Information for Your Safety
Please read all the following information, which contains important instructions for the safety, the use and the maintenance of the appliance.
This appliance complies with the following EC Directives: -73/23/EEC, 93/68/EEC-Low Voltage Directive-89/336EEC -EMC Directive.
Never allow children to use the appliance unsupervised.
Do not allow it to use as a toy, injury could result.
Do not continue to the cleaner if any appears to be faulty, missing or damaged. In these cases, contact an approved LG Electronics Service Agent.
Repairs, when necessary, must be performed at an approved LG Electronics Service Agent.
Only use parts produced or recommended by LG doing otherwise could invalidate your guarantee.
Do not use without the dust tank or air filter.
Do not use the vacuum cleaner If the power cord is damaged or faulty.
If the power cord is damaged, it must be replaced by an approved LG Electronics Service Agent to avoid a hazard.
Do not unplug by pulling on cord.
Do not pull on the supply cord, run over it, pull it around sharp edhes or near/over hot surfaces.
Always turn the vacuum cleaner off before:
Emptying the dust chamber.
Cleaning or changing the filter.
Romoving from the mains outlet.
Do not leave vacuum cleaner with the plug connected to a mains outlet-unplug when not in use.
Do not use the vacuum with any of the openings blocked with any object that may restrict the airflow.
Do not put any part of the body, colthes or any object (e.g. stick) or into the opening or moving parts of the clsaner.
Do not use outdoors.
Do not vacuum hot ash, embers etc. or sharp objects.
Do not vacuum flammable or explosive substances(liquids or gases).
Do not vacuum water or other liquids.
Do not handle the cleaner or plug with wet hands.
Do not immerse the whole cleaner in water.
Do not use vacuum cleaner without repaired if it was under water.
When you vacuum with an attachment appliance that has a rotating brush roller:
Do not reach into the running brush roller.
Thermal protector: This vacuum cleaner has a special thermostat that protects the cleaner in case of motor overheating. If the cleaner suddenly shuts off, turn off the switch and unplug the cleaner. Check the cleaner for a possible source of overheating such as a full dust chamber, a blocked hose or clogged filter. If these conditions are found, fix them and wait at least 30 minutes before attempting to use the cleaner. After the 30 minutes period, plug the cleaner back in and turn on the switch. If the cleaner still does not run, contact a qualified electrician.
3
3828Fi2846x
How to Use Assembling the Cleaner
Fit the large cleaning head onto the end of the tube.
Elbow tube
Spring latch
2
(depending on model)
1
|
NZ-50 |
Large cleaning head |
Telescopic tube |
Push the head onto the telescopic tube.
•Press the spring latch to release.
•Pull out the tube to the desired length.
•Release spring latch to lock the tube in position.
•Push telescopic tube into hose handle firmly.
4
3828Fi2846x
Button
Flexible Hose
Attachment Point
Head
3
Connecting the hole to the cleaner
Push the end of the head on the flexible hose into the attachment point on the vacuum cleaner. To remove the flexible hose from the vacuum cleaner, press on the button situated on the head, then pull the head out of the vacuum cleaner.
5
3828Fi2846x
How to Use Using the Cleaning head and Accessory Nozzles
1 |
2 |
Upholstery Nozzle |
Dusting Brush & Crevice Tool |
Upholstery Nozzle is for |
Dusting Brush is for vacuuming picture |
vacuuming upholstery, |
frames, furniture frames, books and other |
mattresses, etc. |
irregular surfaces. |
The thread collectors |
Crevice Tool is for vacuuming in those |
help to pick up |
normally hard-to-reach places such as |
the threads and fluff. |
reaching cobwebs, or between the cushions |
|
of a sofa. |
6
3828Fi2846x
1
4
Pedal
2 |
4 |
5 |
(depending on model)
• Cleaning carpet and floor nozzle
The 2 position head
•The 2 position cleaning head equipped with a pedal which allows you to alter its position according to the type of floor to be cleaned.
•Hard floor position (tiles, parquets floor)
Press the pedal to lower brush.
•Carpet or rug position
Press the pedal to lift the brush up.
•Open the cover by pulling the hook.
•Divide the nozzle into two parts
•Clean the hole of the nozzle.
7
3828Fi2846x )
How to Use Using the Elbow tube
5
Spring
latch
Spring latch
Elbow tube(depending on model)
Elbow tube is for cleaning under the sofa, table and bed easily.
• Connect the elbow tube to the flexible hose and, connect the telescopic tube to the elbow tube. (You can also connect the telescopic tube to the flexible hose without the elbow tube.)
• If you pull the spring latch, the elbow tube is bended.
• If you stretch the elbow tube, it is returned to its position.
8
3828Fi2846x
Emptying the Dust Chamber
Dust chamber cap
Button
Button
Bottom plate
Dust chamber
The dust chamber needs emptying when dust reaches the MAX indicator on the dust chamber.
•Turn off the vacuum cleaner and unplug it.
•Press the button of the cover and pull the dust chamber out.
Remove the dust chamber cap and empty the dust chamber. Push the button, then dust will fell down as the button plate is open.
•To reinstall the dust chamber, replace the dust chamber cap and push the dust chamber into the tank mount as far as it will go.
CAUTION
•The dust chamber needs to be emptied when it is filled to the maximum level as indicated.
•It is recommended that the filter be cleaned once every 5 times the chamber is emptied.
9
3828Fi2846x
How to Use Operation
1 |
Cord reel button |
2 |
Suction control switch |
3 |
4 |
|
|
|
|
|
|
|
|
MAX |
FL |
|
|
|
|
CA |
|
|
|
|
|
|
|
|
|
|
|
|
S |
|
|
|
|
|
CU |
|
|
|
|
MIN |
|
|
|
How to Plug in and Use
•Pull out the power cable to the desired length and put plug into the soctet.
•Press the cable reel button to retract the power cord after use.
Adjusting the Suction |
Park System |
Storage |
power |
|
|
•Adjust the power by using the power control switch on the handle.
•When
this lamp is on which means the dust chamber is full, pls empty the dust chamber.
•Once you plug in an outlet,
this lamp will be on and
it generates fresh ion('-' ion) automatically.
• To store after vacuuming |
• When you have |
and pause while |
switched off and |
vacuuming. |
unplugged. |
• For deposit after |
• The appliance, press |
vacuuming, for example |
on the button to |
to move a small piece of |
automatically rewind |
furniture or a rug, use |
the cord. |
the Park system to |
• You can store your |
support the flexible hose |
appliance in a vertical |
and cleaning head. |
position by sliding the |
- Slide the hook on the |
hook on the large |
large cleaning head |
cleaning head into the |
into the slot on the rear |
clip on the underside |
of the vacuum cleaner. |
of the appliance. |
10
