RACLETTE GRILL SRGS 1400 B2
RACLETTE GRILL
Operating instructions
RACLETTE-GRILL
Bedienungsanleitung
RACLETTE-GRILL
Betjeningsvejledning
IAN 277059
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Før du læser, vend siden med billeder frem og bliv bekendt med alle apparatets funktioner.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.
GB / IE / NI Operating instructions Page 1
DK Betjeningsvejledning Side 15
DE / AT / CH Bedienungsanleitung Seite 29
A
A
B
Contents
Introduction ...................................................2
Intended use ..................................................2
Package contents ..............................................2
Appliance description ...........................................2
Technical details ...............................................3
Safety information .............................................3
Assembly and setting up ........................................6
Before first use ................................................6
Operation ....................................................7
Raclette ................................................................ 8
Grill ................................................................... 9
Cleaning and care .............................................10
Storage .....................................................11
Troubleshooting ..............................................11
Disposal .....................................................11
Kompernass Handels GmbH warranty ............................12
Service ................................................................13
Importer ............................................................... 13
Read these operating instructions carefully before using the appliance
for the first time and retain them for future reference. Please pass these
operating instructions on to any future owner(s).
SRGS 1400 B2
GB│IE│NI
│
1 ■
Introduction
Congratulations on the purchase of your new device.
You have selected a high-quality product. The operating instructions are part
of this product. They contain important information about safety, usage and
disposal. Before using the product, please familiarise yourself with all operating
and safety instructions. Use the product only as described and for the range of
applications specified. Please also pass these operating instructions on to any
future owner.
Intended use
This appliance is intended exclusively for grilling and heating food indoors.
This appliance is intended solely for use in private households. Do not use it for
commercial purposes.
Package contents
Raclette Grill (base, griddle and stone griddle)
8 pans
8 spatula
Operating instructions
NOTE
Check contents for completeness and damage immediately after unpacking.
Contact Customer Services if necessary.
Appliance description
Figure A:
Griddle
Temperature control
Heat-up indicator lamp
Power indicator lamp
Stone griddle
Figure B:
Pan
Spatula
│
■ 2
GB│IE│NI
SRGS 1400 B2
Technical details
Mains voltage 220 - 240 V ~, 50/60 Hz
Power consumption max. 1400 W
All parts of this appliance which come into
contact with food are food-safe.
Safety information
DANGER – RISK OF ELECTRICAL SHOCK!
► To prevent accidents, have defective plugs and/or power
cables replaced immediately by an authorised specialist
technician or our Customer Service department.
► Do not allow the power cable to come into contact with
hot appliance parts. Never use the appliance near naked
flames, a hotplate or a heated oven.
► Do not expose the appliance to rain, and never use it in
a humid or wet environment. Ensure that the power cable
never becomes wet or moist during operation.
► Check the device for visible external damage before use.
Do not operate a device that has been damaged or dropped.
► The power cable must be checked for signs of damage at
regular intervals. If the power cable is damaged, the appliance
may no longer be used.
SRGS 1400 B2
GB│IE│NI
│
3 ■
DANGER – RISK OF ELECTRICAL SHOCK!
► The appliance must be connected to a mains socket with a
protective earth.
► The device must not come into contact with moisture such as
rain or water.
Never immerse the appliance in water or any other liquid!
There is a risk of fatal electric shock if residual liquids come
into contact with live components during operation.
WARNING – RISK OF INJURY!
► This appliance may be used by children of the age of 8 years
or more and by persons with reduced physical, sensory or
mental capabilities or lack of experience and/or knowledge
only if they are being supervised or have been instructed with
regard to the safe use of the appliance and have understood
the potential risks.
► Children must not play with the device.
► Cleaning and user maintenance must not be performed by
children unless they are older than 8 years of age and are
supervised.
► Children younger than 8 years must be kept away from the
appliance and the power cable.
► After use, allow the appliance to cool down completely
before cleaning it. Risk of burns!
► If possible, set up the appliance close to a power socket.
Ensure that the power plug is quickly reachable in case of
danger, and that the cable poses no risk of tripping.
► Provide a stable location for the appliance.
► Touch only the temperature control while the appliance is in use.
The surfaces of the appliance become very hot during use.
│
■ 4
GB│IE│NI
SRGS 1400 B2
WARNING – RISK OF INJURY!
Caution! Hot surface!
CAUTION – PROPERTY DAMAGE!
► Do not use an external timer switch or a separate remote
control system to operate the appliance.
► Never leave the device unattended during operation.
► Ensure that the appliance, the power cable and the plug do
not come into contact with heat sources such as hotplates or
naked flames.
► Do not use charcoal or similar fuels to operate the appliance!
► To protect the non-stick coating on the pans and the grill, do
not use metallic tools such as knives, forks, etc.
► Operate the appliance only with the original accessories
supplied.
SRGS 1400 B2
GB│IE│NI
│
5 ■
Assembly and setting up
WARNING! RISK OF FIRE!
► Never place the device underneath wall cupboards or next to curtains,
cupboard walls or other flammable objects.
► Always place the appliance on a heat-resistant surface.
1) Take all the parts out of the box and remove the packaging material and any
protective wrapping or stickers.
2) Clean all of the components as described in the Chapter "Cleaning and care"
to remove any packaging residue. Ensure that all parts are completely dry.
3) Place the appliance on a clean and level heat-resistant surface. Do not place
the appliance directly next to a wall or a cupboard. Each person should have
unimpaired access to the pans .
4) Place the stone griddle on the side of the base unit where the indicator
lamps are located. The surrounding fat channel must be facing upwards, the
holding pins in the base must protrude into the recesses in the underside of the
stone griddle so that it sits firmly on the base.
5) Place the griddle onto the other side of the base. Here you can choose
between the smooth griddle or the grooved griddle surface. If you use the
grooved griddle, your food will have the typical grill pattern.
6) Push the pans into the device.
Before first use
The appliance is assembled and set up as described above.
1) Set the temperature control to MIN.
2) Insert the plug into a mains power socket. The power indicator lamp lights
up red to show that the appliance is connected to the mains.
3) Turn the temperature control to MAX. The heat-up indicator lamp lights
up green to show that the appliance is heating up. As soon as the heat-up
indicator lamp goes off, the appliance has heated up.
4) After 20 minutes, turn the temperature control to MIN.
5) Then pull out the plug and allow the appliance to cool down.
■ 6
│
GB│IE│NI
SRGS 1400 B2
NOTE
► The first time the appliance heats up, a small amount of smoke and odour
may be generated due to production-related residue. This is normal and is
completely harmless. Ensure sufficient ventilation; for example, by opening
a window.
6) Clean the griddle , the stone griddle , the spatula and the pans as
described in the section "Cleaning and care".
7) Ensure that all parts are completely dry before operating the device.
The appliance is now ready for use.
Operation
WARNING! RISK OF BURNS!
► If you want to move the appliance when it is hot, do not touch the metal
surfaces, the stone griddle or the griddle ! Hold the appliance as
shown below:
SRGS 1400 B2
GB│IE│NI
│
7 ■
Raclette
1) Oil the stone griddle and the griddle on the top and the pans on the
2) Insert the plug into a mains power socket. The power indicator lamp lights
3) Turn the temperature control to MAX. The heat-up indicator lamp lights
4) Fill the pans with the desired ingredients. Ensure that the pans are not
5) Place the pans into the device. The slight recess in the appliance helps to
6) Turn the temperature control towards MIN if you want to reduce the tem-
7) Remove the pans from the device as soon as the contents are cooked.
inside.
up red to show that the appliance is connected to the mains.
up green to show that the appliance is heating up. As soon as the heat-up
indicator lamp goes off, the appliance has heated up.
NOTE
► The heat-up indicator lamp may come on and go out several times
during this process. This is not an appliance malfunction! It merely indicates that the appliance is maintaining the set temperature.
► Depending on the room temperature, heating up will start at different
positions on the temperature control . The appliance does not heat
up at normal room temperature in the striped area of the temperature
control scale . If you turn the temperature control towards MAX,
you will hear a slight "click" and the appliance will start to heat up.
If you only want to use the raclette, allow the appliance to heat up for 10 minutes. If you want to use the stone griddle at the same time to grill food, wait
around 30 minutes until the stone griddle has heated up (see Chapter
"Grill").
The pans do not need to be pushed into the appliance while it is heating up.
overfilled otherwise the food could get too close to the heating elements and
could even touch them!
keep the pans in place.
perature. Turn the temperature control towards MAX if you want to increase
the temperature again.
■ 8
│
GB│IE│NI
SRGS 1400 B2
Grill
WARNING! RISK OF INJURY!
► Apart from the insulated handles, the pans are very hot! Therefore, hold
the pans only by the handle!
8) Empty the contents of the pan onto your plate using the spatula .
You can now refill the pan and push it back into the device. Do not push
used, but empty pans into the device. Any remaining food in the pans
could burn on.
NOTE
► Because of the non-stick coating in the pans , it is not necessary to re-
grease them before every use.
9) Once you have finished using the appliance, turn the temperature control
to "MIN" and remove the plug from the mains socket.
Using the griddle and the stone griddle , you can simultaneously grill meat,
vegetables or small pieces of fruit to accompany the raclette.
NOTE
► The griddle takes about 10 minutes to heat up. You cannot cook food
on the griddle until then!
► The stone griddle takes about 30 minutes to heat up. You cannot cook
food on the stone griddle until then!
1) Oil the stone griddle and the griddle on the top.
2) Place the food onto the stone griddle and griddle and turn it occasionally as required.
ATTENTION! PROPERTY DAMAGE!
► Do not use metal implements such as knives, forks, etc. when you remove
NOTE
► Over time, the stone griddle may become slightly discoloured. This will
SRGS 1400 B2
food from the griddle as they could damage the non-stick coating. If the
non-stick coating is damaged, stop using the appliance.
not impair its functionality.
│
GB│IE│NI
9 ■
Cleaning and care
DANGER – RISK OF ELECTRICAL SHOCK!
► Before cleaning the appliance, disconnect the power plug from the mains
power socket! There is a risk of electric shock!
Never immerse the device in water or any other liquid!
WARNING! RISK OF INJURY!
► Always allow the appliance to cool down before cleaning it. Otherwise
there is a risk of burns!
■ It is best to clean the device as soon as it has cooled down. This makes food
residues easier to remove.
ATTENTION! PROPERTY DAMAGE!
► Do not use abrasive or aggressive cleaning materials. These can damage
the surface of the appliance!
► Do not clean the components of the appliance in a dishwasher!
► Do not clean the stone griddle until it has cooled down. Otherwise the
stone griddle could crack and break.
■ Wipe the device housing and the heating elements with a moist cloth. If neces-
sary, put a little mild detergent on the cloth and wipe this off afterwards with
clear water. Dry everything properly.
■ Clean the griddle , the stone griddle , the spatula and the pans in
warm soapy water. Dry all parts properly after cleaning.
■ 10
NOTE
► You can also use a soft, non-abrasive sponge to clean the stone griddle .
► To remove undesirable odours such as fish smells, rub the stone griddle
down with a little lemon juice.
► The stone griddle takes longer to dry.
│
GB│IE│NI
SRGS 1400 B2
Storage
■ Allow the appliance to cool down before putting it away. You can store the
empty, cleaned pans in the appliance.
■ Store the cleaned device in a clean, dust-free and dry place.
Troubleshooting
Fault Cause The solution
The plug is not connected
to the mains power.
The appliance is not
working.
If the malfunction cannot be corrected using one of the suggestions above, or
if you have found some other kind of malfunction, please contact our Customer
Service department.
The mains power socket is
defective.
The appliance is defective.
Insert the plug into a
mains power socket.
Use a different mains
power socket.
Contact Customer
Services.
Disposal
Never dispose of the appliance in your normal domestic
waste. This product is subject to the provisions of European
Directive 2012/19/EU.
Dispose of the device via an approved disposal company or your municipal
waste facility. Please comply with all applicable regulations. Please contact
your waste disposal centre if you are in any doubt.
The packaging is made of environmentally friendly materials which you can
dispose of at your local recycling centre.
SRGS 1400 B2
GB│IE│NI
│
11 ■
Loading...
