX807

8. P.AMP UNIT

Proceeding : TOP COVER →

→

A.VIDEO UNIT, AUDIO UNIT and RADIATOR UNIT ASSY

→→→

REG UNIT AMP UNIT P.AMP JOINT UNIT P.AMP UNIT

(1) Remove the screws.

Direction of photograph: B

CX803CX805

BACK PANEL UNIT ASSY

CX804

→

DIGITAL UNIT ASSY

→

14

AVR-4310CI/AVR-4310/AVC-4310

SPECIAL MODE

ON/OFF

RETURN

ZONE2

DSP

SIMULATION

STANDARD STATUSENTER

PURE

DIRECT

DIRECT/

STEREO

MENU

CURSOR

Special mode setting button

※ Press the ON/OFF button to turn on while pressing both buttons A and B at the same time.

Mode Button A Button B contents

Version display (µcom/DSP Error Display)

Displaying the protection history mode

Initialization mode (Remove settings for Installer Setup.)

Initialization mode (Includes settings for Installer Setup)

Mode for switching tuner frequency step

Mode for preventing remote control acceptance

Panel lock mode

Panel lock mode (Remove Master volume)

Cancellation of panel lock mode

Installer Setup mode*1

STATUS RETURN

STATUS MENU

STANDARD

CURSOR UP

STANDARD

STATUS ENTER

DSP

SIMULATION

DIRECT/ STEREO

PURE

DIRECT

MENU

SIMULATION

CURSOR

DOWN

DIRECT/ STEREO

ZONE2

CURSOR

LEFT

DSP

Serial No. and firmware versions such as Main, Sub, DSP are displayed in the FL manager. Errors are displayed when they occur. (Refer to 16 page.)

Displaying the protection history (Refer to 18 page.)

Backup data initialization is carried out. (Remove settings for Installer Setup.)

Backup data initialization is carried out. (Includes settings for Installer Setup)

---E2 model only--Change tuner frequency step to FM:200kHz/AM:10kHzSTEP. g

Operations using remote control are rejected. (Mode cancellation: Turn off power and execute the same button operations as when performing setup.)

Operations using main unit panel buttons or master volume are rejected.

Operations using main unit panel buttons are rejected.

Panel lock mode is cancelled.

Access Remote Maintenance mode via the internet.Installer Setup is displayed on GUI/Option Menu.

Refer to AVR4310_RemoteMaintenance_.pdf of SDI.

*1 : About RS-232C communications

RS-232C communications are not possible when" " is displayed on the FL display. Press and hold in the "STATUS" and " ▽ " buttons for over 3 seconds with the power turned on to turn the " " display off. RS-232C communications are now enabled.

AVR-4310CI/AVR-4310/AVC-4310

15

1. Version display (µcom/DSP Error Display)

S

er ial No. AVR

9

041500001

Ma i n : . Ma i n ROM : .

Ma i n FBL : .

Sub : .

DSP1 : . DSP2 : .

A

ud i o PLD : .

V

ideo PLD : .

G

UI Conf ig:

G

UI PRG:

G

UI DAT:

E

ther FBL

-

E

ther SBL

-

E

ther IMG

-

*

Ethernet MAC

-

*

HDSDK : .

*

HDDSP : C0 0 0 2 . 0 0 0

*

Mu l t EQ P r o APP

...

*

Mu l t EQ P r o I CL

...

1. Version display (µcom/DSP Error Display)

1.1. Operation Spec

µcom version display mode:

When the following conditions are satisfied at its starting state, error information is displayed before version information.

Starting method (same as µcom version display):

Press the ON/OFF button to turn on while pressing both buttons STATUS and RETURN at the same time.

Press the ON/OFF button to turn on while pressing both buttons STATUS and RETURN at the same time. ("Error information" is displayed after about 10 seconds.)

("Error information" is displayed after about 10 seconds.) The FL display changes in the order given in item-1.2. each time you press the STATUS button.

The FL display changes in the order given in item-1.2. each time you press the STATUS button.

1.2. Display Order

Error information(Refer to 1.3. Error display) → qModel destination information wMain-µcom version information

Error information(Refer to 1.3. Error display) qModel destination information wMain-µcom version information

eMain1st Boot Loader rDSP1version information tAudio PLD yGUI FPGA Config uGUI Nios Program

eMain1st Boot Loader rDSP1version information tAudio PLD yGUI FPGA Config uGUI Nios Program iETHER(DM860) First BootLoafer, HardwareID oETHER(DM860) Second BootLoafer, RhapsodyFlag

iETHER(DM860) First BootLoafer, HardwareID oETHER(DM860) Second BootLoafer, RhapsodyFlag Q0ETHER(DM860) IMAGE Q1ETHER(DM850) MAC ADDRESS information

Q0ETHER(DM860) IMAGE Q1ETHER(DM850) MAC ADDRESS information

(E2 model only)

Q2HD RADIO SDK /HD RADIO DSP

Q2HD RADIO SDK /HD RADIO DSP Q4MultEQ Pro ICL (Displayed when Audyssey Pro is complete)

Q4MultEQ Pro ICL (Displayed when Audyssey Pro is complete)

No. Display item Display

q

Model destination

Cereal No.

(E2 model only)

Q3MultEQ Pro APP (Displayed when Audyssey Pro is complete)

w

e

r

t

y

u

i

o

Main-µcom

MainFLASH

Main 1st Boot Loder

Sub-µcom

Audio PLD

Video PLD

GUI FPGA

GUI Sflash Nios

GUI Sflash Font

DM860 1st Bootloader

- Hard ID

DM860 2nd Bootloader

- Rhapsody Flag

DSP 1

DSP 2

Q0

Q1

Q2

Q3

Q4

DM860 Image

ETHER MAC ADDRESS

HD RADIO SDK

HD RADIO DSP

MultEQ Pro APP

MultEQ Pro ICL

16

AVR-4310CI/AVR-4310/AVC-4310

1.3. Error display

P

ROT EC T H I STORY

:

NO PROTEC T

P

ROT EC T H I STORY

:

ASO / DC

P

ROT EC T H I STORY

:

THERMAL

See the following table for each "Error information" display and its contents (status). Display order is ①②③④⑤⑥ .

Condition State Display

①

Sub-µcom

NG

② DIR NG ③ DSP1 NG

④ DSP2 NG

⑤ EEPROM NG ⑥

Both SUB/DSP

/EEPROM OK

No response from Sub-µcom

No response from DIR

When DSP boot, executing DSP reset makes no change to DSP1 FLAGO port "H".

No change to DSP1 FLAGO port "H" before issuing DSP command.

When DSP data read, executing WRITE="L" makes no change to ACK="H".

When DSP data read, executing REQ="L" makes no change to ACK="L".

When DSP data write, executing WRITE="H" makes no change to ACK="H".

When DSP data write, executing REQ="L" makes no change to ACK="L".

When DSP special code boot, executing DSP reset makes no change to DSP1

FLAGO port "H".

No change to DSP1 FLAGO port "H" before issuing DSP special read command.

No change to DSP1 FLAGO port "H" before DSP version read.

When DSP boot, executing DSP reset makes no change to DSP2 FLAGO port "H".

No change to DSP2 FLAGO port "H" before issuing DSP command.

When DSP data read, executing WRITE="L" makes no change to ACK="H".

When DSP data read, executing REQ="L" makes no change to ACK="L".

When DSP data write, executing WRITE="H" makes no change to ACK="H".

When DSP data write, executing REQ="L" makes no change to ACK="L".

When DSP special code boot, executing DSP reset makes no change to DSP2

FLAGO port "H".

No change to DSP2 FLAGO port "H" before issuing DSP special read command.

No change to DSP2 FLAGO port "H" before DSP version read.

Error appeared in EEPROM checksum.(*** is a block address number.)

"□ＳＵＢ□ □ＥＲＲＯＲ□０１□□"

"□ＤＩＲ□ □ＥＲＲＯＲ□０１□□"

"□ ＤＳＰ1 □ＥＲＲＯＲ □０１□ □"

"□ ＤＳＰ1 □ＥＲＲＯＲ □０２□ □"

"□ ＤＳＰ1 □ＥＲＲＯＲ □０３□ □"

"□ ＤＳＰ1 □ＥＲＲＯＲ □０４□ □"

"□ ＤＳＰ1 □ＥＲＲＯＲ □０５□ □"

"□ ＤＳＰ1 □ＥＲＲＯＲ □０６□ □"

"□ ＤＳＰ1 □ＥＲＲＯＲ □１１□ □"

"□ ＤＳＰ1 □ＥＲＲＯＲ □１２□ □"

"□ ＤＳＰ1 □ＥＲＲＯＲ □１３□ □"

"□ ＤＳＰ2 □ＥＲＲＯＲ □０１□ □"

"□ ＤＳＰ2 □ＥＲＲＯＲ □０２□□ "

"□ ＤＳＰ2 □ＥＲＲＯＲ □０３□ □"

"□ ＤＳＰ2 □ＥＲＲＯＲ □０４□ □"

"□ ＤＳＰ2 □ＥＲＲＯＲ □０５□ □"

"□ ＤＳＰ2 □ＥＲＲＯＲ □０６□ □"

"□ ＤＳＰ2 □ＥＲＲＯＲ □１１□ □"

"□ ＤＳＰ2 □ＥＲＲＯＲ □１２□ □"

"□ ＤＳＰ2 □ＥＲＲＯＲ □１３□ □"

"□Ｅ2ＰＲＯＭ□ＥＲＲ＊＊＊□ □"

(No error display, version display only)

2. Displaying the protection history mode

2.1. Operation specifications

ERROR MODE(displaying the protection history) When started up, the error information is displayed.

Starting up:

With the "MENU" and "STATUS" buttons pressed, press the "ON/OFF" button to turn the power on. The error (protection history display) mode is set. Then, press the "STATUS" button to turn on the FL display.

2.2. About the display on the FL display

When the "STATUS" button is pressed after setting the error (protection history display) mode, a history like the one shown below is displayed, depending on the conditions.

(1) Normally (when there has been no protection incident)

(2) For ASO/DC (when the last protection incident was ASO or DC protection)

(3) For THERMAL (when the last protection incident was THERMAL protection)

When the "STATUS" button is pressed again after the above protection history is displayed, the normal display reappears.

17

AVR-4310CI/AVR-4310/AVC-4310

2.3. Clearing the protection history

P

ROT EC T H I STORY

:

THERMAL

P

ROT EC T H I STORY

CLEAR

P

ROT EC T H I STORY

:

NO PROTEC T

*

Tune r FRQ Se t

0

MA9/FM50M

1

*

Tune r FRQ Se t

0

MA10/FM20

1

There are two ways to clear the protection history, as described below.

(1) Start up the error (protection history display) mode, display the error, then press and hold in the "ENTER" button for 3

seconds.

Press and hold in the "ENTER" button for 3 seconds

The above is displayed and the protection history is cleared.

(2) Initialize.

※ If you want to save a backup, use the method in 3.(1) above.

Warning indication by the STANDBY LED

If the power is turned off when a protection incident has been detected, the STANDBY LED (red) flashes as follows as warning according to the conditions in which the protection incident occurred.

(1) ASO/DC PROTECTION : Flashes in cycles of 0.5 seconds (0.25 seconds lit, 0.25 seconds off)

(2) THERMAL PROTECTION : Flashes in cycles of 2 seconds (1 second lit, 1 second off)

3. Mode for switching tuner frequency step ---E2 model only--- g

3.1. Operation specifications

Change tuner frequency step to FM:200kHz/AM:10kHz STEP.

Starting up:

(1) With the "STANDARD" and "DIRECT/STEREO" buttons pressed, press the "ON/OFF" button to turn the power on.

"*Tuner FRQ Set" appears on the display.

(2) Use 0 1 and select "<AM10/FM200>".

(3) Press the "ENTER" button.

(4) Press the "ON/OFF" button to turn the power off.

(5) Then, press the "ON/OFF" button to turn the power on.

NOTE : Backup data(Remove settings for Installer Setup) initialization is carried out automatically.

18

AVR-4310CI/AVR-4310/AVC-4310

VERSION UPGRADE PROCEDURE OF FIRMWARE

You can update by downloading the latest firmware from the Internet.

1.Update from the Internet

1.1. Connecting to the Network

(1) System Requirement

• Internet Connection by Broadband Circuit

• Modem

• Router

• Ethernet cable (CAT-5 or greater recommended)

(2) Setting

Internet

Computer

Router

Modem

To WAN port

To LAN port

ETHERNET connector

LAN port/ Ethernet connector

1.2. Check for Update and Update

Check if the latest firmware exists. You can also check approximately how long it will take to complete an update.

(1) Press the MENU button on the remote control to display the GUI menu.

(2) Use the cursor buttons to select "Manual Setup" → "Option Setup" → "Firmware Update" → "Update Check".

(3) Press the ENTER buttom.

• The latest version of the firmware uploaded to the web is displayed.

• If the latest firmware version is on the web, proceed to (4).

• If the latest firmware is already installed, press the MENU button to close the menu.

(4) Use the cursor buttons to select "Update", then press the ENTER button.

• During update, the power indicator lights red and the GUI screen is shut down. And a rough remaining time is indicated on the display.

• When updating is complete the power indicator lights green and normal status is resumed.

(5) Press the MENU button to close the menu.

--- Cautions on Firmware Update ---

• In order to use these functions, you must have the correct system requirements and settings for a broadband Internet connection.

• Do not turn off the power until updating is completed. Even with a broadband connection to the Internet, approximately about 1 hour is required for the updating procedure to

be completed. Once updating starts, normal operations on the AVR-4310 cannot be performed until updating is completed. Also, setting items of the GUI menu of AVR-4310 or setting items of the image adjustment may be initialized. Make a note of the settings before updating, and set them again after updating.

19

AVR-4310CI/AVR-4310/AVC-4310

1.3. About the error code

See the chart below for error codes, details of faults, and coping strategies when firmware updates are performed through DPMS (Denon Product Management Server).

Error code

01 Log-in to DPMS has failed.

02

03 Connection to DPMS failed.

04

05

06

Details of Error code Display Coping strategies

Line, etc., is busy when logging into DPMS.

Firmware file data was requested but error message was received.

Firmware file data was requested but it timed out.

Firmware file data was requested but error message was received.

og i n f a i l ed

L

erver is busy

S

onnec t i on f a i l

C

onnec t i on f a i l

C

onnec t i on f a i l

C

onnec t i on f a i l

C

Reset and update again. Carry out the update in an environment that has little network load.

01

Carry out the update in an environment that has little network load.

02

Check the network connection. Carry out the update in an environment that has little network load.

03

Check the network connection. Carry out the update in an environment that has little network load.

04

Check the network connection. Carry out the update in an environment that has little network load.

05

Check the network connection. Carry out the update in an environment that has little network load.

06

All firmware file data was

07

requested but it timed out.

Main CPU firmware file data was

08

requested but error message was received.

Main CPU firmware file data was

09

requested but it timed out.

Error (NG) message received when downloading Main CPU firm-

0A

ware.

Error (line congestion) message

0B

received when downloading Main CPU firmware.

Error (connection failure) mes-

0C

sage received when downloading Main CPU firmware.

Data acquisition failed (timed out)

0D

when downloading Main CPU firmware.

onnec t i on f a i l

C

onnec t i on f a i l

C

onnec t i on f a i l

C

own l o ad f a i l

D

own l o ad f a i l

D

own l o ad f a i l

D

onnec t i on f a i l

C

Check the network connection. Carry out the update in an environment that has little network load.

07

Check the network connection. Carry out the update in an environment that has little network load.

08

Check the network connection. Carry out the update in an environment that has little network load.

09

Turn the power off then back on. Updating starts automatically. Carry out the update in an environment

0A

that has little network load.

Turn the power off then back on. Updating starts automatically. Carry out the update in an environment

0B

that has little network load.

Turn the power off then back on. Updating starts automatically. Carry out the update in an environment

0C

that has little network load.

Turn the power off then back on. Updating starts automatically. Carry out the update in an environment

0D

that has little network load.

Main CPU failed to receive firm-

30

ware for rewriting sent from DM860 (when timed out).

ain F i r m

M

pda t i ng fa i l 30

U

***

mi n

20

AVR-4310CI/AVR-4310/AVC-4310

Turn the power off then back on. Updating starts automatically.

Error code

Details of Error code Display Coping strategies

Main CPU failed to receive firm-

31

ware for rewriting sent from DM860 (when an error )

There was invalid data in the firmware for rewriting sent from

32

DM860 to Main CPU (when a Check Sum error).

The deletion of block data failed

33

before rewriting Main CPU.

The rewriting of block data failed

34

when rewriting Main CPU.

The data verification was invalid

35

after rewriting Main CPU.

Log-in to DPMS has failed when

36

rewriting firmware such as Sub CPU, DSP, FPGA, and PLD.

Line, etc., is busy when logging into DPMS when rewriting firm-

37

ware such as Sub CPU, DSP, FPGA, and PLD.

ain Fi rm

M

pda t i ng fa i l 31

U

ain

M

pda t i ng fa i l 32

U

ain

M

rase fai l 33

E

ain

M

pda t i ng fa i l 34

U

ain

M

pda t eCheckNG 35

U

og i n f a i l ed

L

erver is busy

S

Firm

***

mi n

Turn the power off then back on. Updating starts automatically.

Carry out the update in an environment that has little network load.

36

Carry out the update in an environment that has little network load.

37

Connection to DPMS failed when

38

rewriting firmware such as Sub CPU, DSP, FPGA, and PLD.

Connection to DPMS timed out

39

when rewriting firmware such as Sub CPU, DSP, FPGA, and PLD.

Error (NG) message received

3A

when downloading firmware when rewriting Main CPU.

Error (line congestion) message

3B

received when downloading firmware when rewriting Main CPU.

Error (connection failure) message received when downloading

3C

firmware when rewriting Main CPU.

Data acquisition failed (timed out)

3D

when downloading firmware when rewriting Main CPU.

Error message received regarding

3E

firmware data when rewriting Main CPU.

onnec t i on f a i l

C

onnec t i on f a i l

C

own l o ad f a i l

D

own l o ad f a i l

D

own l o ad f a i l

D

onnec t i on f a i l

C

onnec t i on f a i l

C

Check the network connection. Carry out the update in an environment that has little network load.

38

Check the network connection. Carry out the update in an environment that has little network load.

39

Turn the power off then back on. Updating starts automatically. Carry out the update in an environment

3A

that has little network load.

Turn the power off then back on. Updating starts automatically. Carry out the update in an environment

3B

that has little network load.

Turn the power off then back on. Updating starts automatically. Carry out the update in an environment

3C

that has little network load.

Turn the power off then back on. Updating starts automatically. Carry out the update in an environment

3D

that has little network load.

Check the network connection. Carry out the update in an environment that has little network load.

3E

Firmware file data was requested

3F

but it timed out when rewriting Main CPU.

onnec t i on f a i l

C

21

AVR-4310CI/AVR-4310/AVC-4310

Check the network connection. Carry out the update in an environment that has little network load.

3F

Error code

Details of Error code Display Coping strategies

Log-in to DPMS has failed when

50

rewriting firmware such as Sub CPU, DSP, FPGA, and PLD.

Line, etc., is busy when logging into DPMS when rewriting firm-

51

ware such as Sub CPU, DSP, FPGA, and PLD.

Connection to DPMS failed when

52

rewriting firmware such as Sub CPU, DSP, FPGA, and PLD.

Connection to DPMS timed out

53

when rewriting firmware such as Sub CPU, DSP, FPGA, and PLD.

Error message received regarding firmware data after logging in to DPMS when rewriting firmware

54

such as Sub CPU, DSP, FPGA, and PLD.

When rewriting firmware such as Sub CPU, DSP, FPGA, and PLD, request was made for firmware

55

data after logging in to DPMS, but it timed out.

Failure to download firmware after logging in to DPMS when rewriting

56

firmware such as Sub CPU, DSP, FPGA, and PLD.

Firmware download error received (line congestion) after logging in to DPMS when rewriting firmware

57

such as Sub CPU, DSP, FPGA, and PLD.

Firmware download error received (connection failure) after logging in to DPMS when rewriting firmware

58

such as Sub CPU, DSP, FPGA, and PLD.

When rewriting firmware such as Sub CPU, DSP, FPGA, and PLD, request was made for downloading

59

firmware after logging in to DPMS, but it timed out.

ub

S

og i n f a i l ed 50

L

ub

S

erver is busy51

S

ub

S

onnec t i onFa i l 52

C

ub

S

onnec t i onFa i l 53

C

ub

S

pda t i ng fa i l 54

U

ub

S

pda t i ng fa i l 55

U

ub

S

own l o ad f a i l 5 6

D

ub

S

erver is busy57

S

ub

S

onnec t i onFa i l 58

C

ub

S

own l o ad f a i l 5 9

D

***

mi n

Carry out the update in an environment that has little network load.

Check the network connection. Carry out the update in an environment that has little network load.

Turn the power off then back on. Updating starts automatically. Carry out the update in an environment that has little network load.

NACK received when “C” com-

5A

mand sent to Sub CPU, DSP, FPGA, PLD etc.

NACK received when “L” com-

5B

mand sent to Sub CPU, DSP, FPGA, PLD etc.

Sub CPU, DSP, FPGA, PLD etc. failed to receive firmware for

5C

rewriting sent from DM860 (when timed out).

Sub CPU, DSP, FPGA, PLD etc. failed to receive firmware for

5D

rewriting sent from DM860 (when an error).

Invalid data in firmware such as Sub CPU, DSP, FPGA, and PLD

5E

for rewriting sent from DM860 (when a Check Sum error).

ub

S

onnec t i onFa i l 5A

C

ub

S

pda t i ng fa i l 5B

U

ub

S

pda t i ng fa i l 5C

U

ub

S

pda t i ng fa i l 5D

U

ub

S

pda t i ng fa i l 5E

U

***

mi n

22

AVR-4310CI/AVR-4310/AVC-4310

Turn the power off then back on. Updating starts automatically.

Error code

5F

Details of Error code Display Coping strategies

Invalid data in firmware such as Sub CPU, DSP, FPGA, and PLD for rewriting sent from DM860 (invalid data received).

ub

S

pda t i ng fa i l 5F

U

***

mi n

Turn the power off then back on. Updating starts automatically.

NACK received when “P” com-

60

mand sent to Sub CPU, DSP, FPGA, PLD etc.

NACK received when “I” command

61

sent to Sub CPU, DSP, FPGA, PLD etc.

Failure to acquire serial flash data

80

and before deleting serial flash.

Failure to delete data before rewrit-

81

ing serial flash.

Failure to receive firmware for

82

serial flash rewriting sent by DM860 (when timed out).

Failure to receive firmware for

83

serial flash rewriting sent by DM860 (when an error).

Failure to receive firmware for

84

serial flash rewriting sent by DM860 (when a Check Sum error).

ub

S

pda t i ng fa i l 60

U

ub

S

pda t eCheckNG 61

U

UI Fl ash

G

pda t i ng fa i l 80

U

UI Fl ash

G

pda t i ng fa i l 81

U

UI Fl ash

G

pda t i ng fa i l 82

U

UI Fl ash

G

pda t i ng fa i l 83

U

UI Fl ash

G

pda t i ng fa i l 84

U

***

mi n

Turn the power off then back on. Updating starts automatically.

Failure to receive firmware for serial flash rewriting sent by

85

DM860 (when invalid data received).

Failure to rewrite when writing data

86

in serial flash.

Failure to acquire (Application

A0

Mode) IP address before rewriting DM860 (AutoIP).

Failure to acquire (Application

A1

Mode) IP address before rewriting DM860 (when timed out).

Notification of invalid login via DPMS access when rewriting

A2

DM860 related firmware (Application Mode).

Notification of line congestion via DPMS access when rewriting

A3

DM860 related firmware (Application Mode).

Notification of connection failure via DPMS access when rewriting

A4

DM860 related firmware (Application Mode).

UI Fl ash

G

pda t i ng fa i l 85

U

UI Fl ash

G

pda t i ng fa i l 86

U

ther IMG

E

onnec t i onFa i l A0

C

ther IMG

E

onnec t i onFa i l A1

C

ther IMG

E

og i n f a i l ed A2

L

ther IMG

E

erver is busyA3

S

ther IMG

E

onnec t i onFa i l A4

C

***

mi n

Turn the power off then back on. Updating starts automatically.

Check the network connection. Carry out the update in an environment that has little network load.

23

AVR-4310CI/AVR-4310/AVC-4310

Error code

A5

A6

A7

Details of Error code Display Coping strategies

Connection through DPMS access timed out when rewriting DM860 related firmware (Application Mode).

Firmware data error message received after DPMS login when rewriting DM860 related firmware (Application Mode).

When rewriting DM860 related firmware (Application Mode), request was made for firmware data after DPMS login but it timed out.

ther IMG

E

onnec t i onFa i l A5

C

ther IMG

E

pda t i ng fa i l A6

U

ther IMG

E

pda t i ng fa i l A7

U

***

mi n

Check the network connection. Carry out the update in an environment that has little network load.

Turn the power off then back on. Updating starts automatically. Carry out the update in an environment that has little network load.

Failure to acquire (Boot Loader

A8

Mode) IP address before rewriting DM860 (AutoIP).

Failure to acquire (Boot Loader

A9

Mode) IP address before rewriting DM860 (when timed out).

Notification of invalid login via DPMS access when rewriting

AA

DM860 related firmware (Boot Loader Mode).

Notification of line congestion via DPMS access when rewriting

AB

DM860 related firmware (Boot Loader Mode).

Notification of connection failure via DPMS access when rewriting

AC

DM860 related firmware (Boot Loader Mode).

Connection through DPMS access timed out when rewriting DM860

AD

related firmware (Boot Loader Mode).

Firmware download error message received (when download fails)

AE

when rewriting DM860 related firmware (Boot Loader Mode).

Firmware download error message received (line congestion) when

AF

rewriting DM860 related firmware (Boot Loader Mode).

Firmware download error message received (connection failure) when

B0

rewriting DM860 related firmware (Boot Loader Mode).

When rewriting DM860 related firmware (Boot Loader Mode),

B1

request was made for firmware download but it timed out .

Error message received when

B2

rewriting DM860 related firmware.

ther IMG

E

onnec t i onFa i l A8

C

ther IMG

E

onnec t i onFa i l A9

C

ther IMG

E

og i n f a i l ed AA

L

ther IMG

E

erver is busyAB

S

ther IMG

E

onnec t i onFa i l AC

C

ther IMG

E

onnec t i onFa i l AD

C

ther IMG

E

own l o ad f a i l AE

D

ther IMG

E

erver is busyAF

S

ther IMG

E

onnec t i onFa i lB0

C

ther IMG

E

own l o ad f a i l B1

D

ther IMG

E

pda t i ng fa i l B2

U

***

mi n

Check the network connection. Carry out the update in an environment that has little network load.

Turn the power off then back on. Updating starts automatically. Carry out the update in an environment that has little network load.

24

AVR-4310CI/AVR-4310/AVC-4310

Device display when firmware updated

Target of devide when firmware updated.

Target of device Display Error cpde

Main

Main ROM

Sub

Audio PLD

Gui Config

Video PLD

DSP1

ain F i r m

M

pda t i ng

U

ain R O M

M

pda t i ng

U

ub

S

pda t i ng

U

PLD

A

pda t i ng

U

UI Conf

G

pda t i ng

U

PLD

V

pda t i ng

U

SP1

D

pda t i ng

U

***

mi n

30 〜 35

80 〜 86

50 〜 61

DSP2

Serial Flash

DM860 Boot Loader

DM860 Image

SP2

D

pda t i ng

U

UI Fl ash

G

pda t i ng

U

ther SBL

E

pda t i ng

U

ther IMG

E

pda t i ng

U

***

mi n

50 〜 61

80 〜 86

A0 〜 B2

25

AVR-4310CI/AVR-4310/AVC-4310

ADJUSTMENT

Audio Section

Idling Current (8U-110049, 8U-110050-3)

Required measurement equipment: DC Voltmeter

Preparation

(1) Avoid direct blow from an air conditioner or an electric fan, and adjust the unit at normal room temperature 15°C ~ 30°C

(59°F ~ 86°F).

(2) Presetting

POWER (Power source switch) OFF SPEAKER (Speaker terminal) No load (Do not connect speaker, dummy resistor, etc.)

Adjustment

(1) Remove top cover and set VR101, VR201, VR301, VR401, VR501, VR601, VR701, on 8U-110049 (POWER AMP Unit)

at fully counterclockwise ( ).

(2) Connect DC Voltmeter to test points(8U-110050-3).

• FRONT-Lch: CX660 ③ ④ pin

• FRONT-Rch: CX660 ⑤ ⑥ pin

• CENTER ch: CX660 ① ② pin

• SURROUND-Lch: CX680 ⑤ ⑥ pin

• SURROUND-Rch: CX680 ⑦ ⑧ pin

• SURROUND BACK-Lch: CX680 ① ② pin

• SURROUND BACK-Rch: CX680 ③ ④ pin)

(3) Connect power cord to AC Line, and turn power switch "ON".

(4) Presetting.

MASTER VOLUME : "---" counterclockwise ( min.) MODE : 7CH STEREO FUNCTION : CD

(5) Allow 2 minutes, and turn VR101 clockwise ( ) to adjust the TEST POINT voltage to 6.5 mV ± 0.5 mV DC. (6) After 10 minutes from preset, turn VR101 to set the voltage to 12 mV ± 0.5 mV DC.

(7) Adjust the Variable Resistors of other channels in the same way. (8) After 5 minutes from (6), turn VR101 to set the voltage to 12 mV ± 0.5 mV DC.

(9) Adjust the Variable Resistors of other channels in the same way.

26

AVR-4310CI/AVR-4310/AVC-4310

DC Voltmeter

SBL ch

CX680

SBR ch

SR ch

SL ch

CX660

C ch

FR ch

FL ch

8U-310030 DIGITAL Unit

8U-110048-4 POWER SUPPLY Unit

VR501

VR701

VR601 VR101

VR301

VR401 VR201

Audio Section

Adjustment volume is set for 8U-110049-1 〜 7. The test point is at 8U-110050-3.

Insert an adjustment driver / connection terminal from an adjustment aperture of 8U-110048-4(POWER SUPPLY Unit)P.W.B..

27

AVR-4310CI/AVR-4310/AVC-4310

SURROUND MODES AND PARAMETERS

AAA

(NOTE1) S (Cinema) AA

Cinema EQ. Mode Room Size Effect Level

Back

Surround

1

z

AFDM

3

z

LFE

2

z

DRC

1

z

D. COMP

Signals and adjustability in the different modes

L/R

Front Height

L/R

Front Wide

z

Subwoofer

Back L/R

Surround

Channel output Parameter (default values are shown in parentheses)

L/R

Surround

vpage 74, 76).

vpage 73).

vpage 76).

4 AAS(OFF) S (Auto) S (0 dB) AAAAAA

Center

SA A AD

L/R

Front

Surround Mode

PURE DIRECT, DIRECT (2ch)

SAAAAA AAAAAAAA A A

SDDDD A A A AS(0 dB) ASAAAA

SDDDD A A A AS(0 dB) S (ON) SAAAA

DSD DIRECT

DSD MULTI DIRECT

MULTI CH DIRECT

SA A AD A AS(OFF) S (Auto) S (0 dB) AAAAAA

STEREO

SDDDD D DS(OFF) S (Auto) S (0 dB) ASS(OFF) AAS(ON, 10)

SDDDDAAAAAAAAA A A

SDDDDD(NOTE4) D (NOTE4) AAS(0 dB) S (ON) SS(OFF) AAA

WIDE SCREEN

EXT. IN

DOLBY PRO LOGIC gz SDDAD A DS(OFF) S (Auto) S (0 dB) AAAS(Height) AA

MULTI CH IN

SDDDDD(NOTE4) D (NOTE4) S (OFF) S (Auto) AASS

DOLBY PRO LOGIC gx SDDDD A AS(OFF) S (Auto) AASS(NOTE1) S (Cinema) AA

DOLBY PRO LOGIC g SDDADD(NOTE4) D (NOTE4) S (OFF) S (Auto) AASS(NOTE2) S (Cinema) AA

DTS NEO:6

AVR-4310CI/AVR-4310/AVC-4310

SDDDDD(NOTE4) D (NOTE3) S (OFF) AS(0 dB) S (ON) SS(OFF) AAA

SDDDDD(NOTE4) D (NOTE3) S (OFF) AS(0 dB) S (ON) SS(OFF)

SDDDDD(NOTE4) D (NOTE4) AAAASAAAA

SDDDDD(NOTE4) D (NOTE3) S (OFF) AS(0 dB) S (ON) SS(OFF) AAA

SDDDDD(NOTE4) D (NOTE3) AS(Auto) S (0 dB) S (ON) SS(OFF) AAA

DTS SURROUND

DTS 96/24

DOLBY DIGITAL

DOLBY DIGITAL Plus

DOLBY TrueHD

DTS-HD

SDDDD D DS(OFF) S (Auto) S (0 dB) ASAAAA

SDDDD D DS(OFF) S (Auto) S (0 dB) AS A AS(Medium) S (10)

DTS EXPRESS

neural

7CH STEREO

SUPER STADIUM

ROCK ARENA

JAZZ CLUB

28

SDDDD D DS(OFF) S (Auto) S (0 dB) AS A AS(Medium) S (10)

SDDDD D DS(OFF) S (Auto) S (0 dB) ASAAAA

SA A AD A AS(OFF) S (Auto) S (0 dB) AAAAAA

NOTE2 : This parameter is availabe when the “Mode” is set to “Cinema” or “ProLogic” (

D : Turned on or off by speaker conﬁguration setting

NOTE1 : This parameter is availabe when the “Mode” is set to “Cinema” (

S : Signal / Adjustable

A : No signal / Not adjustable

CLASSIC CONCERT

MONO MOVIE

VIDEO GAME

MATRIX

VIRTUAL

1 : When playing Dolby Digital and DTS signals.

2 : When playing Dolby TrueHD signal.

NOTE:

3 : When playing Dolby Digital, DTS, DVD-Audio and Super Audio CD.z4 : When the “Subwoofer Mode” is set to “LFE+Main” (vpage 35) only.

z

NOTE3 : This parameter is availabe when the “Front Height” is set to “ON” or “DSX” is set to “ON” (

NOTE4 : This parameter is availabe when the “DSX” is set to “ON” (

RESTORER DSX

Volume

Dynamic

Tone Control MultEQ XT Dynamic EQ

Att.

Subwoofer

EXT. IN only

mode only

NEO:6 MUSIC

Signals and adjustability in the different modes

Parameter (default values are shown in parentheses)

PRO LOGIC g/gx MUSIC mode only

Delay Time Subwoofer Front Height

Panorama Dimension Center Width Center Image

ASAAAAAAAAAAAA

AAAAAAAAAAAAAA

AAAAAAAAS(OFF) S (OFF) SSSA

AASAAAAAS(OFF) S (OFF) SSAS

AAAAAAAAS(OFF) S (OFF) SSSA

AAAAAAASAAAAAA

AASAAAAAS(OFF) S (OFF) SSAS

AAAAAAS(0.3) AS(OFF) S (OFF) SSSS

AASAAAAAS(OFF) S (OFF) SSAS

AAAAAAAAS(NOTE5) S (OFF) SSS A

AAAAAAAAS(OFF) S (OFF) SSSA

AAAAAAAAS(OFF) S (OFF) SSSS

AASAAAAAS(OFF) S (OFF) SSAS

AAAAAAAAS(OFF) S (OFF) SSSA

AAAAAAAAS(NOTE6) S (OFF) SSS A

AAAAAAAAS(OFF) S (OFF) SSSA

S (30 ms) AAAAAAAS(OFF) S (OFF) SSS A

S : Signal / Adjustable

A : No signal / Not adjustable

NOTE5 : BASS +6 dB, TREBLE 0 dB

AAAAAAAAS(OFF) S (OFF) SSSA

NOTE6 : BASS +6 dB, TREBLE +4 dB

Surround Mode

PURE DIRECT, DIRECT (2ch)

DSD DIRECT

DSD MULTI DIRECT

MULTI CH DIRECT

STEREO

EXT. IN

MULTI CH IN

DOLBY PRO LOGIC gx AASS(OFF) S (3) S (3) AAS(OFF) S (OFF) SSS A

DOLBY PRO LOGIC gAASS(OFF) S (3) S (3) AAS(OFF) S (OFF) SSSS

DOLBY PRO LOGIC gz AASAAAAAS(OFF) S (OFF) SSS A

WIDE SCREEN

DOLBY DIGITAL Plus

DOLBY DIGITAL

DTS NEO:6

DOLBY TrueHD

DTS 96/24

DTS SURROUND

DTS-HD

7CH STEREO

neural

DTS EXPRESS

29

AVR-4310CI/AVR-4310/AVC-4310

SUPER STADIUM

ROCK ARENA

MONO MOVIE

CLASSIC CONCERT

JAZZ CLUB

VIDEO GAME

MATRIX

VIRTUAL

DOLBY

Input signals

DSD

PCM

DOLBY

DIGITAL

DOLBY

DIGITAL

DOLBY

DIGITAL

DIGITAL EX

DIGITAL

DOLBY

DIGITAL

DOLBY

DTS

(2ch)

(multi ch)

(2ch)

(multi ch)

(2ch)

(4/3ch)

(5.1/5/4ch)

Flag)

(With no

Flag)

EX (With

Plus

TrueHD

96/24

F : Mode selectable in initial status

D : Mode ﬁxed when “AFDM” is “ON”

S : Selectable mode

A : Non-selectable mode

DTS

(5.1ch)

MTRX

DTS ES

DSCRT

DTS ES

DTS

EXPRESS

High

DTS-HD

Resolution

DTS-HD DTS DOLBY DOLBY DIGITAL MULTI CH PCM Super Audio CD

Master

DTS-HD

/

(Windows

Media Audio)

MP3 / MPEG-4

WMA

WAV

PCM /

LINEAR

ANALOG

Note

(With Flag)

Audio

AAC / FLAC

AA A F A A A A AAAA A A A AA A A A A

AA A A F A A A AAAA A A A AA A A A A

AA A A A AF D A AAAA A A A AA A A A A

AA A A A A A F DAAAA A A A AA A A A A

AA A AA A S SFAAA A A AAAAAAA

AA A AA A A A AFAA A A AAAAAAA

AA A SS S S SSSAA A A AAAAAAA

AA A A A F A A AAAA A A A AA A A A A

AA A SS S A SSSAA A A AAAAAAA

SS S AA A A A AAAA A A A ASASAS

1

z

2

1

3

z

1

z

AA A AA A A A AAFAA A AAAAAAA

AA A A A A A A AAAF A A A AA A A A A

AA A AA A A A AAAAS S SSAAAAA

AA A AA A A A AASSA A AAAAAAA

AA A AA A A A AAAAS F FFAAAAA

AA A AA A A A AASSF DS SSAAAAA

AA A AA A A A AASSS S SSAAAAA

SS S AA A A A AAAA A A A ASASAS

1

z

2

z

AA A AA A A A AASSS S SSAAAAA

1

3

z

SS S AA A A A AAAA A A A ASASAS

3

1

z

SS S AA A A A AAAA A A A ASASAS

SS S A A A A A AAAA A A A AA A S A A

1: This mode is not available when the surround back speaker setup is set to “None”.z2: This mode is not available when the surround back speaker setup is set to “1spkr” or “None”.z3: This mode is not available when the front height speaker setup is set to “None”.

z

NOTE:

Button

Surround Mode

STANDARD

DTS-HD MSTR

DTS SURROUND

DTS ES MTRX6.1

DTS ES DSCRT6.1

DTS SURROUND

DTS-HD HI RES

DTS 96/24

DTS (–HD) + PLgx CINEMA

DTS (–HD) + PLgx MUSIC

DTS (–HD) + PLgz HEIGHT

DTS EXPRESS

DTS (–HD) + NEO:6

DTS NEO:6 CINEMA

DTS NEO:6 MUSIC

DOLBY TrueHD

DOLBY DIGITAL+

DOLBY DIGITAL EX

DOLBY (D+) (HD) +EX

DOLBY DIGITAL

DOLBY SURROUND

30

AVR-4310CI/AVR-4310/AVC-4310

DOLBY (D) (D+) (HD) +PLgx

CINEMA

DOLBY (D) (D+) (HD) +PLgx

MUSIC

DOLBY (D) (D+) (HD) +PLgz

HEIGHT

DOLBY PRO LOGIC gx CINEMA

DOLBY PRO LOGIC gz HEIGHT

DOLBY PRO LOGIC gx MUSIC

DOLBY PRO LOGIC gx GAME

DOLBY PRO LOGIC g CINEMA SS S AA A A A AAAA A A A ASASAS

DOLBY PRO LOGIC g MUSIC SS S A A A A A AAAA A A A ASASAS

DOLBY PRO LOGIC g GAME SS S AA A A A AAAA A A AASASAS

DOLBY PRO LOGIC

neural
