Nissan VERSA NOTE 2019 Quick Reference Guide
QUICK REFERENCE GUIDE
2019 VERSA NOTE
2
4
7
9
10
11
Beneath
2
4
7
9
10
11
instrument
panel
Trip Computer
Low Tire Pressure Warning Light
Instrument Brightness Control*
Headlight and Turn Signal Switch
Wiper and Washer Switch
*See your Owner’s Manual for information.
Outside Mirror Control Switch
Steering Wheel Switches for
Audio Control/Bluetooth®/
Trip Computer
Cruise Control
Steering Wheel Tilt Adjustment*
Vehicle Dynamic Control (VDC)
OFF Switch*
Fuel-ller Door Release
Hood Release*
Front Passenger Air Bag
Status Light*
Audio System
Heater and Air Conditioner
(manual)
USB Port/AUX Jack
12V Power Outlet
TABLE OF CONTENTS
NEW SYSTEM FEATURES
Apple Carplay™ (if so equipped) .......................................................2
Android Auto™ (if so equipped) ........................................................3
ESSENTIAL INFORMATION
Rearview Monitor ......................................................................5
Tire Pressure Monitoring System (TPMS) with Easy-Fill Tire Alert (if so equipped) .....5
Loose Fuel Cap.........................................................................6
Fuel-ller Door .........................................................................7
Divide-N-Hide® Adjustable Floor (if so equipped) ......................................7
Clock Set/Adjustment (If so equipped) ................................................8
FIRST DRIVE FEATURES
Nissan Intelligent Key® System (if so equipped) .......................................9
Rear Hatch Release (Nissan Intelligent Key® models only – if so equipped) . . . . . . . . . .10
Seat Adjustments .....................................................................10
Starting/Stopping the Engine .........................................................11
Headlight Control Switch .............................................................12
Heater and Air Conditioner (manual) .................................................13
Wiper and Washer Switch .............................................................14
Outside Mirror Control Switch ........................................................14
Cruise Control (if so equipped)........................................................15
FM/AM Radio/SiriusXM® Satellite Radio (if so equipped) .............................16
SYSTEM GUIDE
USB (Universal Serial Bus) Connection Port/AUX Jack and iPod® Interface ..........17
Trip Computer ........................................................................17
Siri® Eyes Free.........................................................................18
Bluetooth® Hands-free Phone System ...............................................18
• System Operating Tips ...........................................................18
Hands-free Text Messaging Assistant ................................................21
Additional information about your vehicle is also available in your Owner’s Manual at
www.NissanUSA.com.
Please see your Owner’s Manual for important safety information and system
operationlimitations.
• A cellular telephone should not be used for any purpose while driving so full attention
may be given to vehicle operation.
• Always wear your seat belt.
• Supplemental air bags do not replace proper seat belt usage.
• Children 12 and under should always ride in the rear seat properly secured in child
restraints or seat belts according to their age and weight.
For more information, refer to the “Safety – Seats, seat belts and supplemental restraint system
(section 1)”, the “Monitor, climate, audio, phone and voice recognition systems (section 4)” and the
“Starting and driving (section 5)” of your Owner’s Manual.
• Do not drink and drive.
NEW SYSTEM FEATURES
APPLE CARPLAY™ (if so equipped)
The in-vehicle system can be used as a controller for some of the iPhone®
functions through Apple CarPlay™.
If your iPhone is compatible, Apple CarPlay can be used.
• Select the
• Select the “CarPlay” key
To connect your compatible iPhone to the system, you must connect the iPhone
cable to the USB connection port located beneath the climate controls.
• Depending on the setting, the “Startup Information” screen will appear.
• Touch “Yes” to use Apple CarPlay.
• After iPhone is connected to the system, the Apple CarPlay top menu screen
will appear. Touch “CarPlay” key
enter the Apple CarPlay screen.
• The Apple CarPlay top menu screen will appear, and the iPhone functions
displayed on the screen can be operated by the in-vehicle system.
• To return to the “Apple CarPlay” top menu
screen after operation, touch the
on the lower left corner of the “Apple
CarPlay” screen.
• To exit the “Apple CarPlay” screen and
display the other screens, press the
MENU button or touch the “NISSAN” key
on the Apple Carplay Menu.
To return to the “Apple CarPlay” screen:
• Select the “CarPlay” key
• Select the “
select “Carplay” key .
MENU key on the screen.
on the lower left corner of the screen.
on the lower left corner of the screen to
key
on the lower left corner of the screen;
Info” key on the launch bar and touch the “Apps” key, then
2
To view detailed instructional videos regarding these and other features,
please go to www.nissanownersinfo.mobi.
When connected to Apple CarPlay, Siri® operation can also be accessed.
There are three ways to start a Siri session.
1. Press and hold the
2. Touch and hold the
button on the steering wheel.
key at the lower lef t corner of the
“Apple CarPlay” screen.
3. Say “Hey Siri” (requires appropriate permissions enabled via phone.)
Press the button on the steering wheel or touch the key at the lower
left corner of the “Apple CarPlay” screen to end Siri.
Keep the interior of the vehicle as quiet as possible. Close the windows to
eliminate the surrounding noises (trac noises, vibration sounds, etc.), which
may prevent the system from recognizing the voice commands correctly.
Some Siri functions may not be available during driving.
For functions that can be used with Siri, please refer to the Apple® website.
Nissan Phone menu and Nissan Voice Recognition cellular phone commands will
not be available when Apple CarPlay is active.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the ”Getting started (section 2)” and the ”Information (section 5)” of your
NissanConnect® Owner’s Manual.
ANDROID AUTO™ (if so equipped)
The in-vehicle system can be used as a controller for some of the Android®
functions through Android Auto™.
INITIAL SETUP
Download the Android Auto app from the Google Play™ store to your
compatible Android phone.
To view detailed instructional videos regarding these and other features,
please go to www.nissanownersinfo.mobi.
3
NEW SYSTEM FEATURES
Launch the app from your Android phone
and follow the directions for setting up
the application.
Complete the initial set-up as prompted on
your Android phone. Several permissions will
need to be given to the app for Android Auto
to fully function on your in-vehicle system.
USING ANDROID AUTO
To connect your Android Auto capable phone
to the system, you must connect a USB cable
to the USB connection port located beneath
the climate controls.
• Depending on the setting, the “Startup
Information” screen will appear on the
center display.
• Touch “Yes” to use Android Auto.
• The Android Auto menu screen will appear, and the Android Auto functions
displayed on the screen can be operated by the in-vehicle system.
When connected to Android Auto, voice operation can be accessed. There are
three ways to start voice operation:
1. Press and hold the
2. Touch the
3. Say “OK Google” (requires appropriate permissions enabled via phone).
To return to the Android Auto home screen
after operation, touch the
bottom of the Android Auto screen.
To exit the Android Auto screen and display
the other screens, select the
button, touch the key and select
the “RETURN TO NISSAN” key on the
Android Auto Menu.
To return to the Android Auto home screen:
• Select the Android Auto key
• Touch the
touch the “Android Auto” key.
Nissan Phone menu and Nissan Voice Recognition cellular phone commands will
not be available when Android Auto is active.
If you have diculties with connection or performance, try a dierent USB cable.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the ”Getting started (section 2)” and the ”Information (section 5)” of your
NissanConnect® Owner’s Manual.
key on the upper right corner of the Android Auto screen.
Info key on the Launch Bar, touch the “Apps” key and then
button on the steering wheel until a beep is heard.
key on the
MENU
on the lower left corner of the screen;
4
To view detailed instructional videos regarding these and other features,
please go to www.nissanownersinfo.mobi.
ESSENTIAL INFORMATION
CHECK
TIRE
PRES
REARVIEW MONITOR
When the shift lever is moved to the
R (Reverse) position, the front display shows
the view to the rear of the vehicle.
The colored lines on the display screen
indicate approximate distances to objects.
• Red 1.5 ft (0.5 m)
• Yellow 3 ft (1 m)
• Green 7 ft (2 m)
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Monitor, climate, audio, phone and voice recognition systems
(section 4)” of your Owner’s Manual.
TIRE PRESSURE MONITORING SYSTEM (TPMS)
WITH EASY-FILL TIRE ALERT (if so equipped)
When one or more tires are low in pressure
and air is needed, the low tire pressure
warning light will illuminate in the
odometer and the CHECK TIRE PRES
(pressure) warning message is displayed.
• The tire pressures should be checked when
the tires are cold. The tires are considered
cold after the vehicle has been parked for
3 hours or more or driven less than
1 mi (1.6 km) at moderate speeds.
After tire pressures are adjusted, drive the vehicle at speeds above
16 mph (25 km/h) to activate the TPMS and the low tire pressure
warning light will extinguish.
When adding air to an under-inated tire, the TPMS with Easy-Fill Tire Alert (if so
equipped) provides visual and audible signals to help you inate the tire to the
recommended COLD tire pressure.
To use the Easy-Fill Tire Alert (if so equipped):
1. Move the shift lever to the
2. Place the ignition switch in the
3. Add air to the under-inated tire, and within a few seconds, the hazard
warning lights will start ashing.
4. When the designated tire pressure is reached, the horn will beep once and the
hazard warning ashers will stop ashing.
5. Repeat this procedure for any additional under-inated tires.
P (Park) position and apply the parking brake.
ON position. Do not start the engine.
To view detailed instructional videos regarding these and other features,
please go to www.nissanownersinfo.mobi.
5
ESSENTIAL INFORMATION
When the low tire pressure warning light ashes for 1 minute and then
remains on, the TPMS is not functioning properly. Have the system checked. It is
recommended that you visit a Nissan dealer for this service.
Tire pressure rises and falls depending on the heat caused by the vehicle’s
operation and the outside temperature. Low outside temperature can lower
the temperature of the air inside the tire, which can cause a lower tire ination
pressure. This may cause the low tire pressure warning light to illuminate. If
the warning light illuminates, check the tire pressure in your tires.
• Check the tire pressure (including the spare tire) often and always prior to long
distance trips.
The Tire and Loading Information label contains valuable information. Please
refer to the “Technical and consumer information (section 10)” of your Owner’s
Manual for the location of the Tire and Loading Information label.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Instruments and controls (section 2)”, the “Starting and
driving (section 5)”, the “In case of emergency (section 6)” and the “Do-it-yourself (section 8)”
of your Owner’s Manual.
LOOSE FUEL CAP
A LOOSE FUEL CAP warning message will
display in the odometer
fuel-ller cap is not tightened correctly.
To tighten, turn the cap clockwise until a
single click is heard.
The warning message will extinguish when
the vehicle detects the fuel-ller cap is
properly tightened and the reset switch
pressed for more than 1 second.
If the cap is not fully tightened, the Malfunction Indicator Light
also illuminate.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Instruments and controls (section 2)” and the “Pre-driving checks
and adjustments (section 3)” of your Owner’s Manual.
when the
is
may
6
To view detailed instructional videos regarding these and other features,
please go to www.nissanownersinfo.mobi.
FUEL-FILLER DOOR
The fuel-ller door release
the left of the steering wheel and below the
instrument panel.
To open the fuel-ller door, pull the release. To
lock, close the fuel-ller door securely.
The fuel-ller door is located on the driver’s
side of the vehicle.
Please see your Owner’s Manual for important safety
information, system limitations, and additional operating and
feature information.
For more information, refer to the “Instruments and controls
(section 2)” and the “Pre-driving checks and adjustments
(section 3)” of your Owner’s Manual.
is located to
DIVIDE-N-HIDE® ADJUSTABLE FLOOR (if so equipped)
Do not place more than 110 lbs (50 kg) on the
adjustable oor.
There are two positions to store
the adjustable oor. The upper
position allows for additional
storage below the adjustable oor .
The adjustable oor has two retaining
tabs on each side to secure the oor
in place. When the retaining tabs are in
the lock position (outboard), the adjustable
oor may be moved along the tracks from
the lower position to the upper position
and vice versa. When the tabs are in the
unlock position (inboard), the adjustable oor
may be removed completely.
To slide the adjustable oor from the lower
position
the guide tracks:
1. Fold the adjustable oor
2. Lift the oor and pull up along the
3. Push the oor back then unfold the oor.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Instruments and controls (section 2)” and the “In case of emergency
(section 6)” of your Owner’s Manual.
to the upper position using
guide tracks.
in half.
To view detailed instructional videos regarding these and other features,
please go to www.nissanownersinfo.mobi.
7
Loading...
