This appliance may be installed in an aftermarket permanently located, manufactured home (USA only) or mobile home, where not prohibited by local codes. This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not convertible for use with other gases, unless a certified kit is used.

In the Commonwealth of Massachusetts:

•Installation must be performed by a licensed plumber or gas fitter;

•See Table of Contents for location of additional Commonwealth of Massachusetts requirements.

WARNING:IFTHEINFORMATIONINTHISMANUAL IS NOT FOLLOWED EXACTLY, A FIRE OR EXPLOSIONMAYRESULTCAUSINGPROPERTYDAMAGE, PERSONAL INJURY OR LOSS OF LIFE.

FOR YOUR SAFETY: Do not store or use gasoline or other flammables or liquids in the vicinity of this or any other appliance.

FOR YOUR SAFETY: What to do if you smell gas:

•DO NOT light any appliance.

•DO NOT touch any electrical switches.

•Do not use any phone in your building.

•Immediately call your gas supplier from a neighbor’s phone. Follow your gas suppliers instructions.

•If your gas supplier cannot be reached, call the fire department.

Installation and service must be performed by a qualified installer, service agency or the gas supplier.

OTL Report No. 116-F-29-5

A French manual is available upon request. Order P/N 700,043CF

Ce manuel d’installation est disponible en francais, simplement en faire la demande. Numéro de la pièce 700,043CF.

INSTALLATION

INSTRUCTIONS

DIRECT VENT

SSDV-3328 SERIES

DIRECT VENT GAS FIREPLACE HEATERS

P/N 700,043M REV. a 06/2008

MODELS

Millivolt Models	Electronic Models
SSDVT-3328CNM	SSDVT-3328CNE
SSDVR-3328CNM	SSDVR-3328CNE

INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference.

AVERTISSEMENT: ASSUREZ-VOUS DE BIEN SUIVRE LES INSTRUCTIONS DONNÉ DANS CETTE NOTICE POUR RÉDUIRE AU MINIMUM LE RISQUE D'INCENDIE OU POUR ÉVITER TOUT DOMMAGE MATÉRIEL, TOUTE BLESSURE OU LA MORT.

POUR VOTRE SÉCURITÉ: Ne pas entreposer ni utiliser d'essence ni d'autre vapeurs ou liquides inflammables dans le voisinage de cet appareil ou

de tout autre appareil.

POUR VOTRE SÉCURITÉ: Que faire si vous sentez une odeur de gaz:

•Ne pas tenter d'allumer d'appareil.

•Ne touchez à aucun interrupteur. Ne pas vous servir des téléphones se trouvant dans le batiment où vous vous trouvez.

•Evacuez la piéce, le bâtiment ou la zone.

•Appelez immédiatement votre fournisseur de gaz depuis un voisin. Suivez les instructions du fournisseur.

•Si vous ne pouvez rejoindre le fournisseur de gaz, appelez le service dos incendies.

L'installation et service doit être exécuté par un qualifié installeur, agence de service ou le fournisseur de gaz.

TABLE OF CONTENTS
Packaging..........................................	Page	2
Introduction.......................................	Page	2
General Information...........................	Page	2
Requirements for the
Commonwealth of Massachusetts..Page		4
New York City Approval.....................	Page	4
Cold Climate Insulation......................	Page	5
Location.............................................	Page	5
Manufactured Home Requirements...	Page	6
Vent Termination Clearances ............	Page	7
Minimum Clearances to Combustibles..	Page	9
Detailed Installation Steps.................	Page	10
Typical Installation Sequence ............	Page	10
Step 1. Framing.................................	Page 10
Step 2. Routing Gas Line...................	Page	10
Fireplace Specifications.....................	Page	11
Step 3. Install the Venting System.....	Page	13
Vertical Termination Systems............	Page	14
Vent Section Length Chart.................	Page	14
Vertical Vent Tables and Figures........	Page	17
Horizontal Termination System..........	Page	19
Horizontal Vent Tables and Figures....	Page	21
Venting Using Flexible Vent Pipe.......	Page	24
Step 4. Field Wiring...........................	Page	25
Step 5. Optional Blower Kit Wiring....	Page	25
Step 6. Connecting Gas Line..............	Page	26
Step 7. Checking Unit Operation........	Page	27
Step 8. Installing Logs ......................	Page	28
Step 9. Installing Glass Door ............	Page	30
Step 10. Burner Adjustments.............	Page	31
Step 11. Hood Installation.................	Page	31
Finishing Requirements.....................	Page	31
Installation Accessories.....................	Page	32
Gas Conversion Kits..........................	Page	34

This installation manual will help you obtain a safe, efficient, dependable installation for your appliance and vent system.

Please read and understand these instructions before beginning your installation.

The Millivolt appliances have a millivolt gas control valve with piezo ignition system

which provides safe, efficient operation. If any optional accessories that will require electrical power are to be installed, the electrical power must be provided at the time of appliance installation.

The Electronic appliances have an electronic intermittent pilot ignition system which provides safe, efficient operation. External electrical power is required to operate these appliances.

PACKAGING

The assembled vented gas fireplace heater is packaged with:

1 - One log set located in firebox area.

2- One envelope containing the literature package which consists of the homeowner's manual, installation instructions, and warranty; envelope is located in the control compartment.

3- One vent restrictor to be applied as shown on Page 13; restrictor is taped to the envelope.

4- One hood located behind the top panel.

5- One bag of decorative volcanic stone located in the control compartment.

6- One bag of glowing embers located in the control compartment.

Introduction

These vented gas fireplace heaters are sealed combustion, air circulating gas fireplaces designed for residential applications.

Approved Vent Components - These fireplaces are designed, tested and listed for operation and installation with, the following vent components only:

•Secure Vent™ Direct Vent System Components,

•Secure Flex™ Flexible Vent Components manufactured by Security Chimneys International and

•Z-FLEX™ Model GA Venting Systems listed to UL1777 and ULCS635 manufactured by

Flexmaster Canada Limited.

These approved vent system components are labeled for identification. DO NOT use any other manufacturer’s vent components with these appliances. Use only the correct size venting (4-1/2" inner & 7-1/2" outer).

These appliances comply with National Safety Standards and are tested and listed by OMNITest Laboratories, Inc. (Report No. 116-F-29-5) to ANSI Z21.88 (in Canada, CSA-2.33), and CAN/CGA-2.17-M91 in both USA and Canada, as vented gas fireplace heaters.

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.

Both millivolt and electronic versions of these appliances are listed by OMNI-Test Laboratories for installation in bedrooms and Manufactured Homes.

Manufactured Homes -

See Manufactured Home Requirements on

Page 6 for additional information.

WARNING

Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Refer to this manual. For assistance or additional information consult a qualified installer, service

agency or the gas supplier.

This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not convertible for use with other gases, unless a certified kit is used.

Cet appareil doit être utilisé uniquement avec les types de gaz indiqués sur la plaque signalétique. Ne pas l'utiliser avec d'autres gaz sauf si un kit de conversion certifié est installé.

Misc. Codes / Standards -

Installation must conform to local codes. In the absence of local codes, installation must comply with the current National Fuel Gas Code, ANSI Z223.1. (In Canada, the current CAN-1 B149 installation code).

The appliance, when installed, must be electrically grounded & wired in accordance with local codes or, in the absence of local codes, with the National Electrical Code, ANSI / NFPA 70-latest edition, or the Canadian Electrical Code, CSA C22.1 - latest edition.

General Information

Note: Installation and repair should be performed by a qualified service person. The appliance should be inspected annually by a qualified professional service technician. More frequent inspections and cleanings may be required due to excessive from carpeting, bedding material, etc.

S'assurer que le brùleur et le compartiment des commandes sont propres. Voir les instructions d'installation et d'utilisation qui accompagnent l'appareil.

Provide adequate clearances around air openings and adequate accessibility clearance for service and proper operation. Never obstruct the front openings of the appliance.

These appliances are designed to operate on natural or propane gas only. To operate on Propane Gas a field converion is necessary (see Pages 34 to 36). Do not use any other fuels. The use of other fuels, or combination of fuels, will degrade the performance of this system and may be dangerous.

These fireplaces are designed as supplemental heaters. Therefore, it is advisable to have an alternate heat source when installed in a dwelling.

Millivolt Models - The millivolt appliances are manually controlled and feature a spark igniter (piezo) that allows the appliance's pilot gas to be lit without the use of matches or batteries. This system provides continued service in the event of a power outage.

Millivolt models come standard with a manu- ally-modulated gas valve; flame appearance and heat output can be controlled at the gas valve. The BTU Input for these appliances is shown in Table 1.

Input (BTU) Manually-Modulated Gas

Valves (millivolt models)

NATURAL & PROPANE GAS

	Models	Input Rate (BTU / HR)

	SSDVT/R-3328	17,500 high
	SSDVT/R-3328	13,500 low
		13,500 low

Table 1

Electronic Models

Electronic models have a fixed rate gas valve. Input of electronic models is shown in Table 2.

Electronic Models with Fixed Rate Gas Valve

Natural and Propane Gas

Model Series	Input Rate (BTU / HR)

SSDVT/R-3328	17,500

Table 2

Gas Pressure - All Models

Tables 3, 4 and 5 show the appliances' gas pressure requirements:

Inlet Gas Supply Pressure

(all models)

Fuel #		Minimum	Maximum

Natural Gas		5.0" WC	10.5" WC
Natural Gas		(1.24 kPa)	(2.61 kPa)
		(1.24 kPa)	(2.61 kPa)

Propane		11.0" WC	13.0" WC
Propane		(2.74 kPa)	(3.23 kPa)
		(2.74 kPa)	(3.23 kPa)
Table 3

Manifold Gas Supply Pressure
	(millivolt models)

Fuel #		Low	High

Natural	(Lo) 2.2" WC		(Hi) 3.5" WC
Gas		(.55 kPa)	(.87 kPa)

Propane	(Lo) 6.3" WC		(Hi) 10.0" WC
Propane		(1.57 kPa)	(2.49 kPa)
		(1.57 kPa)	(2.49 kPa)

Table 4

Manifold Gas Supply Pressure

(electronic models)

Fuel #	Manifold Pressure

Natural Gas	3.5" WC (.87 kPa)

Propane	10.0" WC (2.49 kPa)

Table 5

Test gauge connections are provided on the front of the millivolt gas control valve, identified IN for the inlet and OUT for the manifold side. A 1/8" NPT Test gauge connection is provided at the inlet and outlet side of the electronic gas control valve.

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.

These appliances must be isolated from the gas supply piping system (by closing their individual manual shut-off valve) during any pressure testing of the gas supply piping system at test pressures equal to or less than 1/2 psig (3.5 kPa).

These appliances and their individual shut-off valves must be disconnected from the gas supply piping system during any pressure testing of that system at pressures greater than 1/2 psig (3.5 kPa).

Orifice Sizes - Sea Level to High Altitude (All Models)

These appliances are tested and approved for installation at elevations of 0-4500 feet (0-1372 meters) above sea level using the standard burner orifice sizes (marked with an "*" in Table 6 ). For elevations above 4500 feet, contact your gas supplier or qualified service technician . Install the appliance according to the regulations of the local authorities having jurisdiction and, in the USA, the National Fuel Gas Code NFPA 54 / ANSI Z223.1 - latest edition or, in Canada, the CAN1-B149.1 and .2 codes - latest edition.

Burner Orifice Sizes Elevation 0-4500 feet ( 0-1372 meters)

Model	Natural	Propane
Model	Gas	Gas
Series	Gas	Gas
Series	drill size (inches)	drill size (inches)

SSDVT/R-3328	#45 *	(0.048") *

* Standard size installed at factory

Table 6

SIT Millivolt			Gas Valve
HI/LO Variable			Inlet Pressure Tap
Flame Height			Inlet Pressure Tap
Adjustment	Manifold Pressure Tap
	Manifold Pressure Tap
HTPT			OUT	IN
HTPT
PT		IH	OFF
			OFF	P
				P
				I
		LOW	it	L
HT		LOW	it	O
				T
			NO
P
I
TOL
Pilot Adjustment			Main Gas
Screw		Control Knob
		OFF/PILOT/ON
Figure 1

Honeywell Millivolt			Gas Valve
		PIEZO
PILOT		IGNITER	CONVERTIBLE
PILOT			CONVERTIBLE
ADJUSTMENT	GAS CONTROL		HI/LO REGULATOR
SCREW	GAS CONTROL		(adjusts flame height
SCREW	KNOB		(adjusts flame height
	KNOB		and heat output)
			and heat output)
TP/TH		O
		O
		NI
			L
		P	O
		P	H
TP	L	I
	FFO TO
TH
WIRING	INLET		OUTLET
TERM-	PRESSURE		PRESSURE
INALS	TAP		TAP
Figure 2

Honeywell Electronic Gas Valve

Manifold Pressure		ON / OFF Switch
Port			Inlet
			Inlet
C			Pressure
LORTNO	FFO NO	N	Port
		I
ERTINGI
		ISP

Electronic Gas

Control Valve

Figure 3

NEW YORK CITY, NY AND MASSACHUSETTS REQUIREMENTS

These appliances are approved for installation in the following USA locations listed in the following:

Massachusetts -

Installation of these fireplaces are approved for installation in the US state of Massachusetts if the following additional requirements are met -

•Installation and repair must be done by a plumber or gas fitter licensed in the Commonwealth of Massachusetts.

•The flexible gas line connector used shall not exceed 36 inches (92 centimeters) in length.

•The individual manual shut-off must be a T-handle type valve.

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.

Massachusetts Horizontal Vent Requirements

In the Commonwealth of Massachusetts, horizontal terminations installed less than seven (7) feet above the finished grade must comply with the following additional requirements:

•A hard wired carbon monoxide detector with an alarm and battery back-up must be installed on the floor level where the gas fireplace is installed. The carbon monoxide detector must comply with NFPA 720, be ANSI/UL 2034 listed and be IAS certified.

•A metal or plastic identification plate must be permanently mounted to the exterior of the building at a minimum height of eight (8) feet above grade and be directly in line with the horizontal termination. The sign must read, in print size no less than one-half (1/2) inch in size, “GAS VENT DIRECTLY BELOW. KEEP CLEAR OF ALL OBSTRUCTIONS.”

New York City, New York

These fireplaces are approved for installation in New York City in the US state of New York.

Cold Climate Insulation

For cold climate installations, seal all cracks around the appliance with noncombustible material and wherever cold air could enter the room. It is especially important to insulate outside chase cavity between studs and under floor on which the appliance rests, if floor is above ground level.

Gas line holes and other openings should be caulked or stuffed with unfaced fiberglass insulation. If the fireplace is being installed on a cement slab, in cold climates, a sheet of plywood or other raised platform can be placed underneath to prevent conducting cold up into the room. It also helps to sheetrock inside surfaces and tape for maximum air tightness and caulk firestops.

Location

In selecting the location, the aesthetic and functional use of the appliance are primary concerns. However, vent system routing to the exterior and access to the fuel supply are also important. Consideration should be given to traffic ways, furniture, draperies, etc., due to elevated surface temperatures (see Figure 4 ). The location should also be free of electrical, plumbing or other heating/air conditioning ducting.

These direct vent appliances are uniquely suited for installations requiring a utility shelf positioned directly above the fireplace. Utility shelves like these are commonly used for locating television sets and decorative plants. Be aware that this is a heat producing appliance. Objects placed above the unit are exposed to elevated temperatures.

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.

To provide for the lowest possible shelf surface use the alternate rear vent outlet with attached venting routed in a way to minimize obstructions to the use of the space above the appliance. Do not insulate the space between the appliance and the area above it. See Figure 9. The minimum height from the base of the appliance to the underside of combustible materials used to construct a utility shelf in this fashion is shown in the Table in Figure 9.

The appliance should be mounted on a fully supported base extending the full width and depth of the unit. The appliance may be located on or near conventional construction materials. However, if installed on combustible materials, such as carpeting, vinyl tile, etc., a metal or wood barrier covering the entire bottom surface must be used.








					HORIZONTAL VENT
	VERTICAL VENT				HORIZONTAL VENT
	VERTICAL VENT				(Rear Vent Application
	(Rear Vent				(Rear Vent Application
	(Rear Vent				without a chase)
	Application)				without a chase)
	Application)

REAR VENT APPLICATION

A E

P A

P R

APPLICATION

TOP VENT

APPLICATION

TOP VENT

APPLICATION

RECESSED

TOP VENT

INSTALLATION

TOP VENT

APPLICATION

HORIZONTAL VENT	VERTICAL VENT





		HORIZONTAL VENT
(Top Vent	(Top Vent	(Rear Vent Application
Application)	Application)	With a chase)

Figure 4 - Typical Locations

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.

MANUFACTURED HOME

REQUIREMENTS

This appliance may be installed in an aftermarket permanently located, manufactured home (USA only) or mobile home, where not prohibited by local codes.

Cet appareil peut être installé dans un maison préfabriquée (É.-U. seulement) ou mobile déjà installée à demeure si les réglements locaux le permettent.

Manufactured Home installations must be installed in accordance with these instructions and the following standards / codes:

•Manufactured Home Construction and Safety Standard Title 24 CFR, Part 3280, or the current Standard for Fire Safety Criteria for Manufactured Home Installations, Sites and Communities ANSI / NFPA 501A in the USA, and CAN / CSA Z240 MH Mobile Home Standard in Canada

•(when applicable) The American National Standard for Manufactured Homes (NCSBCS / ANSI A225.1 - latest edition).

CAUTIONS

Ensure that the cross members are not cut or weakened during installation. The structural integrity of the manufactured home floor, wall, and ceiling / roof must be maintained.

This appliance must be grounded to the chassis of the manufactured home in accordance with local codes or in the absence of local codes, with the National Electrical Code ANSI / NFPA 70 - latest edition or the Canadian ElectricalCodeCSAC22.1-latest edition.

Vent Termination Clearances

These instructions should be used as a guideline and do not supersede local codes in any way. Install vent according to local codes, these instructions, the current National Fuel Gas Code (ANSI-Z223.1) in the USA or the current standards of CAN/CGA-B149.1 and -B149.2 in Canada.

Terminate multiple vent terminations according to the installation codes listed above.

Terminate single vent caps relative to building components according to Figure 5.

Vertical Vent Termination Clearances

TERMINATION HEIGHTS FOR VENTS ABOVE FLAT OR SLOPED ROOFS

Horizontal Overhang

2 FT MIN.

Vent

Termination

Storm Collar

Flashing

Concentric

Vent Pipe

2 FT		Vertical
MIN.		Wall
		Wall

Lowest

Discharge

Opening

Roof Pitch is X/12

1 inch (25.4 mm) Minimum Clearance to Combustibles

*H = MINIMUM HEIGHT FROM ROOF TO LOWEST DISCHARGE OPENING OF VENT

The vent / air intake termination clearances above the high side of an angled roof is as shown in the following chart:

Termination Heights For Vents Above Flat Or Sloped Roofs Ref. NFPA 54 / ANSI Z223.1, 7.6

Roof Pitch	* Feet	*Meters

Flat to 6/12	1.0	0.3

6/12 to 7/12	1.25	0.38

7/12 to 8/12	1.5	0.46
8/12 to 9/12	2.0	0.61

9/12 to 10/12	2.5	0.76
10/12 to 11/12	3.25	0.99

11/12 to 12/12	4.0	1.22

12/12 to 14/12	5.0	1.52
14/12 to 16/12	6.0	1.83

16/12 to 18/12	7.0	2.13
18/12 to 20/12	7.5	2.29

20/12 to 21/12	8.0	2.44

Figure 5

Horizontal Vent Termination Clearances

The horizontal vent termination must have a minimum of 3" (76 mm) clearance to any overhead combustible projection of 2 1/2" (64 mm) or less. For projections exceeding 2 1/2" (64 mm), see Figure 6. All horizontal terminations may be located as close as 6" (152mm) to any combustible exterior sidewall. This distance may be decreased to 2" (51mm) if the SV4.5HT-2 or SF4.5HT-2 termination is used and the exterior sidewall is non-combustible only. For additional vent location restrictions refer to Figure 7 on Page 8.

Horizontal Vent Termination Clearances

			Combustible Projection			All horizontal terminations
		2-1/2 inches or less in length				may be located as close
		Combustible Projection				as 6” (152mm) to any
		Combustible Projection				(non-combustible and
greater than 2-1/2 inches in length						combustible) exterior
						sidewall. This distance
Ventilated						may be decreased to
	Soffit	Unventilated				2” (51mm) for non-
		Soffit				combustible exterior
						sidewalls only, if the
						sidewalls only, if the
				3"		SV4.5HT-2 or SF4.5HT-2
				3"		termination
					(76 mm)	is used.
						Termination Kit
18"		12"				Termination Kit
18"		12"
(457 mm)		(305 mm)

Termination Kit

Note - See Figure 33 on Page 20 for the exterior wall recess allowances of the square horizontal termination.

Figure 6

Side Elevation View

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.

Exterior HORIZONTAL Vent TERMINATION Clearance Requirements

V L

NOTE: Local Codes Or Regulations

* See Item D in the Text Below.

May Require Different Clearances.

NOTE: Location Of The Vent Termination

Exterior Wall

Center Line

Inside

of Termination

Corner Detail

Must Not Interfere With Access To The

*18

Electrical Service.

Horizontal

Termination

Ventilated Soffit

Inside Corner

= 9

in U.S.

Detail D

= 12 in Canada

3 ft.

Fixed

Operable

Closed

Window

3 ft.

Window

X = Air Supply Inlet

V = Vent Termination

= Area where Termination is not Permitted

	Canadian Installation*	US Installation**

A = Clearance above grade, veranda, porch, deck, or balcony.	12 inches (30cm)*	12 inches (30cm)**

B = Clearance to window or door that may be opened.	6 inches (15cm) for appliances	6 inches (15cm) for appliances
	< 10,000 Btuh (3kW), 12 inches (30cm)	< 10,000 Btuh (3kW), 9 inches (23cm)
	for appliances > 10,000 Btuh (3kW)	for appliances > 10,000 Btuh (3kW) and
		< 50,000 Btuh (15kW), 12 inches (30cm)
		for appliances > 50,000 Btuh (15kW)**

C = Clearance to permanently closed window	12 inches (305mm) recommended to	9 inches (229mm) recommended to
	prevent window condensation	prevent window condensation
D = Vertical clearance to ventilated soffit located above the	18 inches (458mm)	18 inches (458mm)
termination within a horizontal distance of 18 inches (458mm)
from the center line of the termination
E = Clearance to unventilated soffit***	12 inches (305mm)	12 inches (305mm)

F = Clearance to outside corner	5 inches (12.7cm) minimum	5 inches (12.7cm) minimum

G = Clearance to inside corner	6 inches (15.2cm) minimum	6 inches (15.2cm) minimum

H = Clearance to each inside of center line extended above	3 feet (91cm) within a height of 15 feet	3 feet (91cm) within a height of 15 feet
meter/regulator assembly	above the meter/regulator assembly*	above the meter/regulator assembly**
I = Clearance to service regulator vent outlet	3 feet (91cm)*	3 feet (91cm)**

J = Clearance to nonmechanical air supply inlet to building or	6 inches (15cm) for appliances	6 inches (15cm) for appliances
the combustion air inlet to any other appliance	< 10,000 Btuh (3kW), 12 inches (30cm)	< 10,000 Btuh (3kW), 9 inches (23cm)
	for appliances > 10,000 Btuh (3kW)	for appliances > 10,000 Btuh (3kW) and
		< 50,000 Btuh (15kW), 12 inches (30cm)
		for appliances > 50,000 Btuh (15kW)**

K = Clearance to a mechanical air supply inlet	6 feet (1.83m)*	3 feet (91cm) above if within 10 feet
		(3m) horizontally**
L = Clearance above paved sidewalk or paved diveway located	7 feet (2.13m)‡	7 feet (2.13m)‡
on public property
M = Clearance under veranda, porch, deck or balcony	12 inches (30cm)*‡	12 inches (30cm)‡
N = Depth of Alcove (Maximum)	6 feet (1.83m)*	6 feet (1.83m)**
O = Clearance to Termination (Alcove)	6 inches (15.2mm)*	6 inches (15.2mm)**

P = Width of Alcove (Minimum)	3 feet (91cm)*	3 feet (91cm)*

Q = Clearance to Combustible Above (Alcove)	18 inches (457mm)*	18 inches (457mm)**

* In accordance with the current CSA-B149.1 National Gas And Propane Installation Code. ** In accordance with the curent ANSI SZ223.1/NFPA 54 National Fuel Gas Codes.

*** Clearance required to vinyl soffit material - 30 inches (76cm) minimum.

‡ A vent shall not terminate directly above a sidewalk or paved driveway which is located between two single family dwellings and serves both dwellings.

*‡ Only permitted if veranda, porch, deck or balcony is fully open on a minimum 2 sides beneath the floor:

Figure 7

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.

Minimum Clearances to Combustibles

Hearth Extension - A hearth extension is not required with this appliance. If a hearth extension is used, do not block the lower control compartment door. Any hearth extension used is for appearance only and does not have to conform to standard hearth extension installation requirements.

Wall Finishes / Surrounds / Mantels

Note: Combustible wall finish materials and/or surround materials must not be allowed to encroach the area defined by the appliance front face (black sheet metal). Never allow combustible materials to be positioned in front of or overlapping the appliance front face. See Figure 57 on Page 31.

Non-combustible materials, such as surrounds and other appliance trim, may be installed on the appliance front face with these exceptions: they must not cover any portion of the removable glass panel or louvers.

Vertical installation clearances to combustible mantels vary according to the depth of the mantel. See Figure 8. Mantels constructed of non-combustible materials may be installed at any height

above the appliance opening; however, do not allow anything to hang below the hood.

		Mantel Depth			inches (millimeters)
14 (356)
12 (305)
10 (254)
8 (203)					Top of
					Top of
6 (152)					Appliance
4 (102)
12	10	8	6	4	2
(305)	(254)	(203)	(152)	(102)	(51)

Hood

Figure 8 - Minimum Mantel Clearances

Appliance and Vent Clearances

The appliance is approved with zero clearance to combustible materials on all sides (as detailed in Table 8), with the following exception: When the unit is installed with one side flush with a wall, the wall on the other side of the unit must not extend beyond the front edge of the unit. Refer to Figure 4.

MINIMUM CLEARANCES Inches (millimeters)

	Back	1/2 (13)
		0 (0) Spacers
	Sides	1/2 (13)
		0 (0) Spacers

	Top Spacers	0 (0)

	Floor	0 (0)
	Bottom of Appliance	64 (1626)
	To Ceiling	64 (1626)
	To Ceiling
	Vent	3 (76) Top *
		1 (25.4) Sides & Bottom

	SERVICE CLEARANCES Feet (meters)

	Front	3 ft. (0.9 m)

Table 8

*Note: 3 in. (75 mm) above any horizontal/inclined vent component.

**Note: See Page 10, Step 1 for clearance requirements to the nailing flange located at each side of the unit and any screw heads adjacent to it.

	Combustible Shelf Height - Inches (millimeters)				Minimum Distance to Unprotected Side Wall
Model No.	Combustible Shelf Height - Inches (millimeters)
Model No.	Top Vent - with One 90 Degree Elbow		Rear Vent - Straight Out the Back		Combustible materials may project beyond the sides of the fire-
	Top Vent - with One 90 Degree Elbow		Rear Vent - Straight Out the Back
	Secure Vent	Secure Flex	Secure Vent	Secure Flex	place opening as long as they are kept within the shaded areas
	Secure Vent	Secure Flex	Secure Vent	Secure Flex	illustrated here.
		(flex elbow)			illustrated here.
		(flex elbow)
SSDVT-3328	*44-1/8 (1121)	*45-7/8 (1165)	N/A	N/A	At 14" minimum	At 8-1/4" side
SSDVR-3328	N/A	N/A	33 1/4 (845)	33 1/4 (845)	side wall clearance,	At 8-1/4" side
SSDVR-3328	N/A	N/A	33 1/4 (845)	33 1/4 (845)	a combustible wall	wall clearance, a	Top View of
* Includes 3” clearance to combustibles (required above vent components)					can project to any	combustible wall	Fireplace
					length.	can project 12"	Fireplace
					length.	can project 12"
			Do not insulate the				Combustible Materials
Do not insulate the			space between the			45o	Combustible Materials
space between the			appliance and the			45o	Allowed In Shaded
appliance and the			area above it.			5 (127)	Area “Safe Zone”
area above it.
							Combustible Walls
							shown in dark gray
			*Shelf Height			12 (305)
Shelf Height			(see table)
(see table)

				19 (483) Inches (millimeters)

	Shelf Above Fireplace With Top Venting
Shelf Above Fireplace With Rear Venting		14
Shelf Above Fireplace With Rear Venting			8-1/4 Protected wall shown in white
			8-1/4 Protected wall shown in white
Figure 9 - Shelf Height Minimum Clearances		(356)	(209)	Figure 10
Figure 9 - Shelf Height Minimum Clearances				Figure 10

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.

Detailed Installation Steps

The appliance is shipped with all gas controls and components installed and pre-wired. Remove the shipping carton, exposing the front glassdoor. Removethetopandbottomlouvered control panel per instructions on Page 27 (see

Control Compartment Access / Louver Panel Instructions). Remove the cardboard from underneath the pressure relief plates, in area behind top louver panel (see Figure 11). Open the two latches (located under the firebox floor) securing the glass door. Remove the door by tilting it outward at the bottom and lifting it up. Set the door aside protecting it from inadvertent damage. See Figure 54 on Page 30.

Pressure Relief Plates
REMOVE	REMOVE
REMOVE	CARDBOARD
CARDBOARD	BEFOREUSING
BEFOREUSING
Remove Cardboard Before
Using Appliance
Figure 11

TYPICAL INSTALLATION SEQUENCE

The typical sequence of installation follows, however, each installation is unique resulting in variations to those described.

See the Page numbers references in the following steps for detailed procedures.

Step 1. (Page 10) Construct the appliance framing. Position the appliance within the framing and secure with nailing brackets.

Step 2. (Page 10) Route gas supply line to appliance location.

Step 3. (Page 13) Install the vent system and exterior termination.

Step 4. (Page 25) Field Wiring

a.Millivolt Appliances – Install the operating control switch (not factory provided) and bring in electrical service line for forced air circulating blower (optional equipment).

b.Electronic Appliances – Field wire and install operating control switch.

Step 5. (Page 25) Install blower kit (optional equipment).

Step 6. (Page 26) Make connection to gas supply.

Step 7. (Page 27) Checkout appliance operation. Step 8. (Page 28) Install the logs, decorative

volcanic stone and glowing embers.

Step 9. (Page 30) Install glass door frame assembly.

Step10.(Page30) Adjustburnertoensureproper flame appearance.

Step 11. (Page 31) Install the hoods.

Step 1. Framing

Frame these appliances as illustrated in Figure 14 on Page 11, unless the appliance is to be installed in a corner. See Figure 15 on Page 12 for corner framing installations. All framing details must allow for a minimum clearance to combustible framing members as shown in

Table 8 on Page 9.

If the appliance is to be elevated above floor level, a solid continuous platform must be constructed.

Headers may be in direct contact with the appliance top spacers but must not be supported by them or notched to fit around them. All construction above the appliance must be self supporting. DO NOT use the appliance for structural support.

Thefireplaceshouldbesecuredtothesideframing membersusingtheunit'snailingflanges-onetop and bottom on each side of the fireplace front. See Figure 12. Use 8d nails or their equivalent.

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.

Side	Unit Nailing Flange
	(No clearance to
Framing	combustible
	framing is required)
Left Side Front Corner of Fireplace Shown
(Right Side Requirements the Same)
Unit Being Secured By Its Nailing Flanges
	To The Framing
Note: The nailing flanges, combustible members
and screw heads located in areas directly adjacent
to the nailing flanges, are EXEMPT from the 1/2”
clearance to combustible requirements for the
firebox outer wrapper. Combustible framing may be
in direct contact with the nailing flanges and may
be located closer than 1/2” from screw heads and
the firebox wrapper in areas adjacent to the nailing
flanges. Frame the opening to the exact dimensions
specified in the framing details of this manual.

Figure 12

Step 2. Routing Gas Line

Route a 1/2" (13 mm) gas line along the inside of the right side framing as shown in Tables. Gas lines must be routed, constructed and made of materials that are in strict accordance with local codes and regulations. All appliances are factory-equipped with a flexible gas line connector and 1/2 inch shutoff valve. (See Step 6 on Page 26).

Right Side Front Corner of Fireplace Framing

6 1/2" (76 mm)

(152 mm)

Also see Figure 14.

Figure 13 - ROUTE GAS LINE

Continued on Page 12.

fireplace specifications

		FRAMING WITH SQUARE HORIZONTAL TERMINATION (SV4.5HT-2)
Notes
Due to Lennox' ongoing commitment to quality,		VENT FRAMING -				Framing should be constructed
Due to Lennox' ongoing commitment to quality,		VENT FRAMING -				Framing should be constructed
all specifications, ratings and dimensions are		TOP VENT WITH ONE		10-1/2		of 2 x 4 or larger lumber.
subject to change without notice.		TOP VENT WITH ONE
subject to change without notice.		90¡ ELBOW
				(267)


		VENT FRAMING -
		VENT FRAMING -
Vent Size		REAR VENT WITH
Co-axial DV Vent Size	4-1/2" Inner	NO ELBOWS
		NO ELBOWS			7

	7-1/2" Outer
	7-1/2" Outer		5-1/8		(178)
			5-1/8			12-1/8
			(130)			12-1/8
						(308)

Vertical Venting Through the Ceiling:
Frame ceiling opening - Use a plumb
line from the ceiling above the appli-
ance to locate center of the vertical run.
Cut and/or frame an opening, 10-1/2"	33-1/4
x 10-1/2" (267 mm x 267 mm) inside	(845)
x 10-1/2" (267 mm x 267 mm) inside
dimensions, about this center mark (see
Figure 19).

Inches (mm)

FRAMING	21-1/2
FRAMING	21-1/2
SPACERS		(546)
(Top and Sides	10-3/4
(Top and Sides	10-3/4
and Rear)	(273)

			6-13/16
			(173)
	Top View
	33-1/8		3 (76)
	(841)
1
(25)
33-1/8		17	30-1/8
33-1/8	27-1/2	(432)	(765)
(841)	27-1/2
(841)	(699)
	(699)

Front View

Figure 14

		7
37-1/8	5-1/8	(178)
37-1/8	5-1/8	12-1/8
(943)	(130)	12-1/8
		(308)

	19-5/8
	(498)
	*12-7/8
16-5/8	(327)
16-5/8
(422)
33-1/4	*12-7/8 inches (327 mm) is the
(845)	required framing depth dimension
	when the finish material (drywall)
	thickness is 1/2 in. (13mm).

*CONCENTRIC FLUE

FLUE - 4-1/2 (114) COMBUSTION AIR - 7-1/2

*SSDVR models have only a rear vent *SSDVT models have only a top vent

Inches (millimeters)

	13
NOTE - Eyebrow	(330)
NOTE - Eyebrow
hood shown as positioned		1/2 (13)
in louvered front model.		1/2 (13)
ELECTRICAL INLET
2-3/4 x 2 (70 x 51)
COVER PLATE with
KNOCKOUT)
		1 (25)
GAS INLET	8-11/32		**19-5/8
(Either Side	(212)	1-5/8	**19-5/8
(Either Side	(212)		(498)
and bottom)			(498)
3 (76)		(42)
3 (76)
		2-3/4 **Rear vent models only
	Right Side View	(70)

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.

fireplace FRAMING specifications

Note-

Venting requirements for rear vent applications in corner installations -

- the horizontal vent length a to b, must not exceed 28 inches (711 mm)

Framing should be constructed of 2x4 or larger lumber.

*These dimensions occur when one 45	SV4.5HTSS & SV4.5HTSSL
degree elbow is connected directly to the	Termination
appliance collar and the unit moved 1/2
in. (13 mm) into the room. This 1/2 in.	*F = 5 in.
movement is required to achieve a min.	(127 mm)
of 5 in (127 mm) in the F dimension.

SV4.5HT-2 Termination

7 (178)

8-3/16 (208)

*34-5/16

(872) *24-1/4

(616)

a	*17-3/16
a	(437)
33-1/8
(841)	Inches
	Inches
*48-1/2	(millimeters)
(1232)

Back wall of chase/enclosure (including any finishing materials)

Figure 15	Corner Framing with Square Termination (SV4.5HT-2)

Proper Sizing of Gas Line						• A pipe joint compound rated for gas should be
Proper Sizing of Gas Line			Schedule 40 / Black Iron Pipe			• A pipe joint compound rated for gas should be
			Schedule 40 / Black Iron Pipe			used on the threaded joints. Ensure propane
			Inside Diameter (Inches)			used on the threaded joints. Ensure propane
Properly size and route the gas supply line			Inside Diameter (Inches)			resistant compounds are used in propane
Properly size and route the gas supply line						resistant compounds are used in propane
from the supply regulator to the area where			Schedule 40 Pipe	Natural	Propane	applications. Be very careful that the pipe
the appliance is to be installed per require-			Length (feet)	Gas	Gas	compound does not get inside the pipe.
ments outlined in the National Fuel Gas Code,			0-10	1/2	3/8	• It is recommended to install a sediment trap
NFPA 54 - latest edition (USA) or B149 - latest						in the supply line as close as possible to the
NFPA 54 - latest edition (USA) or B149 - latest			10-40	1/2	1/2	in the supply line as close as possible to the
edition (Canada).			10-40	1/2	1/2	appliance (see Figure 46). Appliances using
edition (Canada).						appliance (see Figure 46). Appliances using
			40-100	1/2	1/2	Propane should have a sediment trap at the
Never use galvanized or plastic pipe. Refer to						base of the tank.
Never use galvanized or plastic pipe. Refer to			100-150	3/4	1/2	base of the tank.
Table 9 for proper sizing of the gas supply line,			100-150	3/4	1/2	• Check with local building official for local code
Table 9 for proper sizing of the gas supply line,			150-200	3/4	1/2	• Check with local building official for local code
if black iron pipe is being used. Gas lines must			150-200	3/4	1/2	requirements(i.e.arebelowgradepenetrations
be routed, constructed and made of materials			Table 9			of the gas line allowed, etc).
that are in strict accordance with local codes						IMPORTANT: If propane is used, be aware that
that are in strict accordance with local codes
and regulations. We recommend that a quali-		Notes:
fied individual such as a plumber or gas fitter		Notes:				if tank size is too small (i.e. under 100-lbs, if
fied individual such as a plumber or gas fitter		•	All appliances are factory-equipped with a			if tank size is too small (i.e. under 100-lbs, if
be hired to correctly size and route the gas		•	All appliances are factory-equipped with a			this is the only gas appliance in the dwelling.
be hired to correctly size and route the gas			flexiblegaslineconnectorand1/2inchshutoff			this is the only gas appliance in the dwelling.
supply line to the appliance. Installing a gas			flexiblegaslineconnectorand1/2inchshutoff			Ref. NPFA 58), there may be loss of pressure,
supply line to the appliance. Installing a gas			valve (see Figure 46 on Page 26 ).			Ref. NPFA 58), there may be loss of pressure,
supply line from the fuel supply to the appliance			valve (see Figure 46 on Page 26 ).			resulting in insufficient fuel delivery (which
supply line from the fuel supply to the appliance		•	See Massachusetts Requirements on Page			resulting in insufficient fuel delivery (which
involves numerous considerations of materials,		•	See Massachusetts Requirements on Page			can result in sooting, severe delayed ignition
protection, sizing, locations, controls, pressure,			4 for additional requirements for installations			or other malfunctions). Any damage resulting
sediment, and more. Certainly no one unfamiliar			in the state of Massachusetts in the USA.			from an improper installation, such as this, is
and unqualified should attempt sizing or install-		•	The gas supply line should Not be connected			not covered under the limited warranty.
ing gas piping.			to the appliance until Step 6 (Page 26).
ing gas piping.

12	NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.

Step 3. Install the Vent System

General Information

Useonlyapprovedventingcomponents. See

Approved Vent Components on Page 2.

These fireplaces must be vented directly to the outside.

The vent system may not service multiple appliances, and must never be connected to a flue serving a solid fuel burning appliance. The vent pipe is tested to be run inside an enclosing wall (such as a chase). There is no requirement for inspection openings in the enclosing wall at any of the joints in the vent pipe.

WARNING

Failure to reinstall and securely tighten cover plate screws could result in leakage of flue products into the living space. Vent cover plate and vent seal plate must remain securely installed on unused vent collar. Failure to do so could result in leakage of flue products into living space.

Installation of Vent Restrictor

Aventrestrictormaybeneededwiththisappliance, installventrestrictor(provided)intheappliancetop flue outlet as shown in Figure 16 (SSDVT-3328 ) or rear flue outlet as shown in Figure 17 (SSDVR3328 ). It is held in place by friction, only.

Vent Restrictor Installation

(Top Vent)

A vent restrictor may be needed when vertically terminating the vent system above the roof (when using the appliance top vent), install vent restrictor in the top vent of the fireplace outlet on SSDV-3328 series models. If needed, install the restrictor orientated as shown, either from inside or outside the unit,in the inner fireplace collar.

Restrictor

Inner

Fireplace

Collar

Appliance Top

Vent Outlet

Figure 16

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.

Vent Restrictor Installation

(Rear Vent)

A vent restrictor may be needed when horzontally terminating the vent system from the rear of the appliance (when using the appliance rear vent), install vent restrictor in the rear vent of the fireplace outlet on SSDV-3328 series models, in any installation that has a vertical vent run in excess of three feet (0.914 meters).

If needed, install the restrictor orientated as shown, either from inside or outside the unit, in the inner fireplace collar

	Inner Fireplace	Appliance Rear
	Collar	Appliance Rear
	Collar	Vent Outlet
		Vent Outlet
		Restrictor

Figure 17

Select Venting System - Horizontal or Vertical

With the appliance secured in framing, determine vent routing and identify the exterior termination location. The following sections describe vertical (roof) and horizontal (exterior wall) vent applications. Refer to the section relating to your installation. A list of approved venting components is shown on Pages 32 through 34.

Vertical Termination Systems (Roof)

Figure 21 (Page 15), and Figures 26 to 30 (Pages 17 and 18) and their associated Vertical Vent Tables illustrate the various vertical venting configurations that are possible for use with these appliances. Secure Vent pipe applications are shown in these Figures; Secure Flex pipe may also be used. A Vertical Vent Table summarizes each system’s minimum and maximum vertical and horizontal length values that can be used to design and install the vent components in a variety of applications.

Both these vertical vent systems terminate through the roof. The minimum vent height above the roof and/or adjacent walls is specified in ANSI Z223.1-(latest edition) (In Canada, the current CAN-1 B149 installation code) by major building codes. Always consult your local codes for specific requirements. A general guide to follow is the Gas Vent Rule (refer to

Figure 5 on Page 7).

Vertical (Straight) Installation

Determine the number of straight vent sections required. 4-1/2" (114 mm), 10-1/2" (267 mm), 22-1/2" (572 mm), 34-1/2" (876 mm) and 46- 1/2" (1181 mm) net section lengths are available (see Table 11 and Page 32 - Item 3). Plan the vent lengths so that a joint does not occur at the intersection of ceiling or roof joists. Refer to the Vent Section Length Chart.

	SV4.5CGV-1	SV4.5FA OR
	Termination	SV4.5FA OR
	Termination	SV4.5FB Flashing
		SV4.5FB Flashing
		AND SV4.5SC
		STORM COLLAR

		1" (25.4 mm)
		Minimum
		Clearance to
		Combustibles
		SV4.5VF
		Firestop/Spacer
40' Max		SV4.5L6/12/24/36/48
(12.2	M)	SV4.5L6/12/24/36/48
(12.2	M)	Vent Sections
		Vent Sections
		When using Secure Flex
		use Firestop/Spacer
		SF4.5VF

Figure 18

VENT SECTION LENGTH CHART

Nominal		6	12	24	36	48	T
Section Length							O
(inches)							T
							A
Net Section		4 ½	10 ½	22 ½	34 ½	46	A
Net Section		4 ½	10 ½	22 ½	34 ½	46	L
Length (inches)						½	Q
Height of Vent			Number of Vent Sections				Q
Height of Vent			Number of Vent Sections				T
							Y
*inches	feet						Y
*inches	feet

4.5	0.375	1	0	0	0	0	1

9	0.75	2	0	0	0	0	2
10.5	0.875	0	1	0	0	0	1
15	1.25	1	1	0	0	0	2

19.5	1.625	2	1	0	0	0	3
19.5	1.625	2	1	0	0		3

21	1.75	0	2	0	0	0	2

22.5	1.875	0	0	1	0	0	1
25.5	2.125	1	2	0	0	0	3
31.5	2.625	0	3	0	0	0	3

34.5	2.875	0	0	0	1	0	1

37.5	3.125	1	1	1	0	0	3

43.5	3.625	0	2	1	0	0	3

45	3.75	0	0	2	0	0	2

46.5	3.875	0	0	0	0	1	1

49.5	4.125	1	0	2	0	0	3

51	4.25	1	0	0	0	1	2

55.5	4.625	0	1	2	0	0	3
57	4.75	0	0	1	1	0	2

66	5.25	0	2	2	0	0	4

67.5	5.625	0	0	3	0	0	3

69	5.75	0	0	0	2	0	2
72	6	1	0	3	0	0	4
73.5	6.125	1	0	0	2	0	3

79.5	6.625	0	1	0	2	0	3

81	6.75	0	0	0	1	1	2
90	7.5	0	2	1	0	1	4
91.5	7.625	0	0	2	0	1	3

93	7.75	0	0	0	0	2	2

96	8	1	0	1	2	0	4

97.5	8.125	1	0	0	0	2	3

102	8.5	2	0	0	0	2	4

103.5	8.625	0	0	0	3	0	3
108	9	1	0	0	3	0	4
114	9.5	0	2	0	0	2	4
117	9.75	1	0	5	0	0	6

118.5	9.875	1	1	0	3	0	5

126	10.5	0	0	1	3	0	4

130.5	10.875	1	0	1	3	0	5
135	11.25	0	0	6	0	0	6
138	11.5	0	0	0	4	0	4

139.5	11.625	0	0	0	0	3	3

142.5	11.875	1	0	0	4	0	5

Table 10a

* Convert inches into metric equivalent measure, as follows:

Millimeters (mm) = Inches x 25.4

Centimeters (cm) = Inches x 2.54

Meters (M) = Inches x .0254

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.

VENT SECTION LENGTH CHART

Nominal Section			6	12	24		36	48	T
	Length (inches)								O
									T
									T
	Net Section		4 ½	10 ½	22 ½		34 ½	46 ½	A
	Length (inches)								L
									Q
	Height of Vent			Number of Vent Sections					Q
									T
*inches		feet							Y

144		12	1	0	0		0	3	4
150		12.5	0	1	0		0	3	4

154.5		12.875	1	1	0		0	3	5

160.5		13.375	0	2	0		0	3	5

172.5		14.375	0	0	0		5	0	5

177		14.75	1	0	0		5	0	6

183		15.25	0	1	0		5	0	6

186		15.5	0	0	0		0	4	4

190.5		15.875	1	0	0		0	4	5

196.5		16.375	0	1	0		0	4	5

205.5		17.125	0	1	1		5	0	7

207		17.25	0	0	0		6	0	6

211.5		17.625	1	0	0		6	0	7

217.5		18.125	0	1	0		6	0	7

229.5		19.125	0	0	1		6	0	7

232.5		19.375	0	0	0		0	5	5
237		19.75	1	0	0		0	5	6
241.5		20.125	0	0	0		7	0	7

246		20.5	1	0	0		7	0	8
252		21	0	1	0		7	0	8
264		22	0	0	1		7	0	8

276		23	0	0	0		8	0	8
279		23.25	0	0	0		0	6	6
280.5		23.375	1	0	0		8	0	9
283.5		23.625	1	0	0		0	6	7

289.5		24.125	0	1	0		0	6	7
301.5		25.125	0	0	1		0	6	7
310.5		25.875	0	0	0		9	0	9

315		26.5	1	0	0		9	0	10
325.5		27.125	0	0	0		0	7	7
330		27.5	1	0	0		0	7	8

336		28	0	1	0		0	7	8
345		28.75	0	0	0		10	0	10
349.5		29.125	1	0	0		10	0	11
372		31	0	0	0		0	8	8

376.5		31.375	1	0	0		0	8	9
379.5		31.625	0	0	0		11	0	11
418.5		34.875	0	0	0		0	9	9

423		35.25	1	0	0		0	9	10
465		38.75	0	0	0		0	10	10

	Table 10b

		Effective Vent Length

		Model			Effective Length

		SV4.5L6				4-1/2"

		SV4.5L12				10-1/2"

		SV4.5L24				22-1/2"

		SV4.5L36				34-1/2"

		SV4.5L48				46-1/2"

	Table 11

Vertical (Offset) Installation

Analyze the vent routing and determine the quantitiesofventsectionsandnumberofelbows required. Refer to Vertical Vent Figures and Tables on Pages 17 and 18 to select the type of vertical installation desired. Vent sections are available in net lengths of 4-1/2" (114 mm), 10-1/2" (267 mm), 22-1/2" (572 mm), 34-1/2 " (876 mm) and 46-1/2" (1181 mm). Refer to the

Vent Section Length Chart on Page 14 for an aid in selecting length combinations. Elbows are available in 90° and 45° configurations. Refer to Figure 22 on Page 16 for the SV4.5E45 and SV4.5E90 elbow dimensional specifications.

Where required, a telescopic vent section (SV4.5LA) may be used to provide the installer with an option in installing in tight and confined spaces or where the vent run made up of fixed length pieces develops a joint in a undesirable location, or will not build up to the required length. The SV4.5LA Telescopic Vent Section has an effective length of from 1-1/2" (38 mm) to 7-1/2" (191 mm). The SV4.5LA is fitted with a locking inclined channel end (identical to a normal vent section component) and a plain end with 3 pilot holes. Slip the plain end over the locking channel end of a standard SV4.5 vent component the required distance and secure with three screws.

Maintain a minimum 1" (25 mm) clearance to combustiblematerialsforallverticalelements. Clearances for all horizontal elements are 3" (76 mm) on top, 1" (25 mm) on sides and 1" (25 mm) on the bottom.

A. Frame ceiling opening - Use a plumb line from the ceiling above the appliance to locate center of the vertical run. Cut and/or frame an opening, 10-1/2" x 10-1/2" (267mm x 267mm) inside dimensions, about this center mark (Figure 19 ).

10-1/2" Min. (267 mm)

10-1/2" Min.

(267 mm)

Figure 19

B. Attach vent components to appliance - Secure Vent SV4.5 direct vent system components are unitized concentric pipe components featuring positive twist lock connections (see

Figure 20).

All of the appliances covered in this document are fitted with collars having locking inclined channels. The dimpled end of the vent components fit over the appliance collar to create the positive twist lock connection.

	Align the dimple (four places) of the
	upper vent section with the opening
	of the locking incline channel on the
	lower vent section or appliance col-
	lar. Twist vent component clockwise
	to engage and seal until arrow and
Arrow	dimple align.
	Dimple
	Locking Incline
	Channel
	Connected Vent	Arrow
	Sections

Appliance Collar or

Vent Section

Figure 20

Toattachaventcomponenttotheappliancecollar, alignthedimpledendoverthecollar,adjustingthe radial alignment until the four locking dimples are aligned with the inlet of the four inclined channels on the collar (refer to Figure 20). Push the vent component against the collar until it fully engages, then twist the component clockwise, running the dimples down and along the incline channels until they seat at the end of the channels. The unitized design of the Secure Vent components will engage and seal both the inner and outer pipe without the need for sealant or screws. If desired, a #6 x 1/2" screw may be used at the joint, but is not required as the pipe will securely lock when twisted.

Note: An elbow may also be attached to the appliance collar. Attach in the same manner as you would a vent section.

C. Attach vent components to each other - Other vent sections may be added to the previously installed section in accordance with the requirements of the vertical vent Figures and Tables.

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.

To add another vent component to a length of vent run, align the dimpled end over the inclined channel end of the previously installed section, adjusting the radial alignment until the four locking dimples are aligned with the inlets of the four incline channels of the previous section.

Push the vent component against the previous section until it fully engages, then twist the componentclockwiserunningthedimplesdown and along the incline channels until they seat at the end of the channels. This seating position is indicated by the alignment of the arrow and dimple as shown in Figure 20.

D.Install firestop/spacer at ceiling - When using Secure Vent, use SV4.5VF firestop/spacer at ceiling joists; when using Secure Flex, use SF4.5VF firestop/spacer. If there is living space above the ceiling level, the firestop/spacer must be installed on the bottom side of the ceiling. If attic space is above the ceiling, the firestop/spacer must be installed on the top side of the joist. Route the vent sections through the framed opening and secure the firestop/spacer with 8d nails or other appropriate fasteners at each corner. Remember to maintain 1" (25 mm) clearance to combustibles, framing members, and attic or ceiling insulation when running vertical chimney sections. Attic insulation shield (96K94) may be used to obtain the required clearances indicated here. See installation accessories, Pages 32 through 34.

E.Support the vertical vent run sections -

Note - Proper venting support is very important. The weight of the vent must not be supported by the firplace in any degree.

Support the vertical portion of the venting system every 8 feet (2.4m) above the fireplace vent outlet.

Blocking

Support Straps

(Plumber's tape)

8 feet (2.4 m)

Maximum

1 inch (25.4

mm) minimum

clearance to

combustibles

Figure 21

One method of support is by utilizing field provided support straps (conventional plumber's tape). Secure the plumber's tape to the framing members with nails or screws. Loop the tape around the vent, securing the ends of the tape to the framing. If desired, sheet metal screws #6 x 1/2" length may be used to secure the support straps to the vent pipe. Refer to Figure 21.

F. Change vent direction to horizontal/inclined run - At transition from or to a horizontal/inclined run, install the SV4.5E45 and SV4.5E90 elbows in the same manner as the straight vent sections. The elbows feature a twist section to allow them to be routed about the center axis of their initial collar section to align with the required direction of the next vent run element.

Twist elbow sections in a clockwise direction only so as to avoid the possiblity of unlocking any of the previously connected vent sections.

See Figure 22.

	8-1/8"
4-13/16	7-5/8”
4-13/16	(194
(122 mm)	(206 mm)
(122 mm)
Swivel Joint	Swivel Joint
(360° swivel)	(360° swivel)
SV4.5E45	SV4.5E90
45° Elbow)	90° Elbow)
Figure 22

G. Continue installation of horizontal/inclined sections - Continue with the installation of the straight vent sections in horizontal/inclined run as described in Step C. Install support straps every 5 ft. (1.52 m) along horizontal/inclined vent runs using conventional plumber’s tape.

See Page 19, Figure 31. It is very important that the horizontal/inclined run be maintained in a straight (no dips) and recommended to be ina slightlyelevatedplane, inadirection away from the fireplace of 1/4 " rise per foot (20 mm per meter) which is ideal, though rise per foot run ratios that are smaller are acceptable all the way down to at or near level. Use a carpenter’s level to measure from a constant surface and adjust the support straps as necessary.

It is important to maintain the required clearances to combustibles: 1" (25 mm) at all sides for all vertical runs; and 3" (76 mm) at the top, 1" (25 mm) at sides, and 1" (25 mm) at the bottom for all horizontal/inclined runs.

H. Frame roof opening - Identify location for vent at the roof. Cut and/or frame opening per Roof Framing Chart and Figure 23.

	C
	D
Framing Dimensions for Roof
	Inches (millimeters)
Pitch	C	D
0/12	10-1/2 in.	10-1/2 in.
	(267 mm)	(267 mm)
6/12	10-1/2 in.	12 in.
	(267 mm)	(305 mm)
12/12	10-1/2 in.	17 3/4 in.
	(267 mm)	(451 mm)
Figure 23 - Roof Framing

I.Install the roof flashing - Extend the vent sections through the roof structure. Install the roof flashing over the vent section and position such that the vent column rises vertically (use carpenters level) (Figure 24 ). Nail along perimeter to secure flashing or adjust roofing to overlap the flashing edges at top and sides only and trim where necessary. Seal the top and both sides of the flashing with waterproof caulking.

J.Install the storm collar - Install the storm collar, supplied with the flashing, over the vent/flashing joint. See Figure 24. Loosen the storm collar screw. Slide collar down until it meets the top of the flashing. Tighten the adjusting screw. Apply non-combustible caulking or mastic around the circumference of the joint to provide a water tight seal.

Storm

Collar

Figure 24

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.

K. Install the vertical termination - The final step involves installation of the SV4.5CGV-1 Vertical Termination. Extend the vent sections to the height as shown in the "Vertical vent termination section" on Page 7. The SV4.5CGV-1 Vertical Termination (Figure 25) can be installed in the exact same fashion as any other Secure Vent section. Align the termination over the end of the previously installed section, adjusting the radial alignment until the four locking dimples of the termination are aligned with the inlets of the four incline channels of the last vent section. Push the termination down until it fully engages, then twist the termination clockwise running the dimples down and along the incline channels until they are seated at the end of the channels.

Figure 25

If the vent system extends more than 5 feet (1.5 m) above the roof flashing, stabilizers may be necessary. Additional screws may be used at section joints for added stability. Guide wires may be attached to the joint for additional support on multiple joint configurations.

VERTICAL VENT FIGURES/TABLES

Note: Secure Vent (rigid vent pipe) is shown in the Figures; Secure Flex (flexible vent pipe) may also be used.

WARNING

Under no circumstances, may separate sections of concentric flexible vent pipe be joined together.

Notes:

•It is very important that the horizontal/inclined run be maintained in a straight (no dips) and recommended to be in a slightly elevated plane, in a direction away from the fireplace of 1/4" rise per foot (20 mm per meter) which is ideal, though rise per foot run ratios that are smaller are acceptable all the way down to at or near level.

•SV4.5VF (Secure Vent), SF4.5VF (Secure Flex) firestop/spacer must be used anytime vent pipe passes through a combustible floor or ceiling. SV4.5HF (Secure Vent), SF4.5HF (Secure Flex)firestop/spacer must be used anytime vent pipe passes through a combustible wall.

•Two 45 degree elbows may be used in place of one 90 degree elbow. The same rise to run ratios, as shown in the venting Figures for 90 elbows, must be followed if 45 degree elbows are used.

•AN ELBOW IS ACCEPTABLE AS 1 FOOT OF VERTICAL RISE EXCEPT WHERE AN ELBOW IS THE ONLY VERTICAL COMPONENT IN THE SYSTEM (See Figure 35).

	uCeiling Firestop /	40 feet
		(12.2 meters)
	Spacer (SV4.5VF)
		Maximum

uWhenusingSecureFlex,useFirestop/Spacer

SF4.5VF

A Vent Restrictor, as shown in Figure 18 Page 13, must be used in this application

Figure 26 - Top Vent - STRAIGHT

	Table A			uWhen using Secure Flex, use Firestop /
H Maximum		V Minimum		uWhen using Secure Flex, use Firestop /
H Maximum		V Minimum		Spacer SF4.5VF.
				Spacer SF4.5VF.
feet	(meter)	feet	(meter)
2	(0.610)	1	(0.305)
4	(1.219)	2	(0.610)
6	(1.829)	3	(0.914)
8	(2.438)	4	(1.219)
V + H = 40 feet (12.2 meters) Max.
	H = 8 feet (2.4 meters) Max.			uCeiling Firestop /
	Ratio V to H ratio is 1:2			Spacer (SV4.5VF)
Example: If 8 feet of (H) horizontal vent run
is needed, then 4 feet minimum (V) vertical
vent will be required.				V
				V

This table shows a 1(V) to 2(H) ratio. For every 1 foot of (V) vertical, you are allowed 2 feet of (H) horizontal run, up to a maximum horizontal run of 8 feet.

Figure 27 - Rear Vent - ONE 90 DEGREE ELBOW
		Table B
H	H Maximum		V Minimum
	feet	(meter)	feet	(meter)
	5	(1.524)	Elbow Only
uCeiling Firestop /	5	(1.524)	1	(0.305)
Spacer (SV4.5VF)	5	(1.524)	1	(0.305)
Spacer (SV4.5VF)	10	(3.048)	2	(0.610)
	10	(3.048)	2	(0.610)
	15	(4.572)	3	(0.914)
	20	(6.096)	4	(1.219)
V1	V + V1	+ H = 40 feet (12.2 m) Max.
	H = 20 feet (6.096 meters) Max.
V	Example: If 20 feet of (H) horizontal vent run
	Example: If 20 feet of (H) horizontal vent run
	is needed, then 4 feet minimum of (V) vertical
	vent will be required.
vWall Firestop/	This table shows a 1(V) to 5(H) ratio. For
vWall Firestop/	every 1 foot of (V) vertical, you are allowed 5
Spacer (SV4.5HF)	every 1 foot of (V) vertical, you are allowed 5
Spacer (SV4.5HF)	feet of (H) horizontal run, up to a maximum
	feet of (H) horizontal run, up to a maximum
	horizontal run of 20 feet.
uWhen using Secure Flex, use Firestop /	An elbow is acceptable as 1 foot of vertical
Spacer SF4.5VF.	rise except where an elbow is the only vertical
vWhen using Secure Flex, use Firestop /	component in the system. See Figure 35.
Spacer SF4.5HF.
Figure 28 - Top Vent - TWO 90 DEGREE ELBOWS
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.				17

VERTICAL VENT FIGURES/TABLES (CONTINUED)

		Table C					H1
H+H1 Maximum		H Maximum		V Minimum			H1
H+H1 Maximum		H Maximum		V Minimum
feet	(meter)	feet	(meter)	feet	(meter)
5	(1.524)	2	(0.610)	1	(0.305)		uCeiling
10	(3.048)	4	(1.219)	2	(0.610)		Firestop / Spacer
10	(3.048)	4	(1.219)	2	(0.610)		(SV4.5VF)
15	(4.572)	6	(1.829)	3	(0.914)
20	(6.096)	8	(2.438)	4	(1.219)		vWall Firestop/
	V + V1	+ H + H1	= 40 feet (12.2 m) Max				vWall Firestop/
	V + V1	+ H + H1	= 40 feet (12.2 m) Max				Spacer (SV4.5HF)
	H = 8 feet (2.438 meters) Max.				V1			uCeiling
	H + H1 = 20 feet (6.096 meters) Max.							Firestop / Spacer
uWhen using Secure Flex, use Firestop / Spacer SF4.5VF								(SV4.5VF)
uWhen using Secure Flex, use Firestop / Spacer SF4.5VF
vWhen using Secure Flex, use Firestop / Spacer SF4.5HF
Example: If 20 feet total (H+H1) horizontal vent run is needed,
then 4 feet minimum of (V) vertical vent will be required.
This table shows a 1(V) to 5(H) ratio.				For every 1 foot of (V)			V
vertical, you are allowed 5 feet of (H+H1) horizontal run up to a
maximum total horizontal run of 20 feet.
Figure 29 - Rear Vent - three elbows							H
Figure 29 - Rear Vent - three elbows
		Table D			Example: If 20 feet total (H+H1)
H + H1 Maximum			V Minimum		horizontal vent run is needed,
H + H1 Maximum			V Minimum		then 4 feet minimum of (V) verti-		uCeiling
feet	(meter)		feet	(meter)	cal vent will be required.		uCeiling
feet	(meter)		feet	(meter)			Firestop / Spacer
5	(1.524)		Elbow Only		This table shows a 1(V) to 5(H)	V1	(SV4.5VF)	vWall Firestop/
					ratio. For every 1 foot of (V)			Spacer (SV4.5HF)
5	(1.524)		1	(0.305)	vertical, you are allowed 5 feet
					of (H+H1) horizontal run up to
10	(3.048)		2	(0.610)	a maximum total horizontal run
15	(4.572)		3	(0.914)	of 20 feet.		H
15	(4.572)		3	(0.914)
20	(6.096)		4	(1.219)	An elbow is acceptable as 1 foot
20	(6.096)		4	(1.219)	of vertical rise except where			V
					of vertical rise except where			V
	H + H1 = 20 feet (6.096 m) Max.				an elbow is the only vertical		H1
	H + H1 = 20 feet (6.096 m) Max.				component in the system. See		H1
	V + V1 + H + H1 = 40 ft. (12.192 m) Max.				Figure 35.
					Figure 35.

uWhen using Secure Flex, use Firestop / Spacer SF4.5VF vWhen using Secure Flex, use Firestop / Spacer SF4.5HF

Figure 30 - Top Vent - three elbows

Horizontal (Outside Wall)	Both of these horizontal vent systems terminate	A. Plan the vent run -
Horizontal (Outside Wall)	Both of these horizontal vent systems terminate	A. Plan the vent run -
Termination System	through an outside wall. Building Codes limit or	Analyze the vent routing and determine the
	prohibit terminating in specific areas. Refer to	types and quantities of sections required
Figure 31, and Figures 34 to 40 on Pages	Figure 7 on Page 8 for location guidelines.	4-1/2" (114 mm), 10-1/2" (267 mm), 22-1/2"
21 to 23 and their associated Horizontal Vent		(572 mm), 34-1/2" (876 mm) and 46-1/2" (1181
21 to 23 and their associated Horizontal Vent	Secure Vent SV4.5 direct vent system compo-	mm) net section lengths are available. Plan the
Table illustrate the various horizontal venting		mm) net section lengths are available. Plan the
Table illustrate the various horizontal venting		vent lengths so that a joint does not occur at the
configurations that are possible for use with	nents are unitized concentric pipe components	vent lengths so that a joint does not occur at the
configurations that are possible for use with	nents are unitized concentric pipe components	intersection of ceiling or roof joists. Make allow-
these appliances. Secure Vent pipe applications	featuring positive twist lock connection, (refer	intersection of ceiling or roof joists. Make allow-
these appliances. Secure Vent pipe applications	featuring positive twist lock connection, (refer	ances for elbows as indicated in Figure 22.
are shown in these Figures; Secure Flex pipe	to Figure 20 on Page 15). All of the appli-	ances for elbows as indicated in Figure 22.
are shown in these Figures; Secure Flex pipe	to Figure 20 on Page 15). All of the appli-	Maintain a minimum 1" (25 mm) clearance to
may also be used. A Horizontal Vent Table sum-	ances covered in this document are fitted with	Maintain a minimum 1" (25 mm) clearance to
marizes each system’s minimum and maximum	collars having locking inclined channels. The	combustibles on the vertical sections. Clear-
	collars having locking inclined channels. The	ances for the horizontal runs are; 3" (76 mm)
	dimpled end of the vent components fit over
vertical and horizontal length values that can be
		on top, 1" (25 mm) on sides, and 1" (25 mm)
	the appliance collar to create the positive twist
used to design and install the vent components
		at the bottom.
	lock connection.	at the bottom.
in a variety of applications.	lock connection.
in a variety of applications.
18	NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
18	NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.

Building	Support Brackets
Support		Horizontal / Inclined Run
Framing			SV4.5HT-2
SV4.5E90			Termination
SV4.5E90			Shown
Elbow			Shown
Elbow
		SV4.5L6/12/24/36/48
Ceiling		Vent Sections	Exterior
Ceiling	uFirestop / Spacer		Wall
Vertical	SV4.5VF	Support Bracket Spacing
Rise		Support Bracket Spacing
Rise		Every 5 ft (1.52 m)
		Every 5 ft (1.52 m)
		uWhen Using Secure Flex,
		Use Firestop / Spacer SF4.5VF	SV4.5HT-2
			SV4.5HT-2
	See Figure 18 on Page 14 or Figure 21 on		Termination
	Page 15 for vertical vent section support.		Shown
		Fireplace

Figure 31 - TYPICAL HORIZONTAL VENT INSTALLATION

B. Frame exterior wall opening -	E. Attach vent components to each other	G. Support the vertical run sections -
B. Frame exterior wall opening -	E. Attach vent components to each other	G. Support the vertical run sections -
Locate the center of the vent outlet on	- Other vent sections may be added to the pre-	See Section E on Page 15.
the exterior wall according to the dimen-	viously installed section in accordance with the
sions shown in Figure 14 on Page 11. Cut	requirements of the vent tables. To add another	H. Change vent direction - At transition from or
and/or frame an opening, 10-1/2" x 12-1/8"	vent component to a length of vent run, align the	to a horizontal/inclined run, install the SV4.5E45
(267 mm x 308mm) inside dimensions, about	dimpled end of the component over the inclined	and SV4.5E90 elbows in the same manner as
this center.	channel end of the previously installed section,	the straight vent sections. The elbows feature a
	adjusting the radial alignment until the four lock-	twist section to allow them to be routed about the
C. Frame ceiling opening - If the vertical route	ing dimples are aligned with the inlets of the four	center axis of their initial collar section to align
is to penetrate a ceiling, use plumb line to locate	incline channels of the previous section.	with the required direction of the next vent run
the center above the appliance. Cut and/or frame	Push the vent component against the previous	element. Twist elbow sections in a clockwise
an opening, 10-1/2" x 10-1/2" (267 mm x 267	Push the vent component against the previous	direction only so as to avoid the possiblity of
mm) inside dimensions, about this center (refer	section until it fully engages, then twist the	unlockinganyofthepreviouslyconnectedvent
to Figure 19 on Page 15).	componentclockwiserunningthedimplesdown	sections. See Figure 22 on Page 16.
	and along the incline channels until they seat at
D. Attach vent components to appliance - To	the end of the channels.This seating position	I. Continue installation of horizontal/inclined
attach a vent component to the appliance collar,	is indicated by the alignment of the arrow and	sections - Continue with the installation of the
align the dimpled end over the collar, adjust-	dimple as shown in Figure 20 on Page 15.	straight vent sections in horizontal/inclined run
ing the radial alignment until the four locking	F. Install firestop/spacer at ceiling -	as described in Step E. Install support straps
dimples are aligned with the inlets of the four	F. Install firestop/spacer at ceiling -	every 5 ft. (1.52 m) along horizontal/inclined
incline channels on the collar (refer to Figure	When using Secure Vent, use SV4.5VF firestop/	vent runs using conventional plumber’s tape.
20 on Page 15).	spacer at ceiling joists; when using Secure Flex,	See Figure 31. It is very important that the
Push the vent component against the collar	use SF4.5VF firestop/spacer.	horizontal/inclined run be maintained in a
Push the vent component against the collar	If there is living space above the ceiling level,	straight (no dips) and recommended to be in
until it fully engages, then twist the component	If there is living space above the ceiling level,	a slightly elevated plane, in a direction away
clockwise, running the dimples down and along	the firestop/ spacer must be installed on the	from the fireplace of 1/4" rise per foot (20 mm
the incline channels until they seat at the end	bottom side of the ceiling. If attic space is	per meter) which is ideal, though rise per foot
of the channels.	above the ceiling, the firestop/ spacer must be	run ratios that are smaller are acceptable all
	installed on the top side of the joist. Route the	the way down to at or near level.
The unitized design of the Secure Vent	vent sections through the framed opening and
components will engage and seal both the	secure the firestop/spacer with 8d nails or other	It is important to maintain the required clear-
inner and outer pipe elements with the same	appropriate fasteners at each corner.	ances to combustibles: 1" (25 mm) at all sides
procedure. Sealant and securing screws are	Remember to maintain 1" (25 mm) clearance	for all vertical runs; and 3" (76 mm) at the top,
not required.	Remember to maintain 1" (25 mm) clearance	1" (25 mm) at sides, and 1" (25 mm) at the
	to combustibles, framing members, and attic	bottom for all horizontal/inclined runs.
Note: An elbow may also be attached to the	or ceiling insulation when running vertical
appliance collar. Attach in the same manner	chimney sections.
as you would a vent section.
	NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.	19

J. Assemble vent run to exterior wall - If not previously measured, locate the center of the vent at the exterior wall. Prepare an opening as described in Step B. Assemble the vent system to point where the terminus of the last section is located relative to the exterior surface to which the termination is to be attached (see Figures 32 & 33 and Table 12 on Page 21.

If the terminus of the last section is not within this distance, use the telescopic vent section SV4.5LA, as the last vent section. For wall thicknesses greater than that shown in Figure 33 on Page 20 and Table 12 on Page 21. This table lists the additional venting components needed (in addition to the termination and adapter) for a particular range of wall thicknesses.

K. Attach termination adapter - Attach the adapter (adapter - SV4.5RCH - provided with the termination) to the vent section or telescoping vent section, elbow or appliance collar as shown in Figures 32 & 33 in the same manner as any SV4.5 vent component (refer to Step E).

L. Install Firestop/Spacer at exterior wall - When using the square termination, install SV4.5HF (Secure Vent), SF4.5HF (Secure Flex) Firestop/Spacer over the opening at the exterior side of the framing, long side up, with the 3 inch spacer clearance at the top as shown in Figure 32, and nail into place.

(The Firestop/Spacer may also be installed over the opening at the interior side of framing).

M. Install the Square Termination (SV4.5HT-2 or SF4.5HT-2)

Install the square termination - For the last step , from outside the exterior wall, slide the collars of the termination onto the adapter (the outer inside the outer and the inner outside the inner) until the termination seats against the exterior wall surface to which it will be attached. Orient the housing of the termination with the arrow pointed upwards. Secure the termination to the exterior wall. The horizontal termination must not be recessed into the exterior wall or siding by more than the 1-1/4" (32 mm) as shown in Figure 33.

IMPORTANT

The vent termination is hot while in operation and for a period of time following the use of the fireplace. To prevent contact with hot surfaces, we recommend the use of a Termination Guard. See Items 12 and 13 on Page 32. This can be purchased at your local dealer.

		To help minimize water infiltration it is
		recommended that the Firestop/Spacer
		(SV4.5HF) be installed on the exterior
		side of the wall.
		SV4.5 HT-2
	7"	Termination
12¹⁄ "	(178)	10¹⁄ "
12¹⁄ "		10¹⁄ "
(308 mm)		(267mm)
	5¹⁄ "
(130 mm)		3"
		3"
		(76 mm)
Adapter		1"
Adapter		(25.4 mm)
SV4.5RCH
		Note: Centerline of Vent Piping is
		NOT the Same as the Centerline of
		the Framed Opening.
6 to 48 inch Vent Section,		See Figure 14 on Page 11 for Min.
6 to 48 inch Vent Section,		Distance to Base of Appliance.
Telescopic vent section,
Elbow or Appliance Collar		Base of Appliance
		Base of Appliance

Figure 32 - INSTALLING SQUARE HORIZONTAL TERMINATION (SV4.5HT-2 or SF4.5HT-2)

Use silicone caulking to seal		Maximum Wall Thickness
the top and sides of the		10 in. (254 mm)
termination, up to the	Interior Surface of	Exterior Surface of Siding
underlayment, stucco, or	Interior Surface of	Exterior Surface of Siding
masonry wall surface.	Finished Wall	Exterior Surface of
	Maximum Extent of	Framing
Siding	Maximum Extent of	6 in. to 9-1/4 in.
Siding	Vent Run Sections	6 in. to 9-1/4 in.
Caulk	Vent Run Sections
Caulk	Relative to Exterior	(152 to 235 mm)
	Surface of Framing

	Last Vent Section.
	Use Telescopic Vent
	Section (SV4.5LA), If
	Necessary		SV4.5 HT-2
			Termination
Caulk	SV4.5 HT-2
	SV4.5 HT-2
	Termination	Adapter
		Adapter
		SV4.5RCH	1-1/4” Maximum Recess of
			1-1/4” Maximum Recess of
			Square Termination
Stucco	vFor thicknesses greater		into Exterior Finishing Material
Stucco	vFor thicknesses greater
	than 10", see Table 12

	Venting Connection and Exterior Wall Recessing
Figure 33		of the Horizontal Square
	Termination (SV4.5HT-2 or SF4.5HT-2).

Horizontal terminations have been designed to perform in a wide range of weather conditions. Our terminations meet or exceed industry standards.

When selecting the locations of your horizontal terminations, do not place the termination where water from eaves and adjoining rooflines may create a heavy flow of cascading water onto the termination cap. If the cap must be placed where the possibility of cascading water exists, it is the responsibility of the builder to direct the water away from the termination cap by using gutters or other means.

Take care to carefully follow the installation instructions for the termination, including the use of silicone caulking where required.

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.

HORIZONTAL VENT FIGURES/TABLES

Notes:

•Secure Vent components (rigid vent pipe and terminal) are shown in the Figures; Secure Flex components (flexible vent pipe and terminal) may also be used.

•Two 45 degree elbows may be used in place of one 90 degree elbow. The same rise to run ratios, as shown in the venting Figures for 90 elbows,must be followed if 45 degree elbows are used.

•SV4.5VF (Secure Vent), SF4.5VF (Secure Flex) firestop/spacer must be used anytime vent pipe passes through a combustible floor or ceiling. SV4.5HF (Secure Vent), SF4.5HF (Secure Flex) firestop/spacer must be used anytime vent pipe passes through a combustible wall.

•The tables show a 1(V) to 5(H) ratio up to a maximum horizontal run of 20 feet except for installations where an elbow is the only vertical vent section in the system (see Figure 35).

•AN ELBOW IS ACCEPTABLE AS 1 FOOT OF VERTICAL RISE EXCEPT WHERE AN ELBOW IS THE ONLY VERTICAL COMPONENT IN THE SYSTEM. See Figure 35.

WARNING

Under no circumstances, may separate sections of concentric flexible vent pipe be joined together.

Table F

H Maximum		V Minimum

feet	(meter)	feet	(meter)
3	(0.914)	Elbow Only

Square termination			H
(SV4.5HT-2) shown.			H
(SV4.5HT-2) shown.

	Flex,	Wall
When using Secure	Flex,
use Firestop/Spacer		Firestop/Spacer
SF4.5HF		(SV4.5HF)
		(SV4.5HF)

Venting Components Required for Various Exterior Wall Thicknesses, when using Square Termination Kit (SV4.5HT-2)

	Vent Components Required	Exterior Wall Thickness - inches (mm)

	Termination Kit Only	6 to 9-1/4 (152 to 235)

	Termination Kit and 6 In. Vent	10-3/4 to 14 (273 to 356)
	Section (SV4.5L6)	10-3/4 to 14 (273 to 356)
	Section (SV4.5L6)

	Termination Kit and 12 in.	16-3/4 to 20 (426 to 508)
	Vent Section (SV4.5L12)	16-3/4 to 20 (426 to 508)
	Vent Section (SV4.5L12)
	Termination Kit and Tele-	11-3/4 to 20 (299 to 508)
	scopic Section (SV4.5L12)	11-3/4 to 20 (299 to 508)
	scopic Section (SV4.5L12)

	Table 12	Note: See Figure 33 showing wall thickness range
		when using SV4.5HT-2 termination kit only.

See Table 12 as an aid in venting component selection for a particular range of exterior wall thicknesses.

H = 28 in. (711 mm) Maximum.
When using Secure Flex,	H
use Firestop/Spacer
SF4.5HF

Wall Firestop/Spacer

(SV4.5HF)

See Table 12 as an aid in venting component selection for a particular range of exterior wall thicknesses.

Figure 35 - Top Vent -

ONE 90 DEGREE ELBOW - ELBOW CONNECTION AT APPLIANCE

Table G

H Maximum			V Minimum

feet		(meter)	feet	(meter)

5		(1.524)	1	(0.305)
10		(3.048)	2	(0.610)
15		(4.572)	3	(0.914)

20		(6.096)	4	(1.219)

	V + H = 40 feet (12.2 m) Max.
		H = 20 ft. (6.096 m) Max.

Example: If 20 feet of (H) hori-

zontal vent run is needed, then 4 feet minimum of (V) vertical vent will be required.

This table shows a 1(V) to 5(H) ratio. For every 1 foot of vertical, you are allowed 5 feet of (H) horizontal run up to a maximum (H) horizontal run of 20 feet.

	Square termination	H
	(SV4.5HT-2) shown.	H
	(SV4.5HT-2) shown.
	When using Secure Flex,
	use Firestop/Spacer
	SF4.5VF.
	When using Secure Flex,
	use Firestop/Spacer
	SF4.5HF.

7 in. (178 mm)

Square termination (SV4.5HT-2) shown.

See Table 12 as an aid in venting component selection for a particular range of exterior wall thicknesses.

	Wall Firestop/Spacer
	(SV4.5HF)
	See Table 12 as an aid in venting	Ceiling
	See Table 12 as an aid in venting	Firestop/Spacer
	component selection for a particular	Firestop/Spacer
	component selection for a particular	(SV4.5VF)
	range of exterior wall thicknesses.

Figure 34	- Rear Vent - NO ELBOWS - Square Horizontal		Figure 36 -	Top Vent - ONE 90 DEGREE ELBOW -
Figure 34	- Rear Vent - NO ELBOWS - Square Horizontal		ELBOW CONNECTION NOT DIRECTLY AT APPLIANCE
Termination (SV4.5HT-2)			ELBOW CONNECTION NOT DIRECTLY AT APPLIANCE
Termination (SV4.5HT-2)

				21
		NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.		21

HORIZONTAL VENT FIGURES / TABLES (CONTINUED)

H1 H

When using Secure Flex, use Firestop/Spacer SF4.5VF.

When using Secure Flex, use Firestop/Spacer SF4.5HF.

Wall

Firestop/Spacer (SV4.5HF)

Ceiling

Firestop/Spacer (SV4.5VF)

Square termination (SV4.5HT-2) shown.

Figure 37 - Rear Vent - TWO 90 DEGREE ELBOWS

Wall Firestop/Spacer

(SV4.5HF)

	Note - When using
	Secure Flex, use	Wall Firestop/Spacer
	Firestop/Spacer SF4.5VF.	Wall Firestop/Spacer
	Firestop/Spacer SF4.5VF.
	When using Secure Flex,	(SV4.5HF)
	When using Secure Flex,
	use Firestop/Spacer	Ceiling
	SF4.5HF.	Ceiling
		Firestop/Spacer
		(SV4.5VF)

Square termination (SV4.5HT-2) shown.

See Table 12 on Page 21 as an aid in venting component selection for a particular range of exterior wall thicknesses.

Figure 38 - Top Vent - TWO 90 DEGREE ELBOWS

Table H

H+H1 Maximum		H Maximum		V Minimum
feet	(meter)	feet	(meter)	feet	(meter)

5	(1.524)	2	(0.610)	1	(0.305)

10	(3.048)	4	(1.219)	2	(0.610)
15	(4.572)	6	(1.829)	3	(0.914)

20	(6.096)	8	(2.438)	4	(1.219)

	V + H + H1 = 40 feet (12.2 m) Max
	H = 8 feet (2.438 meters) Max.

H + H1 = 20 feet (6.096 meters) Max.

Example: If 20 feet of (H + H1) horizontal vent run is needed, then 4 feet minimum of (V) vertical vent will be required.

This table shows a 1(V) to 5(H) ratio. For every 1 foot of (V) vertical, you are allowed 5 feet of (H+ H1) horizontal run, up to a maximum horizontal run of 20 feet.

See Table 12 on Page 21 as an aid in venting component selection for a particular range of exterior wall thicknesses.

				Table J
		H + H1 Maximum			V Minimum
		feet		(meter)	feet	(meter)

		3		(0.914)	Elbow Only
		5		(1.524)	1	(0.305)

V		10		(3.048)	2	(0.610)
V
		15		(4.572)	3	(0.914)

		20		(6.096)	4	(1.219)
			V + H + H1 = 40 feet (12.2 m) Max.
				H + H1 = 20 ft. (6.096 m) Max.
	Example: If 20 feet of (H + H1) horizontal vent run is needed,
	then 4 feet minimum of (V) vertical vent will be required.
	This table shows a 1(V) to 5(H) ratio. For every 1 foot of (V)
	vertical, you are allowed 5 feet of (H+ H1) horizontal run, up
	to a maximum horizontal run of 20 feet.

An elbow is acceptable as 1 foot of vertical rise except where an elbow is the only vertical component in the system. See

Figure 35.

22	NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.

HORIZONTAL VENT FIGURES / TABLES (CONTINUED)

Wall Firestop/Spacer

(SV4.5HF)

Square termination (SV4.5HT-2) shown.

When using Secure Flex, use Firestop/Spacer SF4.5VF.

When using Secure Flex, use Firestop/Spacer SF4.5HF.

Ceiling

Firestop/Spacer

(SV4.5VF)

Table K

H + H1 + H2 Maximum		H Maximum		V Minimum
feet	(meter)	feet	(meter)	feet	(meter)

5	(1.524)	2	(0.610)	1	(0.305)

10	(3.048)	4	(1.219)	2	(0.610)
15	(4.572)	6	(1.829)	3	(0.914)

20	(6.096)	8	(2.438)	4	(1.219)

V + H + H1 + H2 = 40 feet (12.2 m) Max

H = 8 feet (2.438 meters) Max.

H + H1+ H2 = 20 feet (6.096 meters) Max.

Example: If 20 feet total (H+H1+H2) horizontal vent run is needed, then 4 feet minimum of (V) vertical vent will be required.

This table shows a 1(V) to 5(H) ratio. For every 1 foot of (V) vertical, you are allowed 5 feet of horizontal run up to a maximum total (H+H1+H2) horizontal run of 20 feet.

See Table 12 on Page 21 as an aid in venting H component selection for a particular range of

exterior wall thicknesses.

Figure 39 - Rear Vent - THREE 90 DEGREE ELBOWS

				Table L
	When using Secure Flex,		H + H1 Maximum		V Minimum
	use Firestop/Spacer		feet	(meter)	feet	(meter)
	SF4.5VF.		feet	(meter)	feet	(meter)
	SF4.5VF.		5	(1.524)	Elbow Only
H1	When using Secure		5	(1.524)	Elbow Only
H1	Flex, use Firestop/Spacer		5	(1.524)	1	(0.305)
	SF4.5HF.		5	(1.524)	1	(0.305)
	SF4.5HF.
	Ceiling		10	(3.048)	2	(0.610)
	Ceiling		15	(4.572)	3	(0.914)
	Firestop/Spacer		15	(4.572)	3	(0.914)
	(SV4.5VF)		20	(6.096)	4	(1.219)
			20	(6.096)	4	(1.219)
			H + H1 = 20 feet (6.096 m) Max.
Wall Firestop/Spacer	H		V + V1+ H + H1 = 40 ft. (12.192 m) Max.
(SV4.5HF)	V1		Example: If 20 feet total (H+H1) horizontal vent
	V1		Example: If 20 feet total (H+H1) horizontal vent
		V	run is needed, then 4 feet minimum of (V) vertical
		V	vent will be required.
See Table 12 on Page			vent will be required.
See Table 12 on Page			This table shows a 1(V) to 5(H) ratio. For every 1
21 as an aid in venting			This table shows a 1(V) to 5(H) ratio. For every 1
21 as an aid in venting			foot of (V) vertical, you are allowed 5 feet of (H+
component selection for			foot of (V) vertical, you are allowed 5 feet of (H+
a particular range of exte-			H1) horizontal run, up to a maximum horizontal
rior wall thicknesses.			run of 20 feet.
			An elbow is acceptable as 1 foot of vertical rise
	Wall Firestop/Spacer		except where an elbow is the only vertical com-
	Wall Firestop/Spacer		ponent in the system. See Figure 35.
	(SV4.5HF)
			Square termination (SV4.5HT-2) shown.
Figure 40 - Top Vent - THREE 90 DEGREE ELBOWS
	NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.					23

Vertical or Horizontal Venting Using Secure Flex Kits and Components

Secure Flex venting kits and components may be used in any venting application in place of rigid Secure Vent (SV4.5) direct vent components. All restrictions, clearances and allowances that pertain to the rigid piping apply to the flexible venting. Secure Flex kits may not be modified; also, under no circumstances may separate sections of flex pipe be joined together.

Using adapter (SV4.5RF), Secure Flex kits may be added to the end of a vent run made up of rigid Secure Vent (SV4.5) vent sections provided that doing so does not violate any of the venting length, height, routing, horizontal to vertical ratio requirements or clearance considerations detailed in this manual.

Secure Flex kits come with an adapter that can be fitted to the inclined channel end of the last Secure Vent (SV4.5) vent section in a rigid system in the exact same fashion as any other

Secure Vent section.

Align the dimpled end of the adapter over the previously installed section or appliance collar, adjusting the radial alignment until the four locking dimples of the adapter are aligned with the inlets of the four incline channels of the last vent section or collar. Push on the adapter until it fully engages, then twist the adapter clockwise running the dimples down and along the incline channels until they seat at the end of the channels.

Attach the flexible vent to the adapter as follows (see also Figure 41):

A.Install the Inner Flex Pipe -

1.Install the small gear clamp loosely around the inner flexible vent pipe, push it back out of the way.

2.Apply a bead of Mill-Pac Black (700° F) high temperature sealant - Catalog No. 10K81 to the inner adapter collar, approximately 1/2 inch from the end.

3.Pull and extend the inner flexible vent pipe.

4.Slide the inner flex pipe over the adapter collar. Ensure the flexible vent pipe completely engages the adapter collar to a distance of 1 3/4 inches from the end, and that it is free from damage or tears.

5. Slide the gear clamp down and tighten it fully to secure the flexible vent to the adapter inner collar approximately 3/4 inch from the end of the flex.

6. Installthreescrews120degreesapartthrough theflexibleventpipeandintotheadaptercollar justbelowthegearclamptoprovideadditional security to the connection.

Note: Outer Pipe Is Pulled Away To Show The Detail of The Inner Pipe

APPLY ONLY MIL-PAC BLACK HIGH TEMPERATURE SEALANT (Cat. No. 10K81) to the outside surface of both collars of the adapter (be especially careful to fill the grooves of the outer collar to be covered by the flexible pipe) and slide flexible pipe over inner and outer adapter collars.

1-3/4 inch (44 mm) Flexible PipeandAdapterOuterCollar Overlap

Adapter (SV4.5RF)

Figure 41

Attach Adapter to Appliance Collar, or Secure Vent Sections

Flex Vent

Securing Screw - 3 Places Equidistant (equally spaced) Just Below Gear Clamp)

Gear Clamps

1 3/4 in. (44 mm) Flexible PipeandAdapterInnerCollar Overlap

Securing Screw

- 3 Places, 120° apart (equally spaced) Just Below Gear Clamp

B.Install the Outer Flex Pipe -

1.Install the large gear clamp loosely around the outer flexible vent pipe, push it back out of the way.

2.Apply a bead of Mill-Pac Black (700° F) high temperature sealant - Catalog No. 10K81) to the outer adapter collar; to the grooves of the collar which extend approximately 1 inch from the end and to the flat surface, approximately 1 3/4 inches from the end.

3.Pull and extend outer flexible vent pipe.

4.Slide the outer flex pipe over the adapter collar. Ensure the flexible vent pipe completely engages the adapter collar to a distance of 1-3/4 inches from the end, and that it is free from damage or tears.

5. Slide the gear clamp down and tighten it fully to secure the flexible vent to the adapter outer collar approximately 3/4 inch from the end of the flex.

6.Install three screws 120 degrees apart through the flexible vent pipe and into the adapter collar just below the gear clamp to provide additional security to the connection.

C.Route Flex Vent -

Ensure that the flex vent is properly routed to provide the required clearance. Do not allow the flexible vent to bend in a radius tighter than 5" (127 mm). Refer to Figure 42. Space out the internal flex vent spacers evenly - approximately every 6 inches - and avoid kinking of inner pipe. Support horizontal sections of flex with metal straps at 2 foot (0.61 m) intervals.

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.

D. Install Firestop / Spacers at ceilings and walls - When Secure Flex penetrates a wall or ceiling, a firestop / spacer is required: use the SF4.5 VF firestop / spacer for ceilings and the SF4.5 HF firestop / spacer for walls. See the appropriate sectionsandFiguresshownthroughouttheventing section for their installation requirements.

Flexible Vent

Section

	5” (127 mm)
	Radius
Figure 42	Minimum
Figure 42

E. Attach Flex Vent to Termination -

Secure Flex components can be purchased separately and attached to bulk lengths of Secure Flex flexible tubing cut to size at the job site. Secure the flexible vent to the Secure Flex terminations in the same manner (see Figure 41) as it was attached to the adapter.

Note: Secure Flex vent must be attached to Secure Flex terminations only. DO NOT substitute Secure Vent terminations or the Secure Vent adapterforSecureFlexcomponents.Thecollars ofSecureFlexterminationsandadaptershavea differentdiameterthanthatusedwiththeSecure Ventpipe. Additionally,SecureFlexcomponents have an extended length center tube for use in attaching the flexible vent.

Factory

Wired

Step 4. Field Wiring

Refer to Section A for millivolt appliances and Section B for electronic appliances. The gas valve is set in place and pre-wired at the factory on both models.

CAUTION

Ensure that wires are positioned away from hot surfaces and sharp edges.

CAUTION

Labelallwirespriortodisconnection when servicing controls. Wiring errors can cause improper and dangerous appliance operation.

CAUTION

Do not connect the optional wall switch for burner operation to a 120 Volt AC power supply.

A. SIT and Honeywell Millivolt Wiring

(See Figure 43) –

1. Select any of the following optional controls: appliance-mounted (rocker switch) or wallmounted switch, wall thermostat, or the standard or deluxe remote control kits. If ap- pliance-mounted ON/OFF control is selected mount it in the gas valve mounting bracket.

2. If wall-mounted ON/OFF control or thermostat is selected mount it in a convenient location on a wall near the fireplace.

3. Wire the control within the millivolt control circuit using the 15 feet of 2 conductor wire supplied with the unit . Caution: do not connect the optional wall switch to a 120V power supply.

4.Alternatively, the appliance may be operated without the use of the controls indicated in Step 1, solely by manipulating the gas valve control knob. In order to use this method, twist the free ends of the two conductor wire (which would otherwise go to the standard ON/OFF switch or Optional Switch) together as shown in Figure 43.

Note: Wire is located inside the control compartment

Note: The supplied 15 feet of 2 conductor wire has one end of each conductor connected to the gas valve circuit and the other end of each conductor placed loose inside the control compartment.

B. Electronic Wiring (See Figure 45) – Note: The electronic appliance must be connected to the main power supply.

The junction box is located on the right side of the appliance. It contains a factory installed and wired outlet box (duplex receptacle). Also, an optional field-provided junction box with receptacle may be installed at the front of the control compartment on either side of the cabinet. See Figure 44. It will be held in place by a conduit fitting and locknut (field-provided).

1.Routea3-wire120Vac60Hz1phpowersupply to the appliance junction box.

2.If the factory-provided outlet/junction box at the right rear of the fireplace is being used, remove the outlet box from the junction box by removing two screws.

TH TP

	Thermopile	TH
*	Thermopile
*
* Twist wires together to operate unit	* Optional	Schematic
solely by manipulating the gas valve	Control Switch	Representation
control knob; or connect wires to		Representation
optional control switch (wall switch,		Only
remote control or wall thermostat to		Field Wired
operate unit.		Field Wired

• If any of the original wire as supplied must be replaced, it must be replaced with Type AWM 105 C - 18 gage wire.

* Optional Kits Installed - ON/OFF wall switch, unit mounted burner ON/OFF switch, wall thermostat or remote control.receiver.

Figure 43 - SIT & HONEYWELL Millivolt Wiring Diagram

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.

3.Connectthepowersupplywires (includingthe ground supply wire) as shown in Figures 44 & 45. (If the field-provided J-box/outlet box is being used, all of the outlet box wiring must be field-provided).

4.Locate and install a low voltage (24V) wallmounted switch or thermostat (both fieldprovided)in the desired location.

5.Connect the low voltage wire, located inside thecontrolcompartment,tothewall-mounted switch or thermostat.

Note: The supplied 15 feet of 2 conductor wire has one end of each conductor connected to the gas valve circuit and the other end of each conductor placed loose inside the control compartment.

6.Insert the control circuit plug into the unswitched receptacle of the outlet box.

7.After wiring is complete, mount the outlet box to the J-Box.

Note: The gas valve-mounted ON/OFF switch is shown in Figure 45. It is integral with the gas valve and should be set to the ON position.

Step 5. Wiring - Optional Forced Air

Blower Kit

FBK-100, FBK-200 and FBK250 Kits

(See Figure 45) -

An electrical outlet box (receptacle) is factory -provided for the installation of the FBK-100, FBK-200 and FBK-250 forced air blower kits. (An optional field-provided outletbox/J-Box may also be used. Electrical power must be connected to either of these receptacles in order to operate these blowers. Install the blower kits according to the installation instructions provided with the kits.

See Figure 14 on Page 11 for Optional Electrical Inlet Knockout Location

*Field-Provided

Junction Box and Duplex Receptacle

*Narrow (2 1/8" Wide) J-Box Required

Optional J-Box/Outlet

Box (Left Side Shown)

Figure 44

	Plug blower		Green
	into this		Green	White		Ground - Green
	into this			White		Ground - Green
	receptacle					Neutral - White
				Black		120 VAC - Black
				Black
Blower						Junction Box
Blower
						* Wall-mounted
	Ground				Tab	ON/ OFF Blower
					Tab	Switch or Variable
	Tab Intact				Broken	Speed Control Switch.
				Red
	Green		Neutral	Hot		J-BOX WIRING FOR
	Green					WALL SWITCH
	Ground
	Ground		Side of	Side of
	Screw		Side of	Side of		BLOWER CONTROL
	Screw		Receptacle	Receptacle		BLOWER CONTROL
View A
J-Box Wiring when			Relay Module C/W FBK-250 only. Plug blower
using unit mounted			Relay Module C/W FBK-250 only. Plug blower
using unit mounted			into J-Box receptacle for FBK-100 or FBK-200
relay module.			into J-Box receptacle for FBK-100 or FBK-200
relay module.			application. See View A for J-Box wiring.
			application. See View A for J-Box wiring.
BK	VAC
W	VAC
W	120
G	120		Optional Blower
Junction Box
			*OFF/ON Switch
Pilot Burner			(Integral with
Assembly			Gas Valve)
			Honeywell
			Electronic
			Gas
			Valve
	Igniter					* Leave the OFF/ON switch, which is
	Connector				GROUND	integral with the gas valve, in the ON
BL				Transformer	GROUND	position.
BL						**Optional Control Switches: Wall
BL BK						Switch, Wall Thermostat or Remote
BL BK			R	BL		Control Receiver.
			R	24 V	120 VAC
		BK		Secondary	120 VAC	Notes:
				Secondary	Primary
					Primary
						1. If any of the original wire as supplied
						must be replaced, use Type AWM 105°C
			BK	BK = BLACK	BL = BLUE	- 18 gage wire ONLY.
Optional Control Switch			BK	BK = BLACK	BL = BLUE	2. 120 VAC, 60 Hz - Less than 3 Amps.
Optional Control Switch				R = RED	W = WHITE	2. 120 VAC, 60 Hz - Less than 3 Amps.
			W	R = RED	W = WHITE	Caution: label all wires prior to
			W	G = GREEN		Caution: label all wires prior to
				G = GREEN		disconnection when servicing controls.
				Field Wired		disconnection when servicing controls.
				Field Wired		Wiring errors can cause improper and
				Factory		dangerous operation.
				Wired

Schematic Representation Only

Electronic Wiring Diagram (Honeywell) Showing Blower Wiring for Optional FBK-100, FBK-200 & FBK-250 Kits

Figure 45

CAUTION

Ground supply lead must be connected to the wire attached to the green ground screw located on the outlet box. See Figure 45. Failure to do so will result in a potential safety hazard. The appliance must be electrically grounded in accordance with local codes or, in the absence of local codes, the National Electrical Code, ANSI/NFPA 70-latest edition. (In Canada, the current CSA C22-1 Canadian Electrical Code).

26	NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.

Gas		Gas Flex Line Connector
		3/8" NPT x	1/2" x 3/8" Flare
Valve
		Flare Fitting
			Shut-off Valve

*Sediment	3"	3/8" Flex Tubing

Trap	Min		1/2" x 3/8"	Gas

3/8" Nipple			Reducer	Stub

3/8" Union

3/8" Close Nipple

3/8" Shut-off Valve

*A Sediment Trap is recommended to prevent moisture and debris in gas line from damaging the valve.

Note:The gas supply line must be installed in accordance with building codes by a qualified installer approved and/or licensed as requed by the locality. In the Commonwealth of Massachusetts, installation must be performed by a licensed plumber or gas fitter.

Figure 46 - GAS CONNECTION

Step 6. Connecting Gas Line

Make gas line connections. All codes require a shut-off valve mounted in the supply line. Figure 46 illustrates two methods for connecting the gas supply. The flex-line method is acceptable in the U.S., however, Canadian requirements vary depending on locality. Installation must be in compliance with local codes.

These appliances are equipped with a gas flex line for use (where permitted) in connecting the appliance to the gas line. A gas flex line is provided to aid in attaching the direct vent appliance to the gas supply. The gas flex line can only be used where local codes permit. See Figure 46 for flex line description. The flex line is rated for both natural gas and propane gas. A manual shut off valve is also provided with the flex line.

The incoming gas line should be piped into the valve compartment and connected (see Figures 46 & 47). The millivolt control valve has a 3/8" (10 mm) NPT thread inlet port. The electronic control valve has a 1/2" (13 mm) NPT thread inlet port and is fitted with a 1/2" x 3/8" (13 mm x 10 mm) NPT fitting.

Secure all joints tightly using appropriate tools and sealing compounds (ensure propane resistant compounds are used in propane applications).

Optional: Seal around the gas line to prevent cold air leakage.

TEST ALL CONNECTIONS FOR GAS LEAKS (FACTORY AND FIELD):

WARNING

Never use an open flame to check for leaks.

Turn on gas supply and test for gas leaks using a gas leak test solution (also referred to as bubble leaksolution). Note:Usingasoapywatersolution (50% dish soap, 50% water) is an effective leak test solution but it is not recommended, because the soap residue that is left on the pipes/fittings can result in corrosion over time.

A.Light the appliance (refer to the lighting instructions label in control compartment or homeowner's manual).

B.Brush all joints and connections with the gas leak test solution to check for leaks. If bubbles are formed, or gas odor is detected, turn the gas control knob (off/pilot/on) to the “OFF” position. Either tighten or refasten the leaking connection, then retest as described above.

C.When the gas lines are tested and leak free be sure to rinse off the leak testing solution,

D.Turn on burner then observe the individual tongues of flame on the burner. Make sure all ports are open and producing flame evenly across the burner. If any ports are blocked, or partially blocked, clean out the ports.

CONTROL COMPARTMENT ACCESS/ LOUVER PANEL INSTRUCTIONS

(Ref. Figure 47)

NOTE: The top louvered panel and the bottom louvered control panel door remove and install the same way as follows:

The gas controls can be found behind the control compartment access door.

Removing Control Compartment Door:

Open the door by gently lifting it upward until the hook catches on boths sides clear the locating slots. Then pull door out to remove.

On millivolt systems, the piezo igniter, HI/LO flame adjustment knob, and pilot and main gas OFF/ON control knob are located below the glass panel enclosure. The gas valve for electronic systems is also located below the glass enclosure panel. See Figure 47.

Reinstalling Control Compartment Door:

To reinstall, insert the hook catches on each side of the door into the corresponding slots in the control compartment opening, then gently push forward and slide down until it locks in place.

	Lift the Lower Control
	Compartment Door
OPENING CONTROL	up and pull out to
COMPARTMENT DOOR	remove.

Hook Catch

Control Valve	Out
	Out
	Up
	Lower Control
	Compartment Door
Figure 47

Step 7. Checking Appliance Operation

With the gas line installed, run initial system checkout before closing up the front of the appliance. Follow the pilot lighting instructions provided in the Homeowner's Care and Operation Instructions. For piezo igniter location see Figure 48 (millivolt appliances only).

Note: The (pull-out) Lighting instructions label can be found in the control compartment (see Figure 47).

When first lighting the appliance, it will take a few minutes for the line to purge itself of air. Once purging is complete, the pilot and burner will light and operate as indicated in the instruction manual. Subsequent lightings of the appliance will not require such purging. Inspect the pilot flame.

SIT and Honeywell Millivolt Appliance Checkout

The pilot flame should be steady, not lifting or floating. Flame should be blue in color with traces of orange at the outer edge.

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.

The top 3/8" (10 mm) at the pilot generator (thermopile) and the top 1/8" min (tip) of the quickdropoutthermocoupleshouldbeengulfed in the pilot flame. The flame should project 1" (25 mm) beyond the hood at all three ports (Figure 49 - SIT, Figure 50 - Honeywell).

To light the burner; rotate the gas valve control knob counterclockwise to the “ON” position then turn “ON” the OFF/ON switch (installed at Step 4).

Observe the individual tongues of flame on the burner. Make sure all ports are open and producing flame evenly across the burner. If any ports are blocked, or partially blocked, clean out the ports.

SIT Gas Valve

Honeywell

Gas Valve

Piezo

Igniter

Sit and Honeywell Millivolt Gas Valve Showing Piezo Igniter Location (Each Unit is Equipped with Only One of these Gas Valves)

Figure 48

SIT MILLIVOLT PILOT ASSEMBLY
Proper Pilot Flame Appearance
Hood	Igniter Rod
Thermocouple	3/8" Min.
	3/8" Min.
	(9 mm)
Pilot
Nozzels
Thermopile
Figure 49

Replace logs if removed for pilot inspection.

To light the burner; turn “ON” the remote wall switch and rotate the gas valve control knob counterclockwise to the “ON” position.

HONEYWELL MILLIVOLT PILOT ASSEMBLY

Proper Pilot Flame Appearance

	Thermocouple
1/8" Min.	Igniter Rod
(3 mm)	Hood

3/8" Min.

(9 mm)

Pilot

Nozzels

Thermopile

Figure 50

Electronic Appliance Checkout

To light the burner, turn ‘ON’ the optional remote wall switch and turn the gas control switch to the “ON” position. Ensure the Igniter lights the pilot. The pilot flame should engulf the flame rod as shown in Figure 51.

ELECTRONIC PILOT ASSEMBLY
Proper Pilot Flame Appearance
Proper Flame	3/8" to 1/2"
Adjustment	(9 -13 mm)
Pilot
Nozzels
	Hot Surface
	Igniter
Figure 51

INSTALL Logs, VOLCANIC STONE and

GLOWING EMBERS

Carefully position the ceramic fiber logs and twigs over the burner according to the following steps, while referring to Figure 52.

1.Set the rear log on the raised log support brackets at the rear of the firebox, fitting the slots in the log over the brackets.

2.Position the front log with the pins for the two side twigs in the up position, and the two vertical burner tabs recessed into the two notches at the rear of the log. Check for recessing of brackets into log notches (by touch) to verify correct log placement.

3.Insert the alignment hole of the left twig over the front log's left pin. Rotate the left twig until it just touches the edge of the ember bracket.

4.Insert the alignment hole of the right twig over the front log's right pin. Rotate the right twig until it almost touches the front panel glass.

Note: Proper twig placement is critical in the gaps between the flame peaks and should be positioned so that at no time they impinge the flames.

Glowing Ember/Volcanic Stone Placement

Remove the replacement rockwool (Glowing Embers) from the packaging and tear into quarter size pieces (see Figure 53 ).

Spread rockwool (quarter-sized pieces) on and along the length of the burner screen. Do not use more than is necessary. To many quartersized pieces on the front burner section will cause poor combustion.

When properly positioned, the rockwool will unevenly cover approximately 85% of the burner screen, with no appreciable gaps or openings.

To install Decorative Volcanic Stone, mound up a portion of the volcanic stone in front of the burner in a pattern to suite individual taste.

Figure 52 - Log Set (Shown With Optional Log Rack)

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.

WARNING

Logs get very hot and will remain hot up to one hour after gas supply is turned off. Handle only when logs are cool. Turn off all electricity to the appliance before you install grate and logs.

WARNING

DONOTattempttoinstallthelogs until the appliance installation has been completed, the gas line connected and tested for leaks and the initial burner operation has been checked out.

WARNING

The size and position of the log set was engineered to give the appliance a safe, reliable and attractive flame pattern. Any attempt to use a different log set in the fireplace will void the warranty and will result in incomplete combustion, sooting, and poor flame quality.

WARNING

This appliance is not designed to burn wood. Any attempt to do so could cause irreparable damage to appliance and prove hazardous to your safety.

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.

Separate into Quarter

Size (separate) Pieces

Bag of Glowing

Embers (rockwool)

Figure 53 - Glowing Embers

REFERENCE

Firebox Accessories / Parts

Cat. No.	Model No.	Description

88L53	FGE	Bag of Glowing Embers
		(1 oz. rockwool)

80L42	FDVS	Bag of Decorative
80L42	FDVS	Volcanic Stone
		Volcanic Stone

Table 13

Step 9. Installing the Glass Door

WARNING

Donotoperateappliancewiththe glass front removed, cracked or broken. Replacementoftheglass should be done by a licensed or qualified service technician.

WARNING

Do not attempt to substitute the materials used on this door, or replace cracked or broken glass with any materials other than those provided by the appliance manufacturer.

WARNING

Handle this glass with extreme care! Tempered glass is susceptible to damage – do not scratch or handle roughly while rein-

stalling the glass door frame.

WARNING

The glass door of this appliance must only be replaced as a complete unit as provided by themanufacturer. Donotattempt to replace broken, cracked or chipped glass separately.

WARNING

Do not attempt to touch the front enclosure glass with your hands while the fireplace is in use.

Removing Glass Enclosure Panels

(see Figure 54)

1.Remove the top louver assembly by lifting it up and pulling it out.

2.Remove the control compartment access door (see removal instructions on Page 27 - Removing Control Compartment Door).

3.Locate the two (2) latches at the top of the control compartment. To disengage the two latches from the bottom vee-flange of the glass enclosure panel, reach for the handles located towards the back of the latches and pull the handles down toward the front of the appliance.

4.Swing the bottom of the door out and raise it slightly to lift the top flange of the door frame away from the appliance.

Installing Glass Enclosure Panels

(see Figure 54)

1.Visuallyinspectthegasketonthebacksideofthe glass panel. The gasket surface must be clean, free of irregularities and seated firmly.

2.Position the glass enclosure panel in front of the firebox opening at a 45 degree angle and engage the top flange over the lip at the top of the firebox opening. See Figure 54.

3.Swing the glass enclosure panel down and back. Ensure the gasket seats evenly as the panel draws shut. Engage the Vee-flange at the bottom of the panel with the latches and close the latches to secure the panel.

4.Reinstall top louver assembly and control compartment door see installation instructions on Page 27 , Reinstalling Control Compartment Door).

	Top Flange on
	Glass Door
	Glass Door
Bottom Vee-flange
Glass Door	Firebox Floor
	Glass Door Latch
Figure 54 - INSTALLING GLASS DOOR

Step 10. Burner Adjustments

Flame Appearance and sooting

Proper flame appearance is a flame which is blue at the base and becomes yellowish-orange in the body of the flame. When the appliance is first lit, the entire flame may be blue and will gradually turn yellowish-orange during the first 15 minutes of operation. If after a short period the flame stays lowered blue, or if the flame is orange with evidence of sooting (black tip), the air shutter opening may need to be adjusted.

If the air shutter openings closed too far, sooting may develop. Sooting is indicated by black puffs developing at the tips of very long orange flames. Sooting results in black deposits forming on the logs, appliance inside surfaces and on exterior surfaces adjacent to the vent termination. Sooting is caused by incomplete combustion in the flames and lack of combustion air entering the air shutter opening. To achieve a warm yellow- ish-orange flame with an orange body that does not soot, the shutter opening must be adjusted between these two extremes.

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.

Air Shutter Adjustment Guidelines

•If there is smoke or soot present, first check the log set positioning to ensure that the flames are not impinging on any of the logs. If the log set is properly positioned and a sooting condition still exists, then the air shutter opening should be increased.

•Themoreoffsetsintheventsystem,thelarger the air shutter opening will need to be.

•An appliance operated with the air shutter opened too far, may have flames that appear blue and transparent. These weak, blue and transparent flames are termed anemic.

•Propane models may exhibit flames which candle or appear stringy. If this is present

and persists, adjust the air shutter to a more closed position, then operate the appliance for a few more minutes to ensure that the flame normalizes and the flames do not appear sooty.

The following chart is provided to aid you in achieving the correct air shutter adjustment for your installation.

Air Shutter Adjustment Guidelines:

Amount of	Flame	Air Shutter
Primary Air	Color	Adjustment
If air shutter is	Flame will	Air shutter
closed too far	be orange	gap should be
		increased

If air shutter is	Flame will	Air shutter
open too far	be blue	gap should be
		decreased

WARNING

Airshutteradjustmentshouldonly beperformedbyaqualifiedprofessional service technician.

WARNING

Ensure front glass panels are in place and sealed during adjustment.

CAUTION

Carbon will be produced if the air shutter is closed too much. Any damage due to carboning resulting from improperly setting the air shutter is not covered under the warranty.

Burner Air Shutter Adjustment Procedure

CAUTION

Theairshutterdoorandnearbyappliancesurfacesare hot. Exercise caution to avoid injury while adjusting flame appearance.

Burner Air Shutter Adjustment Procedure

1. Locate adjustment rod and adjust air shutter to the standard setting as shown in Figure 56 (adjustment rod is located in the lower control compartment).

Note: Move the adjustment rod down to decreases air and up to increases.

2.Light appliance (follow lighting procedure on lighting label in control compartment or see Care and Operations manual).

3.Allow the burner to operate for at least 15 minutes while observing the flame continuously to ensure that the proper flame appearance has been achieved (see Figure 55). If the following conditions are present, adjust accordingly.

•If flame appears weak or sooty, adjust air shutter, incrementally, to a more open position until the proper flame appearance is achieved.

•Ifflamestaysloweredblue,adjust airshutter,incrementally,toamore closed position until the proper flame appearance is achieved.

4.Leave the control knob (off/pilot/on) in the ON position and the burner OFF/ON switch OFF (& remote switches, if applicable).

5.When satisfied that the burner flame appearance is normal, re-install the lower control compartment door then proceed to finish the installation.

Burner Flame Appearance Models -

SSDV-3328 Series

Figure 55

Burner Air Shutter Adjustment
	Adjustment Setscrew
	Adjustment Rod Up
	(Fully Open Position)
Burner Tube
Air Shutter
Adjustment Rod Down	Ref. Air shutter Patent:
Adjustment Rod Down	U.S. Pat. 5,553,603
(minimum air opening	U.S. Pat. 5,553,603
(minimum air opening
position)
	Main Burner Factory Air Shutter
	Opening Setting - Inches (millimeter)
	Model	Natural	Propane
		Gas	Gas
	SSDVT-3328	1/32	5/16
Figure 56	SSDVR-3328	(0.826 mm)	(7.94 mm)

Step 11. Hood Installation

(Refer to Figure 57)

All of these appliances must have hoods installed prior to operating.

Slide the hood into the slots on the lower edge of the cabinet top.

Finishing Requirements - Wall Details

Complete finished interior wall. To install the appliance facing flush with the finished wall, position framework to accommodate the thick-

ness of the finished wall (Figure 57).

See Page 6 for Cold Climate Insulation and Page 9 for Clearances

	This Area Must	3"
	Remain Clear of	3"
	Remain Clear of	(76 mm)
	Combustible	(76 mm)
	Materials
Combustible Finished	1 in. Min.
Wall Materials	1 in. Min.
	(25 mm)
	Top Spacers

Drywall Bracket / Spacer

Combustible material may touch the appliance top

Top of Appliance Louvers

Top of Door Frame Hood must be installed as shown.

Figure 57 - Combustible Wall Framing

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.

Installation Accessories

Item	Cat. No.	Model	Description

1	H1968	SV4.5HT-2	Horizontal Square Termination With Firestop/spacer
			(H2246) & Adapter (74L61)
2a	H2152	SV4.5CGV-1	Vertical Termination Cap
2b	H4687	SV4.5CTS	Chase Top Termination Square

2b	H4716	SV4.5CTS-B	Chase Top Termination Square, Black

2b	H4717	SV4.5CTS-TC	Chase Top Termination Square, Terra Cotta

3	77L70	SV4.5L6	6 Inch (152 mm) Vent Section
3	77L71	SV4.5L12	12 Inch (305 mm) Vent Section

3	77L72	SV4.5L24	24 Inch (610 mm) Vent Section

3	77L73	SV4.5L36	36 Inch (914 mm) Vent Section

3	77L74	SV4.5L48	48 Inch (1219 mm) Vent Section
3	77L75	SV4.5LA	Telescopic Section (1-1/2" to 7-1/2" effective length)

4	77L76	SV4.5E45	45 Degree Elbow

5	77L77	SV4.5E90	90 Degree Elbow

The following flashings come packaged with a storm collar:

6	77L78	SV4.5F	Flat Roof Flashing

6	77L79	SV4.5FA	1/2 to 7/12 Adjustable Flashing

6	77L80	SV4.5FB	7/2 to 12/12 Adjustable Flashing

7	77L81	SV4.5SC6	Storm Collar (6 per box)
8	H2246	SV4.5HF	Firestop / Spacer-Horizontal (3-1-1 spacing), 10 Pack

8	H2247	SV4.5VF	Firestop / Spacer-Vertical (1-1-1 spacing), 10 Pack

9	96K93	SV4.5SU	Support Strap

10	96K94	SV4.5RSA	Attic Insulation Shield
11	96K92	SV4.5SP	Support Plate

12	17M52	SV4.5HGS-1	Termination Guard, Square (1 pack)
			(for square termination)
12	17M53	SV4.5HGS-12	Termination Guard, Square (12 pack)
			(for square termination)
13	H5820	4.5HTSK	Termination Shroud (Guard) for Horizontal Square
			Termination (1 pack)

9	10	8	11
2a		2b

32	NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.

1
3
4	5
6
7
12
13

Installation Accessories

Item

Cat. No.

Model

Description

H1969

SF4.5HT-2

Horizontal Square Termination (without flex)

77L87

SFKIT12S

FlexSquareTerm.(with12inch[305mm]*compressedflex)

77L88

SFKIT18S

FlexSquareTerm.(with18inch[457mm]*compressedflex)

77L89

SFKIT24S

FlexSquareTerm.(with24inch[610mm]*compressedflex)

77L90

SFKIT36S

FlexSquareTerm.(with36inch[914mm]*compressedflex)

77L91

SFKIT48S

FlexSquareTerm.(with48inch[1219mm]*compressedflex)

56L74

SFVT30

Vertical Termination for flex (flat to 6/12) with flex adapter, section of rigid vent,

roof support collar assembly, roof flashing and storm collar.

56L75

SFVT45

Vertical Termination for flex (6/12 to 12/12) with flex adapter, section of rigid

vent, roof support collar assembly, roof flashing and storm collar.

*20

60L10

SF-18

18 ft. (5.49 m) * compressed flex

*20

98K03

SF-12

12 ft. (3.66 m) * compressed flex

10K81

SFMP

Mill-Pac, Black, High Temperature Sealant

89L40

SFMP-12

Mill-Pac, Black, High Temperature Sealant - Bulk 12 pack

91L66

SF-GC4-6

Gear Clamp 4.5 in. (114 mm) for flex (6 pieces)

91L67

SF-GC7-6

Gear Clamp 7.5 in. (190.5 mm) for flex (6 pieces)

99L02

SV4.5HRK14

Horizontal Riser Kit, 14"

99L03

SV4.5HRK36

Horizontal Riser Kit, 36"

H1988

CTSA-33

Chase Top Shroud Kit, Arch Top 3 X 3

H1985

CTSO-33

Chase Top Shroud Kit, Open Top 3 X 3

H1987

CTSO-44

Chase Top Shroud Kit, Open Top 4 X 4

H1986

CTSO-46

Chase Top Shroud Kit, Open Top 4 X 6

H2248

SF4.5HF

Firestop / Spacer - Horizontal (flex) (3-1-1 spacing), 10 Pack

H2249

SF4.5VF

Firestop / Spacer - Vertical (1-1-1 spacing), 10 Pack

CTSO-46 Shroud

typ.

All compressed flex vents can be

for double

terminations

expanded up to two times.

1 typ.

Closed Top Shroud Termination Kits

2 typ.

Inches (millimeters)

Model

CTSA-33

34"

(864)

(127)

(864)

CTSO-33/44 Shrouds

for Single terminations

Open Top Shroud Kits

Inches (millimeters)

Model

CTSO-33

37-5/8

7-1/2

24-1/2

(955)

(191)

(622)

(76)

Sea

CTSO-44

48-5/8

7-1/2

24-1/2

(1235)

(191)

(622)

(76)

CTSO-46

48-5/8

73 1/4

7-1/2

24-1/2

(1235)

(1860)

(191)

(622)

(76)

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.

INSTALLATION ACCESSORIES

Listed Secure Flex™ Components

Cat. No.	Model	Description

94L04	SFKIT12SS	Flex - Small Square Termination with 12 in.
		(305 mm) of *compressed flex vent
94L05	SFKIT18SS	Flex - Small Square Termination with 18 in.
		(457 mm) of *compressed flex vent
94L06	SFKIT24SS	Flex - Small Square Termination with 24 in.
		(610 mm) of *compressed flex vent
94L07	SFKIT36SS	Flex - Small Square Termination with 36 in.
		(914 mm) of *compressed flex vent
94L08	SFKIT48SS	Flex - Small Square Termination with 48 in.
		(1219 mm) of *compressed flex vent
94L09	SF-HTSS	Horizontal Small Square Termination
		without flex vent
	Listed Secure Vent™ Components

94L10	SV4.5HTSS	Horizontal - Small Square Termination with
		Firestop/Spacer (H2246) & Adapter (74L61).
H5817	SV4.520SSWSK	Small Square 20" Termination

* All compressed flex vents can be expanded up to two times.

Gas Conversion Kits

Millivolt SIT Systems

Natural Gas To Propane Gas

Conversion Kits

Models	Cat. No.

SSDVT/R-3328	H1594

Millivolt SIT Systems

Propane to Natural Gas

Conversion Kits

Models	Cat. No.
SSDVT/R-3328	H1595

Millivolt HONEYWELL Systems

Natural Gas To Propane Gas

Conversion Kits

Models	Cat. No.
SSDVT/R-3328	26M51

Millivolt HONEYWELL Systems

Propane Gas To Natural Gas

Conversion Kits

Models	Cat. No.

SSDVT/R-3328	26M55

Electronic HONEYWELL Systems

Natural Gas To Propane Gas

Conversion Kits

Models	Cat. No.

SSDVT/R-3328	99L90

Electronic HONEYWELL Systems

Propane Gas To Natural Gas

Conversion Kits

Models	Cat. No.

SSDVT/R-3328	99L91

34	NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.

WARNING

This conversion kit shall be installed by a qualified service agency in accordance with the manufacturer's instructions and all applicable codes and requirements of the authorized havingjurisdiction. Iftheinformation in these instructions is not followed exactly, a fire, explosion or production of carbon monoxide may result causing property damage, personal injury or loss of life. The installation is not proper and complete until the operation of the converted appliance is checked as specified in the owner instructions suppliedwith the kit. The qualified service agency performing thisinstallationassumesresponsibility for this conversion.

AVERTISSEMENT

Cet équipement de conversion sera installé par une agence qualifiée de service conformément aux instructions du fabricant et toutes exigences et codes applicables de l'autorisés avoir la juridiction. Si l'information danscetteinstructionn'estpassuivie exactement,unfeu,explosionouproductiondeprotoxydedecarbonepeut résulter le dommages causer de propriété, perte ou blessure personnelle de vie. L'agence qualifiée de service estesponsabledel'installationpropre de cet équipment. L'installation n'est pas propre et compléte jusqu'à l'opération de l'appareil converti est chéque suivant les critères établis dans les instructions de propriétaire provisionnées avec l'équipement.

IMPORTANT/CANADA

The conversion shall be carried out in accordance with the requirements of the provincial authorities having jurisdiction and in accordance with therequirementsoftheCAN1-B149.1 And B149.2 Installation code.

IMPORTANT

LE CANADA SEULEMENT

La conversion devra être effectuée conformément aux recommandations des autorités provinciales ayant juridiction et conformément auxexigencesducoded'installation CAN1-B149.1 ET.2.

Gas conversion kits are available to adapt the appliance from the use of one type of gas to the use of another. These kits contain all the necessary components needed to complete the task including labeling that must be affixed to ensure safe operation.

Kit part numbers are listed here and the following steps detail the conversion procedure.

Step 1. Turn off the gas supply to the appliance. Remove the front glass door/frame from the appliance. Access the control compartment.

Step 2. Carefully remove the logs. Exercise care so as not to break the logs.

Step 3. Locate the screws securing the burner assembly to the appliance. Remove the burner assembly and retain the securing screws.

Step 4. Millivolt Appliances - SIT Systems

a. See Figure 58 and the instructions provided with the kit. Using a Torx T20, tool or or standard flat screwdriver remove and discard the three pressure regulator mounting screws. Remove the pressure regulator, spring, poppet, diaphragm and bushing. Discard all removed components. Ensure the rubber gasket installed on the back of the replacement pressure regulator is properly positioned and install the new pressure regulator using the new screws supplied with the kit. Tighten screws to 25 In. lb. torque.

SIT Millivolt Gas Valve

Pressure

Regulator

Remove

These

Components

Figure 58

Pilot for SIT Millivolt Gas Valve

Pilot

Orifice

Figure 59

b.Attach manometer to the manifold side pressure test fitting and verify manifold pressure reads 3.5 inches water column (0.87 kPa) for natural gas, and 10.0 inches water column (2.49 kPa) for propane gas.

c.Refer to Figure 59 and remove the pilot hoodassemblytoaccessthehexedpilotorifice. Remove and replace the orifice with the one provided with the kit.

Step 5. Millivolt Appliances

Honeywell Systems -

a. Convert the gas valve as follows

(seeFigure60):Removetheplasticprotecting cap. Remove the gas type setting screw by turningitcounterclockwise. Obtainthereplacement gas type setting screw from the kit and screw it into place (red for propane and blue for natural gas). Tighten the gas type setting screw by turning it clockwise. Replace the plastic protecting cap.

Honeywell Millivolt Gas Valve

Adjusting Knob

Regulator Cap

Conversion screw

(blue natural gas;

red LP/propane gas)

Figure 60

c.Convert the pilot orifice as follows (see

Figures 61 & 62):

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.

Note - Use extra care not to engage the orifice strip with the 7/16" open end wrench (contactingtheorificestripcouldcausestrip distortion rendering the pilot inoperative). Also avoid wrench contact to any of the other pilot parts.

Use a 7/16" open end wrench and turn the pilot hex fitting counter-clockwise 1/4 turn. (See Figure 62 ).

Note - The orifice strip tab may be randomly located on any side of the hex fitting.

d.Push the orifice strip tab all the way against the hex fitting to align the appropriate gas type orifice (see Figures 61 & 62 ). The type of gas for which the pilot is set, is, the gas type shown on the tab.

e.Retighten, clockwise, the pilot hex fitting until the pilot hood aligns with the thermocouple and thermopile as indicated by the arrows shown in Figure 62.

Pilot for Honeywell Millivolt Gas Valve

Orifice Strip Tab Position Identification

For LP (propane gas) and Natural Gas

P	L			LP (propane) Gas Posi-
				LP (propane) Gas Posi-
				tion - 1/16 inch hole,
				tion - 1/16 inch hole,
				LP and red color shown
				on tab.
				Natural Gas Position
		NA	T	- NAT shown on tab.
			T

Top View of Hex Fiting and Orifice Strip Tab

Figure 61

Pilot for Honeywell Millivolt Gas Valve (Loosening of Hex Fitting For Orifice Strip Tab Positioning)

	Hood	Hood
	Hood	Alignment
		Alignment

7/16 in. Open End Wrench

Orifice

Strip Tab

Take care not to contact the orifice strip tab with the hex fitting wrench - distortion of the tab may render the pilot inoperative.

Figure 62

Step 6. Electronic Appliances -

Honeywell Systems

See Figure 63 and the instructions provided with the kit. Remove the slotted cap screw, o-ring, pressure-regulating adjusting screw and spring. Retain all parts for possible later use. Install new components from the kit. Black cap and red spring for propane gas units. Silver cap and stainless steel spring for natural gas units. Before installing the cap, attach manometer to the manifold side pressure test fitting and adjust screw until pressure reads 3.5 inches water column (0.87 kPa) for natural gas, and 10.0 inches water column (2.49 kPa) for propane gas.

OFF ON CONTROL	Inlet Pressure Test Port
	I
ETINGI
	ISP
Manifold
Pressure
Test Port
Slotted
Cap
	Spring
	Adjusting
	Screw
Figure 63

See Figure 64 and replace the pilot orifice as follows: Remove the Igniter assembly retainer clip, and carefully remove the Igniter assembly.

Exercise extreme care to prevent damage to or breakage of the Igniter assembly. Remove the screwsecuringthepilotassemblytoitsmounting bracket. Back off the flare nut at the end of the pilot gas line to free the pilot assembly from the gas line. Remove the pilot orifice and replace it with the one provided with the conversion kit. Reinstall the pilot assembly by reversing the steps detailed here.

When reinstalling the Igniter assembly, use extreme care to prevent damage and breakage. Do not apply any leverage to the Igniter assembly while restoring the retainer clip to its original position.

All Models

Step 7. Remove the burner orifice from the manifold and replace it with the one provided with the kit. See Table 14 for orifice sizes required for use with natural gas or propane gas. Figure 65

illustrated the orifice.

Pilot

Assembly

Pilot

Orifice

Ignitor

Assembly

	Retaining
Flare Nut	Clip

Note: If the Igniter is damaged, a replacement kit is available - order Catalog Number 87L54.

Figure 64

Burner Orifice Sizes Elevation 0-4500 feet ( 0-1372 meters)

Model	Natural	Propane
Series	Gas	Gas

SSDV-3328T/R	#45	0.048
SSDV-3328T/R	#45	inch
		inch

* Standard size installed at factory
• Part /Cat. Number

Table 14

Figure 65

Step 9. Reassemble all removed components by reversing the procedures outlined in the preceding steps. Use pipe joint compound or Teflon tape on all pipe fittings before installing (ensure propane resistant compounds are used in propane applications, do not use pipe joint compounds on flare fittings).

Step 10. Attach the conversion label provided in the conversion kit to the rating plate on the appliance.

Step 11.Turn on gas supply and test for gas leaks.

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.

Lennox Hearth Products reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products. Consult your local distributor for fireplace code information.

	Printed in U.S.A. © 2007 by LHP
36	P/N 700,043M REV. A 06/2008	NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
36		NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.

LHP

1110 West Taft Avenue • Orange, CA 92865
