AEG L7FEE965R User Manual

L7FEE965R

USER MANUAL

EN User Manual

Washing Machine

2www.aeg.com

CONTENTS

1.	SAFETY INFORMATION.............................................................................................		3
2.	SAFETY INSTRUCTIONS.............................................................................................		4
3.	PRODUCT DESCRIPTION...........................................................................................		6
4.	TECHNICAL DATA......................................................................................................		7
5.	INSTALLATION............................................................................................................		8
6.	ACCESSORIES...........................................................................................................		13
7.	CONTROL PANEL.....................................................................................................		14
8.	DIAL AND BUTTONS................................................................................................		16
9.	PROGRAMMES..........................................................................................................		18
10.		SETTINGS................................................................................................................	23
11.		BEFORE FIRST USE.................................................................................................	24
12.		DAILY USE................................................................................................................	24
13.		HINTS AND TIPS.....................................................................................................	30
14.		CARE AND CLEANING..........................................................................................	31
15.		TROUBLESHOOTING.............................................................................................	37
16.		CONSUMPTION VALUES.......................................................................................	40
17. QUICK GUIDE.........................................................................................................			42

FOR PERFECT RESULTS

Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.

Visit our website to:

Get usage advice, brochures, trouble shooter, service and repair information: www.aeg.com/support

Register your product for better service:

www.registeraeg.com

Buy Accessories, Consumables and Original spare parts for your appliance:

www.aeg.com/shop

CUSTOMER CARE AND SERVICE

Always use original spare parts.

When contacting our Authorised Service Centre, ensure that you have the following data available: Model, PNC, Serial Number.

The information can be found on the rating plate.

Warning / Caution-Safety information

General information and tips Environmental information

Subject to change without notice.

ENGLISH 3

1. SAFETY INFORMATION

Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damages that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.

1.1 Children and vulnerable people safety

•This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved.

•Children between 3 and 8 years of age and persons with very extensive and complex disabilities shall be kept away from the appliance unless continuously supervised.

•Children of less than 3 years of age should be kept away from the appliance unless continuously supervised.

•Do not let children play with the appliance.

•Keep all packaging away from children and dispose of it appropriately.

•Keep detergents away from children.

•Keep children and pets away from the appliance when the door is open.

•If the appliance has a child safety device, it should be activated.

•Children shall not carry out cleaning and user maintenance of the appliance without supervision.

1.2General Safety

•Do not change the specification of this appliance.

•This appliance is intended to be used in household and similar applications such as:

4www.aeg.com

–staff kitchen areas in shops, offices and other working environments;

–by clients in hotels, motels, bed & breakfast and other residential type environments;

–areas for communal use in blocks of flats or in launderettes.

•Do not exceed the maximum load of 9 kg (refer to the "Programme chart" chapter).

•The operating water pressure at the water entry point from the outlet connection must be between 0.5 bar (0.05 MPa) and 8 bar (0.8 MPa).

•The ventilation opening in the base must not be covered by a carpet, mat, or any floor covering.

•The appliance must be connected to the water mains using the new supplied hose sets, or other new hose sets supplied by the Authorised Service Centre.

•Old hose sets must not be reused.

•If the mains power supply cable is damaged, it must be replaced by the manufacturer, its Authorised Service Centre or similarly qualified persons to avoid an electrical hazard.

•Before any maintenance operation, deactivate the appliance and disconnect the mains plug from the socket.

•Do not use high pressure water sprays and/or steam to clean the appliance.

•Clean the appliance with a moist cloth. Use only neutral detergents. Do not use abrasive products, abrasive cleaning pads, solvents or metal objects.

2. SAFETY INSTRUCTIONS

2.1 Installation

The installation must comply with relevant national regulations.

•Remove all the packaging and the transit bolts including rubber bush with plastic spacer.

•Keep the transit bolts in a safe place. If the appliance is to be moved in the future they must be reattached to lock the drum to prevent an internal damage.

•Always take care when moving the appliance as it is heavy. Always use safety gloves and enclosed footwear.

•Follow the installation instructions supplied with the appliance.

•Do not install or use a damaged appliance.

•Do not install or use the appliance where the temperature can be less than 0°C or where it is exposed to the weather.

•The floor area on which the appliance is to be installed must be flat, stable, heat resistant and clean.

•Make sure that there is air circulation between the appliance and the floor.

•When the appliance is in its permanent position, check if it is levelled correctly with the aid of a spirit level. If it is not, adjust the feet accordingly.

•Do not install the appliance directly above a floor drain.

•Do not spray water on the appliance and do not expose it to excessive humidity.

•Do not install the appliance where the appliance door cannot be fully opened.

•Do not put a closed container to collect possible water leakage under the appliance. Contact the Authorised Service Centre to ensure which accessories can be used.

2.2 Electrical connection

WARNING!

Risk of fire and electric shock.

•The appliance must be earthed.

•Always use a correctly installed shockproof socket.

•Make sure that the parameters on the rating plate are compatible with the electrical ratings of the mains power supply.

•Do not use multi-plug adapters and extension cables.

•Make sure not to cause damage to the mains plug and to the mains cable. Should the mains cable need to be replaced, this must be carried out by our Authorised Service Centre.

•Connect the mains plug to the mains socket only at the end of the installation. Make sure that there is access to the mains plug after the installation.

ENGLISH 5

•Do not touch the mains cable or the mains plug with wet hands.

•Do not pull the mains cable to disconnect the appliance. Always pull the mains plug.

•This appliance is fitted with a 13 A mains plug. If it is necessary to change the mains plug fuse, use only a 13 A ASTA (BS 1362) fuse (UK and Ireland only).

2.3Water connection

•Do not cause damage to the water hoses.

•Before connection to new pipes, pipes not used for a long time, where repair work has been carried out or new devices fitted (water meters, etc.), let the water flow until it is clean and clear.

•Ensure that there are no visible water leaks during and after the first use of the appliance.

•Do not use an extension hose if the inlet hose is too short. Contact the Authorised Service Centre for the replacement of the inlet hose.

•When unpacking the appliance, It is possible to see water flowing from the drain hose. This is due to the testing of the appliance with the use of water in the factory.

•You can extend the drain hose to maximum 400 cm. Contact the Authorised Service Centre for the other drain hose and the extension.

•Make sure that there is access to the tap after the installation.

2.4Use

WARNING!

Risk of injury, electric shock, fire, burns or damage to the appliance.

•Follow the safety instructions on the detergent packaging.

•Do not put flammable products or items that are wet with flammable products in, near or on the appliance.

•Do not wash fabrics which are heavily soiled with oil, grease or other greasy substances. It can damage rubber parts of the washing machine. Prewash such fabrics by hand before

6www.aeg.com

loading them into the washing machine.

•Do not touch the glass door while a programme operates. The glass can get hot.

•Make sure that all metal objects are removed from the laundry.

2.5 Service

•To repair the appliance contact the Authorised Service Centre. Use original spare parts only.

•Please note that self-repair or nonprofessional repair can have safety consequences and might void the guarantee.

•The following spare parts will be available for 10 years after the model has been discontinued: motor and motor brushes, transmission between motor and drum, pumps, shock absorbers and springs, washing drum, drum spider and related ball bearings, heaters and heating elements, including heat pumps, piping and related equipment including hoses, valves, filters and aquastops, printed circuit boards, electronic displays,

pressure switches, thermostats and sensors, software and firmware including reset software, door, door hinge and seals, other seals, door locking assembly, plastic peripherals such as detergent dispensers. Please note that some of these spare parts are only available to professional repairers, and that not all spare parts are relevant for all models.

2.6 Disposal

WARNING!

Risk of injury or suffocation.

•Disconnect the appliance from the mains electrical and water supplies.

•Cut off the mains electrical cable close to the appliance and dispose of it.

•Remove the door catch to prevent children or pets from becoming trapped in the drum.

•Dispose of the appliance in accordance with local requirements for the disposal of Waste Electrical and Electronic Equipment (WEEE).

3. PRODUCT DESCRIPTION

3.1 Special features

Your new washing machine meets all modern requirements for an effective treatment of laundry with low water, energy and detergent consumption and proper care of fabric.

•The ProSense technology detects the laundry load size defining the programme duration in 30 seconds. The washing programme is tailored to the laundry load and the type of fabric without consuming more time, energy and water than necessary.

•The steam has a quick and easy way to refresh the clothes. The gentle

steam programmes remove odours and reduce creases in dry fabrics so they need little ironing.

The Plus Steam option, finishes every cycle with gentle steam that relaxes the fibres and reduces fabric creasing. Ironing will be easier!

•Thanks to the Soft Plus option, the fabric softener is uniformly spread out in the laundry and deeply penetrates the fabric fibres favouring a perfect softness.

ENGLISH

7

3.2 Appliance overview

1	2	3	8	9
				10
			4
			5
				11 12
			6
			7
Worktop			Drain hose
Detergent dispenser			Inlet hose connection
Control panel			Mains cable
Door handle			Transit bolts
Rating plate			Hose support
Drain pump filter
Feet for levelling the appliance

A B

C D

MOD. XXXXXXXXX

PROD.NO. 910000000 00

000V ~ 00HZ 0000 W

00A

00000000

The rating plate reports the model name (A), product number (B), electrical ratings (C) and serial number (D).

4. TECHNICAL DATA

Dimension	Width/ Height/ Total depth	59.7 cm /84.7 cm /66.0 cm
Electrical connection	Voltage	230-240 V
	Overall power	2200 W
	Fuse	13 A
	Frequency	50 Hz

8 www.aeg.com

Level of protection against ingress of solid particles and		IPX4
moisture ensured by the protective cover, except where
the low voltage equipment has no protection against
moisture
Water supply pressure	Minimum	0.5 bar (0.05 MPa)
1)	Maximum	8 bar (0.8 MPa)
Water supply 2)		Cold water
Maximum Load	Cotton	9 kg
Spin Speed	Maximum spin speed	1551 rpm

1)The appliance works correctly if the water pressure is not lower than 0.05 MPa (0.5 bar). If you cannot connect the water inlet hose to the cold water tap of the primary hydraulic system, connect it to your domestic cold water storage system. Make sure not to exceed a distance of 5.02 m (16.5 ft) between the appliance inlet hose and the bottom of the water storage tank.

2)Connect the water inlet hose to a water tap with a 3/4'' thread.

5.INSTALLATION

WARNING!

Refer to Safety chapters.

5.1 Unpacking

WARNING!

Remove all the packaging and the transit bolts before installing the appliance.

WARNING!

Use the gloves.

1.Remove the external film. If necessary, use a cutter.

2.Remove the cardboard top and the polystyrene packaging materials.

3. Remove the internal film.

4.Open the door and remove the polystyrene piece from the door seal and all the items from the drum.

ENGLISH 9

5.Carefully put the appliance down on its rear side.

6.Put the front polystyrene packaging element on the floor under the appliance.

Make sure not to damage the hoses.

7.Remove the polystyrene protection from the bottom.

1

8.Pull up the appliance in vertical position.

9.Remove the power supply cable and the drain hose from the hose holders.

It is possible to see water flowing from the drain hose. This is due to the testing with water of the appliance in factory.

10.Remove the three bolts by using the spanner supplied with the appliance.

11.Pull out the plastic spacers.

12.Put the plastic caps, that you find in the user manual bag, in the holes.

10 www.aeg.com

We recommend that you keep the packaging and the transit bolts for any movement of the appliance.

5.2 Installation on suspended flooring

Suspended wooden floors are particularly susceptible to vibration.

To limit vibration we recommend placing a waterproof wooden panel, at least 15 mm thick, under the appliance. It should be screwed to at least 2 floor beams and should extend beyond the front feet.

If possible, install the appliance where the floor is more stable.

5.3Positioning and levelling

1.Install the appliance on a flat hard floor.

Make sure that carpets do not stop the air circulation below the appliance.

Make sure that the appliance does not touch the wall or other units.

2.Loosen or tighten the feet to adjust the level.

WARNING!

Do not put cardboard, wood or equivalent materials below the appliance feet to adjust the level.

X4

The appliance must be level and stable.

A correct adjustment of the appliance level prevents the vibration, noise and the movement of the appliance when in operation.

When a tumble dryer is stacked on the washing machine, use the accessory described in chapter 'Accessories'. Read carefully the instructions supplied with the appliance and with the accessory.

5.4 The inlet hose

1.Connect the water inlet hose to the back of the appliance.

2.Position it toward left or right depending on the position of the water tap.

45º

20º

Make sure that the inlet hose is not in vertical position.

3.If necessary, loose the ring nut to set it in the correct position.

4.Connect the water inlet hose to the cold water tap with 3/4" thread.

CAUTION!

Make sure that there are no leaks from the couplings.

Do not use an extension hose if the inlet hose is too short. Contact the service centre for the replacement of the inlet hose.

5.5 Water drainage

ENGLISH 11

You can extend the drain hose to maximum 400 cm. Contact the authorized service centre for the other drain hose and the extension.

It is possible to connect the drain hose in different ways:

1.Make a U shape with the drain hose and put it around the plastic hose guide.

2.On the edge of a sink - Fasten the guide to the water tap or to the wall.

Make sure that the plastic guide cannot move when the appliance drains.

Make sure that the drain hose end is not immersed in the water. There may be a return of dirty water into the appliance.

The drain hose should be positioned at a height of not less than 60 cm and not more than 100 cm from the floor.

3.To a stand pipe with vent-hole - Insert the drain hose directly into a drain pipe. Refer to the illustration.

12 www.aeg.com

The end of the drain hose must always be ventilated , i.e. the inner diameter of the drain pipe (min. 38 mm - min. 1.5") must be larger than the external diameter of the drain hose.

4.If the end of the drain hose looks like this (see the picture), you can push it directly into the stand pipe.

5.Without the plastic hose guide, to a sink spigot - Put the drain hose in the spigot and tighten it with a clamp. Refer to the illustration.

Make sure that the drain hose makes a loop to prevent particles going into the appliance from the sink.

6.Position the hose directly to a builtin drain pipe in the room wall and tighten it with a clamp.

5.6 Electrical connection

At the end of installation you can connect the mains plug to the mains socket.

The rating plate on the inner edge of the appliance door and the 'Technical Data' chapter indicate the necessary electrical ratings. Make sure that they are compatible with the mains power supply.

Check that your domestic electrical installation can take the maximum load required, also taking into account any other appliances in use.

Connect the appliance to an earthed socket.

The power supply cable must be easily accessible after installing the appliance.

For any electrical work required to install this appliance, contact our Authorised Service Centre.

The manufacturer does not accept any responsibility for damage or injury through failure to comply with the above safety precaution.

6. ACCESSORIES

6.1 Available in www.aeg.com/shop or from authorised dealer

Read carefully the instructions supplied with the accessory.

Only appropriate accessories approved by AEG ensure the safety standards of the appliance. If unapproved parts are used, any claims will be invalidated.

6.2 Stacking kit

The tumble dryer can be stacked on the top of the washing machine only by using the correct stacking kit manufactured and approved by AEG.

Verify the compatible stacking kit by checking the depth of your appliances.

ENGLISH 13

The stacking kit can be used only with the appliances specified in the leaflet provided with the accessory.

Read carefully the instructions supplied with the appliance and with the accessory.

WARNING!

Do not put the tumble dryer under the washing machine.

6.3 Pedestal with the drawer

To raise your appliance and make loading and unloading laundry easier.

The drawer can be used for laundry storage e.g.: towels, cleaning products and more.

Read carefully the instructions supplied with the accessory.

14www.aeg.com

7.CONTROL PANEL

7.1Control panel description

1		2		3

Programme

Eco 40-60 Cottons Synthetics Delicates Wool / Silk Steam 20 min. - 3kg Outdoor Duvet Sports

On/O

	Drain only
	Spin only
Temp.	Spin
Soft Plus

Stains

Prewash

Stains/

Prewash

Delay Start

Time Save

Extra rinse Rinse only

Rinse

Plus Steam Anti-Allergy	Start/Pause

4

5

12		11		10		9		8		7		6

Programme dial Display

Delay start touch button (Delay Start)

Time saving touch button (Time Save)

Rinse touch button (Rinse)

•Extra rinse option (Extra Rinse)

•Skipping wash phase - Only Rinse option (Only Rinse)

Start/Pause touch button (Start/ Pause)

Stain/Prewash touch button (Stains/ Prewash)

•Stain option (Stains)

•Prewash option (Prewash)

Anti-Allergy touch button (AntiAllergy)

Steam Plus touch button (Plus Steam)

Spin reduction touch button (Spin)

•Rinse Hold option

•Quiet option

•Skipping wash and rinse phases - Only Spin option (Spin only)

•Skipping wash, rinse and spin phases - Only Drain option (Drain

only)

Temperature touch button (Temp.)

On/Off push button (On/Off)

ENGLISH 15

7.2 Display

MIX

Maximum load indicator. The indicator flashes during the laundry load estimation (refer to ProSense load detection paragraph) .

Maximum laundry indicator. It blinks if the laundry amount exceeds the declared load.

Door locked indicator.

Delay start indicator.

The digital indicator can show:

•Programme duration (e. g. ).

•Delay time (e. g. or ).

•Cycle end ().

•Warning code (e.g. ).

Washing phase indicator. It flashes during pre-wash and wash phase.

Rinsing phase indicator. It flashes during rinse phase.

When the Soft Plus option is activated, the indicator appears.

Spinning and draining phase indicator. It flashes during spin and drain phase.

Steam phase indicator.

Anti-crease phase indicator.

Child safety lock indicator.

Time saving indicator.

Spin speed indicator.
