Magellan® CrossoverGPS

Reference Manual

™

Instructions for Operating the

Magellan CrossoverGPS

IMPORTANT SAFETY WARNINGS

The Magellan CrossoverGPS is a vehicle-navigation aid designed to assist you in arriving to your selected destinations. When using the Magellan CrossoverGPS, these safety rules must be followed to prevent accidents that can result in injury or death to yourself or others:

• California and Minnesota law prohibits mounting any item to your windshield. Please check with your state or local law enforcement for applicable regulations regarding windshield mounting. Go to www.magellanGPS.com for alternate mounting solutions. An adhesive disk is supplied with the Magellan CrossoverGPS for use as an alternate mounting solution to the dashboard.

• When driving, the need to view the display is minimal. Voice prompts will guide you to your destination. The driver should enter data or program the Magellan CrossoverGPS only when the vehicle is stopped. Only a vehicle passenger should enter data or program the Magellan CrossoverGPS while the vehicle is moving.

• It is your responsibility to comply with all traffic laws.

• Every attempt is made to ensure that the database is accurate. However, roadways, points of interest (POIs), and business and service locations may change over time. The database does not include, analyze, process, consider, or reflect any of the following: legal restrictions (such as vehicular type, weight, height, width, load and speed restrictions); road slope or grade; bridge height, width, weight, or other limits; population density; neighborhood quality or safety; availability or proximity of law enforcement, emergency rescue, medical, or other assistance; construction work zones or hazards; road or lane closures; road, traffic, or traffic facilities’ safety or condition; weather conditions; pavement characteristics or conditions; special events; traffic congestion. It is your responsibility to disregard any unsafe, hazardous, or illegal route suggestions.

• Keep the Magellan CrossoverGPS safe from extreme temperature conditions. For example, do not leave it exposed to direct sunlight for an extended period of time.

• Take care when mounting the Magellan CrossoverGPS in your vehicle, whether using the windshield mount or other mount or accessories, that it does not obstruct the driver's view of the road, interfere with the operation of the vehicle's safety devices such as air bags, or present a hazard to occupants of the vehicle should the Magellan CrossoverGPS be dislodged while driving. You assume the risks associated with damage to your vehicle or vehicle occupants as the result of your choices in mounting the Magellan CrossoverGPS.

• Laws in some states prohibit wearing stereo headphones while operating a motor vehicle. Please contact your state’s Department of Motor Vehicles for information.

• The battery in the Magellan CrossoverGPS is rechargeable and should not be removed. In the event it should need to be replaced, please contact Magellan Technical Support.

About Charging the Magellan CrossoverGPS

• Use only the AC adapter approved for your Magellan CrossoverGPS. Use of another type of AC adapter can result in malfunction and/or possible fire hazard due to battery over heating.

• Use only the car charger approved for / supplied with your Magellan CrossoverGPS. Use of another type of car charger will result in malfunction and/or damage to the receiver.

• The Magellan CrossoverGPS is intended to be supplied with a LISTED Power Unit marked with "LPS", "Limited Power Source" and output rated + 5 V dc / 2.0 A".

• Use the USB cable approved for / supplied with your Magellan CrossoverGPS.

• For safety reasons, the battery in your Magellan CrossoverGPS will stop charging when the ambient temperature is less than 32°F (0°C) or more than 113°F (45°C)

IMPORTANT SAFETY WARNINGS

About the AC Adapter

• Do not use the adapter in a high moisture environment. Never touch the adapter when your hands or feet are wet.

• Allow adequate ventilation around the adapter when using it to operate the device or charging the battery. Do not cover the AC adapter with paper or other objects that will reduce cooling. Do not use the AC adapter while it is inside a carrying case.

• Connect the adapter to a proper power source. The voltage and grounding requirements are found on the product case and/or packaging.

• Do not use the adapter if the cord becomes damaged.

• Do not attempt to service the Magellan CrossoverGPS. There are no serviceable parts inside. Replace the Magellan CrossoverGPS if it is damaged or exposed to excess moisture.

About the Battery

• Do not attempt to replace the battery. Please contact Magellan Technical Support for issues related to the battery.

• Use the charger approved for your Magellan CrossoverGPS.

IMPORTANT SAFETY WARNINGS

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures:

• -Reorient or relocate the receiving antenna.

• -Increase the separation between the equipment and receiver.

• -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• -Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment.

IMPORTANT NOTE:

FCC Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance.

This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

In order to maintain compliance with FCC regulations, shielded cables must be used with this equipment. Operation with non-approved equipment or unshielded cables is likely to result in interference to radio and TV reception. The user is cautioned that changes and modifications made to the equipment without the approval of manufacturer could void the user's authority to operate this equipment.

The Magellan CrossoverGPS must be installed and operated at a distance no closer then 8 inches (20 cm) from the user.

This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.

Cet appareil numerique de la classe B respecte toutes les exigences du Reglement sur le materiel brouilleur du Canada.

IMPORTANT SAFETY WARNINGS

IC statement

Operation is subject to the following two conditions:

1. This device may not cause interference and

2. This device must accept any interference, including interference that may cause undesired operation of the device.

IMPORTANT NOTE:

IC Radiation Exposure Statement:

This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific operating instructions for satisfying RF exposure compliance.

This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

© 2006 Magellan Navigation, Inc. All rights reserved. The Magellan Logo, Magellan, Magellan CrossoverGPS, Turn it on and go, TrueView, QuickSpell, SmartDetour, and SmartVolume are trademarks of Magellan Navigation, Inc. No part of this user manual may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, for any purpose other than the purchaser’s personal use, without the prior written permission of Magellan Navigation, Inc.

631409-01 A

Magellan CrossoverGPS ........................................................................ 1

What the Magellan CrossoverGPS can do for you... ......................................................1

Magellan CrossoverGPS Reference Manual ..................................................................2

Magellan CrossoverGPS .............................................................................................2

Magellan CrossoverGPS Right Side View .....................................................................3

Magellan CrossoverGPS Left Side View .......................................................................3

Magellan CrossoverGPS Application Menu Screen ..................................... 4

The Application Menu ................................................................................................4

Accessing the Application Menu .................................................................................5

Satellite Status .........................................................................................................5

Magellan CrossoverGPS Vehicle Navigation Screens .................................. 6

Map Screen ..............................................................................................................6

Main Menu Screens ..................................................................................................7

Main Menu - Active Route ....................................................................................7

Main Menu - No Active Route ................................................................................9

Locate Screen ....................................................................................................... 10

Maneuver List Screen ..............................................................................................10

Creating Routes ................................................................................. 11

Overview ................................................................................................................11

Creating a route to a street address 1.........................................................................1

Creating a route using POIs .....................................................................................12

Creating a route to a POI by name .......................................................................12

Creating a route to a nearest POI ........................................................................13

Creating a route to a POI from an upcoming freeway exit .......................................13

Creating a route to go home ....................................................................................14

Setting the home address ..................................................................................14

Changing the home address ................................................................................14

Create a route to the home address ....................................................................15

Using the address book ...........................................................................................15

Creating a route to a previous destination ............................................................15

Adding a previous destination to your address book ...............................................15

Creating a route to a favorite destination .............................................................16

Creating a route to an address in the address book ...............................................16

Editing an address in the address book ................................................................16

Deleting an address from the address book ..........................................................17

Creating a new address ......................................................................................17

Creating a route to an intersection ......................................................................18

Using the Trip Planner ........................................................................ 19

Overview ................................................................................................................19

Creating a multiple destination trip ...........................................................................19

Activating a multiple destination trip .........................................................................19

Editing a multiple destination trip ..............................................................................20

Deleting a multiple destination trip ............................................................................21

Renaming a multiple destination trip .........................................................................21

Magellan CrossoverGPS Enhanced POIs ................................................. 22

Overview ................................................................................................................22

Accessing the Enhanced POI Menu ............................................................................22

Loading an Enhanced POI file ....................................................................................22

Displaying/Selecting Categories ................................................................................22

Setting Alarms .......................................................................................................22

Setting Alert Parameters .........................................................................................22

Creating a Route Using Enhanced POIs ......................................................................23

Saving a POI to your Address Book from Enchanced POIs ............................................23

Marine Navigation .............................................................................. 24

Loading MapSend BlueNav Charts .............................................................................24

Changing Regions ....................................................................................................24

Special Terminology .................................................................................................25

Waypoints ........................................................................................................25

Track ................................................................................................................25

Backtrack .........................................................................................................25

Goto .................................................................................................................25

Trip ..................................................................................................................25

Map Screen Overview ..............................................................................................26

Creating a Waypoint from the Map Screen ................................................................27

Creating a Waypoint from the Compass Screen .........................................................27

Creating a Waypoint from the Marine Navigation Menu ...............................................27

Setting your Port ....................................................................................................28

Going to your Port ...................................................................................................28

Creating a Goto Route from the Map Screen ..............................................................28

Creating a Goto Route from the Marine Navigation Menu ............................................29

Creating a Trip .......................................................................................................29

Activating a Trip ......................................................................................................30

Track Tools .............................................................................................................30

Bow View ...............................................................................................................31

Accessing the Bow View......................................................................................31

Outdoor Navigation ............................................................................. 32

Loading MapSend Topo Charts 3 .................................................................................2

Changing Regions ....................................................................................................32

Special Terminology .................................................................................................33

Waypoints ........................................................................................................33

Track ................................................................................................................33

Backtrack .........................................................................................................33

Goto .................................................................................................................33

Trip ..................................................................................................................33

Map Screen Overview ..............................................................................................34

Creating a Waypoint from the Map Screen ................................................................35

Creating a Waypoint from the Compass Screen .........................................................35

Creating a Waypoint from the Outdoor Navigation Menu .............................................35

Setting your Base Camp ..........................................................................................36

Going to your Base Camp .........................................................................................36

Creating a Goto Route from the Map Screen ..............................................................36

Creating a Goto Route from the Outdoor Navigation Menu ...........................................37

Creating a Trip .......................................................................................................37

Activating a Trip ......................................................................................................38

Track Tools .............................................................................................................38

Nav Road View ........................................................................................................39

Accessing the Nav Road View .............................................................................39

Setting User Options ........................................................................... 40

Overview ................................................................................................................40

POI Selection ..........................................................................................................40

Address Book Options (Waypoint Options in Marine and Outdoor) ................................40

Active Track Options (Marine and Outdoor only) ........................................................40

Map Options ...........................................................................................................41

Map Colors (Vehicle Navigation only) ........................................................................41

Route Preferences (Vehicle Navigation only) ..............................................................41

Detour Options (Vehicle Navigation only) ...................................................................42

Simulator Mode (Vehicle Navigation only) ..................................................................42

Menu Colors ...........................................................................................................42

Tone Options ..........................................................................................................43

Navigation Instruction (Vehicle Navigation only) .........................................................43

GPS Options ...........................................................................................................43

Backup and Restore (Vehicle Navigation only) ............................................................43

Export Data / Import Data (Marine and Outdoor Navigation only) .................................43

System Settings ................................................................................. 44

Overview ................................................................................................................44

Volume ..................................................................................................................44

Brightness .............................................................................................................44

Power ....................................................................................................................44

Language ...............................................................................................................44

Time Zone ..............................................................................................................44

Unit of Measure ......................................................................................................45

Page 2 ..................................................................................................................45

Product Information .................................................................................................45

Diagnosis ............................................................................................................... 45

Additional Items ......................................................................................................45

Battery Life ............................................................................................................45

Contact Us .............................................................................................................45

Magellan CrossoverGPS PC Tools Installation .......................................... 46

Installing the Software .............................................................................................46

Magellan CrossoverGPS POI Manager ................................................... 47

Latitude .................................................................................................................47

Longitude ...............................................................................................................47

Altitude ..................................................................................................................48

Opening a POI File ...................................................................................................48

Creating a New POI FIle ...........................................................................................49

Adding Individual POI’s .............................................................................................49

Importing a Data FIle ...............................................................................................51

Magellan CrossoverGPS Music Manager ................................................ 52

Magellan CrossoverGPS Photo Manager ................................................ 53

Music Player ...................................................................................... 54

Single Song Play ......................................................................................................54

Multiple Song Play ...................................................................................................55

Play ..................................................................................................................55

Create ..............................................................................................................55

Modify ..............................................................................................................55

Delete ..............................................................................................................55

Rename ............................................................................................................56

Play Mode ..............................................................................................................56

List Songs ..............................................................................................................56

Equalizer ................................................................................................................56

Help ......................................................................................................................56

Photo Viewer ..................................................................................... 57

View Single Photo ...................................................................................................57

Previous Image (left arrow) ................................................................................57

Zoom 5 ..............................................................................................................7

Slideshow ........................................................................................................58

Pan .................................................................................................................58

Rotate Image ...................................................................................................58

Next Image (right arrow) ........................................................................................58

ESC .................................................................................................................58

Manage Photos .......................................................................................................58

List View ..........................................................................................................58

Thumbnail .........................................................................................................58

Rename ............................................................................................................58

Properties ........................................................................................................58

Tools .....................................................................................................................59

Preferences ...................................................................................................... 59

Delete Files....................................................................................................... 59

About ............................................................................................................... 59

Magellan CrossoverGPS

NOTICE: If this is the first time you are using the Magellan CrossoverGPS you must follow

the instructions provided in the Getting Started document to set the reset switch in the up

position.

Thank you for your purchase of the Magellan CrossoverGPS. The Magellan CrossoverGPS

will be your perfect driving, hiking and boating companion for all your trips, from a trip to

the grocery store or a hike to the country store.

What the Magellan CrossoverGPS can do for you...

• Provide turn-by-turn driving instructions to any address you enter.

• Contains an address book that you can save addresses that you commonly need

to go to. You can even marked an address as a favorite to make it easier to find.

• Comes preloaded with a large, easily accessible points of interest (POI) database

that can be used to quickly find a restaurant, gas station, bank or other popular

destinations.

• The Magellan CrossoverGPS includes a SmartDetour™ tool that will automati-

cally ask you if you want to detour around those stubborn traffic jams.

• Includes a trip planner that provides you with the ability to create a trip with

multiple destinations.

• A trip computer that provides a record of your trip that can be saved.

• You can even route to an intersection when you are unsure of the exact address

but you are familiar with the cross streets.

• Hikers can use the Magellan CrossoverGPS to plan their hike or return to camp.

• Boaters will be able to set fishing hotspots that they can return to on their next

trip.

• Small and portable, the Magellan CrossoverGPS fits in your pocket and is ready

to go with you anywhere.

The interface of the Magellan CrossoverGPS is smart and easy-to-use. Every function is

just a tap away using the touchscreen of the Magellan CrossoverGPS.

Magellan CrossoverGPS 1

Magellan CrossoverGPS Reference Manual

It is not necessary to read this entire document to begin using the Magellan

CrossoverGPS. Most users will find that they can use the Magellan CrossoverGPS right

out of the box and just refer to this manual on those rare occasions when a little help on a

function is needed.

Magellan CrossoverGPS

Power

The Magellan CrossoverGPS uses a touchscreen display for all user inputs. The only

readily accessible button that is normally used is the power button located on the right

side of the unit. To prevent accidental turn on, you need to press and hold the power

button for a few seconds to turn the Magellan CrossoverGPS on. [Note: The reset switch

must be on (in the up position) before the Magellan CrossoverGPS can be turned on.]

All connections to the Magellan CrossoverGPS are located on the left and right sides of

the unit, protected by a rubber covering to keep out moisture. When you need to access

the connectors, simply lift the protective cover from the bottom.

Magellan CrossoverGPS 2

Magellan CrossoverGPS Right Side View

Power - Press and hold to turn the Magellan

CrossoverGPS on or off. (Note: The reset

switch MUST be in the up (1) position.)

USB Connection - (under protective cover)

Used for connecting to a personal computer

to upgrade the firmware.

Headphone Connector - (under protective

cover) Please check local laws for use of

headphones while driving.

External Power Input - (under protective

cover) Connects power to the Magellan

CrossoverGPS from a cigarette lighter

adapter or an approved AC adapter.

Magellan CrossoverGPS Left Side View

SD Card Slot - (under protective cover) Used

to accept an optional SD card. The SD card

can be used to store music and photos as well

as optional region maps.

Reset - (under protective cover) Should the

Magellan CrossoverGPS not function or during

firmware updates you may be required to reset

the unit. (The Magellan CrossoverGPS will

operate only if the reset switch is in the up

position.)

Hold Button - (under protective cover) Used to

turn off the touchscreen portion of the display

and sets the receiver into a power saving mode.

Primarily used for outdoor use where the

Magellan CrossoverGPS might be in a pocket or

backpack.

Magellan CrossoverGPS 3

Magellan CrossoverGPS Application Menu Screen

The Application Menu is the first screen displayed after you go through the initial setup

and is the starting point for all of the Magellan CrossoverGPS built-in applications.

The Application Menu

NAV - The NAV button takes you to the Vehicle Navigation application in the Magellan CrossoverGPS, This

application is used to provide you with turn-by-turn driving instructions using the built-in street maps.

Marine - The Marine button takes you to the Marine Navigation application in the Magellan CrossoverGPS,

This application provides you with the basic tools you need for boating and fishing. Additional marine mapping

information can be added by purchasing one of the Magellan BlueNav SD cards.

Outdoor - The Outdoor button takes you to the Outdoor Navigation application in the Magellan CrossoverGPS,

This application provides you with the tools you need for hiking and camping. The Magellan CrossoverGPS has

90 meter topographic maps included for the 48 contiguous United States. More detailed (30 meter) topographic

maps can be added by purchasing one of the Magellan MapSend Topographic products from

www.magellanGPS.com.

System - The System button takes you the System Settings menu providing you with access to volume,

brightness and other global settings you can select for your Magellan CrossoverGPS.

Music - The Music button opens the Music Player application where you can play MP3 files that you can store

on an optional SD card.

Photos - The Photos button opens the Photo Viewer application where you can view photos that you can store

on an optional SD card.

Magellan CrossoverGPS Application Menu 4

Accessing the Application Menu

The Application Menu can be accessed from any of the applications by

tapping the Exit icon found on the individual application’s main menu.

Sample Marine Navigation Menu showing

the Exit button highlighted.

Please note that the System Settings menu does not display an Exit button. To access

the Application Menu from System Settings, press the ‘X’ in the upper right corner.

Satellite Status

All of the navigation screens display a bar graph of the satellite status in the

upper right corner. When the bars are green, the Magellan CrossoverGPS is

getting GPS signals and is computing a position fix, defining your location.

When the bars are yellow, the Magellan CrossoverGPS is getting a satellite signal but has

not been able to compute your location yet. A red X through the icon indicates that the

Magellan CrossoverGPS is unable to get GPS satellite signals.

Tapping on the Satellite Status icon displays the

Satellite Status screen with more information

about the satellites and the signals being

received.

Magellan CrossoverGPS Application Menu 5

Magellan CrossoverGPS Vehicle Navigation Screens

Map Screen

The Map Screen is the most commonly used screen on the Magellan CrossoverGPS.

Whether you are getting directions or just driving around town, the Map screen will give

you the peace of mind of knowing where you are.

This map shows the vehicle travelling on 1st Ave. with a left turn on Cedar St. coming up in 0.2 miles. At

the posted speed limit, the turn will occur in 1 minute.

Current Street Name Name of street you are

currently on.

When tapped, displays the Locate screen

Magellan Crossover Vehicle Navigation Screens 6

Zoom out When tapped, zooms out the map

display.

Destination Icon Provides a visual indication

of your destination.

POI Icon Sample indicated is the icon

for a restaurant.

Location Icon Provides visual indication of

your current position.

Next Maneuver Indicates what type of

maneuver you will need to perform when directed.

Distance to Next Maneuver

Displays the computed distance to your next maneuver in the unit of measure chosen.

When tapped, offers you the option of setting a trip to that POI.

When tapped displays your heading as N, NE, NW, W, etc.

When tapped repeats the last verbal instruction.

Time to Next Maneuver Displays the computed time

to your next maneuver.

Tapping this button toggles the field between time to next maneuver and remaining distance of the trip

Menu Button When tapped, brings up the main

vehicle navigation menu.

Next Maneuver Street Name

Volume Tapping this button displays a

Zoom In When tapped, zooms in the map

Satellite Status Displays a bar graph

Displays the name of the street that the next maneuver will occur.

indicating satellite signal strength.

When tapped, displays the maneuver list screen.

volume control slider and a mute button.

display.

When tapped displays the Satellite Status screen.

Main Menu Screens

The Main Menu has two modes; active route and normal. When a route is active the Main

Menu provides functions that pertain to the route. With no active route, the Main Menu

provides access to functions that are used to create a route.

Main Menu - Active Route

Magellan Crossover Vehicle Navigation Screens 7

Map Button Used to access the Map Screen

Detour Button Detour gives you the option of re-

routing the trip around traffic problems ahead of you.

Cancel Route Button Cancels the route you are travelling on.

Satellite Status Displays a bar graph indicating satellite

signal strength.

Re-route Button. Provides a way to re-calculate the route

you are on. Useful when you have veered off the route and need it recalculated.

Exit POI Button This function provides you access to a

listing of common POI categories that are near upcoming freeway exits. (Only used while travelling on a freeway.)

Menu Page 2 Accesses the second page of the route

main menu.

Options Button Accesses the options menu.

When tapped displays the Satellite Status screen.

The Magellan CrossoverGPS will automatically attempt to reroute you when you are off course or you can use this button.

Menu Page 1 Accesses the first page of the route

main menu.

Application Menu Accesses the Application Menu for

additional applications and system settings.

Active Trip Button Functional only when travelling on a

multidestination trip. Provides access to tools to modify the trip you are on.

Trip Computer Accesses the trip computer feature

providing information about the trip that can be saved.

Magellan Crossover Vehicle Navigation Screens 8

Main Menu - No Active Route

Map Button Used to access the Map Screen

Street Address Button Create a trip using a street address as

the destination.

POI Button Create a trip using a point of interest

from the POI database as the destination.

Satellite Status Displays a bar graph indicating satellite

signal strength.

Home Button. Save your home address in the

Magellan CrossoverGPS and easily create a trip with your home as the destination.

Address Book Button Access addresses saved to the address

book. Can also be to re-route to a previous destination.

Intersection Button Create a route to an intersection.

Menu Page 2 Accesses the second page of the route

main menu.

Region Used to access additional map regions

stored in the Magellan CrossoverGPS.

Options Button Accesses the options menu.

When tapped displays the Satellite Status screen.

Menu Page 1 Accesses the first page of the route

main menu.

Magellan Crossover Vehicle Navigation Screens 9

Application Menu Accesses the Application Menu for

additional applications and system settings.

Enhanced POIs Used to access personal POIs created

with the Magellan PC Toolkit

Trip Planner Used to create a multidestination trip

that can be travelled or saved.

Trip Computer Accesses the trip computer feature

providing information about previous trips that can be saved.

Locate Screen (Tap the top bar on the Map screen)

The Locate screen displays information about your present position and provides access to

saving your present position in your address book.

The left side of the screen indicates your

heading, an address for your present position (if

able to calculate), the next and previous street,

as well as the latitude/longitude of your present

position.

The right side of the screen shows a compass,

the elevation (if able to compute) and the speed

you are travelling.

Use the Save button to store your current position into your address book. Tap the “X” in

the upper right corner to return to the Map screen.

Maneuver List Screen (Tap the next maneuver bar on the Map screen)

The Maneuver List screen displays all of the

maneuvers remaining to do to reach your

destination.

Tap on one of the maneuvers to exclude that

maneuver from the route. The maneuver will be

excluded and the route re-calculated.

The bottom of the screen displays from left to

right, the heading, distance to next maneuver,

time to next maneuver and distance for the entire route.

Tap the “X” in the upper right corner to return to the Map screen.

Magellan Crossover Vehicle Navigation Screens 10

Creating Routes

Overview

Creating a route involves selecting a destination and choosing how you would like the

route calculated. Once this is done, the Magellan CrossoverGPS will calculate the route

using the guidelines you provide and displays the Map screen with information guiding

you to your destination.

Creating a route to a street address

Most street addresses should be very easy to enter without any problems. If you are having problems entering an specific address, or just need additional information, go to the Magellan web site at http://www.magellangps.com/support/faqdetail.asp?faqid=355&prodid=1748 for a FAQ that discusses some of the more common issues found.

1. From the Main Menu, tap Street Address.

2. Select Search By City, Search by Zip Code or Previous City.

3. Input the information as requested depending upon your selection in step 2.

If using Search By City: Spell the city

name and select the city from the list,

spell the name of the street and select

from the available street list, and enter

the address number for the street. (If the

address you want to enter does not fall

within the acceptable range displayed,

enter the closest possible address.)

If using Search by Zip Code: Enter the

zip code for the address and select the

city from the list of available cities.

Spell the name of the street and select

Using the keyboard to enter information.

The keyboard will display only those letters that

spell an item in the database. This provides a

quick and easy tool to enter city and street

information.

Use the “123” button to enter numbers and the

“More” button to access symbols.

from the available street list, and enter

the address number for the street (it

must fall within the street number range

displayed at the top of the screen).

If using Previous City: Select a city from the list of previously used cities. Spell

the name of the street and select from the available street list, and enter the

Creating Routes 11

address number for the street (it must fall within the street number range

displayed at the top of the screen).

4. Select the method to be used to calculate the route.

NOTE: When entering street names, do not use the prefix for the street. If you are

creating a destination to W. Main, enter just Main. You will be given the opportunity to

select W. Main from the list of available streets.

Creating a route using POIs

POIs (points of interest) have been preloaded into the Magellan CrossoverGPS for

commonly used categories such as banks, restaurants, gas stations, etc. Following the

steps provided you will be able to create a route to any of these destinations.

Creating a route to a POI by name

1. From the Main Menu, tap POI.

2. Select the category of the POI and, if

displayed, the subcategory.

3. Tap Spell Name.

4. Spell out the POI name. You do not need

to spell out the complete name.

However, the more letters you enter, the

narrower the search will be. If you

entered ‘Star’ looking for Starbucks you

Scroll down the list of available categories to

select the one you are looking for. Select ‘Other’

for additional categories.

might see China Star or other POI names

that have a word beginning with ‘Star’ in the list.

5. Select Current Position, Address or City Center.

The most common will be Current Position or City Center. In this case you could

be looking for the Starbuck’s nearest to where you are or or possibly nearest to the

center of a city you are planning on going to.

If you select city center, airport or address, you will need to input the name and

select from the list of available items before continuing.

6. Select the POI from the list of POIs that you are looking for.

7. Once the POI has been selected from the available list, select the routing method

you want to use and the Magellan CrossoverGPS will begin calculating the route.

Creating Routes 12

Creating a route to a nearest POI

1. From the Main Menu, tap POI.

2. Select the category of the POI. (Select any subcategory if prompted.)

3. Tap Near.

4. Select Current Position, Address, or City Center.

The most common will be Current Position. In this case you could be looking for

the nearest gas station to your current position.

5. A list of POIs for that category nearest to

the criteria you selected in step 4 will be

presented. Tap on the POI you wish to go

to.

6. Once the POI has been selected from the

available list, select the routing method

you want to use and the Magellan

CrossoverGPS will begin calculating the

route.

This is a sample list of POIs that meet the

criteria set. The address and phone number is displayed to help you select the right POI. The red arrow indicates the approximate direction of

the POI from your current position.

Creating a route to a POI from an upcoming freeway exit

This feature functions only if you are travelling on a freeway. If you try to access it while

not on a freeway, an alert is displayed indicating that it is not available.

1. From the Main Menu, tap POI.

2. Tap POI Near Exit.

3. Select the exit you would like the POI displayed for to see all four of the categories

for that exit or select the icon of the category just to see those POIs for that

category for that exit

4. Select a POI from the list of available POIs.

5. Once the POI has been selected, select the routing method you want to use and

the Magellan CrossoverGPS will begin calculating the route.

This function is available whether you are operating on a route or just travelling without a

selected destination as long as you are on a freeway. Please note that if you are travelling

on a route, selecting this will cancel the route and create a new one. You will then need

Creating Routes 13

to redo the route, using Previous Destinations in the address book, to finish the original

route.

Creating a route to go home

Setting the home address

1. From the Main Menu, tap Home.

2. If you have not entered a home address previously, tap Yes to enter your home

address.

3. Select Search By City, Search by Zip Code or Previous City.

4. Input the information as requested depending upon your selection in step 3.

If using Search By City: Spell the city name and select the city from the list, spell

the name of the street and select from the available street list, and enter the

address number for the street (it must fall within the street number range

displayed at the top of the screen).

If using Search by Zip Code: Enter the zip code for the address and select the city

from the list of available cities. Spell the name of the street and select from the

available street list, and enter the address number for the street (it must fall within

the street number range displayed at the top of the screen).

If using Previous City: Select a city from the list of previously used cities. Spell

the name of the street and select from the available street list, and enter the

address number for the street (it must fall within the street number range

displayed at the top of the screen).

5. Tap Save to store the home address.

Changing the home address

1. From the Main Menu, tap Home.

2. Tap Change to change your home address.

3. Confirm the change by tapping Yes.

4. Select Search By City, Search by Zip Code or Previous City.

5. Input the information as requested depending upon your selection in step 4.

If using Search By City: Spell the city name and select the city from the list, spell

the name of the street and select from the available street list, and enter the

Creating Routes 14

address number for the street (it must fall within the street number range

displayed at the top of the screen).

If using Search by Zip Code: Enter the zip code for the address and select the city

from the list of available cities. Spell the name of the street and select from the

available street list, and enter the address number for the street (it must fall within

the street number range displayed at the top of the screen).

If using Previous City: Select a city from the list of previously used cities. Spell

the name of the street and select from the available street list, and enter the

address number for the street (it must fall within the street number range

displayed at the top of the screen).

6. Tap Save to store the home address.

Create a route to the home address

1. From the Main Menu, tap Home.

2. Tap Route.

3. Select the routing method you want to use and the Magellan CrossoverGPS will

begin calculating the route home.

Using the address book

Creating a route to a previous destination

1. From the Main Menu, tap Address Book.

2. Tap Previous Destinations.

3. Select the desired destination from the list of previous destinations.

4. Tap Route.

5. Select the desired route method.

Adding a previous destination to your address book

1. From the Main Menu, tap Address Book.

2. Tap Previous Destinations.

3. Select the desired destination from the list of previous destinations.

4. Tap Edit.

Creating Routes 15

5. (Optional) Edit the name of the address by tapping on top line of the address.

6. (Optional) Tap the Favorite check box to add this address to your list of favorite

addresses.

7. Tap Save.

8. Tap Route to begin routing to the destination or tap the ‘X’ multiple times to exit

out and return to the Main Menu.

Creating a route to a favorite destination

1. From the Main Menu, tap Address Book.

2. Tap Favorites.

3. Select the desired destination from the list of favorite destinations.

4. Tap Route. (You also have the option of editing or deleting this destination.)

5. Select the desired route method.

Creating a route to an address in the address book

1. From the Main Menu, tap Address Book.

2. Tap List Addresses

3. Select List All or Search Address Book.

If you do a search, you will be asked to enter the first few characters on the

address name.

4. Select the desired destination from the list of addresses in your address book.

5. Tap Route. (You also have the option of editing or deleting this address.)

6. Select the desired route method.

Editing an address in the address book

1. From the Main Menu, tap Address Book.

2. Tap List Addresses

3. Select List All or Search Address Book.

If you do a search, you will be asked to enter the first few characters on the

address name.

4. Select the desired address from the list of addresses in your address book.

Creating Routes 16

5. Tap Edit.

6. Tap on the top line to change the name

or the bottom line to change the address

information. Use the keyboard to enter

the new text.

7. Tap on the Favorite check box if you want

to add this address to your favorites list.

8. Tap Save to store the changes into your

You can change the name or add information

(phone number, etc.) by tapping on the top or

bottom line and use the keyboard to enter new

text.

address book.

9. Tap the “X” in the upper right corner a

few times to return to the Main Menu if

you are done.

Deleting an address from the address book

1. From the Main Menu, tap Address Book.

2. Tap List Addresses

3. Select List All or Search Address Book.

If you do a search, you will be asked to enter the first few characters on the

address name.

4. Select the desired address from the list of addresses in your address book.

5. Tap Delete.

6. Confirm the deletion by tapping Yes.

7. Tap the “X” in the upper right corner a few times to return to the Main Menu if you

are done.

Creating a new address

1. From the Main Menu, tap Address Book.

2. Tap Create New Entry

3. Select Select on Map, Select Address, Dining, ATM, Gas.. or Intersection.

Select on Map: The Map screen is displayed. Use your finger or stylus to pan the

crosshair cursor around the map. When the crosshair cursor is over the point on

the map you want, tap on the crosshair cursor.

Creating Routes 17

Select Address: Follow the instructions for selecting an address, either by city, zip

code or previous cities.

Dining, ATM, Gas...: Follow the instructions previously mentioned in selecting a

POI.

Intersection: Follow the instructions provided later in this chapter for

intersections. (Setting a destination as an intersection will provide you with

instructions to travel to two cross streets you have selected.)

4. The Edit Address Book screen is displayed. Edit the name or information line if

desired. If this address is to be added to your favorites list, tap on the check box

for Favorite.

5. Tap Save.

Creating a route to an intersection

1. From the Main Menu, tap Intersection.

2. Select Search By City, Search by Zip Code or Previous City.

3. Input the information as requested depending upon your selection in step 3.

If using Search By City: Spell the city name and select the city from the list, spell

the name of the street and select from the available street list, and enter the

address number for the street (it must fall within the street number range

displayed at the top of the screen).

If using Search by Zip Code: Enter the zip code for the address and select the city

from the list of available cities. Spell the name of the street and select from the

available street list, and enter the address number for the street (it must fall within

the street number range displayed at the top of the screen).

If using Previous City: Select a city from the list of previously used cities. Spell

the name of the street and select from the available street list, and enter the

address number for the street (it must fall within the street number range

displayed at the top of the screen).

4. With the city selected, enter the name of the first street. When given the list of

streets, select the desired one from the list of available streets.

5. Enter the name of the second street. When given the list of streets, select the

desired one from the list of available streets.

6. Select the desired route method.

Creating Routes 18

Using the Trip Planner

Overview

Normal routes are calculated from your present position to a single destination. It is

sometimes beneficial to have a trip that goes to multiple destinations. The Trip Planner

gives you the means to create and save multiple destination trips.

Creating a multiple destination trip

1. From the Main Menu, tap to go to page 2 of the Menu.

2. Select Trip Planner.

3. Select New.

4. Use the keyboard to enter a name for the trip. Tap OK when done.

5. Select Add from the list of available options.

6. Using the instructions found in Creating a Route, enter the first destination in the

trip.

7. With the address selected, tap Save on the Add address to Trip screen.

8. The first destination has been added to the trip. To add more destinations, tap on

the destination in the Trip List and select Add. Using the instructions found in

Creating a Route, add the second destination to the list.

9. Continue adding destinations by tapping on the last listed destination and

selecting Add until you have entered all of the destinations desired for your trip.

10. With the trip complete, tap on Save.

Activating a multiple destination trip

1. From the Main Menu, tap to go to page 2 of the Menu.

2. Select Trip Planner.

3. Select Guide Me.

4. Select the Trip to be activated from the list of saved trips.

Using the Trip Planner 19

5. A list of the individual destinations is

displayed. Tap on the first destination on

the list to activate the trip.

6. Select the routing method to compute

the trip.

You can also pick which destination to begin the

trip on, skipping over destinations prior to it, by

tapping on the first destination you want to go to. In this example, tapping on ‘Texacoe’ will go to all four destinations in the trip. If you tapped

on ‘Jaguar Seattle’ the trip would be from your

present position to ‘Jaguar Seattle’ and then to

Editing a multiple destination trip

1. From the Main Menu, tap to go to page 2 of the Menu.

the Space Needle.

2. Select Trip Planner.

3. Select Edit.

4. Select the Trip to be edited from the list of saved trips.

5. Select the destination from the list of available destinations that is to be edited.

6. Select the action required from the list of available actions. You can select Add,

Move Up, Move Down, Delete or Cancel.

Add: Using the standard methods of selecting a destination, a new destination

can be selected and added to the trip after the destination selected in step 5.

Move Up: Moves the destination selected up one level in the trip list.

Move Down: Moves the destination selected down one level in the trip list.

Delete: Removes the destination selected from the trip list.

Cancel: Makes no changes and returns to the trip list.

7. With the trip edits complete, tap on Save.

Using the Trip Planner 20

Deleting a multiple destination trip

1. From the Main Menu, tap to go to page 2 of the Menu.

2. Select Trip Planner.

3. Select Delete, Rename.

4. Select Delete.

5. Select the Trip to be deleted from the list of saved trips.

6. Confirm the deletion by tapping Yes.

Renaming a multiple destination trip

1. From the Main Menu, tap to go to page 2 of the Menu.

2. Select Trip Planner.

3. Select Delete, Rename.

4. Select Rename.

5. Select the Trip to be renamed from the list of saved trips.

6. Using the keyboard, enter a new name for the trip. Tap OK when done.

Using the Trip Planner 21

Magellan CrossoverGPS Enhanced POIs

Overview

Personal POIs can be created using the Magellan PC Tools and loaded into your Magellan

CrossoverGPS or an optional SD card. The Enhanced POI option provides a way of loading

POIs into the receiver and can then be used to create a route.

Accessing the Enhanced POI Menu

1. From the Main Menu, tap to get to the second page of the Main Menu.

2. Tap the Enhanced POI icon.

Loading an Enhanced POI file

1. Install an SD card with POIs you’ve created using the Magellan PC Tools.

2. Access the Enhanced POI menu.

3. Tap Change My POI file.

4. Tap Select a POI File.

5. Tap on the desired POI file from the list of POI files available.

Displaying/Selecting Categories

1. Load a POI file as described in ‘Loading an Enhanced POI file’.

2. Tap Display Categories.

3. Select categories you want displayed or not displayed went selecting a POI to route

to. (‘X’ will be shown.)

Setting Alarms

1. Load a POI file as described in ‘Loading an Enhanced POI file’.

2. Tap Set Alarms.

3. Tap on those categories you want to be alerted to when approaching. (See Setting

Alert Parameters.)

Setting Alert Parameters

1. Load a POI file as described in ‘Loading an Enhanced POI file’.

2. Tap Alert Parameters.

3. Tap on the category you want set the parameters for.

Magellan CrossoverGPS Enhanced POIs 22

4. Select the Detection angle by tapping on the detection angle button and entering a

new angle [default is 45 degrees]. (This is the area in front of you that will be

used to see if one of your POIs is in front of you.)

5. Set the distance for the first and last warning by tapping on their respective

buttons and enter the distance desired.

6. Tap Save when complete.

Creating a Route Using Enhanced POIs

1. With an enhance POI file loaded, access the Enhanced POI menu.

2. Tap Select category.

3. Select the category that the POI is in.

4. Select Nearest (closest to your present position) or Spell POI Name.

5. If you selected Nearest, select the destination from the Select POI list.

If you selected Spell POI Name, enter the first few letters for the desired POI and

tap OK. Select the desired POI from the list.

6. Tap Route.

7. Select routing method.

Saving a POI to your Address Book from Enchanced POIs

1. With an enhance POI file loaded, access the Enhanced POI menu.

2. Tap Select category.

3. Select the category that the POI is in.

4. Select Nearest (closest to your present position) or Spell POI Name.

5. If you selected Nearest, select the destination from the Select POI list.

If you selected Spell POI Name, enter the first few letters for the desired POI and

tap OK. Select the desired POI from the list.

6. Tap Save.

7. Edit the POI as needed by tapping on the desired field and entering the

information.

8. Add the POI to your favorites list if desired by checking the Favorite checkbox.

9. Tap Save.

10. You can now route to this POI by tapping Route or return to the main menu by

tapping Cancel.

Magellan CrossoverGPS Enhanced POIs 23

Marine Navigation

The Marine application provides a basic form of navigation for marine use. Without

loading any external maps (Magellan BlueNav) you can create a track, add waypoints,

navigate to a saved waypoint and perform a backtrack (following your track back to your

point of origin).

If you have loaded any of the Magellan BlueNav charts you will have additional marine

navigational information that can enhance your marine trip.

Marine Map without BlueNav map

loaded.

Marine Map with BlueNav map loaded.

Magellan BlueNav charts are available from Magellan at http://www.magellangps.com/

products/software.asp. The Magellan CrossoverGPS is compatible with MapSend BlueNav

Local Charts and any of the eXplorist MapSend BlueNav XL3 Charts. (Meridian MapSend

BlueNav XL3 charts will not work in the Magellan CrossoverGPS.)

Loading MapSend BlueNav Charts

1. Install the SD card with the BlueNav Chart into the SD card slot on the left side of

the Magellan CrossoverGPS.

2. If the unit is on or after you turn it on, a message will be displayed that maps have

been found on the SD card.

3. Tap Yes.

4. Select the map you want to load.

Changing Regions

1. Access the Marine Navigation Menu. (From the Map screen, tap the MENU

button.) NOTE: If you have an active trip or goto you will need to cancel it before

being able to select a region from the SD card.

2. Tap the Right Arrow in the lower right corner to access page 2 of the menu.

3. Tap Select Region.

Marine Navigation 24

4. Tap Yes.

5. Select the map you want to load.

Special Terminology

Waypoints

A waypoint is similar to an address. An address uses the street name and number, the

city, and the state to define its location, while a waypoint uses imaginary lines drawn on

the globe (latitude and longitude) to pinpoint its location. They function the same, just

how they are defined is different.

Track

Track is a record of your travels. As you move across the water the Magellan

CrossoverGPS drops and records electronic breadcrumbs that represent your movement.

When you look at the map screen you will notice a dotted line showing you a history of

how you travelled. This dotted line is your track. Track is primarily used to create a

backtrack route that returns you to your starting point.

Backtrack

As explained above, the Magellan CrossoverGPS records your track while you are moving.

You can then create a route (called backtrack) that follows this track back to where you

started.

Goto

A goto is a route that tries to go in a straight line from your present position to a waypoint

or a point you have selected on the map.

Trip

A trip is a route with multiple legs or destinations. Suppose you want to leave the port

and go to the bait boat. After getting your bait you want to travel to the fishing hotspot

you saved from your last trip. This would be a trip with two destinations (or two legs).

You would use the Magellan CrossoverGPS to create a trip that goes from your port

waypoint, to the bait boat waypoint, and finally to the hotspot waypoint.

Marine Navigation 25

Map Screen Overview

Information Bar Displays information for the

cursor position while panning around the map.

Zoom out When tapped, zooms out the map

display.

Position Icon Provides a visual indication

of your current position.

Icon points in the direction you are heading

North Indicator Arrow points towards North. When tapped displays the compass

screen.

Data field Displays navigation data

selected.

Map Scale Displays the current distance

scale for the map.

MENU button Tap to display the Marine Navigation

Create Waypoint Tap to save your current position or

Brightness When tapped displays a slider bar

Zoom In When tapped, zooms in the map

Satellite Status Displays a bar graph

indicating satellite signal strength.

Tap and hold for 3 seconds. A list of possible data types is displayed. Tap on the data type you want shown.

menu.

the cursor position as a waypoint. If cursor position, you can also create a goto route to that waypoint.

that can be used to adjust the display brightness.

display.

When tapped displays the Satellite Status screen.

Marine Navigation 26

Creating a Waypoint from the Map Screen

1. Tap

2. Tap on any of the fields to edit the name, lat/lon, altitude or information.

3. Tap Favorite to include this waypoint in your Favorites list.

4. Tap Save.

5. A waypoint is created and indicated by an ‘x’ on the map.

Creating a Waypoint from the Compass Screen

1. Tap

2. Tap

3. Tap on any of the fields to edit the name, lat/lon, altitude or information.

4. Tap Favorite to include this waypoint in your Favorites list.

5. Tap Save.

6. A waypoint is created and indicated by an ‘x’ on the map.

Creating a Waypoint from the Marine Navigation Menu

1. Tap

2. Select Create New Entry.

3. Select Select on Map to visually place the waypoint or Enter Lat/Lon to type in the

latitude and longitude for the waypoint.

4. Use the method selected to locate or enter the waypoint position.

5. Tap on any of the fields to edit the name, lat/lon, altitude or information.

6. Tap Favorite if you want to include this waypoint in your Favorites list.

7. Tap Save.

8. A waypoint is created and indicated by an ‘x’ on the map.

Marine Navigation 27

Setting your Port

1. Tap

2. Select Change Port.

Note: If this is the first time you have accessed the Port function you will be

asked to either select the port from the map or enter it’s latitude and longitude.

3. Select Select on Map to visually place your port on the map or Enter Lat/Lon to

type in the latitude and longitude for your port.

4. Use the method selected to locate or enter the port’s position.

5. Tap on any of the fields to edit the name, lat/lon, altitude or information.

6. Tap Favorite to include this waypoint in your Favorites list.

7. Tap Save.

Going to your Port

1. Tap

2. Select Goto Port.

3. The Map screen is displayed with a Goto route line displayed. Navigate along this

line to return to your port.

Creating a Goto Route from the Map Screen

1. Pan the cursor along the map to the location you want to go to.

2. Tap

3. Tap Go To.

4. The Map screen is displayed with a Goto route line displayed. Navigate along this

line to go to your destination waypoint.

Marine Navigation 28

Creating a Goto Route from the Marine Navigation Menu

1. Tap

2. Select List Waypoints or Favorites.

3. If List Waypoints is selected, select List Waypoints again or use the search feature

to find the desired waypoint.

4. Tap on the waypoint name from the list of waypoints.

5. Tap Go To.

6. The Map screen is displayed with a Goto route line displayed. Navigate along this

line to go to your destination waypoint.

Creating a Trip

1. From the Marine Navigation menu, tap

2. Select New.

3. Using the keypad, enter a unique name for the trip.

4. Tap on Add.

5. Select the first waypoint in the trip from Previous Destinations, Favorites, List

Waypoints or Create New Entry.

6. When the Waypoint Details screen is display, tap Save.

7. The list of waypoint destinations is displayed. Tap on the last waypoint in the list

for a list of options.

8. Tap Add and repeat steps 5 though 8 until the entire trip has been entered.

9. Tap Save.

10. The trip is saved and the Trip Planner menu screen is displayed.

Marine Navigation 29

Activating a Trip

1. From the Marine Navigation menu, tap

2. Select Guide Me.

3. Tap on the name of the saved trip you want to use.

4. A list of the waypoints in the trip is displayed. Tap on the first waypoint in the list

to navigate on the entire trip.

5. The map is displayed with the route highlighted by a pink line.

Track Tools

1. From the Marine Navigation menu, tap

•Tap Start or Stop to turn tracking on or off.

•Tap Reset to clear the active track.

•Tap Back Track to create a route that follows your active track.

•Tap Save As... to save your active track.

•Tap To R o ut e to save your active track as a trip that can be used again later.

•Tap View on Map to see the entire active track displayed on the map.

•Tap Color to change the color of the track line displayed on the map.

• Show on Map sets the track to be visible on the map while navigating.

Marine Navigation 30

Bow View

With an active trip or goto you can use the Bow View to help navigate to your destination.

The red arrow indicates the direction you need to steer to get to the proper heading to go to your destination.

The three data fields at the bottom of the display are customizable. Tap and hold on the data field for 3 seconds. A popup menu will appear with a list of available data types.

Accessing the Bow View

1. From the Marine Navigation menu, tap

Tap on the “X” in the lower right corner to exit Bow View.

Marine Navigation 31

Outdoor Navigation

The Outdoor application provides a basic form of navigation for hiking and camping.

Without loading any external maps (Magellan MapSend Topo) you can create a track, add

waypoints, navigate to a saved waypoint and perform a backtrack (following your track

back to your point of origin). The Magellan CrossoverGPS has 90 meter topographic maps

installed for the continental United States excluding Alaska. With MapSend Topo maps,

you can install 30 meter topographic maps.

Outdoor Map without a MapSend Topo

map loaded.

Outdoor Map a MapSend Topo map

loaded.

Magellan MapSend Topo maps are available from Magellan at

http://www.magellangps.com/products/software.asp. The Magellan CrossoverGPS is

compatible with MapSend Topo maps that are preloaded on SD cards. (MapSend Topo

products sold on a CD-ROM or DVD are NOT compatible with the Magellan CrossoverGPS.)

Loading MapSend Topo Charts

1. Install the SD card with the MapSend Topo Chart into the SD card slot on the left

side of the Magellan CrossoverGPS.

2. If the unit is on or after you turn it on, a message will be displayed that maps have

been found on the SD card.

3. Tap Yes.

4. Select the map you want to load.

Changing Regions

1. Access the Outdoor Navigation Menu. (From the Map screen, tap the MENU

button.) NOTE: If you have an active trip or goto you will need to cancel it before

being able to select a region from the SD card.

2. Tap the Right Arrow in the lower right corner to access page 2 of the menu.

Outdoor Navigation 32

3. Tap Select Region.

4. Tap Yes.

5. Select the map you want to load.

Special Terminology

Waypoints

A waypoint is similar to an address. An address uses the street name and number, the

city, and the state to define its location, while a waypoint uses imaginary lines drawn on

the globe (latitude and longitude) to pinpoint its location. They function the same, just

how they are defined is different.

Track

Track is a record of your travels. As you move across the land the Magellan CrossoverGPS

drops and records electronic breadcrumbs that represent your movement. When you look

at the map screen you will notice a dotted line showing you a history of how you travelled.

This dotted line is your track. Track is primarily used to create a backtrack route that

returns you to your starting point.

Backtrack

As explained above, the Magellan CrossoverGPS records your track while you are moving.

You can then create a route (called backtrack) that follows this track back to where you

started.

Goto

A goto is a route that tries to go in a straight line from your present position to a waypoint

or a point you have selected on the map.

Trip

A trip is a route with multiple legs or destinations. Suppose you want to leave your

basecamp and go to the bridge. From the bridge, you want to hike to a scenic spot you

found last trip. This would be a trip with two destinations (or two legs). You would use

the Magellan CrossoverGPS to create a trip that goes from your basecamp waypoint, to the

bridge waypoint, and finally to the scenic waypoint.

Outdoor Navigation 33

Map Screen Overview

Information Bar Displays information for the

cursor position while panning around the map.

Zoom out When tapped, zooms out the map

display.

Position Icon Provides a visual indication

of your current position.

Icon points in the direction you are heading

North Indicator Arrow points towards North. When tapped displays the compass

screen.

Data field Displays navigation data

selected.

Map Scale Displays the current distance

scale for the map.

MENU button Tap to display the Outdoor

Create Waypoint Tap to save your current position or

Brightness When tapped displays a slider bar

Zoom In When tapped, zooms in the map

Satellite Status Displays a bar graph

indicating satellite signal strength.

Tap and hold for 3 seconds. A list of possible data types is displayed. Tap on the data type you want shown.

Navigation menu.

the cursor position as a waypoint. If cursor position, you can also create a goto route to that waypoint.

that can be used to adjust the display brightness.

display.

When tapped displays the Satellite Status screen.

Outdoor Navigation 34

Creating a Waypoint from the Map Screen

1. Tap

2. Tap on any of the fields to edit the name, lat/lon, altitude or information.

3. Tap Favorite to include this waypoint in your Favorites list.

4. Tap Save.

5. A waypoint is created and indicated by an ‘x’ on the map.

Creating a Waypoint from the Compass Screen

1. Tap

2. Tap

3. Tap on any of the fields to edit the name, lat/lon, altitude or information.

4. Tap Favorite to include this waypoint in your Favorites list.

5. Tap Save.

6. A waypoint is created and indicated by an ‘x’ on the map.

Creating a Waypoint from the Outdoor Navigation Menu

1. Tap

2. Select Create New Entry.

3. Select Select on Map to visually place the waypoint or Enter Lat/Lon to type in the

latitude and longitude for the waypoint.

4. Use the method selected to locate or enter the waypoint position.

5. Tap on any of the fields to edit the name, lat/lon, altitude or information.

6. Tap Favorite to include this waypoint in your Favorites list.

7. Tap Save.

8. A waypoint is created and indicated by an ‘x’ on the map.

Outdoor Navigation 35

Setting your Base Camp

1. Tap

2. Select Change Basecamp.

Note: If this is the first time you have accessed the Base Camp function you will

be asked to either select the port from the map or enter it’s latitude and longitude.

3. Select Select on Map to visually place your port on the map or Enter Lat/Lon to

type in the latitude and longitude for your port.

4. Use the method selected to locate or enter the base camp’s position.

5. Tap on any of the fields to edit the name, lat/lon, altitude or information.

6. Tap Favorite to include this waypoint in your Favorites list.

7. Tap Save.

Going to your Base Camp

1. Tap

2. Select Goto Basecamp.

3. The Map screen is displayed with a Goto route line displayed. Navigate along this

line to return to your basecamp.

Creating a Goto Route from the Map Screen

1. Pan the cursor along the map to the location you want to go to.

2. Tap

3. Tap Go To.

4. The Map screen is displayed with a Goto route line displayed. Navigate along this

line to go to your destination waypoint.

Outdoor Navigation 36

Creating a Goto Route from the Outdoor Navigation Menu

1. Tap

2. Select List Waypoints or Favorites.

3. If List Waypoints is selected, select List Waypoints again or use the search feature

to find the desired waypoint.

4. Tap on the waypoint name from the list of waypoints.

5. Tap Go To.

6. The Map screen is displayed with a Goto route line displayed. Navigate along this

line to go to your destination waypoint.

Creating a Trip

1. From the Outdoor Navigation menu, tap

2. Select New.

3. Using the keypad, enter a unique name for the trip.

4. Tap on Add.

5. Select the first waypoint in the trip from Previous Destinations, Favorites, List

Waypoints or Create New Entry.

6. When the Waypoint Details screen is display, tap Save.

7. The list of waypoint destinations is displayed. Tap on the last waypoint in the list

for a list of options.

8. Tap Add and repeat steps 5 though 8 until the entire trip has been entered.

9. Tap Save.

10. The trip is saved and the Trip Planner menu screen is displayed.

Outdoor Navigation 37

Activating a Trip

1. From the Outdoor Navigation menu, tap

2. Select Guide Me.

3. Tap on the name of the saved trip you want to use.

4. A list of the waypoints in the trip is displayed. Tap on the first waypoint in the list

to navigate on the entire trip.

5. The map is displayed with the route highlighted by a pink line.

Track Tools

1. From the Outdoor Navigation menu, tap

•Tap Start or Stop to turn tracking on or off.

•Tap Reset to clear the active track.

•Tap Back Track to create a route that follows your active track.

•Tap Save As... to save your active track.

•Tap To R o ut e to save your active track as a trip that can be used again later.

•Tap View on Map to see the entire active track displayed on the map.

•Tap Color to change the color of the track line displayed on the map.

• Show on Map sets the track to be visible on the map while navigating.

Outdoor Navigation 38

Nav Road View

With an active trip or goto you can use the Nav Road View to help navigate to your

destination.

Follow the road to go to your destination.

The three data fields at the bottom of the display are customizable. Tap and hold on the data field for 3 seconds. A popup menu will appear with a list of available data types.

Accessing the Nav Road View

1. From the Outdoor Navigation menu, tap

Tap on the “X” in the lower right corner to exit Nav Road View.

Outdoor Navigation 39

Setting User Options

Overview

Portions of the Magellan CrossoverGPS are customizable to your needs. To access the

User Options menu, select Options from page 2 of the Main Menu and select the option

you want to change.

POI Selection

In POI Selection you can select which POI icons will be displayed on the Map screen

Check the POI category name to select or deselect it. POI’s with an “X” will be

displayed on the screen. Use ‘Mark All’ or ‘Clear All’ for global selections.

NOTE - Marine and Outdoor use: When you have added maps using Magellan

BlueNav or Magellan MapSend Topo the POI category list will be created from the

categories supplied on the optional maps. With no accessory map installed, the

POI list will be empty for marine and contain the vehicle navigation POI list for

outdoor.

Address Book Options (Waypoint Options in Marine and Outdoor)

This option provides a way to quickly clear addresses from your address book.

Clear Addresses clears all of the addresses in your address book.

Clear Favorites clears the addresses marked as favorites from your address book.

Clear Previous clears the previous destinations list.

Active Track Options (Marine and Outdoor only)

Track is a recording of your journey on land or water. Active Track Options sets some of

the parameters for the active track.

Continue Track on Application Start: You can set the track to continue from the

last track point set automatically (Yes), have a new track started and the old track

deleted every time you start (Reset), or set it to ask you if you want to continue the

track every time you start the outdoor/marine application (Ask).

When track is full: When the track memory is full you can set the Magellan

CrossoverGPS to keep adding new track points to the end of the track and delete

Setting User Options 40

track points from the start of the track (Cycle), clear out the track log and start a

new one (Reset), or pop up an alert asking you what you want to do at the time the

track log is full (Ask).

Track filtering preset: [Advanced users] Sets the interval that track points are

collected during the trip. If you are unsure, leave this option as ‘Detailed smart

algorithm’.

Map Options

Provides access to customizing how the Map screen functions.

3D / 2D: Changes the display of the map to be a 3D (forward looking display) or

2D (overhead display). [Vehicle Navigation only]

Heading Up / North Up: Sets the top of the map display to be either the direction

you are heading or North. Note that ‘North Up’ is only available when the map is

set to 2D mode.

TrueView: As you approach a maneuver, the map screen changes to a TrueView

display and then back to the map display just prior to the maneuver. This is the

default setting. You can turn this feature off by unchecking ‘Auto TrueView’.

TrueView can also be selected to view Split TrueView (default where half the

display is the map and the other half an arrow indicating the maneuver

requirements) or a Single TrueView (only the arrow is displayed). [Vehicle

Navigation only]

Map Colors (Vehicle Navigation only)

You can select from nine different combination of colors for the map display.

Auto Night Mode: Changes the colors of the display to the one chosen for ‘Night

Screen’ during evening hours. With Auto Night Mode off, only the Day Screen

colors are used.

Day Screen / Night Screen: Tap on these buttons to go to the map color selection

screen. Select the desired color from the list on the left.

Route Preferences (Vehicle Navigation only)

You can turn automatic re-routing on or off. With automatic re-routing on, the receiver

will automatically recalculate the route whenever you leave the planned route.

Automatic Re-Route: When checked, automatic re-routing is on.

Setting User Options 41

Detour Options (Vehicle Navigation only)

The Magellan CrossoverGPS detects when you are on a route and you are moving slowly or

not moving at all on a freeway. It then provides you with the option of detouring around

the problem area. It can alert you visually on the map by displaying the detour icon or you

can set it to not alert you and you’ll select detour from the main menu.

3 mi / 5 mi / 10 mi or Custom: This setting determines the distance that detour

will take you around. (If you are on stopped on a freeway and select to detour, the

Magellan CrossoverGPS will calculate the detour and try to get you back on the

original route in the distance specified.)

Enable automatic detour: This defines if the detour icon will be shown on the map

when the Magellan CrossoverGPS determines that a detour should be used.

Alert After: This sets the duration that you are stopped or moving slowly on the

freeway before a detour icon is displayed.

Example: Settings of ‘3 mi’, ’Enable automatic detour’ on, and ‘Alert After’ set to

1 min. You are being routed on a freeway and have been moving at 10 mph due to

a traffic jam ahead. After 1 minute of moving slowly, the detour icon will be

displayed on the left side of the map indicating that a detour should be used. If

you want to activate the detour, press MENU and select ‘Detour’. Press ‘Route’

and the Magellan CrossoverGPS will calculate a new route, detouring around the

next 3 miles.

Simulator Mode (Vehicle Navigation only)

This option provides a way to set the Magellan CrossoverGPS into simulation mode. In

simulation mode you can create a route and observe the Magellan CrossoverGPS in action

as it simulates travelling along the route.

Simulation: Check “Propose simulator mode when calculating a route.” to turn the

simulator on. When on, you will be asked each time you create a route if you want

it to be simulated.

Menu Colors

The Magellan CrossoverGPS has four color schemes built in; Default, Pastel, Forest and

Desert.

Menu Colors: Tap on the desired color theme.

Setting User Options 42

Tone Options

The Magellan CrossoverGPS uses an alert tone to indicate that a maneuver is upcoming or

been completed. You can select the type of alert tone to be used.

Tone Options: Tap on Bell, Chime or Beep.

Navigation Instruction (Vehicle Navigation only)

You can select what will be announced while routing. You may turn ‘Announce street

name” on (checked) or off and you may turn “Announce exit ramp name” on (checked) or

off.

GPS Options

You can check the status of the GPS signals or set a starting location for the GPS receiver.

GPS Status: Displays high-level information about the satellite and the signal it is

transmitting.

Set GPS Position: This is only useful if you have travelled a great distance with the

Magellan CrossoverGPS off and it is having problems getting GPS signals. You will

be prompted to enter an address for your present location that the Magellan

CrossoverGPS can base its satellite search from. (It is extremely unlikely that you

will ever need to use this option unless instructed to do so by a service technician

if you are experiencing difficulties.)

Backup and Restore (Vehicle Navigation only)

Backup and Restore will save (backup) all of your address, trips, and option settings to an

SD card installed in the Magellan CrossoverGPS. You can then upload (restore) this

information in the future should you lose the information or accidentally clear the

addresses.

Export Data / Import Data (Marine and Outdoor Navigation only)

Export and Import Data brings up a menu that enables you to save or load waypoints, trips

or tracks to an optional SD card. You can also backup and restore all of you data to an

optional SD card.

Setting User Options 43

System Settings

Overview

System settings provides access to some global settings for the Magellan CrossoverGPS.

The following is a listing of the accessible settings. From the Main Menu screen, tap on

the Application Menu icon and then the System icon.

Volume

A slider bar is displayed that can be tapped on to raise or lower the volume of

alerts. Tapping on the speaker icon (above the slider) will mute or unmute the

speaker.

Brightness

The top of the display is a slider bar that can be tapped to increase or decrease the

brightness of the display.

‘On-battery dimming (80%)’ should be checked if you want the display dimmed

while operating on the internal battery only. This will lengthen the usable battery

life between battery charging.

Power

This setting tells the Magellan CrossoverGPS how long it should stay on while there

is no noticeable activity. (Noticeable activity would include button presses and the

location of the Magellan CrossoverGPS not changing.)

Language

Changes the language used for voice alerts as well as menu items in to one of five

languages. Please note that voice alerts are available only in English and French.

Time Zone

Use the ‘+’ and ‘-’ buttons to change the time zone to your local area. Check the

Daylight Savings box if you want the time automatically changed for daylight

savings.

Setting User Options 44

Unit of Measure

You can set distances to be displayed as Miles/Feet or Kilometers/Meters.

Page 2 (tap )

Product Information

Provides detailed information about the software and firmware installed in the

Magellan CrossoverGPS. Also shown is the unique serial number for the receiver.

Diagnosis

Provides a way to diagnose the audio, touchscreen or video portions of the

Magellan CrossoverGPS.

Additional Items

Battery Life

A battery charge indicator is shown at the bottom of the display. When the

Magellan CrossoverGPS is charging, the green bars will sequence from left to right.

Remove the power cable and the green lights will display the approximate battery

charge.

Tap the question mark in the bottom left corner and then “Contact Us” to display a

screen with telephone and e-mail information for contacting Magellan about your

Magellan CrossoverGPS.

Setting User Options 45

Magellan CrossoverGPS PC Tools Installation

The Magellan CrossoverGPS Tools application enables you to create custom POI’s and

load them onto the SD card in your Magellan CrossoverGPS.

Installing the Software

1. Insert the Magellan CrossoverGPS Tools PC Application CD into your PC’s CD

drive.

2. The setup application will begin automatically. If it does not, browse your

computer’s CD drive and double-click on the setup.exe file.

3. Select a default language for the Application.

4. The Welcome screen will appear to begin the

installation process.

5. Choose a destination for the application.

Select Next to use the default location, or

select Browse to choose a custom destination.

6. Next, choose a Program Folder to place the

application icons.

7. The Magellan CrossoverGPS Tools software

will be installed. After it has finished

installing, a dialog box pertaining to

Microsoft DIgital Signatures may appear,

select

8. When it has finished, to can have the

installer launch the application

automatically, or deselect to exit without

launching the application. Select Finish.

Magellan RoadMate PC Tools 46

Magellan CrossoverGPS POI Manager

The Magellan CrossoverGPS POI Manager enables you to transfer custom points of

interest files from your computer to your Magellan CrossoverGPS.

Before we add any custom POI’s to the Magellan CrossoverGPS, you should understand

how the POI Manager plots POIs.

Latitude

Latitude can be expressed by dividing Earth into

horizontal segments totalling 180 degrees.

Starting at the Equator, or zero degrees Latitude,

lines (or Parallels) are drawn in 10-degree

increments 90 degrees to the north and 90

degrees to the south. If your location is below the

Equator, you are at a South Latitude.

0°

10°

20°

30°

40°

50°

60°

70°

80°

90° (North Pole)

North Latitude

Equator

South Latitude

90° (South Pole)

80°

70°

60°

50°

40°

30°

20°

10° 0°

Longitude

Conversely, longitude lines can be expressed by

dividing Earth into vertical segments totalling

360 degrees. Starting at the Prime Meridian

(which is The Royal Observatory in Greenwich,

England), or zero degrees Longitude, lines are

drawn in 10-degree increments 180 degrees to

the West and 180 degrees to the East. If your

90°

West Longitude

70° 50° 30° 10° 10° 30° 50° 70° 90°

80° 60° 40° 20° 0° 20° 40° 60° 80°

East Longitude

location is on the western hemisphere, you are at

a West Longitude.

Additionally, to narrow down your location

further, each 10-degree segment is divided into 60 smaller segments called minutes and,

still further, each minute is divided into 60 segments called seconds.

To express this in coordinates, the city of Los Angeles is located at 34° (degrees) 03’

(minutes) and 08 (seconds) North of the Equator, and 118° (degrees) 14’ (minutes) and

42 (seconds) West of the Prime Meridian.

Magellan POI Manager 47

Altitude

Each location can also have an

Altitude. Altitude is expressed by how

100’ Above

far the point is above or below the

level of the ocean, or Sea Level. For

example, Los Angeles, California is

about 300 feet above sea level. Death

Valley, California is about 270 feet

below sea level.

80’ Above

60’ Above

40’ Above

20’ Above

Sea Level 0’

20’ Below

40’ Below

60’ Below

80’ Below

100’ Below

Turn on your Magellan CrossoverGPS by pressing and holding the Power button for

approximately 2-3 seconds. When the Warning screen appears, insert the small end of

the USB cable into the USB port on your Magellan CrossoverGPS, and the large end into

an available USB port on your computer.

Launch the Magellan CrossoverGPS PC Tools application and from the Magellan PC Tools

screen, click on POI.

The left side of the window shows the contents of your computer and the right side of the

window shows the contents of the Magellan CrossoverGPS.

Opening a POI File

When you start the POI Manager the contents of your “My POI’s” folder will be displayed.

This is the default location for storing custom POI files.

Magellan POI Manager 48

Locate the POI files you wish to load. When you have selected a file, the Copy To Unit

arrow will turn green. Click on the arrow to copy the file to your Magellan CrossoverGPS.

When you have finished copying files, remove the USB cable from the Magellan

CrossoverGPS.

Creating a New POI FIle

There are two ways to create a POI file. You can either add POI’s individually, or you can

import a character delimited file containing the information need to plot the POI’s. To

plot a POI, each item must have a name, longitude, and latitude. Longitude and latitude

must be in decimal format.

Adding Individual POI’s

Click on the New POI File Button to launch the POI Editor.

Click on the Add button .

Magellan POI Manager 49

Enter the Name, the Latitude, and the Longitude. The Altitude and Description fields are

optional.

Select the Category field and select New. A dialog box will appear to create a new POI

category. Enter the Name and assign an Image (icon) for the POI. The Description field is

optional.

The Alert feature is an audible alarm that lets you know when you are within a certain

distance from the POI. You can set an initial reminder (Distance 1), a secondary reminder

(Distance 2).

Distance 1 Distance 2

Select your preferred unit or measure (Meters or Feet).

The Detection angle sets the range of alert in degrees from the POI.

Select Activate alert for this category to enable the alert settings.

When you have finished, select OK.

Magellan POI Manager 50

Importing a Data FIle

The POI Manager software supports ASCII file format (.ASC,.CSV,.TXT); GPS Exchange

file format (.GPS,.XML); Magellan Waypoint file format (.WPT,.RTE); and Garmin PCX5

Waypoint file format (.WPT,.RTE).

Click on the Open button .

Select the file you wish to import and click Open.

Start by choosing which line in the data file to start importing data. If your data file has a

header row, this row will generate an error so you should start at line two or below.

Next, choose how the data is separated and click on Next.

You now need to define the data columns. Click on the pull down menu and assign a field

name to the appropriate column. Click on Finish.

Click on The Save POI file button. Assign a name to your file and click on Save.

Close the POI File Editor. Select the POI file you just created and click on the transfer

button (right arrow) to upload the file to your Magellan CrossoverGPS.

Magellan POI Manager 51

Magellan CrossoverGPS Music Manager

The Magellan CrossoverGPS Music Manager enables you to transfer song files in MP3 or

WMA format from your computer to an optional SD memory card installed in your

Magellan CrossoverGPS. The amount of music you can load depends on the size of the

card.

Insert the memory card into the memory card slot. Turn on your Magellan CrossoverGPS

by pressing and holding the Power button for approximately 2-3 seconds if in sleep mode.

(Ten seconds if not in sleep mode.) When the Warning screen appears, insert the small

end of the USB cable into the USB port on your Magellan CrossoverGPS and the large end

into an available USB port on your computer.

Launch the Magellan CrossoverGPS

Tools application. From the Magellan

CrossoverGPS Tools screen, click on

Music.

The left side of the window shows the

contents of your computer and the right

side of the window shows the contents

of the memory card installed in your

Magellan CrossoverGPS.

Locate the song files you wish to load.

When you have selected a file, the

Transf e r arrow will turn green. Click on

Transfer arrow to copy the file(s) to

the

the memory card.

In the same way, if you have loaded

song files onto a memory card from

another computer, you can copy the

files from the memory card to your

computer.

When you have finished copying files,

remove the USB cable from the Magellan CrossoverGPS.

Magellan CrossoverGPS Music Manager 52

Magellan CrossoverGPS Photo Manager

The Magellan CrossoverGPS Photo Manager enables you to transfer image files in multiple

formats from your computer to an optional memory card installed in your Magellan

CrossoverGPS. The number of images you can load depends on the size of the card.

Insert the memory card into the memory card slot. Turn on your Magellan CrossoverGPS

by pressing and holding the Power button for approximately 2-3 seconds (Ten seconds if

the Magellan CrossoverGPS is not in sleep mode.) When the Warning screen appears,

insert the small end of the USB cable into the USB port on your Magellan CrossoverGPS,

and the large end into an available USB port on your computer.

Launch the Magellan CrossoverGPS Tools

application. From the Magellan

CrossoverGPS Tools screen, click on Photo.

The left side of the window shows the

contents of your computer and the right side

of the window shows the contents of the

memory card installed in your Magellan

CrossoverGPS.

Locate the image files you wish to load.

When you have selected a file, the Transfer

arrow will turn green. Click on the Transfer

arrow to copy the file(s) to the memory

card.In the same way, if you have loaded

image files onto a memory card from another

computer, you can copy the files from the

card to your computer.

When you have finished copying files,

remove the USB cable from the Magellan

CrossoverGPS.

Magellan CrossoverGPS Photo Manager 53

Music Player

The Magellan CrossoverGPS Music Player enables you to play music files in MP3, or WMA

format, stored on an optional memory card installed in your Magellan CrossoverGPS. If

you have not already done so, you must install the Magellan CrossoverGPS Tools

application and transfer files onto the card using the Magellan CrossoverGPS Music

Manager.

Note: You must use the Magellan CrossoverGPS PC Tools to load music files onto the SD

Card.

Press the MENU key on the Magellan CrossoverGPS and select the Music Player. .

The Music Player control pad will appear.

Single Song Play

Select Browse Music

Use the Navigation key or the Down arrow to select the song file you

wish to play and press

The song will begin playing automatically.

At the top of the screen is displayed the name of the song, the artist (if available), the selected play mode, the elapsed time, and the song duration.

Press the the

Press the pressing the

Play/Pause button to suspend song play. To resume song play, press

Play/Pause button again.

Stop button to stop song play. Once a song has been stopped,

Play/Pause button will start the song from the beginning.

OK.

Magellan CrossoverGPS Music Player 54

Multiple Song Play

Multiple song play enables you to create a “playlist”. A playlist consists of one or more songs in a group that can be played continuously.

Select

The Playlist menu will appear. To exit from the playlist menu, select

Playlist

ESC.

Play

To hear a previously created playlist, select Play.

Use the Up or Down arrow to select the desired playlist. Select

The songs will begin playing automatically in order.

OK.

Create

To make a new playlist, select Create.

Use the backspace key (<-) to erase the default name; and the keypad to enter a new name for your playlist. When you have finished, select OK.

The next screen to appear shows the song files stored on the memory card on the left side, and the playlist on the right side.

Use the arrow buttons on the left side of the screen to highlight the Music folder and then, select

List Files.

Use the arrow buttons to highlight the song files you wish to add to the playlist. Select arrow) to add the highlighted song to the playlist.

Continue adding files to the playlist. When you have finished, select

OK.

Add to Playlist (right

Modify

Modify enables you to add or remove songs from the selected playlist. Select Modify.

To remove a song from the playlist, use the arrow keys on the right side of the screen to highlight the desired song and then select

Use the arrow buttons on the left side of the screen to highlight the song files you wish to add to the playlist. Select

Continue adding files to the playlist. When you have finished, select

Add to Playlist (right arrow) to add the highlighted song to the playlist.

Remove From Playlist (left arrow).

OK.

Delete

To remove a playlist, select Delete.

Select the playlist you wish to delete and select

A dialog box will appear asking to confirm your selection. Select

OK.

Yes to delete the playlist.

Magellan CrossoverGPS Music Player 55

Rename

If you want to change the name of a playlist, select Rename.

Select the playlist you wish to rename and then, select

Use the backspace key (<-) to erase the name; and the keypad to enter a new name for your playlist. When you have finished, select

OK.

Play Mode

While in single song play, select Play Mode for song play options.

Repeat All - Repeats all the songs in the current playlist starting at the beginning of the order. This function works only if there are two or more songs in the playlist.

Repeat - repeats the song that is currently playing.

Preview - Plays the first five seconds of each song in the current playlist.

Normal - Plays all songs in the current playlist in order.

Random - Plays the songs in the current playlist in random order.

List Songs

Select List Songs to view the current playlist.

Equalizer

The Equalizer provides advanced sound options so you can customize the quality of the playback. The equalizer will only be available for MP3 format sound files. Select an equalizer preset from the following preconfigured options: Default (flat), Jazz, Classical, Rock, Techno, Dance Hall, Live, Full Bass, Full Treble, and Full Bass & Treble. You are not able to however, manually set the equalizer.

Select the

Select the equalizer preset by pressing the button at the top of the screen .

When you are satisfied with your selection, select

Equalizer

OK. To exit without setting the equalizer, select ESC.

Help

Select Help for descriptions of the Music Player buttons.

Magellan CrossoverGPS Music Player 56

Photo Viewer

The Magellan CrossoverGPS Photo Viewer enables you to view image files in JPG and BMP

format, stored on an optional memory card installed in your Magellan CrossoverGPS. If

you have not already done so, you must install the Magellan CrossoverGPS Tools

application and transfer files onto the card using the Magellan CrossoverGPS Photo

Manager.

Press the MENU key on the Magellan CrossoverGPS. Select the Photo Viewer .

The Photo Viewer screen will appear. The Photo viewer will show

the contents of the SD or MMC card installed in your Magellan

CrossoverGPS.

View Single Photo

The next screen to appear shows the file structure of the memory card. Select List Files .

Use the Navigation key or the Down arrow to highlight the photo you wish to

view and select While viewing the image, double clicking on the image (that is tapping twice on the screen) will show the image in full screen. You can then cycle through the images by pressing left or right on the Navigation key.

View.

Previous Image (left arrow)

Press the right arrow button to view the previous image in the folder. This button is grayed out (not functional) when viewing the first image in the folder.

Zoom

Press the Zoom button to reduce or enlarge the current photo. The top of the zoom menu shows the current zoom level. Select another zoom level from the list of presets. Select Best Fit to adjust the zoom to fit within the display boundaries; select Actual Size to display the image at 100%; select 25% to 150% to reduce or enlarge the image to the preset level.

Magellan CrossoverGPS Photo Viewer 57

Slideshow

Press the Slideshow button to cycle through all the photos in the Pictures folder

automatically.

Pan

If you enlarge an image beyond the screen boundaries, press the Pan button to enable

image scrolling. While enabled, you can drag the image in any direction to view other

areas of the image. Press the Pan button again to disable Pan mode.

Rotate Image

Press the Rotate Image button to rotate the image 90° counterclockwise, 90° clockwise,

or 180°.

Next Image (right arrow)

Press the right arrow button to view the next image in the folder. This button is grayed out

(not functional) when viewing the last image in the folder.

ESC

Press ESC to return to the folder list.

Manage Photos

List View

Press List view to show the files in a hierarchal list view.

Thumbnail

Press Thumbnail to show the files as thumbnails.

Rename

To change the name of the selected file or folder, press Rename. Use the backspace key (<-) to erase the name; and the keypad to enter a new name for your file. When you have finished, select OK.

Properties

To view information on the selected file or folder, press Properties. A thumbnail of the

image will be displayed along with the width and height in pixels, the size, and the format

Magellan CrossoverGPS Photo Viewer 58

(image type). When viewing the properties for folders, width, height, and format are not

shown. Size shown is the combined size of all images in the selected folder.

When you are finished viewing the properties, select OK.

Tools

Preferences

General - The General preferences, you can set the default file

view to either thumbnail or file list view.

Slideshow - The slideshow preferences enable you to set the view

properties, the sequence of photos, the transition between

photos, and the duration between photos.

Background - The background preferences enable you to set the color of the background

behind the photo being viewed.

Delete Files

Use the arrow keys to select the file or folder you wish to delete. Press the Delete button

(trash can).

A dialog box will appear asking to confirm your selection. Select Yes to delete the file.

About

This option will display the current version of the Photo Viewer software.

Magellan CrossoverGPS Photo Viewer 59

Contact Information

If you need support for your Magellan CrossoverGPS and you wish to contact Magellan, please use the following information to direct your questions/comments to the proper person.

Technical Support

If you need technical assistance or “how-to” help, or if you have a technical question about the functionality of your Magellan product, please contact us on the Internet at

Our Technical Support phone representatives are available Monday through Friday, 6:00 a.m. to 5:00 p.m. PST/PDT. After hours, you may leave a detailed voice mail message that will be returned within the next business day.

www.magellanGPS.com or reach us by fax or by phone.

Telephone: (

You may also reach Technical Support by Fax:

http://www.magellanGPS.com/support/.

800) 707-9971 or (909) 394-5000 (outside the United States)

(909) 494-7777 [Attn: Tech. Support]; or web URL:

Warranty Service

To obtain warranty service on your Magellan CrossoverGPS, you must contact us for a return authorization (RA) before you ship the product. Packages arriving at our dock without an RA will be refused.

To obtain an RA, simply contact our Technical Support group at: Telephone: ( the United States); Fax:

http://www.magellanGPS.com/support/.

(909) 394-7050 [Attn: Tech. Support]; or web URL:

800) 707-9971 or (909) 394-5000 (outside

Customer Service

If you need to order accessories or obtain unlock codes, you can call our Customer Service Department Monday through Friday, 6:00 a.m. to 5:00 p.m. PST/PDT, or visit our Web site at

Telephone: (

866) 339-0488 or (909) 394-5000 (outside the United States).

www.magellanGPS.com.

Registration

Please make sure to register your Magellan CrossoverGPS at www.magellanGPS.com. By registering, you will be informed of the latest product updates.

Magellan CrossoverGPS 2500T User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
