Product CadMouse® Wireless
Language
length
Product Copy (medium length version)
Product Copy (long length
Document Type Product Copy Master Document (PCMD)
Category CadMouse
EN
Part number 3DX-700062
EAN 4260016340910
UPC 821123700628
Product Claim
The Wireless Mouse for CAD Professionals
Product Copy (short
version)
CadMouse Wireless is the standard mouse for mobile CAD workstations. It provides all key features that
professional CAD users require: a dedicated middle mouse button, a smart mouse wheel and an
optical sensor with a resolution up to 7,200 dpi.
CadMouse Wireless is not just another mouse – specific features like the dedicated middle mouse
button, the smart mouse wheel or the radial menu that provides quick access for up to eight of
your favourite commands, makes it the ideal tool for mobile CAD users.
Compact and ergonomically designed, the CadMouse Wireless has an optical sensor with a
resolution up to 7,200 dpi and an adaptive polling rate. In combination with its optimally shaped
PTFE feet, the equilibrium between static and kinetic friction has been optimised to ensure continuous
tactile feedback, in turn ensuring constant precision and fluid mouse movements.
The rechargeable Li-Ion battery with a battery life of up to 2 months*, is the basis for maximum
mobility and flexibility. The variable connection options of the CadMouse Wireless substantiate these
attributes. You can work wireless via the 3Dconnexion Universal Receiver, Bluetooth or via USB
cable while charging the Li-Ion battery.
To protect your mobile device while travelling, 3Dconnexion includes a compact and lightweight carry
case with a durable surface.
* 2-month battery life based on 8 hours per day, 5 days per week.
version)
CadMouse Wireless is not just another mouse: Developed for mobile workstations, it is a professional
tool for high performance, precision and comfort in CAD and 3D applications.
Compact Ergonomic Design
Modern engineering and mobile workplace concepts demand powerful yet portable equipment. With the
CadMouse Wireless users benefit from CAD-specific features such as the dedicated middle mouse
button and the smart mouse wheel in one compact, wireless mouse.
Precision for Demanding CAD Projects
The high precision, energy saving optical sensor ensures that the mouse cursor is aligned with your
intention, thanks to the resolution up to 7,200 dpi and the adaptive polling rate up to 1000 Hz (via USB
connection). The best thing is: you get high performance specifications and can work with the
CadMouse Wireless up to two months on just one battery charge*.
Triple Connectivity
There are three kinds of ways to connect the CadMouse Wireless. Users can easily switch between the
3Dconnexion Universal Receiver with 2.4GHz wireless technology, Bluetooth or USB cable for parallel
charging the Li-Ion battery.
Professional Zoom and Scroll Navigation
There are two features, which support working in CAD applications particularly effectively: the smart
mouse wheel with SmartScroll function and the QuickZoom thumb buttons.
SmartScroll recognises the actual application environment and automatically delivers the right kind of
scrolling: precise, click-to-click zooming for CAD applications or speed scrolling with inertia effects in
browsers and documents.
QuickZoom allows users to zoom in and out of the centre of details with a single click of a thumb
button. Simply keep pressing the button to fine-tune the zoom level until the desired view is reached.
Easy Access to Favourite Application Commands
The gesture button opens an application or environment-specific radial menu, which gives direct access
to up to 8 of your favourite commands for each application or environment. Simply activate those
commands with a mouse gesture. Either by swiping the cursor over the command or clicking on it
directly.
Effortless Precision
The CadMouse Wireless has optimally shaped PTFE feet. These ensure smooth and fluid mouse
movements thanks to an almost perfect equilibrium between static and kinetic friction. Their shape also
helps to damp vibration.
Tailored Carry Case Included
Mobile working involves frequent changes of location. While travelling, it is essential to protect your
devices. For this reason, 3Dconnexion delivers the CadMouse Wireless with a compact and lightweight
carry case.
One Driver. Multiple Devices.
3DxWare 10 is the all-in-one driver for all 3Dconnexion devices. Its simple yet powerful user interface
allows the CadMouse Wireless to be customised and optimised to your work style, for each separate
application and environment.
* 2-month battery life based on 8 hours per day, 5 days per week.
Technical Specification
Supported Operating Systems
7 buttons (including dedicated middle mouse button)
Optical Sensor with up to 7,200 dpi resolution and adaptive polling rate with up to 1000 Hz (via USB
connection)
QuickZoom
Smart Mouse Wheel
Specially developed PTFE feet
3Dconnexion Universal Receiver with 2.4 GHz Wireless Technology
Bluetooth 4.0 Low Energy Technology
Micro USB Cable
Li-Ion Battery
Dimensions (LxWxH): 110 x 67 x 38 mm / 9.8" x 6.1" x 2.3"
Weight: approx. 110 g
Warranty: 2 years
Windows 10, Windows 8.1, Windows 8, Windows 7, macOS 10.10 or later
Certificates and Licences
CE, FCC, RCM, BSMI, ROHS, WEEE, NCC, MIC, IC
List of Main Features and Functions
Compact Design – mobile optimized ergonomic design with dedicated middle
mouse button.
High Performance – rechargeable battery and high precision, energy saving
optical sensor with a resolution up to 7,200 dpi.
Triple Connectivity – work wireless via Universal Receiver and Bluetooth or with
USB cable.
Smart Mouse Wheel – automatically switches between smooth scrolling and
click-to-click-zooming in CAD applications.
QuickZoom – effortlessly zoom in and out of your geometry with a single click.
Radial Menu – quick access for up to eight of your favourite application
commands.
FCC warning
§ 15.21 Information to user.
Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to
operate the equipment.
§ 15.105 Information to the user.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
16. label statement
§ 15.19 Labelling requirements. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received, including interference
that may cause undesired operation
15. RF exposure statement
The device has been evaluated to meet general RF exposure requirement. The device
can be used in portable exposure condition without restriction.
