Sprint Worldwide Services Guide

HTC Touch Pro2

www.sprint.com

© 2009 Sprint. Sprint and the logo are trademarks of Sprint. Other marks are the property of their respective owners.

Table of Contents

Sprint Worldwide Wireless Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Your SIM Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2

Using Your Device in GSM Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5

Using Your SIM Card’s PhoneBook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

11

Setting GSM Services Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

15

Contacting Sprint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

17

Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

19

Selecting a Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

20

Sprint Worldwide Wireless Service

YourSIMCard(page2)

UsingYourDeviceinGSMMode(page5)

UsingYourSIMCard’sPhoneBook(page11)

SettingGSMServicesOptions(page15)

ContactingSprint(page17)

Services(page19)

SelectingaNetwork(page20)

YourdeviceallowsyoutoroamthroughouttheworldusingbothCDMA(CodeDivisionMultipleAccess) andGSM(GlobalSystemforMobileCommunications)networks.For a complete list of countries and features available, visit www.sprint.com/sww.

Note To use Sprint international roaming services, you must be a current Sprint subscriber. You must also meet international toll authorization and credit requirements to roam in most places outside of the United States. Depending on your overseas location and coverage, you may not have access to all features. Service may be interrupted if you change phones or phone numbers before traveling abroad.

Sprint Worldwide

Wireless Service





Sprint Worldwide Wireless Service

1

Your SIM Card

Your device comes with a preinstalled SIM (Subscriber Identity Module) card to support roaming on compatible GSM networks. The SIM card must be activated for international wireless service prior to its initial use (outside of the United States).

ToactivateSprintWorldwideservice:

Visit www.sprint.com/international.

Click Chatwithus to talk online with a Sprint representative

– or –

Click Emailus to send an email to a Sprint representative

– or –

Call 1-888-226-7212,option2, to speak to a Sprint representative.

For more help with Sprint Worldwide international setup, tap Start>AllPrograms , scroll down the All Programs screen, and then tap InternationalUsage to display a brief set of onscreen GSM setup instructions.

Note Your SIM card should be preinstalled. If you need to reinstall your SIM card, see “Removing Your SIM Card” on page 3. The SIM card included with your device contains information specific to your device and should be retained with the device for use on GSM networks.

2Sprint Worldwide Wireless Service

Removing Your SIM Card

The SIM card comes preinstalled but can be removed if necessary.

1.Remove the back cover.

Remove the stylus. (You need to temporarily remove the stylus to be able to remove the back cover.)

Hold the device with both hands and the front panel facing down.

Push the back cover up with your thumb until it disengages from the device and then slide it up to remove.

Sprint Worldwide

Wireless Service













Sprint Worldwide Wireless Service

3

2.Remove the battery if it is installed. To remove, lift out the battery from the groove at the upper right side of the battery compartment.

Groove

3.To remove the SIM card, first insert the tip of the stylus into the small hole above the SIM card slot, and then push the SIM card out with the stylus. Slide the SIM card out from the slot with your thumb or finger.

4.Press the Power button to turn the device on.

Your device will turn on, search for Sprint service, and then enter standby mode.

If your device is not yet activated, see the “Activating Your Device” section of the HTC Touch Pro2 User Guide for more information.

By default, your device is set to Global mode. If there is no SIM card on your device, your

device will display a message to inform you

Removing the SIM Card

that it will switch to CDMA mode.



Note Your device’s battery should have enough charge to turn on, find a signal, set up your voicemail, and make a call. You should fully charge your battery as soon as possible. See the “Charging the Battery” section of the HTC Touch Pro2 User Guide for details.

4Sprint Worldwide Wireless Service
