Xilinx Spartan-6 FPGA Power Management User Manual

Spartan-6 FPGA
Power Management

User Guide

UG394 (v1.1) September 4, 2012

Notice of Disclaimer

The information disclosed to you hereunder (the “Materials”) is provided solely for the selection and use of Xilinx products. To the maximum
extent permitted by applicable law: (1) Materials are made available "AS IS" and with all faults, Xilinx hereby DISCLAIMS ALL
WARRANTIES AND CONDITIONS, EXPRESS, IMPLIED, OR STATUTORY, INCLUDING BUT NOT LIMITED TO WARRANTIES OF
MERCHANTABILITY, NON-INFRINGEMENT, OR FITNESS FOR ANY PARTICULAR PURPOSE; and (2) Xilinx shall not be liable (whether
in contract or tort, including negligence, or under any other theory of liability) for any loss or damage of any kind or nature related to, arising
under, or in connection with, the Materials (including your use of the Materials), including for any direct, indirect, special, incidental, or
consequential loss or damage (including loss of data, profits, goodwill, or any type of loss or damage suffered as a result of any action
brought by a third party) even if such damage or loss was reasonably foreseeable or Xilinx had been advised of the possibility of the same.
Xilinx assumes no obligation to correct any errors contained in the Materials or to notify you of updates to the Materials or to product
specifications. You may not reproduce, modify, distribute, or publicly display the Materials without prior written consent. Certain products are
subject to the terms and conditions of the Limited Warranties which can be viewed at http://www.xilinx.com/warranty.htm
subject to warranty and support terms contained in a license issued to you by Xilinx. Xilinx products are not designed or intended to be
fail-safe or for use in any application requiring fail-safe performance; you assume sole risk and liability for use of Xilinx products in Critical
Applications: http://www.xilinx.com/warranty.htm#critapps

© Copyright 2010–2012 Xilinx, Inc. Xilinx, the Xilinx logo, Artix, ISE, Kintex, Spartan, Virtex, Zynq, Vivado, and other designated brands
included herein are trademarks of Xilinx in the United States and other countries. All other trademarks are the property of their respective
owners.

.

; IP cores may be

Revision History

The following table shows the revision history for this document.

Date Version Revision

05/18/10 1.0 Initial Xilinx release.

09/04/12 1.1 • Updated Additional Documentation section.

•In Chapter 1, deleted first and last paragraphs from Differential I/O Standards.
Eliminated statements pertaining to differential drivers and receivers disabled in
suspend mode. Reinforced the directive that the SUSPEND pin must be tied to GND
when the suspend feature is disabled by adding “or High” to second paragraph of

SUSPEND Pin. Changed “X” to “0” in first row of Tab le 1- 5. Changed the AWAKE

output pin power supply to V

Pin Behavior when Suspend Feature is Enabled. Added “for Recommended

Operating Conditions” to data sheet power levels referenced in FPGA Voltage

Requirements During Suspend Mode.

•In Chapter 2, changed “used” to “being programmed” in description section, last row,
of Ta bl e 2 -1 . Added V

±5%” specification from first paragraph in VCCAUX Specifications and third

“

CCAUX

paragraph of VCCO.

•In Chapter 3, removed “approximately one speed grade slower (~15%)” from first
paragraph in Introduction. Added a UG382 reference to Designing Using the

Lower-Power Spartan-6 LX Devices. Added V

paragraphs to Lower-Power Spartan-6 LX Device Specifications.

•In Chapter 5, removed “50%” specification from second paragraph in Saving Power.
Also remove last sentence referencing techniques for past FPGA families from last
paragraph in ISE Design Suite Power Optimization.

power rail on bank 1 in third paragraph of AWAK E

CCO

setting restriction paragraphs to VCCAUX. Removed

and IODELAY2 specification

CCAUX

Spartan-6 FPGA Power Management www.xilinx.com UG394 (v1.1) September 4, 2012

Table of Contents

Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Preface: About This Guide

Guide Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Additional Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Additional Support Resources. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Chapter 1: Power Management With Suspend Mode

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Differences from Extended Spartan-3A Family. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Multi-Pin Wake-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Suspend Synchronization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Suspend Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Design Steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Entering Suspend Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Exiting Suspend Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

PROGRAM_B Programming Pin Always Overrides Suspend Mode . . . . . . . . . . . . . 14

Enable the Suspend Feature and Glitch Filtering. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

User Constraints File Enable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Bitstream Generator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Define the Multi-Pin Wake-Up Feature and Pins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Define the I/O Behavior During Suspend Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Single-Ended I/O Standards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Differential I/O Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

SUSPEND Attribute. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

UCF Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Design Maintained during Suspend Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Design Requirements to Maintain Application Data . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Suspend Mode Wake-Up Timing Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Wake-Up Timing Clock Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Switch Outputs from Suspend to Normal Behavior . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Release Write Protect on Clocked Primitives. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Dedicated Configuration Pins Unaffected During Suspend Mode. . . . . . . . . . . . 19

JTAG Operations Allowed During Suspend Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

SUSPEND Pin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

SUSPEND Input Glitch Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

SUSPEND_SYNC Primitive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

AWAKE Pin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

General Behavior (Suspend Feature Disabled) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

AWAKE Pin Behavior when Suspend Feature is Enabled . . . . . . . . . . . . . . . . . . . . . . 21

Controlling Wake-Up from an External Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Synchronizing Wake-Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Spartan-6 FPGA Power Management www.xilinx.com 3

UG394 (v1.1) September 4, 2012

Post-Configuration CRC Limitations When Using Suspend Mode. . . . . . . . . . . . 22

FPGA Voltage Requirements During Suspend Mode . . . . . . . . . . . . . . . . . . . . . . . . 24

Memory Controller Block . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Chapter 2: Voltage Supplies

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

VCCINT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

VCCAUX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Setting the VCCAUX Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

VCCAUX Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

VCCO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

VREF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Board Design and Signal Integrity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Simultaneously Switching Outputs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Power Distribution System Design and Decoupling/Bypass Capacitors . . . . . . . . . . 28

Chapter 3: Lower-Power Spartan-6 LX Devices

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Designing Using the Lower-Power Spartan-6 LX Devices . . . . . . . . . . . . . . . . . . . . 29

Lower-Power Spartan-6 LX Device Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Chapter 4: Power-On and Power-Down Behavior Including Hibernate

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Power-On Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Supply Sequencing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Ramp Rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Hot Swap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Configuration Data Retention and Brown Out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

GTP Transceiver Power-Up and Power-Down . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Hibernate Power Down . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Forcing FPGA to Quiescent Current Levels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Entering Hibernate State . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Turn Off VCCO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Exiting Hibernate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Design Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Chapter 5: Power Estimation

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Voltage Regulators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Saving Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Saving Clock Routing Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

ISE Design Suite Power Optimization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

4 www.xilinx.com Spartan-6 FPGA Power Management

UG394 (v1.1) September 4, 2012

About This Guide

This document provides information on the various hardware methods of power
management in Spartan-6 FPGAs, primarily focusing on the suspend mode. Other power
management topics include the lower-power Spartan-6 LX devices (-1L) and the
programmable V
provided on the power rails, including hot swap and hibernate (power-off) options.

Guide Contents

This user guide contains the following chapters:

• Chapter 1, Power Management With Suspend Mode

• Chapter 2, Voltage Supplies

• Chapter 3, Lower-Power Spartan-6 LX Devices

• Chapter 4, Power-On and Power-Down Behavior Including Hibernate

• Chapter 5, Power Estimation

level available in all Spartan-6 devices. In addition, more detail is

CCAUX

Preface

Additional Documentation

These documents are available for download at

http://www.xilinx.com/support/documentation/spartan-6.htm

• Spartan-6 Family Overview

This overview outlines the features and product selection of the Spartan-6 family.

• Spartan-6 FPGA Data Sheet: DC and Switching Characteristics

This data sheet contains the DC and switching characteristic specifications for the
Spartan-6 family.

• Spartan-6 FPGA Packaging and Pinout Specifications

This specification includes the tables for device/package combinations and maximum
I/Os, pin definitions, pinout tables, pinout diagrams, mechanical drawings, and
thermal specifications.

• Spartan-6 FPGA Configuration User Guide

This all-encompassing configuration guide includes chapters on configuration
interfaces (serial and parallel), multi-bitstream management, bitstream encryption,
boundary-scan and JTAG configuration, and reconfiguration techniques.

• Spartan-6 FPGA SelectIO Resources User Guide

This guide describes the SelectIO™ resources available in all Spartan-6 devices.

.

Spartan-6 FPGA Power Management www.xilinx.com 5

UG394 (v1.1) September 4, 2012

Running H/F 3

•Spartan-6 FPGA Clocking Resources User Guide

This guide describes the clocking resources available in all Spartan-6 devices,
including the DCMs and PLLs.

• Spartan-6 FPGA Block RAM Resources User Guide

This guide describes the Spartan-6 device block RAM capabilities.

• Spartan-6 FPGA Configurable Logic Blocks User Guide

This guide describes the capabilities of the configurable logic blocks (CLBs) available
in all Spartan-6 devices.

• Spartan-6 FPGA GTP Transceivers User Guide

This guide describes the GTP transceivers available in the Spartan-6 LXT FPGAs.

• Spartan-6 FPGA DSP48A1 Slice User Guide

This guide describes the architecture of the DSP48A1 slice in Spartan-6 FPGAs and
provides configuration examples.

• Spartan-6 FPGA Memory Controller User Guide

This guide describes the Spartan-6 FPGA memory controller block, a dedicated
embedded multi-port memory controller that greatly simplifies interfacing
Spartan-6 FPGAs to the most popular memory standards.

• Spartan-6 FPGA PCB Design and Pin Planning Guide

This guide provides information on PCB design for Spartan-6 devices, with a focus on
strategies for making design decisions at the PCB and interface level.

These documents provide additional background:

• WP298

At 40 and 45 nm process nodes, power has become the primary factor for FPGA
selection. Spartan-6 FPGAs offer lower power, simpler power systems and PCB
complexity, better reliability, and lower system cost. This white paper details how
Xilinx designed for this new reality in Spartan-6 (45 nm) and Virtex®-6 (40 nm) FPGA
families, achieving dramatic power reductions over previous generation devices.

• WP370

Xilinx delivers the first automated, fine-grain clock-gating solution that can reduce
dynamic power by up to 30% for Spartan-6 FPGA designs.

• WP396
White Paper

This white paper describes how Spartan-6 FPGAs address the needs of high-volume
systems. The ability to connect efficiently and inexpensively to commodity memories,
high-performance chip-to-chip interface capability, and innovative power down
modes are just a few of the problems solved by high-performance, low-power, and
low-cost Spartan-6 FPGAs.

, Power Consumption at 40 nm and 45 nm, White Paper

, Reducing Switching Power with Intelligent Clock Gating, White Paper

, High-Volume Spartan-6 FPGAs: Performance and Power Leadership by Design,

Additional Support Resources

To search the database of silicon and software questions and answers or to create a
technical support case in WebCase, see the Xilinx website at:

http://www.xilinx.com/support

6 www.xilinx.com Spartan-6 FPGA Power Management

.

UG394 (v1.1) September 4, 2012

Chapter 1

Power Management With Suspend Mode

Introduction

Some applications require the lowest possible system cost or highest performance, and
other applications require the lowest possible standby power. Spartan®-6 FPGAs offer
low-power options to balance these cost and performance trade-offs.

The Spartan-6 family offers the suspend mode, an advanced static power-management
feature, which reduces FPGA power consumption while retaining the FPGA's
configuration data and maintaining the design. The device can quickly enter and exit
suspend mode as required in an application.

Differences from Extended Spartan-3A Family

The suspend mode in Spartan-6 FPGAs is a superset of the suspend feature in the
Extended Spartan-3A FPGAs. Two new enhancements include multi-pin wake-up and
suspend synchronization.

Multi-Pin Wake-up

The multi-pin wake-up feature allows the FPGA to monitor for a wake-up signal on up to
eight pins. In the Extended Spartan-3A family, monitoring was limited to the SUSPEND
pin itself. Multi-pin wake-up also allows a number of independent sources to trigger the
FPGA to return to the normal application.

Suspend Synchronization

The Spartan-6 FPGA primitive, SUSPEND_SYNC, enables the synchronization of the
suspend action with the application design. In the Extended Spartan-3A family, the
suspend mode activation begins immediately upon asserting the SUSPEND pin. The
Spartan-6 FPGA SUSPEND_SYNC primitive allows the application design to
acknowledge a suspend request, thereby allowing the application to finish necessary
functions prior to entering the suspend mode.

Spartan-6 FPGA Power Management www.xilinx.com 7

UG394 (v1.1) September 4, 2012

Chapter 1: Power Management With Suspend Mode

Suspend Features

The significant features and benefits of the suspend mode:

• Quickly and easily puts the FPGA into a static condition, eliminating most active
current.

• Reduces quiescent current by 40% or more.

• Retains FPGA configuration data and the state of the FPGA application during
suspend mode.

• Fast, programmable FPGA wake-up time from suspend mode.

• Individual control on each user-I/O pin to define pin behavior while in suspend
mode.

• Activated externally by the system using a single dedicated control pin (SUSPEND).

• Indicates the present suspend mode status using the AWAKE pin.

• Awakens an FPGA in suspend mode using any of eight SUSPEND control pins (SCP).

• SUSPEND_SYNC primitive to acknowledge a ready state prior to entering suspend
mode.

Design Steps

To use the suspend feature:

• Enable the Suspend Feature and Glitch Filtering, page 14

• Define the Multi-Pin Wake-Up Feature and Pins, page 15

• Define the I/O Behavior During Suspend Mode, page 15

• Implement steps to maintain application data during suspend mode
(SUSPEND_SYNC) (see Design Requirements to Maintain Application Data, page 17)

• Define the Suspend Mode Wake-Up Timing Controls, page 17

• Define the AWAKE Pin Behavior when Suspend Feature is Enabled, page 21

Entering Suspend Mode

Figure 1-1 is a block diagram of the FPGA entering suspend mode. Figure 1-2, page 10

shows example waveforms.

8 www.xilinx.com Spartan-6 FPGA Power Management

UG394 (v1.1) September 4, 2012

X-Ref Target - Figure 1-1

Entering Suspend Mode

FPGA Application Logic

SUSPEND

FPGA
Inputs

Glitch Filter

Writable Clocked Primitives

Flip-Flops

Latches

SUSPEND_SYNC

SREQ SACK

SRL

LUT RAM

Block RAM

Block FPGA

Inputs

Write-Protect Writable

Clocked Primitives

Apply SUSPEND Attribute

to FPGA Outputs

SUSPEND

Attribute

SUSPEND

Attribute

FPGA

Outputs

AWAK

E

Suspend Enable

ENABLE_SUSPEND

Filter Select

ENABLE_SUSPEND

SUSPEND_SYNC

Instantiated

UG394_c1_01_020310

Figure 1-1: Entering Suspend Mode

The FPGA can only enter suspend mode if enabled in the configuration bitstream (see

Enable the Suspend Feature and Glitch Filtering, page 14). The SUSPEND pin must be Low

during power up and configuration. Once enabled through the bitstream, and the
SUSPEND_SYNC primitive is not present in the design, when the SUSPEND pin is
asserted, the FPGA unconditionally and quickly enters suspend mode.

If the SUSPEND_SYNC primitive is present in the design, the FPGA does not enter
suspend mode until the suspend-acknowledge signal (SACK) is asserted. After the
SUSPEND pin is asserted, the SREQ port of the SUSPEND_SYNC primitive transitions
High. This can be used in the design to initiate any functions that must be completed prior
to the FPGA entering suspend mode. When these functions are complete, drive the SACK
port High.

After the FPGA enters suspend mode, all nonessential FPGA functions are shut down to
minimize power dissipation. The FPGA retains all configuration data while in suspend
mode. After entering suspend mode, all writable clocked primitives are write-protected
against spurious write operations, and all FPGA inputs and interconnects are shut down.
This allows the design state to be held static during suspend mode. If a specific design state
must be maintained, see Design Requirements to Maintain Application Data, page 17.

Spartan-6 FPGA Power Management www.xilinx.com 9

UG394 (v1.1) September 4, 2012

Chapter 1: Power Management With Suspend Mode

ug394_c1_02_042910

Blocked

t

SUSPEND_DISABLE

t

AWAKE_GWE

t

AWAKE_GTS

SUSPEND Input

AWAKE Output

Flip-Flops, Block RAM,

Distributed RAM

FPGA Outputs

FPGA Inputs,
Interconnect

Write Protected

Defined by SUSPEND Attribute

1

2

3

4

5

6

7

8

10

9

Entering Suspend Mode Exiting Suspend Mode

sw_gts_cycle

sw_gwe_cycle

t

SUSPEND_ENABLE

t

SUSPENDLOW_AWAKE

t

SUSPEND_GTS

t

SUSPENDHIGH_AWAKE

t

SUSPEND_GWE

Each FPGA output pin or bidirectional I/O pin assumes its defined suspend mode
behavior, which is described as part of the FPGA design using a SUSPEND attribute.

The AWAKE pin goes Low, indicating that the FPGA is in suspend mode. The DONE pin
remains High while the FPGA is in suspend mode because the FPGA configuration data is
not lost.

X-Ref Target - Figure 1-2

Figure 1-2: Suspend Mode Waveforms (Entering and Exiting)

This section details the waveform notes in Figure 1-2.

Entering Suspend in Figure 1-2

1. An external signal drives the FPGA's SUSPEND pin High, unconditionally forcing the
FPGA into the power-saving suspend mode (if SUSPEND_SYNC is not used). When

10 www.xilinx.com Spartan-6 FPGA Power Management

SUSPEND_SYNC is used, this phase does not complete until the SACK port of the
SUSPEND_SYNC primitive is asserted. Data values are captured for I/O pins with a
SUSPEND attribute set to DRIVE_LAST_VALUE; however, this value is not presented
until Step 4.

2. In response to the SUSPEND input going High or SACK assertion on the
SUSPEND_SYNC primitive, and after a delay of t
protects and preserves the states of all clocked primitives. The states of all flip-flops,
block RAM, distributed RAM (LUT RAM), shift registers (SRL), and I/O latches are
preserved during suspend mode.

SUSPEND_GWE

, the FPGA write

UG394 (v1.1) September 4, 2012

Entering Suspend Mode

3. After a delay of t

SUSPENDHIGH_AWAKE

, the FPGA drives the AWAKE output Low to

indicate that it is entering suspend mode.

4. After a delay of t

SUSPEND_GTS

, the FPGA switches the normal behavior of all outputs
over to the suspend mode behavior defined by the SUSPEND attribute assigned to
each I/O. See Define the I/O Behavior During Suspend Mode, page 15.

5. After a delay of t

SUSPEND_DISABLE

, FPGA inputs are blocked and the interconnect shut

off (High) to prevent any internal switching activity.

Exiting Suspend in Figure 1-2

6. The system drives the FPGA's SUSPEND input Low, causing the FPGA to exit suspend
mode. If using multi-pin wake-up mode, the system first drives the FPGA's SUSPEND
input LOW, then drives any of the enabled multi-pin wake-up pins High, causing the
FPGA to exit suspend mode.

7. The FPGA releases the inputs and interconnect after a delay of t

SUSPEND_ENABLE

allowing signals to propagate internally. There is no danger of corrupting the internal
state because all clocked primitives are still write protected.

8. After a delay of t

SUSPENDLOW_AWAKE

or t

SCP_AWAKE

, the FPGA asserts the AWAKE

signal with the bitstream option drive_awake:yes. If the option is drive_awake:no,
then the FPGA releases AWAKE to become an open-drain output. In this case, an
external pull-up resistor is required or an external signal must drive AWAKE High
before the FPGA continues to awaken. All subsequent timing is measured from when
the AWAKE output transitions High. If multiple FPGAs are waking up and need to be
synchronized, set drive_awake:no in each and then use an external pull-up resistor to
synchronize the AWAKE pins. If other devices are waking up and the FPGA(s) need to
wait, set drive_awake:no and use an external signal to control the AWAKE pin and
drive it High once the rest of the system is ready.

9. After a delay of t

AWAK E_ GTS

, the FPGA switches output behavior from the specified
SUSPEND attribute to the function specified in the FPGA application. The timing of
this switch-over is controlled by the suspend/wake sw_gts_cycle bitstream
generation setting, which defines when the FPGA's internal global three-state (GTS)
control is released. After the specified number of clock cycles, the outputs are active
according to the normal FPGA application. By default, the outputs are enabled four
clock cycles after AWAKE goes High. The outputs are generally released before the
clocked primitives to allow signals to propagate out of the FPGA.

10. After a delay of t

AWAK E_ GWE

, the writable, clocked primitives are released according
to the suspend/wake sw_gwe_cycle bitstream generator setting, which defines when
the FPGA's internal global write enable (GWE) control is asserted. After the specified
cycle, it is again possible to write to flip-flops, block RAM, distributed RAM (LUT
RAM), shift registers (SRL), and I/O latches. By default, the clocked primitives are
released five clock cycles after AWAKE transitions High. The write-protect lock should
be held until after outputs are enabled.

,

Spartan-6 FPGA Power Management www.xilinx.com 11

UG394 (v1.1) September 4, 2012

Chapter 1: Power Management With Suspend Mode

Exiting Suspend Mode

There are four possible ways to exit suspend mode in a powered system:

• Drive the SUSPEND input Low, exiting suspend mode.

• If multi-pin wake-up mode is enabled, drive the SUSPEND input Low and then assert
any one of the user enabled SCP pins.

• Pulse the PROGRAM_B input Low to reset the FPGA and cause the FPGA to
reprogram.

• Power cycle the FPGA, causing the FPGA to reprogram.

The block diagram in Figure 1-3 shows how to exit suspend mode using the SUSPEND
pin.

When SUSPEND transitions Low, the FPGA automatically re-enables all inputs and
interconnects after a delay of t
SUSPEND must first transition Low, then when any of the user enabled SCP pins for
multi-pin wake up mode transition High, the FPGA re-enables all inputs and interconnects
after a delay of t

When enabled in the FPGA bitstream, all flip-flops are optionally globally set or reset
according to the FPGA design description. By default, the flip-flops are not globally set or
reset, which preserves the state of the FPGA application from the beginning of suspend
mode.

SUSPEND_ENABLE

SUSPEND_ENABLE

.

. If using multi-pin wake-up mode,

The remaining wake-up process depends on two user-programmable timers which define
when FPGA outputs are re-enabled and when the write-protect lock is released from all
writable clocked primitives. These timers begin after the AWAKE pin is High. The
wake-up timing clock source is also programmable.

12 www.xilinx.com Spartan-6 FPGA Power Management

UG394 (v1.1) September 4, 2012

X-Ref Target - Figure 1-3

Exiting Suspend Mode

FPGA Application Logic

SUSPEND

FPGA
Inputs

Glitch Filter

Writable Clocked Primitives

LUT RAM

Re-enable

Set/Reset
Flip-Flops

SRL

Block RAM

Enable

Flip-Flops

Latches

FPGA Inputs

en_sw_gsr

Wake-Up

Timing Clock

Source

sw_clk

sw_gwe_cycle

Unlock Clocked

Primitives

1 1,024

5

sw_gts_cycle

Activate Outputs

1

4

1,024

FPGA

Outputs

SUSPEND

Attribute

SUSPEND

Attribute

AWAKE

SCP0

SCP1

SCP7

Suspend Enable

ENABLE_SUSPEND

Filter Select

ENABLE_SUSPEND

edge detector

wakeup_mask<0>

edge detector

wakeup_mask<1>

edge detector

wakeup_mask<7>

drive_awake

Multi-Pin Wake-up

multipin_wakeup

UG394_c1_03_020310

Figure 1-3: Exiting Suspend Mode

Spartan-6 FPGA Power Management www.xilinx.com 13

UG394 (v1.1) September 4, 2012

Chapter 1: Power Management With Suspend Mode

PROGRAM_B Programming Pin Always Overrides Suspend Mode

Pulsing the PROGRAM_B programming pin Low always overrides suspend mode and
forces the FPGA to restart configuration. Power-cycling the FPGA also restarts
configuration. If the SUSPEND input remains High, the device re-enters suspend mode
after finishing configuration.

Enable the Suspend Feature and Glitch Filtering

Before it can be used, the suspend power-saving feature must first be enabled in the FPGA
bitstream. By default, the suspend feature is disabled and driving the SUSPEND pin has no
effect. The suspend feature is enabled using the user constraints file (UCF), or through a
bitstream generator (BitGen) option.

User Constraints File Enable

Suspend mode is enabled and the SUSPEND input glitch filter option is defined using a
CONFIG statement in a UCF. Ta bl e 1-1 shows the available options. This is the
recommended method for enabling suspend mode as this attribute also automatically
reserves the AWAKE pin.

Config ENABLE_SUSPEND = "FILTERED" ;

Table 1-1: Available Options for the ENABLE_SUSPEND Attribute

Option Suspend Mode SUSPEND Pin Filter AWAKE Pin

NO Suspend mode is disabled Not applicable. Connect

SUSPEND pin to GND.

FILTERED Suspend mode is enabled Glitch filter is enabled. AWAKE status indicator.

UNFILTERED Glitch filter is bypassed.

Available as a user I/O pin
in the FPGA application.

Bitstream Generator

Setting the en_suspend bitstream option is an alternate way to enable the suspend mode.
However, this method is not recommended because it does not automatically reserve the
AWAKE pin in the application.

bitgen -g en_suspend:Yes

The following option enables the glitch filter on the SUSPEND pin.

bitgen -g suspend_filter:Yes

14 www.xilinx.com Spartan-6 FPGA Power Management

UG394 (v1.1) September 4, 2012

Enable the Suspend Feature and Glitch Filtering

Define the Multi-Pin Wake-Up Feature and Pins

The multi-pin wake-up feature is not required to use the suspend mode feature. If
multi-pin wake-up is not enabled, suspend mode is enabled and disabled using just the
SUSPEND pin. Multi-pin wake-up is enabled using a BitGen option.

bitgen -g multipin_wakeup:Yes

If multi-pin wake-up is enabled, select which pins are monitored for a rising edge to bring
the FPGA out of suspend mode. Eight SCP pins are used for the multi-pin wake-up
feature. Select from one to eight of these pins to monitor. The SCP pins are dual-purpose
user I/O pins and can be used as general-purpose I/O independent of the suspend
options. Any pins that are not used can be masked out as inputs to the multi-pin wake-up.
The option accepts two hex values for the mask. A value of FF enables all SCP pins, 0F
enables SCP<3..0>.

bitgen -g wakeup_mask:FF

Define the I/O Behavior During Suspend Mode

Use a SUSPEND attribute to define the behavior of each I/O and output pin during
suspend mode.

Single-Ended I/O Standards

Each output, open-drain output, or bidirectional I/O pin in the FPGA application that uses
a single-ended I/O standard can be individually programmed for one of the suspend
mode behaviors shown in Tab le 1 -2 . The default behavior is for a high impedance pin
during suspend mode although other options are available.

Table 1-2: Output Behavior Options during Suspend Mode

SUSPEND Attribute Function

The output continues to drive the level that was last stored in the output latch, according

DRIVE_LAST_VALUE

3STATE

(default)

3STATE_PULLUP

3STATE_PULLDOWN The output is in the high-impedance state with an internal pull-down resistor to GND.

3STATE_KEEPER

to the chosen standard. Requires V
for the bank.

The output is in the high-impedance state with no active internal pull-up or pull-down
resistor. Results in the lowest possible I/O current draw.

The output is in the high-impedance state with an internal pull-up resistor to the associated

supply. Requires V

V

CCO

bank.

The output is high impedance. The internal bus keeper circuit is active. Requires V
remain at the recommended operating conditions for the bank.

to remain at the recommended operating conditions for the

CCO

to remain at the recommended operating conditions

CCO

Differential I/O Standards

CCO

to

The output drivers for the LVDS, RSDS, mini-LVDS, PPDS, and TMDS differential I/O
standards are high impedance, using any of the 3STATE attributes described in Ta bl e 1- 2.
The DRIVE_LAST_VALUE attribute is not supported for differential output drivers.

Treat the pseudo-differential I/O standards, such as BLVDS, DIFF_HSTL, and DIFF_SSTL,
as two single-ended I/O pins. All the attributes apply as for Single-Ended I/O Standards

Spartan-6 FPGA Power Management www.xilinx.com 15

UG394 (v1.1) September 4, 2012

Chapter 1: Power Management With Suspend Mode

although for any differential standard the settings must be set appropriately for both pins
of the complementary pair.

When in the high-impedance state, the differential driver pair does not conduct current to
the power or ground rails, or between adjacent pins.

SUSPEND Attribute

The SUSPEND attribute allows each pin to have an individually defined behavior during
suspend mode. The available options are listed in Tab le 1- 2.

UCF Example

This UCF constraint example defines the suspend mode behavior for a specific pin. The
SUSPEND attribute can be included on the same UCF line as other constraints for a pin.

Net "<net_name>" SUSPEND = "io_type" ;

UCF entries for a single-ended pin and a differential pair are shown in the following
example:

NET "TX<0>" IOSTANDARD = LVCMOS_33 | SUSPEND = "DRIVE_LAST_VALUE" ;
NET "TX_P<0>" IOSTANDARD = LVDS_33 | SUSPEND = "3STATE_PULLUP" ;
NET "TX_N<0>" IOSTANDARD = LVDS_33 | SUSPEND = "3STATE_PULLDOWN" ;

Design Maintained during Suspend Mode

After entering suspend mode, all writable clocked primitives are write-protected after a
delay of t
suspend mode.

• Logic block flip-flops

• I/O block latches and flip-flops

• Logic block distributed RAM (LUT RAM)

• Logic block shift registers (SRL)

• Block RAM and registers

When exiting suspend mode, all writable clocked primitives are re-enabled, controlled by
the sw_gwe_cycle setting.

An additional bitstream option, en_sw_gsr, controls whether all clocked primitives are
globally set or reset when the FPGA awakens from suspend mode. By default,
en_sw_gsr:No signifies that clocked primitives are not set or reset when the FPGA
awakens and all states are preserved.

SUSPEND_GWE

. The state of all clocked memory primitives is maintained during

16 www.xilinx.com Spartan-6 FPGA Power Management

UG394 (v1.1) September 4, 2012

Suspend Mode Wake-Up Timing Controls

Design Requirements to Maintain Application Data

When a design requires that application data be preserved when entering suspend mode,
the SUSPEND_SYNC primitive should be used. When the FPGA enters suspend mode, the
global write enable (GWE) is removed, maintaining the state of all flip-flops and user
RAM. The FPGA requires a delay of t
SUSPEND pin and disabling GWE internally. This is the first event after SUSPEND
transitions High, before AWAKE toggles, and before the inputs are disabled if
SUSPEND_SYNC is not used. During this delay, additional user clocks to flip-flops or
RAM can continue to update their contents. Since the GWE signal can have some skew
between locations on the device, some locations can be disabled while others remain
enabled on the last clock edge before GWE takes full effect. This situation can be avoided
when using the SUSPEND_SYNC feature. After the suspend request is driven out of the
SUSPEND_SYNC primitive, disable the clocks and/or clock enables on the logic that must
retain its current state. After the disable is complete, drive the SACK port of the
SUSPEND_SYNC primitive and the FPGA begins the process to enter suspend mode.

To avoid initializing the flip-flops when exiting suspend mode, choose en_sw_gsr:No.
Exiting suspend mode should be synchronized to a user clock to avoid race conditions
corrupting the application data. Inputs are enabled first, allowing control signals to
continue to hold off the toggling of storage primitives. The assertion of GWE can be
synchronized to a user clock to align it with a system clock edge.

SUSPEND_GWE

between recognizing a High on the

Suspend Mode Wake-Up Timing Controls

When exiting suspend mode, the wake-up sequence for the FPGA is programmable and
controlled by a single clock.

Wake-Up Timing Clock Source

The wake-up timing when exiting suspend mode is controlled by a selectable clock source
as shown in Figure 1-4 and described in Tab le 1- 3. The clock source is defined by one or
two bitstream generator options, sw_clk and sometimes StartupClk.

The internal oscillator is disabled during suspend mode to conserve power.

Spartan-6 FPGA Power Management www.xilinx.com 17

UG394 (v1.1) September 4, 2012

Chapter 1: Power Management With Suspend Mode

X-Ref Target - Figure 1-4

CCLK input only available for
applications that configure in Slave
mode. Persist = Yes required.

CCLK

TCK

User Clock from
FPGA Interconnect

STARTUP_SPARTAN6

CLK

Figure 1-4: Suspend Mode Wake-Up Timing Control Clock Selection

•The sw_clk option is specific to the suspend feature. By default,
sw_clk:InternalClk.

•The StartupClk option is available on every application. The same option used to
clock the start-up process at the end of configuration can be used to clock the wake-up
process at the end of suspend. StartupClk:Cclk is the default; however, using this
for suspend wake-up requires a persisted slave configuration mode. When using
sw_clk:StartupClk and StartupClk:Cclk, and exiting suspend mode, the
CCLK pin becomes the clock source. The Persist option also retains the dual-purpose
configuration pins associated with the configuration logic.

Cclk

Jtag

UserClk

StartupClk

~50 MHz

Internal

Oscillator

StartupClk

InternalClk

sw_clk

Suspend

Wake-Up

Timing

Control

UG394_c1_04_121009

Table 1-3: Clock Sources to Wake-Up from Suspend Mode

sw_clk

Setting

InternalClk NA Internal Oscillator

StartupClk

18 www.xilinx.com Spartan-6 FPGA Power Management

StartupClk

Setting

Cclk CCLK pin on FPGA

JtagClk TCK pin on FPGA

UserClk

Clock Source Restriction

The oscillator has an imprecise frequency of about
50 MHz.

This option is only available for FPGAs using Slave
configuration mode. The bitstream option Persist:Yes
must be set. This option is not available for FPGAs
using the master configuration mode; use InternalClk
instead.

The JTAG interface must be active to exit suspend
mode.

The clock input to the STARTUP design primitive can
CLK input on the
STARTUP_SPARTAN6
design primitive

originate from any non-clocked signal in the FPGA. It

cannot originate from a flip-flop source because all

clocked primitives are write-protected while in

suspend mode.

UG394 (v1.1) September 4, 2012

Dedicated Configuration Pins Unaffected During Suspend Mode

Switch Outputs from Suspend to Normal Behavior

The suspend/wake sw_gts_cycle bitstream option controls when I/O pins are released
from their SUSPEND attribute settings and returned to normal operation. The timing is
controlled by the Wake-Up Timing Clock Source, page 17. The default sw_gts_cycle setting
is four cycles, but this control can be set for any value between one and 1,024 clock cycles.

The suspend/wake control becomes active after the AWAKE pin transitions High. After
the specified number of clock cycles, all output, open-drain output, and bidirectional I/O
pins transition from their suspend behavior, either the default 3STATE or individually
specified using the SUSPEND attribute, back to the normal behavior specified in the
original FPGA application.

The outputs should be released before releasing the write-protect lock on all clocked
primitives.

Release Write Protect on Clocked Primitives

The suspend/wake sw_gwe_cycle bitstream option controls when the write-protect lock is
released on all clocked primitives.

The timing is controlled by sw_clk the Wake-Up Timing Clock Source, page 17. The default
sw_gwe_cycle setting is five cycles, but the suspend/wake control can be set for any value
between one and 1,024 clock cycles.

This suspend/wake control becomes active after the AWAKE pin transitions High. After
the specified number of clock cycles, the write-protect lock is released from all writable,
clocked primitives such as flip-flops, block RAM, etc.

When the en_sw_gsr:yes option is set, the clocked primitives are already globally set or
reset to the value specified in the original FPGA design before the write-protect lock is
released. The option en_sw_gsr:no signifies that the state of the FPGA after entering
suspend mode is preserved.

The outputs should be released before releasing the write-protect lock on all clocked
primitives.

Dedicated Configuration Pins Unaffected During Suspend Mode

The following dedicated configuration pins are unaffected when the FPGA is in suspend
mode:

• JTAG pins: TDI, TMS, TCK, and TDO

•DONE pin

•PROGRAM_B pin

JTAG Operations Allowed During Suspend Mode

Tab le 1- 4 shows the JTAG operations permitted when the FPGA is in suspend mode.

Executing these JTAG operations increases the FPGA's power consumption while in
suspend mode.

Spartan-6 FPGA Power Management www.xilinx.com 19

UG394 (v1.1) September 4, 2012

Chapter 1: Power Management With Suspend Mode

Table 1-4: JTAG Operations Allowed during Suspend Mode

SUSPEND Pin

Boundary-Scan

Command

Read the JTAG ID code that describes the Spartan-6 FPGA array

IDCODE

BYPASS Enables BYPASS.

USERCODE Read the user-defined code embedded in the FPGA bitstream.

type in the JTAG chain. This value is different from the Device
DNA identifier, which is unique to every device.

Description

Do not use any other JTAG instructions when in suspend mode or while transitioning into
and out of suspend mode. Furthermore, do not enter suspend mode when performing a
readback operation.

When the suspend feature is enabled (see Enable the Suspend Feature and Glitch Filtering,

page 14), the SUSPEND pin controls when the FPGA enters suspend mode. During normal

FPGA operation, the SUSPEND pin must be Low. When High, the SUSPEND pin forces the
FPGA into the low-power suspend mode. Tab le 1- 5 describes the functionality of the
SUSPEND pin.

If the suspend feature is not enabled for an application (the application never enters
low-power mode), then connect the SUSPEND pin to GND. Do not leave the pin floating
or High.

Table 1-5: SUSPEND Pin Functionality

ENABLE_SUSPEND

Settings

NO (default)

Suspend Mode

Disabled

Filtered, Unfiltered

Suspend Mode

Enabled

SUSPEND

Pin

0

0

1

The suspend feature is disabled. The SUSPEND pin is unused and ignored.
Connect the SUSPEND pin to GND.

The FPGA performs the application described in the bitstream loaded into the
FPGA during configuration. When the SUSPEND pin changes from High to
Low, wake the FPGA from suspend mode. Return from suspend mode also
depends on the SCP pins, if used.

Force the FPGA to enter power-saving suspend mode pending SACK assertion
on SUSPEND_SYNC primitive, if used.

Characteristics

The SUSPEND pin is an LVCMOS/LVTTL receiver, and power to the input buffer is
supplied by the V
configuration, and the HSWAPEN control has no effect on the SUSPEND pin.

Function

power rail. The SUSPEND pin has no pull-up resistors during

CCAUX

20 www.xilinx.com Spartan-6 FPGA Power Management

UG394 (v1.1) September 4, 2012

SUSPEND Input Glitch Filter

The SUSPEND pin has a programmable glitch filter to guard against short pulses, which
could cause the FPGA to spuriously enter suspend mode. Turning off the filter allows the
FPGA to enter or exit suspend mode more quickly, but the application must guard against
spurious pulses. The difference in delay is the t
FPGA Data Sheet: DC and Switching Characteristics. See Enable the Suspend Feature and

Glitch Filtering, page 14.

SUSPEND_SYNC Primitive

The SUSPEND_SYNC primitive is the application interface to a suspend request. If this
primitive is not present in the design, the FPGA begins the suspend sequence solely on the
state of the SUSPEND pin.

When the SUSPEND_SYNC primitive is in the design, after the SUSPEND pin is asserted
High and the filter delay (when the glitch filter is enabled), the SUSPEND_SYNC primitive
drives the SREQ port High on the next rising clock edge on the CLK port. This indicates
that a request has been received to enter suspend mode. The FPGA does not enter suspend
mode until the SACK port is driven High on a rising edge of CLK.

This primitive provides an ideal interface for the application to complete any functions
prior to entering suspend mode. Any I/O interface ports can be closed, buffers flushed,
and clocks disabled to ensure the application is in a ready state prior to being suspended.
For more details, see Design Maintained during Suspend Mode, page 16.

SUSPEND Input Glitch Filter

SUSPENDFILTER

value in DS162, Spartan-6

AWAKE Pin

General Behavior (Suspend Feature Disabled)

AWAKE Pin Behavior when Suspend Feature is Enabled

The AWAKE pin (optionally) provides status on the suspend power-savings mode.

Unless the suspend feature is enabled, the AWAKE pin is a general-purpose user-I/O pin.

If the suspend feature is enabled, then the AWAKE pin indicates the present state of the
FPGA, as summarized in Ta bl e 1 -6 . The AWAKE pin cannot be used by the FPGA
application as a general-purpose I/O pin.

Table 1-6: AWAKE Pin Status

AWAKE Pin Indication

0 The FPGA is presently in the low-power suspend mode.

1 The FPGA is active.

The AWAKE pin can further be configured as an open-drain output (the default) or a
full-swing output driver, as shown in Figure 1-5. This behavior is controlled by a bitstream
generator (BitGen) option:

bitgen -g drive_awake:no

Spartan-6 FPGA Power Management www.xilinx.com 21

UG394 (v1.1) September 4, 2012

Chapter 1: Power Management With Suspend Mode

X-Ref Target - Figure 1-5

drive_awake=yes drive_awake=no

FPGA FPGA

Internal

Awake
Signal

O

AWAKE AWAKE

Internal

Awake
Signal

External Pull-up

Resistor Required

V

CC

20 kΩ

(OE)

T

O

LVCMOS

12 mA
FAST

Figure 1-5: AWAKE Output Drive Options if Suspend Mode Enabled

The AWAKE output pin is supplied by the V

power rail on bank 1.

CCO

When the option drive_awake:yes is set, the AWAKE pin is an active output driver,
equivalent to a user I/O configured as LVCMOS, with a 12 mA output drive and a fast
slew rate.

Controlling Wake-Up from an External Source

The default option is drive_awake:no. The drive_awake:no option signifies that the
AWAKE pin is an open-drain output capable of sinking 12 mA. In this case, an external
pull-up resistor is required to exit suspend mode. To minimize the amount of current flow
during suspend mode, the resistor value should be high. The resistor needs to be strong
enough to overcome the I/O pin leakage. A large resistor value also equates to a longer
AWAKE rise time. The FPGA does not exit suspend mode and begin the wake-up process
until AWAKE transitions High.

Synchronizing Wake-Up

The wake-up process can be synchronized across multiple FPGAs or between the FPGAs
and the system by using one SUSPEND signal to control multiple devices. The AWAKE pin
can also synchronize multiple devices. To start the wake-up process at the same time, the
AWAKE pins of multiple FPGAs can be tied to a single pull-up resistor. The wake-up
counters can also be synchronized if sw_clk:StartupClk and StartupClk:UserClk.

LVCMOS

12 mA
FAST

UG394_c1_05_121009

Holding the AWAKE pin Low delays the transition from suspend mode to active mode by
holding off the sw_gwe_cycle and sw_gts_cycle counters, and allows an external
controller to decide when to begin the wake-up process in the FPGA.

Post-Configuration CRC Limitations When Using Suspend Mode

To minimize power, post-configuration CRC checking stops during suspend mode.

If an active application uses the post-configuration CRC feature and an error occurs, do not
enter suspend mode. If there is a CRC error, the FPGA does not wake from suspend mode
without reprogramming, such as asserting PROGRAM_B or power-cycling the FPGA.

22 www.xilinx.com Spartan-6 FPGA Power Management

UG394 (v1.1) September 4, 2012

Post-Configuration CRC Limitations When Using Suspend Mode

Several design options are possible:

1. Do not use the post-configuration CRC feature when the suspend mode feature is
enabled and vice versa.

2. Always reprogram the device when a CRC error occurs.

Tab le 1- 7 summarizes the various bitstream options associated with suspend mode.

Table 1-7: Suspend Mode Bitstream Generator Options

Suspend Mode

Bitstream Options

drive_awake

en_sw_gsr No

sw_clk StartupClk

sw_gwe_cycle

Options

(Default) Description

No

(Default)

Ye s

(Default)

Ye s

(Default)

InternalClk

1,..,5,...,1024

Default is 5

If suspend mode is enabled, indicates the present status on AWAKE using an
open-drain output. An external pull-up resistor or High signal is required to exit
SUSPEND mode.

If suspend mode is enabled, indicates the current status by actively driving the
AWAKE output.

The state of all clocked primitives in the FPGA is preserved.

Pulses the GSR signal during wake-up, setting or resetting all clocked
primitives, as originally specified in the FPGA application. The GSR pulse
occurs before the AWAKE pin transitions High and before the sw_gwe_cycle
and sw_gts_cycle settings are active.

Uses the clock defined by the StartupClk bitstream generator setting to
control the suspend wake-up timing.

Uses the internally generated 50 MHz oscillator to control the suspend wake-up
timing.

After the AWAKE pin is High, indicates the number of clock cycles as defined by
the sw_clk setting, when the global write-protect lock is released for writable
clocked primitives (flip-flops, block RAM, etc.). The default value is five clock
cycles after the AWAKE pin transitions High. Generally, this value is equal to or
greater than the sw_gts_cycle setting.

sw_gts_cycle

1,..,4,...,1024

Default is 4

multipin_wakeup No

(Default)

Yes Enables multi-pin wake-up.

wakeup_mask 0x00

(Default)

<hex string> FF enables SCP<7:0>, 0F enables SCP<3:0>.

Spartan-6 FPGA Power Management www.xilinx.com 23

UG394 (v1.1) September 4, 2012

After the AWAKE pin is High, indicates the number of clock cycles as defined by
the sw_clk setting, when the I/O pins switch from their SUSPEND Attribute,

page 16 settings back to their normal functions. The default value is four clock

cycles after the AWAKE pin goes High. Generally, this value is equal to or less
than the sw_gwe_cycle setting.

Disables multi-pin wake-up.

Masks out SCP<7:0>

Chapter 1: Power Management With Suspend Mode

FPGA Voltage Requirements During Suspend Mode

During suspend mode, the V
sheet levels for Recommended Operating Conditions. However, the V
of the I/O banks can be (potentially) turned off to conserve additional power, depending
on system requirements. Optionally, V
also affects the voltage levels for any output pin with a SUSPEND attribute set to
DRIVE_LAST_VALUE.

The FPGA's power-on reset (POR) circuit continues to monitor the V
supplies. Although V
does not monitor the V
V

CCAUX

supply dips below the minimum specified data sheet voltage limit, then the FPGA

restarts configuration.

Memory Controller Block

Recommendations and methods for using the memory controller block interface with the
Spartan-6 FPGA suspend mode are found in UG388
Block User Guide.

and V

CCINT

CCO

is an input to the POR circuit at initial power-on, the POR circuit

CCO2

supplies after configuration. By default, if the V

CCO

rails must remain powered at the data

CCAUX

supply to each

CCO

can be reduced during suspend mode, but this

and V

CCINT

CCINT

, Spartan-6 FPGA Memory Controller

CCAUX

or

24 www.xilinx.com Spartan-6 FPGA Power Management

UG394 (v1.1) September 4, 2012

Voltage Supplies

Introduction

Spartan-6 FPGAs have multiple voltage supply inputs, as shown in Ta bl e 2- 1. There are
two supply inputs for internal logic functions, V
has a separate V
I/O bank. V

CCO

voltage is needed for HSTL/SSTL standards. The GTP transceivers have dedicated analog
power rails (see UG386
AES circuitry has its own power supplies for the encryption key, depending on how it is
stored (see UG380

Table 2-1: Spartan-6 FPGA Voltage Supplies

supply input that powers the output buffers within the associated

CCO

is also used for input buffers for some I/O standards. A V

, Spartan-6 FPGA Configuration User Guide for more details).

Chapter 2

and V

CCINT

, Spartan-6 FPGA GTP Transceivers User Guide for more details). The

. Each of the I/O banks

CCAUX

reference

REF

Supply Input Description Devices

Internal core supply voltage. Supplies all internal logic

V

CCINT

V

CCAUX

V

CCO_0

V

CCO_1

V

CCO_2

functions, such as CLBs, block RAM, and DSP blocks.
Input to the power-on reset (POR) circuit. Powers input
signals for most standards at 1.2V, 1.5V, and 1.8V.

Auxiliary supply voltage. Supplies clock management
tiles (CMTs), some I/O resources, some dedicated
configuration pins, and JTAG interface. Powers input
signals for most standards at 2.5V and 3.3V. Input to the
POR circuit.

Supplies the output buffers in I/O bank 0, the bank
along the top edge of the FPGA.

Supplies the output buffers in I/O bank 1, the bank
along the right edge of the FPGA. During configuration
in byte-wide peripheral interface (BPI) Parallel Flash
Mode, connects to the same voltage as the Flash PROM.

Supplies the output buffers in I/O bank 2, the bank
along the bottom edge of the FPGA. Connects to the
same voltage as the FPGA configuration source. Input to
the POR circuit.

Nominal Supply

Volt ag e

All 1.2V; 1.0V (-1L)

lower-power

in

Spartan-6 LX

devices

All 2.5V;

3.3V optional

All Selectable: 3.3V,

2.5V, 1.8V, 1.5V,
or 1.2V

All Selectable: 3.3V,

2.5V, 1.8V, 1.5V,
or 1.2V

All Selectable: 3.3V,

2.5V, 1.8V, 1.5V,
or 1.2V

Supplies the output buffers in I/O bank 3, the bank

V

CCO_3

Spartan-6 FPGA Power Management www.xilinx.com 25

UG394 (v1.1) September 4, 2012

along the left edge of the FPGA.

All Selectable: 3.3V,

2.5V, 1.8V, 1.5V,
or 1.2V

Chapter 2: Voltage Supplies

Table 2-1: Spartan-6 FPGA Voltage Supplies (Cont’d)

Supply Input Description Devices

V

CCO_4

Supplies the output buffers in I/O bank 4, the bank
along the top of the left edge of the FPGA in 6-bank
devices.

LX75/T, LX100/T,

and the LX150/T

in FG(G)676 and

Nominal Supply

Volt ag e

Selectable: 3.3V,

2.5V, 1.8V, 1.5V,
or 1.2V

FG(G)900

V

CCO_5

Supplies the output buffers in I/O bank 5, the bank
along the top of the right edge of the FPGA in 6-bank
devices.

LX75/T, LX100/T,

and the LX150/T

in FG(G)676 and

Selectable: 3.3V,

2.5V, 1.8V, 1.5V,
or 1.2V

FG(G)900

V

REF

MGTAVCC

Input threshold voltage pins when HSTL/SSTL
standards are used in the bank, otherwise user I/Os.
When used as a reference voltage within a bank, all

V

pins within that bank must be connected.

REF

Power-supply pin for the transceiver mixed-signal
circuitry.

All Varies

LXT 1.2V

MGTAVCCPLL0/1 Power-supply pin for the transceiver PLL LXT 1.2V

MGTAVTTTX/RX

MGTAVTTRCAL

Power-supply pin for the transceiver TX and RX
circuitry.

Power-supply pin for the transceiver resistor calibration
circuit.

LXT 1.2V

LXT 1.2V

V

BATT

V

FS

V

CCINT

V

CCAUX

Decryptor key memory backup supply. When key is not
used, tie this pin to V

or GND, or it can be left float ing.

CC

Decryptor key EFUSE power supply pin for
programming. When key is not being programmed, tie
this pin to V

V

CCINT

or GND, or it can be left floating.

CC

is the primary power supply for the FPGA. In the Spartan-6 LXT family and the

LX75/T, LX100/T,

LX150/T

LX75/T, LX100/T,

LX150/T

standard devices in the Spartan-6 LX family (-2 and -3 speed grades), V

CCINT

3.3V

3.3V

has a

nominal value of 1.2V. The lower-power Spartan-6 LX devices (-1L speed grade) uses a
nominal V

V

powers the auxiliary logic, including configuration logic and some internal and

CCAUX

I/O resources. The Spartan-6 FPGA’s V
provide greater flexibility and allow V
rail, to minimize the number of power rails. Reducing V
power consumption on the V

During configuration, if V
V

can be either 2.5V or 3.3V. See UG380, Spartan-6 FPGA Configuration User Guide.

CCAUX

The -1L speed grade devices require V

of 1.0V. See Chapter 3, Lower-Power Spartan-6 LX Devices.

CCINT

is either 2.5V or 3.3V. These two voltages

CCAUX

to be set to the same level as an existing V

CCAUX

CCAUX

CCAUX

CCO_2

rail by 40%.

is 1.8V, V

CCAUX

must be 2.5V. If V

CCAUX

= 2.5V when using the LVDS_25, LVDS_33,

to 2.5V can reduce the

is 2.5V or 3.3V,

CCO_2

BLVDS_25, LVPECL_25, RSDS_25, RSDS_33, PPDS_25, and PPDS_33 I/O standards on
inputs. See DS162

, Spartan-6 FPGA Data Sheet: DC and Switching Characteristics.

CCO

26 www.xilinx.com Spartan-6 FPGA Power Management

UG394 (v1.1) September 4, 2012

VCCO

Setting the V

The user must set the CONFIG V
to the V
affects the banking rules for I/O placement within the automated placer, as well as in the
pin assignments tool. It also affects the end-generated bitstream for the device. The
V

CCAUX

particular primitive.

V

CCAUX

Specifications

Both the 2.5V and 3.3V settings for V

3.45V). The data retention voltage is the same for both at 2.0V, so more care must be taken
with a 2.5V rail to not let it drop more than 0.5V. See DS162
and Switching Characteristics for complete specifications.

The CONFIG V
LVCMOS25 inputs can be powered by V
to power LVCMOS25 inputs. If CONFIG V
with LVCMOS25 inputs. Setting V
LVCMOS25 and LVCMOS33 can help optimize placement.

There are some slight changes to resistor values depending on whether V

2.5V or 3.3V. The I/O pull-down resistor values are lower for a V
differential termination resistor (DIFF_TERM) can be more tightly controlled around 100Ω
when V
Characteristics and the Spartan-6 FPGA IBIS models at:

CCAUX

Level

attribute according to the voltage being provided

rails. The valid values for this attribute are 2.5 (default) or 3.3. This attribute

CCAUX

CCAUX

attribute is a global attribute for the Spartan-6 device and is not attached to any

CONFIG VCCAUX=3.3;

allow a variation (2.375V to 2.625V, or 3.15V to

CCAUX

, Spartan-6 FPGA Data Sheet: DC

attribute is used by the ISE® Design Suite software to determine if

CCAUX

CCAUX

is 3.3V. See DS162, Spartan-6 FPGA Data Sheet: DC and Switching

CCAUX

CCAUX

CCAUX

. If CONFIG V

= 3.3, V

CCO

= 2.5, V

CCAUX

CCAUX

must be 2.5V for any banks

to match whichever is more common between

CCAUX

of 3.3V. The

CCAUX

is used

is set to

V

CCO

h

ttp://www.xilinx.com/support/download/index.htm

V

powers the I/O resources, and has separate rails for each bank of I/O for maximum

CCO

flexibility. All of the V
same voltage. The V

connections to a specific I/O bank must be connected to the

CCO

voltage can be 1.2V to 3.3V, depending on the output standard

CCO

specified for a given bank. Most devices have four I/O banks, while the XC6SLX75/T and
larger in the FG(G)676 and FG(G)900 packages offer six I/O banks. The V

pins for a

CCO

bank should all be tied to a supply rail, even if the bank is completely unused.

In a 3.3V-only application, all V

supplies and V

CCO

connect to 3.3V. Spartan-6

CCAUX

FPGAs allow bridging between different I/O voltages and standards by applying different
voltages to the V

U

G381, Spartan-6 FPGA SelectIO Resources User Guide for the I/O standards that can be

inputs of different banks. Refer to the I/O banking rules section in

CCO

mixed within a single I/O bank.

The Spartan-6 FPGA V
Refer to DS162

, Spartan-6 FPGA Data Sheet: DC and Switching Characteristics for specific

ranges support variation around the nominal supply voltage.

CCO

voltage levels.

Spartan-6 FPGA Power Management www.xilinx.com 27

UG394 (v1.1) September 4, 2012

Chapter 2: Voltage Supplies

V

REF

Each I/O bank also has a separate, optional input voltage reference supply, called V
the I/O bank includes an I/O standard that requires a voltage reference such as HSTL or
SSTL, then all V
V

pins are available as I/O pins if no standards within a bank require them.

REF

Xilinx recommends always separating V
A stable V
implementation is also possible. Knowledge of the PCB environment, such as frequency of
coupled noise, is required to correctly calculate the resistance and capacitance values of the
divider circuit. As a result, an isolated reference supply is usually a more robust and
simpler approach. Refer to UG381
details on V

REF

REF

pins within the I/O bank must be connected to the same voltage. The

REF

using a small LDO is the desirable implementation. A voltage divider

.

Board Design and Signal Integrity

Building a working system today requires knowledge of the many options available. The
advantages of feature size reduction and reduced power consumption have reduced core
voltages down to the 1.0V range. This change in voltage and signal frequency content
requires the use of advanced design practices to manage electrical effects. The documents
and links on the Xilinx Signal Integrity website provides everything needed to achieve
reliable PCB designs the first time:

. If

REF

from VTT as the VTT supply can be very noisy.

REF

, Spartan-6 FPGA SelectIO Resources User Guide for more

http://www.xilinx.com/products/technology/signal-integrity/index.htm

Simultaneously Switching Outputs

Ground or power bounce occurs when a large number of outputs simultaneously switch in
the same direction. Each FPGA family provides guidelines for the recommended
maximum allowable number of simultaneously switching outputs (SSOs). For more
information on SSO, see the Simultaneously Switching Outputs section of UG381

Spartan-6 FPGA SelectIO Resources User Guide and DS162
and Switching Characteristics.

, Spartan-6 FPGA Data Sheet: DC

,

Power Distribution System Design and Decoupling/Bypass Capacitors

Good power distribution system (PDS) design is important for all FPGA designs,
especially for high-performance applications greater than 100 MHz. Proper design results
in better overall performance, lower clock jitter, and a generally more robust system.
Before designing the printed circuit board (PCB) for the FPGA design, review UG393
Spartan-6 FPGA PCB Design Guide.

,

28 www.xilinx.com Spartan-6 FPGA Power Management

UG394 (v1.1) September 4, 2012

Chapter 3

Lower-Power Spartan-6 LX Devices

Introduction

The lower-power Spartan-6 LX devices (-1L) meet lower quiescent and dynamic current
levels than the standard Spartan-6 LX devices. They also operate at a reduced V

1.0V, versus the 1.2V of the standard Spartan-6 family, thus reducing core power. The
lower-power Spartan-6 LX devices are supported by the -1L speed grade. Although the -1L
devices are slower than the standard Spartan-6 LX family's slowest speed grade (-2), an
additional 30–40% power savings is attained.

Use L1 as the speed grade when ordering the lower-power Spartan-6 LX devices, which is
also the way the speed grade is marked on the device. For example, the FPGA ordered as
the XC6SLX16-L1CSG324 is marked as either L1C for commercial temperature range or L1I
for industrial temperature range.

CCINT

of

Designing Using the Lower-Power Spartan-6 LX Devices

To design for the lower-power Spartan-6 LX devices, select the appropriate device during
implementation. A design targeted to the lower-power Spartan-6 LX devices can be
defined using all the same methods and options as available to the standard Spartan-6 LX
devices. All primitives that support the Spartan-6 LX family also support the lower-power
Spartan-6 LX devices. The lower-power Spartan-6 LX devices can be selected using the ISE
Design Suite in the Project Navigator. Different from the ordering code or actual device
marking, the Xilinx tools display the part number with an appended L (for example,
XC6SLX16L). The only speed grade supported for these devices is the -1L. The same speed
grade supports both the commercial and industrial temperature ranges.

The resulting bitstream is identical in format between the standard Spartan-6 LX devices
and the lower-power Spartan-6 LX devices. The JTAG device IDCODEs are identical and
the iMPACT software identifies the device under the same standard Spartan-6 FPGA part
number. However, there are small implementation differences between the two families,
including a reset circuit used for the DCM CLKFX output (see the RST Input Logic section
of UG382
configuration. Therefore, the designer must target the correct device both to generate the
correct timing information, and to account for implementation differences between the
two families. The standard and lower-power Spartan-6 LX device bitstreams can not be
used in both families. A standard Spartan-6 LX device should not be powered at 1.0V, and
a lower-power Spartan-6 LX device should not be powered at 1.2V.

, Spartan-6 FPGA Clocking Resources User Guide), and differences in block RAM

Spartan-6 FPGA Power Management www.xilinx.com 29

UG394 (v1.1) September 4, 2012

Chapter 3: Lower-Power Spartan-6 LX Devices

Tab le 3- 1 summarizes the designations for a member of the lower-power Spartan-6 LX

devices.

Table 3-1: Lower-Power Spartan-6 LX Device Designation Examples

Designation Example

Ordering Code XC6SLX16-L1CSG324C

Mark

XC6SLX16

CSG324

DxxxxxxxA (lot code)

L1C

Software Family

Software Device XC6SLX16L-1LCSG324

Speed Specification -1L

In software choose:

Spartan6 Lower Power

Lower-Power Spartan-6 LX Device Specifications

Several specifications are different for the lower-power Spartan-6 LX devices than in the
standard Spartan-6 LX family. All of the differences are listed in DS162
Data Sheet: DC and Switching Characteristics.

The lower-power Spartan-6 LX devices require a V
is not tested or guaranteed at 1.2V, and therefore the V
between 1.2V and 1.0V. In the same way, a standard Spartan-6 LX device cannot be
operated at 1.0V.

The lower-power Spartan-6 LX devices have lower-power specifications, as seen in the
data sheet for quiescent current, and in the Power Estimators for both quiescent and
dynamic current and power. See Chapter 5, Power Estimation.

Because of the reduction in maximum V
shorter. See the V

CCINTR

ramp time specification in DS162, Spartan-6 FPGA Data Sheet: DC

, the maximum time for ramping up is

CCINT

and Switching Characteristics.

Because the I/O thresholds for LVCMOS12, LVCMOS15, and LVCMOS18 are based on the
V

level, they are slightly lower for the lower-power Spartan-6 LX devices than the

CCINT

standard Spartan-6 family. See the SelectIO Interface DC Input and Output Levels table in

DS162

, Spartan-6 FPGA Data Sheet: DC and Switching Characteristics.

of 1.0V ±5%, or 0.95V to 1.05V. It

CCINT

CCINT

, Spartan-6 FPGA

cannot be scaled up and down

The lower-power Spartan-6 LX devices require V
LVDS_33, BLVDS_25, LVPECL_25, RSDS_25, RSDS_33, PPDS_25, and PPDS_33
I/O standards on inputs. LVPECL_33 is not supported in these devices.

Lower-power Spartan-6 LX devices only support tap 0 of the IODELAY2.

30 www.xilinx.com Spartan-6 FPGA Power Management

CCAUX

= 2.5V when using the LVDS_25,

UG394 (v1.1) September 4, 2012

Chapter 4

Power-On and Power-Down Behavior
Including Hibernate

Introduction

Spartan-6 FPGAs are designed for maximum system flexibility and reliability when
powering up and powering down. During power-on, the device ensures reliable
configuration by waiting until a fixed time after the supply rails are valid. During
power-down or hibernate, the device disables the outputs and awaits re-application of
power to reconfigure. Both power-up and power-down are enhanced by the hot swap
compliance of the I/O, allowing the FPGA to be moved in or out of a powered system
without damage.

Power-On Reset

Spartan-6 FPGAs have a built-in power-on reset (POR) circuit that monitors the three
power rails required to successfully configure the FPGA (see Figure 4-1). At power-up, the
POR circuit holds the FPGA in a reset state until the V
reach their respective input threshold levels. A time t
respective thresholds, the POR reset is released and the FPGA begins its configuration
process.

X-Ref Target - Figure 4-1

V

CCINT

V

CCAUX

V

CCO_2

PROGRAM_B

Power-On

Reset

Glitch

Filter

Glitch

Filter

, V

CCINT

after all three supplies reach their

POR

CCAUX

, and V

CCO_2

Spartan-6 FPGA

Reset

Configuration

Logic

UG394_c4_01_022210

supplies

Spartan-6 FPGA Power Management www.xilinx.com 31

UG394 (v1.1) September 4, 2012

Figure 4-1: Simplified POR Circuit Diagram

Chapter 4: Power-On and Power-Down Behavior Including Hibernate

The V

CCO_2

are in bank 2. V
V

CCO_2

after configuration for a lower-voltage I/O standard such as LVCMOS15 or LVCMOS12.

For information on the power-on reset step as part of the configuration process, see Device
Power-Up in UG380

Supply Sequencing

The Spartan-6 FPGA can be powered up and powered down in any sequence. Because the
three FPGA supply inputs must be valid to release the POR and can be supplied in any
order, there is no FPGA-specific voltage sequencing requirement. Although the FPGA has
no specific voltage sequence requirements, any potential sequencing requirement of the
configuration device attached to the FPGA, such as an SPI serial Flash PROM, a parallel
NOR Flash PROM, or a microcontroller should be considered. For example, Flash PROMs
have a minimum time requirement before the PROM can be selected, and this time must be
considered if the 3.3V supply is the last in the sequence. See Power-On Sequence Precautions
in UG380

Ramp Rate

The power supplies should ramp monotonically within the power supply ramp time range
specified in DS162
successful power-on, V
respective threshold-voltage ranges with no dips. The maximum ramp time for V
the lower-power Spartan-6 LX devices is slightly lower than for the standard family
because of the reduced voltage.

supplies are part of the POR circuit, because the primary configuration pins

is typically at 2.5V or 3.3V for the configuration interface. Make sure

CCO_2

reaches the proper level for POR and for configuration, especially if it is reduced

, Spartan-6 FPGA Configuration User Guide.

, Spartan-6 FPGA Configuration User Guide.

, Spartan-6 FPGA Data Sheet: DC and Switching Characteristics. To ensure

CCINT

, V

bank 2, and V

CCO

supplies must rise through their

CCAUX

CCINT

in

Hot Swap

Hot swap, also known as hot plug or hot insertion, refers to plugging an unpowered board
into a powered system. To support hot swap, an unpowered board or device must be able
to be plugged directly into a powered system or backplane without affecting or damaging
the system or the board/device. Spartan-6 FPGAs are fully hot swap compliant and
include the following I/O features:

• Signals can be applied to I/O pins before powering the device

• I/O pins are high-impedance (that is, three-stated) before and throughout the
power-up and configuration processes

• There is no current path from the I/O pin back to the voltage supplies

Power rails can be disabled in any order without damage to the FPGA. It is recommended
that all I/O pins be ignored after any of the power rails (V

CCINT

, V

CCO

, or V

CCAUX

) drops
below its minimum operating voltage. To transition cleanly from valid signals to the
disabled state, either first disable the outputs in the design, or shut down V
by V

CCAUX

and then V

CCINT

.

followed

CCO

32 www.xilinx.com Spartan-6 FPGA Power Management

UG394 (v1.1) September 4, 2012

Configuration Data Retention and Brown Out

Configuration Data Retention and Brown Out

The FPGA's configuration data is stored in robust CMOS configuration latches. The data in
these latches is retained even when the voltages drop to the minimum levels necessary to
preserve RAM contents, as specified in DS162
Switching Characteristics (V

After configuration, if the V

DRINT

CCAUX

and V

or V
retention voltage, the integrity of the CMOS configuration latches is no longer guaranteed,
and the current device configuration must be cleared using one of the following methods:

, Spartan-6 FPGA Data Sheet: DC and
).

DRAUX

supply drops below its minimum data

CCINT

•Force the V

CCAUX

or V

supply voltage to GND, then raise the voltages back to

CCINT

the recommended operating range (as shown in DS162
DC and Switching Characteristics)

• Assert PROGRAM_B Low, then raise it back High

The POR circuit does not monitor the V
dropping the V

voltage does not reset the device by triggering a POR event. The

CCO_2

supply after configuration. Consequently,

CCO_2

PROGRAM_B input bypasses the POR circuit (see Figure 4-1, page 31) and therefore can
be used as an independent means to initialize the FPGA.

After the INIT_B signal goes High to indicate successful clearing of the FPGA, reconfigure
the FPGA.

GTP Transceiver Power-Up and Power-Down

All GTP_DUAL tiles are reset automatically after configuration. The supplies for the
calibration resistor and calibration resistor reference must be powered up before
configuration to ensure correct calibration of the termination impedance of all transceivers.

The reference clock and the power to the GTP_DUAL tile must be available before
configuring the FPGA. If the reference clock or GTP_DUAL tile is powered up after
configuration, apply GTPRESET to allow the PMA PLL to lock.

The GTP transceiver supports a range of power-down modes. These modes support both
generic power management capabilities as well as those defined in the PCI Express and
SATA standards.

, Spartan-6 FPGA Data Sheet:

Each channel in each direction can be powered down separately using TXPOWERDOWN
and RXPOWERDOWN. Each PLLPOWERDOWN port directly affects the associated PLL
that is selected by the PLL_SOURCE attribute.

For more details on the GTP Transceivers, see UG386
User Guide, Managing Used and Unused GTP Transceivers, Board Design Guidelines.

Hibernate Power Down

Hibernate is effectively powering down the FPGA (Figure 4-2). Due to the hot swap
compliance of the Spartan-6 family, this is allowed even if external devices are still
providing active signals to the FPGA. The FPGA loses its configuration data and must be
re-programmed after power-on. Hibernate provides the maximum possible power savings
for applications that can be turned off for long periods of time and that can afford to lose
the present design state.

Spartan-6 FPGA Power Management www.xilinx.com 33

UG394 (v1.1) September 4, 2012

, Spartan-6 FPGA GTP Transceivers

Chapter 4: Power-On and Power-Down Behavior Including Hibernate

V

CCAUX

PROGRAM_B

Active Device
Connected on

Board

UG394_c4_02_111109

Power

Switch

2.5V/3.3V 1.2V/1.0V

V

CCINT

V

CCO

V

CCO

Supply

Spartan-6

FPGA

X-Ref Target - Figure 4-2

Figure 4-2: Spartan-6 FPGA Power-Off Diagram

Forcing FPGA to Quiescent Current Levels

Before removing the power supplies, it is recommended to first put the device into the
quiescent state. Pulse PROGRAM_B Low to achieve the quiescent current levels. Driving
PROGRAM_B Low forces all I/Os into a high-impedance state, ceases all internal
switching, and converts the bitstream held in internal memory to all zeros. During and
after the Low pulse on PROGRAM_B, disable the internal pull-up resistors on all I/Os by
driving the HSWAPEN input High. Holding PROGRAM_B Low continues clearing the
configuration memory. To minimize quiescent current, release PROGRAM_B High but
hold off configuration by holding INIT_B Low, or by setting the Mode pins to a slave or
JTAG configuration mode and disabling the external configuration clock (CCLK or TCK).

To restart the application, release PROGRAM_B High and in slave or JTAG modes, enable
the external configuration source. The FPGA must reconfigure before the application
restarts. No state information is preserved. If the application must retain the FPGA
configuration bitstream, then use the suspend mode.

Entering Hibernate State

Hibernate starts with the approach described in Forcing FPGA to Quiescent Current

Levels, page 34. Hibernate provides further power savings by switching off power rails.

This state reduces quiescent power consumption to the lowest possible level. The FPGA
enters Hibernate by switching off the V
(output) power supplies. Power FETs with low on resistance are recommended to perform
the switching action. Configuration data is lost upon entering Hibernate; therefore, the
device reconfigures after exiting the state.

CCINT

(core), V

(auxiliary), and V

CCAUX

CCO

Holding the PROGRAM_B input Low during the transition into Hibernate keeps all FPGA
output drivers in a high-impedance state. Release PROGRAM_B after re-applying power.
See Design Considerations, page 36 for recommended levels on Dedicated and
Dual-Purpose pins.

34 www.xilinx.com Spartan-6 FPGA Power Management

UG394 (v1.1) September 4, 2012

Hibernate Power Down

PROGRAM_B

I/Os

V

CCINT

V

CCAUX

V

CCO

(per I/O Bank)

INIT_B

DONE

CCLK

Undefined

in Master Mode

UG394_c4_03_111309

Hibernate

Undefined

STARTUP cycles

Turn Off V

CCO

Spartan-6 FPGA I/O pins have a floating-well structure, providing full hot-swap/
hot-insertion capability. When a Spartan-6 FPGA is in the Hibernate state, the V
can be safely turned off without adversely affecting either the FPGA or the external
application. When entering the Hibernate state, V

should be turned off first to disable

CCO

the outputs without any unwanted transitions.

Figure 4-3 shows the waveforms for entering and exiting Hibernate. The steps for entering

Hibernate are as follows:

1. Pull the PROGRAM_B pin Low to force all user-I/O pins into a high-impedance state.

2. The FPGA drives the INIT_B and DONE pins Low.

3. External switches turn off the V

CCINT

, V

CCAUX

, and V

supply rails to the FPGA.

CCO

4. The FPGA is now in Hibernate. While the FPGA is kept in this state, power

consumption rests at the lowest possible level.

X-Ref Target - Figure 4-3

CCO

supply

Spartan-6 FPGA Power Management www.xilinx.com 35

UG394 (v1.1) September 4, 2012

Figure 4-3: Hibernate Waveform

Chapter 4: Power-On and Power-Down Behavior Including Hibernate

Exiting Hibernate

The steps for exiting Hibernate are as follows.

1. Reapply power to all rails that were switched off. Apply power in any sequence.

2. Before FPGA initialization can begin, deassert PROGRAM_B to a High logic level. The

rising transition on PROGRAM_B must occur after turning all three power supplies
back on.

3. After logic initialization, the FPGA releases the open-drain INIT_B signal. With

INIT_B High, the FPGA starts its configuration process.

4. When configuration is complete, the FPGA enters the Start-up phase, asserts DONE,

and enables the I/Os, according to how the BitGen options are set.

5. The FPGA is now ready for user operation.

Design Considerations

Be aware of how various pins are powered in the application. Most user-I/O pins,
including the dual-purpose configuration pins and the dedicated PROGRAM_B and
DONE pins, are powered by a specific V
such as SUSPEND and the JTAG pins are powered by the V
power to any of these supplies, consider how that affects FPGA configuration when power
is re-applied.

supply input. Dedicated configuration pins

CCO

CCAUX

supply. If disconnecting

For specific information on configuration pins and their associated power rails, refer to

UG380

, Spartan-6 FPGA Configuration User Guide.

36 www.xilinx.com Spartan-6 FPGA Power Management

UG394 (v1.1) September 4, 2012

Power Estimation

Introduction

Xilinx provides a complete power estimation solution using power estimators and
analyzers, power-driven implementation tool algorithms, and a variety of power-related
documentation. The Power Advantage page provides access to these tools,
documentation, and news:

h

ttp://www.xilinx.com/products/technology/power/index.htm

To estimate the total power consumption (quiescent plus dynamic) for a specific design use
one of the following tools:

• The XPower Power Estimator spreadsheet provides quick, approximate estimates,

and does not require the design’s netlist.

• The XPower Analyzer is delivered with the ISE Design Suite software and uses a

netlist as input to provide more accurate estimates.

Chapter 5

The XPower Power Estimator (XPE) spreadsheet is a power estimation tool typically used
in the pre-design and pre-implementation phases of a project. XPE assists with architecture
evaluation and device selection, and helps in selecting the appropriate power supply and
thermal management components. For comparison and analysis, the XPE spreadsheet for
the Spartan-6 family also includes the Extended Spartan-3A family.

XPE considers the resource usage, toggle rates, I/O loading, and many other design
factors. Combined with device models, the estimated power distribution can be calculated
in XPE. The device models are extracted from measurements, simulation, and/or
extrapolation.

After implementation, the XPower Analyzer (XPA) tool (available in the ISE Design Suite
software) is used for more accurate estimates and power analysis. For more information
about XPA, see the XPower Analyzer Help.

Voltage Regulators

The choice of a voltage regulator depends on system requirements and the estimated
power consumption requirements for the FPGA. Use the XPower tools to calculate the
requirements for a specific device and design. Then choose a regulator from a
pin-compatible family so the current capability can be adjusted up or down. External
power FETs are easy to upgrade. A soft-start feature that controls output ramp time is
useful.

With care, use of overcurrent protection is possible, such as foldback or fuses. Be aware
that capacitors are charging at power-on and might draw a significant amount of current
for a short time.

Spartan-6 FPGA Power Management www.xilinx.com 37

UG394 (v1.1) September 4, 2012

Chapter 5: Power Estimation

If necessary, slow the supply voltage ramp to control the charge current. If foldback is not
a design requirement, it is best to avoid it, keeping the power-supply design simple.

Various power-supply manufacturers offer complete power solutions for Xilinx FPGAs
including some with integrated three-rail regulators specifically designed for Xilinx
FPGAs.

Saving Power

Lower-power consumption not only reduces power supply requirements but also reduces
heat, which increases reliability, allows for smaller form factor packaging, and helps
eliminate heat sinks and fans. Spartan-6 FPGAs are designed to minimize power
consumption without sacrificing high performance and low cost.

The lowest power state is the quiescent state with no inputs toggling, all outputs disabled,
and no pull-up or pull-down resistors in use. This static power state is often dominated by
transistor leakage current, which can increase at smaller process geometries. Xilinx has
made major advances in the design of the 45 nm Spartan-6 devices. Comparing Spartan-6
FPGAs to Spartan-3A FPGAs, the average static power in Spartan-6 devices is lower.
Quiescent current levels are specified in DS162
Switching Characteristics. The lower-power Spartan-6 LX devices offer the lowest quiescent
current.

Dynamic (active) power is a function of capacitance, voltage, and frequency (CV
general, capacitance decreases as transistors shrink. But smaller transistors allow users to
take advantage of more of them per device, while using faster switching rates, which can
lead to increases in dynamic power. Dynamic power consumption can be reduced by
reducing the number or frequency of nodes and I/O toggling in a design. Consider the
following techniques to eliminate any unnecessary switching in a design and reduce
dynamic power:

, Spartan-6 FPGA Data Sheet: DC and

2

f). In

• Bring all incoming signals to a static state

• Apply rail-to-rail levels to inputs wherever possible

• Turn off as many outputs as possible

• Assign signal standards with small swings to outputs

• Use lower output drive and slower slew rates

• Tie all unused inputs to V

or GND outside the device

CCO

• Avoid instantiating pull-up and pull-down resistors on I/Os

• Reduce the total length of heavy loaded signals to reduce capacitance

• Disable as many internal oscillating circuits as possible

• Have block RAMs operate in NOCHANGE mode to reduce toggling of the outputs of

the block RAM

38 www.xilinx.com Spartan-6 FPGA Power Management

UG394 (v1.1) September 4, 2012

Saving Clock Routing Power

Clocks are a significant aspect of power consumption because of their high fanout nets and
also because controlling them limits the number of logic primitives toggling in a design. If
possible, stop the clock where it enters the FPGA, so that it does not consume any FPGA
power. If the clock can not be gated externally, then disable it inside the FPGA using the
BUFGCE primitive. Avoid using logic to gate clocks, since CLB logic introduces
route-dependent skew and makes the design sensitive to the timing hazards of lot-to-lot
variations. Minimizing the amount of routing a clock net uses is helpful, since the Xilinx
software automatically disables clock nets where possible for unused areas of CLBs.

If possible, minimize the number of DCMs or PLLs required in the design. A single PLL
can be shared with both halves of a GTP_DUAL transceiver. A DCM_CLKGEN can be
used to dynamically scale clock frequency as needed for the application, helping to
minimize power.

ISE Design Suite Power Optimization

Power can also be reduced automatically in the Xilinx design tools. With goal-based
implementation, the ISE Design Suite offers a simple, one-step process to specify power
optimization. Design Goals and Strategies control the implementation tools by using
preset process properties designed to achieve a particular design goal. Power optimization
attempts to meet timing constraints as well as reduce power consumption.

ISE Design Suite Power Optimization

For guidelines on design techniques to reduce power consumption, see the Power
Advantage page at:

h

ttp://www.xilinx.com/products/technology/power/index.htm

Spartan-6 FPGA Power Management www.xilinx.com 39

UG394 (v1.1) September 4, 2012
