Bongard M2, 2T Installation Manual

⁄2"

1

3" min.

Teflon® is a registered trademark of the E.I. Dupont de Nemours & Company, Incorporated.

Hose Adapter

0862000 2-M2-RK 2-M2, 2T-M2
Code No. No. For Size
Ordering Kit

O-ring

Adapter

Hose

Spindle O-ring

Lower Teflon Disc

Ball Valve

Side Plug

2-Spindle O-rings 2-Hose Adapter O-rings

4-Teflon Discs 2-Adapter Screw O-rings

1-Side Plug O-rings 2-Adapter O-rings

Side Plug O-ring

Upper Teflon Disc

Kit for No. 2-M2 consists of:

Model M2 identification shown on body casting.

Screw O-ring

Adapter O-ring

4. Pipe connections are 23⁄8" (60mm) on center.
or side.
machine Ell adapters can be orientated to top, bottom

3. Install a minimum of 3" (76mm) above top of washing

3" min.

soldering.

2. Disassemble adapters and remove O-rings prior to
sweat.

No. 2

No. 2T

No. 2T features 1⁄2" combination male thread/female

1. No. 2 features 1⁄2" sweat copper ell adapters.

Installation Instructions

IS-2-M2

1

⁄2" Ell adapters for

exposed pipe

No. 2-M2 & 2T-M2

Fit any type of installation

Maintenance

1. Shutoff water supply and loosen adapter screws to
remove valve.

2. Remove O-rings and screws from adapters.

3. Move lever to on position and unscrew from spindle.

4. Use 3⁄8" allen wrench to remove hose adapters and
remove bottom Teon® discs. This allows removal
of the balls from the spindle by shaking slightly.

5. Insert a pencil through rear of valve to pry upper

21⁄4"

Screw

O-ring

Lever

9

3

⁄16"

3

⁄4" Hose

Connection

23⁄8"

1

⁄2" Male connections for concealed piping

O-ring

"

1

16

⁄

1

23⁄8"

Teon® discs loose.

6. To replace spindle O-rings, use 1⁄4" allen wrench
to remove side plug.

7. Reassemble by replacing all seals, assembling in re­verse order. Tighten adapters securely to avoid leakage.

Limited Warranty: Watts Regulator Co. (the “Company”) warrants each product to be free from defects in material and workmanship under normal usage for a period of one year from the date of
original shipment. In the event of such defects within the warranty period, the Company will, at its option, replace or recondition the product without charge.

THE WARRANTY SET FORTH HEREIN IS GIVEN EXPRESSLY AND IS THE ONLY WARRANTY GIVEN BY THE COMPANY WITH RESPECT TO THE PRODUCT. THE COMPANY MAKES NO OTHER
WARRANTIES, EXPRESS OR IMPLIED. THE COMPANY HEREBY SPECIFICALLY DISCLAIMS ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

The remedy described in the first paragraph of this warranty shall constitute the sole and exclusive remedy for breach of warranty, and the Company shall not be responsible for any incidental, special
or consequential damages, including without limitation, lost profits or the cost of repairing or replacing other property which is damaged if this product does not work properly, other costs resulting
from labor charges, delays, vandalism, negligence, fouling caused by foreign material, damage from adverse water conditions, chemical, or any other circumstances over which the Company has no
control. This warranty shall be invalidated by any abuse, misuse, misapplication, improper installation or improper maintenance or alteration of the product.
Some States do not allow limitations on how long an implied warranty lasts, and some States do not allow the exclusion or limitation of incidental or consequential damages. Therefore the above
limitations may not apply to you. This Limited Warranty gives you specific legal rights, and you may have other rights that vary from State to State. You should consult applicable state laws to
determine your rights. SO FAR AS IS CONSISTENT WITH APPLICABLE STATE LAW, ANY IMPLIED WARRANTIES THAT MAY NOT BE DISCLAIMED, INCLUDING THE IMPLIED WARRANTIES OF

MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO ONE YEAR FROM THE DATE OF ORIGINAL SHIPMENT.

Ball-type Washing Machine Shutoff Valve

Model No. 2, No. 2T

A Watt s Water Techn ologies Compa ny

IS-2-M2 1039 EDP# 1910509 © 2010 Watts
