PPHA 20-Li B2
GB│CY
│
1 ■
CORDLESS PLANER 20V
PPHA20-Li B2
Introduction
Congratulations on the purchase of your new
appliance. You have selected a high-quality product.
The operating instructions are part of this product.
They contain important information about safety,
usage and disposal. Before using the product, please
familiarise yourself with all operating and safety
instructions. Use the product only as described and
for the specified range of applications. Please also
pass these operating instructions on to any future
owner.
Intended use
The appliance is designed for planing workpieces
such as beams or planks that are firmly held in
place. The appliance is also suitable for chamfering
edges and for grooving. Any other uses of or
modifications to the appliance are deemed to be
improper usage and may result in serious physical
injury. The manufacturer accepts no responsibility
for damage(s) attributable to misuse. This appliance is not intended for commercial use.
Features
Safety lock-out
ON/OFF switch
Chip ejector (optionally right/left)
Belt cover
Battery display LED
Battery charge level button
Release button for the battery pack
Screws for belt cover
Fastening screw for the rip fence/fold depth
stop
Plane sole
V grooves
Marking for cut depth scale
Cut depth scale
Dial for setting the cut depth (additional handle)
Adapter for external extraction
Parking shoe
Cutter block
Clamping element
Fastening screw for the planing blade
Planing blade
20a
Tensioning plate groove
Hex screws
Lateral cutter block guard
Drive belt
Large belt wheel
Small belt wheel
Open-ended spanner
Hex key
Fold depth stop (not supplied)
28a
Rip fence (not supplied)
Battery pack*
High-speed charger*
Red charge control LED
Green charge control LED
v Ready2Connect LED
b Accessory compartment
Package contents
1 cordless planer 20V
1 hex key (see fig. G)
1 open-ended spanner (see fig. G)
1 adapter for external extraction
1 carrying case
1 set of operating instructions
■
2 │ GB
│
CY
PPHA 20-Li B2
Technical details
Cordless Planer 20V PPHA20-Li B2
Rated voltage 20 V (DC)
Rated idle speed n
Plane width 82 mm
Cut depth 0–2 mm
Fold depth max. 17 mm
Maximum high-frequency
output 10dBm
Battery PAP 20 B3*
Type LITHIUM ION
Rated voltage 20 V
Capacity 4.0 Ah
Cells 10
High-speed battery charger PLG 20 C3*
INPUT
Rated voltage 230–240 V ∼ 50 Hz (AC)
Rated power
consumption 120 W
Fuse (internal) 3.15 A
OUTPUT
Rated voltage 21.5 V (DC)
Rated current 4.5 A
Charging time approx. 120 min.
Protection class II /
* BATTERY AND CHARGER ARE NOT SUPPLIED
Noise and vibration data
Noise measurement value determined in
accordance with EN62841. The A-rated
noise level of the power tool is typically:
Noise emission value
Sound pressure level L
Sound power level L
Uncertainty K = 3 dB
= 14000 rpm
0
(DC)
T3.15A
(double insulation)
= 88.3 dB (A)
PA
= 99.3 dB (A)
WA
Total vibration value
Handle a
= 3.944 m/s
h
Additional handle ah = 5.950 m/s
Uncertainty K = 1.5 m/s
NOTE
► For an accurate estimate of the vibration load
during a specific working period, the periods
during which the appliance is switched off or
is running but not actually being used must
also be taken into consideration. This can
significantly reduce the vibration load over
the total working period.
► The vibration emission values and the noise
emission values given in these instructions
have been measured in accordance with a
standardised test procedure and can be used
for comparison of the power tool with another
tool.
► The specified total vibration values and the
noise emission values can also be used to
make a provisional load estimate.
WARNING!
► Depending on the manner in which the power
tool is being used and, in particular, the kind
of workpiece being worked, the vibration and
noise emission values can deviate from the
values given in these instructions during actual
use of the power tool. Try to keep the vibration loads as low as possible. Measures to
reduce the vibration load are, e.g. wearing
gloves and limiting the working time. Wherein
all states of operation must be included (e.g.
times when the power tool is switched off and
times where the power tool is switched on but
running without load).
2
2
2
Wear ear muffs!
PPHA 20-Li B2
GB│CY
│
3 ■
General power
tool safety warnings
WARNING!
► Read all safety warnings, instructions,
illustrations and specifications provided
with this power tool. Failure to follow all
instructions listed below may result in electric
shock, fire and/or serious injury.
Save all warnings and instructions for future
reference.
The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or batteryoperated (cordless) power tool.
1. Work area safety
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmos-
pheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can
cause you to lose control.
2. Electrical safety
a) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets
will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of
electric shock if your body is earthed or
grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord
for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
e) When working outdoors with an electrical
power tool always use extension cords that
are also suitable for use outdoors. Use of a
cord suitable for outdoor use reduces the risk
of electric shock.
f) If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD
re duces the risk of electric shock.
3. Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired
or under the influence of drugs, alcohol or
medication.
A moment of inattention while operating a power
tool may result in serious personal injury.
b) Use
personal protective equipment. Always
wear safety goggles. Protective equipment such
as a dust mask, non-skid safety shoes, hard hat or
hearing protection used for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to power source and/or battery pack, picking
up or carrying the tool. Carrying power tools
with your finger on the switch or energising
power tools that have the switch on invites
accidents.
d) Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key
left attached to a rotating part of the power tool
may result in personal injury.
e) Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away
from moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.
g) If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used.
Use of dust collection can reduce dust-related
hazards.
■
4 │ GB
│
CY
PPHA 20-Li B2
h) Do not allow yourself to get lulled into a false
sense of security and do not ignore the safety
regulations for power tools, even if you are
familiar with the power tool after repeated
use. A careless action can cause severe injury
within a fraction of a second.
4. Power tool use and care
a) Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at
the rate for which it was designed.
b) Do not use the power tool if the switch does
not turn it on and off. Any power tool that
cannot be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source
and/or remove the battery pack, if detachable, from the power tool before making any
adjustments, changing accessories, or storing
power tools. Such preventive safety measures
reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of
children and do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool. Power tools are
dangerous in the hands of untrained users.
e) Maintain power tools and accessories. Check
for misalignment or binding of moving parts,
breakage of parts and any other condition
that may affect the power tool’s operation. If
damaged, have the power tool repaired
before use. Many accidents are caused by
poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to
control.
g) Use the power tool, accessories and tool bits,
etc. in accordance with these instructions,
taking into account the working conditions
and the work to be performed. Use of the
power tool for operations different from those
intended could result in a hazardous situation.
h) Keep handles and grasping surfaces dry,
clean and free from oil and grease. Slippery
handles and grasping surfaces do not allow
for safe handling and control of the tool in
unexpected situations.
5. Use and handling of the cordless
electrical power tool
a) Only charge rechargeable batteries using the
chargers that are recommended by the manufacturer. Chargers are often designed for a
particular type of rechargeable battery unit.
There is a risk of fire if other types of rechargeable battery units are used.
b) Only the rechargeable battery units supplied
are to be used with an electrical power tool.
The use of other rechargeable battery units may
lead to the danger of injury or fire.
c) When they are not being used, store
rechargeable battery units away from paperclips, coins, keys, nails, screws or other small
metal objects that could cause the contacts to
be bridged. Short-circuiting the contacts of a
rechargeable battery unit may result in heat
damage or fire.
d) Fluids may leak out of rechargeable battery
units if they are misused. If this happens,
avoid contact with the fluid. If contact occurs,
flush the affected area with water. Seek additional medical help if any of the fluid gets into
your eyes. Escaping battery fluid may cause
skin irritation or burns.
e) Do not use a damaged or modified battery.
Damaged or modified batteries may behave
unexpectedly and cause fires, explosions or
pose a risk of injury.
f) Do not expose a battery to fire or excessively
high temperatures. Fire or temperatures in excess
of 130°C (265°F) can cause an explosion.
g) Follow all instructions regarding charging
and never charge the battery or the cordless
tool outside the temperature range given in
the operating instructions. Incorrect charging
or charging outside of the permissible temperature range can destroy the battery and increase
the risk of fire.
PPHA 20-Li B2
GB│CY
│
5 ■
CAUTION! RISK OF EXPLOSION!
Never charge non-rechargeable
batteries.
Protect the rechargeable battery from heat; for example, from
continuous exposure to sunlight, fire, water
and moisture. There is a risk of explosion.
6. Service
a) Have your power tool serviced by a qualified
repair person using only identical replacement parts. This will ensure that the safety of
the power tool is maintained.
b) Never try to repair damaged batteries.
Batteries should only be maintained by the
manufacturer or an approved customer service
centre.
Appliance-specific safety instructions
for power planers
■ Wait until the cutter block comes to a complete
standstill before putting down the power tool.
An exposed, rotating cutter block can catch in
the surface and cause a loss of control which
could result in serious injuries.
■ Fix and secure the workpiece to a sturdy
work surface using clamps or other methods.
If you hold the workpiece only with your hand
or against your body, it will remain unstable.
This can lead to a loss of control.
■ Do not insert your fingers into the chip
ejector
parts.
■ Always switch the appliance on before
applying it to the workpiece. Otherwise,
there is a risk of a kickback if the planing blade
catches in the workpiece.
■ The plane sole must lie flat on the work-
piece when working. Otherwise, there is a
risk of injury due to the plane jamming.
. You can injure yourself on rotating
■ Never plane over metal objects. Otherwise,
the planing blade/cutter block
damaged.
■ Do not process materials containing asbestos.
Asbestos is a known carcinogen.
■ Dusts can be produced while working that
are hazardous to health, inflammable or
explosive. Wear a dust mask and use a suitable
dust/chip extractor. Some dusts are carcinogenic.
■ When working for extended periods of time
on wood and, in particular, materials that
produce dust which is hazardous to health,
connect the appliance to an appropriate
external dust extraction appliance. Do not
use the power planer if the battery is damaged. Damaged cables increase the risk of
electric shock.
■ Do not rest your hands next to or in front of
the appliance and the area being worked.
Otherwise, there is a risk of injury if you slip.
■ In the event of danger, remove the mains
plug from the socket immediately.
■ Always remove the plug from the power
socket in event of danger, during work
breaks, when working on the appliance
(e.g. when changing planing blade).
■ Always route the power cord towards the
rear, away from the appliance.
■ Use only sharp planing blades.
■ Do not soak the materials or the area to be
processed with liquids containing solvents.
■ Avoid all contact with rotating parts.
■ Never use the appliance for purposes other
than those for which it was designed, and
only use original parts/accessories.
■ Hold the appliance firmly while working.
Ensure that your stance is secure and stable.
■ The appliance must always be kept clean,
dry and free from oil or grease.
could be
■
6 │ GB
│
CY
PPHA 20-Li B2
Safety guidelines for battery chargers
■ This tool may be used by children
aged 8 years and above and
by persons with limited physical,
sensory or mental capabilities or
lack of experience and knowledge, provided that they are
under supervision or have been
told how to use the tool safely
and are aware of the potential
risks. Do not allow children to use
the tool as a toy. Cleaning and
user maintenance tasks may not
be carried out by children unless
they are supervised.
■ To avoid potential risks, if the
appliance power cable is damaged, it must be replaced by the
manufacturer, its customer service
or by a qualified technician.
The charger is suitable for indoor use only.
WARNING!
■ If the mains cable requires replacement, this
should be carried out by the manufacturer or
an approved representative to avoid safety
hazards.
ATTENTION!
♦ This charger can only charge the following
batteries: PAP20A1/PAP20A2/
PAP20A3/PAP20B1/PAP20B3/
PAPS204A1/PAPS208A1.
♦ A current list of battery compatibility can
be found at www.Lidl.de/Akku.
Original accessories/attachments
■ Use only the accessories and additional
equipment that are specified in the operating instructions and are compatible with
the appliance. Using attachments or accessory
tools other than those recommended in the
operating instructions can lead to a risk of
injury.
Before use
Charging the battery pack (see fig. I)
CAUTION!
► Always unplug the charger before you
remove the battery pack
to the charger.
NOTE
► Never charge the battery pack
ambient temperature is below 10°C or
above 40°C. If a lithium-ion battery is to be
stored for an extended period, the charge
level should be checked regularly. The optimum charge level is between 50% and 80%.
The storage climate should be cool and dry,
and the ambient temperature should be
between 0°C and 50°C.
♦ Insert the battery pack
charger (see fig. I).
♦ Insert the power plug into the socket.
The control LED
♦ The green control LED
charging process is complete and the battery
pack is ready for use.
ATTENTION!
♦ If the red control LED
that the battery pack has overheated and
cannot be charged.
♦ If the red and green control LEDs
flash, this means that the battery pack is
defective.
lights up red.
from or connect it
when the
into the high-speed
indicates that the
flashes, this means
both
PPHA 20-Li B2
GB│CY
│
7 ■
♦ Push the battery pack into the appliance.
♦ Switch off the charger
between successive charging sessions. Also
disconnect the power plug from the mains
power socket.
for at least 15 minutes
Inserting/removing the battery
pack
Inserting the battery pack
♦ Allow the battery pack to click into place in
the appliance.
Removing the battery pack
♦ Press the release button
battery pack .
and remove the
Checking the battery charge level
♦ Press the battery charge level button to
check the status of the battery (see also main
diagram). The status will be shown on the
battery display LED as follows:
RED/ORANGE/GREEN = maximum charge
RED/ORANGE = medium charge
RED = low charge – charge the battery
Using the appliance
Switching on/off
Switching on
♦ First, press the safety lock-out
♦ Then press and hold the ON/OFF switch
You can now release the safety lock-out .
Switching off
♦ Release the ON/OFF switch
NOTE
► For safety reasons, the ON/OFF switch
cannot be locked.
.
.
Setting the cut depth
Use the dial to adjust the cutting depth (0–2mm)
in 1/10 mm increments using the cutting depth
scale . This can then be read via the marking.
Vacuuming dust/chips (see fig. A)
WARNING!
Always wear a dust mask!
RISK OF INJURY!
► Always switch the appliance off and remove
the battery before carrying out any work on
the appliance.
Adjustable chip ejector (left/right)
♦ Unlock the chip ejector
opposite direction to the arrow (from the
"LOCK" position).
♦ Pull the chip ejector
♦ The chip ejector
plane on the left or the right. Make sure that
the tab on the chip ejector
corresponding recess on the housing.
♦ Push the chip ejector
♦ Lock the chip ejector
position "LOCK".
External extraction
When using a workshop extractor, for example, it
may be necessary to use the adapter for external
extraction
.
be suitable for the material being processed.
Connection
♦ Push the adapter for external extraction
firmly onto the chip ejector .
♦ Push the hose of a suitable workshop vacuum
cleaner onto the chip ejector
for external extraction , as applicable.
Removal
♦ Pull the hose of the workshop vacuum cleaner
off the chip ejector
♦ Pull off the adapter for external extraction
if attached.
. The workshop vacuum cleaner must
by turning it in the
out of the appliance.
can be attached to the
fits into the
into the appliance.
by turning it to the
or the adapter.
or the adapter
,
■
8 │ GB
│
CY
PPHA 20-Li B2
Parking shoe (see fig. B)
The parking shoe allows you to put the appliance
down without risking damage to the workpiece.
While working, the parking shoe is flipped up
and rear part of the plane sole is exposed.
Planing
Removing/fitting the planing
blade (seefigs.C–D)
RISK OF INJURY!
► Always switch the appliance off and remove
the battery before carrying out any work on
the appliance.
CAUTION! RISK OF KICKBACK!
► Always switch the appliance on before
applying it to the workpiece.
♦ Set desired cut depth.
♦ Switch the appliance on.
♦ Place the appliance with the front part of the
plane sole
♦ Move the appliance with straight, even motions
over the workpiece.
♦ Push forward slowly and do not exert excessive
pressure on the plane sole
reduces the surface quality and can lead to
clogging of the chip ejector.
on the workpiece.
. Excessive speed
Chamfering edges
The V grooves in the front plane sole allow
easy chamfering of workpiece edges.
♦ Use the V groove that corresponds to the
chamfer width required.
♦ Place the planer with the V groove
workpiece edge and guide it forwards.
onto the
Fitting the rip fence (not supplied,
seefig.G)
NOTE
► Replacement parts that are not listed (such as
batteries, rip fence or fold depth stop) can be
ordered via our Service Hotline.
♦ Undo the fastening screw
♦ Fit the rip fence
fastening screw .
onto the appliance using the
on the appliance.
CAUTION!
► There is a risk of injury due to the cutting
edges of the planing blade
► Never touch the cutting edges of the planing
blade
The planing blade has two cutting edges and
can be turned.
♦ Replace the planing blade
ting edges are blunt.
♦ Do not try to sharpen the planing blade
Turn the planing blade
WARNING! RISK OF INJURY!
► Wear suitable protective gloves when
changing the planing blades.
NOTE
► Do not undo the two hex screws
are used for adjusting the height of the cutter
block. No adjustment is required if you use
the planing blades sold by the manufacturer.
Otherwise, an imbalance may occur. Use
only the planing blades supplied by the
manufacturer.
► When changing the blade, always replace
both blades to prevent an imbalance.
► Unscrew only one blade to start with. This will
allow you to use the factory-mounted second
blade for reference when reassembling later.
♦ Use the supplied open-ended spanner
undo the 3 fastening screws a little way so
that the planing blade can be moved (see
fig. C).
.
!
when both cut-
.
or replace it
. They
to
PPHA 20-Li B2
GB│CY
│
9 ■
♦ Push the movable cutter block guard into the
slot in the housing.
♦ Push the planing blade
clamping element
NOTE
► The planing blade
with protective lacquer. It is not necessary to
re-bond the blade.
♦ Fit either a new or turned blade in the reverse
order. Make sure that the notch on the planing
blade
groove
♦ Make sure that the planing blade
a little way (approx. 1 mm) from the cutter
block in the direction of the movable lateral
cutter block guard . Carefully turn the cutter
block to check that the planing blade does not
scrape anywhere.
♦ Also ensure that the clamping element
flush to the cutter block . The clamping element must lie on the hex screws before
the fastening screws can be tightened.
♦ Planing blades
from the address given below (see section
"Service"). Do not use planing blades from
other manufacturers.
Setting the planing blade
♦ Set the cutting depth to 0 mm.
♦ Check the position of the planing blade
both ends. Use a flat, straight object as a guide
strip over the plane sole .
♦ The tip of the planing blade
with the surface of the plane sole .
♦ The height of the planing blade
adjusted using the hex key via the two hex
screws
the tip of the planing blade is flush with the
plane sole on both sides.
slides into the tensioning plate
20a
(see fig. E).
. Adjust the two hex screws so that
sideways out of the
(see fig. D)
may be factory-bonded
protrudes
closes
can be purchased exclusively
height
must be flush
can be
Replacing the drive belt (see fig. F)
RISK OF INJURY!
► Always switch the appliance off and remove
the battery pack
work on the appliance.
♦ Remove the screws
belt cover .
♦ Remove the worn drive belt
♦ Fit the new drive belt
wheel first and then turn the drive belt
and pull it onto the large belt wheel .
♦ Replace the drive belt cover
place using the screws .
before carrying out any
and detach the drive
onto the small belt
Maintenance and cleaning
WARNING! RISK OF INJURY! Always
switch the appliance off and remove
the battery before carrying out any
work on the appliance.
♦ Keep the appliance and the ventilation slits
clean to ensure fault-free operation.
♦ Clean the chip ejector
♦ To clean a blocked chip ejector, use a suitable
tool (e.g. a piece of wood, compressed air, etc.).
♦ Use a dry cloth to clean the housing.
♦ Use a brush to remove any dust stuck to the
appliance.
at
♦ Never use sharp objects, petrol, solvents or
cleansers which can damage plastic. Do not
allow any liquids to get into the interior of the
appliance.
WARNING!
■ Do not use any accessories that are not
recommended by PARKSIDE. This can lead
to an electric shock and fire.
NOTE
► Replacement parts that are not listed (such as
batteries, rip fence or fold depth stop) can be
ordered via our Service Hotline.
.
and fix it in
regularly.
■
10 │ GB
│
CY
PPHA 20-Li B2
Disposal
Do not dispose of power tools
in your normal domestic waste!
The adjacent symbol of a crossed-out
dustbin means that this appliance is
subject to Directive 2012/19/EU. This directive
states that this appliance may not be disposed of in
the normal household waste at the end of its useful
life, but must be taken to specially set-up collection
locations, recycling depots or disposal companies.
The disposal is free of charge for the user.
Protect the environment and dispose of this
appliance properly.
If your old appliance has stored any personal data,
you are responsible for deleting it yourself before
returning it.
If it is possible to do so without destroying the old
appliance, remove the old batteries or rechargeable batteries before returning the appliance for
disposal and take them to a separate collection
point. In the case of permanently installed
rechargeable batteries, you must indicate during
disposal that the appliance contains a battery.
Your local community or municipal
authorities can provide information on
how to dispose of the worn-out product.
The packaging is made from environmentally friendly material and can be
disposed of at your local recycling plant.
Dispose of the packaging in an
environmentally friendly manner.
Note the labelling on the packaging
and separate the packaging material
components for disposal if necessary. The packaging material is labelled with abbreviations (a) and
numbers (b) with the following meanings:
1–7: plastics, 20–22: paper and cardboard,
80–98: composites.
Do not dispose of batteries in
your normal household waste!
Defective or worn-out rechargeable
batteries must be recycled according to
Directive 2006/66/EC. Batteries/rechargeable
batteries must be treated as hazardous waste and
must therefore be disposed of in an environmentally
sound manner by appropriate bodies (dealers,
specialist dealers, public municipal bodies, commercial disposal companies). Batteries/rechargeable batteries may contain toxic heavy metals.
For this reason, do not dispose of batteries/
rechargeable batteries in domestic waste. Take
them to a specialist collection point. Only return
batteries that are fully discharged.
PPHA 20-Li B2
GB│CY
│
11 ■
Kompernass Handels GmbH
warranty
Dear customer,
This appliance comes with a 5-year warranty
valid from the date of purchase. In the event that
this product has any defects, you, the buyer, have
certain statutory rights. Your statutory rights are
not limited in any way by the warranty described
below.
Warranty conditions
The warranty period starts on the date of purchase.
Please keep your receipt in a safe place. This will
be required as proof of purchase.
If any material or manufacturing fault occurs within
5 years of the product’s date of purchase, we
will either repair or replace the product for you
or refund the purchase price (at our discretion).
This warranty service requires that you present
the defective appliance and the proof of purchase (receipt) within the 5-year warranty period,
together with a brief written description of the fault
and of when it occurred.
If the defect is covered by the warranty, your
product will either be repaired or replaced by us.
The repair or replacement of a product does not
signify the beginning of a new warranty period.
The X 20 V Team Series battery pack comes with
a 3-year warranty valid from the date of purchase.
Warranty period and statutory claims
for defects
The warranty period is not prolonged by repairs
effected under the warranty. This also applies to
replaced and repaired components. Any damage
and defects present at the time of purchase must
be reported immediately after unpacking. Repairs
carried out after expiry of the warranty period shall
be subject to a fee.
Scope of the warranty
This appliance has been manufactured in accordance with strict quality guidelines and inspected
meticulously prior to delivery.
The warranty covers material faults or production
faults. The warranty does not extend to product
parts subject to normal wear and tear or to fragile
parts which could be considered as consumable
parts such as switches or parts made of glass.
The warranty does not apply if the product has
been damaged, improperly used or improperly maintained. The directions in the operating
instructions for the product regarding proper use
of the product are to be strictly followed. Uses
and actions that are discouraged in the operating
instructions or which are warned against must be
avoided.
This product is intended solely for private use and
not for commercial purposes. The warranty shall
be deemed void in cases of misuse or improper
handling, use of force and modifications / repairs
which have not been carried out by one of our
authorised Service centres.
The warranty period does not apply to
■ Normal reduction of the battery capacity
over time
■ Commercial use of the product
■ Damage to or alteration of the product by the
customer
■ Non-compliance with safety and maintenance
instructions, operating errors
■ Damage caused by natural hazards
■
12 │ GB
│
CY
PPHA 20-Li B2
Warranty claim procedure
To ensure quick processing of your case, please
observe the following instructions:
■ Please have the till receipt and the item number
(IAN) 402247_2201 available as proof of
purchase.
■ You will find the item number on the type plate
on the product, an engraving on the product,
on the front page of the operating instructions
(below left) or on the sticker on the rear or
bottom of the product.
■ If functional or other defects occur, please
contact the service department listed either by
telephone or by e-mail.
■ You can return a defective product to us free of
charge to the service address that will be provided to you. Ensure that you enclose the proof
of purchase (till receipt) and information about
what the defect is and when it occurred.
You can download these instructions
along with many other manuals,
product videos and installation
software at www.lidl-service.com.
This QR code will take you directly to the Lidl
service page (www.lidl-service.com) where you
can open your operating instructions by entering
the item number (IAN) 402247_2201.
Service
Service Great Britain
Tel.: 0800 404 7657
E-Mail: kompernass@lidl.co.uk
CY
Service Cyprus
Tel.: 8009 4241
E-Mail: kompernass@lidl.com.cy
IAN 402247_2201
Importer
Please note that the following address is not the
service address. Please use the service address
provided in the operating instructions.
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com
WARNING!
► Have your appliances repaired by the
Service Centre or a trained electrician, and
use only original spare parts. This will
ensure that the safety of the appliance is
maintained.
► If the appliance's mains cable is damaged,
it must be replaced with a special cable
that is available from the manufacturer or
its customer service.
PPHA 20-Li B2
GB│CY
│
13 ■
Original declaration of conformity
We, KOMPERNASS HANDELS GMBH, document officer: Mr Semi Uguzlu, BURGSTR. 21,
44867 BOCHUM, GERMANY, hereby declare that this product complies with the following
standards, normative documents and EC directives:
Machinery Directive
(2006/42/EC)
EMC (Electromagnetic Compatibility)
(2014/30/EU)
RoHS Directive
(2011/65/EU)*
* The manufacturer bears the sole responsibility for compliance with this conformity declaration. The subject of the
declaration described above meets the requirements of Directive 2011/65/EU of the European Parliament and
Council of 8 June 2011 on the limitations of use of certain dangerous substances in electrical and electronic
appliances.
Related harmonised standards
EN 62841-1:2015
EN 62841-2-14:2015
EN IEC 55014-1:2021
EN IEC 55014-2:2021
EN IEC 63000:2018
Type designation of the machine: Cordless Planer 20V PPHA 20-Li B2
Year of manufacture: 06–2022
Serial number: IAN 402247_2201
Bochum, 14/06/2022
Semi Uguzlu
- Quality Manager -
We reserve the right to make technical changes in the context of further product development.
■
14 │ GB
│
CY
PPHA 20-Li B2
Ordering a replacement battery
If you want to order a replacement battery for your appliance, you can do so easily via the Internet on
www.kompernass.com or by telephone.
NOTE
► Online ordering of replacement parts is not possible in all countries. If this is the case, please contact
the Service Hotline.
Telephone ordering
Service Great Britain Tel.: 0800 404 7657
CY
Service Cyprus Tel.: 8009 4241
To ensure fast processing of your order, have the article number of your appliance (IAN402247_2201)
to hand in case of questions. The article number can be found on the type plate or the title page of these
instructions.
PPHA 20-Li B2
GB│CY
│
15 ■
■
16 │ GB
│
CY
PPHA 20-Li B2
Sadržaj
Uvod ................................................................18
Namenska upotreba ................................................................18
Oprema ..........................................................................18
Obim isporuke .....................................................................18
Tehnički podaci ....................................................................19
Opšte bezbednosne napomene za električne alate .......................... 20
1. Bezbednost na radnom mestu .......................................................20
2. Električna bezbednost .............................................................20
3. Bezbednost lica ..................................................................21
4. Upotreba i postupanje sa električnim alatom ............................................21
5. Upotreba i postupanje sa akumulatorskim alatom ........................................22
6. Servis ..........................................................................22
Specifične bezbednosne napomene za električne rendisaljke .................................22
Bezbednosne napomene za punjače ....................................................23
Originalni pribor/dodatni uređaji ......................................................24
Pre puštanja u rad .....................................................24
Punjenje akumulatorskog paketa (vidi sliku I) ..............................................24
Stavljanje/vađenje akumulatorskog paketa u uređaj/iz uređaja ...............................24
Provera stanja akumulatora ...........................................................24
Puštanje u rad .........................................................24
Uključivanje i isključivanje ............................................................24
Podešavanje dubine rendisanja ........................................................25
Usisavanje prašine/strugotine (vidisliku A) ...............................................25
Papuča za odlaganje (vidi sliku B) ......................................................25
Proces rendisanja ...................................................................25
Obaranje ivica .....................................................................25
Montaža paralelnog graničnika (nijeu obimu isporuke, vidi sliku G) ...........................26
Demontaža/montaža noža rendisaljke
Zamena pogonskog remena (vidi sliku F) ................................................27
Održavanje i čišćenje ...................................................27
Odlaganje ............................................................28
Servis ................................................................ 29
Garancija i garantni list ................................................. 29
Prevod originalne Izjave o usklađenosti ...................................31
Poručivanje rezervnog akumulatora ......................................32
Poručivanje telefonom ...............................................................32
(vidi slikuC–E) ...................................26
PPHA 20-Li B2
RS
│
17 ■
AKU RENDE 20 V PPHA20-Li B2
Uvod
Čestitamo Vam na kupovini Vašeg novog uređaja.
Time ste se odlučili za visokokvalitetan proizvod.
Uputstvo za upotrebu je deo ovog proizvoda. Ono
sadrži važne napomene o bezbednosti, upotrebi i
odlaganju. Pre korišćenja proizvoda, upoznajte se
sa svim napomenama vezanim za rukovanje i bezbednost. Koristite proizvod samo na opisani način
i u navedene svrhe. Predajte svu dokumentaciju prilikom prosleđivanja proizvoda trećim licima.
Namenska upotreba
Uređaj je predviđen za rendisanje radnih predmeta
od drveta, kao što su grede ili daske, kada radni
predmet čvrsto naleže. Osim toga, uređaj je namenjen za obaranje ivica i za pravljenje žleba. Svaka
druga upotreba ili promena mašine važi kao nenamenska i krije znatne opasnosti od nezgoda. Proizvođač ne preuzima odgovornost za štete koje su
nastale nenamenskom upotrebom. Ovaj uređaj nije
namenjen za komercijalnu upotrebu.
Oprema
Blokada uključivanja
Prekidač za uključivanje/isključivanje
Izbacivanje strugotine (po izboru desno/levo)
Štitnik remena
LED lampica na displeju akumulatora
Taster za stanje akumulatora
Taster za deblokadu akumulatorskog paketa
Vijci za štitnik remena
Pričvrsni vijak za paralelni graničnik/graničnik
dubine žleba
Osnovna ploča rendisaljke
V-urezi
Oznaka za skalu dubine rendisanja
Skala dubine rendisanja
Regulator dubine rendisanja (dodatna ručka)
Adapter za spoljno usisavanje
Papuča za odlaganje
Vratilo noža
Stezni element
Pričvrsni vijci za nož rendisaljke
Nož rendisaljke
20a
Urez stezne ploče
Imbus-vijci
Bočni štitnik vratila noža
Pogonski remen
Velika remenica
Mala remenica
Viljuškasti ključ
Imbus-ključ
Graničnik dubine žleba (nije u obimu isporuke)
28a
Paralelni graničnik (nije u obimu isporuke)
Akumulatorski paket*
Brzi punjač*
Crvena kontrolna LED lampica napunjenosti
Zelena kontrolna LED lampica napunjenosti
v Ready2Connect LED lampica
b Odeljak za pribor
Obim isporuke
1 aku rende 20 V
1 imbus-ključ (vidi sliku G)
1 viljuškasti ključ (vidi sliku G)
1 adapter za spoljno usisavanje
1 kofer za nošenje
1 uputstvo za upotrebu
■
18 │ RS
PPHA 20-Li B2
Tehnički podaci
Aku rende 20 V PPHA20-Li B2
Nominalni napon 20 V
(jednosmerna struja)
Nominalni broj obrtaja
u praznom hodu n
14000 min
0
Širina rendisanja 82 mm
Dubina rendisanja 0–2 mm
Dubina žleba maks. 17 mm
Maksimalna visokofrekventna
izlazna snaga 10 dBm
Akumulator PAP 20 B3*
Tip LITIJUM-JONSKI
Nominalni napon 20 V
struja)
Kapacitet 4,0 Ah
Ćelije 10
Brzi punjač za akumulator PLG 20 C3*
ULAZ/Input
Nominalni napon 230–240 V ∼, 50 Hz
(naizmenična struja)
Nominalna ulazna snaga 120 W
Osigurač (unutra) 3,15 A
IZLAZ/Output
Nominalni napon 21,5 V
(jednosmerna struja)
Nominalna struja 4,5 A
Vreme punjenja oko 120 min.
Klasa zaštite II/
(dvostruka
izolacija)
-1
(jednosmerna
T3.15A
Informacije o buci i vibracijama
Merna vrednost za buku je određena u skladu sa
EN 62841. Nivo buke električnog alata sa ocenom
A iznosi obično:
Vrednost emisije buke
Nivo zvučnog pritiska L
Nivo zvučne snage L
= 88,3 dB (A)
PA
= 99,3 dB (A)
WA
Odstupanje K = 3 dB
Nosite štitnike za sluh!
Ukupna vrednost vibracija
Ručka a
= 3,944 m/s
h
Dodatna ručka ah = 5,950 m/s
Odstupanje K = 1,5 m/s
2
2
2
NAPOMENA
► Za tačnu procenu opterećenja vibracijama u
toku određenog radnog intervala trebalo bi
da se uzme u obzir i vreme u kojem je uređaj
isključen ili radi, ali nije stvarno u upotrebi.
To značajno može da umanji opterećenje
vibracijama u toku celog radnog intervala.
► Navedene ukupne vrednosti vibracija i
navedene vrednosti emisije buke su izmerene
prema normiranom postupku ispitivanja i
mogu da se koriste za međusobno poređenje
električnih alata.
► Navedene ukupne vrednosti vibracija i nave-
dene vrednosti emisije buke mogu da se koriste
i za preliminarnu procenu opterećenja.
NAPOMENA
Ovim znakom se potvrđuje, da je
ovaj uređaj u skladu sa srpskim zahtevima za bezbednost proizvoda.
* AKUMULATOR I PUNJAČ NISU U OBIMU ISPORUKE
PPHA 20-Li B2
RS
│
19 ■
UPOZORENJE!
► Emisije vibracije i buke mogu u toku stvarnog
korišćenja da odstupaju od navedenih vrednosti, u zavisnosti od načina na koji se koristi
električni alat, posebno u zavisnosti od vrste
radnog predmeta koji se obrađuje. Pokušajte
da držite opterećenje vibracijama što manjim.
Primeri mera za smanjenje opterećenja vibracijama su nošenje rukavica prilikom upotrebe
alata i ograničenje radnog vremena. Pritom
treba uzeti u obzir sve udele radnog ciklusa
(na primer vremena u kojima je električni alat
isključen, kao i vremena u kojima je uključen,
ali radi bez opterećenja).
Opšte bezbednosne
napomene za električne
alate
UPOZORENJE!
► Pročitajte sve bezbednosne napomene, sva
uputstva, sve ilustracije i tehničke podatke
kojima je opremljen ovaj električni alat. Pro-
pusti prilikom pridržavanja sledećih uputstava
mogu da dovedu do električnog udara, požara
i/ili teških povreda.
Sačuvajte sve bezbednosne napomene i sva
uputstva za ubuduće.
Pojam „električni alat” korišćen u bezbednosnim
napomenama se odnosi na električne alate na
mrežni pogon (sa mrežnim vodom) i na električne
alate na akumulatorski pogon (bez mrežnog
voda).
1. Bezbednost na radnom mestu
a) Držite Vaše radno područje čisto i dobro
osvetljeno. Nered i neosvetljena radna pod-
ručja mogu da dovedu do nezgoda.
b) Ne radite električnim alatom u okruženju
ugroženom eksplozivnom atmosferom, u
kojem se nalaze zapaljive tečnosti, gasovi
ili prašina. Električni alati stvaraju varnice
koje mogu da zapale prašinu ili isparenja.
c) Držite decu i druga lica podalje tokom koriš-
ćenja električnog alata. U slučaju odvraćanja
pažnje možete da izgubite kontrolu nad električnim alatom.
2. Električna bezbednost
a) Priključni utikač električnog alata mora da
odgovara utičnici. Utikač ne smete ni na koji
način da promenite. Ne koristite adapterske
utikače zajedno sa zaštitno uzemljenim električnim alatima. Originalni utikači i odgovaraju-
će utičnice smanjuju rizik od električnog udara.
b) Izbegavajte telesni kontakt sa uzemljenim
površinama, kao npr. od cevi, radijatora,
šporeta i frižidera. Postoji povišeni rizik od
električnog udara kada je Vaše telo uzemljeno.
c) Držite električne alate podalje od kiše ili vlage.
Prodiranje vode u električni alat povećava rizik
od električnog udara.
d) Ne koristite priključni kabl nenamenski, da
biste nosili električni alat, vešali ga ili da biste
izvukli utikač iz utičnice. Držite priključni kabl
podalje od visokih temperatura, ulja, oštrih
ivica ili pokretnih delova. Oštećeni ili zapleteni
priključni kablovi povećavaju rizik od električnog udara.
e) Kada radite električnim alatom napolju, kori-
stite samo produžne kablove koji su pogodni
za spoljno područje. Upotreba produžnog
kabla koji je pogodan za spoljno područje
smanjuje rizik od električnog udara.
f) Kada ne možete da izbegnete rad električ-
nog alata u vlažnom okruženju, koristite FI
zaštitnu sklopku. Upotreba FI zaštitne sklopke
smanjuje rizik od električnog udara.
■
20 │ RS
PPHA 20-Li B2
3. Bezbednost lica
a) Budite pažljivi, pazite na to šta radite i razum-
no obavljajte radove električnim alatom.
Ne koristite električni alat kada ste umorni
ili pod uticajem droga, alkohola ili lekova.
Jedan trenutak nepažnje za vreme upotrebe
električnog alata može da dovede do ozbiljnih
povreda.
osite ličnu zaštitnu opremu i uvek nosite
b) N
zaštitne naočare. Nošenje lične zaštitne opreme,
kao što su maska protiv prašine, protivklizne
zaštitne cipele, zaštitni šlem ili štitnici za sluh,
zavisno od vrste i primene električnog alata,
smanjuje rizik od povreda.
c) Izbegavajte nenamerno puštanje u rad.
Uverite se da je električni alat isključen pre
nego što ga priključite na strujno napajanje
i/ili akumulator, i pre nego što ga podignete
ili nosite. Držanje prsta na prekidaču prilikom
nošenja električnog alata ili priključivanje već
uključenog električnog alata na električno
napajanje, može da dovede do nezgoda.
d) Uklonite alate za podešavanje ili ključeve za
vijke pre nego što uključite električni alat. Alat
ili ključ, koji se nalazi u rotirajućem delu električnog alata, može da dovede do povreda.
e) Izbegavajte neprirodan položaj tela. Pobrinite
se za stabilan položaj i u svakom trenutku
držite ravnotežu. Na taj način možete bolje
da kontrolišete električni alat u neočekivanim
situacijama.
f) Nosite prikladnu odeću. Ne nosite široku
odeću ili nakit. Držite kosu i odeću podalje
od pokretnih delova. Opuštena odeća, nakit ili
duga kosa mogu da budu zahvaćeni pokretnim
delovima.
g) Ako mogu da se montiraju uređaji za usisa-
vanje ili sakupljanje prašine, ove uređaje
morate ispravno da priključite i koristite.
Korišćenjem uređaja za usisavanje prašine
mogu da se smanje opasnosti od prašine.
h) Ne mislite da ste bezbedni i ne odbacujte
bezbednosna pravila za električne alate, iako
ste nakon česte upotrebe dobro upoznati sa
električnim alatom. Nepažljive aktivnosti mogu
u deliću sekunde da dovedu do teških povreda.
4. Upotreba i postupanje
sa električnim alatom
a) Ne preopterećujte električni alat. Koristite
odgovarajući električni alat za posao koji
obavljate. Sa odgovarajućim električnim alatom
ćete bolje i bezbednije raditi u navedenom
području snage.
b) Ne koristite električni alat čiji je prekidač
neispravan. Električni alat, koji više ne može
da se uključi ili isključi, je opasan i morate da
ga popravite.
c) Izvucite utikač iz utičnice i/ili uklonite odvojivi
akumulator pre nego što obavite podešavanja
uređaja, zamenu alata za umetanje ili odlaganje električnog alata. Ova bezbednosna
mera sprečava nenamerno pokretanje električnog alata.
d) Električne alate koje ne koristite, čuvajte van
domašaja dece. Nemojte dozvoliti da električni
alat koriste druga lica koja nisu upoznata
s njim i koja nisu pročitala ova uputstva. Elek-
trični alati su opasni kada ih koriste neiskusna
lica.
e) Pažljivo održavajte električne alate i alate za
umetanje. Prekontrolišite da li pokretni delovi
besprekorno funkcionišu i da nisu zaglavljeni,
da li su delovi slomljeni ili oštećeni, tako da
ometaju funkciju električnog alata. Dajte
oštećene delove na popravku pre korišćenja
električnog alata. Mnoge nezgode su prouzro-
kovane loše održavanim električnim alatima.
f) Držite alate za rezanje oštre i čiste. Pažljivo
održavani alati za rezanje, sa oštrim sečivima,
se ređe zaglavljuju i lakše se vode.
g) Koristite električni alat, alate za umetanje itd.
prema ovim uputstvima. Pritom uzmite u obzir
radne uslove i delatnost koju treba obaviti.
Upotreba električnih alata za druge primene,
osim navedenih, može da dovede do opasnih
situacija.
h) Držite ručke i površine ručke suve, čiste i
bez ulja i masti. Klizave ručke i površine ručke
onemogućuju bezbedno rukovanje i kontrolu
električnog alata u nepredviđenim situacijama.
PPHA 20-Li B2
RS
│
21 ■
5. Upotreba i postupanje
sa akumulatorskim alatom
a) Punite akumulatore samo punjačima koje
preporučuje proizvođač. Korišćenjem punjača
namenjenog za određenu vrstu akumulatora,
postoji opasnost od požara ako se koristi za
neku drugu vrstu akumulatora.
b) Koristite u električnim alatima samo akumula-
tore predviđene za tu vrstu alata. Korišćenje
nekih drugih akumulatora može da dovede do
povreda i opasnosti od požara.
c) Akumulator koji ne koristite, držite podalje
od kancelarijskih spajalica, kovanica, ključeva,
eksera, vijaka ili drugih sitnih metalnih predmeta, jer mogu da izazovu kratak spoj između kontakata. Kratak spoj između kontakata
akumulatora može da ima za posledicu opekotine ili požar.
d) U slučaju pogrešne primene, tečnost može da
iscuri iz akumulatora. Izbegavajte kontakt sa
iscurelom tečnošću. Ako slučajno dođete u
kontakt sa ovom tečnošću, isperite je vodom.
Ako ova tečnost dospe u oči, obratite se i
lekaru. Iscurela tečnost iz akumulatora može
da dovede do iritacije kože ili opekotina.
e) Ne koristite oštećen ili izmenjen akumulator.
Oštećeni ili izmenjeni akumulatori mogu da se
ponašaju nepredvidivo i da dovedu do požara,
eksplozije ili povreda.
f) Ne izlažite akumulator vatri ili previsokim
temperaturama. Vatra ili temperature preko
130 °C (265 °F) mogu da izazovu eksploziju.
g) Sledite uputstva za punjenje i nikada ne punite
akumulator ili akumulatorski alat van temperaturnog područja navedenog u uputstvu za
rukovanje. Pogrešno punjenje ili punjenje van
dozvoljenog opsega temperature može da
uništi akumulator i može da poveća opasnost
od požara.
OPREZ! OPASNOST OD EKSPLOZIJE!
Nikada ne punite baterije koji nisu
punjive.
Čuvajte akumulator
od toplote, npr. od trajnog izlaganja suncu,
od vatre, vode i vlage. Postoji opasnost od
eksplozije.
6. Servis
a) Popravku Vašeg električnog alata treba da
obavlja isključivo kvalifikovano stručno osoblje
i samo sa originalnim rezervnim delovima.
Na taj način bezbednost električnog alata
ostaje nepromenjena.
b) Nikada ne obavljajte održavanje oštećenog
akumulatora. Sve radove na održavanju akumulatora treba da obavlja isključivo proizvođač
ili ovlašćeni korisnički servis.
Specifične bezbednosne napomene
za električne rendisaljke
■ Sačekajte da se vratilo noža zaustavi pre
nego što odložite električni alat. Nezaštićeno,
rotirajuće vratilo noža može da se zaglavi i dovede do gubitka kontrole kao i do teških povreda.
■ Pričvrstite i osigurajte radni predmet na stabil-
nu podlogu pomoću stega ili na drugi način.
Kada radni predmet držite samo rukom ili uz
telo, on nije stabilan i to može da dovede do
gubitka kontrole.
■ Ne hvatajte prstima deo za izbacivanje
strugotine
rotirajućih delova.
■ Usmerite uređaj ka radnom predmetu samo
kada je uključen. U suprotnom, postoji opa-
snost od povratnog udara kada se nož
rendisaljke zaglavi u radnom predmetu.
■ U toku rada, osnovna ploča rendisaljke
mora ravno da naleže. U suprotnom, postoji
opasnost od povreda kada je rendisaljka zakošena.
■ Nikada ne rendišite preko metalnih predmeta.
Nož rendisaljke/vratilo noža će se inače
oštetiti.
■ Materijali koji sadrže azbest ne smeju da
se obrađuju. Azbest važi kao kancerogen
materijal.
. Opasnost od povreda od
■
22 │ RS
PPHA 20-Li B2
Loading...
