BELT SANDER PBS 900 B2
BELT SANDER
Translation of the original instructions
ŞLEFUITOR CU BANDĂ
Traducerea instrucţiunilor de utilizare original
BANDSCHLEIFER
Originalbetriebsanleitung
IAN 279873
TRAČNA BRUSILICA
Prijevod originalnih uputa za uporabu
ΤΑΙΝΙΟΛΕΙΑΝΤΗΡΑΣ
Μετάφραση των αυθεντικών οδηγιών λειτουργίας
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Prije nego što pročitate tekst, otvorite stranicu sa slikama i upoznajte se na osnovu toga sa svim funkcijama
uređaja.
Înainte de a citi instrucţiunile, priviţi imaginile şi familiarizaţi-vă cu toate funcţiile aparatului.
Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τη σελίδα με τις εικόνες και εξοικειωθείτε με όλες τις λειτουργίες
της συσκευής.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.
GB / CY Translation of the original instructions Page 1
HR Prijevod originalnih uputa za uporabu Stranica 11
RO Traducerea instrucţiunilor de utilizare original Pagina 21
GR / CY Μετάφραση των αυθεντικών οδηγιών λειτουργίας Σελίδα 31
DE / AT / CH Originalbetriebsanleitung Seite 41
A B C
D E
Contents
Introduction ......................................................2
Intended use ................................................................ 2
Depicted components ......................................................... 2
Package contents ............................................................ 2
Technical details ............................................................. 2
General Power Tool Safety Warnings ................................3
1. Work area safety .......................................................... 3
2. Electrical safety ........................................................... 3
3. Personal safety ............................................................ 4
4. Use and handling of the power tool ........................................... 4
5. Service .................................................................. 5
Appliance-specific safety instructions for belt sanders ................................ 5
Safety information for sanders .................................................. 5
Operation .......................................................5
Tensioning/replacing the abrasive belt ........................................... 5
Working procedures .......................................................... 6
Dust extraction .............................................................. 6
Operation .......................................................7
Switching on and off .........................................................7
Selecting speed and abrasive belt ............................................... 7
Stationary work ............................................................. 8
Tips and tricks ............................................................... 8
Maintenance and cleaning ..........................................8
Disposal .........................................................8
Kompernass Handels GmbH warranty ...............................9
Service ................................................................... 10
Importer ..................................................................10
Translation of the original Conformity Declaration .....................10
PBS 900 B2
GB│CY
│
1 ■
BELT SANDER PBS 900 B2
Introduction
Congratulations on the purchase of your new appliance. You have selected a high-quality product.
The operating instructions are part of this product.
They contain important information about safety,
usage and disposal. Before using the product, please
familiarise yourself with all operating and safety
instructions. Use the product only as described and
for the range of applications specified. Please also
pass these operating instructions on to any future
owner.
Intended use
The belt sander is designed for the dry surface
sanding of wood, plastic, metal and plaster and
painted surfaces (depending on the type of sandpaper used). The appliance may only be used
for dry sanding. Please note that you need to use
appropriate abrasive belts with different grains for
working different materials, and that you may need
to adapt the speed to suit the material. The appliance is not intended for commercial use. Any other
uses of or modification to the appliance is deemed
to be improper and carries the risk of serious personal injury. The manufacturer accepts no responsibility for damage(s) attributable to misuse.
Depicted components
Speed preselector wheel
Lock button
ON/OFF switch
Drive belt cover
Extraction nozzle
Adjustment screw for belt tracking
Additional handle
Ventilation slits
Clamping lever
Dust collector
Dust extraction adapter
Reducer
Screw clamps 2 x
Package contents
Check the package contents immediately
after unpacking the appliance:
1 belt sander PBS 900 B2
1 abrasive belt
1 dust collector
1 dust extraction adapter and reducer
(for external dust extraction)
2 screw clamps
1 set of operating instructions
Technical details
Rated voltage: 230 V ∼ 50 Hz
(alternating current)
Rated power
consumption: 900 W
Idling belt speed: 240–400 m/min
Rated idling speed:
Abrasive belt: 75 x 533 mm
Protection class: II /
Noise emission value:
Noise measurement value determined in accordance
with EN 60745. The A-rated noise level of the tool
is typically:
Sound pressure level: L
Uncertainty: KpA = 3 dB
Sound power level: LWA = 103.22 dB(A)
Uncertainty: K
Wear hearing protection!
Total vibration value:
Total vibration values (vector total of three directions) determined in accordance with EN 60745:
Vibration emission value: a
Uncertainty K = 1.5 m/s
n0 450–750 rpm
(double insulation)
= 92.22 dB(A)
pA
= 3 dB
WA
= 6.115 m/s
h
2
2
■ 2 │ GB
│
CY
PBS 900 B2
NOTE
► The vibration emission value specified in these
instructions has been measured in accordance
with a standardised measuring procedure and
can be used to make equipment comparisons.
The specified vibration emission value can also
be used to make an initial exposure estimate.
WARNING!
► The vibration emission value varies in accord-
ance with the use of the power tool and may
be higher than the value specified in these
instructions in some cases. Regular use of the
power tool in such a way may cause the user
to underestimate the vibration. Try to keep the
vibration loads as low as possible. Examples
of measures for reducing the vibration load
are wearing gloves when using the tool and
limiting the working time. Wherein all states
of operation must be included (e.g. times
when the power tool is switched off and times
where the power tool is switched on but running without load).
General Power Tool
Safety Warnings
WARNING!
► Read all safety warnings and all instruc-
tions. Failure to follow the safety information
and instructions may result in electric shock,
fire and/or serious injury.
Save all warnings and instructions for future
reference.
The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or batteryoperated (cordless) power tool.
1. Work area safety
a) Keep work area clean and well lit. Cluttered
or dark areas invite accidents.
b) Do not operate power tools in explosive atmo-
spheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
PBS 900 B2
2. Electrical safety
a) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded)
power tools. Unmodified plugs and matching
outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of elec-
tric shock if your body is earthed or grounded.
GB│CY
│
3 ■
c) Do not expose power tools to rain or wet con-
ditions. Water entering a power tool will increase
the risk of electric shock.
d) Do not abuse the cord. Never use the cord
for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
e) When operating a power tool outdoors, use
an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces
the risk of electric shock.
f) If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces
the risk of electric shock.
3. Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired
or under the influence of drugs, alcohol or
medication. A moment of inattention while
operating power tools may result in serious
personal injury.
b) Use personal protective equipment. Always
wear eye protection. Protective equipment such
as dust mask, non-skid safety shoes, hard hat,
or hearing protection used for appropriate
conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to power source and/or battery pack, picking
up or carrying the tool. Carrying power tools
with your finger on the switch or energising
power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key
left attached to a rotating part of the power tool
may result in personal injury.
e) Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewel-
lery or long hair can be caught in moving parts.
g) If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of
dust collection can reduce dust-related hazards.
4. Use and handling of the power
tool
a) Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at
the rate for which it was designed.
b) Do not use the power tool if the switch does
not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous
and must be repaired.
c) Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing accessories or storing power tools. Such preven-
tive safety measures reduce the risk of starting
the power tool accidentally.
d) Store idle power tools out of the reach of
children and Do not allow persons unfamiliar
with the power tool or these instructions to
operate the power tool. Power tools are dan-
gerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment
or binding of moving parts, breakage of parts
and any other condition that may affect the
power tool’s operation. If damaged, have the
power tool repaired before use. Many ac-
cidents are caused by poorly maintained power
tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to
control.
■ 4 │ GB
│
CY
PBS 900 B2
g) Use the power tool, accessories and tool
bits, etc. in accordance with these instructions, taking into account the working conditions and the work to be performed. Use of
the power tool for operations different from
those intended could result in a hazardous
situation.
5. Service
a) Have your power tool serviced by a qualified
repair person using only identical replacement parts. This will ensure that the safety of
the power tool is maintained.
Appliance-specific safety instructions
for belt sanders
■ Hold the appliance by the insulated handles
since the grinding belt can come into contact
with its own power cable. Damage to a live
wire may make exposed metal parts of the power
tool live and could give the operator an electric
shock.
Safety information for sanders
WARNING!
■ Dusts from materials such as leaded paint,
some types of wood and metal can be harmful to your health.
■ Contact with or inhalation of these dusts can
represent a health hazard for the person
operating the appliance and other people in
the vicinity.
■ Wear safety goggles and a protective dust
mask!
Operation
Tensioning/replacing the abrasive
belt
WARNING! RISK OF INJURY
■ Always remove the power plug from the wall
socket before carrying out any work on the
belt sander.
1. Loosen the clamping device for the abrasive
belt by swivelling the clamping lever
way out (see fig. A). The clamping device is
now open and the abrasive belt can be removed.
2. Now fit a new abrasive belt or swap the belt
to work a different material or to use a different
grain size. IMPORTANT: The direction of the
arrows on the inside of the abrasive belt and
on the appliance housing must match.
3. Push the clamping lever
position.
Adjusting the abrasive belt:
♦ Pick up the appliance, switch it on and turn it
over. Adjust the belt tracking. To do this, turn
the adjustment screw
abrasive belt is flush with and runs parallel to
the appliance edge (fig. B). IMPORTANT:
It is important to ensure that the abrasive belt
does not rub against the housing. Check the
belt tracking regularly and adjust it with the
adjusting screw if required .
back into its initial
until the edge of the
all the
PBS 900 B2
GB│CY
│
5 ■
Working procedures
Dust extraction
A light grinding pressure is sufficient:
■ Apply minimal pressure when grinding. The belt
sander's own weight is sufficient for a good
grinding result. In addition, working this way
helps to reduce the wear on the abrasive belt
and the surface of the workpiece will become
smoother.
Removal and surface:
■ The material removal rate and surface quality
are determined by the belt speed and grain
strength of the sandpaper (see also the section
"Selecting speed and abrasive belt").
Grinding:
■ Place the appliance on the workpiece when
switched on and work at a moderate feed rate.
Guide the sander in parallel and overlapping
sanding motions over the workpiece. To avoid
unpleasant transverse grinding marks, always
sand in the direction of the grain.
After completing the task, lift the appliance from
the workpiece and then switch it off.
NOTE
► Always hold the appliance firmly with two
hands while working.
WARNING! RISK OF EXPLOSION
■ If there is an explosive dust/air mixture, you
must use a specially-designed extraction
device.
RISK OF FIRE DUE TO FLYING SPARKS!
Do not use dust extraction systems (dust collector
or vacuum cleaners) when grinding
metals.
■ Materials containing asbestos may not be pro-
cessed. Asbestos is a known carcinogen.
WARNING! RISK OF FIRE!
■ When working with power tools which
have a dust collector or can be connected
to a vacuum cleaner via a vacuum cleaner
adapter, there is a risk of fire! In unfavourable
conditions, e.g. when sparks are flying while
sanding metal or metal residues in wood,
wood dust in the dust collector (or the bag
of the vacuum cleaner) can spontaneously
ignite. This is a particular risk if the wood
dust is mixed with paint residues or other
chemicals and the workpiece has become hot
after being worked for a long time. Therefore,
do not allow the workpiece to overheat and
always empty the dust box or the dust bag
of the vacuum cleaner before taking a break
from work.
■ Ensure that your workplace is adequately
ventilated.
■ Observe the regulations applicable in
your country regarding the materials to be
worked.
!
■ 6 │ GB
│
CY
■
Dust extraction with dust collector (see fig. C):
♦ Push the dust collector
nozzle .
Wear a dust mask.
onto the extraction
PBS 900 B2
Dismantling/removing the dust collector:
♦ Pull the dust collector
Dust extraction adapter (with reducer )
(see fig. C):
♦ Push the dust extraction adapter
extraction nozzle . If necessary, use the reducer by pushing it onto the dust extraction
adapter .
♦ Push the hose from a suitable dust extraction
appliance (e.g. a workshop vacuum cleaner)
onto the dust extraction adapter
reducer if necessary.
Removal:
♦ Pull off the dust extraction device hose.
♦ Pull the dust extraction adapter
the reducer , if attached).
off the appliance.
onto the
; use the
off (and also
Operation
Switching on and off
While operating the belt sander, you can choose
between instantaneous and continuous operation.
Switching to instantaneous operation:
♦ Press the ON/OFF switch
Switching off instantaneous operation:
♦ Release the ON/OFF switch
Switching to continuous operation:
♦ Press the ON/OFF switch
in and then press the lock button .
Switching off continuous operation:
♦ Press the ON/OFF switch
it.
.
.
, keep it pressed
and then release
Selecting speed and abrasive belt
You can use the speed preselector wheel to adjust the speed, even while the appliance is running
(– = lower speed, + = higher speed). The optimum
belt speed is dependent on the workpiece or material being processed. We recommend carrying out
a practice run to determine the correct speed. In
the table below, you will find some recommended
values which will help you determine which belt
and speed to use for which job.
Material/
working area
Rough sanding
(grain size)
Finishing (grain size) 240
Speed preselection high (5–6)
Material/
working area
Rough sanding
(grain size)
Finishing (grain size) 180
Speed preselection high (5–6)
Material/
working area
Rough sanding
(grain size)
Finishing (grain size) 150
Speed preselection high (5–6)
Material/
working area
Rough sanding
(grain size)
Finishing (grain size) ––
Speed preselection high (5–6)
Softwood
60
Hardwood
60
Chipboard
60
Removing paint/
varnish
60
PBS 900 B2
GB│CY
│
7 ■
Material/
working area
Rough sanding
(grain size)
Finishing (grain size) 320
Speed preselection low (1–2)
Material/working
area
Rough sanding
(grain size)
Finishing (grain size) 120
Speed preselection medium/high (3–4)
Material/
working area
Rough sanding
(grain size)
Finishing (grain size) 240
Speed preselection low/medium (2–3)
Material/
working area
Rough sanding
(grain size)
Finishing (grain size) 150
Speed preselection medium/high (3–4)
Rubbing down
paintwork/varnish
150
Removing rust from
steel
40
Plastics
120
Non-ferrous metals
(e.g. aluminium)
80
Tips and tricks
■ Never use the same abrasive belt to process
wood and metal.
■ Worn or cracked abrasive belts can damage
the workpiece. Therefore, be sure to replace
worn abrasive belts before starting work.
■ Always hang up the abrasive belts to store
them, as kinks etc. can make them unusable.
Maintenance and cleaning
WARNING! RISK OF INJURY! Switch
the appliance off and remove the
power plug before starting any work
on the appliance.
The belt sander is maintenance-free.
■ Always clean the appliance directly after finishing
work.
■ Use a dry cloth to clean the housing. Under
no circumstances should you use detergents,
solvents or abrasive cleaners.
■ Ensure ventilation openings are always free.
■ Remove any adhering grinding dust with a
brush.
Disposal
The packaging is made from environmen-
tally friendly material and can be disposed of at your local recycling plant.
Stationary work
♦ Turn the power tool over as shown in figure E
and place it on a stable worktop.
♦ Attach the two screw clamps
tool as shown and tighten them.
♦ Set the speed using the speed preselector
wheel
■ 8 │ GB
.
│
CY
to the power
Do not dispose of power tools in
your normal household waste!
European Directive 2012/19/EU requires that
worn-out power tools be collected separately and
recycled in an environmentally compatible manner.
Your local community or municipal authorities can
provide information on how to dispose of the wornout appliance.
PBS 900 B2
Kompernass Handels GmbH
warranty
Dear Customer,
This appliance has a 3-year warranty valid from
the date of purchase. If this product has any faults,
you, the buyer, have certain statutory rights. Your
statutory rights are not restricted in any way by the
warranty described below.
Warranty conditions
The validity period of the warranty starts from the
date of purchase. Please keep your original receipt
in a safe place. This document will be required as
proof of purchase.
If any material or production fault occurs within
three years of the date of purchase of the product,
we will either repair or replace the product for you
at our discretion. This warranty service is dependent on you presenting the defective appliance and
the proof of purchase (receipt) and a short written
description of the fault and its time of occurrence.
If the defect is covered by the warranty, your product
will either be repaired or replaced by us. The repair
or replacement of a product does not signify the
beginning of a new warranty period.
Warranty period and statutory
claims for defects
The warranty period is not prolonged by repairs
effected under the warranty. This also applies to
replaced and repaired components. Any damage
and defects present at the time of purchase must
be reported immediately after unpacking. Repairs
carried out after expiry of the warranty period shall
be subject to a fee.
Scope of the warranty
This appliance has been manufactured in accordance with strict quality guidelines and inspected
meticulously prior to delivery.
The warranty covers material faults or production
faults. The warranty does not extend to product
parts subject to normal wear and tear or fragile
parts such as switches, batteries, baking moulds or
parts made of glass.
The warranty does not apply if the product has
been damaged, improperly used or improperly
maintained. The directions in the operating instructions for the product regarding proper use of
the product are to be strictly followed. Uses and
actions that are discouraged in the operating
instructions or which are warned against must be
avoided.
This product is intended solely for private use and not for
commercial purposes. The warranty shall be deemed
void in cases of misuse or improper handling, use of
force and modifications/repairs which have not been
carried out by one of our authorised Service centres.
Warranty claim procedure
To ensure quick processing of your case, please
observe the following instructions:
▯ Please have the till receipt and the item number
(e.g. IAN 12345) available as proof of purchase.
▯ You will find the item number on the type plate,
an engraving on the front page of the instructions
(bottom left), or as a sticker on the rear or bottom
of the appliance.
▯ If functional or other defects occur, please
contact the service department listed either by
telephone or by e-mail.
▯ You can return a defective product to us free of
charge to the service address that will be provided
to you. Ensure that you enclose the proof of
purchase (till receipt) and information about
what the defect is and when it occurred.
PBS 900 B2
You can download these instructions
along with many other manuals,
product videos and software on
www.lidl-service.com.
GB│CY
│
9 ■
Service
WARNING!
■ Have the power tool repaired by the service
centre or a qualified electrician and only
using genuine replacement parts. This will
ensure that the safety of the appliance is
maintained.
WARNING!
■ Always ensure that the power plug or the
mains cable is replaced only by the manufacturer of the appliance or by an approved
customer service provider. This will ensure that
the safety of the appliance is maintained.
NOTE
► Replacement parts not listed (such as carbon
brushes, switches) can be ordered via our
call centre.
Service Great Britain
Tel.: 0871 5000 720 (£ 0.10/Min.)
E-Mail: kompernass@lidl.co.uk
CY
Service Cyprus
Tel.: 8009 4409
E-Mail: kompernass@lidl.com.cy
IAN 279873
Translation of the original
Conformity Declaration
We, KOMPERNASS HANDELS GMBH, documents officer: Mr. Semi Uguzlu, BURGSTR. 21,
44867 BOCHUM, Deutschland, hereby declare
that this product complies with the following standards, normative documents and the EC directives:
Machinery Directive
(2006/42/EC)
EMC (Electromagnetic Compatibility)
(2014/30/EU)
RoHS Directive
(2011/65/EU)
Applied harmonised standards:
EN 60745-1: 2009+A11
EN 60745-2-4: 2009+A11
EN 55014-1: 2006+A1+A2
EN 55014-2: 1997+A1+A2
EN 61000-3-2: 2006+A1+A2
EN 61000-3-3: 2013
Type designation of machine:
Belt sander PBS 900 B2
Year of manufacture: 06 - 2016
Serial number: IAN 279873
Importer
Please note that the following address is not the
service address. Please use the service address
provided in the operating instructions.
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com
■ 10 │ GB
│
CY
Bochum, 09/05/2016
Semi Uguzlu
- Quality Manager The right to effect technical changes in the context
of further development is reserved.
PBS 900 B2
Sadržaj
Uvod ..........................................................12
Namjenska uporaba ........................................................ 12
Prikazane komponente .......................................................12
Opseg isporuke ............................................................ 12
Tehnički podaci ............................................................ 12
Opće sigurnosne napomene za uporabu električnog alata ..............13
1. Sigurnost na radnom mjestu ................................................. 13
2. Električna sigurnost. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3. Sigurnost osoba ..........................................................14
4. Korištenje i rukovanje električnim alatom .......................................14
5. Servis ..................................................................15
Sigurnosne napomene specifične za tračne brusilice ................................ 15
Sigurnosne napomene za brusilice .............................................15
Puštanje u rad ...................................................15
Zatezanje / zamjena brusne trake ..............................................15
Napomene za rad ..........................................................16
Usisavanje prašine ..........................................................16
Rukovanje ......................................................17
Uključivanje i isključivanje ....................................................17
Izbor broja okretaja i brusne trake ..............................................17
Stacionaran rad ............................................................18
Savjeti i trikovi ..............................................................18
Održavanje i čišćenje .............................................18
Zbrinjavanje ....................................................18
Jamstvo tvrtke Kompernass Handels GmbH ..........................19
Servis ....................................................................20
Uvoznik ..................................................................20
Prijevod originalne izjave o sukladnosti .............................20
PBS 900 B2
HR │ 11 ■
TRAČNA BRUSILICA PBS 900 B2
Uvod
Čestitamo na kupnji Vašeg novog uređaja. Time ste
se odlučili za vrlo kvalitetan proizvod. Upute za uporabu sastavni su dio ovog proizvoda. One sadrže
važne napomene za sigurnost, rukovanje i zbrinjavanje. Prije uporabe proizvoda upoznajte se sa svim
napomenama za rukovanje i sa svim sigurnosnim
napomenama. Proizvod koristite isključivo na opisani
način i u navedenim područjima uporabe. U slučaju
predaje proizvoda trećim osobama, priložite i također predajte i svu dokumentaciju.
Namjenska uporaba
Tračna brusilica je - ovisno o brusnom papiru - koncipirana za suho brušenje drveta, plastike, metala
i gipsa, kao i lakiranih površina. Uređaj se smije
koristiti isključivo za suho brušenje. Pazite da za
obradu različitih materijala koristite odgovarajuće
brusne trake različite gradacije i da broj okretaja
također prilagodite materijalu. Uređaj nije namijenjen za komercijalnu uporabu. Svaki drugi način
uporabe i svaka izmjena uređaja smatra se nenamjenskom i krije znatnu opasnost od nezgoda. Proizvođač ne preuzima odgovornost za štete nastale
uslijed nenamjenskog korištenja uređaja.
Prikazane komponente
Kotačić za predodabir broja okretaja
Gumb za fiksiranje
Prekidač UKLJ / ISKLJ
Pokrov zupčastog remena
Usisni nastavak
Vijak za podešavanje hoda trake
Dodatna ručka
Ventilacijski otvori
Zatezna poluga
Kutija za sakupljanje prašine
Adapter za usisavanje
Redukcijski nastavak
Navojne stege 2 x
Opseg isporuke
Neposredno nakon raspakiranja uređaja
provjerite cjelovitost opsega isporuke:
1 Tračna brusilica PBS 900 B2
1 Brusna traka
1 Kutija za sakupljanje prašine
1 Adapter za usisavanje i redukcijski nastavak
(za vanjsko usisavanje prašine)
2 Navojne stege
1 Upute za uporabu
Tehnički podaci
Nazivni napon: 230 V ∼ 50 Hz
(naizmjenični napon)
Nazivna snaga: 900 W
Brzina trake u
praznom hodu: 240–400 m / min
Nazivni broj okretaja
u praznom hodu:
n0 450–750 min
Brusna traka: 75 x 533 mm
Razred zaštite: II /
(dvostruka izolacija)
Vrijednost emisije buke:
Mjerna vrijednost buke ustanovljena sukladno EN
60745. A-ocijenjena razina emisije buke električnog alata tipično iznosi:
Razina zvučnog tlaka: L
= 92.22 dB (A)
pA
Nesigurnost: KpA = 3dB
Razina zvučne snage: LWA = 103.22 dB (A)
Nesigurnost: K
= 3 dB
WA
Nosite zaštitu sluha!
Ukupna vrijednost vibracija:
Ukupne vrijednosti vibracija (zbroj vektora triju
smjerova) izračunat u skladu s normom EN 60745:
Vrijednost emisije vibracija: a
Nesigurnost K = 1,5 m/s
= 6,115 m/s
h
2
-1
2
■ 12 │ HR
PBS 900 B2
NAPOMENA
► Vrijednost emisije vibracija navedena u ovim
uputama izmjerena je u skladu s normiranom
procedurom mjerenja i može se koristiti za
usporedbu uređaja. Navedena razina emisije
vibracija može se koristiti i za uvodnu procjenu izloženosti.
UPOZORENJE!
► Vrijednost emisije vibracija mijenja se ovisno
o uporabi električnog alata i u nekim slučajevima može biti iznad vrijednosti navedene u
ovim uputama. Vibracijsko opterećenje može
se i potcijeniti ako se električni alat redovito
koristi na takav način. Nastojte održavati što
manje opterećenje vibracijama. Primjerne
mjere za smanjenje opterećenja vibracijama
su nošenje rukavica prilikom uporabe uređaja
i ograničenje radnog vremena. Pritom morate
uzeti u obzir sve sastavne dijelove ciklusa pogona (primjerice razdoblja u kojima je električni uređaji isključen, kao i razdoblja u kojima je
uređaj uključen ali radi bez opterećenja).
Opće sigurnosne
napomene za uporabu
električnog alata
UPOZORENJE!
► Pročitajte sve sigurnosne napomene i upute.
Nepridržavanje sigurnosnih napomena i uputa
može uzrokovati strujni udar, požar i/ili teške
ozljede.
Sačuvajte sve sigurnosne napomene i upute
za buduću uporabu.
Pojam „električni alat“ koji se koristi u sigurnosnim
napomenama odnosi se na električni alat s mrežnim napajanjem (s mrežnim kabelom) i na električni
alat s pogonom na baterije (bez mrežnog kabela).
1. Sigurnost na radnom mjestu
a) Radno mjesto držite čistim i dobro osvijetlje-
nim. Neuredno i neosvijetljeno radno mjesto
može uzrokovati nezgode.
b) Električni alat ne koristite u eksplozivnom
okruženju u kojem se nalaze zapaljive tekućine, plinovi ili prašina. Električni uređaji stvaraju
iskre koje mogu zapaliti prašinu ili pare.
c) Djecu i druge osobe držite podalje tijekom
korištenja električnog alata. U slučaju nepažnje možete izgubiti kontrolu nad uređajem.
PBS 900 B2
2. Električna sigurnost
a) Utikač električnog alata mora pristajati u
utičnicu. Utikač se ni na koji način ne smije
mijenjati.
Ne koristite adapterske utikače s uzemljenim
električnim alatom. Neizmijenjeni utikači i od-
govarajuće utičnice umanjuju rizik od strujnog
udara.
b) Izbjegavajte tjelesni kontakt s uzemljenim
površinama kao što su cijevi, sustavi grijanja,
štednjaci ili hladnjaci. Rizik od strujnog udara
veći je kada je tijelo uzemljeno.
c) Električni alat zaštitite od kiše i vlage. Prodi-
ranje vode u električni uređaj povećava rizik od
strujnog udara.
HR │ 13 ■
d) Ne koristite kabel za druge namjene, primje-
rice za nošenje uređaja, vješanje uređaja ili
izvlačenje utikača iz utičnice. Kabel uređaja
držite podalje od izvora topline, ulja, oštrih
bridova i pokretnih dijelova uređaja. Oštećeni
ili zapetljani kabeli povećavaju rizik od strujnog
udara.
e) Ako električni alat koristite na otvorenom,
koristite samo produžne kabele koji su odobreni za uporabu na otvorenom. Uporaba
takve vrste produžnog kabela prikladnog za
uporabu na otvorenom umanjuje rizik od strujnog udara.
f) Ako nije moguće izbjeći uporabu električnog
alata u vlažnom okruženju, koristite fido
sklopku. Korištenje fido sklopke smanjuje rizik
od strujnog udara.
3. Sigurnost osoba
a) Uvijek budite pažljivi i pazite na ono što radite,
i električnim alatom rukujte razumno. Električni
alat ne koristite ako ste umorni ili pod utjecajem droga, alkohola ili lijekova. Samo jedan
trenutak nepažnje za vrijeme uporabe električnog
alata može dovesti do ozbiljnih ozljeda.
b) Nosite osobnu zaštitnu opremu i uvijek nosite
zaštitne naočale. Nošenje osobne zaštitne opreme kao što je maska protiv prašine, nošenje sigurnosnih cipela s potplatima koji ne klize, zaštitnih
rukavica, zaštitne kacige ili zaštite za sluh – ovisno o vrsti i namjeni električnog alata – umanjuje
rizik od ozljeda.
c) Izbjegavajte nehotično uključivanje uređaja.
Uvjerite se da je električni alat isključen prije
nego ga priključite na napajanje i/ili bateriju,
uhvatite ili nosite. Ako prilikom nošenja uređaja
prst držite na prekidaču UKLJ/ISKLJ ili priključite
napajanje uključenog uređaja, može doći do
nezgode.
d) Alat za podešavanje ili ključeve za matice
uklonite prije uključivanja električnog alata.
Alat ili ključ koji se nalazi u rotirajućem dijelu
uređaja mogu dovesti do ozljeda.
e) Izbjegavajte neprirodan položaj tijela. Pobri-
nite se da čvrsto stojite i održavajte ravnotežu u svakom trenutku. Na taj ćete način moći
bolje kontrolirati električni alat u neočekivanim
situacijama.
f) Nosite prikladnu odjeću. Ne nosite široku odje-
ću ili nakit. Kosu, odjeću i rukavice držite podalje od pokretnih dijelova. Pokretni dijelovi mogu
zahvatiti ležernu, široku odjeću, nakit ili kosu.
g) Ako je moguće montirati usisivač i sustav za
prihvat piljevine, uvjerite se da su priključeni
i da se ispravno koriste. Uporaba usisivača
može smanjiti ugroženost prašinom.
4. Korištenje i rukovanje električnim
alatom
a) Ne preopterećujte uređaj. Koristite električni
alat prikladan za vrstu posla koji obavljate.
Prikladnim električnim alatom moći ćete bolje i
sigurnije raditi u navedenom području.
b) Ne koristite električne alate s oštećenim preki-
dačima. Električni alat koji ne možete uključiti i
isključiti opasan je i treba ga popraviti.
c) Izvucite utikač iz utičnice i/ili odstranite bate-
riju prije nego što započnete podešavati uređaj, mijenjati pribor ili odložite uređaj. Ova
mjera predostrožnosti onemogućuje nehotično
uključivanje uređaja.
d) Električni alat koji se ne koristi čuvajte izvan
dohvata djece. Osobama koje nisu upoznate
s načinom rada uređaja ili nisu pročitale upute nemojte dozvoliti da koriste uređaj. Električ-
ni alat je opasan ako njime rukuju osobe bez
iskustva.
e) Pažljivo održavajte električni alat. Provjerite
rade li svi pokretni dijelovi uređaja besprijekorno i da slučajno nisu zaglavljeni. Provjerite da
dijelovi uređaja eventualno nisu odlomljeni ili
da dijelovi nisu do te mjere oštećeni, da ometaju rad električnog alata. Prije uporabe uređaja
oštećene dijelove dajte popraviti. Mnoge ne-
sreće uzrokovane su loše održavanim električnim
alatom.
f) Sav alat za rezanje održavajte oštrim i čistim.
Pažljivo održavani alat za rezanje s oštrim oštricama rjeđe se zaglavljuje i lakše se navodi.
■ 14 │ HR
PBS 900 B2
Loading...
