HP NC1020 PCI 1000T Gigabit Server Adapter

HP NC1020 PCI 1000T Gigabit Server AdapterHP NC1020 PCI 1000T Gigabit Server Adapter

Overview

The NC1020 server adapter is a single-port, copper, Gigabit Ethernet PCI bus adapter that supports basic server functionality. It runs over Category 5 (or better) twisted-pair cabling and is targeted to customers who deploy HP ProLiant 100 and 300 series servers. It is supported in 32-bit PCI, 33/66 MHz slots, comes with 64KB onboard memory, and provides 10/100/1000T auto-negotiated speed and duplex.

The NC1020 has been designed with server needs in mind and offers these server features: Wake-on-LAN, PXE support, as well as link and activity LEDs. Additionally, it supports these IEEE NIC standards: 802.3, 802.3u, 802.3ad, and 802.3ab, 802.1x, 802.1Q and 802.1p.

Models

ModelsModels

HP NC1020 PCI 1000T Gigabit Server Adapter Kit Contents

Kit Contents

Kit ContentsKit Contents

NOTE:

NOTE: NOTE: specifications, please visit:

For a brief, printer friendly data sheet that describes this product and informs you of the essential capabilities and

HP NC1020 PCI 1000T Gigabit Server Adapter CD containing Drivers, User Guide, and Installation and Diagnostic Utilities Quick Install Card Product Quality Statement Product Warranty Statement

http://h71028.www7.hp.com/ERC/downloads/4AA0-6064ENW.pdf

DA - 11890 Worldwide — Version 13 — September 5, 2007

353377-B21

.

Page 1

QuickSpecs

Performance

Gigabit Ethernet

Gigabit EthernetGigabit Ethernet Throughput

Throughput

ThroughputThroughput

Load Balancing

Load BalancingLoad Balancing

Scalability and Reliability

Scalability and ReliabilityScalability and Reliability

Tri-Speed Support

Tri-Speed SupportTri-Speed Support

Up to 1000Mbps Ethernet transfer rate delivers outstanding network performance that improves response time and removes bottlenecks across the entire network.

Transmit Load Balancing (TLB) and Switch-Assisted Load Balancing (SLB) are two advanced features used to build a bigger pipe for improved networking bandwidth. These port bonding techniques enable users to install up to eight NC1020 adapters in a HP ProLiant server and aggregate their throughput up to a theoretical maximum of 16 Gigabits per second full-duplex transmission.

The NC1020 can be configured to work with other NC-series Ethernet server adapter teams supported on HP ProLiant servers, when running under Microsoft Windows, Linux, or NetWare operating systems.

If Large Send Offload (LSO) is enabled, the NC1020 can only team in Microsoft Operating Systems with another NC1020 or a NC7761.

If LSO is disabled, the NC1020 can team with all of HP ProLiant NC-Series NICs without problems.

Because the NC1020 supports 10Mbps Ethernet and 100Mbps Fast Ethernet in addition to Gigabit Ethernet, users are guaranteed end-to-end protocol support across their enterprise. Like all HP server adapters, the NC1020 adheres to open industry standards, insuring that it will work seamlessly with any network devices that also support IEEE standards.

HP NC1020 PCI 1000T Gigabit Server Adapter

HP NC1020 PCI 1000T Gigabit Server AdapterHP NC1020 PCI 1000T Gigabit Server Adapter

Traditional PCI slot

Traditional PCI slotTraditional PCI slot

Network Fault Tolerance

Network Fault ToleranceNetwork Fault Tolerance (NFT)

PCI Hot Plug

PCI Hot PlugPCI Hot Plug

The NC1020 is specified to run in either 33 or 66MHz PCI slots. If customers want to place it into 64-bit, 66/100/133MHz slots, they can do so with the potential for performance degradation.

Network Fault Tolerance, sometimes called "failover" or "NIC redundancy", allows for the installation of multiple NC1020 server adapters or other network adapters so that the active device can be backed up by a redundant adapter to improve availability. HP's teaming utility also allows users to specify that when a failed adapter is fixed and replaced, the original adapter resumes its function as the primary network connection. The NC1020 can be configured to work with other NC-series Ethernet server adapter teams supported on HP ProLiant servers, when running under Microsoft Windows, Linux, or NetWare operating systems. If Large Send Offload (LSO) is enabled, the NC1020 can only team in Microsoft Operating Systems with another NC1020 or a NC7761. If LSO is disabled, the NC1020 can team with all of HP ProLiant NCSeries NICs without problems.

The NC1020 ships with PCI Hot Plug support, which enables it to be replaced or added to a PCI Hot Plug compatible server without powering down the system. This feature provides increased system availability and non-stop serviceability in business-critical computing environments.

DA - 11890 Worldwide — Version 13 — September 5, 2007

Page 2

QuickSpecs

Performance

Operating System Support

Operating System SupportOperating System Support

32-bit Windows

64-bit Windows

Microsoft certified miniport and teaming drivers Red Hat Enterprise Linux SUSE Linux Enterprise Server Novell NetWare 6 Novell NetWare 6.5 Novell Open Enterprise Server x86 SCO UnixWare 7.1.3 SCO UnixWare 7.1.4 SCO OpenServer 5.0.7 SCO OpenServer 6.0.0 Solaris 9 Solaris 10 NDIS 2 for DOS unattended operating system install (43K or less in size)

NOTE:

NOTE: NOTE: BladeSystem Server Linux matrix:

HP NC1020 PCI 1000T Gigabit Server Adapter

HP NC1020 PCI 1000T Gigabit Server AdapterHP NC1020 PCI 1000T Gigabit Server Adapter

Microsoft Windows Server 2003 Standard, Web, Small Business, and Enterprise Editions Microsoft Windows 2000 Server and Advanced Server

Microsoft Windows Server 2003 Standard and Enterprise Editions

For more Linux OS support & certification information, please visit our the ProLiant &

http://h18004.www1.hp.com/products/servers/linux/hpLinuxcert.html

Warranty

WarrantyWarranty

Network Management

Network ManagementNetwork Management

Auto-negotiation

Auto-negotiationAuto-negotiation

Management Support

Management SupportManagement Support

Server Integration

Server IntegrationServer Integration

Configuration Utilities

Configuration UtilitiesConfiguration Utilities

Maximum

MaximumMaximum

Minimum

MinimumMinimum

The NC1020 automatically senses and configures itself to the speed of the device to which it is attached. It also automatically configures for half or full duplex, depending on the duplex mode of the switch, hub, or router at the other end of the cable.

Like all HP server adapters, the NC1020 ships with drivers and agents that can be managed from all versions of HP Insight Manger 7, as well as using any management application that supports SNMP.

HP's SmartStart configuration utility includes setup support for the NC1020 so the adapter can be configured as part of the SmartStart configuration process. HP Insight Manager can recognize the NC1020 individually or in port-bonded teams, and can collect and report SNMP statistics on the adapter events. Additionally, Integrated Management Log (IML) support is provided by the NC1020 for critical event logging on HP servers.

Each NC1020 ships with a suite of OS-tailored configuration utilities that allow the user to run initial diagnostics and configure adapter teams for Network Fault Tolerance, Transmit Load Balancing, or Switch-Assisted Load Balancing (Dynamic 802.3ad) in the Windows®, Linux, or NetWare operating systems.

The remaining warranty of the HP product in which it is installed (to a maximum three-year, limited warranty).

One year limited warranty.

LED Indicators

LED IndicatorsLED Indicators

Bracket LED indicators show link integrity, network activity, and network speed for easy troubleshooting.

DA - 11890 Worldwide — Version 13 — September 5, 2007

Page 3

QuickSpecs

Related Options

Additional Gigabit Server

Additional Gigabit ServerAdditional Gigabit Server Adapters

Adapters

AdaptersAdapters

Combo Switch Adapter

Combo Switch AdapterCombo Switch Adapter

10 Gigabit Server

10 Gigabit Server10 Gigabit Server Adapters

Adapters

AdaptersAdapters

HP NC110T PCI Express Gigabit Server Adapter

NOTE:

NOTE: NOTE:

HP NC360T PCI Express Dual Port Gigabit Server Adapter HP NC364T PCI Express Quad Port Gigabit Server Adapter

NOTE:

NOTE: NOTE:

HP NC373F PCI Express Multifunction Gigabit Server Adapter HP NC373T PCI Express Multifunction Gigabit Server Adapter HP NC380T PCI Express Dual Port Multifunction Gigabit Server Adapter HP NC7170 PCI-X Dual Port 1000T Gigabit Server Adapter HP NC7170 PCI-X Low Profile Dual Port 1000T Gigabit Server Adapter HP NC7771 PCI-X 1000T Gigabit Server Adapter

HP NC150T PCI 4-port 1000T Gigabit Combo Switch Adapter

HP NC510C PCIe 10 Gigabit Server Adapter

NOTE:

NOTE: NOTE: NC510C adapter.

HP NC510F PCIe 10 Gigabit Server Adapter

NOTE:

NOTE: NOTE: NC510F adapter.

HP NC1020 PCI 1000T Gigabit Server Adapter

HP NC1020 PCI 1000T Gigabit Server AdapterHP NC1020 PCI 1000T Gigabit Server Adapter

Does not support Windows 2000.

A minimum of 1 gigabyte (1 GB) of server memory is required per each

434905-B21

412648-B21 435508-B21

394793-B21 394791-B21 394795-B21 313881-B21 383738-B21 290563-B21

367132-B21

414129-B21

414126-B21

DA - 11890 Worldwide — Version 13 — September 5, 2007

Page 4

QuickSpecs

Technical Specifications

Compliance

ComplianceCompliance

General Specifications

General SpecificationsGeneral Specifications

Power and Environmental

Power and EnvironmentalPower and Environmental Specifications

Specifications

SpecificationsSpecifications

IEEE 802.3, 802.3u, Dynamic 802.3ad, and 802.3ab, 802.1x, 802.1Q and 802.1p PCI 2.3 ACPI v1.1a

Communications

CommunicationsCommunications Processor

Processor

ProcessorProcessor On-board memory

On-board memory

On-board memoryOn-board memory Data rate

Data rate

Data rateData rate Data path

Data path

Data pathData path

Interrupt levels

Interrupt levelsInterrupt levels Connector

Connector

ConnectorConnector Distance

Distance

DistanceDistance Wiring

Wiring

WiringWiring Dimensions

Dimensions

DimensionsDimensions Operating

Operating

OperatingOperating

Non-operating

Non-operatingNon-operating

Power requirement

Power requirementPower requirement

Emissions Classifications

Emissions ClassificationsEmissions Classifications Agency Approvals

Agency Approvals

Agency ApprovalsAgency Approvals

(LxW)

HP NC1020 PCI 1000T Gigabit Server Adapter

HP NC1020 PCI 1000T Gigabit Server AdapterHP NC1020 PCI 1000T Gigabit Server Adapter

Broadcom 5705

64KB 10/100/1000 Mbps, Half- and full-duplex The NC1020 is specified to run in either 33 or 66MHz PCI slots. Customers

may put it into 64-bit, 66/100/133MHz slots with the potential for performance degradation.

INTA RJ-45 Up to 328 ft (100 m) Category 5 or higher UTP

4.7 x 2.0 inches (L x W), 11.938 cm x 5.08 cm Temperature Humidity Temperature Humidity Operating Voltage: 3.3V +/- 5% Maximum Power Consumption: 2.5 Watts Maximum: 750 mA @ 3V(DC) Class B USA: FCC (CFR 47 part 15) and UL 60950

Canada: ICES-003 and CSA60950 Japan: VCCI Korea: MIC (RRL), EMC Registration Australia: ACA, AS/NZS3548/EN55022:1998, EN55024:1998 EU: EN55022:1998 (CISPR 22), EN55024:1998, and IEC60950:1999 (EN60950:2000)

32° to 131° F (0° to 55° C) 5% to 95% non-condensing

-40° to 149° F (-40° to 65° C) 5% to 95% non-condensing

Environment-friendly

Environment-friendlyEnvironment-friendly Products and Approach

Products and Approach

Products and ApproachProducts and Approach

End-of-life Management

End-of-life ManagementEnd-of-life Management and Recycling

and Recycling

and Recyclingand Recycling

DA - 11890 Worldwide — Version 13 — September 5, 2007

Hewlett-Packard offers end-of-life HP product return, trade-in, and recycling programs in many geographic areas. For trade-in information, please go to

http://www.hp.com/go/green http://www.hp.com/go/green

Products returned to HP will be recycled, recovered or disposed of in a responsible manner.

The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by treatment facilities. This information (product disassembly instructions) is posted on the Hewlett Packard web site at: be used by recyclers and other WEEE treatment facilities as well as HP OEM customers who integrate and re-sell HP equipment.

http://www.hp.com/go/green

. To recycle your product, please go to: or contact your nearest HP sales office.

. These instructions may

Page 5

QuickSpecs

HP NC1020 PCI 1000T Gigabit Server Adapter

HP NC1020 PCI 1000T Gigabit Server AdapterHP NC1020 PCI 1000T Gigabit Server Adapter

Technical Specifications

The information contained herein is subject to change without notice.

Microsoft and Windows are US registered trademarks of Microsoft Corporation. Unix is a registered trademark of The Open Group. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

DA - 11890 Worldwide — Version 13 — September 5, 2007
