Congratulations!

Thank you for purchasing Global Water Instrumentation, Inc.’s Model AD200-4, the
“smartest”, most comprehensive automatic voice/pager security dialer available.
Representing an exciting new level of achievement, the AD200-4 combines
technologically advanced features, ease of programming and reliable operation in a
compact, unobtrusive dialer completely compatible with any security alarm system.
Installation and hookup are quick and easy, whether installed in conjunction with
normally open, normally closed dry contact, or voltage activation sensors. The unit can
also function as a stand -alone device, by simple connection to an ordinary telephone jack.
The keypad cover glides on and off for added attractiveness and security.

Table of Contents:

I) AD200-4 Checklist................................................................................................3

II) Inspection...............................................................................................................3

III) How It Works........................................................................................................3

IV) Panel Displays........................................................................................................5

V) Installation Hookups.............................................................................................6

VI) Programming the Dialer.......................................................................................8

VII) Testing Your System...........................................................................................17

VIII) Operating Your System......................................................................................18

IX) Sample Program Planner ................................................................................... 20

X) Specifications .......................................................................................................24

XI) Dialer Accessories...............................................................................................24

XII) Important Information/Maintenance................................................................25

XIII) Warranty..............................................................................................................27

* Copyright  Global Water Instrumentation, Inc. 2006

- 2 -

Global Water

800-876-1172 • globalw.com

I) AD200-4 Checklist

a) One (1) ea. MODEL AD200-4
b) One (1) ea. PHONE CABLE
c) One (1) ea. INSTRUCTION MANUAL
d) Four (4) ea. 1K RESISTORS

II) Inspection

a) Your AD200-4 unit was carefully inspected and certified by our Quality

Assurance Team before shipping. If any damage has occurred during shipping,
please notify Global Water Instrumentation, Inc. and file a claim with the carrier
involved.

Use the checklist to ensure that you have received everything needed to operate
the AD200-4.

III) How It Works

a) The AD200-4 dialer features busy-line and no -answer detection to ensure prompt

transmission of up to 4 pre-recorded messages delivered sequentially to as many
as 8 standard telephones, cellular phones, voice and/or numeric pagers. Messages
to both local and long-distance calls can be transmitted. When activated, the dialer
instantly begins calling the numbers in sequence, delivering each message 1 to 3
times in a row, in accordance with the pre-selected number of dialing attempts.

The AD200-4 is extensively programmable, offering personalized customization
to fulfill virtually any residential or business requirement. Plain-English prompts
walk the user through the process in a timely manner.

Programming options abound, allowing the user to:

• Store up to eight (8) telephone/pager numbers.

• Choose 1- 9 calling efforts for the numbers dialed.

• Select 1-3 message repeats.

• Record a variable combination (maximum: 7) of instructional

outgoing messages (total elapsed time: 51 seconds).

Program up to four (4) separate input channels with individually enable/disable,
entry/exit delay and activation options (Normally Open (N.O.), Normally Closed
(N.C.) (dry contact or voltage activation) including momentary and continuous
activation for each).

Further individualize each channel by selecting the delay times, telephone/pager
numbers to be dialed, and the spec ific outgoing messages to be played.

- 3 -

Global Water

800-876-1172 • globalw.com

Please Familiarize Yourself With These Instructions Before
Installation/Operation. This guide describes how to program and operate the
dialer. We strongly recommend that you read the entire manual before attempting
to use the unit.

To enhance ease of programming and operation, this guide includes:

• A Programming Sample/Quick Setup review (Page 20) with a

corresponding Program Planner.

• A Blank Program Planner (Page 23). One copy of this Planner should

be kept in a safe place by the end user. The installer should also retain
a separate copy.

We are happy to provide a full measure of security reassurance and peace of mind
with the Model AD200-4. For information about other innovative Global Water
equipment, call [phone].

- 4 -

IV) Panel Displays

Global Water

800-876-1172 • globalw.com

- 5 -

V) Installation Hookups

Global Water

800-876-1172 • globalw.com

- 6 -

Global Water

800-876-1172 • globalw.com

- 7 -

VI) Programming the Dialer

a) Overview

Please study this section thoroughly before beginning to program the dialer,
referring to the Sample Program Planner on page 20. Then, select from among the
options for each feature, listing each choice in pencil on the blank Program
Planner on page 23. Once the dialer is correctly programmed, list each choice in
ink. One copy of the Planner should be kept by the installer; one copy should
remain with the end user.

A look at the keypad:

Global Water

800-876-1172 • globalw.com

CALLOUT FOR NUMERALS:

Press these keys to enter telephone numbers and other
programming information as specified in this manual. A
maximum of 50 digits can be input in each phone/pager
location.

CALLOUT FOR P:

Press this key to program in a pause. Each “P” provides
a 2-second pause.

CALLOUT FOR R:

Press this key to record the combination of identification
and directional outgoing messages (OGMs). The total
elapsed OGM time cannot exceed 51 seconds.

CALLOUT FOR M:

Press this key to change the Mode of the dialer, in
sequence: PROGRAM TEST OPERATE OFF.

Once the unit has been programmed, removing power or placing the dialer in the
OFF mode will not affect the programming.

- 8 -

Global Water

800-876-1172 • globalw.com

b) Programming Telephone and/or Pager Numbers

First Time Installation to Initialize Dialer Follow Steps 1 & 2.

1. Apply power to the unit.

• The LCD will read: NOT PROGRAMMED

PRESS KEYPAD #1

2. Press 1.

• The LCD will change to read: USP AD200-4 X.X

• Then: PROGRAM: NUMBERS

• Then: SELECT: 1-8

• 0(DONE)

3. You are now ready to begin programming the dialer. All programming can

be input before connecting the dialer to a telephone line. Check the unit’s
LCD as you program numbers in the dialer to ensure accuracy. Please
complete all programming instructions before attempting to operate the
unit.

Before programming your dialer to call the police, fire department, or
9-1-1 directly, you must check with these agencies for their approval.

A maximum of 50 digits (including pauses) can be programmed in at each
location.

*PROGRAM: NUMBERS SELECT: 1-8
1(YES) 2(NO ) 0(DONE)

*This prompt will appear after a number has been programmed and this section
has been exited.

1. Step 1 - Press location number 1-8 to program the first number. This can

be any location 1-8. You do not have to program locations in sequence.
For example, you can program numbers in locations 3 and 5. When you

are done programming all the desired telephone and/or pager
numbers, press “O” to exit this section.
The LCD will read: PAGER
1(YES) 2(NO)

2. Step 2 - Press “1” if you wish to program in a numeric pager number (step

3A). Press “2” if you wish to program in a telephone number (step 3B),
cellular phone number (step 3B), or a voice pager (step 3C).

3. STEP 3A - NUMERIC PAGERS NOTE: WHEN PROGRAMMING

NUMERIC PAGERS, YOU MUST PROGRAM IN ONE OR MORE
PAUSES. EACH “P” PROVIDES A 2- SECOND PAUSE. BEFORE
PROGRAMMING IN A PAGER, CALL THE NUMBER TO
DETERMINE THE NUMBER OF 2-SECOND PAUSES TO BE

- 9 -
