The Guide and the Reference book
This Guide contains all the information you need to get the full benefit of your
product. The Reference book contains information about connecting and
operating external equipment, as well as an overview of on-screen menus.
An explanation of symbols in the Guide
and Reference book
Buttons on the Beo4
remote control
TV
LIST
m
p
Display on the Beo4 remote
STORE
control
Display on the screen
TV 12
We expect your Bang & Olufsen retailer to deliver, install and set up your product.
However, the information required to install and set up the product is included in the
Guide and the Reference book. This is useful if you move your product or expand
your system at a later date.
The Guide and the Reference book both contain an index which can help you find
the specific subject you want to know more about.
Contents
Introducing your BeoSystem 1, 4
Find out how to use the Beo4 remote control and bring up the menus on the
screen.
Daily use, 7
Find out all there is to know about the daily use of BeoSystem 1, including how to
turn it into a Home Theatre for watching movies and how to use teletext functions.
Advanced operation, 15
All you need to know about using BeoSystem 1 beyond daily use, such as advanced
teletext, set-top box operation, and the pincode system.
Tuning and preference settings, 25
Find out how to tune in channels. This chapter also contains information about
settings for time, date, picture and sound.
3
Placement, connections and maintenance, 39
Find out how to handle and place your BeoSystem 1, connect additional video
equipment, and where the sockets are placed.
Index, 51
4
The Beo4 remote control gives you
access to all functions. When a
function is in use, you are informed
via displays on Beo4 or on the screen.
Introducing BeoSystem 1 and Beo4
Switch on BeoSystem 1
Switch on a set-top box. Only available if a set-top
box is connected and registered as STB (SAT)
Select channels or teletext pages or enter data in
on-screen menus
Switch on teletext
Step between channels and move through menu
options
Move the cursor from setting to setting in a fill-in
menu
Accept and store instructions or settings
Reveal additional functions in the Beo4 display,
such as FORMAT
TV
SAT
0 – 9
TEXT
m
p
l n
GO
LIST
TV LIGHT RADIO
SAT DVD CD
V MEM RECORD A MEM
789
456
123
TEXT
LIST EXIT
STOP
MENU
0
GO
TV
FORMAT
MENU
STOP
EXIT
r
u
•
The Beo4 display shows the source you have
selected, or extra functions available when you
press the LIST button
Bring up the main menu for access to a T V list,
timed playback and timed standby, and setup
options
Press to go from one menu back to a previous
menu
Exit all on-screen menus
Adjust sound volume; press in the middle to mute
the sound
Switch BeoSystem 1 to standby
For information on how to add extra functions to
those shown in the Beo4 display, refer to the
chapter ‘Customise Beo4’ on page 18 in the
Reference book.
5
Displayed information and menus
Information about the selected source is
shown at the top of the screen. On-screen
menus allow you to adjust settings.
TV 12
VOL 30
Menu
1 Timer play
2 TV list
3 Setup
On-screen menus give you either a
vertical list of options to choose from or
a horizontal list of set tings to fill in.
You can choose whether or not you
want the navigation cues in the menus
to be shown. The function is activated
from the factory, but you can choose
to deactivate it. Bring up ‘Menu’ from
the ‘Setup’ menu and choose ‘On’ to
activate navigation cues or ‘Off ’ to
deactivate them.
The selected source is shown briefly when you
switch it on. Volume level is shown while you
adjust it, and disappears after a few seconds.
Source Pr Start Stop Date
TV 1 13:30 - 14:30 27 Oct OK
Press MENU for Timer index
Source Pr Start Stop Date
TV 1 13:30 - 14:30 27 Oct OK
Press MENU for Timer index
Option menu
Menu
1 Timer play
2 TV list
3 Setup
Source Pr Start Stop Date
TV 1 13:30 - 14:30 27 Oct OK
Press MENU for Timer index
Fill-in menu
How to use option menus…
Press to switch on BeoSystem 1
Press to bring up the main menu
Press to move through the
option menu and press GO to
enter your choice, or…
…use the number buttons on
Beo4 to select a numbered
option in a list
Press to go back to a previous
menu
Press to exit all menus
How to use fill-in menus…
Press to view options for a single
setting in a fill-in menu
Press to move from setting to
setting
Press the number buttons on
Beo4 to enter settings
Press to store a setting you have
made
Press to go back to a previous
menu
TV
MENU
m p
GO
1 – 9
STOP
EXIT
m p
l n
0 – 9
GO
STOP
Press to leave all menus
EXIT
6
Daily use
7
This chapter contains information
about the basic functions of your
BeoSystem 1.
For information about more
advanced operation, timed playback
and standby, and the use of the
pincode system refer to the chapter
‘Ad v a n ce d op e r ation’ on page 15.
Watch TV, 8
• Select a TV channel
• Bring up a TV list
• Adjust or mute the volume
• Change sound type or language
Home Theatre, 10
• Select speakers for movie sound
• Make the picture fill out the screen
Teletex t , 12
• Basic teletex t functions
• Store favourite pages
• Day-to-day use of memory pages
• Activate subtitles from teletext
See two sources at the same time, 14
8
Watch TV
Choose a TV channel by its number
and switch to another channel or
source. Bring up a list of TV channels
on the screen, adjust the sound
volume or change the sound type or
language.
Select a TV channel
When you switch BeoSystem 1 on, the last
channel viewed appears on the screen.
Press to switch on BeoSystem 1
Press a channel number to go
directly to that channel
Press to change channels one by
one
Press to swap between the
current and the previous TV
channel
Press to switch BeoSystem 1 to
standby
You can change source at any
time without switching
BeoSystem 1 off first. Press for
example DVD, if available in your
system.
TV
TV 2
0 – 9
m
p
0
•
Bring up a TV list
All your TV channels appear on a list, which
you can bring up on the screen. The list
contains channel numbers and names, and
can contain up to 99 T V channels.
Press to switch on BeoSystem 1
Press and hold to bring up a TV
list on the screen
Press to view the previous or
following page of the TV list
To select a channel, enter the
channel number, or…
…press until the desired channel
is highlighted
Press to switch on the chosen
channel
Press to leave the menu
You can also bring up the TV list
by pressing MENU to bring up
the main menu, and then 2 to
select the TV list.
TV
TV 2
GO
l n
0 – 9
m
p
GO
EXIT
9
1 BBC 1
2 BBC 2
3 ITV
4 Super Ch
5 SKÝ
6 ZDF
7 Children
8 CNN
9 . . . . . . . .
10 . . . . . . . .
11 . . . . . . . .
12 Eurosprt
13 . . . . . . . .
14 . . . . . . . .
15 MTV
16
17
18
19
The TV channel list. Dotted lines indicate that a
channel has been stored, but not named. An
empty slot in the list indicates that no channel has
been stored.
Adjust or mute the volume
You can adjust or mute the sound at any
time.
Press either end of the button to
adjust the volume up or down
Press in the middle of the button
to mute the sound
Press either end of the button to
bring the sound back
Prolonged listening at high
volume can cause hearing
damage!
r
u
r
u
Change sound type or language
The names of the various types of sound
available are shown in the display as you
proceed.
Press repeatedly to display
SOUND on Beo4
Press to bring up the current
sound type in the display
Press repeatedly to switch to
another sound type or language
in a multi-language programme
Press to exit the SOUND function
In order to display SOUND on
Beo4, you must first add it to the
Beo4 list of functions. Refer to
the chapter ‘Customise Beo4’ on
page 18 in the Reference book.
You can store your favourite
sound type when tuning in your
TV channels. For further
information, refer to the chapter
‘Edit tuned T V channels’ on page
28.
LIST
SOUND
GO
STEREO
GO
GO
EXIT
10
Home Theatre
You can extend your system into a
fully equipped Home Theatre by
connecting four Bang & Olufsen
loudspeakers and a BeoLab 2
subwoofer*.
When you switch on one of the
sources in BeoSystem 1, speakers in
a surround sound system can be cut
in or out, depending on what kind of
sound suits the source you are using.
BeoSystem 1 may switch on a
speaker combination automatically.
This happens if a broadcasted
programme contains information
about the number of speakers to be
switched on. However, you are still
free to choose the speaker
combination you prefer.
With Beo4, you can choose the
picture format you prefer for movie
viewing, and switch between two
connected screens.
Select speakers for movie sound
You can select the speaker combination that
suits the source you are using, provided that
the various sound modes are available in your
system.
Press repeatedly to display
SPEAKER on Beo4
Press the number of the speaker
combination you want. The
selected speakers cut in
automatically
Press to adjust the balance
between the front and rear
speakers
Press to adjust the balance
between the left and right
speakers
Press to remove SPEAKER from
the Beo4 display and to return to
the source you were using
LIST
SPEAKER
1 – 5
m
p
l n
EXIT
Speaker combinations
SPEAKER 1
Sound in the centre speakers only.
SPEAKER 2
Stereo sound in the two front speakers. The
BeoLab 2 subwoofer is active.
SPEAKER 3
The centre speakers, front speakers and the
BeoLab 2 subwoofer are active.
SPEAKER 4
Enhanced stereo sound in the front and rear
speakers. The BeoLab 2 subwoofer is active.
SPEAKER 5
Surround sound from all speakers including the
BeoLab 2 subwoofer. For programmes encoded
in Surround Sound.
If you have connected only two front speakers to
BeoSystem 1, you will only be able to choose
SPEAKER 1–3.
*NOTE! For further information on how to
connect speakers to BeoSystem 1, refer to the
chapter ‘Loudspeaker connections – surround
sound’ on page 4 in the Reference book.
11
Make the picture fill out the screen
BeoSystem 1 always ensures you the best
possible picture. It automatically adapts the
picture so that it fills out as much of the
screen as possible. However, you can still
choose the format you prefer. When you
select a format yourself, the automatic
format selection is deactivated.
Press repeatedly to display
FORMAT on Beo4
Press if you want to optimise the
picture, or…
…press the number of the
desired picture format
If you have chosen Format 1…
Press l or n to select variations
of this format
If you have chosen Format 2…
Press m or p to move the
picture up and down
Press to leave the FORMAT
function
LIST
FORMAT
GO
0 – 3
l n
m
p
EXIT
Picture formats to choose from
FORMAT 0… For setups with two screens. Moves
the picture from, for example, a plasma screen
onto a larger projector screen, or vice versa.
BeoSystem 1 switches the picture and the display
information concerning the current source to the
selected screen.
FORMAT 1… For standard TV pictures. Two
variations are available: 15:9 and Panoramic
view (for the largest picture).
FORMAT 2… For letter-box pictures. When you
select FORMAT 2, the picture is automatically
adjusted vertically. This ensures that channel
names or subtitles – if these appear in the
broadcasted picture – can be seen.
FORMAT 3… For genuine 16:9 wide-screen
pictures. FORMAT 3 is usually selected
automatically. If this is not the case, you can
select it yourself.
Switch between two screens
If you have connected two screens to
BeoSystem 1 at the same time, such as a
plasma screen and a projector screen for
Home Theatre use, you can switch between
these at any time by selecting FORMAT 0 on
Beo4.
If you have a home automation system connected,
the screen, lights and curtains can be equally
adjusted when you choose FORMAT 0 and switch
to the Home Theatre setup. For information about
how to connect BeoSystem 1 to a home automation
system, refer to the chapter ‘Connect a screen to
BeoSystem 1’ on page 42.
12
Teletext
If you select a channel and the
broadcaster offers a teletext service,
BeoSystem 1 gives you access to
teletext pages and any subpages
linked to the pages.
To make your favourite teletext pages
appear first when you bring up
teletext, store them as memory
pages.
When you store the teletext subtitles
page as memory page number four,
you can activate subtitles for that
particular channel automatically.
Basic teletext functions
You can find information on teletex t pages in
three steps: switch on the teletext service,
read the index page to find the desired page
number, and call up the desired page.
Press to bring up the teletext
index page
Press the number of a teletext
page you want to see
Press to move to the previous or
following page
If the current page contains
subpages, you can press STOP to
pause subpage turning
To view a particular subpage,
enter the four-digit number of
the desired page, or press m or
p to step to the page
Press again to resume subpage
turning
Press to leave teletext and return
to the channel you were
watching
TEXT
0 – 9
m
p
STOP
0 – 9
m
p
STOP
EXIT
Store favourite teletext pages
Four memory pages are available for each
channel’s teletext service.
Press to bring up teletext
Press the number buttons, or m
or p to go to a page you refer to
often
Press repeatedly to display
STORE on Beo4
Press to select the current page
for storing
Enter the number of the memory
page you want to use
Press to store the page as a
memory page, or…
…press to exit the STORE
function and return to teletext
without storing
Note that set-top box teletext
pages can be viewed, but not
stored as memory pages!
TEXT
0 – 9
m
p
LIST
STORE
GO
1 – 4
GO
EXIT
NOTE! If BeoSystem 1 is linked via a Master Link
cable to another television, stored memory pages
are not shared among these televisions. Memory
pages must be stored on each television.
13
Day-to-day use of memory pages
You may wish to refer to your teletext
memory pages quickly, for example, if you
are leaving for work and wish to check traffic
information on a teletext service.
Press to switch on a TV channel
which offers a teletext service
Press to switch on teletext. The
page stored as memory page 1
appears automatically
Press to view the other memory
pages
To view stored memor y pages
from another channel’s
teletext service…
Press to return to channel
viewing
Press the channel number, m or
p to change channels
TV
TEXT
l n
EXIT
0 – 9
m
p
Activate subtitles from teletext
You can activate subtitles for a channel, if
that channel offers teletext subtitles. The
teletext subtitles page number can often be
found in an index on teletext page 100.
Press to bring up teletext
Press the number buttons or m
p to locate the teletext
subtitles page. Subtitles appear
on the screen
Press to cancel subtitles
To store subtitles
permanently from the
teletext subtitles page…
Press repeatedly to display
STORE on Beo4
Press to select the page
Press to store the subtitles page
as memory page number 4
TEXT
0 – 9
m
p
EXIT
LIST
STORE
GO
4
A typical teletext page. The current page number,
channel name, date and time appear at the top of
the screen, as well as a three-digit number
showing the progress of the page search function.
Press to bring up teletext
TEXT
Press to return to T V viewing
To cancel stored subtitles,
simply store another teletext
page as memory page number
4.
TV
14
See two sources at the same time
Your Beo4 remote control gives you
access to a dual-screen function for
viewing two video sources at the
same time. For example, you can
view a videotape playback and a TV
programme at the same time,
provided that the selected sources
are available in your system.
While watching a programme or
recording, you can divide the screen
between the current programme or
recording (picture A in the second
illustration) and a new programme or
recording (picture B). You can also
swap the two pictures at any time.
The sound always follows picture A.
Volume adjustment with Beo4 always
affects picture A, while other Beo4
operations, such as selecting
channels, affect picture B. Choosing
a new source cancels dual-screen
viewing.
While watching, for example,
TV…
Press repeatedly to display
P-IN-P* on Beo4
Press, for example, V TAPE to
select a source to view on the
right side of the screen (B)
Press 0 to swap the left picture
and right picture
To leave the dual-screen
function…
Press to leave the function and
return to normal T V viewing
Pressing TEXT on Beo4 cancels
dual-screen viewing and
attempts to access teletext for
the source shown in picture A. If
there is no teletext service
available for this source, the
screen turns blank.
LIST
P-IN-P
V TAPE
0
TV
A
A B
To view a source registered in the ‘Connections’
menu as V.AUX, such as a set-top box, press LIST
repeatedly until P-V.AUX* is shown in the Beo4
display instead.
B
*In order to display P-IN-P or P-V.AUX on Beo4,
you must add them to the Beo4 list of functions.
For further information, refer to the chapter
‘Customise Beo4’ on page 18 in the Reference
book.
Advanced operation
15
Find out how to operate BeoSystem 1
beyond daily use.
This is also the chapter that informs
you of how to operate a connected
set-top box.
Advanced teletext functions, 16
• Extra teletext functions
• See updated teletext pages
• Go directly to a page via Fastext
Make BeoSystem 1 start and stop automatically, 18
• Timed play and timed standby
• Timed play via teletext
• To activate the timed play function
• View, edit or delete a Timer
Set-top box operation, 20
• Universal Beo4 operation
• Use the set-top box’s own menu
• Set-top Box Controller menu
• Use a set-top box in a link room
The pincode system, 22
• Activate the pincode system
• Change or delete your pincode
• Use your pincode
• Did you forget your pincode?
16
Advanced teletext functions
BeoSystem 1 supports three extra
teletext functions: text enlargement
for easy reading, placement of a
teletext page over a TV picture, and
display of hidden text, such as the
answer to a quiz or joke.
BeoSystem 1 can also notify you
when a desired page has been found
or updated. This is useful, for
example, if you want to see the latest
news headlines while watching TV.
If your teletext broadcaster offers a
Fastext service, you can use the
coloured buttons on Beo4 to step to
one of four linked teletext pages.
Basic teletext functions are described
on page 12.
Extra teletext functions
While using teletext, you can enlarge the
text, place the teletext page over the T V
picture or reveal hidden text.
To enlarge the screen text
size…
Press repeatedly to display
LARGE on Beo4
Press to activate – the upper half
of the page is shown
Press to view the lower half
Press to restore the normal text
size
To keep the TV picture in
teletext…
Press repeatedly to display MIX
on Beo4
Press to superimpose the teletext
page on the T V picture
Press to remove the TV picture
LIST
LARGE
GO
GO
GO
LIST
MIX
GO
GO
See updated teletext pages
BeoSystem 1 supports the page update
function, provided by some teletext
broadcasters to announce that a teletex t
page has been updated.
Bring up the relevant teletext
page…
Press repeatedly to display
UPDATE on Beo4
Press to activate
When the page is found, FOUND
appears on the screen
When the page has been
updated, UPDATE appears on
the screen
Press to bring up the located or
updated page
Press to leave teletext
The function is cancelled when
you change channels.
LIST
UPDATE
GO
FOUND
UPDATE
GO
EXIT
To reveal hidden text…
Press repeatedly to display
REVEAL on Beo4
Press to activate – if there is
concealed text on that page, it
becomes visible
Press to remove the revealed text
LIST
REVEAL
GO
GO
Go directly to a page via Fastext
Some teletext broadcasters offer a Fastext
service that enables you to step directly to
one of four linked teletext pages.
While the TV is switched on…
Press to bring up teletext
TEXT
17
Press to find a Fastext page, or…
…enter the page number using
the number buttons
Press one of the coloured
buttons on Beo4 to gain access
to the Fastext function. The titles
of the four linked pages appear
at the top of the screen
Press the coloured button which
corresponds to the linked page
you wish to see
Press to leave Fastext and return
to normal teletext viewing, or…
…press to leave teletext
m
p
0 – 9
TEXT
EXIT
A teletext page with the colour bar at the top
right indicating that it is a Fastext page.
The titles of the four linked pages appear at the
top of the activated Fastext page, each with their
own colour.
NOTE! For information about presetting recordings
from teletext pages, refer to your video tape
recorder’s own Guide.
18
Make your BeoSystem 1 start and stop automatically
You can use the timed play function
if there is a programme you do not
want to miss, or if you want a
morning wake-up call. Use timed
standby, for example, to make
BeoSystem 1 switch off automatically
when you leave for work in the
morning.
Enter as many as eight Timer settings,
and view all the Timer settings you
have entered. From this list, you can
edit or delete your Timer settings.
If your BeoSystem 1 is integrated
with a Bang & Olufsen audio or video
system with a Master Link cable,
these systems can perform the timed
play or timed standby functions.
If you wish to enter Timer settings,
make sure that the built-in clock is set
to the correct time. For further
information, refer to the chapter ‘Set
the time and date’ on page 37.
Timed play and timed standby
You can preset Beosystem 1 to start and stop
automatically on a specific date and time, or
at the same time and day every week.
Menu
1 Timer play
2 TV list
3 Setup
Timer play
1 Set timer
2 Activate timer
Source Pr Start Stop Date
TV 1 13:30 - 14:30 27 Oct OK
Press MENU for Teletext programming
The system writes:
Jan… January Jul… July
Feb… February Aug… August
Mar… March Sep… September
Apr… April Oct… October
May… May Nov… November
Jun… June Dec… December
Mon… Monday
Tue… Tues day
Wed… Wednesday
Thu… Thursday
Fri… Friday
Sat… Saturday
Sun… Sunday
To enter settings for timed play or timed
standby…
> Press MENU to bring up the main menu.
> Press GO to bring up the Timer play menu.
> Press GO to bring up the Set Timer menu.
> Press l or n to move through menu items.
> Press m or p to choose options for a menu
item. For example, set Source (source) to
Standby if you want to switch BeoSystem 1 to
standby, or TV if you want to view a TV channel
at a specific time.
> Press the number buttons to fill in e.g. a channel
number or start and stop times.
> If you want to set Timers for certain days of the
week, press n to highlight Date and then press
MENU to change Date to Days. Select the
specific weekday(s) on which you want your
Timer executed. All the weekdays are displayed
– starting with M for Monday. Press n to move
through the days and press p to remove any
day you do not want. When the weekday (s) you
want are displayed, press GO. OK is then
highlighted.
> When you have filled in the required
information, press GO to store your Timer
settings, or…
> …press EXIT to leave all menus without storing.
NOTE! If BeoSystem 1 is set up in a link room,
Timer programming must be carried out via your
main room system.
19
Timed play via teletext
It is also possible to program timed play
settings via teletext.
To enter timed play settings via teletext…
> Press MENU while Start (start) is highlighted to
bring up teletext.
> Enter the number of the teletext page you
want.
> When the page is found, press MENU to make
a timed play programming. A cursor highlights
the first start time on the list.
> Press m or p to move the cursor to the
programme you wish to make a timed play for.
> Press GO to accept the start time.
> Press m or p to move to the stop time you
want, and press GO to accept it.
> A line appears on top of the teletext page listing
the start and stop time, followed by ‘OK? ’.
> Press GO to store your timed play settings.
To activate the timed play function
You must activate the timed play function in
order for your Timers to be executed.
To activate the timed play function…
> Press MENU to bring up the main menu.
> Press GO to bring up the Timer play menu.
> Press 2 to bring up the Activate Timer menu.
> Press m or p to reveal Yes. To switch off the
Timer play function, select No instead.
> Press GO to store your timed play settings, or…
> …press EXIT to leave all menus without storing.
If you connect a Bang & Olufsen audio or video
product to BeoSystem 1 with a Master Link cable,
you can exclude or include it in timed functions
via the Timer play menu. For example, set
BeoSystem 1 Timer to Yes and the audio system
Timer to OFF if you wish timed functions to apply
only to BeoSystem 1.
For further information about how to switch the
Play Timer on or off for a connected Bang &
Olufsen audio or video product, refer to the Guide
enclosed with the product.
View, edit or delete a Timer
Bring up an on-screen list of the Timer
settings you have entered. From this list, you
can edit or delete your Timer settings.
To view, edit or delete your Timer settings…
> Press MENU while Source (source) or Pr
(program) is highlighted in the Set Timer menu
to bring up a current Timer index of previously
entered Timer settings.
> Press p or m to move through the list to a
setting you wish to edit or delete.
> To edit a setting, press GO and follow the
procedure described earlier.
> To be able to delete a setting, press MENU. The
date is replaced by Clear?
> Press GO to delete the setting, or EXIT to keep
it.
20
Set-top box operation
The built-in Set-top Box Controller
acts as an interpreter between the
set-top box of your choice and the
Beo4 remote control. When a set-top
box is connected, you can use the
Beo4 remote control to gain access
to the programmes and functions
offered by the set-top box.
For further information about how to
connect and register a set-top box,
refer to the chapter ‘Connect
additional equipment’ on page 44
and the chapter ‘Register and use
additional video equipment’ on page
32.
Universal Beo4 operation
If you know which Beo4 button activates the
function you want, you can bring up the
function without activating the Set-top Box
Controller menu first.
While your set-top box is
activated…
Press GO and then the number
button that activates the
function you want
Press GO and then m or p to
step up or down through
programs directly
Press and hold GO to bring up
the Program guide or the ‘Now/
Next’ banner on the screen
depending on your set-top box
GO
0 – 9
GO
m
p
GO
Use the set-top box’s own menu
Once you have activated your set-top box,
you can operate the set-top box’s own
menus, such as the Program Guide, via Beo4.
While the set-top box’s own
menu is shown…
Moves the cursor up or down
Moves the cursor
Selects and activates a function
Press GO and then l or n to
step between menu pages or
step in program lists
Exits menus, or returns to a
previous menu
m
p
l n
GO
GO
GO
l n
STOP
Exits menus, enters or exits
different modes, such as radio
Use the coloured buttons as
indicated in the menus of your
set-top box
When set-top box is selected as
source, press MENU twice to
bring up the BeoSystem 1 main
menu.
EXIT
21
Set-top Box Controller menu
Some of the buttons on your set-top box
remote control are not immediately available
on Beo4. To find out which Beo4 buttons
activate specific services or functions in your
set-top box, bring up the Set-top Box
Controller menu on the screen.
If your set-top box is
registered as STB (SAT)…
Press to switch on the set-top
box
If your set-top box is
registered as STB (V.AUX)…
Press repeatedly to display
V.AUX on Beo4
Press to switch on the set-top
box
Then,
Press to bring up the Set-top Box
Controller menu
Press the number button that
activates the function you want,
or…
SAT
LIST
V.A UX
GO
MENU
1 – 9
Use a set-top box in a link room
When your set-top box is connected to the
television in the main room, you can operate
the set-top box from the link room television.
However, the Set-top Box Controller menu
cannot be displayed on the television screen
in the link room.
If your set-top box is
registered as STB (SAT)…
Press to switch on the set-top
box in the main room
If your set-top box is
registered as STB (V.AUX)…
Press repeatedly to display
V.AUX o n Be o 4
Press to switch on the set-top
box in the main room
Press to select a function, and…
…press the number button that
activates the function you want
Press one of the coloured
buttons to activate a function
SAT
LIST
V.A UX
GO
GO
1 – 9
1
2
3
4
5
•
GUIDE
MENU
TEXT
INFO
WIDE
•
1
GUIDE
2
MENU
3
TEXT
4
INFO
5
WIDE
Example of a Set-top Box Controller menu – The
Beo4 buttons are shown to the left on the menu
and the set-top box buttons are shown to the
right.
…press one of the coloured
buttons to activate a function
22
The pincode system
You choose whether or not to
activate the pincode system. The
pincode system is deactivated when
you delete your pincode.
The pincode system is intended to
make normal use of BeoSystem 1
impossible for someone who does
not know the pincode.
When BeoSystem 1 has been
disconnected from the mains for
15–30 minutes, the pincode system
goes into effect.
When reconnected and switched on,
BeoSystem 1 automatically switches
itself off after four minutes. Entering
the pincode returns BeoSystem 1 to
normal.
Should you lose or forget your code,
contact your Bang & Olufsen retailer
to receive a mastercode which
disables your pincode.
Activate the pincode system Change or delete your pincode
Menu
1 Timer play
3 TV list
4 Setup
Pincode Confirm pincode
----
----
While the TV is switched on…
Press to bring up the main menu
Press l twice, followed by STOP.
The Pincode menu appears on
the screen
Use the number buttons on
Beo4 to enter the four digits of
your code
Press to move the cursor to
Confirm pincode when you have
entered your code once
Re-enter the code. If the two
codes are not identical, the input
fields are cleared and you must
enter the code again
Press to store the code
MENU
l l
STOP
0 – 9
n
0 – 9
GO
Pincode
1 Delete code
2 New code
New pincode Confirm pincode
----
----
While the TV is switched on…
Press to bring up the main menu
Press l twice, followed by STOP.
BeoSystem 1 prompts you for
your pincode
Enter your pincode
If the code is incorrect, the input
fields are cleared and you must
enter the code again
When you have entered your
code, the Pincode menu prompts
you to delete your code or enter
a new code
Press 1 to delete your code, or 2
to enter a new code
MENU
l l
STOP
PIN _ _ _ _
0 – 9
PIN ** _ _
PIN _ _ _ _
1
2
NOTE! You can change your pincode up to five
times within a three-hour period.
To cancel a code entry…
Press to cancel a code entry, and
the input fields are cleared
STOP
Enter the new code
Press to move the cursor to
Confirm pincode, when you have
entered your new code once
Re-enter the new code
Press to store the new code
To cancel a pincode entr y…
Press to cancel a code entry, and
the input fields are cleared
0 – 9
n
GO
STOP
23
Use your pincode
If BeoSystem 1 has been disconnected from
the mains for 15–30 minutes, BeoSystem 1
prompts you for the pincode when you switch
it on. If you do not enter the pincode,
BeoSystem 1 switches to standby after
approximately 4 minutes.
When BeoSystem 1 is
switched on…
BeoSystem 1 prompts you for
your pincode
Enter your pincode
BeoSystem 1 restarts when the
last digit is entered
If an incorrect code is entered,
ERROR is shown. Re-enter the
code
To cancel a code entry…
Press to cancel a code entry, and
the input fields are cleared
PIN _ _ _ _
0 – 9
PIN * * _ _
PIN * * * *
ERROR
PIN _ _ _ _
STOP
Did you forget your pincode?
Contac t a Bang & Olufsen retailer to receive a
five-digit mastercode.
When you have received a
mastercode…
When BeoSystem 1 prompts you
for your pincode, press and hold
l to bring up the mastercode
display
Entering this five-digit code
deactivates your pincode and
reactivates BeoSystem 1.
DELETED is displayed
To use the pincode system
again…
Follow the procedure for
activating the pincode system
PIN _ _ _ _
l
PIN_ _ _ _ _
0 – 9
DELETED
Five incorrect entries cause
BeoSystem 1 to shut down for
three hours, during which time
operation is not possible.
Approximately 20 seconds
before the system automatically
switches to standby, it cannot be
operated by remote control.
Therefore, it is not possible to
enter a pincode during this time.
24
Tuning and preference settings
25
This chapter informs you how to tune
in and add new TV channels and
make adjustments to TV channels
and how to make your own settings
for picture and sound.
For information about setting up
your television and connecting
additional video equipment, refer to
the chapter ‘Placement, connections
and maintenance’ on page 39.
Tune in TV channels, 26
• Find available channels
• Add new channels
Edit tuned TV channels, 28
• Adjust tuned TV channels
• Move tuned channels
• Name tuned channels
• Delete tuned channels
Register and use additional video equipment, 32
• What is connected?
• Choose a set-top box
• Get access to additional video equipment
Adjust picture and sound settings, 34
• Adjust colour, brilliance or contrast
• Adjust volume, bass, treble or loudness
See the name of the active sound system, 36
Set the time and date, 37
26
Tune in TV channels
You can make BeoSystem 1 find your
TV channels for you.
Preset up to 99 different TV channels
on channel numbers of their own
and give each channel a distinct
name.
You can tune in new channels or retune previously deleted channels.
When tuning in channels via the Add
program menu, your previously tuned
channels are left unchanged. This
allows you to keep channel names,
their order in the TV list, and any
special settings you may have stored
for those channels, such as decoder
or broadcast system settings.
Find available channels
When you set up BeoSystem 1 for the first
time, you can tune in the T V channels that
are available in your area via the TV tuning
menu. BeoSystem 1 finds available channels
and stores them by number and name.
TV tuning
1 Edit TV list
2 Add program
3 Auto tuning
4 Manual tuning
Freq Pr
210 12
> Press MENU to bring up the main menu.
> Press 3 to bring up the Setup menu.
> Press GO to bring up the Tuning menu.
> Press GO again to bring up the TV tuning menu.
> Press 3 to bring up the Auto tuning menu. The
Freq (frequency) and Pr (program) fields are
shown.
> Press m to start automatic tuning. The content
of the frequency and program fields show your
progress.
When tuning is completed, you can rearrange,
delete or rename channels from a T V list. This list
also appears if you press STOP during auto tuning.
For information about editing the TV list, refer to
the chapter ‘Edit tuned TV channels’ on page 28.
Add new channels
You can add new or previously deleted TV
channels to your TV list at any time using the
‘Add program’ menu.
27
TV tuning
1 Edit TV list
2 Add program
3 Auto tuning
4 Manual tuning
Freq Pr
210 12
> Press MENU to bring up the main menu.
> Press 3 to bring up the Setup menu.
> Press GO to bring up the Tuning menu.
> Press GO again to bring up the TV tuning menu.
> Press 2 to bring up the Add program menu.
> Press m to start adding new channels. The Freq
(frequency) and Pr (program) fields show tuning
progress.
> Press STOP to stop adding channels. You can
then move, rename or delete channels from a
list, as described in the chapter ‘Edit tuned TV
channels’ on page 28.
> Press EXIT when your channels have been
tuned in, named and placed in the order you
choose.
28
Edit tuned TV channels
You can make adjustments to your
tuned TV channels at any time, or
tune in channels not stored during
auto tuning.
You can also enter settings before
you tune in channels. These may
include choosing a broadcast system
for certain types of channels, or
setting up a connected decoder to be
switched on automatically whenever
a coded channel is switched on.
In addition, you can edit your list of
channels by renaming channels,
moving them around in the list, or
deleting all your unwanted channels
from the TV list, thereby reducing the
time you spend changing channels.
Adjust tuned TV channels
You can store T V channels on program
numbers of their own. Fine tune the channel
reception, indicate the presence of coded
channels and choose appropriate sound types
for the individual channels.
TV tuning
1 Edit TV list
2 Add program
3 Auto tuning
4 Manual tuning
Freq Pr Name
210 1 . . . . . . . . More
Fine Decoder Sound
0 Off Stereo-2
If the item ‘System’ appears on the menu, then
make sure that the correct broadcast system is
displayed before you start tuning:
B/G… for PAL/SECAM B/G
I… for PAL I
L… for SECAM L
M… for NTSC M
D/K… for PAL /SECAM D/K
> Press MENU to bring up the main menu.
> Press 3 to bring up the Setup menu.
> Press GO to bring up the Tuning menu.
> Press GO again to bring up the TV tuning menu.
> Press 4 to bring up the Manual tuning menu.
> Press l or n to move between items on the
menu and m or p to view your choices for each
item. Pressing m when the cursor is placed on
Freq (frequency) starts automatic search for a
channel. Numeric values can be entered using
the number buttons on Beo4. When entering
names, press m or p to reveal the character you
want. Then press n to move to the next
character position.
> To view more options, press n to move the
cursor to More and press GO. If you set the item
Decoder to On, Dec1 or Dec2, you can return to
the previous menu to start tuning in coded
channels by pressing GO.
> When a channel is tuned in, you can also select
the sound system you want; press m or p to
switch bet ween the sound modes currently
transmitted or fine tune the channel.
> Press GO when you have entered your settings,
or…
> …press EXIT to leave all menus without storing.
All options may not be available, as this depends
on the television t ype.
If channel broadcasts are in two languages and
you want both languages, you can store the
channel twice, once with each language.
Move tuned channels
You can rearrange the order in which your
channels appear when you switch channels,
as well as in the on-screen TV list.
29
TV tuning
1 Edit TV list
2 Add program
3 Auto tuning
4 Manual tuning
1 BBC 1
2 BBC 2
3 ITV
4 SUPER CH
5 Sky
6 ZDF
7 CHILDREN
8 CNN
9 . . . . . . . .
10 . . . . . . . .
11 . . . . . . . .
12 EUROSPRT
13 . . . . . . . .
14 . . . . . . . .
15 MTV
16
17
18
19
>>
to
Press
move
> Press MENU to bring up the main menu.
> Press 3 to bring up the Setup menu.
> Press GO to bring up the Tuning menu.
> Press GO again to bring up the TV tuning menu.
> Press GO to bring up the Edit TV list menu.
> Press p or m to move through your list of
channels.
> When you find a channel you wish to move,
press n to move it out of the list.
> Press p or m to move the channel to its new
location, or press the number of the new
location.
> Press l to move the channel back into the list. If
it changes places with another channel, this
channel is moved out of the list and can be
placed elsewhere.
> When you have moved your channels, press
EXIT to leave all menus.
30
>> Edit tuned TV channels
Name tuned channels
BeoSystem 1 automatically names your tuned
channels during auto tuning, if possible, but
you can rename your channels at any time.
TV tuning
1 Edit TV list
2 Add program
3 Auto tuning
4 Manual tuning
1 BBC 1
2 BBC 2
3 ITV
4 SUPER CH
5 SKY
6 ZDF
7 CHILDREN
8 CNN
9 . . . . . . . .
10 . . . . . . . .
11 . . . . . . . .
12 EUROSPRT
13 . . . . . . . .
14 . . . . . . . .
15 MTV
16
17
18
19
Press
>>
to
move
Freq Pr Name
48 1 BBC 1 More
> Press MENU to bring up the main menu.
> Press 3 to bring up the Setup menu.
> Press GO to bring up the Tuning menu.
> Press GO again to bring up the TV tuning menu.
> Press GO to bring up the Edit TV list menu.
> Press p or m to move through your list of
channels.
> When you have found a channel you wish to
name, press GO. The cursor is located on the
first character in the channel name.
> Press l or n to move between characters, and
m or p to choose characters.
> Press GO to store a name and return to the list,
or…
> …press STOP to return to the list without
storing the name.
> Press EXIT to leave all menus.
Delete tuned channels
You can remove all your unwanted tuned
channels from the T V list.
31
TV tuning
1 Edit TV list
2 Add program
3 Auto tuning
4 Manual tuning
1 BBC 1 Del?
2 BBC 2
3 ITV
4 SUPER CH
5 SKY
6 ZDF
7 CHILDREN
8 CNN
9 . . . . . . . .
10 . . . . . . . .
11 . . . . . . . .
12 EUROSPRT
13 . . . . . . . .
14 . . . . . . . .
15 MTV
16
17
18
19
Press GO
to delete
> Press MENU to bring up the main menu.
> Press 3 to bring up the Setup menu.
> Press GO to bring up the Tuning menu.
> Press GO to bring up the Edit TV list menu.
> Press p or m to move through your list of
channels.
> When you have found a channel you wish to
delete, press MENU. Del? appears next to the
channel name.
> Press GO to delete the channel, or…
> …press STOP to return to the list without
deleting the channel.
> Press EXIT to leave all menus.
32
Register and use additional video equipment
If you connect additional video
sources or equipment to BeoSystem 1,
you must register the equipment in
the Connections menu.
The settings you select in the
Connections menu tell BeoSystem 1
what is connected.
For information about where and
how to connect extra equipment,
refer to the chapters ‘Connect
additional equipment’ on page 44 as
well as ‘Socket panels’ on page 45.
When your additional video
equipment has been connected and
registered in the Connections menu,
as described, you can operate it with
the Beo4 remote control.
What is connected?
Registering the equipment connected to
BeoSystem 1 enables you to activate it with
the Beo4 remote control.
Setup
1 Tuning
2 Sound
3 Picture
4 Connections
5 Menu
6 Clock
V. Tape AV Decoder
V. Tape DVD Decoder
Equipment you can connect to each socket
V.Tape
V.Tap e… for a Bang & Olufsen video tape
recorder
DVD… for a DVD player
STB (SAT), STB (V.AUX)… for a set-top box*
None… if nothing is connected
AV
DVD… for a DVD player
STB (SAT), STB ( V.AUX)… for a set-top box*
V. AUX… for other equipment
Non B& O V.Tape2… for a non-Bang & Olufsen
video tape recorder
V.Tap e2… for a Bang & Olufsen video tape
recorder
S-VHS V.TP2… for a Super-VHS video tape
recorder
Decoder(2)… for a second decoder – Connect
your primary decoder to the DECODER socket
None… if nothing is connected
> Press MENU to bring up the main menu.
> Press 3 to bring up the Setup menu.
> Press 4 to bring up the Connections menu.
> Press n to select a socket.
> Press m or p to step through the list of
available equipment types until you find what
you have connected. Select None if nothing is
connected.
> When you have selected your equipment types,
press GO to store your settings, or…
> …press EXIT to leave all menus without storing.
Decoder
Decoder(1)… for a primary decoder or expander
box
STB (SAT), STB ( V.AUX)… for a set-top box*
V. AUX… for other non- Bang & Olufsen
equipment
Non B& O V.Tape2… for a non-Bang & Olufsen
video tape recorder
None… if nothing is connected
*NOTE: Choose STB (SAT) for a primar y set-top
box and STB ( V.AUX) for a secondary set-top box.
33
Choose a set-top box
A list of set-top boxes to choose from appears
when you register a set-top box in the
Connections menu.
STB (V.AUX)
1 SELECTOR
2 NOKIA 9800S/02S
3 NOKIA 9602S
4 NOKIA 9820T
5 NOKIA 9200
6 NOKIA D-BOX II
7 NOKIA D-BOX
8 NOKIA 9850T
9 PACE DTR730-IM
10 PHILIPS DTX637x
11 PACE DSR600
12 SKY DIGITAL
13 CANALdig DK/S/N
14 CANAL+ SAT r2
15 CANALdigital I
16 CANALdigital E
17 CANALdigital NL
18 CANALdigital B+
19 MACAB DCB-101
set-top box to the Camcorder socket. Refer to the
chapter ‘Connect a set-top box or decoder’ on
page 8 in the Reference book for further
information.
When the set-top box list appears…
> Press p to move down the list.
> Press GO to select your STB type.
Get access to additional video equipment
Some of the connec ted equipment is
accessible via the Beo4 remote control.
Press to switch on a video tape
recorder
Press repeatedly to display
V.TAPE2 on Beo4
Press to switch on a second
video tape recorder
Press repeatedly to display
V.AUX o n Be o 4
Press to switch on a source
registered as V.AUX, such as a
set-top box
In order to display V.AUX or
V.TAPE2 on Beo4, you must add
them to the Beo4 list of
functions. Refer to the chapter
‘Customise Beo4’ on page 18 in
the Reference book for further
information.
V TAPE
LIST
V.TAP E2
GO
LIST
V.A UX
GO If all sockets are in use, you can connect a second
34
Adjust picture and sound settings
Picture and sound settings are preset
from the factory to neutral values
which suit most viewing and listening
situations. However, if you wish, you
can adjust these settings to your
liking.
Adjust picture brilliance, colour or
contrast. Sound settings include
volume, bass, treble and loudness.
You can also adjust subwoofer level,
if BeoLab 2 is part of your setup.
Store your picture and sound settings
temporarily – until BeoSystem 1 is
switched off – or store them
permanently.
For information about how to change
the picture format, refer to the
chapter ‘Home Theatre’ on page 10.
Change brilliance, colour or contrast
Adjust the picture settings via the Picture
menu. Temporary settings are cancelled
when you switch off BeoSystem 1.
Setup
1 Tuning
2 Sound
3 Picture
4 Connections
5 Menu
6 Clock
Brilliance Colour Contrast
32 32 20
To change brilliance, colour or contrast…
> Press MENU to bring up the main menu.
> Press 3 to bring up the Setup menu.
> Press 3 to bring up the Picture menu.
> Press l or n to move between the items on the
menu.
> Press m or p to adjust the settings for each
item.
> Press EXIT to store your settings until you
switch off BeoSystem 1, or…
> …press GO to store your settings permanently.
For video sources using the NTSC signal a four th
option – TINT (colour shade or nuance) – will be
available for adjustment.
Change volume, bass, treble or loudness
You can adjust sound volume, select a
speaker combination or adjust the speaker
balance directly on Beo4 at any time without
bringing up a menu, but you must bring up
the Sound menu in order to be able to adjust
bass, treble or loudness.
35
Setup
1 Tuning
2 Sound
3 Picture
4 Connections
5 Menu
6 Clock
Sound
1 Adjustment
2 Speaker type
3 Speaker distance
4 Speaker level
5 Sound system
Volume Bass Treble Loudness
Counter Tape Speed PDC&VPS Marker
32 0 0 On
Time used 240 SP On On
To change volume, bass, treble or loudness…
> Press MENU to bring up the main menu.
> Press 3 to bring up the Setup menu.
> Press 2 to bring up the Sound* menu.
> Press GO to bring up the Adjustment menu.
> Press l or n to move between menu items.
> Press m or p to adjust the settings for each
item.
> Press EXIT to store your settings until you
switch off BeoSystem 1, or…
> …press GO to store your settings permanently.
The content of the ‘Sound’ menu depends on how
many speakers are connected to BeoSystem 1.
*NOTE! The Sound menu lets you calibrate your
surround sound speaker setup permanently. For
further information, refer to the chapter
‘Loudspeaker connections – surround sound’ on
page 4 in the Reference book.
36
See the name of the active sound system
The surround sound module in your
television allows you to see which
active sound system is currently
playing on the source or programme
you are watching.
The sound system is an integrated
part of a programme or, for example,
a DVD disc. Therefore, as the sound
system is distributed to you from the
broadcaster, you can not preset a
sound system in this menu.
A given sound system signal may
automatically switch on the speaker
combination considered optimal for
the specific sound system. You can
always choose to disregard such
automatic change in speaker
combination. For further information,
refer to the chapter ‘Home Theatre’
on page 10.
Sound systems that can appear in the menu are:
Dolby Digital, Dolby Surround Pro Logic, Dolby
3 Stereo, Dolby Digital + Dolby Surround Pro
Logic, Mono /Stereo and DTS Digital Surround.
Sound
1 Adjustment
2 Speaker type
3 Speaker distance
4 Speaker level
5 Sound system
> Press MENU to bring up the main menu.
> Press 3 to bring up the Setup menu.
> Press 2 to bring up the Sound menu.
> Press 5 to bring up the Sound system menu. The
current sound system is shown. Mono/Stereo
appears if Dolby sound is not active.
> Press EXIT to exit all menus.
Set the time and date
37
BeoSystem 1 has a built-in 24-hour
clock.
When you preset BeoSystem 1 to
switch itself on or off at a particular
time, or when you preset a timed
recording of a programme on a
connected BeoCord V 8000 video
tape recorder, the clock ensures that
these features are switched on and
off at the right times.
The simplest way to set the clock is
to synchronise it with a tuned TV
channel’s teletext service via the
Clock menu. If you choose to
synchronise the clock, this is done
with the teletext service offered by
the TV channel you are currently
watching. If a teletext service is not
available, you can set the clock
manually.
Before synchronising the clock with a tuned
channel, make sure that the channel you are
watching of fers a teletext ser vice.
Setup
1 Tuning
2 Sound
3 Picture
4 Connections
5 Menu
6 Clock
Time Date Year Synch
14:25 Fri 2 Nov 2001 No
Abbreviations for month and day of the
week
Jan… January Jul… July
Feb… February Aug… August
Mar… March Sep… September
Apr… April Oct… October
May… May Nov… November
Jun… June Dec… December
To set the time and date…
> Press MENU to bring up the main menu.
> Press 3 to bring up the Setup menu.
> Press 6 to bring up the Clock menu. Time is
already highlighted. It is only necessary to enter
the time manually if Synch is set to No.
> Enter the time by pressing the number buttons
on your Beo4 remote control.
> Press l or n to move through menu items.
> Press m or p to see your options for a menu
item. Select the current channel by pressing m
or p until the channel name is shown.
> Press GO to store your clock and calendar
settings, or…
>…press EXIT to leave all menus without storing.
If the clock is not updated in the transition
between summer and winter time, simply select
the channel with which you originally
synchronised the clock, and the clock is updated.
Mon… Monday
Tu e… Tuesday
Wed… Wednesday
Thu… Thursday
Fri… Friday
Sat… Saturday
Sun… Sunday
38
Placement, connections and maintenance
39
In this chapter, you can find out how
to place, connect and maintain
BeoSystem 1. It also gives you an
overview of the socket panels.
We recommend that you follow the
procedure described below when
you set up BeoSystem 1:
– Unpack and place BeoSystem 1 as
described on the following pages
– Consider the appropriate
surroundings for BeoSystem 1
Guidelines are included on the
next page
– Mount the IR receiver
– Mount the screen
– Connect the cables, additional
equipment, and speakers as
described on the following pages.
Set up BeoSystem 1, 40
• Place BeoSystem 1 in your home
• Overview of socket and connection panels
• Connect the IR receiver
• Connect a screen to BeoSystem 1
• Aerial and mains connec tion
Connect additional equipment, 44
• Audio master
• AV 2 Expander
• Set-top box
• Decoder
• Video tape recorder
• DVD player
• Game console, Camcorder, etc.
Socket panels, 45
• AV and aerial socket panel
• Speaker and digital input socket panel
• Additional sockets
Close-up socket panel, 48
• The close-up socket panel
• Watch Camcorder via BeoSystem 1
• Copy from a Camcorder
Maintenance of BeoSystem 1, 49
• Cleaning surfaces…
• Cleaning the Beo4
• Changing the batteries…
40
2
7
Set up BeoSystem 1
We recommend that you follow the
procedure described below when you
set up BeoSystem 1:
– Unpack and place BeoSystem 1 as
described on the following pages
– Consider the appropriate
surroundings for BeoSystem 1
Guidelines are included on this
page
– Mount the IR receiver
– Mount the screen
– Connect the cables, additional
equipment, and speakers as
described on the following pages.
Do not connect BeoSystem 1 to the
mains until you have connected your
screen, loudspeakers and other
equipment to BeoSystem 1!
For further information about the
close-up socket panel, refer to the
chapter ‘Close-up socket panel’ on
page 48.
Place BeoSystem 1 in your home
– Make sure that BeoSystem 1 is set up,
placed and connected in accordance with
this Guide.
– BeoSystem 1 is developed for indoor use in
dry, domestic environments only, and for
use within a temperature range of 10– 40ºC
(50–105ºF).
– Do not place any items on top of
BeoSystem 1.
– To ensure proper ventilation, allow for at
least 5 centimetres (2”) of space at the
sides of BeoSystem 1 and 10 centimetres
(4”) above it.
– Always place BeoSystem 1 on a firm and
stable surface.
– Do not attempt to open BeoSystem 1.
Leave such operations to qualified service
personnel.
Overview of sockets
1 Mains switch
2 IR receiver socket
3 Close-up socket panel
4 Mains connection
5 Projector and plasma screen socket area
6 Speaker and digital input socket panel
7 AV and aerial socket panel
8 Fan socket
9 0/12 V control socket
1
5
6
3
4
89
Refer to the chapter ‘Socket panels’ on page 45
for further information about the sockets.
Connect the IR receiver
A
41
To facilitate remote control operation of
BeoSystem 1 and all connected equipment,
you must connect the IR receiver to
BeoSystem 1.
The IR receiver is a kind of ‘eye’ which is
capable of receiving signals from your Beo4
remote control and sending them to
BeoSystem 1. BeoSystem 1 then sends the
appropriate control signals to your screen,
projector or other connected equipment.
To connect the IR receiver…
> Detach the IR receiver’s rear cover (unscrew the
two (C) screws and loosen the two ( D) screws,
then lift off the cover).
> Cut the included cable to the required length
and strip the cable.
> Insert the cable end through the cable clamp (E)
and connect the leads to the terminals inside
the receiver in the order indicated. Tighten the
clamp.
> Attach the rear cover and fasten the IR receiver
to the wall as described below.
> Connect the cable to the IR RECEIVER socket on
BeoSystem 1.
Green
Yellow
Brown
E
C
C
D
D
To fasten the IR receiver to the wall…
> Using the wall bracket as a template, mark and
drill two holes in the wall.
B
> Using the two screws and wall plugs supplied
(A), fasten the wall bracket to the wall.
> When you have mounted the receiver cable as
described above, hang the receiver on the wall
bracket and secure it with screw (B).
> Fasten the cable to the wall and run it to
A
BeoSystem 1.
42
Connect a screen to BeoSystem 1
BeoSystem 1 is intended for use with a
plasma screen. However, it also supports the
use of a front projector, rear projector, or
LCD screen. You can also connec t a home
automation system to BeoSystem 1, and
thereby control room lights and curtains
when BeoSystem 1 is switched off.
IMPORTANT! The screen you connect to
BeoSystem 1 must be compatible with 50 Hz
input!
The diagrams show examples of BeoSystem 1 in
setups with, respectively, a plasma screen/LCD
screen, a projector and a home automation system.
More than one screen type can be connected at
one time.
The diagrams are provided as examples, and therefore may not apply to your particular screen. Your
installer should set up your screen and connect it
to BeoSystem 1.
>> Set up BeoSystem 1
IR IN
RGB
RS232
BeoSystem 1 connected to a plasma screen or LCD screen.
IR IN
RGB
0/12V
CONTROL
BeoSystem 1 connected to a projector.
0/12V CONTROL
BeoSystem 1 connected to a home automation system. It is only possible to connect a home automation
system in a setup with a front or rear projector.
Aerial and mains connection
When you set BeoSystem 1 up on its own,
simply connect the aerial to the socket marked
VHF/ UHF on BeoSystem 1 and connect
BeoSystem 1 to the mains.
If you have not yet connected speakers, or you wish
to connect any other equipment to BeoSystem 1,
do not connect to the mains yet!
When connections are complete…
Connect BeoSystem 1 to the mains and switch on
the mains switch on the back of BeoSystem 1. The
system is in standby mode and ready to be used. If
BeoSystem 1 is set up on its own, you can now
begin tuning in channels, as explained in ‘Tune in
TV channels’ on page 26.
BeoSystem 1 was designed to be left in standby
mode when not in use. Therefore, to facilitate
remote control operation, it is essential that you
leave the mains switch on.
43
BeoSystem 1
44
Connect additional equipment
You can connect different types of
audio and video equipment to
BeoSystem 1, such as a video tape
recorder, set-top box or Camcorder.
Audio equipment is connected
through the Master Link socket.
When connecting video equipment
to BeoSystem 1, remember to use the
AV socket on BeoSystem 1 first, if it is
vacant. Should you require further
information about connections, refer
to the Reference book.
Refer to the guides included with
your additional equipment to make
sure it is connected properly.
Remember to register all connected
equipment. For further information
refer to the chapter ‘Register and use
additional video equipment’ on page
32.
Audio Master
Using a BeoLink cable, connect the one multipin plug to the socket marked MASTER LINK
on BeoSystem 1, and the other multi-pin plug
to the socket marked MASTER LINK on the
audio system.
AV 2 Expander
The optional AV 2 Expander accessory is a
SCART expander for connection of nonBang & Olufsen equipment, such as decoders,
game consoles, and cameras to the DECODER
socket on BeoSystem 1. Use a 21-pin cable to
connec t one plug to the socket marked T V on
the Expander box, and connect the other
plug to the socket marked DECODER on
BeoSystem 1. Remote control operation of
equipment connected via the AV 2 Expander
is not possible.
Set-top box
Use the 21-pin AV cable to connect the set-top
box to BeoSystem 1. To enable remote control
of your set-top box with the Beo4 remote
control, you must also connect a low-power
IR transmitter.
Video tape recorder
Use a 21-pin cable to connect a BeoCord
V 8000 video tape recorder to the V.TAPE
socket on BeoSystem 1. Connect the cable
from the aerial to the input socket on the
video tape recorder. Forward the aerial cable
to the aerial socket on BeoSystem 1.
DVD player
Use a 21-pin cable to connect a DVD player,
such as a Bang & Olufsen DVD 1, to
BeoSystem 1. Connect one end to the socket
marked AV on your DVD player and the other
to the socket marked AV on BeoSystem 1.
Connect the socket marked DIGITAL OUTPUT
on DVD 1 to the SPDIF 1 socket on BeoSystem
1. If the required cable is not enclosed, it is
available from your Bang & Olufsen retailer.
Game console, Camcorder, etc.
We recommend that you use the close-up
socket panel for equipment you connec t on a
temporary basis, such as a game console or
Camcorder. The use of these sockets is
explained in the chapter ‘Close-up socket
panel’ on page 48.
Decoder
To connect an AV decoder (a baseband
decoder, such as Canal+), connect the cable
from the aerial to BeoSystem 1. Connect the
AV decoder to the 21-pin socket marked
DECODER on BeoSystem 1.
To connect an RF decoder, connect the
external aerial cable to the decoder input
socket and then for ward the cable to
BeoSystem 1 aerial socket (marked VHF/UHF) .
Connect the RF decoder to the 21-pin socket
marked DECODER on BeoSystem 1.
Socket panels
45
The socket panel on BeoSystem 1
allows you to connect signal input
cables as well as a variety of extra
equipment, such as a DVD player or a
linked Bang & Olufsen audio system.
The V.TAPE, AV and DECODER
sockets are available for connection
of extra equipment.
Any equipment you connect to these
sockets must be registered in the
Connections menu. For further
information, refer to the chapter
‘Register and use additional video
equipment’ on page 32.
AV and aerial socket panel
V.TAP E
21-pin socket for the connection of a BeoCord
V 8000 video tape recorder.
AV
21-pin socket for the AV connection of other
equipment, such as a DVD player, set-top box
or a second decoder (do not connect
baseband decoders here).
DECODER
21-pin socket for the connection of a
secondary set-top box or a primary decoder.
The socket provides the opportunity to
connect either an AV decoder or an RF
decoder.
The socket may be used for an AV 2 Expander
instead, which gives the oppor tunity to
connec t a decoder or other non-Bang &
Olufsen auxiliar y video equipment at the
same time.
MASTER LINK
Socket for connec tion of a compatible Bang &
Olufsen audio system.
The socket is also used for BeoLink
distribution of sound throughout the house.
MASTER LINK
AVV.TAPE
VHF/UHF
LINK
DECODER
75 Ω
IR-OUT
ATTN.
OFF ON
LINK
Aerial output socket for distribution of video
signals to other rooms.
VHF/UHF
Aerial input socket from your external aerial
or cable TV network.
ATTN. ON /OFF
Aerial signal attenuator. Options are:
OFF: Normal setting
ON: Signals damped
IR OUTPUT
For connection of a set-top box.
46
>> Socket panels
Speaker and digital input socket panel
FRONT
The two sockets are used for connecting the
front speakers in a surround sound setup.
CENTRE
Socket for connec ting centre speakers in a
surround sound setup.
REAR
The two sockets are used for connecting the
rear speakers in a surround sound setup.
SUBWOOFER
Socket used for connecting a BeoLab 2
subwoofer in a surround sound setup.
SPDIF 1
Digital input socket for connection of, for
example, a DVD player. SPDIF 1 is for digital
input from equipment connected to the AV
socket on BeoSystem 1.
SPDIF 2
Digital input socket for connection of, for
example, a DVD player. SPDIF 2 is for digital
input from equipment connected to the
V.TAPE socket on BeoSystem 1.
FRONT FRONT
REAR SUBWOOFER REAR
CENTRE SPDIF
1
2
SPDIF
If the V.TAPE socket is set up for V.ta pe or
None, the SPDIF 2 socket is dedicated to the
equipment connected to the DECODER socket
instead.
47
Additional sockets
ON/OFF
Mains switch
IR IN
For connection of a BeoLink IR receiver
enabling remote control operation of
BeoSystem 1
MAINS
Connection to the mains
RGB
For connection of a plasma screen, LCD
screen or a large-screen projector.
RS232
For connection of a plasma screen supported
by Bang & Olufsen or a large-screen
projector.
0/12V CONTROL
For connection of a home automation system
with a projector.
FAN
For connection of an external ventilator.
MAINS
IR-IN
S-VHS
VIDEO
R
L
PHONES
ON/OFF
RGB
RS232
0/12 V CONTROL
FAN
S-VHS / VIDEO / R / L / PHONES
The Camcorder and headphones sockets. For
more information, refer to the chapter ‘Close-
up socket panel’ on page 48.
48
Close-up socket panel
You can connect headphones and
listen to a TV programme, or you can
connect a Camcorder and watch your
home movies on BeoSystem 1. If you
have connected for example a
BeoCord V 8000 video tape recorder,
you can copy Camcorder recordings
onto a videotape.
The close-up socket panel
S-VHS
For the connection of S-VHS or Hi-8 Camcorders
only.
VIDEO – R – L
These sockets are for connection of a video
camera:
L – R: For audio connection (right and left sound
channel respectively).
VIDEO: For the Video signal.
PHONES
You can connec t stereo headphones to the
socket marked PHONES. The speakers
connec ted to BeoSystem 1 can then be cut out
by pressing the middle of the Beo4 volume
button.
Watch Camcorder on BeoSystem 1
To watch your Camcorder recordings, connect
the Camcorder and switch BeoSystem 1 on.
When you start playback on your Camcorder,
BeoSystem 1 automatically registers the signal
and you can see the pictures from the
Camcorder on the screen.
PHONES
LRVIDEOS-VHS
Copy from a Camcorder
If you have connected a video tape recorder,
such as a BeoCord V 8000, to BeoSystem 1,
and you connect your Camcorder to the
Camcorder and headphones sockets, you can
copy Camcorder recordings onto a videotape.
While the tape is being copied, you can watch
a TV programme or switch BeoSystem 1 to
standby.
To copy a recording from a Camcorder…
> Connect your Camcorder and start playback on
the Camcorder.
> Press RECORD to prepare BeoCord V 8000 for
recording.
> Press RECORD again to start recording.
> Press V TAPE and then STOP to pause a
recording.
> Press RECORD to resume a paused recording,
or…
> …press STOP again to stop a recording entirely.
If the signal from the Camcorder is switched
off…
> Press LIST repeatedly to display CAMCORD on
Beo4 and press GO.
In order to display C AMCORD on Beo4, you must
first add it to the Beo4 list of functions. For
further information, refer to the chapter
‘Customise Beo4’ on page 18 in the Reference
book.
Maintenance of BeoSystem 1
49
Regular maintenance, such as
cleaning BeoSystem 1, is the
responsibility of the user. To achieve
the best result, follow the
instructions to the right. Contact your
Bang & Olufsen retailer to determine
recommendations for regular
maintenance.
Any defective parts are covered by
the guarantee during the warranty
period.
Cleaning surfaces…
Wipe dust off the surfaces using a dry, soft
cloth. Remove grease stains or persistent dirt
with a soft, lint-free, firmly wrung cloth,
dipped in a solution of water containing only
a few drops of mild detergent, such as
washing-up liquid.
Cleaning the Beo4
Wipe the Beo4 remote control with a soft,
lint-free, firmly wrung cloth.
Changing the batteries…
When ‘BATTERY’ appears in the Beo4 display,
it is time to change the batteries in the
remote control.
The Beo4 requires three batteries. We
recommend that you use Alkaline batteries
only (1.5 volt – size A AA). Replace the
batteries as shown on this page. Keep a
finger on top of the batteries until the lid is
replaced.
Never use alcohol or other solvents to clean
any part of BeoSystem 1!
2
1
3
When you have replaced the batteries, you
must wait for about 10 seconds until ‘TV’
appears in the display. The Beo4 remote
control is then ready for use again.
2
1
50
Index
51
Beo4 remote control
Add a ‘button’ to the Beo4 list, Reference book
p. 18
Changing the Beo4 batteries, 49
Get access to extra equipment via Beo4, 33
Introducing BeoSystem 1 and Beo4, 4
Move extra ‘buttons’, Reference book p. 19
Remove a ‘button’ from the Beo 4 list,
Reference book p. 19
Set up Beo4, Reference book p. 18
Using Beo4, 4
BeoLink
Distribute sound and picture, Reference book
p. 14
Link connections, Reference book p. 14
Link frequency, Reference book p. 15
Link socket – Master Link, 45, Reference book
p. 14
System modulator, Reference book p. 15
BeoSystem 1 in a link room – connection,
Reference book p. 16
BeoSystem 1 in a link room – operation,
Reference book p. 17
Connections
Additional video equipment, 44
– Audio Master, AV 2 Expander, Set-top box,
Decoder, Video tape recorder, DVD player,
Game console, Camcorder, etc.
Aerial and mains connection, 43
Audio system – connect to BeoSystem 1, 44,
Reference book p. 12
Close-up socket panel, 48
Connect BeoSystem 1, 40
Connect speakers, Reference book p. 5
Decoder – AV or RF decoder, 44, Reference
book p. 10
Decoder – Two decoders, Reference book p. 10
Headphones, 48
Link connections, Reference book p. 14
Register and use additional video equipment, 32
Set-top box – Alternative set-top box
connection, Reference book p. 9
Set-top box – AV connection, Reference book p. 8
Set-top box – IR transmitter, Reference book p. 8
Socket panels, 45– 48
What’s on the Connections menu, Reference book
p. 25
Contact
Camcorder
Connect a Camcorder, 48
Copy from a Camcorder to a videotape, 48
Watch Camcorder on BeoSystem 1, 48
Clock
Enter set tings for the built-in clock, 37
What’s on the Clock menu, Reference book p.
25
Contact Bang & Olufsen, 54
Decoder
Connect AV or RF decoder, 44, Reference book
p. 10
Connect two decoders, Reference book p. 10
Socket panels, 45
Displays and menus
Displayed information and menus, 5
On-screen display, 5
On-screen menus, Reference book pp. 20 –26
Format
How to choose a picture format, 11
Headphones
Close-up socket panel, 48
52
>> Index
Home automation system
Additional sockets – home automation
system, 47
Connect a home automation system, 42
Home Theatre
Make the picture fill out the screen, 11
Select speakers for movie sound, 10
IR receiver
Enable Beo4 operation – connect the IR
receiver, 41
Language
Change sound type or language, 9
LCD screen
Additional sockets – LCD screen, 47
Connect an LCD screen, 42
Master Link
Connect and operate an audio system,
Reference book p. 12
Distribute sound and pic ture with BeoLink,
Reference book p. 14
BeoSystem 1 in a link room, Reference book p.
16
Adjust brilliance, colour or contrast, 34
Make the picture fill out the screen, 11
Picture within a picture, 14
What’s on the Picture menu, Reference book p.
26
Pincode
Activate the pincode system, 22
Change or delete your pincode, 22
Did you forget your pincode?, 23
Use your pincode, 23
Placement
Loudspeakers
Calibrate the sound level, Reference book p. 7
Connect speakers, Reference book p. 5
Place external speakers, Reference book p. 4
Select speakers for movie sound, 10
Set speaker distance, Reference book p. 6
What’s on the Speaker distance menu,
Reference book p. 24
What’s on the Speaker level menu, Reference
book p. 24
What’s on the Speaker type menu, Reference
book p. 24
Maintenance
Changing the Beo4 batteries, 49
Maintenance of BeoSystem 1, 49
Place BeoSystem 1, 40
Placing external speakers, Reference book p. 4
Plasma screen
Additional sockets – plasma screen, 47
Connect a plasma screen, 42
Projector
Additional sockets – projector, 47
Connect a projector, 42
Set-top box
Alternative set-top box connection, Reference
book p. 9
Set-top Box Controller menu, 20
Set-top box – AV connection, Reference book
p. 8
Set-top box – IR-transmitter, Reference book p. 8
Set-top box operation, 20
53
Socket panels
Additional sockets, 47
AV and aerial socket panel, 45
Close-up socket panel, 48
Connect additional equipment, 44
Speaker and digital input socket panel, 46
Socket panels, 45
Sound
Adjust or mute the sound, 9
Adjust volume, bass, treble or loudness, 35
Calibrate the sound level, Reference book p. 7
Change sound type or language, 9
Choose a speaker combination, 10
See the name of the ac tive sound system, 36
Select speakers for movie sound, 10
What’s on the Adjustment menu, Reference
book p. 23
Subtitles
Activate subtitles from teletext, 13
Surround sound
Timer
Activate the timed play function, 19
Enter set tings for the built-in clock, 37
Make BeoSystem 1 start and stop
automatically, 18
Timed play via teletext, 19
To view, edit or delete a Timer, 19
What’s on the Activate Timer menu, Reference
book p. 21
Tun e
Add new channels, 27
Adjust tuned channels, 28
Delete tuned channels, 31
Find available channels, 26
Move tuned channels, 29
Name tuned channels, 30
What’s on the Add program menu, Reference
book p. 22
What’s on the Auto tuning menu, Reference
book p. 22
What’s on the first TV manual tuning menu,
Reference book p. 23
What’s on the second TV manual tuning
menu, Reference book p. 23
Loudspeaker setup – surround sound,
Reference book pp. 4–7
Select speakers for movie sound, 10
Speaker and digital input socket panel, 46
Teletext
Activate subtitles from teletext, 13
Basic teletext functions, 12
Go directly to a page via Fastext, 17
Store favourite teletext pages – memory
pages, 12
Teletext – large, mix and reveal, 16
Updated teletext pages, 16
TV channels
Add new channels, 27
Adjust tuned channels, 28
Delete tuned channels, 31
Find available channels, 26
Move tuned channels, 29
Name tuned channels, 30
See the channel list, 8
Select a TV channel, 8
What’s on the Edit TV list menu, Reference book
p. 22
54
For your information…
This product fulfils the conditions stated
in the EEU directives 89/336 and 73/23.
Til det norske marked:
Mekaniske og elektroniske komponenter i
produktene slites ved bruk. Det må derfor påregnes
reparasjoner og utskiftning af komponenter innenfor kjøpslovens reklamasjonstid, som må regnes
som vedlikehold av produktene. Slik vedligehold gir
ikke grunnlag for å rette mangelskrav mot forhandler eller leverandør, og må bekostes af kjøper.
Your needs as a user are given careful
consideration during the design and
development process of a Bang & Olufsen
produc t and we strive to make our products
easy and comfortable to operate.
Therefore, we hope that you will take the
time to tell us about your experiences with
your Bang & Olufsen product. Any thing
which you consider important – positive or
negative – may help us in our efforts to refine
our products.
Thank you!
Write to: Bang & Olufsen a /s
Customer Service
dept. 7205
Peter Bangsvej 15
DK–7600 Struer
or fax: Bang & Olufsen
Customer Service
+45 97 85 39 11 (fax)
or e-mail: beoinfo1@bang-olufsen.dk
Manufactured under license from Dolby
Laboratories. “Dolby” and the double-D symbol
are trademarks of Dolby Laboratories.
Confidential unpublished works.
Copyright 1992–1997. All rights reserved.
DTS and DTS Digital Surround are registered
trademarks of Digital Theater Systems, Inc.
Visit our Web-site on…
www.bang-olufsen.com
Technical specifications, features and the use
thereof are subject to change without notice.
3508890 0404 Printed in Denmark by Bogtr ykkergården a -s, Struer
www.bang-olufsen.com
Loading...
