P5KPL-AM INGB
User Manual
40 pgs1.9 Mb0

Asus P5KPL-AM INGB User Manual

Download
P5KPL-AM IN/GB
Motherboard
E4450
First Edition V1
March 2009
Copyright © 2009 ASUSTeK Computer Inc. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means, except documentation kept by the purchaser for backup purposes, without the express written permission of ASUSTeK Computer Inc. (“ASUS”).
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the owners’ benet, without intent to infringe.
ii
Contents
Notices .......................................................................................................... v
Safety information ...................................................................................... vi
About this guide ......................................................................................... vi
P5KPL-AM IN/GB specications summary ............................................ viii
Chapter 1: Product introduction
1.1 Before you proceed ..................................................................... 1-1
1.2 Motherboard overview ................................................................. 1-2
1.2.1 Motherboard layout ......................................................... 1-2
1.2.2 Layout contents ............................................................... 1-2
1.3 Central Processing Unit (CPU) ................................................... 1-3
1.4 System memory ........................................................................... 1-3
1.4.1 Overview ......................................................................... 1-3
1.4.2 Memory congurations .................................................... 1-3
1.5 Expansion slots ............................................................................ 1-7
1.5.1 PCI slots .......................................................................... 1-7
1.5.2 PCI Express x16 slot ....................................................... 1-7
1.6 Jumpers ........................................................................................ 1-7
1.7 Connectors ................................................................................... 1-9
1.7.1 Rear panel ports ............................................................. 1-9
1.7.2 Internal connectors ....................................................... 1-10
1.8 Software support ........................................................................ 1-15
1.8.1 Installing an operating system ...................................... 1-15
1.8.2 Support CD information ................................................ 1-15
Chapter 2: BIOS information
2.1 Managing and updating your BIOS ............................................ 2-1
2.1.1 ASUS Update utility ........................................................ 2-1
2.1.2 ASUS EZ Flash 2 utility ................................................... 2-2
2.1.3 ASUS CrashFree BIOS 3 utility ...................................... 2-3
2.2 BIOS setup program .................................................................... 2-4
2.3 Main menu .................................................................................... 2-4
2.3.1 System Time ................................................................... 2-4
2.3.2 System Date ................................................................... 2-4
2.3.3 Primary IDE Master/Slave, SATA 1/2 .............................. 2-5
2.3.4 Storage Conguration ..................................................... 2-5
2.3.5 System Information ......................................................... 2-6
iii
Contents
2.4 Advanced menu ........................................................................... 2-6
2.4.1 JumperFree Conguration .............................................. 2-6
2.4.2 USB Conguration .......................................................... 2-8
2.4.3 CPU Conguration .......................................................... 2-8
2.4.4 Chipset ............................................................................ 2-9
2.4.5 Onboard Devices Conguration .................................... 2-10
2.4.6 PCI PnP ........................................................................ 2-10
2.5 Power menu ................................................................................ 2-11
2.5.1 Suspend Mode ...............................................................2-11
2.5.2 ACPI 2.0 Support ...........................................................2-11
2.5.3 ACPI APIC Support ........................................................2-11
2.5.4 APM Conguration ........................................................ 2-12
2.5.5 Hardware Monitor ......................................................... 2-12
2.6 Boot menu .................................................................................. 2-13
2.6.1 Boot Device Priority ...................................................... 2-13
2.6.2 Boot Settings Conguration .......................................... 2-13
2.6.3 Security ......................................................................... 2-14
2.7 Tools menu ................................................................................. 2-15
2.7.1 ASUS EZ Flash 2 .......................................................... 2-15
2.7.2 AI NET 2........................................................................ 2-15
2.8 Exit menu .................................................................................... 2-16
iv

Notices

ASUS REACH
Complying with the REACH (Registration, Evaluation, Authorisation, and Restriction of Chemicals) regulatory framework, we published the chemical substances in our products at ASUS REACH website at http://green.asus.com/ english/REACH.htm.
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with manufacturer’s instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
The use of shielded cables for connection of the monitor to the graphics card is required
to assure compliance with FCC regulations. Changes or modications to this unit not expressly approved by the party responsible for compliance could void the user’s authority
to operate this equipment.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.
This class B digital apparatus complies with Canadian ICES-003.
DO NOT throw the motherboard in municipal waste. This product has been designed to enable proper reuse of parts and recycling. This symbol of the crossed out wheeled bin indicates that the product (electrical and electronic equipment) should not be placed in municipal waste. Check local regulations for disposal of electronic products.
DO NOT throw the mercury-containing button cell battery in municipal waste. This symbol of the crossed out wheeled bin indicates that the battery should not be placed in municipal waste.
v

Safety information

Electrical safety
• To prevent electric shock hazard, disconnect the power cable from the electric outlet
before relocating the system.
•
When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. If possible, disconnect all power cables from the existing system before you add a device.
•
Before connecting or removing signal cables from the motherboard, ensure that all power cables are unplugged.
•
Seek professional assistance before using an adapter or extension cord. These devices could interrupt the grounding circuit.
• Ensure that your power supply is set to the correct voltage in your area. If you are not sure about the voltage of the electrical outlet you are using, contact your local power company.
• If the power supply is broken, do not try to x it by yourself. Contact a qualied service
technician or your retailer.
Operation safety
•
Before installing the motherboard and adding devices on it, carefully read all the manuals that came with the package.
•
Before using the product, ensure that all cables are correctly connected and the power cables are not damaged. If you detect any damage, contact your dealer immediately.
•
To avoid short circuits, keep paper clips, screws, and staples away from connectors, slots, sockets, and circuitry.
• Avoid dust, humidity, and temperature extremes. Do not place the product in any area where it may become wet.
•
Place the product on a at and stable surface.
• If you encounter technical problems with the product, contact a qualied service
technician or your retailer.

About this guide

This user guide contains the information you need when installing and conguring the
motherboard.
How this guide is organized
This guide contains the following parts:
• Chapter 1: Product introduction
This chapter describes the features of the motherboard and the new technology it
supports.
• Chapter 2: BIOS information
This chapter tells how to change system settings through the BIOS setup menus.
Detailed descriptions of the BIOS parameters are also provided.
vi
Conventions used in this guide
To ensure that you perform certain tasks properly, take note of the following symbols used throughout this manual.
DANGER/WARNING: Information to prevent injury to yourself when trying toInformation to prevent injury to yourself when trying to
complete a task.
CAUTION: Information to prevent damage to the components when trying toInformation to prevent damage to the components when trying to
complete a task.
IMPORTANT: Instructions that you MUST follow to complete a task.
NOTE: Tips and additional information to help you complete a task.Tips and additional information to help you complete a task.
Where to nd more information
Refer to the following sources for additional information and for product and software updates.
1. ASUS websites
The ASUS website provides updated information on ASUS hardware and software
products.
2. Optional documentation
Your product package may include optional documentation, such as warranty yers,
that may have been added by your dealer. These documents are not part of the standard package.
Typography
Bol d te xt Indicates a menu or an item to select.
Italics
Used to emphasize a word or a phrase.
<Key> Keys enclosed in the less-than and greater-than sign means that you must press the enclosed key. Example: <Enter> means that you must press the Enter or Return key.
<Key1>+<Key2>+<Key3> If you must press two or more keys simultaneously, the key names are linked with a plus sign (+). Example: <Ctrl>+<Alt>+<D>
vii
P5KPL-AM IN/GB specications summary
CPU LGA775 socket for Intel® Core™2 Extreme / Core™2 Quad
Chipset Northbridge: Intel® G31
Front Side Bus 1600 (O.C.) / 1333 / 1066 / 800MHz
Memory Dual channel memory architecture
Expansion Slots 1 x PCIe x16 slot
VGA Integrated Graphics Media Accelerator (Intel® GMA3100)
Storage Intel® ICH7 southbridge supports:
LAN Gb LAN
Audio VT1705 6-channel High Denition Audio CODEC
USB 8 x USB 2.0 ports (4 ports at mid-board, 4 ports at the back
ASUS Features ASUS CrashFree BIOS 3
/ Core™2 Duo / Pentium® D / Pentium® 4 / Celeron® E1000 Series and Celeron® 400 Series
processors Supports Intel® 45nm CPU Supports Intel® Hyper-Threading Technology and Enhanced Intel SpeedStep® Technology (EIST) * Refer to www.asus.com for the Intel CPU support list
Southbridge: Intel® ICH7
2 x 240-pin DIMM sockets support unbuffered non-ECC 800 / 667MHz DDR2 memory modules
Supports up to 4GB system memory * Refer to www.asus.com for the latest Memory QVL (Qualied Vendors List). ** When you install a total memory of 4GB or more, Windows® 32-bit operating system may only recognize less than 3GB. Hence, a total installed memory of less than 3GB is recommended if you are using a Windows
32-bit operating system.
2 x PCI slots
supports:
- Maximum resolution: 2048 x 1536 @ 75Hz
- 1 x UltraDMA 133/100/66 connector
- 2 x SATA 3Gb/s connectors
panel)
ASUS Q-Fan
ASUS EZ Flash 2 ASUS AI NET2
viii
(continued on the next page)
P5KPL-AM IN/GB specications summary
Internal connectors 2 x USB 2.0 connectors support additional 4 USB 2.0 ports
Rear panel ports 1 x PS/2 keyboard port
BIOS 8Mb Flash ROM, AMI BIOS, PnP, DMI2.0, WfM2.0,
Manageability WOL, PXE, RPL, WOR, PME Wake Up
Support CD Drivers
Accessories 1 x SATA cable
Form factor MicroATX form factor: 9.6 in x 7.0 in (24.4 cm x 17.8 cm)
1 x Speaker connector 2 x SATA connectors 1 x CPU fan connector
1 x 24-pin EATX power connector 1 x 4-pin ATX 12V power connector
1 x Front panel audio connector 1 x System Panel connector 1 x IDE connector
1 x PS/2 mouse port 1 x COM port 1 x VGA port 1 x LAN (RJ-45) port
4 x USB 2.0 ports 6-channel audio I/O ports
SM BIOS 2.5
ASUS PC Probe II ASUS Update
1 x UltraDMA 133/100/66 cable 1 x I/O shield
1 x User Manual
*Specications are subject to change without notice.
ix
Chapter 1
Product introduction
Thank you for buying an ASUS® P5KPL-AM IN/GB motherboard! Before you start installing the motherboard, and hardware devices on it, check the items in
your motherboard package. Refer to page ix for the list of accessories.
If any of the items is damaged or missing, contact your retailer.

1.1 Before you proceed

Take note of the following precautions before you install motherboard components or change any motherboard settings.
• Unplug the power cord from the wall socket before touching any component.
• Before handling components, use a grounded wrist strap or touch a safely grounded object or a metal object, such as the power supply case, to avoid damaging them due to static electricity
• Hold components by the edges to avoid touching the ICs on them.
• Whenever you uninstall any component, place it on a grounded antistatic pad or in the bag that came with the component.
• Before you install or remove any component, ensure that the ATX power supply is switched off or the power cord is detached from the power supply. Failure to do so may cause severe damage to the motherboard, peripherals, or components.
Onboard LED
This motherboard comes with a standby power LED that lights up to indicate that the system is ON, in sleep mode, or in soft-off mode. This is a reminder that you must shut down the system and unplug the power cable before removing or plugging in any motherboard component. The illustration below shows the location of the onboard LED.
1-1 ASUS P5KPL-AM IN/GB

1.2 Motherboard overview

1.2.1 Motherboard layout

Ensure that you install the motherboard into the chassis in the correct orientation. The edge with external ports goes to the rear part of the chassis.
Place this side towards the rear of the chassis.
Place six screws into the holes indicated by circles to secure the motherboard to the
chassis. DO NOT overtighten the screws! Doing so can damage the motherboard.

1.2.2 Layout contents

Connectors/Jumpers/Slots/LED Page Connectors/Jumpers/Slots/LED Page
1. ATX power connectors (24-pin EATXPWR, 4-pin ATX12V) 1-13 9. IDE connector (40-1 pin PRI_IDE) 1-11
2. CPU fan connector (4-pin CPU_FAN) 1-12 10. USB connectors (10-1 pin USB56, USB78) 1-13
3. Keyboard/mouse power (3-pin PS2_USBPW1-4) 1-9 11. USB device wake-up (3-pin USBPW 5-8) 1-7
4. LGA775 CPU socket 1-3 12. System panel connector (10-1 pin F_PANEL) 1-14
5. DDR2 DIMM slots 1-3 13. Standby power LED (SB_PWR) 1-1
6. Serial ATA connectors (7-pin SATA1, SATA2) 1-10 14. Front panel audio connector (10-1 pin AAFP) 1-12
7. Clear RTC RAM (3-pin CLRTC) 1-8 15. PCIe x16 / PCI slots 1-7
8. Internal speaker connector (4-pin SPEAKER) 1-11
Chapter 1: Product introduction 1-2

1.3 Central Processing Unit (CPU)

This motherboard comes with a surface mount LGA775 socket designed for the Intel®
Core™2 Extreme / Core™2 Quad / Core™2 Duo / Pentium® D / Pentium® 4 / Celeron
Series and Celeron® 400 Series processors.
Ensure that all power cables are unplugged before installing the CPU.
• Upon purchase of the motherboard, ensure that the PnP cap is on the socket and the socket contacts are not bent. Contact your retailer immediately if the PnP cap is missing,
or if you see any damage to the PnP cap/socket contacts/motherboard components. ASUS will shoulder the cost of repair only if the damage is shipment/transit-related.
• Keep the cap after installing the motherboard. ASUS will process Return Merchandise
Authorization (RMA) requests only if the motherboard comes with the cap on the
LGA775 socket.
• The product warranty does not cover damage to the socket contacts resulting from
incorrect CPU installation/removal, or misplacement/loss/incorrect removal of the PnP
cap.
This motherboard supports Intel® Hyper-Threading Technology and Enhanced Intel SpeedStep® Technology (EIST).
®
E1000

1.4 System memory

1.4.1 Overview

The motherboard comes with two Double Data Rate 2 (DDR2) Dual Inline Memory Modules (DIMM) sockets. The gure illustrates the location of the DDR2 DIMM sockets:
Channel Sockets
Channel A DIMM_A1
Channel B DIMM_B1
1.4.2 Memory congurations
You may install 512MB, 1GB, 2GB, and 4GB unbuffered non-ECC DDR2 DIMMs into the
DIMM sockets.
1-3 ASUS P5KPL-AM IN/GB
• You may install varying memory sizes in Channel A and Channel B. The system maps the total size of the lower-sized channel for the dual-channel conguration. Any excess memory from the higher-sized channel is then mapped for single-channel operation.
• Always install DIMMs with the same CAS latency. For optimum compatibility, we recommend that you obtain memory modules from the same vendor.
• Due to the memory address limitation on 32-bit Windows® OS, when you install 4GB
or more memory on the motherboard, the actual usable memory for the OS can be about 3GB or less. For effective use of memory, we recommend that you do any of the following:
- Install a maximum of 3GB system memory if you are using a 32-bit WindowsInstall a maximum of 3GB system memory if you are using a 32-bit Windows
OS.
- Use a 64-bit WindowsWindows® OS if you want to install 4GB or more memory on the motherboard.
• This motherboard does not support DIMMs made up of 256 megabits (Mb) chips or less.
The motherboard supports up to 4GB memory modules on Windows® XP Professional x64
and Vista x64 editions.
P5KPL-AM IN/GB Motherboard Qualied Vendors Lists (QVL)
DDR2-667MHz capability
Vendor Part No. Size
A-Data M2OAD5G3H3160Q1C52 512MB SS ADATA AD29608A8A-3EG20813 • • A-Data M2OAD5G314170Q1C58 1024MB DS ADATA AD29608A8A-3EG80814 • • A-Data M2OAD5H3J4170I1C53 2048MB DS ADATA AD20908A8A-3EG 30724 • • Apacer 78.91G92.9K5 512MB SS Apacer AM4B5708JQJS7E0751C 5 • • Apacer AU 512E667C5KBGC 512MB SS Apacer AM4B5708GQJS7E06332F 5 • • Apacer AU 512E667C5KBGC 512MB SS Apacer AM4B5708MIJS7E0627B 5 • • Apacer 78.01G9O.9K5 1024MB SS Apacer AM4B5808CQJS7E0751C 5 • • Apacer AU01GE667C5KBGC 1024MB DS Apacer AM4B5708GQJS7E0636B • • Apacer AU01GE667C5KBGC 1024MB DS Apacer AM4B5708MIJS7E0627B 5 • • Apacer AM4B5808CQJS7E0749B 2048MB DS Apacer 78.A1G9O.9K4 5 • • Corsair VS 512MB667D2 512MB DS Corsair MIII0052532M8CEC • • Corsair VS1GB667D2 1024MB DS Corsair MID095D62864M8CEC • • Corsair XMS2-5400 1024MB DS Corsair Heat-Sink Package 4 • • G.SKILL F2-5400PHU2-2GBNT 2048MB(2 x 1GB) DS G.SKILL D2 64M8CCF 0815 C7173S 5-5-5-15 • • G.SKILL F2-5300CL5D-4GBMQ 4096MB(2 x 2GB) DS G.SKILL Heat-Sink Package SN:8151030036559 5-5-5-15 • • GEIL GX21GB5300SX 1024MB DS GEIL Heat-Sink Package 3 • • GEIL GX22GB5300LX 2048MB DS GEIL Heat-Sink Package 5 • • GEIL GX24GB5300LDC 2048MB DS GEIL Heat-Sink Package 5 • • Kingmax KLCC28F-A8KB5 512MB SS Kingmax KKEA88B4LAUG-29DX • • Kingmax KLCD48F-A8KB5 1024MB DS Kingmax KKEA88B4LAUG-29DX • •
Kingston KVR667D2N5/ 512 512MB SS Kingston
Kingston KVR667D2N5/1G 1024MB DS Kingston
Kingston KVR667D2N5/2G 2048MB DS Micron 7RE22 D9HNL 5-5-5-15 • • Kingston KVR667D2N5/2G 2048MB DS ELPIDA E1108ACBG-8E-E 0813A90CC 5 • • Micron MT8HTF12864AY-667E1 1024MB SS Micron D9HNL 7ZE17 5 • • PSC AL6E8E63J-6E1 512MB SS PSC A3R12E3JFF717B9A00 5 • • PSC AL7E8F73C-6E1 1024MB SS PSC A3R1GE3CFF734MAA0J 5 • • PSC AL6E8E63J-6E1 1024MB DS PSC A3R12E3JFF717B9A01 5 • • PSC AL8E8F73C-6E1 2048MB DS PSC A3R1GE3CFF733MAA00 5 • • Samsung M378T5263AZ3-CE6 4096MB DS Samsung K4T2G084QA-HCE6 • •
Super Talent T667UB1GV 1024MB DS
Transcend JM667QLU-1G 1024MB SS Transced TQ243PCF8T0838 5 • • Transcend JM667QLJ-1G 1024MB DS Elpida E5108AJBG-6E-E 5 • • Transcend JM667QLU-2G 2048MB DS Transced TQ243PCF8T0834 5 • • Twinmos 8D-A3JK5MPETP 512MB SS PSC A3R12E3GEF633ACAOY 5 • •
SS/DSChip
Brand
Super Talent
Chip NO. CL
SO1237650821 SBP D6408TR4CGL25 USL074905PECNB
SO1280420822 SOP D6408TR4CGL25 USL156304PECXA
PG 64M8-800 0750 5 • •
5 • •
5 • •
DIMM
support
A* B*
®
Chapter 1: Product introduction 1-4
DDR2-800MHz capability
Vendor Part No. Size
A-Data M2GVD6G3H3160Q1E52 512MB SS VDATA VD29608A8A-25EG20813 • • A-Data M2OAD6G3H3160Q1E58 512MB SS ADATA AD29608A8A-25EG80812 • • A-Data AD2800E001GOU 2048MB(2 x 1GB) SS N/A Heat-Sink Package 4-4-4-12 • • A-Data M2GVD6G314170Q1E58 1024MB DS VDATA VD29608A8A-25EG80813 • • A-Data M2OAD6G314170Q1E58 1024MB DS ADATA AD29608A8A-25EG80810 • • A-Data AD2800E002GOU 4096MB(2 x 2GB) DS N/A Heat-Sink Package 4-4-4-12 • • Apacer 78.91G91.9K5 512MB SS Apacer AM4B5708JQJS8E0751C 5 • • Apacer 78.01GA0.9K5 1024MB SS Apacer AM4B5808CQJS8E0749D 5 • • Apacer 78.A1GA0.9K4 2048MB DS Apacer AM4B5808CQJS8E0740E 5 • • Apacer 78.A1GA0.9K4 2048MB DS Apacer AM4B5808CQJS8E0747D 5 • • Corsair CM2X1024-6400 1024MB DS Corsair Heat-Sink Package • • Corsair XMS2-6400 1024MB DS Corsair Heat-Sink Package 4 • • Corsair XMS2-6400 1024MB DS Corsair Heat-Sink Package 5 • • Corsair CM2X2048-6400C5DHX 4096MB(2 x 2GB) DS N/A Heat-Sink Package 5 • • Corsair CM2X2048-6400C5 4096MB(2 x 2GB) DS N/A Heat-Sink Package 5 • • Crucial BL12864AA804.8FE5(EPP) 2048MB(2 x 1GB) SS N/A Heat-Sink Package • • Crucial BL12864AL804.8FE5(EPP) 2048MB(2 x 1GB) SS N/A Heat-Sink Package 4 • • G.SKILL F2-6400CL5D-1GBNQ 512MB SS G.SKILL Heat-Sink Package SN:8151030036642 5-5-5-15 • • G.SKILL F2-6400CL4D-2GBPK 1024MB DS G.SKILL Heat-Sink Package 4 • • G.SKILL F2-6400CL5D-2GBNQ 1024MB DS G.SKILL Heat-Sink Package 5 • • G.SKILL F2-6400CL4D-4GBPK 2048MB DS G.SKILL Heat-Sink Package 4 • • G.SKILL F2-6400CL5D-4GBPQ 2048MB DS G.SKILL Heat-Sink Package 5 • • G.SKILL F2-6400CL6Q-16GMQ 4096MB DS N/A Heat-Sink Package 5 • • GEIL GB22GB6400C4DC 1024MB DS GEIL GL2L64M088BA30EB 5 • • GEIL GB22GB6400C5DC 1024MB DS GEIL GL2L64M088BA30EB 5 • • GEIL GB24GB6400C4QC 1024MB DS GEIL GL2L64M088BA30EB 4 • • GEIL GB24GB6400C5QC 1024MB DS GEIL GL2L64M088BA30EB 5 • • GEIL GE22GB800C4DC 1024MB DS GEIL Heat-Sink Package 4 • • GEIL GE22GB800C5DC 1024MB DS GEIL Heat-Sink Package 5 • • GEIL GE24GB800C4QC 1024MB DS GEIL Heat-Sink Package 4 • • GEIL GE24GB800C5QC 1024MB DS GEIL Heat-Sink Package 5 • • GEIL GX22GB6400DC 1024MB DS GEIL Heat-Sink Package 5 • • GEIL GX22GB6400UDC 1024MB DS GEIL Heat-Sink Package 4 • • GEIL GB24GB6400C4DC 2048MB DS GEIL GL2L128M88BA25AB 4 • • GEIL GB24GB6400C5DC 2048MB DS GEIL GL2L128M88BA25AB 5 • • GEIL GB28GB6400C4QC 2048MB DS GEIL GL2L128M88BA25AB 4 • • GEIL GB28GB6400C5QC 2048MB DS GEIL GL2L128M88BA25AB 5 • • GEIL GE24GB800C4DC 2048MB DS GEIL Heat-Sink Package 4 • • GEIL GE24GB800C5DC 2048MB DS GEIL Heat-Sink Package 5 • • GEIL GE28GB800C4QC 2048MB DS GEIL Heat-Sink Package 4 • • GEIL GE28GB800C5QC 2048MB DS GEIL Heat-Sink Package 5 • • GEIL GX22GB6400CUSC 2048MB DS GEIL Heat-Sink Package 4 • • GEIL GX22GB6400LX 2048MB DS GEIL Heat-Sink Package 5 • • GEIL GX24GB6400DC 2048MB DS GEIL Heat-Sink Package 5 • • Kingmax KLDC28F-A8KI5 512MB SS Kingmax KKA8FF1XF-JFS-25A • • Kingmax KKB8FFBXF-CFA-25U 1024MB SS Kingmax KLDD48F-B8KB5 • • kingmax KLDE88F-B8KB5 2048MB DS kingmax KKB8FFBXF-CFA-25U • • Kingston KVR800D2N6/ 512 512MB SS Elpida E5108AJBG-8E-E 6 • • Kingston KHX6400D2LLK2/1GN 1024M(2 x 512MB) SS Kingston Heat-Sink Package 4-4-4-12 • • Kingston KHX6400D2LL/1G 1024MB DS Kingston Heat-Sink Package 4-4-4-12 • • Kingston KVR800D2N5/1G 1024MB DS Kingston D6408TR4CGL25USL362406PECXA 5 • • Kingston KVR800D2N6/1G 1024MB DS Elpida E5108AJBG-8E-E • • Kingston KHX6400D2K2/2G 2048MB(2 x 1GB) DS N/A Heat-Sink Package 5-5-5-15 • • Kingston 461625.010819 PTGC 2048MB DS Kingston KVR800D2N6/2G 6 • • Kingston KHX6400D2/2G 2048MB DS Kingston Heat-Sink Package 5 • • Kingston KVR800D2N5/2G 2048MB DS Elpida E1108ACBG-8E-E 5 • • Kingston KVR800D2N6/4G 4096MB DS Elpida E2108ABSE-8G-E 6 • •
OCZ OCZ2G800R22GK 1024MB DS OCZ Heat-Sink Package 5 • • OCZ OCZ2P800R22GK 1024MB DS OCZ Heat-Sink Package 4 • • OCZ OCZ2RPR8002GK 1024MB DS OCZ Heat-Sink Package 4 • • OCZ OCZ2VU8004GK 1024MB DS OCZ Heat-Sink Package 6 • • OCZ OCZ2F8004GK 2048MB DS N/A Heat-Sink Package 5 • • OCZ OCZ2P8004GK 4096MB(2 x 2GB) DS N/A Heat-Sink Package 5 • •
PSC AL7E8F73C-8E1 1024MB SS PSC A3R1GE3CFF734MAA0E 5 • • PSC AL8E8F73C-8E1 2048MB DS PSC A3R1GE3CFF734MAA0E 5 • • PSC SHG772-AA3G 2048MB DS PSC PL8E8F73C-8E1 • • PSC XCP271A3G-A 2048MB DS PSC PL8E8G73E-8E1 • • Qimonda HYS64T256020EU-2.5-C2 2048MB DS Qimonda HY818T1G800C2F-2.5 5 • • Samsung K4T51083QG-HCF7 512MB SS Qimonda M378T6553GZS-CF7 6 • • Samsung K4T1G084QQ-HCF7 1024MB SS Qimonda M378T2863QZS-CF7 6 • • Samsung K4T51083QG-HCF7 1024MB DS Samsung M378T2953GZ3-CF7 6 • • Samsung K4T1G084QQ-HCF7 2048MB DS Samsung M37875663QZ3-CF7 6 • •
SS/
Chip Brand Chip NO. CL
DS
(continued on the next page)
DIMM
support
A* B*
1-5 ASUS P5KPL-AM IN/GB
DDR2-800MHz capability
Vendor Part No. Size
Samsung M378T5263AZ3-CF7 4096MB DS Samsung K4T2G084QA-HCF7 • • Super Talent T800UB1GC4 1024MB DS Super Talent Heat-Sink Package 4 • • Transcend TS64MLQ64V8J 512MB SS Micron 7HD22 D9GMH 5 • • Transcend JM800QLU-1G 1024MB SS Transced TQ1243PCF8 5 • • Transcend TS128MLQ64V8U 1024MB SS ELPIDA E1108ACBG-8E-E 5 • • Transcend JM800QLJ-1G 1024MB DS Transced TQ123PJF8F0801 5 • • Transcend JM800QLJ-1G 1024MB DS Transcend TQ123YBF8 T0747 5 • • Transcend TS128MLQ64V8J 1024MB DS Mircon 7HD22D9GMH 5 • • Transcend JM800QLU-2G 2048MB DS Transced TQ243PCF8 5 • • Transcend TS256MLQ64V8U 2048MB DS Elpida E1108ACBG-8E-E 5 • •
SS/
Chip Brand Chip NO. CL
DS
DIMM
support
A* B*
DDR2-1066MHz capability
Vendor Part No. Size
A-Data AD21066E002GU 4096MB(2 x 2GB) DS N/A Heat-Sink Package 5-5-5-15 • • Apacer 78.0AG9S.9K4 2048MB(2 x 1GB) DS N/A Heat-Sink Package 5-5-5-15 • Apacer 78.AAGAL.9KZ 4096MB(2 x 2GB) DS N/A Heat-Sink Package 5-5-5-15 • • Corsair CM2X1024-8500C5 1024MB DS Corsair Heat-Sink Package • • Crucial BL12864AA1065.8FE5(epp) 2048MB(2 x 1GB) SS N/A Heat-Sink Package • • G.SKILL F2-8500CL5S-1GBPK 1024MB DS N/A Heat-Sink PackageSN:815130037562 5-5-5-15 • G.SKILL F2-8500CL5D-2GBPK 2048MB(2 x 1GB) DS N/A Heat-Sink Package 5-5-5-15 • • G.SKILL F2-8500CL5D-4GBPK 4096MB(2 x 2GB) DS N/A Heat-Sink Package 5-5-5-15 • • GEIL GB22GB8500C5DC 1024MB SS GEIL GL2L128M88BA25AB 5 • • GEIL GB24GB8500C5QC 1024MB SS GEIL GL2L128M88BA25AB 5 • • GEIL GE22GB1066C5DC 1024MB SS GEIL Heat-Sink Package 5 • • GEIL GE24GB1066C5QC 1024MB SS GEIL Heat-Sink Package 5 • • GEIL GB24GB8500C5DC 2048MB DS GEIL GL2L128M88BA25AB 5 • • GEIL GE24GB1066C5DC 2048MB DS GEIL Heat-Sink Package 5 • • GEIL GX24GB8500C5UDC 4096MB(2 x 2GB) DS N/A Heat-Sink Package 5 • • Kingston KHX8500D2/ 512 512MB SS Kingston Heat-Sink Package 5-5-5-18 • • Kingston KHX8500D2K2/1GN(EPP) 1024MB(2 x 512MB) SS Kingston Heat-Sink Package 5-5-5-18 • • Kingston KHX8500D2K2/2GN(EPP) 1024MB DS Kingston Heat-Sink Package 5-5-5-18 • •
OCZ OCZ2N10662GK 2048MB(2 x 1GB) DS OCZ Heat-Sink Package 004820806001601-2 • • OCZ OCZ2N1066SR2DK(Epp) 2048MB(2 x 1GB) DS OCZ Heat-Sink Package 004820806001601-2 5-5-5-15 • • OCZ OCZ2N1066SR2DK(EPP) 2048MB(2 x 1GB) DS OCZ Heat-Sink Package 004820806001601-2 • • OCZ OCZ2RPR10664GK 4096MB(2 x 2GB) DS N/A Heat-Sink Package 5-5-5-15 • •
Qimonda HYS64T128000EU-1.9-C2 1024MB DS Qimonda HYB18T1G800C2F-1.9FSS25253 • • Transcend TX1066QLU-2GK 2048MB(2 x 1GB) SS N/A Heat-Sink Package 5 • Transcend TX1066QLJ-2GK 2048MB(2 x 1GB) DS Transcend Heat-Sink Package 5 • • Transcend TX1066QLU-4GK 4096MB(2 x 2GB) DS Transcend Heat-Sink Package 5 • •
SS/
Chip Brand Chip NO. CL
DS
DIMM
support
A* B*
SS: Single-sided / DS: Double-sided DIMM support:
• A*: Supports one module inserted into either slot as Single-channel memory
conguration.
• B*: Supports one pair of modules inserted into both the yellow slots as one pair of
Dual-channel memory conguration.
Visit the ASUS website at www.asus.com for the latest QVL.
Chapter 1: Product introduction 1-6

1.5 Expansion slots

In the future, you may need to install expansion cards. Refer to the technical documentation that comes with your expansion card for installation details.
Ensure to unplug the power cord before adding or removing expansion cards. Failure to do so may cause you physical injury and damage motherboard components.

1.5.1 PCI slots

The PCI slot supports cards such as LAN cards, SCSI cards, USB cards, and other cards
that comply with the PCI specications.

1.5.2 PCI Express x16 slot

This motherboard supports a PCI Express x16 graphics card that complies with the PCI Express specications.

1.6 Jumpers

1. USB device wake-up (3-pin USBPW5-8)
Set this jumper to +5V to wake up the computer from S1 sleep mode (CPU stopped, DRAM refreshed, system running in low power mode) using the connected USB devices. Set this jumper to +5VSB to wake up from S3 and S4 sleep modes (no power to CPU, DRAM in slow refresh, power supply in reduced power mode). The USBPW5-8 jumper is for the internal USB connectors that you can connect to addition USB ports.
• The USB device wake-up feature requires a power supply that can provide 500mA on the +5VSB lead for the USB port. Otherwise, the system will not power up.
• The total current consumed must NOT exceed the power supply capability (+5VSB) whether under normal condition or in sleep mode.
1-7 ASUS P5KPL-AM IN/GB
2. Clear RTC RAM (3-pin CLRTC)
This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS. You can clear the CMOS memory of date, time, and system setup parameters by erasing the CMOS RTC RAM data. The onboard button cell battery powers the RAM data in CMOS, which include system setup information such as the system passwords.
To erase the RTC RAM:
1. Turn OFF the computer and unplug the power cord.
2. Move the jumper cap from pins 1-2 (default) to pins 2-3. Keep the cap on pins 2-3 for about 5-10 seconds, then move the cap back to pins 1-2.
3. Plug the power cord and turn ON the computer.
4. Hold down the <Del> key during the boot process and enter BIOS setup to reenter data.
Except when clearing the RTC RAM, never remove the cap on CLRTC jumper default
position. Removing the cap will cause system boot failure!
• If the steps above do not help, remove the onboard battery and move the jumper again to clear the CMOS RTC RAM data. After clearing the CMOS, reinstall the battery.
• You do not need to clear the RTC when the system hangs due to overclocking. For system failure due to overclocking, use the CPU Parameter Recall (C.P.R) feature. Shut down and reboot the system so the BIOS can automatically reset parameter settings to default values.
Chapter 1: Product introduction 1-8
3. Keyboard/mouse power (3-pin PS2_USBPW1-4)
3 42
57 6
1
9
8
10
This jumper allows you to enable or disable the keyboard/mouse and USB port 1-4 wake-up feature. When you set this jumper to pins 2-3 (+5VSB), you can wake up the
computer by pressing a key on the keyboard (the default is the Space Bar), clicking the mouse, or using a USB device. This feature requires an ATX power supply that can supply at least 1A on the +5VSB lead, and a corresponding setting in the BIOS. The
PS2_USBPW1-4 jumper is for the rear USB ports.

1.7 Connectors

1.7.1 Rear panel ports

1. PS/2 mouse port (green). This port is for a PS/2 mouse.
2. LAN (RJ-45) port. This port allows Gigabit connection to a Local Area Network (LAN)
through a network hub. Refer to the table below for the LAN port LED indications.
LAN port LED indications
Activity/Link LED Speed LED
Status Description Status Description
OFF No link OFF 10Mbps connection
ORANGE Linked ORANGE 100Mbps connection
BLINKING Data activity GREEN 1Gbps connection
1-9 ASUS P5KPL-AM IN/GB
ACT/LINK
LED
LAN port
SPEED
LED
3. Line In port (light blue). This port connects to the tape, CD, DVD player, or other
audio sources.
4. Line Out port (lime). This port connects to a headphone or a speaker. In 4-channel
and 6-channel conguration, the function of this port becomes Front Speaker Out.
5. Microphone port (pink). This port connects to a microphone.
Refer to the audio conguration table below for the function of the audio ports in 2, 4, or 6-channel conguration.
Audio 2, 4, 6-channel conguration
Port Headset 2-channel 4-channel 6-channel
Light Blue Line In Rear Speaker Out Rear Speaker Out
Lime Line Out Front Speaker Out Front Speaker Out
Pink Mic In Mic In Bass/Center
6. USB 2.0 ports 1 and 2. These two 4-pin Universal Serial Bus (USB) ports connect to
USB 2.0 devices.
7. USB 2.0 ports 3 and 4. These two 4-pin Universal Serial Bus (USB) ports connect to
USB 2.0 devices.
8. Video Graphics Adapter (VGA) port. This 15-pin port is for a VGA monitor or other
VGA-compatible devices.
9. COM port. This 9-pin COM port is for pointing devices or other serial devices.
10. PS/2 keyboard port (purple). This port is for a PS/2 keyboard.

1.7.2 Internal connectors

1. Serial ATA connectors (7-pin SATA1, SATA2)
These connectors are for the Serial ATA signal cables for Serial ATA 3Gb/s hard disk drives and optical disk drives. The Serial ATA 3Gb/s is backward compatible with the Serial ATA 1.5Gb/s specication. The data transfer rate of the Serial ATA 3Gb/s is faster than that of the standard parallel ATA (133Mb/s).
Install the Windows® Service Pack 1 before using Serial ATA.
Chapter 1: Product introduction 1-10
2. IDE connector (40-1 pin PRI_IDE)
The onboard IDE connector is for the Ultra DMA 133/100/66 signal cable. There are three connectors on each Ultra DMA 133/100/66 signal cable: blue, black, and gray. Connect the blue connector to the motherboard’s IDE connector, then select one of the following modes to congure your device.
Driver Jumper setting Mode of device(s) Cable connector
Single device Cable-Select or Master - Black
Two devices
Cable-Select
Master Master
Slave Slave
Pin 20 on the IDE connector is removed to match the covered hole on the Ultra DMA cable
connector. This prevents incorrect insertion when you connect the IDE cable.
• Use the 80-conductor IDE cable for Ultra DMA 133/100/66 IDE devices.
• If any device jumper is set to Cable-Select, ensure that all other device jumpers have the same setting.
Master Black
Slave Gray
Black or gray
3. Speaker connector (4-pin SPEAKER)
This 4-pin connector is for the chassis-mounted system warning speaker. The speaker allows you to hear system beeps and warnings.
1-11 ASUS P5KPL-AM IN/GB
4. Front panel audio connector (10-1 pin AAFP)
This connector is for a chassis-mounted front panel audio I/O module that supports either HD Audio or legacy AC’97 audio standard.
• We recommend that you connect a high-denition front panel audio module to this connector to get the motherboard’s high-denition audio capability.
• If you want to connect a high-denition front panel audio module to this connector, set the Front Panel Support Type item in the BIOS to [HD Audio]. If you want to connect
an AC'97 front panel audio module to this connector, set the item to [AC97]. See 2.4.4 Chipset for details.
5. CPU fan connector (4-pin CPU_FAN)
The CPU fan connector supports a cooling fan of 350mA ~ 2000mA (24W max.).
Connect the CPU fan cable to the CPU fan connector on the motherboard, ensuring that the black wire of each cable matches the ground pin of the connector.
Only the CPU fan supports the ASUS Q-Fan feature.
DO NOT forget to connect the CPU fan cable to the CPU fan connector. Insufcient air ow inside the system may damage the motherboard components. It is not a jumper! DO NOT place a jumper cap on the CPU fan connector!
Chapter 1: Product introduction 1-12
6. ATX power connectors (24-pin EATXPWR, 4-pin ATX12V)
These connectors are for ATX power supply plugs. The power supply plugs are
designed to t these connectors in only one orientation. Find the proper orientation and push down rmly until the connectors completely t.
•
For a fully congured system, we recommend that you use a power supply unit (PSU)
that complies with ATX 12V Specication 2.0 (or later version) and provides a minimum
power of 400W.
• DO NOT forget to connect the 4-pin ATX12V power plug. Otherwise, the system will not
boot.
• We recommended that you use a PSU with a higher power output when conguring
a system with more power-consuming devices or when you intend to install additional devices. The system may become unstable or may not boot up if the power is inadequate.
7. USB connectors (10-1 pin USB56, USB78)
These connectors are for USB 2.0 ports. Connect the USB module cable to any of
these connectors, then install the module to a slot opening at the back of the system
chassis. These USB connectors comply with the USB 2.0 specication that supports up
to 480Mbps data transmission speed.
Never connect a 1394 cable to the USB connectors. Doing so will damage the motherboard!
The USB module cable is purchased separately.
1-13 ASUS P5KPL-AM IN/GB
8. System panel connector (10-1 pin F_PANEL)
This connector supports several chassis-mounted functions.
• System power LED (2-pin PWRLED)
This 2-pin connector is for the system power LED. Connect the chassis power LED
cable to this connector. The system power LED lights up when you turn on the system, and blinks when the system is in sleep mode.
• Hard disk drive activity LED (2-pin +HDLED)
This 2-pin connector is for the HDD Activity LED. Connect the HDD Activity LED cable
to this connector. The IDE LED lights up or ashes when data is read from or written to
the HDD.
• ATX power button/soft-off button (2-pin PWRBTN)
This connector is for the system power button. Pressing the power button turns
the system on or puts the system in sleep or soft-off mode depending on the BIOS settings. Pressing the power switch for more than four seconds while the system is ON turns the system OFF.
• Reset button (2-pin RESET)
This 2-pin connector is for the chassis-mounted reset button for system reboot without
turning off the system power.
Chapter 1: Product introduction 1-14

1.8 Software support

1.8.1 Installing an operating system

This motherboard supports Windows® XP/Vista Operating Systems (OS). Always install the
latest OS version and corresponding updates to maximize the features of your hardware.
• Motherboard settings and hardware options vary. Refer to your OS documentation for detailed information.
• Ensure that you install Windows® XP Service Pack 3 or later versions / Windows® Vista Service Pack 1 or later versions before installing the drivers for better compatibility and system stability.

1.8.2 Support CD information

The Support CD that comes with the motherboard package contains the drivers, software applications, and utilities that you can install to avail all motherboard features.
The contents of the Support CD are subject to change at any time without notice. Visit the ASUS website at www.asus.com for updates.
To run the Support CD
Place the Support CD into the optical drive. The CD automatically displays the Drivers menu if Autorun is enabled on your computer.
Click an icon to display Support CD/motherboard information
Click an item to install
If Autorun is NOT enabled on your computer, browse the contents of the Support CD to
locate the le ASSETUP.EXE from the BIN folder. Double-click the ASSETUP.EXE to run
the CD.
1-15 ASUS P5KPL-AM IN/GB
Chapter 2
BIOS information

2.1 Managing and updating your BIOS

Save a copy of the original motherboard BIOS le to a USB ash disk in case you need to
restore the BIOS in the future. Copy the original motherboard BIOS using the ASUS Update utility..

2.1.1 ASUS Update utility

The ASUS Update is a utility that allows you to manage, save, and update the motherboard BIOS in Windows® environment.
• ASUS Update requires an Internet connection either through a network or an Internet Service Provider (ISP).
• This utility is available in the Support CD that comes with the motherboard package.
Installing ASUS Update:
1. Place the Support CD into the optical drive. The Drivers menu appears.
2. Click the Utilities tab, then click ASUS Update.
3. Follow the onscreen instructions to complete the installation.
Quit all Windows® applications before you update the BIOS using this utility.
Updating the BIOS:
1. From the Windows® desktop, click Start > Programs > ASUS > ASUS Update >
ASUS Update to launch the ASUS Update utility.
2. From the dropdown list, select either of the following methods:
Updating from the Internet
a. Select Update BIOS from the Internet, then click Next.
b. Select the ASUS FTP site nearest you to avoid network trafc, or click Auto Select
then click Next.
c. From the FTP site, select the BIOS version you want to download then click Next.
The ASUS Update utility is capable of updating itself through the Internet. Always update the utility to get all its features.

Chapter 2: BIOS information 2-1

Updating from a BIOS file
a. Select Update BIOS from a le, then click Next.
b. Locate the BIOS le from the Open window, then click Open.
3. Follow the onscreen instructions to complete the updating process.

2.1.2 ASUS EZ Flash 2 utility

The ASUS EZ Flash 2 feature allows you to update the BIOS without using an OS-based
utility.
Download the latest BIOS le from the ASUS website at www.asus.com.
To update the BIOS using EZ Flash 2:
1. Insert the USB ash disk that contains the latest BIOS le to a USB port, then launch EZ Flash 2 in either of these two ways:
• Press <Alt> + <F2> during POST to display the following:
ASUSTek EZ Flash 2 BIOS ROM Utility V3.34
FLASH TYPE: MXIC 25L8005
Current ROM
BOARD: P5KPL-AM IN/GB VER: 0303 (H:00 B:03) DATE: 02/09/2009
PATH: A:\
A:
Update ROM
BOARD: Unknown VER: Unknown DATE: Unknown
Note
[Enter] Select or Load [Tab] Switch [V] Drive Info [Up/Down/Home/End] Move [B] Backup [Esc] Exit
• Enter the BIOS setup program. Go to the Tools menu to select EZ Flash 2 and press <Enter> to enable it.
2. Press <Tab> to locate the correct BIOS le. Press <Enter>. EZ Flash 2 performs the
BIOS updating process and automatically reboots the system when done.
• Only a USB ash disk with FAT 32/16 format and single partition supports ASUS EZ
Flash 2.
• DO NOT shut down or reset the system while updating the BIOS to prevent system boot failure.
2-2 ASUS P5KPL-AM IN/GB

2.1.3 ASUS CrashFree BIOS 3 utility

The ASUS CrashFree BIOS 3 is an auto recovery tool that allows you to restore the BIOS le
when it fails or gets corrupted during the updating process. You can update a corrupted BIOS
le using the motherboard Support CD or a USB ash disk that contains the updated BIOS le.
• Prepare the motherboard Support CD or the USB ash disk containing the updated
motherboard BIOS before using this utility.
• Always connect the SATA cable to the SATA1 / SATA2 connector; otherwise, the utility
will not function.
Recovering the BIOS
To recover the BIOS:
1. Turn on the system.
2. Insert the Support CD or the USB ash disk containing the BIOS le to the optical drive
or USB port.
The utility displays the following message and automatically checks the Support CD or
USB ash disk for the BIOS le.
Bad BIOS checksum. Starting BIOS recovery... Checking for CD-ROM...
When the BIOS le is found, the utility reads it and starts erasing the corrupted BIOS le.
Bad BIOS checksum. Starting BIOS recovery... Checking for CD-ROM... CD-ROM found!
Reading le “P5KPLGIN.ROM”. Completed.
Start Erasing... Start Programming...
3. Restart the system after the utility completes the updating process.
• Only a USB ash disk with FAT 32/16 format and single partition supports ASUS CrashFree BIOS 3. The device size should be smaller than 8GB.
• DO NOT shut down or reset the system while updating the BIOS! Doing so can cause system boot failure!
The recovered BIOS may not be the latest BIOS version for this motherboard. Download
the latest BIOS le from the ASUS website at www.asus.com.
Chapter 2: BIOS information 2-3

2.2 BIOS setup program

Use the BIOS Setup program when you are installing a motherboard, reconguring your system, or prompted to “Run Setup.” This section explains how to congure your system
using this utility. If you want to enter Setup after POST, reboot the system by doing any of the following
procedures:
• Restart using the OS standard shut-down procedure.
• Press <Ctrl>+<Alt>+<Del> simultaneously.
• Press the reset button on the system chassis.
• Press the power button to turn the system off then back on.
Using the power button, reset button, or the <Ctrl>+<Alt>+<Del> keys to force reset from a running operating system can cause damage to your data or system. We recommend that you always shut down the system properly from the operating system.
• The default BIOS settings for this motherboard apply to most conditions to ensure optimum performance. If the system becomes unstable after changing any BIOS settings, load the default settings to ensure system compatibility and stability. Select the Load Setup Defaults item under the Exit menu. See section 2.8 Exit menu.
• The BIOS setup screens in this chapter are for reference only. They may not exactly match what you see on your screen.
• Visit the ASUS website at www.asus.com to download the latest BIOS le for this motherboard.

2.3 Main menu

When you enter the BIOS Setup program, the Main menu screen appears, giving you an overview of the basic system information.
Main Advanced Power Boot Tools Exit

System Time [14:14:35] System Date [Wed 04/16/2008]

Primary IDE Master [Not Detected] Primary IDE Slave [Not Detected] SATA 1 [Not Detected] SATA 2 [Not Detected]
BIOS SETUP UTILITY
Use [ENTER], [TAB] or [SHIFT-TAB] to select
a eld.
Use [+] or [-] to
congure system time.
Storage Conguration
System Information
v02.58 (C)Copyright 1985-2009, American Megatrends, Inc.
Select Screen
Select Item +- Change Field Tab Select Field F1 General Help F10 Save and Exit ESC Exit
2.3.1 System Time [xx:xx:xx]
Allows you to set the system time.
2.3.2 System Date [Day xx/xx/xxxx]
Allows you to set the system date.
2-4 ASUS P5KPL-AM IN/GB

2.3.3 Primary IDE Master/Slave, SATA 1/2

While entering Setup, the BIOS automatically detects the presence of IDE/SATA devices. There is a separate submenu for each IDE/SATA device. Select a device item then press <Enter> to display the IDE/SATA device information.
The BIOS automatically detects the values opposite the dimmed items (Device, Vendor, Size,
LBA Mode, Block Mode, PIO Mode, Async DMA, Ultra DMA, and SMART monitoring). These
values are not user-congurable. These items show N/A if no IDE/SATA device is installed in
the system.
Type [Auto]
Selects the type of the IDE drive. Setting this item to [Auto] allows automatic selection of the appropriate IDE device type. Select [CDROM] if you are specically conguring a CD-ROM drive. Select [ARMD] (ATAPI Removable Media Device) if your device is either a ZIP, LS-120,
or MO drive. Conguration options: [Not Installed] [Auto] [CDROM] [ARMD]
This item only appears in the Primary IDE Master/Slave menus.
LBA/Large Mode [Auto]
Enables or disables the LBA mode. Setting this item to [Auto] enables the LBA mode if the device supports this mode, and if the device was not previously formatted with LBA mode
disabled. Conguration options: [Disabled] [Auto]
Block (Multi-Sector Transfer) M [Auto]
Enables or disables data multi-sectors transfers. When you set this item to [Auto], the data transfer from and to the device occurs multiple sectors at a time if the device supports multi­sector transfer feature. When you set this item to [Disabled], the data transfer from and to
the device occurs one sector at a time. Conguration options: [Disabled] [Auto]
PIO Mode [Auto]
Selects the PIO mode. Conguration options: [Auto] [0] [1] [2] [3] [4]
DMA Mode [Auto]
Selects the DMA mode. Conguration options: [Auto]
SMART Monitoring [Auto]
Sets the Smart Monitoring, Analysis, and Reporting Technology.
Conguration options: [Auto] [Disabled] [Enabled]
32Bit Data Transfer [Enabled]
Enables or disables 32-bit data transfer. Conguration options: [Disabled] [Enabled]
2.3.4 Storage Conguration
The items in this menu allow you to set or change the congurations for the storage devices installed in the system. Select an item then press <Enter> if you want to congure the item.
ATA/IDE Conguration [Enhanced]
Sets the ATA/IDE conguration. Conguration options: [Disabled] [Compatible] [Enhanced]
Enhanced Mode Support On [S-ATA] Sets Serial ATA, Parallel ATA, or both as native mode. Configuration options: [S-ATA+P-ATA] [S-ATA] [P-ATA]
Chapter 2: BIOS information 2-5
IDE Detect Time Out (Sec) [35]
Selects the time out value for detecting ATA/ATAPI devices. Conguration options: [0] [5] [10] [15] [20] [25] [30] [35]

2.3.5 System Information

This menu gives you an overview of the general system specications. The BIOS
automatically detects the items in this menu.
Bios Information
Displays the auto-detected BIOS information.
Processor
Displays the auto-detected CPU specication.
System Memory
Displays the auto-detected system memory.

2.4 Advanced menu

The Advanced menu items allow you to change the settings for the CPU and other system devices.
Take caution when changing the settings of the Advanced menu items. Incorrect eld
values can cause the system to malfunction.
JumperFree Conguration
USB Conguration
CPU Conguration
Chipset
Onboard Devices Conguration
PCIPnP
Adjust system frequency/voltage
2.4.1 JumperFree Conguration
AI Overclocking [Auto]
Selects the CPU overclocking options to achieve desired CPU internal frequency. Conguration options:
[Manual] - Allows you to individually set overclocking parameters. [Auto] - Loads the optimal settings for the system.
[Overclock Prole] - Loads overclocking proles with optimal parameters for stability when
overclocking. [Test Mode] - Loads overclock (overclocking 5%) with spread spectrum.
The following item appears only when you set the AI Overclocking item to [Manual].
2-6 ASUS P5KPL-AM IN/GB
CPU Frequency [xxx]
Displays the frequency sent by the clock generator to the system bus and PCI bus. The value of this item is auto-detected by the BIOS. Use the <+> and <-> keys to adjust the CPU frequency. You can also key in the desired CPU frequency using the numeric keypad. The
values range from 133 to 600. Refer to the table below for the correct Front Side Bus and
CPU External Frequency settings.
FSB / CPU External Frequency Synchronization
Front Side Bus CPU External Frequency
FSB 1600 400MHz
FSB 1333 333MHz
FSB 1066 266MHz
FSB 800 200MHz
The following item appears only when you set the AI Overclocking item to [Overclock Prole].
Overclock Options [Overclock 5%]
Allows selection of CPU overclocking options to achieve desired CPU internal frequency.
Conguration options: [Overclock 5%] [Overclock 10%] [Overclock 15%] [Overclock 20%] [Overclock 30%]
DRAM Frequency [Auto]
Allows you to set the DDR2 operating frequency. Conguration options (for 1600MHz FSB CPU): [Auto] [800MHz] [960MHz] [1000MHz] [1200MHz]
Conguration options (for 1333MHz FSB CPU): [Auto] [667MHz] [800MHz] [1000MHz] [1100MHz]
Conguration options (for 1066MHz FSB CPU): [Auto] [667MHz] [800MHz] [1067MHz]
Conguration options (for 800MHz FSB CPU): [Auto] [667MHz] [800MHz]
Selecting a very high DRAM frequency may cause the system to become unstable! If this
happens, revert to the default setting.
1.8V Dual Over Voltage [Auto]
Manually set memory voltage or set to Auto for safe mode.
Conguration options: [Auto] [1.92V] [2.01V] [2.17V] [2.26V]
VTT_CPU Over Voltage [Auto]
Manually set FSB Termination Voltage or set to Auto for safe mode.
Conguration options: [Auto] [1.2V] [1.35V]
1.25V Over Voltage [Auto]
Manually set MCH Chipset Voltage or set to Auto for safe mode.
Conguration options: [Auto] [1.25V] [1.4V]
1.5V Over Voltage [Auto]
Manually set ICH Chipset Voltage or set to Auto for safe mode.
Conguration options: [Auto] [1.5V] [1.6V]
Chapter 2: BIOS information 2-7
2.4.2 USB Conguration
The items in this menu allows you to change the USB-related features. Select an item then press <Enter> to display the conguration options.
The Module Version and USB Devices Enabled items show the auto-detected values. If no USB device is detected, the item shows None.
USB Functions [Enabled]
Allows you to enable or disable the USB functions.Conguration options: [Disabled] [Enabled]
USB 2.0 Controller [Enabled]
Allows you to enable or disable the USB 2.0 controller. Conguration options: [Enabled] [Disabled]
Legacy USB Support [Auto]
Allows you to enable or disable support for legacy USB devices. Setting to [Auto] allows the system to detect the presence of USB devices at startup. If detected, the USB controller legacy mode is enabled. If no USB device is detected, the legacy USB support is disabled.
Conguration options: [Disabled] [Enabled] [Auto]
USB 2.0 Controller Mode [HiSpeed]
Allows you to set the USB 2.0 controller mode to HiSpeed (480 Mbps) or FullSpeed (12 Mbps). This item appears only when you enable the USB 2.0 Controller item. Conguration options: [FullSpeed ] [HiSpeed ]
2.4.3 CPU Conguration
The items in this menu show the CPU-related information that the BIOS automatically detects.
CPU Ratio Setting [Auto]
Sets the ration between CPU core clock and the FSB frequency. Conguration options: [Auto]
If an invalid ratio is set in CMOS, then the actual and set values may differ.
Key in ratio numbers directly.
C1E Support [Enabled]
Enable this item and users can congure the Enhanced Halt State function. Conguration options: [Disabled] [Enabled]
Max CPUID Value Limit [Disabled]
Enable this item to boot legacy operating systems that cannot support CPUs with extended
CPUID functions. Conguration options: [Disabled] [Enabled]
Vanderpool Technology [Enabled]
Enable this item when the processor supports Vanderpool technology. Users need to reset
the computer to change the conguration of this item. Conguration options: [Disabled] [Enabled]
2-8 ASUS P5KPL-AM IN/GB
CPU TM function [Enabled]
Enables or disables Intel® CPU Thermal Monitor (TM2) function, a CPU overheating
protection function. When this item is set to [Enabled], the CPU core frequency and voltage is reduced when the CPU overheats. Conguration options: [Enabled] [Disabled]
Execute Disable Bit [Enabled]
Allows you to Enable/disable Execute Disable Function. Conguration options: [Disabled] [Enabled]
Intel® SpeedStep® Technology [Enabled]
Allows you to use the Enhanced Intel® SpeedStep® Technology. When this item is set to [Enabled], you can adjust the system power settings in the operating system to use the EIST feature. Set this item to [Disabled] if you do not want to use the EIST.
Conguration options: [Enabled] [Disabled]

2.4.4 Chipset

The Chipset menu allows you to change the advanced chipset settings. Select an item then press <Enter> to display the sub-menu.
North Bridge Conguration
Memory Remap Feature [Enabled]
Allows you to enabled or disable the remapping of the overlapped PCI memory above the
total physical memory. Enable this option only when you install 64-bit operating system. Conguration options: [Disabled] [Enabled]
Congure DRAM Timing by SPD [Enabled]
Allows you to enable or disable congurating DRAM Timing by SPD. Conguration options: [Enabled] [Disabled]
Initiate Graphic Adapter [PCI/IGD]
Allows you to decide which graphics controller to use as the primary boot device.
Conguration options: [IGD] [PCI/IGD]
Internal Graphics Mode Select [Enabled, 8MB]
Allows you to select the amout of system memory used by the Interanal graphics device.
Conguration options: [Disabled] [Enabled, 1MB] [Enabled, 8MB] PEG Port Conguration
Video Function Conguration
DVMT Mode Select [DVMT Mode]
Allows you to select the DVMT Mode. Conguration options: [Fixed Mode] [DVMT Mode]
DVMT/FIXED Memory [256MB]
Allows you to select the amount of the DVMT/FIXED Memory. Conguration options: [128MB] [256MB] [Maximum DVMT]
Chapter 2: BIOS information 2-9
South Bridge Conguration
Audio Controller [Azalia]
Allows you to set the audio controller. Conguration options: [Azalia] [All Disabled]
Front Panel Support Type [HD Audio]
Allows you to select the front panel support type. Conguration options: [AC97] [HD Audio]
2.4.5 Onboard Devices Conguration
Onboard PCIE 1000M Lan [Enabled]
Allows you to enable or disable the onboard LAN controller. Conguration options: [Enabled] [Disabled]
LAN Option ROM [Disabled]
Allows you to enable or disable the boot ROM in the onboard LAN controller. This item appears only when the Onboard LAN item is set to [Enabled]. Conguration options:
[Disabled] [Enabled]

2.4.6 PCI PnP

The PCI PnP menu items allow you to change the advanced settings for PCI/PnP devices. The menu includes setting IRQ and DMA channel resources for either PCI/PnP or legacy ISA devices, and setting the memory size block for legacy ISA devices.
Take caution when changing the settings of the PCI PnP menu items. Incorrect eld values
can cause the system to malfunction.
Plug and Play O/S [No]
When this item is set to [No], BIOS congures all the devices in the system. When this item is set to [Yes] and if you install a Plug and Play operating system, the operating system
congures the Plug and Play devices not required for boot. Conguration options: [No] [Yes]
PCI Latency Timer [64]
Allows you to select the value in units of PCI clocks for the PCI device latency timer register.
Conguration options: [32] [64] [96] [128] [160] [192] [224] [248]
Allocate IRQ to PCI VGA [Yes]
When this item is set to [Yes], BIOS assigns an IRQ to PCI VGA card if the card requests for an IRQ. When this item is set to [No], BIOS does not assign an IRQ to the PCI VGA card
even if requested. Conguration options: [Yes] [No]
Palette Snooping [Disabled]
When this item is set to [Enabled], the pallete snooping feature informs the PCI devices that an ISA graphics device is installed in the system so that the latter can function correctly.
Conguration options: [Disabled] [Enabled]
2-10 ASUS P5KPL-AM IN/GB
IRQ-xx assigned to [PCI Device]
When set to [PCI Device], the specic IRQ is free for use of PCI/PnP devices. When set to [Reserved], the IRQ is reserved for legacy ISA devices. Conguration options: [PCI Device] [Reserved]

2.5 Power menu

The Power menu items allow you to change the settings for the Advanced Power Management (APM). Select an item then press <Enter> to display the conguration options.
Main Advanced Power Boot Tools Exit
Suspend Mode [Auto]

ACPI 2.0 Support [Disabled] ACPI APIC Support [Enabled]

APM Conguration
Hardware Monitor
2.5.1 Suspend Mode [Auto]
Allows you to select the Advanced Conguration and Power Interface (ACPI) state to be used for system suspend. Conguration options: [S1 (POS) Only] [S3 Only] [Auto]
[S1(POS) Only] - Enables the system to enter the ACPI S1 (Power on Suspend) sleep state. In S1 sleep state, the system appears suspended and stays in a low power mode. The system can be resumed at any time.
[S3 Only] - Enables the system to enter the ACPI S3 (Suspend to RAM) sleep state (default). In S3 sleep state, the system appears to be off and consumes less power than in the S1 state. When signaled by a wake-up device or event, the system resumes to its working state exactly where it was left off.
[Auto] - Detected by OS.
BIOS SETUP UTILITY
Select the ACPI state used for System Suspend.
2.5.2 ACPI 2.0 Support [Disabled]
Allows you to add more tables for Advanced Conguration and Power Interface (ACPI) 2.0 specications. Conguration options: [Disabled] [Enabled]
2.5.3 ACPI APIC Support [Enabled]
Allows you to enable or disable the Advanced Conguration and Power Interface (ACPI)
support in the Advanced Programmable Interrupt Controller (APIC). When this item is set to [Enabled], the ACPI APIC table pointer is included in the RSDT pointer list.
Conguration options: [Disabled] [Enabled]
Chapter 2: BIOS information 2-11
2.5.4 APM Conguration
Restore on AC Power Loss [Power Off]
When this item is set to [Power Off], the system goes into off state after an AC power loss. When this item is set to [Power On], the system goes on after an AC power loss. When this item is set to [Last State], the system goes into either off or on state, whatever the system
state was before the AC power loss. Conguration options: [Power Off] [Power On] [Last State]
Power On By RTC Alarm [Disabled]
Disable/Enable RTC to generate a wake event. Conguration options: [Disabled] [Enabled]
The computer cannot receive or transmit data until the computer and applications are fully
running. Thus, connection cannot be made on the rst try. Turning an external modem off and then back on while the computer is off causes an initialization string that turns the
system power on.
Power On By PCI Devices [Disabled]
Disable/Enable PME to generate a wake event. Conguration options: [Disabled] [Enabled]
Power On By PCIE Devices [Disabled]
Conguration options: [Disabled] [Enabled]
Power On By PS/2 Keyboard [Disabled]
Allows you to use specic keys on the keyboard to turn on the system. This feature requires an ATX power supply that provides at least 1A on the +5VSB lead. Conguration options: [Disabled] [Space Bar] [Ctrl-Esc] [Power Key]
Power On By PS/2 Mouse [Disabled]
When set to [Enabled], this parameter allows you to use the PS/2 mouse to turn on the
system. This feature requires an ATX power supply that provides at least 1A on the +5VSB
lead. Conguration options: [Disabled] [Enabled]

2.5.5 Hardware Monitor

CPU Temperature [xxxºC/xxxºF]
The onboard hardware monitor automatically detects and displays the CPU temperatures. Select Ignored if you do not wish to display the detected temperatures.
CPU Fan Speed (RPM) [xxxxRPM] or [N/A] or [Ignored]
The onboard hardware monitor automatically detects and displays the CPU fan speed in
rotations per minute (RPM). If the fan is not connected to the motherboard, the eld shows
N/A. Select [Ignored] if you do not want to display the detected speed.
CPU Q-Fan Function [Disabled]
Allows you to enable or disable the Q-Fan function. Conguration options: [Disabled] [Enabled]
VCORE Voltage, 3.3V Voltage, 5V Voltage, 12V Voltage
The onboard hardware monitor automatically detects the voltage output through the onboard voltage regulators.
2-12 ASUS P5KPL-AM IN/GB

2.6 Boot menu

The Boot menu items allow you to change the system boot options. Select an item then press <Enter> to display the submenu.
Main Advanced Power Boot Tools Exit
Boot Device Priority
Boot Settings Conguration
Security

2.6.1 Boot Device Priority

1st ~ xxth Boot Device
These items specify the boot device priority sequence from the available devices. The number of device items that appears on the screen depends on the number of devices
installed in the system. Conguration options: [Hard Drive] [Removable Dev.] [ATAPI CD-ROM] [Disabled]
2.6.2 Boot Settings Conguration
Quick Boot [Enabled]
Enabling this item allows the BIOS to skip some power on self tests (POST) while booting to decrease the time needed to boot the system. When this item is set to [Disabled], BIOS
performs all the POST items. Conguration options: [Disabled] [Enabled]
Full Screen Logo [Enabled]
This allows you to enable or disable the full screen logo display feature. Conguration options: [Disabled] [Enabled]
BIOS SETUP UTILITY
Species the Boot
Device Priority sequence.
A virtual oppy disk
drive (Floppy Drive B:) may appear when you set the CD-ROM drive as the
rst boot device.
Set this item to [Enabled] to use the ASUS MyLogo™ feature.
AddOn ROM Display Mode [Force BIOS]
Sets the display mode for option ROM. Conguration options: [Force BIOS] [Keep Current]
Bootup Num-Lock [On]
Allows you to select the power-on state for the NumLock. Conguration options: [Off] [On]
PS/2 Mouse Support [Auto]
Allows you to enable or disable support for PS/2 mouse. Conguration options: [Disabled] [Enabled] [Auto]
Chapter 2: BIOS information 2-13
Wait For ‘F1’ If Error [Enabled]
When set to Enabled, the system waits for the F1 key to be pressed when error occurs.
Conguration options: [Disabled] [Enabled]
Hit ‘DEL’ Message Display [Enabled]
When this item is set to [Enabled], the system displays the message Press DEL to run Setup during POST. Conguration options: [Disabled] [Enabled]

2.6.3 Security

The Security menu items allow you to change the system security settings. Select an item then press <Enter> to display the conguration options.
Change Supervisor Password
Select this item to set or change the supervisor password. The Supervisor Password item on top of the screen shows the default Not Installed. After you set a password, this item shows Installed.
To set a Supervisor Password:
1. Select the Change Supervisor Password item and press <Enter>.
2. From the password box, key in a password composed of up to six letters and/or
numbers, then press <Enter>.
3. Conrm the password when prompted.
The message Password Installed appears after you successfully set your password.
To change the supervisor password, follow the same steps in setting a supervisor password.
To clear the supervisor password, select the Change Supervisor Password then press <Enter> twice. The message Password uninstalled appears.
If you forget your BIOS password, you can clear it by erasing the CMOS Real Time Clock (RTC) RAM. See section 1.6 Jumpers for information on how to erase the RTC RAM.
After you have set a supervisor password, the other items appear to allow you to change other security settings.
User Access Level [Full Access]
This item allows you to select the access restriction to the Setup items.
Conguration options: [No Access] [View Only] [Limited] [Full Access]
[No Access] - prevents user access to the Setup utility. [View Only] - allows access but does not allow change to any eld. [Limited] - allows changes only to selected elds, such as Date and Time. [Full Access] - allows viewing and changing all the elds in the Setup utility.
2-14 ASUS P5KPL-AM IN/GB
Change User Password
Select this item to set or change the user password. The User Password item on top of the screen shows the default Not Installed. After you set a password, this item shows Installed.
To set a User Password:
1. Select the Change User Password item and press <Enter>.
2. From the password box, type a password composed of up to six letters and/or
numbers, then press <Enter>.
3. Conrm the password when prompted.
The message Password Installed appears after you set your password successfully. To change the user password, follow the same steps in setting a user password.
Clear User Password
Select this item to clear the user password.
Password Check [Setup]
When set to [Setup], BIOS checks for user password when accessing the Setup utility. When set to [Always], BIOS checks for user password both when accessing Setup and booting the
system. Conguration options: [Setup] [Always]

2.7 Tools menu

The Tools menu items allow you to congure options for special functions. Select an item
then press <Enter> to display the submenu.
Main Advanced Power Boot Tools Exit
ASUS EZ Flash 2
AI NET 2
BIOS SETUP UTILITY
Press ENTER to run the utility to select and update BIOS. This utility supports:
1.FAT 12/16/32 (r/w)
2.NTFS (read only)
3.CD-DISC (read only)

2.7.1 ASUS EZ Flash 2

Allows you to run ASUS EZ Flash 2. When you press <Enter>, a conrmation message appears. Use the left/right arrow key to select between [Yes] or [No], then press <Enter> to conrm your choice.

2.7.2 AI NET 2

Check Realtek LAN cable [Disabled]
Enables or disables checking of the Realtek LAN cable during the Power-On Self-Test
(POST). Conguration options: [Disabled] [Enabled]
Chapter 2: BIOS information 2-15
Exit system setup after saving the changes.
F10 key can be used for this operation.

2.8 Exit menu

The Exit menu items allow you to load the optimal or failsafe default values for the BIOS items, and save or discard your changes to the BIOS items.
Main Advanced Power Boot Tools Exit
Exit Options
Exit & Save Changes
Exit & Discard Changes Discard Changes
Load Setup Defaults
Pressing <Esc> does not immediately exit this menu. Select one of the options from this menu or <F10> from the legend bar to exit.
Exit & Save Changes
Once you are nished making your selections, choose this option from the Exit menu to
ensure the values you selected are saved to the CMOS RAM. An onboard backup battery sustains the CMOS RAM so it stays on even when the PC is turned off. When you select this
option, a conrmation window appears. Select OK to save changes and exit.
Exit & Discard Changes
Select this option only if you do not want to save the changes that you made to the Setup
program. If you made changes to elds other than System Date, System Time, and Password, the BIOS asks for a conrmation before exiting.
Discard Changes
This option allows you to discard the selections you made and restore the previously saved values. After selecting this option, a conrmation appears. Select OK to discard any changes and load the previously saved values.
Load Setup Defaults
This option allows you to load the default values for each of the parameters on the Setup menus. When you select this option or if you press <F5>, a conrmation window appears. Select OK to load default values. Select Exit & Save Changes or make other changes before saving the values to the non-volatile RAM.
BIOS SETUP UTILITY
2-16 ASUS P5KPL-AM IN/GB
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
