Silvercrest SKRD 30 A1 User Manual [en, pl, cs]

Under-Cabinet Radio SKRD 30 A1

KOMPERNASS GMBH

BURGSTRASSE 21 · D-44867 BOCHUM

www.kompernass.com

ID-Nr.: SKRD 30 A1-09/10-V3

Under-Cabinet Radio

Operating instructions

Rádió

Használati utasítás

Rádio na vestavění

Návod k obsluze

Radio podwieszane

Instrukcja obsługi

Podelementni radio

Navodila za uporabo

Rádio

Návod na obsluhu

SKRD 30 A1

5 6 7 8 9 0 q w e r

uiopp

Index

Introduction . . . . . . . . . . . . . . 2

Information for these operating

instructions . . . . . . . . . . . . . . . . . . . . 2

Proper usage . . . . . . . . . . . . . . . . . . 2

Warning notices . . . . . . . . . . . . . . . .3

Safety . . . . . . . . . . . . . . . . . . . . . . . .4

Danger from electric shock . . . . . . . . 4

Handling of batteries . . . . . . . . . . . . 4

Basic Safety Instructions . . . . . . . . . .5

Operating components . . . . .6

Setting up and connecting . . .7

Safety instructions . . . . . . . . . . . . . . 7

Package contents and transport

inspection . . . . . . . . . . . . . . . . . . . . .7

Unpacking . . . . . . . . . . . . . . . . . . . . 7

Disposal of the packaging . . . . . . . . 8

Set-up location requirements. . . . . . .8

Electrical connection . . . . . . . . . . . . . 8

Inserting the battery . . . . . . . . . . . . . 9

Mounting under a wall cupboard . . 9

Disassembly . . . . . . . . . . . . . . . . . .10

Setting up the device . . . . . . . . . . . 10

Providing mains power . . . . . . . . . .10

VHF wire antenna . . . . . . . . . . . . .10

Handling and operation . . .11

Switching On and Oﬀ . . . . . . . . . .11

Basic settings . . . . . . . . . . . . . . . . .11

Activating the settings menu . . . . . 11

Setting the time . . . . . . . . . . . . . . . .12

Setting the date . . . . . . . . . . . . . . .12

Adjusting the display brightness . . .13

Setting the memory function . . . . . .13

Setting the time of day format . . . .14

Kitchen timer . . . . . . . . . . . . . . . . . .14

Setting the kitchen timer . . . . . . . . .14

Starting the kitchen timer . . . . . . . .15

Pausing the kitchen timer. . . . . . . . .15

Programming the kitchen timer . . . .16

Accessing the kitchen timer . . . . . .16

Programming alarm wake times . . .17

Wake with alarm tone . . . . . . . . . .17

Waken with radio . . . . . . . . . . . . . .18

Switching the alarm oﬀ . . . . . . . . . .18

When the wake time has arrived . .18

Radio operation . . . . . . . . . . . . . . .19

Switching the radio on/oﬀ . . . . . . .19

Adjusting the volume. . . . . . . . . . . .19

Manual station selection. . . . . . . . .19

Search for the next station . . . . . . .19

Saving stations manually . . . . . . . .20

Access saved stations . . . . . . . . . .20

Automatic station search

(AMS function) . . . . . . . . . . . . . . .20

Additional functions . . . . . . . . . . . .21

Automatic switch oﬀ (Sleep function) 21

Button lock . . . . . . . . . . . . . . . . . . . 21

Bass accentuation . . . . . . . . . . . . . .21

Cleaning . . . . . . . . . . . . . . . .22

Safety instructions . . . . . . . . . . . . . 22

Cleaning the housing . . . . . . . . . . .22

Troubleshooting . . . . . . . . . .22

Safety instructions . . . . . . . . . . . . . 22

Malfunction causes and remedies . 23

Storage/Disposal . . . . . . . . .24

Storage . . . . . . . . . . . . . . . . . . . . . .24

Disposal of the device . . . . . . . . . .24

Disposing of the batteries . . . . . . . .24

Appendix . . . . . . . . . . . . . . .25

Information regarding the

EG conformity declaration . . . . . . .25

Technical data . . . . . . . . . . . . . . . .25

Warranty . . . . . . . . . . . . . . . . . . . .26

Service . . . . . . . . . . . . . . . . . . . . . .26

Importer . . . . . . . . . . . . . . . . . . . . .26

SKRD 30 A1

Introduction

Information for these operating instructions

These operating instructions are a component of the Under-Cabinet Radio SKRD 30 A1 (henceforth designated as the device) and they provide you with important information about the intended use, safety, installation and connection as well as operation of the device.

The operating instructions must be kept available in the vicinity of the device at all times. They are to be read and used by anyone assigned to service and repair faults in the device.

Retain these operating instructions and pass them on with the device to any future owners.

This documentation is copyright protected. Any copying or reproduction, including as extracts, as well as the reproduction

of images, also in an altered state, is not permitted without the express written consent of the manufacturer.

Proper usage

This device is only intended for the reception of VHF radio programmes, as a kitchen timer and as an alarm by means of an alarm tone or radio in enclosed spaces. The device is intended as a free standing unit or for mounting under a cupboard. For these purposes the supplied stand and/or mounting plate must be used. Any other use or uses beyond those mentioned are considered unintended use. The device is not intended for use in commercial or industrial environments.

WARNING Danger from unintended use!

Danger from the device can result if it is used for unintended purposes and/or other types of use.

Use the device exclusively for intended purposes. ► Observe the procedures described in these operating instructions. ►

No warranty claims of any kind will be accepted for damage caused by improper use, unauthorised r replacement parts.

The operator alone bears liability.

s, unauthorised modiﬁ cations or for the use of unapproved

epair

SKRD 30 A1

Introduction

Warning notices

In the current operating instructions the following warning notices are used:

DANGER

A warning in this danger level indicates a hazard threatening situation.

In the ev or serious injury.

The directives in this warning are there in order to avoid the danger of ► death or serious injury.

WARNING A warning of this danger level signiﬁ es a possible dangerous

situation.

If the dangerous situation is not avoided it can lead to injuries.

The directives in this warning are there to avoid personal injuries. ►

IMPORTANT

A warning of this danger level signiﬁ es possible pr damage.

If the situation is not avoided it can lead to property damage.

The directives in this warning are there to avoid property damage. ►

ent that the hazardous situation is not avoided it can lead to death

operty

SKRD 30 A1

NOTICE

A notice signiﬁ es additional information that assists in the handling of the ► device.

Safety

In this section you receive important safety information regarding handling of the device.

This device complies with the statutory safety regulations. Incorrect usage can lead to injuries and property damage.

Danger from electric shock

DANGER

Risk of fatal electrocution! A life-t

hreatening situation can arise from contact with live

wires or components!

Observe the following safety instructions to avoid electric shock hazards:

Do not use the device if the mains power plug or the connection cable are ► damaged.

Do not, under any cir electric shock is present if the power carrying connections are touched or the electrical or mechanical construction is changed.

Handling of batteries

cumstances, open the device housing. The risk of an ►

Introduction

WARNING Danger from improper use!

For safe handling of batteries observe the following safety instructions:

Do not throw batteries into a ﬁ re. ► Do not short circuit batteries. ► Do not attempt to recharge batteries. ► Regularly check the condition of the batteries. Leaking battery acid can

►

cause permanent damage to the device. Special caution should be shown when handling damaged or leaking batteries. Danger from acid burns! W

ear protective gloves.

Store batteries in a place inaccessible to children. If swallowed seek ► immediate medical attention.

If you do not intend to use the de remove the batteries.

vice for an extended period of time, ►

SKRD 30 A1

Introduction

Basic Safety Instructions

For safe handling of the device observe the following safety instructions:

Before use check the device for visible external damage. Do not put into ■ operation a device that is damaged or has been dr

Damaged cables or connections should be replaced by authorised qualiﬁ ed ■ persons or by the customer service department.

Per

sons who, due to their physical, intellectual or motor abilities, are incapable ■ of operating the device safely may only use the device under supervision or direction fr

Only allow children to use the device under supervision. ■ Repairs should only be carried out by authorized specialist companies or by ■

the customer service department. Incorrect repairs can result in danger to the user

A repair to the device during the warranty period may only be carried out ■ by a customer service department authorized by the manufacturer otherwise no additional warr

Defective components may only be replaced with original replacement parts. ■ Only by using original replacement parts can you guarantee that the safety requir

Protect the device from moisture and liquid penetration. Never submerge the ■ device in water, do not place the device in the vicinity of water and do not stand any object ﬁ

Do not place any objects on the device. ■ Do not operate the device in the vicinity of open ﬂ ames (i.e. candles). ■ Avoid direct sunlight. ■ Always pull on the power plug when disconnecting from the wall socket, ■

never pull on the connection cable. If malfunctions occur or thunder storms thr

wall socket.

om a responsible person.

. In addition w

ements are complied with.

opped.

arranty claims become void.

anty claims can be considered for subsequent damages.

lled with liquid (i.e. vases) on the device.

eaten pull the po

wer plug from the ■

SKRD 30 A1

Operating components

(for illustrations see fold out sides ﬁ gure A)

Mounting plate/Stand

Control panel

Display

On/Oﬀ : On/Oﬀ switch (Radio)

AOT: Timer switch oﬀ

Lock/Mem.: Button lock/memory slot selection

Bass/AMS/Mode: Bass accentuation/Station search/Access setting menu

Alarm 1: Alarm 1 programming

Alarm 2: Alarm 2 programming

Preset–: selection of the previous memory slot

Preset+: selection of the next memory slot

Tune–: Decrease the reception frequency Tune+: Increase the reception frequency

VOLUME/Snooze/Timer: Volume control/Alarm switch oﬀ /Timer setting

Wire antenna for VHF reception

Mains connection cable

Recesses for stand

Speakers

Battery compartment

Unlocking buttons for the mounting plate

SKRD 30 A1

Setting up and connecting

Safety instructions

WARNING Damage may occur to property and injuries to people when

operating the device!

Observe the following safety instructions to avoid dangers:

Packaging material should not be used as a play thing. There is a risk of ► suﬀ ocation!

To av

oid risks to persons and property, observe the requirements for the ►

set-up location and the electrical connections.

Package contents and transport inspection

The device is delivered with the following components as standard:

Under-Cabinet Radio SKRD 30 A1 ▯ Mounting plate/Stand ▯ 4 Securing screws ▯ 1 x Battery 3 V Type CR2032 ▯ Operating instructions ▯

Unpacking

SKRD 30 A1

NOTICE

Check the contents to make sure everything is there and for visible damage. ► If the items supplied are incomplete, or damaged due to defective packaging ►

or transportation, contact the Service Hotline (see section Service

Remove all device parts and the operating instructions from the carton. ♦ Remove all packing material. ♦

Setting up and connecting

Disposal of the packaging

The packaging protects the device from transport damage. The packaging materials are selected from the point of view of their environmental friendliness and disposal technology and are therefore recyclable.

The recirculation of packaging into the material circuit saves on raw material and reduces generated waste. Dispose of packaging material that is no longer needed according to the regionally established regulations.

NOTICE

If possible preserve the device's original packaging during the warranty ► period so that in the case of a warranty claim you can package the device properly for r

Set-up location requirements

For the safe and fault free operation of the device, the set-up location must fulﬁ ll the following conditions:

When setting up the device place it on a ﬁ rm, ﬂ at and even surface. Use the ■ supplied stand.

Set up or mount the device in such a w ings and the speaker ar

Do not operate the device in a hot, wet or very humid location or in the vicin- ■ ity of ﬂ ammable materials.

The surfaces of furnitur ten the rubber feet on the device. If necessary, place an anti-slip mat under the rubber feet of the device.

The w can be quickly withdrawn from the socket.

eturn.

e not covered.

e may contain components that could aﬀ ect and sof- ■

all socket must be easily accessible so that, in an emergency, the plug ■

ay that the available ventilation open- ■

Electrical connection

Before connecting the device, compare the connection data (voltage and ■ frequency) on the rating plate of the device with that of your power supply network. This data must be compatible to av

Make sure that the device's connection cable is not damaged and is not ■ laying over hot surfaces and/or sharp edges.

e sur

Mak Do not allow the connection cord to hang over edges (Trip wire eﬀ ect). ■

oid possible damage to the device.

e that the connection cable is not tightly stretched or bent. ■

SKRD 30 A1

Setting up and connecting

Inserting the battery

By inserting the battery you can avoid the loss of programmed time of day and alarm times in the event of a possible power outage. The battery ensures that the internal clock continues to run even during a power failure. When power is restored the correct time appears automatically in the display

NOTICE

The device can also be operated without a battery. ►

Open the cover of the battery compartment ♦ device by turning the cover to the left, with a coin, as far as it will go and then lift oﬀ .

Insert the battery type CR2032 (supplied) into the battery compartment. ♦ The side with the marking + points upwards.

Close the battery compar turn it to the right.

Mounting under a wall cupboard

(Illustration see fold out side ﬁ gure B)

With the supplied mounting plate you can mount the device under, for example, a wall cupboard. For mounting of the device proceed as follows:

Press both unlocking buttons ♦ thereby, at the same time, sliding the mounting plate remove the mounting plate

Find a suitable set-up location for the device (see also the section ♦ Requirements for the set-up location).

Hold the mounting plate ♦ edge of the mounting plate should be approx. 4 cm behind the front of the cupboard so that, after Remove the mounting, the device is ﬂ ush with the cupboard.

Mark the 4 fastening points with a pencil. ♦ Using a spike or nail, make a small depression at the respective marking ♦

points. Screw the mounting plate illustrated in ﬁ gure B.

Place the device aslant, with the front recesses in the top face, in the mount- ♦ ing plate plate until the device audibly locks into place.

Check to make sure that the device is secure. ♦

. Press the rear part of the device upwards against the mounting

tment by attaching the cover and then with a coin ♦

on the rear panel of the device downwards

under the set-up location. Thereby the front

on the underside of the

backwards and

tightly with the supplied screws as

SKRD 30 A1

Disassembly

Press both unlocking buttons ♦ thereby sliding, at the same time, the device forward and then remove the device downwards.

Unscrew the screws on the mounting plate ♦ plate .

Setting up the device

As an alternative you can stand the device on a top. So as not to cover up the ventilation slots and the speaker up the device it must be mounted on the stand proceed as follows:

Press both unlocking buttons ♦ thereby, at the same time, sliding the mounting plate the mounting plate

Slide both front retaining tabs of the stand ♦ the underside of the device.

Press both rear retaining tabs of the stand ♦ the underside of the device until the stand audibly locks into place.

Find a suitable set-up location for the device (see also the section ♦ Requirements for the set-up location).

Setting up and connecting

on the rear panel of the device downwards,

and remove the mounting

on the underside of the device, when setting

. For assembly of the stand

on the rear panel of the device downwards

backwards and remove

. The mounting plate can now be used as a stand.

into the rear recesses 17 on

into the front recesses 17 on

Providing mains power

Insert the mains connection cable ♦ day will be shown in the display

VHF wire antenna

Unwind the wire antenna ♦

power plug into a socket. The time of

(0:00 o'clock).

completely for VHF reception.

SKRD 30 A1

Handling and operation

In this section you receive important information for the handling and operation of the device.

Switching On and Oﬀ

After the device has been connected to the power supply it is already switched on. Via the On/Oﬀ standby operation and radio.

NOTICE

The On/Oﬀ switch ► mains power. To completely disconnect the device from the mains power the mains power cable plug 16 must be pulled from the mains socket.

Basic settings

After the device has been connected to the mains power supply it shows the time of day and the day of the week in the display mode clock/standby operation.

Activating the settings menu

To activate the settings menu, whilst in the operational mode clock/standby operation, press the Bass/AMS/Mode begins to blink. Each further actuation of the Bass/AMS/Mode to the next setting potential. The menu item sequence is:

Setting the time of day ▯ Setting the date ▯ Adjusting the display brightness ▯ Setting the memory function ▯ Setting the time of day format ▯

button you switch between the operational modes clock/

does not disconnect the device completely from the

button. The time of day, shown in the display 3,

. The device is in the operational

button switches

SKRD 30 A1

NOTICE

The setting menu ends automatically if you do not actuate any buttons for ► approx. 15 seconds. The executed setting is saved.

Setting the time

Prerequisite: The device is in the operational mode clock/standby operation.

Press the Bass/AMS/Mode ♦ begins to blink.

Set with the buttons Tune+ ♦ each button press the time of day changes by one minute. Holding down the respective button for more than 2 seconds starts the speed setting.

Press the Bass/AMS/Mode ♦ move to the next menu item.

NOTICE

The time of day will revert back to 00:00 o'clock if the device is disconnected ► from the mains power supply and no battery is inserted or if the battery is too weak.

Setting the date

Prerequisite: The device is in the operational mode clock/standby operation.

Press the Bass/AMS/Mode ♦ blink.

Set with the buttons Tune+ ♦ button press the date is changed by one day. The weekday indicator changes automatically. Holding down the respective button for more than 2 seconds starts the speed setting.

Press the Bass/AMS/Mode ♦ move to the next menu item.

Handling and operation

button once. The time of day indicator

and Tune– 12 the current time of day. With

button again to save the current setting and

button twice. The date indicator begins to

and Tune– 12 the current date. With each

button again to save the current setting and

NOTICE

The date will revert back to 01.01.2010: if the device is disconnected from ► the mains power supply and no battery is inserted or if the battery is too weak.

SKRD 30 A1

Handling and operation

Adjusting the display brightness

Prerequisite: The device is in the operational mode clock/standby operation.

Press the Bass/AMS/Mode ♦ display brightness is shown (H=bright or L=dim).

Set, with the button Tune+ ♦ display to be brighter.

Set, with the button Tune– ♦ display to be darker.

Press the Bass/AMS/Mode ♦ move to the next menu item.

Setting the memory function

You can set up to 10 date reminders to which an automatic reminder will be triggered. The function SdA (SdA=Special Day Alert) is useful as a reminder, for example, of birthdays or other recurring events. The reminder occurs every year on the same date.

Prerequisite: The device is in the operational mode clock/standby operation.

Press the Bass/AMS/Mode ♦ selected reminder date is shown alternating with the indicator SDA. Next to the indicator SDA is the number of the memory slot for that date. Possible reminders are SDA 0 to SDA 0.

Select with the buttons Preset+ ♦ date to be set.

Set with the buttons Tune+ ♦ With each button press the date is changed by one day. Holding down the respective button for more than 2 seconds starts the speed setting.

button three times. The current setting for the

, the display brightness to H if you want the

, the display brightness to L if you want the

button again to save the current setting and

button four times. The current setting of the

and Preset– 10 the memory slot for the

and Tune– 12 the date for this memory slot.

SKRD 30 A1

NOTICE

Press the button AOT ► for the currently selected memory slot. In the display -- -- is shown.

Press the button Lock/Mem. ♦ function is to be triggered. The setting is carried out with the buttons Tune+

and Tune– programmed reminder dates

Press the Bass/AMS/Mode ♦ move to the next menu item.

on the hour between 00 and 23. This setting applies to all

if you want to switch oﬀ the reminder function

to set the time of day at which the reminder

button again to save the current setting and

Setting the time of day format

Prerequisite: The device is in the operational mode clock/standby operation.

Press the Bass/AMS/Mode ♦ time of day format is shown (24=24 hour format or 12=12 hour format).

With the button Tune+ ♦ time of day display in the 24 hour format .

With the button Tune– ♦ time of day display in the 12 hour format .

Press the Bass/AMS/Mode ♦ move to the next menu item.

set the time of day format to 24 if you want a

set the time of day format to 12 if you want a

Kitchen timer

The device has a convenient kitchen timer with which, for example, cooking and baking times can be monitored. The programmable time range of the kitchen timer lies between 1 minute and 23 hours, 59 minutes.

Setting the kitchen timer

Press the Snooze/Timer ♦ upper corner of the display the saucepan symbol for the kitchen timer is superimposed.

Turn the VOLUME ♦ Turning in a clockwise direction increases the time; turning in a counter clockwise direction reduces the time.

knob to set the time range for the kitchen timer.

Handling and operation

button ﬁ ve times. The current setting for the

button again to save the current setting and

button. The display shows 00:00. In the right

NOTICE

If, during the setting, approx. 15 seconds passes without any changes ► taking place the device reverts back to the previous operational mode.

SKRD 30 A1

Handling and operation

Starting the kitchen timer

After setting the time press the button Snooze/Timer ♦ time begins to run backwards. In the right, upper corner of the display a backwards running clock is superimposed.

NOTICE

If, during the operation of the kitchen timer, another function is selected ► the display of the remaining time fades out. The saucepan symbol and the

d running clock in the right, upper corner of the display, however,

backwar continue to be shown. Press the button Snooze/Timer the remaining time of the kitchen timer to be shown once more.

30 seconds before the kitchen timer run time has expired the device begins to acoustically indicate, with individual signal tones, the arrival of the set time. Thereby the interval between the individual tones becomes shorter and shorter. When the set time has arrived the kitchen timer's alarm signal sounds as a continuous tone.

Press the button Snooze/Timer ♦

Pausing the kitchen timer.

Press, while the kitchen timer is running, the button Snooze/Timer ♦ kitchen timer is paused. The displayed remaining time begins to blink.

NOTICE

After approx. 15 seconds the device reverts back to the previous operational ► mode. Press the button Snooze/Timer of the kitchen timer to be shown once more.

To restart the kitchen timer press the button Snooze/Timer ♦ kitchen timer restarts.

To switch oﬀ the kitchen timer before the set time has expired press and hold ♦ down the Snooze/Timer

button for at least 2 seconds.

again. The displayed

again to allow

to switch oﬀ the kitchen timer alarm signal.

again to allow the remaining time

again. The

. The

SKRD 30 A1

Handling and operation

Programming the kitchen timer

You can preprogramme the kitchen timer with the most frequently used times so that it is not necessary to continually reenter them. Up to 10 times can be preprogrammed. All 10 memory slots are preprogrammed with 10 minutes as standard.

For the programming of the kitchen timer proceed as follows:

Press the button Snooze/Timer ♦ Turn the VOLUME ♦

clockwise direction increases the time; turning in a counter clockwise direction reduces the time.

Press the button Lock/Mem. ♦ kitchen timer saucepan symbol a blinking T is shown.

Select with the buttons Preset+ ♦ T0 and T9 for the timer that is to be set.

Press the button Lock/Mem. ♦ selected memory slot. The blinking T under the saucepan symbol is now showing constantly.

Repeat the process for the other memory slots. ♦

knob to set the time to be programmed. Turning in a

Accessing the kitchen timer

To access a programmed time for the kitchen timer proceed as follows:

Press the button Snooze/Timer ♦ Select with the buttons Preset+ ♦

T0 and T9. Press the button Snooze/Timer ♦

to activate the timer selection. Under the

again to programme the set time on the

to activate the kitchen timer.

and Preset– 10 a memory slot between

to activate the kitchen timer.

and Preset– 10 the desired timer between

again to start the kitchen timer.

SKRD 30 A1

Handling and operation

Programming alarm wake times

The device has two alarms available. All settings for both alarms can be carried out independently from each other. You can select whether at the programmed time an alarm tone shall sound or the radio shall play.

NOTICE

If, during alarm wake programming, no button is pressed for approx. ► 15 seconds the alarm will activate with the current settings.

equisite: The device is in the operational mode clock/standby operation.

Prer

To set the wake time proceed as follows:

Press the Alarm1 button ♦ of the respective alarm is shown blinking in the display 3 and the indicator A1 and/or A2 appears. The weekday on which this alarm is to be activated is shown above the time indicator.

Set with the buttons Tune+ ♦ each button press the wake time changes by one minute. Holding down the respective button for more than 2 seconds starts the speed setting.

Press the button AOT ♦ Sa-Su or Mo-Su. The respective selected combination is shown above the wake time.

Press and hold down the button AOT ♦ between the weekday combinations and individual weekday setting alternatives.

or the Alarm2 button 9. The set wake time

to switch between the weekday combinations Mo-Fr,

and Tune– 12 the desired wake time. With

for at least 2 seconds to switch

NOTICE

With the individual weekday setting alternative you switch between ► the days of the week with the button AOT

Wake with alarm tone

Prerequisite: The device is in the operational mode clock/standby operation.

To select "Alarm tone" for the respective alarm press the Alarm1 button ♦ or the Alarm2 button

the symbol

SKRD 30 A1

appears.

several times in succession until, in the display 3,

Handling and operation

Waken with radio

If you want to be woken by the radio, before activating the wake time carry out the following settings:

Switch the radio on by pressing the On/Oﬀ ♦ Select the station with which you want to be woken (see section ♦

Station setting). With the VOL

Volume settings). Switch the radio oﬀ by pressing the On/Oﬀ ♦ To select "Radio" for the respective alarm press the Alarm1 button ♦

Alarm2 button symbol

Switching the alarm oﬀ

Prerequisite: The device is in the operational mode clock/standby operation.

To switch oﬀ the respective alarm press the Alarm1 button ♦ button display 3.

When the wake time has arrived

With the setting "Wake with alarm tone" a fourfold signal tone sounds in intervals of 2 seconds. The volume of the signal tone will continually increase until the maximum volume has been reached. The duration of the wake signal is restricted to 10 minutes.

With the setting "Wake with radio" the radio will switch on. The previously selected station will be activated for a maximum of 60 minutes at the set volume.

Press the button Snooze/Timer ♦

UME ♦

appears.

several times in succession until no symbols are shown in the

knob set the desired volume (see section

several times in succession until, in the display 3, the

button.

or the Alarm2

to activate a repeat wake after 9 minutes.

or the

NOTICE

The repeat wake function is possible up to 60 minutes after the set wake ► time has arrived.

♦

Press the Alarm1 button alarm.

NOTICE

The alarm becomes active again when the next wake time has arrived ► (i.e. on the next day).

or the Alarm2 button 9 to end the current

SKRD 30 A1

Handling and operation

Radio operation

NOTICE

For a good radio reception the wire antenna ► coiled. Adjust the antenna, whilst in radio operation, to the best reception.

The technical factors of the device allow for tuning reception frequencies ► outside of the permitted VHF (FM) range of 87.5–108 MHz. In some countries, diﬀ frequency ranges. Please note that information received outside of the assigned radio frequency ranges may not be exploited, passed on to third parties or otherwise misused.

Switching the radio on/oﬀ

Switch the radio on by pressing the On/Oﬀ ♦ shows the current reception frequency of the tuned station.

Switch the radio oﬀ by pressing the On/Oﬀ ♦ changes back to the operational mode clock/standby operation. The current time of day is shown.

Adjusting the volume.

With the VOLUME ♦ direction increases the volume; turning in a counter clockwise direction reduces the volume. The volume level is shown on the left border of the display

erent national regulations may apply to the assigned radio

knob set the desired volume. Turning in a clockwise

must be completely un-

button.The display 3

button again.The device

Manual station selection

By a single press on the buttons Tune+ ♦ station. The frequency of the station is shown in the display tuning the speaker is switched oﬀ .

Search for the next station

The device can automatically search for the nearest station.

Press and hold down the button Tune+ ♦ The device searches for the nearest station with suﬃ cient reception quality.

Repeat this process until you have found the station you are looking for. ♦

SKRD 30 A1

and Tune– 12 tune the desired

or Tune- 12 for at least two seconds.

. During the

Handling and operation

Saving stations manually

Prerequisite: The device is in the radio operational mode.

The device has 30 memory slots available for station frequencies. To save a station frequency proceed as follows:

Tune, as described previously, the desired station. ♦ Press the button Lock/Mem. ♦

the lower, right corner of the display. Select with the buttons Preset+ ♦

for the tuned station between 1 and 30. Press the button Lock/Mem. ♦

station is saved on the selected memory slot. The symbol MEM lights up constantly.

Access saved stations

Prerequisite: The device is in the radio operational mode.

Select with the buttons Preset+ ♦ for the saved station between 1 and 30.

Automatic station search (AMS function)

Prerequisite: The device is in the radio operational mode.

To allocate the memory slots to the station frequencies with the strongest receivable stations a station search can be carried out.

once. The symbol MEM begins to blink in

and Preset– 10 the desired memory slot

again. The reception frequency of the tuned

and Preset– 10 the desired memory slot

NOTICE

With the carrying out of the following described function all previously ► saved stations will be lost.

Press and hold do seconds. The device begins the station search and allocates to the memory slots 1-30 the found stations.

NOTICE

If more than 30 stations are found only the ﬁ rst 30 reception frequencies ► will be saved.

If less than 30 stations are found the last memor

wn the button Bass/AMS/Mode ♦

for at least two

y slots remain unchanged. ►

SKRD 30 A1

Handling and operation

Additional functions

Automatic switch oﬀ (Sleep function)

With the sleep function the radio switches itself oﬀ after a time lapse of between 5 and 120 minutes.

To access the function press the button AOT ♦ until the radio switches itself oﬀ is shown.

Press the button AOT ♦ the button for more than 2 seconds starts the speed setting.

NOTICE

The setable time frame lasts from 120 to 5 minutes. The setting takes place ► in stages of 5 minutes. After which the indicator OFF appears. With the indicator OFF the sleep function is switched oﬀ

Button lock

You can lock the buttons of the device so that settings cannot be altered by unauthorised people or children.

Press and hold down the button Lock/Mem. ♦ switch the button lock on or oﬀ . When the button lock is switched on the symbol

repeatedly to set the desired time. Holding down

appears in the display.

. The current remaining time

for at least two seconds to

Bass accentuation

With the bass accentuation you can switch on an enhanced playback of the low frequencies.

Prerequisite: The device is in the radio operational mode.

SKRD 30 A1

Press brieﬂ y the button Bass/AMS/Mode ♦ on or oﬀ . With the bass accentuation switched on the symbol BASS appears in the display.

to switch the bass accentuation

Cleaning

Safety instructions

DANGER

Life-threatening situation from electric shock!

Remo

ve the plug from the mains power socket before cleaning. ►

IMPORTANT

Damaging of the device!

Make sur in order to avoid irreparable damage to it.

e when you are cleaning the device that no moisture gets inside ►

Cleaning the housing

Clean the surfaces of the device with a soft, dry cloth. ■

Troubleshooting

In this section you receive important information for the localization and remedying of malfunctions. Observe the instructions in order to avoid danger and damage.

Cleaning/Troubleshooting

Safety instructions

WARNING

Observe the following safety information to avoid danger and property damage:

Repairs to electronic devices may only be carried out by specialists who ► have been trained by the manufacturer. Considerable danger to the consumer and damage to the device can occur as a r

esult of incorrect repairs.

SKRD 30 A1

Troubleshooting

Malfunction causes and remedies

The following table will help with localizing and remedying minor malfunctions:

Defect Possible cause Solution

The display is showing nothing.

No sound

Noisy radio reception

NOTICE

The plug is not inserted.

Mains power socket is not supplying power.

The volume is set to minimum.

The radio is switched oﬀ .

The radio station is not properly tuned in.

Reception is too weak.

If you cannot solve the problem with the aforementioned methods, please ► contact Customer Service.

Insert the plug into the mains power socket.

Check the circuit fuse.

Increase the volume with the VOLUME

Switch the radio on with the On/Oﬀ

Tune the station correctly with the buttons Tune+

Try to improve reception by moving the wire antenna

button.

knob.

and Tune– 12.

SKRD 30 A1

Storage/Disposal

Storage

If you do not intend to use the device for an extended period of time, disconnect it from the mains power supply, remove the battery and store it at a clean, dry location that is not subjected to direct sunlight.

Disposal of the device

Do not dispose of the device in your normal domestic waste. This product is subject to the European directive 2002/96/EC-WEEE (Waste Electrical and Electronic Equipment).

Dispose of the device through an approved disposal centre or at your community waste facility. Observe the currently applicable regulations. In case of doubt, please contact your waste disposal centre.

Disposing of the batteries

Batteries must not be disposed of in the household waste. Every consumer is legally obligated to hand in batteries at a collection centre in his/her community/district or a dealer. This obligation is intended to ensure that batteries are disposed of in an environmentally friendly manner. Hand batteries in only when they are fully discharged.

SKRD 30 A1

Appendix

Information regarding the EG conformity declaration

This device complies regarding conformance to the basic requirements and other relevant regulations of the European directive for electromagnetic compatibility 2004/108/EC, the low voltage directive 2006/95/EC as well as the Ecodesign directive 2009/125/EC (Supplement 1275/2008 Appendix II, Nr.1)

The complete original declaration of conformity can be obtained from the importer.

Technical data

Operational voltage 220-240 V / 50 Hz

Battery for data retention

Power consumption

Operation approx. 5 W

1 x 3 V Type CR2032

(supplied)

SKRD 30 A1

Standby approx. 1.8 W

Speaker power output:

Radio frequency range (VHF) 87.5 - 108 MHz

Operating temperature +5 - +40 °C

Humidity (no condensation) 5 - 90 % Measurements (H x W x D):

(without stand) Weight approx. 600 g

Protection class

(with 10 % harmonic distortion)

4.9 x 22 x 12 cm

approx. 1W

Warranty

With this device you receive a 3 year warranty from the date of purchase. The device has been manufactured with care and meticulously examined before delivery.

Please retain your receipt as proof of purchase. In the case of a warranty claim, please get in touch, by telephone, with our service department. Only in this way can a post-free dispatch for your goods be assured.

NOTICE

The device is intended solely for private, non-commercial use. If this product has been subjected to improper or inappropriate handling, abuse, or modiﬁ cations not carried out by one of our authorised sales and service outlets, the warranty becomes void.

Your statutory rights are not restricted in any way by this warranty. The warranty period will not be extended as a result of warranty adjustments. This applies also to replacement and repaired parts.

Possible damage and/or faults present at the time of purchase must be reported immediately after unpacking or, at the very latest, within two days after the purchase date.

After expiry of the warranty period incidental repairs are subject to payment.

Appendix

The warranty adjustment is valid only for material or manufacturing defects ► not, however, for transport damage, wear and tear or for damage to breakable parts, i.e. switches or r

echargeable batteries.

Service

Importer

DES UK LTD

Tel.: 0871 5000 700 E-Mail: support.uk@kompernass.com

Kompernass Service Ireland

Tel: 1850 930 412

Standard call rates apply. Mobile operators may vary.

E-Mail: support.ie@kompernass.com

KOMPERNASS GMBH BURGSTRASSE 21 44867 BOCHUM, GERMANY www.kompernass.com

(£ 0.10 / minute)

(0,082 EUR/Min.)

SKRD 30 A1

Spis treści

Wprowadzenie . . . . . . . . . . . . .28

Informacje o niniejszej instrukcji obsługi .28

Prawo autorskie . . . . . . . . . . . . . . . . . .28

Użycie zgodne z przeznaczeniem . . .28

Wskazówki ostrzegawcze . . . . . . . . . .29

Bezpieczeństwo . . . . . . . . . . . . . . . . . .30

Niebezpieczeństwo porażenia

prądem elektrycznym . . . . . . . . . . . . .30

Postępowanie z bateriami . . . . . . . . . .30

Podstawowe wskazówki bezpieczeństwa 31

Elementy obsługowe . . . . . . . .32

Ustawianie i podłączanie . . . .33

Wskazówki bezpieczeństwa . . . . . . . .33

Zakres dostawy i przegląd po

rozpakowaniu . . . . . . . . . . . . . . . . . . .33

Rozpakowanie . . . . . . . . . . . . . . . . . . .33

Utylizacja opakowania . . . . . . . . . . . .34

Wymagania dotyczące miejsca

ustawienia . . . . . . . . . . . . . . . . . . . . . .34

Przyłącze elektryczne . . . . . . . . . . . . . 34

Wkładanie baterii . . . . . . . . . . . . . . . . 35

Podwieszanie pod wiszącą szafką . . .35

Demontaż . . . . . . . . . . . . . . . . . . . . . . 36

Ustawianie urządzenia . . . . . . . . . . . . 36

Podłączanie do zasilania prądem . . . .36

Antena przewodowa UKW . . . . . . . . 36

Obsługa i użytkowanie . . . . . .37

Włączanie i wyłączanie . . . . . . . . . . .37

Ustawienia podstawowe . . . . . . . . . . .37

Otwieranie menu ustawień . . . . . . . . .37

Ustawianie godziny . . . . . . . . . . . . . . . 38

Ustawianie daty . . . . . . . . . . . . . . . . . .38

Regulacja jasności wyświetlacza . . . . .39

Ustawianie funkcji przypominania . . . .39

Ustawianie formatu czasu . . . . . . . . . .40

Minutnik . . . . . . . . . . . . . . . . . . . . . . . . 40

Ustawianie czasomierza kuchennego .40

Włączanie minutnika . . . . . . . . . . . . . . 41

Przerywanie odliczania czasu na

minutniku . . . . . . . . . . . . . . . . . . . . . . . 41

Programowanie minutnika . . . . . . . . . .42

Wyświetlanie czasu minutnika . . . . . . .42

Programowanie czasów budzenia . . .43

Budzenie dźwiękiem alarmu . . . . . . . .43

Budzenie radiem . . . . . . . . . . . . . . . . .44

Wyłączanie budzika . . . . . . . . . . . . . .44

Gdy nadejdzie czas budzenia . . . . . . 44

Słuchanie radia . . . . . . . . . . . . . . . . . .45

Włączanie/wyłączanie radia . . . . . . .45

Ustawianie głośności . . . . . . . . . . . . . .45

Ręczne wyszukiwanie stacji . . . . . . . . .45

Wyszukiwanie następnej stacji . . . . . . 45

Ręczne zapamiętywanie stacji . . . . . .46

Nastawianie zaprogramowanej stacji .46 Automatyczne wyszukiwanie stacji

(funkcja AMS) . . . . . . . . . . . . . . . . . . .46

Pozostałe funkcje . . . . . . . . . . . . . . . . .47

Automatyczne wyłączanie (funkcja sleep) 47

Blokada przycisków . . . . . . . . . . . . . . .47

Wzmacnianie tonów niskich . . . . . . . . 47

Czyszczenie . . . . . . . . . . . . . . .48

Wskazówki bezpieczeństwa . . . . . . . .48

Czyszczenie obudowy . . . . . . . . . . . .48

Usuwanie usterek . . . . . . . . . . .48

Wskazówki bezpieczeństwa . . . . . . . .48

Przyczyny błędów i ich usuwanie . . . . 49

Przechowywanie/Utylizacja . .50

Przechowywanie . . . . . . . . . . . . . . . . .50

Utylizacja urządzenia . . . . . . . . . . . . .50

Utylizacja akumulatorów . . . . . . . . . . . 50

Załącznik . . . . . . . . . . . . . . . . . .51

Wskazówki dotyczące deklaracji

zgodności WE . . . . . . . . . . . . . . . . . . .51

Dane techniczne . . . . . . . . . . . . . . . . .51

Gwarancja . . . . . . . . . . . . . . . . . . . . . . 52

Serwis . . . . . . . . . . . . . . . . . . . . . . . . . 52

Importer . . . . . . . . . . . . . . . . . . . . . . . .52

SKRD 30 A1

Wprowadzenie

Informacje o niniejszej instrukcji obsługi

Niniejsza instrukcja obsługi stanowi część radia podwieszanego SKRD 30 A1 (zwanego dalej urządzeniem) i zawiera ważne wskazówki dotyczące użytkowania zgodnie z przeznaczeniem, bezpieczeństwa, podłączania oraz obsługi urządzenia.

Instrukcję obsługi należy przechowywać stale w pobliżu urządzenia. Instrukcję musi przeczytać każda osoba, która będzie się zajmowała obsługą i usuwaniem usterek urządzenia.

Przechowuj instrukcję obsługi i w razie odsprzedaży radioodtwarzacza przekaż ją wraz z urządzeniem nowemu właścicielowi.

Prawo autorskie

Niniejsza dokumentacja jest prawnie chroniona. Wszelkie rozpowszechnianie, wzgl. przedruk, także we fragmentach, jak

również odtwarzanie ilustracji, nawet w zmienionym stanie, wymaga uzyskania pismnej zgodny producenta.

Użycie zgodne z przeznaczeniem

Niniejsze urządzenie jest przeznaczone do odbioru programów radiowych UKF, posiada funkcję minutnika i budzika budzącego dzwonkiem alarmu lub radiem i jest przeznaczone wyłącznie do pracy w pomieszczeniach zamkniętych. Urządzenie jest przystosowane do stawiania i do powieszania pod szafką. Należy do tego użyć dołączonej podstawki wzgl. płytki montażowej. Inne lub wykraczające poza powyższe użytkowanie, uznaje się za niezgodne z przeznaczeniem. Urządzenie nie jest przeznaczone do zastosowań przemysłowych ani profesjonalnych.

OSTRZEŻENIE Niebezpieczeństwo spowodowane użytkowaniem niezgodnie

z przeznaczeniem!

Użytkowanie urządzenia niezgodnie z jego przeznaczeniem i/lub inne wykorzystanie urządzenia może wiązać się z różnymi zagrożeniami.

Urządzenie należy użytkować wyłącznie zgodnie z jego przeznaczeniem. ► Należy przestrzegać opisanych w niniejszej instrukcji obsługi metod ►

postępowania.

Wszelkie r z przeznaczeniem, niefachowych napraw, niedozwolonych zmian i stosowania niedopuszczonych części zamiennych, wykluczone.

Wszelkie ryzyko ponosi wyłącznie użytkownik.

oszczenia z powodu szkód wynikających z użytkowania niezgodnie

SKRD 30 A1

+ 128 hidden pages

Silvercrest SKRD 30 A1 User Manual [en, pl, cs]

Specifications and Main Features

Frequently Asked Questions

User Manual
