ENGLISH Easy Setup Guide
Please read this manual carefully before operating your set and retain it for future reference.
ESPAÑOL Guía Rápida de Configuración
Lea atentamente este manual antes de poner en marcha el equipo y consérvelo para futuras consultas.
FRANÇAIS Guide de configuration rapide
Avant d’utiliser l’appareil, veuillez lire attentivement ce manuel et le conserver pour pouvoir vous y reporter ultérieurement.
LED TV
43UT672M0UC
49UT672M0UB
55UT672M0UC
www.lg.com
Printed in Korea
ENGLISH Read Safety and Reference. ESPAÑOL Leer Seguridad y Consultas. FRANÇAIS Lisez Sécurité et références.
GAME CONTROL
/ M.P.I.
Kg
43UT672M0UC |
973 |
973 |
572 |
572 |
85.0 |
85,0 |
8.0 |
8,0 |
120 W |
|
(38.3) |
(38,3) |
(22.5) |
(22,5) |
(3.3) |
(3,3) |
(17.6) |
(17,6) |
|||
|
|
|||||||||
49UT672M0UB |
1,110 |
1 110 |
650 |
650 |
81.1 |
81,1 |
11.1 |
11,1 |
125 W |
|
(43.7) |
(43,7) |
(25.5) |
(25,5) |
(3.1) |
(3,1) |
(24.4) |
(24,4) |
|||
|
|
|||||||||
55UT672M0UC |
1,244 |
1 244 |
726 |
726 |
87.1 |
87,1 |
14.3 |
14,3 |
165 W |
|
(48.9) |
(48,9) |
(28.5) |
(28,5) |
(3.4) |
(3,4) |
(31.5) |
(31,5) |
|||
|
|
|||||||||
|
|
|
|
|
|
|
|
AC 120 V ~ 50 / 60 Hz |
||
*MFL71382569*
(1908-REV00)
OWNER’S MANUAL
Safety and Reference
LED TV*
* LG LED TV applies LCD screen with LED backlights.
Please read this manual carefully before operating your set and retain it for future reference.
43UT672M0UC
49UT672M0UB
55UT672M0UC
*MFL71402072* |
www.lg.com |
Copyright © 2019 LG Electronics Inc. All Rights Reserved. |
(1908-REV00) |
Printed in Korea |
ENGLISH
Important Safety Instruction
•• Read these instructions.
•• Keep these instructions.
•• Heed all warnings.
•• Follow all instructions.
•• Do not use this apparatus near water.
•• Clean only with dry cloth.
•• Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
•• Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
•• Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
•• Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.
•• Only use attachments/accessories specified by the manufacturer.
•• Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
•• Unplug this apparatus during lightning storms or when unused for long periods of time.
•• Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
2
Warning! Safety instructions
CAUTION
RISKOFELECTRICSHOCK
DONOTOPEN
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL.
The symbol is intended to alert the user to the presence of uninsulated dangerous
voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
The symbol is intended to alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature accompanying the device.
WARNING : TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
•• TO PREVENT THE SPREAD OF FIRE, KEEP CANDLES OR OTHER ITEMS WITH OPEN FLAMES AWAY FROM THIS PRODUCT AT ALL TIMES.
•• Do not place the TV and/or remote control in the following environments:
-- Keep the product away from direct sunlight.
-- An area with high humidity such as a bathroom -- Near any heat source such as stoves and other
devices that produce heat.
-- Near kitchen counters or humidifiers where they can easily be exposed to steam or oil.
-- An area exposed to rain or wind.
-- Do not expose to dripping or splashing and do not place objects filled with liquids, such as
vases, cups, etc. on or over the apparatus (e.g., on shelves above the unit).
-- Near flammable objects such as gasoline or candles, or expose the TV to direct air conditioning.
-- Do not install in excessively dusty places.
Otherwise, this may result in fire, electric shock, combustion/ explosion, malfunction or product deformation.
•• Ventilation
-- Install your TV where there is proper ventilation. Do not install in a confined space such as a bookcase.
-- Do not install the product on a carpet or cushion. -- Do not block or cover the product with cloth or
other materials while unit is plugged in.
•• Take care not to touch the ventilation openings. When watching the TV for a long period, the ventilation openings may become hot.
•• Protect the power cord from physical or mechanical abuse, such as being twisted, kinked, pinched, closed in a door, or walked upon. Pay particular attention to plugs, wall outlets, and the point where the cord exits the device.
•• Do not move the TV whilst the Power cord is plugged in.
•• Do not use a damaged or loosely fitting power cord.
•• Be sure do grasp the plug when unplugging the power cord. Do not pull on the power cord to unplug the TV.
•• Do not connect too many devices to the same AC power outlet as this could result in fire or electric shock.
•• Disconnecting the Device from the Main Power
-- The power plug is the disconnecting device. In case of an emergency, the power plug must remain readily accessible.
•• Do not let your children climb or cling onto the TV. Otherwise, the TV may fall over, which may cause serious injury.
ENGLISH
3
ENGLISH
•• Outdoor Antenna Grounding (Can differ by country):
-- If an outdoor antenna is installed, follow the precautions below. An outdoor antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can come in contact with such power lines or circuits as death or serious injury can occur. Be sure the antenna system is grounded to provide some protection against voltage surges and built-up static charges Section 810 of the National Electrical Code (NEC) in the U.S.A. provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection
to grounding electrodes and requirements for the grounding electrode. Antenna grounding according to the National Electrical Code, ANSI/ NFPA 70
•• Grounding (Except for devices which are not grounded.)
-- TV with a three-prong grounded AC plug must be connected to a three-prong grounded AC outlet. Ensure that you connect the earth ground wire to prevent possible electric shock.
•• Never touch this apparatus or antenna during a lightning storm. You may be electrocuted.
•• Make sure the power cord is connected securely to the TV and wall socket if not secured damage to the Plug and socket may occur and in extreme cases a fire may break out.
•• Do not insert metallic or inflammable objects into the product. If a foreign object is dropped into the product, unplug the power cord and contact the customer service.
•• Do not touch the end of the power cord while it is plugged in. You may be electrocuted.
•• If any of the following occur, unplug the product immediately and contact your local customer service.
-- The product has been damaged.
-- If water or another substance enters the product (like an AC adapter, power cord, or TV).
-- If you smell smoke or other odors coming from the TV.
-- When lightning storms or when unused for long periods of time.
Even the TV is turned off by remote control or button, AC power source is connected to the unit if not unplugged in.
•• Do not use high voltage electrical equipment near the TV (e.g., a bug zapper). This may result in product malfunction.
•• Do not attempt to modify this product in any way without written authorization from LG Electronics. Accidental fire or electric shock can occur. Contact your local customer service for service or repair.
Unauthorized modification could void the user’s authority to operate this product.
•• Use only an authorized attachments / accessories approved by LG Electronics. Otherwise, this may result in fire, electric shock, malfunction, or product damage.
•• Never disassemble the AC adapter or power cord. This may result in fire or electric shock.
•• Handle the adapter carefully to avoid dropping or striking it. An impact could damage the adapter.
•• To reduce the risk of fire or electrical shock, do not touch the TV with wet hands. If the power cord prongs are wet or covered with dust, dry the power plug completely or wipe dust off.
•• Batteries
-- Store the accessories (battery, etc.) in a safe location out of the reach of children.
-- Do not short circuit, disassemble, or allow the batteries to overheat. Do not dispose of batteries in a fire. Batteries should not be exposed to excessive heat.
4
•• Moving
-- When moving, make sure the product is turned off, unplugged, and all cables have been removed. It may take 2 or more people to carry larger TVs. Do not press or put stress on the front panel of the TV. Otherwise, this may result in product damage, fire hazard or injury.
•• Keep the packing anti-moisture material or vinyl packing out of the reach of children.
•• Do not allow an impact shock, any objects to fall into the product, and do not drop anything onto the screen.
•• Do not press strongly upon the panel with a hand or a sharp object such as a nail, pencil, or pen,
or make a scratch on it. It may cause damage to screen.
•• Cleaning
-- When cleaning, unplug the power cord and wipe gently with a soft/dry cloth. Do not spray water or other liquids directly on the TV. Do not clean your TV with chemicals including glass cleaner, any type of air freshener, insecticide, lubricants, wax (car, industrial), abrasive, thinner, benzene, alcohol etc., which can damage the product and/or its panel. Otherwise, this may result in electric shock or product damage.
Preparing
•• When the TV is turned on for the first time after being shipped from the factory, initialization of the TV may take approximately one minute.
•• Image shown may differ from your TV.
•• Your TV’s OSD (On Screen Display) may differ slightly from that shown in this manual.
•• The available menus and options may differ from the input source or product model that you are using.
•• New features may be added to this TV in the future.
•• The device must be easily accessed to a location outlet near the access. Some devices are not made by turning on / off button, turning off the device and unplugging the power cord.
•• The items supplied with your product may vary depending upon the model.
•• Product specifications or contents of this manual may be changed without prior notice due to upgrade of product functions.
•• For an optimal connection, HDMI cables and USB devices should have bezels less than 10 mm (0.39 inches) thick and 18 mm (0.7 inches) width.
•• Use an extension cable that supports USB 2.0 if the USB cable or USB flash drive does not fit into your TV’s USB port.
•• Use a certified cable with the HDMI logo attached.
•• If you do not use a certified HDMI cable, the screen may not display or a connection error may occur. (Recommended HDMI cable types)
-- Ultra High-Speed HDMI®/™ cable (3 m (9.84 feet) or less)
B |
B |
* A |
10 mm |
|
|
|
(0.39 inches) |
||
A |
A |
* B |
18 mm |
|
(0.7 inches) |
||||
|
|
|||
•• Do not use any unapproved items to ensure the safety and lifespan of the product.
•• Any damages or injuries by using unapproved items are not covered by the warranty.
ENGLISH
5
ENGLISH
Optional Extras
Optional extras can be changed or modified for quality improvement without any notification. Contact your dealer for buying these items.
These devices work only with certain models.
The model name or design may be changed due to the manufacturer’s circumstances or policies.
(Depending upon model)
Wall Mounting Bracket
Make sure to use screws and wall mounts that meet the VESA standard. Standard dimensions for the wall mount kits are described in the following table.
Lifting and Moving the TV
When moving or lifting the TV, read the following to prevent the TV from being scratched or damaged and for safe transportation regardless of its type and size.
•• It is recommended to move the TV in the box or packing material that the TV originally came in.
•• Before moving or lifting the TV, disconnect the power cord and all cables.
•• When holding the TV, the screen should face away from you to avoid damage.
•• Hold the top and bottom of the TV frame firmly. Make sure not to hold the transparent part, speaker, or speaker grille area.
Model |
43UT672M0UC |
49UT672M0UB |
|
|
55UT672M0UC |
VESA (A x B) |
200 x 200 |
300 x 300 |
Standard screw |
M6 |
M6 |
Number of screws |
4 |
4 |
Wall mount bracket |
LSW240B |
OLW480B |
(optional) |
MSW240 |
MSW240 |
•• Use at least two people to move a large TV.
6
