Yamaha PSR-295, PSR-293 User Manual 2

Page 1

Owner’s Manual

Page 2

SPECIAL MESSAGE SECTION

This product utilizes batteries or an external power supply (adapter). DO NOT connect this product to any power supply or adapter other than one described in the manual, on the name plate, or speciﬁcally recommended by Yamaha.

This product should be used only with the components supplied or; a cart, rack, or stand that is recommended by Yamaha. If a cart, etc., is used, please observe all safety markings and instructions that accompany the accessory product.

SPECIFICATIONS SUBJECT TO CHANGE:

The information contained in this manual is believed to be correct at the time of printing. However, Yamaha reserves the right to change or modify any of the speciﬁcations without notice or obligation to update existing units.

This product, either alone or in combination with an ampliﬁer and headphones or speaker/s, may be capable of producing sound levels that could cause permanent hearing loss. DO NOT operate for long periods of time at a high volume level or at a level that is uncomfortable. If you experience any hearing loss or ringing in the ears, you should consult an audiologist. IMPORTANT: The louder the sound, the shorter the time period before damage occurs.

NOTICE:

Service charges incurred due to a lack of knowledge relating to how a function or effect works (when the unit is operating as designed) are not covered by the manufacturer’s warranty, and are therefore the owners responsibility. Please study this manual carefully and consult your dealer before requesting service.

ENVIRONMENTAL ISSUES:

Yamaha strives to produce products that are both user safe and environmentally friendly. We sincerely believe that our products and the production methods used to produce them, meet these goals. In keeping with both the letter and the spirit of the law, we want you to be aware of the following:

Battery Notice:

This product MAY contain a small non-rechargeable battery which (if applicable) is soldered in place. The average life span of this type of battery is approximately ﬁve years. When replacement becomes necessary, contact a qualiﬁed service representative to perform the replacement.

This product may also use “household” type batteries. Some of these may be rechargeable. Make sure that the battery being charged is a rechargeable type and that the charger is intended for the battery being charged.

When installing batteries, do not mix batteries with new, or with batteries of a different type. Batteries MUST be installed correctly. Mismatches or incorrect installation may result in overheating and battery case rupture.

Warning:

Do not attempt to disassemble, or incinerate any battery. Keep all batteries away from children. Dispose of used batteries promptly and as regulated by the laws in your area. Note: Check with any retailer of household type batteries in your area for battery disposal information.

Disposal Notice:

Should this product become damaged beyond repair, or for some reason its useful life is considered to be at an end, please observe all local, state, and federal regulations that relate to the disposal of products that contain lead, batteries, plastics, etc. If your dealer is unable to assist you, please contact Yamaha directly.

NAME PLATE LOCATION:

The name plate is located on the bottom of the product. The model number, serial number, power requirements, etc., are located on this plate. You should record the model number, serial number, and the date of purchase in the spaces provided below and retain this manual as a permanent record of your purchase.

Model

Serial No.

Purchase Date

92-BP

PLEASE KEEP THIS MANUAL

(bottom)

DGX-205/203, PSR-295/293 Owner’s Manual

Page 3

FCC INFORMATION (U.S.A.)

1. IMPORTANT NOTICE: DO NOT MODIFY THIS UNIT!

This product, when installed as indicated in the instructions contained in this manual, meets FCC requirements. Modiﬁcations not expressly approved by Yamaha may void your authority, granted by the FCC, to use the product.

2. IMPORTANT:

or another product use only high quality shielded cables. Cable/s supplied with this product MUST be used. Follow all installation instructions. Failure to follow instructions could void your FCC authorization to use this product in the USA.

3. NOTE:

requirements listed in FCC Regulations, Part 15 for Class “B” digital devices. Compliance with these requirements provides a reasonable level of assurance that your use of this product in a residential environment will not result in harmful interference with other electronic devices. This equipment generates/uses radio frequencies and, if not installed and used according to the instructions found in the users manual, may cause interference harmful to the operation of other electronic devices. Compliance with FCC regulations does

* This applies only to products distributed by YAMAHA CORPORATION OF AMERICA.

When connecting this product to accessories and/

This product has been tested and found to comply with the

OBSERVERA!

Apparaten kopplas inte ur växelströmskällan (nätet) så länge som den ar ansluten till vägguttaget, även om själva apparaten har stängts av.

ADVARSEL: Netspæendingen til dette apparat er IKKE afbrudt, sålæenge

netledningen siddr i en stikkontakt, som er t endt — også selvom der or slukket på apparatets afbryder.

VAR OITUS: Laitteen toisiopiiriin kytketty käyttökytkin ei irroita koko laitetta

verkosta.

not guarantee that interference will not occur in all installations. If this product is found to be the source of interference, which can be determined by turning the unit “OFF” and “ON”, please try to eliminate the problem by using one of the following measures:

Relocate either this product or the device that is being affected by the interference.

Utilize power outlets that are on different branch (circuit breaker or fuse) circuits or install AC line ﬁlter/s.

In the case of radio or TV interference, relocate/reorient the antenna. If the antenna lead-in is 300 ohm ribbon lead, change the lead-in to co-axial type cable.

If these corrective measures do not produce satisfactory results, please contact the local retailer authorized to distribute this type of product. If you can not locate the appropriate retailer, please contact Yamaha Corporation of America, Electronic Service Division, 6600 Orangethorpe Ave, Buena Park, CA90620

The above statements apply ONLY to those products distributed by Yamaha Corporation of America or its subsidiaries.

(class B)

(standby)

Entsorgung leerer Batterien (nur innerhalb Deutschlands)

Leisten Sie einen Beitrag zum Umweltschutz. Verbrauchte Batterien oder Akkumulatoren dürfen nicht in den Hausmüll. Sie können bei einer Sammelstelle für Altbatterien bzw. Sondermüll abgegeben werden. Informieren Sie sich bei Ihrer Kommune.

(battery)

DGX-205/203, PSR-295/293 Owner’s Manual

Page 4

PRECAUTIONS

PLEASE READ CAREFULLY BEFORE PROCEEDING

* Please keep this manual in a safe place for future reference.

WARNING

Always follow the basic precautions listed below to avoid the possibility of serious injury or even death from electrical shock, short-circuiting, damages, ﬁre or other hazards. These precautions include, but are not limited to, the following:

Power supply/AC power adaptor

• Only use the voltage speciﬁed as correct for the instrument. The required voltage is printed on the name plate of the instrument.

• Use the speciﬁed adaptor (PA-5D, PA-3C or an equivalent recommended by Yamaha) only. Using the wrong adaptor can result in damage to the instrument or overheating.

• Check the electric plug periodically and remove any dirt or dust which may have accumulated on it.

• Do not place the AC adaptor cord near heat sources such as heaters or radiators, and do not excessively bend or otherwise damage the cord, place heavy objects on it, or place it in a position where anyone could walk on, trip over, or roll anything over it.

Do not open

• Do not open the instrument or attempt to disassemble the internal parts or modify them in any way. The instrument contains no user-serviceable parts. If it should appear to be malfunctioning, discontinue use immediately and have it inspected by qualiﬁed Yamaha service personnel.

Water warning

• Do not expose the instrument to rain, use it near water or in damp or wet conditions, or place containers on it containing liquids which might spill into any openings.

• Never insert or remove an electric plug with wet hands.

Fire warning

• Do not put burning items, such as candles, on the unit. A burning item may fall over and cause a ﬁre.

If you notice any abnormality

• If the AC adaptor cord or plug becomes frayed or damaged, or if there is a sudden loss of sound during use of the instrument, or if any unusual smells or smoke should appear to be caused by it, immediately turn off the power switch, disconnect the adaptor plug from the outlet, and have the instrument inspected by qualiﬁed Yamaha service personnel.

CAUTION

Always follow the basic precautions listed below to avoid the possibility of physical injury to you or others, or damage to the instrument or other property. These precautions include, but are not limited to, the following:

Power supply/AC power adaptor Battery

• When removing the electric plug from the instrument or an outlet, always hold the plug itself and not the cord.

• Unplug the AC power adaptor when not using the instrument, or during electrical storms.

• Do not connect the instrument to an electrical outlet using a multiple-connector. Doing so can result in lower sound quality, or possibly cause overheating in the outlet.

DGX-205/203, PSR-295/293 Owner’s Manual

• Always make sure all batteries are inserted in conformity with the +/- polarity markings. Failure to do so might result in overheating, ﬁre, or battery ﬂuid leakage.

• Always replace all batteries at the same time. Do not use new batteries together with old ones. Also, do not mix battery types, such as alkaline batteries with manganese batteries, or batteries from different makers, or different types of batteries from the same maker, since this can cause overheating, ﬁre, or battery ﬂuid leakage.

(4)-8

1/2

Page 5

●

• Do not dispose of batteries in ﬁre.

• Do not attempt to recharge batteries that are not intended to be charged.

• When the batteries run out, or if the instrument is not to be used for a long time, remove the batteries from the instrument to prevent possible leakage of the battery ﬂuid.

• Keep batteries away from children.

• If the batteries do leak, avoid contact with the leaked ﬂuid. If the battery ﬂuid should come in contact with your eyes, mouth, or skin, wash immediately with water and consult a doctor. Battery ﬂuid is corrosive and may possibly cause loss of sight or chemical burns.

Location

• Do not expose the instrument to excessive dust or vibrations, or extreme cold or heat (such as in direct sunlight, near a heater, or in a car during the day) to prevent the possibility of panel disﬁguration or damage to the internal components.

• Do not use the instrument in the vicinity of a TV, radio, stereo equipment, mobile phone, or other electric devices. Otherwise, the instrument, TV, or radio may generate noise.

• Do not place the instrument in an unstable position where it might accidentally fall over.

• Before moving the instrument, remove all connected adaptor and other cables.

• Use only the stand speciﬁed for the instrument. When attaching the stand or rack, use the provided screws only. Failure to do so could cause damage to the internal components or result in the instrument falling over.

Connections

• Before connecting the instrument to other electronic components, turn off the power for all components. Before turning the power on or off for all components, set all volume levels to minimum. Also, be sure to set the volumes of all components at their minimum levels and gradually raise the volume controls while playing the instrument to set the desired listening level.

Maintenance

• When cleaning the instrument, use a soft, dry cloth. Do not use paint thinners, solvents, cleaning ﬂuids, or chemical-impregnated wiping cloths.

Handling caution

• Do not insert a ﬁnger or hand in any gaps on the instrument.

• Never insert or drop paper, metallic, or other objects into the gaps on the panel or keyboard. If this happens, turn off the power immediately and unplug the power cord from the AC outlet. Then have the instrument inspected by qualiﬁed Yamaha service personnel.

• Do not place vinyl, plastic or rubber objects on the instrument, since this might discolor the panel or keyboard.

• Do not rest your weight on, or place heavy objects on the instrument, and do not use excessive force on the buttons, switches or connectors.

• Do not operate the instrument for a long period of time at a high or uncomfortable volume level, since this can cause permanent hearing loss. If you experience any hearing loss or ringing in the ears, consult a physician.

Saving data

Saving and backing up your data

• The panel settings and some other types of data (page 42) will be lost if the power is turned off before they are saved. Be sure to save data you want to keep to the internal Flash Memory (page 42) before turning off the power. Saved data may be lost due to malfunction or incorrect operation. Save the important data to your computer. For information on sending the data, see page 64 (FUNCTION Bulk Send item)

Yamaha cannot be held responsible for damage caused by improper use or modiﬁcations to the instrument, or data that is lost or destroyed.

Always turn the power off when the instrument is not in use.

When using a power adaptor, even when the power switch is in the “STANDBY” position, electricity is still ﬂowing to the instrument at the minimum level. When you are not using the instrument for a long time, make sure you unplug the AC power adaptor from the wall AC outlet.

Make sure to discard used batteries according to local regulations.

• The illustrations and LCD screens as shown in this owner’s manual are for instructional purposes only, and may be different from the ones on your instrument.

• Unless otherwise indicated, the example panel control illustrations, Keyboard illustrations and LCD screenshots are taken from the DGX-205.

• Please note that the DGX-205/203 and PSR-295/293 have different numbers of keys: the DGX-205/203 has 76 keys, and the PSR-295/293 has 61 keys.

Trademarks

•Windows is the registered trademark of Microsoft

Corporation.

• All other trademarks are the property of their respective holders.

(4)-8

2/2

DGX-205/203, PSR-295/293 Owner’s Manual

Page 6

Copyright Notice

The followings are the titles, credits and copyright notices for three (3) of the songs pre-installed in this electronic keyboard:

Don’t Know Why

Words and Music by Jesse Harris Copyright All Rights Administered by Sony/ATV Music Publishing, 8 Music

My Favorite Things from THE SOUND OF MUSIC

Lyrics by Oscar Hammerstein II Music by Richard Rodgers

Killing Me Softly With His Song

(P.O. Box 15221, Beverly Hills, CA 90209 USA) Copyright Renewed All Rights on behalf of Rodali Music Administered by Sony/ATV

This product incorporates and bundles computer programs and contents in which Yamaha owns copyrights or with respect to which it has license to use others’ copyrights. Such copyrighted materials include, without limitation, all computer software, styles ﬁles, MIDI ﬁles, WAVE data and sound recordings. Any unauthorized use of such programs and contents outside of personal use is not permitted under relevant laws. Any violation of copyright has legal consequences. DON’T MAKE, DISTRIBUTE OR USE ILLEGAL COPIES.

Copying of the commercially available software is strictly prohibited except for your personal use.

Panel logos

GM System Level 1

“GM System Level 1” is an addition to the MIDI standard which ensures that any GM-compatible music data can be accurately played by any GM-compatible tone generator, regardless of manufacturer. The GM mark is afﬁxed to all software and hardware products that support GM System Level.

XGlite

As its name implies, “XGlite” is a simpliﬁed version of Yamaha’s high-quality XG tone generation format. Naturally, you can play back any XG song data using an XGlite tone generator. However, keep in mind that some songs may play back differently compared to the original data, due to the reduced set of control parameters and effects.

USB

USB is an abbreviation for Universal Serial Bus. It is a serial interface for connecting a computer with peripheral Devices. It allows “hot swapping” (connecting peripheral devices while the power to the computer is on).

DGX-205/203, PSR-295/293 Owner’s Manual

Page 7

●

Congratulations and thank you for purchasing

the Yamaha DGX-205/203 Portable Grand or PSR-295/293 PortaTone!

Please read this owner’s manual carefully before using the instrument

in order to take full advantage of its various features.

Make sure to keep this manual in a safe and handy place even after you ﬁnish reading,

and refer to it often when you need to better understand an operation or function.

Supplied Accessories

The DGX-205/203, PSR-295/293 package includes the following items. Please check that you have them all.

• Music rest • Accessory CD-ROM

• Owner’s manual (this book) • Song book

About the Supplied CD-ROM

The following software which facilitates data transfer between a computer and the instrument is provided on the supplied CD-ROM.

This software is compatible with Windows operating systems only.

• USB driver

• Musicsoft Downloader

The USB Driver enables data communication with the computer via USB. The Musicsoft Downloader application allows you to transfer songs downloaded from the Internet, as well as songs provided on the Accessory CD-ROM, to the instrument’s ﬂash memory. For details refer to the Accessory CD-ROM Installation Guide (page 70) and to the online help provided for each program.

CAUTION

•Never attempt to play the supplied CD-ROM on an audio CD player. Doing so can result in damage to your audio system and speakers, and potentially to your hearing!

Music Rest

Insert the music rest into the slots as shown.

DGX-205/203, PSR-295/293 Owner’s Manual

Page 8

Special features of the DGX-205/203, PSR-295/293

■ Performance assistant technology page 14

Play along with a song on the instrument’s keyboard and produce a perfect performance every time … even if you play wrong notes! All you have to do is play on the keyboard – alternately on the left- and right-hand ranges of the keyboard, for example – and you’ll sound like a pro as long as you play in time with the music.

■ Play a Variety Of Instrument Voices page 18

The instrument voice that sounds when you play the keyboard can be changed to violin, ﬂute, harp, or any of an extensive range of voices. You can change the mood of a song written for piano, for example, by using violin to play it instead. Experience a whole new world of musical variety.

■ Learning music is fun page 32

This instrument includes a range of songs covering a variety of genres that are enjoyable to listen to, or to play along with. You can start practicing with just one hand, and you can even practice at your own tempo, one note at a time as slowly as you like, until you are able to play at full speed. Song playback will automatically follow your tempo. You can also use songs you have downloaded from the Internet for lessons, so your musical resources are essentially unlimited! The instrument will even evaluate and grade your performance for you!

■ Play Along With Styles page 24

Excellen

Want to play with full accompaniment? Try the auto-accompaniment Styles. The accompaniment styles provide the equivalent of a full backing band covering wide variety of styles from waltzes to 8-beat to euro-trance … and much more. Select a style that matches the music you want to play, or experiment with new styles to expand your musical horizons.

DGX-205/203, PSR-295/293 Owner’s Manual

PopBossa

080

Page 9

Panel logos ............................................................................ 6

Supplied Accessories............................................................. 7

Special features of the DGX-205/203, PSR-295/293............. 8

Setting Up 10

Power Requirements ........................................................... 10

Connecting headphones (PHONES/OUTPUT jack) ............ 11

Connecting a footswitch (SUSTAIN JACK).......................... 11

Connecting to a computer (USB terminal) ........................... 11

Turn on the power................................................................ 11

Panel Controls and Terminals 12

Front Panel .......................................................................... 13

Rear Panel........................................................................... 13

Quick Guide

The Easy Way To Play Piano 14

Play With Both Hands.......................................................... 14

Change the Song Tempo..................................................... 17

Play the Demo Song............................................................ 17

Try Playing a Variety Of Instrument Voices 18

Select and Play a Voice – MAIN.......................................... 18

Play Two Voices Simultaneously – DUAL ........................... 19

Play Different Voices With the Left and Right Hands – SPLIT

Play the Grand Piano Voice................................................. 22

Pitch Bend (DGX-205/203 only)........................................... 22

Touch Response.................................................................. 22

Fun Sounds 23

Drum Kits ............................................................................. 23

Sound Effects....................................................................... 23

Styles (Auto Accompaniment) 24

Play Along With Auto Accompaniment – STYLE................. 24

Harmony .............................................................................. 26

A Variety Of Ways To Start and Stop Style Playback.......... 28

Using Songs 30

Select and Listen To a Song................................................ 30

Types Of Songs ................................................................... 31

Select a Song For a Lesson 32

Lesson 1: Waiting ................................................................ 32

Lesson 2: Your Tempo......................................................... 34

Lesson 3: Minus One........................................................... 35

Practice Makes Perfect – Repeat and Learn ....................... 35

Change a Song’s Style 36

Using the Easy Song Arranger ............................................ 36

Record Your Own Performance 38

Track Configuration.............................................................. 38

Recording Procedure........................................................... 39

Song Clear – Deleting User Songs...................................... 41

Track Clear – Deleting a Specified Track From a User Song

Backup and Initialization 42

Backup................................................................................. 42

Initialization .......................................................................... 42

Basic Operation and Displays 43

Basic Operation ................................................................... 43

Display Items ....................................................................... 45

.. 20

... 41

Reference

Handy Performance Features 46

Adding Reverb ..................................................................... 46

Adding Chorus ..................................................................... 47

The Metronome.................................................................... 48

Touch Response Sensitivity................................................. 49

One Touch Setting ............................................................... 49

Adjusting the Voice Parameters........................................... 50

Adjusting the Harmony Volume ........................................... 50

Panel Sustain....................................................................... 50

Style (Auto-accompaniment) Functions 51

Setting the Split Point........................................................... 51

Play Only the Style Rhythm ................................................. 51

Play a Style With Chords but No Rhythm

(Stop Accompaniment) ...................................................52

Adjusting the Style Volume .................................................. 52

Playing Auto-accompaniment Chords.................................. 53

Looking Up Chords Using the Chord Dictionary .................. 55

Song Settings 57

Song Volume ....................................................................... 57

A-B Repeat .......................................................................... 57

Muting Independent Song Parts .......................................... 57

Change the Key Of a Song .................................................. 58

Song Fast Forward, Fast Reverse, and Pause.................... 58

Change the Melody Voice.................................................... 59

Memorize Your Favorite Panel Settings 60

Saving Settings to the Registration Memory........................ 60

Function settings 62

Locating and Editing the Function Settings.......................... 62

Connecting To a Computer 65

What Is MIDI? ...................................................................... 65

USB Connection .................................................................. 66

MIDI Settings ....................................................................... 66

MIDI (PC Mode) Settings For Computer Connection........... 67

Remote Control Of MIDI Devices......................................... 67

Transferring Song Files From a Computer .......................... 68

Accessory CD-ROM Installation Guide 70

CD-ROM Contents............................................................... 70

System Requirements.......................................................... 71

Software Installation............................................................. 71

Appendix

Troubleshooting................................................................. 75

Specifications..................................................................... 77

Voice List ............................................................................ 78

Drum Kit List ...................................................................... 82

Style List ............................................................................ 84

Song List............................................................................. 85

Effect Type List .................................................................. 86

MIDI Implementation Chart ............................................... 87

MIDI Data Format ............................................................... 88

Index.................................................................................... 89

DGX-205/203, PSR-295/293 Owner’s Manual

Page 10

Setting Up

• Use only manganese or alkaline batteries for this instrument. Other types of batteries (including rechargeable batteries) may have sudden drops of power when battery power becomes low, possibly resulting in loss of data in the ﬂash memory.

• Make sure to install the batteries in the same direction, maintaining the correct polarity (as shown). Incorrect battery installation may result in heat, ﬁre and/or leaking of corrosive chemicals.

• When the batteries run down, replace them with a complete set of six new batteries. NEVER mix old and new batteries. Do not use different kinds of batteries (e.g. alkaline and manganese) at the same time.

• If the instrument is not to be in use for a long time, remove the batteries from it, in order to prevent possible ﬂuid leakage from the battery.

• Please use the power adaptor when transferring data to ﬂash memory. Batteries (including rechargeable types) can be drained rapidly by this type of operation. If the batteries do become drained during a data transfer, both the data being transferred and the data currently in the transfer destination will be lost.

Be sure to do the following operations BEFORE turning on the power.

Power Requirements

Although the instrument will run either from an optional AC adaptor or batteries, Yamaha recommends use of an AC adaptor whenever possible. An AC adaptor is more environmentally friendly than batteries and does not deplete resources.

Using an AC Power Adaptor



Make sure that the [STANDBY/ON] switch of the instrument is set to STANDBY.

WARNING

• Use ONLY a Yamaha PA-5D or PA-3C AC Power Adaptor (or other adaptor speciﬁcally recommended by Yamaha) to power your instrument from the AC mains. The use of other adaptors may result in irreparable damage to both the adaptor and the instrument.

■

 Connect the AC adaptor (PA-5D, PA-3C or other

adaptor speciﬁcally recommended by Yamaha) to the power supply jack.

 Plug the AC adaptor into an AC outlet.

CAUTION

• Unplug the AC Power Adaptor when not using the instrument, or during electrical storms.





PA-5D or

PA-3C

AC outlet

For battery operation the instrument requires six 1.5V “D” size, R20P (LR20) or equivalent batteries. (Alkaline batteries are recommended.) When battery power becomes too low for proper operation, the battery exchange indication ﬂashes in the display. As soon as this message appears, make sure to replace all batteries, following the precautions listed below. If necessary, also make sure to save all important User data (see page 42), since custom panel settings are lost when the batteries are removed.

CAUTION

■ Using Batteries

 Open the battery compartment cover located on the

instrument’s bottom panel.

 Insert the six new batteries, being careful to follow

the polarity markings on the inside of the compartment.

 Replace the compartment cover, making sure that it

locks ﬁrmly in place.

NOTE

• Connecting the AC power adaptor automatically supplies power from the adaptor and overrides battery power, even when batteries are installed.

DGX-205/203, PSR-295/293 Owner’s Manual

Page 11

Make all necessary connections BEFORE turning the power on.

• Even when the switch is in the “STANDBY” position, a small amount of electricity is still being consumed by the instrument. When you are not using the instrument for a long time, make sure you unplug the AC power adaptor from the wall AC outlet, and/or remove the batteries from the instrument.

•Never attempt to turn the power off when a “WRITING!” message is shown in the display. Doing so can damage the ﬂash memory and result in a loss of data.

Setting Up

Connecting headphones (PHONES/OUTPUT jack)

The DGX-205/203, PSR-295/293 speakers are automatically shut off when a plug is inserted into this jack.

The PHONES/OUTPUT jack also functions as an external output. You can connect the PHONES/OUTPUT jack to a keyboard ampliﬁer, stereo system, mixer, tape recorder, or other line-level audio device to send the instrument’s output signal to that device.

WARNING

•Avoid listening with the headphones at high volume for long periods of time; doing so may not only result in ear fatigue, it may be damaging to your hearing.

CAUTION

•To prevent damage to the speakers, set the volume of the external devices at the minimum setting before connecting them. Failure to observe these cautions may result in electric shock or equipment damage. Also, be sure to set the volumes of all devices at their minimum levels and gradually raise the volume controls while playing the instrument to set the desired listening level.

Connecting to a computer (USB terminal)

Connect the instrument’s USB terminal to the USB terminal of a computer, and you can transfer performance data and song ﬁles between the two (page 66). To use the USB data-transfer features you’ll need to do the following:

• Connect the USB terminal of the computer to the USB terminal on the instrument using a standard USB cable.

• Install the USB MIDI driver on your computer.

Installation of the USB MIDI driver is described on page 71. With this capability you can, for example, use the Musicsoft Downloader software provided on the supplied CD-ROM to transfer songs from your computer to the instrument’s ﬂash memory.

NOTE

• Make sure to purchase a quality USB cable at a musical instrument store, computer store or electrical appliance store.

Turn on the power

Connecting a footswitch (SUSTAIN JACK)

The sustain function lets you produce a natural sustain as you play by pressing an optional footswitch. Plug the Yamaha FC4 or FC5 footswitch into this jack and use it to switch sustain on and off.

NOTE

• Make sure that the footswitch plug is properly connected to the SUSTAIN jack before turning on the power.

• Do not press the footswitch while turning the power on. Doing this changes the recognized polarity of the footswitch, resulting in reversed footswitch operation.

Turn down the volume by turning the [MASTER VOLUME] control to the left and press the [STANDBY/ON] switch to turn on the power. Pressing the switch again turns the power off.

Backup data in the ﬂash memory (page 42) is loaded to the instrument when the power is turned on. If no backup data exists on ﬂash memory, all instrument settings are restored to the initial factory defaults when the power is turned on.

CAUTION

DGX-205/203, PSR-295/293 Owner’s Manual 11

Page 12

Panel Controls and Terminals

001

GrandPno

092 001

DGX-205/203

Song Category List

(pages 31, 85)

PSR-295/293

Style Category List

(page 84)

@4 @5 @6 @7 @8 @9

Display

(page 45)

Song Category List

(pages 31, 85)

DGX-205/203, PSR-295/293

Style Category List

(page 84)

@4 @5 @6 @7 @8 @9

i o

Display

(page 45)

GrandPno

001

092 001

#3 #4 #5 #6

12 DGX-205/203, PSR-295/293 Owner’s Manual

Page 13

Panel Controls and Terminals

Front Panel

Voice Category List

(page 78)

#0 #1

Voice Category List

(page 78)

q [STANDBY/ON] switch ..................................... page 11

w [MASTER VOLUME] control..................... pages 11, 15

e [TOUCH] button .......................................... page 22, 49

r [HARMONY] button .......................................... page 26

t [DUAL] button ................................................... page 19

y [SPLIT] button................................................... page 20

u [DEMO] button .................................................. page 17

i [LESSON MODE] button .................................. page 33

o [LESSON L/R] button ....................................... page 32

!0 [LESSON REPEAT & LEARN] button.............. page 35

!1 [PERFORMANCE ASSISTANT] button............ page 14

!2 [FUNCTION] button .......................................... page 62

!3 [PC] button ........................................................ page 67

!4 [METRONOME] button ..................................... page 48

!5 [PORTABLE GRAND] button ...........................page 22

!6 Dial............................................................. pages 44, 62

!7 CATEGORY buttons [ ], [ ] .................. pages 44, 62

!8 [SONG] button .................................................. page 30

!9 [EASY SONG ARRANGER] button.................. page 36

@0 [STYLE] button ................................................. page 24

@1 [VOICE] button.................................................. page 18

@2 Number buttons [0] – [9],

[+] and [-] buttons..................................... pages 44, 62

@3 [ACMP ON/OFF] / [ ] button .......... pages 24, 57

@4 [SYNC STOP] button ........................................ page 28

@5 [SYNC START] / [ ] button..................... pages 25, 58

❙ ❙

@6 [INTRO/ENDING/rit.] / [ ] button .......... pages 25, 58

@7 [MAIN/AUTO FILL] / [ ] button ............. pages 26, 58

@8 [START/STOP] / [ ] button........... pages 24, 30, 44

>>>>/ ■

@9 [TEMPO/TAP] button ........................................page 17

#0 REGIST. MEMORY

[●] (MEMORY/BANK), [1], [2] buttons............. page 60

#1 SONG MEMORY

[REC], [1] – [5], [A] buttons.............................. page 39

#2 PITCH BEND wheel (DGX-205/203 only)......... page 22

#0 #1

Rear Panel

#3 USB terminal............................................. pages 11, 66

#4 SUSTAIN jack .................................................... page 11

#5 PHONES/OUTPUT jack..................................... page 11

#6 DC IN 12V jack .................................................. page 10

DGX-205/203, PSR-295/293 Owner’s Manual 13

Page 14

The Easy Way To Play Piano

Quick Guide

This instrument includes a performance assistant technology feature that lets you play along with a song and sound like a great pianist (even though you might be making lots of mistakes)! In fact, you can play any notes and still sound good! So even if you can’t play piano and can’t read a note of music, you can have some musical fun.

The secret to the performance assistant technology’s ability to turn random playing into music is divulged on page 16. Enjoy the feature for a while ﬁrst, then read about how its done.

Play With Both Hands

To use the performance assistant technology you must be playing a song that includes chord data.

Press the [SONG] button.

The song number and name will be displayed. You can use the dial or other selection controls to select a different song.

NOTE

•For details on Chords, see pages 53, 54.

DontKnow

001

Select a song.

Rotate the dial and watch the displayed song names – for this example we’ll select song “026 Twinkle Star.”

Twinkle

026

The song displayed here will be played.

Press the [PERFORMANCE ASSISTANT] button.

This turns on the performance assistant technology feature. Icon will appear after displaying “PERFORMANCE ASSISTANT”.

Song name

Song number

NOTE

• MIDI songs included on the supplied Accessory CD-ROM can also be transferred to the instrument and used with the performance assistant technology. (page 16, 68)

14 DGX-205/203, PSR-295/293 Owner’s Manual

Page 15

The Easy Way To Play Piano Quick Guide

Twinkle

026

Press the [PERFORMANCE ASSISTANT] button to turn the function on or off.

Press the [START/STOP] button.

Icon will appear when performance assistant technology is on.

Song playback will begin. Use the [MASTER VOLUME] control to adjust the overall volume.

Play on the keyboard.

To begin, try to feel the rhythm of the song. Then, with your hands spread as shown in the illustration, simply play the keyboard alternately with your left and right hands (any notes will do).

Sounds like you’re playing the right notes!

Adjust volume

You will get even better results if you match your left-hand rhythm to the rhythm of the chord indicator in the display.

How does it sound? You’ll get acceptable results no matter where you play thanks to performance assistant technology!

Next try the three playing methods illustrated below. Different ways of playing produce different results.

● Play with the left and right hands at the same timing – type 1.

Play 3 notes at once with your right hand.

● Play with the left and right hands at the same timing – type 2.

Play 1 note at a time with your right hand (for example: index ﬁnger middle ﬁnger

→

ring ﬁnger).

→

● Play alternately with the left and right hands – type 3.

Once you get a feel for it, try playing chords with your left hand and a melody with your right … or any other combination.

Song playback will stop automatically when the song has played all the way through. You can also stop playback at any time by pressing the [START/STOP] button. When you want to end performance assistant technology operation press the [PERFORMANCE ASSISTANT] button.

DGX-205/203, PSR-295/293 Owner’s Manual 15

Play 3 notes at once with your right hand.

Page 16

Quick Guide The Easy Way To Play Piano

— The Secret Of performance assistant technology —

How It Creates Music From Random Notes

Performance assistant technology reads the chord data from the song and only assigns notes that will “work” at that moment to the keyboard. Since the chords of a song are constantly changing, different notes and chords will be produced even if you repeatedly play the same keys.

Song

• Melody data

• Chord data

• Rhythm data

Playback

performance assistant

technology

Chord tones and other usable notes are assigned to the keyboard.

You produce a harmonious group of notes no matter where you play.

● Songs That Can Be Used With the performance assistant technology

Performance assistant technology can only be used with songs that include chord data. Preset Songs can be used with performance assistant technology since the songs include chord data.

● External Songs and the performance assistant technology

In addition to the instrument’s internal songs, the 70 songs provided on the Accessory CD-ROM (page 70) can be used with performance assistant technology. A list of the MIDI songs included on the Accessory CD-ROM is provided on page 85. Songs downloaded from the Internet can also be used with performance assistant technology as long as they include the required chord data. Transfer song ﬁles you want to use from your computer to the instrument’s ﬂash memory (page 68).

16 DGX-205/203, PSR-295/293 Owner’s Manual

Page 17

The Easy Way To Play Piano Quick Guide

Change the Song Tempo

When using the performance assistant technology or in other situations in which the tempo of the song is too fast or too slow for you, you can change the tempo as required. Press the [TEMPO/TAP] button. The tempo display will appear and you can use the dial, the [+] and [-] buttons, or the [0] – [9] number buttons to set to tempo to anywhere from 032 and 280 quarter-note beats per minute.

Tempo

090

Current Tempo value

You can also set the tempo by simply tapping the [TEMPO/TAP] button at the required tempo – 4 times for time signatures in 4, and three times for time signatures in 3. You can change the tempo during song playback by pressing the button just twice.

090 001

You can return to the original tempo by simultaneously pressing the [+] and [-] buttons.

About the Beat Display

The arrow marks in the beat display ﬂash in time with the rhythm of the song or style.

First beat of measure Third beat

Second beat Fourth beat

Play the Demo Song

DGX-205/203 and PSR-295/293 are packed with a total of 30 songs, including three Demo songs – listen to some of the outstanding instrument voices provided! You can use the performance assistant technology with the demo songs.

Press the [DEMO] button.

The demo songs will start playing. The song playback sequence will repeat: 001

→

002 → 003 → 001 ...

You can stop demo playback at any time by pressing the [START/STOP] button.

DontKnow

001

DGX-205/203, PSR-295/293 Owner’s Manual 17

Page 18

Try Playing a Variety Of Instrument Voices

In addition to piano, organ, and other “standard” keyboard instruments, this instrument has a large range of voices that includes guitar, bass, strings, sax, trumpet, drums and percussion, sound effects … a wide variety of musical sounds.

Select and Play a Voice – MAIN

This procedure selects the main voice you will play on the keyboard. The voice is known as the “main voice.”

Press the [VOICE] button.

The voice number and name will be displayed. You can use the dial or other selection controls to select a different song.

GrandPno

001

Select the voice you want to play.

While watching the displayed voice name rotate the dial. The available voices will be selected and displayed in sequence. The voice selected here becomes the main voice. For this example select the 090 Flute voice.

Play the keyboard.

Flute

090

Select 090 Flute

voice name

voice number

NOTE

•You can also select the voice using the CATEGORY button [ ], [ ] after pressing the

[VOICE] button.

Try selecting and playing a variety of voices.

18 DGX-205/203, PSR-295/293 Owner’s Manual

Page 19

Try Playing a Variety Of Instrument Voices Quick Guide

Play Two Voices Simultaneously – DUAL

You can select a second voice which will play in addition to the main voice when you play the keyboard. The second voice is known as the “dual” voice.

Press the [DUAL] button.

The [DUAL] button turns the dual voice on or off. When turned on the dual voice icon will appear in the display. The currently selected dual voice will sound in addition to the main voice when you play the keyboard.

NOTE

• The dual voice feature cannot be used during a song lesson (page 32).

Flute

090

Dual voice icon

Press and hold the [DUAL] button for longer than a second.

“D. VOICE” appears in the display for a few seconds, then the currently selected dual voice will be displayed.

Marimba

108

Hold for longer than a second

Select the desired dual voice.

Watch the displayed dual voice and rotate the dial until the voice you want to use is selected. The voice selected here becomes the dual voice. For this example try selecting the 107 Vibraphone voice.

The currently selected dual voice

NOTE

•You can also select the Dual Voice display by pressing the [FUNCTION] button and then using the CATEGORY buttons to select the “D.Voice” item.

Vibes

107

DGX-205/203, PSR-295/293 Owner’s Manual 19

Page 20

Quick Guide Try Playing a Variety Of Instrument Voices

Play the keyboard.

Tw o voices will sound at the same time.

Try selecting and playing a range of dual voices.

Play Different Voices With the Left and Right Hands – SPLIT

In the split mode you can play different voices to the left and right of the keyboard “split point.” The main and dual voices can be played to the right of the split point, while the voice played to the left of the split point is known as the “split voice”. The split point setting can be changed as required (page 51).

Split point

Main voice and dual voiceSplit voice

Press the [SPLIT] button.

The [SPLIT] button turns the split voice on or off. When turned on the split voice icon will appear in the display. The currently selected split voice will sound to the left of the keyboard split point.

Flute

090

Press and hold the [SPLIT] button for longer than a second.

“S. VOICE” appears in the display for a few seconds, then the currently selected split voice will be displayed.

NOTE

• The split voice feature cannot be used during a song lesson (page 32).

Split voice icon

NOTE

•You can also select the Split Voice display by pressing the [FUNCTION] button and then using the CATEGORY buttons to select the “S.Voice” item.

Hold for longer than a second

20 DGX-205/203, PSR-295/293 Owner’s Manual

FngrBass

041

The currently selected SPLIT voice

Page 21

Try Playing a Variety Of Instrument Voices Quick Guide

Select the desired split voice.

Watch the displayed split voice and rotate the dial until the voice you want to use is selected. The voice selected here becomes the split voice which will play to the left of the keyboard split point. For this example try selecting the 031 Folk Guitar voice.

Folk Gtr

031

Play the keyboard.

Try selecting and playing a range of split voices.

DGX-205/203, PSR-295/293 Owner’s Manual 21

Page 22

Quick Guide Try Playing a Variety Of Instrument Voices

Play the Grand Piano Voice

When you just want to play piano, all you have to do is press one convenient button.

Press the [PORTABLE GRAND] button.

The “001 Grand Piano” voice will be selected.

NOTE

• When you press the [PORTABLE GRAND] button all settings other than touch sensitivity are turned off. The dual and split voices will also be turned off, so only the Grand Piano voice will play over the entire keyboard.

Pitch Bend (DGX-205/203 only)

The pitch bend wheel provided on the DGX-205/203 can be used to add smooth pitch variations to notes you play on the keyboard. Roll the wheel upward to raise the pitch, or downward to lower the pitch. If you use this feature with a voice such as the “038 Overdriven” guitar voice (page 18), you can produce remarkably realistic string-bending effects.

Touch Response

When touch response is on you can control the volume of notes according to how hard you play the keys – much like a real piano responds to subtle touch nuances. When touch response is off the same volume will be produced no matter how hard you play the keys.

Press the [TOUCH] button.

The [TOUCH] button turns touch response on or off. Touch response is normally on. When touch response is on the touch response icon will appear in the display.

NOTE

•Touch response sensitivity can be adjusted in three steps – page 49.

GrandPno

001

22 DGX-205/203, PSR-295/293 Owner’s Manual

Touch response icon

Page 23

Fun Sounds

This instrument includes a range of drum kits and unique sound effects you can use for entertainment. Laughter, babbling brooks, jet ﬂy-bys, eerie effects, and much more. These sounds can be a great way to enhance the mood at parties.

Drum Kits

Drum kits are collections of drum and percussion instruments. When you select a violin or other normal instrument main voice, for example, all keys produce the sound of the same violin, only at different pitches. If you select a drum kit as the main voice, however, each key produces the sound of a different drum or percussion instrument.

◆

Drum Kit Selection Procedure ➔ (refer to steps 1 and 2 on page 18)

Press the [VOICE] button.

Use the dial to select “115 Std.Kit1”.

Try out each key and enjoy the drum and percussion sounds!

Don’t forget the black keys! You’ll hear a triangle, maracas, bongos, drums … a comprehensive variety of drum and percussion sounds. For details on the instruments included in the drum kit voices (voice numbers 115 – 126), see the “Drum kit List” on page 82.

Sound Effects

The sound effects are included in the drum kit voice group (voice numbers 125 and 126). When either of these voices are selected you will be able to play a range of sound effects on the keyboard.

◆ Sound Effect Selection Procedure ➔ (refer to steps 1 and 2 on page 18)

Press the [VOICE] button from the MAIN display.

Use the dial to select “126 SFX Kit2”.

Try out each key and enjoy the sound effects!

As you try out the various keys you’ll hear the sound of a submarine, a telephone bell, a creaking door, laughter, and many other useful effects. “125 SFX Kit1” includes lightning, running water, dogs barking, and others. Some keys do not have assigned sound effects, and will therefore produce no sound. For details on the instruments included in the SFX kit voices, see “SFX Kit 1” and “SFX Kit 2” in the “Drum kit List” on page 83.

DGX-205/203, PSR-295/293 Owner’s Manual 23

Page 24

Styles (Auto Accompaniment)

This instrument includes an auto-accompaniment feature that plays appropriate “styles” (rhythm + bass + chord accompaniment) when you play left-hand chords. 135 different styles covering a wide range of musical genres are provided (see page 84 for a complete style list). Here’s how you can use the auto-accompaniment feature.

Play Along With Auto Accompaniment – STYLE

Press the [STYLE] button.

The currently selected style number and name will be displayed. You can now use the dial to select the desired style

Select a style.

Use the dial to select a style. For this example try selecting the “080 PopBossa” style.

Press the [START/STOP] button.

Rhythm-only playback of the selected style will begin.

Press the [START/STOP] button again.

The style rhythm will stop.

8BtModrn

001

PopBossa

080

Style rhythm start!

The currently selected style number and name

NOTE

• Since style number 112 and the pianist category styles (124 –

135) have no rhythm parts, no sound will be produced if you start rhythm-only playback. To use these styles turn on the auto-accompaniment and play on the keyboard as described on page 28 (the bass and chord accompaniment parts will sound).

Press the [ACMP ON/OFF] button.

This turns auto-accompaniment on. Check that “ACMP ON” appears in the display.

PopBossa

080

“ACMP ON” appears when auto-accompaniment is on.

24 DGX-205/203, PSR-295/293 Owner’s Manual

NOTE

• If “ACMP ON” is not showing in the display press the [ACMP ON/OFF] button so that it appears. The [ACMP ON/OFF] button alternately turns autoaccompaniment on and off.

Page 25

Styles (Auto Accompaniment) Quick Guide

● When Auto-accompaniment Is On …

The left-hand section of the keyboard becomes the “accompaniment range” in which you will play the chords that deﬁne the accompaniment.

Split point

Accompaniment range

If you press the [START/STOP] button at this point rhythm-only playback will begin. Then if you play a chord in the accompaniment range bass and chord accompaniment will also begin. You can start style playback in a number of ways – see page 28.

Press the [INTRO/ENDING/rit.] button.

“INTRO→A” or “INTRO→B” will appear in the display. Style playback will then start with an introduction, which will lead to either the MAIN A or MAIN B accompaniment pattern, accordingly.

INTRO≥B

NOTE

• The auto-accompaniment range of the keyboard can be changed as required by changing the split point (page 51).

Press the [SYNC START] button.

The beat display will begin ﬂashing, indicating that the synchro-start standby mode has been engaged.

PopBossa

080

● The Synchro-start Standby Mode Is …

When the synchro-start standby mode is engaged style playback will begin as soon as you play a chord in the accompaniment range of the keyboard. You can disengage the synchro-start standby mode by pressing the [SYNC START] button again.

Start style playback by playing a chord in the accompani-

ment range of the keyboard.

Not sure how to play chords? No problem! This instrument is capable of playing chords even if you only play one key – refer to page 53 for detailed instructions for playing chords. There’s even a “Chord Dictionary” that will show you the ﬁngerings for chords you specify by name (page 55).

Synchro-start standby mode

Split point

Accompaniment range

Style start

DGX-205/203, PSR-295/293 Owner’s Manual 25

Page 26

Quick Guide Styles (Auto Accompaniment)

Play along with the style.

Play a melody with right hand while playing cords in the accompaniment range of the keyboard with your left hand. The beat display will ﬂash at the current playback tempo.

Accompani-

ment range

Chords

Each style has two main patterns – MAIN A and MAIN B. If you press the [MAIN/AUTO FILL] button during playback a ﬁll-in will play and then playback will switch to the other MAIN pattern.

● An example of how you might play a pattern:

Melody

PopBossa

080

Flashes at the current tempo

INTRO A MAIN A FILL B MAIN B ENDING

Press the [INTRO/ENDING/rit.] button to end.

Style playback will stop after an appropriate ending.

Style stopStyle preparation

ENDING

Harmony

This feature adds harmony notes to the main voice. When you press the [HARMONY] button to turn this feature on, the appropriate harmony type for the currently selected main voice is automatically selected. 26 different harmony types are provided. You can select a different harmony type by following the procedure outlined below. The effect and operation of each harmony type is different – refer to the Harmony Type List on page 86 for details.

Press the [HARMONY] button.

The [HARMONY] button turns the harmony feature on and off. When harmony is on the harmony icon will appear in the display.

GrandPno

001

26 DGX-205/203, PSR-295/293 Owner’s Manual

NOTE

• Harmony cannot be turned on or off during a song lesson.

Harmony icon

Page 27

Styles (Auto Accompaniment) Quick Guide

Press and hold the [HARMONY] button for longer than a second.

“HarmType” appears in the display for a few seconds, and the currently selected harmony type will be displayed. Use the dial to select a different harmony type.

NOTE

•You can also select the Harmony Type item after pressing the [FUNCTION] button (page

62).

The currently selected harmony type

Select a harmony type.

Hold for longer than a second

Trio

Rotate the dial to select a harmony type from 01 through 26. Select “03 (Block)” for this example.

Block

“03 (Block)” selected

Perform steps 1, 2, 3, and 5 on page 24.

Auto-accompaniment will be on. Check that “ACMP ON” appears in the display. If “ACMP ON” is not showing in the display press the [ACMP ON/OFF] button so that it appears.

NOTE

• Harmony types 01 – 05 only function when auto-accompaniment is on and a style is being played. Harmony notes are added to the right-hand melody based on the chords played in the accompaniment range of the keyboard.

• Harmony types 06 – 26 can be used when auto-accompaniment is off. After step 4, try playing these harmony types after checking the operating conditions listed in the Harmony type list on page 86.

PopBossa

080

Play a chord in the accompaniment range of the keyboard.

Style playback will begin.

Split point

Accompaniment range

Play the keyboard.

Harmony notes will be added to a melody you play in the right-hand section of the keyboard.

Accompaniment range

Melody

“ACMP ON” appears

NOTE

• The Harmony feature produces little or no effect with drum kit or sound effect voices. Use the Harmony feature with pitched instrument voices.

DGX-205/203, PSR-295/293 Owner’s Manual 27

Page 28

■

●

Quick Guide Styles (Auto Accompaniment)

A Variety Of Ways To Start and Stop Style Playback

Ways To Start Style Playback

● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ●

There are four different ways to start style playback, listed below. In all cases you will need to press the [ACMP ON/OFF] button to turn auto-accompaniment on before actually starting style playback. Whichever method you choose, you can press the [INTRO/ENDING/rit.] before starting playback. To begin your performance, an introduction will play automatically, then will automatically switch to the MAIN section when ﬁnished.

Immediate Start

Press the [START/STOP] button to begin rhythm-only playback of the selected style. The bass and chords will begin playing as soon as you play a chord in the accompaniment range of the keyboard.

Immediate start

Chord Start

Press the [SYNC START] button and the beat display will begin ﬂashing, indicating that the synchro start “standby” mode has been engaged. The style will begin playing as soon as you play a chord in the accompaniment range of the keyboard.

Accompani-

ment range

Style playback begins

8BtModrn

when you play a chord

001

Synchro-start standby

Synchro Stop

When this function is selected the accompaniment style will only play while you are playing chords in the accompaniment range of the keyboard. Style playback will stop when you release the keys. Press the [SYNC STOP] button. The synchro-start standby mode will be engaged and the beat display will begin ﬂashing. Style playback will begin as soon as you play a chord in the accompaniment range of the keyboard, but then style playback will stop (the synchro start standby mode will be re-engaged) when you release the left-hand keys. Style playback will continue only while you are actually playing in the keyboard’s accompaniment range.

Accompani-

ment range

8BtModrn

001

The style will play while you are playing the keys

Style playback will stop when you release the keys

Synchro-stop indicator

Synchro-start standby

Press the [SYNC STOP] button to disengage the synchro-stop mode.

DGX-205/203, PSR-295/293 Owner’s Manual

Page 29

Styles (Auto Accompaniment) Quick Guide

● Tap Start

You can supply a count-in at any tempo you like to start playback. Simply tap the [TEMPO/TAP] button at any tempo – 4 times for time signatures in 4, and 3 times for time signatures in 3 – and the selected style will begin playing at the tapped tempo.

Start at the tapped tempo

■ Ways To Stop Style Playback ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ●

The following three methods can be used to stop style playback.

● Immediate Stop

Playback will stop as soon as you press the [START/STOP] button.

Immediate stop

● Stop and Enter Synchro Start Mode

If you press the [SYNC START] button during style playback, playback will stop immediately and the synchro-start standby mode will be engaged (the beat display will ﬂash).

Stop immediately and enter the Synchro Start mode

● Play the Ending and Stop

Press the [INTRO/ENDING/rit.] button to begin playing ending section. Playback will stop when the ending has played all the way through.

Stop after ending plays

If you press the [INTRO/ENDING/rit.] button a second time (while the ending is playing) the ending will play ritardando (the tempo will gradually get slower).

8BtModrn

001

Synchro-start standby

■ Changing the Voice ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ●

During style playback the voice you play on the keyboard is the currently selected main/dual/split voices. Select an appropriate voice for the style you are using in the normal way (page 18).

DGX-205/203, PSR-295/293 Owner’s Manual 29

Page 30

Using Songs

This instrument has 30 built in songs that you can simply listen to and enjoy, or use with a range of other features. Use the songs with the lesson features described on page 32 and you have an advanced learning tool that will let you learn playing techniques. The internal songs aren’t the only ones you can use, however. Songs you have downloaded from the Internet can also be used with many of the instrument’s features.

The term “SONG” refers to a data ﬁle including both melody and auto-accompaniment data.

Select and Listen To a Song

Press the [SONG] button.

The song number and name will be displayed. You can now use the dial to select a different song.

Twinkle

026

The currently selected song and number are displayed

Select a song.

Select a song after referring to the preset song category list on page 31. Rotate the dial to select the song you want to listen to.

DontKnow

001

The song displayed here can be played

Listen to the song.

Press the [START/STOP] button to begin playback of the selected song. You can stop playback at any time by pressing the [START/STOP] button again.

NOTE

• In addition to the dial you can also use the [+] and [-] buttons or the number buttons [0] – [9] to directly select songs.

•You can also listen to songs you have recorded yourself (page

38) and songs transferred from computer into the instrument’s ﬂash memory (page 68).

30 DGX-205/203, PSR-295/293 Owner’s Manual

Song start!

Page 31

Using Songs Quick Guide

Types Of Songs

The following three types of songs can be used by the DGX-205/203 and PSR-295/293.

● Preset Songs (the 30 songs built into the instrument)................ Song numbers 001 – 030.

● User Songs (recordings of your own performances) .................. Song numbers 031 – 035.

● External song ﬁles (song data transferred from a computer*) ... Song numbers 036 –.

* The Accessory CD-ROM includes a selection of 70 MIDI songs. See page 68 for instructions on how to

transfer the songs to the instrument.

The different types of songs can be saved to different song numbers. The chart below shows the basic DGX-205/203 and PSR-295/293 processes ﬂow for using the preset songs, user songs, and external song ﬁles – from storage to playback.

Computer

Your own performance External song ﬁle

DGX-205/203, PSR-295/293 Song Storage locations

Preset Songs

(001 – 030)

The 30 songs built into the instrument.

Record

(page 39)

User Songs

(031 – 035)

Stored in the internal ﬂash memory.

Play

Transfer

(page 68)

Flash Memory

(036 – 134)

Save to internal ﬂash memory. Currently available.

External song ﬁles can be saved to ﬂash memory (036 –).

NOTE

• Different ﬂash memory areas are used to store user songs and external song ﬁles transferred from a computer. User songs cannot be directly transferred to the external song ﬁle ﬂash memory area, and vice versa.

● Preset Song Categories

The 30 preset songs have been organized into 8 categories that make it easier to select appropriate songs for lessons. Refer to this chart when selecting songs.

Category Number Ideal for …

Favorites 001 – 003 Popular songs, for people who want to play pops. Easy Play 004 – 008 Right-hand melody songs. Ideal for beginner lessons.

Pianist 009 – 013

Organist 014 – 016 Players who enjoy the rich resonance of organ pieces. Advanced 017 – 021 Lively tunes … when it’s time to move up from one-hand lessons. Band Play 022 – 024 Slow ballads. Experience the role of the pianist in an ensemble. Duet 025 – 027 Songs made up of two right-hand melodies. Holidays 028 – 030 Songs for anyone who wants to expand their repertoire.

Folk songs arranged for piano. For people who want to play in a classic style.

DGX-205/203, PSR-295/293 Owner’s Manual 31

Page 32

Select a Song For a Lesson

Yamaha Education Suite 4

You can select any song you like and use it for a left-hand, right-hand, or both-hands lesson. You can also use songs (only SMF format 0) downloaded from the Internet and saved to ﬂash memory. During the lesson you can play as slowly as you like, and you can even play wrong notes. Song playback will slow down to a speed you can handle. It’s never too late to start learning!

The lesson procedure is as follows:

Select the song you want to learn. (Refer to the category list on page 31)

Select the part you want to work on

(right hand, left hand, both hands)

Select lesson 1, 2, or 3. (Refer to step 3 on page 33)

● Lesson 1 ...........(Learn to play the correct notes): The song will wait until you play the right note.

● Lesson 2 ...........(Learn to play the correct notes with the correct timing): Song playback tempo will vary to match the speed

you are playing at. The song will slow down when you play wrong notes, so you can learn at your own pace.

● Lesson 3 ...........(Learn to play the correct notes at the correct timing along with the song): here’s where you can perfect your

technique.

Only songs in SMF Format 0 can be used for practice. You need to specify which channels are to be played back as the right/left-hand parts when you practice using songs downloaded from the Internet (page 69).

➞ ➞

(Refer to step 2 below)

Lesson 1: Waiting

Select a song for your lesson.

Press the [SONG] button so that the song number and name are displayed. Use the dial to select the song you want to use for your lesson. As listed on page 31 there are a variety of song types. For this example select “011 Londonderry Air” from the “PIANIST” category (009 – 013).

NOTE

• Song numbers 004 – 008 (Simple melodies) are intended for use as right-hand lessons, and cannot be used for left-hand or both-hands lessons.

Londonde

011

Select the part you want to practice.

Press the [LESSON L/R] button to select the part you want to practice. Each time you press the [LESSON L/R] button the parts are selected in sequence: right hand → left hand → both hands → right hand …. The currently selected part is shown in the display.

Right

Left

BothHand

32 DGX-205/203, PSR-295/293 Owner’s Manual

Right-hand lesson

Left-hand lesson

Both-hands lesson

Page 33

Select a Song For a Lesson Quick Guide

Use the [LESSON MODE] button to select Lesson 1.

Press the [LESSON MODE] button to select Lesson 1. Each time the [LESSON MODE] button is pressed the lesson modes are selected in sequence: Lesson 1 ➔ Lesson 2 ➔ Lesson 3 ➔ Off ➔ Lesson 1 …. The currently selected mode is shown in the display.

Waiting

(Lesson 1)

NOTE

• What the upper-right-corner displays mean:

Right

Left

Hand

Both

hands

Lesson 1 r1 L 1 Lr1

Hand

Lesson 2 r2 L 2 Lr2 Lesson 3 r3 L 3 Lr3

YourTemp

MinusOne

Londonde

011

(Lesson 2)

(Lesson 3)

(Song Lesson off)

Song playback will begin automatically when you select Lesson 1.

Start the lesson!

Play the note shown in the display. When you play the correct note, the next note you need play is shown. The song will wait until you play the correct note.

Waiting

057 007

Left-hand part Right-hand part

(In the case of a right-hand lesson)

DGX-205/203, PSR-295/293 Owner’s Manual 33

Page 34

Quick Guide Select a Song For a Lesson

■ See How You’ve Done● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ●

Excellent

Very Good Good OK

The evaluation will appear after you have played all the way through the song. After the evaluation display has appeared, the lesson will start again from the beginning. Press the [START/STOP] button to exit from the lesson mode.

Once you’ve mastered Lesson 1, move on to Lesson 2.

~~~~~~~~ ~~~~~~ ~~~~ ~~

When the lesson song has played all the way through your performance will be evaluated in 4 levels: OK, Good, Very Good, or Excellent. “Excellent” is the highest evaluation.

Lesson 2: Your Tempo

Select the song and part you want to practice (steps 1 and

2 on page 32).

Press the [LESSON MODE] button twice to start Lesson 2.

Each time the [LESSON MODE] button is pressed the lesson modes are selected in sequence: Lesson 1 → Lesson 2 → Lesson 3 → Off → Lesson 1 …

NOTE

• The evaluation feature can be turned off via the FUNCTION Grade item (page 64).

YourTemp

Song playback will begin automatically when Lesson 2 is selected.

Play the note shown in the display. Try to play the notes at the correct timing. As you learn to play the right notes at the right timing the tempo will increase until eventually you’ll be playing at the song’s original tempo.

Left-hand part Right-hand par t

The evaluation display will appear when the song has played all the way through. Press the [START/STOP] button to exit from the lesson mode.

Start the lesson!

(In the case of a right-hand lesson)

In this case the icons “r2” indicate that right-hand lesson 2 has been selected.

Once you’ve mastered Lesson 2, move on to Lesson 3.

34 DGX-205/203, PSR-295/293 Owner’s Manual

Page 35

Select a Song For a Lesson Quick Guide

Lesson 3: Minus One

Select the song and part you want to practice (steps 1 and

2 on page 32).

Press the [LESSON MODE] button three times to start Lesson 3.

Each time the [LESSON MODE] button is pressed the lesson modes are selected in sequence: Lesson 1 → Lesson 2 → Lesson 3 → Off → Lesson 1 …

MinusOne

Song playback will begin automatically when Lesson 3 is selected.

Start the lesson!

In this case the icons “r3” indicate that right-hand lesson 3 has been selected.

The song will play at the normal tempo, minus the part you have chosen to play. Play along while listening to the song.

Left-hand part Right-hand part

(In the case of a right-hand lesson)

The evaluation display will appear when the song has played all the way through. Press the [START/STOP] button to exit from the lesson mode.

Practice Makes Perfect – Repeat and Learn

Use this feature when you want to start again just ahead of a section on which you made a mistake, or to repeatedly practice a section you ﬁnd difﬁcult.

Press the [LESSON REPEAT & LEARN] button during a lesson.

The song location will move back four measures from the point at which you pressed the button, and playback will begin after a one-measure count-in. Playback will continue up to the point at which you pressed the [LESSON REPEAT & LEARN] button, and then jump back four measures and begin again after a count-in. This process will repeat, so all you have to do is press [LESSON REPEAT & LEARN] when you make a mistake in order to repeat practice of that section until you get it right.

Song playback direction

Jump back 4 measures and repeat playback

Press immediately

Oops!

A mistake!

NOTE

•You can change the number of measures the Repeat and learn function jumps back by pressing a number button [0] – [9] during

DGX-205/203, PSR-295/293 Owner’s Manual 35

repeat playback.

Page 36

Change a Song’s Style

In addition to each song’s default style, you can select any other style to play the song with the Easy Song Arranger feature. This means that you can play a song that is normally a ballad, for example, as a bossa nova, as a hip-hop tune, etc. Since songs are combinations of a melody and a style, you can create totally different arrangements by changing the style with which a song is played. You can also change the song’s melody voice and the keyboard voice for a complete change of image.

Using the Easy Song Arranger

Press the [EASY SONG ARRANGER] button.

The song number and name will be displayed. You can now use the dial to select a different song.

Londonde

011

Select a song.

Use the dial to select the song you want to arrange. For this example select “004 Down By The River.”

Riversid

004

Listen to the song.

Press the [START/STOP] button to begin playback of the song. Move on to the next step while the song is playing.

Song start!

The currently selected song number and name

NOTE

• When playing song numbers 022 – 024 while using the Easy Song Arranger, melody tracks will be automatically muted and no melody will sound. In order to hear the melody tracks you will need to press the SONG MEMORY buttons [3] – [5].

Press the [EASY SONG ARRANGER] button.

The style number and name will be displayed. You can now use the dial to select a different style.

PopShf 1

012

36 DGX-205/203, PSR-295/293 Owner’s Manual

The currently selected style number and name

Page 37

Change a Song’s Style Quick Guide

Select a style.

Rotate the dial and listen to how the song sounds with different styles. As you select different styles the song will remain the same while only the styles change. When you have selected a suitable style move on to the next step while the song is still playing (if you have stopped the song, start it again by pressing the [START/STOP] button).

TchPolis

031

Press the [VOICE] button.

The currently selected voice number and name will be displayed. You can now use the dial to select a different voice.

NOTE

• Because the Easy Song Arranger uses song data you can’t specify chords by playing in the accompaniment range of the keyboard. The [ACMP ON/ OFF] button will not function.

• If the time signature of the song and style are different, the time signature of the song will be used.

GrandPno

001

Select a voice.

Rotate the dial until the voice you want to use is selected.

Press and hold the [VOICE] button for longer than a second.

After MELODY VOICE CHANGE appears on the display the voice you selected in step 7 becomes the song’s melody voice.

MELODY V

The currently selected voice number and name

Hold for longer than a second

DGX-205/203, PSR-295/293 Owner’s Manual 37

Page 38

Record Your Own Performance

You can record up to 5 of your own performances and save them as user songs 031 through 035. You can also record performances using the performance assistant technology feature.

■ Recordable Data

You can record to a total of 6 tracks: 5 melody tracks and 1 style (chord) track. Each track can be recorded individually.

● Melody Track [1] – [5].................. Record the melody parts.

● Style Track [A] ............................. Records the chord part.

● Data Recorded On the Melody Tracks [1] – [5]

• Note on/off (keys pressed and released)

•Velocity (keyboard dynamics)

•Voice number

•Reverb type*

• Chorus type*

• Harmony note

• Sustain on/off

•Tempo*/time signature* (only when the style track is not recorded)

• Pitch bend (DGX-205/203 only)

• Pitch bend range (DGX-205/203 only)

• Dual voice on/off

•Panel sustain on/off

• Main/Dual voice – Voice volume, Octave, Pan, Reverb send level, Chorus send level

● Data Recorded On the Style Track [A]

• Chord changes and chord

timing

• Style pattern changes

• Style number*

•Reverb type*

• Chorus type*

•Tempo

•Time signature*

• Style volume*

NOTE

•A maximum of 5 user songs can be recorded. If you record a 6th song after recording to the 5 available user song locations, choose a song number (031 –

035) containing a song that you don’t mind erasing so that you can overwrite the internal user song memory without permanently losing your song data.

• Up to approximately 10,000 notes can be recorded if you record only to the melody tracks. Up to approximately 5,500 chord changes can be recorded if you record only to the style track.

* These data items are recorded at the beginning of the track. Changes made during the song will

not be recorded.

Track Configuration

To record your own performance, ﬁrst use the SONG MEMORY [1] – [5] and [A] buttons to specify the track(s) you want to record on. The track you record on determines the part that plays back later.

Melody Chords

Tra c k1Tra c k2Tra c k3Tra c k4Tra c k5Tra c k

Right-hand

melody

(MELODY R)

Left-hand

melody

(MELODY L)

The parts played by each track

when a user song is played back.

Other perfor-

mance data

Specify track(s) and record

Style

• Track [1] – Will play back as the right-hand melody part (MELODY R)

• Track [2] – Will play back as the left-hand mel- ody part (MELODY L)

• Tracks [3] – [5] – Will play back as “other” performance data.

• Track [A] – Will play back as the Style (auto- accompaniment) part.

NOTE

• The Difference Between MELODY R and MELODY L …

Songs are a combination of a melody and an autoaccompaniment style. Normally “melody” refers to the right-hand part, but in this instrument “melody” parts are provided for both the right and left hands. MELODY R is the melody part played by the right hand, and MELODY L is the melody part played by the left hand.

38 DGX-205/203, PSR-295/293 Owner’s Manual

Page 39

Record Your Own Performance Quick Guide

Recording Procedure

Press the [SONG] button, then use the dial to select the user song number (031 – 035) you want to record to.

User 1

031

Select the track(s) you want to record to and conﬁrm your

selection on the display.

◆ Record a Melody Track and the Accompaniment Track Together

Press the melody track button [1] – [5] you want to record to while holding the [REC] button. Next, press the [A] button while holding the [REC] button. The selected tracks will ﬂash in the display.

User 1

rEC

Press and hold

120 001

Rotate the dial to select a song number between 031 and 035.

CAUTION

• If you record to a track that contains previously-recorded data the previous data will be overwritten and lost.

NOTE

• Style accompaniment is automatically turned on when you select the style track [A] for recording.

• Style accompaniment cannot turned on or off while recording is in progress.

• If you use a split voice for recording, notes played to the left of the split point will not be recorded.

◆ Record a Melody track

Press the melody track button [1] – [5] you want to record to while holding the [REC] button. The selected track will ﬂash in the display.

User 1

rEC

120 001

DGX-205/203, PSR-295/293 Owner’s Manual 39

NOTE

• If style accompaniment is on and track [A] has not yet been recorded, the style track [A] will automatically be selected for recording when a melody track is selected. If you only want to record a melody track, be sure to turn the style track [A] off.

•To cancel recording to a selected track, press that track button a second time. Style accompaniment cannot be turned on or off while recording is in progress.

Page 40

Quick Guide Record Your Own Performance

Recording will start when you play on the keyboard.

You can also start recording by pressing the [START/STOP] button. The current measure will be shown on the display during recording.

Recording starts

Stop recording by pressing the [START/STOP] or [REC]

button.

User 1

rEC

NOTE

• If the memory becomes full during recording a warning message will appear and recording will stop automatically. Use the song clear or track clear (page

41) function to delete unwanted data and make more room available for recording, then do the recording again.

120 003

Current measure

If you press the [INTRO/ENDING/rit.] button while recording the style track an appropriate ending pattern will play and then recording will stop. When recording stops the current measure number will return to 001 and the recorded track numbers in the display will light.

● To Record Other Tracks

Repeat steps 2 through 4 to record any of the remaining tracks. By selecting an unrecorded track – SONG MEMORY buttons [1] – [5], [A] – you can record the new track while listening to previously recorded tracks (the playback tracks will appear in the display). You can also mute previously recorded tracks (the muted tracks will not appear in the display) while recording new tracks.

● To Re-record a Track

Simple select the track you want to re-record for recording in the normal way. The new material will overwrite the previous data.

When the recording is done …

◆ To Play Back a User Song

User songs are played back in the same way as regular songs (page 30).

1 Press the [SONG] button. 2 The current song number/name will be displayed – use the dial to select the

user song (031 – 035) you want to play.

3 Press the [START/STOP] button to start playback.

40 DGX-205/203, PSR-295/293 Owner’s Manual

Page 41

Song Clear – Deleting User Songs

Record Your Own Performance Quick Guide

This function clears an entire user song (all tracks).

Press the [SONG] button, then select the user song (031 –

035) you want to clear.

Press and hold the SONG MEMORY [1] button for longer than

a second while holding the SONG MEMORY [A] button.

A conﬁrmation message will appear on the display.

ClrUser1

Hold for longer than a second

Press the [+] button.

A conﬁrmation message will appear on the display. You can cancel the clear operation by pressing the [-] button.

Press the [+] button to clear the song.

The clear-in-progress message will appear brieﬂy on the display while the song is being cleared.

Press and hold

YES

NOTE

• If you only want to clear a speciﬁc track from a user song use the Track Clear function.

NOTE

•To execute the Song Clear function press the [+] button. Press [-] to cancel the Song Clear operation.

Track Clear – Deleting a Specified Track From a User Song

This function lets you delete a speciﬁed track from a user song.

Press the [SONG] button, then select the user song (031 –

035) you want to clear.

Press

[A]) corresponding to the track you want to clear for longer than a second.

A conﬁrmation message will appear on the display.

and hold

the SONG MEMORY track button ([1] – [5],

ClrTr1

YES

Hold for longer than a second

Press the [+] button.

A conﬁrmation message will appear on the display. You can cancel the clear operation by pressing the [-] button.

Press the [+] button to clear the track.

The clear-in-progress message will appear brieﬂy on the display while the track is being cleared.

NOTE

•To execute the Track Clear function press the [+] button. Press [-] to cancel the Track Clear operation.

DGX-205/203, PSR-295/293 Owner’s Manual 41

Page 42

Backup and Initialization

Backup

Some internal DGX-205/203 and PSR-295/293 parameters will revert to their default values if not saved before the power is turned off. In order to backup these parameters press and hold the [FUNCTION] button for longer than a second.

Hold for longer than a second

● The Backup Parameters

• User songs.

•Touch response on/off.

•Registration memory.

• The following FUNCTION settings: Tuning, Split Point, Touch Sensitivity, Style Volume, Song Volume, Metronome Volume, Grade, Demo Cancel, Panel Sustain.

Initialization

This function erases all backup data in the instrument’s ﬂash memory and restores the initial default settings. The following initialization procedures are provided.

■ Backup Clear ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ●

To clear data backed up to the internal ﬂash memory – panel user setting, registration memory (page 60), user songs (page 39) – turn the power on by pressing the [STANDBY/ON] switch while holding the highest white key on the keyboard. The backed up data will be erased and the default values restored.

DGX-205/203 PSR-295/293

■ Flash Clear ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ●

To clear song data that has been transferred to the internal ﬂash memory from a computer, turn the power on by pressing the [STANDBY/ON] switch while simultaneously holding the highest white key on the keyboard and the three highest black keys.

DGX-205/203 PSR-295/293

CAUTION

• When you execute the Flash Clear operation, song data you have purchased will also be cleared. Be sure to save data you want to keep to a computer.

42 DGX-205/203, PSR-295/293 Owner’s Manual

Page 43

Basic Operation and Displays

Basic Operation

Overall DGX-205/203 and PSR-295/293 control is based on the following simple operations.

Press a button to select a basic function.

Use the dial to select an item or value.

Start a function.

3 Start a function.

● Volume Adjustment

Adjusts the volume of the sound heard via the instrument’s speakers or a pair of headphones plugged into the PHONES jack.

Rotate counterclockwise to lower the volume.

Rotate clockwise to increase the volume.

2 Select an item or value. 1 Select a basic function.

Display (page 45)

GrandPno

888

001

888 888

092 001

The “Press & Hold” Symbol

The “ ” symbol that appears next to some buttons indicates that the button can be pressed and held for longer than a second to call up a related function. This provides convenient direct access to a range of functions.

1 Press a button to select a basic function.

Select a song you want to listen to or a song you want to use for a lesson.

Select an auto-accompaniment style.

Select a voice you want to play on the keyboard.

DGX-205/203, PSR-295/293 Owner’s Manual 43

Page 44

Basic Operation and Displays

2 Use the dial to select an item or value.

When you select a basic function, the item corresponding to that function will be displayed. You can then use the dial or the number buttons [0] – [9] to select the desired item.

This portion of the display indicates the name and number of

DontKnow

001

■ Changing Values● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ●

the currently selected song, voice and style. It also displays the name and current setting/ value of other functions.

● Dial

Rotate the dial clockwise to increase the value of the selected item, or counterclockwise to decrease it’s value. Rotate the dial continuously to continuously increase or decrease the value.

● [+] and [-] Buttons

Press the [+] button brieﬂy to increment the value by 1, or press the [-] button brieﬂy to decrement the value by 1. Press and hold either button to continuously increment or decrement the value in the corresponding direction.

● Number Buttons [0] – [9]

The number buttons can be used to directly enter a song number or parameter value. Hundreds or tens digits that are “0” can be omitted (see below).

Example: Song number “003”

can be entered in three ways.

• [0] → [0] → [3]

• [0] → [3] (“003” will appear on the display after a brief delay)

• [3] (“003” will appear on the display after a brief delay)

Decrease Increase

Press brieﬂy to decrement.

Press number buttons [0], [0], [3].

Press brieﬂy to increment.

● CATEGORY Buttons [ ], [ ]

When selecting a song, style, or voice, you can use these buttons to jump to the ﬁrst item in the next or previous category.

The CATEGORY buttons are useful for selecting categorized items, as in the example below.

Example: VOICE SELECT

Jump to the ﬁrst item in the next or previous category.

SweetFlt

088

The ﬁrst voice in the selected category is selected.

In a display in which a category appears, selection is easy if you ﬁrst use the CATEGORY [ ] and [ ] buttons to select the category containing the desired item, then use the dial or [+] and [-] buttons to select the item. This can be particularly handy when you have to select from a large number of voices.

In most procedures described throughout this owner’s manual the dial is recommended for selection simply because it is the easiest and most intuitive selection method. Please note however, that most items or values that can be selected using the dial can also be selected using the [+] and [-] buttons.

3 Start a function.

This is the [START/STOP] button. Press the [START/STOP] button after pressing the [SONG] or [STYLE] button to start playback of the selected song or style (rhythm).

44 DGX-205/203, PSR-295/293 Owner’s Manual

Page 45

Basic Operation and Displays

Display Items

The display shows all of the current basic settings: song, style, voice. It also includes a range of indicators that show the on/off status of a range of functions.

Notation

Displays the melody and chord notes of a song when the Easy Performer function is in use, or the notes of chords you specify when the Dictionary function is in use. At other times the notes you play on the keyboard are displayed.

NOTE

•Any notes occurring below or above the staff are indicated by “8va” in the notation.

•For a few speciﬁc chords, not all notes may be shown in the notation section of the display. This is due to space limitations in the display.

Battery Level Indicator

Indicates battery power is too low to ensure proper operation. (see page 10)

Measure and Tempo

Indicates the current measure during playback of a song or style, and the currently set Tempo value for the song or style. (see page 17)

092 001

Chord Display

Indicates the name of the chord currently being played back, or the name of the chord being played on the keyboard.

SONG TRACK DISPLAY

Information related to the song tracks is shown here. (see page 57)

GrandPno

092 001

001

Beat Display

Indicates the current style or song beat with ﬂashing arrows. (see page 17)

Performance assistant technology

Indicates that performance assistant technology is turned on. (see page 15)

Indicates that Touch response is turned on. (see page 22)

HARMONY

Indicates that Harmony is turned on. (see page 26)

TOUCH

DUAL

Indicates that the Dual voice is turned on. (see page 19)

SPLIT

Indicates that the Split voice is turned on. (see page 20)

ACMP ON

Indicates that Accompaniment is turned on. (see page

24)

SYNC STOP

Indicates that SYNC STOP is turned on. (see page 28)

DGX-205/203, PSR-295/293 Owner’s Manual 45

Page 46

Hall3

Selected reverb type

Reference

Handy Performance Features

Adding Reverb

Reverb lets you play with a rich concert hall type ambience. When you select a style or song the optimum reverb type for the voice used is automatically selected. If you want to select a different reverb type, use the procedure described below. Refer to the Effect Type List on page 86 for information about the available reverb types.

1 Press the [FUNCTION] button.

StyleVol

100

2 Use the CATEGORY [ ] and [ ] buttons to

select the Reverb Type item. “Reverb” appears in the display for a few seconds, then the currently selected reverb type will be displayed.

3 Use the dial to select a reverb type.

You can check how the selected reverb type sounds by playing on the keyboard.

● Adjusting the Reverb Send Level

You can individually adjust the amount of reverb that is applied to the main, dual, and split voices. If you press the CATEGORY [ ] or [ ] button a number of times in step 2 of the above procedure, the items listed below will appear. You can then use the dial to adjust the reverb send level for the selected voice (refer to page 62 for details).

Hall2

The currently selected Reverb Type

46 DGX-205/203, PSR-295/293 Owner’s Manual

• M. Reverb Main voice reverb send level.

• D. Reverb Dual voice reverb send level.

• S. Reverb Split voice reverb send level.

Page 47

Handy Performance Features Reference

Adding Chorus

The chorus effect creates a thick sound that is similar to many of the same voices being played in unison. When you select a style or song the optimum chorus type for the voice used is automatically selected. If you want to select a different chorus type, use the procedure described below.

1 Press the [FUNCTION] button.

2 Use the CATEGORY [ ] and [ ] buttons to

select the Chorus Type item. “Chorus” appears in the display for a few seconds, then the currently selected chorus type will be displayed.

Chorus1

The currently selected Chorus Type

3 Use the dial to select a chorus type.

You can check how the selected chorus type sounds by playing on the keyboard.

Chorus2

Selected chorus type

● Adjusting the Chorus Send Level

You can individually adjust the amount of chorus that is applied to the main, dual, and split voices. If you press the CATEGORY [ ] or [ ] button a number of times in step 2 of the above procedure, the items listed below will appear. You can then use the dial to adjust the chorus send level for the selected voice (refer to page 62 for details).

• M. Chorus Main voice chorus send level.

• D. Chorus Dual voice chorus send level.

• S. Chorus Split voice chorus send level.

DGX-205/203, PSR-295/293 Owner’s Manual 47

Page 48

Reference Handy Performance Features

•You can also access the Time Signature item by pressing the [FUNCTION] button and using the CATEGORY [ ] and [ ] buttons to locate the item (page 62).

NOTE

100

MtrVol

The Metronome

The metronome can be set for up to 15-beat time signatures. A chime will sound on the ﬁrst beat of each measure, while a metronome “click” will sound on all others. You can also set the time signature to “00,” in which case the chime will not sound and the “click” sound will be heard on all beats. The metronome will automatically be set to match the time signature and tempo of the selected song or style, but you can also change the tempo and time signature yourself.

1 Press the [METRONOME] button to start the

metronome.

5 Use the dial or the [0] – [9] number buttons

to select a time signature between 00 and 15 beats per measure.

1090

You can stop the metronome by pressing the [METRONOME] button a second time.

Indicates the beat number in the measure

2 Press the [TEMPO/TAP] button to call up the

TEMPO setting.

Tempo

090

3 Use the dial or the [0] – [9] number buttons

to select a tempo from 032 to 280 quarternote beats per minute.

4 Press and hold the [METRONOME] button

for longer than a second so that the Time Signature item appears.

090 1

■ Adjusting the Metronome Volume

● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ●

6 Press the [FUNCTION] button.

7 Use the CATEGORY [ ] and [ ] buttons to

select the Metronome Volume item.

Hold for longer than a second

TimeSig

48 DGX-205/203, PSR-295/293 Owner’s Manual

8 Use the dial or the [0] – [9] number buttons

to set the metronome volume as required.

Page 49

Handy Performance Features Reference

Hold for longer than a second

• The initial default touch sensitivity setting is “2.”

•You can also access the Touch Sensitivity item by pressing the [FUNCTION] button and using the CATEGORY [ ] and [ ] buttons to locate the item (page 62).

NOTE

Touch Response Sensitivity

When touch response is on you can adjust the sensitivity of the keyboard in response to keyboard dynamics in three steps.

1 Press the [TOUCH] button to turn touch

response on.

The touch response icon will appear in the display when touch response is on (pages 22, 45).

Medium

Touch Sensitivity

GrandPno

001

Touch Response icon

2 Press and hold the [TOUCH] button for

longer than a second so that the Touch Sensitivity item appears. “TouchSns” appears in the display for a few seconds, then the currently selected Touch Sensitivity will be displayed.

3 Use the dial to select a touch sensitivity set-

ting between 1 and 3. Higher values produce greater (easier) volume variation in response to keyboard dynamics – i.e. greater sensitivity.

One Touch Setting

Sometimes selecting the ideal voice to play with a song or style can be confusing. The One Touch Setting feature automatically selects a well-balanced voice for you when you select a style or song. Simply select voice number “000” to activate this feature.

1 Select voice number “000” (steps 1 – 2 on

page 18).

If you have stopped playback at some point during this procedure press the [START/STOP] button to start playback again.

4 Use the dial to change songs, then play the

keyboard and listen to the voice.

SweetSpr

000

Use the dial to select voice number 000.

2 Select and play back any song (steps 1 – 3

on page 30).

3 Play the keyboard and remember the sound

of the voice.

You should hear a different keyboard voice than you played in step 3. If you select a different song the keyboard voice will also change accordingly.

DGX-205/203, PSR-295/293 Owner’s Manual 49

Page 50

Reference Handy Performance Features

080

HarmVol

Adjusting the Voice Parameters

Reverb send level, pan, and a variety of other parameters can be individually adjusted for the main, dual, and split voices. Press the [FUNCTION] button and then use the CATEGORY [ ] and [ ] buttons to locate any of the following parameters. Once you have selected an appropriate parameter you can use the dial to adjust its value.

● Main Voice Parameters (page 63)

• M. Volume Main voice volume.

• M. Octave Main voice octave.

• M. Pan Main voice pan.

• M. Reverb Main voice reverb send level.

• M. Chorus Main voice chorus send level.

● Dual Voice Parameters (page 63)

• D. Volume Dual voice volume.

• D. Octave Dual voice octave.

• D. Pan Dual voice pan.

• D. Reverb Dual voice reverb send level.

• D. Chorus Dual voice chorus send level.

● Split Voice Parameters (page 63)

• S. Volume Split voice volume.

• S. Octave Split voice octave.

• S. Pan Split voice pan.

• S. Reverb Split voice reverb send level.

• S. Chorus Split voice chorus send level.

Adjusting the Harmony Volume

The harmony volume level can be adjusted for harmony types 01 (Duet) through 05 (octave).

1 Press the [FUNCTION] button.

2 Use the CATEGORY [ ] and [ ] buttons to

select the Harmony Volume item.

3 Use the dial or the [0] – [9] number buttons

to set the harmony volume from 000 through 127 as required.

Panel Sustain

This function adds sustain to the keyboard voices. Use it when you want to add sustain to the voices at all times, regardless of footswitch (optionally-available) operation. Press the [FUNCTION] button and then use the CATEGORY [ ] and [ ] buttons to locate the Sustain item. You can then use the [+] and [-] buttons to turn panel sustain on or off.

NOTE

• The sustain of some voices may not be markedly affected when the panel sustain function is turned on.

50 DGX-205/203, PSR-295/293 Owner’s Manual

Page 51

Split point (54: F#2)

Main voice

Split voice

• When you change the split point the auto-accompaniment split point also changes.

• The split point cannot be changed during a song lesson.

• The split voice sounds when the split-point key is played.

NOTE

•You can also access the Split Point item by pressing the [FUNCTION] button and using the CATEGORY [ ] and [ ] buttons to locate the item (page 62).

NOTE

• Since style numbers 112 and 124 – 135 (Pianist) have no rhythm parts, no rhythm will play when you start these styles.

NOTE

Style (Auto-accompaniment) Functions

Basic operation of the Style (auto-accompaniment) feature is described on page 24 of the Quick Guide. Here are some other ways you can play the styles, the style volume adjustment procedure, how you can play chords using the styles, and more.

Setting the Split Point

The initial default split point is key number 54 (the F#2 key), but you can change it to another key using the procedure described below.

1 Press the [STYLE] button or the [EASY

SONG ARRANGER] button.

2 Press and hold the [ACMP ON/OFF] for

longer than a second so that the FUNCTION Split point item appears.

Hold for longer than a second

SplitPnt

054

NOTE

• The FUNCTION Split point item can only be accessed by pressing and holding the [ACMP ON/OFF] button when either the [STYLE] button or the [EASY SONG ARRANGER] is engaged and lit.

092 001

Split point

3 Use the dial or the [0] – [9] number buttons

to set the split point to any key from 000 (C-

2) through 127 (G8).

Play Only the Style Rhythm

Auto-accompaniment is alternately turned on and off each time the [ACMP ON/OFF] button is pressed. If you use the [ACMP ON/OFF] button to turn auto-accompaniment off, only the rhythm (percussion) parts will play when the style is started.

Press the [STYLE] button to engage the style function.

PopBossa

080

ACMP ON indicator not showing

DGX-205/203, PSR-295/293 Owner’s Manual 51

Page 52

Reference Style (Auto-accompaniment) Functions

Accompaniment

range

Play a Style With Chords but No Rhythm (Stop Accompaniment)

When auto accompaniment is on (the ACMP ON icon is showing) and Synchro Start is off, you can play chords in the left-hand accompaniment range of the keyboard while the style is stopped and still hear the accompaniment chords. This is “Stop Accompaniment,” and any of the chord ﬁngerings recognized by the instrument can be used (page 53). The chord root and type will be shown on the display. You can also use the Harmony effects with Stop Accompaniment.

Press the [STYLE] button to engage the style function.

PopBossa

080

Adjusting the Style Volume

Press the [STYLE] button to engage the style function.

1 Press the [FUNCTION] button.

2 Use the CATEGORY [ ] and [ ] buttons to

select the Style Volume item.

StyleVol

100

3 Use the dial or the [0] – [9] number buttons

to set the style volume between 000 and 127 as required.

52 DGX-205/203, PSR-295/293 Owner’s Manual

Page 53

Style (Auto-accompaniment) Functions Reference

( )

CmM7

CM7

Csus4

Caug

CM7aug

C7aug

C7sus4

C1+2+5

Cdim

Cdim7

CmM7

(9)

CM7

(9)

Cm7

(9)

(b9)

(

b13

)

Cm7

(11)

CM7

(

#11

)

(b5)

(9)

(

)

(9)

(

#11

)

(#9)

(13)

Cm6

Cm7

(b5)

CM7

(b5)

Cm7

(b5)

CmM7

(b5)

● How to play Standard Chords [Example for “C” chords]

* Notes enclosed in parentheses ( ) are optional; the chords will

be recognized without them.

Playing Auto-accompaniment Chords

There are two ways of playing auto-accompaniment chords:

● Easy Chords

● Standard Chords

The instrument will automatically recognize the different chord types. This function is called Multi Fingering.

Press the [ACMP ON/OFF] button to turn auto-accompaniment on (page 24). The keyboard to the left of the split point (default: 54/F#2) becomes the “accompaniment range.” Play the accompaniment chords in this area of the keyboard.

Split point (default: 54/F#2)

DbEbF#G#BbDbEbF

DEFGABCDEF

Accompaniment

Root notes and the corresponding keys

■ Easy Chords● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ●

This method lets you easily play chords in the accompaniment range of the keyboard using only one, two, or three ﬁngers.

Cm7

•To play a major chord

Press the root note of the chord.

•To play a minor chord

Press the root note together with the nearest black key to the left of it.

•To play a seventh chord

Press the root note together with the nearest white key to the left of it.

•To play a minor seventh chord

Press the root note together with the nearest white and black keys to the left of it (three keys altogether).

range

■ Standard Chords● ● ● ● ● ● ● ● ● ● ● ● ● ●

This method lets you produce accompaniment by playing chords using normal ﬁngerings in the accompaniment range of the keyboard.

DGX-205/203, PSR-295/293 Owner’s Manual 53

Page 54

Reference Style (Auto-accompaniment) Functions

(9)C6(9)

CM7

(9)

(b5)

CM7

(b5)

Csus4

CM7aug

(9)

Cm6

Cm7

(9)

Cm7

(11)

CmM7

(9)

CmM7

(b5)

Cdim

Cdim7

(b9)C7(

b13

)

(9)

(

#11

)

(13)

(#9)

C7aug

C7sus4

C1+2+5

•Inversion of the 7sus4 and m7(11) chords are not recognized if the notes shown in parentheses are omitted.

• The auto accompaniment will sometimes not change when related chords are played in sequence (e.g. some minor chords followed by the minor seventh).

•Two-note ﬁngerings will produce a chord based on the previously played chord.

NOTE

■ Recognized Standard Chords ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ●

All chords in the chart are “C-root” chords.

Chord Name/[Abbreviation] Normal Voicing Chord (C) Display

Major [M] 1 - 3 - 5 C

Add ninth [(9)] 1 - 2 - 3 - 5 C

Sixth [6] 1 - (3) - 5 - 6 C6

Sixth ninth [6(9)] 1 - 2 - 3 - (5) - 6 C6

Major seventh [M7]

1 - 3 - (5) - 7 or 1 - (3) - 5 - 7

Major seventh ninth [M7(9)] 1 - 2 - 3 - (5) - 7 CM7

(

Major seventh add sharp eleventh [M7(#11)]

1 - (2) - 3 - #4 - 5 - 7 or 1 - 2 - 3 - #4 - (5) - 7

CM7

#11

)

Flatted ﬁfth [(b5)] 1 - 3 - b5C

Major seventh ﬂatted ﬁfth [M7b5] 1 - 3 - b5 - 7 CM7b5 *

Suspended fourth [sus4] 1 - 4 - 5 Csus4

Augmented [aug] 1 - 3 - #5Caug

Caug

Major seventh augmented [M7aug] 1 - (3) - #5 - 7 CM7aug *

Minor [m] 1 - b3 - 5 Cm

Minor add ninth [m(9)] 1 - 2 - b3 - 5 Cm

Minor sixth [m6] 1 - b3 - 5 - 6 Cm6

Minor seventh [m7] 1 - b3 - (5) - b7Cm7

Minor seventh ninth [m7(9)] 1 - 2 - b3 - (5) - b7Cm7

Minor seventh add eleventh [m7(11)] 1 - (2) - b3 - 4 - 5 - (b7) Cm7

Minor major seventh [mM7] 1 - b3 - (5) - 7 CmM7

Minor major seventh ninth [mM7(9)] 1 - 2 - b3 - (5) - 7 CmM7

Minor seventh ﬂatted ﬁfth [m7b5] 1 - b3 - b5 - b7Cm7

(b5)

Cm7

Minor major seventh ﬂatted ﬁfth [mM7b5] 1 - b3 - b5 - 7 CmM7b5 *

Diminished [dim] 1 - b3 - b5Cdim

Diminished seventh [dim7] 1 - b3 - b5 - 6 Cdim7

Seventh [7]

1 - 3 - (5) - b7 or 1 - (3) - 5 - b7

Seventh ﬂatted ninth [7(b9)] 1 - b2 - 3 - (5) - b7C7

Seventh add ﬂatted thirteenth [7(b13)] 1 - 3 - 5 - b6 - b7C7

Seventh ninth [7(9)] 1 - 2 - 3 - (5) - b7C7

Seventh add sharp eleventh [7(#11)]

1 - (2) - 3 - #4 - 5 - b7 or 1 - 2 - 3 - #4 - (5) - b7

Seventh add thirteenth [7(13)] 1 - 3 - (5) - 6 - b7C7

Seventh sharp ninth [7(#9)] 1 - #2 - 3 - (5) - b7C7

Seventh ﬂatted ﬁfth [7b5] 1 - 3 - b5 - b7C7b5 *

C7b5

Seventh augmented [7aug] 1 - 3 - #5 - b7C

Seventh suspended fourth [7sus4] 1 - 4 - (5) - b7C7sus4

One plus two plus ﬁve [1+2+5] 1 - 2 - 5 C *

* These chords are not shown in the Dictionary function.

(9)

CM7

7aug

(9)

(#11)

(9)

(11)

(b9)

(b13)

(9)

(#11)

(13)

(#9)

(9)

NOTE

• Notes in parentheses can be omitted.

• Playing two same root keys in the adjacent octaves produces accompaniment based only on the root.

•A perfect ﬁfth (1 + 5) produces accompaniment based only on the root and ﬁfth which can be used with both major and minor chords.

• The chord ﬁngerings listed are all in “root” position, but other inversions can be used — with the following exceptions: m7, m7 aug, dim7, 7

5, 6(9), 1+2+5.

54 DGX-205/203, PSR-295/293 Owner’s Manual

5, 6, m6, sus4,

Page 55

Style (Auto-accompaniment) Functions Reference

Notation of chord

Chord name (root and type)

Individual notes of chord (keyboard)

•To call up possible inversions of the chord, press the [+]/[-] buttons.

Dict.

092 001

• About major chords: Simple major chords are usually indicated only by the root note. For example, “C” refers to C major. However, when specifying major chords here, make sure to select “M” (major) after pressing the root note.

NOTE

Looking Up Chords Using the Chord Dictionary

The Dictionary function is essentially a built-in “chord book” that shows you the individual notes of chords. It is ideal when you know the name of a certain chord and want to quickly learn how to play it.

1 Press and hold the [LESSON MODE] button

for longer than a second.

Hold for longer than a second

Dict.

2 As an example, we’ll learn how to play a

GM7 (G major seventh) chord. Press the “G” key in the section of the keyboard labeled “CHORD ROOT.” (The note doesn’t sound.) The root note you set is shown in the display.

3 Press the “M7” (major seventh) key in the

section of the keyboard labeled “CHORD TYPE.” (The note doesn’t sound.) The notes you should play for the speciﬁed chord (root note and chord type) are shown in the display, both as notation and in the keyboard diagram.

Dict.

092 001

4 Try playing a chord in the auto accompani-

ment section of the keyboard, checking the indications in the display. When you’ve played the chord properly, a bell sound signals your success and the chord name in the display ﬂash.

DGX-205/203, PSR-295/293 Owner’s Manual 55

Page 56

Reference Style (Auto-accompaniment) Functions

3rd

Root

Root note Chord type

■ Chord Basics

Two or more notes played together constitute a “chord.”

The most basic chord type is the “triad” consisting of three notes: the root, third, and ﬁfth degrees of the corresponding scale. A C major triad, for example, is made up of the notes C (the root), E (the third note of the C major scale), and G (the ﬁfth note of the C major scale).

In the C major triad shown above, the lowest note is the “root” of the chord (this is the chord’s “root position” … using other chord notes for the lowest note results in “inversions”). The root is the central sound of the chord, which supports and anchors the other chord notes. The distance (interval) between adjacent notes of a triad in root position is either a major or minor third.

Major third – four half steps (semitones) Minor third – three half steps (semitones)

The lowest interval in our root-position triad (between the root and the third) determines whether the triad is a major or minor chord, and we can shift the highest note up or down by a semitone to produce two additional chords, as shown below.

Major chord Minor chord Augmented chord Diminished chord

CM Cm Caug C dim

Minor 3rd Major 3rd Major 3rd Minor 3rd Major 3rd Major 3rd Minor 3rd Minor 3rd

The basic characteristics of the chord sound remain intact even if we change the order of the notes to create different inversions. Successive chords in a chord progression can be smoothly connected, for example, by choosing the appropriate inversions (or chord “voicings”).

● Reading Chord Names

Chord names tell you just about everything you need to know about a chord (other than the inversion/voicing). The chord name tells you what the root of the chord is, whether it is a major, minor, or diminished chord, whether it requires a major or ﬂatted seventh, what alterations or tensions it uses … all at a glance.

● Some Chord Types (These are just some of the “Standard” chord types recognized by the DGX-205/203 and PSR-295/

293.)

Suspended 4

Csus4 C7 Cm7 CM7

Minor 7

Major 7

Perfect 5

Minor/major 7

Perfect 4

CmM7

Major 7

Minor chord

56 DGX-205/203, PSR-295/293 Owner’s Manual

Flatted 7

th, ﬂatted 5

Flatted 5

Major chord

(b5)

th chord

Flatted 7

Minor 7

Flatted 5

th, ﬂatted 5

Cm7

Minor chord

(b5)

Minor 7

th chord

Flatted 7

Major 7

th, suspended 4

C7sus4

Major chord

Suspended 4 chord

Page 57

• Song volume can be adjusted while a song is selected.

NOTE

• The repeat start and end points can be speciﬁed in one-measure increments.

• The current measure number is shown in the display during playback.

• If you want to set the start point “A” at the very beginning of the song press the [ ] button before starting playback of the song.

NOTE

Tr ack number off — Track is muted or contains no data

Tr ack number on — Track will play back.

Song Settings

Song Volume

1 Press the [FUNCTION] button.

2 Use the CATEGORY [ ] and [ ] buttons to

select the Song Volume item.

SongVol

100

Song Volume item

Song Volume

A-B Repeat

You can specify a section of a song – “A” is the start point and “B” is the end point – for repeat playback.

3 Use the dial or the [0] – [9] number buttons

to set the song volume between 000 and 127 as required.

2 Press the [ ] button a second time at

the end of the section you want to repeat (the “B” point).

1 Play the song (page 30) and press the

[] button at the beginning of the section you want to repeat (the “A” point).

Muting Independent Song Parts

Each “track” of a song plays a different part of the song – melody, percussion, accompaniment, etc. You can mute individual tracks and play the muted part on the keyboard yourself, or simply mute tracks other than the ones you want to listen to. Use the SONG MEMORY [1] – [5] and [A] buttons to mute or un-mute the corresponding tracks. The track number in the display disappears when that track is muted. Refer to page 38 for information about the song track conﬁguration.

3 The speciﬁed A-B section of the song will

now play repeatedly.

You can stop repeat playback at any time by pressing the [ ] button.

DGX-205/203, PSR-295/293 Owner’s Manual 57

Page 58

Reference Song Settings

• The pitch of Drum Kits voices cannot be changed.

NOTE

• When an A-B repeat range is speciﬁed the fast reverse and forward function will only work within that range.

NOTE

Change the Key Of a Song

◆ Large Pitch Changes (Transpose)

The overall pitch of the instrument can by shifted up or down by a maximum of 1 octave in semitone increments.

1 Press the [FUNCTION] button.

2 Use the CATEGORY [ ] and [ ] buttons to

select the Transpose item.

Transpos

3 Use the dial or the [0] – [9] number buttons

to set the transpose value between -12 and +12 as required.

NOTE

• The pitch of Drum Kits voices cannot be changed.

◆ Small Pitch Changes (Tuning)

The overall tuning of the instrument can by shifted up or down by a maximum of 100 cents in 1-cent increments (100 cents = 1 semitone).

1 Press the [FUNCTION] button.

2 Use the CATEGORY [ ] and [ ] buttons to

select the Tuning item.

Tuning

000

3 Use the dial or the [0] – [9] number buttons

to set the tuning value between -100 – +100 as required.

Song Fast Forward, Fast Reverse, and Pause

These are just like the transport controls on a cassette deck or CD player, letting you fast forward [ ], rewind [ ] and pause [ ] playback of the song.

Press the pause button to pause playback.

❙

Press the fast reverse button to rapidly return to an earlier point in the song.

Press the fast forward button to rapidly skip ahead to a later point in the song.

58 DGX-205/203, PSR-295/293 Owner’s Manual

Page 59

Change the Melody Voice

Hold for longer than a second

MELODY V

You can change a song’s melody voice to any other voice you prefer.

Song Settings Reference

NOTE

•You cannot change the melody voice of a user song.

1 Select the song and play it.

2 Rotate the dial to select the song you want

to listen to after pressing the [VOICE] button.

Strings

048

3 Press the [VOICE] button for longer than a

second. “MELODY VOICE CHANGE” appears in the display for a few seconds, indicating that the voice selected in step #2 has replaced the song’s original melody voice.

DGX-205/203, PSR-295/293 Owner’s Manual 59

Page 60

Bank

Bank number

• Data cannot be saved to the registration memory during song playback.

NOTE

Memorize Your Favorite Panel Settings

This instrument has a Registration Memory feature that lets you save your favorite settings for easy recall whenever they’re needed. Up to 16 complete setups can be saved (8 banks of two setups each).

8 Banks

Up to 16 presets (eight

Memory 1

Memory 2

Saving Settings to the Registration Memory

banks of two each) can be memorized.

■ Settings That Can be Saved to the Registration Memory

• Style settings*

Style number, Auto Accompaniment ON/OFF, Split Point, Style settings (Main A/B), Style Volume, Tempo

• Voice settings

Main Voice setting (Voice number, Volume, Octave, Pan, Reverb Send Level, Chorus Send Level), Dual Voice settings (Dual ON/OFF, Voice number, Volume, Octave, Pan, Reverb Send Level, Chorus Send Level), Split Voice settings (Split ON/OFF, Voice number, Volume, Octave, Pan, Reverb Send Level, Chorus Send Level)

• Effect settings

Reverb Type, Chorus Type, Panel Sustain ON/OFF

• Harmony settings

Harmony ON/OFF, Harmony Type, Harmony Volume

• Other settings

Transpose, Pitch Bend Range (DGX-205/203 only)

* Style settings are not available for Registration Memory when

using the Song features.

● ● ● ● ● ● ● ● ● ●

■ Saving to the Registration

Memory

● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ●

1 Set the panel controls as required – select a

voice, accompaniment style, etc.

2 Press the [●] (MEMORY/BANK) button. A

bank number will appear in the display when you release the button.

3 Use the dial or the [1] – [8] number buttons

to select a bank number from 1 to 8.

60 DGX-205/203, PSR-295/293 Owner’s Manual

Page 61

Memorize Your Favorite Panel Settings Reference

Bank

Bank number

4 Press the REGIST. MEMORY [1] or [2] button

while holding the [●] (MEMORY/BANK) button to store the current panel settings to the speciﬁed registration memory.

Bank

Bank number

NOTE

• If you select a Registration Memory number that already contains data, the previous data is deleted and overwritten by the new data.

CAUTION

• Do not turn off the power while saving settings to the registration memory, otherwise the data may be damaged or lost.

■

Recalling a Registration Memory

● ● ● ●

1 Press the [●] (MEMORY/BANK) button. A

bank number will appear in the display when you release the button.

2 Use the dial or the [1] – [8] number buttons

to select bank you want to recall.

3 Press the REGIST. MEMORY button, [1] or

[2], containing the settings you want to recall. The panel controls will be instantly set accordingly.

DGX-205/203, PSR-295/293 Owner’s Manual 61

Page 62

Directly enter numeric values

• Increase a value by 1

•Turn a setting ON

•Execute an operation

• Decrease a value by 1

•Turn a setting OFF

• Cancel an operation

Reset a value to its default setting

Hold for longer than a second

Function settings

The Function settings include detailed settings for the instrument’s voices, effects, split point, tuning, and more. Button shortcuts can be used to quickly access commonly used settings: hold a shortcut button for longer than a second to directly access the related setting.

Locating and Editing the Function Settings

1 Press the [FUNCTION] button.

StyleVol

100

2 Use the CATEGORY [ ] and [ ] buttons to

select the required item.

For details on individual settings refer to the FUNCTION Setting List on page 63.

3 Set the value as required using the dial, the

[+] and [-] buttons, or the [0] – [9] number buttons.

For ON/OFF settings use the [+] button to turn the function ON and the [-] button to turn the function OFF. Use the [+] button to begin execution of operations, or the [-] button to cancel the selected operation. All these settings can be conveniently reset to their initial default values by pressing the [+] and [-] buttons simultaneously. (The exception to this is Initial Setup Send and Bulk Send, which is an operation, not a setting.)

62 DGX-205/203, PSR-295/293 Owner’s Manual

Transpos

Current item

4 If necessary, hold the [FUNCTION] button for

longer than a second to save your settings to ﬂash memory.

Although all settings are retained by the instrument while the power is on, your custom settings will be lost when the power is turned off unless you save them to ﬂash memory. Simply save the settings to ﬂash memory by holding the [FUNCTION] button for more than a second, and your settings will be retained in ﬂash memory even while the power is off and will be recalled the next time the instrument is turned on.

CAUTION

• Do not turn off the power while saving settings, otherwise the data may be damaged or lost.

Page 63

Function settings Reference

■ Function Setting List

Category Setting Item title Range/Settings Description

VOLUME Style Volume StyleVol 000 – 127 Determines the volume of the Style.

Song Volume SongVol 000 – 127 Determines the volume of the Song.

OVERALL Transpose Transpos -12 – 12 Determines the pitch of the instrument by semitone

Tuning Tuning -100 – 100 Sets the pitch of the instrument’s sound in 1-cent

Pitch Bend Range (DGX-205/203 only)

Split Point

Touch Sensitivity

MAIN VOICE Volume M.

Octave M

Pan M.Pan 000 (left) – 64 (center)

Reverb Send Level M

Chorus Send Level

DUAL VOICE Voice

Volume

Octave D

Pan D.Pan 000 (left) – 64 (center)

Reverb Send Level D.Reverb 000 – 127 Determines how much of the Dual voice’s signal is

Chorus Send Level D

SPLIT VOICE Voice S

Volume S

Octave S

Pan S.Pan 000 (left) – 64 (center)

Reverb Send Level S

Chorus Send Level S.Chorus 000 – 127 Determines how much of the Split voice’s signal is

EFFECT Reverb Type Reverb 01 – 10 Determines the Reverb type, including off (10). (See

Chorus Type Chorus 01 – 05 Determines the Chorus type, including off (05). (See

Panel Sustain Sustain ON/OFF Determines whether or not panel sustain is always

HARMONY Harmony Type H

Harmony Volume

PBRange 01 – 12 Sets the pitch bend range in semitone increments.

SplitPnt 000 – 127 (C-2 – G8) Determines the highest key for the Split voice and

TouchSns 1 (Soft)/2 (Medium)/

3 (Hard)

Volume 000 – 127 Determines the volume of the Main voice.

.Octave -2 – +2 Determines the octave range for the Main voice.

– 127 (right)

.Reverb 000 – 127 Determines how much of the Main voice’s signal is

.Chorus

000 – 127 Determines how much of the Main voice’s signal is

D.Voice 001 – 487 Selects the Dual voice.

D.Volume 000 – 127 Determines the volume of the Dual voice.

.Octave -2 – +2 Determines the octave range for the Dual voice.

– 127 (right)

.Chorus 000 – 127 Determines how much of the Dual voice’s signal is

.Voice 001 – 487 Selects the Split voice.

.Volume 000 – 127 Determines the volume of the Split voice.

.Octave -2 – +2 Determines the octave range for the Split voice.

– 127 (right)

.Reverb 000 – 127 Determines how much of the Split voice’s signal is

armType 01 – 26 Determines the Harmony type. (See the list on page

HarmVol 000 – 127 Determines the volume of the Harmony effect when

increments.

sets the Split “point” — in other words, the key that separates the Split (lower) and Main (upper) voices. The Split Point setting and Accompaniment Split Point setting are automatically set to the same value.

When Touch Response is on, this determines the sensitivity of the feature.

Determines the pan position of the Main voice in the stereo image. The value “0” results in the sound being panned full left; the value “127” results in the sound being panned full right.

sent to the Reverb effect.

sent to the Chorus effect.

Determines the pan position of the Dual voice in the stereo image. The value “0” results in the sound being panned full left; the value “127” results in the sound being panned full right.

sent to the Reverb effect.

sent to the Chorus effect.

Determines the pan position of the Split voice in the stereo image. The value “0” results in the sound being panned full left; the value “127” results in the sound being panned full right.

sent to the Reverb effect.

sent to the Chorus effect.

the list on page 86)

applied to the MAIN/DUAL/SPLIT voices. Panel sustain is applied continuously when ON, or not applied when OFF. (page 50)

86)

Harmony type 1-5 is selected.

DGX-205/203, PSR-295/293 Owner’s Manual 63

Page 64

Reference Function settings

Category Setting Item title Range/Settings Description

PC MODE PC mode PC mode PC1/PC2/OFF Optimizes the MIDI settings when you connect to a

MIDI Local On/Off Local ON/OFF Determines whether the instrument’s keyboard con-

External Clock E

Keyboard Out

Style Out S

Song Out SongOut ON/OFF Determines whether Song data is transmitted (ON)

Initial Setup Send

Bulk Send

METRONOME Time Signature

Metronome Volume

LESSON Lesson Track (R) R-Part GuideTrack 1 – 16 Determines the guide track number for your right

Lesson Track (L) L-Part GuideTrack 1 – 16 Determines the guide track number for your left hand

UTILITY Grade Grade ON/OFF Determines whether the Grade function is on or off.

Demo Cancel D-Cancel ON/OFF Determines whether Demo cancel is enabled or not.

* All these settings can be conveniently reset to their initial default values by pressing the [+] and [-] buttons simultaneously.

(The exception to this is Initial Setup Send and Bulk Send, which is an operation, not a setting.)

xtClock ON/OFF Determines whether the instrument synchronizes to

KbdOut ON/OFF Determines whether keyboard performance data of

tyleOut ON/OFF Determines whether Style data is transmitted (ON)

InitSend YES/NO Lets you send the data of the panel settings to a com-

BulkSend YES/NO User song and registration memory data can be

TimeSig 00 – 15 Determines the time signature of the Metronome.

MtrVol 000 – 127 Determines the volume of the Metronome.

computer (page 67).

PC1 sets local off and external clock on for use

with an external sequencer or similar device.

The PC2 setting allows the instrument to use Digi-

tal Music Notebook content on the connected computer.

OFF turns local control on, external clock off, key-

board out on, style out on, and song out on.

trols the internal tone generator (ON) or not (OFF). (page 66)

the internal clock (OFF) or an external clock (ON). (page 66)

the instrument is transmitted (ON) or not (OFF).

via USB or not (OFF) during Style playback.

via USB or not (OFF) during Song playback.

puter. Press [+] to send, or press [-] to cancel. Use the [+] button to transmit the data. Use the [-] button to stop the transmission.

transmitted as bulk data to sequence software running on your computer, where it can be stored for later retrieval and use. The instrument must be connected to a computer on which the appropriate USB MIDI driver is installed. With Bulk Send showing on the instrument’s display, press [+] to begin bulk data transmission. Press [-] to cancel the transmission. Refer to page 67 for information on connecting the instrument to a computer, and to page 71 for information on installing the USB MIDI driver.

hand lesson. The setting is only effective for songs in SMF format 0 transferred from a computer.

lesson. The setting is only effective for songs in SMF format 0 transferred from a computer.

When this is set to ON, the Demo Song will not play, even if the [DEMO] button is pressed.

64 DGX-205/203, PSR-295/293 Owner’s Manual

Page 65

Connecting To a Computer

Nearly all of the electronic musical instruments made today – particularly synthesizers, sequencers and computer music related devices – use MIDI. MIDI is a worldwide standard that allows these devices to send and receive performance and setting data. Naturally, this instrument lets you save or send your keyboard performance as MIDI data, as well as the songs, styles and panel settings. The potential MIDI holds for your live performances and music creation/production is enormous – simply by connecting this instrument to a computer and transmitting MIDI data. In this section, you’ll learn the basics of MIDI and the speciﬁc MIDI functions provided by this instrument.

What Is MIDI?

No doubt you have heard the terms “acoustic instrument” and “digital instrument.” In the world today, these are the two main categories of instruments. Let’s consider a grand piano and a classical guitar as representative acoustic instruments. They are easy to understand. With the piano, you strike a key, and a hammer inside hits some strings and plays a note. With the guitar, you directly pluck a string and the note sounds. But

ator. Using these numbers as a basis, the tone generator plays the stored sampling note.

Example of Keyboard Information

Voice number (with what voice) 1 (grand piano) Note number (with which key) 60 (C3) Note on (when was it pressed) and

note off (when was it released) Velocity (about how strong) 120 (strong)

how does a digital instrument go about playing a note?

● Acoustic guitar note production

Your keyboard performance and all panel operations of this instrument are processed as MIDI data. The songs, auto accompaniment (styles), and User songs are also made up of MIDI data. MIDI is an acronym that stands for Musical Instrument Digital Interface and it allows different musical instruments and devices to instantly communicate with each other, via digital data. The MIDI standard is used all over the world and was designed to transmit performance data between electronic musical instruments (or computers). Thanks to MIDI, you can control one instrument from another and transmit performance data between the devices-taking your creative and perfor-

● Digital instrument note production

Pluck a string and the body resonates the sound.

mance potential to even higher levels.

Sampling

Note

Tone Generator

(Electronic circuit)

Sampling

Note

MIDI messages can be divided into two groups: Channel messages and System messages.

● Channel Messages

Playing the keyboard

This instrument is capable of handling 16 MIDI channels simultaneously – meaning it can play up to sixteen

Based on playing information from the keyboard, a sampling note stored in the tone generator is played through the speakers.

As shown in the illustration above, in an electronic instrument the sampling note (previously recorded note) stored in the tone generator section (electronic circuit) is played based on information received from the key-

different instruments at the same time. Channel messages transmit information such as Note ON/OFF, Program Change, for each of the 16 channels.

Message Name Instrument Operation/Panel Setting

Note ON/OFF Performance data of the keyboard (contains

Program Change Instrument selection (including bank select

board. So then what is the information from the keyboard that becomes the basis for note production?

For example, let’s say you play a “C” quarter note using the grand piano sound on the instrument. Unlike an acoustic instrument that puts out a resonated note, the electronic instrument puts out information from the keyboard such as “with what voice,” “with which key,” “about how strong,” “when was it pressed,” and “when was it released.” Then each piece of information is changed into a number value and sent to the tone gener-

Control Change Instrument settings (volume, pan, etc.)

● System Messages

This is data that is used in common by the entire MIDI system. System messages include messages like Exclusive Messages that transmit data unique to each instrument manufacturer and Realtime Messages that control the MIDI device.

Message Name Instrument Operation/Panel Setting

Exclusive Message Reverb/chorus settings, etc. Realtime Messages Start/stop operation

Timing expressed numerically (quarter note)

note number and velocity data)

MSB/LSB, if necessary)

DGX-205/203, PSR-295/293 Owner’s Manual 65

Page 66

Reference Connecting To a Computer

• The Musicsoft Downloader application may not be able to access the instrument in the following cases:

• During a MIDI bulk dump.

• During style playback.

• During song playback.

NOTE

• If External Clock is ON and no clock signal is being received from an external device, the song, style, and metronome functions will not start.

NOTE

USB Connection

This instrument can be connected to a computer to allow transfer of MIDI data. Connect a standard USB cable between the instrument’s rear-panel USB connector and the USB connector on your computer (USB cable sold separately). It is also necessary to install the USB driver provided on the supplied CD-ROM on your computer. Refer to the “Accessory CD-ROM Installation Guide” on page 70 for details. The supplied CD-ROM also includes a Musicsoft Downloader application that allows you to transfer song ﬁles from your computer to the instrument’s ﬂash memory.

DGX-205/203

USB cable

PSR-295/293

■ USB Precautions

Please observe the following precautions when connecting the instrument to a computer via a USB cable.

Failure to do so can cause the instrument and/or the computer to hang up (freeze), possibly causing corruption or loss of data. If the instrument or computer does hang up, turn the power to both devices off and then on again, and restart the computer.

CAUTION

•Wake the computer from a sleep/suspended/standby mode before connecting the USB cable.

• Connect the USB cable to the instrument and computer before turning power to the instrument on.

• Check the following points before turning the instrument’s power on or off, and before plugging or unplugging the USB cable.

• Quit all applications.

• Make sure that no data transfer is in progress (data is transferred whenever you play on the keyboard or play a song).

• Allow at least 6 seconds between turning the instrument’s power on and off, and between plugging and unplugging the USB cable.

• Directly connect the instrument to the computer using a single USB cable. Do not use a USB hub.

MIDI Settings

These settings pertain to MIDI data transmission and reception.

■ Local ON/OFF ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ●

Local control determines whether or not notes played on the instrument are sounded by its internal tone generator system: the internal tone generator is active when local control is on, and inactive when local control is off.

ON This is the normal setting in which notes played on the

OFF With this setting the instrument itself produces no sound

Local control can turned on or off via the FUNCTION Local item (page 64).

• If you can’t get any sound out of the instrument, this may be the most

66 DGX-205/203, PSR-295/293 Owner’s Manual

instrument’s keyboard are sounded by the internal tone generator system. Data received via the instrument’s USB connector will also be played by the internal tone generator.

(keyboard performance, harmony, or style playback), but the performance data is transmitted via the USB connector. Data received via the instrument’s USB connector will also be played by the internal tone generator.

NOTE

likely cause. Playing the keyboard results in no sound when Local is set to OFF.

■ External Clock ON/OFF ● ● ● ● ● ● ● ● ●

These settings determine whether the instrument is synchronized to its own internal clock (OFF), or to a clock signal from an external device (ON).

ON The instrument’s time based functions will be synchro-

nized to the clock from an external device connected to the USB connector.

OFF The instrument uses its own internal clock (default).

External clock control can turned on or off via the FUNCTION External Clock item (page 64).

Page 67

Connecting To a Computer Reference

• When the PC2 setting is selected the instrument’s style, song, demo, song recording, and lesson features cannot be used.

NOTE

•You can also access the PC Mode item by ﬁrst pressing the [FUNCTION] button and then using the CATEGORY [ ] and [ ] buttons to locate it (page 62).

NOTE

C#1

C6: Fast forward

B5: Start

A5: Stop

G5: Rewind

F5: Top (move to the beginning of

the song)

E5: Metronome ON/OFF

• Remote control of MIDI devices will function independently of the PC2 mode.

NOTE

MIDI (PC Mode) Settings For Computer Connection

A number of MIDI settings need to be made when you connect the instrument to a computer. The PC Mode item can conveniently make multiple settings for you in one operation. Three settings are available: PC1, PC2, and OFF. Press the [PC] button to call up the PC Mode item, and select PC1 or PC2, as required. The setting you choose will set parameters such as Local ON/OFF, External Clock ON/OFF, and others for optimum operation with a sequencer application on your computer, for example. Refer to page 64 for details about the MIDI settings.

NOTE

• Set the PC mode to PC2 when using Digital Music Notebook* in the supplied CD-ROM.

* “Digital Music Notebook” is a software application for handling songs

and scores on your computer. Refer to the application’s online help ﬁle for more information.

PC1 PC2 PC Mode = OFF

Local OFF OFF ON External Clock ON OFF OFF Keyboard Out OFF ON ON Style Out OFF OFF ON Song Out OFF OFF ON

■ Setting the PC Mode ● ● ● ● ● ● ● ● ● ● ●

1 Press the [PC] button so that the FUNCTION

display PC Mode item appears.

PC mode

oFF

2 Use the dial or the [+] and [-] buttons to

select PC1, PC2, or OFF.

Remote Control Of MIDI Devices

You can also use this instrument as a remote control device for the Digital Music Notebook application on your computer (via the USB connection) — controlling playback, stop and transport functions from the panel.

■ Remote control keys● ● ● ● ● ● ● ● ● ● ●

DGX-205/203: To use the remote control functions, simultaneously hold down the lowest two keys on the keyboard (E0 and F#0) and press the appropriate key (shown below).

F#0

B5: Metronome ON/OFF

G6: Fast forward

F6: Start

E6: Stop

D6: Rewind

C6: Top (move to the beginning of

the song)

PSR-295/293: To use the remote control functions, simultaneously hold down the lowest two keys on the keyboard (C1 and C#1) and press the appropriate key (shown below).

DGX-205/203, PSR-295/293 Owner’s Manual 67

Page 68

Reference Connecting To a Computer

• If a song or style is being played, stop playback before proceeding.

NOTE

• The instrument cannot be operated while the Musicsoft Downloader is running.

NOTE

q Click the CD-ROM drive

w Double-click “SongCollection”

Folder. Double-click “for_CD” Folder and click a song ﬁle.

e Click “Open”

Transferring Song Files From a Computer

This instrument can access ﬂash memory for storage and retrieval of song data: When song ﬁles are transferred to ﬂash memory media from your computer they can be used with the instrument’s performance assistant technology or Lesson functions. In order to transfer songs between your computer and the instrument you will need to install the Musicsoft Downloader application and the USB-MIDI Driver included on the Accessory CD-ROM on your computer. Refer to the Accessory CD-ROM Installation Guide on page 70 for installation details.

NOTE

•A USB cable is required in order to transfer song ﬁles to the instrument’s ﬂash memory.

USB cables can be purchased at an electrical goods or computer supply store.

● Data That Can be Transferred From a Computer To This Instrument

• Song Capacity (max.) Flash memory 99 songs

• Data Capacity Flash memory 373 kb

• Data Format SMF format 0/1

● What is SMF (Standard MIDI File)?

The SMF (Standard MIDI File) format is one of the most common and widely compatible sequence formats used for storing sequence data. There are two variations: Format 0 and Format 1. A large number of MIDI devices are compatible with SMF Format 0, and most commercially available MIDI sequence data is provided in SMF Format 0.

(Song numbers 036 – 134)

■ With the Musicsoft Downloader You Can

● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ●

● Transfer MIDI songs you have downloaded from the

Internet or created on your computer from the computer to the instrument’s ﬂash memory.

➔ Refer to the step #1 – #9.

The procedure for transferring songs included on the Accessory CD-ROM from your computer to the instrument is given as an example.

■ Use Musicsoft Downloader To Transfer Songs From the Accessory CD-ROM To the Instrument’s Flash Memory

● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ●

1 Install the Musicsoft Downloader application

and the USB-MIDI driver on your computer (page 71 – 73).

2 Insert the supplied CD-ROM into your com-

puter’s CD-ROM drive. The start window should appear automatically, and close the window.

3 Double-click the Musicsoft Downloader

shortcut icon that is created on the desktop. This will launch the Musicsoft Downloader application and the main window will appear.

4 Click the “Add File” button and the Add File

window will appear.

5 Click the [▼] button to the right of “Look in”

and select the CD-ROM drive from the dropdown menu that appears. Double-click the “SongCollection” Folder on the window. Select the ﬁle you want to transfer to the instrument, and click “Open.”

Use the Musicsoft Downloader application with Internet Explorer 5.5 or higher.

68 DGX-205/203, PSR-295/293 Owner’s Manual

Page 69

Connecting To a Computer Reference

6 A copy of the selected MIDI song ﬁle will

appear in the “List of ﬁles stored temporarily” at the top of the window. The ﬂash memory medium will also be displayed at the bottom of the window to specify the destination for the transfer. Click the ﬂash memory.

● To Use transferred Songs For Lessons

In order to use songs (only SMF format 0) transferred from a computer for lessons it is necessary to specify which channels are to be played back as the right-hand and left-hand parts. The procedure for setting the “guide track” is as follows:

1 Press the [SONG] button and select the song

(036 –) residing in ﬂash memory for which you want to set the guide track.

2 Press the [FUNCTION] button. 3 Use the CATEGORY [ ] and [ ] buttons to

select the R-Part or L-Part item.

4 Use the dial to select the channel you want to

play back as the speciﬁed right- or left-hand part.

We recommend that you select channel 1 for the right-hand part and channel 2 for the left-hand part.

q Click the “Flash Memory”

7 After selecting the ﬁle in the “List of ﬁles

stored temporarily”, click the downward [Move] button and a conﬁrmation message will appear. Click [OK] and the song will be transferred from the “List of ﬁles stored temporarily” to the instrument’s ﬂash memory.

8 Close the window to end the Musicsoft

Downloader.

NOTE

• Quit the Musicsoft Downloader to play back the song transferred from your computer.

9 To play back a song stored in ﬂash memory,

press the [SONG] button. Use the dial to select the song you want to play, then press the [START/STOP] button to start playback.

CAUTION

• Do not unplug the USB cable during a data transfer. Not only will the data not be transferred and saved, but operation of the memory media may become unstable and its contents may disappear completely when the power is turned on or off.

CAUTION

• Stored data can be lost due to equipment malfunction or improper operation. For safety we recommend that you keep a copy of all important data stored on your computer.

•We recommend that you use a power adaptor rather than batteries when transferring data. The data can be corrupted if the batteries fail during the transfer.

DGX-205/203, PSR-295/293 Owner’s Manual 69

Page 70

Accessory CD-ROM Installation Guide

SPECIAL NOTICES

• The software and this Installation Guide are exclusive copyrights of Yamaha Corporation.

• Use of the software and this guide is governed by the SOFTWARE LICENSING AGREEMENT which the purchaser fully agrees to upon breaking the seal of the software packaging. (Please read the AGREEMENT at the end of this guide carefully before installing the application.)

• Copying of the software or reproduction of this guide in whole or in part by any means is expressly forbidden without the written consent of the manufacturer.

•Yamaha makes no representations or warranties with regard to the use of the software and documentation and cannot be held responsible for the results of the use of this guide and the software.

• This disc is a CD-ROM. Do not attempt to play the disc

• Copying of commercially available music data is strictly prohibited except for your personal use.

• The company names and product names in this Installation Guide are the trademarks or registered trademarks of their respective companies.

• Future upgrades of application and system software and any changes in speciﬁcations and functions will be announced separately.

• Software such as the USB MIDI driver may be revised and updated without prior notice. Make sure to check and download the latest version of the software from the following site.

http://music.yamaha.com/download/

• Depending on the version of your operating system, the screen shots and messages shown in this guide may differ to those that you see on your computer screen.

on an audio CD player. Doing so may result in irreparable damage to your audio CD player.

CD-ROM Contents

The data on this CD-ROM is compatible with computers running the Windows® operating system.

CAUTION

• Do not attempt to play this CD-ROM on an audio CD player. The result high-volume noise can potentially cause hearing damage or damage your CD player and speakers.

Folder Name Application/Data Name Contents

MSD_ Musicsoft Downloader *1 *2

DMN_ Digital Music Notebook *2

USBdrv_ USB Driver For Windows 98/Me

USBdrv2k_ USB Driver For Windows 2000/XP

for_CD The “SongCollection” folder contains two folders. The “for_CD” folder contains

SongCollection

* 1 The software cannot be used when the instrument is in the follow-

ing state:

• During style or song playback.

• During a lesson.

for_Preset (Only Score)

■ Using the CD-ROM ● ● ● ● ● ● ● ● ● ● ● ●

Please read the Software License Agreement on page 74 before opening the CD-ROM package.

1 Check the system requirements to make

sure that the software will run on your computer.

This application can be used to download MIDI song data from the Internet and transfer it from the computer to memory media supported by the instrument (eg. ﬂash memory).

Digital Music Notebook is a major new multimedia platform for music tuition and performance.

This driver software is necessary to connect MIDI devices to your computer via USB.

the 70 MIDI songs and the corresponding 70 notation PDF ﬁles. These songs can be transferred to the instrument for listening and/or lessons. The “for_Preset (Only Score)” folder contains the notation PDF ﬁles of the 30 songs provided with the instrument (not including copyrighted songs).

* 2 This software includes an online manual. * 3 This software is not supported by Yamaha Corporation.

3 Connect the instrument to the computer.

The connection procedure is described on page 66.

4 Install the driver on your computer and

make the necessary settings.

Refer to “Installing the USB-MIDI Driver” on page 71 for installation and setup instructions.

2 Insert the Accessory CD-ROM into your

computer’s CD-ROM drive. The start window should appear automatically.

70 DGX-205/203, PSR-295/293 Owner’s Manual

Page 71

Accessory CD-ROM Installation Guide Reference

Driver

USB Cable

MIDI device

Computer

Sequence

software

5 Install the software.

• Digital Music Notebook and Musicsoft Downloader:

Refer to page 73.

6 Launch the software.

For further software operation refer to the online help supplied with the software.

•YAMAHA USB-MIDI Driver:

Refer to page 71.

System Requirements

Application/Data OS CPU Memory Hard Disk Display

at least 128 MB of free space (at least 512 MB of free space is recommended)

at least 2 MB of free space

at least 50 MB of free space

Musicsoft Downloader

USB Driver for Windows 98/Me

USB Driver for Windows 2000/XP

Digital Music Notebook

Digital Music Notebook (Requirements for playing content with video included.)

Windows 98SE/Me/2000/ XP Home Edition/ XP Professional

Windows 98/98SE/Me Windows 2000/XP Home

Edition/XP Professional

Windows Edition, SP1a more Windows Edition, SP1a more Windows 2000 Professional, SP4 more

XP Professional

XP Home

233 MHz or higher; Intel

Pentium processor family

166 MHz or higher; Intel Pentium processor family

300MHz or higher; Intel Pentium Processor family (1GHz or more is recommended)

1GHz or higher; Intel Pentium Processor family (1.4GHz or more is recommended)

/Celeron®

64 MB or more (256 MB or more is recommended)

32 MB or more (64 MB or more is recommended)

128 MB or more (256 MB or more is recommended)

256 MB or more

800 x 600 HighColor (16-bit)

—

1024 x 768

HighColor (16-bit)

Software Installation

● Uninstall (Removing the Software)

Installed software can be removed from your computer as follows: From the Windows Start menu select Start → Settings → Control panel → Add or Remove Applications → Install and Uninstall. Select the item you want to remove and click [Add or Remove]. Follow the on-screen instructions to remove the selected software.

NOTE

• The actual names of the menu items and buttons will depend on the OS version you are using.

■ Installing the USB-MIDI Driver ● ● ● ●

In order to be able to communicate with and use MIDI devices connected to your computer, the appropriate driver software must be properly installed on your computer. The USB-MIDI driver allows sequence software and similar applications on your computer to transmit and receive MIDI data to and from MIDI devices via a USB cable.

• Windows 98/Me installation ➔ page 72.

• Windows 2000 installation ➔ page 72.

• Windows XP installation ➔ page 73.

Check the drive name of the CD-ROM drive you will be using (D:, E:, Q: etc.) The drive name is displayed beside the CD-ROM icon in your “My Computer” folder. The root directory of the CD-ROM drive will be D:\, E:\, or Q:\, respectively.

DGX-205/203, PSR-295/293 Owner’s Manual 71

Page 72

Reference Accessory CD-ROM Installation Guide

• The system may ask you to insert a Windows CD-ROM while it checks for the driver. Specify the “USBdrv2k_” directory of the CDROM drive (such as D:\USBdrv2k_\) and continue the installation.

NOTE

• Some computers may take about ten seconds to show this screen after the installation is complete.

NOTE

Installing the driver on Windows 98/Me

1 Start the computer.

2 Insert the supplied CD-ROM into the CD-

ROM drive. A start window will appear automatically. Close the window.

3 First, make sure the POWER switch on the

instrument is set to OFF, then use a USB cable to connect the USB terminal of the computer to the USB connector of the instrument. When the instrument is turned on, the computer automatically displays the “Add New Hardware Wizard.” If the Add New Hardware Wizard does not appear, click “Add New Hardware” in the Control Panel.

For Windows Me users, check the radio button to the left of “Automatic search for a better driver (Recommended)” and click [Next]. The system automatically starts searching and installing the driver. Proceed to Step 8. If the system does not detect the driver, select “Specify the location of the driver (Advanced)” and specify the CD-ROM drive’s “USBdrv_” folder to install the driver and click [Next]. Execute the installation by following the onscreen instructions and proceed to Step 8.

NOTE

• If you are using Windows Me, skip Step 4 – 7.

Installing the driver on Windows 2000

1 Start the computer and use the “Administra-

tor” account to log into Windows 2000.

2 Select [My Computer] ➔ [Control Panel] ➔

[System] ➔ [Hardware] ➔ [Driver Signing] ➔ [File Signature Veriﬁcation], and check the radio button to the left of “Ignore — Install all ﬁles, regardless of ﬁle signature” and click [OK].

3 Insert the supplied CD-ROM into the CD-

ROM drive. A start window will appear automatically. Close the window.

4 First, make sure the POWER switch on the

instrument is set to OFF, then use a USB cable to connect the USB connector of the computer to the USB connector of the instrument. When the instrument is turned on, the computer automatically displays “Found New Hardware Wizard.” Click [Next].

5 Check the radio button to the left of “Search

for a suitable driver for my device. (Recommended).” Click [Next].

The window that appears enables you to select a location in which to install the driver.

4 Click [Next].

The window that appears enables you to select the search method.

5 Check the radio button to the left of “Search

for the best driver for your device. (Recommended).” Click [Next].

The window that appears enables you to select a location in which to install the driver.

6 Check the “Specify a location” box, click

“Browse..”, then specify the USBdrv directory of the CD-ROM drive (such as D:\USBdrv_\) and continue the installation.

7 When the system detects the driver on the

CD-ROM and is ready for installation, an appropriate message will appear on the screen. Make sure that the “YAMAHA USB MIDI Driver” is listed, and click [Next]. The installation process will begin.

8 When installation is complete, a message

indicating so appears. Click [Finish].

NOTE

• Some computers may take about ten seconds to show this screen after the installation is complete.

6 Check the “CD-ROM drives” box and

uncheck all other items. Click [Next].

7 When the installation is complete, the sys-

tem displays “Completing the Found New Hardware Wizard.” Click [Finish].

8 Restart the computer.

The driver has been installed.

72 DGX-205/203, PSR-295/293 Owner’s Manual

Page 73

• You will need to log in with administrator (root) privileges in order to install Musicsoft Downloader on a computer running Windows 2000 or XP.

• You will need to log in with administrator (root) privileges in order to install Digital Music Notebook on a computer running Windows 2000 or XP.

IMPORTANT

• When installing the Digital Music Notebook, make sure that Internet Explorer 6.0 (with SP1) or higher is installed to your computer.

IMPORTANT

• Credit card settlement is required to purchase Digital Music Notebook content. Credit card processing may not be possible for some areas, so please check with your local authorities to make sure that your credit card can be used.

IMPORTANT

• Use of the DMN (Digital Music Notebook) is governed by the SIBELIUS SCORCH LICENSE AGREEMENT, which the purchaser fully agrees to when using the application. Please read carefully the AGREEMENT at the end of this manual before using the application.

NOTE

• If the start window does not appear automatically, double click your “My Computer” folder to open it. Right-click the CD-ROM icon and select “Open” from the pop-up menu. Double click “Start.exe” and proceed to step 2, below.

NOTE

• Only Musicsoft Downloader can be used to transfer ﬁles between this instrument and a computer. No other ﬁle transfer application can be used.

IMPORTANT

■

Accessory CD-ROM Installation Guide Reference

Installing the driver on Windows XP

Start the computer.

Select [Start] ➔ [Control Panel]. If the control panel appears as “Pick a category”, click “Switch to Classic View” in the upper left of the window. All control panels and icons will be displayed.

Go to [System] ➔ [Hardware] ➔ [Driver Signing Options] and check the radio button to the left of “Ignore” and click [OK].

Click the [OK] button to close System Properties, and then click “X” in the upper right of the window to close the Control Panel.

Insert the supplied CD-ROM into the CDROM drive. A start window will appear automatically. Close the window.

First, make sure the POWER switch on the instrument is set to OFF, then use a USB cable to connect the USB connector of the computer to the USB connector of the instrument. When the instrument is turned on, the computer automatically displays the “Found New Hardware Wizard.”

NOTE

• Some computers may take a few minutes to show this screen.

Installing the Musicsoft Downloader and Digital Music Notebook Applications

Insert the Accessory CD-ROM into your computer’s CD-ROM drive. The start window will appear automatically showing software applications.

● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ●

Check the radio button to the left of “Install

the software automatically. (Recommended).” Click [Next]. The system starts the installation.

When the installation is complete, the system displays “Completing the Found New Hardware Wizard.” Click [Finish].

NOTE

• Some computers may take about a few minutes to show this screen after the installation is complete.

Restart the computer. The driver has been installed.

The driver has been installed.

Click [Musicsoft Downloader] or [Digital

Music Notebook].

Click the [install] button, and follow the onscreen instructions to install the software.

For Digital Music Notebook operating instructions see the help menu: launch the Digital Music Notebook application and click “Help”.

For Musicsoft Downloader operating instructions see the Help menu: launch the Musicsoft Downloader application and click “Help”.

* You can obtain the latest version of the Musicsoft

Downloader at the following Internet URL.

http://music.yamaha.com/download/

DGX-205/203, PSR-295/293 Owner’s Manual

Page 74

Reference Accessory CD-ROM Installation Guide

SOFTWARE LICENSING AGREEMENT

The following is a legal agreement between you, the end user, and Yamaha Corporation (“Yamaha”). The enclosed Yamaha software program is licensed by Yamaha to the original purchaser for use only on the terms set forth herein. Please read this licensing agreement with care. Opening this package indicates that you accept all terms outlined herein. If you do not agree to the terms, return this package unopened to Yamaha for a full refund. In the event that you obtained the enclosed Yamaha software program(s) as a part of a software package or software bundled with a hardware product, you may not return the enclosed Yamaha software program(s) to Yamaha.

1. GRANT OF LICENSE AND COPYRIGHT

Yamaha grants you, the original purchaser, the right to use one copy of the enclosed software program and data (“SOFTWARE”) on a single-user computer system. You may not use it on more than one computer or computer terminal. The SOFTWARE is owned by Yamaha and is protected by Japanese copyright laws and all applicable international treaty provisions. You are entitled to claim ownership of the media in which the SOFTWARE is included. Therefore, you must treat the SOFTWARE like any other copyrighted materials.

2. RESTRICTIONS

The SOFTWARE program is copyrighted. You may not engage in reverse engineering or reproduction of the SOFTWARE by other conceivable methods. You may not reproduce, modify, change, rent, lease, resell, or distribute the SOFTWARE in whole or in part, or create derivative works from the SOFTWARE. You may not transmit or network the SOFTWARE with other computers. You may transfer ownership of the SOFTWARE and the accompanying written materials on a permanent basis provided that you retain no copies and the recipient agrees to the terms of the licensing agreement.

3. TERMINATION

The licensing condition of the software program becomes effective on the day that you receive the SOFTWARE. If any one of the copyright laws or clauses of the licensing conditions is violated, the licensing agreement shall be terminated automatically without notice from Yamaha. In this case, you must destroy the licensed SOFTWARE and its copies immediately.

4. PRODUCT WARRANTY

Yamaha warrants to the original purchaser that if the SOFTWARE, when used in normal conditions, will not perform the functions described in the manual provided by Yamaha, the sole remedy will be that Yamaha will replace any media which proves defective in materials or workmanship on an exchange basis without charge. Except as expressly set forth above, the SOFTWARE is provided “as is,” and no other warranties, either expressed or implied, are made with respect to this software, including, without limitation the implied warranties of merchantability and ﬁtness for a particular purpose.

5. LIMITED LIABILITY

Your sole remedies and Yamaha’s entire liability are as set forth above. In no event will Yamaha be liable to you or any other person for any damages, including without limitation any incidental or consequential damages, expenses, lost proﬁts, lost savings or other damages arising out of the use or inability to use such SOFTWARE even if Yamaha or an authorized dealer has been advised of the possibility of such damages, or for any claim by any other party.

6. GENERAL

This license agreement shall be interpreted according to and governed by Japanese laws.

74 DGX-205/203, PSR-295/293 Owner’s Manual

Page 75

■

Appendix

Troubleshooting

For the DGX-205/203, PSR-295/293

Problem

When the instrument is turned on or off, a popping sound is temporarily produced.

When using a mobile phone, noise is produced.

There is no sound even when the keyboard is played or when a song or style is being played back.

Playing keys in the right hand area of the keyboard does not produce any sound.

• The volume is too soft.

• The sound quality is poor.

• The rhythm stops unexpectedly or will not play.

• The recorded data of the song, etc. does not play correctly.

• The LCD display suddenly goes dark, and all panel settings are reset.

The style or song does not play back when the [START/ STOP] button is pressed.

The style does not sound properly.

No rhythm accompaniment plays when the [START/ STOP] button is pressed after selecting style number 112 or a style between 124 and 135 (Pianist).

Not all of the voices seem to sound, or the sound seems to be cut off.

The footswitch (for sustain) seems to produce the opposite effect. For example, pressing the footswitch cuts off the sound and releasing it sustains the sounds.

The sound of the voice changes from note to note.

The wrong notes sound when the keyboard is played.

The ACMP ON indicator does not appear when the [ACMP ON/OFF] button is pressed.

There is no harmony sound.

This is normal and indicates that the instrument is receiving electrical power.

Using a mobile phone in close proximity to the instrument may produce interference. To prevent this, turn off the mobile phone or use it further away from the instrument.

Check that nothing is connected to the PHONES/OUTPUT jack on the rear panel. When a set of headphones is plugged into this jack, no sound is output.

Check the Local Control on/off. (See page 66.)

When using the Dictionary function (page 55), the keys in the right hand area are used only for entering the chord root and type.

The batteries are low or dead. Replace all six batteries with completely new ones, or use the optional AC adaptor.

Is External Clock set to ON? Make sure External Clock is set to OFF; refer to “External Clock” on page 66.

Make sure that the Style Volume (page 63) is set to an appropriate level.

Is the split point set at an appropriate key for the cords you are playing? Set the split point at an appropriate key (page 51). Is the “ACMP ON” indicator showing in the display? If it is not showing press the [ACMP ON/OFF] button so that it does show.

This is not a malfunction. Style number 112 and style numbers 124 – 135 (Pianist) have no rhythm parts, so no rhythm will play. The other parts will begin playing when you play a chord in the accompaniment range of the keyboard if style playback is turned on.

The instrument is polyphonic up to a maximum of 32 notes. If the Dual voice or Split voice is being used and a style or song is playing back at the same time, some notes/sounds may be omitted (or “stolen”) from the accompaniment or song.

The polarity of the footswitch is reversed. Make sure that the footswitch plug is properly connected to the SUSTAIN jack before turning on the power.

This is normal. The AWM tone generation method uses multiple recordings (samples) of an instrument across the range of the keyboard; thus, the actual sound of the voice may be slightly different from note to note.

Perhaps the performance assistant technology is turned on. Press the [PERFORMANCE ASSISTANT] button to turn it off.

Is the [STYLE] button lit? Always press the [STYLE] button ﬁrst when you are going to use any style-related function.

The harmony effects (01 – 26) behave differently according to their type. Types 01 – 05 function when style playback is on, chords are played in the accompaniment range of the keyboard, and a melody is played in the righthand range. Types 06 – 26 will function whether style playback is on or off. For types 06 = 12 you need to play two notes at the same time.

Possible Cause and Solution

DGX-205/203, PSR-295/293 Owner’s Manual

Page 76

Troubleshooting

■ For the included software

The driver cannot be installed.

• Is the USB cable connected correctly?

Check the USB cable connection. Disconnect the USB cable, then connect it again.

• Is the USB function enabled on your computer?

When you connect the instrument to the computer for the ﬁrst time, if the “Add New Hardware Wizard” does not appear, the USB function on the computer may be disabled. Perform the following steps.

1 Select [Control Panel] ➔ [System] ➔ [Device Manager]

(for Windows 98/Me), or select [Control Panel]* ➔ [System] ➔ [Hardware] ➔ [Device Manager] (for Windows 2000/XP).

* Classic View only in Windows XP.

2 Make sure that no “!” or “x” marks appear at “Universal

serial bus controller” or “USB Root Hub.” If you see an “!” or “x” mark, the USB controller is disabled.

• Is any unknown device registered?

If driver installation fails, the instrument will be marked as an “Unknown device,” and you will not be able to install the driver. Delete the “Unknown device” by following the steps below.

•Are you using the latest USB MIDI driver? The latest driver can be downloaded from the following web site.

http://music.yamaha.com/download/

Playback response is delayed.

• Does your computer satisfy the system requirements?

• Is any other application or device driver running?

Cannot suspend or resume the computer correctly.

• Do not suspend the computer while the MIDI application is running.

If you are using Windows 2000, you may not be able to suspend/resume normally, depending on the particular environment (USB Host Controller, etc.). Even so, simply disconnecting and connecting the USB cable will allow you to use the instrument functions again.

1 Select [Control Panel] ➔ [System] ➔ [Device Manager]

(for Windows 98/Me), or select [Control Panel]* ➔ [System] ➔ [Hardware] ➔ [Device Manager] (for Windows 2000/XP).

* Classic View only in Windows XP.

2 Look for “Other devices” in the menu “View devices by

type.”

3 If you ﬁnd “Other devices,” double-click it to extend the

tree to look for “Unknown device.” If one appears, select it and click the [Remove] button.

4 Remove the USB cable from the instrument, and make

the connection again.

5 Install the driver again.

• Windows 98/Me users .......... see page 72

• Windows 2000 users ............ see page 72

• Windows XP users ............... see page 73

When controlling the instrument from your computer via USB, the instrument does not operate correctly or no sound is heard.

• Did you install the driver? (page 71)

• Is the USB cable connected correctly?

•Are the volume settings of the instrument, playback device, and application program set to the appropriate levels?

•Have you selected an appropriate port in the sequence software?

How can I delete or re-install the driver?

Windows Me/98

1 When the instrument is recognized correctly, double-

click “System” in the Control Panel to open the System window.

2 Double-click the “Device Manager” tab, select “YAMAHA

USB MIDI Driver” and delete it.

3 Use the MS-DOS prompt or Explorer to delete the fol-

lowing three ﬁles.

NOTE

•To delete these ﬁles using Explorer, select “Folder Options” from the Tool (View) menu, and select “Show all ﬁles (and folders).”

• \WINDOWS\INF\OTHER\***.INF

• \WINDOWS\SYSTEM\Xgusb.drv

• \WINDOWS\SYSTEM\Ymidusb.sys

4 Disconnect the USB cable. 5 Restart the computer. 6 Re-install the driver.

76 DGX-205/203, PSR-295/293 Owner’s Manual

Page 77

Speciﬁcations

Keyboards

• DGX-205/203: 76 standard-size keys (E0 – G6), with Touch Response.

• PSR-295/293: 61 standard-size keys (C1 – C6), with Touch Response.

Display

• Large multi-function LCD display (backlit)

Setup

• STANDBY/ON

• MASTER VOLUME: MIN - MAX

Panel Controls

• SONG, VOICE, STYLE, EASY SONG ARRANGER, PERFORMANCE ASSISTANT, PC, LESSON L/R, LESSON MODE, LESSON REPEAT & LEARN, METRONOME, PORTABLE GRAND, DEMO, FUNCTION, TOUCH, HARMONY, DUAL, SPLIT, TEMPO/TAP, [0] – [9], [+], [–], CATEGORY, Dial, ACMP ON/OFF, SYNC STOP, SYNC START, START/STOP, INTRO/ENDING/rit., MAIN/AUTO FILL, REGIST. MEMORY ([●] (MEMORY/BANK), [1], [2]), SONG MEMORY (REC, [1] – [5], [A])

Realtime Control

• Pitch Bend Wheel (DGX-205/203 only)

Voice

• 114 panel voices + 12 drum kits + 359 XGlite voices + 2 XGlite optional voices

• Polyphony: 32

• DUAL

• SPLIT

Style

• 135 Preset Styles

• Style Control: ACMP ON/OFF, SYNC STOP,

• Fingering: Multi fingering

• Style Volume

SYNC START, START/STOP, INTRO/ENDING/rit., MAIN/AUTO FILL

Education Feature

• Dictionary

• Lesson 1-3, Lesson Repeat & Learn

Registration Memory

•8 banks x 2 types

Function

• VOLUME: Style Volume, Song Volume

• OVERALL: Tuning, Transpose, Split Point, Touch Sensi-

MAIN VOICE: Volume, Octave, Pan, Reverb Send Level,

•

• DUAL VOICE: Voice, Volume, Octave, Pan, Reverb Send

• SPLIT VOICE: Voice, Volume, Octave, Pan, Reverb Send

• EFFECT: Reverb Type, Chorus Type, Panel Sustain

• HARMONY: Harmony Type, Harmony Volume

• PC: PC1/PC2/Off

• MIDI: Local On/Off, External Clock, Initial Setup

• METRONOME: Time Signature, Metronome Volume

• LESSON: Lesson Track (R), Lesson Track (L)

• UTILITY: Grade, Demo Cancel

tivity, Pitch Bend Range

Chorus Send Level

Level, Chorus Send Level

Send, Keyboard Out, Style Out, Song Out, Bulk Send

(DGX-205/203 only)

Effects

• Reverb: 9 types

• Chorus: 4 types

• Harmony: 26 types

Song

• 30 Preset Songs + 5 User Songs + Accessory CD-ROM Songs (70)

• Song Clear, Track Clear

• Song Volume

Performance assistant technology

Recording

• Song

User Song: 5 Songs Recording Tracks: 1, 2, 3, 4, 5, STYLE

MIDI

• Local On/Off • Initial Setup Send • External Clock

• Keyboard Out • Style Out • Song Out

• Bulk Send

Auxiliary jacks

• PHONES/OUTPUT, DC IN 12V, USB, SUSTAIN

Ampliﬁer

• DGX-205/203: 6W + 6W

• PSR-295/293: 3W + 3W

Speakers

• 12cm x 2 + 3cm x 2

Power Consumption

• DGX-205/203: 20W (When using PA-5D power adaptor)

• PSR-295/293: 16W (When using PA-3C power adaptor)

Power Supply

• Adaptor: Yamaha PA-5D AC power adaptor

(DGX-205/203) Yamaha PA-3C AC power adaptor (PSR-295/293)

• Batteries: Six “D” size, R20P (LR20) or equivalent

batteries

Dimensions (W x D x H)

• DGX-205/203: 1,178 x 412 x 150 mm (46-3/8" x 16-1/4" x 5-7/8")

• PSR-295/293: 952 x 388 x 146 mm (37-1/2" x 15-1/4" x 5-3/4")

Weight

• DGX-205/203: 8.8kg (19 lbs. 6 oz.) (not including batteries)

• PSR-295/293: 7.0kg (15 lbs. 7 oz.) (not including batteries)

Supplied Accessories

• Music Rest

• Accessory CD-ROM

• Owner’s Manual

• Song Book

Optional Accessories

• AC Power Adaptor: PA-5D/PA-5C (DGX-205/203)

PA-3C (PSR-295/293)

• Footswitch: FC4/FC5

• Keyboard Stand: LW-15/LW-16 (DGX-205/203)

L-2C/L-2L (PSR-295/293)

* Specifications and descriptions in this owner’s manual are for

information purposes only. Yamaha Corp. reserves the right to change or modify products or specifications at any time without prior notice. Since specifications, equipment or options may not be the same in every locale, please check with your Yamaha dealer.

DGX-205/203, PSR-295/293 Owner’s Manual 77

Page 78

Voice List

■ Maximum Polyphony • • • • • • • • • • • • • • • • • • • •

The instrument has 32-note maximum polyphony. This means that it can play a maximum of up to 32 notes at once, regardless of what functions are used. Auto accompaniment uses a number of the available notes, so when auto accompaniment is used the total number of available notes for playing on the keyboard is correspondingly reduced. The same applies to the Split Voice and Song functions. If the maximum polyphony is exceeded, earlier played notes will be cut off and the most recent notes have priority (last note priority).

● Panel Voice List

Voice

No.

001 000 112 001 Grand Piano 002 000 112 002 Bright Piano 003 000 112 004 Honky-tonk Piano 004 000 112 003 MIDI Grand Piano 005 000 113 003 CP 80 006 000 112 007 Harpsichord

007 000 114 005 Cool! Galaxy Electric Piano 008 000 112 005 Funky Electric Piano 009 000 112 006 DX Modern Electric Piano 010 000 113 006 Hyper Tines 011 000 114 006 Venus Electric Piano 012 000 112 008 Clavi

013 000 118 019 Cool! Organ 014 000 112 017 Jazz Organ 1 015 000 113 017 Jazz Organ 2 016 000 112 018 Click Organ 017 000 116 017 Bright Organ 018 000 112 019 Rock Organ 019 000 114 019 Purple Organ 020 000 118 017 16'+2' Organ 021 000 119 017 16'+4' Organ 022 000 114 017 Theater Organ 023 000 112 020 Church Organ 024 000 113 020 Chapel Organ 025 000 112 021 Reed Organ

026 000 113 022 Traditional Accordion 027 000 112 022 Musette Accordion 028 000 113 024 Bandoneon 029 000 112 023 Harmonica

030 000 112 025 Classical Guitar 031 000 112 026 Folk Guitar 032 000 113 026 12Strings Guitar 033 000 112 027 Jazz Guitar 034 000 113 027 Octave Guitar 035 000 112 028 Clean Guitar 036 000 117 028 60’s Clean Guitar 037 000 112 029 Muted Guitar 038 000 112 030 Overdriven Guitar 039 000 112 031 Distortion Guitar

040 000 112 033 Acoustic Bass 041 000 112 034 Finger Bass 042 000 112 035 Pick Bass 043 000 112 036 Fretless Bass 044 000 112 037 Slap Bass 045 000 112 039 Synth Bass 046 000 113 039 Hi-Q Bass 047 000 113 040 Dance Bass

Bank Select

MSB

(0 - 127)

LSB

(0 - 127)

MIDI Program Change# (1 - 128)

PIANO

E.PIANO

ORGAN

ACCORDION

GUITAR

BASS

Voice Name

Voice

No.

048 000 112 049 String Ensemble 049 000 112 050 Chamber Strings 050 000 112 051 Synth Strings 051 000 113 050 Slow Strings 052 000 112 045 Tremolo Strings 053 000 112 046 Pizzicato Strings 054 000 112 041 Violin 055 000 112 043 Cello 056 000 112 044 Contrabass 057 000 112 106 Banjo 058 000 112 047 Harp 059 000 112 056 Orchestra Hit

060 000 112 053 Choir 061 000 113 053 Vocal Ensemble 062 000 112 054 Vox Humana 063 000 112 055 Air Choir

064 000 117 067 Sweet! Tenor Sax 065 000 113 065 Sweet! Soprano Sax 066 000 112 067 Tenor Sax 067 000 112 066 Alto Sax 068 000 112 065 Soprano Sax 069 000 112 068 Baritone Sax 070 000 114 067 Breathy Tenor Sax 071 000 112 069 Oboe 072 000 112 072 Clarinet 073 000 112 070 English Horn 074 000 112 071 Bassoon

075 000 115 057 Sweet! Trumpet 076 000 112 057 Trumpet 077 000 112 060 Muted Trumpet 078 000 112 058 Trombone 079 000 113 058 Trombone Section 080 000 112 061 French Horn 081 000 112 059 Tuba

082 000 112 062 Brass Section 083 000 113 062 Big Band Brass 084 000 119 062 Mellow Horns 085 000 112 063 Synth Brass 086 000 113 063 80’s Brass 087 000 114 063 Techno Brass

088 000 114 074 Sweet! Flute 089 000 113 076 Sweet! Pan Flute 090 000 112 074 Flute 091 000 112 073 Piccolo 092 000 112 076 Pan Flute 093 000 112 075 Recorder 094 000 112 080 Ocarina

NOTE

• The Voice List includes MIDI program change numbers for each voice. Use these program change numbers when playing the instrument via MIDI from an external device.

• Program Numbers 001 to 128 directly relate to MIDI Program Change Numbers 000 to 127. That is, Program Numbers and Program Change Numbers differ by a value of 1. Remember to take this into consideration.

• Some voices may sound continuously or have a long decay after the notes have been released while the sustain pedal (footswitch) is held.

Bank Select

MSB

(0 - 127)

LSB

(0 - 127)

MIDI Program Change# (1 - 128)

STRINGS

CHOIR

SAXOPHONE

TRUMPET

BRASS

FLUTE

Voice Name

78 DGX-205/203, PSR-295/293 Owner’s Manual

Page 79

Voice List

Voice

No.

095 000 112 081 Square Lead 096 000 112 082 Sawtooth Lead 097 000 112 086 Voice Lead 098 000 112 099 Star Dust 099 000 112 101 Brightness 100 000 115 082 Analogon 101 000 119 082 Fargo

102 000 112 089 Fantasia 103 000 113 101 Bell Pad 104 000 112 092 Xenon Pad 105 000 112 095 Equinox 106 000 113 090 Dark Moon

107 000 112 012 Vibraphone 108 000 112 013 Marimba 109 000 112 014 Xylophone 110 000 112 115 Steel Drums 111 000 112 009 Celesta 112 000 112 011 Music Box 113 000 112 015 Tubular Bells 114 000 112 048 Timpani

115 127 000 001 Standard Kit 1 116 127 000 002 Standard Kit 2 117 127 000 009 Room Kit 118 127 000 017 Rock Kit 119 127 000 025 Electronic Kit 120 127 000 026 Analog Kit 121 127 000 028 Dance Kit 122 127 000 033 Jazz Kit 123 127 000 041 Brush Kit 124 127 000 049 Symphony Kit 125 126 000 001 SFX Kit 1 126 126 000 002 SFX Kit 2

Bank Select

MSB

(0 - 127)

LSB

(0 - 127)

MIDI Program Change# (1 - 128)

SYNTH LEAD

SYNTH PAD

PERCUSSION

DRUM KITS

Voice Name

● XGlite Voice/XGlite Optional Voice* List

Voice

No.

127 000 000 001 Grand Piano 128 000 001 001 Grand Piano KSP 129 000 040 001 Piano Strings 130 000 041 001 Dream 131 000 000 002 Bright Piano 132 000 001 002 Bright Piano KSP 133 000 000 003 Electric Grand Piano 134 000 001 003 Electric Grand Piano KSP 135 000 032 003 Detuned CP80 136 000 000 004 Honky-tonk Piano 137 000 001 004 Honky-tonk Piano KSP 138 000 000 005 Electric Piano 1 139 000 001 005 Electric Piano 1 KSP 140 000 032 005 Chorus Electric Piano 1 141 000 000 006 Electric Piano 2 142 000 001 006 Electric Piano 2 KSP

*143 000 032 006 Chorus Electric Piano 2

144 000 041 006 DX + Analog Electric Piano 145 000 000 007 Harpsichord 146 000 001 007 Harpsichord KSP 147 000 035 007 Harpsichord 3 148 000 000 008 Clavi 149 000 001 008 Clavi KSP

150 000 000 009 Celesta 151 000 000 010 Glockenspiel 152 000 000 011 Music Box

Bank Select

MSB

(0 - 127)

LSB

(0 - 127)

MIDI Program Change# (1 - 128)

PIANO

CHROMATIC

Voice Name

Voice

No.

153 000 064 011 Orgel 154 000 000 012 Vibraphone 155 000 001 012 Vibraphone KSP 156 000 000 013 Marimba 157 000 001 013 Marimba KSP 158 000 064 013 Sine Marimba 159 000 097 013 Balimba 160 000 098 013 Log Drums 161 000 000 014 Xylophone 162 000 000 015 Tubular Bells 163 000 096 015 Church Bells 164 000 097 015 Carillon 165 000 000 016 Dulcimer 166 000 035 016 Dulcimer 2 167 000 096 016 Cimbalom 168 000 097 016 Santur

169 000 000 017 Drawbar Organ 170 000 032 017 Detuned Drawbar Organ 171 000 033 017 60’s Drawbar Organ 1 172 000 034 017 60’s Drawbar Organ 2 173 000 035 017 70’s Drawbar Organ 1 174 000 037 017 60’s Drawbar Organ 3 175 000 040 017 16+2' 2/3 176 000 064 017 Organ Bass 177 000 065 017 70’s Drawbar Organ 2 178 000 066 017 Cheezy Organ 179 000 067 017 Drawbar Organ 3 180 000 000 018 Percussive Organ 181 000 024 018 70’s Percussive Organ 182 000 032 018 Detuned Percussive Organ 183 000 033 018 Light Organ 184 000 037 018 Percussive Organ 2 185 000 000 019 Rock Organ 186 000 064 019 Rotary Organ 187 000 065 019 Slow Rotary 188 000 066 019 Fast Rotary 189 000 000 020 Church Organ 190 000 032 020 Church Organ 3 191 000 035 020 Church Organ 2 192 000 040 020 Notre Dame 193 000 064 020 Organ Flute 194 000 065 020 Tremolo Organ Flute 195 000 000 021 Reed Organ 196 000 040 021 Puff Organ 197 000 000 022 Accordion 198 000 000 023 Harmonica 199 000 032 023 Harmonica 2 200 000 000 024 Tango Accordion 201 000 064 024 Tango Accordion 2

202 000 000 025 Nylon Guitar 203 000 043 025 Velocity Guitar Harmonics 204 000 096 025 Ukulele 205 000 000 026 Steel Guitar 206 000 035 026 12-string Guitar 207 000 040 026 Nylon & Steel Guitar 208 000 041 026 209 000 096 026 Mandolin 210 000 000 027 Jazz Guitar 211 000 032 027 Jazz Amp 212 000 000 028 Clean Guitar 213 000 032 028 Chorus Guitar 214 000 000 029 Muted Guitar 215 000 040 029 Funk Guitar 1 216 000 041 029 Muted Steel Guitar 217 000 045 029 Jazz Man 218 000 000 030 Overdriven Guitar 219 000 043 030 Guitar Pinch 220 000 000 031 Distortion Guitar

Bank Select

MSB

(0 - 127)

LSB

(0 - 127)

MIDI

Program

Change#

(1 - 128)

ORGAN

GUITAR

Voice Name

Steel Guitar with Body Sound

DGX-205/203, PSR-295/293 Owner’s Manual 79

Page 80

Voice List

Voice

No.

221 000 040 031 Feedback Guitar 222 000 041 031 Feedback Guitar 2 223 000 000 032 Guitar Harmonics 224 000 065 032 Guitar Feedback 225 000 066 032 Guitar Harmonics 2

226 000 000 033 Acoustic Bass 227 000 040 033 Jazz Rhythm 228 000 045 033 229 000 000 034 Finger Bass 230 000 018 034 Finger Dark 231 000 040 034 232 000 043 034 Finger Slap Bass 233 000 045 034 Finger Bass 2 234 000 065 034 Modulated Bass 235 000 000 035 Pick Bass 236 000 028 035 Muted Pick Bass 237 000 000 036 Fretless Bass 238 000 032 036 Fretless Bass 2 239 000 033 036 Fretless Bass 3 240 000 034 036 Fretless Bass 4 241 000 000 037 Slap Bass 1 242 000 032 037 Punch Thumb Bass 243 000 000 038 Slap Bass 2 244 000 043 038 Velocity Switch Slap 245 000 000 039 Synth Bass 1 246 000 040 039 Techno Synth Bass 247 000 000 040 Synth Bass 2 248 000 006 040 Mellow Synth Bass 249 000 012 040 Sequenced Bass 250 000 018 040 Click Synth Bass 251 000 019 040 Synth Bass 2 Dark

*252 000 040 040 Modular Synth Bass

253 000 041 040 DX Bass

254 000 000 041 Violin 255 000 008 041 Slow Violin 256 000 000 042 Viola 257 000 000 043 Cello 258 000 000 044 Contrabass 259 000 000 045 Tremolo Strings 260 000 008 045 Slow Tremolo Strings 261 000 040 045 Suspense Strings 262 000 000 046 Pizzicato Strings 263 000 000 047 Orchestral Harp 264 000 040 047 Yang Chin 265 000 000 048 Timpani

266 000 000 049 Strings 1 267 000 003 049 Stereo Strings 268 000 008 049 Slow Strings 269 000 035 049 60’s Strings 270 000 040 049 Orchestra 271 000 041 049 Orchestra 2 272 000 042 049 Tremolo Orchestra 273 000 045 049 Velocity Strings 274 000 000 050 Strings 2 275 000 003 050 Stereo Slow Strings 276 000 008 050 Legato Strings 277 000 040 050 Warm Strings 278 000 041 050 Kingdom 279 000 000 051 Synth Strings 1 280 000 000 052 Synth Strings 2 281 000 000 053 Choir Aahs 282 000 003 053 Stereo Choir 283 000 032 053 Mellow Choir 284 000 040 053 Choir Strings 285 000 000 054 Voice Oohs 286 000 000 055 Synth Voice 287 000 040 055 Synth Voice 2

Bank Select

MSB

(0 - 127)

LSB

(0 - 127)

MIDI Program Change# (1 - 128)

BASS

STRING

ENSEMBLE

Voice Name

Velocity Crossfade Upright Bass

Bass & Distorted Electric Guitar

Voice

No.

288 000 041 055 Choral 289 000 064 055 Analog Voice 290 000 000 056 Orchestra Hit 291 000 035 056 Orchestra Hit 2 292 000 064 056 Impact

293 000 000 057 Trumpet 294 000 032 057 Warm Trumpet 295 000 000 058 Trombone 296 000 018 058 Trombone 2 297 000 000 059 Tuba 298 000 000 060 Muted Trumpet 299 000 000 061 French Horn 300 000 006 061 French Horn Solo 301 000 032 061 French Horn 2 302 000 037 061 Horn Orchestra 303 000 000 062 Brass Section 304 000 035 062 305 000 000 063 Synth Brass 1 306 000 020 063 Resonant Synth Brass 307 000 000 064 Synth Brass 2 308 000 018 064 Soft Brass 309 000 041 064 Choir Brass

310 000 000 065 Soprano Sax 311 000 000 066 Alto Sax 312 000 040 066 Sax Section 313 000 000 067 Tenor Sax 314 000 040 067 Breathy Tenor Sax 315 000 000 068 Baritone Sax 316 000 000 069 Oboe 317 000 000 070 English Horn 318 000 000 071 Bassoon 319 000 000 072 Clarinet

320 000 000 073 Piccolo 321 000 000 074 Flute 322 000 000 075 Recorder 323 000 000 076 Pan Flute 324 000 000 077 Blown Bottle 325 000 000 078 Shakuhachi 326 000 000 079 Whistle 327 000 000 080 Ocarina

328 000 000 081 Square Lead 329 000 006 081 Square Lead 2 330 000 008 081 LM Square 331 000 018 081 Hollow 332 000 019 081 Shroud 333 000 064 081 Mellow 334 000 065 081 Solo Sine 335 000 066 081 Sine Lead 336 000 000 082 Sawtooth Lead 337 000 006 082 Sawtooth Lead 2 338 000 008 082 Thick Sawtooth 339 000 018 082 Dynamic Sawtooth 340 000 019 082 Digital Sawtooth 341 000 020 082 Big Lead 342 000 096 082 Sequenced Analog 343 000 000 083 Calliope Lead 344 000 065 083 Pure Pad 345 000 000 084 Chiff Lead 346 000 000 085 Charang Lead 347 000 064 085 Distorted Lead 348 000 000 086 Voice Lead 349 000 000 087 Fifths Lead 350 000 035 087 Big Five 351 000 000 088 Bass & Lead 352 000 016 088 Big & Low 353 000 064 088 Fat & Perky

Bank Select

MSB

(0 - 127)

LSB

(0 - 127)

MIDI

Program

Change#

(1 - 128)

BRASS

REED

PIPE

SYNTH LEAD

Voice Name

Tr umpet & Trombone Section

80 DGX-205/203, PSR-295/293 Owner’s Manual

Page 81

Voice List

Voice

No.

354 000 065 088 Soft Whirl

355 000 000 089 New Age Pad 356 000 064 089 Fantasy 357 000 000 090 Warm Pad 358 000 000 091 Poly Synth Pad 359 000 000 092 Choir Pad 360 000 066 092 Itopia 361 000 000 093 Bowed Pad 362 000 000 094 Metallic Pad 363 000 000 095 Halo Pad 364 000 000 096 Sweep Pad

365 000 000 097 Rain 366 000 065 097 African Wind 367 000 066 097 Carib 368 000 000 098 Sound Track 369 000 027 098 Prologue 370 000 000 099 Crystal 371 000 012 099 Synth Drum Comp 372 000 014 099 Popcorn 373 000 018 099 Tiny Bells 374 000 035 099 Round Glockenspiel 375 000 040 099 Glockenspiel Chimes 376 000 041 099 Clear Bells 377 000 042 099 Chorus Bells 378 000 065 099 Soft Crystal 379 000 070 099 Air Bells 380 000 071 099 Bell Harp 381 000 072 099 Gamelimba 382 000 000 100 Atmosphere 383 000 018 100 Warm Atmosphere 384 000 019 100 Hollow Release 385 000 040 100 Nylon Electric Piano 386 000 064 100 Nylon Harp 387 000 065 100 Harp Vox 388 000 066 100 Atmosphere Pad 389 000 000 101 Brightness 390 000 000 102 Goblins 391 000 064 102 Goblins Synth 392 000 065 102 Creeper 393 000 067 102 Ritual 394 000 068 102 To Heaven 395 000 070 102 Night 396 000 071 102 Glisten 397 000 096 102 Bell Choir 398 000 000 103 Echoes 399 000 000 104 Sci-Fi

400 000 000 105 Sitar 401 000 032 105 Detuned Sitar 402 000 035 105 Sitar 2 403 000 097 105 Tamboura 404 000 000 106 Banjo 405 000 028 106 Muted Banjo 406 000 096 106 Rabab 407 000 097 106 Gopichant 408 000 098 106 Oud 409 000 000 107 Shamisen 410 000 000 108 Koto 411 000 096 108 Taisho-kin 412 000 097 108 Kanoon 413 000 000 109 Kalimba 414 000 000 110 Bagpipe 415 000 000 111 Fiddle 416 000 000 112 Shanai

417 000 000 113 Tinkle Bell 418 000 096 113 Bonang 419 000 097 113 Altair

Bank Select

MSB

(0 - 127)

LSB

(0 - 127)

MIDI Program Change# (1 - 128)

SYNTH PAD

SYNTH EFFECTS

WORLD

PERCUSSIVE

Voice Name

Voice

No.

420 000 098 113 Gamelan Gongs 421 000 099 113 Stereo Gamelan Gongs 422 000 100 113 Rama Cymbal 423 000 000 114 Agogo 424 000 000 115 Steel Drums 425 000 097 115 Glass Percussion 426 000 098 115 Thai Bells 427 000 000 116 Woodblock 428 000 096 116 Castanets 429 000 000 117 Taiko Drum 430 000 096 117 Gran Cassa 431 000 000 118 Melodic Tom 432 000 064 118 Melodic Tom 2 433 000 065 118 Real Tom 434 000 066 118 Rock Tom 435 000 000 119 Synth Drum 436 000 064 119 Analog Tom 437 000 065 119 Electronic Percussion 438 000 000 120 Reverse Cymbal

439 000 000 121 Fret Noise 440 000 000 122 Breath Noise 441 000 000 123 Seashore 442 000 000 124 Bird Tweet 443 000 000 125 Telephone Ring 444 000 000 126 Helicopter 445 000 000 127 Applause 446 000 000 128 Gunshot 447 064 000 001 Cutting Noise 448 064 000 002 Cutting Noise 2 449 064 000 004 String Slap 450 064 000 017 Flute Key Click 451 064 000 033 Shower 452 064 000 034 Thunder 453 064 000 035 Wind 454 064 000 036 Stream 455 064 000 037 Bubble 456 064 000 038 Feed 457 064 000 049 Dog 458 064 000 050 Horse 459 064 000 051 Bird Tweet 2 460 064 000 056 Maou 461 064 000 065 Phone Call 462 064 000 066 Door Squeak 463 064 000 067 Door Slam 464 064 000 068 Scratch Cut 465 064 000 069 Scratch Split 466 064 000 070 Wind Chime 467 064 000 071 Telephone Ring 2 468 064 000 081 Car Engine Ignition 469 064 000 082 Car Tires Squeal 470 064 000 083 Car Passing 471 064 000 084 Car Crash 472 064 000 085 Siren 473 064 000 086 Train 474 064 000 087 Jet Plane 475 064 000 088 Starship 476 064 000 089 Burst 477 064 000 090 Roller Coaster 478 064 000 091 Submarine 479 064 000 097 Laugh 480 064 000 098 Scream 481 064 000 099 Punch 482 064 000 100 Heartbeat 483 064 000 101 Footsteps 484 064 000 113 Machine Gun 485 064 000 114 Laser Gun 486 064 000 115 Explosion 487 064 000 116 Firework

The voice number with an asterisk (*) is XGlite optional voice.

Bank Select

MSB

(0 - 127)

LSB

(0 - 127)

DGX-205/203, PSR-295/293 Owner’s Manual 81

MIDI

Program

Change#

(1 - 128)

SOUND EFFECTS

Voice Name

Page 82

Drum Kit List

•“ ” indicates that the drum sound is the same as “Standard Kit 1”.

• Each percussion voice uses one note.

• The MIDI Note # and Note are actually one octave lower than keyboard Note # and Note. For example, in “115: Standard Kit 1”, the “Seq Click H” (Note# 36/Note C1) corresponds to (Note# 24/Note C0).

•Key Off: Keys marked “O” stop sounding the instant they are released.

•Voices with the same Alternate Note Number (*1 … 4) cannot be played simultaneously. (They are designed to be played alternately with each other.)

MSB (0 - 127) / LSB (0 - 127) / PC (1 - 128) 127/000/001 127/000/002 127/000/009 127/000/017 127/000/025 127/000/026

Keyboard MIDI

Note# Note Note# Note

25 C# 013C# -1 3 Surdo Mute 26 D 0 14 D -1 3 Surdo Open 27 D# 015D# -1 Hi Q

28 E 0 16 E -1 Whip Slap 29 F 0 17 F -1 4 Scratch Push 30 F# 018F# -1 4 Scratch Pull

F#0

31 G 0 19 G -1 Finger Snap 32 G# 020G# -1 Click Noise

G#0

33 A 0 21 A -1 Metronome Click 34 A# 022A# -1 Metronome Bell

A#0

35 B 0 23 B -1 Seq Click L 36 C 1 24 C 0 Seq Click H 37 C# 125C# 0 Brush Tap

C#1

38 D 1 26 D 0 O Brush Swirl 39 D# 127D# 0 Brush Slap

D#1

40 E 1 28 E 0 O Brush Tap Swirl Reverse Cymbal Reverse Cymbal 41 F 1 29 F 0 O Snare Roll 42 F# 130F# 0 Castanet Hi Q 2 Hi Q 2

F#1

43 G 1 31 G 0 Snare H Soft Snare H Soft 2 SD Rock H Snare L SD Rock H 44 G# 132G# 0 Sticks

G#1

45 A 1 33 A 0 Bass Drum Soft Bass Drum H Bass Drum H 46 A# 134A# 0 Open Rim Shot Open Rim Shot 2

A#1

47 B 1 35 B 0 Bass Drum Hard Bass Drum H BD Rock BD Analog L 48 C 2 36 C 1 Bass Drum Bass Drum 2 BD Rock BD Gate BD Analog H 49 C# 237C# 1 Side Stick Analog Side Stick

C#2

50 D 2 38 D 1 Snare M Snare M 2 SD Room L SD Rock L SD Rock L Analog Snare 1 51 D# 239D# 1 Hand Clap

D#2

52 E 2 40 E 1 Snare H Hard Snare H Hard 2 SD Room H SD Rock Rim SD Rock H Analog Snare 2 53 F 2 41 F 1 Floor Tom L Room Tom 1 Rock Tom 1 E Tom 1 Analog Tom 1 54 F# 242F# 11Hi-Hat Closed Analog HH Closed 1

F#2

55 G 2 43 G 1 Floor Tom H Room Tom 2 Rock Tom 2 E Tom 2 Analog Tom 2 56 G# 244G# 11Hi-Hat Pedal Analog HH Closed 2

G#2

57 A 2 45 A 1 Low Tom Room Tom 3 Rock Tom 3 E Tom 3 Analog Tom 3 58 A# 246A# 11Hi-Hat Open Analog HH Open

A#2

59 B 2 47 B 1 Mid Tom L Room Tom 4 Rock Tom 4 E Tom 4 Analog Tom 4 60 C 3 48 C 2 Mid Tom H Room Tom 5 Rock Tom 5 E Tom 5 Analog Tom 5 61 C# 349C# 2 Crash Cymbal 1 Analog Cymbal

C#3

62 D 3 50 D 2 High Tom Room Tom 6 Rock Tom 6 E Tom 6 Analog Tom 6 63 D# 351D# 2 Ride Cymbal 1

D#3

64 E 3 52 E 2 Chinese Cymbal 65 F 3 53 F 2 Ride Cymbal Cup 66 F# 354F# 2 Tambourine

F#3

67 G 3 55 G 2 Splash Cymbal 68 G# 356G# 2 Cowbell Analog Cowbell

G#3

69 A 3 57 A 2 Crash Cymbal 2 70 A# 358A# 2 Vibraslap

A#3

71 B 3 59 B 2 Ride Cymbal 2 72 C 4 60 C 3 Bongo H 73 C# 461C# 3 Bongo L

C#4

74 D 4 62 D 3 Conga H Mute Analog Conga H 75 D# 463D# 3 Conga H Open Analog Conga M

D#4

76 E 4 64 E 3 Conga L Analog Conga L 77 F 4 65 F 3 Timbale H 78 F# 466F# 3 Timbale L

F#4

79 G 4 67 G 3 Agogo H

G#4

80 G# 468G# 3 Agogo L 81 A 4 69 A 3 Cabasa

A#4

82 A# 470A# 3 Maracas Analog Maracas 83 B 4 71 B 3 O Samba Whistle H 84 C 5 72 C 4 O Samba Whistle L

C#5

85 C# 573C# 4 Guiro Short 86 D 5 74 D 4 O Guiro Long

D#5

87 D# 575D# 4 Claves Analog Claves 88 E 5 76 E 4 Wood Block H 89 F 5 77 F 4 Wood Block L

F#5

90 F# 578F# 4 Cuica Mute Scratch Push Scratch Push 91 G 5 79 G 4 Cuica Open Scratch Pull Scratch Pull

G#5

92 G# 580G# 42Triangle Mute 93 A 5 81 A 4 2 Triangle Open

A#5

94 A# 582A# 4 Shaker 95 B 5 83 B 4 Jingle Bell 96 C 6 84 C 5 Bell Tree

C#6

97 C# 685C# 5 98 D 6 86 D 5

D#6

99 D# 687D# 5

100 E 6 88 E 5 101 F 6 89 F 5

F#6

102 F# 690F# 5 103 G 6 91 G 5

Voice No. 115 116 117 118 119 120

Key Off

Alternate

assign

Standard Kit 1 Standard Kit 2 Room Kit Rock Kit Electronic Kit Analog Kit

82 DGX-205/203, PSR-295/293 Owner’s Manual

Page 83

Drum Kit List

MSB (0 - 127) / LSB (0 - 127) / PC (1 - 128) 127/000/001 127/000/028 127/000/033 127/000/041 127/000/049 126/000/001 126/000/002

Keyboard MIDI

Note# Note Note# Note

25 C# 013C# -1 3 Surdo Mute 26 D 0 14 D -1 3 Surdo Open 27 D# 015D# -1 Hi Q

28 E 0 16 E -1 Whip Slap 29 F 0 17 F -1 4 Scratch Push 30 F# 018F# -1 4 Scratch Pull

F#0

31 G 0 19 G -1 Finger Snap 32 G# 020G# -1 Click Noise

G#0

33 A 0 21 A -1 Metronome Click 34 A# 022A# -1 Metronome Bell

A#0

35 B 0 23 B -1 Seq Click L 36 C 1 24 C 0 Seq Click H 37 C# 125C# 0 Brush Tap

C#1

38 D 1 26 D 0 O Brush Swirl 39 D# 127D# 0 Brush Slap

D#1

40 E 1 28 E 0 O Brush Tap Swirl Reverse Cymbal 41 F 1 29 F 0 O Snare Roll 42 F# 130F# 0 Castanet Hi Q 2

F#1

43 G 1 31 G 0 Snare H Soft AnSD Snappy SD Jazz H Light Brush Slap L 44 G# 132G# 0 Sticks

G#1

45 A 1 33 A 0 Bass Drum Soft AnBD Dance-1 Bass Drum L 46 A# 134A# 0 Open Rim Shot AnSD OpenRim

A#1

47 B 1 35 B 0 Bass Drum Hard AnBD Dance-2 Gran Cassa 48 C 2 36 C 1 Bass Drum AnBD Dance-3 BD Jazz BD Jazz Gran Cassa Mute Cutting Noise Phone Call 49 C# 237C# 1 Side Stick Analog Side Stick Cutting Noise 2 Door Squeak

C#2

50 D 2 38 D 1 Snare M AnSD Q SD Jazz L Brush Slap Marching Sn M Door Slam 51 D# 239D# 1 Hand Clap String Slap Scratch Cut

D#2

52 E 2 40 E 1 Snare H Hard AnSD Ana+Acoustic SD Jazz M Brush Tap Marching Sn H Scratch 53 F 2 41 F 1 Floor Tom L Analog Tom 1 Jazz Tom 1 Brush Tom 1 Jazz Tom 1 Wind Chime 54 F# 242F# 11Hi-Hat Closed Analog HH Closed 3 Telephone Ring 2

F#2

55 G 2 43 G 1 Floor Tom H Analog Tom 2 Jazz Tom 2 Brush Tom 2 Jazz Tom 2 56 G# 244G# 11Hi-Hat Pedal Analog HH Closed 4

G#2

57 A 2 45 A 1 Low Tom Analog Tom 3 Jazz Tom 3 Brush Tom 3 Jazz Tom 3 58 A# 246A# 11Hi-Hat Open Analog HH Open 2

A#2

59 B 2 47 B 1 Mid Tom L Analog Tom 4 Jazz Tom 4 Brush Tom 4 Jazz Tom 4 60 C 3 48 C 2 Mid Tom H Analog Tom 5 Jazz Tom 5 Brush Tom 5 Jazz Tom 5 61 C# 349C# 2 Crash Cymbal 1 Analog Cymbal Hand Cym. L

C#3

62 D 3 50 D 2 High Tom Analog Tom 6 Jazz Tom 6 Brush Tom 6 Jazz Tom 6 63 D# 351D# 2 Ride Cymbal 1 Hand Cym.Short L

D#3

64 E 3 52 E 2 Chinese Cymbal Flute Key Click Car Engine Ignition 65 F 3 53 F 2 Ride Cymbal Cup Car Tires Squeal 66 F# 354F# 2 Tambourine Car Passing

F#3

67 G 3 55 G 2 Splash Cymbal Car Crash 68 G# 356G# 2 Cowbell Analog Cowbell Siren

G#3

69 A 3 57 A 2 Crash Cymbal 2 Hand Cym. H Train 70 A# 358A# 2 Vibraslap Jet Plane

A#3

71 B 3 59 B 2 Ride Cymbal 2 Hand Cym.Short H Starship 72 C 4 60 C 3 Bongo H 73 C# 461C# 3 Bongo L

C#4

74 D 4 62 D 3 Conga H Mute Analog Conga H Submarine 75 D# 463D# 3 Conga H Open Analog Conga M

D#4

76 E 4 64 E 3 Conga L Analog Conga L 77 F 4 65 F 3 Timbale H 78 F# 466F# 3 Timbale L

F#4

79 G 4 67 G 3 Agogo H 80 G# 468G# 3 Agogo L Shower Laugh

G#4

81 A 4 69 A 3 Cabasa Thunder Scream 82 A# 470A# 3 Maracas Analog Maracas

A#4

83 B 4 71 B 3 O Samba Whistle H 84 C 5 72 C 4 O Samba Whistle L Bubble FootSteps 85 C# 573C# 4 Guiro Short Feed

C#5

86 D 5 74 D 4 O Guiro Long 87 D# 575D# 4 Claves Analog Claves

D#5

88 E 5 76 E 4 Wood Block H 89 F 5 77 F 4 Wood Block L 90 F# 578F# 4 Cuica Mute Scratch Push

F#5

91 G 5 79 G 4 Cuica Open Scratch Pull 92 G# 580G# 42Triangle Mute

G#5

93 A 5 81 A 4 2 Triangle Open 94 A# 582A# 4 Shaker

A#5

95 B 5 83 B 4 Jingle Bell 96 C 6 84 C 5 Bell Tree Dog Machine Gun 97 C# 685C# 5 Horse Laser Gun

C#6

98 D 6 86 D 5 Bird Tweet 2 Explosion 99 D# 687D# 5 Firework

D#6

100 E 6 88 E 5 101 F 6 89 F 5 102 F# 690F# 5

F#6

103 G 6 91 G 5 Maou

Voice No. 115 121 122 123 124 125 126

Key

Off

Alternate

Standard Kit 1 Dance Kit Jazz Kit Brush Kit Symphony Kit SFX Kit 1 SFX Kit 2

assign

Wind Punch Stream Heartbeat

Burst Roller Coaster

DGX-205/203, PSR-295/293 Owner’s Manual 83

Page 84

Style List

Style No. Style Name

8BEAT

001 8BeatModern 002 60’sGuitarPop 003 8BeatAdria 004 60’s8Beat 005 8Beat 006 OffBeat 007 60’sRock 008 HardRock 009 RockShuffle 010 8BeatRock

16BEAT

011 16Beat 012 PopShuffle1 013 PopShuffle2 014 GuitarPop 015 16BeatUptempo 016 KoolShuffle 017 JazzRock 018 HipHopLight

BALLAD

019 PianoBallad 020 LoveSong 021 6/8ModernEP 022 6/8SlowRock 023 OrganBallad 024 PopBallad 025 16BeatBallad1 026 16BeatBallad2

DANCE

027 EuroTrance 028 Ibiza 029 HouseMusik 030 SwingHouse 031 TechnoPolis 032 Clubdance 033 ClubLatin 034 Garage1 035 Garage2 036 TechnoParty 037 UKPop 038 HipHopGroove 039 HipShuffle 040 HipHopPop

DISCO

041 70’sDisco1 042 70’sDisco2 043 LatinDisco 044 DiscoPhilly 045 SaturdayNight 046 DiscoChocolate 047 DiscoHands

SWING&JAZZ

048 BigBandFast 049 BigBandMedium 050 BigBandBallad 051 BigBandShuffle 052 JazzClub 053 Swing1

Style No. Style Name

054 Swing2 055 Five/Four 056 JazzBallad 057 Dixieland 058 Ragtime 059 AfroCuban 060 Charleston

R&B

061 Soul 062 DetroitPop1 063 60’sRock&Roll 064 6/8Soul 065 CrocoTwist 066 Rock&Roll 067 DetroitPop2 068 BoogieWoogie 069 ComboBoogie 070 6/8Blues

COUNTRY

071 Country8Beat 072 CountryPop 073 CountrySwing 074 Country2/4 075 CowboyBoogie 076 CountryShuffle 077 Bluegrass

LATIN

078 BrazilianSamba 079 BossaNova 080 PopBossa 081 Tijuana 082 DiscoLatin 083 Mambo 084 Salsa 085 Beguine 086 GuitarRumba 087 RumbaFlamenca 088 RumbaIsland 089 Reggae

BALLROOM

090 VienneseWaltz 091 EnglishWaltz 092 Slowfox 093 Foxtrot 094 Quickstep 095 Tango 096 Pasodoble 097 Samba 098 ChaChaCha 099 Rumba 100 Jive

TRADITIONAL

101 USMarch 102 6/8March 103 GermanMarch 104 PolkaPop 105 OberPolka 106 Tarantella 107 Showtune

Style No. Style Name

108 ChristmasSwing 109 ChristmasWaltz 110 ScottishReel 111 Hawaiian

WALTZ

112 GuitarSerenade 113 SwingWaltz 114 JazzWaltz1 115 JazzWaltz2 116 CountryWaltz 117 OberWaltzer 118 Musette

119 DJ-HipHop 120 DJ-DanceSwing 121 DJ-House 122 DJ-GarageHouse 123 DJ-PopR&B

PIANIST

124 Stride 125 PianoSwing 126 PianoRag 127 Arpeggio 128 Musical 129 Habanera 130 SlowRock 131 8BtPianoBallad 132 PianoMarch 133 6/8PianoMarch 134 PianoWaltz 135 PianoBeguine

84 DGX-205/203, PSR-295/293 Owner’s Manual

Page 85

Song List

● Preset Songs

Song No. Song Name

Favorites

001 Don’t Know Why (Jesse Harris (Norah Jones)) 002 My Favorite Things (Richard Rodgers)

003

004 Down By The Riverside (Traditional) 005 I’ve Been Working On The Railroad (Traditional) 006 Carry Me Back To Old Virginny (James A. Bland) 007 The Last Rose Of Summer (Thomas Moore) 008 The First Noel (Traditional)

009 The Entertainer (S. Joplin) 010 Greensleeves (Traditional) 011 Londonderry Air (Traditional) 012 Träumerei (R. Schumann) 013 Pastorale (J.F. Burgmüller)

014

015 Allein Gott In Der Hoh Sei Eh (N. Decius) 016 Wachet Auf, Ruft Uns Die Stimme. (J.S. Bach)

017 Menuett In G Major WoO 10-2 (L.v. Beethoven) 018 Prelude Op.28 No.7 (F. Chopin) 019 To A Wild Rose (E.A. Macdowell) 020 Für Elise (L.v. Beethoven) 021 Etude Op.10-3 “Chanson de l’adieu” (F. Chopin)

022 Aura Lee (G. Poulton) 023 Canon (J. Pachelbel) 024 Symphonie Nr.9 (L.v. Beethoven)

025 Sur Le Pont D’Avignon (Traditional) 026 Twinkle Twinkle Little Star (Traditional) 027 Muffin Man (Traditional)

028 Joy To The World (G.F. Händel) 029 Ave Maria (F. Schubert) 030 Jingle Bells (Traditional)

●

70 MIDI Songs Provided On the Supplied CD-ROM

File Name Song Name

AMERICA America The Beautiful (S.A. Ward) ATHOME Old Folks At Home (S.C. Foster) AURALEE Aura Lee (G. Poulton)

BABBINO

BANJO Ring De Banjo (S.C. Foster)

BILLBAIL

BROWNJUG Little Brown Jug (Traditional) CAMPTOWN Camptown Races (S.C. Foster) CANON Canon (J. Pachelbel) D_AGSTIN O Du Lieber Augustin (DUET) (Traditional) D_CHTREE O Christmas Tree (DUET) (Traditional)

D_CLOSE

D_CUCKOO The Cuckoo (DUET) (Traditional) D_IMMAI Im Mai (DUET) (Traditional) D_INDIAN Ten Little Indians (DUET) (Septimus Winner) D_LONDON London Bridge (DUET) (Traditional) D_MARY Mary Had A Little Lamb (DUET) (Traditional) D_ROWROW

Killing Me Softly With His Song (Charles Fox (Roberta Flack))

Easy Play

Pianist

Organist

Wedding March From A Midsummer Night’s Dream (F. Mendelssohn)

Advanced

Band Play

Duet

Holidays

O Mio Babbino Caro (From “Gianni Schicchi”) (G. Puccini)

Bill Bailey (Won’t You Please Come Home) (H. Cannon)

Close Your Hands, Open Your Hands (DUET) (J.J. Rousseau)

Row Row Row Your Boat (DUET) (Traditional)

File Name Song Name

D_SCARBO Scarborough Fair (DUET) (Traditional) D_SMOKY On Top Of Old Smoky (DUET) (Traditional) D_THREE Three Blind Mice (DUET) (Traditional) D_WEASEL Pop Goes The Weasel (DUET) (Traditional) D_WEWISH DANUBEWA The Danube Waves (I. Ivanovici) FRULIED Frühlingslied (F. Mendelssohn) FRUSTIME Frühlingsstimmen (J. Strauss II) FUNICULA Funiculi-Funicula (L. Denza) GAVOTTE Gavotte (F.J. Gossec) GUILLAUM Guillaume Tell (G. Rossini) IRISHEYE When Irish Eyes Are Smiling (E.R. Ball) JOYOFMAN Jesu, Joy Of Man’s Desiring (J.S. Bach) LIEBEST3 Liebesträume Nr.3 (F. Liszt) LOMOND Loch Lomond (Traditional) LORELEI Die Lorelei (F. Silcher) MAGICFLT From “The Magic Flute” (W.A Mozart)

MIRLITON

MONDSHIN MUSSIDEN Muss I Denn (F. Silcher) MYBONNIE My Bonnie (Traditional) ORPHEE “Orphée Aux Enfers” Ouverture (J. Offenbach) P_ANGELS Angels Serenade (Traditional) P_ARABES Arabesque (J.F. Burgmüller) P_CANDEU La Candeur (J.F. Burgmüller) P_CHEVAL La Chevaleresque (J.F. Burgmüller) P_CONSOL Consolation (J.F. Burgmüller) P_INOCEN Innocence (J.F. Burgmüller) P_MENUBA Menuett (J.S. Bach) P_MENUBO Menuett (L. Boccherini) P_MOMENT Moments Musicaux Op.94-3 (F. Schubert) P_PCHIEN Valse Op.64-1 “Petit Chien” (F. Chopin) P_PETITE Petite Réunion (J.F. Burgmüller) P_PROGRE Progrès (J.F. Burgmüller) P_SARAFA Krasnyj Sarafan (Traditional) P_TENDRE Tendre Fleur (J.F. Burgmüller) P_TMARCH Turkish March (W.A. Mozart) P_VIOLET La Viollette (Streabbog) PEARLFIS Song Of The Pearl Fisher (G. Bizet) PRIMVERA SAINTSGO When The Saints Go Marchin’ In (Traditional)

SERENAHY

SILENTNT Silent Night (F. Gruber) SLAVON10 Slavonic Dances No.10 (A. Dvorák) SURPRISE “The Surprise” Symphony (F.J. Haydn) SUSANNA Oh! Susanna (S.C. Foster) SYMPHO9 Symphonie Nr.9 (L.v. Beethoven) THAIS Méditation De Thais (J. Massenet) TOREADOR Air de Toréador “Carmen” (G. Bizet) TURKEY Turkey In The Straw (Traditional) UNGARIS5 Ungarische Tänze Nr.5 (J. Brahms) VOGLEIN Wenn Ich Ein Vöglein Wär? (Traditional)

File names that begin with “P_” do not include chord data and they cannot be used with the performance assistant technology feature or Easy Song Arranger feature.

We Wish You A Merry Christmas (DUET) (Traditional)

Danse Des Mirlitons From “The Nutcracker” (P.I. Tchaikovsky)

Piano Sonate Op.27-2 “Mondschein” (L.v. Beethoven)

La Primavera (From Le Quattro Stagioni) (A. Vivaldi)

String Quartet No.17 2nd Mov. “Serenade” (F.J. Haydn)

DGX-205/203, PSR-295/293 Owner’s Manual 85

Page 86

Effect Type List

● Harmony Types

No. Harmony Type Description

01 Duet Harmony types 01 – 05 are pitch-based and add one-, two- or three-note harmonies to

02 Trio

03 Block

04 Country

05 Octave

06 Trill 1/4 note

07 Trill 1/6 note

08 Trill 1/8 note

09 Trill 1/12 note

10 Trill 1/16 note

11 Trill 1/24 note

12 Trill 1/32 note

13 Tremolo 1/4 note

14 Tremolo 1/6 note

the single-note melody played in the right hand. These types sound when chords are played in the auto accompaniment range of the keyboard. These Harmony types will also work when playing songs that contain chord data.

Types 6 – 26 are rhythm-based effects and add embellishments or delayed repeats in time with the auto accompaniment. These types sound whether the

auto accompaniment is on or not; however, the actual speed of the effect depends on the Tempo setting (page 17). The individual note values in each type let you synchronize the effect precisely to the rhythm. Triplet settings are also available: 1/6 = quarter-note triplets, 1/12 = eighth-note triplets, 1/24 = six-

teenth-note triplets.

• The Trill effect Types (06 – 12) create two-note trills (alternating notes) when two notes are held.

• The Tremolo effect Types (13 – 19) repeat all held notes (up to four).

• The Echo effect Types (20 – 26) create delayed repeats of each note played.

15 Tremolo 1/8 note

16 Tremolo 1/12 note

17 Tremolo 1/16 note

18 Tremolo 1/24 note

19 Tremolo 1/32 note

20 Echo 1/4 note

21 Echo 1/6 note

22 Echo 1/8 note

23 Echo 1/12 note

24 Echo 1/16 note

25 Echo 1/24 note

26 Echo 1/32 note

Reverb Types

No. Reverb Type Description

01 – 03 Hall 1 – 3 Concert hall reverb.

04 – 05 Room 1 – 2 Small room reverb.

06 – 07 Stage 1 – 2 Reverb for solo instruments.

08 – 09 Plate 1 – 2 Simulated steel plate reverb.

10 Off No effect.

Chorus Types

No. Chorus Type Description

01 – 02 Chorus 1 – 2 Conventional chorus program with rich, warm chorusing.

03 – 04 Flanger 1 – 2 Pronounced three-phase modulation with a slight metallic sound.

05 Off No effect.

86 DGX-205/203, PSR-295/293 Owner’s Manual

Page 87

MIDI Implementation Chart

YAMAHA [ Portable Grand/PORTATONE ] Date:27-Jan-2004 Model DGX-205/203,PSR-295/293 MIDI Implementation Chart Version : 1.0

Transmitted Recognized Remarks

Function...

Basic Default 1 - 16 1 - 16 Channel Changed x x

Default 3 3

Mode Messages x x

Altered ************** x

Note 0 - 127 0 - 127 Number : True voice ************** 0 - 127

Velocity Note ON o 9nH,v=1-127 o 9nH,v=1-127

Note OFF x x

After Key’s x x Touch Ch’s x x

Pitch Bend o *2 o

0,32 o o Bank Select

1x *1 o Modulation wheel 6o *2 o Data Entry(MSB)

38 o *2 o Data Entry(LSB)

7o o Part Volume

10 o o Pan

Control 11 x *1 o Expression

64 o o Sustain

Change 84 x *1 o Portamento Cntrl

71 x *1 o Harmonic Content 72 o o Release Time 73 x *1 o Attack Time

74 x *1 o Brightness 91,93 o o Effect Depth 96,97 x o RPN Inc,Dec

100,101 o *2 o RPN LSB,MSB

Prog o 0 - 127 o 0 - 127 Change : True # **************

System Exclusive o *3 o *3

: Song Pos. x x Common : Song Sel. x x : Tune x x

System : Clock o o Real Time: Commands o o

Aux :All Sound OFF x o(120,126,127) :Reset All Cntrls x o(121) :Local ON/OFF x o(122) :All Notes OFF x o(123-125) Mes- :Active Sense o o sages:Reset x x

*1 Refer to #2 on page 88. *2 DGX-205/203 only. Refer to #2 on page 88 as for PSR-295/293. *3 Refer to #3 on page 88. Mode 1 : OMNI ON , POLY Mode 2 : OMNI ON ,MONO o : Yes Mode 3 : OMNI OFF, POLY Mode 4 : OMNI OFF,MONO x : No

DGX-205/203, PSR-295/293 Owner’s Manual 87

Page 88

MIDI Data Format

NOTE:

1 By default (factory settings) the instrument ordinarily functions

as a 16-channel multi-timbral tone generator, and incoming data does not affect the panel voices or panel settings. However, the MIDI messages listed below do affect the panel voices, auto accompaniment, and songs.

• MIDI Master Tuning

• System exclusive messages for changing the Reverb Type and Chorus Type.

2 Messages for these control change numbers cannot be trans-

mitted from the instrument itself. However, they may be transmitted when playing the accompaniment, song or using the Harmony effect.

3 Exclusive

<GM System ON> F0H, 7EH, 7FH, 09H, 01H, F7H

• This message automatically restores all default settings for the instrument, with the exception of MIDI Master Tuning.

<MIDI Master Volume> F0H, 7FH, 7FH, 04H, 01H, ll, mm, F7H

• This message allows the volume of all channels to be changed simultaneously (Universal System Exclusive).

• The values of “mm” is used for MIDI Master Volume. (Values for “ll” are ignored.)

<MIDI Master Tuning> F0H, 43H, 1nH, 27H, 30H, 00H, 00H, mm, ll, cc, F7H

• This message simultaneously changes the tuning value of all channels.

• The values of “mm” and “ll” are used for MIDI Master Tuning.

• The default value of “mm” and “ll” are 08H and 00H, respectively. Any values can be used for “n” and “cc.”

<Reverb Type> F0H, 43H, 1nH, 4CH, 02H, 01H, 00H, mmH, llH, F7H

• mm : Reverb Type MSB

• ll : Reverb Type LSB Refer to the Effect Map (page 88) for details.

<Chorus Type> F0H, 43H, 1nH, 4CH, 02H, 01H, 20H, mmH, llH, F7H

• mm : Chorus Type MSB

• ll : Chorus Type LSB Refer to the Effect Map (page 88) for details.

4 When the accompaniment is started, an FAH message is trans-

mitted. When accompaniment is stopped, an FCH message is transmitted.When the clock is set to External, both FAH (accompaniment start) and FCH (accompaniment stop) are recognized.

5 Local ON/OFF

<Local ON> Bn, 7A, 7F <Local OFF> Bn, 7A, 00 Value for “n” is ignored.

■ Effect map

* When a Type LSB value is received that corresponds to no effect type, a value corresponding to the effect type

(coming the closest to the speciﬁed value) is automatically set.

* The numbers in parentheses in front of the Effect Type names correspond to the number indicated in the display.

● REVERB

TYPE

MSB

000 No Effect

001 (01)Hall1 (02)Hall2 (03)Hall3

002 Room (04)Room1 (05)Room2

003 Stage (06)Stage1 (07)Stage2

004 Plate (08)Plate1 (09)Plate2

005...127 No Effect

00 01 02 08 16 17 18 19 20

● CHORUS

TYPE

MSB

000...063 No Effect

064 Thru

065 Chorus (02)Chorus2

066 Celeste (01)Chorus1

067 Flanger (03)Flanger1 (04)Flanger2

068...127 No Effect

00 01 02 08 16 17 18 19 20

TYPE LSB

88 DGX-205/203, PSR-295/293 Owner’s Manual

Page 89

Index

Panel controls and terminals Alphabetical order

+/– .................................................. 13, 44

.................................................. 13, 58

ff rr

.................................................. 13, 58

..................................................... 13, 58

❙

......................................................... 43

.......................................... 13, 57

............................................... 13, 44

>>>>/ ■

0 – 9 ................................................ 13, 44

ACMP ON/OFF .............................13, 24

CATEGORY / ....................... 13, 44

DC IN 12V ..................................... 10, 13

DEMO ............................................ 13, 17

Dial ................................................. 13, 44

DUAL ............................................. 13, 19

EASY SONG ARRANGER .......... 13, 36

FUNCTION .......................................... 13

HARMONY ................................... 13, 26

INTRO/ENDING/rit. .......... 13, 25, 28, 29

LESSON L/R ................................. 13, 32

LESSON MODE ............................ 13, 33

LESSON REPEAT & LEARN ...... 13, 35

MAIN/AUTO FILL ........................ 13, 26

MASTER VOLUME ............... 11, 13, 43

MEMORY/BANK, 1, 2 ................. 13, 60

METRONOME .............................. 13, 48

PC ................................................... 13, 67

PERFORMANCE ASSISTANT

.............................................. 13, 14, 16

PHONES/OUTPUT ....................... 11, 13

PITCH BEND wheel ...................... 13, 22

PORTABLE GRAND .................... 13, 22

REC, 1 – 5, A ..................... 13, 38, 41, 57

REGIST. MEMORY ...................... 13, 60

SONG ....................................... 13, 30, 31

SONG MEMORY .............. 13, 38, 41, 57

SPLIT ....................................... 13, 20, 51

STANDBY/ON ........................ 11, 13, 42

START/STOP ................................ 13, 44

STYLE ............................... 13, 24, 28, 51

SUSTAIN ....................................... 11, 13

SYNC START ............................... 13, 25

SYNC STOP .................................. 13, 28

TEMPO/TAP ............................ 13, 17, 48

TOUCH .................................... 13, 22, 49

USB ................................................ 13, 66

VOICE ............................................ 13, 18

A-B Repeat ...........................................57

Accessories (Optional) .........................77

Accessories (Supplied) ...........................7

ACMP ON ...................................... 24, 28

Auto Accompaniment Range ................25

Auto-Accompaniment ..............24, 25, 28

AWM ....................................................75

Backup ..................................................42

Battery ..................................................10

Bulk Send .............................................64

CD-ROM ..............................................70

Channel Message ..................................65

Chord ........................................25, 53, 55

CHORD ROOT ....................................55

CHORD TYPE .....................................55

Chorus ...................................................47

Chorus Type ...................................63, 86

Computer ......................11, 31, 65, 66, 67

D. Chorus ........................................ 50, 63

D. Octave ........................................ 50, 63

D. Pan .............................................50, 63

D. Reverb ........................................ 50, 63

D. Volume ......................................50, 63

Default Setting ......................................62

Demo ....................................................17

Demo Cancel ........................................64

Dictionary .............................................55

Display ..................................................45

Drum Kit ......................................... 23, 79

Drum Kit List ........................................82

Dual Voice ............................................19

Easy Chords ..........................................53

Easy Song Arranger ..............................13

Effect Map ............................................88

Effect Type List .................................... 86

External Clock ................................64, 66

External Song .......................................31

Flash Memory ....................................... 31

Foot Switch ........................................... 11

Function .................................... 62, 63, 64

Grade .............................................. 34, 64

Harmony ............................................... 26

Harmony Type ..................................... 86

Harmony Volume ................................. 50

Headphones .......................................... 11

Initial Send ........................................... 64

Initialization ......................................... 42

Keyboard Out ....................................... 64

Lesson .................................................. 32

Local ..................................................... 66

L-Part ............................................. 32, 64

M. Chorus ....................................... 50, 63

M. Octave ....................................... 50, 63

M. Pan ............................................ 50, 63

M. Reverb ....................................... 50, 63

M. Volume ..................................... 50, 63

Main Voice ........................................... 18

Measure ................................................ 45

Melody ................................................. 38

MELODY R, MELODY L .................. 38

Melody Voice ................................. 37, 59

Metronome ........................................... 48

MIDI ............................................... 66, 67

MIDI Data Format ............................... 88

MIDI Implementation Chart ................ 87

Music Rest .............................................. 7

Musicsoft Downloader ............. 68, 70, 73

Mute ..................................................... 57

One Touch Setting ............................... 49

Panel Sustain .................................. 50, 63

PC Mode ........................................ 64, 67

performance assistant technology .. 14, 16

Pitch Bend Range ........................... 22, 63

Power Adaptor ..................................... 10

Preset Song ..................................... 30, 31

DGX-205/203, PSR-295/293 Owner’s Manual 89

Page 90

Index

Recording ............................................. 38

Registration Memory ........................... 60

Remote control ..................................... 67

Repeat ............................................. 35, 57

Reverb .................................................. 46

Reverb Type ......................................... 86

R-Part ............................................. 32, 64

S. Chorus ........................................ 50, 63

S. Octave ........................................ 50, 63

S. Pan .............................................. 50, 63

S. Reverb ........................................ 50, 63

S. Volume ....................................... 50, 63

SMF (Standard MIDI File) ................... 68

Software Licensing Agreement ............ 74

Song ................................................ 30, 31

Song Book ........................................ 7, 70

Song Clear ............................................ 41

Song List .............................................. 85

Song Memory ........................... 38, 41, 57

Song Out ............................................... 64

Song Volume ........................................ 57

Specifications ....................................... 77

Split Point ....................................... 20, 51

Split Voice ............................................ 20

Standard Chords ................................... 53

Style .................................... 13, 24, 28, 51

Style List .............................................. 84

Style Out ............................................... 64

Style Volume ........................................ 52

Sustain ............................................ 50, 63

Synchro Start .................................. 13, 25

Synchro Stop .................................. 13, 28

System Message ................................... 65

Voice .....................................................18

Voice List .............................................78

XGlite .....................................................6

Tempo ............................................ 17, 48

Time Signature ..................................... 48

Touch Response ................................... 22

Touch Sensitivity ................................. 49

Track .................................................... 38

Track Clear ........................................... 41

Transfer .................................... 31, 68, 69

Transpose ....................................... 58, 63

Troubleshooting ................................... 75

Tuning ............................................ 58, 63

USB ................................................ 13, 66

USB MIDI Driver ............... 66, 68, 70, 71

User Song ....................................... 31, 38

90 DGX-205/203, PSR-295/293 Owner’s Manual

Page 91

SIBELIUS SCORCH LICENSE AGREEMENT

By using this Product you (an individual or legal entity) agree with the Licensor to be bound by the terms of this License which will govern your use of the Product. If you do not accept these terms, do not use this Product. This Product is copyright (c) Sibelius Software Limited and its licensors 1987-2005.

1. Deﬁnitions

In this License the following words and expressions have the following meanings : "License": this agreement between you and the Licensor and, if permitted by the context, the conditional license granted to you in this agreement. "Licensor": Sibelius Software Limited, an English company (registered no. 3338819) of The Old Toy Factory, 20-22 City North, Fonthill Road, London N4 3HN, UK. "Product": the Software and the Documentation. "Software": the Sibelius Scorch web browser plug-in, Opus and Inkpen2 font families, any other programs or ﬁles supplied by the Licensor which are included in or with the Sibelius Scorch installer, and the Sibelius Scorch installer. "Documentation": any documentation in any form relating to the Software supplied to you with the Software or by the Licensor.

2. License

2.1 The Licensor grants to you a non-exclusive non-transferable

license to use this Software in accordance with the Documentation on a single terminal of a single computer in a single location. Any further use is prohibited. Title to the Product is not transferred to you. Ownership of the Product remains vested in the Licensor, subject to the rights granted to you under this License. All other rights are reserved.

2.2 You may make one printout for your own use of any part of the

Documentation provided in electronic form. You shall not make or permit any third party to make any further copies of any part of the Product whether in eye or machine-readable form.

2.3 You shall not, and shall not cause or permit any third party to,(1)

translate, enhance, modify, alter or adapt the Product or any part of it for any purpose (including without limitation for the purpose of error correction); (2) create derivative works based on the Product, or cause the whole or any part of the Product to be combined with or incorporated into any other program, ﬁle or product, for any purpose; or (3) use the Software to create ﬁles in any format (other than temporary ﬁles created and required by your computer's operating system), including without limitation screen capture ﬁles, ﬁles generated from the Software's playback, graphics ﬁles and print ﬁles, for any purpose, except for creating MIDI ﬁles (if permitted by the Software) for private non-commercial use.

2.4 You shall not, and shall not cause or permit any third party to,

decompile, decode, disassemble or reverse engineer the Software in whole or in part for any purpose.

2.5 You shall not, and shall not cause any third party to, translate,

convert, decode or reverse engineer any ﬁle capable of being read by any copy or version of the Software or any data transmitted to or from any copy or version of the Software, in whole or in part for any purpose.

2.6 The Product or any part of it must not be used to infringe any

right of copyright or right of privacy, publicity or personality or any other right whatsoever of any other person or entity.

3. Copyright

3.1 You acknowledge that copyright in the Product as a whole and

in the components of the Product as between you and the Licensor belongs to the Licensor or its licensees and is protected by copyright laws, national and international, and all other applicable laws.

4. Disclaimer of Liability

4.1 In consideration of the fact that the Product is licensed hereunder free of charge, (a) the Licensor disclaims any and all warranties with respect to the Product, whether expressed or implied, including without limitation any warranties that the Product is free from defects, will perform in accordance with the Documentation, is merchantable, or is ﬁt for any particular purpose, and (b) the Licensor shall not have or incur any liability to you for any loss, cost, expense or claim (including without limitation any liability for loss or corruption of data and loss of proﬁts, revenue or goodwill and any type of special, indirect or consequential loss) that may arise out of or in connection with your installation and use of the Product.

5. Termination

5.1 This License shall terminate automatically upon your destruction of the Product. In addition, the Licensor may elect to terminate this License in the event of a material breach by you of any condition of this License or of any of your representations, warranties, covenants or obligations hereunder. Upon notiﬁcation of such termination by the Licensor, you will immediately delete the Software from your computer and destroy the Documentation.

6. Miscellaneous

6.1 No failure to exercise and no delay in exercising on the part of the Licensor of any right, power or privilege arising hereunder shall operate as a waiver thereof, nor shall any single or partial exercise of any right, power or privilege preclude any other or further exercise thereof or the exercise of any other right, power or privilege. The rights and remedies of the Licensor in connection herewith are not exclusive of any rights or remedies provided by law.

6.2 You may not distribute, loan, lease, sub-license, rent or otherwise transfer the Product to any third party.

6.3 You agree to the use of your personal data in accordance with the Licensor's privacy policy (available from the Licensor or on www.sibelius.com) which may change from time to time.

6.4 This License is intended by the parties hereto to be a ﬁnal expression of their agreement with respect to the subject matter hereof and a complete and exclusive statement of the terms of such agreement. This License supercedes any and all prior understandings, whether written or oral, between you and the Licensor relating to the subject matter hereof.

6.5 (This section only applies if you are resident in the European Union:) This License shall be construed and governed by the laws of England, and both parties agree to submit to the exclusive jurisdiction of the English courts.

6.6 (This section only applies if you are not resident in the European Union:) This License shall be construed and enforced in accordance with and governed by the laws of the State of California. Any suit, action or proceeding arising out of or in any way related or connected to this License shall be brought and maintained only in the United States District Court for the Northern District of California, sitting in the City of San Francisco. Each party irrevocably submits to the jurisdiction of such federal court over any such suit, action or proceeding. Each party knowingly, voluntarily and irrevocably waives trial by jury in any suit, action or proceeding (including any counterclaim), whether at law or in equity, arising out of or in any way related or connected to this License or the subject matter hereof.

(License v2.8, 10 Jan 2005)

DGX-205/203, PSR-295/293 Owner’s Manual

Page 92

Limited Warranty

90 DAYS LABOR 1 YEAR PARTS

Yamaha Corporation of America, hereafter referred to as Yamaha, warrants to the original consumer of a product included in the categories listed below, that the product will be free of defects in materials and/or workmanship for the periods indicated. This warranty is applicable to all models included in the following series of products:

, PSR SERIES OF ELECTRONIC KEYBOARDS

If during the ﬁrst 90 days that immediately follows the purchase date, your new Yamaha product covered by this warranty is found to have a defect in material and/or workmanship, Yamaha and/or its authorized representative will repair such defect without charge for parts or labor.

If parts should be required after this 90 day period but within the one year period that immediately follows the purchase date, Yamaha will, subject to the terms of this warranty, supply these parts without charge. However, charges for labor, and/or any miscellaneous expenses incurred are the consumers responsibility. Yamaha reserves the right to utilize reconditioned parts in repairing these products and/or to use reconditioned units as warranty replacements.

THIS WARRANTY IS THE ONLY EXPRESS WARRANTY WHICH YAMAHA MAKES IN CONNECTION WITH THESE PRODUCTS. ANY IMPLIED WARRANTY APPLICABLE TO THE PRODUCT, INCLUDING THE WARRANTY OF MERCHANT ABILITY IS LIMITED TO THE DURATION OF THE EXPRESS WARRANTY. YAMAHA EXCLUDES AND SHALL NOT BE LIABLE IN ANY EVENT FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES.

Some states do not allow limitations that relate to implied warranties and/or the exclusion of incidental or consequential damages. Therefore, these limitations and exclusions may not apply to you.

This warranty gives you speciﬁc legal rights. You may also have other rights which vary from state to state.

CONSUMERS RESPONSIBILITIES

If warranty service should be required, it is necessary that the consumer assume certain responsibilities:

1. Contact the Customer Service Department of the retailer selling the product, or any retail outlet authorized by Yamaha to sell the product for assistance. You may also contact Yamaha directly at the address provided below.

2. Deliver the unit to be serviced under warranty to: the retailer selling the product, an authorized service center, or to Yamaha with an explanation of the problem. Please be prepared to provide proof purchase date (sales receipt, credit card copy, etc.) when requesting service and/or parts under warranty.

3. Shipping and/or insurance costs are the consumers responsibility.* Units shipped for service should be packed securely.

*Repaired units will be returned PREPAID if warranty service is required within the ﬁrst 90 days.

IMPORTANT: Do NOT ship anything to ANY location without prior authorization. A Return Authorization (RA) will be issued that has a tracking number assigned that will expedite the servicing of your unit and provide a tracking system if needed.

4. Your owners manual contains important safety and operating instructions. It is your responsibility to be aware of the contents of this manual and to follow all safety precautions.

EXCLUSIONS

This warranty does not apply to units whose trade name, trademark, and/or ID numbers have been altered, defaced, exchanged removed, or to failures and/or damages that may occur as a result of:

1. Neglect, abuse, abnormal strain, modiﬁcation or exposure to extremes in temperature or humidity.

2. Improper repair or maintenance by any person who is not a service representative of a retail outlet authorized by Yamaha to sell the product, an authorized service center, or an authorized service representative of Yamaha.

3. This warranty is applicable only to units sold by retailers authorized by Yamaha to sell these products in the U.S.A., the District of Columbia, and Puerto Rico. This warranty is not applicable in other possessions or territories of the U.S.A. or in any other country.

Please record the model and serial number of the product you have purchased in the spaces provided below.

Model___________________________ Serial #________________________________ Sales Slip #________________________________

Purchased from____________________________________________________________ Date______________________________________ (Retailer)

YAMAHA CORPORATION OF AMERICA

Electronic Service Division 6600 Orangethorpe Avenue

Buena Park, CA 90620

KEEP THIS DOCUMENT FOR YOUR RECORDS. DO NOT MAIL!

Page 93

For details of products, please contact your nearest Yamaha representative or the authorized distributor listed below.

Pour plus de détails sur les produits, veuillez-vous adresser à Yamaha ou au distributeur le plus proche de vous ﬁgurant dans la liste suivante.

Die Einzelheiten zu Produkten sind bei Ihrer unten aufgeführten Niederlassung und bei Yamaha Vertragshändlern in den jeweiligen Bestimmungsländern erhältlich.

Para detalles sobre productos, contacte su tienda Yamaha más cercana o el distribuidor autorizado que se lista debajo.

NORTH AMERICA

CANADA

Yamaha Canada Music Ltd.

135 Milner Avenue, Scarborough, Ontario, M1S 3R1, Canada Tel: 416-298-1311

U.S.A.

Yamaha Corporation of America

6600 Orangethorpe Ave., Buena Park, Calif. 90620, U.S.A. Tel: 714-522-9011

CENTRAL & SOUTH AMERICA

MEXICO

Yamaha de México S.A. de C.V.

Calz. Javier Rojo Gómez #1149, Col. Guadalupe del Moral C.P. 09300, México, D.F., México Tel: 55-5804-0600

BRAZIL

Yamaha Musical do Brasil Ltda.

Av. Reboucas 2636-Pinheiros CEP: 05402-400 Sao Paulo-SP. Brasil Tel: 011-3085-1377

ARGENTINA

Yamaha Music Latin America, S.A. Sucursal de Argentina

Viamonte 1145 Piso2-B 1053, Buenos Aires, Argentina Tel: 1-4371-7021

PAN AMA AND OTHER LATIN AMERICAN COUNTRIES/ CARIBBEAN COUNTRIES

Yamaha Music Latin America, S.A.

Torre Banco General, Piso 7, Urbanización Marbella,

Calle 47 y Aquilino de la Guardia, Ciudad de Panamá, Panamá Tel: +507-269-5311

EUROPE

THE UNITED KINGDOM

Yamaha-Kemble Music (U.K.) Ltd.

Sherbourne Drive, Tilbrook, Milton Keynes, MK7 8BL, England Tel: 01908-366700

IRELAND

Danfay Ltd.

61D, Sallynoggin Road, Dun Laoghaire, Co. Dublin Tel: 01-2859177

GERMANY

Yamaha Music Central Europe GmbH

Siemensstraße 22-34, 25462 Rellingen, Germany Tel: 04101-3030

SWITZERLAND/LIECHTENSTEIN

Yamaha Music Central Europe GmbH, Branch Switzerland

Seefeldstrasse 94, 8008 Zürich, Switzerland Tel: 01-383 3990

AUSTRIA

Yamaha Music Central Europe GmbH, Branch Austria

Schleiergasse 20, A-1100 Wien, Austria Tel: 01-60203900

THE NETHERLANDS

Yamaha Music Central Europe, Branch Nederland

Clarissenhof 5-b, 4133 AB Vianen, The Netherlands Tel: 0347-358 040

BELGIUM/LUXEMBOURG

Yamaha Music Central Europe GmbH, Branch Belgium

Rue de Geneve (Genevastraat) 10, 1140 - Brussels, Belgium Tel: 02-726 6032

FRANCE

Yamaha Musique France

BP 70-77312 Marne-la-Vallée Cedex 2, France Tel: 01-64-61-4000

ITALY

Yamaha Musica Italia S.P.A.

Viale Italia 88, 20020 Lainate (Milano), Italy Tel: 02-935-771

SPAIN/PORTUGAL

Yamaha-Hazen Música, S.A.

Ctra. de la Coruna km. 17, 200, 28230 Las Rozas (Madrid), Spain Tel: 91-639-8888

GREECE

Philippos Nakas S.A. The Music House

147 Skiathou Street, 112-55 Athens, Greece Tel: 01-228 2160

SWEDEN

Yamaha Scandinavia AB

J. A. Wettergrens Gata 1 Box 30053 S-400 43 Göteborg, Sweden Tel: 031 89 34 00

DENMARK

YS Copenhagen Liaison Ofﬁce

Generatorvej 6A DK-2730 Herlev, Denmark Tel: 44 92 49 00

FINLAND

F-Musiikki Oy

Kluuvikatu 6, P.O. Box 260, SF-00101 Helsinki, Finland Tel: 09 618511

NORWAY

Norsk ﬁlial av Yamaha Scandinavia AB

Grini Næringspark 1 N-1345 Østerås, Norway Tel: 67 16 77 70

ICELAND

Skifan HF

Skeifan 17 P.O. Box 8120 IS-128 Reykjavik, Iceland Tel: 525 5000

OTHER EUROPEAN COUNTRIES

Yamaha Music Central Europe GmbH

Siemensstraße 22-34, 25462 Rellingen, Germany Tel: +49-4101-3030

AFRICA

Yamaha Corporation, Asia-Paciﬁc Music Marketing Group

Nakazawa-cho 10-1, Hamamatsu, Japan 430-8650 Tel: +81-53-460-2312

MIDDLE EAST

TURKEY/CYPRUS

Yamaha Music Central Europe GmbH

Siemensstraße 22-34, 25462 Rellingen, Germany Tel: 04101-3030

OTHER COUNTRIES

Yamaha Music Gulf FZE

LB21-128 Jebel Ali Freezone P.O.Box 17328, Dubai, U.A.E. Tel: +971-4-881-5868

ASIA

THE PEOPLE’S REPUBLIC OF CHINA

Yamaha Music & Electronics (China) Co.,Ltd.

25/F., United Plaza, 1468 Nanjing Road (West), Jingan, Shanghai, China Tel: 021-6247-2211

HONG KONG

Tom Lee Music Co., Ltd.

11/F., Silvercord Tower 1, 30 Canton Road, Tsimshatsui, Kowloon, Hong Kong Tel: 2737-7688

INDONESIA

PT. Yamaha Music Indonesia (Distributor) PT. Nusantik

Gedung Yamaha Music Center, Jalan Jend. Gatot Subroto Kav. 4, Jakarta 12930, Indonesia Tel: 21-520-2577

KOREA

Yamaha Music Korea Ltd.

Tong-Yang Securities Bldg. 16F 23-8 Yoido-dong, Youngdungpo-ku, Seoul, Korea Tel: 02-3770-0660

MALAYSIA

Yamaha Music Malaysia, Sdn., Bhd.

Lot 8, Jalan Perbandaran, 47301 Kelana Jaya, Petaling Jaya, Selangor, Malaysia Tel: 3-78030900

PHILIPPINES

Yupangco Music Corporation

339 Gil J. Puyat Avenue, P.O. Box 885 MCPO, Makati, Metro Manila, Philippines Tel: 819-7551

SINGAPORE

Yamaha Music Asia Pte., Ltd.

#03-11 A-Z Building 140 Paya Lebor Road, Singapore 409015 Tel: 747-4374

TAIWAN

Yamaha KHS Music Co., Ltd.

3F, #6, Sec.2, Nan Jing E. Rd. Taipei. Taiwan 104, R.O.C. Tel: 02-2511-8688

THAILAND

Siam Music Yamaha Co., Ltd.

891/1 Siam Motors Building, 15-16 ﬂoor Rama 1 road, Wangmai, Pathumwan Bangkok 10330, Thailand Tel: 02-215-2626

OTHER ASIAN COUNTRIES

Yamaha Corporation, Asia-Paciﬁc Music Marketing Group

Nakazawa-cho 10-1, Hamamatsu, Japan 430-8650 Tel: +81-53-460-2317

OCEANIA

AUSTRALIA

Yamaha Music Australia Pty. Ltd.

Level 1, 99 Queensbridge Street, Southbank, Victoria 3006, Australia Tel: 3-9693-5111

NEW ZEALAND

Music Houses of N.Z. Ltd.

146/148 Captain Springs Road, Te Papapa, Auckland, New Zealand Tel: 9-634-0099

COUNTRIES AND TRUST TERRITORIES IN PACIFIC OCEAN

Yamaha Corporation, Asia-Paciﬁc Music Marketing Group

Nakazawa-cho 10-1, Hamamatsu, Japan 430-8650 Tel: +81-53-460-2312

[PK] 34

HEAD OFFICE Yamaha Corporation, Pro Audio & Digital Musical Instrument Division

Nakazawa-cho 10-1, Hamamatsu, Japan 430-8650 Tel: +81-53-460-3273

Page 94

Yamaha PK CLUB (Portable Keyboard Home Page, English Only)

http://www.yamahaPKclub.com/

Yamaha Manual Library

http://www2.yamaha.co.jp/manual/english/

WC34910 ???PO???.?-03C0 Printed in China

Yamaha PSR-295, PSR-293 User Manual 2

Specifications and Main Features

Frequently Asked Questions

User Manual

PRECAUTIONS

Copyright Notice

Panel logos

Supplied Accessories

Special features of the DGX-205/203, PSR-295/293

Contents

Setting Up

Power Requirements

Connecting headphones (PHONES/OUTPUT jack)

Connecting to a computer (USB terminal)

Turn on the power

Connecting a footswitch (SUSTAIN JACK)

Panel Controls and Terminals

Front Panel

Rear Panel

The Easy Way To Play Piano

Quick Guide

Play With Both Hands

Change the Song Tempo

Play the Demo Song

Try Playing a Variety Of Instrument Voices

Play the Grand Piano Voice

Pitch Bend (DGX-205/203 only)

Touch Response

Fun Sounds

Drum Kits

Sound Effects

Styles (Auto Accompaniment)

Harmony

A Variety Of Ways To Start and Stop Style Playback

Using Songs

Select and Listen To a Song

Types Of Songs

Select a Song For a Lesson

Lesson 1: Waiting

Lesson 2: Your Tempo

Lesson 3: Minus One

Using the Easy Song Arranger

Record Your Own Performance

Track Configuration

Recording Procedure

Backup and Initialization

Backup

Initialization

Basic Operation and Displays

Basic Operation

Display Items

Reference

Handy Performance Features

Adding Reverb

Adding Chorus

The Metronome

Touch Response Sensitivity

One Touch Setting

Adjusting the Voice Parameters

Adjusting the Harmony Volume

Panel Sustain

Style (Auto-accompaniment) Functions

Setting the Split Point

Play Only the Style Rhythm

Play a Style With Chords but No Rhythm (Stop Accompaniment)

Adjusting the Style Volume

Playing Auto-accompaniment Chords

Looking Up Chords Using the Chord Dictionary

Song Settings

Song Volume

A-B Repeat

Muting Independent Song Parts

Change the Key Of a Song

Song Fast Forward, Fast Reverse, and Pause

Change the Melody Voice

Memorize Your Favorite Panel Settings

Saving Settings to the Registration Memory

Function settings

Locating and Editing the Function Settings

Connecting To a Computer
