Beckhoff C3640 Installation Manual

Installation- and Operating instructions for

Build-in Industrial PCs
C3620, C3640 from -0060

Version: 4.0
Date: 2020-04-24

Table of contents

C3620, C3640 1

Table of contents

1. General instructions 3

Notes on the Documentation 3

Liability Conditions 3
Trademarks 3
Patent Pending 3
Copyright 3
State at Delivery 3
Delivery conditions 3

Description of safety symbols 4
Basic safety measures 5
Operator's obligation to exercise diligence 6
Operator requirements 6

2. Product Description 7

Appropriate Use 7
Structure of the C3620 7
Structure of the C3640 8
CD/DVD-Drive (optional) 8
Interfaces from C3620/ C3640-0060 9

PS/2 connections 9
USB interfaces 9
Network connection 9
DVI-D (Digital Visual Interface) 9
Serial interfaces 9
DisplayPort 9
Sound-On-Board 9
Additional plug-in cards (optional) 9

3. Installation Instructions 10

Transport and Unpacking 10

Transport 10
Unpacking 10

Installation of the PC in the control cabinet 11

Earthing measures 11

Power Supply Connection 12

Power Supply Configuration 12
Pin assignment and cable requirements 13
Fitting the Power Supply Cable 14
Connecting Power Supply 15
Wiring diagram 16

Connecting devices 17

Connecting cables 17
Check voltage rating and connect. 17

4. Operating Instructions 18

Switching the Industrial PC on and off 18

First switching on and driver installation 18

Maintenance 19

Cleaning the Industrial PC 19
Replacing the battery on the motherboard 19
Servicing 19

Shutting down 19

Disposal 19

5. Troubleshooting 20

Fault correction 20
Service and Support 21

Beckhoff's branch offices and representatives 21
Beckhoff headquarters 21

Table of contents

2 C3620, C3640

Beckhoff Support 21
Beckhoff Service 21

6. Assembly dimensions 22

Industrial PC C3620 22
Industrial PC C3640 23
Mounting Opening 24

7. Appendix 25

Technical data 25
Approvals 25

FCC: Federal Communications Commission Radio Frequency Interference
Statement 25
FCC: Canadian Notice 25

General instructions

C3620, C3640 3

General instructions

Notes on the Documentation

This description is only intended for the use of trained specialists in control
and automation engineering who are familiar with the applicable national
standards. It is essential that the following notes and explanations are
followed when installing and commissioning these components.
The responsible staff must ensure that the application or use of the
products described satisfy all the requirements for safety, including all the
relevant laws, regulations, guidelines and standards.

Liability Conditions

The documentation has been prepared with care. The products described
are, however, constantly under development. For that reason the
documentation is not in every case checked for consistency with
performance data, standards or other characteristics. In the event that it
contains technical or editorial errors, we retain the right to make alterations
at any time and without warning. No claims for the modification of products
that have already been supplied may be made on the basis of the data,
diagrams and descriptions in this documentation.
All pictures shown in the documentation are exemplary. Illustrated
configurations can differ from standard.

Trademarks

Beckhoff®, TwinCAT®, EtherCAT®, Safety over EtherCAT®, TwinSAFE®
and XFC® are registered trademarks of and licensed by Beckhoff
Automation GmbH.
Other designations used in this publication may be trademarks whose use
by third parties for their own purposes could violate the rights of the
owners.

Patent Pending

The EtherCAT Technology is covered, including but not limited to the
following patent applications and patents:
EP1590927, EP1789857, DE102004044764, DE102007017835
with corresponding applications or registrations in various other countries.
The TwinCAT Technology is covered, including but not limited to the
following patent applications and patents:
EP0851348, US6167425 with corresponding applications or registrations in
various other countries.

Copyright

© Beckhoff Automation GmbH & Co.KG.
The reproduction, distribution and utilization of this document as well as the
communication of its contents to others without express authorization are
prohibited. Offenders will be held liable for the payment of damages. All
rights reserved in the event of the grant of a patent, utility model or design.

State at Delivery

All the components are supplied in particular hardware and software
configurations appropriate for the application. Modifications to hardware or
software configurations other than those described in the documentation
are not permitted, and nullify the liability of Beckhoff Automation
GmbH & Co.KG.

Delivery conditions

In addition, the general delivery conditions of the company Beckhoff
Automation GmbH & Co.KG apply.

General instructions

4 C3620, C3640

Description of safety symbols

The following safety symbols are used in this operating manual. They are
intended to alert the reader to the associated safety instructions.

Danger

This symbol is intended to highlight risks for the life or health of personnel.

Warning

This symbol is intended to highlight risks for equipment, materials or the
environment.

i

Note

This symbol indicates information that contributes to better understanding.

General instructions

C3620, C3640 5

Basic safety measures

Only switch the PC off after
closing the software

Before the Industrial PC is switched off, software that is running must
be properly closed.

Otherwise it is possible that data on the hard disk is lost. Please read the
section Switching the Industrial PC on and off.

Warning

Switch off all parts of the equipment, then uncouple the fieldbus!

Before opening the housing of the PC, and whenever the PC is being used
for purposes other than plant control, such as during functional tests
following repair, all parts of the equipment must first be switched off, after
which the Industrial PC can be uncoupled from the plant.

Pulling out the fieldbus connection plug uncouples the PC (optional).
Items of equipment that have been switched off must be secured against

being switched on again.

Danger

Displays used for the PCs LC-display are operated with a voltage of up to
1000 V, depending on type. For that reason:

The supply voltage must be disconnected before the housing of the

Control Panel is opened.

The Industrial PC’s power supply unit must be supplied with
100 V

AC

- 240 VAC or 24VDC (optional).

Danger

Do not open the power supply unit while voltage is applied!

The supply voltage must be switched off before the power supply unit
housing is opened.

Do not exchange any parts when under power!

When components are being fitted or removed, the supply voltage must be
switched off.

Fitting work on the Industrial PC can result in damage:

• If metal objects such as screws or tools fall onto operating circuit
boards.

• If connecting cables internal to the PC are removed or inserted
during operation.

• If plug-in cards are removed or inserted when the PC is switched
on.

General instructions

6 C3620, C3640

Operator's obligation to exercise diligence

The operator must ensure that

• the Industrial PC is only used for its intended use (see also chapter

Product Description).

• the Industrial PC is in a sound condition and in working order
during operation.

• the operation manual is in good condition and complete, and
always available for reference at the location of the Industrial PC.

• the Industrial PC is operated, maintained and repaired only by
sufficiently qualified and authorized personnel.

• the personnel is instructed regularly about relevant occupational
safety and environmental protection aspects, and is familiar with
the operating manual and in particular the safety notes contained
herein.

• none of the safety and warning notes attached to the Industrial PC
are removed, and that all notes remain legible.

National regulations
depending on the machine
type

Depending on the type of machine and plant in which the Industrial PC is
being used, there will be national regulations for the control of such
machines and plant that the operator must observe. These regulations
cover, amongst other things, the intervals between inspections of the
controller.

The operator must initiate such inspections in good time.

Warning

Only trained persons may open the Industrial PC housing!

The operator is responsible for ensuring that only trained electrical staff
opens the housing of the Industrial PC.

Procedure in the event of a
fault

In the event of a fault in the Industrial PC, appropriate measures can be
determined with the aid of the list in the Fault correction section.

Operator requirements

Read the operating
instructions

Every user of the Industrial PC must have read these operating
instructions.

Software knowledge

Every user must be familiar with any of the functions of the software
installed on the PC that he can reach.

Product Description

C3620, C3640 7

Product Description

Appropriate Use

The C3620 and C3640 Industrial PCs are designed for mounting in control
cabinets in machine and plant engineering applications.

Structure of the C3620

View of the open PC C3620

Opening the housing

After loosening the two screws (see arrows) the front of the PC with TFT­display can be opened, thus providing access to the drive (optional),
3½“ hard disk, processor, memory and plug-in cards.

An ATX motherboard with seven slots for plug-in cards is located behind
the removable card holder and the swivel-mounted power supply unit.

The connections of the Industrial PC to the outside are located on top of
the housing.

100-240 VAC­full range power supply

3½“ hard disk

Slimline CD/ DVD­ROM-drive (optional)

12“ TFT-display

card holder

7-Slot­ATX motherboard

Product Description

8 C3620, C3640

Structure of the C3640

View of the open PC C3640

Opening the housing

After loosening the two screws (see arrows) the front of the PC with TFT­display can be opened, thus providing access to the drive (optional),
3½“ hard disk, processor, memory and plug-in cards.

An ATX motherboard with seven slots for plug-in cards is located behind
the removable card holder and the swivel-mounted power supply unit.

The connections of the Industrial PC to the outside are located on top of
the housing.

CD/DVD-Drive (optional)

Configuration with
CD/DVD-drive (optional)

Optional the Industrial PC is fitted with a CD/ DVD-drive.
The drive is located at the rear side of the PC.

100-240 VAC­full range power supplyl

3½“ hard disk

Slimline CD/ DVD­ROM drive (optional)

15“ TFT-display

card holders

7-Slot­ATX motherboard

Product Description

C3620, C3640 9

Interfaces from C3620/ C3640-0060

ATX motherboard
interfaces

PS/2 connections

PS/2

The upper PS/2 connector (X104) allows a PS/2 mouse to be used, while a
PC keyboard can be connected to the lower PS/2 connector (X103).

USB interfaces

USB1 – USB4

The four USB interfaces (X108 – X111) are used to connect
peripheral devices with USB connections:

▪ Devices with Intel® 4th generation processors

(C3620/ C3640-0060) are equipped with 2 USB2.0 (X110,
X111) and 2 USB3.0 (X108, X109) interfaces.

▪ Devices from Intel® 6th and 7th generation processors

(C3620/ C3640-0070) are equipped with 4 USB3.0
interfaces.

Network connection

LAN1, LAN2

The RJ-45 connectors (X112, X113) allow the PC to be connected to a
10/100/1000BASE-T Local Area Network (LAN).

DVI-D (Digital Visual Interface)

DVI out

The DVI connectors (X114, X115) are used for transferring the video
signal. DVI-D standard is supported.

Serial interfaces

RS 232
COM1 – COM2

The basic version of the Industrial PC has one serial interface, COM1
(X116), using the type RS 232, which is brought to a 9 pin SUB-D plug
connector.

DisplayPort

DisplayPort

The DisplayPort (X117) is used for transferring the video signal.

Sound-On-Board

Sound

The Industrial PC has an on-board-interface with the following connectors:
Line In (X122), Line Out (X121) and Microphone jack (X120).

Additional plug-in cards (optional)

Type plate

There is a type plate on the top of the Industrial PC which provides
information about the hardware configuration of the Industrial PC at the
time it was supplied.

Installation Instructions

10 C3620, C3640

Installation Instructions

Please also refer to chapter General instructions.

Transport and Unpacking

The specified storage conditions must be observed (see chapter Technical

data).

Transport

Despite the robust design of the unit, the components are sensitive to
strong vibrations and impacts. During transport, your Industrial PC should
therefore be protected from excessive mechanical stress. Therefore,
please use the original packaging.

Warning

Danger of damage to the unit!
If the device is transported in cold weather or is exposed to extreme
variations in temperature, make sure that moisture (condensation) does not
form on or inside the device.

Prior to operation, the unit must be allowed to slowly adjust to room
temperature. Should condensation occur, a delay time of approximately 12
hours must be allowed before the unit is switched on.

Unpacking

Proceed as follows to unpack the unit:

1. Remove packaging.

2. Do not discard the original packaging. Keep it for future relocation.

3. Check the delivery for completeness by comparing it with your order.

4. Please keep the associated paperwork. It contains important
information for handling the unit.

5. Check the contents for visible shipping damage.

6. If you notice any shipping damage or inconsistencies between the
contents and your order, you should notify Beckhoff Service.

Installation Instructions

C3620, C3640 11

Installation of the PC in the control cabinet

The C3620 and C3640 Industrial PCs are designed for rack mounting in
machine and plant engineering applications.

The ambient conditions specified for operation must be observed (see the
section Technical data).

Preparation of the control
cabinet wall

The control cabinet wall must be prepared with the required mounting
opening for the computer unit and the eight holes for the set screws
according to the PC's dimensions (see chapter Assembly dimensions).

i

Note

When the unit is installed in an enclosure, adequate space for
ventilation and for opening the PC must be provided.

Please note the following points during installation of the PC:

• Position the PC in such a way that reflections on the screen are
avoided as far as possible.

• Use the position of the screen as a guide for the correct installation
height; it should be optimally visible for the user at all times.

• The PC should not be exposed to direct sunlight.

• When the unit is in its mounting position, the ventilation openings must

not be obstructed.

Warning

Extreme environmental conditions should be avoided as far as
possible. Protect the rear of your PC from dust, humidity and heat.

The clearance above and below the housing must be at least 100 mm
in order to ensure adequate ventilation of the PC.

The ventilation slots of the PC must not be covered.

Installation in a control
cabinet wall

Proceed as follows:

1. Insert the PC at the intended control cabinet wall position and protect it
from falling out, prior to final mounting.

2. Us ing 8 M4 nuts, fix the PC to the control cabinet wall by screwing the
nuts from the rear onto the set screws of the PC housing.

Earthing measures

Earthing measures

Earthing connections dissipate interference from external power supply
cables, signal cables or cables to peripheral equipment.

Establish a low-impedance connection from the earthing point on the PC
housing to the central earthing point on the control cabinet wall, in which
the computer is being installed. The earthing connection of the Industrial
PC is located beside the power supply connector.

Installation Instructions

12 C3620, C3640

Power Supply Connection

The 5-pin CAGE CLAMP plug connector and mounting flange illustrated is
located on the PC housing in order to connect the power supply.

Socket at the PC housing

Connection socket when
fitted with 100-240 VAC,
50-60 Hz power supply
unit (standard)

Technical data

Connecting socket

Number of contacts

5

Contact spacing

5 mm

Minimum conductor cross-section

1.5 mm²

Minimum conductor cross-section

(AWG)

16

Rated voltage (EN)

250 V

Rated voltage (CSA)

300 V

Current EN [A]

12 A

Current CSA [A]

15 A

Length of stripped conductor

8 to 9 mm

Power Supply Configuration

Supplied mains power unit

The Industrial PCs is either fitted with a 100-240 VAC, 50-60 Hz power
supply unit (standard) or with a 24 VDC power supply unit (with the option of
an uninterruptible power supply, UPS).

Current carrying capacity of
the 100-240 V power
supply unit

Output voltages from

the 100-240 V power

supply unit

Current loading
maximum

+3,3 V

16 A

+5 V stand by

2 A

+5 V

25 A

-5 V

0.3 A

+12 V

13 A

-12 V

0.8 A

Current carrying capacity of
the 24 V power supply unit

Output voltages from

the 24 V power supply

unit

Current loading
maximum

+5 V

25 A

-5 V

1 A

+12 V

10 A

-12 V

1.5 A

Installation Instructions

C3620, C3640 13

Coding pieces

The connectors are coded differently at the factory, using snap-on coding
pieces, according to the power supply unit that has been fitted.

Differently coded plug
connectors

Coding for the 100-240 VAC,
50-60 Hz power supply unit

Coding for the 24 VDC power supply
unit

Pin assignment and cable requirements

Pin assignment

There is an adhesive label with the pin assignments on the top of the
female plug connector. The minimum permitted conductive cross-

section is 1.5 mm², fused for 10 A (AWG 16).
Industrial PCs with 100-240 VAC, 50-60 Hz power supply unit

Pin assignment for the
100-240 V, 50-60 Hz power
supply unit

Pin

Function

1

N

100 – 240V

AC

Power supply

2

L

3

4

not used

5

not used

Industrial PCs with 24 VDC power supply unit

Pin assignment for the
24 VDC power supply unit

Pin assignment for
connecting the power
switch

Pin

Funktion

1

Power-Status

2

PC_ON

3

24 VDC Versorgungsspannung + Pol

Pin

Function

1

+

24V

DC

Power supply

2

-

3

4

not used

5

not used

5 4 3 2 1 5 4 3 2

1

1 2 3

Installation Instructions

14 C3620, C3640

Fitting the Power Supply Cable

A 5-pin female plug connector with CAGE CLAMP connection and insertion
catches is supplied along with a snap-on strain relief housing in order to
assemble the PC power supply cable.

Materials for assembly of
the connector

Female plug connector

Strain relief housing

Female plug connector is
correspondingly coded

This female plug connector is also coded at the factory, according to the
type of power supply fitted, so that the plug, when assembled, will fit the
Industrial PC's connecting socket.

Technical data

Female plug connector

Number of contacts

5

Contact spacing

5 mm

Minimum conductor cross-section

1.5 mm²

Minimum conductor cross-section

(AWG)

16

Rated voltage (EN)

250 V

Rated voltage (CSA)

300 V

Current (EN)

16 A

Current (CSA)

15 A

Length of stripped conductor

8 to 9 mm

Fitting the connector to the
cable

The plug is fitted to the cable as follows:

1. Strip insulation from the cable ends. Follow the technical data for

the female plug connector in the above table!

2. Push the conductors into their mountings, simply by pushing them

in as indicated on the pin assignment label.

3. Push the lower part (part A) of the strain relief housing (see

photograph on page 14) onto the top of the female plug connector
until it snaps into place.

4. Relieve the strain on the supply cable by fixing it in place with the

cable clamp (part C) and fixing screws (part D) (see photograph
below).

Applying the strain relief

Fix the upper part (part B) of the strain relief housing by snapping it onto
the lower part.

A

B C D

Installation Instructions

C3620, C3640 15

Cable-cross-section for
connection of power supply

Warning

PC_ON and power status

Warning

UPS output

UPS output function

Connecting Power Supply

The external wiring consists of the connection of the power supply, the
battery pack (optional) and the connection of customized components for
shutting down the PC.

Cable Cross Sections

For the connection of the power supply, wiring with a cable-cross-section of

1.5 mm2 must be used.
With bigger distances between voltage source and PC, you take the

voltage drop as a function of the cable-cross-section as well as voltage
fluctuations of your distribution voltage into account, so that is secured that
the voltage doesn't fall under 22 V at the power supply.

The power supply must be protected with maximum 16 A.

Configuration for shutting down the PC

The connections for shutting down the Industrial PCs are established via
the PC_ON input and the Power Status output.

PC_ON and Power Status functions

• If the PC_ON input is connected to 24 V via a switch, the PC shuts

down according to the rules. The PC_ON signal is inverted, i.e. the
PC shuts down if the 24 V connection is live.

• If the PC_ON input is NOT connected by the user, the PC can be

booted in the familiar way by connecting the supply voltage and
shut down via the battery by switching off the supply voltage.

This procedure significantly reduces the service life of the
rechargeable battery and should therefore not be used.

• Once the PC has shut down, the Power Status output is switched

from 24 V to 0 V. Via this output a signal lamp can be connected or
a contactor for de-energizing the whole system. The maximum
load for the Power Status output is 0.5 A and a suitable fuse
should be provided.

UPS output

In order to maintain a screen display for the PC in the event of a power
failure, the power supply unit is equipped with a UPS output for connecting
a Control Panel. The maximum load for the output is 1.4 A (max. 2.5 A
from 2016 and later).

UPS output function

• The 24 V DC connection at the UPS output is live even after a

power failure. The maximum load is 1.4 A (max. 2.5 A from 2016
and later).

• Once the PC has been de-energized via the UPS software, the

UPS output is switched to 0 V. Any connected panel is thus
switched off, and total discharge of the rechargeable battery is
prevented.

Installation Instructions

16 C3620, C3640

Wiring diagram external
switch and power supply

Wiring diagram

Wiring according to the wiring diagram (the circuit of PC_ON and Power­Status is symbolical):

Connection of the Battery Pack and UPS Output only in combination with
integrated UPS (order option).

Installation Instructions

C3620, C3640 17

Connecting devices

Warning

The power supply plug must be withdrawn!
Please read the documentation for the external devices prior to connecting

them.
During thunderstorms, plug connector must neither be inserted nor

removed.
When disconnecting a plug connector, always handle it at the plug. Do not

pull the cable!

Connecting cables

The connections are located at the side of the Industrial PC and at the rear
(power supply connection), and are documented in the section Product

Description.

When connecting the cables to the Industrial PC, proceed according to the
following sequence:

• Switch off all the devices that are to be connected.

• Disconnect all the devices that are to be connected from the power

supply.

• Connect all the cables between the Industrial PC and to the

devices that are to be connected.

• Connect all data transfer cables (if present) to the appropriate

plug-in receptacles of the data/telecommunication networks.

• Reconnect all devices to the power supply.

Check voltage rating and connect.

With compact 100-240 VAC 50/60 Hz power supply:

1. Check that the mains voltage is correct.

2. Insert the power supply cable that you have assembled (see the

section on Fitting the Power Supply Cable) into the Industrial PC's
power supply socket. Then connect it to a power socket with a
grounded earth connection.

When fitted with the (optional) 24 VDC power supply unit:

1. Check that the external power supply is providing the correct

voltage.

2. Insert the power supply cable that you have assembled (see the

section on Fitting the Power Supply Cable) into the Industrial PC's
power supply socket. Then connect it to your external 24 V power
supply.

Warning

If a 24 V UPS is installed, the correct type of rechargeable battery
must be used.

Operating Instructions

18 C3620, C3640

Operating Instructions

Switching the Industrial PC on and off

Switch on

The Industrial PC does not have its own mains switch. The Industrial PC
will start when the equipment is switched on, or when it is connected to the
power supply.

Shutting down and
switching off

When the plant is switched off, or when it is disconnected from its power
supply, the Industrial PC will be switched off.

Control software such as is typically used on Industrial PCs permits various
users to be given different rights. A user who may not close software may
also not switch the Industrial PC off, since data can be lost from the hard
disk by switching off while software is running.

Warning

First shut down, then switch off the PC!

If the Industrial PC is switched off as the software is writing a file to the
hard disk, the file will be destroyed. Control software typically writes
something to the hard disk every few seconds, so that the probability of
causing damage by switching off while the software is running is very high.

Warning

When you have shut down the Industrial PC, you have to switch off power
supply for at least 10 seconds before rebooting the system.
After resetting power supply the PC will start booting automatically.

First switching on and driver installation

When you switch on the Industrial PC for the first time, the pre-installed
operating system (optional) will be started. In this case, all the required
drivers for any additional, optional hardware components ordered with the
PC will already have been installed.

If the PC was ordered without operating system, you have to install the
operating system and the driver software for any auxiliary hardware
yourself. Please follow the instructions in the documentation for the
operating system and the additional devices.

Operating Instructions

C3620, C3640 19

Maintenance

Please also refer to chapter General instructions.

Cleaning the Industrial PC

Danger

Switch off the Industrial PC and all connected devices, and disconnect the
Industrial PC from the power supply.

The Industrial PC can be cleaned with a soft, damp cloth. Do not use any
aggressive cleaning materials, thinners, scouring material or hard objects
that could cause scratches.

Replacing the battery on the motherboard

A used battery on the motherboard has to be replaced according to the
rules of the board manufacturer.

Danger

Danger of Explosion!

Replace battery only with the identical type or an alternative type
recommended by the manufacturer. Notice correct polarity!

Danger

Handling of Lithium Batteries

Lithium Batteries should not be recharged, exposed to fire, opened and
they should be protected against sunlight and moisture.

The used battery must be disposed of in accordance with national
electronics scrap regulations.

Servicing

The Industrial PC requires no maintenance.

Shutting down

Disposal

Dismantling the Industrial
PC

Observe national
electronics scrap
regulations

The device must be fully dismantled in order to dispose of it. The housing
can be sent for metal recycling.

Electronic parts such as disk drives and circuit boards must be disposed of
in accordance with national electronics scrap regulations.

Troubleshooting

20 C3620, C3640

Troubleshooting

Please also refer to chapter General instructions.

i

Note

Pixel errors in the TFT display are production-caused and represent
no complaint-reason!

Fault correction

Fault

Cause

Procedure

Nothing happens after the Industrial
PC has been switched on

No power supply to the Industrial
PC

Other cause

Check power supply cable

Call Beckhoff Service

The Industrial PC does not boot
fully

CD in drive (optional).

Setup settings are incorrect

Other cause

Remove CD and press any
key

Check the setup settings

Call Beckhoff Service

Computer boots, software starts,
but control does not operate
correctly

Cause of the fault is either in the
software or in parts of the plant
outside the Industrial PC

Call the manufacturer of the
machine or the software

Error during CD access

Faulty CD

Faulty disk drive

Check the disk in another
disk drive

Call Beckhoff Service

The Industrial PC functions only
partially or only part of the time, e.g.
no or dark picture, but disk drive
responds when switching on

Defective components in the
Industrial PC

Call Beckhoff Service

C3620, C3640 21

Service and Support

Beckhoff and their partners around the world offer comprehensive service
and support, making available fast and competent assistance with all
questions related to Beckhoff products and system solutions.

Beckhoff's branch offices and representatives

Please contact your Beckhoff branch office or representative for local

support and service on Beckhoff products!

The addresses of Beckhoff's branch offices and representatives round the
world can be found on her internet pages:

http://www.beckhoff.com

You will also find further documentation for Beckhoff components there.

Beckhoff headquarters

Beckhoff Automation GmbH & Co. KG
Huelshorstweg 20
D-33415 Verl
Germany

Phone:

+49(0)5246/963-0

Fax:

+49(0)5246/963-198

e-mail:

[e-mail]

Beckhoff Support

Support offers you comprehensive technical assistance, helping you no
only with the application of individual Beckhoff products, but also with
other, wide-ranging services:

• world-wide support

• design, programming and commissioning of complex automation

systems

• and extensive training program for Beckhoff system components

Hotline:

+49(0)5246/963-157

Fax:

+49(0)5246/963-9157

e-mail:

[e-mail]

Beckhoff Service

The Beckhoff Service Center supports you in all matters of after-sales
service:

• on-site service

• repair service

• spare parts service

• hotline service

Hotline:

+49(0)5246/963-460

Fax:

+49(0)5246/963-479

e-mail:

[e-mail]

Quote the project number

If servicing is required, please quote the project number of your Industrial
PC.

Assembly dimensions

22 C3620, C3640

Assembly dimensions

Industrial PC C3620

Warning

The assembly of the unit must take place with the orientation diagrammed
here.

All dimensions in mm.

front view
left view

rear view

Assembly dimensions

C3620, C3640 23

Industrial PC C3640

Warning

The assembly of the unit must take place with the orientation diagrammed
here.

All dimensions in mm.

front view

left view

rear view

Assembly dimensions

24 C3620, C3640

Mounting Opening

A mounting opening according to the following diagram is required:

Mounting opening for
C3620

Mounting opening for
C3640

Appendix

C3620, C3640 25

Appendix

Technical data

Dimensions

C3620

Dimensions (W x H x D): 388 x 324 x 201 mm
Weight: 11.5 kg (basic configuration)

C3640

Dimensions (W x H x D): 470 x 348 x 199 mm
Weight: 14.1 kg (basic configuration)

Color
Display

C3620

Size, Resolution: 12“, 800 x 600 dpi

C3640

Size, Resolution: 15“, 1024 x 768 dpi

Do not use the PC in areas
of explosive hazard

The Industrial PC may not be used in areas of explosive hazard.
The following conditions must be observed during operation:

Environmental conditions

Ambient temperature: 0 to 55°C
Atmospheric humidity: Maximum 95%, non-condensing

Shock resistance

Sinusoidal vibration:
(EN 60068-2-6) 10 to 58 Hz: 0.035 mm

58 to 500 Hz: 0.5 G (~ 5 m/ s2)

During reading of CD-ROM: 10 to 58 Hz: 0.019 mm

58 to 500 Hz: 0.25 G (~ 2.5 m/ s2)

Impact:
(EN 60068-2-27) 5 G (~ 50 m/ s²), duration: 30 ms
During reading of CD-ROM: 5 G (~ 50 m/ s²), duration: 11 ms

Protection class

Protection class: Front side IP65, rear side IP20

Power supply with
100-240 VAC power supply
unit or 24 VDC power supply
unit (optional)

Supply voltage: 100-240 VAC 50-60 Hz
Optional: 24 V

DC

(22 – 30 VDC)

Power consumption: C3620-0020: ca. 89 W
(for the basic version) C3620-0030: ca. 114 W
C3640-0020: ca. 98 W
C3640-0030: ca. 123 W
If operated with UPS: additional 30 W (while charging)

Electromagnetic
Compatibility (EMC)

Interference resistance: according to EN 61000-6-2
Emitted resistance: according to EN 61000-6-4

Transport and storage

The same values for atmospheric humidity and shock resistance are to be
observed during transport and storage as in operation. The shock
resistance during transport can be improved by means of suitably packing
the Industrial PC. The ambient temperature during storage and transport
must be between -20°C and +65°C.

i

Note

Pixel errors in the TFT display are production-caused and represent
no complaint-reason!

Approvals

FCC: Federal Communications Commission
Radio Frequency Interference Statement

FCC Approval for USA

This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his
own expense.

FCC: Canadian Notice

FCC Approval for Canada

This equipment does not exceed the Class A limits for radiated emissions as
described in the Radio Interference Regulations of the Canadian Department of
Communications.
