3Dconnexion CadMouse Properties Panel

You can access the 3Dconnexion Properties panel via the icon in your notification area (systray), 3D
Mouse Home (on your desktop) or by selecting
launched by pressing the Radial Menu Button on the top of the CadMouse).

This slider sets the overall speed for your CadMouse.

speed slider sets speed globally for all applications.

This is where you can configure specific CadMouse settings.

The Buttons panel within 3Dconnexion Properties allows you to assign commands, Macros or Radial

The active application is displayed at the top left of the panel and any changes made are only applied to
that application. This allows you to configure your CadMouse individually for each of your applications.

Some applications feature environment sensitive button mapping.
In those applications you can have different button assignments depending on the current active
environment. More information can be found in the application specific help sections of the affe

Speed

Note: The CadMouse

Advanced Settings

Buttons

Menus to the CadMouse buttons.

Environment sensitivity

applications:

cted

Autodesk Inventor

Assigning "Quick Macros" to buttons

To quickly assign a keystroke or macro to a button, simply click on
the required key or key combination. For example, in the screenshot below, clicking on "CTRL+A" would
make the field active and the next keyboard command pressed would be assigned to button number 1.

macro is created, it always sends a "press and release" command. If you want to assign a
"press and hold" command (for example Ctrl or Shift), you should use the "Keyboard" command
category in the flyout window (i.e. not the "Quick Macro" function describe

Assigning Commands using the flyout window

Clicking on the ">" arrow on the right hand side of the button field opens a flyout window for that

The category of the command that is currently assigned to that button is high

Siemens NX
PTC Creo Parametric
Siemens Solid Edge
Dassault Systèmes SolidWorks

Note: When a

d above).

CadMouse button:

The flyout window allows you to browse or search for commands in different categories such as
3Dconnexion or application commands. When you select a command by clicking on it, it is automatically

You can search for specific commands by typing text into the Live Search field. Only commands (and
their parent categories) which contain the text sequence you enter are shown in the flyout window.

To create a new Radial Menu, expand the "Radial Menu" category and click on "New Radial Menu".

assigned to the CadMouse button:

Using the Live Search field

Creating Radial Menus
