Magellan CrossoverGPS 980890-05 User Manual
Magellan® CrossoverGPS
Reference Manual
™
Instructions for Operating the
Magellan CrossoverGPS
IMPORTANT SAFETY WARNINGS
The Magellan CrossoverGPS is a vehicle-navigation aid designed to assist you in arriving at your selected destinations.
When using the Magellan CrossoverGPS, these safety rules must be followed to prevent accidents that can result in injury or
death to yourself or others:
• Some countries prohibit mounting any item to your windscreen. Please check the applicable regulations in your country
as regards windscreen mounting. Go to www.magellanGPS.com for alternate mounting solutions. An adhesive disk is
supplied with the Magellan CrossoverGPS for use as an alternative mounting solution to the dashboard.
• When driving, the need to view the display is minimal. Voice prompts will guide you to your destination. The driver
should enter data or programme the Magellan CrossoverGPS only when the vehicle is stationary. Only a vehicle
passenger should enter data or programme the Magellan CrossoverGPS while the vehicle is moving.
• It is your responsibility to comply with all traffic laws.
• Every attempt is made to ensure that the database is accurate. However, roadways, points of interest (POIs), and
business and service locations may change over time. The database does not include, analyse, process, consider, or
reflect any of the following: legal restrictions (such as vehicular type, weight, height, width, load and speed restrictions);
road slope or grade; bridge height, width, weight, or other limits; population density; neighbourhood quality or safety;
availability or proximity of police, emergency rescue, medical or other assistance; construction work zones or hazards;
road or lane closures; road, traffic, or traffic facilities’ safety or condition; weather conditions; pavement characteristics
or conditions; special events; traffic congestion. It is your responsibility to disregard any unsafe, hazardous, or illegal
route suggestions.
• Keep the Magellan CrossoverGPS safe from extreme temperature conditions. For example, do not leave it exposed to
direct sunlight for an extended period of time.
• Take care when mounting the Magellan CrossoverGPS in your vehicle, whether using the windscreen mount or other
mount or accessories, that it does not obstruct the driver’s view of the road, interfere with the operation of the vehicle’s
safety devices such as air bags, or present a hazard to occupants of the vehicle should the Magellan CrossoverGPS be
dislodged while driving. You assume the risks associated with damage to your vehicle or vehicle occupants as the result
of your choices in mounting the Magellan CrossoverGPS.
• Laws in some countries prohibit wearing stereo headphones while operating a motor vehicle. Please check the applicable
laws in the country you are driving.
• Proceed with caution when listening to music for prolonged periods of time through headphones, as this may lead to
hearing loss.
• The battery in the Magellan CrossoverGPS is rechargeable and should not be removed. In the event that it should need
to be replaced, please contact Magellan Technical Support.
About Charging the Magellan CrossoverGPS
• Only use the AC adapter (Phihong: PSC2200R-050) approved for your Magellan CrossoverGPS. Use of another type of
AC adapter can result in malfunction and/or possible fire hazard due to battery overheating.
• Only use the car charger approved for/supplied with your Magellan CrossoverGPS. Use of another type of car charger will
result in malfunctioning and/or may be hazardous.
• The Magellan CrossoverGPS is intended to be supplied with a LISTED Power Unit marked with "LPS", "Limited Power
Source" and output rated + 5 V dc/2.0 A".
• Use the USB cable approved for/supplied with your Magellan CrossoverGPS.
• For safety reasons, the battery in your Magellan CrossoverGPS will stop charging when the ambient temperature is below
0°C (32°F) or above 45°C (113°F).
1
IMPORTANT SAFETY WARNINGS
About the AC Adapter
• Do not use the adapter in a high moisture environment. Never touch the adapter when your hands or feet are wet.
• Allow adequate ventilation around the adapter when using it to operate the device or charging the battery. Do not cover
the AC adapter with paper or other objects that will reduce cooling. Do not use the AC adapter while it is inside a
carrying case.
• Connect the adapter to a suitable power source. The voltage and grounding requirements are found on the product case
and/or packaging.
• Do not use the adapter if the cord becomes damaged.
• Do not attempt to service the Magellan CrossoverGPS. There are no serviceable parts inside. Replace the Magellan
CrossoverGPS if it is damaged or exposed to excess moisture.
About the Battery
• Do not attempt to replace the battery. Please contact Magellan Technical Support for issues related to the battery.
• Use the charger approved for your Magellan CrossoverGPS.
2
IMPORTANT SAFETY WARNINGS
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for class B digital devices, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and if not properly installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by taking one of the following steps:
• Reorient or relocate the receiving aerial.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device
may not cause harmful interference and (2) this device must accept any interference received, including interference that
may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate this equipment.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits established for an uncontrolled environment. End users must
follow the specific operating instructions for satisfying RF exposure compliance.
This transmitter must not be placed next to or operated in conjunction with any other aerial or transmitter.
In order to maintain compliance with FCC regulations, shielded cables must be used with this equipment. Operation with
non-approved equipment or unshielded cables is likely to result in interference to radio and TV reception. The user should
note that any changes or modifications made to the equipment not expressly approved by the manufacturer could void the
user’s authority to operate this equipment.
The Magellan CrossoverGPS must be installed and operated at a distance of at least 8 inches (20 cm) from the user.
3
IMPORTANT SAFETY WARNINGS
IC statement
Operation is subject to the following two conditions:
1. This device may not cause interference and
2. This device must accept any interference, including interference that may cause undesired operation of the
device.
IMPORTANT NOTE:
IC Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits established for an uncontrolled environment. End users must
follow the specific operating instructions for satisfying RF exposure compliance.
This transmitter must not be placed next to or operated in conjunction with any other aerial or transmitter.
© 2007 Magellan Navigation, Inc. All rights reserved. The Magellan Logo, Magellan, Magellan CrossoverGPS, Turn it on and
go, TrueView, QuickSpell, SmartDetour, and SmartVolume are trademarks of Thales. No part of this user manual may be
reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, for
any purpose other than the purchaser’s personal use, without the prior written permission of Magellan Navigation, Inc.
631409-18 B
4
Magellan CrossoverGPS .............................................................................1
What the Magellan CrossoverGPS can do for you... ..............................................1
Magellan CrossoverGPS Reference Manual .........................................................2
Magellan CrossoverGPS .....................................................................................2
Magellan CrossoverGPS Right Side View .............................................................3
Magellan CrossoverGPS Left Side View ...............................................................3
Magellan CrossoverGPS Application Menu Screen ......................................4
Accessing the Enhanced POI Menu .....................................................................5
Satellite Status ..................................................................................................5
Magellan CrossoverGPS Vehicle Navigation Screens ...................................6
Map Screen .......................................................................................................6
Main Menu Screens ...........................................................................................7
Main Menu - Active Route ..................................................................... 7
Main Menu - No Active Route ................................................................ 9
Locate Screen .................................................................................................10
List of Directions ..............................................................................................10
Creating Routes .......................................................................................11
Overview .........................................................................................................11
Creating a route to a street address ..................................................................11
Creating a route using POIs ..............................................................................12
Creating a route to a POI by name ........................................................ 12
Creating a route to a nearest POI ......................................................... 13
Creating a route to a POI near an upcoming motorway exit ...................... 13
Creating a route to go home .............................................................................14
Setting the home address .................................................................... 14
Changing the home address ................................................................. 15
Create a route to the home address ...................................................... 15
Using the address book ....................................................................................15
Creating a route to a previous destination ............................................. 15
Adding a previous destination to your address book ............................... 16
Creating a route to a favourite destination ............................................. 16
Creating a route to an address in the address book ................................ 16
Editing an address in the address book ................................................. 17
Deleting an address from the address book ........................................... 17
Creating a new address ....................................................................... 18
Creating a route to a Junction .............................................................. 18
Magellan CrossoverGPS Enhanced POIs ....................................................20
Overview .........................................................................................................20
Speed Camera POIs ..........................................................................................20
Accessing the Enhanced POI Menu ...................................................................20
Loading an Enhanced POI file ...........................................................................20
Displaying/Selecting Categories .......................................................................20
Setting Alarms .................................................................................................21
Setting Alert Parameters ..................................................................................21
Creating a Route Using Enhanced POIs ..............................................................21
Saving a POI to your Address Book from Enchanced POIs ...................................21
Using the Trip Planner .............................................................................23
Overview .........................................................................................................23
Creating a multiple destination trip ...................................................................23
Activating a multiple destination trip .................................................................23
Editing a multiple destination trip .....................................................................24
Deleting a multiple destination trip ...................................................................25
Renaming a multiple destination trip .................................................................25
Marine Navigation ...................................................................................26
Loading MapSend BlueNav Charts .....................................................................26
Changing Regions ............................................................................................26
Special Terminology ........................................................................................27
Waypoints .......................................................................................... 27
Track ................................................................................................ 27
Backtrack .......................................................................................... 27
Goto .................................................................................................. 27
Trip ................................................................................................... 27
Map Screen Overview ......................................................................................28
Creating a Waypoint from the Map Screen .........................................................29
Creating a Waypoint from the Compass Screen ..................................................29
Creating a Waypoint from the Marine Navigation Menu ......................................29
Setting your Port ..............................................................................................30
Going to your Port ............................................................................................30
Creating a Goto trip from the Map Screen ..........................................................30
Creating a Goto trip from the Marine Navigation Menu .......................................31
Creating a multiple destination trip ...................................................................31
Activating a multiple destination trip .................................................................32
Track Tools .....................................................................................................32
Bow View ........................................................................................................33
Accessing the Bow View ...................................................................... 33
Outdoor Navigation ..................................................................................34
Loading MapSend Topo Charts ..........................................................................34
Changing Regions ............................................................................................34
Special Terminology ........................................................................................35
Waypoints .......................................................................................... 35
Track ................................................................................................ 35
Backtrack .......................................................................................... 35
Goto .................................................................................................. 35
Trip ................................................................................................... 35
Map Screen Overview ......................................................................................36
Creating a Waypoint from the Map Screen .........................................................37
Creating a Waypoint from the Compass Screen ..................................................37
Creating a Waypoint from the Outdoor Navigation Menu .....................................37
Setting your Base Camp ...................................................................................38
Going to your Base Camp ..................................................................................38
Creating a Goto trip from the Map Screen ..........................................................38
Creating a Goto trip from the Outdoor Navigation Menu ......................................39
Creating a multiple destination trip ...................................................................39
Activating a multiple destination trip .................................................................40
Track Tools .....................................................................................................40
Nav Road View ................................................................................................41
Accessing the Nav Road View .............................................................. 41
Setting User Options ................................................................................42
Overview .........................................................................................................42
POI Selection ...................................................................................................42
Address Book Options (Waypoint Options for Marine and Outdoor use) ................42
Active Track Options (Marine and Outdoor use only) .........................................42
Map Options ....................................................................................................43
Map Colours (Vehicle Navigation only) ............................................................43
Route Preferences (Vehicle Navigation only) ....................................................43
Detour Options (Vehicle Navigation only) .........................................................44
Simulator Mode (Vehicle Navigation only) ........................................................44
Menu Colours ..................................................................................................44
Tone Options ...................................................................................................45
Navigation Instruction (Vehicle Navigation only) ..............................................45
GPS Options .....................................................................................................45
Backup and Restore (Vehicle Navigation only) .................................................45
Export Data/Import Data (Marine and Outdoor Navigation only) ..........................45
System Settings ......................................................................................46
Overview .........................................................................................................46
Volume ............................................................................................................46
Brightness .......................................................................................................46
Power .............................................................................................................46
Language ........................................................................................................46
Time Zone .......................................................................................................46
Unit of Measurement ........................................................................................47
Page 2 ............................................................................................................47
Product Information .........................................................................................47
Diagnosis ........................................................................................................47
Additional Items ...............................................................................................47
Battery Life ......................................................................................................47
Contact Us .......................................................................................................47
Magellan CrossoverGPS PC Tools Installation ..........................................48
Installing the Software .....................................................................................48
Magellan CrossoverGPS POI Manager ......................................................49
Latitude ...........................................................................................................49
Longitude ........................................................................................................49
Altitude ...........................................................................................................50
Opening a POI File ...........................................................................................50
Creating a New POI FIle ....................................................................................51
Adding Individual POIs .....................................................................................51
Importing a Data File ........................................................................................53
Magellan CrossoverGPS Music Manager ..................................................54
Magellan CrossoverGPS Photo Manager ...................................................55
Music Player ...........................................................................................56
Single Song Play .............................................................................................56
Multiple Song Play ...........................................................................................57
Play .................................................................................................. 57
Create ............................................................................................... 57
Modify ............................................................................................... 57
Delete ............................................................................................... 58
Rename ............................................................................................. 58
Play Mode .......................................................................................................58
List Songs .......................................................................................................58
Equaliser .........................................................................................................59
Help ................................................................................................................59
Photo Viewer ..........................................................................................60
View Single Photo ............................................................................................60
Previous Image .................................................................................. 60
Zoom ............................................................................................... 61
Slideshow ......................................................................................... 61
Pan .................................................................................................. 61
Rotate Image .................................................................................... 61
Next Image ......................................................................................................61
ESC ................................................................................................. 61
Manage Photos ................................................................................................62
List View ........................................................................................... 62
Thumbnail ......................................................................................... 62
Rename ............................................................................................. 62
Properties .......................................................................................... 62
Tools ...............................................................................................................62
Preferences ....................................................................................... 62
Delete Files ....................................................................................... 62
About ................................................................................................ 62
Magellan CrossoverGPS
Thank you for purchasing the Magellan CrossoverGPS. The Magellan CrossoverGPS will be
your perfect driving, hiking and boating companion for all your trips, from a trip to the
grocery store or a week’s holiday.
What the Magellan CrossoverGPS can do for you...
• Provide turn-by-turn driving instructions to any address in the selected country.
• Contains an address book that you can save addresses to that you often need to
route to. You can even mark an address as a favourite to make it easier to find.
• Comes preloaded with an extensive, easily accessible points of interest (POI)
database that can be used to quickly find a restaurant, petrol station, bank or
other popular destinations.
• The Magellan CrossoverGPS includes a SmartDetour™ tool that will
automatically ask you if you want to detour around unrelenting traffic jams.
• Provides alerts to notify you of approaching speed traps.
• Includes a trip planner that provides you with the ability to create a trip with
multiple destinations.
• It comes preloaded with Marco Polo travel guides.
• A trip computer that provides a record of your trip that can be saved.
• Hikers can use the Magellan CrossoverGPS to plan their hike or return to camp.
• Boaters will be able to set fishing hotspots that they can return to on their next
trip.
• Small and portable, the Magellan CrossoverGPS fits into your pocket and is
ready to go with you anywhere.
The interface of the Magellan CrossoverGPS is smart and easy-to-use. Every feature is just
a tap away with the Magellan CrossoverGPS touchscreen.
Magellan Crossover GPS 1
Magellan CrossoverGPS Reference Manual
It is not necessary to read this entire document to begin using the Magellan
CrossoverGPS. Most users will find that they can use the Magellan CrossoverGPS straight
out of the box and just refer to this manual on those rare occasions when a little help on a
feature is required.
Magellan CrossoverGPS
Power
The Magellan CrossoverGPS uses a touchscreen display for all user inputs. The only
readily accessible button that is normally used is the power button located on the right
side of the unit.
You will need to press and hold the power button down for a few seconds to turn the
Magellan CrossoverGPS on. This function prevents the unit from accidentally switching
on.
To turn the Magellan CrossoverGPS off, you will need to press the power button down
again for 1 second if you want to put it into sleep mode or for 3 seconds to completely
switch it off.
All connections to the Magellan CrossoverGPS are located on the left and right sides of
the unit, protected by a rubber covering to keep out moisture. When you need to access
the connectors, simply lift the protective cover from the bottom.
Magellan Crossover GPS 2
Magellan CrossoverGPS Right Side View
Power - Press and hold to turn the power on or off.
USB Connection - (under protective cover) Used for
connecting to a personal computer to upgrade the
firmware or to upload music files, photos and
custom POIs.
Headphone Connector - (under protective cover)
Please check local laws for use of headphones
while driving.
External Power Input - (under protective cover)
Connects power to the Magellan CrossoverGPS
from a cigarette lighter adapter or an approved
AC adapter.
Magellan CrossoverGPS Left Side View
SD Card Slot - (under protective cover) Contains an
SD card with a detailed map for your country and
any files you may have transferred from a PC.
Additional SD cards with street maps from other
countries, topo maps or marine charts are available
from www.magellanGPS.com
Reset - (under protective cover) You may be
required to reset the unit should the Magellan
CrossoverGPS cease functioning or during firmware
updates.
Hold Button - (under protective cover) Used to turn
off the touchscreen portion of the display and
switches the receiver into power saving mode.
Primarily used for outdoor use where the Magellan
CrossoverGPS might be in a pocket or backpack.
Magellan Crossover GPS 3
Magellan CrossoverGPS Application Menu Screen
The Application Menu is the first screen displayed after you go through the
initial setup and is the starting point for all of the Magellan CrossoverGPS
built-in applications. You can access this menu by selecting the Exit icon
found on the main menu of each application.
Application Menu
Allows you to access the Vehicle
Navigation application. Uses street
maps preloaded on SD cards to guide
you to a street address or POI with
turn-by-turn driving instructions or
basic walking directions.
Allows you to access the Outdoor
Navigation application. This
application provides you with all the
tools you need for hiking and camping
activities. The Magellan CrossoverGPS
has a built-in basemap for all your
outdoor activities. Detailed topographic
information can be added using
optional MapSend Topographic maps
available at www.magellanGPS.com.
The Music button launches the built-in
Music Player application, for reading
MP3 files that can be stored on an SD
Card.
The Marine button allows you to access
the Magellan CrossoverGPS Marine
Navigation application. This application
provides you with all the tools you need
for boating and fishing activities. The
Magellan CrossoverGPS has a built-in
basemap for all your outdoor activities.
Detailed marine charts can be added
using optional MapSend BlueNav charts
available at www.magellanGPS.com.
Allows you to access System
Configuration. Used to adjust the
language, volume, brightness, and other
system settings.
Allows you to access the built-in Photo
Viewer application, for viewing photos
that can be stored on an SD Card.
Magellan CrossoverGPS Application Menu 4
Accessing the Application Menu
The Application Menu can be accessed from any of the applications by
tapping the Exit icon found on the main menu of each application.
Example: the Marine Navigation Menu
with the Exit button outlined.
Please note that the System Settings menu does not display an Exit button. To access the
Application Menu from System Settings, press the ‘X’ in the upper right-hand corner.
Satellite Status
All of the navigation screens display a bar graph of the satellite status in the
upper right-hand corner. When the bars are green, the Magellan CrossoverGPS is
receiving GPS signals and is calculating a position fix, defining your location.
When the bars are yellow, the Magellan CrossoverGPS is receiving GPS signals but has not
been able to calculate your location yet. A red X through the icon indicates that the
Magellan CrossoverGPS is unable to receive GPS satellite signals.
Selecting the Satellite Status icon displays the
Satellite Status screen providing more information
about the satellites and the signals being received.
Magellan CrossoverGPS Application Menu 5
Magellan CrossoverGPS Vehicle Navigation Screens
Map Screen in Car/Motorcycle mode
The Map Screen is the most commonly used screen on the Magellan CrossoverGPS.
Whether you are getting directions or just driving around town, the Map screen will give
you the peace of mind of knowing where you are and where you are going.
1
2
13
12
3
11
4
5
10
6
9
7
1
Current Street Name Name of street you are
currently on.
8
When selected, displays the Locate
screen
2
3
4
5
6
7
Magellan CrossoverGPS Vehicle Navigation Screens 6
Zoom out When selected, zooms out the map
display.
Destination Icon Provides a visual indication
of your destination.
POI Icon The sample indicated is the
icon for a restaurant.
Location Icon Provides a visual indication
of your current position.
Next Manoeuvre Indicates what type of
manoeuvre you will need to
perform when directed.
Distance to Next
Manoeuvre
Displays the calculated
distance to your next
manoeuvre in the chosen unit
of measurement.
When selected, it offers you the
option of setting a trip to that POI.
When selected, displays that you are
heading in a N, NE, NW, or W
direction.
When selected, repeats the last
verbal instruction.
When selected, displays the total
remaining distance of the trip.
8
Time to Next Manoeuvre Displays the calculated time
to your next manoeuvre.
Selecting this button toggles the
field between time to next
manoeuvre and remaining distance
of the trip.
9
10
11
12
13
Menu Button When selected, brings up the main
Vehicle Navigation menu.
Next Manoeuvre Street
Name
Mute Selecting this button will mute the
Zoom In When selected, zooms in the map
Satellite Status Displays a bar graph
Displays the name of the
street for the next
manoeuvre.
indicating satellite signal
strength.
When selected, displays the
manoeuvre list screen.
speaker.
display.
When selected displays the Satellite
Status screen.
Map Screen in Pedestrian mode
In Pedestrian Mode the Map Screen doesn’t display the same information as in Car/
Motorcycle Mode. Your route is shown as a straight line from your current position to
your destination and no turn-by-turn guidance is given. You can easily walk to your
destination using the straight line displayed on the street map as a guide.
Magellan CrossoverGPS Vehicle Navigation Screens 7
Main Menu Screens
The Main Menu has two modes: active route and normal. When a route is active the Main
Menu provides functions that pertain to the route. With no active route, the Main Menu
provides access to functions that are used to create a route.
Main Menu - Active Route
2
1
5
1
Map Button Used to access the Map Screen
3
6
7
10
4
12
11
10
8
9
2
3
4
5
6
Magellan CrossoverGPS Vehicle Navigation Screens 8
Detour Button Detour gives you the option of re-
routing the trip around traffic problems
ahead of you.
Cancel Route Button Cancels the route you are travelling on.
Satellite Status Displays a bar graph indicating satellite
signal strength.
Re-route Button. Provides a way to re-calculate the route
you are on. Useful when you have
veered off the route and need it to be
re-calculated.
POI Near Exit Button This function provides you with access
to a listing of common POI categories
that are near upcoming motorway exits.
(Can only be used while travelling on a
motorway.)
When selected displays the
Satellite Status screen.
The Magellan CrossoverGPS
performs automatic re-routing.
This button can be used to
speed up the re-routing process.
7
Menu Page 2 Accesses the second page of the route
main menu.
10
11
12
8
9
Options Button Accesses the options menu.
Menu Page 1 Accesses the first page of the route
main menu.
Application Menu Accesses the Application Menu for
additional applications and system
settings.
Active Trip Button Functional only when travelling on a
multi-destination trip. Provides access
to tools to modify the trip you are on.
Trip Computer Accesses the trip computer feature
providing information about the trip
that can be saved.
Magellan CrossoverGPS Vehicle Navigation Screens 9
Main Menu - No Active Route
2
1
5
1
2
Map Button Used to access the Map Screen
Street Address Button Create a trip using a street address as
6
3
7
the destination.
8
14
15
4
13
12
9
10
11
3
4
5
6
7
8
9
POI-Points of Interest
Button
Satellite Status Displays a bar graph indicating satellite
Home Button Save your home address in the
Address Book Button Accesses addresses saved to the
Town Centre Button Create a route to the centre of any
Menu Page 2 Accesses the second page of the route
Destination country
button
Create a trip using a point of interest
from the POI database as the
destination.
signal strength.
Magellan CrossoverGPS and easily
create a trip with your home as the
destination.
address book. Can also be used to reroute to a previous destination.
selected town.
main menu.
Used to access country detailed maps
loaded in the Magellan CrossoverGPS.
This button can be selected only if
several countries are loaded on your SD
Card.
When selected displays the
Satellite Status screen.
When several countries are loaded
on your SD Card, always make
sure the appropriate country is
first selected when you search for
an address or a POI.
10
11
Options Button Accesses the options menu.
Menu Page 1 Accesses the first page of the route
main menu.
Magellan CrossoverGPS Vehicle Navigation Screens 10
12
Application Menu Accesses the Application Menu for
additional applications and system
settings.
13
14
15
Enhanced POIs Used to access personal POIs created
with the Magellan PC Tools and
Premium POIs.
Trip Computer Accesses the trip computer feature
providing information about the trip
that can be saved.
Trip Planner Used to create a multi-destination trip
that can be routed to or saved.
Locate Screen (Select the top bar on the Map screen)
The Current Location screen displays information about your present position and
provides a way to save your present position in your address book.
The left side of the screen indicates your
heading, an address for your present position (if
able to calculate), the next and previous street,
as well as the latitude/longitude of your present
position.
The right side of the screen shows a compass,
the elevation (if able to calculate) and the speed
at which you are travelling.
Use the Save button to store your current position into your address book. Select "X" in
the top right-hand corner to return to the Map screen.
List of Directions (Select the next manoeuvre bar on the Map screen)
The List of Directions screen displays all of the
manoeuvres remaining before reaching your
destination.
Select one of the manoeuvres in the list to
exclude that manoeuvre from the route. The
manoeuvre will be excluded and the route
recalculated.
The bottom of the screen displays the heading,
distance to next manoeuvre, time to next manoeuvre and distance for the entire route.
Select "X" in the top right-hand corner to return to the Map screen.
Magellan CrossoverGPS Vehicle Navigation Screens 11
Creating Routes
Overview
Creating a route involves selecting a destination and choosing how you would like the
route calculated. Once this is done, the Magellan CrossoverGPS will calculate the route
using the guidelines you provide and displays the Map screen with information guiding
you to your destination. You can select to be guided while driving - you will then receive
detailed turn-by-turn visual and vocal instructions - or while walking - you will then be
guided by a straight line displayed on the map from your current position to your
destination.
Selecting the routing method is a two-step process that is always identical. It shall thus
be described first in this section.
Selecting a routing method
Whatever way you select your destination (entering an address, selecting a POI, choosing
an address from your address book or a town) you must select the routing method to allow
your CrossoverGPS to calculate your route. To do this you will have to choose the
Navigation mode first and then the Route Preference.
Choosing the Navigation Mode
When a destination has been chosen (an address, POI,
or town centre), a screen is displayed allowing you to
select the Navigation Mode you wish to use. Tap the
Navigation Mode button to select Car/Motorcycle to get
turn-by-turn vocal and visual guidance to your
destination or select Pedestrian to display a straight line
on the map from your current position to your
destination, to allow you to easily walk to the selected
address.
Creating Routes 11
Choosing the Route Preference
If you selected Car/Motorcycle as your
Navigation method. Select from one of the
available options: Shortest Time, Shortest
Distance, Least Use of Freeways or Most use of
Freeways.
Route button
Once you have selected your Navigation Mode and Route Method (Car/Motorcycle only),
tick the Avoid Toll Roads option if you want your route to be calculated avoiding toll roads
and then select the Route button to calculate your route.
The Map screen will automatically display with your route highlighted.
Note that all Navigation Mode and Route Preference settings will be saved for your next
address selection but they can be overridden on each new trip if you wish.
Choosing your destination
Detailed map routing: The Magellan CrossoverGPS can only provide routing information
for detailed maps that are loaded on the SD Card. The detailed maps loaded on your SD
Card can cover one or several countries. It is not possible to be guided from and to an
address that doesn’t belong to the detailed maps that are loaded on your SD Card.
When your SD card is loaded with detailed maps for several countries, you must make
sure that the approriate Country of Destination has been selected before you start
searching for an address or a POI.
Creating Routes 12
Creating a route to a street address
1. From the Main Menu, select Street Address.
2. Select Search By Town, Search by Postcode or Previous Towns.
3. Input the information as requested depending upon your selection in step 2.
If using Search By Town: Spell the name
of the town and select from the town list,
spell the name of the street and select
from the available street list, then enter
the address number for the street. (If the
address you want to enter does not fall
within the acceptable range displayed,
enter the closest possible address.)
If using Search by Postcode: Enter the
postcode for the address and select the
town from the list of available towns.
Spell the name of the street and select
from the available street list, then enter
Using the keypad to enter information.
The keyboard will display only those letters that
spell an item in the database. This provides a
quick and easy tool to enter town and street
information.
Use the “123” button to enter numbers and the
“& ? / -” button to access symbols and accented
characters.
the address number for the street (it
must fall within the street number range displayed at the top of the screen).
If using Previous Towns: Select a town from the list of previously used towns.
Spell the name of the street and select from the available street list, then enter
the address number for the street (it must fall within the street number range
displayed at the top of the screen).
4. Select the navigation method and route preference to be used to calculate
the route.
NOTE: All the street names are indexed using the main significant words in their names
(i.e. not the prefixes or articles). However, there are some exceptions where you may
encounter problems trying to find a street by typing only the significant word in its name.
If this is the case, try typing the prefix or article of the street name first.
Creating Routes 13
Loading...
