B. Connected.
Outlook®300 Safety Infusion System
Improve safety, efficiency and workflow across
departments with wireless access to infusion data.
For Advanced Infusion Therapy
Safety and Efficiency
Improve your ability to monitor
safe medication practices
• Improve department efficiency
by identifying trends in medication
delivery and usage
• Help reduce medication
errors proactively
• Access a real-time view of
IV therapy progress for
continuous maintenance
• Capture the cost of “lost”
doses with an audit that
can close the billing loop
B. Innovative.
“The ability to access real-time
infusion data helps improve
safety and reduce potential
IV medication errors before
they happen.”
Hospital
Interface
WIRELESS NETWORK
• Real-time infusion status
• Drug usage per care area
Pharmacy
• Dose limit alerts
• Dose limit overrides
• Drug usage per care area
Risk Management
• Real time ope
• Automated Ch
• Integration wi
Nursing
• Asset Uilization
• Preventative maint
Biomedical Engine
“Real-time access to
infusion status is important
to me, especially if it helps
me address patient and
clinician safety proactively.”
“A new technology needs to be easy
to implement. But when it improves
the safety and overall efficiency of
operations, multiple departments gain.”
Leverage real-time data collected
at the point of care for easy use by
multiple departments
• Easy integration with existing hospital
information systems via open
architecture
• Utilizes industry standard 802.11b
wireless protocol
• Minimize network traffic and enable
easy translation with ASCII data string
• Enable authorized users to access real-
time infusion data – from a PDA, at the
nursing station, in the pharmacy, or at
the pump
• Eliminate the need for externally
mounted interface with built-in
wireless radio
Improve the quality, safety and
efficiency of patient care, without
impacting clinical workflow, using
wireless communication
• Immediate access to DoseGuard™ dose limit
data for continuous safety improvement
• Track medication delivery trends to identify
clinical support and training needs
• At-a-glance visualization of vital
information concerning patient’s IV therapy
• Focus more time on patient care with
automated charting
ration/alarm display
Promote Safe IV Medication Delivery.
Preventing medication errors begins
with confirming the right patient with
the right drug and the right dose along
with the right route, the right time,
and the right clinician.
Outlook™300 Safety Infusion System
SPECIFICATIONS
Mechanism: Volumetric, Positive Pressure Displacement Reservoir
Width: 30.5 cm (12 in)
Height: 11.4 cm (4.5 in)
Depth: 22.2 cm (8.75 in)
Weight: 5 kg (11 lbs)
Power: 120 VAC, 3A, 60 Hz USA excluding accessories
Grounding
Resistance: Meets UL Standard 2601-1
Leakage
current: Meets or Exceeds UL Standard 2601-1
Battery: 12 V sealed lead-acid battery
Battery
Operating Time: 2.5 hours ± 30 min. at 125 mL/hr
Rate Range: 0.1 to 999.9 mL/hr in 0.1 mL increments
Micro Mode: 0.1 to 99.9 mL/hr in 0.1 mL increments
Volume to be
Infused Range: 0.1 to 9999.9 mL in 0.1 mL increments
Variable
Occlusion
Pressure: 75, 100, 200, 300, 400, 500, and 750 mmHg
KVO Rate: 3 mL/hr or selected rate whichever is lower
Volumetric
Accuracy: ± 5%
Alarms: Air-in-Line, Bag Empty, Door Open, Downstream Occlusion,
Hold time Exceeded, Low Battery, Plug-in, System Error,
Upstream Occlusion, Check Set, DoseGuard™ Alert
Memory: Permanent data retention after the pump is turned off
unless alternative Data Retention Defaults have been
selected in the Biomed Options
Tubing: Horizon® Pump Sets
Modes/Features: DoseScan,™ Dose Mode with Drug Menu and DoseGuard™
dose limits, Primary and Piggyback Modes, Set Time and
Volume, Schedule Next Run, Profile Mode for TPN,
Program Mode, q(x) Mode, Site Trend, Variable Occlusion
Pressure, Micro Mode, Epidural Mode
Laser: Class 2 Per IEC 60825-1*
Wireless Radio: 2.4 GHz, 802.11b
Please contact your B. Braun sales representative for information on availability.
*Applies to laser barcode scanner.
B. Safe.
Extend your Outlook on Safety.
Schedule a consultation with a
B. Braun Infusion Specialist by calling
1-800-227-2862.
