Teac W-600R User Manual

3D0025600B

W-600R

Stereo Double Cassette Deck

OWNER’S MANUAL

MANUEL DU PROPRIETAIRE

Thanks for buying a TEAC. Read this manual carefully to get the best performance from this unit.

Nous vous remercions pour l’achat d’un appareil TEAC. Lire ce manuel avec attention pour obtenir les
meilleures performances possibles de cet appareil.

ENGLISH FRANÇAIS

2

Lire ceci avant de faire fonctionner l'appareil

<

Choisir avec soin l'endroit où vous placerez votre appareil.
Eviter de le placer directement au soleil ou près d'une source
de chaleur. Eviter aussi les endroits sujets à des vibrations, à
de la poussière excessive, à la chaleur, au froid ou à l'humidité.
Toujours le garder éloigné de sources de bourdonnements
telles que des transformateurs ou moteurs.

<

Ne pas ouvrir le coffret car ceci risquerait de provoquer des
dommages aux circuits ou des chocs électriques. Si un objet
rentre dans l'appareil, contacter votre revendeur.

<

Lors du débranchement du cordon d'alimentation de la prise
murale, toujours tirer sur la fiche et non sur le cordon.

<

Ne pas essayer de nettoyer l'appareil avec des solvants
chimiques car ceci pourrait endommager le fini de l'appareil.
Utiliser un chiffon propre et sec.

<

Garder soigneusement ce manuel d'instructions pour une
référence ultérieure.

Read this before operation

<

Choose unit installation location carefully. Avoid placing it in
direct sunlight or close to a source of heat. Also avoid locations
subject to vibrations and excessive dust, heat, cold or moisture.
Keep away from sources that hum, such as transformers or
motors.

<

Do not open the cabinet as this might result in damage to the
circuitry or electrical shock. If a foreign object should get into
the set, contact your dealer.

<

When removing the power plug from the wall outlet, always pull
directly on the plug, never yank the cord.

<

Do not attempt to clean the unit with chemical solvents as this
might damage the finish. Use a clean, dry cloth.

<

Keep this manual in a safe place for future reference.

CAUTION

< DO NOT REMOVE THE PROTECTIVE HOUSING USING

SCREWDRIVER.

<

USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF
PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY
RESULT IN HAZARDOUS RADIATION EXPOSURE.

<

IF THIS PRODUCT DEVELOPS TROUBLE, MAKE A CONTACT
WITH OUR SERVICEMAN, AND DO NOT USE THE PRODUCT IN
A TROUBLED STATE.

AC POWER CORD CONNECTION
CAUTION:

TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG
TO WIDE SLOT, FULLY INSERT.

For CANADA

CORDE DE CONNEXION CA
ATTENTION:

POUR ÉVITER LES CHOCS ÉLECTRIQUES, INTRODUIRE LA LAME
LA PLUS LARGE DE LA FICHE DANS LA BORNE
CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.

Pour le CANADA

WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER­SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

Y
E

R

THE EXCLAMATION POINT WITHIN AN EQUILATERAL TRIANGLE IS INTENDED TO ALERT THE USER TO THE PRESENCE OF IMPORTANT
OPERATING AND MAINTENANCE (SERVICING) INSTRUCTIONS IN THE LITERATURE ACCOMPANYING THE APPLIANCE.

THE LIGHTNING FLASH WITH ARROWHEAD SYMBOL, WITHIN AN EQUILATERAL TRIANGLE, IS INTENDED TO ALERT THE USER TO THE
PRESENCE OF UNINSULATED "DANGEROUS VOLTAGE" WITHIN THE PRODUCT’S ENCLOSURE THAT MAY BE OF SUFFICIENT MAGNITUDE
TO CONSTITUTE A RISK OF ELECTRIC SHOCK TO PERSONS.

Before Use Avant Utilisation

CAUTION

< Read all of these Instructions.
<

Save these Instructions for later use.

<

Follow all Warnings and Instructions marked on the audio equipment.

1) Read Instructions — All the safety and operating instructions should
be read before the product is operated.

2) Retain Instructions — The safety and operating instructions should
be retained for future reference.

3) Heed Warnings — All warnings on the product and in the operating
instructions should be adhered to.

4) Follow Instructions — All operating and use instructions should be
followed.

5) Cleaning — Unplug this product from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for
cleaning.

6) Attachments — Do not use attachments not recommended by the
product manufacturer as they may cause hazards.

7) Water and Moisture — Do not use this product near water — for
example, near a bath tub, wash bowl, kitchen sink, or laundry tub; in a
wet basement; or near a swimming pool; and the like.

8) Accessories — Do not place this product on an unstable cart, stand,
tripod, bracket, or table. The product may fall, causing serious injury to
a child or adult, and serious damage to the product. Use only with a
cart, stand, tripod, bracket, or table recommended by the manufacturer,
or sold with the product. Any mounting of the product should follow the
manufacturer’s instructions, and should use a mounting accessory
recommended by the manufacturer.

9) A product and cart combination should be moved
with care. Quick stops, excessive force, and uneven
surfaces may cause the product and cart combination
to overturn.

10) Ventilation — Slots and openings in the cabinet are provided for
ventilation and to ensure reliable operation of the product and to
protect it from overheating, and these openings must not be blocked or
covered. The openings should never be blocked by placing the product
on a bed, sofa, rug, or other similar surface. This product should not be
placed in a built-in installation such as a bookcase or rack unless
proper ventilation is provided or the manufacturer’s instructions have
been adhered to.

11) Power Sources — This product should be operated only from the
type of power source indicated on the marking label. If you are not sure
of the type of power supply to your home, consult your product dealer
or local power company. For products intended to operate from battery
power, or other sources, refer to the operating instructions.

12) Grounding or Polarization — This product may be equipped with a
polarized alternating-current line plug (a plug having one blade wider
than the other). This plug will fit into the power outlet only one way. This
is a safety feature. If you are unable to insert the plug fully into the
outlet, try reversing the plug. If the plug should still fail to fit, contact
your electrician to replace your obsolete outlet. Do not defeat the safety
purpose of the polarized plug.

13) Power-Cord Protection — Power-supply cords should be routed so
that they are not likely to be walked on or pinched by items placed upon
or against them, paying particular attention to cords at plugs,
convenience receptacles, and the point where they exit from the
product.

14) Outdoor Antenna Grounding — If an outside antenna or cable
system is connected to the product, be sure the antenna or cable
system is grounded so as to provide some protection against voltage
surges and built-up static charges. Article 810 of the National Electrical
Code, ANSI/NFPA 70, provides information with regard to proper
grounding of the mast and supporting structure, grounding of the lead­in wire to an antenna discharge unit, size of grounding conductors,
location of antenna-discharge unit, connection to grounding electrodes,
and requirements for the grounding electrode.

Note to CATV system installer:

This reminder is provided to call the CATV system installer’s attention to
Section 820-40 of the NEC which provides guidelines for proper
grounding and, in particular, specifies that the cable ground shall be
connected to the grounding system of the building, as close to the point
of cable entry as practical."

15) Lightning — For added protection for this product during a lightning
storm, or when it is left unattended and unused for long periods of time,
unplug it from the wall outlet and disconnect the antenna or cable
system. This will prevent damage to the product due to lightning and
power-line surges.

16) Power Lines — An outside antenna system should not be located in
the vicinity of overhead power lines or other electric light or power
circuits, or where it can fall into such power lines or circuits. When
installing an outside antenna system, extreme care should be taken to
keep from touching such power lines or circuits as contact with them
might be fatal.

17) Overloading — Do not overload wall outlets, extension cords, or
integral convenience receptacles as this can result in risk of fire or
electric shock.

18) Object and Liquid Entry — Never push objects of any kind into this
product through openings as they may touch dangerous voltage points
or short-out parts that could result in a fire or electric shock. Never spill
liquid of any kind on the product.

19) Servicing — Do not attempt to service this product yourself as
opening or removing covers may expose you to dangerous voltage or
other hazards. Refer all servicing to qualified service personnel.

20) Damage Requiring Service — Unplug this product from the wall
outlet and refer servicing to qualified service personnel under the
following conditions:

a ) when the power-supply cord or plug is damaged.
b ) if liquid has been spilled, or objects have fallen into the product.
c ) if the product has been exposed to rain or water.
d)if the product does not operate normally by following the operating

instructions. Adjust only those controls that are covered by the
operating instructions as an improper adjustment of other controls may
result in damage and will often require extensive work by a qualified
technician to restore the product to its normal operation.

e) if the product has been dropped or damaged in any way.
f)when the product exhibits a distinct change in performance _ this

indicates a need for service.

21) Replacement Parts — When replacement parts are required, be
sure the service technician has used replacement parts specified by
the manufacturer or have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock, or other
hazards.

22) Safety Check — Upon completion of any service or repairs to this
product, ask the service technician to perform safety checks to
determine that the product is in proper operating condition.

23) Wall or Ceiling Mounting — The product should be mounted to a
wall or ceiling only as recommended by the manufacturer.

24) Heat — The product should be situated away from heat sources
such as radiators, heat registers, stoves, or other products (including
amplifiers) that produce heat.

ANTENNA
LEAD IN
WIRE

ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)

GROUNDING CONDUCTORS
(NEC SECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250. PART H)

NEC - NATIONAL ELECTRICAL CODE

ELECTRIC
SERVICE
EQUIPMENT

Example of Antenna Grounding
as per National Electrical
Code, ANSI/NFPA 70

GROUND
CLAMP

Important Safety Instructions

3

ENGLISH FRANÇAIS

Connections Connexions

4

AC Power outlet
Price secteur CA

W-600R

REC PLAY

LINE IN OUTPUT

LRL

R

VOLTAGE

SELECTOR

LINE IN OUTPUT

L

R

L

R

B

A

Amplifier
Amplificateur

TAPE

CAUTION

Do not plug the power cord of any
component into AC outlets and do not turn
their POWER switches on until all
connections have been performed.

ATTENTION

Ne pas brancher aucun composants et ne
pas les allumer jusqu'à temps que toutes
les connextions soit faites.

LINE IN/OUTPUT jacks

Connect the LINE IN/OUTPUT jacks to the
amplifier by audio signal connection
cords.

<

Make sure to connect :

white plug w white jack(L:left)
red plug w

red jack(R:right)

<

Be sure to insert each plug securely. To
prevent hum and noise, do not bundle the
connection cords with the power cord or
speaker cord.

A

Connecteurs LINE IN/OUTPUT

Branchez ces prises sur l’Amplificateur à
l’aide du câble à fiches coaxiales.

<

Assurez vous de connecter:

Fiche blanche

w

connecteur blanc (L:gauche)

Fiche rouge

w

connecteur rouge (R:droit)

<

Assurez-vous que chaque fiche est
enfoncée bien à fond. Pour éviter le
ronflement, éloignez les câbles de
raccordement du cordon d’alimentation et
des câbles des haut-parleurs.

A

Les têtes et le chemin de la bande doivent
être nettoyés et démagnétisés
périodiquement.

Nettoyage du chemin de bande

<

Appliquer un liquide de nettoyage de tête
sur le cotontige spécial ou sur un chiffon
doux et frotter légèrement les têtes,
cabestans et toutes les pièces de métal
du chemin de bande.

<

Nettoyer aussi le galet presseur avec un
liquide de nettoyage pour caoutchouc.

Démagnétisation des têtes

S'assurer que l’alimentation est coupée,
puis démagnétiser les têtes avec le
démagnétiseur.
Pour plus de détails sur son utilisation, lire
son manuel d’instructions.

Attention

Si la surface de l'appareil devient sale,
nettoyer celle-ci à l'aide d'un chiffon doux
ou utiliser un liquide de nettoyage neutre.
La nettoyer entièrement. Ne pas utiliser
de diluant, de benzine ou d'alcool car ils
risquent d'endommager la surface de
l'appareil.

The heads and tape path should be
cleaned and demagnetized periodically.

Cleaning Tape Path

<

Apply head cleaning fluid to a cotton swab

or soft cloth, and lightly rub the heads,
capstan and all metal parts in the tape
path.

<

Also clean the pinch roller using rubber

cleaning fluid.

Demagnetizing Heads

Be sure that the power is off, then
demagnetize the heads using a
demagnetizer. For details of its use, read
its instructions.

Caution:

If the surface of the unit gets dirty, wipe
with a soft cloth or use diluted neutral
cleaning liquid. Be sure to remove any
fluid completely. Do not use thinner,
benzine or alcohol as they may damage
the surface of the unit.

Voltage Conversion
(General export models only)

Be sure to remove the power cord from
the AC outlet before repositioning the
voltage converter switch.

1. Locate the voltage selector on the bottom
of the main unit.

2. Using a flat-bladed screwdriver, set to the
appropriate 230V or 120V position
according to your area.

IN NORTH AMERICA USE ONLY ON 120 V
SUPPLY.

B

Maintenance Entretien

Changement de tension (Modèles
s'exportation générale seulement)

Bien débrancher le cordon d'alimentation
de la prise secteur avant de repositionner
le sélecteur de changement de tension.

1. Localiser le sélecteur de tension par le
fond du appareil.

2. En utilisant un tournevis à lame plate,
régler sur la position appropriée 230V ou
120V en fonction de la tension locale.

DANS L'AMÉRIQUE DU NORD: UTILISABLE
SUR 120 V D'ALIMENTATION UNIQUEMENT.

B

5

ENGLISH FRANÇAIS

Cassette Tape Bandes

A

Tape Handling

Use your finger or a pencil to turn the
cassette's hub and take up any slack
tape.

<

Avoid touching the tape. Fingerprints

attract dust and dirt.

Do not store tapes in the following places:

<

On top of heaters, exposed to direct

sunlight or in any other places with high
temperatures.

<

Near speakers, on TV sets or amplifiers or

where they would be exposed to strong
magnetic fields.

<

Where humidity is high and in dirty, dusty

places.

<

Avoid dropping or subjecting cassettes to

excessive shocks.

<

As C-120 tapes are physically weak and

could become entangled in the transport
mechanism, do not use them.

B

b

c

a

Ne pas entreposer des bandes dans les
endroits suivants:

<

Sur des radiateurs, au soleil ou dans un
endroit où la température est élevée.

<

Près de haut-parleurs, sur des téléviseurs
ou amplificateurs ou encore près de
champs magnétiques puissants.

<

Dans des endroits où l'humidité est
élevée ou poussiéreux et sales.

<

Eviter d’échapper ou soumettre les
cassettes à des chocs excessifs.

<

Comme les bandes des cassettes C120
sont physiquement faibles et peuvent
facilement se coincer dans le mécanisme
de transport, ne pas les utiliser.

Choix de bande

Pour que le choix automatique de bande
fonctionne correctement, les bandes
métals ou chromes (cobalt) doivent
posséder des trous d’identification.

<

Cet appareil permet d' utiliser des
cassettes Normales (type!

) ou CrO2

(type@).

A

Manipulation des bandes

Utiliser un doigt ou un crayon pour
tourner le moyeu de la cassette et
rattraper le jeu de la bande.

<

Eviter de toucher la bande. Les
empreintes digitales attirent la poussière
et les saletés.

B

B

Normal / Normale (Type!)
CrO

2 (Type@)

Metal / Métal (Type!%

)

c

b

a

Basic description of Dolby NR

During low-level program material, Dolby
NR acts to boost high-frequency signals.
During playback, these signals are
restored to their original level. Any noise
introduced in between these processes
(during recording) will be reduced in
playback. Dolby NR also employs the
principle of least treatment, leaving high­level signals unprocessed since the
louder program material serves to
effectively mask any tape hiss.

Principe de fonctionnement du Dolby NR

Le dispositif de réduction de bruit Dolby
NR fonctionne en renforçant les signaux
de fréquence élevée lorsque le
programme est à un niveau faible. A la
lecture, ces signaux sont ramenés à leur
niveau d’origine. Tout bruit introduit entre
ces deux processus, c’est-à-dire pendant
l’enregistrement, sera réduit à la lecture.
Le dispositif Dolby NR obéit également au
principe de traitement minimum, c’est à
dire en ne traitant pas les signaux de
niveau élevé puisqu’un niveau sonore
plus élevé a pour effet de masquer
suffisamment tout sifflement sur la bande.

Dolby noise reduction manufactured under
license from Dolby Laboratories Licensing
Corporation.
"DOLBY" and the double-D symbol U

are
trademarks of Dolby Laboratories
Licensing Corporation.

Réduction de bruit Dolby fabriquée sous
licence de Dolby Laboratories Licensing
Corporation.
DOLBY et le symbole double-D U

sont
des marques de Dolby Laboratories
Licensing Corporation.

Tape Selection

Metal and chrome (cobalt) tapes have
identification holes.

<

You can use normal(Type!) or CrO2(Type@)

tape.

A
