Beckhoff C6920, C6925 Installation And Operating Instructions Manual

Installation and Operating instructions for

C6920, C6925

Control Cabinet Industrial PCs

Version: 2.5
Date: 2016-09-29

Table of contents

Table of contents

1 Foreword 3

1.1 Notes on the Documentation 3

1.1.1 Liability Conditions 3

1.1.2 Trademarks 3

1.1.3 Patent Pending 3

1.1.4 Copyright 3

1.1.5 State at Delivery 3

1.1.6 Delivery conditions 3

1.2 Description of safety symbols 4

1.3 Basic safety measures 5

1.4 Operator’s obligation to exercise diligence 6

1.4.1 National regulations 6

1.4.2 Procedure in the event of a fault 6

1.4.3 Operator requirements 6

2 Product Description 7

2.1 Product overview 7

2.2 Appropriate Use 8

2.3 Access to the battery and drives 9

2.4 Status-LEDs 10

2.5 Fan cartridge C6920 10

2.5.1 Exchanging the fan cartridge 10

2.6 Extension for PCI and PCIe plug-in cards 11

2.6.1 Access to the plug-in card slots 11

2.7 Interfaces 12

2.7.1 Power Supply (X101) 12

2.7.2 Network connection (X102, X103) 12

2.7.3 USB-Interfaces (X104 – X107) 12

2.7.4 DVI (Digital Visual Interface) (X108) 12

2.7.5 Serial interface (X109) 12

2.7.6 Fieldbus (X110) 12

2.7.7 Additional plug-in cards (optional) 12

2.7.8 Extension for PCI and PCIe plug-in cards (optional) 12

2.7.9 Ground connection 12

3 Installation 13

3.1 Transport and Unpacking 13

3.1.1 Transport 13

C6920/ C6925 1

Table of contents

3.1.2 Unpacking 13

3.2 Installation of the PC in the control cabinet 14

3.2.1 Preparation of the control cabinet 14

3.2.2 Earthing measures 14

3.3 Power supply of the Industrial PC 15

3.3.1 Beckhoff power supply technology 15

3.3.2 Fitting the cable 17

3.3.3 Connecting Power Supply 18

3.4 Connecting the Industrial PC 20

3.4.1 Connecting cables 20

3.4.2 Check voltage rating and connect 20

4 Operating Instructions 21

4.1 Switching the Industrial PC on and off 21

4.1.1 Switch on 21

4.1.2 Shutting down and switching off 21

4.1.3 First switching on and driver installation 21

4.2 Servicing and maintenance 22

4.2.1 Cleaning of the Industrial PC 22

4.2.2 Maintenance 22

4.2.3 Replacing the Battery on the Motherboard 22

4.3 Emergency procedures 22

4.4 Shutting down 22

4.4.1 Disposal 22

5 UPS Software Components (optional) 23

5.1 Installation on the PC 23

5.2 Help files 23

6 Troubleshooting 24

7 Assembly dimensions 25

8 Technical Data 31

9 Appendix 32

9.1 Beckhoff Support and Service 32

9.1.1 Beckhoff branches and partner companies 32

9.1.2 Beckhoff company headquarters 32

9.2 Approvals for USA and Canada 33

9.3 FCC Approvals for the United States of America 33

9.4 FCC Approval for Canada 33

2 C6920/ C6925

Foreword

1 Foreword

1.1 Notes on the Documentation

This description is only intended for the use of trained specialists in control and automation engineering
who are familiar with the applicable national standards. It is essential that the following notes and
explanations are followed when installing and commissioning these components.

The responsible staff must ensure that the application or use of the products described satisfy all the
requirements for safety, including all the relevant laws, regulations, guidelines and standards.

1.1.1 Liability Conditions

The documentation has been prepared with care. The products described are, however, constantly under
development. For that reason the documentation is not in every case checked for consistency with
performance data, standards or other characteristics. In the event that it contains technical or editorial
errors, we retain the right to make alterations at any time and without warning. No claims for the
modification of products that have already been supplied may be made on the basis of the data, diagrams
and descriptions in this documentation.

All pictures shown in the documentation are exemplary. Illustrated configurations can differ from standard.

1.1.2 Trademarks

Beckhoff®, TwinCAT®, EtherCAT®, Safety over EtherCAT®, TwinSAFE® and XFC® are registered
trademarks of and licensed by Beckhoff Automation GmbH.
Other designations used in this publication may be trademarks whose use by third parties for their own
purposes could violate the rights of the owners.

1.1.3 Patent Pending

The EtherCAT Technology is covered, including but not limited to the following patent applications and
patents: EP1590927, EP1789857, DE102004044764, DE102007017835 with corresponding applications
or registrations in various other countries.
The TwinCAT Technology is covered, including but not limited to the following patent applications and
patents: EP0851348, US6167425 with corresponding applications or registrations in various other
countries.

1.1.4 Copyright

©

Beckhoff Automation GmbH & Co. KG.
The reproduction, distribution and utilization of this document as well as the communication of its contents
to others without express authorization are prohibited. Offenders will be held liable for the payment of
damages. All rights reserved in the event of the grant of a patent, utility model or design.

1.1.5 State at Delivery

All the components are supplied in particular hardware and software configurations appropriate for the
application. Modifications to hardware or software configurations other than those described in the
documentation are not permitted, and nullify the liability of Beckhoff Automation GmbH & Co. KG.

1.1.6 Delivery conditions

In addition, the general delivery conditions of the company Beckhoff Automation GmbH & Co. KG apply.

C6920/ C6925 3

Foreword

1.2 Description of safety symbols

The following safety symbols are used in this operating manual. They are intended to alert the reader to
the associated safety instructions.

Acute risk of injury!

DANGER

If you do not adhere the safety advise adjoining this symbol, there is immediate
danger to life and health of individuals!

Risk of injury!

WARNING

If you do not adhere the safety advise adjoining this symbol, there is danger to life and
health of individuals!

Hazard to individuals!

CAUTION

If you do not adhere the safety advise adjoining this symbol, there is obvious hazard to
individuals!

Hazard to devices and environment

Attention

If you do not adhere the notice adjoining this symbol, there is obvious hazard to
materials and environment.

Note or pointer

Note

This symbol indicates information that contributes to better understanding.

4 C6920/ C6925

Foreword

1.3 Basic safety measures

Before the Industrial PC is switched off, software that is running must be properly closed.
Otherwise it is possible that data on the storage medium is lost. Please read the section Switching the

Industrial PC on and off.

Switch off all parts of the equipment, then uncouple the fieldbus

Attention

Before opening the housing, and whenever the Industrial PC is not being used for
control purposes (such as during functional checks after a repair), all parts of the
equipment must first be switched off, after which the Industrial PC is to be
disconnected from the equipment.

Pulling out the fieldbus connection plug uncouples the PC (optional).
Items of equipment that have been switched off must be secured against being switched on again.

The Industrial PC’s power supply unit must be supplied with 24 VDC.

Do not exchange any parts when under power

Attention

When components are being fitted or removed, the supply voltage must be switched
off.

Fitting work on the Industrial PC can result in damage:

• if metal objects such as screws or tools fall onto operating circuit boards.

• if connecting cables internal to the PC are removed or inserted during

operation.

• if plug-in cards are removed or inserted when the PC is switched on.

C6920/ C6925 5

Foreword

1.4 Operator’s obligation to exercise diligence

The operator must ensure that

• the product is only used as intended (see chapter Product Description)

• the product is in a sound condition and in working order during operation

• the product is operated, maintained and repaired only by suitably qualified and authorized

personnel

• the personnel is instructed regularly about relevant occupational safety and environmental
protection aspects, and is familiar with the operating manual and in particular the safety notes
contained herein

• the operation manual is in good condition and complete, and always available for reference at the
location of the product.

Only trained persons may open the Industrial PC housing

Attention

The operator is responsible for ensuring that only trained electrical staff opens the
housing of the Industrial PC.

1.4.1 National regulations

Depending on the type of machine and plant in which the Industrial PC is used, national regulations
governing the controllers of such machines will apply, and must be observed by the operator. These
regulations cover, amongst other things, the intervals between inspections of the controller. The operator
must initiate such inspections in good time.

1.4.2 Procedure in the event of a fault

In the event of faults at the Industrial PC, the list in the section Troubleshooting can be used to determine
the measures to be taken.

1.4.3 Operator requirements

Anyone who uses the Industrial PC must have read these operating instructions and must be familiar with
all the functions of the software installed on the Industrial PC to which he has access.

6 C6920/ C6925

Product Description

2 Product Description

2.1 Product overview

C6920 | Control cabinet Industrial PC

The Industrial PC C6920 is designed for control cabinet installation. The compact case is equipped with a
3½-inch motherboard for Intel® Celeron® or Core™ i3/i5/i7. All PC connections are located at the front of
the housing. The cooling is done by internal cooling fins and an easily exchangeable fan cartridge at the
bottom of the housing.

C6925 | Fanless control cabinet Industrial PC

The Industrial PC C6925 is designed for control cabinet installation. The compact housing is equipped
with an Intel® Celeron® M ULV processor or Intel® Atom™ processor with up to four cores on a 3½-inch
motherboard. All PC connections are located at the front of the housing. The cooling is done by cooling
fins inside the housing. The PC can operate at temperatures up to 55 °C.

The Industrial PCs offer the following benefits:

• Industrial PC for space-saving control cabinet installation

• mounting sheet at the rear wall

• all connectors on the front

• status LEDs

• lithium battery accessible behind the front flap

• protection class IP 20

• operating temperature 0…55 °C.

C6920/ C6925 7

Product Description

2.2 Appropriate Use

The C6920/ C6925 series Industrial PCs are designed for mounting in control cabinets for machine and
plant engineering applications.

Risk of explosion!

Danger

The Industrial PC must not be used where there is a risk of explosion.

Front view of C6920/
C6925

C6920

C6925

The C6920 is fitted with a fan cartridge with observated double ball bearing fans, exchangeable at the
front.

The C6925 is a fanless Industrial PC with passive cooling.

8 C6920/ C6925

Product Description

2.3 Access to the battery and drives

Access to hard-disk
(optional), CF-Card/
CFast-Card and the battery

1

3

4

2

Opening the front flap (1) allows access to the battery (2), the CF-Card/ CFast-Card (3) and the hard
disk (4) (optional).

When provided with a CF-Card the ejection of the card occurs by pressing the eject button below the card
slot.

Danger of Explosion!

WARNING

Replace battery only with the identical type or an alternative type recommended by the
manufacturer. Notice correct polarity!

Polarity of the battery:

-

+

Handling of Lithium Batteries

WARNING

Lithium Batteries should not be recharged, exposed to fire, opened and they should be
protected against sunlight and moisture.

C6920/ C6925 9
