SCE81821FS
USER MANUAL
EN |
User Manual |
2 |
FR |
Fridge Freezer |
|
Notice d'utilisation |
20 |
|
DE |
Réfrigérateur/congélateur |
|
Benutzerinformation |
40 |
|
|
Kühl - Gefrierschrank |
|
2 www.aeg.com |
|
|
CONTENTS |
|
|
1. |
SAFETY INFORMATION............................................................................................. |
2 |
2. |
SAFETY INSTRUCTIONS............................................................................................. |
4 |
3. |
INSTALLATION............................................................................................................ |
6 |
4. |
OPERATION................................................................................................................. |
7 |
5. |
DAILY USE.................................................................................................................. |
10 |
6. |
HINTS AND TIPS........................................................................................................ |
12 |
7. |
CARE AND CLEANING............................................................................................. |
13 |
8. |
TROUBLESHOOTING............................................................................................... |
14 |
9. |
NOISES....................................................................................................................... |
17 |
10. TECHNICAL DATA.................................................................................................. |
18 |
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information: www.aeg.com/webselfservice
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following data available: Model, PNC, Serial Number.
The information can be found on the rating plate. Warning / Caution-Safety information
General information and tips Environmental information
Subject to change without notice.
Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damages that are the result of incorrect installation or
ENGLISH 3
usage. Always keep the instructions in a safe and accessible location for future reference.
•This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved.
•This appliance may be used by children between 3 and 8 years of age and persons with very extensive and complex disabilities, if they have been properly instructed.
•Children of less than 3 years of age should be kept away from the appliance unless continuously supervised.
•Do not let children play with the appliance.
•Children shall not carry out cleaning and user maintenance of the appliance without supervision.
•Keep all packaging away from children and dispose of it appropriately.
•This appliance is intended to be used in household and similar applications such as:
–Farm houses; staff kitchen areas in shops, offices and other working environments
–By clients in hotels, motels, bed and breakfast and other residential type environments
•WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.
•WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.
•WARNING: Do not damage the refrigerant circuit.
4www.aeg.com
•WARNING: Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.
•Do not use water spray and steam to clean the appliance.
•Clean the appliance with a moist soft cloth. Only use neutral detergents. Do not use abrasive products, abrasive cleaning pads, solvents or metal objects.
•Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.
•If the supply cord is damaged, it must be replaced by the manufacturer, its Authorised Service Centre or similarly qualified persons in order to avoid a hazard.
WARNING!
Only a qualified person must install this appliance.
•Remove all the packaging.
•Do not install or use a damaged appliance.
•Do not use the appliance before installing it in the built-in structure due to safety manner.
•Follow the installation instructions supplied with the appliance.
•Always take care when moving the appliance as it is heavy. Always use safety gloves and enclosed footwear.
•Make sure the air can circulate around the appliance.
•At first installation or after reversing the door wait at least 4 hours before connecting the appliance to the power supply. This is to allow the oil to flow back in the compressor.
•Before carrying out any operations on the appliance (e.g. reversing the door), remove the plug from the power socket.
•Do not install the appliance close to radiators or cookers, ovens or hobs.
•Do not expose the appliance to the rain.
•Do not install the appliance where there is direct sunlight.
•Do not install this appliance in areas that are too humid or too cold.
•When you move the appliance, lift it by the front edge to avoid scratching the floor.
•The appliance contains a bag of desiccant. This is not a toy. This is not food. Please dispose of it immediately.
WARNING!
Risk of fire and electric shock.
WARNING!
When positioning the appliance, ensure the supply cord is not trapped or damaged.
WARNING!
Do not use multi-plug adapters and extension cables.
•The appliance must be earthed.
•Make sure that the parameters on the rating plate are compatible with the
electrical ratings of the mains power supply.
•Always use a correctly installed shockproof socket.
•Make sure not to cause damage to the electrical components (e.g. mains plug, mains cable, compressor). Contact the Authorised Service Centre or an electrician to change the electrical components.
•The mains cable must stay below the level of the mains plug.
•Connect the mains plug to the mains socket only at the end of the installation. Make sure that there is access to the mains plug after the installation.
•Do not pull the mains cable to disconnect the appliance. Always pull the mains plug.
2.3 Use
WARNING!
Risk of injury, burns, electric shock or fire.
The appliance contains flammable gas, isobutane (R600a), a natural gas with a high level of environmental compatibility. Be careful not to cause damage to the refrigerant circuit containing isobutane.
•Do not change the specification of this appliance.
•Do not put electrical appliances (e.g. ice cream makers) in the appliance unless they are stated applicable by the manufacturer.
•If damage occurs to the refrigerant circuit, make sure that there are no flames and sources of ignition in the room. Ventilate the room.
•Do not let hot items to touch the plastic parts of the appliance.
•Do not put soft drinks in the freezer compartment. This will create pressure on the drink container.
•Do not store flammable gas and liquid in the appliance.
•Do not put flammable products or items that are wet with flammable products in, near or on the appliance.
ENGLISH 5
•Do not touch the compressor or the condenser. They are hot.
•Do not remove or touch items from the freezer compartment if your hands are wet or damp.
•Do not freeze again food that has been thawed.
•Follow the storage instructions on the packaging of frozen food.
•Wrap the food in any food contact material before putting it in the freezer compartment.
WARNING!
Risk of electric shock.
•The type of lamp used for this appliance is for household appliances only. Do not use it for house lighting.
WARNING!
Risk of injury or damage to the appliance.
•Before maintenance, deactivate the appliance and disconnect the mains plug from the mains socket.
•This appliance contains hydrocarbons in the cooling unit. Only a qualified person must do the maintenance and the recharging of the unit.
•Regularly examine the drain of the appliance and if necessary, clean it. If the drain is blocked, defrosted water collects in the bottom of the appliance.
•To repair the appliance contact the Authorised Service Centre.
•Use original spare parts only.
WARNING!
Risk of injury or suffocation.
•Disconnect the appliance from the mains supply.
•Cut off the mains cable and discard it.
6www.aeg.com
•Remove the door to prevent children and pets to be closed inside of the appliance.
•The refrigerant circuit and the insulation materials of this appliance are ozone-friendly.
•The insulation foam contains flammable gas. Contact your
WARNING!
Refer to Safety chapters.
Refer to the assembly instructions for the installation.
To ensure best performance, install the appliance well away from sources of heat such as radiators, boilers, direct sunlight etc. Make sure that air can circulate freely around the back of the cabinet.
municipal authority for information on how to discard the appliance correctly.
•Do not cause damage to the part of the cooling unit that is near the heat exchanger.
Some functional problems might occur for some types of models when operating outside of that range. The correct operation can only be guaranteed within the specified temperature range. If you have any doubts regarding where to install the appliance, please turn to the vendor, to our customer service or to the nearest Authorised Service Centre.
Install the appliance in a dry, well ventilated indoors where the ambient temperature corresponds to the climate class indicated on the rating plate of the appliance.
Climate |
Ambient temperature |
class |
|
|
|
SN |
+10°C to + 32°C |
|
|
N |
+16°C to + 32°C |
|
|
ST |
+16°C to + 38°C |
|
|
T |
+16°C to + 43°C |
|
|
•Before plugging in, ensure that the voltage and frequency shown on the rating plate correspond to your domestic power supply.
•The appliance must be earthed. The power supply cable plug is provided with a contact for this purpose. If the domestic power supply socket is not earthed, connect the appliance to a separate earth in compliance with current regulations, consulting a qualified electrician.
•The manufacturer declines all responsibility if the above safety precautions are not observed.
•This appliance complies with the E.E.C. Directives.
The airflow behind the appliance must be sufficient.
ENGLISH 7
5 CM |
MIN. |
|
CAUTION! |
|
200 |
CM2 |
Refer to the assembly |
|
|
||
|
|
|
instructions for the |
|
|
|
installation. |
|
|
|
MIN. |
|
|
|
200 CM2 |
1
8 |
|
7 |
|
6 |
|
5 |
|
4 |
|
3 |
|
2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
Display
Freezer Temperature warmer button Freezer Temperature colder button OK
Mode
Fridge Temperature warmer button
Fridge Temperature colder button
ON/OFF
It is possible to change predefined sound of buttons by pressing together Mode and temperature colder button for a few seconds. Change is reversible.
A B C D E F |
G |
A. Fridge compartment indicator |
||||||||||||||||||
B. |
Timer indicator |
|||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
OFF |
|
|
|
|
|
|
|
/Temperature indicator |
||||||||||
|
|
MIN |
|
|
|
|
|
|
C. ON/OFF indicator |
|||||||||||
|
|
|
|
|
|
|
|
|||||||||||||
|
|
|
|
|
|
|
|
D. Coolmatic function |
||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
L K J I |
|
H |
E. |
Holiday mode |
|||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
F. |
Frostmatic function |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
G. |
Temperature indicator |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
H. |
Freezer compartment indicator |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
I. |
Alarm indicator |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
J. |
ChildLock function |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
K. |
DrinksChill function |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
L. |
DYNAMICAIR function |
8www.aeg.com
1.Connect the mains plug to the power socket.
2.Press the appliance ON/OFF if the display is off. The temperature indicators show the set default temperature.
The alarm buzzer could operate after few seconds. To reset the alarm refer to "High temperature alarm".
To select a different set temperature refer to "Temperature regulation".
If "dEMo" appears on the display, refer to "Troubleshooting" .
1.Press the appliance ON/OFF for 5 seconds.
The display switches off.
2.Disconnect the mains plug from the power socket.
Set the temperature of the appliance by pressing the temperature regulators. Default set temperature:
•+5°C for the fridge
•-18°C for the freezer
The temperature indicators show the set temperature.
The set temperature will be reached within 24 hours. After a power failure the set temperature remains stored.
To switch on the fridge it is enough to press the fridge temperature regulator. To switch on the fridge in the other way:
1.Press Mode until the corresponding icon appears.
The Fridge OFF indicator flashes. 2. Press OK to confirm.
The fridge OFF indicator goes off.
To select a different set temperature refer to "Temperature regulation".
1.Press Mode until the corresponding icon appears.
The fridge OFF indicator and the fridge compartment indicator flash.
The fridge temperature indicator shows dashes.
2. Press OK to confirm.
The fridge OFF indicator is shown.
If you need to insert a large amount of warm food, for example after doing the grocery shopping, we suggest activating the Coolmatic function to chill the products more rapidly and to avoid warming the other food which is already in the refrigerator.
1.Press the Mode until the corresponding icon appears.
The Coolmatic indicator flashes. 2. Press the OK to confirm.
The Coolmatic indicator is shown. The Coolmatic function shuts off automatically after approximately 6 hours.
To switch off the function before its automatic end, repeat the procedure.
The function switches off by selecting a different fridge set temperature.
This mode allows you to keep the appliance closed and empty during a long holiday period without the formation of bad odours.
1.Press the Mode until the corresponding icon appears.
The Holiday indicator flashes. The temperature indicator shows the set temperature.
2. Press the OK to confirm. The Holiday indicator is shown.
This mode switches off after selecting a different temperature.
The Frostmatic function accelerates the freezing of fresh food and, at the same time, protects foodstuffs already stored from undesirable warming.
1.To activate this function press the Mode button until the corresponding icon appears.
The Frostmatic indicator flashes. 2. Press the OK button to confirm. The Frostmatic indicator is shown.
This function stops automatically after 52 hours.
To switch off the function before its automatic end repeat the procedure until the Frostmatic indicator turns off.
The function switches off by selecting a different set temperature.
Activate the ChildLock function to lock the buttons from unintentional operation.
1.Press Mode until the corresponding icon appears.
The ChildLock indicator flashes. 2. Press OK to confirm.
The ChildLock indicator is shown.
To deactivate the ChildLock function, repeat the procedure until the ChildLock indicator goes off.
The DrinksChill function is to be used to set an acoustic alarm at the preferred time, useful for example when a recipe requires to cool down food products for a certain period of time.
It is also useful when a reminder is needed in order not to forget the bottles placed in the freezer for fast cooling.
1.Press Mode until the corresponding icon appears.
The DrinksChill indicator flashes. The Timer shows the set value (30 minutes) for a few seconds.
2.Press the Timer regulator to change the Timer set value from 1 to 90 minutes.
ENGLISH 9
3. Press OK to confirm. TheDrinksChill indicator is shown. The Timer start to flash (min).
At the end of the countdown the DrinksChill indicator flashes and an audible alarm sounds. Press OK to switch off the sound and terminate the function.
To switch off the function repeat the procedure until the DrinksChill goes off.
It is possible to change the time at any time during the countdown and at the end by pressing the Temperature colder button and the Temperature warmer button.
An increase in the temperature in the freezer compartment (for example due to an earlier power failure) is indicated by flashing the alarm icon and freezer temperature indicators, and sounding of buzzer.
Press any button.
The buzzer switches off.
The freezer temperature indicator shows the highest temperature reached for a few seconds, then displays the set temperature again.
The alarm indicator continues to flash until the normal conditions are restored.
If the door is left open for approximately 90 seconds, the acoustic alarm starts and alarm indicator flashes.
The alarm stops after closing the door. During the alarm, the acoustic signal can be muted by pressing any button.
To switch on the function:
1.Press the Mode button until the corresponding icon appears.
The DYNAMICAIR indicator flashes.
2.Press the OK button to confirm.
The DYNAMICAIR indicator is shown.
10 www.aeg.com
To switch off the function repeat the procedure until the DYNAMICAIR indicator icon goes off.
WARNING!
Refer to Safety chapters.
Before using the appliance for the first time, the interior and all internal accessories should be washed with lukewarm water and some neutral soap to remove the typical smell of a brandnew product, then dried thoroughly.
CAUTION!
Do not use detergents, abrasive powders, chlorine or oil-based cleaners as they will damage the finish.
To permit storage of food packages of various sizes, the door shelves can be placed at different heights.
1.Gradually pull the shelf up until it comes free.
2.Reposition as required.
If the function is activated automatically the DYNAMICAIR indicator is not shown (refer to "Daily use").
The activation of the DYNAMICAIR function increase the energy consumption.
This model is equipped with a variable storage box which can be moved sideways.
The walls of the refrigerator are equipped with a series of runners so that the shelves can be positioned as desired.
1
2
Do not move the glass shelf above the vegetable drawer to ensure correct air circulation.
The refrigerator compartment is equipped with a device that allows rapid cooling of food and keeps a more uniform temperature in the compartment.
This device activates automatically when needed, for example for a quick temperature recovery after door opening or when the ambient temperature is high.
It is possible to switch on the device manually when needed (refer to "DYNAMICAIR function").
The DYNAMICAIR device stops when the door is open and restarts immediately after the door closing.
ENGLISH 11
The freezer compartment is suitable for freezing fresh food and storing frozen and deep-frozen food for a long time.
When first starting-up or after a period out of use, before putting the products in the compartment let the appliance run at least 2 hours with the Frostmatic function turned on.
To freeze fresh food place it in the middle compartment.
The maximum amount of food that can be frozen in 24 hours is specified on the rating plate, a label located on the inside of the appliance.
The freezing process lasts 24 hours, during this period do not add other food to be frozen.
In the event of accidental defrosting, for example due to a power failure, if the power has been off for longer than the value shown in the technical characteristics chart under "rising time", the defrosted food must be consumed quickly or cooked immediately and then refrozen (after cooling).
Deep-frozen or frozen food, prior to being used, can be thawed in the refrigerator compartment or at room temperature, depending on the time available for this operation.
Small pieces may even be cooked still frozen, directly from the freezer: in this case, cooking will take longer.
This appliance is equipped with one or more trays for the production of icecubes.
12 www.aeg.com
Do not use metallic instruments to remove the trays from the freezer.
1.Fill these trays with water
2.Put the ice trays in the freezer compartment.
The following sounds are normal during operation:
•A faint gurgling and bubbling sound from coils sound when refrigerant is pumped.
•A whirring and pulsating sound from the compressor when refrigerant is pumped.
•A sudden cracking noise from inside appliance caused by thermic dilatation (a natural and not dangerous physical phenomenon).
•A faint click noise from the temperature regulator when the compressor switches on or off.
•Do not open the door frequently or leave it open longer than absolutely necessary.
•Do not store warm food or evaporating liquids in the refrigerator.
•Cover or wrap the food, particularly if it has a strong flavour.
•Position food so that air can circulate freely around it.
Useful hints:
•Meat (all types): wrap in a suitable packaging and place it on the glass shelf above the vegetable drawer. Store meat for at most 1-2 days.
•Cooked foods, cold dishes: cover and place on any shelf.
•Fruit and vegetables: clean thoroughly and place in a special drawer. Bananas, potatoes, onions and garlic must not be kept in the refrigerator if not packed.
•Butter and cheese: place in a special airtight container or wrap in an aluminium foil or a polythene bag to exclude as much air as possible.
•Bottles: close with a cap and place on the door bottle shelf, or (if available) on the bottle rack.
•Freeze only top quality, fresh and thoroughly cleaned food products.
•For more efficient freezing and thawing divide food into small portions.
•Wrap the food in aluminium foil or polythene. Make sure that the packages are airtight.
•To avoid increase in temperature of already frozen food, do not place fresh unfrozen food directly next to it.
•Lean foods store better and longer than fatty ones. Salt reduces the storage life of food.
•Do not eat ice cubes, water ices or ice lollies immediately after taking them out of the freezer. Risk of frostbites.
•It is advisable to show the freezing date on each individual pack to enable you to keep tab of the storage time.
•Make sure that the commercially frozen food products were adequately stored by the retailer.
•Make sure that frozen foodstuffs are transferred from the food store to the freezer in the shortest possible time.
•Once defrosted, food deteriorates rapidly and cannot be refrozen.
•Do not exceed the storage period indicated by the food manufacturer.
WARNING!
Refer to Safety chapters.
CAUTION!
Unplug the appliance before carrying out any maintenance operation.
This appliance contains hydrocarbons in its cooling unit; maintenance and recharging must therefore only be carried out by authorized technicians.
The accessories and parts of the appliance are not suitable for washing in a dishwasher.
CAUTION!
Do not pull, move or damage any pipes and/or cables inside the appliance.
CAUTION!
Do not damage the cooling system.
The equipment has to be cleaned regularly:
1.Clean the inside and accessories with lukewarm water and some neutral soap.
2.Regularly check the door seals and wipe them clean to ensure they are clean and free from debris.
3.Rinse and dry thoroughly.
4.If accessible, clean the condenser and the compressor at the back of the appliance with a brush.
This will improve the performance of the appliance and save electricity consumption.
ENGLISH 13
Frost is automatically eliminated from the evaporator of the refrigerator compartment every time the motor compressor stops, during normal use. The defrost water drains out through a trough into a special container at the back of the appliance, over the motor compressor, where it evaporates.
It is important to periodically clean the defrost water drain hole in the middle of the refrigerator compartment channel to prevent the water overflowing and dripping onto the food inside.
CAUTION!
Never use sharp metal tools to scrape off frost from the evaporator as you could damage it. Do not use a mechanical device or any artificial means to speed up the thawing process other than those recommended by the manufacturer. A temperature rise of the frozen food packs, during defrosting, may shorten their safe storage life.
About 12 hours prior to defrosting, set a lower temperature, in order to build up sufficient chill reserve for the interruption in operation.
14 www.aeg.com
A certain amount of frost will always form on the freezer shelves and around the top compartment.
Defrost the freezer when the frost layer reaches a thickness of about 3-5 mm.
1.Switch off the appliance, or pull out electrical plug from the wall socket.
2.Remove any stored food, wrap it in several layers of newspaper and put it in a cool place.
WARNING!
Do not touch frozen goods with wet hands. Hands can freeze to the goods.
3.Leave the door open.
In order to speed up the defrosting process, place a pot of warm water in the freezer compartment. In addition, remove pieces of ice that break away before defrosting is complete.
4.When defrosting is completed, dry the interior thoroughly.
5.Switch on the appliance.
After three hours reload the previously removed food into the freezer compartment.
When the appliance is not in use for long periods, take the following precautions:
1.Disconnect the appliance from electricity supply.
2.Remove all food.
3.Defrost the appliance (if necessary).
4.Clean the appliance and all accessories.
5.Leave the door/doors open to prevent unpleasant smells.
CAUTION!
If you want to keep the appliance switched on, ask somebody to check it once in a while to prevent the food inside from spoiling in case of a power failure. We recommend activating Holiday Mode.
WARNING!
Refer to Safety chapters.
Problem |
Possible cause |
Solution |
|
|
|
The appliance does not op- |
The appliance is switched |
Switch on the appliance. |
erate. |
off. |
|
|
|
|
|
The mains plug is not con- |
Connect the mains plug to the |
|
nected to the mains socket |
mains socket correctly. |
|
correctly. |
|
There is no voltage in the mains socket.
Connect a different electrical appliance to the mains socket. Contact a qualified electrician.
Audible or visual alarm is on. The cabinet has been re- |
Refer to "High temperature |
cently switched on or the |
alarm". |
temperature is too high. |
|
|
|
|
|
|
|
ENGLISH 15 |
|
|
|
|
|
||
Problem |
|
Possible cause |
Solution |
||
|
|
|
|
|
|
|
|
|
The temperature in the ap- |
Contact a qualified electrician |
|
|
|
|
pliance is too high. |
or contact the nearest Author- |
|
|
|
|
|
ised Service Centre. |
|
|
|
|
|
|
|
|
|
|
The door is left open. |
Close the door. Refer to "Door |
|
|
|
|
|
open alarm" |
|
|
|
|
|
|
|
A |
or |
symbol is shown |
Temperature sensor prob- |
Contact the nearest Author- |
|
lem. |
ised Service Centre (the cool- |
||||
instead of numbers on the |
|||||
|
ing system will continue to |
||||
Temperature Display. |
|
||||
|
keep food products cold, but |
||||
|
|
|
|
||
|
|
|
|
temperature adjustment will |
|
|
|
|
|
not be possible). |
|
|
|
|
|||
The lamp does not work. |
The lamp is in stand-by. |
Close and open the door. |
|||
|
|
|
|
|
|
|
|
|
The lamp is defective. |
Contact the nearest Author- |
|
|
|
|
|
ised Service Centre. |
|
|
|
|
|||
The compressor operates |
Temperature is set incor- |
Refer to "Operation". |
|||
continually. |
|
rectly. |
|
||
|
|
|
|
|
|
|
|
|
Many food products were |
Wait few hours and then check |
|
|
|
|
put in at the same time. |
the temperature again. |
|
|
|
|
|
|
|
|
|
|
The room temperature is |
Refer to climate class chart on |
|
|
|
|
too high. |
the rating plate. |
|
|
|
|
|
|
|
|
|
|
Food products placed in |
Allow food products to cool to |
|
|
|
|
the appliance were too |
room temperature before stor- |
|
|
|
|
warm. |
ing. |
|
|
|
|
|
|
|
|
|
|
The door is not closed cor- |
Refer to "Closing the door". |
|
|
|
|
rectly. |
|
|
|
|
|
|
|
|
|
|
|
The "Frostmatic function" |
Refer to "Frostmatic function" |
|
|
|
|
or "Coolmatic function" is |
or "Coolmatic function". |
|
|
|
|
switched on. |
|
|
|
|
|
|||
There is too much frost and |
The door is not closed cor- |
Refer to "Closing the door". |
|||
ice. |
|
|
rectly or the gasket is de- |
|
|
|
|
|
formed/dirty. |
|
|
|
|
|
|
|
|
|
|
|
Temperature is set incor- |
Refer to "Operation" . |
|
|
|
|
rectly. |
|
The compressor does not start immediately after pressing the "Frostmatic" or "Coolmatic", or after changing the temperature.
This is normal, no error has occurred.
The compressor starts after a period of time.
16 www.aeg.com
Problem |
Possible cause |
Solution |
|
|
|
Water flows inside the refrig- |
Food products prevent the |
Make sure that food products |
erator. |
water to flow into the wa- |
do not touch the rear plate. |
|
ter collector. |
|
|
|
|
|
The water outlet is clog- |
Clean the water outlet. |
|
ged. |
|
Water flows on the floor.
The melting water outlet is not connected to the evaporative tray above the compressor.
Attach the melting water outlet to the evaporative tray.
Temperature cannot be set. The "Frostmatic function" or "Coolmatic function" is switched on.
Switch off "Frostmatic function" or "Coolmatic function" manually, or wait until the function resets automatically to set the temperature. Refer to "Frostmatic function" or "Coolmatic function".
dEMo appears on the display.
The appliance is in demonstration mode.
Keep the OK pressed for approximately 10 seconds until a long sound is heard and display shuts off for a short time.
The temperature in the ap- |
The temperature regulator |
Set a higher/lower tempera- |
pliance is too low/too high. |
is not set correctly. |
ture. |
|
|
|
|
The door is not closed cor- |
Refer to "Closing the door". |
|
rectly. |
|
|
|
|
|
The food products' tem- |
Let the food products temper- |
|
perature is too high. |
ature decrease to room tem- |
|
|
perature before storage. |
|
|
|
|
Many food products are |
Add less food products at the |
|
stored at the same time. |
same time. |
|
|
|
|
The thickness of the frost is |
Defrost the appliance. |
|
greater than 4-5 mm. |
|
|
|
|
|
The door has been |
Open the door only if necessa- |
|
opened often. |
ry. |
|
|
|
|
The "Frostmatic function" |
Refer to "Frostmatic function" |
|
or "Coolmatic function" is |
or "Coolmatic function". |
|
switched on. |
|
There is no cold air circulation in the appliance.
Make sure that there is cold air circulation in the appliance.
ENGLISH 17
If the advice does not lead to the desired result, contact the nearest Authorised Service Centre.
The appliance is equipped with a longlife LED interior light.
Only service is allowed to replace the lighting device. Contact your Authorised Service Centre.
1.Clean the door gaskets.
2.If necessary, adjust the door. Refer to assembly instructions.
3.If necessary, replace the defective door gaskets. Contact the Authorised Service Centre.
There are some sounds during normal running (compressor, refrigerant circulation).
OK
SSSRRR!
HISSS! BLUBB!
CLICK! BRRR!
CRACK!
SSSRRR! SSSRRR!
CLICK! |
CLICK! |
18 www.aeg.com
HISSS! HISSS!
BRRR! |
BRRR! |
BLUBB! |
BLUBB! |
CRACK! |
CRACK! |
Trade Mark |
AEG |
|
|
Model |
SCE81821FS 925500019 |
|
|
Category |
7. Refrigerator-freezer |
|
|
Energy efficiency class |
A++ |
|
|
Energy consumption in kWh per year, based on |
227 |
standard test results for 24 hours. The actual energy |
|
consumption will depend on how the appliance is |
|
used and where it is located |
|
|
|
Storage volume in litres, Fridge |
192 |
|
|
Storage volume in litres, Star |
- |
|
|
Storage volume in litres, Cellar zone |
- |
|
|
Storage volume in litres, Wine |
- |
|
|
Storage volume in litres, Total |
264 |
|
|
Storage volume in litres, Freezer |
72 |
|
|
