National Semiconductor MNLM710-X Technical data
MNLM710-X REV 1AL
VOLTAGE COMPARATOR
MILITARY DATA SHEET
Original Creation Date: 04/17/96
Last Update Date: 06/28/96
Last Major Revision Date: 06/24/96
Industry Part Number
LM710
Prime Die
LM710
Processing
MIL-STD-883, Method 5004
Quality Conformance Inspection
MIL-STD-883, Method 5005
NS Part Numbers
LM710H-MLS
LM710H/883
Subgrp Description Temp ( C)
1 Static tests at +25
2 Static tests at +125
3 Static tests at -55
4 Dynamic tests at +25
5 Dynamic tests at +125
6 Dynamic tests at -55
7 Functional tests at +25
8A Functional tests at +125
8B Functional tests at -55
9 Switching tests at +25
10 Switching tests at +125
11 Switching tests at -55
o
1
MNLM710-X REV 1AL
MILITARY DATA SHEET
Electrical Characteristics
DC PARAMETERS
(The following conditions apply to all the following parameters, unless otherwise specified.)
DC: +Vcc = 12V, -Vcc = -6V
SYMBOL PARAMETER CONDITIONS NOTES
Vio Input Offset
Iio Input Offset
Iib Input Bias
CMRR Common Mode
Voh Positive Output
Vol Negative Output
Isink Output Sink
I+ Positive Supply
I- Negative Supply
Delta
Vio/Delta
T
Delta
Iio/Delta
T
Pd Power Dissipation Vo = 1.4V 150 mW 1, 2,
Rout Output Resistance Vo = 1.4V(KO=K Ohm) 500 Ohm 1
Vin Input Voltage
Avs Voltage Gain (Open Loop)(1.25K=1250V/V) 1.25K V/V 4
Voltage
Current
Current
Rejection Ratio
Level
Level
Current
Current
Current
Input Offset
Voltage
Sensitivity
Input Offset
Current
Sensitivity
Range
Vo=1.8V(-55 C); 1.4V(25 C); 1V(125 C);
Rs=<200 Ohms
Vo=1.8V(-55 C); 1.4V(25 C); 1V(125 C);
Rs=<200 Ohms
Vo as in Vio 3 -3 3 uA 1, 2
3 -7 7 uA 3
Vo as in Vio -20 20 uA 1
Vin=10V(p-p),
(1mV|maximum|=80dB|minimum|)
Vin = 5mV, Ioh = -5mA 2.5 4 V 1
Vin = 5mV, Iol = 0mA -1 -0 V 1, 2,
Vin = 5mV, Vout = 0V 2 mA 1
Vo = 1.4V 9 mA 1, 2,
Vo = 1.4V -7 mA 1, 2,
25 C < T < 125 C 2 -10 10 uV/ C 2
-55 C < T < 25 C 2 -10 10 uV/ C 3
25 C < T < 125 C 2 -25 25 nA/ C 2
-55 C < T < 25 C 2 -75 75 nA/ C 3
1+5 V 1, 2,
PINNAME
MIN MAX UNIT
-2 2 mV 1
-3 3 mV 2, 3
-40 40 uA 2, 3
80 dB 1, 2,
2.4 4 V 2, 3
0.5 mA 2
1mA3
1K V/V 5, 6
SUB-
GROUPS
3
3
3
3
3
3
2
