Yamaha DGX-650 User Manual

Owner’s Manual

Setting UpReferenceAppendix Basic Guide

Keyboard Stand Assembly

For information on assembling the keyboard stand, refer to the instructions on page 10 of this manual.

SPECIAL MESSAGE SECTION

This product utilizes batteries or an external power supply (adapter). DO NOT connect this product to any power supply or adapter other than one described in the manual, on the name plate, or specifically recommended by Yamaha.

WARNING:

walk on, trip over, or roll anything over power or connecting cords of any kind. The use of an extension cord is not recommended! If you must use an extension cord, the minimum wire size for a 25’ cord (or less ) is 18 AWG. NOTE: The smaller the AWG number, the larger the current handling capacity. For longer extension cords, consult a local electrician.

This product should be used only with the components supplied or; a cart, rack, or stand that is recommended by Yamaha. If a cart, etc., is used, please observe all safety markings and instructions that accompany the accessory product.

Do not place this product in a position where anyone could

SPECIFICATIONS SUBJECT TO CHANGE:

The information contained in this manual is believed to be correct at the time of printing. However, Yamaha reserves the right to change or modify any of the specifications without notice or obligation to update existing units.

This product, either alone or in combination with an amplifier and headphones or speaker/s, may be capable of producing sound levels that could cause permanent hearing loss. DO NOT operate for long periods of time at a high volume level or at a level that is uncomfortable. If you experience any hearing loss or ringing in the ears, you should consult an audiologist. IMPORTANT: The louder the sound, the shorter the time period before damage occurs.

Some Yamaha products may have benches and / or accessory mounting fixtures that are either supplied with the product or as optional accessories. Some of these items are designed to be dealer assembled or installed. Please make sure that benches are stable and any optional fixtures (where applicable) are well secured BEFORE using. Benches supplied by Yamaha are designed for seating only. No other uses are recommended.

NOTICE:

Service charges incurred due to a lack of knowledge relating to how a function or effect works (when the unit is operating as designed) are not covered by the manufacturer’s warranty, and are therefore the owners responsibility. Please study this manual carefully and consult your dealer before requesting service.

ENVIRONMENTAL ISSUES:

Yamaha strives to produce products that are both user safe and environmentally friendly. We sincerely believe that our products and the production methods used to produce them, meet these goals. In keeping with both the letter and the spirit of the law, we want you to be aware of the following:

Battery Notice:

This product MAY contain a small non-rechargeable battery which (if applicable) is soldered in place. The average life span of this type of battery is approximately five years. When replacement becomes necessary, contact a qualified service representative to perform the replacement.

This product may also use “household” type batteries. Some of these may be rechargeable. Make sure that the battery being charged is a rechargeable type and that the charger is intended for the battery being charged.

When installing batteries, never mix old batteries with new ones, and never mix different types of batteries. Batteries MUST be installed correctly. Mismatches or incorrect installation may result in overheating and battery case rupture.

Warning:

Do not attempt to disassemble, or incinerate any battery. Keep all batteries away from children. Dispose of used batteries promptly and as regulated by the laws in your area. Note: Check with any retailer of household type batteries in your area for battery disposal information.

Disposal Notice:

Should this product become damaged beyond repair, or for some reason its useful life is considered to be at an end, please observe all local, state, and federal regulations that relate to the disposal of products that contain lead, batteries, plastics, etc. If your dealer is unable to assist you, please contact Yamaha directly.

NAME PLATE LOCATION:

The name plate is located on the bottom of the product. The model number, serial number, power requirements, etc., are located on this plate. You should record the model number, serial number, and the date of purchase in the spaces provided below and retain this manual as a permanent record of your purchase.

Model

Serial No.

Purchase Date

92-BP (bottom)

PLEASE KEEP THIS MANUAL

FCC INFORMATION (U.S.A.)

1. IMPORTANT NOTICE: DO NOT MODIFY THIS UNIT!

This product, when installed as indicated in the instructions contained in this manual, meets FCC requirements. Modifications not expressly approved by Yamaha may void your authority, granted by the FCC, to use the product.

2. IMPORTANT: When connecting this product to accessories and/

or another product use only high quality shielded cables. Cable/s supplied with this product MUST be used. Follow all installation instructions. Failure to follow instructions could void your FCC authorization to use this product in the USA.

3. NOTE: This product has been tested and found to comply with the

requirements listed in FCC Regulations, Part 15 for Class “B” digital devices. Compliance with these requirements provides a reasonable level of assurance that your use of this product in a residential environment will not result in harmful interference with other electronic devices. This equipment generates/uses radio frequencies and, if not installed and used according to the instructions found in the users manual, may cause interference harmful to the operation of other electronic devices. Compliance with FCC regulations does

* This applies only to products distributed by YAMAHA CORPORATION OF AMERICA. (class B)

DGX-650 Owner’s Manual

not guarantee that interference will not occur in all installations. If this product is found to be the source of interference, which can be determined by turning the unit “OFF” and “ON”, please try to eliminate the problem by using one of the following measures:

Relocate either this product or the device that is being affected by the interference.

Utilize power outlets that are on different branch (circuit breaker or fuse) circuits or install AC line filter/s.

In the case of radio or TV interference, relocate/reorient the antenna. If the antenna lead-in is 300 ohm ribbon lead, change the lead-in to co-axial type cable.

If these corrective measures do not produce satisfactory results, please contact the local retailer authorized to distribute this type of product. If you can not locate the appropriate retailer, please contact Yamaha Corporation of America, Electronic Service Division, 6600 Orangethorpe Ave, Buena Park, CA90620

The above statements apply ONLY to those products distributed by Yamaha Corporation of America or its subsidiaries.

COMPLIANCE INFORMATION STATEMENT

(DECLARATION OF CONFORMITY PROCEDURE)

Responsible Party : Yamaha Corporation of America

Type of Equipment : Digital Piano

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

1) this device may not cause harmful interference, and

2) this device must accept any interference received including

See user manual instructions if interference to radio reception is suspected.

* This applies only to products distributed by

YAMAHA CORPORATION OF AMERICA.

Address : 6600 Orangethorpe Ave., Buena Park, Calif.

Telephone : 714-522-9011

90620

Model Name : DGX-650

interference that may cause undesired operation.

(FCC DoC)

OBSERVERA!

Apparaten kopplas inte ur växelströmskällan (nätet) så länge som den ar ansluten till vägguttaget, även om själva apparaten har stängts av.

ADVARSEL: Netspændingen til dette apparat er IKKE afbrudt,

sålænge netledningen sidder i en stikkontakt, som er tændt — også selvom der er slukket på apparatets afbryder.

VAR OITU S: Laitteen toisiopiiriin kytketty käyttökytkin ei irroita koko

laitetta verkosta.

(standby)

The model number, serial number, power requirements, etc., may be found on or near the name plate, which is at the bottom of the unit. You should note this serial number in the space provided below and retain this manual as a permanent record of your purchase to aid identification in the event of theft.

Model No.

Serial No.

(bottom_en_01)

Information for Users on Collection and Disposal of Old Equipment

This symbol on the products, packaging, and/or accompanying documents means that used electrical and electronic products should not be mixed with general household waste. For proper treatment, recovery and recycling of old products, please take them to applicable collection points, in accordance with your national legislation and the Directives 2002/96/EC.

By disposing of these products correctly, you will help to save valuable resources and prevent any potential negative effects on human health and the environment which could otherwise arise from inappropriate waste handling.

For more information about collection and recycling of old products, please contact your local municipality, your waste disposal service or the point of sale where you purchased the items.

[For business users in the European Union]

If you wish to discard electrical and electronic equipment, please contact your dealer or supplier for further information.

[Information on Disposal in other Countries outside the European Union]

This symbol is only valid in the European Union. If you wish to discard these items, please contact your local authorities or dealer and ask for the correct method of disposal.

(weee_eu_en_01)

DGX-650 Owner’s Manual

Table of Contents

Basic Guide Reference AppendixSetting Up

Setting Up

Special Features ..............................................................5

PRECAUTIONS ...............................................................6

Compatible Format...........................................................8

About Manuals .................................................................9

Included Accessories .......................................................9

Keyboard Stand Assembly 10

Panel Controls and Terminals 14

Front Panel.....................................................................14

Rear Panel .....................................................................15

Setting Up 16

Power Requirements......................................................16

Connecting a Footswitch (SUSTAIN Jack).....................16

Connecting Headphones or External Audio Equipment

(PHONES/OUTPUT Jack) .........................................17

Connecting a Pedal Unit (PEDAL UNIT jack).................18

Connecting a Computer (USB TO HOST terminal)........19

Turning the Power On/Off ..............................................19

Setting the Volume.........................................................20

Auto Power Off Function................................................20

MAIN Display 21

Basic Controls 22

Basic Guide

Try Playing a Variety of Instrument Voices 23

Selecting a Main Voice...................................................23

Playing the “Grand Piano”..............................................23

Layering Two Voices—Dual Voice.................................24

Playing a Split Voice in the Left Hand area ....................24

Using the Metronome.....................................................25

Adding Harmony ............................................................27

Playing Styles 28

Using the Music Database .............................................29

Chords............................................................................30

Using the Smart Chord feature ......................................31

Calling up Optimum Styles for Your Performance

(Style Recommender) ................................................33

Playing Songs and Audio Files 34

Listening to the Overview Demo ....................................34

Playing Back a Song or Audio File.................................35

Fast Forward, Rewind, and Pause.................................36

A-B Repeat.....................................................................36

Turning Each Track On/Off ............................................36

Displaying the Song Score.............................................37

Displaying the Lyrics ......................................................37

Using the Song Lesson Feature 38

Three Types of Song Lesson.........................................38

Practicing with Song Lesson..........................................38

Making Practice Perfect—Repeat & Learn.....................39

Recording Your Performance 40

Song Recording .............................................................40

Recording to a Specified Track......................................42

Clearing a User Song.....................................................44

Clearing a Specified Track from a User Song ................44

Audio Recording.............................................................45

Memorizing Your Favorite Panel Settings 46

Memorizing Panel Settings to the Registration Memory Recalling Panel Settings from the Registration Memory

...46 ...47

Playing Audio Files via an External Audio Player 48

Backup Parameters and Initialization 49

Backup Parameters .......................................................49

Initialization ....................................................................49

Reference

Handy Performance Features 50

Selecting a Reverb Type................................................50

Selecting a Chorus Type................................................50

Selecting a DSP Type....................................................51

Panel Sustain.................................................................52

Pitch Controls—Transpose............................................52

Pitch Controls—Tuning ..................................................53

Pitch Controls—the PITCH BEND wheel.......................53

Touch Response Sensitivity...........................................54

Selecting an EQ Setting for the Best Sound..................54

Setting the Output Gain Level........................................55

Speaker On/Off Setting..................................................55

Intelligent Acoustic Control (IAC)...................................56

Voice Settings 57

Selecting a Dual Voice...................................................57

Selecting a Split Voice ...................................................57

Voice Editing ..................................................................57

Style (Auto Accompaniment) Functions 58

Style Variations—Sections.............................................58

Changing the Tempo .....................................................60

Adjusting the Volume of the Style ..................................60

Playing Chords Without Style Playback .........................60

Setting the Split Point.....................................................61

Setting the Chord Fingering...........................................61

Looking Up Chords Using the Chord Dictionary ............62

Song and Audio Settings 63

Background Music (BGM) Playback ..............................63

Random Playback..........................................................63

Tempo Setting of the Song ............................................64

Song Volume .................................................................64

Audio Volume.................................................................64

Changing the Voice of the Song ....................................65

Specifying the Channel for the Lesson Part...................65

The Functions 66

Function List...................................................................67

USB Flash Memory Operations 70

Connecting a USB Flash Memory..................................71

Formatting a USB Flash Memory...................................72

Saving a Registration Memory to USB Flash Memory ... 73

Saving a User Song to USB Flash Memory...................74

Converting a User Song to an Audio file ........................75

Loading Files from a USB Flash Memory ......................76

Deleting files from a USB Flash Memory .......................77

Deleting User Data from the Instrument.........................77

Appendix

Troubleshooting........................................................... 78

Messages...................................................................... 79

Specifications............................................................... 80

Index.............................................................................. 82

DGX-650 Owner’s Manual

Setting Up

Special Features

Natural Piano Voice Page 23

The DGX-650 features an amazingly realistic piano Voice (“Natural! Grand Piano”; Voice 001) meticulously sampled from a concert grand piano—fantastic for playing not only classical compositions but also piano pieces in any style. No matter what instrument settings have been made, you can instantly call up the Piano Voice by simply pressing the [PORTABLE GRAND] button.

Graded Hammer Standard Keyboard

Thanks to our experience as the world’s leading manufacturer of acoustic pianos, we’ve developed a keyboard with action that’s virtually indistinguishable from the real thing. Just as on a traditional acoustic piano, the keys of the lower notes have a heavier touch, while the higher ones are more responsive to lighter playing. The keyboard’s sensitivity can even be adjusted to match your playing style. This Graded Hammer technology gives the DGX-650 remarkably authentic touch in a lightweight instrument.

Amazingly Realistic and Dynamic Sounds Page 23

Yamaha’s authentic Voices (especially the highly acclaimed Live!, Sweet! and Cool! Voices) deliver incredibly natural and dynamic sound—with all the nuances of the original instrument, from delicate to powerful.

Setting Up

Play Along with Styles Page 28

The DGX-650 also has complete and fully automatic accompaniment features with the Styles. These Styles provide the equivalent of a full backing band covering wide variety of genres—from waltz and swing to 8-beat and euro-trance, plus much more. Select a Style that matches the music you want to play, or experiment with new Styles to expand your musical horizons. And if it’s difficult to select the right Style from the huge variety available, use the Style Recommender function, which calls up a list of suggested Styles, based on a sample rhythm you play. Also, this instrument features a Smart Chord function, allowing you to simply press single keys, and yet play various chord progressions that authentically match the music genre and key you specify—giving you even greater enjoyment from the Styles!

Easy Performance with Music Notation Display Page 37

When you play back a Song, the corresponding score is shown on the display. This is a great way to learn how to read music. If the Song contains lyric and chord data, the lyrics and chords also appear in the score.

USB TO DEVICE Page 70

Connect a USB flash memory device to the USB TO DEVICE terminal on the instrument, and save or load registrations, and User Songs that you’ve created on the instrument, as well as read data from the device, such as MIDI files or Style files. Also, Audio files (.wav) stored to USB flash memory can be played back on the instrument. Moreover, you can record your performance as Audio data to a USB flash memory device. For more on Audio playing and recording, see pages 34 and 40.

DGX-650 Owner’s Manual

Setting Up

Power supply/AC power adaptor

Do not open

Water warning

Fire warning

If you notice any abnormality

Power supply/AC power adaptor

Assembly

Location

PRECAUTIONS

PLEASE READ CAREFULLY BEFORE PROCEEDING

Please keep this manual in a safe and handy place for future reference.

WARNING

Always follow the basic precautions listed below to avoid the possibility of serious injury or even death from electrical shock, short-circuiting, damages, fire or other hazards. These precautions include, but are not limited to, the following:

• Do not place the power cord near he at sources such as heaters or radiators. Also, do not excessively bend or otherwise damage the cord, or place heavy objects on it.

• Only use the voltage specified as correct for the instrument. The required voltage is printed on the name plate of the instrument.

• Use the specified adaptor (page 81) only. Using the wrong adaptor can result in damage to the instrument or overheating.

• Check the electric plug periodically and remove any dirt or dust which may have accumulated on it.

• This instrument contains no user-serviceable parts. Do not open the instrument or attempt to disassemble or modify the internal components in any way. If it should appear to be malfunctioning, discontinue use immediately and have it inspected by qualified Yamaha service personnel.

• Do not expose the instrument to rain, use it near water or in damp or wet conditions, place on it any containers (such as vases, bottles or glasses) containing liquids which might spill into any openings. If any liquid such as water seeps into the instrument, turn off the power immediately and unplug the power cord from the AC outlet. Then have the instrument inspected by qualified Yamaha service personnel.

• Never insert or remove an electric plug with wet hands.

• Do not put burning items, such as candles, on the unit. A burning item may fall over and cause a fire.

• When one of the following problems occur, immediately turn off the power switch and disconnect the electric plug from the outlet. Then have the device inspected by Yamaha service personnel.

- The power cord or plug becomes frayed or damaged.

- It emits unusual smells or smoke.

- Some object has been dropped into the instrument.

- There is a sudden loss of sound during use of the instrument.

CAUTION

Always follow the basic precautions listed below to avoid the possibility of physical injury to you or others, or damage to the instrument or other property. These precautions include, but are not limited to, the following:

• Do not connect the instrument to an electrical outlet using a multiple-connector. Doing so can result in lower sound quality, or possibly cause overheating in the outlet.

• When removing the electric plug from the instrument or an outlet, always hold the plug itself and not the cord. Pulling by the cord can damage it.

• Remove the electric plug from the outlet when the instrument is not to be used for extended periods of time, or during electrical storms.

• Read carefully the attached documentation explaining the assembly process. Failure to assemble the instrument in the proper sequence might result in damage to the instrument or even injury.

DGX-650 Owner’s Manual

• Do not place the instrument in an unstable position where it might accidentally fall over.

• When transporting or moving the instrument, always use two or more people. Attempting to lift the instrument by yourself may damage your back, result in other injury, or cause damage to the instrument itself.

• Before moving the instrument, remove all connected cables, to prevent damage to the cables or injury to anyone who might trip over them.

• When setting up the product, make sure that the AC outlet you are using is easily accessible. If some trouble or malfunction occurs, immediately turn off the power switch and disconnect the plug from the outlet. Even when the power switch is turned off, electricity is still flowing to the product at the minimum level. When you are not using the product for a long time, make sure to unplug the power cord from the wall AC outlet.

• Use only the stand specified for the instrument. When attaching the stand or rack, use the provided screws only. Failure to do so could cause damage to the internal components or result in the instrument falling over.

DMI-5 1/2

• Before connecting the instrument to other electronic components, turn off the

Connections

Handling caution

power for all components. Before turning the power on or off for all components, set all volume levels to minimum.

• Be sure to set the volumes of all components at their minimum levels and gradually raise the volume controls while playing the instrument to set the desired listening level.

Yamaha cannot be held responsible for damage caused by improper use or modifications to the instrument, or data that is lost or destroyed.

Always turn the power off when the instrument is not in use.

Even when the [ ] (Standby/On) switch is in standby status (display is off), electricity is still flowing to the instrument at the minimum level.

When you are not using the instrument for a long time, make sure you unplug the power cord from the wall AC outlet.

• Do not insert a finger or hand in any gaps on the instrument.

• Never insert or drop paper, metallic, or other objects into the gaps on the panel. This could cause physical injury to you or others, damage to the instrument or other property, or operational failure.

• Do not rest your weight on, or place heavy objects on the instrument, and do not use excessive force on the buttons, switches or connectors.

• Do not use the instrument/device or headphones for a long period of time at a high or uncomfortable volume level, since this can cause permanent hearing loss. If you experience any hearing loss or ringing in the ears, consult a physician.

NOTICE

To avoid the possibility of malfunction/ damage to the product, damage to data, or damage to other property, follow the notices below.

 Handling and Maintenance

• Do not use the instrument in the vicinity of a TV, radio, stereo equipment, mobile phone, or other electric devices. Otherwise, the instrument, TV, or radio may generate noise. When you use the instrument along with the application on your iPhone/iPad, we recommend that you set “Airplane Mode” to “ON” on your iPhone/iPad in order to avoid noise caused by communication.

• Do not expose the instrument to excessive dust or vibrations, or extreme cold or heat (such as in direct sunlight, near a heater, or in a car during the day) to prevent the possibility of panel disfiguration, damage to the internal components or unstable operation. (Verified operating temperature range: 5° – 40°C, or 41° – 104°F.)

• Do not place vinyl, plastic or rubber objects on the instrument, since this might discolor the panel or keyboard.

• When cleaning the instrument, use a soft, dry cloth. Do not use paint thinners, solvents, cleaning fluids, or chemical-impregnated wiping cloths.

• During extreme changes in temperature or humidity, condensation may occur and water may collect on the surface of the instrument. If water is left, the wooden parts may absorb the water and be damaged. Make sure to wipe any water off immediately with a soft cloth.

Setting Up

 Saving data

• Some data items (page 49) are automatically saved as backup data in the internal memory even if you turn the power off. Saved data may be lost due to malfunction or incorrect operation. Save important data to external device such as a USB flash memory (pages 73–75).

• The recorded Songs are lost when you turn off the power of the instrument without saving. It occurs also when the power is turned off by Auto Power Off function (page 20). Save the recorded data to the instrument.

Information

 About copyrights

• Copying of the commercially available musical data including but not limited to MIDI data and/or audio data is strictly prohibited except for your personal use.

• This product incorporates and bundles computer programs and contents in which Yamaha owns copyrights or with respect to which it has license to use others’ copyrights. Such copyrighted materials include, without limitation, all computer software, style files, MIDI files, WAVE data, musical scores and sound recordings. Any unauthorized use of such programs and contents outside of personal use is not permitted under relevant laws. Any violation of copyright has legal consequences. DON’T MAKE, DISTRIBUTE OR USE ILLEGAL COPIES.

 About functions/data bundled with the instrument

• Some of the preset songs have been edited for length or arrangement, and may not be exactly the same as the original.

 About this manual

• The illustrations and LCD screens as shown in this manual are for instructional purposes only, and may appear somewhat different from those on your instrument.

• Apple, iPhone, iPod touch and iPad are trademarks of Apple Inc., registered in the U.S. and other countries.

• The company names and product names in this manual are the trademarks or registered trademarks of their respective companies.

DMI-5 2/2

DGX-650 Owner’s Manual

Compatible Format

Setting Up

GM System Level 1

“GM System Level 1” is an addition to the MIDI standard which ensures that any GM-compatible music data can be accurately played by any GM-compatible tone generator, regardless of manufacturer. The GM mark is affixed to all software and hardware products that support GM System Level.

The Yamaha XF format enhances the SMF (Standard MIDI File) standard with greater functionality and open-ended expandability for the future. The instrument is capable of displaying lyrics when an XF file containing lyric data is played.

STYLE FILE

The Style File Format is Yamaha’s original style file format which uses a unique conversion system to provide high-quality automatic accompaniment based on a wide range of chord types.

XGlite

As its name implies, “XGlite” is a simplified version of Yamaha’s high-quality XG tone generation format. Naturally, you can play back any XG song data using an XGlite tone generator. However, keep in mind that some songs may play back differently compared to the original data, due to the reduced set of control parameters and effects.

DGX-650 Owner’s Manual

About Manuals

Insert the music rest into the slots as shown.

Music Rest

This instrument has the following documents and instructional materials.

 Included Documents

Owner’s Manual (this book)

• Setting Up Please read this section first.

• Basic Guide This section explains how to use the basic functions. Refer to this section while playing the instrument.

• Reference This section explains how to make detailed settings for the various functions of the instrument.

• Appendix This section includes troubleshooting information and specifications.

Data List

Contains various important preset content lists such as those of Voices, Styles, and Effects.

 Online Materials (from Yamaha Downloads)

MIDI Reference

Contains MIDI related information such as MIDI Data Format and the MIDI Implementation Chart.

MIDI Basics (only in English, French, German and Spanish)

Contains basic explanations about MIDI.

Computer-related Operations

Includes instructions on connecting this instrument to a computer, and operations related to transferring files and MIDI data.

Setting Up

To obtain these manuals, access the Yamaha Downloads website, select your country, enter “DGX-650” in the Model Name box, then click [Search].

Yamaha Downloads http://download.yamaha.com/

 Online Material (for Yamaha Online members)

Song Book (only in English, French, German and Spanish)

Contains music scores for the preset Songs (excluding the Over View Demo Song and Songs 1–11) of this instrument. After completing the user registration at the website below, you can download this Song Book free of charge.

Yamaha Online Member https://member.yamaha.com/myproduct/regist/ You will need the PRODUCT ID on the sheet “Online Member Product Registration” packaged with this manual in order to fill out the User Registration form.

Included Accessories

• Owner’s Manual (this book)

• Data List

• Keyboard Stand

• Footswitch

• Music Rest

• AC Power Adaptor

• Online Member Product Registration

*1: May not be included depending on your particular locale.

Check with your Yamaha dealer.

*2: The PRODUCT ID on the sheet will be needed when you

fill out the User Registration form.

DGX-650 Owner’s Manual

Setting Up

CAUTION

q Joint connectors

(4 pcs.)

r 6 x 70 mm roundhead

screws (4 pcs.)

t 6 x 30 mm roundhead

screws (4 pcs.)

y 5 x 16 mm roundhead

screws (4 pcs.)

Assembly Parts

Back board

Side

boards

Stand bases

w Metal brackets e 3 x 8 mm roundhead

screws (12 pcs.)

A (1 pc.) B (1 pc.) C (2 pcs.)

Keyboard Stand Assembly

Read these cautions carefully before you assemble or use the keyboard stand. These cautions are to promote safe use of the stand and to prevent injury and damage from occurring to you and others. By following these cautions carefully, your keyboard stand will provide you with safe and prolonged use.

• Be careful not to confuse parts, and be sure to install all parts in the correct direction. Please assemble in accordance with the sequence given below.

• Assembly should be carried out by at least two persons.

• Be sure to use the correct screw size, as indicated below. Use of incorrect screws can cause damage.

• Use the stand after assembly is complete. An uncompleted stand may overturn or the keyboard may drop.

• Always place the stand on a flat, stable surface. Placing the stand on uneven surfaces may cause it to become unstable or overturn, the keyboard to drop, or injury.

• Do not use the stand for anything other than its designed purpose. Placing other objects on the stand may result in the object dropping or the stand overturning.

• Do not apply excessive force to the keyboard as it may cause the stand to overturn or the keyboard to drop.

• Make sure the stand is sturdy and safe, and all screws have been tight and firm before use. If not, the stand may overturn, the keyboard may drop, or may result in injury to the user.

• To disassemble, reverse the assembly sequence given below.

Have a phillips-head (+) screwdriver of the appropriate size ready.

The parts shown in the “Assembly Parts” illustration will be used. Follow the assembly

instructions and select the parts as needed.

DGX-650 Owner’s Manual

Keyboard Stand Assembly

e 3 x 8 mm

roundhead screws

w Metal bracket

(C)

w Metal bracket

(A)

w Metal bracket

(B)

w Metal bracket

(C)

e 3 x 8 mm

roundhead screws

q Joint

connectors

r 6 x 70 mm

roundhead screws

“L”

“R”

NOTE

Attach the metal brackets.

Attach the metal brackets w to the top of the side boards, using the screws

Attach the stand bases.

Insert the joint connectors q into the side boards as shown. The joint connectors have been installed properly if you can see the screw head on the connector.

e as shown.

Setting Up

• If you put the connectors in wrong direction and want to take them out, tap around the holes on the boards.

Attach the “L” (Left) and “R” (Right) stand bases to the bottom of the side boards, using the screws

r. “L” (Left) and “R” (Right) are marked on the

upper surfaces of the stand bases. If you have trouble fastening the screws, use a screwdriver to rotate the joint connectors so that the connector holes are aligned with the screw holes on the stand bases.

DGX-650 Owner’s Manual

Setting Up

t 6 x 30 mm roundhead screws

At least 10 cm

Be sure to place your hands at least 10 cm from either end of the keyboard when positioning it.

CAUTION

NOTE

CAUTION

Keyboard Stand Assembly

Attach the back board.

Attach the back board, using the screws t. Check the back-to-front orientation for the side boards. Make sure the non-colored surface is facing down.

• Be careful not to drop the back board or touch the sharp metal fittings .

• If you have purchased an optional pedal unit, attach the pedal unit before proceeding to the next step. Refer to the instructions provided with your pedal unit.

Put the keyboard on the stand.

Check the back-to-front orientation for stand, and carefully place the keyboard on the side boards. Slowly move the keyboard so that the holes on the bottom of the keyboard are properly aligned with the holes on the angle brackets.

• Be careful not to drop the keyboard or to get your fingers caught between the keyboard and the stand parts.

• Do not hold the keyboard in any position other than the position shown in the illustration.

DGX-650 Owner’s Manual

Post-assembly checklist

y 5 x 16 mm

roundhead screws

Once you’ve assembled the stand, check the following points:

• Are there any parts left over?  If so, read the assembly instructions again and cor-

rect any errors you might have made.

• Is the instrument clear of doors and other movable fixtures?  If not, move the instrument to an appropriate loca-

tion.

• Does the instrument make a rattling noise when you play it or move it?  If so, properly tighten all screws.

• Also, if the keyboard makes a creaking noise or seems unsteady when you play it, refer carefully to the assembly instructions and diagrams and retighten all screws.

Keyboard Stand Assembly

Install the keyboard to the stand.

Fix the keyboard to the angle brackets, using the

screws

Setting Up

DGX-650 Owner’s Manual

Setting Up

ert

!1 !2

Front Panel

Song category list Style category list

Panel Controls and Terminals

Front Panel

q [ ] (Standby/On) switch.....................page 19

w [MASTER VOLUME] control ................page 20

e [DEMO/BGM] button ....................pages 34, 63

r [SCORE] button....................................page 37

t [LYRICS] button....................................page 37

y [REC] button........................... pages 40, 42, 45

u LESSON START

i [SMART CHORD] button......................page 31

o [STYLE RECOMMENDER] button .......page 33

!0 Song Track

!1 [METRONOME ON/OFF] button ..........page 25

!2 [TEMPO/TAP] button.................... pages 60, 64

!3 SONG/AUDIO

[WAITING] button..............................page 39

[YOUR TEMPO] button .....................page 39

[MINUS ONE] button.........................page 39

[1]–[5], [A] buttons............................page 36

Lesson

[R] and [L] buttons ...........................page 38

[REPEAT&LEARN] button................page 39

[A-B REPEAT] button........................page 36

[REW] button.....................................page 36

[FF] button.........................................page 36

[PAUSE] button .................................page 36

[START/STOP] button .......................page 35

!4 STYLE

[ACMP ON/OFF] button....................page 28

[INTRO/ENDING/rit.] button ............. page 58

[MAIN/AUTO FILL] button ................page 58

[SYNC STOP] button ........................page 59

[SYNC START] button.......................page 29

[START/STOP] button.......................page 29

!5 REGIST MEMORY

[BANK], [1]–[4] buttons....................page 46

!6 CATEGORY [

!7 [EXIT] button ........................................ page 21

!8 [EXECUTE] button ...............................page 72

!9 DATA ENTRY

Dial, Number buttons [0]–[9],

[+] and [-] buttons.............................page 22

@0 [FILE CONTROL] button......................page 72

@1 [FUNCTION] button.............................. page 66

@2 [PORTABLE GRAND] button...............page 23

@3 [SONG/AUDIO] button .........................page 35

@4 [STYLE] button..................................... page 28

@5 [VOICE] button .....................................page 23

@6 [MUSIC DATABASE] button................. page 29

@7 [SPLIT ON/OFF] button ....................... page 24

@8 [DUAL ON/OFF] button ........................page 24

@9 [HARMONY ON/OFF] button............... page 27

#0 [PITCH BEND] wheel ...........................page 53

#1 USB TO DEVICE terminal ............ pages 70, 71

#2 Compatible Formats ..............................page 8

] and [f] buttons....... page 22

DGX-650 Owner’s Manual

!7 !8

@2 @3

@4 @5

@7 @8 @9

#7 #8 #9#6#5#4#3

A-1C0C1C2C3C4C5C6C7

Rear Panel

Voice category list Music Database category listDisplay (page 21)

Panel Controls and Terminals

Setting Up

Rear Panel

#3 CONTRAST knob .................................page 21

#4 USB TO HOST terminal................ pages 19, 68

#5 SUSTAIN jack .......................................page 16

#6 PEDAL UNIT jack .................................page 18

#7 AUX IN jack...........................................page 48

#8 PHONES/OUTPUT jack........................page 17

#9 DC IN jack .............................................page 16

“Press & Hold” symbol

By holding down one of the buttons having this symbol, you can call up an alternate function, other than the one called up when simply pressing.

DGX-650 Owner’s Manual

Setting Up

WARNING

CAUTION

AC outlet

AC powe r

adaptor

CAUTION

Setting Up

Power Requirements

• Use the specified adaptor (page 81) only. Using the wrong adaptor can result in damage to the instrument or overheating.

Connect the AC power adaptor to the DC

IN jack.

Plug the AC power adaptor into an AC

outlet.

• Unplug the AC Power Adaptor when not using the instrument, or during electrical storms, to avoid the possibility of physical injury to you or others, or damage to the instrument or other property.

• Before connecting the instrument to other electronic components, turn off the power of all the components. Also, before turning any components on or off, make sure to set all volume levels to minimum (0). Otherwise, damage to the components, electrical shock, or even permanent hearing loss may occur.

Connecting a Footswitch (SUSTAIN Jack)

NOTE

• The sustain function does not affect the Split Voice (page 24).

• Make sure that the footswitch plug is properly connected to the SUSTAIN jack before turning on the power.

• Do not press the footswitch while turning the power on. Doing this changes the recognized polarity of the footswitch, resulting in reversed footswitch operation.

The sustain function lets you produce a natural sustain as you play by pressing a footswitch. Plug the supplied footswitch into this jack and use it to switch sustain on and off.

Damper Resonance

This function simulates the sustain sound produced with the damper pedal on a grand piano. If you want to use this function, select Voice 001 (page 23), then press the Footswitch. This function can be turned off via the FUNCTION display (page 68).

DGX-650 Owner’s Manual

Setting Up

Standard stereo phone plug

Audio cable

Standard stereo phone plug

CAUTION

NOTICE

Connecting Headphones or External Audio Equipment (PHONES/OUTPUT Jack)

• When the instrument’s sound is output to an external

Headphones

Any pair of stereo headphones with a standard stereo phone plug can be plugged in here for convenient monitoring. The speakers are automatically shut off when a plug is inserted into this jack. This setting can be changed so that speaker sound is always on regardless whether a plug is inserted or not (page 55).

External Audio Equipment

device, first turn on the power to the instrument, then to the external device. Reverse this order when you turn the power off. If the instrument’s power is automatically turned off via the Auto Power Off function (page 20), first turn off the external device, then turn on the power to the instrument then the external device again.

• Do not route the output from the PHONES/OUTPUT jack to the AUX IN jack. If you make this connection, the signal input at the AUX IN jack is output from the PHONES/OUTPUT jack. These connections could result in a feedback loop that will make normal performance impossible, and may even damage both pieces of equipment.

NOTE

• Use audio cables and adaptor cables having no (zero) resistance.

Setting Up

The PHONES/OUTPUT jack also functions as an external output. You can connect the PHONES/OUTPUT jack to a keyboard amplifier, stereo system, mixer, tape recorder, or other line-level audio device to send the instrument’s output signal to that device.

Optimum setting

Output gain level for this jack is set to a value suitable for connecting headphones, as the default setting. You can switch this to the value suitable for connecting an external audio device. For details on how to switch the value, see page 55.

DGX-650 Owner’s Manual

Setting Up

Keyboard Stand

LP-7A/7AWH (optional)

If you press and hold the damper pedal here, all the notes shown will be sustained.

If you press and hold the sostenuto pedal here, only the notes held at this timing will be sustained.

Connecting a Pedal Unit (PEDAL UNIT jack)

Setting Up

This jack is for connecting an optional LP-7A/LP7AWH pedal unit. When connecting the pedal unit, make sure to also assemble the unit on the supplied keyboard stand.

NOTE

• Make sure that power is off when connecting or disconnecting the pedal.

• This affects only Main/Dual Voices and Harmony sound (pages 23, 24 and 27).

Pedal Unit functions

Damper Pedal (Right)

Pressing this pedal will sustain notes longer. Releasing this pedal immediately stops (damps) any sustained notes. A “halfpedal” function of this pedal creates partial sustain effects, depending on how far down you press the pedal. When using both a footswitch and pedal unit, the last effect applied takes priority.

Damper Resonance

This function simulates the sustain sound produced with a damper pedal on a grand piano. This effect is added when the Damper pedal is pressed for Voice 001. You can turn this function on or off via the FUNCTION display (page 68).

DGX-650 Owner’s Manual

Sostenuto Pedal (Center)

If you play a note or notes on the keyboard and press the sostenuto pedal while the note(s) are held, those notes will sustain as long as you hold the pedal (as if the damper pedal had been pressed) but all subsequently played notes will not be sustained. This makes it possible to sustain a note or notes, for example, while other notes are played “staccato.”

Soft Pedal (Left)

The soft pedal reduces the volume and slightly changes the timbre of notes played while the pedal is pressed. The soft pedal will not affect notes that are already playing when it is pressed.

Setting Up

CAUTION

USB terminal USB TO HOST terminal

USB cable

Instrument

NOTICE

CAUTION

Connecting a Computer (USB TO HOST terminal)

By connecting a computer to the USB TO HOST terminal, you can transfer data between the instrument and the computer via MIDI. For details on using a computer with this instrument, refer to “Computer-related Operations” on the website (page 9).

• Use an AB type USB cable of less than 3 meters. USB 3.0 cables cannot be used.

NOTE

• The instrument will begin transmission a short time after the USB connection is made.

• When using a USB cable to connect the instrument to your computer, make the connection directly without passing through a USB hub.

• For information on setting up your sequence software, refer to the owner’s manual of the relevant software.

iPhone/iPad Connection

By connecting your iPhone or iPad to the USB TO HOST terminal of this instrument and using applications, you can manage your music files more easily and take advantage various functions. For details on connection, refer to “iPhone/iPad Connection Manual” downloadable from the website “Yamaha Downloads” (page 9). For information about available applications, access the following page: http://www.yamaha.com/kbdapps/

Setting Up

Turning the Power On/Off

Turn down the MASTER VOLUME control to “MIN” then press the [ ] (Standby/On) switch to turn on the power. While playing the keyboard, adjust the MASTER VOLUME control. To turn off the power, press the [ ] (Standby/On) switch again for a second.

• When using a power adaptor, even when the power is off, a small amount of electricity is still being consumed by the instrument. When you are not using the instrument for a long time, make sure to unplug the AC power adaptor from the wall AC outlet.

DGX-650 Owner’s Manual

Setting Up

CAUTION

NOTICE

Setting the Volume

Setting Up

To adjust the volume level of the entire keyboard sound, use the MASTER VOLUME control located at the left of the panel. Play the keyboard to actually produce sound while you adjusting the volume to the desired level.

Auto Power Off Function

To prevent unnecessary power consumption, this instrument features an Auto Power Off function that automatically turns the power off if the instrument is not operated for a specified period of time. The amount of time that will elapse before the power is automatically turned off is set by default to 30 minutes.

To disable the Auto Power Off function:

Turn off the power, then press the [ ] (Standby/On) switch to turn on the power while holding down the lowest key. Make sure to hold down lowest key until a message appears at the top left of the display after pressing the power switch.

NOTE

• Adjusting the MASTER VOLUME control also affects the output level of the PHONES/OUTPUT jack.

• Do not use the instrument at a high volume level for a long period of time, or your hearing may be damaged.

Intelligent Acoustic Control (IAC)

IAC is a function which automatically adjusts and controls the sound quality according to the overall volume of the instrument. Even when the volume is low, it permits both low sounds and high sounds to be clearly heard. For details, refer to page 56.

To set the time that elapses before Auto Power Off is executed:

Press the [FUNCTION] button, press the CATEGORY [r] or [f] button several times until “Auto Power Off” appears, then select the desired value by using the dial.

Settings: OFF, 5, 10, 15, 30, 60, 120 Default value: 30

• The recorded Song will be lost if the power is automatically turned off without executing the save operation. Make sure to save your recorded Song before the power turns off.

• Depending on the instrument status, the power may not turn off automatically, even after the elapse of the specified period of time. Always turn off the power manually when the instrument is not in use.

• When the instrument is not operated for a specified period of time while connected to an external device such as an amplifier, speaker or computer, make sure to follow the instructions in the Owner’s Manual to turn off the power to the instrument and the connected devices, in order to protect the devices from damage. If you do not want the power to turn off automatically when a device is connected, disable Auto Power Off.

DGX-650 Owner’s Manual

MAIN Display

Registration Memory Status

Shows the selected bank number.

Shows the memory numbers that contain data. A border appears around the selected number.

Style Status

Appears when Auto Accompaniment (ACMP) is on.

Appears when the Synchro Stop function is engaged.

Shows section name

Song Track Status

Indicates the track status of the current Song (pages 36 and 42).

Contains no data.

Contains data and is muted.

Highlighted when ready for reco rding.

Specified as Song recording target.

Contains data and can be played back.

Tempo

Display Title

Time

Signature

Measure Number

A-B Repeat

Appears when A-B Repeat playback is engaged.

Lesson part

Shows the current Lesson part

Voi ce

Indicates the current Voices (Main, Dual and Split) (pages 23, 24).

Song or Audio

Indicates the current Song or Audio file.

Style

Indicates the current Style (page

28).

Smart Chord setting (page 31)

M.D.B.

Indicates the current M.D.B. (page 29).

Transpose

Chord indication

Appears when the corresponding function is turned on.

Page 51

Page 27

When the power is turned on, the MAIN display automatically appears. This display shows the basic settings of the instrument, including the current Voice, Style, Song, Audio and other settings.

To Return to the MAIN Display

You can return to the MAIN display from any other display by pressing the [EXIT] button.

CONTRAST knob

Adjust the CONTRAST knob on the rear panel of the instrument for optimum display legibility.

Setting Up

DGX-650 Owner’s Manual

Setting Up

IncreaseDecrease

Press number buttons [0], [0], [3].

Press briefly to increase.

Press briefly to decrease.

Previous category Next category

Current category

Basic Controls

Before operating the instrument, it may be helpful to familiarize yourself with the basic controls below that are used to select items and change values.

 Dial

Rotate the dial clockwise to increase the value, or counterclockwise to decrease the value.

 Number buttons

Use the Number buttons to directly enter a number or parameter value. For numbers that start with one or two zeroes (such as “003”), the first zeroes can be omitted. However, completely entering [0][0][3] will display “003” quicker than pressing only [3].

Example: Selecting Voice 003

 CATEGORY buttons

Use these buttons to jump to the first Voice, Style, or Song in the next or previous Category, and call up the next or previous Function sequentially.

Example: VOICE SELECT (MAIN) display

 [-] and [+] buttons

Press the [+] button briefly to increase the value by 1, or press the [-] button briefly to decrease the value by

1. Press and hold either button to continuously increase or decrease the value in the corresponding direction. To restore the value to the default setting, press both buttons simultaneously.

In most procedures described throughout this owner’s manual the dial is recommended for selection simply because it is the easiest and most intuitive selection method. Please note however, that most items or values that can be selected using the dial can also be selected using the [+] and [-] buttons.

DGX-650 Owner’s Manual

Try Playing a Variety of Instrument Voices

Current Voice number and name

Select 022 Cool! Organ

Basic Guide

In addition to the wonderfully realistic piano sounds, you can select and play other musical instrument Voices, such as organ, guitar, bass, strings, sax, trumpet, drums and percussion, and even sound effects.

Play the keyboard.

Selecting a Main Voice

This procedure selects the Main Voice for playing on the keyboard.

Press the [VOICE] button to call up the

Main Voice selection display.

The current Voice number and name will be highlighted.

Preset Voice Types

001–147 163–543

148–162 (Drum Kit)

000

Instrument Voices

Various drum and percussion sounds are assigned to individual keys. Details on assigning instruments to keys are provided in the Drum Kit List of the separate Data List.

One Touch Setting (OTS)

The One Touch Setting feature automatically selects the most suitable Voice for you when you select a Style or Song. Simply select Voice number “000” to activate this feature.

Basic Guide

Use the dial to select the desired Voice.

The Voice List is provided on the front panel, or in the separate Data List.

Playing the “Grand Piano”

When you want to reset various settings to default and simply play a Piano sound, press the [PORTABLE GRAND] button.

The Voice number is set to 001 “Natural! Grand Piano” and all the settings are turned off automatically, so only the Grand Piano Voice will play over the entire keyboard.

DGX-650 Owner’s Manual

Try Playing a Variety of Instrument Voices

Two voices will sound at the same time.

Dual Voice number and name appear when Dual is on.

Split Voice

Split point

Main Voice and Dual Voice

Split Voice number and name appear when Split is on.

Layering Two Voices—Dual Voice

In addition to the Main Voice, you can layer a different Voice over the entire keyboard as a “Dual Voice.”

Press the [DUAL ON/OFF] button to turn

Dual on.

Basic Guide

You can confirm whether the Dual function is on in the MAIN display (page 21).

Playing a Split Voice in the Left Hand area

By dividing the keyboard into two separate areas, you can play one Voice with your right hand and a different Voice with your left.

Press the [SPLIT ON/OFF] button to turn

on Split.

The keyboard is divided into the left hand and right hand areas.

You can play a “Split Voice” on the left hand area of the keyboard while playing a Main Voice and Dual Voice on the right hand area of the keyboard. The highest key for the left hand area is referred to as the “Split Point” which can be changed from the default F#2 key. For details, refer to page 61.

Press the [DUAL ON/OFF] button again

to exit from Dual.

Although turning on Dual will select a Dual Voice suitable for the current Main Voice, you can easily select a different Dual Voice (page 57).

DGX-650 Owner’s Manual

You can confirm whether the Split function is on in the MAIN display (page 21).

Press the [SPLIT ON/OFF] button again

to exit from Split.

You can easily select a different Split Voice (page

57).

Try Playing a Variety of Instrument Voices

Current setting

Indicates the beat number in the measure.

Te mp o

Hold for longer than a second

Numerator (Number of beats per measure)

Denominator (The length of one beat)

NOTE

Using the Metronome

The instrument features a built-in metronome (a device that keeps an accurate tempo), convenient for practicing.

Press the [METRONOME ON/OFF] but-

ton to start the metronome.

Press the [METRONOME ON/OFF] but-

ton again to stop the metronome.

Adjusting the Metronome Tempo

Press the [TEMPO/TAP] button to call up the Tempo value, then use the dial to adjust the Tempo value.

Setting the Time Signature

Here, we’ll set a time signature of 3/4 as an example.

Hold down the [METRONOME ON/OFF]

button for longer than a second to call up “Time Signature - Numerator.”

The time signature is shown on the display.

• The metronome time signature will synchronize to a Style or Song that is selected, so these parameters cannot be changed while a Style or Song is playing.

Rotate the dial to select “3.”

A bell will sound on the first beat of each measure while the other beats will click.

Basic Guide

Press the [EXIT] button to return to the MAIN display.

Press the CATEGORY [f] button to call

up “Time Signature - Denominator.”

DGX-650 Owner’s Manual

Try Playing a Variety of Instrument Voices

Metronome volume

Rotate the dial to select “4.”

Confirm the setting by playing the Met-

ronome.

Basic Guide

Setting the Metronome Volume

Press the [FUNCTION] button to call up

the FUNCTION display.

Press the CATEGORY [r] or [f] but-

tons repeatedly to select “Metronome Volu me .”

Setting the Bell sound

This allows you to select whether the click sound has a bell accent, or plays only a click sound.

Press the [FUNCTION] button.

Use the CATEGORY [r] or [f] button

repeatedly to select “Bell.”

Rotate the dial to turn the bell sound on

or off.

Rotate the dial to set the Metronome Vol-

ume.

DGX-650 Owner’s Manual

+ 60 hidden pages
