User Manual
CONTENTS
1. Introduction
2. Unpacking
3. Connectors/Cabling
4. Polarity Checking
5. Amplification & Power Handling
6. Crossovers
7. Equalisation
8. Arraying
9. Dimensions
10. Performance Data
11. Technical Specifications
12. Rigging & Suspension
12.1 General Safety Advice
12.2 Secur – ET VMY Yoke bracket
12.3 Secur – ET VMB Wall mounting Bracket
12.4 Secur – ET VEB Eyebolts
12.5 Secur – ET VTH Pole mount
12.6 Secur – ET VCS Ceiling Saddle
12.7 Secur – ET VPC Pole Clamp
13. System Configuration & OEM Controllers
13.1 Passive or Biamp ?
13.2 Passive System Parameters (optional)
13.3 Biamp System Parameters
14. V300 Recommended Service Parts & Accessories
15. Warranty
16. Declaration of Conformity
1. Introduction
The ultimate in sound quality for critical applications such as theatre, acoustic music venues and
houses of worship. For all applications where performance is the focus and the system should be so
accurate that it reinforces, but remains unobtrusive and acoustically transparent to the audience, the
V300 is the natural choice. The 12” SuperDual™ ensures the most even frequency response over a
wide coverage areain the medium size venues for which the Tannoy V300 is designed. In common
with the rest of the V series products the V300 features a foam covered mesh grill, aesthetically
essential for use in theatres and live performance applications.
The V300 comprises one 12 inch Dual Concentric driver in which the low frequency (LF) and high
frequency (HF) sources are coincidentally aligned to a point source, resulting in a smooth uniform
frequency response over a wide area of coverage either as a portable stand alone system or in a
multi-cabinet array. The sophisticated CAD designed waveguide combines 90 degree conical
dispersion and excellent acoustic impedance characteristics. As the system is a point source,
clusters and arrays have minimal lobing.
The asymmetric cabinet profile allows flexible and discreet installation. As a foreground system,
installation is made simple with a range of Secur-ET mounting hardware, designed specifically for the
V series – or the system can be flown using the integral M10 inserts.
For portable stage use the birch ply cabinet has a recessed carrying handle on the rear of the cabinet
and a blanking plate, which can be removed to install an optional pole mount. As a versatile low
profile stage monitor, the conical coverage pattern gives the performer greater freedom of movement
than allowed by conventional horn loaded designs. The V300 can be configured for both passive full
range or biamped operation, a full description is provided later in this manual.
2. Unpacking
Every Tannoy V300 product is carefully tested and inspected before being packaged and leaving the
factory. After unpacking your loudspeaker, please inspect for any exterior physical damage, and save
the carton and any relevant packaging materials in case the loudspeaker again requires packing and
shipping. In the event that damage has been sustained in transit notify your dealer immediately.
3.1 Connectors/Cabling
The V300 is fitted with 4-pole Neutrik Speakon connectors. Speakon has the following advantages
over EP and XLR type connectors: All terminations are solderless; this makes life easier at the time
of installation or when field servicing is required. Contacts will accept 6 sq. mm wire with an outside
diameter of up to 15mm and a current rating of 30 Amps. The pins of the 2 Speakon sockets
identified input/output on the rear of the input panel are paralleled within the enclosure. Tannoy has
adopted the conventional wiring standard for the V300 product :-
Mode Of Operation
Speakon Pin No. Passive Full Range Bi - Amp
1+ Full Range + LF +
1- Full Range - LF 2+ No Connectors HF +
2- No Connectors HF -
For a worldwide list of Neutrik distributors see http://www.neutrik.com/
Cable choice consists mainly of selecting the correct cross sectional area in relation to the cable
length and the load impedance. A small cross sectional area would increase the cables series
resistance, inducing power loss and response variations (damping factor).
Connectors should be wired with a minimum of 2.5 sq. mm (12 gauge) cable. This will be perfectly
satisfactory under normal conditions. In the case of very long cable runs the wire size should exceed
this, refer to the following table for guidance: -
CABLE RUN
(m)
10 2.5
25 2.5
50 2.5
100 2.5
4. Polarity Checking
It is most important to check the polarity of the wiring before the speaker system is flown. A simple
method of doing this without a pulse based polarity checker for LF units is as follows: Connect two
wires to the +ve and -ve terminals of a PP3 battery. Apply the wire which is connected to the +ve
terminal of the battery to the speaker cable leg which you believe to be connected to pin 1+ of the
speaker connector and likewise the -ve leg of the battery to pin 1-.
If you have wired it correctly the LF drive unit will move forward, indicating the wiring is correct. All
that remains now is to connect the +ve speaker lead to the +ve terminal on the amplifier and the -ve
lead to the -ve terminal on the amplifier. If however the LF driver moves backwards, the input
connections need to be inverted.
If problems are encountered, inspect the cable wiring in the first instance. It should also be noted that
different amplifier manufacturers utilise different pin configurations and polarity conventions, if you are
using amplifiers from more than one manufacturer, check the polarity at the amplifiers as well as the
loudspeakers.
C.S.A. OF EACH
CONDUCTOR (mm)
4.0
6.0
4.0
6.0
4.0
6.0
4.0
6.0
CABLE
RESISTANCE ΩΩ
0.14
0.09
0.06
0.35
0.22
0.14
0.69
0.43
0.29
1.38
0.86
0.58
% POWER LOSS
INTO 8ΩΩ LOAD
1.7
1.1
0.73
4.3
2.7
1.8
8.6
5.4
3.6
17.0
11.0
7.2
% POWER LOSS
INTO 4ΩΩ LOAD
3.5
2.2
1.5
8.6
5.4
3.6
17.0
11.0
7.2
35.0
22.0
14.0
5. Amplification & Power Handling
As with all professional loudspeaker systems, the power handling is a function of voice coil thermal
capacity. Care should be taken to avoid running the amplifier into clip (clipping is the end result of
overdriving any amplifier). Damage to the loudspeaker will be sustained if the amplifier is driven into
clip for any extended period of time. Headroom of at least 3dB should be allowed. When evaluating an
amplifier, it is important to take into account its behaviour under low impedance load conditions. A
loudspeaker system is highly reactive and with transient signals it can require more current than the
nominal impedance would indicate.
Generally a higher power amplifier running free of distortion will do less damage to the loudspeaker
than a lower power amplifier continually clipping. It is also worth remembering that a high powered
amplifier running at less than 90% of output power generally sounds a lot better than a lower power
amplifier running at 100%. An amplifier with insufficient drive capability will not allow the full
performance or the loudspeaker to be realised. (See technical specifications section for
recommended amplifier power)
It is important when using different manufacturers amplifiers in a single installation that the have very
closely matched gains, the variation should be less than +/- 0.5dB. This precaution is important to
the overall system balance when only a single active crossover is being used with multiple cabinets; it
is therefore recommended that the same amplifiers be used throughout.
6. Crossovers
The V300 is supplied as standard for passive operation via the internal crossover network. If higher
peak outputs and additional low frequency output is required then the V300 can be used in
conjunction with the TDX2 or other OEM louds peaker management systems.The Tannoy TDX2 Digital
controller will provide crossover, parametric EQ, limiter and delay functions (See the relevant literature
on the TDX2 for further information).
The V300 can be easily configured for Biamp operation in conjunction with the TDX2 or other OEM
controller/crossovers. A detailed description along with system parameters is given in Section 13 of
this manual.
7. Equalisation
The V300 loudspeaker is designed to need no equalisation or correction to overcome system
limitations. As a result, it will only need equalisation to compensate for difficult acoustic
environments.
Over equalisation can reduce system headroom, and introduce phase distortion resulting in greater
problems than cures. If equalisation is required then it should be applied gently and smoothly. The
V300 loudspeaker is a point source, phase coherent designs and violent equalisation will be
detrimental to the overall sound quality.
When a loudspeaker is used in close proximity to another, comb filtering effects can create coverage
problems, comb filtering creates an uneven frequency response across the coverage area due to
constructive and destructive interference effects between the sources. The amount of comb filtering is
affected by the spacing of the relative sound sources. Minimising this effect cannot be cured by
equalisation (see the following section for more details).
8. Arraying
As discussed in the previous section, comb filtering is a phenomenon, which cannot not be cured by
equalisation. Small alterations to loudspeaker positions can have the effect of minimising problematic
combing frequencies. Arrays should be constructed so that the individual coverage patters of each
loudspeaker combine with minimal overlap. The design of the V300 cabinet greatly simplifies the
creation of effective arrays, allowing seamless wide (140 degree) horizontal coverage using two
loudspeakers without the need for tedious experimentation.
By placing the V300 cabinets with the 30 degree angled rear panels together, minimal dispersion
pattern overlap is achieved, guaranteeing an extraordinarily smooth transition.
In many applications the 90-degree dispersion pattern may be sufficient in the horizontal plane.
It is also possible to stack the cabinets vertically using the above method, say for use in a central
cluster, where greater vertical dispersion is required.
9.
V300
60deg
As shown in the above diagram, one of the V300 cabinets is inverted to allow the optimum splay
angle to be achieved. The grill can be simply removed from this cabinet and be replaced in the
correct orientation. The grill is held in position by the two fixing screws on the top and bottom
lips of the cabinet.
9. Dimensions
30deg
50deg
175.0
V300
375.0
180.0
284.0
370.0
590.0
180.0284.0
504.0180.0
205.0
43.0
175.0
175.0
185.0
295.0
!!
12. Rigging & Suspension
12.1 General Safety Advice
The Tannoy Professional hardware covered in this guide has been designed to offer quick, simple,
cost effective and secure solutions for mounting specific Tannoy Professional
loudspeakers. This hardware has been designed and manufactured with a high safety load factor for
its specific role. To ensure the safest possible use of the hardware covered in this guide, it must be
assembled in strict accordance with the instructions specified. The information in these manuals
relating to the assembly and the safe use of these accessories must be understood and followed.
The installation of Tannoy Professional loudspeakers using the dedicated hardware should only ever
be carried out by fully qualified installers, in accordance with all the required safety codes and
standards that are applied at the place of installation.
WARNING: As the legal requirements for flying change from country to country, please consult you
local safety standards office before installing any product. We also recommend that you thoroughly
check any laws and bylaws prior to commencing work.
Tannoy Professional hardware has been designed for use with specific Tannoy Professional
loudspeakers, and is not designed or intended for use with any other Tannoy Professional products,
or any other devices. Using Tannoy Professional hardware for any purpose other than that indicated in
this guide is considered to be improper use. Such use can be very dangerous as overloading,
modifying, assembling in anyway other than that clearly stated in the manual, or damaging Tannoy
Professional hardware will compromise safety.
The component parts of any Tannoy Professional hardware device must only be assembled using the
accessory kits supplied and in strict compliance with the user manual. The use of other accessories
or non-approved methods of assembly may result in an unsafe hardware system by reducing the load
safety factor. Welding, or any other method of permanently fixing hardware components together or to
the integral fixing points in the cabinet should never be used.
Whenever a Tannoy Professional loudspeaker is fixed to a surface using a Ta nnoy
Professional hardware device, the installer must ensure that the surface is capable of safely and
securely supporting the load. The hardware employed must be safely, securely, and in
accordance with the manual, attached both to the loudspeaker and also to the surface in question,
using only the fixing holes provided as standard and covered in the manual. Secure fixings to the
building structure are vital. Seek help from architects, structural engineers or other specialists if in
any doubt.
All louds peakers flown in theatres, nightclubs, conference centre or other places of work and
entertainment must, be provided with an independent, correctly rated and securely attached
secondary safety – in addition to the principle hardware device. This secondary safety must prevent
the loudspeaker from dropping more than 150mm (6”) should the principle hardware
device fail.
!!
12.2 SECUR ET – VMY Yoke Bracket
The VMY is an adjustable yoke bracket (available in both black and white), allowing the us er to fly the
Tannoy V300 loudspeaker in either portrait or landscape orientations using the same bracket (Figures
1 & 2).
The Tannoy V300 loudspeaker is attached to the bracket using the M10 bolts and washers supplied
in the accessory pack.
Only the screws, fasteners, shakeproof and plain washers specified on figure 3. should be
used to assemble the VMY bracket
Pivot studs (Figure 3.) (Supplied with the VMY) are attached to the cabinet using the M10 bolts
supplied. These bolts locate on the M10 inserts in the cabinet. The VMY adjustable yoke bracket
then connects to the centre of these mounting plates (using the M10 screws supplied). These
bracket pick up points which are in line with the bracket’s axis of rotation, are also positioned on the
centre of gravity of the V300 in both orientations to allow easy adjustment for optimum coverage.
The vertical distance between the apex of the VMY and the top of the Tannoy V300 loudspeaker can
be adjusted by connecting to varying mounting points on the bracket allowing varying degrees of
vertical rotation. The top centre fixing hole of the VMY then provides a pick up point for a variety of
Tannoy Professional hardware accessories including the VMB wall mounting plate (shown in Figure
2.), the VCS ceiling saddle, and the VPC pole clamp.
Use the table of parts along with the assembly drawing (Figure 3.) to assemble the VMY.
Figure 4 shows the VMY assembled.
Fig.1 Fig. 2
Fig 3.
Number on Assembly View (Fig 3.) Description Quantity
1 Hanging Bracket 2
2 Cross Member 1
3 Pivot Stud 2
4 M10 Plain Washer 2
5 M8 Spring Washer 2
6 M10 Spring Washer 4
7 M10 x 30mm Screw 2
8 M8 x 20mm Screw 2
9 M10 x 30mm Screw 2
10 M10 Nyloc Nut 2
11 Friction Washer 2
12 30mm Square Blank Plug 2
Fig 4.
12.3 SECUR ET – VMB Wall Mounting Bracket
plate and along the fixing beam to the terminal
2
3
!!
FIG 1.
The VMB is wall mounting bracket for the
attachment of a VMY, available in both black
and white finishes, allowing the user secure
the Tannoy V300 loudspeaker in either portrait
or landscape orientations to a wall.
The Tannoy V300 loudspeaker is attached to
the bracket using the accessories supplied.
This wall-mounting bracket has a larger wall
plate than previous models to maximise the
integrity of fixing obtained. There are also two
holes either side of the fixing beam to allow
the speaker cable the pass through the wall
panel resulting in a more discrete installation.
The fixing beam on the VMB has a number of
mounting points from which the VMY can be
attached at varying distances from the
mounting surface.
Only the screws, fasteners, shakeproof
and plain washers specified on figure 3.
should be used to assemble the VMB
bracket
1
FIG 3.
Number on Fig 3. Description Quantity
1 VMB Wall Bracket 1
2 M10 Nyloc Nut 1
3 M10 Plain Washer 1
4 30mm Square Blank Plug 1
5 Nylon Spacer 1
6 M10 x 85mm Screw 1
FIG 2.
4
5
6
12.4 SECUR ET – VEB Eyebolt
8:1984. The loudspeakers are equipped with
nclosure from another to form a
!!
FIG 1.
The Tannoy V300 loudspeaker can be flown with
high quality VEB M10 eyebolts with collar to
BS427
internal steel braces, which also double as the
flying points, and accept VEB M10 eyebolts.
To install the VEB M10 eyebolts remove the
original M10 counter sunk screws from the
locations you wish to install the VEB M10
eyebolts. Then replace these counter sunk M10
screws with the VEB M10 eyebolts. The M10
insert on the rear of the cabinet also accepts a
VEB M10 eyebolt and should only be used for
tilting the loudspeaker to the desired angle.
Important: It is impe rative for safety reasons
that two eyebolts linked to two independently
fixed straps are used per cabinet. VEB
eyebolts should be installed into the relative
sides of the cabinet, and should NEVER be
installed on the top of the cabinet. Never
suspend one e
line array or cluster using these fittings.
The correct method is shown in figure 2.
Never attempt to use formed eyebolts i.e.
formed from a steel rod and bent into an eye.
Only use the outer fixing points on the top and
sides of the V300 cabinet for fixing eyebolts. The
inner two fixing points on each side of the cabinet
are for dedicated bracketry (VMY) only.
p r o f e s s i o n a l
p r o f e s s i o n a l
p r o f e s s i o n a l
p r o f e s s i o n a l
FIG 2.
12.5 SECUR – ET VTH Pole Mount
35mm pole mount this blanking plate can be
threaded rod in place at the top of the ceiling
12.6 SECUR – ET VCS Ceiling Saddle
Fig 1.
12.7 SECUR – ET VPC Pole Clamp
The Tannoy V300 loudspeaker is fitted as
standard with a blanking plate on the base
of the cabinet. However, should you ever
wish to mount the V300 onto a standard
quickly and easily removed and replaced by
a VTH pole mount. The same screws which
secure the blanking plate should be used to
secure the VTH in position.
VCS
The VCS ceiling saddle available in both
black and white finishes, and is to be used
in conjunction with the VMY and a length of
M10 threaded rod (not supplied by Tannoy
Limited). The VCS ceiling saddle allows the
Tannoy V300 loudspeaker to be suspended
at a user defined distance from the ceiling
as shown in Figure 1.
Included with the VCS is an M10 nut. This
should be used to secure and lock the
saddle.
The VPC pole clamp can be used along with the
VMY yoke bracket to suspend a Tannoy V300
loudspeaker from an overhead bar, truss or
suitable structure. Only the parts supplied
should be used to secure the VPC to the VMY
yoke bracket.
The following items are included with each
Description Quantity
VPC Pole Clamp 1
M10 Washer 1
M10 x 50mm Screw 1
M10 Nyloc Nut (Black) 1
13. System Configuration & OEM Controllers
13.1 Passive or Biamp?
The V300 is supplied as standard for passive operation via the internal crossover network and is
connected as shown in Figure 1. To reconfigure for Biamp operation simply follow the wiring
schematic as shown in Figure 2. This mode of operation bypasses the internal passive crossover
network and connects the input seakon connectors directly to the LF & HF sections of the driver
separately (see section 3.1 for connection details). The Biamp controller parameters in section
13.3 must be adhered to for optimum performance.
A loudspeaker driven in Biamp mode offers a number of performance advantages, such as increased
system headroom. Audio program materiel is made up of many different frequencies and harmonics.
In music materiel, most of the energy is in the low frequencies, with less in the highs. When both
high and low frequencies are present in a signal, the stronger low frequencies can use up amp power,
leaving little or no reserve for the highs, so they are more likely to cause the power amplifier to clip. In
a Biamp driven system, a smaller amp can handle high frequencies, LF amp clipping is less of a
factor, and less overall amplifier capacity is needed due to the efficiency improvement in the absence
of a passive crossover.
Fig.1
Fig. 2
13.2 Passive System Parameters (optional)
With the vast array of digital loudspeaker management systems available it is inevitable that the user
may opt to use a controller other than the TX2 & TDX2 as part of a large scale integrated system. In
passive mode the V300 has been designed to need no external equalisation to overcome system
limitations. If the V300 is to be used alone with additional bass enhancement required and have the
frequency response limits tighter than +/- 3dB as stated in section 11, then apply the parameters in
the table below for optimised performance: -
Parameter Unit/Name
Gain (dB) User definable
Delay (ms) User definable
Polarity Positive
HPF â Freq (Hz) 45.1
LPF Freq (Hz) Thru
PEQ 1 ââ
PEQ 2
PEQ 3
PEQ 4
PEQ 5
ââ Note : When using the V300 with subs, set HPF @ 80 – 100Hz
Slope (dB/oct) 24
Filter Shape Butterworth
Slope (dB/oct) NA
Filter Shape NA
Freq (Hz) 60.1
Level (dB) +7
Type Parametric
Q / Bandwidth 2.8 / 0.3536
Freq (Hz) 281
Level (dB) -2.5
Type Parametric
Q / Bandwidth 2.0 / 0.500
Freq (Hz) 1560
Level (dB) -2.5
Type Parametric
Q / Bandwidth 4.8 / 0.2012
Freq (Hz) 3360
Level (dB) -2
Type Parametric
Q / Bandwidth 2.5 / 0.3969
Freq (Hz) 14800
Level (dB) -3
Type Parametric
Q / Bandwidth 4.0 / 0.2500
(24dB/oct LR) and omit PEQ1.
PEQ 1 may also be omitted when using the V300 as a floor monitor.
13.3 Biamp System Parameters
Parameter Unit/Name Low Section High Section
Gain (dB) 0 -6
Delay (ms) 0 0
Polarity Positive Positive
HPF â Freq (Hz) 45.1 1920
LPF Freq (Hz) 1820 Thru
PEQ 1 ââ
PEQ 2
PEQ 3
PEQ 4
PEQ 5
ââ Note : When using the V300 with subs, set HPF on LF section @ 80 – 100Hz
Slope (dB/oct) 24 24
Filter Shape Butterworth Linkwitz Riley
Slope (dB/oct) 24 NA
Filter Shape Linkwitz Riley NA
Freq (Hz) 60.1 6100
Level (dB) +7 +3.5
Type Parametric Hi - Shelf
Q / Bandwidth 2.8 / 0.3536 NA
Freq (Hz) 281 10500
Level (dB) -2.5 +4
Type Parametric Parametric
Q / Bandwidth 2 / 0.500 9.5 / 0.1051
Freq (Hz) 749 NA
Level (dB) -2 NA
Type Parametric NA
Q / Bandwidth 2 / 0.500 NA
Freq (Hz) 606 NA
Level (dB) -2 NA
Type Parametric NA
Q / Bandwidth 6 / 1.669 NA
Freq (Hz) 1650 NA
Level (dB) -2 NA
Type Parametric NA
Q / Bandwidth 7.1 / 0.1403 NA
(24dB/oct LR) and omit PEQ1 (on LF only)
PEQ 1 (on LF only) may also be omitted when using the V300 as a floor monitor.
14. V300 Service Parts & Accessories
Part Number Description
7900 0386 Driver Kit - 3138
7900 0387 Recone Kit - 3138
7900 0326 HF Diaphragm Kit
7300 0826 Crossover
8001 2780 VMY – Secur ET – Yoke Adjustable (Black)
8001 2790 VMY – Secur ET – Yoke Adjustable (White)
8001 2800 VMB – Secur ET – Wall Bracket (Black)
8001 2810 VMB – Secur ET – Wall Bracket (White)
8001 2820 VEB – Secur ET – Eyebolts M10
8001 2830 VCS – Secur ET – Ceiling Saddle (Black)
8001 2840 VCS – Secur ET – Ceiling Saddle (White)
8001 2850 VPC – Secur ET – Pole Clamp
8001 2860 VTH – Secur ET – Top Hat (Black)
8001 2870 VTH – Secur ET – Top Hat (White)
8001 1930 Tannoy TDX2 Digital System Controller 90 – 250V UK
8001 1940 Tannoy TDX2 Digital System Controller 90 – 250V EUR
8001 1950 Tannoy TDX2 Digital System Controller 90 – 250V USA
14. Warranty
No maintenance of the V300 loudspeaker is necessary.
All Tannoy professional loudspeaker products are covered by a 5 year warranty from the date of
manufacture subject to the absence of misuse, overload or accidental damage. Claims will not be
considered is the serial number has been altered or removed. Work under warranty should only be
carried out by a Tannoy Professional dealer or service agent. Th is warranty in no way affects your
statutory rights. For further information please contact your dealer or distributor in your country. If you
cannot locate your distributor please contact Customer Services, Tannoy Ltd at the address given
below.
Customer Services
Tannoy Ltd.
Rosehall Industrial Estate
Coatbridge
Strathclyde
ML5 4TF
Scotland
Telephone: 01236 420199 (National)
+44 1236 420199 (International)
Fax: 01236 428230 (National)
+44 1236 428230 (International)
E-Mail: prosales@tannoy.com
DO NOT SHIP ANY PRODUCT TO TANNOY WITHOUT PREVIOUS AUTHORISATION
Our policy commits us to incorporating improvements to our products through continuous research
and development. Please confirm current specifications for critical applications with your supplier.
16. Declaration of Conformity
The following apparatus is/are manufactured in the United Kingdom by Tannoy Ltd of
Rosehall Industrial estate, Coatbridge, Scotland, ML5 4TF and conform(s) to the
protection requirements of the European Electromagnetic Compatibility Standards
and Directives relevant to Domestic Electrical Equipment. The apparatus is designed
and constructed such that electromagnetic disturbances generated do not exceed
levels allowing radio and telecommunications equipment and other apparatus to
operate as intended, and, the apparatus has an adequate level of intrinsic immunity
to electromagnetic disturbance to enable operation as specified and intended.
Details of the Apparatus: Tannoy Contractor Loudspeaker
Model Number: V300
Associated Technical File: EMCV300
Applicable Standards: EN 50081-1 Emission
EN 50082-1 Immunity
Electrical Safety: EN 60065
Signed:
Position: Engineering Director – Professional Products
Tannoy Professional
Date: 10/06/2002
For Tannoy Ltd
Tannoy Loudspeakers are manufactured
in Great Britain by :
Tannoy Ltd, Rosehall Industrial Estate, Coatbridge,
Strathclyde, ML5 4TF, SCOTLAND
Telephone: +44 (0)1236 420199 Fax: +44 (0)1236 428230
Tannoy North America Inc, Suite 1. 335 Gage Avenue, Kitchener, Ontario, CANADA, N2M 5E1
Telephone: (519) 745 1158 Fax: (519) 745 2364
Tannoy Nederland BV, Anthonetta Kuijlstraat 19, 3066 GS, Rotterdam THE NETHERLANDS
Telephone: (010) 2860554 Fax: (010) 2860431
Issue 1.0 Part No. 6481 0387
th
GH 10
June 2002
Loading...
