Teac SL-D800BT User Manual
Z
77-20S800T00001
SL
-
D800BT
CD RADIO WITH BLUETOOTH
ENGLISH FRANÇAIS DEUTSCH ITALIANO NEDERLANDS SVENSKAESPAÑOL
OWNER'S MANUAL
MODE D’EMPLOI
MANUAL DEL USUARIO
BEDIENUNGSANLEITUNG
MANUALE DI ISTRUZIONI
GEBRUIKSAANWIJZING
BRUKSANVISNING
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO USERSERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead in an equi-
M
V
WARNING: TO PREVENT FIRE OR SHOCK
HAZARD, DO NOT EXPOSE THIS APPLIANCE
TO RAIN OR MOISTURE.
CAUTION
o DO NOT REMOVE EXTERNAL CASES OR CABINETS TO
EXPOSE THE ELECTRONICS. NO USER SERVICEABLE
PARTS ARE INSIDE.
o IF YOU ARE EXPERIENCING PROBLEMS WITH THIS
PRODUCT, CONTACT THE STORE WHERE YOU
PURCHASED THE UNIT FOR A SERVICE REFERRAL. DO
NOT USE THE PRODUCT UNTIL IT HAS BEEN REPAIRED.
o USE OF CONTROLS OR ADJUSTMENTS OR
PERFORMANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN COULD RESULT IN HAZARDOUS
RADIATION EXPOSURE.
lateral triangle is intended to alert the user to
the presence of uninsulated “dangerous voltage” within the product’s enclosure that could
be of sufficient magnitude to constitute a risk
of electric shock to persons.
The exclamation point in an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the literature
accompanying the appliance.
1)
Read these instructions.
2)
Keep these instructions.
3)
Heed all warnings.
4)
Follow all instructions.
5)
Do not use this apparatus near water.
6)
Clean only with dry cloth.
7)
Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
8)
Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9)
Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If
the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
10)
Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11)
Only use attachments/accessories specified by the
manufacturer.
12)
Use only with the cart, stand, tripod, bracket, or table specified
by the manufacturer, or sold with
the apparatus. When a cart is
used, use caution when moving
the cart/apparatus combination
to avoid injury from tip-over.
13)
Unplug this apparatus during lightning storms or when
unused for long periods of time.
14)
Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally,
or has been dropped.
o The apparatus draws nominal non-operating power
from the AC outlet with its POWER or STANDBY/ON
switch not in the ON position.
o The mains plug is used as the disconnect device, the
disconnect device shall remain readily operable.
o Caution should be taken when using earphones or
headphones with the product because excessive sound
pressure (volume) from earphones or headphones can
cause hearing loss.
22
CAUTION
o Do not expose this apparatus to drips or splashes.
o Do not place any objects filled with liquids, such as
vases, on the apparatus.
o Do not install this apparatus in a confined space such as
a book case or similar unit.
o The apparatus should be located close enough to the
AC outlet so that you can easily reach the power cord
plug at any time.
o If the product uses batteries (including a battery pack
or installed batteries), they should not be exposed to
sunshine, fire or excessive heat.
o CAUTION for products that use replaceable lithium
batteries: there is danger of explosion if a battery is
replaced with an incorrect type of battery. Replace only
with the same or equivalent type.
ENGLISH
This product is protected by certain intellectual property
rights of Microsoft. Use or distribution of such technology
outside of this product is prohibited without a license from
Microsoft.
MPEG Layer-3 audio coding technology licensed from
Fraunhofer IIS and Thomson.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such
marks by TEAC CORPORATION is under license.
Other company names and product names in this document are the trademarks or registered trademarks of their
respective owners.
33
IMPORTANT SAFETY INSTRUCTIONS (continued)
V Precautions concerning batteries
Misuse of batteries could cause them to rupture or leak leading
to fire, injury or the staining of nearby things. Please read and
observe the following precautions carefully.
o Be sure to insert the batteries with correct positive (¥) and
negative (^) orientations.
o Use batteries of the same type. Never use different types of
batteries together.
o If the remote control is not used for a long time (more than a
month), remove the batteries to prevent them from leaking.
o If the batteries leak, wipe away the leakage inside the battery
compartment and replace the batteries with new ones.
o Do not use batteries of types other than those specified. Do
not mix new batteries with old ones or use different types of
batteries together.
o Do not heat or disassemble batteries. Never throw batteries
into fire or water.
o Do not carry or store batteries with other metallic objects. The
batteries could short circuit, leak or explode.
o Never recharge a battery unless it is confirmed to be a
rechargeable type.
V WARNING
DO NOT INGEST BATTERY, CHEMICAL BURN HAZARD
o The remote control supplied with this product contains a coin/
button cell battery. If the coin/button cell battery is swallowed,
it can cause severe internal burns in just 2 hours and can lead
to death.
o Keep new and used batteries away form children. If the battery
compartment does not close securely, stop using the product
and keep it away from children.
If you think batteries might have swallowed or placed inside
any part of the body, seek immediate medical attention.
Laser Information
This product contains a semiconductor laser system inside the
cabinet and is classified as a “CLASS 1 LASER PRODUCT”.
To prevent being exposed to the laser beam, do not try to open
the enclosure.
Laser:
Type: SF-P101VZ
Manufacturer: LIAN ZHONG ELECTRONIC TECHNOLOGY
(HK) Co.,LTD.
Laser output: Less than 0.5 mW
Wavelength: 790 ± 10 nm
DECLARATION OF CONFORMITY
We, TEAC AUDIO EUROPE, Liegnitzer Straße
6, 82194 Gröbenzell, Germany declare in own
responsibility, the TEAC product described in this
manual is in compliance with the corresponding
technical standards.
4
Pb, Hg, Cd
Wireless equipment precautions
For European Customers
Disposal of electrical and electronic equipment
(a)
All electrical and electronic equipment should be disposed
of separately from the municipal waste stream via collection facilities designated by the government or local
authorities.
(b)
By disposing of electrical and electronic equipment correctly, you will help save valuable resources and prevent
any potential negative effects on human health and the
environment.
(c)
Improper disposal of waste electrical and electronic equipment can have serious effects on the environment and
human health because of the presence of hazardous substances in the equipment.
(d)
The Waste Electrical and Electronic Equipment
(WEEE) symbol, which shows a wheeled bin that
has been crossed out, indicates that electrical
and electronic equipment must be collected and
disposed of separately from household waste.
(e)
Return and collection systems are available to end users.
For more detailed information about the disposal of old
electrical and electronic equipment, please contact your
city office, waste disposal service or the shop where you
purchased the equipment.
Disposal of batteries and/or accumulators
(a)
Waste batteries and/or accumulators should be disposed
of separately from the municipal waste stream via collection facilities designated by the government or local
authorities.
(b)
By disposing of waste batteries and/or accumulators correctly, you will help save valuable resources and prevent
any potential negative effects on human health and the
environment.
(c)
Improper disposal of waste batteries and/or accumulators
can have serious effects on the environment and human
health because of the presence of hazardous substances in
them.
(d)
The WEEE symbol, which shows a wheeled bin
that has been crossed out, indicates that batteries and/or accumulators must be collected and
disposed of separately from household waste.
If a battery or accumulator contains more than
the specified values of lead (Pb), mercury (Hg), and/or
cadmium (Cd) as defined in the Battery Directive (2006/66/
EC), then the chemical symbols for those elements will be
indicated beneath the WEEE symbol.
(e)
Return and collection systems are available to end users.
For more detailed information about the disposal of waste
batteries and/or accumulators, please contact your city
office, waste disposal service or the shop where you purchased them.
Compliance of radio transmitter and
interference
Model for EEA (European Economic Area)
This equipment complies with the harmonised standards of
DIRECTIVE 1999/5/EC (R&TTE).
Labeling of conformity
CE marking:
CAUTION
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate the equipment.
CAUTION
Authorization of wireless devices are different in countries or
regions. Please use only in the country where you purchased the
product.
o Depending on the country, restrictions on the use of Bluetooth
wireless technology might exist.
Radiation Exposure requirements
This equipment meets the regulation, which is recognized
internationally, for the case of human exposure to radio waves
generated by the transmitter.
Statement of compliance
EEA (European Economic Area) model
This equipment complies with EN.62311; Assessment of electronic
and electrical equipment related to human exposure restrictions
for electromagnetic fields; the harmonised standard of DIRECTIVE
1999/5/EC.
Bluetooth® notes
When using this unit with a mobile phone or other Bluetooth
devices, they should be no more than about 10 m (33 ft) apart.
Depending on the circumstances of use, however, the effective
transmission distance might be shorter.
Wireless communication with every device that supports
Bluetooth wireless technology is not guaranteed.
To determine the compatibility between this unit and another
device that supports Bluetooth wireless technology, refer to that
device's operation manual or contact the shop where you purchased it.
5
ENGLISH
Contents
Before use
Thank you very much for purchasing this TEAC product.
Please read this manual carefully before using the unit.
IMPORTANT SAFETY INSTRUCTIONS ......................2
Wireless equipment precautions ..........................5
Bluetooth® notes .........................................5
Before use ................................................6
MP3/WMA files ...........................................7
Discs .....................................................8
Names and functions of parts (main unit) ................10
Names and functions of parts (remote control) ...........12
Using the remote control ................................13
Preparation ..............................................14
Setting the clock. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Basic operation ..........................................16
Listening to a CD ........................................18
Programmed playback (CD) ..............................20
Repeat/intro/shuffle playback (CD) .......................22
About MP3/WMA file playback ...........................24
Listening to audio from a Bluetooth device ..............25
Pairing with another Bluetooth device ...................26
Listening to the radio ....................................27
Preset tuning ............................................28
Wakeup timer ...........................................30
Sleep timer ..............................................32
Automatic power saving function ........................32
Troubleshooting .........................................33
Specifications ............................................35
Included items
Check to be sure the box includes all the supplied accessories shown below. Please contact the store where you
purchased this unit if any of these accessories are missing
or have been damaged during transportation.
Remote control (RC-1317) × 1
CR2032 button cell battery for remote control × 1
AM antenna × 1
PS-M0926 AC adapter × 1
Owner’s manual (this document) × 1
o Keep this manual in a safe place for future reference.
o See the back of this document for information about
the warranty in Europe and other countries or areas.
Precautions for use
o Avoid placing the unit in direct sunlight, close to a
source of heat or in other similar conditions. Do not
place the unit on top of an amplifier or other equipment that might generate heat that exceeds the
operating temperature range of this unit. Doing so
could cause discoloration, deformation or malfunction.
o As the unit could become warm during operation,
always leave sufficient space around it for ventilation.
When installing this unit, leave a little space (at least
20 cm (8”)) between it and other devices and walls to
allow good heat dissipation. When placing it in a rack,
for example, leave at least 5 cm (2”) open above it and
10 cm (4”) open behind it. Failure to provide these gaps
could cause heat to build up inside and result in fire.
o DO NOT MOVE THE UNIT DURING PLAYBACK. During
playback, the disc rotates. Do not lift or move the unit
during playback. Doing so may damage the disc or the
unit.
o Always remove the disc before relocating or moving
this unit. Moving the unit with a disc inside could damage the disc or could cause a malfunction.
6
o Do not open the cabinet as this might result in damage
to the circuitry or electrical shock. If a foreign object
should get into the unit, contact your dealer.
o If a TV is turned on while the unit is on, static might
appear on the TV screen depending on the characteristics of the TV broadcast signal. If this occurs, put this
unit into standby mode (off) when using the TV.
Maintenance
If the surface of the unit gets dirty, wipe it with a soft cloth
or use diluted mild liquid soap. Allow the surface of the
unit to dry completely before using.
Do not use chemical cleaning cloths, thinner or similar substances as they could damage the surface of the unit.
V
CAUTION
For safety, disconnect the power cord from the
socket before cleaning.
MP3/WMA files
This unit can play MP3 and WMA files that are on CD-R/
CD-RW discs.
o Audio file formats that can be played back
MP3 (file extension: .mp3)
Bit rate: 8 kbps to 320 kbps
Sampling frequency: 16 kHz to 48 kHz
WMA (file extension: .wma)
Bit rate: 8 kbps to 320 kbps
Sampling frequency: 32 kHz, 44.1 kHz, 48 kHz
Note: Digital Rights Management (DRM) is not
supported.
o Up to eight levels of folders supported.
Precautions when creating MP3/WMA
files on a computer
o Only discs that have been recorded using the ISO 9660
standard can be played by this unit.
o MP3 and WMA files are recognized by their file exten-
sions (“.mp3” for MP3 files and “.wma” for WMA files.)
Always include the extension in the file name.
o Files without extensions cannot be recognized. A file
cannot be played back regardless of the file name
extension, if the data is not in the MP3 or WMA format.
o After recording to a CD-R/CD-RW, always close the
session (complete disc creation). This unit cannot play a
disc if its session has not been closed.
o A maximum of 999 files and 99 folders on a disc can be
played. If the media has more than these maximums,
this unit might not be able to correctly play any file that
is the 1000th or higher or any folder that is the 100th or
higher.
o Discs made with multi-session recording are not sup-
ported. Only the first session can be played back.
o Depending on the condition of the disc, playback might
not be possible or the sound might skip.
o This unit cannot play copyright-protected audio files.
ENGLISH
7
Discs
Discs that can be played on this unit
CDs with the Compact disc Digital Audio logo
CD-R and CD-RW discs that have been created in
the audio CD format and finalized correctly.
CD-R and CD-RW discs that have been written with
MP3 or WMA files and finalized.
This unit can play the above types of discs (without adapters). This unit cannot play any other types of discs.
V
CAUTION
If you try to play any other type of disc with this unit,
loud noises that damage speakers or harm hearing
could occur. Never try to play any other type of disc
with this unit.
o This unit might not be able to properly play back Copy
Control CDs, Dual Discs and other special CDs that do
not conform to the Red Book CD standard. Operation
and sound quality cannot be guaranteed when special
discs are used in this unit. If playback of a special disc
should cause trouble, contact the seller of the disc.
CD-R/CD-RW discs
Precautions for use
o Do not use cracked discs because they could damage
the unit.
o When writing something on the label side of a disc, use
a felt tip permanent marker. The use of a ballpoint pen
or other pen with a hard tip could damage the disc,
making it unplayable.
o Never use commercially-available CD stabilizers. Doing
so could make the disc unplayable or damage the unit.
o Never use CDs with irregular shapes, including heart-
shaped and octagonal discs because such discs could
damage the unit.
Handling precautions
o Always load the disc with the label side up.
o If the side of the disc that the signal is recorded on
(unlabeled side) has scratches, fingerprints or dirt on it,
for example, playback errors could occur. Please handle
discs with care.
o To remove a disc from its case, press down on the cen-
ter of the case and hold the disc by its edges. Do not
touch the side of the disc that has the data encoded on
it (unlabeled side).
This unit can play back CD-R and CD-RW discs that have
been recorded in the audio CD format (CD-DA) and the
MP3 or WMA format.
o Discs created by a CD recorder must be finalized with
the CD recorder that was used to create the discs before
being used with this unit.
o Depending on disc quality and recording conditions,
playback of some discs might not be possible. Please
see the manual for the device that you used to create
the disc.
o If you are uncertain about the handling of a CD-R or
CD-RW disc, please contact the seller of the disc directly.
8
Removal from case Holding by edges
Storage precautions
Maintenance
o Discs should be stored in their cases when not being
used. Failure to do so could result in warping and
scratches.
o Do not leave discs in places that are exposed to direct
sunlight or that are very humid or hot. Long exposure
to such conditions could warp or degrade discs, making
them unplayable.
o Since CD-R/CD-RW discs are more susceptible to the
effects of heat and ultraviolet rays compared to commercial CDs, do not leave them for long periods of time
in places that are, for example, exposed to direct sunlight or near equipment that generate heat.
o Smudges on a disc might cause the sound to skip or
degrade the sound quality. Always clean discs before
storing them.
o If the side of the disc that has the data encoded on
it (unlabeled side) becomes dirty with fingerprints or
dust, use a soft cloth to wipe the surface from the center directly toward the edge.
o Never use record cleaners, antistatic treatments, thin-
ners or similar chemicals to clean discs. Such chemicals
could harm the surface of the disc.
ENGLISH
9
G
H I
K
Names and functions of parts (main unit)
Top
A
L
M
A
Open/close button (-)
Push to open the lid.
B
STANDBY/ON button
Press this button to turn the unit on or put it in standby.
FrontSide
D
D
Speakers (stereo)
E
Display
F
Indicators
The indicator for the selected source lights.
B C
E
D
F F
J
C
Function buttons
To listen to a CD, press the CD button.
To listen to a Bluetooth device, press the Bluetooth
button.
To listen to the radio, press the FM/AM button. Each
time you press the FM/AM button, the unit will switch
between FM and AM broadcast reception.
10
G
Remote control signal receiver
Signals sent from the remote control are received
here. When using a remote, point it toward this spot.
H
VOLUME knob
Use to adjust the volume. Turn right to raise the volume and left to lower it.
I
Control buttons
Stop (8) button
Press to stop playback.
J
MULTI JOG dial
Use when tuning the radio to select stations (page
27).
Use this also to set the current time and the wakeup
timer (pages 15 and 30).
When listening to MP3/WMA files, use to select folders
(page 24).
Play/pause (y/9) button
Press to start or pause playback.
If a disc is loaded, playback will start. If no disc is
loaded, “NO DISC” will appear on the display.
Skip/search (.m/,/) buttons
Use to select tracks/files. Press the .m or
,/ button to skip to the previous or next track/
file (page 19).
During playback, press and hold the ,/ button
to search forward or the .m button to search
backward (page 19).
Use when setting radio station presets (AM, FM) and
to select them (page 27).
PLAY MODE button
When listening to a CD or an MP3/WMA file, use to
change the play mode (normal, repeat, intro, shuffle)
(page 22).
When listening to FM radio, use to switch between
stereo and mono (page 28).
DISPLAY/DIMMER button
Each time this button is pressed, the display changes
(page 17).
Press and hold to adjust the display brightness (page
17).
K
USB port for charging
Devices can be recharged by connecting them using
a USB-A type connector (0.5 A maximum).
L
CLOCK ADJUST button
Use to adjust the clock (page 15).
M
TIMER button
Use to set the wakeup timer (page 30).
ENGLISH
SLEEP button
Use to set the sleep timer (page 32).
MEMORY button
Use for CD programmed playback (page 20).
When listening to the radio, use when setting radio
station presets (page 29).
11
Names and functions of parts (remote control)
a
b
c
d
e
f
g
h
i
j
When both the main unit and the remote control have
buttons with the same functions, the instructions in this
manual refer to only one set of buttons, but the other
set of buttons can be used in the same way.
a
PAIRING button
Use this when pairing with other Bluetooth devices
and when ending Bluetooth connections (pages 25
and 26).
b
Standby/on (¤) button
m
f
Skip/search (.m/,/) buttons
k
l
n
o
When listening to the radio, use to select preset radio
stations (page 29).
When listening to a CD, use to skip to the previous or
next track/file. Press and hold during CD or MP3/WMA
file playback to search forward/backward (page 19).
g
Stop (8) button
Press to stop playback.
h
Play/pause (y/9) button
Press when stopped or paused to start playback.
Use this button to pause playback during playback
(page 19).
i
TONE button
Use to adjust the bass and treble (page 16).
j
MUTE button
Use this button to mute the sound temporarily (page
17).
k
Function button
Each time you press this button, the source will
change as shown below.
CD Bluetooth FM AM
o Press when the unit is in standby mode to turn it
on.
c
SLEEP button
Use this button to set the sleep timer (page 32).
d
TIMER button
Use to turn the wakeup timer on and off (page 30).
e
TUNE/MULTI JOG buttons
When setting the clock and the wakeup timer, use to
set the time (pages 15 and 30).
When listening to an MP3/WMA file, use to select the
folder number (page 20).
12
l
DISPLAY/DIMMER button
Each time this button is pressed, the display changes
(page 17).
Press and hold to adjust the display brightness (page
17).
m
MEMORY/CLOCK ADJ button
Use for CD programmed playback (page 20).
When listening to the radio, use when setting radio
station presets (page 28).
Use to adjust the clock (page 15).
n
PLAY MODE/FM MODE button
When listening to a CD, use to change the play mode
(normal, repeat, intro, shuffle) (page 22).
When listening to FM radio, use to switch between
stereo and mono (page 28).
o
VOLUME (+/−) buttons
Use to adjust the volume. Press the + button to raise
the volume, and press the − button to lower the
volume.
Using the remote control
Precautions for use
o When using the remote control, point it toward the
remote control signal receiver on the main unit from a
distance of 5 m (16 ft) or less. Do not place obstructions
between the main unit and the remote control.
o The remote control might not work if the remote
control signal receiver on the main unit is exposed to
sunlight or bright lights. In this case, try moving the
main unit.
o Beware that use of this remote control could cause the
unintentional operation of other devices that can be
controlled by infrared rays.
Installing the battery
Insert a fine rod into the hole on the back of the remote
control and pull the cover forward while pushing down.
Insert the lithium button cell battery (CR2032) with the
+side up, and close the cover.
ENGLISH
1
2
When to replace the battery
If the distance from the main unit that the remote can be
used becomes shorter or if the unit stops responding to
the remote buttons, replace the battery with a new one.
Dispose of the used battery according to the instructions
on it or the requirements set by the local government.
V
CAUTION
Misuse of batteries could cause them to rupture or
leak, which might result in fire, injury or the staining
of nearby materials. Please read and observe the precautions on page 4 carefully.
13
A
Preparation
V
Precautions when making connections
o Do not plug the unit in until all connections have been completed.
o Carefully read the manuals of the devices that you are connecting
and follow their instructions when making connections.
AM antenna
B C
A
FM antenna
After finding a position where FM broadcasts can be
received and the reception is good, attach it to the
wall or ceiling using tacks or tape, for example.
o See page 27 for instructions about how to receive
radio signals.
o Do not bundle the antenna with other wires
because doing so will reduce its sensitivity.
B
DC input connector (DC IN 9V)
After completing all the connections, connect the
included AC adapter (PS-M0926) to this jack.
Next, plug the AC adapter into a power outlet.
Unplug the power adapter from the outlet when
you are not planning to use the unit for an extended
period of time.
Do not use any AC adapter other than the one included
(PS-M0926).
Included PS-M0926
AC adapter
C
AM antenna connector
Assemble the included AM loop antenna and connect
it to the AM antenna connector on the back of the
unit.
Place the antenna in the position that provides the
best AM reception.
Assembling the AM antenna
To assemble the AM antenna, turn the base in the direction
of the arrow. Then, insert the hook at the bottom of the
loop into the slot in the base.
1 2
Antenna base Hook
14
Setting the clock
Set the current time before using the unit.
4 Press the skip/search (.m/,/)
buttons to turn on/off automatic time
adjustment using RDS clock time (CT).
c3
ENGLISH
5 Press the CLOCK ADJUST button.
The hour value blinks.
6 Use the skip/search (.m/,/)
buttons to set the hour.
7 Press the CLOCK ADJUST button.
The minute value blinks.
1 Press the STANDBY/ON button to put the
unit into standby.
2 Press and hold the CLOCK ADJUST button
for at least two seconds.
3 Press the skip/search (.m/,/)
buttons to switch between “24H” (24-hour)
and “12H” (12-hour) time display.
c3
8 Use the skip/search (.m/,/)
buttons to set the minute.
9 Press the CLOCK ADJUST button.
This completes the procedures for setting the time.
The clock will start from the set minute at 0 seconds.
o The unit’s current time data will be erased if the power
supply is interrupted for about 10 minutes because
a power outage occurs or the power plug is disconnected from an outlet.
15
Basic operation
13 2
1 Press the STANDBY/ON button to turn the
unit on.
o The default value is 12.
o When you turn the VOLUME knob, the volume will
be shown for about three seconds.
V
Sudden loud noises could damage your
hearing or cause other harm. Set the volume
to minimum. After sound output begins,
adjust the volume to a suitable level.
NOTE
When not using this unit, press the STANDBY/ON button to put the unit into standby.
Changing the tone
o Even when in standby (unit off), pressing a func-
tion button will turn the unit on.
2 Press a function button to set the playback
source.
When a playback source is selected, the correspond-
ing indicator lights.
o When using the remote control, press the
FUNCTION button repeatedly until the indicator for
the desired audio source lights.
3 Turn the VOLUME knob to adjust the volume.
1 Press the TONE button.
In the middle of the display “tone” will appear and the
“b” above it will blink.
2 Use the MULTI JOG buttons to set the low
frequency value.
o The default setting is 0 for both the low-frequency
and high-frequency bands. They can be set
between −5 and 5.
00 (MIN): minimum volume (no sound)
36 (MAX): maximum volume
Turn the VOLUME knob right to raise the volume and
left to lower it.
16
3 Press the TONE button.
The “t” at the top of the display will blink.
4 Use the MULTI JOG buttons to set the high
frequency value.
o When the mute function is active, “00” blinks on the
display.
o When the mute function is active, adjusting the volume
will unmute the output.
o When the mute function is active, changing the source
will unmute the output.
Changing the display
5 If 10 seconds pass without any adjustment,
the setting mode will end.
Adjusting the brightness of the display
Press the DIMMER button for at least two seconds to dim
the display. Press it again for at least two seconds to restore
normal display brightness.
o When the unit enters standby, the dimmer setting is
reset to normal brightness.
Muting the output
Each time the DISPLAY button is pressed, the display
changes as follows.
When an audio CD is playing
Track elapsed time Track remaining time
Clock display
When an MP3/WMA disc is playing
File elapsed time Clock display
When a Bluetooth device is playing
Clock only
Total remaining time
ENGLISH
Press the MUTE button to temporarily silence the output.
Press the MUTE button again to resume output at the previously set volume level.
When the function is AM/FM
Clock only
o When the function is AM or FM and a preset station
is selected, press this button to alternately display
the preset number and the time.
17
Listening to a CD
1 Press the CD function button.
The CD indicator lights when CD mode is active.
o When using the remote control, press the
FUNCTION button repeatedly until the CD indicator lights.
2 Press the open/close (-) button to open
the lid. Place a disc with the labeled side
facing up and close the lid.
o Do not load multiple discs at the same time. Doing
so could cause malfunction.
o Loading a disc takes a few seconds.
o “NO DISC” will be displayed if a disc has not been
loaded.
o When closing the lid, press the “PUSH CLOSE” spot
near its right front corner. The lid might not close if
you press the left side.
o Be careful not to let your fingers get caught when
closing the lid.
o A non-audio disc might be “played” in the same
manner as an audio disc, but sound will not be
output.
o When the current file is a WMA file, “WMA” will
appear at the bottom of the display.
o When a disc is being read, “rEAd” appears on the
display.
3 Press the play/pause (y/9) button.
Playback will start from the first track/file and y will
appear on the display.
18
Display example
Folder number
(When an audio
CD is loaded, “Cd”
appears on the
display.) Track/file number
Stopping playback
Press the stop (8) button to stop playback.
Data format Elapsed time of
currently playing track/file
o This unit treats MP3/WMA files that are not in fold-
ers as being in the 01 folder. Playback starts with
the first track in the 01 folder.
o For details about the playback order of MP3/WMA
files, see page 24.
o After all tracks/files have played, playback will auto-
matically stop.
o During playback, a pair of lines moves around the
outer edge of the display.
V
Never open the disc lid during playback. Doing
so could cause the disc to fly out, possibly resulting in injury or damage.
Skipping tracks/files
During playback and when paused, press a skip/search
(.m/,/) button to skip to the previous or
next track/file. Press repeatedly until you reach the song
you want.
Playback will start from the beginning of the selected
track/file.
When stopped, press a skip (.m / ,/) button
repeatedly until the desired track/file is found and press the
play/pause (y/9) button to start playback.
During playback and when paused, press the .m
button once to return to the beginning of the track/
file being played. To play an even earlier song, press the
.m button repeatedly.
During programmed playback (page 20), the next or previous track/file in the program will be played.
ENGLISH
Pausing playback
Press the play/pause (y/9) button to pause playback.
When paused, press the play/pause (y/9) button to
resume playback from the paused point.
o When paused, the playback time will blink.
Search for a part of a track/file
During playback, press and hold a skip/search (.m/
,/) button to search backward/forward. At the
point where you want to listen, press the play/pause
(y/9) button.
19
Programmed playback (CD)
3
Up to 32 CD tracks or MP3/WMA files can be programmed
in the desired order.
Program tracks/files when playback is stopped.
Programming tracks/files
24 1
1 When the CD function is active, press the
MEMORY button when stopped.
o If you change the folder or file number, only the
MEMORY indicator will blink.
3 Press the MEMORY button.
The selected track/file is added to the program, and
“P02” appears on the display.
o To program multiple tracks/files, repeat steps 2 to
3
.
o To stop programming, press the stop (8) button.
4 When you have nished adding tracks/les
to a program, press the play/pause (y/9)
button to start programmed playback.
o To stop programmed playback, press the stop (8) but-
ton. The contents of the program are retained.
o During programmed playback, use the skip/search
(.m/,/) buttons to select different tracks/
files in the program.
o During programmed playback, intro and shuffle play-
back are not possible.
The track number (or folder and file numbers) and the
MEMORY indicator blink.
o To stop programming, press the stop (8) button
or wait 20 seconds or more.
o During programming if you do nothing for 20 sec-
onds or more, the program will be confirmed.
2 Select a track/le to add to the program.
With an audio CD
Use the skip/search (.m/,/) buttons to
select a track by number.
MP3/WMA file example
To select a folder by number, turn the MULTI JOG dial.
To select a file by number, use the skip/search
(.m/,/) buttons.
o This unit treats MP3/WMA files that are not in fold-
ers as being in the 01 folder.
20
Checking the program order
When stopped, press the MEMORY button to cycle
through the program numbers and the programmed
track/file numbers in order.
Adding tracks/files to the end of the
3
3
Changing a track/file within the
program
1
2
1 When stopped, press the MEMORY button
repeatedly to show the number which is
one higher than the last program number.
program
1
2
1 When programmed playback is stopped,
press the MEMORY button repeatedly until
the program number of the track/file you
want to change appears on the display.
ENGLISH
When using an audio CD, the track number and
MEMORY indicator will blink.
When using MP3/WMA files, the folder number, file
number and MEMORY indicator will blink.
2 Press the skip/search (.m/,/)
button to select a track/le.
3 Press the MEMORY button.
The track/file is added to the end of the program.
2 Use the skip/search (.m/,/)
button to select the track/le that you want
to use as a replacement in the program.
3 Press the MEMORY button.
The selected track/file is added at the selected program number, replacing the track/file that was there.
21
Programmed playback (CD) (cont’d)
Clearing all the program contents
Press for at least
2 seconds
Press and hold the stop (8) button for at least two seconds when stopped.
The contents of the program are cleared, and the display
MEMORY indicator becomes unlit.
o The program is also cleared in the following cases.
• The unit enters standby mode
• When you press a function button (Bluetooth or FM/
AM) on the main unit or the FUNCTION button on
the remote control to change the function
• The disc lid is opened
Repeat/intro/shuffle playback (CD)
When the CD function is active, press the PLAY MODE button to cycle through the following playback modes.
REPEAT (single track/file repeat)
REPEAT FOLDER
(MP3/WMA files only)
REPEAT ALL (all track/file repeat)
INTRO (intro playback)
SHUFFLE*
OFF (normal playback)
Press the play/pause (y/9) button when the mode you
want to select appears to start playback.
*If shuffle is selected, playback starts automatically.
o You can also change the playback mode by pressing
the PLAY MODE button during playback.
o Any of the following operations will end repeat or shuf-
fle playback mode.
• The stop (8) button is pressed
• The unit enters standby mode
• When you press a function button (Bluetooth or FM/
AM) on the main unit or the FUNCTION button on
the remote control to change the function
• The disc lid is opened
22
Repeat playback
Intro playback
REPEAT (single track/file repeat)
During playback, press the PLAY MODE button once to
repeat playback of the currently playing track/file. “REPEAT”
appears on the display.
o If you press a skip/search (.m /,/) button
to select another track/file, that track/file will be played
repeatedly.
o When stopped, press the PLAY MODE button and then
use the skip/search (.m/,/) buttons to
select a track/file. Press the play/pause (y/9) button
to start single repeat playback.
o During programmed playback, the track/file being
played will be played repeatedly.
REPEAT ALL (all track/file repeat)
Press the PLAY MODE button twice (or three times for MP3/
WMA files).
“REPEAT ALL” appears on the display and all tracks/files are
played back repeatedly.
o During programmed playback, the programmed tracks/
files will be played repeatedly.
REPEAT FOLDER
(MP3/WMA files only)
Press the PLAY MODE button twice.
“REPEAT” blinks on the display, and the files in the selected
folder are played back repeatedly.
You can play back just the beginnings of tracks/files one
after another.
INTRO
Press the PLAY MODE button repeatedly until “INTRO”
appears to play back only the first 10 seconds of all tracks/
files.
During programmed playback, intro playback is not
possible.
Shuffle playback
All the tracks/files are played back randomly.
SHUFFLE
Press the PLAY MODE button repeatedly until “SHUFFLE”
appears on the display.
o During shuffle playback, press the skip/search (,/)
button to start playback of the next random track/file.
Press the skip/search (.m) button to return to the
beginning of the current track/file.
o Shuffle playback is not possible during programmed
playback.
ENGLISH
23
About MP3/WMA file playback
File playback order
A disc that contains MP3/WMA files can have the files in
folders in the same manner that files are managed on an
ordinary computer. One folder can also contain multiple
subfolders.
Example of folder numbers and file playback order
(1 to 9) during normal playback of a disc that contains MP3/WMA files
01 (ROOT)
1
MP3/WMA file
2
MP3/WMA file
02 folder
3
MP3/WMA file
4
MP3/WMA file
04 folder
6
7
MP3/WMA file
MP3/WMA file
03 folder
5
MP3/WMA file
Selecting folders and files
To select a folder by number, turn the MULTI JOG dial.
When using the remote control, press the TUNING/MULTI
JOG buttons.
Folder
05 folder
8
MP3/WMA file
9
MP3/WMA file
o Adding, removing or relocating files and folders could
change the order shown in the above illustration.
24
To select a file by number, use the skip/search (.m/
,/) buttons.
o After selecting the folder/file number, press the play/
pause (y/9) button to start playback.
Listening to audio from a Bluetooth device
With this unit, you can enjoy listening to music played back
on another Bluetooth device wirelessly.
1 Press the Bluetooth function button.
The Bluetooth icon ( ) blinks, and the unit searches
for paired devices.
o When using the remote control, press the
FUNCTION button repeatedly until the Bluetooth
indicator lights.
o The Bluetooth indicator lights when Bluetooth is
selected.
When connection with another Bluetooth device
succeeds, the Bluetooth icon ( ) will appear on the
display without blinking.
o The unit will automatically try to connect to the
previously connected device.
o Pairing is necessary before using the Bluetooth
function of this unit for the first time and when you
want to connect a new Bluetooth device.
o If connection fails, confirm that the other Bluetooth
device is ready to make a Bluetooth connection.
o If the connection is lost during use, and the
Bluetooth icon ( ) blinks on the display, conduct
the connection operations again on this unit and
the other Bluetooth device.
2 Operate the Bluetooth device to start
playback.
If the connected Bluetooth device supports AVRCP,
you can use this unit or the remote control to play,
pause or stop audio on that device.
Depending on the Bluetooth device being used,
remote control operation might not be supported or
actual operations might differ.
o The volume, however, cannot be adjusted remotely.
Audio/Video Remote Control Profile (AVRCP)
To control playback of a Bluetooth device, the Bluetooth
device must support AVRCP.
Some Bluetooth devices, however, have different functions
depending on their specifications.
o If you cannot control another Bluetooth device with this
unit, operate the other Bluetooth device directly.
Unpairing a device
To disconnect, press and hold the Bluetooth function button for at least two seconds or the remote control PAIRING
button.
o If you later want to use a Bluetooth connection with
that Bluetooth device, you must pair them again.
o This deletes all pairing information. Unpairing with just
one device is not possible.
ENGLISH
25
Pairing with another Bluetooth device
Pairing is necessary before using the Bluetooth function of
this unit for the first time and when you want to connect a
new Bluetooth device.
Follow these procedures to pair the unit with the other
device.
Pairing
1 Press the Bluetooth function button.
The Bluetooth indicator lights and the Bluetooth icon
( ) blinks, showing that pairing is possible.
o When using the remote control, press the
FUNCTION button repeatedly until the Bluetooth
indicator lights.
2 Enable the Bluetooth communication func-
tion on the other Bluetooth device.
3 From the Bluetooth device, select
“SL-D800BT” (this unit).
o If a passkey is required during pairing, input “0000”.
When connection succeeds, the Bluetooth icon ( )
will appear on the display without blinking.
o This unit can retain pairing data for up to five devices.
After five devices have been paired, if a new device is
paired, the oldest pairing will be overwritten.
o When a Bluetooth device is connected, if you
change the source with a function button or press
the STANDBY/ON button to put the unit into standby
mode, the next time the unit is turned on, the unit will
try to connect automatically with the last connected
Bluetooth device.
o When the other Bluetooth device is disconnected, the
Bluetooth icon ( ) will appear blinking on the display
of this unit.
o If the other Bluetooth device is waiting to pair, pairing
will occur automatically when this unit enters pairing
mode.
Touch pairing
If the other Bluetooth device supports NFC, you can pair it
with this unit using the following procedures.
1 Press the Bluetooth function button.
o You cannot use touch pairing if another function is
selected.
2 Hold the antenna of the device that sup-
ports NFC toward the touch pairing reader.
Do this within two minutes of selecting “Bluetooth”.
Touch pairing reader
o Hold the device that supports NFC within 2 cm of
the touch pairing reader.
o Before using the Touch Pairing feature, enable both
the Bluetooth and Touch Pairing functions on your
smartphone or tablet. If available, turn on “NFC
Reader/Writer/P2P.”
o Touch Pairing is dependent on where the antenna
exists in your device. If it doesn’t work on the first
try, move your device round to find the antenna
position. The antenna may be strongest on the
back of the device, towards the bottom, on the
side, etc.
26
Listening to the radio
Press the FM/AM button to select FM or AM broadcast
reception.
When using the remote control
Automatic station selection
Press a skip/search (.m/,/) button until the
frequency begins to change. After the frequency starts
changing, stop pressing the button to start automatic station selection.
o When a radio station is received, automatic station
selection ends.
o To cancel automatic station selection, press a skip/
search (.m/,/) button.
o If the reception is poor or the antenna is disconnected,
“PLEASE CHECK ANTENNA” scrolls across on the display.
Check the antenna position and connection and then
try the operation again.
Manual station selection
Turn the MULTI JOG dial to change the reception frequency.
Turn right to increase the reception frequency and left to
decrease it.
When using the remote control
ENGLISH
o Press the FUNCTION button repeatedly until the
FM or AM indicator lights.
FM radio reception example
Frequency received
Stereo indicator
Press a TUNING (j/k) button briefly to change the fre-
quency by a fixed step.
Press the TUNING (j/k) button repeatedly until you find
the station that you want.
27
Listening to the radio (cont’d) Preset tuning
FM MODE button
When a stereo FM program is tuned in, you can switch
between stereo and mono by pressing the PLAY MODE
button.
Stereo mode: (St:on)
Mono mode: (St:oF)
Stereo mode selection
When an FM stereo broadcast is being received in stereo,
the STEREO indicator appears.
o If reception is poor, the STEREO indicator will not appear.
Mono mode selection
When the reception of an FM stereo broadcast is poor,
select this mode.
Use to receive broadcasts in mono to improve the sound.
You can store FM and AM stations into preset numbers 1 to
20 respectively.
1 Press the FM/AM button to select FM or AM
broadcast reception.
Each time you press the FM/AM button, the unit will
switch between FM and AM broadcast reception.
2 Turn the MULTI JOG dial to search for the
desired radio station.
3 After selecting a radio station, press the
MEMORY button.
The preset number and the MEMORY indicator blink
on the display.
4 Use the skip/search (.m/,/)
buttons to select the preset number that
you want to use to store that radio station.
5 Press the MEMORY button.
The radio station will be stored, and the preset number and the MEMORY indicator will stop blinking and
continue to appear on the display.
28
To save more radio station presets, repeat procedures
2
to 5.
Automatic presets
Listening to a preset station
The unit can automatically search for and add presets for
the stations that it can receive.
1 Press the FM/AM button to select FM or AM
broadcast reception.
Each time you press the FM/AM button, the unit will
switch between FM and AM broadcast reception.
2 Press and hold the MEMORY button for at
least two seconds.
“AUTO” appears on the display and the unit automatically adds presets for the stations that it can receive.
Press for at least
2 seconds
1 Press the FM/AM button to choose the
band.
2 Press a skip/search (.m/,/)
button repeatedly until you nd the preset
number of the radio station you want.
The preset number appears on the display.
o When a preset station is selected, the MEMORY
indicator appears.
o After manually selecting a station, the preset num-
ber and MEMORY indicator will disappear.
ENGLISH
o After 20 presets have been added automatically,
“FULL” will appear followed by preset 01 and reception of that station will start.
29
Wakeup timer
At the set time, sound will be output from the speakers.
o Adjust the clock before setting the timer (page 15).
Setting the timer
1 Put the unit into standby (power o).
The unit must be in standby to set the timer.
Press the STANDBY/ON button to put the unit into
standby.
2 Press and hold the TIMER button for at least
two seconds.
Press for at least
2 seconds
The timer indicator ( ) blinks and “SET TIMER” scrolls
across the display once. “ON TIME” appears and then
the time input mode becomes active.
The hour value blinks.
o If no action is taken for 20 seconds, timer setting
will end automatically.
30
3 Turn the MULTI JOG dial to set the timer
starting hour, and press the TIMER button.
o After setting the hour, the minutes blink.
4 Turn the MULTI JOG dial to set the timer
starting minute, and press the TIMER
button.
e
After making the TIMER ON setting, “OFF TIME” appears
and the hour value blinks.
Loading...
